Monogram
®
Assembly Instructions
Before you Begin – Read these instructions completely and carefully.
Note To Installer: Be sure to leave these instructions with the Consumer.
Note to Consumer: Keep these instructions with your Owner’s Manual for future reference.
If you received a damaged Grill Cart, you should contact
your dealer.
Assembly of this grill cart requires basic mechanical skills.
Proper assembly is the responsibility of the installer.
Step 1:
Remove
Packaging
Open the box and remove the contents.
Remove packaging and protective film.
Locate the hardware accessory package and
check contents.
24" and 27" Outdoor Cooking Center
Grill Carts
Models ZX24CTBSS/ZX27CTACSS
For Monogram local service in your area, 1.800.444.1845.
For Monogram service in Canada, 1.888.880.3030.
For Monogram Parts and Accessories, call 1.800.626.2002.
NOTE:
Carts must be completely assembled before any gas
connections are made.
24” Grill Cart
1/4-20 x 3/4"
Hex Bolts
1/4-20 Hex
Keps Nuts
Shelf with
Handle
Cart
27” Grill Cart
1/4-20 x 1/2" Hex Bolts
Flat Washers
Shelf Brackets
10-24 x 1/2" Screws
Fold-Down Shelf
Cart
Shelf Stops
10-24 x 1-1/8" Screws
1/4-20 Acorn
Lock Nut
ITEM QUANTITY
1/4-20 x 3/4" HEX BOLTS 4
1/4-20 HEX KEPS NUTS 8
1/4-20 ACORN LOCK NUTS 8
ITEM QUANTITY
1/4-20 x 1/2" HEX BOLTS 4
10-24 x 1/2" SCREWS 4
10-24 x 1-1/8" SCREWS 2
ALUMINUM SHELF STOPS 3/8 x 3/8 2
1/4 x 3/4" WASHER FLT SS 4
