769-21791 / 00 05/19
REPLACEMENT PARTS - MODEL TB272V
2-CYCLE BLOWER
PPN 41AR272V766
Item Part No. Description
1 753-06027 Muffler Assembly (includes 2 & 3)
2 753-06294 Muffler Screws
3 753-05946 Muffler Gasket
4 753-06687 Shortblock Assembly (includes 5 - 11)
5 710-04715 Screw
6 753-06847 Spark Plug
7 753-06443 Module Assembly
8 753-06827 Cylinder Gasket
9 753-06175 Flywheel Assembly
10 736-04107 Washer
11 712-04137 Nut
Item Part No. Description
12 753-05949 Lead Wire
13 753-06690 Throttle Cable
14 753-06189 Insulator Assembly (includes 15)
15 753-06185 Insulator O-Ring
16 753-08637 Carburetor Assembly (includes 17)
17 753-06253 Carburetor Gasket
18 753-08636 Air Cleaner Assembly (includes 19)
19 791-181757 Air Filter
20 753-06720 Fuel Tank Assembly (includes 21 & 22)
21 710-04194 Screw
22 753-06857 Fuel Cap
4
7
5
6
8
9
10
11
1
3
2
12
13
15
16
14
17
18
19
22
21
20
REPLACEMENT PARTS - MODEL TB272V
2-CYCLE BLOWER
PPN 41AR272V766
24
25
26
27
47
23
48
46
33
41
35
36
29
37
38
39
40
33
44
43
42
45
29
30
31
32
33
34
44
33
46
46
28
49
50
Item Part No. Description
23 753-06694 Muffler Cover Assembly (includes 33)
24 753-05936 Upper Tube
25 753-05937 Lower Tube
26 753-06660 Upper Vac Tube
27 791-180467 Lower Vac Tube
28 753-05932 Outer Trigger Lock
29 753-05919 Handle Grips
30 791-182405 Switch
31 753-05925 Wavey Washer
32 753-05924 Inner Trigger Lock
33 710-04194 Screw
34 753-05930 Throttle Trigger
35 753-05926 Latch Tube
36 753-05939 Latch Spring
Item Part No. Description
37 1755 Screw
38 753-06696 Door Lock
39 753-06678 Intake Cover (includes 37 & 38)
40 753-05918 Spring
41 753-06679 Impeller Housing
42 753-06700 Adapter
43 912-0237 Nut
44 753-05928 Washer
45 753-05929 Impeller
46 791-181862 Screw
47 753-06693 Impeller Housing
48 753-06695 Engine Cover Assembly (includes 33 & 46)
49 753-06658 Elbow
50 753-06659 Bag
769-21791 / 00 05/19
