Operating and installation
instructions
Wine conditioning unit
To avoid the risk of accidents or damage to the appliance it is essen-
tial to read these instructions before it is installed and used for the
first time.
en-GB M.-Nr. 09 875 610
Contents
2
Warning and Safety instructions...................................................................... 4
Caring for the environment .............................................................................. 13
Saving energy .................................................................................................... 14
Guide to the appliance...................................................................................... 15
Accessories ....................................................................................................... 17
Accessories supplied .......................................................................................... 17
Optional accessories........................................................................................... 17
Switching on and off ......................................................................................... 18
Before using for the first time.............................................................................. 18
Switching the wine unit on .................................................................................. 18
Switching the alarm off................................................................................... 18
Switching the wine unit off .................................................................................. 18
Switching off for longer periods of time .............................................................. 19
Selecting further settings ................................................................................. 20
Safety lock ...................................................................................................... 20
Activating or deactivating the lock ................................................................. 20
To change the brightness of
the temperature display....................................................................................... 21
The optimum temperature and air quality....................................................... 22
The optimum temperature................................................................................... 22
Setting the temperature.................................................................................. 23
Temperature range ......................................................................................... 24
Temperature display ....................................................................................... 24
Air quality and humidity....................................................................................... 25
DynaCool (constant humidity) ................................................................... 25
Air filtration with the Active AirClean filters .................................................... 26
Temperature and door alarm............................................................................ 27
Temperature alarm............................................................................................... 27
Door alarm........................................................................................................... 28
Feature lighting.................................................................................................. 29
Switching the feature lighting on and off............................................................. 29
Setting the brightness of the feature lighting ................................................. 29
Storing wine bottles .......................................................................................... 30
Wooden shelves.................................................................................................. 31
Moving the wooden shelves........................................................................... 31
Maximum capacity .............................................................................................. 32
Contents
3
Automatic defrosting ........................................................................................ 33
Cleaning and care ............................................................................................. 34
Cleaning agents................................................................................................... 34
Before cleaning the wine conditioning unit ......................................................... 35
Interior, accessories, and appliance door ........................................................... 35
Cleaning the ventilation gaps .............................................................................. 35
Cleaning the door seal ........................................................................................ 35
Cleaning the air filter............................................................................................ 35
After cleaning ...................................................................................................... 35
Active AirClean filters ....................................................................................... 36
Replacing the Active AirClean filter ..................................................................... 36
Problem solving guide ...................................................................................... 37
Noises................................................................................................................. 42
After sales service and warranty ..................................................................... 43
Contact in the event of a fault ............................................................................. 43
EPREL database ................................................................................................. 43
Warranty .............................................................................................................. 43
Electrical connection ........................................................................................ 44
Installation.......................................................................................................... 45
Location............................................................................................................... 45
Side-by-side........................................................................................................ 45
Climate range ...................................................................................................... 46
Ventilation............................................................................................................ 46
Before installing the wine conditioning unit......................................................... 46
Installation dimensions........................................................................................ 47
View from above............................................................................................. 48
Changing the door hinging ............................................................................... 49
Installing the wine conditioning unit................................................................ 52
Setting up the wine conditioning unit.................................................................. 52
Aligning the wine conditioning unit to taller furniture doors ........................... 54
Push the wine conditioning unit into the niche.................................................... 55
Securing the wine conditioning unit in the niche ................................................ 56
Adjusting the lateral alignment of the appliance door.................................... 57
Warning and Safety instructions
4
This wine conditioning unit complies with all current local and na-
tional safety requirements. Inappropriate use can, however, lead to
personal injury and material damage.
Read the operating and installation instructions carefully before
using the wine conditioning unit. They contain important informa-
tion on safety, installation, use and maintenance. This is to protect
yourself from injury, and from damaging your wine conditioning
unit.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the wine conditioning unit as well as the
safety instructions and warnings.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owner.
Danger of injury from broken glass.
If installed at altitudes above 1500m there is a risk of the glass in
the door breaking because of changes in air pressure.
Shards of glass can cause severe injury.
Correct application
This wine conditioning unit is intended for use in the home and in
similar environments, for example
– in shops, offices and similar work settings
– by the guests in hotels, motels, bed & breakfasts and other typical
home settings.
This wine conditioning unit is not intended for outdoor use.
Warning and Safety instructions
5
The wine conditioning unit is intended for domestic use only for
storing wine.
It must not be used for any other purpose.
The wine conditioning unit is not suitable for storing and keeping
cool medicines, blood plasma, laboratory preparations or other such
materials or products. Incorrect use of the wine conditioning unit for
such purposes can cause deterioration of the items stored. The wine
conditioning unit is not suitable for use in areas where there is a risk
of explosion.
Miele cannot be held liable for damage resulting from improper or in-
correct use of the appliance.
This wine conditioning unit may only be used by people (including
children) with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they are supervised whilst using
it.
The wine conditioning unit may only be used by these people
without supervision if they have been shown how to use it in a safe
way and recognise and understand the consequences of incorrect
operation.
Warning and Safety instructions
6
Safety with children
Children under 8years of age must be kept away from the wine
conditioning unit unless they are constantly supervised.
Children aged 8 and older may only use the wine conditioning unit
without supervision if they have been shown how to use it in a safe
manner. Children must be able to understand and recognise the pos-
sible dangers caused by incorrect operation.
Children must not be allowed to clean or maintain the wine condi-
tioning unit unsupervised.
Please supervise children in the vicinity of the wine conditioning
unit and do not let them play with it.
Danger of suffocation! Whilst playing, children could become en-
tangled in packaging (such as plastic wrapping) or pull it over their
head and suffocate. Keep packaging material away from children.
Warning and Safety instructions
7
Technical safety
The refrigerant circuit has been checked for leaks. The wine con-
ditioning unit complies with statutory safety requirements and the
appropriate EU directives.
This wine conditioning unit contains the coolant Isobutane
(R600a), a natural gas which is environmentally friendly. The coolant
does not damage the ozone layer and does not contribute to the
greenhouse effect.
The use of this coolant has, however, led to a slight increase in the
noise level of the appliance. In addition to the noise of the com-
pressor, you might be able to hear the coolant flowing around the
cooling circuit. Unfortunately, this cannot be avoided, but it does not
affect the performance of the wine conditioning unit.
When transporting and installing the wine conditioning unit, ensure
that no parts of the cooling circuit are damaged. Splashes of coolant
can damage the eyes.
In the event of damage:
- Avoid naked flames or anything which creates a spark.
- Disconnect the wine conditioning unit from the mains electricity
supply.
- Ventilate the room where the wine conditioning unit is located for
several minutes.
- Contact the Miele Customer Service Department.
The more coolant there is in a wine conditioning unit, the larger
the room it should be installed in. In the event of a leakage, if the ap-
pliance is in a small room, there is the danger of combustible gases
building up. For every 11 g of coolant at least 1m
3
of room space is
required. The amount of coolant in the appliance is stated on the
data plate inside the wine conditioning unit.
Warning and Safety instructions
8
To avoid the risk of damage to the wine conditioning unit, make
sure that the connection data (fuse rating, frequency and voltage) on
the data plate corresponds to the household supply.
Check that this is the case before connecting the wine conditioning
unit. Consult a qualified electrician if in any doubt.
The electrical safety of the wine conditioning unit can only be
guaranteed when correctly earthed. It is essential that this standard
safety requirement is met. If in any doubt please have the electrical
installation tested by a qualified electrician.
Reliable and safe operation of the wine conditioning unit can only
be assured if it has been connected to the mains electricity supply.
If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
Do not connect the wine conditioning unit to the mains electrical
supply by a multi-socket adapter or extension lead. These are a fire
hazard and do not guarantee the required safety of the appliance.
If moisture gets into electrical components, it could cause a short
circuit. Therefore, do not operate this wine conditioning unit in areas
which are exposed to moisture (e.g in a garage or utility room).
Warning and Safety instructions
9
This wine conditioning unit must not be used in a non-stationary
location (e.g. on a ship).
Do not use a damaged wine conditioning unit. It could be danger-
ous. Check the wine conditioning unit for visible signs of damage.
For safety reasons, this wine conditioning unit may only be used
after it has been built in.
The wine conditioning unit must be isolated from the electricity
supply during installation, maintenance and repair work.
Unauthorised installation, maintenance and repairs can cause
considerable danger for the user.
Installation, maintenance and repairs must only be carried out by a
Miele authorised technician.
While the wine conditioning unit is under warranty, repairs should
only be undertaken by a Miele authorised service technician. Other-
wise the warranty is invalidated.
Faulty components must only be replaced with genuine Miele ori-
ginal spare parts. Miele can only guarantee the safety standards of
the appliance when Miele replacement parts are used.
This wine conditioning unit is supplied with a special lamp to cope
with particular conditions (e.g. temperature, moisture, chemical res-
istance, abrasion resistance and vibration). This lamp must only be
used for the purpose for which it is intended. The lamp is not suit-
able for room lighting. Replacement lamps may only be fitted by a
Miele authorised technician or by the Miele Customer Service De-
partment. This wine conditioning unit contains several light sources
with at least energy efficiency classE.
Warning and Safety instructions
10
Correct use
The wine conditioning unit is designed for use within a certain cli-
mate range (ambient temperatures), and should not be used outside
this range. The climate range for your wine conditioning unit is stated
on the data plate inside the appliance. Installing it in a room with too
low an ambient temperature, e.g. a garage, will lead to the wine con-
ditioning unit switching off for longer periods so that it cannot main-
tain the required temperature.
Do not cover or block the air vents as this could impair the effi-
ciency of the appliance, increase the electricity consumption and
could cause damage to the components.
If the wine conditioning unit is used for storing food which con-
tains fat or oil, make sure that it does not come into contact with
plastic components. Any spillages of oil or fat could cause stress
cracks to the plastic and cause it to break or split.
Risk of fire and explosion. Do not store explosive materials in the
wine conditioning unit or any products containing propellants (e.g.
spray cans). Electrical components can cause flammable mixes of
gases to ignite.
Danger of explosion. Do not operate any electrical appliances in-
side the wine conditioning unit. Danger of sparking and explosion.
Accessories and spare parts
Only use genuine original Miele accessories and spare parts with
this appliance. Using accessories or spare parts from other manu-
facturers will invalidate the warranty, and Miele cannot accept liabil-
ity.
Miele will guarantee to supply functional spare parts for a min-
imum of 10years and up to 15years following the discontinuation of
your wine unit.
Warning and Safety instructions
11
Cleaning and care
Do not use any oils or grease on the door seals, as these will
cause the seals to deteriorate and become porous with time.
Do not use a steam cleaning appliance to clean this wine condi-
tioning unit.
The steam could reach electrical components and cause a short cir-
cuit.
Sharp edged or pointed objects will damage the evaporator, caus-
ing irreversible damage to the wine conditioning unit. Do not use
sharp edged or pointed objects to
- remove frost and ice,
- remove labels, stickers etc.
Warning and Safety instructions
12
Transporting the appliance
Always transport the wine conditioning unit in an upright position
and in its original transport packaging to avoid damage in transit.
Danger of injury and damage to the appliance. The wine condi-
tioning unit is very heavy and must be transported by two people.
Disposing of your old appliance
If your old wine unit or refrigeration appliance has a door lock,
destroy it.
This will prevent the risk of children playing accidentally locking
themselves in and endangering their lives.
Splashes of coolant can damage the eyes. Be careful not to dam-
age any part of the pipework whilst awaiting disposal, e.g. by
- puncturing the coolant channels in the condenser,
- bending any pipework, or
- scratching the surface coating.
Caring for the environment
13
Disposal of the packing mater-
ial
The packaging is designed to protect
the wine conditioning unit from damage
during transportation. The packaging
materials used are selected from mater-
ials which are environmentally friendly
for disposal and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur-
ing process and also reduces the
amount of waste in landfill sites.
Disposing of your old appli-
ance
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials, com-
pounds and components which were
essential for their correct functioning
and safety. These could be hazardous
to your health and to the environment if
disposed of with general waste or if
handled incorrectly. Please do not,
therefore, dispose of your old appliance
with general waste.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle elec-
trical and electronic appliances in your
local community, with your dealer or
with Miele. By law, you are solely re-
sponsible for deleting any personal data
from the appliance prior to disposal.
Take care not to damage your wine
conditioning unit's pipework before or
during transportation to an authorised
collection depot.
This is to ensure that coolant in the
cooling circuit and oil in the compressor
is contained, and will not leak into the
environment.
Please ensure that your old appliance
poses no risk to children while being
stored prior to disposal. For further in-
formation, see “Warning and safety in-
structions” in these operating and in-
stallation instructions.
Saving energy
14
Normal energy consump-
tion
Increased energy con-
sumption
Installation /
Maintenance
In a ventilated room. In an enclosed, unventilated
room.
Protected from direct sun-
light.
In direct sunlight.
Not near to a heat source
(radiator, oven).
Near to a heat source (radi-
ator, oven).
Where the ideal ambient
room temperature is approx.
20°C.
Where the ambient room
temperature is above 25°C.
Ventilation gaps uncovered
and dusted regularly.
Ventilation gaps covered or
dusty.
Remove and clean the air fil-
ter with a vacuum cleaner at
least once a year.
If dust has accumulated on
the air filter.
Temperature
setting
10 to 12°C The lower the temperature,
the higher the energy con-
sumption.
Use Wooden shelves arranged
as they were when the appli-
ance was delivered.
Only open the door when
necessary and for as short a
time as possible. Store wine
bottles in an organised way.
Frequent opening of the
door for long periods will
cause a loss of coldness.
The wine conditioning unit
works harder to cool down
and the compressor runs for
longer periods.
Do not over-fill the appliance
to allow air to circulate.
Poor air circulation will
cause a loss of coldness.
Guide to the appliance
15
a
For switching the entire
wine unit on and off
b
For setting the temperature in the
upper wine conditioning zone
( for warmer)
c
Temperature display for the
upper wine conditioning zone
d
For setting the temperature in the
upper wine conditioning zone
( for colder)
e
For switching the DynaCool function
(constant humidity) on and off, with
indicator light
f
Safety lock indicator light (only visible
when the safety lock is switched on)
g
For switching the temperature or
door alarm off
h
For setting the temperature in the
lower wine conditioning zone
( for warmer)
i
Temperature display for the
lower wine conditioning zone
j
For setting the temperature in the
lower wine conditioning zone
( for colder)
k
For switching the feature lighting on
and off, with indicator light
Guide to the appliance
16
a
Lighting strip
(in both wine conditioning zones)
b
Active AirClean filter
c
Control panel for the upper and
lower wine conditioning zones /
isolation plate for thermal separation
of the zones
d
Isolation strips for thermal
separation of the temperature zones
e
Wooden racks
f
Safety glass door
with UV filter
g
Ventilation grille
with air filter located behind it
Accessories
17
Accessories supplied
Active AirClean filter
The Active AirClean filter ensures op-
timum air quality in the wine condition-
ing unit by filtering the incoming air.
Air filter
The air filter behind the ventilation grille
protects the cooling system from dust.
Optional accessories
A range of useful Miele accessories and
care products are available for your
wine conditioning unit.
Multi-purpose microfibre cloth
The microfibre cloth is suitable for re-
moving fingerprints and light soiling
from surfaces such as stainless steel,
glass, plastic and chrome without the
use of chemicals.
MicroCloth Kit
The MicroCloth Kit contains a universal
cloth, a glass cloth and a polishing
cloth.
These cloths are extremely resistant to
tearing and very robust. Thanks to very
fine microfibres these cloths achieve an
excellent cleaning performance.
Active AirClean filters
See “Accessories supplied”.
Accessories are available to order via
the Miele Webshop, from Miele dir-
ectly (see back cover for contact de-
tails) or from your Miele dealer.
Switching on and off
18
Before using for the first time
Packaging material
Remove all packaging material from
the inside of the appliance.
Cleaning the wine unit
Please refer to the relevant instruc-
tions in “Cleaning and care”.
Clean the inside of the appliance and
the accessories.
Switching the wine unit on
Touch the On/Off sensor for the
whole appliance so that the temper-
ature displays light up.
An alarm will sound. The wine unit will
start to cool and the interior lighting will
come on when the appliance door is
opened.
Switching the alarm off
Touch the sensor for switching off the
temperature or door alarm.
The alarm will stop. The temperature
displays will flash until the set temperat-
ures are reached.
Switching the wine unit off
Touch and keep your finger on the
On/Off sensor for the whole wine unit
until the temperature displays go
dark.
The cooling system will be switched off.
If this is does not happen, the safety
lock is still activated (see “Selecting fur-
ther settings - Safety lock”).
Switching on and off
19
Switching off for longer peri-
ods of time
If the wine unit is not going to be used
for a longer period of time:
Switch the wine unit off.
Switch off at the wall and withdraw
the plug from the socket, or discon-
nect the fuse.
Clean the wine unit.
Leave the door ajar to air the wine
unit and avoid odours building up in-
side it.
If the wine unit is switched off, but
not cleaned, during a long absence
and the door is left shut, there is a
risk of mould building up inside the
appliance.
The wine unit must be cleaned.
Selecting further settings
20
Safety lock
The safety lock can be activated to pre-
vent the wine unit being switched off by
mistake.
Activating or deactivating the lock
Touch and keep your finger on the
DynaCool On/Off sensor for approx. 5
seconds.
The sensor's indicator light flashes and
a c flashes in the temperature display
for the lower wine conditioning zone
(display on the right).
Touch the DynaCool On/Off sensor
again.
By pressing the sensors for setting
the temperature, you can now choose
between and :
: Lock function is deactivated,
: Lock function is activated.
To save the setting, touch the
DynaCool On/Off sensor.
When the lock function is activated, its
indicator lights up.
To exit settings mode, touch the On/
Off sensor for the whole wine unit.
Otherwise the appliance will switch to
normal operation after approximately
two minutes.
Selecting further settings
21
To change the brightness of
the temperature display
The default brightness for the wine unit
temperature display is set to .
To change the brightness of the tem-
perature display (the temperature dis-
plays will change together):
Touch and keep your finger on the
DynaCool On/Off sensor for approx. 5
seconds.
The sensor's indicator light flashes and
a flashes in the temperature display
for the lower wine conditioning zone
(display on the right).
Press one of the temperature setting
sensors as often as necessary until
is displayed.
Touch the DynaCool On/Off sensor
again. will light up in the display.
By pressing the sensors for setting
the temperature, you can now set the
display brightness. You can choose
between levels to :
: Minimum brightness,
: Maximum brightness.
To save the setting, touch the
DynaCool On/Off sensor.
To exit settings mode, touch the On/
Off sensor for the whole wine unit.
Otherwise the appliance will automat-
ically switch to normal operation after
approximately two minutes.
The optimum temperature and air quality
22
Wine keeps on maturing depending on
the surrounding conditions. The length
of time for which wine can be kept in
good condition will therefore depend
not only on the temperature but also on
the air quality.
The wine conditioning unit with its con-
stant ideal temperature, increased air
humidity and odour free atmosphere of-
fers the perfect conditions for storing
your wine.
It also guarantees a vibration-free envir-
onment (in contrast to a refrigerator) so
that the maturing process is not dis-
turbed.
The optimum temperature
Wine can be stored at a temperature
between 6 and 18°C. If you are storing
white and red wines together, select a
temperature between 12 and 14°C.
This is suitable for both white and red
wines. Red wine should be taken out of
the wine conditioning unit and opened
at least two hours before drinking to al-
low it to breathe and develop its aroma.
At too high a temperature (over 22°C)
wine matures too quickly, which pre-
vents the aromas from developing fur-
ther. Wine cannot mature fully at too
low a temperature (below 5°C).
Fluctuations in temperature put wine
under stress and interrupt the maturing
process. It is therefore very important to
maintain a constant temperature.
Type of wine Recommended
drinking
temperature*
Light, fruity reds: +14°C to +16°C
Full-bodied reds: +18°C
Rosé wines: +8°C to +10°C
Delicate, aromatic
whites:
+8°C to +12°C
Full-bodied or
sweet whites:
+12°C to +14°C
Champagne,
sparkling white
wines, Prosecco:
+6°C to +10°C
* Store the wine 1 or 2°C cooler than
the recommended drinking temperature
as it warms up a little when poured into
the glass.
Tip: Full-bodied reds should be opened
for 2-3 hours before drinking to allow
the wine to breathe and develop its
aroma.
The optimum temperature and air quality
23
Safety device in case of low ambient
temperatures
The appliance is equipped with a safety
thermostat to protect your wine against
a sharp drop in temperature. If the ex-
ternal temperature should fall, a heater
element switches on automatically to
keep the temperature inside as constant
as possible. If the ambient temperature
continues to fall, the appliance switches
itself off automatically.
Isolator plate for thermal separation
The unit comes with a fixed isolation
panel that partitions the interior of the
wine conditioning unit into two separate
temperature zones. This enables you to
store different types of wine at the same
time, e.g., red wine and Champagne.
The isolation strips inside the glass
door prevent the exchange of heat
between the individual zones.
Setting the temperature
You can set the respective temperat-
ures using the two sensors below the
temperature displays.
To do so press the sensors under the
relevant temperature display.
Touch
- the temperature will get colder,
- the temperature will get warmer.
The temperature range being set will
flash in the display as you do this.
When you touch the sensors, you will
see the following changes in the re-
spective temperature display:
- Touching a sensor once: the last tem-
perature selected flashes.
- Each subsequent touch of a sensor:
The temperature is adjusted in 1°C
steps.
- Keeping your finger on the sensor:
changes the temperature continu-
ously.
Approximately 5 seconds after you re-
lease the sensor, the actual temperature
in the respective zone will be displayed
automatically.
The optimum temperature and air quality
24
The two temperature zones are cooled
alternately which means that, depend-
ing on the amount of wine being
stored, it may take a few hours before
the set temperatures are reached and
the temperature displays have adjus-
ted accordingly. If, after this time, the
temperature is still too high or too low,
you will need to adjust it again.
Temperature range
In both zones it is possible to set tem-
peratures between 5 and 20°C.
Temperature display
In normal operation the temperature
displays in the control panel show the
actual temperatures in the wine unit.
The temperature display will flash if
- a different temperature is being set,
- the temperature in one zone deviates
from the set temperature by more
than 5°C.
The optimum temperature and air quality
25
Air quality and humidity
In most refrigerators the humidity is too
low for wine and therefore a refrigerator
is not suitable for wine storage. High
humidity levels are necessary when
storing wine to moisten corks from the
outside. When the humidity is too low
the corks dry out and the bottle is no
longer tightly sealed. For this reason
wine bottles should always be stored
horizontally to ensure that corks are
also kept moist from the inside. If air
gets into the bottle, this will have a neg-
ative impact on the wine!
Danger of damage from excess
amounts of moisture
An increase in humidity will lead to
condensation on the interior walls.
Condensate can cause damage such
as corrosion to the wine unit.
Do not introduce additional moisture
to air in the cabinet, e.g. by placing a
dish of water in the wine unit.
DynaCool (constant humidity)
DynaCool raises the relative humidity
inside the whole of wine conditioning
unit. It also distributes the humidity and
the temperature evenly around the in-
terior so that you can store all your wine
under the same excellent conditions.
This will create a stable climate in the
unit which imitates that of a wine cellar.
Switching on DynaCool
If you would like to use the wine unit to
store wine long term, we recommend
that you keep the DynaCool function
switched on.
Touch the DynaCool function On/Off
sensor so that the indicator light
comes on.
Even if DynaCool has not been turned
on, the fans in the wine unit will come
on automatically when the cooling
system turns on. This ensures the op-
timum climate for your wine is main-
tained.
When the appliance door is open, the
fan automatically turns off temporarily
to save energy.
The optimum temperature and air quality
26
Switching off DynaCool
The wine unit uses slightly more energy
and is a little noisier when the DynaCool
function is switched on. You can switch
it off now and then if you wish.
Touch the DynaCool function On/Off
sensor to switch off the indicator
light.
Air filtration with the Active AirClean
filters
The Active AirClean filter achieves op-
timum air quality by filtering the incom-
ing air.
Fresh air from the room enters the ap-
pliance via the Active AirClean filter.
The fans (DynaCool) then distribute the
air evenly throughout the cabinet.
Filtering the incoming air through the
Active AirClean filter ensures that all the
air entering the appliance is fresh and
free from dust and odours.
This also ensures your wine does not
absorb any unwanted odours through
the corks.
The Active AirClean filter should be
replaced at least every 12 months.
Active AirClean filters can be ob-
tained from your Miele dealer, Miele
or from the Miele website.
Temperature and door alarm
27
This wine conditioning unit is equipped
with an alarm system so that the tem-
perature cannot rise or fall unnoticed,
thus possibly damaging the wine.
Temperature alarm
An alarm will sound if the temperature
in one of the wine conditioning zones
becomes too warm or too cold.
The relevant temperature display will
flash at the same time.
The temperature the wine unit is set at
determines the temperature the appli-
ance recognises as being too warm or
too cold.
Audible and visual signals will be activ-
ated, for example,
- when the wine unit is switched on
and the temperature in one of the
temperature zones differs greatly
from the set temperature,
- too much warm ambient air entering
the cabinet when bottles are being
rearranged or taken out,
- when a large number of bottles are
stored for the first time,
- in the event of a power cut.
The alarm will stop and the temperature
displays will light up constantly when
temperature reaches the correct level
again.
Switching the temperature alarm off
early
If the noise disturbs you, you can
switch the alarm off if you wish.
Touch the sensor for switching off the
temperature alarm.
The alarm will stop.
The relevant temperature display will
continue to flash until the temperature is
at the correct level.
Temperature and door alarm
28
Door alarm
An alarm will sound if the appliance
door has been left open for longer than
60seconds.
It will stop as soon as the door is
closed.
Switching the door alarm off early
If the noise disturbs you, you can
switch the alarm off if you wish.
Touch the sensor for switching off the
door alarm.
The alarm will stop.
Feature lighting
29
The interior lighting can be set to re-
main on when the door is closed so
your wines can be on display at all
times.
Each wine conditioning zone has its
own lighting strip so that all zones are
illuminated.
Thanks to the use of LED lighting, the
wine will not be adversely affected by
heat or UV light.
Switching the feature lighting
on and off
Touch the feature lighting On/Off
sensor so that the indicator light
comes on.
The interior lighting is now switched on
in both wine conditioning zones, even
when the door is closed.
To switch the feature lighting off
again:
Touch the feature lighting On/Off
sensor so that the indicator light goes
out.
The interior lighting is now switched off
when the appliance door is closed.
Setting the brightness of the feature
lighting
The brightness of the feature lighting
can be adjusted.
Touch and keep you finger on the
feature lighting On/Off sensor.
At the same time, touch the sensors
for setting the temperature.
Touch
- the lighting becomes dimmer
- the lighting becomes brighter.
Danger of injury from LED light-
ing.
This lighting corresponds to risk
group RG2. If the cover is defective,
there is a danger of eye injury.
If the lighting cover is defective, do
not look from a close range directly
into the lighting with optical instru-
ments (e.g. magnifying glass or sim-
ilar).
Storing wine bottles
30
Vibration and movement have a negat-
ive effect on the maturing process,
which can in turn affect the taste of the
wine.
To avoid disturbing other bottles when
removing a bottle of wine, store bottles
of the same type beside each other on
the same shelf. Avoid stacking bottles
on top of one another on the wooden
shelves.
Always place the bottles in a horizontal
position so that the natural corks can
be kept moist on the inside and air is
prevented from getting into the bottles.
Tip: We also recommend increasing the
humidity level inside the wine condition-
ing unit for wine bottles with natural
corks (see “The optimum temperature
and air quality – Using DynaCool (con-
stant humidity)”).
Risk of injury from falling wine
bottles.
Wine bottles may become wedged in
the wooden shelves above and fall
out of the wine conditioning unit
when the shelves are pulled out.
Always pull out the wooden shelves
slowly and carefully.
Risk of damage and injury from
broken glass.
If wooden shelves and bottles pro-
trude too far forwards, they may
damage the glass door when it is
closed.
Please ensure that the wooden
shelves and wine bottles do not pro-
trude.
Do not cover the vents in the rear
wall, as they are essential for keeping
the appliance cool.
Storing wine bottles
31
Wooden shelves
The wooden shelves are on telescopic
runners which can be pulled out to
make it easier to store and remove
bottles.
Moving the wooden shelves
The wooden shelves can be removed
and replaced again if required.
Pull the wooden shelf out until it
stops .
Release the wooden shelf at the
back, lifting the shelf on the left and
right at the same time .
Lift the wooden shelf forwards to re-
move it.
To replace the shelf, place it on the
extended rails. The notches in the
wooden shelf fit onto the retaining
bolts on the runners.
Slide the wooden shelf back into the
appliance as far as it will go .
Push the wooden shelf right back so
that it clicks into place at the front.
Press down on the back of the
wooden shelf until it clicks into place
at the back .
Storing wine bottles
32
Maximum capacity
Up to 34 Bordeaux bottles (0.75l) can
be stored in the wine conditioning unit,
with 14 in the upper zone and 20 in the
lower zone.
The total of 34 bottles can only be
achieved by using all the wooden
shelves.
Please note that each wooden shelf
has a maximum load-bearing capa-
city of 25kg. Please avoid stacking
bottles on the wooden shelves.
Automatic defrosting
33
The wine conditioning unit defrosts
automatically.
Cleaning and care
34
Do not let water get into the elec-
tronic module, the ventilation grille or
the lighting.
Risk of damage due to moisture
ingress.
The steam from a steam cleaner can
damage plastic and electrical com-
ponents.
Do not use a steam cleaner to clean
the wine conditioning unit.
The data plate located inside the wine
conditioning unit must not be re-
moved. It contains information which
is required in the event of a service
call.
Cleaning agents
To avoid damaging the surfaces of your
appliance, do not use
- Cleaning agents containing soda,
ammonia, acids or chlorides
- Cleaning agents containing descaling
agents
- Abrasive cleaning agents (e.g. scour-
ing powder, scouring liquid or pumice
stones)
- Cleaning agents containing solvents
- Stainless steel cleaning agents
- Dishwasher cleaner
- Oven sprays
- Glass cleaner (except on the glass in
the appliance door)
- Hard, abrasive sponges and brushes
(e.g. pot scourers)
- Eraser stain remover blocks
- Sharp metal scrapers
Cleaning and conditioning agents
used inside the wine conditioning
unit must be food safe.
We recommend using lukewarm water
with a little washing-up liquid for clean-
ing.
Cleaning and care
35
Before cleaning the wine con-
ditioning unit
Switch the wine conditioning unit off.
Take any wine bottles out of the wine
conditioning unit and store them in a
cool place.
Take out all other removable parts for
cleaning.
Interior, accessories, and ap-
pliance door
Clean the wine unit at least once a
month.
Remove soiling immediately to pre-
vent it from drying on.
Clean the interior with a solution of
lukewarm water and a little washing-
up liquid.
The wooden shelves should only be
wiped with a well wrung-out damp
cloth. They must not be allowed to
get wet.
After cleaning, wipe the interior and
accessories with a damp cloth and
dry with a soft cloth. Leave the door
open to air the wine unit for a short
while.
Clean the appliance door with a pro-
prietary glass cleaner.
Cleaning the ventilation gaps
A build-up of dust will increase the en-
ergy consumption of the appliance.
The ventilation gaps should be
cleaned on a regular basis with a
brush or vacuum cleaner (you could
use a Miele vacuum cleaner dusting
brush, for example).
Cleaning the door seal
Risk of damage as a result of in-
correct cleaning.
If you treat the door seal with oils or
grease, it can become porous.
Do not use any oils or grease on the
door seal.
The door seal should be cleaned reg-
ularly with clean water, and then
wiped dry with a soft cloth.
Cleaning the air filter
Clean the air filter behind the ventila-
tion grille at least once a year.
Remove the air filter and vacuum it
thoroughly on both sides. A dirty filter
can prevent the wine conditioning
unit from cooling sufficiently.
After cleaning
Replace all shelves and accessories
in the wine conditioning unit.
Reconnect to the mains and switch
the wine conditioning unit back on.
Place the wine bottles back in the
wine conditioning unit and close the
appliance door.
Active AirClean filters
36
Fresh air from the room enters the wine
conditioning unit through the Active
AirClean filter. Filtering the incoming air
through the Active AirClean filter en-
sures that all the air entering the appli-
ance is fresh and free from dust and
odours.
Replacing the Active AirClean
filter
Push the filter in and then release it.
Pull the filter out.
Detach the back part of the filter from
the cover.
Push the new filter onto the cover.
Insert the new filter.
Push the filter in and then release it.
The filter will lock into place automat-
ically with an audible click.
Active AirClean filters can be obtained
from your Miele dealer, Miele or from
the Miele website.
Problem solving guide
37
Some minor problems can be corrected without contacting Miele.
If, having followed the suggestions below, you still cannot resolve the problem,
please contact Miele.
To prevent unnecessary loss of temperature it is advisable not to open the door
while waiting for the wine conditioning unit to be serviced.
Unauthorised installation, maintenance and repairs can cause considerable
danger for the user.
Installation, maintenance and repairs must only be carried out by a Miele au-
thorised technician.
Problem Cause and remedy
The wine unit is not get-
ting cold, the interior
lighting does not come
on when the door is
opened, and the tem-
perature display is not
lit up.
The wine unit is not switched on.
Switch the wine unit on. The temperature displays
must be lit up.
The plug is not inserted in the socket correctly.
Insert the plug into the socket.
The mains fuse has tripped. There could be a fault
with the wine unit, the household electrical wiring or
another electrical appliance.
Contact a qualified electrician or Miele.
The wine unit is not get-
ting cold. However, the
appliance and the in-
terior lighting are work-
ing fine.
Demo mode has been activated. Demo mode allows
the Wine unit to be presented in the showroom
without the cooling system being switched on. Do
not activate this setting for domestic use.
Contact the Miele Service Department for informa-
tion on deactivating Demo mode.
Problem solving guide
38
Problem Cause and remedy
The compressor is
switching on more fre-
quently and for longer
periods of time, the
temperature in the wine
conditioning unit is fall-
ing.
The temperature in the wine conditioning unit is set
too low.
Adjust the temperature.
The appliance door is not properly closed.
Check that the appliance door closes properly.
The appliance door has been opened too frequently.
Only open the door when necessary and for as
short a time as possible.
The ventilation gaps have been covered over or be-
come dusty.
Do not cover the ventilation gaps and dust them
regularly.
The air filter is dusty.
Clean the air filter (see “Cleaning and care”).
The ambient room temperature is too warm.
Decrease the ambient room temperature.
The compressor comes
on less and less often
and for shorter periods
of time. The temperat-
ure in the wine condi-
tioning unit rises.
Not a fault. The temperature is too high.
Correct the temperature setting.
Check the temperature again after 24hours.
The air filter in the appliance plinth is dirty.
Clean the air filter (see “Cleaning and care”).
Problem solving guide
39
Display warnings
Message Cause and remedy
A dash is lit up up/flash-
ing in the display.
Only temperatures within the range the wine condi-
tioning unit can display will be shown.
F0 or F1 appears in the
temperature display.
There is a fault.
Call Service.
The alarm is sounding
and the temperature
display is flashing.
The temperature in the zone concerned has risen
higher or fallen lower than the temperature set.
This could be due to, for example:
– the appliance door being opened too often, or
being left open,
– blocked ventilation gaps,
– a lengthy interruption to the power supply.
Rectify the cause of the alarm. The temperature
display will stop flashing and the alarm will stop.
Problem solving guide
40
The interior lighting is not working.
Problem Cause and remedy
The LED interior lighting
is not working.
The wine conditioning unit is not switched on.
Switch the wine conditioning unit on.
To avoid overheating, the LED lighting switches itself
off automatically after approx. 15minutes if the door
is left open.
If this is not the cause, then there is a fault.
Danger of electric shock.
There are live electrical components under the
lighting cover.
The LED lighting may only be repaired or replaced
by the Customer Service Department.
Risk of injury from LED lighting.
This lighting corresponds to risk group RG2. If the
cover is defective, there is a danger of eye injury.
If the lighting cover is defective, do not look from a
close range directly into the lighting with optical in-
struments (e.g. magnifying glass or similar).
Call the Customer Service Department.
The LED interior lighting
is on even when the
door is closed.
The feature lighting is switched on.
Switch the feature lighting off (see “Feature light-
ing”).
Problem solving guide
41
General problems with the wine conditioning unit
Problem Cause and remedy
An alarm sounds. The appliance door has been open for longer than
approx.60 seconds.
Close the appliance door.
The wine conditioning
unit cannot be switched
off.
The safety lock has been activated.
Completely deactivate the safety lock (see “Select-
ing further settings – Activating and deactivating
the safety lock”).
The slats on the
wooden shelves are
warping.
Volume change due to moisture absorption or drying
out is a typical characteristic of wood. An increase in
humidity will cause wooden components to warp,
which can lead to cracking. Knots and grain patina
are part of the natural character of wood.
Mildew has begun to
form on the wine bottle
labels.
Mildew can begin to form on the labels, depending
on the type of label adhesive used.
Clean the wine bottles and remove any adhesive
residue.
A white deposit has
formed on the wine
bottle corks.
The corks have oxidised due to contact with the air.
Use a dry cloth to wipe off the deposit. The de-
posit will not affect the quality of the wine.
Noises
42
Normal noises What causes them
Brrrrr ... A humming noise is made by the motor (compressor). This
noise can get louder for brief periods when the motor switches
on.
Blubb, blubb ... A gurgling noise can be heard when coolant is circulating
through the pipes.
Click ... Clicking sounds are made when the thermostat switches the
motor on and off.
Sssrrrrr ... On multi-zone wine conditioning units you can sometimes just
hear the sound of the fan inside the appliance.
Crack ... A cracking sound can be heard when material inside the wine
conditioning unit expands.
Remember that the noise of the compressor and the coolant circulating in the
system is unavoidable.
Noises that you
can easily rectify
Possible cause Remedy
Rattling, vibrating The wine conditioning unit is
uneven.
Realign the wine condition-
ing unit using a spirit level,
by raising or lowering the
screw feet underneath the
appliance.
Shelves are unstable or stick-
ing.
Check all removable items
and refit them correctly.
Bottles or containers are
touching each other.
Separate them.
The transport cable clips are
hanging loose at the back of
the appliance.
Remove the cable clips.
After sales service and warranty
43
Contact in the event of a fault
In the event of any faults which you
cannot remedy yourself, please contact
your Miele dealer or the Miele Customer
Service Department.
You can book a Miele Customer Ser-
vice Department call-out online at
www.miele.com/service.
Contact information for the Miele Cus-
tomer Service Department can be
found at the end of this document.
Please quote the model identifier and
serial number of your appliance (Fabr./
SN/Nr.) when contacting the Miele Cus-
tomer Service Department. This inform-
ation can be found on the data plate.
Please note that telephone calls may be
monitored and recorded for training
purposes and that a call-out charge will
be applied to service visits where the
problem could have been resolved as
described in this booklet.
The data plate is located inside the wine
unit.
EPREL database
From 1 March 2021, information on en-
ergy labelling and ecodesign require-
ments will be available in the European
Product Database (EPREL). You can
find the product database at the follow-
ing link https://eprel.ec.europa.eu/. You
will be asked to enter the model identi-
fier.
The model identifier can be found on
the data plate.
SN-ST
R600a:
XXXXXX
Nr. XX/ XXXXXXXXX.
XXX l
XXg
Warranty
The appliance warranty is valid for 2
years from date of purchase. In the UK,
you must activate your cover by calling
0330 160 6640 or registering online at
www.miele.co.uk.
For more information on country-spe-
cific warranty terms and conditions,
please contact Miele Customer Service.
Electrical connection
*INSTALLATION*
44
The wine conditioning unit is supplied
with a mains cable with moulded plug
ready for connection to an earthed
socket.
The socket must be easily accessible
after the wine conditioning unit has
been installed. If the socket is not easily
accessible, ensure that a suitable
means of disconnection is provided on
the installation side for each pole.
Risk of fire from overheating.
Connecting the refrigeration appli-
ance to a multi-socket plug adapter
or to an extension lead can overload
the cable.
For safety reasons, do not use an ex-
tension lead or multi-socket adapter.
The electrical system must comply with
local and national safety regulations
(BS7671 in the UK).
For safety reasons, we recommend us-
ing a type residual current device
(RCD) in the assigned electrical installa-
tion for connecting the wine condition-
ing unit.
If the mains connection cable is dam-
aged, it must only be replaced with a
specific mains connection cable of the
same type (available from the Miele
Customer Service Department). For
safety reasons, such replacement may
only be carried out by a qualified spe-
cialist or the Miele Customer Service
Department.
These operating instructions and the
data plate indicate the nominal power
consumption and the appropriate fuse
rating. Compare this information with
the data of the on-site electrical con-
nection.
If in any doubt, consult a qualified elec-
trician.
Do not connect the wine conditioning
unit to a stand-alone inverter such as
those used with an autonomous power
supply, e.g. solar power. When the wine
conditioning unit is switched on, power
surges could result in an auto switch-
off. This could damage the electronic
module.
Installation
45
A wine unit that has not been in-
stalled in its niche can tip up.
Keep the appliance door shut until
the wine unit has been built in and
secured in its housing in accordance
with these operating and installation
instructions.
Fire risk and danger of damage!
This wine unit must not be installed
underneath a hob.
Location
This appliance should be installed in a
dry, well-ventilated room.
When deciding where to install your
wine unit please bear in mind that it will
use more energy if installed near to a
heater, a cooker or other appliance that
gives off heat. Direct sunlight should
also be avoided.
The higher the room temperature, the
longer the compressor runs and the
higher the energy consumption is.
When installing the wine unit, please
note:
- The socket must be easily accessible
in an emergency, not concealed be-
hind the appliance.
- The plug and cable must not touch
the back of the wine unit as they
could be damaged by vibrations from
the appliance.
- Do not plug in other appliances be-
hind this wine unit.
Danger from broken glass!
Danger of injury from broken glass.
If installed at altitudes above 1500m
there is a risk of the glass in the door
breaking because of changes in air
pressure. Shards of glass can cause
severe injury if not handled with care.
Side-by-side
This wine conditioning unit can be in-
stalled side-by-side with another refri-
geration appliance.
A side-by-side installation kit is re-
quired for this. This is available from
Miele or your Miele dealer.
Your dealer will be able to advise you
which combination of models is pos-
sible.
Instructions for fitting appliances side-
by-side are given in the side-by-side
fitting kit instruction manual.
Installation
46
Climate range
The wine conditioning unit is designed
for use within a certain climate range
(ambient temperatures) and should not
be used outside this range. The climate
range of the wine conditioning unit is
stated on the data plate inside it.
Climate range Ambient room
temperature
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
Operating in a room which is too cold
will cause the compressor to switch off
for too long, causing the internal tem-
perature in the wine conditioning unit to
rise which could lead to damage.
Risk of damage due to high hu-
midity.
In environments with high humidity,
condensation can build up on the ex-
ternal wine conditioning unit panels,
which can cause corrosion.
Install the wine conditioning unit with
sufficient ventilation in a dry and/or
air-conditioned room.
After installation, make sure that the
appliance door closes properly, the
ventilation gaps are not covered and
that the wine conditioning unit has
been installed in accordance with
these operating and installation in-
structions.
Ventilation
The wine conditioning unit is ventilated
via the grille in the plinth. This must not
be covered over or blocked. Clean the
plinth regularly to remove any dust.
The cut-out in the plinth facing must
be aligned centrally with the wine con-
ditioning unit.
Before installing the wine con-
ditioning unit
Take any accessories out of the appli-
ance.
Remove the cable clip from the back
of the appliance (depending on
model).
Installation
47
Installation dimensions
Before installation, ensure the the niche dimensions are the correct size. Before in-
stallation, ensure that the ventilation gap dimensions are the correct size. The spe-
cified air vents must be observed and the cut-out in the plinth facing must be
aligned centrally with the appliance in order to ensure the correct functioning of the
wine unit.
The ventilation grille supplied and foam block supplied must be fitted and
used together.
Installation
48
View from above
Changing the door hinging
49
The wine conditioning unit is supplied
right-hinged. If left-hand hinging is re-
quired, the hinges must be changed.
To change the door hinging, you will
need the following tools:
Danger of injury and damage to
the appliance.
The glass door is breakable.
The glass door is heavy. Always
change the door hinging with the as-
sistance of another person.
Danger of injury and damage to
the appliance.
The glass door can drop.
When changing the door hinging
make sure that all fixing parts are se-
curely screwed into position.
Tip: Place a suitable cover on the floor
in front of the wine conditioning unit to
protect the glass door and your floor
from damage when changing the
hinging.
Be careful not to damage the door
seal. If the door seal is damaged, the
appliance door may not close prop-
erly and cooling will be insufficient.
Use a screwdriver to remove covers
.
Danger of injury and damage to
the appliance.
The appliance door is not secure
once the screws in the retaining
brackets have been removed.
The second person must support the
appliance door.
Remove the screws completely. Start
with the bottom screws , then un-
screw the top screws .
Remove the appliance door .
Changing the door hinging
50
Place the appliance door with the
outer side upwards on a stable sur-
face.
Take off the upper retaining bracket
and replace it on the opposite
side.
Remove the retaining bracket at the
bottom right of the appliance and
fit it to the bottom left. Make sure the
drill holes match up.
Remove the hinge bracket at the top
and the cover cap on the op-
posite side.
Push out the bushing.
Switch the positions of the cover cap
and bushing.
Unscrew the bottom hinge bracket
.
Remove the washer from the hinge
pin and from the screw.
Changing the door hinging
51
Unscrew the door opening angle lim-
iter from the lower hinge bracket
.
Screw the door opening angle limiter
onto the other hinge bracket .
Place one washer over the hinge pin
and the other washer between the
door and the screw.
Screw the hinge bracket with the
door opening angle limiter onto the
bottom left of the door .
Fit the other hinge bracket to the top
left of the door.
The second person must now sup-
port the appliance door.
Fit the appliance door .
Screw the door into the drill holes .
Now install the wine unit.
Installing the wine conditioning unit
52
Risk of damage and injury from
wine conditioning unit tipping over.
There is an increased risk of injury
and damage if the wine conditioning
unit is installed by a single person.
Two people are required for installing
the wine conditioning unit.
Install the wine conditioning unit in a
stable, solid housing unit, positioned
on an even and level floor.
The building-in niche must be hori-
zontally and vertically aligned.
The required ventilation gaps must be
provided (see “Installation” – “Ventila-
tion” and “Building-in dimensions”).
To install the wine conditioning unit,
you will need the following tools:
- Screwdrivers of various sizes
- A spirit level
- A tape measure
The following installation parts are
required:
- Ventilation grille
- Air filter
- Foam block for airflow separation
in the appliance plinth
- Screws to secure the appliance in
the niche
- Spanner to adjust height in the
niche
Setting up the wine condition-
ing unit
The air filter prevents soiling of the
compressor compartment to ensure
efficient functioning of the appliance.
Remove the protective foil from air fil-
ter .
Insert the air filter into the bottom left
of the appliance plinth.
Connect the wine conditioning unit to
the mains electrical supply (see
“Electrical Connection”).
Position the wine conditioning unit in
front of the niche.
Unscrew feet clockwise until the
appliance is 4mm less than the
height of the niche.
Installing the wine conditioning unit
53
The feet can be adjusted with the
spanner supplied or with an allen
key .
Align the wine conditioning unit hori-
zontally and vertically. If the wine
conditioning unit is not correctly
aligned it can distort.
Check the alignment of adjacent fur-
niture housing doors. If adjacent
doors vary in height from the wine
conditioning unit, see “Aligning the
wine conditioning unit to taller fur-
niture doors”.
Installing the wine conditioning unit
54
Aligning the wine conditioning unit to
taller furniture doors
If adjacent furniture doors are taller
than the wine unit door, the wine unit
can be aligned to the adjacent furniture
doors using a filler panel.
The filler panel must be made exactly to
measure. Please also take into account
the door hinge when having the filler
panel made.
A retaining bracketis required to se-
cure the filler panel. This is available
from Miele or from specialist retailers.
The retaining bracket can be fitted
above or below the wine conditioning
unit as required:
To avoid damaging the wine con-
ditioning unit, the ventilation grille
must be positioned precisely in front
of the vent outlet. If you wish to fit a
plinth facing across the front of the
wine unit make sure it provides ad-
equate ventilation.
The filler panel must be made exactly
to measure.
Installing the wine conditioning unit
55
Fix retaining bracket to the back of
filler panel .
Pull the wine unit as far as you need
to out of the niche so that you can tilt
it towards you.
Loosely hand-screw the retaining
bracket with the filler panel to
the wine unit.
Align the filler panel to the wine unit
door using the long slots to give a
flush finish.
Now tighten the screws.
You can now push the wine unit into
the niche.
Push the wine conditioning
unit into the niche
Make sure that the mains cable
does not become trapped or dam-
aged as you push the wine condi-
tioning unit into its niche.
To avoid damaging flooring which is
susceptible to scratching, take great
care when pushing the appliance into
its niche.
Push the wine conditioning unit into
the niche until the front of the appli-
ance door is flush with adjacent fur-
niture doors.
Pull the wine conditioning unit for-
ward so that it stands proud of the
furniture doors evenly by 2mm.
Installing the wine conditioning unit
56
Securing the wine conditioning
unit in the niche
The wine unit must stand proud of
furniture doors evenly by 2 mm.
Open the appliance door.
Remove cover , and first screw the
wine unit to the adjacent furniture unit
at the top left .
The wine conditioning unit will align it-
self to the left side of the niche. The
front of the appliance door must be
flush with the furniture front.
Refit the cover .
Screw the wine conditioning unit at
the bottom left and right to adjacent
furniture units.
If necessary a fourth screw can be
used in the top right hand hinge to
secure the wine unit.
To do so dismantle the door and then
fit this extra screw.
Close the appliance door and check
that the side edges of the appliance
door are aligned with the side walls of
the wine unit.
Installing the wine conditioning unit
57
Adjusting the lateral alignment of the
appliance door
If the appliance door is not aligned with
the housing side walls, the appliance
door can be adjusted using the screws
underneath the hinges.
Loosen screws and align the appli-
ance door.
Tighten screws again.
Fit the covers .
Insert foam block supplied into the
appliance plinth.
If the foam block is not fitted, the
wine unit will not achieve optimum
cooling and can suffer damage.
Installing the wine conditioning unit
58
Fit plinth facing in position.
The cut-out in the plinth facing
must be aligned centrally with the
wine unit.
Fit ventilation grille into the plinth
facing. This will cause the foam block
to be pushed back.
The foam block must be resting
against the ventilation grille in order
to separate the airflow.
United Kingdom
Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW
Tel: 0330 160 6600, Internet: www.miele.co.uk/service, E-mail: [email protected]
Australia
Miele Australia Pty. Ltd.
ACN 005 635 398
ABN 96 005 635 398
1 Gilbert Park Drive
Knoxfield, VIC 3180
Tel: 1300 464 353
Internet: www.miele.com.au
Miele Electrical Appliances Co., Ltd.
1-3 Floor, No. 82 Shi Men Yi Road
Jing' an District
200040 Shanghai, PRC
Tel: +86 21 6157 3500
Fax: +86 21 6157 3511
E-mail: [email protected],
Internet: www.miele.cn
China Mainland
Miele (Hong Kong) Ltd.
41/F - 4101, Manhattan Place
23 Wang Tai Road
Kowloon Bay, Hong Kong
Tel: (852) 2610 1025
Fax: (852) 3579 1404
Email:
Website: www.miele.hk
Hong Kong, China
Miele India Pvt. Ltd.
1st Floor, Copia Corporate Suites,
Commercial Plot 9,
Mathura Road, Jasola,
New Delhi - 110025
E-mail: customercare@miele.in
Website: www.miele.in
India
Miele Ireland Ltd.
2024 Bianconi Avenue
Citywest Business Campus
Dublin 24
Tel: (01) 461 07 10
Fax: (01) 461 07 97
E-Mail: [email protected]
Internet: www.miele.ie
Ireland
Malaysia
Miele Sdn Bhd
Suite 12-2, Level 12
Menara Sapura Kencana
Petroleum
Solaris Dutamas No. 1
Jalan Dutamas 1
50480 Kuala Lumpur, Malaysia
Phone: +603-6209-0288
Fax: +603-6205-3768
Miele New Zealand Limited
IRD 98 463 631
8 College Hill
Freemans Bay, Auckland 1011
New Zealand
Tel: 0800 464 353
Internet: www.miele.co.nz
New Zealand
Miele Pte. Ltd.
29 Media Circle
#11-04 ALICE@Mediapolis
Singapore 138565
sTel: +65 6735 1191
Fax: +65 6735 1161
E-Mail: [email protected]
Internet: www.miele.sg
Singapore
Miele (Pty) Ltd.
63 Peter Place
Bryanston 2194
P.O. Box 69434
Bryanston 2021
Tel: (011) 875 9000
Fax: (011) 875 9035
E-mail: [email protected]
Internet: www.miele.co.za
South Africa
Miele Appliances Ltd.
Showroom 1
Eiffel 1 Building
P.O. Box 114782 - Dubai
Tel. +971 4 3044 999
Fax. +971 4 3418 852
800-MIELE (64353)
E-Mail: [email protected]
Website: www.miele.ae
United Arab Emirates
Manufacturer:
Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Thailand
Miele Appliances Ltd.
BHIRAJ TOWER at EmQuartier
43rd Floor Unit 4301-4303
689 Sukhumvit Road
North Klongton Sub-District
Vadhana District
Bangkok 10110, Thailand
Sheikh Zayed Road, Umm Al Sheif
M.-Nr. 09 875 610 / 07en-GB
KWT 6321 UG
