Kenmore 11173307910 bottom-mount refrigerator User Manual

Use & Care Guide

Manual de Uso y Cuidado

English / Español

Kenmore

Bottom Freezer Refrigerator

Refrigerador Congelador Inferior

Models, Modelos: 111.7303* & 111.7330*

* color number, número de color

60139-0021700-00

Code : F706-10

(-GPOQTGKPFF 

TABLE OF CONTENTS

Warranty

.................................................................. 3

Product Record

.......................................................4

Important Safety Instructions

......................... 5-8

Parts and Features

................................................ 9

Refrigerator Installation

................................ 10-18

Unpacking Your Refrigerator ............................ 10

Prior to Use ........................................................... 11

Installation ............................................................ 11

Removing/Replacing Your Refrigerator

and Freezer Handles,

Doors and Drawers ....................................... 12-17

Refrigerator Leveling & Door Adjustment .......18

Using Your Refrigerator

................................ 19-27

Setting the Controls .............................................19

Control Panel .......................................................20

Icemaker ...............................................................21

Refrigerator Section ...........................................24

Connecting the Water Line

.................................28

Water Filter

............................................................29

Care and Cleaning

........................................ 30-31

Troubleshooting Guide

................................32-39

Service

.................................................... Back Cover

(-GPOQTGKPFF 

KENMORE LIMITED WARRANTY

REFRIGERATOR WARRANTY

KENMORE LIMITED WARRANTY

WITH PROOF OF SALE, the following warranty coverage applies when this appliance is correctly installed,

operated and maintained according to all supplied instructions.

One Year on Appliance

FOR ONE YEAR from the date of sale this appliance is warranted against defects in material or workmanship. A

defective appliance will receive free repair. If the appliance cannot be repaired it will be replaced free of charge.

This warranty coverage applies for only 90 days from the sale date if the appliance is ever used for other than

private household purposes.

Lifetime on Storage Bins

FOR AS LONG AS IT IS USED from the date of sale, a free replacement will be supplied for a defective refrigerator

or freezer compartment storage bin.* If the defect appears within the first year, a new bin will be installed at no

charge. If the defect appears after the first year, a new bin will be supplied but not installed at no charge. This

Lifetime warranty covers only storage bins, and does not apply to any other related component or mechanism. You

are responsible for the labor cost of bin installation after the first year from the date of sale. This warranty coverage

applies for only 90 days from the date of sale if the appliance is ever used for other than private household

purposes. *Warranty coverage applies to door bins, drawer bins and basket bins. Defects must be verified by a

Sears authorized service representative.

For warranty coverage details to obtain free repair or replacement, visit the web page: www.kenmore.com/warranty

This warranty covers ONLY defects in material and workmanship, and will NOT pay for:

1. Expendable items that can wear out from normal use, including but not limited to filters, belts, bags or screw-in

base light bulbs.

2. A service technician to clean or maintain this appliance, or to instruct the user in correct appliance installation,

operation and maintenance.

3. Service calls to correct appliance installation not performed by Sears authorized service agents, or to repair

problems with house fuses, circuit breakers, house wiring, and plumbing or gas supply systems resulting from such

installation.

4. Damage to or failure of this appliance resulting from installation not performed by Sears authorized service

agents, including installation that was not in accord with electrical, gas or plumbing codes.

5. Damage to or failure of this appliance, including discoloration or surface rust, if it is not correctly operated and

maintained according to all supplied instructions.

6. Damage to or failure of this appliance, including discoloration or surface rust, resulting from accident, alteration,

abuse, misuse or use for other than its intended purpose.

7. Damage to or failure of this appliance, including discoloration or surface rust, caused by the use of detergents,

cleaners, chemicals or utensils other than those recommended in all instructions supplied with the product.

8. Damage to or failure of parts or systems resulting from unauthorized modifications made to this appliance.

9. Service to an appliance if the model and serial plate is missing, altered, or cannot easily be determined to have

the appropriate certification logo.

Disclaimer of implied warranties; limitation of remedies

Customer’s sole and exclusive remedy under this limited warranty shall be product repair or replacement as provided

herein. Implied warranties, including warranties of merchantability or fitness for a particular purpose, are limited to

one year on the appliance and for as long as used on the storage bins, or the shortest period allowed by law. Seller

shall not be liable for incidental or consequential damages. Some states do not allow the exclusion or limitation

of incidental or consequential damages, or limitation on the duration of implied warranties of merchantability or

fitness, so these exclusions or limitations may not apply to you.

This warranty applies only while this appliance is used in the United States.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Sears Brands Management Corporation, Hoffman Estates, IL 60179

(-GPOQTGKPFF 

PRODUCT RECORD

In the space below, record the date of purchase, model and serial number of your product. You will find the model and

serial number printed on an identification label located on the interior liner of the refrigerator compartment. Have these

items of information available whenever you contact Sears concerning your product.

Model No.___________________ Date of Purchase ___________________

Serial No.___________________

Save these instructions and attach your sales receipt for future reference.

(-GPOQTGKPFF 

IMPORTANT SAFETY INSTRUCTIONS

BASIC SAFETY PRECAUTIONS

This guide contains many important safety messages. Always

read and obey

all safety messages.

This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or

hurt you or others, or cause damage to the product.

All safety messages will be preceded by the safety alert symbol and the hazard signal word DANGER,

WARNING or CAUTION. These words mean:

WARNING

7RUHGXFHWKHULVNRIÀUHHOHFWULFVKRFNRUSHUVRQDO

injury when using your product, basic safety

precautions should be followed, including the

following.

Read all instructions before using this appliance.

• NEVER unplug your refrigerator by pulling on the

power cord. Always grip the plug firmly and pull it

straight out from the outlet.

• If the supply cord is damaged, it must be replaced

by the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard. Do not use

a cord that shows cracks or abrasion damage along its

length or at either the plug or connector end.

• Do not modify or extend the power cord length. It

could cause electric shock or fire.

• When moving your refrigerator away from the wall, be

careful not to roll over or damage the power cord.

• DO NOT store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any other

appliance.

• This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person

responsible for their safety.

• DO NOT allow children to climb, stand, or hang on the

refrigerator doors or shelves in the refrigerator. They

could damage the refrigerator and seriously injure

themselves.

• Keep fingers out of pinch point areas; clearances

between the doors and cabinets are necessarily small.

Be careful closing doors when children are in the area.

• Unplug your refrigerator before cleaning or making

any repairs.

NOTE:

It is strongly recommended that any service be

performed by a qualified technician.

• Keep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

• Do not use mechanical devices or other means to

accelerate the defrosting process, other than those

recommended by the manufacturer

• Do not damage the refrigerant circuit

• Do not use electrical appliances inside the food storage

compartments of the appliance unless they are of the

type recommended by the manufacturer

• Connect to potable water supply only.

You

will

be killed or seriously injured if you do not follow instructions.

You

can

be killed or seriously injured if you do not follow instructions.

Indicates an imminently hazardous situation which, if not avoided,

may

result in minor or moderate injury, or product damage.

SAVE THESE INSTRUCTIONS

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if

the instructions are not followed.

(-GPOQTGKPFF 

WARNING

• Before replacing a burned-out or broken light bulb,

unplug the refrigerator or turn off power at the circuit

breaker or fuse box in order to avoid contact with a

live wire filament. (A burned-out light bulb may break

when being replaced exposing the wire filament.)

NOTE

: Some models have LED interior lighting and

service should be performed by a qualified technician.

WARNING

: Setting either or both controls to the OFF

position does not remove power to the light circuit.

• When you are finished, reconnect the refrigerator to

the electrical source and reset the controls (Thermostat,

Refrigerator Control, and or Freezer Control, depending

on the model) to the desired setting.

• This refrigerator must be properly installed in

accordance with the Attention Installer Instructions.

• After your refrigerator is in operation, do not touch the

cold surfaces in the freezer compartment when hands

are damp or wet. Skin may adhere to the extremely

cold surfaces.

• Do not plug several appliances into the same wall

outlet. - It can be a cause of overheating and/or

fire. Use an exclusive grounding receptacle for the

refrigerator.

• Never hold the power cord or plug with wet hands. -

There is a risk of electric shock

• Never use a damaged power cord or plug, or loose

main socket. - There is a risk of fire, electric shock or

serious injury.

• Be sure to ground. Check if your wall outlet is grounded

(earthed). - There is a risk of electric shock hazards.

• Do not install the refrigerator on a wet floor or in a

place with excessive humidity and moisture. - Electric

insulation gets weakened, resulting in a risk of electric

shock hazards.

• Never let the power cord touch or pass over heating

appliances. - Power cord can be damaged, resulting in

a risk of electric shock hazards.

• Make sure plug is fully inserted into socket to prevent

the risk of electrical shock.

• Do Not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any other

appliance.

• Never pour or spray water into the refrigerator

(both interior and exterior). - Electric insulation gets

weakened, resulting in a risk of electric shock hazards.

• Do not place containers with water or liquid on top of

refrigerator. - Water can spill into the refrigerator and

can cause electric shock hazards or damage.

• Do not move or remove compartment shelves/pockets

while foods and containers are on them. - Hard

containers (of glass, metal etc.) can fall to hurt you and

can break glass shelf and interior parts.

• Never repair, disassemble or alter the refrigerator on

your own. - There is a risk of personal injury or damage

to the refrigerator. It is recommended that any service

be carried out by a qualified person.

• If a gas leak is found near the refrigerator or in the

kitchen, ventilate it immediately without touching the

power plug or refrigerator.

• Do not store medicine, academic research samples

which require strict temperature control in the

refrigerator.

• Never insert fingers or hands into the bottom of the

refrigerator, especially into the bottom back. - You can

be hurt by sharp metal edges or can receive an electric

shock.

• When you find the power cord damaged or cut, call

the service agent immediately.

• When you get rid of your old refrigerator, be sure

to remove the door packings first. - Children can

be entrapped and suffocated in an abandoned

refrigerator.

• It is recommended to unplug the refrigerator when it is

not going to be used for a long period of time.

• Never touch foods and containers especially of metal

with wet hands in the freezer compartment. - You can

be hurt by chilblains or cold burns.

• Never eat any decayed or deteriorated food at

all. - Foods stored too long in the refrigerator can

deteriorate and become decayed.

• Never place bottles and containers of glass in the

freezer compartment. - Glass containers and bottles

can break and hurt you.

• When moving the refrigerator (horizontally or tilted),

more than 2 persons are required to hold it.(One to

hold top back handles, the other to hold the bottom

holder). If other parts are held instead, it is very

dangerous and likely to slip.

SAVE THESE INSTRUCTIONS

(-GPOQTGKPFF 

WARNING

DANGER: RISK OF CHILD ENTRAPMENT

• Be sure to turn up the wheel first before moving the

refrigerator - Be sure to turn up the wheel first before

moving the refrigerator, Otherwise, the parts can

collide and break each other.

• DO NOT touch the automatic ice making mechanism

while the refrigerator is plugged in.

• DO NOT refreeze frozen foods which have thawed

completely. The United States Department of Agriculture

in Home and Garden Bulletin No. 69 says:

…You may safely refreeze frozen foods that have thawed

if they still contain ice crystals or if they are still cold—

below 39°F (4°C).

…Thawed ground meats, poultry or fish that have any

off-odor or off-color should not be refrozen and should

not be eaten. Thawed ice cream should be discarded.

If the odor or color of any food is poor or questionable,

dispose of it. The food may be dangerous to eat.

Even partial thawing and refreezing reduces the eating

quality of foods, particularly fruits, vegetables and

prepared foods. The eating quality of red meats is

affected less than that of many other foods. Use refrozen

foods as soon as possible to save as much of their quality

as you can.

Junked or abandoned refrigerators are dangerous, even if they are sitting for only a few days. If you are getting rid of

your old refrigerator, please follow the instructions below to help prevent accidents (child entrapment and suffocation).

WARNING

: The use of this appliance can expose you to chemicals known to the state of California

to cause cancer, birth defects, or other reproductive harm. For more information go to

www.P65Warnings.ca.gov

SAVE THESE INSTRUCTIONS

BEFORE YOU THROW AWAY

YOUR OLD REFRIGERATOR

OR FREEZER:

• Take off the doors.

• Leave the shelves in place so that

children may not easily climb inside.

(-GPOQTGKPFF 

CFC/HCFC DISPOSAL

ELECTRICAL & GROUNDING REQUIREMENTS

Your old refrigerator may have a cooling system

that used CFCs or HCFCs (chlorofluorocarbons or

hydrochlorofluorocarbons). CFCs and HCFCs are believed

to harm stratospheric ozone if released to the atmosphere.

Other refrigerants may also cause harm to the environment

if released to the atmosphere

If you are throwing away your old refrigerator, make

sure the refrigerant is removed for proper disposal by a

qualified technician. If you intentionally release

refrigerant, you may be subject to fines and imprisonment

under provisions of environmental legislation.

IMPORTANT

: Please read carefully.

TO CONNECT ELECTRICITY

RECOMMENDED GROUNDING METHOD

The refrigerator should always be plugged into its own

individual properly grounded electrical outlet rated for

115 Volts, 60 Hz, AC only, and fused at 15 or 20 amperes.

This provides the best performance and also prevents

overloading house wiring circuits which could cause a fire

hazard from overheated wires. It is recommended that a

separate circuit serving only this appliance be provided.

Use a receptacle that cannot be turned off with a switch

or pull chain. Do not use an extension cord.

Where a standard two-prong wall outlet is encountered,

it is your personal responsibility and obligation to have

it replaced with a properly grounded three-prong wall

outlet.

USE OF EXTENSION CORDS

Because of potential safety hazards under certain

conditions, the use of an extension cord is not

recommended.

However, if you still elect to use an

extension cord, it is absolutely necessary that it be a UL-

listed (USA), 3-wire grounding type appliance extension

cord having a grounding type plug and outlet, and that

the electrical rating of the cord be 15 amperes (minimum)

and 120 volts.

Use of an extension cord will increase the clearance

needed for the back of the refrigerator.

WARNING

Electrical Shock Hazard

FOR PERSONAL SAFETY,

this appliance must be

properly grounded. Have the wall outlet and the circuit

checked by a qualified electrician to make sure the

outlet is properly grounded.

3-prong

grounding

plug

3-prong

grounding type

wall receptacle

Ensure proper

ground exists

before use.

(-GPOQTGKPFF 

PARTS AND FEATURES

This instruction manual refers to several models. Features may vary according to model.

Features with * are applicable on 7330* models only

1. Covered Dairy Bin or Covered Storage Bin

for storing butter and cheese.

2. Low profile door storage bin

for items of medium to large size.

3. Gallon door storage bin

for items of medium to large size.

4. Low profile door storage bin

for items of medium size.

5. Small door storage bin

for small items.

6. Narrow door storage bin

for small items.

7. Icemaker/Ice cube bin

for making and holding ice for through-the-door

dispenser.

8. Air filter

9. Water filter

10. Narrow Top Shelf

11. Adjustable glass shelf

12. Slide Shelf (*)

13. Humidity controlled crisper bin

for storage of fruits and vegetables

14. Temperature Control full width pantry drawer (*)

for storage of meat and fresh vegetables

15. Pull out freezer drawer

16. Lower freezer basket

for general freezer storage

17. Freezer Ice Storage Bin

18. Control and display panel

19. Ice/Water Dispenser

20. Freezer icemaker (*)

❺

❻

❹

⓱

❼ ❽

⓮

⓯

⓰

❶

⓲

⓳

❷

❸

❹

❾

❿ ⓫

⓫ ⓬

⓭⓭

⓴

(-GPOQTGKPFF 

REFRIGERATOR INSTALLATION

WARNING

Excessive Weight Hazard:

Use two or more people to move and install the

refrigerator. Failure to do so can result in back or other

injury.

UNPACKING YOUR REFRIGERATOR

Remove tape and any temporary labels from your

refrigerator before using. Do not remove any warning- type

labels, the model and serial number label, or

the Tech Sheet that is located under the front of the

refrigerator.

To remove any remaining tape or glue, rub the area briskly

with your thumb. Tape or glue residue can also be easily

removed by rubbing a small amount of liquid dish soap

over the adhesive with your fingers. Wipe with warm water

and dry.

Do not use sharp instruments, rubbing alcohol, flammable

fluids, or abrasive cleaners to remove tape or glue. These

products can damage the surface of your refrigerator.

Refrigerator shelves are installed in the shipping position.

Please reinstall shelves according to your individual storage

needs.

Remove all cantilevered refrigerator compartment shelves

and remove the protective shipping tape found on the

attachment hooks at back of shelves. For shelf removal

instructions, see Refrigerator Shelves in USING YOUR

REFRIGERATOR section of this Use & Care Guide.

WARNING

Excessive Weight Hazard:

Your refrigerator is heavy. When moving the refrigerator

for cleaning or service, be sure to protect the floor.

Always pull the refrigerator straight out when moving

it. Do not wiggle or walk the refrigerator when trying to

move it, as floor damage could occur.

WARNING

Explosion Hazard:

Keep flammable materials and vapors, such as gasoline,

away from the refrigerator. Failure to do so can result in

fire, explosion, or death.

(-GPOQTGKPFF 

REFRIGERATOR INSTALLATION

PRIOR TO USE

Clean your refrigerator thoroughly and wipe off all

dust that accumulated during shipping.

Install accessories such as ice cube bin, drawers,

shelves, etc., in their proper places. They are packed

together to prevent possible damage during shipment.

Allow your refrigerator to run for at least two to three

hours before putting food in it. Check the flow of

cold air in the freezer compartment to ensure proper

cooling. Your refrigerator is now ready for use.

INSTALLATION

The refrigerator should always be plugged into its own

individual properly grounded electrical outlet rated for

115 Volts, 60 Hz, AC only, and fused at 15 or 20 amperes.

This provides the best performance and also prevents

overloading house wiring circuits which could cause a fire

hazard from overheated wires. It is recommended that a

separate circuit serving only this appliance be provided.

WARNING

Shock Hazard:

To reduce the risk of electric shock, do not install the

refrigerator in a wet or damp area.

INSTALLATION (continued)

To avoid noise and vibration, the unit must be leveled

and installed on a solidly constructed floor. If required,

adjust the leveling legs to compensate for unevenness

of the floor. The front should be slightly higher than the

rear to aid in door closing. Leveling legs can be turned

easily by tipping the cabinet slightly. Turn the leveling

legs to the left to raise the unit or to the right to lower

it. (See Leveling and door AlIgnment.)

NOTE:

Installing on carpeting, soft tile surfaces,

a platform or weakly supported structure is not

recommended.

Install this appliance in an area where the temperature

is between 55°F (13°C) and 110°F (43°C). If the

temperature around the appliance is too low or high,

cooling ability may be adversely affected.

Select a place where a water supply can be easily

connected for the automatic icemaker.

NOTE:

The water pressure must be from 30 to 125 psi

or 207-862 kPa or 2.1-8.8 kgf/cm². If the refrigerator

is installed in an area with low water pressure below

30 psi, you can install a booster pump to compensate

for the low pressure.

For sufficient door opening clearance, allow at least

4 inches between each side of the refrigerator and an

adjacent wall or surface.

Too small of a distance from adjacent surfaces may

result in lowered freezing capability and increased

electricity consumption charges. Provide the following

unobstructed clearance for sufficient air flow around

the refrigerator:

- At least 2 inches between refrigerator back and wall.

- At least 2 inches between refrigerator top and

overhead surface.

(-GPOQTGKPFF 

NOTE:

Removing the doors is always recommended

when it is necessary to move the refrigerator through

a narrow opening. If it is necessary to remove the

handles, follow the directions below.

HOW TO REMOVE REFRIGERATOR

DOOR HANDLE

NOTE:

Handle appearance may vary from the

illustrations on this page.

Removing Refrigerator Handle

Use the provided 2.5 mm hex key to loosen the

set screw located on the top inside end of the

handle far enough to pull the handle free from

the underlying mounting bolt. Carefully slide the

handle up to free the bottom end of the handle

from its mounting bolt.

HOW TO REPLACE REFRIGERATOR

DOOR HANDLE

NOTE:

Handle appearance may vary from the

illustrations on this page.

Replacing Refrigerator Handle

Place the bottom end of the handle over the lower

mounting bolt on the door and carefully slide

handle down until it stops. Lower the top end of

the handle over the top mounting bolt. Use a 2.5

mm hex key to tighten the set screw to secure the

handle in place.

Mounting

Bolts

Set Screw

hex key

Mounting Bolt

REFRIGERATOR INSTALLATION

(-GPOQTGKPFF 

HOW TO REMOVE FREEZER DRAWER HANDLE

NOTE:

Handle appearance may vary from the

illustrations on this page.

Removing Freezer Drawer Handle

Use a 2.5 mm hex key to loosen the set screw

located on the lower left end of the handle far

enough to pull the handle free from the underlying

mounting bolt. Carefully slide the handle to the

left to free the right end of the handle from its

mounting bolt.

HOW TO REPLACE FREEZER DRAWER HANDLE

NOTE:

Handle appearance may vary from the

illustrations on this page.

Replacing Freezer Drawer Handle

Place the right end of the handle over the mounting

bolt on the right side of the freezer drawer and

carefully slide handle to the right until it stops.

Lower the left end of the handle over the left side

mounting bolt. Use a 2.5 mm hex key to tighten the

set screw to secure the handle in place.

NOTE

: If the handle mounting fasteners need to be

tightened or removed, use a ¼ in. Allen wrench.

WARNING

When assembling or disassembling the handles:

• Grasp the handle firmly to ensure it will not drop or

cause injury.

• Prevent the handle from swinging toward nearby

people or animals.

• Insert the handle footprints over the door mounting

fasteners and tighten the hex screws to fix the handle

in place.

• Check for any gap between the door and handle after

the handle is fixed in place.

NOTE:

Removing the doors is always recommended when it is necessary to move the refrigerator through a narrow

opening. If it is necessary to remove the handles, follow the directions below.

Mounting Bolt

REFRIGERATOR INSTALLATION

(-GPOQTGKPFF 

REMOVING AND REPLACING

REFRIGERATOR DOORS

WARNING

Risk of electric shock!

Before removing top hinge cover

• Shut off the water supply to the appliance.

• Unplug the appliance or switch off power from the

breaker or fuse panel.

To remove the left refrigerator door:

Remove top hinge cover using a phillips screwdriver by

removing 5 screws.

Remove the hinge grounding wire screw and pull the

two grounding wire connections away from the hinge.

Disconnect the three wire harnesses and the water

tube. Push in the small first ring on the connection

collar to remove the tube.

Using a large phillips screwdriver, turn top hinge

fastener counterclockwise to remove the top hinge

plate.

CAUTION:

After the hinge is removed, the door can

fall down forward. Hold the door to prevent it from

falling.

Lift the door from the middle hinge pin and remove

the door. Place the door, inside facing up, on a non-

scratch surface.

To remove the right refrigerator door:

Remove top hinge cover using a phillips screwdriver by

removing 5 screws.

Using a large phillips screwdriver, turn top hinge

fastener counterclockwise to remove the top hinge

plate.

CAUTION:

After the hinge is removed, the door can

fall down forward. Hold the door to prevent it from

falling.

Lift the door from the middle hinge pin and remove

the door. Place the door, inside facing up, on a non-

scratch surface.

REFRIGERATOR INSTALLATION

Push In

(-GPOQTGKPFF 

Reinstalling the Left Refrigerator Door

Lower the door onto the middle hinge.

Fit the top hinge over the mounting holes and align to

proper position before tightening.

Turn top hinge fastener clockwise to secure the hinge.

Securely reconnect the grounding wires, wire harnesses

and water tube. Simply push the water tube back into

the collar to connect.

Screw top hinge cover into place with a screwdriver.

Reinstalling the Right Refrigerator Door

Lower the door onto the middle hinge.

Fit the top hinge over the mounting holes and align to

proper position before tightening.

Turn top hinge fastener clockwise to secure the hinge.

Screw top hinge cover into place with a screwdriver.

REFRIGERATOR INSTALLATION

(-GPOQTGKPFF 

HOW TO REMOVE THE FREEZER DRAWER

WARNING

: Use two or more people to remove and

install the freezer drawer. Failure to do so can result in

personal injury, product or property damage.

Take out the ice bin first, and then take out the upper

freezer drawer by lifting it up.

Remove lower freezer basket by pulling up and tilting

toward refrigerator until it can be removed from the

freezer drawer/door assembly.

Push the rail support locking tabs to release the main

freezer drawer rails from the cabinet while slightly

pulling the exterior freezer drawer outwards, so that the

locking tab does not return to the locked position. The

locking tabs are located in the freezer compartment to

the rear of the main rail assembly (which is attached

to main exterior freezer drawer) as shown in the

illustration below.

Pull exterior freezer drawer to fully disengage the rail

assembly from the unit. Use 2 people for this task as

the door is heavy and awkward to handle.

CAUTION

: Do not hold the handle when removing or

replacing the drawer. The handle may come off and it

could cause personal injury.

Place the door on a non-scratch surface.

REFRIGERATOR INSTALLATION

Locking Tab

(-GPOQTGKPFF 

HOW TO INSTALL THE FREEZER DRAWER

Using 2 people (recommended), align end of the

exterior drawer rails to the lower rail guides located on

the sidewalls of the freezer compartment. Make sure

the gear teeth are engaged to the gear rail the same

amount on both sides.

Fully push in and close freezer drawer to engage rails

with rail support locking tab, applying a bit of pressure

after the door is closed to seat the tabs to the rail.

CAUTION

: Make sure the tabs are completely

engaged to the rail or the refrigerator drawer could be

pulled out of the refrigerator by the user. Fully open the

freezer door to check and see if the locking tabs are

fully engaged. If they are not engaged, gently push

each freezer rail with a flat head screwdriver towards

the freezer compartment until the locking tabs snap to

the locked position.

Replace the lower freezer drawer basket.

Insert the upper freezer drawer above the lower basket,

and replace ice bin into upper drawer.

Open and close the freezer drawer several times to

make sure operation is smooth and seal is consistent all

the way around the freezer compartment.

REFRIGERATOR INSTALLATION

This shows that

the tab is not

fully locked

If the tab is not fully engaged,

use a flat screwdriver to push

on the rail as shown to allow

the tab to snap into position

This shows that the

tab is fully in the

locked position

(-GPOQTGKPFF 

REFRIGERATOR LEVELING

& DOOR ADJUSTMENT

The refrigerator must be level in order to maintain optimal

performance and desirable front appearance.

(If the floor beneath the refrigerator is uneven, the freezer

and refrigerator doors look unbalanced.)

Leveling Refrigerator

Pull open the freezer compartment and remove the

upper drawer and lower drawer basket to gain access.

Using the wrench provided, turn the leveling leg

clockwise to lower and counterclockwise to raise the

front corners of the refrigerator.

Install the lower drawer basket and upper drawer,

then open and close the freezer compartment several

times to make sure operation is smooth and without

hindrance.

Adjusting a refrigerator door

If the height of the refrigerator doors is uneven, turn the

screw nut on the middle hinge to adjust the refrigerator door.

To raise a refrigerator door turn the screw

counterclockwise.

To lower a refrigerator door turn the screw clockwise.

Adjusting the freezer drawer

If the freezer drawer is lower on one side than the other,

perform the steps listed below to raise that side. To access

the adjustment components, first pull the drawer out to full

extension. then remove the pullout drawer and the freezer

basket.

Loosen the four screws on the rail bracket on the side

where adjustment is needed.

Unscrew and remove Stopper and flat washers from

the lower position (left picture). Insert washers and

screw Stopper into the upper position (right picture).

The stopper will serve as a fixed edge against which

to turn the Position Knob to adjust the height of the rail

bracket.

Slightly pull the Position Knob forward and firmly

rotate it to a different position, then release the knob

back into place. The knob surfaces push against the

edge of the stopper ring to vary the height of the

rail bracket. The maximum adjustment variance is

approximately 1/8 inch.

Retighten the four rail bracket screws.

Reinsert the freezer basket and pullout drawer.

When inserting the basket, make sure that the tabs at

the front of the basket fit into the slots on the freezer

drawer rails.

Raise Lower

REFRIGERATOR INSTALLATION

(-GPOQTGKPFF 

USING YOUR REFRIGERATOR

SETTING THE CONTROLS

Temperature Control

NOTE:

When changing control settings, wait 24 hours

before making additional adjustments. The controls are set

correctly when milk or juice is as cold as you would like

and when ice cream is firm. If the temperature in either

compartment is too cold or too warm, change the setting

one increment at a time. Wait 24 hours for the change to

stabilize before adjusting again.

• The refrigerator temperature control is preset to

37 deg F (3 deg C) and the freezer control is preset

to 0 deg F (-18 deg C). These are recommended

temperature settings for normal use conditions.

Freezer Compartment

Push the Freezer button and the temperature setting

changes in the sequence as shown below:

>>> Sequential Temperature Change <<<

Accela Chill Freezer function:

To activate freezer Accela Chill, press and hold the

Freezer button for 3 seconds. Accela Chill LED will turn

on. Push the button again to cancel.

The Accela Chill function is useful to help quickly chill the

freezer compartment when needed. For example: If a

large quantity of warm food is placed inside the freezer,

or if loading the freezer with new groceries which may

not be as cold as normal freezer temperatures.

Accela Chill will automatically cancel (Accela Chill LED

will turn off) after 50 hours.

Refrigerator Compartment

Push the Refrigerator button and the temperature setting

changes in the sequence as shown below:

>>> Sequential Temperature Change <<<

Accela Chill Refrigerator function:

To activate refrigerator Accela Chill, press and hold the

Refrigerator button for 3 seconds. Accela Chill LED will

turn on. Push the button again to cancel.

The Accela Chill function is useful to help quickly cool the

refrigerator compartment when needed. For example:

If a large quantity of warm food is placed inside the

refrigerator, or if loading the refrigerator with new

groceries which may not be as cold as normal refrigerator

temperatures.

Accela Chill refrigerator function will automatically cancel

(Accela Chill LED will turn off) after 6 hours

Demo Mode (For Store Use Only)

The Demo Mode disables all cooling in the refrigerator

and freezer sections to conserve energy while on display

in a retail store.

When Demo Mode is active, the icons for the various

refrigerator functions will light up in sequence across the

face of the panel.

To activate:

Push and hold Light button for 3 seconds to lock control

panel. The Locked icon will appear.

While pressing and holding the Accela Ice and

Refrigerator Temp buttons, press the Light button 5

times. You will hear a soft beep with each press. After

the fifth press the Demo Mode is activated.

To deactivate:

While pressing and holding the Accela Ice and

Refrigerator Temp buttons, press the Light button 5

times. You will hear a soft beep with each press. After

the fifth press the Demo Mode is deactivated.

Push and hold Light button for 3 seconds to unlock

control panel. The Locked icon will disappear.

(-GPOQTGKPFF 

USING YOUR REFRIGERATOR

Control Panel

1. Freezer button

Selection button for freezer compartment temperature.

2. Accela Ice button

1) Press the Accela ice button once to turn on Accela

Ice Mode

Press the “Accela” button one time to cancel Accela

Ice feature (LED Off)

This function increases ice-making capabilities for 24

hours.

2) Filter Reset

When the Filter Change icon turns on, you need to

change the water filter. After changing the water

filter, press and hold the Accela Ice button for

3 seconds to turn the indicator light off.

You need to change the water filter approximately

every 6 months.

3. Water / Ice Select

Press either Water or Ice Select button according to

your needs.

Press Ice select again according to your ice preference.

(Cube/Crushed)

4. Refrigerator button

Selection button for refrigerator compartment

temperature.

5. Light button

1) Press to turn dispenser light on or off.

2) To lock the control panel: Press and hold light button

for 3 seconds. Locked icon will appear.

To unlock, press and hold Light button for 3 seconds.

Locked icon will disappear.

6. Symbols on the display panel

Accela Ice

Illuminates when Accela Ice function is ON.

Replace Filter

When the Filter Change icon turns on, you need to

change the water filter. After changing the water filter,

press and hold the Accela Ice button for three seconds

to turn the indicator light off. You need to change the

water filter approximately every six months.

Panel lock

Illuminates when the panel lock is on.

Ice Maker

Illuminates when the Ice maker is off

Cubed/Crushed Ice

Changes according to your ice preference (Ice Select)

7. Temperature Mode Switch Function (°F

°C)

If you want to convert °F to °C or vice Versa:

1. Press and hold the

Lock

button for 3 seconds.

The lock icon will illuminate.

2. Press and hold Freezer Temp and Refrigerator Temp

buttons at same time for 5 seconds until temperature

mode changes.

NOTE:

If the lock icon is illuminated after performing this

function, press and hold Lock button for 3 seconds to turn

control lock OFF.

(-GPOQTGKPFF 

ICEMAKER

Turning on the icemaker

Both the The 7303* and 7330* models have a dispenser

connected icemaker located on the left side of the

refrigerator compartment. The 7330* model also features

an icemaker located on the left side of the bottom freezer

compartment.

Whenever the refrigerator is plugged in after being

unplugged, icemaking is automatically set to On. To turn

icemaking Off or On, see the instructions in Shutting

icemaking off.

For the 7330* model the control panel On and Off

icemaking settings apply to both icemakers at the same

time.

NOTE:

As long as icemaking is turned On in the control

panel, if an icemaker stops production because the ice bin

becomes full, production will resume operation once the

ice bin is cleared of ice.

Dispenser Icemaker Alternate On/Off

The dispenser icemaker is equipped with an On/Off

button in the upper left corner. You may turn the icemaker

On or Off by pressing the button for 3 seconds. When

turned On, the indicator light next to the button will

illuminate. See detailed instructions on the label found on

the side of the dispenser icemaker.

NOTE:

In model 7330*, turning off icemaking with the

button on the dispenser icemaker will also turn off the

freezer icemaker. Turning dispenser icemaker back on with

the button will also turn on the freezer icemaker.

In case the icemaker doesn’t work

• Did you wait for 12 hours after installation of the water

supply line before making ice?

• Is the water line connected and the shut-off valve

opened?

• Did you manually stop the ice making function?

• Is the freezer temperature too warm? Try setting the

freezer temperature lower.

In case of power failure

In the event of a lengthy power failure, remove ice cubes

in the storage bin as the ice may melt and flow down to

the ice dispenser and leak out.

Place bin back in the icemaker assembly.

Shutting icemaking off

Important!

If you do not intend to use any ice cubes for longer than

one week (e.g. because you are going on holiday), shut

off icemaking for that period to prevent ice cubes from

freezing together.

To turn OFF :

Press and hold Water and Ice Select buttons at same

time for 3 seconds until Ice Off illuminates in the

control panel display.

To turn ON :

Press and hold Water and Ice Select buttons at same

time for 3 seconds until Ice Off ceases to illuminate in

the control panel display.

Empty and clean the ice cube bin.

To remove ice bin from dispenser icemaker, grasp front

of ice bin and pull forward.

To remove freezer ice bin, pull freezer drawer all the

way forward and lift ice bin up and out of pullout

drawer.

NOTE:

There is a fingerhold indentation on the bottom

front of the dispenser ice bin for ease of bin removal.

Return the ice cube bin into position.

NOTE:

The ice bin should be emptied any time the

icemaker is turned off.

USING YOUR REFRIGERATOR

(-GPOQTGKPFF 

ICEMAKER (continued)

CAUTION

• The first ice and water dispensed may include particles

or odor from the water supply line or the water tank.

• Throw away the first few batches of ice. This is also

necessary if the refrigerator has not been used for a

long time.

• Never store beverage cans or other items in the ice

bin for the purpose of rapid cooling. Doing so may

damage the icemaker or the containers may burst.

• If discolored ice is dispensed, check the water filter

and water supply. If the problem continues, contact a

Sears or other qualified service center. Do not use the

ice or water until the problem is corrected.

• Keep children away from the dispenser. Children may

play with or damage the controls.

• The ice passage may become blocked with frost if only

crushed ice is used. Remove the frost that accumulates

by removing the ice bin and clearing the passage with

a rubber spatula. Dispensing cubed ice can also help

prevent frost buildup.

• Never use thin crystal glass or crockery to collect ice.

Such containers may chip or break resulting in glass

fragments in the ice.

• Dispense ice into a glass before filling it with water

or other beverages. Splashing may occur if ice is

dispensed into a glass that already contains liquid.

• Never use a glass that is exceptionally narrow or

deep. Ice may jam in the ice passage and refrigerator

performance may be affected.

• Keep the glass at a proper distance from the ice outlet.

A glass held too close to the outlet may prevent ice

from dispensing.

• To avoid personal injury, keep hands out of the ice

door and passage.

• Never remove the dispenser cover.

• If ice or water dispenses unexpectedly, turn off the

water supply and contact Sears Home Services at

1-844-469-6667.

WHEN TO SET ICEMAKER TO OFF

• When the water supply will be shut off for several

hours.

• When the ice bin is removed for more than one or two

minutes.

• When the refrigerator will not be used for several days.

NOTE:

The ice bin should be emptied any time the

icemaker is turned off.

PREPARING FOR VACATION

Set the icemaker ON/OFF button to OFF and shut off the

water supply to the refrigerator.

To turn OFF :

Press and hold Water and Ice Select buttons at same time

for 3 seconds until Ice Off illuminates in the control panel

display.

To turn ON :

Press and hold Water and Ice Select buttons at same

time for 3 seconds until Ice Off ceases to illuminate in the

control panel display.

NOTE:

The ice bin should be emptied any time the

icemaker is turned off.

If the ambient temperature will drop below freezing, have

a qualified technician drain the water supply system to

prevent serious property damage due to flooding caused

by ruptured water lines or connections.

USING YOUR REFRIGERATOR

(-GPOQTGKPFF 

How to use the Automatic Icemaker

The dispenser icemaker will produce 12 cubes per cycle.

The freezer icemaker will produce 7 cubes per cycle.

• The dispenser icemaker will produce approximately

216 - 288 cubes (20 - 24 cycles a day) in a 24

hour period, depending on freezer compartment

temperature, room temperature, number of door

opening and other user conditions.

• The freezer icemaker will produce 50 to 70 ice cubes

in a 24 hour period depending on the same conditions

listed above.

• It is normal for the icemaker to make banging sounds

when the ice cubes are falling into the ice storage bin

• To prevent bad odor smell, regularly clean the ice cube

storage bin.

• If the amount of ice in the storage bin is not sufficient,

the ice may not be dispensed. Wait a day or so to

make more ice.

• If the ice does not dispense easily, ensure the dispenser

outlet is not blocked.

• Throw away the first few batches of ice to allow the

water line to clear. Be sure nothing interferes with

the level of the optical sensor space at the dispenser

icemaker base or the shutoff arm of the freezer

icemaker.

Optical Sensor Space

Freezer IcemakerDispenser Icemaker

Icemaking will stop when the dispenser ice bin fills to the

level of the optical sensor, or when the freezer ice bin fills

and pushes the shutoff arm all the way up.

Clear the bin of of excessive ice. If you remove bin for

clearing, return bin correctly into place. Icemaking will

resume after the ice bin is cleared to below the optical

sensor in the dispenser icemaker, or cleared to allow the

shutoff arm to lower in the freezer icemaker.

It is normal for several ice cubes to be joined together.

If ice is not used frequently, old ice cubes will become

shrunken, cloudy and taste stale. If you won't use ice

frequently, shut icemaking off.

USING YOUR REFRIGERATOR

(-GPOQTGKPFF 

FOOD STORAGE GUIDE

Wrap or store food in the refrigerator in airtight and

moisture-proof material unless otherwise noted. This

prevents food odor and taste transfer throughout the

refrigerator. For dated products, check date code to

ensure freshness.

Items How to

Butter or

margarine

Keep opened butter in a covered

dish or closed compartment.

When storing an extra supply,

wrap in freezer packaging and

freeze.

Cheese

Store in the original wrapping

until you are ready to use it. Once

opened, rewrap tightly in plastic

wrap or aluminum foil.

Milk

Wipe milk cartons. For best

storage, place milk on interior

shelf, not on door shelf.

Eggs

Store in original carton on interior

shelf, not on door shelf.

Fruit

Do not wash or hull the fruit

until it is ready to be used. Sort

and keep fruit in its original

container, in a crisper, or store in

a completely closed paper bag

on a refrigerator shelf.

Leafy

vegetables

Remove store wrapping and trim

or tear off bruised and discolored

areas. Wash in cold water and

drain. Place in plastic bag or

plastic container and store in

crisper.

Vegetables

with skins

(carrots,

peppers)

Place in plastic bags or plastic

container and store in crisper.

Fish

Store fresh fish and shellfish in

the freezer section if they are not

being consumed the same day of

purchase. It is recommended to

consume fresh fish and shellfish

the same day purchased.

Leftovers

Cover leftovers with plastic wrap

or aluminum foil, or store in

plastic containers with tight lids.

STORING FROZEN FOOD

NOTE:

Check a freezer guide or a reliable cookbook for

further information about preparing food for freezing or

food storage times.

Freezing

Your freezer will not quick-freeze a large quantity of

food. Do not put more unfrozen food into the freezer

than will freeze within 24 hours (no more than 2 to 3

lbs. of food per cubic foot of freezer space). Leave

enough space in the freezer for air to circulate around

packages. Be careful to leave enough room at the

front so the door can close tightly.

Storage times will vary according to the quality and

type of food, the type of packaging or wrap used

(how airtight and moisture-proof) and the storage

temperature. Ice crystals inside a sealed package are

normal. This simply means that moisture in the food

and air inside the package have condensed, creating

ice crystals.

NOTE:

Allow hot foods to cool at room temperature

for 30 minutes, then package and freeze. Cooling hot

foods before freezing saves energy.

Packaging

Successful freezing depends on correct packaging.

When you close and seal the package, it must not

allow air or moisture in or out. If it does, you could

have food odor and taste transfer throughout the

refrigerator and could also dry out frozen food.

Packaging recommendations:

• Rigid plastic containers with tight-fitting lids

• Straight-sided canning/freezing jars

• Heavy-duty aluminum foil

• Plastic-coated paper

• Non-permeable plastic wraps

• Specified freezer-grade self-sealing plastic bags

Follow package or container instructions for proper

freezing methods.

Do not use

• Bread wrappers

• Non-polyethylene plastic containers

• Containers without tight lids

• Wax paper or wax-coated freezer wrap

• Thin, semi-permeable wrap

CAUTION

: Do not keep beverage cans or plastic

food containers in the freezer compartment. They may

break or burst if they freeze.

USING YOUR REFRIGERATOR

(-GPOQTGKPFF 

REFRIGERATOR SECTION

WATER OR ICE DISPENSER

To dispense water or ice, press the Water or Ice Select

button on control panel and push on the dispenser lever

with the side of your glass.

NOTE:

The dispenser is equipped with a light that turns on

when the dispenser lever is pressed.

When Ice Select button is pressed once, cubed ice will

dispense. Press Ice Select button a second time to dispense

crushed ice.

NOTE:

Some ice may drop outside of cup during Ice

dispensing.

Slowly remove glass from dispenser Lever before full to

help prevent ice spillage.

A few uncrushed ice cubes may mix in with Crushed Ice

when you dispense Crushed Ice.

WARNING

: Do not put your fingers up the ice chute

opening. Doing so can result in severe injury.

CAUTION

: Do not dispense ice into fine china or

crystal glasses. China or crystal can break.

Foldaway door bar (mullion bar)

- When closing the left refrigerator door, the mullion bar

folds behind the right refrigerator door, forming a seal

between the refrigerator doors.

- When opening the left refrigerator door, the mullion

bar folds back to the left door automatically.

- The mullion bar may become damaged upon closing

if it has been extended to the right while the door left

door is open.

CAUTION

: Before closing the left refrigerator door,

make sure the mullion bar is folded back to the left

door position or product damage may result.

Opening: Mullion bar

folds back

Closing: Mullion bar folds

to right

USING YOUR REFRIGERATOR

Water & Ice Dispenser

Switch

(-GPOQTGKPFF 

REFRIGERATOR SHELVES

The shelves in your refrigerator are adjustable to meet

your individual storage needs. Your model may have glass

or wire shelves.

Adjusting the shelves to fit different heights of items will

make finding the exact item you want easier. Doing so will

also reduce the amount of time the refrigerator door is

open which will save energy.

IMPORTANT:

Do not clean glass shelves with warm water

while they are cold. Shelves may break if exposed to

sudden temperature changes or impact.

CAUTION

: Glass shelves are heavy. Use special care

when removing them.

Adjusting Shelves (Cantilever)

Remove shelves from the shipping position and replace

shelves in the position you want.

To remove a shelf

: Lift up on front of shelf with one

hand and with other hand push up on back of shelf to

release attachment hooks from attachment slots. Pull

the shelf out.

To reinstall a shelf:

With front of shelf angled slightly

up, engage hooks on back of shelf into attachment

slots, and then lower front of shelf into place.

CAUTION

: Make sure that shelves are level from one

side to the other. Failure to do so may result in the shelf

falling or spilling food.

Slide Glass Shelf (model 7330* only)

To create space for tall item storage, grasp edge of front

half of shelf and slide down and under the back half of

shelf.

USING YOUR REFRIGERATOR

(-GPOQTGKPFF 

HUMIDITY CONTROLLED CRISPER

The crispers provide fresher tasting fruit and vegetables

by letting you easily control humidity inside the drawer.

You can control the amount of humidity in the moisture

sealed crispers crispers by adjusting the control to any

setting between

VEGETABLES

and

FRUIT

- Slide the Humidity Control toward “hi” to keep moist air

in crisper for best storage of fresh, leafy vegetables.

- Slide the Humidity Control toward “lo” to release moist

air from crisper for best storage of fruit.

REMOVING THE HUMIDITY CONTROLLED CRISPER

To remove, pull the drawer

out to full extension.

Lift the front of the crisper

up, then pull it straight out.

To install, slightly tilt up the front, insert the drawer into

the frame and push it back into place.

FREEZER SECTION

PULLOUT FREEZER DRAWER

To remove, pull the freezer

drawer out to full extension.

Lift out the ice bin if present.

Tilt the front of the pullout

freezer drawer up and then

lift drawer out.

CAUTION

: Pinch hazard! Keep hands and feet clear

of the bottom of the freezer drawer when opening and

closing.

To replace, hold pullout freezer drawer with back

angled down. Insert the back rollers over the front edge

of the runers built into the sides of the freezer cabinet.

Slide the drawer back and into place. Fit ice bin back

into pullout freezer drawer.

WARNING

: When the pullout drawer is removed, there

is enough room in the lower freezer drawer for a child or

pet to crawl inside. To prevent accidental child and pet

entrapment or suffocation risk, DO NOT allow children or

pets to touch or go near the lower freezer drawer.

Temperature Controlled Pantry Drawer

(model 7330* only)

The Temperature Controlled Pantry Drawer provides

storage space with a variable temperature control that

can keep the compartment colder than the refrigerator

section. This drawer can be used for large party trays, deli

items, and beverages. (This drawer should not be used for

vegetables that require high humidity).

Press Select button to choose between Produce, Deli or

Meat.

DOOR BIN

The door bins are removable for easy cleaning and

adjustment.

To remove the bin, simply lift the bin up and pull

straight out.

To replace the bin, slide it in above the desired support

and push down until it snaps into place.

NOTE:

Some bins may vary in appearance and will

only fit in one location.

CAUTION

: Do not overfill or pack items too tightly

into door bins. Doing so may cause damage to the bin

or personal injury if items are removed with excessive

force.

USING YOUR REFRIGERATOR

(-GPOQTGKPFF 

CONNECTING THE WATER LINE

BEFORE YOU BEGIN

This water line installation is not covered by the

refrigerator warranty. Follow these instructions carefully to

minimize the risk of expensive water damage.

Water hammer (water banging in the pipes) in house

plumbing can cause damage to refrigerator parts and

can lead to water leakage or flooding. Call a qualified

plumber to correct water hamme

CAUTION

: To prevent burns and product damage,

only connect the refrigerator water line to a cold water

supply.

IMPORTANT:

If you use your refrigerator before

connecting the water line, make sure the icemaker is

turned OFF at the control panel.

CAUTION

: Do not install the icemaker tubing in areas

where temperatures fall below freezing.

WATER PRESSURE

The water pressure must be from 30 to 125 psi or 207-862

kPa or 2.1-8.8 kgf/cm

. If the refrigerator is installed in

an area with low water pressure “below 30 psi”, you can

install a booster pump to compensate for the low pressure.

WATER SUPPLY KIT

* Connecting the water line to the refrigerator.

(Necessary parts are available at local service agents.)

Connect water line to the compression fitting.

- If you are using copper tubing (not supplied), slip

the compression nut (not supplied) and ferrule (not

supplied) on copper tubing.

- If you are using plastic tubing (not supplied), insert

the molded ending of the plastic tubing into the

compression fitting.

Tighten the compression nut onto the compression

fitting.

Turn the water on and check for any leakage.

WARNING

To reduce the risk associated with ingestion of

contaminants: Do not use with water that is

microbiologically unsafe or of unknown quality

without adequate disinfection before and after the

system. Systems certified for cyst reduction may be

used on disinfected water that may contain filterable

cysts. EPA Establishment Number 10350-MN-005

(-GPOQTGKPFF 

WATER FILTER

Installation

Turn of the water supply to the refrigerator. Dispense

water for 3 seconds to prevent water drops from falling

while installing filter.

The water filter is located in

the top of the refrigerator

compartment. Pull the water

filter cover toward you and

down.

Remove the locking cap by turning 1/2

counterclockwise. Save locking cap for possible future

use. Always install locking cap if no filter is in place.

Insert water filter and rotate

clockwise 1/2 turn to secure

in place. Raise the water filter

cover and slide back into place.

Dispense water over the course of 5 minutes in cycles

of 30 seconds ON and 60 seconds OFF. Do not

dispense water continuously for 5 minutes.

✳

One filter is supplied with the refrigerator.

A replacement filter can be purchased at a Sears

store or by calling 1-844-553-6667.

CAUTION

: Wipe with cloth if droplets fall when

exchanging a filter.

&OHDQÁRZ$LU)LOWHU

NOTE:

Air Filter should be changed every 6 months.

Replacing the water filter at same time as air filter is

recommended.

,QIRUPDWLRQFRQFHUQLQJWKHZDWHUÀOWHU

- After use, the water system is subject to low pressure.

Proceed with caution when removing the filter.

Dispenser water 1-3 seconds before water filter change

to prevent water drops from falling.

Flush the water system if the appliance has not been

in use for a long period of time, or if the ice/water has

an unpleasant taste or smell. To do this, dispense water

through the water dispenser for several minutes.

If the unpleasant taste or smell remains, replace the filter.

To protect from frost, remove the filter cartridge if you

expect the temperature to drop below freezing.

- If pressure surges could occur in the water pipe, do not

install the water filter without a suitable surge eliminator.

Contact an installation expert if you are not sure

whether pressure surges could occur in the water pipe.

- After installing a new filter : Discard any ice produced

in the first 24 hours after switching on.

- If no ice has been removed for a long period of time,

empty the ice cube bin and discard any ice produced

over the next 24 hours.

WARNING

To reduce the risk associated with ingestion of contaminants:

Do not use with water that is microbiologically unsafe or of

unknown quality without adequate disinfection before and

after the system. Systems certified for cyst reduction may

be used on disinfected water that may contain filterable

cysts. EPA Establishment Number 10350-MN-005

CAUTION

To reduce the risk associated with property damage

due to water leakage:

•

Read and follow

the Water Filter instructions before

installation and use of this system.

• Installation and use

MUST

comply with all state and

local plumbing codes.

•

Do not

install if water pressure exceeds 125 psi

(862 kPa). Contact a plumbing professional if you

are uncertain of how to check your water pressure.

•

Do not

install where water hammer conditions may

occur. If water hammer conditions exist, you must

install a water hammer arrester. Contact a plumbing

professional if you are uncertain of how to check for

this condition.

•

Do not

install on hot water supply lines.

The maximum operating water temperature of this

water filter system is 100°F (38°C).

•

3URWHFWZDWHUÀOWHUIURPIUHH]LQJ

. Do not operate

refrigerator in ambient conditions below 55°F

(12.7°C). Drain water filter when storing unit in

temperatures below 40°F (4.4°C).

• The disposable water filter must be replaced every

six months, at the rated capacity, or if a noticeable

reduction in flow rate occurs.

Insert fingertips beneath base

of filter cover and pull toward

you to remove.

Turn cover over. Slide filter to

right to remove. Slide new filter

to left to insert.

Insert tabs at top of cover into

slots in cabinet wall. Push cover

forward to secure in place.

(-GPOQTGKPFF 

CARE AND CLEANING

1. Water Dispenser

• Clean the water collecting tray with a sponge or

absorbent cloth.

2. Ice Storage Bin

• Removing: Pull out and remove the ice cube bin

• Cleaning: Empty the ice cube bin and clean with

lukewarm water.

Thoroughly dry the bin and screw conveyor to

prevent new ice cubes from sticking.

• Replacing: Push the ice cube bin all the way back

onto the supports until it locks into position.

If the bin cannot be pushed all the way back, rotate

the ice auger a quarter turn and insert again.

3. Freezer & Refrigerator Bins

• Hold both ends and pull up.

4. Refrigerator Shelves

To remove a shelf: Lift up

on front of shelf with one

hand and with other hand

push up on back of shelf

to release attachment

hooks from attachment

slots. Pull the shelf out.

To reinstall a shelf: With

front of shelf angled

slightly up, engage hooks

on back of shelf into

attachment slots, and

then lower front of shelf

into place.

CAUTION

: Make sure that shelves are level from one

side to the other. Failure to do so may result in the shelf

falling or spilling food.

(-GPOQTGKPFF 

CARE AND CLEANING

LIGHT BULB REPLACEMENT

NOTE:

The refrigerator and freezer compartment

lights have LED interior lighting, and service should be

performed by a qualified technician.

POWER INTERRUPTIONS

If the power will be out for 24 hours or less, keep all

refrigerator doors closed to help foods stay cold and

frozen.

If the power will be out for more than 24 hours,

remove all frozen food and store it in a frozen food

locker.

WHEN YOU GO ON VACATION

If you choose to leave the refrigerator on while you

are away,

follow these steps to prepare your refrigerator

before you leave.

Use up any perishables and freeze other items.

Turn off the icemaker and empty the ice bin.

If you choose to turn the refrigerator off before you

leave,

follow these steps.

Remove all food from the refrigerator.

Clean the refrigerator, wipe it and dry well.

Tape rubber or wood blocks to the tops of both doors

to prop them open far enough for air to get in. This

stops odor and mold from building up.

WHEN YOU MOVE

When you are moving your refrigerator to a new home,

follow these steps to prepare it for the move.

Remove all food from the refrigerator and pack all

frozen food in dry ice.

Unplug the refrigerator.

Clean, wipe and dry thoroughly.

Take out all removable parts, wrap them well and tape

them together so they do not shift and rattle during the

move. Refer to the

Using your Refrigerator

section for

removing instructions.

Tape the doors shut and tape the power cord to the

refrigerator cabinet.

When you get to your new home, put everything back

and refer to the

Refrigerator Installation

section for

preparation instructions.

WARNING

Electrical Shock Hazard

Before replacing a Compartment Lamp, either unplug

the refrigerator or turn off power at the circuit breaker

or fuse box.

(-GPOQTGKPFF 

TROUBLESHOOTING GUIDE

COOLING

Problem Possible Causes Solutions

Refrigerator and

Freezer section are

not cooling.

Power cord unplugged. Plug into a known properly grounded 3-prong outlet.

Refrigerator is set to demo mode. Demo Mode allows the lights and control display to work

normally while disabling cooling to save energy while

on the showroom floor. Refer to the Setting the Controls

section for instructions on how to disable Demo Mode.

Refrigerator is in the defrost cycle. During the defrost cycle, the temperature of each

compartment may raise slightly. Wait 30 minutes and

confirm the proper temperature has been restored once

the defrost cycle has completed.

Refrigerator was recently installed. It may take up to 24 hours for each compartment to

reach the desired temperature.

Refrigerator was recently relocated. If the refrigerator was stored for a long period of time or

moved on its side, it is necessary for the refrigerator to

stand upright for 24 hours before connecting it to power.

Cooling System runs

too much.

Refrigerator is replacing an older

model.

Modern refrigerators require more operating time but use

less energy due to more efficient technology.

Refrigerator was recently plugged in

or power restored.

The refrigerator will take up to 24 hours to cool

completely.

Door opened often or a large amount

of food / hot food was added.

Adding food and opening the door warms the

refrigerator, requiring the compressor to run longer in

order to cool the refrigerator back down. In order to

conserve energy, try to get everything you need out of

the refrigerator at once, keep food organized so it is

easy to find, and close the door as soon as the food is

removed. (Refer to the Food Storage Guide.)

Doors are not closed completely. Firmly push the doors shut. If they will not shut all the

way, see the Doors will not close completely or pop open

section in Parts & Features Troubleshooting.

Refrigerator is installed in a hot

location.

The compressor will run longer under warm conditions.

At normal room temperatures (70°F) expect your

compressor to run about 40% to 80% of the time.

Under warmer conditions, expect it to run even more

often. The refrigerator should not be operated above

110°F.

Condenser / back cover is clogged. Use a vacuum cleaner with an attachment to clean the

condenser cover and vents. Do not remove the panel

covering the condenser coil area.

(-GPOQTGKPFF 

TROUBLESHOOTING GUIDE

COOLING

Problem Possible Causes Solutions

Refrigerator or

Freezer section is too

warm.

Refrigerator was recently installed. It may take up to 24 hours for each compartment to

reach the desired temperature.

Doors are opened often or for long

periods of time.

When the doors are opened often or for long periods

of time, warm, humid air enters the compartment. This

raises the temperature and moisture level within the

compartment. To lessen the effect, reduce the frequency

and duration of door openings.

Unit is installed in a hot location. The refrigerator should not be operated in temperatures

above 110F.

A large amount of food or hot food

was added to either compartment.

Adding food warms the compartment requiring the

cooling system to run. Allowing hot food to cool to room

temperature before putting it in the refrigerator will

reduce this effect.

Doors not closed correctly. See the Doors will not close correctly or pop open

section in Parts & Features Troubleshooting

Temperature control is not set

correctly.

If the temperature is too warm, adjust the control one

increment at a time and wait for the temperature to

stabilize. Refer to the Setting the Controls section for

more information.

Defrost cycle has recently completed. During the defrost cycle, the temperature of each

compartment may raise slightly and condensation may

form on the back wall. Wait 30 minutes and confirm the

proper temperature has been restored once the defrost

cycle has completed.

Interior moisture

buildup.

Doors are opened often or for long

periods of time.

When the doors are opened often or for long periods of

time, warm, humid air enters the compartment.

This raises the temperature and moisture level within the

compartment. To lessen the effect, reduce the frequency

and duration of door openings.

Doors not closed correctly. See the Doors will not close correctly section in the

Troubleshooting section.

Weather is humid. Humid weather allows additional moisture to enter the

compartments when the doors are opened leading to

condensation or frost. Maintaining a reasonable level of

humidity in the home will help to control the amount of

moisture that can enter the compartments.

Defrost cycle recently completed. During the defrost cycle, the temperature of each

compartment may raise slightly and condensation may

form on the back wall. Wait 30 minutes and confirm

that the proper temperature has been restored once the

defrost cycle has completed.

Food is not packaged correctly. Food stored uncovered or unwrapped, and damp

containers can lead to moisture accumulation within each

compartment. Wipe all containers dry and store food in

sealed packaging to prevent condensation and frost.

(-GPOQTGKPFF 

COOLING/ICE & WATER

Problem Possible Causes Solutions

Food is freezing

in the refrigerator

compartment.

Food with high water content was

placed near an air vent.

Rearrange items with high water content away from air

vents.

Refrigerator temperature control is set

incorrectly.

If the temperature is too cold, adjust the control one

increment at a time and wait for the temperature to

stabilize. Refer to the Setting the Controls section for

more information.

Refrigerator is installed in a cold

location.

When the refrigerator is operated in temperature

below 41°F (5°C), food can freeze in the refrigerator

compartment. The refrigerator should not be operated in

temperature below 55°F (13°C).

Frost or ice crystals

form on frozen food

(outside of package).

Door is opened frequently or for long

periods of time.

When the doors are opened often or for long periods

of time, warm, humid air enters the compartment. This

raises the temperature and moisture level within the

compartment. Increased moisture will lead to frost and

condensation. To lessen the effect, reduce the frequency

and duration of door openings.

Door is not closing properly. Refer to the Doors will not close correctly or pop open

section in the Troubleshooting section.

Refrigerator or

Freezer section is too

cold.

Incorrect temperature control settings. If the temperature is too cold, adjust the control one

increment at a time and wait for the temperature to

stabilize. Refer to the Setting the Controls sect;ion for

more information.

Frost or ice crystals

on frozen food

(inside of sealed

package).

Condensation from food with a high

water content has frozen inside of the

food package.

This is normal for food items with a high water content.

Food has been left in the freezer for a

long period of time.

Do not store food items with high water content in the

freezer for a long period of time.

Icemaker is not

making enough ice.

Demand exceeds ice storage

capacity.

The dispenser icemaker will produce approximately

216-288 cubes in a 24 hour period. The freezer icemaker

will produce approximately 50 to 70 cubes in a 24 hour

period.

House water supply is not connected,

valve is not turned on fully, or valve is

clogged.

Connect the refrigerator to a cold water supply with

adequate pressure and turn the water shutoff valve fully

open.

If the problem persists, it may be necessary to contact a

plumber.

Water filter has been exhausted. It is recommended that you replace the water filter:

Approximately every six months.

• When the water filter indicator turns on.

• When the water dispenser output decreases.

• When the ice cubes are smaller than normal.

Low house water supply pressure.

NOTE:

The water pressure must be from 30 to 125 psi

or 207-862 kPa or 2.1-8.8 kgf/cm

. If the refrigerator

is installed in an area with low water pressure below

30 psi, you can install a booster pump to compensate

for the low pressure.

If the problem persists, it may be necessary to contact a

plumber or install a booster pump to compensate for the

low pressure.

Reverse Osmosis filtration system is

used.

Reverse osmosis filtration systems can reduce the water

pressure below the minimum amount and result in

icemaker issues. (Refer to Water Pressure section.)

TROUBLESHOOTING GUIDE

(-GPOQTGKPFF 

ICE & WATER

Problem Possible Causes Solutions

Icemaker is not

making enough ice

(continued).

Tubing connecting refrigerator to

house supply valve is kinked.

The tubing can kink when the refrigerator is moved

during installation or cleaning resulting in reduced water

flow. Straighten or repair the water supply line and

arrange it to prevent future kinks.

Doors are opened often or for long

periods of time.

If the doors of the unit are opened often, ambient

air will warm the refrigerator which will prevent the

unit from maintaining the set temperature. Lowering

the refrigerator temperature can help, as well as not

opening the doors as frequently.

Doors are not closed completely. If the doors are not properly closed, ice production

will be affected. See the Doors will not close

completely or pop open section in Parts & Features

Troubleshooting for more information.

The temperature setting for the

freezer is too warm.

The recommended temperature for the freezer

compartment for normal ice production is 0°F. If the

freezer temperature is warmer, ice production will be

affected.

Dispensing water

slowly.

Water filter has been exhausted. It is recommended that you replace the water filter:

Approximately every six months.

• When the water filter indicator turns on.

• When the water dispenser output decreases.

• When the ice cubes are smaller than normal.

Low house water supply pressure.

NOTE:

The water pressure must be from 30 to 125 psi

or 207-862 kPa or 2.1-8.8 kgf/cm

. If the refrigerator

is installed in an area with low water pressure below

30 psi, you can install a booster pump to compensate

for the low pressure.

If the problem persists, it may be necessary to contact

a plumber or install a booster pump to compensate

for the low pressure.

Not dispensing ice. Doors are not closed completely. Ice will not dispense if any of the refrigerator doors

are left open.

Infrequent use of the dispenser. Infrequent use of the ice dispenser will cause the cubes

to stick together over time, which will prevent them

from properly dispensing. Check the ice bin for ice

cubes clumping/sticking together. If they are, break up

the ice cubes to allow for proper operation.

The delivery chute is clogged with

frost or ice fragments.

Eliminate the frost or ice fragments by removing the

ice bin and clearing the chute with a plastic utensil.

Dispensing cubed ice can also help prevent frost or ice

fragment buildup.

The dispenser display is locked. Press and hold the Lock button for three seconds to

unlock the control panel and dispenser.

Ice bin is empty. It may take up to 24 hours for each compartment to

reach the desired temperature and for the icemaker

to begin making ice. Make sure that the shutoff (arm/

sensor) is not obstructed.

Once the ice supply in the bin has been completely

exhausted, it my take up to 90 minutes before

additional ice is available, and approximately 24

hours to completely refill the bin.

TROUBLESHOOTING GUIDE

(-GPOQTGKPFF 

ICE & WATER

Problem Possible Causes Solutions

Icemaker is not

making ice.

Refrigerator was recently installed or

icemaker recently connected.

It may take up to 24 hours for each compartment to

reach the desired temperature and for the icemaker to

begin making ice.

Icemaker not turned on. Locate the icemaker on/of button and confirm that

it is turned ON.

The refrigerator is not connected to

a water supply or the supply shutoff

valve is not turned on.

Connect refrigerator to the water supply and turn the

water shutoff valve fully open.

Icemaker shutoff

1. Dispenser icemaker optical sensor is

blocked by ice.

2. Freezer icemaker shutoff arm is

pushed all the way up by ice.

1. Remove enough ice from bin so that the optical

sensing space is not blocked.

2. Remove enough ice from bin to allow shutoff arm to

lower from shutoff position.

Not dispensing water. New installation or water line recently

connected.

Dispense 2.5 gallons of water (flush for approximately

5 minutes) to remove trapped air and contaminates

from the system. Do not dispense the entire 2.5

gallon amount continuously. Depress and release the

dispenser pad for cycles of 30 seconds ON and 60

seconds OFF.

The dispenser panel is locked. Press and hold the Lock button for three seconds to

unlock the control panel and dispenser.

The dispenser is not set for water

dispensing.

On the control panel press the Water button.

Refrigerator or freezer doors are not

closed properly.

Water will not dispense if any of the refrigerator

doors are left open.

Water filter has been recently

removed or replaced.

After the water filter is replaced, dispense 2.5 gallons

of water (flush for approximately 5 minutes) to remove

trapped air and contaminates from the system. Do not

dispense the entire 2.5 gallon amount continuously.

Depress and release the dispenser pad for cycles of

30 seconds ON and 60 seconds OFF.

Tubing connecting refrigerator to

house supply valve is kinked.

The tubing can kink when the refrigerator is moved

during installation or cleaning resulting in reduced

water flow. Straighten or repair the water supply line

and arrange it to prevent future kinks.

The house water supply is not

connected, the valve is not turned on

fully, or the valve is clogged.

Connect refrigerator to the water supply and turn the

water shutoff valve fully open.

If the problem persists, it may be necessary to contact

a plumber.

TROUBLESHOOTING GUIDE

(-GPOQTGKPFF 

ICE & WATER

Problem Possible Causes Solutions

Ice has bad taste or

odor.

Water supply contains minerals such

as sulfur.

A water filter may need to be installed to eliminate

taste and odor problems.

NOTE: In some cases, a filter may not help. It may not

be possible to remove all minerals / odor / taste in all

water supplies.

Icemaker was recently installed. Discard the first few batches of ice to avoid discolored

or bad tasting ice.

Ice has been stored for too long. Ice that has been stored for too long will shrink,

become cloudy, and may develop a stale taste. Throw

away old ice and make a new supply.

The food has not been stored

properly in either compartment.

Rewrap the food. Odors may migrate to the ice if

food is not wrapped properly.

The interior of the refrigerator needs

to be cleaned.

See the Care and Cleaning section for more

information.

The ice storage bin needs to be

cleaned.

Empty and wash the bin (discard old cubes). Make

sure that the bin is completely dry before reinstalling

it.

Dispensing warm

water.

Refrigerator was recently installed. Allow 24 hours after installation for the water storage

tank to cool completely.

The water dispenser has been used

recently and the storage tank was

exhausted.

Depending on your specific model, the water storage

capacity will range from approximately 20 to 30 oz.

Dispenser has not been used for

several hours.

If the dispenser has not been used for several hours,

the first glass dispensed may be warm. Discard the

first 10 oz.

Refrigerator is connected to the hot

water supply.

Make sure that the refrigerator is connected to a cold

water pipe.

WARNING: Connecting the refrigerator to a hot

water line may damage the icemaker.

Water has bad taste

or odor.

Water supply contains minerals such

as sulfur.

A water filter may need to be installed to eliminate

taste and odor problems.

Water filter has been exhausted. It is recommended that you replace the water filter:

Approximately every 6 months.

• When the water filter indicator turns on.

• When the water dispenser output decreases.

• When the ice cubes are smaller than normal.

Refrigerator was recently installed. Dispense 2.5 gallons of water (flush for approximately

5 minutes) to remove trapped air and contaminates

from the system. Do not dispense the entire 2.5

gallon amount continuously. Depress and release the

dispenser pad for cycles of 30 seconds ON and 60

seconds OFF.

TROUBLESHOOTING GUIDE

(-GPOQTGKPFF 

NOISE

Problem Possible Causes Solutions

Clicking The defrost control will click when

the automatic defrost cycle begins

and ends. The thermostat control (or

refrigerator control on some models)

will also click when cycling on and

off.

Normal Operation

Rattling

Rattling noises may come from the

flow of refrigerant, the water line on

the back of the unit, or items stored

on top of or around the refrigerator.

Normal Operation

Refrigerator is not resting solidly on

the floor.

Floor is weak or uneven or leveling legs need to be

adjusted. See the Door Alignment section.

Refrigerator with linear compressor

was jarred while running.

Normal Operation

Whooshing Evaporator fan motor is circulating

air through the refrigerator and

freezer compartments.

Normal Operation

Air is being forced over the condenser

by the condenser fan.

Normal Operation

Gurgling

Refrigerant flowing through the

cooling system.

Normal Operation

Popping

Contraction and expansion of the

inside walls due to changes in

temperature.

Normal Operation

Sizzling

Water dripping on the defrost heater

during a defrost cycle.

Normal Operation

Vibrating

If the side or back of the refrigerator

is touching a cabinet or wall, some of

the normal vibrations may make an

audible sound.

To eliminate the noise, make sure that the sides and

back cannot vibrate against any wall or cabinet.

Dripping Water running into the drain pan

during the defrost cycle.

Normal Operation

Pulsating or High-

Pitched Sound

Your refrigerator is designed to run

more efficiently to keep your food

items at the desired temperature. The

high efficiency compressor may cause

your new refrigerator to run longer

than your old one, but it is still more

energy efficient than previous models.

While the refrigerator is running, it is

normal to hear a pulsating or

highpitched

sound.

Normal Operation

TROUBLESHOOTING GUIDE

(-GPOQTGKPFF 

PARTS & FEATURES

Problem Possible Causes Solutions

Doors will not close

correctly or pop

open.

Food packages are blocking the door

open.

Rearrange food containers to clear the door and door

shelves.

Ice bin, crisper cover, pans, shelves,

door bins, or baskets are out of

position.

Push bins all the way in and put crisper cover, pans,

shelves and baskets into their correct positions. See the

Using Your Refrigerator section for more information.

The doors were removed during

product installation and not properly

replaced.

Remove and replace the doors according to the

Removing and Replacing Refrigerator Handles and

Doors section.

Refrigerator is not leveled properly. See Door Alignment in the Refrigeration Installation

section to level refrigerator.

Doors are difficult to

open.

The gaskets are dirty or sticky. Clean the gaskets and the surfaces that they touch.

Rub a thin coat of appliance polish or kitchen wax on

the gaskets after cleaning.

Door was recently closed. When you open the door, warmer air enters the

refrigerator. As the warm air cools, it can create a

vacuum. If the door is hard to open, wait one minute

to allow the air pressure to equalize, then see if it

opens more easily.

Refrigerator wobbles

or seems unstable.

Leveling legs are not adjusted

properly.

Refer to the Leveling and Door Alignment section.

Floor is not level. It may be necessary to add shims under the leveling

legs or rollers to complete installation.

Lights do not work.

LED interior lighting failure. The refrigerator compartment lamp is LED interior

lighting, and service should be performed by

a qualified technician. Refer to the Light Bulb

Replacement section.

The interior of

the refrigerator is

covered with dust or

soot.

The refrigerator is located near a fire

source, such as a fireplace, chimney

or candle.

Make sure that the refrigerator is not located near a

fire source, such as a fireplace, chimney or candle.

The refrigerator

compartment has an

unpleasant odor.

1. Food may be producing unpleasant

odor.

2. The Air Filter may need to be

replaced.

1. Remove odor producing food. Place box of baking

soda in refrigerator compartment to absorb odors.

2. To replace, see Cleanflow Air Filter information in

WATER FILTER section of this Use & Care Guide.

TROUBLESHOOTING GUIDE

(-GPOQTGKPFF 

.HQPRUH§

&XVWRPHU&DUH+RWOLQH

7RVFKHGXOHLQKRPHUHSDLUVHUYLFH

RURUGHUUHSODFHPHQWSDUWV

3DUDSHGLUVHUYLFLRGHUHSDUDFLÚQ

DGRPLFLOLR\RUGHQDUSLH]DV



ZZZNHQPRUHFRP



(-GPOQTGKPFF 

ࢆܢזݣܶࢺࡿՄۭ

הۭ؞ୋ )ࠒ ࢓ۺ࢒ гз࢒ રચ࢝

ˮٔ ȿݦǹܹࢽ

࠾঍ࢇ࢒ 

࠾঍ْۭ

θۢۏܽ θۢۏܽ θۢۏܽ

ْૺ%1&' ૺֵ ʵ $W[GT

0$18$/ %দ3)ࠒ߭

.HQPRUH

ەۼέࡅ

ࠒݛଢق

ݦদS૲ی؀ࢊԜݛઝ୎୚দFXW

ܹࢽদS

ࢊԜݛઝۘܹࢽFXWҡݛ૕۰Ԃіࢇ܊ی؀ࢊԜݛઝ୎୚FXWBࢇࠖЧ

ܹࢽদSی؀ࢊԜݛઝ୎୚দFXWBࢇࠖЧ

ܹࢽদSBࢇࠖЧࢊԜݛઝۘܹࢽFXWBࢇࠖЧ

ܹࢽদSBࢇࠖЧࢊԜݛઝۘFXW

ܹࢽদSBࢇࠖЧ

ܹࢽদSBࢇࠖЧࢊԜݛઝۘܹࢽFXWBࢇࠖЧ

ܹࢽদS୘ࢊ؀ࢊԜݛઝ୎୚দFXWBࢇࠖЧ

ܹࢽদSB۶ָ۰Җȥ)BࢇࠖЧ

ܹࢽদSBࢇࠖЧ

Ȅطঌ˗԰ҡ࢕ࢉیߦ۰ٕ˗԰3')ળࢊٕ

ەࠧʈࢄݣܶࢺࡳࡿՄଟПЩ



лࡆࢴ࢒ε࢝˅ː࢝۟یܺરચ

(-GPOQTGKPFF 

Kenmore 11173307910 bottom-mount refrigerator

Product's Documents

User Manual

Specifications

Kenmore 11173307910 Questions and Answers
