User manual of Neff B57CS22N0 (40 pages)
file thumbnail

Table of contents

INFORMATION FOR USE

Safety .. 2

Preventing material damage. 5

Environmental protection and saving en ergy .. 5

Familiarising yourself with your appliance .. 6

Accessories. 8

Before using for the first time 10

Basic operation .. 10

Time-setting options 12

Baking and roasting assistant .. 13

Childproof lock 14

Rapid heat-up .. 14

Sabbath mode. 15

Basic settings .. 15

Cleaning and servicing .. 16

Cleaning functions 18

Rails .. 20

Appliance door 20

Troubleshooting. 25

Disposal .. 27

Customer Service .. 27

How it works. 27

INSTALLATION INSTRUCTIONS .. 32

22.1 General installation instructions .. 32

1 Safety

Observe the following safety instructions.

1.1 General information ¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the

¡ Do not connect the appliance if it has been

1.2 Intended use This appliance is designed only to be built into kitchen units. Read the special installation instructions.

Only a licensed professional may connect ap pliances without plugs. Damage caused by in correct connection is not covered under the warranty.

Only use this appliance: ¡ To prepare meals and drinks. ¡ In private households and in enclosed

¡ Up to an altitude of max. 4000 m above

1.3 Restriction on user group This appliance may be used by children aged 8 or over and by people who have reduced physical. sensory or mental abilities or inad equate experience and/or knowledge. provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers.

Do not let children play with the appliance.

Children must not perform cleaning or user maintenance unless they are at least 15 years old and are being supervised.

Keep children under the age of 8 years away from the appliance and power cable.

1.4 Safe use Always place accessories in the cooking com partment the right way round. → "Accessories". Page 8

WARNING ‒ Risk of fire!

Combustible objects that are left in the cook ing compartment may catch fire. ▶ Never store combustible objects in the

▶ If smoke is emitted. the appliance must be

Loose food remnants. fat and meat juices may catch fire. ▶ Before using the appliance. remove the

Safety en

Opening the appliance door creates a draught. Greaseproof paper may come into contact with the heating element and catch fire. ▶ Never place greaseproof paper loosely

▶ Always cut greaseproof paper to size and

WARNING ‒ Risk of burns!

The appliance and its parts that can be touched become hot during use. ▶ Caution should be exercised here in order

▶ Young children under 8 years of age must

Accessories and cookware get very hot. ▶ Always use oven gloves to remove ac

When the cooking compartment is hot. any al coholic vapours inside may catch fire. ▶ Only use small quantities of drinks with a

▶ Open the appliance door carefully.

WARNING ‒ Risk of scalding!

The accessible parts of the appliance become hot during operation. ▶ Never touch these hot parts. ▶ Keep children at a safe distance.

Hot steam may escape when you open the appliance door. Steam may not be visible. de pending on the temperature. ▶ Open the appliance door carefully. ▶ Keep children at a safe distance.

If there is water in the cooking compartment when it is hot. this may create hot steam. ▶ Never pour water into the cooking compart

WARNING ‒ Risk of injury!

Scratched glass in the appliance door may develop into a crack. ▶ Do not use any harsh or abrasive cleaners

The appliance and its parts that can be touched may have sharp edges. ▶ Take care when handling and cleaning

▶ If possible. wear protective gloves.

The hinges on the appliance door move when the door is opened and closed. which could trap your fingers. ▶ Keep your hands away from the hinges.

Components inside the appliance door may have sharp edges. ▶ Wear protective gloves.

WARNING ‒ Risk of electric shock!

Incorrect repairs are dangerous. ▶ Repairs to the appliance should only be

▶ Only use genuine spare parts when repair

▶ If the power cord of this appliance is dam

If the insulation of the power cord is dam aged. this is dangerous. ▶ Never let the power cord come into contact

▶ Never let the power cord come into contact

▶ Never kink. crush or modify the power

An ingress of moisture can cause an electric shock. ▶ Do not use steam- or high-pressure clean

If the appliance or the power cord is dam aged. this is dangerous. ▶ Never operate a damaged appliance. ▶ Never pull on the power cord to unplug the

▶ If the appliance or the power cord is dam

▶ Call customer services. → Page 27

WARNING ‒ Danger: Magnetism!

Permanent magnets are used in the control panel or in the controls. These may affect electronic implants. e.g. heart pacemakers or insulin pumps. ▶ Wearers of electronic implants must stay at

WARNING ‒ Risk of suffocation!

Children may put packaging material over their heads or wrap themselves up in it and suffocate. ▶ Keep packaging material away from chil

▶ Do not let children play with packaging ma

Children may breathe in or swallow small parts. causing them to suffocate. ▶ Keep small parts away from children. ▶ Do not let children play with small parts.

1.5 Halogen bulb

WARNING ‒ Risk of burns!

The bulbs in the cooking compartment get very hot. There is still a risk of burning for some time after they have been switched off. ▶ Do not touch the glass cover. ▶ Avoid contact with your skin when cleaning.

WARNING ‒ Risk of electric shock!

When changing the bulb. the bulb socket con tacts are live. ▶ Before replacing the bulb. ensure that the

▶ Also unplug the appliance from the mains

1.6 Cleaning function

WARNING ‒ Risk of fire!

Loose food remnants. fat and meat juices may catch fire when the cleaning function is in progress. ▶ Before starting the cleaning function. al

The outside of the appliance gets very hot when the cleaning function is in progress. ▶ Never hang combustible objects. e.g. tea

▶ Leave the front of the appliance clear. ▶ Keep children at a safe distance.

If the door seal is damaged. a large amount of heat is generated around the door. ▶ Do not scrub or remove the seal. ▶ Never operate the appliance if the seal is

WARNING ‒ Risk of serious harm to

▶ Only clean enamelled accessories at the

WARNING ‒ Risk of harm to health!

The cleaning function heats up the cooking compartment to a very high temperature so that food left over from roasting. grilling and baking will burn off. This process releases va pours. which can irritate mucous membranes. ▶ Keep the kitchen well ventilated while the

▶ Do not remain in the room for long periods. ▶ Keep children and pets away.

WARNING ‒ Risk of burns!

The cooking compartment gets very hot when the cleaning function is in progress. ▶ Never open the appliance door. ▶ Allow the appliance to cool down. ▶ Keep children at a safe distance.

The outside of the appliance gets very hot

Preventing material damage en

2 Preventing material damage

2.1 General

ATTENTION!

Objects on the cooking compartment floor at over 50 °C will cause heat to build up. The baking and roasting times will no longer be correct and the enamel will be damaged. Do not place any accessories. greaseproof paper or foil of any kind on the cooking compartment floor.

Only place cookware on the cooking compartment floor if a temperature above 50 °C has been set.

When the cooking compartment is hot. any water in side it will create steam. The change in temperature may cause damage. Never pour water into the cooking compartment when it is still hot.

Never place cookware containing water on the cooking compartment floor.

The prolonged presence of moisture in the cooking compartment leads to corrosion. Allow the cooking compartment to dry after use.

Do not keep moist food in the cooking compartment for a long time with the door closed.

Do not store food in the cooking compartment.

Leaving the appliance to cool down with the door open will damage the front of neighbouring kitchen units over time. Always allow the cooking compartment to cool down with the door closed after cooking at high temperatures.

Take care not to trap anything in the appliance door.

Only leave the cooking compartment to dry with the door open if a lot of moisture was produced during operation.

Fruit juice dripping from the baking tray leaves stains that cannot be removed. When baking very juicy fruit flans. do not pack too much on the baking tray.

If possible. use the deeper universal pan.

Using oven cleaner in a hot cooking compartment damages the enamel. Never use oven cleaner in the cooking compartment when it is still warm.

Remove all food remnants from the cooking com partment and the appliance door before you next heat up the appliance.

If the seal is very dirty. the appliance door will no longer close properly during operation. This may dam age the front of adjacent kitchen units. Keep the seal clean at all times.

Never operate the appliance if the seal is damaged or missing.

Sitting or placing objects on the appliance door may damage it. Do not place or hang objects on the appliance door.

Do not place cookware or accessories on the appli ance door.

With certain models. accessories may scratch the door pane when closing the appliance door. Always push accessories fully into the cooking com partment.

3 Environmental protection and saving energy

3.1 Disposing of packaging

The packaging materials are environmentally compat ible and can be recycled. Sort the individual components by type and dispose of them separately.

3.2 Saving energy

If you follow these instructions. your appliance will use less power.

Only preheat the appliance if the recipe or the recom mended settings tell you to do so. ¡ Not preheating the appliance can reduce the en

Use dark-coloured. black-coated or enamelled baking tins. ¡ These types of baking tin absorb the heat particu

Open the appliance door as little as possible during operation. ¡ This maintains the temperature in the cooking com

When baking multiple dishes. do so in succession or in parallel. ¡ The cooking compartment is heated after baking

If the cooking time is relatively long. you can switch the appliance off 10 minutes before the cooking time ends. ¡ There will be enough residual heat to finish cooking

Remove any accessories that are not being used from the cooking compartment. ¡ Accessories that are not being used do not need to

Allow frozen food to defrost before cooking. ¡ This saves the energy that would otherwise be re

Note: The appliance requires: A maximum of 1 W when the appliance is in opera tion with the display switched on

A maximum of 0.5 W when the appliance is in oper ation with the display switched off

4 Familiarising yourself with your appliance

4.1 Control panel

You can use the control panel to configure all functions of your appliance and to obtain information about the operat ing status.

Display Buttons

Control element

4.2 Buttons

The buttons are touch-sensitive areas. To select a function. press the corresponding button.

Symbol Name Use

On/off Switch the appliance on or off

Main menu Select operating modes and settings

Time-setting options/ childproof lock

Set the "timer". "cooking time" or "Ready at" time for delayed starts

Activate or deactivate the "childproof lock"

Information View additional information

View the current temperature

Rapid heat-up Activate or deactivate the "Rapid heat-up" function

Activate or deactivate the "PowerBoost" function

Start/stop Start or pause the appliance

Familiarising yourself with your appliance en

4.3 Control element

You can configure all the functions on your appliance using the control element. You can change the setting values that are displayed more brightly.

Press and hold a button to scroll through the setting values quickly. Release the button to stop scrolling quickly.

Button Name Use

Left Navigate to the left on the display

Right Navigate to the right on the display

Up Navigate upwards on the display

Down Navigate downwards on the display

4.4 Display

The display shows the current settings. options or rel evant information.

4.5 Main menu

The main menu provides an overview of your appliance's functions.

Press the ​⁠ button to open the main menu.

Function Name Use

Heating functions Select the required heating function and temperature for your food

Baking and roasting assistant

Recommended settings for baking and roasting

MyProfile Individually adjust the appliance settings

EasyClean Clean less stubborn dirt from the cooking compartment

Pyrolytic self-cleaning Clean the cooking compartment

4.6 Types of heating

This is where you will find an overview of the types of heating. You will find recommendations for using the types of heating.

For temperatures above 275 °C. the appliance reduces the temperature to approx. 275 °C after around 40 minutes.

Symbol Heating function Temperature Use

CircoTherm hot air 40 - 200 °C Bake or roast on one or more levels.

The fan distributes the heat from the ring-shaped heating ele ment in the back wall evenly around the cooking compartment.

Top/bottom heating 50 - 275 °C Traditionally bake or roast on one level. This type of heating is especially good for cakes with moist toppings.

The heat is emitted evenly from above and below.

Circo-roasting 50 - 250 °C Roast poultry. whole fish or larger pieces of meat.

The grill element and the fan switch on and off alternately. The fan circulates the hot air around the food.

CircoTherm Intensive 50 - 275 °C Cook pizza or food that requires a lot of heat from below.

The bottom heating element and the ring-shaped heating ele ment in the back wall heat the cooking compartment.

Bread-baking setting 180 - 240 °C For baking bread. bread rolls and baked goods that require high temperatures.

Grill. large area 50 - 290 °C For grilling flat items such as steaks. sausages or bread. and for cooking au gratin.

The entire area below the grill element becomes hot.

Grill. small area 50 - 290 °C For grilling small amounts of steaks. sausages or bread. and for cooking au gratin.

The central area below the grill element becomes hot.

Symbol Heating function Temperature Use

Bottom heating 50 - 250 °C For cooking in a bain marie and for baking food for extra time.

The heat is emitted from below.

Low Temperature Cooking

70 - 120 °C For gentle. low temperature cooking of seared. tender pieces of meat in cookware without a lid.

The heat is emitted evenly from above and below at a low tem perature.

Dough proving 35 - 55 °C For proving dough and culturing yoghurt.

Dough will prove more quickly than at room temperature. The surface of the dough does not dry out.

Defrost 30 - 60 °C For gently defrosting frozen food.

Top/bottom heating eco

50 - 275 °C For gently cooking selected types of food.

Heat is emitted from above and below.

This type of heating is most effective between 150 and 250 °C.

This type of heating is used to determine the energy consump tion in the conventional mode.

CircoTherm eco 40 - 200 °C For gently cooking selected types of food on one level without preheating.

The fan distributes the heat from the ring-shaped heating ele ment in the back wall around the cooking compartment.

This type of heating is most effective between 125 and 200 °C.

This type of heating is used to determine the energy consump tion in circulating-air mode and the energy efficiency class.

4.7 Cooking compartment

The functions in the cooking compartment make your appliance easier to use.

Shelf supports The rails in the cooking compartment enable you to place accessories at different heights. → "Accessories". Page 8 Your appliance has four shelf positions. The shelf posi tions are numbered from bottom to top.

You can remove the rails. e.g. for cleaning. → "Rails". Page 20

Lighting One or more oven lights illuminate the cooking com partment.

When you open the appliance door. the light in the cooking compartment switches on. If the appliance door remains open for longer than 15 minutes. the light switches off again.

For most operating modes. the lighting is switched on during operation. The lighting switches off again when the operation ends.

Cooling fan The cooling fan switches on and off depending on the appliance's temperature. The hot air escapes above the door.

ATTENTION!

Do not cover the ventilation slot above the appliance door. The appliance overheats. Ensure that the ventilation slots are unobstructed.

To ensure that the appliance cools down more quickly after operation. the cooling fan continues to run for a certain period afterwards.

Appliance door If you open the appliance door during operation. the operation stops. When you close the appliance door. the operation continues automatically.

5 Accessories

Use original accessories. These have been made espe cially for your appliance.

Note: Accessories may become deformed if they get hot. Deformation has no effect on function. As the ac cessory cools down. it will regain its original shape.

The accessories supplied may differ depending on the appliance model.

Accessories en

Accessories Use

Wire rack Cake tins

Ovenproof dishes

Cookware

Meat. e.g. roasting joints or steak

Frozen meals

Universal pan Moist cakes

Baked items

Bread

Large roasts

Frozen meals

Catch dripping liquids. e.g. fat when grilling food on the wire rack.

Baking tray Tray bakes

Small baked items

Accessory support When using the cleaning function. you can accessories at the same time. e.g. the univer sal pan. → "Self-cleaning function". Page 18

5.1 Locking function

The locking function prevents the accessories from tilt ing when they are pulled out.

You can pull out the accessories approximately halfway without them tipping. The accessories must be inserted into the cooking compartment correctly for the tilt pro tection to work properly.

5.2 Sliding accessories into the cooking compartment

Always slide the accessory into the cooking compart ment the right way round. This is the only way to en sure that accessories can be pulled out approximately halfway without tipping.

1. Turn the accessories so that the notch ​⁠ is at the

2. Insert the accessory between the two guide rods for

Wire rack Insert the wire rack with the open side facing the appliance door and the curved lip ​⁠ facing downwards.

Baking tray E.g. univer sal pan or baking tray

Slide the tray in with the sloping edge ​⁠ towards the appliance door.

3. Push the accessory all the way in. making sure that

Note: Take any accessories that you will not be using out of the cooking compartment while the appliance is in operation.

Combining accessories You can combine the wire rack with the universal pan to catch any liquid that drips down.

1. Place the wire rack on the universal pan so that

2. Insert the universal pan between the two guide rods

Wire rack on univer sal pan

5.3 Other accessories

You can purchase other accessories from our after sales service. specialist retailers or online.

You will find a comprehensive range of products for your appliance in our brochures and online: www.neff-international.com Accessories vary from one appliance to another. When purchasing accessories. always quote the exact product number (E no.) of your appliance.

You can find out which accessories are available for your appliance in our online shop or from our after sales service.

6 Before using for the first time

Configure the settings for initial start-up. Clean the ap pliance and accessories.

6.1 Initial use

When the appliance is connected to the power supply for the first time or following a lengthy power failure. the settings that you will need to configure before you can use it will appear.

Note: You can change these settings at any time by going to the basic settings. → "Basic settings". Page 15

Setting the language 1. Connect the appliance to the power supply. a The first setting will appear after a few seconds.

2. Use the ​⁠ button to navigate to the bottom row.

3. Use the ​⁠ or ​⁠ button to select the language.

4. Use the ​⁠ button to navigate back to the top row.

5. Use the ​⁠ button to select the next setting.

Setting the time 1. Use the ​⁠ button to navigate to the bottom row.

2. Use the ​⁠ or ​⁠ button to select the correct hour.

3. Use the ​⁠ button to navigate to the next row.

4. Use the ​⁠ or ​⁠ button to select the correct number of

5. Use the ​⁠ button to navigate back to the top row.

6. Use the ​⁠ button to select the next setting.

Setting the date 1. Use the ​⁠ button to navigate to the next row.

2. Use the ​⁠ or ​⁠ button to select the correct day.

3. Use the ​⁠ button to navigate to the next row.

4. Use the ​⁠ or ​⁠ button to select the correct month.

5. Use the ​⁠ button to navigate to the next row.

6. Use the ​⁠ or ​⁠ button to select the correct year.

7. Press the ​⁠ button repeatedly until "Date" appears.

8. Use the ​⁠ button to apply the settings.

9. Open and close the appliance door once. a The appliance will perform a self-test. after which it

6.2 Cleaning the appliance

Before using the appliance to cook food for the first time. you must clean the cooking compartment and ac cessories.

1. Remove the product information. accessories and

2. Wipe the smooth surfaces in the cooking compart

3. Press ​⁠ to switch the appliance on.

→ "Switching on the appliance". Page 10

4. Set the required heating function and temperature

→ "Setting the type of heating and temperature".

Page 11

Heating up Heating function CircoTherm hot air

Temperature Maximum

Cooking time 1 hour

5. Keep the kitchen ventilated while the appliance is

6. Press ​⁠ to switch off the appliance after 1 hour.

→ "Switching off the appliance". Page 11

7. Allow the appliance to cool down.

8. Clean the smooth surfaces with soapy water and a

9. Thoroughly clean any accessories you used with

7 Basic operation

7.1 Switching on the appliance

Press ​⁠ to switch the appliance on.

Notes In the basic settings. you can specify whether the heating functions or the main menu should appear when you switch on the appliance. → "Basic settings". Page 15

Basic operation en

If you do not perform any actions on the appliance for an extended period. it will automatically switch it self off.

7.2 Switching off the appliance

Press ​⁠ to switch the appliance off.

Notes The residual heat indicator will appear on the dis play while the cooking compartment is still hot. → "Residual heat indicator". Page 11

The cooling fan will continue to run until the cooking compartment has cooled down. → "Cooling fan". Page 8

7.3 Residual heat indicator

After you have switched off the appliance. the residual heat indicator will appear on the display.

Display Temperature

Residual heat high Over 120 °C

Residual heat low Between 60 and 120 °C

7.4 Setting the type of heating and temperature

1. Press ​⁠ to switch the appliance on.

3. Use the ​⁠ button to navigate to the next row.

4. Use the ​⁠ or ​⁠ button to select the required temperat

5. Press ​⁠ to start.

6. When the food is ready. press ​⁠ to switch the appli

7.5 Changing the temperature

You can also change the temperature once you have started the appliance.

1. Use the ​⁠ or ​⁠ button to select the temperature

2. Use the ​⁠ or ​⁠ button to select the required temperat

7.6 Changing the type of heating

If you switch to a different heating function. the appli ance will reset all the settings.

1. Press ​⁠ to pause operation.

2. Use the ​⁠ or ​⁠ button to select the required heating

3. Use the ​⁠ button to navigate to the next row.

4. Use the ​⁠ or ​⁠ button to select the required temperat

5. Press ​⁠ to start.

7.7 Pausing operation

1. Press

2. Press ​⁠ again to resume operation.

7.8 Cancelling operation

Note: Some functions. e.g. cleaning functions. cannot be cancelled.

Press and hold the ​⁠ button until the function that is

7.9 Viewing the current temperature

You can view the current temperature while the appli ance is heating up. Press ​⁠.

7.10 Displaying information

Requirement: The ​⁠ button must be lit. Press ​⁠.

8 Time-setting options

Your appliance has different time-setting options. with which you can control its operation.

8.1 Overview of the time-setting options

When you are setting a time. the time values will in crease by greater increments as you scroll through the higher values. The cooking time. for example. can be set in 1-minute increments up to 1 hour. and then in 5 minute increments thereafter.

Time-setting option

Timer ​⁠ When you set a time on the timer. the timer will run independently of the appliance and will not intervene in its operation. The timer does not affect the appliance.

Cooking time

Once the cooking time has elapsed. the appliance automatically stops heating.

Ready at ​⁠ Along with the cooking time (dura tion). you can set the time at which you want cooking to end. The appli ance will start up automatically so that it finishes cooking at the re quired time.

8.2 Timer

You can set the timer regardless of whether the appli ance is on or off.

Setting the timer 1. Press

2. Once the appliance is switched on. use the

​⁠ button to select "Timer" ​⁠.

3. Use the ​⁠ or ​⁠ button to select the timer duration.

4. Press ​⁠ to start the timer.

​⁠ will appear on the display. The timer duration will

5. Press any button to end the audible signal.

Changing the timer 1. Press

2. Use the ​⁠ or ​⁠ button to change the timer duration. a The setting will then be applied.

Cancelling the timer 1. Press

2. Use the ​⁠ button to set a timer duration of "00:00". a This cancels the current timer duration.

8.3 Cooking time

Once the set cooking time has elapsed. the appliance switches off automatically. You can only use the cook ing time in conjunction with a heating function.

Setting the cooking time 1. Set a heating function and a temperature.

2. Press

3. Select the default value.

Button Default value

​⁠10 minutes

​⁠30 minutes

4. Use the ​⁠ or ​⁠ button to select the required cooking

5. Once the cooking time has been set. press ​⁠ to

6. Press any button to end the audible signal.

Changing the cooking time 1. Press

2. Use the ​⁠ or ​⁠ button to change the cooking time. a The setting will then be applied.

Cancelling the cooking time 1. Press

2. Use the ​⁠ button to set a cooking time of "00:00". a This cancels the current cooking time.

3. To continue without setting a cooking time. press

8.4 Delayed start/"Ready at" time

With this function. the appliance automatically switches itself on. and then switches itself off at the preselected end time. To enable it to do this. you set the cooking time (duration) and specify when you want your food to be ready. You can only use the delayed start function in conjunction with a heating function.

Setting the Ready at time for delayed starts Notes Do not leave food that spoils easily in the cooking compartment for too long.

You cannot use the delayed start function with every heating function.

1. Place the food into the cooking compartment and

2. Set a heating function and a temperature.

3. Press

4. Use the ​⁠ or ​⁠ button to select the required cooking

5. Use the ​⁠ button to navigate to "Ready at" ​⁠.

6. Use the ​⁠ button to select the required end time.

7. Press ​⁠ to confirm the delayed start.

8. Press any button to end the audible signal.

Changing the Ready at time for delayed starts 1. Press

2. Use the ​⁠ button to select "Ready at" ​⁠.

Baking and roasting assistant en

3. Use the ​⁠ or ​⁠ button to change the end time. a The setting will then be applied.

Cancelling the Ready at time for delayed starts 1. Press

2. Use the ​⁠ button to reset the end time. a The end time corresponds to the current time plus

9 Baking and roasting assistant

The baking and roasting assistant helps you to use your appliance to cook various dishes by suggesting the optimal settings.

The baking and roasting assistant helps you to make classic cakes. bread and roasts. The appliance selects the optimal heating function for you. The default tem perature and cooking time can be changed according to your requirements.

9.1 Overview of available foods

You can choose from the following foods: Sponge in a springform tin/loaf tin

Sponge (6 eggs)

Swiss roll

Yeast dough tray bakes with dry topping

Plaited ring/loaf

Small baked puff-pastry items

Muffins. on one level

White bread in a loaf tin

Part-baked bread rolls/baguettes

Pizza. frozen. thin base. x 1

Chips. frozen. on one level

Potato gratin. made from raw potatoes

Baked potatoes

Lasagne. fresh

Joint of pork. marbled. without rind

Meat loaf (1 kg)

Sirloin. medium. 1.5 kg

Beef pot roast

Leg of lamb. boned

Chicken. whole

Chicken legs

Goose. whole (3-4 kg)

9.2 Configuring the baking and roasting assistant

Note: Use fresh and. ideally. chilled food. Use frozen food straight from the freezer.

Requirement: The cooking compartment must have cooled down.

1. Press ​⁠ to switch the appliance on.

2. Press

3. Use the ​⁠ or ​⁠ button to select the "Baking and roast

4. Use the ​⁠ button to navigate to the next row.

5. Use the ​⁠ or ​⁠ button to select the required category.

6. Use the ​⁠ button to navigate to the next row.

7. Use the ​⁠ or ​⁠ button to select the required food.

8. Use the ​⁠ button to navigate to the next row.

9. Note: Additional information cannot be selected for

10. Use the ​⁠ button to navigate back to the recommen

11. Use the ​⁠ button to adjust the temperature or cook

Use the ​⁠ or ​⁠ button to change the setting.

12. Press ​⁠ to start the baking and roasting assistant.

13. Note: Some programs allow you to extend the cook

​⁠ button to select "End".

9.3 Extending the cooking time

1. Use the ​⁠ button to select "Extend cooking time".

2. Use the ​⁠ or ​⁠ button to change the settings. if re

3. Press ​⁠ to start the appliance again for the extra

10 Childproof lock

You can secure your appliance to prevent children from accidentally switching it on or changing the set tings.

10.1 Locks

Your appliance has two different locks:

Lock Activate/deactivate

Automatic childproof lock Via the MyProfile menu

One-time childproof lock Using the ​⁠ button

10.2 Activating the automatic childproof lock

The automatic childproof lock disables the control panel to prevent children from accidentally switching on the appliance. To switch on the appliance. interrupt the automatic childproof lock. Once the appliance has finished cooking. it automatically disables the control panel.

Note: When you activate the automatic childproof lock. the appliance will immediately disable the control panel. The ​⁠ and ​⁠ buttons will not be disabled.

Requirement: The appliance must be switched on.

1. Press

2. Use the ​⁠ or ​⁠ button to select "MyProfile"

3. Use the ​⁠ button to navigate to the next row.

4. Use the ​⁠ or ​⁠ button to select "Automatic childproof

5. Use the ​⁠ button to select the required settings.

6. Use the ​⁠ button to set the lock to "Activated".

7. Press

8. Use the ​⁠ button to save your settings.

10.3 Interrupting the automatic childproof lock

1. Press and hold the ​⁠ button until "Childproof lock

2. Press ​⁠ to switch the appliance on and then start it

10.4 Deactivating the automatic childproof lock

1. Press and hold the ​⁠ button until "Childproof lock

2. Press ​⁠ to switch the appliance on.

3. Press

4. Use the ​⁠ or ​⁠ button to select "MyProfile"

5. Use the ​⁠ button to navigate to the next row.

6. Use the ​⁠ or ​⁠ button to select "Automatic childproof

7. Use the ​⁠ button to select the required settings.

8. Use the ​⁠ button to set the lock to "Deactivated".

9. Press

10. Use the ​⁠ button to save your settings.

10.5 Activating the one-time childproof lock

The one-time childproof lock disables the control panel to prevent children from accidentally switching on the appliance. To switch on the appliance. deactivate the one-time childproof lock. After you have switched off the appliance. the control panel will no longer be dis abled.

Note: When you activate the automatic childproof lock. the appliance will immediately disable the control panel. The ​⁠ and ​⁠ buttons will not be disabled.

Press and hold the ​⁠ button until "Childproof lock

10.6 Deactivating the one-time childproof lock

Press and hold the ​⁠ button until "Childproof lock

11 Rapid heat-up

You can use the "Rapid heat-up" and "PowerBoost" functions to reduce the heat-up time. Whether the appliance is preheated with the "Rapid heat-up" function or the "PowerBoost" function depends on the heating function that has been set.

11.1 Rapid heat-up and PowerBoost

Function Heating function Food in the cooking compartment

Rapid heat-up Top/bottom heating ​⁠After preheating

PowerBoost CircoTherm hot air

Bread-baking setting

Before heating up Only cook on one level

Sabbath mode en

11.2 Activating the "Rapid heat-up" function

1. Set Top/bottom heating ​⁠ and a temperature of at

2. Press ​⁠ to start.

3. Use the ​⁠ button to activate the "Rapid heat-up"

​⁠ will appear on the display.

"Rapid heat-up" function will switch itself off auto matically and an audible signal will sound. ​⁠ will go

4. Place the food in the cooking compartment.

11.3 Deactivating the "Rapid heat-up" function

Use the ​⁠ button to deactivate the "Rapid heat-up"

11.4 Activating the "PowerBoost" function

1. Place the food on a single level in the cooking com

2. Set CircoTherm hot air ​⁠ or the Bread-baking

3. Press ​⁠ to start.

4. Press the ​⁠ button to activate the "PowerBoost"

​⁠ will appear on the display.

"PowerBoost" function will switch itself off automatic ally and an audible signal will sound. ​⁠ will go out

11.5 Deactivating the "PowerBoost" function

Use the ​⁠ button to deactivate the "PowerBoost"

12 Sabbath mode

You can set a cooking time of up to 74 hours using Sabbath mode. You can use top/bottom heating to keep food warm between 85 °C and 140 °C during this time without having to switch the appliance on or off.

12.1 Starting Sabbath mode

Notes If you open the appliance door during operation. the appliance stops heating. When you close the appli ance door. the appliance continues to heat again.

Once you have started the operation. you cannot change any settings or pause operation.

Requirement: Sabbath mode must be activated in "Fa vourites" in the basic settings. → "Basic settings". Page 15 1. Press ​⁠ to switch the appliance on.

2. Use ​⁠ or ​⁠ to select "Sabbath mode".

3. Use ​⁠ to navigate to the next row.

4. Use ​⁠ or ​⁠ to select the temperature.

5. Use ​⁠ to navigate to the next row.

6. Use ​⁠ or ​⁠ to select the cooking time.

7. Press ​⁠ to start Sabbath mode.

8. Once the cooking time has elapsed. an audible sig

The appliance automatically switches off after ap prox. 10 to 20 minutes.

12.2 Cancelling Sabbath mode

Press ​⁠ to cancel Sabbath mode.

13 Basic settings

You can configure the appliance to meet your needs.

13.1 Overview of the basic settings

Here you can find an overview of the basic settings and factory settings. The basic settings depend on the features of your appliance.

Basic setting Selection

Language See selection on the appliance

Time 00:00 - 23:59

Date Day. month and year

1 Depending on the appliance specifications

Basic setting Selection

Favourites → "Changing your favourites".

Page 16

Set the heating functions that you want to appear in the heat ing functions menu

Audible signal Short duration

Medium duration

Long duration

Button tone Off (except for

Display brightness 5 settings

Clock display Digital

1 Depending on the appliance specifications

Basic setting Selection

Lighting On during operation

Off during operation

Childproof lock Button lock only

Door lock and button lock

Automatic childproof lock

Deactivated

Activated

Operation after switch-on

Main menu

Types of heating

Baking and roasting assist ant

Night-time dimming Switched off

On (display dimmed between 10 p.m. and 5.59 a.m.)

Brand logo Indicators/symbols

Do not display

Fan run-on time Recommended

Minimum

Pull-out rail system1 Not retrofitted (rack or single set of pull-out rails)

Retrofitted (two or three sets of pull-out rails)

Factory settings Restore

1 Depending on the appliance specifications

13.2 Changing MyProfile

1. Press ​⁠ to switch the appliance on.

2. Press

3. Use the ​⁠ or ​⁠ button to select "MyProfile"

4. Use the ​⁠ button to navigate to the next row.

5. Use the ​⁠ or ​⁠ button to select a setting.

6. Use the ​⁠ button to navigate to the next row.

7. Use the ​⁠ or ​⁠ button to change the setting.

8. Press

9. To save your settings. use the ​⁠ button to select

"Save". To discard your settings. use the ​⁠ button to se

13.3 Changing your favourites

In Favourites. you can set the heating functions that you want to appear in the heating functions menu.

Note: Some heating functions cannot be deactivated: CircoTherm hot air

Circo-roasting

Full-surface grill

1. Press ​⁠ to switch the appliance on.

2. Press

3. Use the ​⁠ or ​⁠ button to select "MyProfile"

4. Use the ​⁠ button to navigate to the next row.

5. Use the ​⁠ or ​⁠ button to select "Favourites".

6. Use the ​⁠ button to select "Set favourites".

7. Use the ​⁠ or ​⁠ button to select the required heating

8. Use the ​⁠ button to navigate to the next row.

9. Use the ​⁠ or ​⁠ button to select a setting.

Setting Display in the heating func tions menu?

Activated Yes

Deactivated No

10. Press

11. To save your settings. use the ​⁠ button to select

"Save". To discard your settings. use the ​⁠ button to se

14 Cleaning and servicing

To keep your appliance working efficiently for a long time. it is important to clean and maintain it carefully.

14.1 Cleaning products

In order to avoid damaging the various oven surfaces on the appliance. do not use unsuitable cleaning products.

WARNING ‒ Risk of electric shock!

An ingress of moisture can cause an electric shock. Do not use steam- or high-pressure cleaners to clean the appliance.

ATTENTION!

Unsuitable cleaning products may damage the sur faces of the appliance. Do not use harsh or abrasive cleaning products.

Do not use cleaning products with a high alcohol content.

Do not use hard scouring pads or cleaning sponges.

Do not use any special cleaners for cleaning the ap pliance while it is hot.

Using oven cleaner in a hot cooking compartment damages the enamel. Never use oven cleaner in the cooking compartment when it is still warm.

Remove all food remnants from the cooking com partment and the appliance door before you next heat up the appliance.

New sponge cloths contain residues from production. Wash new sponge cloths thoroughly before use.

Cleaning and servicing en

Suitable cleaning agents Only use cleaning agents that are suitable for the differ ent surfaces on your appliance.

Follow the instructions on cleaning the appliance. → "Cleaning the appliance". Page 18

Appliance front

Surface Suitable cleaning agents Information

Stainless steel Hot soapy water

Special stainless steel cleaning products suitable for hot sur faces

To prevent corrosion. remove any limescale. grease. starch or albu min (e.g. egg white) stains on stainless steel fronts immediately.

Apply a thin layer of the stainless steel cleaning product with a soft cloth.

Plastic or painted surfaces E.g. control panel

Hot soapy water Do not use glass cleaner or a glass scraper.

To avoid permanent stains. remove any descaling agent that gets onto the surface immediately.

Appliance door

Area Suitable cleaning agents Information

Door panels Hot soapy water Do not use a glass scraper or a stainless steel wool.

Tip: Remove the door panels in order to clean them thoroughly. → "Appliance door". Page 20

Door cover Made of stainless steel: Stainless steel cleaner

Made of plastic: Hot soapy water

Do not use glass cleaner or a glass scraper.

Do not use stainless steel care products.

Tip: Remove the door cover for thorough cleaning. → "Appliance door". Page 20

Stainless steel in terior door frame

Stainless steel cleaner Discolouration can be removed using stainless steel cleaner.

Do not use stainless steel care products.

Door handle Hot soapy water To avoid permanent stains. remove any descaling agent that gets onto the surface immediately.

Door seal Hot soapy water Do not remove or scrub.

Cooking compartment

Area Suitable cleaning agents Information

Enamel surfaces Hot soapy water

Vinegar water

Oven cleaner

Soak any heavily soiled areas and use a brush or steel wool.

Leave the appliance door open to dry the cooking compartment after cleaning it.

Notes It is best to use the cleaning function. → "Self-cleaning function". Page 18

Enamel burns at very high temperatures. causing minor discol ouration. The functionality of your appliance is not affected by this.

The edges of thin trays cannot be completely enamelled and may be rough. This does not impair corrosion protection.

Food residues will leave a white coating on the enamel surfaces.

The coating does not pose a health risk. The functionality of your appliance is not affected by this. You can remove residues with lemon juice.

Glass cover for the oven light

Hot soapy water Use oven cleaner to remove very heavy soiling.

Rails Hot soapy water Soak any heavily soiled areas and use a brush or steel wool.

Note: To clean thoroughly. detach the rails. → "Rails". Page 20

Accessories Hot soapy water

Oven cleaner

Soak any heavily soiled areas and use a brush or steel wool.

Enamelled accessories are dishwasher-safe.

14.2 Cleaning the appliance

In order to avoid damaging the appliance. you must clean your appliance only as specified. and with suit able cleaning products.

WARNING ‒ Risk of burns!

The appliance and its parts that can be touched be come hot during use. Caution should be exercised here in order to avoid touching heating elements.

Young children under 8 years of age must be kept away from the appliance.

WARNING ‒ Risk of fire!

Loose food remnants. fat and meat juices may catch fire. Before using the appliance. remove the worst of the food residues and remnants from the cooking com partment. heating elements and accessories.

Requirement: Read the information on cleaning products. → "Cleaning products". Page 16 1. Clean the appliance using hot soapy water and a

2. Dry with a soft cloth.

15 Cleaning functions

You can use the cleaning functions to clean the appli ance.

15.1 Self-cleaning function

The "Self-cleaning" function cleans the cooking com partment virtually automatically.

Use this cleaning function to clean the cooking com partment every 2 to 3 months. You can use the clean ing function more often. if required. The cleaning func tion requires approx. 2.5 - 4.7 kilowatt hours.

Preparing the appliance for the cleaning function To achieve a good cleaning result and prevent dam age. prepare the appliance carefully.

WARNING ‒ Risk of fire!

Combustible objects that are left in the cooking com partment may catch fire. Never store combustible objects in the cooking compartment.

If smoke is emitted. the appliance must be switched off or the plug must be pulled out and the door must be held closed in order to stifle any flames.

Loose food remnants. fat and meat juices may catch fire when the cleaning function is in progress. Before starting the cleaning function. always remove the worst of the food residues and remnants from the cooking compartment and accessories.

The outside of the appliance gets very hot when the cleaning function is in progress. Never hang combustible objects. e.g. tea towels. on the door handle.

Leave the front of the appliance clear.

Keep children at a safe distance.

If the door seal is damaged. a large amount of heat is generated around the door. Do not scrub or remove the seal.

Never operate the appliance if the seal is damaged or missing.

1. Remove accessories and cookware from the cook

2. Detach the shelf supports and remove them from

3. Remove coarse dirt from the cooking compartment.

4. Use a detergent solution and a soft cloth to clean

5. Remove any objects from the cooking compartment.

The cooking compartment must be empty.

Using accessory supports With the accessory supports. you can clean an access ory at the same time when cleaning using the cleaning function.

1. Attach the accessory supports in the same way as

2. Remove coarse dirt from the accessory.

3. Place the accessory on the accessory supports.

Note: Only clean accessories that were included with the appliance and that are enamelled. e.g. the universal pan or the baking tray. Wire racks are not suitable for the cleaning function and will become discoloured.

Cleaning functions en

Configuring the Self-cleaning function

WARNING ‒ Risk of harm to health!

The cleaning function heats up the cooking compart ment to a very high temperature so that food left over from roasting. grilling and baking will burn off. This pro cess releases vapours. which can irritate mucous mem branes. Keep the kitchen well ventilated while the cleaning function is running.

Do not remain in the room for long periods.

Keep children and pets away.

WARNING ‒ Risk of burns!

The cooking compartment gets very hot when the cleaning function is in progress. Never open the appliance door.

Allow the appliance to cool down.

Keep children at a safe distance.

The outside of the appliance gets very hot when the

Allow the appliance to cool down.

Keep children at a safe distance.

Note: The oven light will not be lit while the cleaning function is running.

Requirement: → "Preparing the appliance for the cleaning function". Page 18.

1. Press ​⁠ to switch the appliance on.

2. Press

3. Use the ​⁠ or ​⁠ button to set "Self-cleaning"

4. Use the ​⁠ button to navigate to the next row.

5. Use the ​⁠ or ​⁠ button to select the cleaning setting.

Cleaning set ting

Cleaning level

Duration in hours

Low Approx. 1:15

Medium Approx. 1:30

High Approx. 2:00

Select a higher cleaning setting if the cooking com partment is particularly dirty or has not been cleaned for a while.

You cannot change the duration of the cleaning function.

Once the cleaning function is in progress. you can not change the cleaning setting.

6. Note: Keep the kitchen ventilated while the cleaning

7. Press ​⁠ to switch the appliance off.

The appliance door will remain locked until the ap pliance has cooled down sufficiently and ​⁠ has gone out.

8. After using the cleaning function. prepare the appli

Preparing the appliance for use following the cleaning function 1. Allow the appliance to cool down.

2. Wipe off any ash that has been left behind in the

3. Remove white residues with lemon juice.

Note: White residues on the enamel surfaces may be caused by heavy soiling. These food residues are harmless. The deposits do not compromise the functionality of the appliance.

4. Attach the shelf supports.

→ "Rails". Page 20

15.2 EasyClean cleaning aid

You can use the "EasyClean" cleaning aid to clean light soiling from the cooking compartment between full cleans. The "EasyClean" cleaning aid soaks dirt by evaporating soapy water. It is then easier to remove the dirt.

Setting the EasyClean cleaning aid

WARNING ‒ Risk of scalding!

If there is water in the cooking compartment when it is hot. this may create hot steam. Never pour water into the cooking compartment when the cooking compartment is hot.

Requirements ¡ You can only start the cleaning aid once the cooking

¡ Do not open the appliance door while the appliance

¡ To remove particularly stubborn dirt. leave the soapy

¡ To remove particularly stubborn dirt. rub washing-up

1. Remove any accessories from the cooking compart

2. ATTENTION!

Distilled water in the cooking compartment leads to corrosion. Do not use distilled water.

Mix 0.4 litres water with a drop of washing-up liquid and pour into the centre of the cooking compart ment floor.

3. Press ​⁠ to switch the appliance on.

4. Press

5. Use the ​⁠ or ​⁠ button to select "EasyClean"

6. Use the ​⁠ button to navigate to the next row.

7. Press ​⁠ to start the cleaning aid.

8. Press any button to end the audible signal.

9. After using the cleaning aid. finish cleaning the

Wiping down the cooking compartment ATTENTION!

The prolonged presence of moisture in the cooking compartment leads to corrosion. After using the cleaning aid. wipe the cooking com partment clean and allow it to dry fully.

Requirement: The cooking compartment must have cooled down.

1. Open the appliance door and remove the remaining

2. Clean the smooth surfaces in the cooking compart

3. Remove limescale with a cloth soaked in vinegar.

Then wipe with clean water and rub dry with a soft cloth (including under the door seal).

4. If there is any stubborn dirt that you are unable to

5. Leave the cooking compartment to dry with the ap

16 Rails

To thoroughly clean the rails and the cooking compart ment. or to replace the rails. you can remove the rails.

16.1 Detaching the rails

WARNING ‒ Risk of burns!

The shelf supports get very hot Never touch the shelf supports when hot.

Always allow the appliance to cool down.

Keep children at a safe distance.

1. Lift the rail forwards slightly ​⁠ and detach it

2. Pull the whole rail to the front ​⁠ and remove it.

3. Clean the rail.

→ "Cleaning products". Page 16

16.2 Attaching the rails

Notes The rails only fit on the right or left.

For both rails. ensure that the retaining bracket is at the front.

1. First. push the rail into the middle of the rear

2. Push the rail into the front socket ​⁠ until the rail

17 Appliance door

To clean the appliance door thoroughly. you can disas semble the appliance door.

WARNING ‒ Risk of injury!

If the hinges are not secured due to an incomplete lock. they can snap shut with great force. To detach or attach the appliance door. always turn the two locks as far as they will go.

If the hinge snaps closed when detaching or attach ing the appliance door. do not reach into the hinge – call the after-sales service.

17.1 Detaching the appliance door

Requirements ¡ Have a torch ready. ¡ Have a small slotted screwdriver ready. ¡ Have a coin ready.

1. To make it easier to see the door lock. shine the

Appliance door en

2. Hold the screwdriver horizontally ​⁠ and use it to

Door lock open

Door lock closed

3. Open the appliance door approx. 45° wide.

4. Insert the coin in the gap in the lock ​⁠ and rotate as

Turn the lock on the left-hand side in a clockwise direction.

Turn the lock on the right-hand side in an anti clockwise direction.

Left-hand lock secured The arrows point to each other

Left-hand lock released

5. ATTENTION!

Opening and closing the appliance door when it is in the lock position damages the door hinges. Never force the appliance door open or closed.

If the door hinge has been damaged. call the after-sales service.

Move the appliance door up and down until you hear a quiet click. You can still only move the appli ance door slightly.

WARNING ‒ Risk of injury!

The appliance door has a weight of 7–10 kg and may fall if it is not handled carefully. Handle the appliance door carefully.

The door handle is not suitable for carrying the ap pliance door. The door handle may break off. Never carry the appliance door by the door handle.

Grab hold of the appliance door with both hands on the left and right to carry it.

Take hold of the appliance door with both hands. one on the left and one on the right. and rotate the door handle upwards ​⁠ until you are able to pull up

7. Set the appliance door down on a flat. soft. clean

17.2 Attaching the appliance door

1. Tip: Ensure that the appliance door is not wedged

2. Rotate the door handle upwards slightly

3. Use a coin to release both locks on the appliance

Turn the lock on the left-hand side in an anti clockwise direction.

Turn the lock on the right-hand side in a clock wise direction.

4. Open the appliance door slightly until you hear a

WARNING ‒ Risk of injury!

If the door locks are unsecured. the appliance door may become detached. After attaching the appliance door. close the left and right-hand door locks.

Hold the screwdriver horizontally ​⁠ and use it to

Appliance door en

17.3 Removing the door panes

To facilitate cleaning. you can remove the door pane.

WARNING ‒ Risk of injury!

Components inside the appliance door may have sharp edges. Wear protective gloves.

Requirement: The appliance door is detached.

1. Lay the appliance door with the front side facing

2. Undo and remove the left- and right-hand screws on

3. Carefully lift the inner pane upwards at an angle

4. Carefully lift the inner pane upwards at an angle and

5. Push down on the intermediate pane lightly around

​⁠. and carefully lift the retainer ​⁠ until you are able

6. Lift the first and second intermediate panes from be

7. Remove the spacers ​⁠ and seals ​⁠ for cleaning. if

WARNING ‒ Risk of injury!

Scratched glass in the appliance door may develop into a crack. Do not use any harsh or abrasive cleaners or sharp metal scrapers to clean the glass on the oven door. as they may scratch the surface.

Clean the door panes on both sides with glass cleaner and a soft cloth.

9. Dry the door panes and refit them.

17.4 Fitting the door panes

WARNING ‒ Risk of injury!

If a door pane or appliance door has not been installed correctly. this is dangerous. Make sure that all of the door panes and the appli ance door have been correctly fitted before you switch the appliance back on again.

1. Tip: When fitting the door panes. make sure that

2. Check the fit of the four spacers and two seals.

Place the spacers on the centre of the lines

Secure the seals at the corners

3. Insert the intermediate pane with spacers and seals

The arrow on the intermediate pane must line up with the arrow on the frame

4. Insert the second intermediate pane without the

The arrow on the intermediate pane must line up with the arrow on the frame

5. Push down lightly on the first intermediate pane

6. Place the inner pane onto the appliance door so

7. Carefully lift the inner pane upwards at an angle and

Troubleshooting en

8. Insert the inner pane with the holder ​⁠ into the

9. Screw both screws back in on the left and right of

18 Troubleshooting

You can rectify minor faults on your appliance yourself.

Read the troubleshooting information before contacting after-sales service. This will avoid unnecessary costs.

WARNING ‒ Risk of injury!

Improper repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist staff.

If the appliance is defective. call Customer Service.

WARNING ‒ Risk of electric shock!

Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist staff.

Only use genuine spare parts when repairing the appliance.

If the power cord of this appliance is damaged. it must be replaced by trained specialist staff.

18.1 Malfunctions

Fault Cause and troubleshooting

The appliance is not working.

The circuit breaker is faulty. Check the circuit breaker in the fuse box.

There has been a power cut. Check whether the lighting in your kitchen or other appliances are working.

"Language English" appears on the dis play.

There has been a power cut. Configure the initial configuration settings. → "Initial use". Page 10

The appliance cannot be switched on;

Automatic childproof lock or childproof lock is activated Press and hold the ​⁠ button until "Childproof lock deactivated" appears on the display.

Appliance will not start or cuts out dur ing operation.

Different causes are possible. Check any notifications that appear on the display. → "Displaying information". Page 11

Malfunction Call the after-sales service. → "Customer Service". Page 27

The appliance is not heating; ​⁠ appears

Demo mode is activated in the basic settings.

1. Briefly disconnect the appliance from the power supply by switching the circuit breaker in

2. Deactivate Demo mode within the next 3 minutes in the

→ "Basic settings". Page 15.

There has been a power cut. Open and close the appliance door once after a power failure.

Time not displayed when appliance switched off.

Basic setting has been changed. Change the basic setting for the clock display. → "Basic settings". Page 15

Fault Cause and troubleshooting

Appliance door can not be opened.

The cleaning function locks the appliance door; ​⁠ is lit on the display. Allow the appliance to cool down until ​⁠ goes out on the display. → "Self-cleaning function". Page 18

The childproof lock locks the appliance door. Use the ​⁠ button to deactivate the childproof lock.

→ "Childproof lock". Page 14 You can switch off the lock in the basic settings. → "Basic settings". Page 15

The interior lighting does not work.

The halogen lamp is defective. Change the oven light bulb. → "Replacing the oven light bulb". Page 26

Maximum operating time reached.

To prevent the appliance from continuing to run when it is no longer needed. it automatically stops heating after a few hours if the settings are not changed during this time. A notifica tion appears on the display.

The point at which the maximum operating time is reached is determined by the corres ponding settings for an operating mode.

1. Press any button to continue operation.

2. If you do not need to use the appliance. press ​⁠ to switch it off.

Tip: To prevent the appliance from switching off when you do not want it to. set a cooking time. → "Setting the cooking time". Page 12

A message with "D" or "E" appears in the display. e.g. D0111 or E0111.

The electronics have detected a fault.

1. Switch the appliance off and on again. a If the fault was a one-off. the message disappears.

2. If the message appears again. call the after-sales service. Please specify the exact error

The cooking result is not satisfactory.

Settings were unsuitable.

Setting values. e.g. temperature or cooking time. depend on the recipe. quantity and food. Next time. set lower or higher values.

Tip: A lot of information about the food preparation and corresponding setting values can be found on our website www.neff-international.com.

18.2 Replacing the oven light bulb

If the light in the cooking compartment fails. change the oven light bulb.

Note: Heat-resistant. 40-watt. 230 V halogen bulbs are available from the after-sales service or specialist retail ers. Only use these bulbs. Hold the new halogen bulbs only with a clean. dry towel. This increases the service life of the bulb.

WARNING ‒ Risk of burns!

The appliance and its parts that can be touched be come hot during use. Caution should be exercised here in order to avoid touching heating elements.

Young children under 8 years of age must be kept away from the appliance.

WARNING ‒ Risk of electric shock!

When changing the bulb. the bulb socket contacts are live. Before replacing the bulb. ensure that the appliance is switched off in order to prevent a potential electric shock.

Also unplug the appliance from the mains or switch off the circuit breaker in the fuse box.

Requirements ¡ The appliance is disconnected from the power sup

¡ The cooking compartment has cooled down. ¡ You have a new halogen bulb to replace the old one.

1. Place a tea towel in the cooking compartment to

2. Turn the glass cover anti-clockwise to remove it

3. Pull out the halogen bulb without turning it

4. Insert the new halogen lamp and press it firmly into

5. Depending on the appliance model. the glass cover

Disposal en

6. Screw the glass cover on.

7. Take the tea towel out of the cooking compartment.

8. Connect the appliance to the power supply.

19 Disposal

19.1 Disposing of old appliance

Valuable raw materials can be reused by recycling.

1. Unplug the appliance from the mains.

2. Cut through the power cord.

3. Dispose of the appliance in an environmentally

This appliance is labelled in accord ance with European Directive 2012/19/EU concerning used elec trical and electronic appliances (waste electrical and electronic equip ment - WEEE).

The guideline determines the frame work for the return and recycling of used appliances as applicable throughout the EU.

20 Customer Service

Detailed information on the warranty period and terms of warranty in your country is available from our after sales service. your retailer or on our website.

If you contact Customer Service. you will require the product number (E-Nr.) and the production number (FD) of your appliance.

The contact details for Customer Service can be found in the enclosed Customer Service directory or on our website.

This product contains light sources from energy effi ciency class G.

20.1 Product number (E-Nr.) and production number (FD)

You can find the product number (E-Nr.) and the pro duction number (FD) on the appliance's rating plate.

The rating plate bearing these numbers can be found on the base of the appliance when you open the appli ance door.

Make a note of your appliance's details and the Cus tomer Service telephone number to find them again quickly.

21 How it works

Here. you can find the ideal settings for various types of food as well as the best accessories and cookware.

We have perfectly tailored these recommendations to your appliance.

21.1 General cooking tips

Please take note of the following information when cooking all types of food. The temperature and cooking time depend on the amount of food and the recipe. Settings ranges are specified for this reason. Try using the lower values to start with.

The setting values apply to food placed in the cook ing compartment while the cooking compartment is still cold. Do not place accessories into the cooking compartment until it has finished preheating.

Remove any accessories that are not being used from the cooking compartment.

21.2 Baking tips

Dark-coloured metal baking tins are most suitable for baking cakes. bread and other baked goods.

Use wide. shallow cookware for bakes and gratins.

Food takes longer to cook in deep. narrow cook ware and it browns more on top.

If you are cooking bakes directly in the universal pan. place the universal pan into the cooking com partment at level 2.

The setting values for bread dough apply to both dough placed on a baking tray and dough placed in a loaf tin.

ATTENTION!

When the cooking compartment is hot. any water in side it will create steam. The change in temperature may cause damage. Never pour water into the cooking compartment when it is still hot.

Never place cookware containing water on the cooking compartment floor.

Shelf positions If you are using the CircoTherm hot air heating func tion. you can choose between shelf positions 1. 2. 3 and 4.

Baking on one level Shelf position

Tall baked items and tins/dishes on the wire rack

Shallow baked items/baking trays

Baking on two or more levels Shelf position

2 levels Universal pan

Baking tray

2 levels Baking tins on two wire racks

3 levels Baking tray

Universal pan

Baking tray

4 levels 4 wire racks with greaseproof pa per

Use the CircoTherm hot air heating function.

Note: Items that are placed in the appliance on baking trays or in baking tins/dishes at the same time will not necessarily be ready at the same time.

21.3 Roasting. braising and grilling tips

The recommended settings are for fridge-temperat ure food and unstuffed. oven-ready poultry.

Place the poultry onto the cookware breast-side or skin-side down.

Turn roasting joints. grilled items or whole fish after approx. ½ to ⅔ of the specified time.

Roasting on the wire rack Food roasted on the wire rack will become very crispy on all sides. You can roast large poultry. for example. or multiple individual pieces at the same time. Roast pieces of a similar weight and thickness. The grilled food will brown evenly and will remain succu lent and juicy.

Place the food to be roasted directly on the wire rack.

To catch any liquids that drip down. place the uni versal pan. with the wire rack inside it. into the cook ing compartment at the specified shelf height.

Add up to ½ litre of water to the universal pan. de pending on the size and type of food that you want to roast.

You can make a sauce from the juices that are col lected. This also means that less smoke is pro duced and the cooking compartment does not be come as dirty.

Roasting in cookware If you cover the cookware when you cook your food. this will keep the cooking compartment cleaner.

General information about roasting in cookware Use heat-resistant. ovenproof cookware.

Place the cookware on the wire rack.

Glass cookware is best.

Follow the manufacturer's instructions for your roast ing dishes.

Roasting in uncovered cookware Use a deep roasting dish.

If you do not have any suitable cookware. you can use the universal pan.

Roasting in covered cookware Use a suitable lid that seals well.

When roasting meat. there should be at least 3 cm between the food and the lid. The meat may ex pand.

WARNING ‒ Risk of scalding!

Very hot steam may escape when the lid is opened after cooking. Steam may not be visible. depending on the temperature. Lift the lid in such a way that the hot steam can es cape away from you.

Keep children away from the appliance.

Grilling Grill food if you want it to be crispy. When grilling several food items. choose pieces that are of a similar weight and thickness. The grilled food will brown evenly and will remain succulent and juicy.

Place the food to be grilled directly onto the wire rack.

To catch any liquids that drip down. place the uni versal pan into the cooking compartment at least one level below the wire rack.

Notes The grill element switches on and off continuously.

This is normal. The temperature that you set determ ines how frequently this occurs.

Smoke may be produced when grilling.

21.4 Cooking frozen products

Do not use heavily frosted frozen products.

Remove any ice.

Some frozen products may be unevenly pre-baked.

Uneven browning may remain even after baking.

21.5 Cooking ready meals

Take ready meals out of the packaging.

If you are warming or cooking the ready meal in cookware. make sure that the cookware is heat-res istant.

How it works en

5. Immediately place the meat into the pre-warmed

6. After low temperature cooking. remove the meat

Recommended settings for slow cooking

Food Accessory/cook ware

Shelf pos ition

Searing time in mins

Heating function → Page 7

Temperature in °C

Cooking time in mins

Duck breast. medium rare. 300 g each

Uncovered cook ware

6 - 8 ​⁠90 1 45 - 60

Fillet of pork. whole Uncovered cook ware

4 - 6 ​⁠80 1 45 - 70

Fillet of beef. 1 kg Uncovered cook ware

4 - 6 ​⁠80 1 90 - 120

Veal medallions. 4 cm thick

Uncovered cook ware

​⁠80 1 30 - 50

Saddle of lamb. bone less. 200 g each

Uncovered cook ware

​⁠80 1 30 - 45

1 Preheat the appliance.

Defrosting You can defrost frozen food in your appliance.

Tips for defrosting food You can use the appliance to defrost frozen fruit. ve getables or baked goods.

It is better to defrost poultry. meat and fish in the re frigerator.

Remove frozen food from its packaging before you defrost it.

The recommended settings are for freezer-temperat ure food (-18 °C).

When defrosting food. use the following shelf posi tions: 1 wire rack: Shelf position 2

2 wire racks: Shelf positions 3 + 1

Stir or turn the food 1-2 times during defrosting.

Turn large items several times. Split the food into smaller pieces as it defrosts.

Remove pieces that have already defrosted from the cooking compartment.

Once the food has defrosted. switch off the appli ance and leave the food in the appliance for another 10 to 30 minutes to allow the temperature to equal ise.

Keeping food warm

Tips for keeping food warm You can keep cooked food warm at 70 °C using the "top/bottom heating" function. This prevents con densation from forming and you will not have to wipe down the cooking compartment.

To prevent the food from drying out. you can cover it.

Do not keep food warming for longer than 2 hours.

Be aware that some types of food will actually con tinue cooking when you are keeping them warm in the oven.

21.8 Test dishes

The information in this section is provided for test institutes to facilitate testing of the appliance in accordance with EN 60350‑1.

Baking The setting values apply to food that is placed into a cold cooking compartment.

Please take note of the information on preheating in the recommended settings tables. These setting val ues assume that the rapid heat-up function is not being used.

For baking. use the lower of the specified temperat ures to start with.

Items that are placed in the appliance on baking trays or in baking tins/dishes at the same time will not necessarily be ready at the same time.

Shelf positions when baking on 2 levels: Universal pan: Shelf position 3 Baking tray: Shelf position 1

Baking tins/dishes on the wire rack: First wire rack: Shelf position 3 Second wire rack: Shelf position 1

Shelf positions when baking on 3 levels: Baking tray: Shelf position 4

Universal pan: Shelf position 3

Baking tray: Shelf position 1

Hot water sponge cake When baking on two levels. place the springform tins at diagonally opposite corners of the wire racks.

Recommended settings for baking

Food Accessory/cookware Shelf pos ition

Heating function → Page 7

Temperature in °C

Cooking time in mins

Viennese whirls Baking tray ​⁠140 - 150 1 25 - 40

Viennese whirls Baking tray ​⁠140 - 150 1 25 - 40

Viennese whirls. on 2 levels Universal pan

Baking tray

​⁠140 - 150 1 30 - 40

Viennese whirls. on 3 levels x 2 Baking tray x 1 Universal pan

4+3+1 ​⁠130 - 140 1 35 - 55

Small cakes Baking tray ​⁠160 1 20 - 30

Small cakes Baking tray ​⁠150 1 25 - 35

Small cakes. on 2 levels Universal pan

Baking tray

​⁠150 1 25 - 35

Small cakes. on 3 levels x 2 Baking tray x 1 Universal pan

4+3+1 ​⁠140 1 35 - 45

Hot water sponge cake Springform cake tin. diameter 26 cm

​⁠160 - 170 2 25 - 35

Hot water sponge cake Springform cake tin. diameter 26 cm

​⁠160 - 170 2 30 - 40

Hot water sponge cake. on 2 levels

Springform cake tin. diameter 26 cm

​⁠150 - 170 2 30 - 50

1 Preheat the appliance for five minutes. Do not use the rapid heating function.

2 Preheat the appliance. Do not use the rapid heating function.

Recommended settings for grilling

Food Accessory/cookware Shelf pos ition

Heating function → Page 7

Temperature in °C

Cooking time in mins

Toasting bread Wire rack ​⁠290 1 4 - 6

1 Do not preheat the appliance.

22 Installation instructions

Observe this information when installing the appliance.

22.1 General installation instructions

Follow these instructions before you start with the installation of the appliance. ¡ The safe operation of this appliance can

Installation instructions en

¡ Do not use the door handle for the trans

¡ Check the appliance for damage after un

¡ Before starting up the appliance. remove

¡ Proceed in accordance with the installation

¡ Fitted units must be heat-resistant up to

95 °C. and adjacent unit fronts up to 70 °C.

¡ Do not install the appliance behind a decor

¡ Cut-out work on the units should be carried

¡ The mains socket for the appliance must

¡ Wear protective gloves so that you do not

¡ Dimensions of the figures in mm.

WARNING ‒ Danger: Magnetism!

Permanent magnets are used in the control panel or in the controls. They may affect elec tronic implants. e.g. pacemakers or insulin pumps. ▶ Wearers of electronic implants must stay at

WARNING ‒ Risk of fire!

It is dangerous to use an extended power cord and non-approved adapters. ▶ Do not use multiple socket strips. ▶ Only use extension cables that are certified.

▶ If the power cord is too short. contact cus

▶ Only use adapters approved by the manu

ATTENTION!

Carrying the appliance by the door handle could break it. The door handle cannot sup port the weight of the appliance. ▶ Do not carry or hold the appliance by the

22.2 Appliance dimensions

You will find the dimensions of the appliance here

22.3 Installation below a worktop

Observe the installation dimensions and the installation instructions when installing below a worktop.

To ventilate the appliance. the intermediate floor must have a ventilation cut-out.

The worktop must be secured to the built-in unit.

Observe any available installation instructions for the hob.

22.4 Installation underneath a hob

If the appliance is installed under a hob. the following minimum dimensions must be adhered to (including substructure. if applicable).

The minimum worktop thickness ​⁠ a is based on the

Hob type a raised in mm a flush in mm b in mm

Induction hob

Full-surface induction hob

Gas hob

Electric hob

22.5 Installation in a tall unit

Observe the installation dimensions and the installation instructions when installing in a tall unit.

To ventilate the appliance. the intermediate floors must have a ventilation cut-out.

If the tall unit has another back panel in addition to the element back panels. this must be removed.

Only fit the appliance up to a height which allows accessories to be easily removed.

Installation instructions en

22.6 Installing two appliances on top of each other

Your appliance can also be installed above or below another appliance. Observe the installation dimensions and the installation instructions when installing appli ances on top of each other.

To ventilate the appliances. the intermediate floor must have a ventilation cut-out.

To ensure sufficient ventilation of the two appli ances. there must be a ventilation opening of at least 200 cm² in the base area. To do this. trim the base panel or fit a ventilation grille.

Ensure that air exchange is guaranteed in accord ance with the diagram.

Only fit appliances up to a height that allows ac cessories to be easily removed.

22.7 Corner installation

Observe the installation dimensions and the installation instructions when installing in a corner.

To ensure that the appliance door can be opened. you must take the minimum dimensions into consid eration when installing in a corner. The dimension

22.8 Electrical connection

In order to safely connect the appliance to the elec trical system. follow these instructions. The appliance corresponds to protection class I and must only be operated with a protective earth con nection.

The fuse protection must correspond to the power rating specified on the appliance's rating plate and to local regulations.

The appliance must be disconnected from the power supply whenever installation work is being carried out.

The appliance must only be connected using the power cable provided.

The power cable must be plugged in at the rear of the appliance until you hear a clicking sound. A 3 m power cable can be obtained from the after-sales service.

The power cable must only be replaced with a cable from the original manufacturer. This is available from after-sales service.

Contact protection must be guaranteed by the in stallation.

Electrically connect the appliance with the protective contact plug Note: The appliance must only be connected to a pro tective contact socket that has been correctly installed.

Insert the plug into the protective contact socket.

When the appliance is installed. the mains plug of the power cord must be freely accessible. If free ac cess to the mains plug is impossible. an all-pole isolating switch must be integrated into the perman ent electrical installation in accordance with the in stallation regulations.

Electrically connecting an appliance without a protective contact plug Note: Only a licensed professional may connect the ap pliance. Damage caused by incorrect connection is not covered under the warranty.

An all-pole isolating switch must be integrated into the permanent electrical installation according to the install ation regulations.

1. Identify the phase and neutral conductors in the

2. Connect the hob in accordance with the connection

3. Connect the wires of the mains power cable accord

Blue = Neutral conductor

Brown = Phase (external conductor)

22.9 Installing the appliance

Note: Do not use a cordless screwdriver to secure the panels. This may damage the panels.

1. If required. you can adjust the gap between the ap

Turning the screws clockwise makes the gap larger Turning the screws anti-clockwise makes the gap smaller

2. Push the appliance in fully.

Do not kink or trap the connection cable. or route it over sharp edges.

3. Centre the appliance.

There must be an air gap of at least 4 mm between the appliance and adjacent unit fronts.

4. Open the appliance door slightly and unscrew pan

5. Close the appliance door.

6. If required. you can adjust the height of the appli

Turning the screws clockwise makes the gap smal ler Turning the screws anti-clockwise makes the gap larger

7. Screw the appliance into place.

8. For handleless kitchens with vertical bar handle

Pre-drill aluminium profiles to establish a screw connection

Secure the appliance using a suitable screw

Installation instructions en

9. Open the appliance door slightly. then refit the pan

Note: The gap between the worktop and the appliance must not be closed by additional battens.

Thermal insulation strips must not be fitted to the side panels of the surround unit.

22.10 Removing the appliance

1. Disconnect the appliance from the power supply.

2. Open the appliance door slightly and unscrew the

3. Undo the fastening screws.

4. Lift the appliance slightly and pull it out completely.

BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München. GERMANY

+9001753624*

9001753624 020518 en

Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd.

Grand Union House Old Wolverton Road Wolverton. Milton Keynes MK12 5PT United Kingdom



Newest Added: SH80PYX(00) S247HDS01A V6320X0EU/03 KA3902I20/07 D46ED52X0

Neff B57CS22N0 | Pages: 40 | Created on: 2022-05-18 | File type: PDF | Filename: 63096130_b57cs22n0.pdf | Size: 6.36 MB | Language: English | Other documents: 4 files.

Download User Manual

Product Infomation and Reviews - B57CS22N0 photo

B57CS22N0 Photo

View more photos

T: @manualsFile

https://manualsFile.com
