Operation Manual

Sewing and Embroidery Machine

Product Code: 888-P10

Be sure to read this document before using the machine.

We recommend that you keep this document nearby for future reference.

Instruction Videos

https://s.brother/cvjap/

Thank you for purchasing this machine. Before using this

machine, carefully read the “IMPORTANT SAFETY

INSTRUCTIONS”, and then study this manual for the

correct operation of the various functions.

In addition, after you have finished reading this manual,

store it where it can quickly be accessed for future

reference.

Please read these safety instructions before attempting to

use the machine.

DANGER

- To reduce the risk of electrical shock

1Always unplug the machine from the

electrical outlet immediately after using,

when cleaning, making any user

servicing adjustments mentioned in this

manual, or if you are leaving the

machine unattended.

WARNING

- To reduce the risk of burns, fire, electrical shock, or

injury to persons.

2Always unplug the machine from the electrical

outlet when making any adjustments mentioned in

the instruction manual.

• To unplug the machine, switch the machine to the

symbol “O” position to turn it off, then grasp the

plug and pull it out of the electrical outlet. Do not

pull on the cord.

• Plug the machine directly into the electrical outlet.

Do not use an extension cord.

• Always unplug your machine if there is a power

failure.

3Electrical Hazards:

• This machine should be connected to an AC power

source within the range indicated on the rating

label. Do not connect it to a DC power source or

inverter. If you are not sure what kind of power

source you have, contact a qualified electrician.

• This machine is approved for use in the country of

purchase only.

4Never operate this machine if it has a damaged cord

or plug, if it is not working properly, has been

dropped or damaged, or water is spilled on the unit.

Return the machine to the nearest authorized

Brother dealer for examination, repair, electrical or

mechanical adjustment.

• While the machine is stored or in use if you notice

anything unusual, such as an odor, heat,

discoloration or deformation, stop using the

machine immediately and unplug the power cord.

• When transporting the machine, be sure to carry it

by its handle. Lifting the machine by any other part

may damage the machine or result in the machine

falling, which could cause injuries.

• When lifting the machine, be careful not to make

any sudden or careless movements, which may

cause a personal injury.

5Always keep your work area clear:

• Never operate the machine with any air openings

blocked. Keep ventilation openings of the machine

and the foot controller free from the build up of lint,

dust, and loose cloth.

• Do not store objects on the foot controller.

• Never drop or insert foreign objects in any opening.

• Do not operate where aerosol (spray) products are

being used or where oxygen is being administered.

• Do not use the machine near a heat source, such as

a stove or iron; otherwise, the machine, power cord

or garment being sewn may ignite, resulting in fire

or an electric shock.

• Do not place this machine on an unstable surface,

such as an unsteady or slanted table, otherwise the

machine may fall, resulting in injuries.

6Special care is required when sewing:

• Always pay close attention to the needle. Do not use

bent or damaged needles.

• Keep fingers away from all moving parts. Special

care is required around the machine needle.

• Switch the machine to the symbol “O” position to

turn it off when making any adjustments in the

needle area.

• Do not use a damaged or incorrect needle plate, as

it could cause the needle to break.

• Do not push or pull the fabric when sewing, and

follow careful instruction when free motion stitching

INTRODUCTION

IMPORTANT SAFETY

INSTRUCTIONS

so that you do not deflect the needle and cause it to

break.

7This machine is not a toy:

• Your close attention is necessary when the machine

is used by or near children.

• This product contains small parts. Keep the product

out of the reach of children to prevent accidental

ingestion of small parts.

• The plastic bag that this machine was supplied in

should be kept out of the reach of children or

disposed of. Never allow children to play with the

bag due to the danger of suffocation.

• Do not use the seam ripper in any other way than

how it is intended.

• Do not use outdoors.

8For a longer service life:

• When using and storing this machine, avoid direct

sunlight and high humidity locations. Do not use or

store the machine near a space heater, iron, halogen

lamp, or other hot objects.

• Do not use cleansers or organic solvents, such as

thinner, petroleum ether or alcohol, to clean the

machine. Otherwise, the finish may peel off or

become scratched.

• Do not oil the machine yourself to prevent

damaging it.

• Always consult the Operation Manual when

replacing or installing any assemblies, the presser

feet, needle or other parts to assure correct

installation.

9For repair or adjustment:

• If the light unit is damaged, it must be replaced by

an authorized Brother dealer.

• In the event a malfunction occurs or adjustment is

required, first follow the troubleshooting table in the

back of the Operation Manual to inspect and adjust

the machine yourself. If the problem persists, please

consult your local authorized Brother dealer.

Use this machine only for its intended use as described

in the manual.

Use accessories recommended by the manufacturer as

contained in this manual.

The contents of this manual and specifications of this

product are subject to change without notice.

For additional product information and updates, visit

our website at www.brother.com

SAVE THESE

INSTRUCTIONS

This machine is intended

for household use.

FOR USERS IN COUNTRIES

EXCEPT EUROPEAN COUNTRIES

This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience and

knowledge, unless they have been

given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

Children should be supervised to

ensure that they do not play with the

appliance.

FOR USERS IN EUROPEAN

COUNTRIES

This appliance can be used by children

aged from 8 years and above and

persons with reduced physical, sensory

or mental capabilities or lack of

experience and knowledge if they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understand the hazards

involved. Children shall not play with

the appliance. Cleaning and user

maintenance shall not be made by

children without supervision.

FOR USERS IN THE UK,

EIRE, MALTA AND

CYPRUS ONLY

IMPORTANT

• In the event of replacing the plug fuse, use a fuse

approved by ASTA to BS 1362, i.e. carrying the

mark, rating as marked on plug.

• Always replace the fuse cover. Never use plugs with

the fuse cover omitted.

• If the available electrical outlet is not suitable for the

plug supplied with this equipment, you should

contact your authorized Brother dealer to obtain the

correct lead.

Federal Communications

Commission (FCC)

Supplier’s Declaration of

Conformity (For U.S.A.

Only)

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2)

this device must accept any interference received,

including interference that may cause undesired

operation.

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio

or television reception, which can be determined by

turning the equipment off and on, the user is

encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

• Consult the authorized Brother dealer or an

experienced radio/TV technician for help.

• This transmitter must not be co-located or operated

in conjunction with any other antenna or

transmitter.

Important

Changes or modifications not expressly approved by

Brother Industries, Ltd. could void the user’s authority

to operate the equipment.

This equipment complies with FCC/IC radiation

exposure limits set forth for an uncontrolled

environment and meets the FCC radio frequency (RF)

Exposure Guidelines and RSS-102 of the IC radio

frequency (RF) Exposure rules. This equipment has very

low levels of RF energy that are deemed to comply

without testing of specific absorption rate (SAR).

Responsible Party: Brother International Corporation

200 Crossing Boulevard

P.O. Box 6911

Bridgewater, NJ 08807-0911

USA

TEL : (908) 704-1700

declares that the product

Product Name:

Model Number:

Brother Sewing Machine

SE700, SE725, LB5500

For Users in Canada

This device complies with Industry Canada’s licence-exempt

RSSs. Operation is subject to the following two conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including

interference that may cause undesired operation of the

device.

This equipment complies with FCC/IC radiation exposure

limits set forth for an uncontrolled environment and meets the

FCC radio frequency (RF) Exposure Guidelines and RSS-102

of the IC radio frequency (RF) Exposure rules. This equipment

has very low levels of RF energy that are deemed to comply

without testing of specific absorption rate (SAR).

For Users in Mexico

The operation of this equipment is subject to the following

two conditions:

(1) it is possible that this equipment or device may not cause

harmful interference, and

(2) this equipment or device must accept any interference,

including interference that may cause undesired

operation.

La operación de este equipo está sujeta a las siguientes dos

condiciones:

(1) es posible que este equipo o dispositivo no cause

interferencia perjudicial y

(2) este equipo o dispositivo debe aceptar cualquier

interferencia, incluyendo la que pueda causar su

operación no deseada.

Declaration of Conformity

(Europe and Turkey only)

We, Brother Industries, Ltd. 15-1 Naeshiro-cho, Mizuho-ku,

Nagoya 467-8561 Japan declare that this product is in

conformity with the essential requirements of all relevant

directives and regulations applied within the European

Community.

The Declaration of Conformity (DoC) can be downloaded

from Brother support website. Visit support.brother.com

Declaration of Conformity

for RE Directive

2014/53/EU (Europe and

Turkey only)

(Applicable to models with

radio interfaces)

We, Brother Industries, Ltd. 15-1 Naeshiro-cho, Mizuho-ku,

Nagoya 467-8561 Japan declare that these products are in

conformity with the provisions of the RE Directive

2014/53/EU.

The Declaration of Conformity (DoC) can be downloaded

from Brother support website. Visit support.brother.com

Wireless LAN (Models with

Wireless LAN function

only)

This machine supports wireless interface.

Frequency band(s): 2400-2483.5 MHz

Maximum radio-frequency power transmitted in the

frequency band(s): Less than 20 dBm(e.i.r.p)

UK Declaration of

Conformity

(Great Britain only)

We, Brother Industries, Ltd. 15-1 Naeshiro-cho, Mizuho-ku,

Nagoya 467-8561 Japan declare that these products are in

conformity with the relevant UK legislation.

The Declaration of Conformity (DoC) can be downloaded

from Brother support website. Visit support.brother.com

UK Declaration of

Conformity for Radio

Equipment Regulation

2017

(Great Britain only)

(Applicable to models with

radio interfaces)

We, Brother Industries, Ltd. 15-1 Naeshiro-cho, Mizuho-ku,

Nagoya 467-8561 Japan declare that these products are in

conformity with the provisions of the Radio Equipment

Regulation 2017.

The Declaration of Conformity (DoC) can be downloaded

from Brother support website. Visit support.brother.com

For Users in Norway

This subsection does not apply for the geographical area

within a radius of 20 km from the centre of Ny-Alesund on

Svalbard.

Dette underavsnittet gjelder ikke for det geografiske området

innenfor en radius av 20 km fra sentrum av Ny-Ålesund på

Svalbard.

For Users in Thailand

This telecommunication equipment conforms to NTC

technical requirement.

IMPORTANT-PLEASE READ

CAREFULLY:

This Terms of Use (“Agreement”) is a legal agreement

between Brother Industries, Ltd. (“Company”) and you that

governs your use of any Software, installed on or made

available by Company for use with sewing or craft products

(“Company Product”). The term of “Software” means any and

all contents data, design data, data format, firmware of

Company Product, and PC application or mobile device

application.

By using the Software and Company Product, you shall be

deemed to have agreed to be bound by the terms of this

Agreement. If you do not agree to the terms of this Agreement,

Company is unwilling to license the Software and you are not

allowed to use the Software. Amendments and supplements to

this Agreement may be attached to the Software.

An individual who accepts this Agreement on behalf of an

entity represents to Company that he or she has the legal right

to enter into a binding legal agreement for that entity.

Terms and Conditions

1 Grant of License.

1.1 Subject to this Agreement, Company hereby

grants you a personal, non-exclusive,

non-transferable and revocable license to use

the Software only within the Company Product.

1.2 Your right to use of the Software is licensed and

not sold, and solely for your use subject to this

Agreement. Company or its suppliers retains all

right, title, and interest relating to Software,

including without limitation all intellectual

property rights relating thereto.

2 Restrictions

2.1 Except as expressly set out in this Agreement or

as required by any local law, you shall

undertake:

2.1.1 not to disassemble, de-compile, reverse

engineer, translate or otherwise attempt

to learn the source code of the Software

(including the data or contents created

by using the Company Product or

contents editing application software;

hereinafter the same shall apply in this

Clause 2.);

2.1.2 not to create derivative works based on

the whole or any part of the Software;

2.1.3 not to distribute, provide or make

available the Software in any form, in

whole or in part to any person without

prior written consent from Company;

2.1.4 not to copy the Software, except where

such copying is incidental to normal

use of the Software with Company

Product or where it is necessary for the

purpose of back-up or operational

security;

2.1.5 not to transfer, rent, lease, sub-license,

loan, translate, merge, adapt, vary, alter

or modify, the whole or any part of the

Software nor permit the Software or any

part of it to be combined with, or

become incorporated in, any other

programs;

2.1.6 to include Company’s copyright notice

and this Agreement on all entire and

partial copies of the Software; and

2.1.7 not to use the Software for any purpose

(including, but not limited to, use with

unauthorized sewing/craft products or

software) other than as provided under

Clause 1 of this Agreement.

3No warranty

TO THE EXTENT PERMISSIBLE BY

APPLICABLE LAW, THIS SOFTWARE IS

PROVIDED TO YOU “AS IS” WITHOUT

WARRANTIES OR CONDITIONS OF ANY

KIND, WHETHER ORAL OR WRITTEN,

EXPRESS OR IMPLIED. COMPANY

SPECIFICALLY DISCLAIMS ANY IMPLIED

WARRANTIES OR CONDITIONS OF

MERCHANTABILITY, SATISFACTORY

QUALITY, NON-INFRINGEMENT AND/OR

FITNESS FOR A PARTICULAR PURPOSE.

4 Limitation of liability

4.1 COMPANY SHALL NOT BE LIABLE TO YOU,

ITS END-USERS OR ANY OTHER ENTITY FOR

ANY LOSS OF PROFITS OR INCOME OR

SAVINGS, LOSS OF DATA, INTERRUPTION

OF USE, OR CONSEQUENTIAL,

INCIDENTAL, SPECIAL, PUNITIVE OR

INDIRECT DAMAGES INCURRED BY SUCH

PARTY (WHETHER IN AN ACTION IN

CONTRACT OR TORT), EVEN IF COMPANY

HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES, ARISING OUT OF OR

RELATING TO THE SOFTWARE, SUPPORT

SERVICE OR THIS AGREEMENT. THESE

LIMITATIONS SHALL APPLY TO THE

MAXIMUM EXTENT ALLOWED BY

APPLICABLE LAW NOTWITHSTANDING

ANY FAILURE OF ESSENTIAL PURPOSE OF

ANY LIMITED REMEDY.

4.2 NOTWITHSTANDING THE CLAUSE 3 OR 4.1

HEREOF, THIS AGREEMENT DOES NOT

PURPORT TO EXCLUDE OR RESTRICT

COMPANY’S LIABILITY FOR DEATH OR

PERSONAL INJURY RESULTING FROM

NEGLIGENCE OR LIMIT THE STATUTORY

RIGHTS OF A CONSUMER.

5Termination

5.1 Company shall have the right to terminate this

Agreement at any time by providing a written

notice to you if you commit a material breach

of any terms of this Agreement and fail to

immediately rectify such breach upon

Company’s request.

5.2 Upon termination for any reason all rights

granted to you under this Agreement shall

cease, you shall cease all activities authorized

by this Agreement and you shall immediately

delete or remove the Software from all

computer equipment in your possession and

delete or destroy all copies of the Software or

its derivative works in your possession. In

addition to the above, you shall delete contents

or design data created by you from the

Company Product in your possession.

6 Miscellaneous terms

6.1 You shall not export or re-export the Software

or any copy or adaptation thereof in violation

of any applicable laws or regulations.

6.2 You shall not assign all or any part of this

Agreement to any third party or any interest

therein, without prior written consent of

Company. A change of control or

reorganization of you pursuant to a merger,

sale of assets or stock shall be deemed to be an

assignment under this Agreement.

6.3 You agree that a breach of this Agreement will

cause irreparable injury to Company for which

monetary damages would not be an adequate

remedy and Company shall be entitled to seek

equitable relief in addition to any remedies it

may have hereunder or at law without a bond,

other security, or proof of damages.

6.4 If any provisions of this Agreement shall be

declared or determined as void or

unenforceable by a court of competent

jurisdiction, such provisions shall be severable

and independent from the other provisions of

this Agreement and the validity of the other

provisions and of the entire Agreement shall

not be affected thereby.

6.5 This Agreement, together with all exhibits or

other attachments referenced herein,

constitutes the entire agreement between the

parties on the subject matter hereof, and

supersedes all proposals, oral and written,

between the parties on this subject.

6.6 If Company fails to insist that you perform any

of your obligations under this Agreement, or if

Company does not enforce any rights against

you, or if Company delay in doing so, that will

not mean that Company have waived any

rights against you and will not mean that you

do not have to comply with those obligations.

If Company does waive a default by you,

Company will only do so in writing, and that

will not mean that Company will automatically

waive any later default by you.

6.7 This Agreement is governed by the laws of

Japan and Japanese Courts shall have exclusive

jurisdiction with respect to this Agreement

except with regard to enforcement in which

case the jurisdiction of the Japanese Courts

shall be non-exclusive.

6.8 The Company may update this Agreement in

the below cases: A) When the changes are

made for the users' benefit, or B) When the

updates to the Agreement are adequate,

reasonable, and not contrary to the purposes of

the Agreement.

The Company will notify you and give you the

opportunity to review any material changes or

updates to the Agreement, by posting a notice

on the Company's website or a website

specified by the Company at least 30 days

before the Agreement enters into effect. Once

the updated Agreement is in effect, you will be

bound by it if you continue to use the Software.

This product includes open-source software.

To see the open source licensing remarks, please go to the

manual download section on your model’s home page of

Brother support website at https://s.brother/cpjap/

WPA™ and WPA2™ are trademarks of Wi-Fi Alliance®.

Any trade names and product names of companies

appearing on Brother products, related documents and any

other materials are all trademarks or registered trademarks

of those respective companies.

This product includes software developed by the following

vendor:

Make sure you use a router or firewall when connecting

your machine to the Internet to protect it against

unauthorized access from the Internet.

OPEN SOURCE LICENSING

REMARKS

TRADEMARKS

PRECAUTION FOR WIRELESS

CONNECTION

CONTENTS

Chapter 1 GETTING READY 9

Names of Machine Parts....................................... 9

Included Accessories .......................................... 11

Turning the Machine On/Off.............................. 11

LCD Operation ................................................... 13

Viewing the LCD.................................................................. 13

Settings screen...................................................................... 15

Adjusting input sensitivity for operation keys........................ 16

Wireless Network Connection Functions............ 17

Operations available with a wireless network connection .... 17

Enabling a wireless network connection............................... 17

Using the wizard to set up the wireless network

connection ........................................................................... 17

Winding/Installing the Bobbin............................ 19

Winding the bobbin ............................................................. 19

Installing the bobbin............................................................. 22

Upper Threading ................................................ 23

Threading the upper thread .................................................. 23

Pulling up the bobbin thread ................................................ 26

Fabric/Thread/Needle Combinations.................. 27

Replacing the Needle.......................................... 28

Checking the needle............................................................. 28

Replacing the needle............................................................ 28

Replacing the Presser Foot.................................. 29

Replacing the presser foot .................................................... 29

Removing and attaching the presser foot holder ................... 30

Chapter 2 SEWING BASICS 31

Sewing ................................................................ 31

Stitch types........................................................................... 31

Basic sewing ........................................................................ 31

Combining stitch patterns..................................................... 33

Sewing reverse/reinforcement stitches .................................. 34

Automatic reverse/reinforcement stitching............................ 34

Automatic thread cutting...................................................... 34

Setting the stitch width/stitch length/“L/R Shift” .................... 35

Adjusting the Thread Tension ............................. 36

Useful Sewing Tips ............................................. 37

Sewing tips........................................................................... 37

Sewing an even seam allowance .......................................... 38

Sewing various fabrics.......................................................... 39

Chapter 3 VARIOUS STITCHES 41

Stitch Chart ........................................................ 41

Utility Stitches.................................................... 44

Overcasting stitches ............................................................. 44

Blind hem stitching .............................................................. 45

Buttonhole sewing................................................................ 47

Button sewing ...................................................................... 49

Zipper insertion.................................................................... 50

Appliqué and patchwork ...................................................... 51

Other stitching applications.................................................. 53

Making Adjustments ........................................... 58

Using the Memory Function ............................... 59

Saving stitch patterns............................................................ 59

Retrieving stitch patterns ...................................................... 59

Chapter 4 EMBROIDERY 61

Embroidering Preparation .................................. 61

Attaching the embroidery foot.................................................... 61

Attaching the embroidery unit ............................................. 62

Embroidering attractive finishes ........................................... 63

Hooping the fabric in the embroidery frame ........................ 64

Attaching the embroidery frame........................................... 66

Embroidering ..................................................... 67

Selecting an embroidery pattern .......................................... 67

Embroidering a pattern ........................................................ 70

Adjusting thread tension ...................................................... 72

Embroidering the appliqué patterns ..................................... 72

Using a frame pattern to make an appliqué.......................... 73

Split embroidery patterns..................................................... 75

Editing Patterns (Pattern Editing Screen)............ 75

Editing Patterns (Embroidery Settings Screen).... 78

Aligning the pattern and the needle position........................ 78

Embroidering linked characters............................................ 79

Using the Memory Function............................... 80

Saving embroidery patterns.................................................. 80

Retrieving embroidery patterns ............................................ 80

Chapter 5 APPENDIX 83

Care and Maintenance ....................................... 83

Cleaning the LCD ................................................................ 83

Cleaning the machine surface.............................................. 83

Restrictions on oiling ........................................................... 83

Precautions on storing the machine ..................................... 83

Cleaning the race................................................................. 83

Touch panel is malfunctioning............................................. 84

Troubleshooting ................................................. 85

Upper thread tightened up................................................... 85

Tangled thread on wrong side of fabric................................ 85

Incorrect thread tension....................................................... 86

Fabric is caught in the machine and cannot be removed ..... 87

If the thread becomes tangled under the bobbin winder

seat...................................................................................... 89

List of symptoms.................................................................. 89

Error messages..................................................................... 93

How can I find the wireless security information (SSID and

network key)........................................................................ 95

Specifications..................................................... 96

Updating Your Machine’s Software ................... 97

Index.................................................................. 98

CONTENTS

Names of Machine Parts

GETTING READY

■ Main parts

1 Bobbin winding thread guide and pretension disk

(page 20)

2 Thread guide (page 20)

3 Spool cap (page 20)

4 Spool pin (page 20)

5 Hole for extra spool pin

This holds an extra spool pin for sewing with twin needle. (page

56) This is not a hole for lubrication. Do not insert oil into this

hole.

6 Bobbin winder (page 19)

7 LCD (liquid crystal display) (page 13)

8 Operation panel (page 10)

9 Operation buttons and sewing speed controller

(page 10)

0 Flat bed attachment (page 37)

A Thread cutter (page 25)

B Needle threader lever (page 25)

C Thread tension dial (page 36, page 72)

D Handwheel

Turn the handwheel toward you (counterclockwise) to raise and

lower the needle to sew one stitch.

E Thread guide cover (page 20)

F Handle

Carry the machine by its handle when transporting.

G Presser foot lever

Raise and lower the presser foot lever to raise and lower the

presser foot.

H Feed dog position switch

Use when lowering the feed dogs for free motion quilting* or

button fitting, and when raising the feed dogs. (page 49)

When the feed dogs are lowered, return to their original raised

position after sewing is finished. The feed dogs are raised when

the machine starts sewing.

* For free motion quilting, purchase a quilting foot sold

separately.

I Main power switch (page 12)

J Power supply jack (page 12)

K Foot controller (page 32)

L Foot controller jack (page 32)

M Air vent

The air vent allows the air surrounding the motor to circulate.

Do not cover the air vent while the machine is being used.

N USB port (for a USB flash drive) (page 59, page 80)

■

Needle and presser foot section

1 Needle bar thread guide (page 25)

2 Needle plate (page 38)

3 Needle plate cover (page 22)

4 Bobbin cover/bobbin case (page 22, page 84)

5 Feed dogs

The feed dogs feed the fabric in the sewing direction.

6 Presser foot

The presser foot applies pressure consistently on the fabric as

the sewing takes place. Attach the appropriate presser foot for

the selected stitch.

7 Presser foot holder (page 30)

8 Presser foot holder screw (page 30)

9 Buttonhole lever (page 48)

Chapter 1

GETTING READY

Note

• Be sure to install the latest software.

Refer to “Updating Your Machine’s Software” on

page 97.

Names of Machine Parts

IMPORTANT

• Do not insert anything other than a USB flash

drive into the USB port. Anything else may

damage the machine.

Names of Machine Parts

■ Embroidery unit

1 Embroidery carriage frame holder (page 66)

2 Embroidery unit connection (page 62)

3 Carriage (page 62)

4 Release button (page 63)

■ Operation buttons

1 “Start/Stop” button

Press the “Start/Stop” button to start or stop sewing.

The button changes color according to the machine’s

operation mode.

2 Reverse/Reinforcement stitch button

Press the reverse/reinforcement button to sew reverse/

reinforcement stitches. (page 34)

3 Needle position button

Press the needle position button to raise or lower the needle.

Pressing the button twice sews one stitch.

4 Thread cutter button

Press the thread cutter button after sewing is stopped to cut

both the upper and the bobbin threads.

5 Sewing speed controller

Slide the sewing speed controller to adjust the sewing speed.

The sewing speed cannot be adjusted while sewing decorative

stitches or embroidering.

■ Operation panel and operation keys

1 LCD (liquid crystal display) (touch panel)

Selected pattern settings and messages are displayed.

Touch the keys displayed on the LCD to perform operations.

For details, refer to “LCD Operation” on page 13.

2 Previous page key

Displays the previous screen when there are items that are not

displayed on the LCD.

3 Next page key

Displays the next screen when there are items that are not

displayed on the LCD.

4 Help key

Touch to get help on using the machine.

5 Settings key

Touch to set the needle stop position, the buzzer sound, and

more.

6 Embroidery key

Touch to display the pattern type selection screen.

7 Utility stitch key

Touch to sew a utility stitch or decorative stitch.

8 Back key

Touch to return to the previous screen.

9 Presser foot/Needle exchange key

Touch this key before changing the needle, the presser foot,

etc. This key locks all key and button functions (except ) to

prevent operation of the machine.

Green: The machine is ready to sew or is sewing.

Red: The machine cannot sew.

Orange: The machine is winding the bobbin thread, or

the bobbin winder shaft is moved to the right

side.

a b

cd e

Note

• The operation keys of this machine are capacitive

touch sensors. Operate the keys by directly

touching them with your finger.

• Since the operation keys react differently

depending on the user, adjust the setting for

“Adjusting input sensitivity for operation keys” on

page 16.

• When using an electrostatic touch pen, make sure

that its point is 8 mm or more. Do not use a touch

pen with a thin point or a unique shape.

Included Accessories

GETTING READY

For included accessories of your machine, refer to the

additional sheet “Included Accessories”.

Pull the top of the flat bed attachment to open the accessory

compartment.

Included Accessories Turning the Machine On/Off

WARNING

• Use only regular household electricity for the

power source. Using other power sources may

result in fire, electric shock, or damage to the

machine.

• Do not touch the plug with wet hands. Electric

shock may result.

• Make sure that the plugs on the power cord

are firmly inserted into the electrical outlet

and the power cord receptacle on the

machine. Otherwise, a fire or electric shock

may result.

• Turn the main power to OFF and remove the

plug in the following circumstances:

• When you are away from the machine

• After using the machine

• When the power fails during use

• When the machine does not operate correctly

due to a bad connection or a disconnection

• During electrical storms

CAUTION

• Use only the power cord included with this

machine. Otherwise, a fire or electric shock

may result.

• Do not use extension cords or multi-plug

adapters with any other appliances plugged

into them. Fire or electric shock may result.

• When unplugging the machine, always turn

the main power to OFF first. Always grasp the

plug to remove it from the electrical outlet.

Pulling on the cord may damage the cord, or

lead to fire or electric shock.

• Do not allow the power cord to be cut,

damaged, modified, forcefully bent, pulled,

twisted, or bundled. Do not place heavy

objects on the cord. Do not subject the cord to

heat. These things may damage the cord, or

cause fire or electric shock. If the cord or plug

is damaged, take the machine to your

authorized Brother dealer for repairs before

continuing use.

• Do not insert the plug on the power cord into

an electrical outlet that is in poor condition.

Turning the Machine On/Off

Make sure that the machine is turned off (the main

power switch on the right side of the machine is set to

“ ”), and then plug the power cord into the power

supply jack underneath it.

Insert the plug of the power cord into a household

electrical outlet.

1 Power supply jack

2 Main power switch

Press the right side of the main power switch to turn

the machine on (set it to “I”).

 The light, LCD and the “Start/Stop” button light up

when the machine is turned on. The needle and the

feed dogs will make a sound when they move; this is

not a malfunction.

When the machine is turned on, the opening movie is

played. Touch anywhere on the screen.

To turn off the machine, press the left side of the main

power switch (set it to “ ”).

CAUTION

•(For U.S.A. only)

This appliance has a polarized plug (one blade

wider than the other). To reduce the risk of

electrical shock, this plug is intended to fit in a

polarized electrical outlet only one way.

If the plug does not fit fully in the electrical

outlet, reverse the plug. If it still does not fit,

contact a qualified electrician to install the

proper electrical outlet. Do not modify the

plug in any way.

Note

When you first turn on the machine:

• Select the display language for the LCD.

• The following message about a wireless LAN

connection appears. To set up a connection, touch

, and then refer to steps c through f in

“Using the wizard to set up the wireless network

connection” on page 17 to finish setting up a

wireless LAN connection.

LCD Operation

GETTING READY

Viewing the LCD

An opening movie may be displayed when the power is turned on.

When the opening movie is displayed, the screen will be displayed if you touch the LCD with your finger.

Touch a key with your finger to select the stitch pattern, to select a machine function, or to select an operation indicated on the

key. The screen below appears when you touch on the operation panel.

LCD Operation

1 Utility stitch

2 Decorative stitch

3 Wireless LAN key

Set the wireless LAN connection. (page 17)

If is displayed, update the software. (page 97)

4 Pattern retrieve key (page 59)

■ Utility stitch screen ■ Utility stitch editing screen

■ Decorative stitch screen ■ Decorative stitch editing screen

Note

• Some editing functions cannot be used with certain stitch patterns. Only the functions for the displayed keys are

available when a stitch pattern is selected.

No. Display Key Name Explanation Page

1 – Stitches Touch the key for the stitch you want to sew. 31

2 Stitch pattern display size Shows the approximate size of the stitch pattern selected. –

3 – Stitch preview Shows a preview of the selected stitch. –

4 Presser foot Shows presser foot to be used. Before sewing, install the presser foot indicated here. 29

Zigzag foot “J” Blind stitch foot “R”

Monogramming foot “N” Button fitting foot “M”

Overcasting foot “G” Side cutter “S” (sold separately)

Buttonhole foot “A”

* The symbols for certain presser feet, such as zipper foot “I” and the quilting foot,

may not appear in the screen.

876

E D B

876

E D B

LCD Operation

5 Needle position setting Shows single or twin needle mode setting, and the needle stop position. 15

: Single needle/down position

: Twin needle/down position

: Single needle/up position : Twin needle/up position

6 Stitch width Shows the stitch width of the currently selected stitch pattern. 35

7 Stitch length Shows the stitch length of the currently selected stitch pattern. 35

8 L/R Shift Shows the distance of left/right shift from the original position. 35

9 Manual adjustment key Touch this key to display the adjustment screen of the stitch width, stitch length and

“L/R Shift”.

0 Page display Shows additional pages that can be displayed. –

A Edit/stitch switching key Touch this key to toggle between the stitch editing screen and the stitch screen. 33

B Image key Shows a preview of the sewn image.

Touch to change the thread color in the image to red, blue, or black.

–

C Memory key Touch this key to save combined stitch patterns. 59

D Automatic thread cutting

key

Touch this key to set the automatic thread cutting function. 34

E Automatic reverse/

reinforcement key

Touch this key to use the automatic reverse/reinforcement stitch function. 34

F Single/repeat sewing key Touch this key to choose single stitch pattern or continuous stitch patterns.

Depending on the selected stitch, this key may be disabled. To finish a complete

motif while sewing the stitch pattern continuously, you can touch this key while

sewing. The machine will automatically stop when the motif is finished.

–

G Back to beginning key When sewing is stopped, touch this key to return to the beginning of the stitch

pattern.

–

H Mirror image key After selecting the stitch pattern, use this key to create a horizontal mirror image of

the stitch pattern.

–

I Some of the following keys will appear, depending on the selected stitch pattern.

Elongation key

When satin stitch patterns are selected, touch this key to choose from 5

automatic length settings, without changing the stitch zigzag width or stitch length

settings.

–

Thread density key

After selecting the decorative satin stitch pattern , use this key to change the

thread density of the stitch pattern.

: Low density

: High density

If the stitches bunch when thread density is changed to , return the thread

density to . If you continue sewing when the stitches are bunched, the needle

may bend or break.

–

J Delete key Touch this key to delete the selected stitch pattern. When you make a mistake in

combining stitch patterns, use this key to delete stitch patterns.

–

No. Display Key Name Explanation Page

LCD Operation

GETTING READY

Settings screen

Touch to change the default machine settings. Touch

or , after you changed necessary settings.

■ Sewing settings

1 Select whether to use the sewing speed controller to

determine the zigzag width. (page 52)

When a straight stitch is selected, the sewing speed

controller can be used to change the needle position.

(page 38)

2 Make adjustments to decorative stitch patterns.

(page 58)

3 Set to [ON] when using twin needle. (page 56)

4 Select either “1-01 Straight stitch (Left)” or “1-03 Straight

stitch (Middle)” as the utility stitch that is automatically

selected when the machine is turned on.

■ Embroidery settings

1 Select the embroidery frame to be used.

2 Select the center mark and grid lines that are displayed.

3 When set to [ON], you can only select the embroidery

pattern corresponding to the embroidery frame size that

you selected in

1. (page 68)

4 Select the thread color display on the embroidery

screen; thread number, color name. (page 71)

5 Select the thread brand. (page 71)

6 Select the display units (mm/inch).

7 Select the size of pattern thumbnails.

8 Select the color of the background for the embroidery

display area.

9 Select the color of the background for the thumbnail

area.

■ General settings

1 Select the needle stop position (the needle position for

when the machine is not being operated) to be up or

down.

2 Select whether to hear the beep operation sound.

3 Select whether to display the opening screen when the

machine is turned on.

4 Select the display language.

5 Select whether to turn work area light on or off.

6 Select the level of the input sensitivity for operation keys.

(page 16)

7 Display the service count which is a reminder to take

your machine in for regular servicing. (Contact your

authorized Brother dealer for details.)

8 Display the total number of stitches sewn on this

machine.

9 The [No.] is the internal machine number for your

machine.

0 Display the program version installed on your machine.

Memo

• The latest version of software is installed in your

machine. Check with your local authorized Brother

dealer or at https://s.brother/cpjap/ for available

updates.

• You can save the current settings screen image in

a USB flash drive by touching when the USB

flash drive is inserted into the USB port. The files

are saved in a folder labeled “bPocket”.

LCD Operation

■ Wireless LAN settings

1 Enable/disable the wireless LAN function. (page 17)

2 Display the connected SSID. (page 17)

3 Set the machine to connect wireless LAN function.

(page 17)

4 Check the wireless LAN status.

5 Display the machine name of wireless LAN function.

6 Change [Machine name].

7 Display a menu to perform other settings or reset the

connection settings of the wireless LAN settings.

(page 19)

8 Check the latest version of the software.

The version will display in [Latest Version Available].

9 Display the latest version of the software.

0 Display a message if [New update on server] is available

for this machine.

If [New update on server] appears, update the machine.

(page 97)

Adjusting input sensitivity for operation keys

You can adjust the sensitivity of the operation keys to 5 levels.

Display the settings screen to set desired level.

Touch to display the settings screen.

Display page 7 by touching / .

Touch [Start].

Adjust the [Input Sensitivity] by touching / .

• The higher the setting, the more sensitive the keys

will be. The default setting is [3].

• We recommend selecting the highest setting if an

electrostatic touch pen is being used.

• While adjusting the input sensitivity, touch to

check whether the key responds.

When the key responds, the setting value indicating

the sensitivity blinks.

Touch to return to previous screen.

■ If the machine does not respond when an

operation key is touched

Turn machine off, then hold down (Thread cutter

button) and turn on the machine to reset [Input

Sensitivity]. Display the settings screen, and then adjust

the [Input Sensitivity] again.

Wireless Network Connection Functions

GETTING READY

Operations available with a wireless

network connection

This machine supports a wireless network connection. The

following useful operations will be available if the machine is

connected to a wireless network.

• Wirelessly transfer an embroidery pattern from your

computer to the machine by using the dedicated

Windows application (Design Database Transfer).

The application can be downloaded from the

following URL.

https://s.brother/cajkb/

* Settings must be specified in Design Database

Transfer. For more information, refer to the manual

for Design Database Transfer.

• Wirelessly transfer to the machine an embroidery

pattern edited with embroidery editing software (PE-

DESIGN version 11 or later) on a computer. Also,

transfer to PE-DESIGN an embroidery pattern edited

on the machine.

* Settings must be specified in PE-DESIGN. For more

information, refer to the manual for PE-DESIGN.

• When an updated version of the software is available

on our website, the wireless LAN key appears as

. (page 97)

Enabling a wireless network connection

The machine can be connected to your wireless network.

Refer to “Specifications” on page 96 for requirements for a

wireless network connection.

Touch .

 Page 9 of the settings screen is displayed.

Set [Wireless LAN Enable] to [ON].

 The machine prepares for wireless connection.

Using the wizard to set up the wireless

network connection

There are multiple ways to set up the wireless network

connection. We recommend the method that uses the wizard

on this machine.

In order to connect your machine to a wireless

network, the security information (SSID and network

key) for your home network will be required. The

network key may also be called a password, security

key or encryption key. Check your security

information, and write it in the space below.

Wireless Network Connection

Functions

SSID Network key (password)

Memo

• The wireless network connection cannot be set up

if you do not have the security information.

• How to find the security information

1 Check the manual provided with your home

network.

2 The default SSID may be the manufacturer's

name or the model name.

3 If you cannot find the security information,

contact the manufacturer of the router, your

network administrator or your Internet provider.

4 Some SSIDs and network keys (passwords) may

be case sensitive.

Wireless Network Connection Functions

Touch beside [Wireless LAN Setup Wizard].

 A list of available SSIDs appears.

Select the SSID that was noted in step a.

 The screen for entering the network key (password)

appears.

Enter the network key (password) that was noted, and

then touch .

1 Text input area

2 Character keys

3 Caps key

4 Space key

5 Letters/numbers/symbols key

6 Cursor keys (Move the cursor to the left or right.)

7 Backspace key (Deletes the character at the cursor's

position.)

When the following message appears, touch .

 When a connection is established, the following

message appears.

Touch to exit the setup.

 Use the [Machine name] on page 10 of the settings

screen for the wireless LAN function.

Memo

• When displaying next or previous pages, touch

or to search the SSID that was noted.

• If the desired SSID is not listed, specify it as

described below.

1 Touch in the end of the SSID list.

2 Enter the desired SSID, and then touch .

3 Select the authentication method and encryption

mode.

• If using a previous connection, touch ,

and then select the saved SSID.

Memo

• While connected, the signal strength can be

confirmed by the wireless LAN key in the lower

right of the stitch or pattern type selection screen.

• Once a wireless network connection has been set

up, a wireless network connection will be

established each time the machine is turned on.

However, [Wireless LAN Enable] in the wireless

LAN settings screen must remain set to [ON].

Winding/Installing the Bobbin

GETTING READY

■ Setting the wireless LAN connection from the

[Others] menu

The [Others] menu on page 10 of the settings screen

contains the following items.

1 TCP/IP settings can be manually entered.

2 Shows the MAC address.

3 Use when proxy settings are required.

4 Resets the wireless LAN connection settings.

Winding the bobbin

This section describes how to wind thread onto a bobbin.

Place the bobbin on the bobbin winder shaft so that the

notch in the bobbin aligns with the spring on the shaft,

and then slide the bobbin winder shaft to the right until

it snaps into place.

Winding/Installing the Bobbin

IMPORTANT

• Use the plastic bobbin that comes with this

machine or bobbins of the same type. The

bobbin's height is 11.5 mm (approx. 7/16

inch). SA156 is a Class 15 type bobbin.

Note

• When winding the bobbin for sewing utility stitches,

use thread appropriate for the fabric that you wish

to sew (page 27). Normally, the thread will be the

same as what is used for the upper threading.

• When winding bobbin for embroidery, be sure to

use the recommended 60 weight embroidery

bobbin thread for this machine.

1 Notch

2 Bobbin winder

shaft spring

Memo

• By placing the bobbin into the bobbin case in the

same orientation that it was on the bobbin winder

shaft, the bobbin can be installed with the correct

winding direction of the bobbin thread.

The “b” mark on one side of the bobbin included

with this machine can be used as a reference.

Winding/Installing the Bobbin

Remove the spool cap and place the spool of thread for

the bobbin onto the spool pin.

Slide the spool onto the spool pin so that the thread

unwinds to the front from the bottom.

1 The thread unwinds to the front from the bottom.

Slide the spool cap onto the spool pin.

Slide the spool cap as far as possible to the right, as

shown, with the rounded side on the left.

While holding the pulled-out thread so that there is no

slack in it, pass the thread under the hook of the thread

guide, then under the thread guide cover and to the

front.

1 Thread guide

2 Thread guide cover

Pass the thread under the hook on the bobbin winding

thread guide, and then wind it counterclockwise under

the pretension disk.

1 Bobbin winding thread guide

2 Pretension disk

3 Pull it in as far as possible

IMPORTANT

• If the spool or the spool cap is not installed

correctly, the thread may become tangled

around the spool pin, and the machine may be

damaged.

• Three spool cap sizes are available, allowing

you to choose a spool cap that best fits the size

of spool being used. If the spool cap is too

small for the spool being used, the thread may

catch on the slit in the spool or the machine

may be damaged. When using mini king thread

spool, use the thread spool insert (mini king

thread spool).

Note

• When using the spool as shown below, use the

thread spool insert (mini king thread spool).

Make sure that the thread spool insert is firmly

inserted. After installing it, pull out some thread,

and check that the thread unwinds without getting

caught.

• When using thread that winds off quickly, such as

transparent nylon thread or metallic thread, place

the spool net over the spool before placing the

spool of thread onto the spool pin.

If the spool net is too long, fold it to fit the size of

the spool.

Note

• Make sure that the thread is passed under the

pretension disk.

1 Thread spool insert

(mini king thread

spool)

2 Hole diameter

8.0 mm to 10.5 mm

(5/16 inch to 13/32

inch)

3 Spool (cross-

wound thread)

Winding/Installing the Bobbin

GETTING READY

Wind the thread clockwise around the bobbin 5 or 6

times, pass the thread through the guide slit in the

bobbin winder seat, and then pull the thread to cut it.

1 Guide slit in bobbin winder seat

(with built-in cutter)

Slide the sewing speed controller to adjust the bobbin

winding speed. Slide the controller to the right to

increase the speed; slide it to the left to reduce the

speed.

Turn on the machine.

• The “Start/Stop” button lights up in orange.

Press the “Start/Stop” button to start winding the

bobbin.

When the foot controller is plugged in, press down on

the foot controller.

When the bobbin winding becomes slow, press the

“Start/Stop” button to stop the machine.

When the foot controller is plugged in, remove your

foot from the foot controller.

Cut the thread, slide the bobbin winder shaft to the left

until it snaps into place, and then remove the bobbin.

Slide the sewing speed controller to desired sewing

speed position.

Remove the spool for the bobbin thread from the spool

pin.

Note

• Be sure to wind the thread clockwise around the

bobbin, otherwise the thread will become wrapped

around the bobbin winder shaft.

CAUTION

• Be sure to cut the thread as described. If the

bobbin is wound without cutting the thread

using the cutter built into the guide slit in the

bobbin winder seat, the thread may become

tangled in the bobbin or the needle may break

and cause injury when the bobbin thread starts

to run out.

Memo

• We recommend winding stretch thread, such as

transparent nylon thread, at a low speed since the

thread may stretch.

IMPORTANT

• When winding transparent nylon thread on the

bobbin, stop bobbin winding when the bobbin

is 1/2 to 2/3 full. If the bobbin was fully

wound with transparent nylon thread, it may

not be wound neatly, or sewing performance

may suffer. In addition, extreme pressure may

be applied to the bobbin, it may not be

possible to remove the bobbin from the bobbin

winder shaft, or the bobbin may break.

IMPORTANT

• When the bobbin winding becomes slow, stop

the machine, otherwise the machine may be

damaged.

Winding/Installing the Bobbin

Installing the bobbin

Install the bobbin wound with thread.

You can begin sewing immediately without pulling up the

bobbin thread by simply inserting the bobbin in the bobbin

case and guiding the thread through the slit in the needle

plate cover.

Turn on the machine.

Press (Needle position button) once or twice to

raise the needle.

Touch .

 The screen changes, and all keys and operation

buttons are locked (except ).

Raise the presser foot lever.

Slide the bobbin cover latch to the right and remove

the bobbin cover.

Insert the bobbin into the bobbin case so that the

thread unwinds to the left.

Lightly hold down the bobbin with your right hand

(1), and then guide the end of the thread around the

tab of the needle plate cover with your left hand (2).

Memo

• If the threads will be pulled to create gathers or the

thread at the beginning of sewing will be finished,

for example, when free motion quilting, first pull up

the bobbin thread.

For details, refer to “Pulling up the bobbin thread”

on page 26.

CAUTION

• Use a bobbin that has been correctly wound

with thread, otherwise there is a risk of poor

thread tension or injury due to the needle

breaking.

• Before inserting or changing the bobbin, be

sure that you have touched on the

operation panel to lock all keys and buttons,

otherwise injuries may occur if the “Start/

Stop” button or any other button is pressed

and the machine starts.

Memo

• For the correct winding direction of the bobbin

thread, be sure to place the bobbin into the bobbin

case in the same orientation that it was on the

bobbin winder shaft.

The “b” mark on one side of the bobbin included

with this machine can be used as a reference.

1 Tab

Note

• Be sure to hold down the bobbin with your finger

and unwind the bobbin thread correctly, otherwise

the thread may break or the thread tension will be

incorrect.

Upper Threading

GETTING READY

While lightly holding down the bobbin with your right

hand (1), guide the thread through the slit in the

needle plate cover (2) and lightly pull it with your left

hand (3).

While lightly holding down the bobbin with your right

hand (1), continue guiding the thread through the slit

with your left hand (2). Then, cut the thread with the

cutter (3).

Reattach the bobbin cover.

Insert the tab of the bobbin cover into the notch of the

needle plate cover, and then lightly press down on the

right side.

Touch to unlock all keys and buttons.

Threading the upper thread

Turn on the machine.

Press (Needle position button) once or twice to

raise the needle.



If the needle is not raised to it's highest position, the needle

threader cannot thread the needle. Be sure to press

(Needle position button) to raise the needle to it's highest

position.

Memo

• By pulling the thread in this way, the thread will

enter the tension spring of the bobbin case to apply

the appropriate tension to the bobbin thread during

sewing.

Upper Threading

CAUTION

• When threading the upper thread, carefully

follow the instructions. If the upper threading

is not correct, the thread may become tangled

or the needle may break and cause injury.

IMPORTANT

• Never use a thread weight of 20 or lower. It

may cause the machine to malfunction.

Use the needle and the thread in the correct

combination. For details on the correct

combination of needles and threads, refer to

“Fabric/Thread/Needle Combinations” on

page 27.

Upper Threading

Touch .

 The screen changes, and all keys and operation

buttons are locked (except ).

Raise the presser foot lever to raise the presser foot.

Remove the spool cap and place the spool of thread

onto the spool pin.

Slide the spool onto the spool pin so that the thread

unwinds to the front from the bottom.

1 The thread unwinds to the front from the bottom.

Slide the spool cap onto the spool pin.

Slide the spool cap as far as possible to the right, as

shown, with the rounded side on the left.

While holding the pulled-out thread so that there is no

slack in it, pass the thread under the hook of the thread

guide, then under the thread guide cover and to the

front.

1 Thread guide

2 Thread guide cover

Pass the thread through the thread channel in the order

shown below.

CAUTION

• When threading the needle, be sure to touch

on the operation panel to lock all keys

and buttons, otherwise injuries may occur if

the “Start/Stop” button or any other button is

pressed and the machine starts.

Memo

• If the presser foot is not raised, the machine cannot

be threaded.

CAUTION

• Choose a spool cap that best fits the size of

spool being used. For more information

regarding the choice of spool caps for your

thread choice, refer to “Note” on page 20.

If the spool or the spool cap is not positioned

correctly, the thread may become tangled

around the spool pin or the needle may break

and cause injury.

Upper Threading

GETTING READY

Make sure that the thread is passed into the thread

take-up lever as shown below.

Slide the thread behind the needle bar thread guide.

The thread can easily be slid behind the needle bar

thread guide by holding the thread in your left hand,

then feeding the thread with your right hand, as shown.

Make sure that the thread is passed through to the left of

the tab of the needle bar thread guide.

Check that the needle and thread are compatible with

the needle threader. If they are compatible, continue

with the next step.

• The needle threader can be used with machine

needles 75/11 through 100/16.

• The needle threader cannot be used with the twin

needle.

• When thread such as transparent nylon

monofilament or specialty threads are used, it is not

recommended to use the needle threader.

• If the needle threader cannot be used, insert the

thread through the eye of the needle from front to

back by hand.

Pull the end of the thread, which has been passed

through the needle bar thread guide, to the left, then

pass the thread through the notch of the thread guide,

and then firmly pull the thread from the front and

insert it into the slit of the thread guide disk marked

“7” all the way.

1 Notch of the thread guide

2 Thread guide disk

Lower the presser foot lever to lower the presser foot.

Cut the thread with the thread cutter on the left side of

the machine.

Lower the needle threader lever on the left side of the

machine as much as possible to make the hook turn.

1 Needle threader lever

2 Needle

3 Hook

Raise the needle threader lever slowly.

1 Needle bar thread

guide

2 Tab

Note

• When using thread that quickly winds off the spool,

such as metallic thread, it may be difficult to thread

the needle if the thread is cut.

Therefore, instead of using the thread cutter, pull

out about 8 cm (approx. 3 inches) of thread after

passing it through the thread guide disk (marked

“7”).

Upper Threading

Carefully pull the end of thread that was passed

through the eye of the needle.

If the needle was not completely threaded, but a loop in

the thread was formed in the eye of the needle, carefully

pull the loop through the eye of the needle to pull out

the end of the thread.

Raise the presser foot lever, pass the end of the thread

through and under the presser foot, and then pull out

about 10 cm (approx. 4 inches) of thread toward the

rear of the machine.

Touch to unlock all keys and buttons.

Pulling up the bobbin thread

If the threads will be pulled to create gathers or the thread at

the beginning of sewing will be finished, for example, when

free motion quilting, first pull up the bobbin thread.

Refer to “Threading the upper thread” on page 23 to

thread the machine with the upper thread and thread

the needle.

Follow steps a to f “Installing the bobbin” on

page 22 for installing the bobbin and to insert the

bobbin into the bobbin case.

Pass the bobbin thread through the slot.

Do not cut the thread with the cutter, otherwise it will

be difficult to pull up the bobbin thread.

Touch to unlock all keys and buttons.

While lightly holding the upper thread with your left

hand, press (Needle position button) twice to lower

and then raise the needle.

 The bobbin thread is looped around the upper thread

and can be pulled up.

Carefully pull the upper thread upward to pull out the

end of the bobbin thread.

Pull up the bobbin thread, pass it under the presser

foot and pull it about 10 cm (4 inches) toward the back

of the machine, making it even with the upper thread.

Reattach the bobbin cover.

Memo

• You can begin sewing without pulling up the

bobbin thread. If you wish to pull up the bobbin

thread before starting to sew, pull up the thread

according to the procedure in “Pulling up the

bobbin thread” on page 26.

Fabric/Thread/Needle Combinations

GETTING READY

• Needles that can be used with this machine: Home sewing machine needles (size 65/9 - 100/16)

* The larger the number, the larger the needle. As the numbers decrease, the needles get finer.

• Thread that can be used with this machine: 30 - 90 weight

* Never use thread of 20 weight or lower. It may cause machine to malfunction.

* The smaller the number, the heavier the thread. As the numbers increase, the thread gets finer.

• The machine needle and thread that should be used depends on the type and thickness of the fabric. Refer to

the following table when choosing the thread and needle appropriate for the fabric that you wish to sew.

- The combinations shown in the table provide a general guideline. Be sure to sew trial stitches on the actual number of

layers and type of fabric to be used in your project.

- The machine needles are consumables. For safety and best results, we recommend replacing the needle regularly. For

details on when to replace the needle, refer to “Checking the needle” on page 28.

• In principle, use a fine needle and thread with lightweight fabrics, and a larger needle and heavier thread with

heavyweight fabrics.

• Select a stitch appropriate for the fabric, and then adjust the stitch length. When sewing lightweight fabrics,

make the stitch length finer (shorter). When sewing heavyweight fabrics, make the stitch length coarser

(longer). (page 35)

When sewing stretch fabrics, refer to “Sewing stretch fabrics” on page 39.

■ Transparent nylon thread

Use a home sewing machine topstitching needle, regardless of the fabric or thread.

■ Sewing decorative stitch patterns (needles and threads)

When sewing lightweight, medium weight or stretch fabrics, use a ball point needle (gold colored) 90/14. When sewing

heavyweight fabrics, use a home sewing machine needle 90/14.

In addition, #50 to #60 thread should be used.

■ Embroidery needles

Use a 75/11 home sewing machine needle for embroidery.

Fabric/Thread/Needle Combinations

Fabric Type/Application

Thread

Size of needle

Stitch length

mm (inch)

Type Weight

Lightweight

fabrics

Lawn, georgette, challis, organdy,

crepe, chiffon, voile, gauze, tulle,

lining, etc.

Polyester

thread

60 - 90

65/9 - 75/11

Fine stitches

1.8-2.5

(1/16-3/32)

Cotton thread,

Silk thread

50 - 80

Medium weight

fabrics

Broadcloth, taffeta, gabardine,

flannel, seersucker, double gauze,

linen, terry cloth, waffle weave,

sheeting, poplin, cotton twill, satin,

quilting cotton, etc.

Polyester

thread

60 - 90

75/11 - 90/14

Regular stitches

2.0-3.0

(1/16-1/8)

Cotton thread,

Silk thread

50 - 60

Heavyweight

fabrics

Denim (12 ounces or more), canvas,

etc.

Polyester

thread,

Cotton thread

30 100/16

Coarse stitches

2.5-4.0

(3/32-3/16)

Denim (12 ounces or more), canvas,

tweed, corduroy, velour, melton

wool, vinyl-coated fabric, etc.

Polyester

thread

90/14 - 100/16

Cotton thread,

Silk thread

30 - 50

Stretch fabrics

(knit fabrics, etc.)

Jersey, tricot, T-shirt fabric, fleece,

interlock, etc.

Polyester thread,

Cotton thread,

Silk thread

Ball point needle

75/11 - 90/14

Setting appropriate for

the fabric thickness

For top-stitching

Polyester thread,

Cotton thread

30 90/14 - 100/16

Setting appropriate for

the fabric thickness

50 - 60 75/11 - 90/14

CAUTION

• The appropriate fabric, thread and needle combinations are shown in the preceding table. If the

combination of the fabric, thread and needle is not correct, particularly when sewing heavy fabrics (such

as denim) with thin needles (such as 65/9 to 75/11), the needle may break and cause injury. In addition,

the stitching may be uneven or puckered or there may be skipped stitches.

Replacing the Needle

Checking the needle

Before using the needle, place the flat side of the needle on a

flat surface and check that the distance between the needle

and the flat surface is even.

Replacing the needle

Use the screwdriver and a new needle that has been

determined to be straight according to the instructions in

“Checking the needle” on page 28.

Press (Needle position button) once or twice to

raise the needle.

Place fabric or paper under the presser foot to cover

the hole in the needle plate to prevent the needle from

falling into the machine.

Touch .

 The screen changes, and all keys and operation

buttons are locked (except ).

Follow steps c to d “Replacing the presser foot” on

page 29 for removing the presser foot.

Hold the needle with your left hand, and then use a

screwdriver to turn the needle clamp screw toward

you (counterclockwise) to remove the needle.

• Do not apply a strong force when loosening or

tightening the needle clamp screw, otherwise certain

parts of the machine may be damaged.

• The needle clamp screw can also be turned with the

disc-shaped screwdriver.

With the flat side of the needle toward the rear of the

machine, insert the new needle until it touches the

needle stopper. Using the screwdriver tighten the

needle clamp screw by turning it clockwise.

Follow steps e to g “Replacing the presser foot” on

page 29 for reattaching the presser foot.

Touch to unlock all keys and buttons.

Replacing the Needle

CAUTION

• Only use recommended home sewing machine

needles. Use of any other needle may break

the needle, possibly resulting in injury.

• Never use bent needles. Bent needles can

easily break, possibly resulting in injuries.

1 Flat side

2 Needle type marking

3 Flat surface

4 Even

5 Not even

Note

• The machine needles are consumables. Replace

the needle in cases such as those described

below.

- If an unusual sound is produced when the needle

enters the fabric. (The tip of the needle may be

broken or dull.)

- If stitches are skipped. (The needle may be bent.)

- Generally, after completing one project, such as

a piece of clothing.

CAUTION

• When replacing the needle, be sure to touch

on the operation panel to lock all keys

and buttons, otherwise injuries may occur if

the “Start/Stop” button or any other button is

pressed and the machine starts.

1 Needle stopper

CAUTION

• Be sure to insert the needle until it touches the

needle stopper and securely tighten the needle

clamp screw with the screwdriver, otherwise

the needle may break and cause injury.

Replacing the Presser Foot

GETTING READY

Replacing the presser foot

Press (Needle position button) once or twice to

raise the needle.

Touch .

 The screen changes, and all keys and operation

buttons are locked (except ).

Raise the presser foot lever.

Press the black button at the back of the presser foot

holder in order to remove the presser foot.

Place the appropriate presser foot below the presser

foot holder so that the presser foot pin is aligned with

the notch in the holder.

Slowly lower the presser foot lever so that the presser

foot pin snaps into the notch in the presser foot holder.

1 Presser foot lever

2 Presser foot holder

3 Notch

4 Pin

 The presser foot is attached.

Raise the presser foot lever to check that the presser

foot is securely attached.

Touch to unlock all keys and buttons.

Replacing the Presser Foot

CAUTION

• Use the appropriate presser foot for the type

of stitch that you wish to sew, otherwise the

needle may hit the presser foot. The needle

may break, possibly resulting in injury. For

details on the presser foot that should be used

with the selected stitch, refer to “Stitch Chart”

on page 41.

IMPORTANT

• Use presser feet designed specifically for this

machine.

Note

• When a stitch is selected, the icon for the presser

foot that should be used appears in the screen.

Check that the correct presser foot is attached

before starting to sew. If the wrong presser foot is

installed, attach the appropriate presser foot.

(page 13)

CAUTION

• When replacing the presser foot, be sure to

touch on the operation panel to lock all

keys and buttons, otherwise injuries may occur

if the “Start/Stop” button or any other button

is pressed and the machine starts.

1 Black button

2 Presser foot holder

1 Presser foot holder

2 Notch

3 Pin

4 Presser foot type

Replacing the Presser Foot

Removing and attaching the presser foot

holder

Remove the presser foot holder when installing a presser foot

that does not use the presser foot holder.

■ Removing the presser foot holder

Touch .

 The screen changes, and all keys and operation

buttons are locked (except ).

Remove the presser foot.

• For details, refer to “Replacing the presser foot” on

page 29.

Use the screwdriver to loosen the presser foot holder

screw.

Turn the screw toward the back of the machine

(counterclockwise).

• The presser foot holder screw can also be loosened

or tightened with the disc-shaped screwdriver.

Touch to unlock all keys and buttons.

■ Attaching the presser foot holder

Touch .

 The screen changes, and all keys and operation

buttons are locked (except ).

Raise the presser foot lever.

Align the notch in the presser foot holder with the

screw.

Hold the presser foot holder in place with your right

hand, and then tighten the screw using the screwdriver

in your left hand.

Turn the screw toward you (clockwise).

Touch to unlock all keys and buttons.

1 Screw

2 Notch in presser foot

holder

CAUTION

• Be sure to securely tighten the presser foot

holder screw, otherwise the presser foot

holder may fall off and the needle may strike

it, causing the needle to break and possibly

resulting in injuries.

Sewing

SEWING BASICS

Stitch types

1 Utility stitches (page 41)

You can select from utility stitches, including straight line

stitching, overcasting, buttonhole and basic decorative

stitches.

2 Decorative stitches

3 Decorative satin stitches

4 Satin stitches

5 Cross stitch stitches

6 Stitch patterns stored in the machine's memory or USB

flash drive (page 59)

Basic sewing

Prepare the appropriate needle and thread for the type

of fabric. (page 27)

If necessary, replace the needle. (page 28)

Wind thread onto a bobbin, and then install it into the

machine. (page 19)

Thread the upper thread. (page 23)

Touch on the operation panel and select the stitch

type.

Select a stitch.

displays the previous screen, and displays the

next screen.

• For details on the key functions, refer to “Viewing the

LCD” on page 13.

• If necessary, change to the desired stitch width or

stitch length. (page 35)

Check which presser foot is indicated in the upper-left

corner of the screen, and then attach it.

Attach zigzag foot “J” in this procedure. (It is on the

machine when purchased.)

• For details on changing the presser foot, refer to

“Replacing the Presser Foot” on page 29.

Chapter 2

SEWING BASICS

Sewing

CAUTION

• While the machine is in operation, pay special

attention to the needle location. In addition,

keep your hands away from all moving parts

such as the needle and handwheel, otherwise

injuries may occur.

• Do not pull or push the fabric too hard while

sewing, otherwise the needle may break and/

or injuries may occur.

• Never use bent needles. Bent needles can

easily break, possibly resulting in injuries.

• Make sure that the needle does not strike

basting pins, otherwise the needle may break

and cause injury.

2 3 4 6

Note

• First, perform a trial sewing, using a piece of fabric

and thread that are the same as those used for

your project.

CAUTION

• Always use the correct presser foot. If the

wrong presser foot is used, the needle may

strike the presser foot. The needle may break,

possibly resulting in injury.

Refer to “Stitch Chart” on page 41 for presser

foot recommendations.

Sewing

Set the fabric under the presser foot. Hold the fabric

and thread with your left hand, and rotate the

handwheel counterclockwise or press (Needle

position button) to set the needle in the sewing start

position.

Lower the presser foot lever.

Adjust the sewing speed with the sewing speed

controller. (when using utility stitches)

Press the “Start/Stop” button to start sewing. (When

the foot controller is plugged in, slowly press down on

the foot controller.)

Guide the fabric lightly by hand.

Press the “Start/Stop” button again to stop sewing.

(When the foot controller is plugged in, remove your

foot from the foot controller.)

Press (Thread cutter button) to trim the upper and

bobbin threads.

When the needle has stopped moving, raise the presser

foot lever and remove the fabric.

Check the sewing finish. If necessary, adjust the thread

tension. (page 36)

■ Using the foot controller

You can also use the foot controller to start and stop

sewing.

Turn off the machine.

Insert the foot controller plug into the foot controller

jack on the machine.

Turn on the machine.

1 Fast

2 Slow

Memo

• When the foot controller is connected, the “Start/

Stop” button cannot be used to start sewing.

IMPORTANT

• Do not press (Thread cutter button) after

the threads have been cut. Doing so could

tangle the thread or damage the machine.

• Do not press (Thread cutter button) when

there is no fabric set in the machine. The

thread may tangle, possibly resulting in

damage.

Note

• When cutting thread such as nylon monofilament

thread, or other decorative threads, use the thread

cutter on the left side of the machine.

Memo

• (For U.S.A. only) Foot controller: Model T

This foot controller can be used on the machine

with product code 888-P10. The product code is

mentioned on the machine rating plate.

• When the foot controller is connected, the “Start/

Stop” button cannot be used to start sewing.

• Bobbin winding can be started and stopped with

the foot controller.

• The foot controller cannot be used when

embroidering.

1 Foot controller jack

Sewing

SEWING BASICS

Slowly depress the foot controller to start sewing.

Release the foot controller to stop sewing.

Combining stitch patterns

Stitch patterns from the following categories can be

combined.

Example:

Touch .

Select the following stitch pattern.

Touch .

 The display returns to the stitch selection screen.

Touch .

Select the following stitch pattern.

If you want to sew the stitch pattern continuously,

touch to display editing screen, and then touch

 The stitch pattern turns continuous.

Memo

• The speed set with the sewing speed controller is

the foot controller’s maximum sewing speed.

Sewing

Sewing reverse/reinforcement stitches

Reverse/reinforcement stitches are generally necessary at the

beginning and end of sewing. Depending on the selected

stitch, reverse or reinforcement stitches are sewn while

(Reverse/Reinforcement stitch button) is kept pressed. With

reinforcement stitches, 3 to 5 stitches are sewn at the same

place. With reverse stitches, the stitching is sewn in the

opposite direction.

1 Reverse stitch

2 Reinforcement stitch

3 (Reverse/Reinforcement stitch button)

Automatic reverse/reinforcement stitching

After selecting a stitch pattern, turn on the automatic reverse/

reinforcement stitching function before sewing, and the

machine will automatically sew reinforcement stitches (or

reverse stitches, depending on the stitch pattern) at the

beginning and end of sewing.

Select a stitch.

• For details on selecting a stitch, refer to “Basic

sewing” on page 31.

Touch to set the automatic reverse/reinforcement

stitching function.

 The key will display as .

Set the needle in the start position and press the “Start/

Stop” button to start sewing.

1 Reverse stitches (or reinforcement stitches)

 The machine will automatically sew reverse stitches

(or reinforcement stitches) and then continue sewing.

Once you have reached the end of the stitching, press

(Reverse/Reinforcement stitch button).

1 Reverse stitches (or reinforcement stitches)

 The machine will sew reverse stitches (or

reinforcement stitches) and stop.

Automatic thread cutting

The machine can be set to automatically cut the threads at the

end of the stitching. If automatic thread cutting is set,

automatic reverse/reinforcement stitching is also set.

If the machine is turned off, automatic thread cutting will be

turned off.

Turn on the machine.

Select a stitch.

• For details on selecting a stitch, refer to “Basic

sewing” on page 31.

Touch on the screen.

 You get

, and the machine is set for

automatic thread cutting and automatic reverse/

reinforcement stitching.

• To turn automatic thread cutting off, touch .

Set the needle in the start position, and press the

“Start/Stop” button once.

 Stitching will begin after reverse stitches (or

reinforcement stitches) are sewn automatically.

Memo

• When any of the following stitches is selected,

pressing (Reverse/Reinforcement stitch button)

will sew reverse stitches.

When any other stitch is selected, pressing

(Reverse/Reinforcement stitch button) will sew

reinforcement stitches.

No. 1-01 1-03 1-08

Stitch

Memo

• You can pause or resume sewing by pressing

“Start/Stop” button while sewing.

Sewing

SEWING BASICS

Once you have reached the end of the stitching, press

(Reverse/Reinforcement stitch button) once.

If stitching, such as buttonholes and bar tacking, that

includes reinforcement stitching has been selected, this

operation is unnecessary.

 After the reverse stitching (or reinforcement stitching)

has been done, the machine stops, and the threads

are cut.

Setting the stitch width/stitch length/“L/R

Shift”

This machine is preset with the default settings for the

stitch width, stitch length and “L/R Shift” for each stitch.

However, you can change any of the settings by touching

in the utility stitch screen.

After changing the settings, touch to return to the utility

stitch screen.

If you wish to save specific settings for a stitch so that they

can be used later, touch after changing the settings to

save the new settings with the selected stitch.

■ Setting the stitch width

The stitch width (zigzag width) can be adjusted to make the

stitch wider or narrower.

■ Setting the stitch length

The stitch length can be adjusted to make the stitch coarser

(longer) or finer (shorter).

■ Setting the “L/R Shift”

The placement of the zigzag stitch can be adjusted to move

the stitch to the right or left.

1 Placement of the stitch pattern

1 The point where the “Start/

Stop” button was pressed.

2 The point where

(Reverse/Reinforcement

stitch button) was pressed.

3 The threads are cut here.

Memo

• Touch to return the setting to its default. If is

then touched, the default settings are saved to the

machine instead of the former settings.

• If the straight stitch or triple stretch stitch was

selected, changing the stitch width changes the

needle position. Increasing the width moves the

needle to the right; reducing the width moves the

needle to the left. (page 35)

• or means the setting cannot be

changed.

Note

• After adjusting the stitch width or the “L/R Shift”,

slowly turn the handwheel toward you

(counterclockwise) and check that the needle does

not touch the presser foot.

IMPORTANT

• If the stitches are bunched together, increase

the stitch length. Continuing to sew with the

stitches bunched together may result in the

needle bending or breaking.

Adjusting the Thread Tension

You may need to change the thread tension, depending on the

fabric and thread being used.

■ Correct thread tension

The upper thread and the bobbin thread should cross near

the center of the fabric. Only the upper thread should be

visible from the right side of the fabric, and only the

bobbin thread should be visible from the wrong side of the

fabric.

■ Upper thread is too tight

If the bobbin thread is visible from the right side of the

fabric, the upper thread is too tight. Loosen the thread

tension.

Turn the thread tension dial counterclockwise to loosen the

upper thread tension.

■ Upper thread is too loose

If the upper thread is visible from the wrong side of the

fabric, the upper thread is too loose. Tighten the thread

tension.

Turn the thread tension dial clockwise to tighten the upper

thread tension.

Adjusting the Thread Tension

1 Wrong side of fabric

2 Right side of fabric

3 Upper thread

4 Bobbin thread

Note

• If the bobbin thread was incorrectly threaded, the

upper thread may be too tight. In this case, refer to

“Installing the bobbin” on page 22 and rethread the

bobbin thread.

1 Wrong side of fabric

2 Right side of fabric

3 Upper thread

4 Bobbin thread

5 The bobbin thread is visible

from the right side of the

fabric.

Note

• If the upper thread was incorrectly threaded, the

upper thread may be too loose. In this case, refer

to “Upper Threading” on page 23 and rethread the

upper thread.

1 Wrong side of fabric

2 Right side of fabric

3 Upper thread

4 Bobbin thread

5 The upper thread is visible

from the wrong side of the

fabric.

Note

• If the upper thread is not threaded correctly or the

bobbin is not installed correctly, it may not be

possible to set the correct thread tension. If the

correct thread tension cannot be achieved,

rethread the upper thread and insert the bobbin

correctly.

Useful Sewing Tips

SEWING BASICS

Sewing tips

■ Trial sewing

Before starting your sewing project, we recommend sewing

trial stitches using thread and scrap fabric that are the same as

those used for your project.

While checking the sewing results, adjust the thread tension

as well as the stitch length and width according to the number

of fabric layers and the stitch that is sewn.

■

Changing the sewing direction

When the stitching reaches a corner, stop the machine.

Leave the needle lowered (in the fabric). If the needle is

up, press (Needle position button) to lower the

needle.

Raise the presser foot lever, and then turn the fabric.

Turn the fabric using the needle as a pivot.

Lower the presser foot lever and continue sewing.

■ Sewing curves

Sew slowly while slightly changing the sewing direction to

sew around the curve. For details on sewing with an even

seam allowance, refer to “Sewing an even seam allowance”

on page 38.

When sewing along a curve while using a zigzag stitch, select

a shorter stitch length in order to obtain a finer stitch.

■ Sewing cylindrical pieces

Removing the flat bed attachment allows for free-arm sewing,

making it easier to sew cylindrical pieces such as sleeve cuffs

and pant legs.

Pull the flat bed attachment off to the left.

Slide the part that you wish to sew onto the free arm,

and then sew from the top.

When you are finished with free arm sewing, install the

flat bed attachment back in its original position.

Useful Sewing Tips

Note

• Other factors, such as fabric thickness, stabilizer

material, etc., also have an effect on the stitch, so

you should always sew a few trial stitches before

beginning your project.

• When sewing decorative satin stitch or satin stitch

patterns, there may be shrinking or bunching of

stitches, so be sure to use a stabilizer material.

Useful Sewing Tips

Sewing an even seam allowance

To sew an even seam, start sewing so that the seam allowance

is to the right of the presser foot, and the edge of the fabric is

aligned with either the right edge of the presser foot or a

marking on the needle plate.

■ Changing the needle position

The needle position used as the baseline is different for the

straight stitch (left needle position) and the straight stitch

(middle (center) needle position).

When the stitch width of the straight stitch (left needle

position) is set to its standard setting (0.0 mm), the

distance from the needle position to the right side of the

presser foot is 12 mm (1/2 inch). If the stitch width is

changed (between 0 and 7.0 mm (1/4 inch)), the needle

position will also change. By changing the stitch width

and sewing with the right side of the presser foot aligned

with the edge of the fabric, a seam allowance can be sewn

with a fixed width.

30 .866 m m30. m m

• For details, refer to “Setting the stitch width” on

page 35.

■ Aligning the fabric with a needle plate marking

The markings on the needle plate show the distance from

the needle position of a seam sewn with the straight stitch

(left needle position). Sew while keeping the edge of the

fabric aligned with a marking on the needle plate. The

distance between the markings in the upper scale is

1/8 inch (3 mm) and the distance between the markings in

the grid is 5 mm (3/16 inch).

For stitches with a left needle position

(Stitch width: 0.0 mm)

■ Aligning the fabric with zigzag foot “J”

The marking on zigzag foot “J” can be used to sew about 5

mm (3/16 inch) from the edge of the fabric. When using

this feature, select a straight stitch, and set the stitch width

to 2.0 mm.

1 Straight stitch (left

needle position)

2 Straight stitch (middle

(center) needle

position)

1 Stitch width setting

2 Distance from the

needle position to the

right side of the

presser foot

3 12.0 mm (1/2 inch)

4 10.0 mm (3/8 inch)

5 6.5 mm (1/4 inch)

6 5.0 mm (3/16 inch)

Memo

• When [Width Control] in the settings screen is set

to [ON], the needle position of a straight stitch can

be changed with the sewing speed controller.

1 Shift the stitch pattern to the right.

2 Shift the stitch pattern to the left.

0.0 2.0 5.5 7.0

34 56

30.866 mm30 . mm

30.866 mm30 . mm 30.866 mm30. mm

1 Seam

2 Presser foot

3 Centimeters

4 Inches

5 Needle plate

6 1.6 cm (5/8 inch)

1 Stitch width 2.0 mm

2 Marking

3 5 mm (3/16 inch)

Useful Sewing Tips

SEWING BASICS

Sewing various fabrics

■ Sewing thick fabrics

 If the fabric does not fit under the presser foot

The presser foot lever can be raised to two different

positions. If the fabric does not fit under the presser foot,

for example, when sewing together thick fabrics, raise the

presser foot lever to its highest position so that the fabric

can be placed under the presser foot.

 If the fabric does not feed

When sewing thick fabric such as denim or quilting, the

fabric may not feed at the start of sewing if the presser foot

is not level, as shown below. In this case, use the presser

foot locking pin (black button on the left side) of zigzag

foot “J” so that the presser foot remains level while sewing,

allowing the fabric to be fed smoothly.

If the presser foot misalignment is too large, place thick

paper or fabric (with the same thickness as the fabric being

sewn) under the heel of the presser foot to be able to start

sewing smoothly.

1 Sewing direction

2 Misalignment

3 Fabric being sewn

4 Fabric or thick paper

Raise the presser foot lever.

Align the beginning of stitching, and then position the

fabric.

While holding zigzag foot “J” level, push in and hold

the presser foot locking pin (black button on the left

side), and lower the presser foot lever.

Release the presser foot locking pin (black button).

 The presser foot remains level, allowing the fabric to

be fed.

 After the seam is sewn, the presser foot will return to

its original angle.

■ Sewing thin fabrics

When sewing thin fabrics such as chiffon, shrinkage of the

stitching may occur, or the fabric may not feed correctly.

Move the needle (be sure to use a fine needle) to the furthest

left or right hand position so that the fabric does not get pulled

down into the feed dog area. If this occurs or there is

shrinkage of the stitching, place non-woven water-soluble

stabilizer under the fabric and sew them together.

■ Sewing stretch fabrics

First, baste the pieces of fabric together, and then sew without

stretching the fabric. If the stitching is misaligned, place non-

woven water-soluble stabilizer under the fabric and sew them

together.

For best results when sewing on knit fabrics use the stretch

stitches. Also be sure to use a needle for knits (Ball point

needle (gold colored)). The recommended stitches and their

stitch numbers are indicated below.

1 Presser foot

locking pin (black

button)

CAUTION

• Do not sew fabric more than 6 mm (15/64

inch) thick or forcefully push fabric.

Otherwise, the needle may break, possibly

resulting in injury.

1 Water-soluble stabilizer

(non-woven)

1 Basting

No. 1-05 1-06 1-11 1-12 2-13

Stitch

Useful Sewing Tips

■ Sewing leathers or vinyl fabrics

If the leather or vinyl fabric sticks to the flat bed attachment,

sew with copy paper or tracing paper placed on top of the flat

bed attachment so the fabric moves smoothly.

If the paper is positioned so that it does not cover the needle

plate, the paper will not be sewn together with the fabric.

Optional presser feet for sewing leather or vinyl fabrics may

be used.

1 Copy paper or tracing paper

■ Sewing hook-and-loop fastener tape

Make sure that the needle passes through the hook-and-loop

fastener tape by turning the handwheel and lower the needle

into the hook-and-loop fastener tape before sewing. And then,

sew the edge of the hook-and-loop fastener tape at a slow

speed.

If the needle does not pass through the hook-and-loop

fastener tape, replace the needle with the needle size for

thicker fabrics. For details, refer to “Fabric/Thread/Needle

Combinations” on page 27.

CAUTION

• If the hook-and-loop fastener tape is sewn with

the thin needle (65/9-75/11), the needle may

break and cause injury.

IMPORTANT

• Use only the adhesive-free hook-and-loop

fastener tape which is designed for sewing.

When the glue adheres to the needle or the

bobbin case, it may cause malfunction.

Note

• Before sewing, baste together the fabric and the

hook-and-loop fastener tape.

1 Edge of the hook-and-loop

fastener tape

Stitch Chart

VARIOUS STITCHES

■ Utility stitches

* Twin needle can be used by attaching zigzag foot “J”.

Chapter 3

VARIOUS STITCHES

Stitch Chart

Memo

• When any of the following stitches are selected,

pressing (Reverse/Reinforcement stitch button)

will sew reverse stitches.

When any other stitch is selected, pressing

(Reverse/Reinforcement stitch button) will sew

reinforcement stitches.

• , , or in some of the illustrations shows

the needle position of the stitch.

Stitch

(Presser

foot)

No. Stitch name/Applications

Stitch

width

(mm

(inch))

Auto.

Manual

Stitch

length

(mm

(inch))

Auto.

Manual

(J)

1-01*

Straight stitch (Left)

General sewing, gather,

pintuck, etc.

0.0 (0)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.2 - 5.0

(1/64 - 3/16)

(J)

1-02*

Straight stitch (Left)

General sewing, gather,

pintuck, etc.

0.0 (0)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.2 - 5.0

(1/64 - 3/16)

(J)

1-03*

Straight stitch (Middle)

General sewing, gather,

pintuck, etc.

3.5 (1/8)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.2 - 5.0

(1/64 - 3/16)

(J)

1-04*

Straight stitch (Middle)

General sewing, gather,

pintuck, etc.

3.5 (1/8)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.2 - 5.0

(1/64 - 3/16)

(J)

1-05*

Triple stretch stitch

General sewing for

reinforcement and

decorative topstitching

0.0 (0)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

1-06*

Stem stitch

Reinforced stitching,

sewing and decorative

applications

1.0 (1/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

No. 1-01 1-03 1-08

Stitch

1 Left needle position

2 Middle (center) needle

position

3 Right needle position

(J)

1-07

Basting stitch

For basting.

If the basting threads fall

out of the fabric, pull up

the bobbin thread before

sewing, and then pull the

upper thread and bobbin

thread under the presser

foot toward the back of the

machine (page 26). Hold

the upper thread and

bobbin thread when

beginning to sew, and

when finished sewing, cut

the threads leaving an

excess amount of thread.

Finally, hold the upper

thread and bobbin thread

at the beginning of the

stitching while arranging

the fabric.

0.0 (0)

0.0 - 7.0

(0 - 1/4)

(J)

1-08*

Zigzag stitch

For overcasting, mending.

3.5 (1/8)

0.0 - 7.0

(0 - 1/4)

1.4 (1/16)

0.0 - 5.0

(0 - 3/16)

(J)

1-09*

Zigzag stitch

For overcasting, mending.

3.5 (1/8)

0.0 - 7.0

(0 - 1/4)

1.4 (1/16)

0.0 - 5.0

(0 - 3/16)

(J)

1-10*

Zigzag stitch (Right)

Start from right needle

position, zigzag sews to

left.

3.5 (1/8)

2.5 - 5.0

(3/32 - 3/16)

1.4 (1/16)

0.3 - 5.0

(1/64 - 3/16)

(J)

1-11*

2 steps elastic zigzag

stitch

Overcasting (medium

weight and stretch fabrics),

tape and elastic

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

1.0 (1/16)

0.2 - 5.0

(1/64 - 3/16)

(J)

1-12*

3 steps elastic zigzag

stitch

Overcasting (medium,

heavyweight and stretch

fabrics), tape and elastic

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

1.0 (1/16)

0.2 - 5.0

(1/64 - 3/16)

(G)

1-13

Overcasting stitch

Reinforcing of light and

medium weight fabrics

3.5 (1/8)

2.5 - 5.0

(3/32 - 3/16)

2.0 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(G)

1-14

Overcasting stitch

Reinforcing of heavyweight

fabric

5.0 (3/16)

2.5 - 5.0

(3/32 - 3/16)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(G)

1-15

Overcasting stitch

Reinforcing of medium,

heavyweight and easily

friable fabrics or decorative

stitching.

5.0 (3/16)

3.5 - 5.0

(1/8 - 3/16)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

1-16*

Overcasting stitch

Reinforced seaming of

stretch fabric

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

Stitch

(Presser

foot)

No. Stitch name/Applications

Stitch

width

(mm

(inch))

Auto.

Manual

Stitch

length

(mm

(inch))

Auto.

Manual

Stitch Chart

(J)

1-17*

Overcasting stitch

Reinforcing of medium

stretch fabric and

heavyweight fabric,

decorative stitching

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

1-18*

Overcasting stitch

Reinforcement of stretch

fabric or decorative

stitching

4.0 (3/16)

0.0 - 7.0

(0 - 1/4)

4.0 (3/16)

0.4 - 5.0

(1/64 - 3/16)

(J)

1-19

Overcasting stitch

Stretch knit seam

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

4.0 (3/16)

0.4 - 5.0

(1/64 - 3/16)

(S)

1-20

With side cutter

Straight stitch while cutting

fabrics

0.0 (0)

0.0 - 2.5

(0 - 3/32)

2.5 (3/32)

0.2 - 5.0

(1/64 - 3/16)

(S)

1-21

With side cutter

Zigzag stitch while cutting

fabrics

3.5 (1/8)

3.5 - 5.0

(1/8 - 3/16)

1.4 (1/16)

0.0 - 5.0

(0 - 3/16)

(S)

1-22

With side cutter

Overcasting stitch while

cutting fabrics

3.5 (1/8)

3.5 - 5.0

(1/8 - 3/16)

2.0 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(S)

1-23

With side cutter

Overcasting stitch while

cutting fabrics

5.0 (3/16)

3.5 - 5.0

(1/8 - 3/16)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(S)

1-24

With side cutter

Overcasting stitch while

cutting fabrics

5.0 (3/16)

3.5 - 5.0

(1/8 - 3/16)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

1-25

Piecing stitch (Right)

Piecework/patchwork 6.5

mm (approx. 1/4 inch) right

seam allowance

5.5 (7/32)

0.0 - 7.0

(0 - 1/4)

2.0 (1/16)

0.2 - 5.0

(1/64 - 3/16)

(J)

1-26

Piecing stitch (Middle)

Piecework/patchwork

2.0 (1/16)

0.2 - 5.0

(1/64 - 3/16)

(J)

1-27

Hand-look quilting stitch

Quilting stitch made to

look like hand quilting

when using transparent

nylon thread for the upper

thread and a thread color

matching the quilt for the

bobbin thread.

Sew with a tight thread

tension so that the bobbin

thread is visible from the

right side of the fabric.

Use a needle between 90/

14 and 100/16.

0.0 (0)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

1-28

Quilting appliqué zigzag

stitch

Zigzag stitch for quilting

and sewing on appliqué

quilt pieces

3.5 (1/8)

0.0 - 7.0

(0 - 1/4)

1.4 (1/16)

0.0 - 5.0

(0 - 3/16)

(J)

1-29

Quilting appliqué stitch

Quilting stitch for invisible

appliqué or attaching

binding

1.5 (1/16)

0.0 - 3.5

(0 - 1/8)

1.8 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(J)

1-30

Quilting stippling stitch

Background quilting

7.0 (1/4)

0.0 - 7.0

(0 - 1/4)

1.6 (1/16)

0.4 - 5.0

(1/64 - 3/16)

Stitch

(Presser

foot)

No. Stitch name/Applications

Stitch

width

(mm

(inch))

Auto.

Manual

Stitch

length

(mm

(inch))

Auto.

Manual

(R)

2-01

Blind hem stitch

Hemming woven fabrics

* The stitch width setting

is in neither millimeters

nor inches.

3 - 3

2.0 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(R)

2-02

Blind hem stretch stitch

Hemming stretch fabric

* The stitch width setting

is in neither millimeters

nor inches.

3 - 3

2.0 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-03*

Blanket stitch

Appliqués, decorative

blanket stitch

3.5 (1/8)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-04*

Blanket stitch

Appliqués, decorative

blanket stitch

2.5 (3/32)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-05*

Shell tuck edge stitch

Shell tuck edge finish on

fabrics

4.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.2 - 5.0

(1/64 - 3/16)

(N)

2-06*

Satin scallop stitch

Decorating collar of

blouse, edge of

handkerchief

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

0.5 (1/32)

0.1 - 5.0

(1/64 - 3/16)

(J)

2-07*

Patchwork join stitch

Patchwork stitches,

decorative stitching

4.0 (3/16)

0.0 - 7.0

(0 - 1/4)

1.2 (1/16)

0.2 - 5.0

(1/64 - 3/16)

(J)

2-08*

Patchwork double

overlock stitch

Patchwork stitches,

decorative stitching

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-09*

Couching stitch

Decorative stitching,

attaching cord and

couching

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

1.2 (1/16)

0.2 - 5.0

(1/64 - 3/16)

(J)

2-10*

Smocking stitch

Smocking, decorative

stitching

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

1.6 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-11*

Feather stitch

Fagoting, decorative

stitching

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-12*

Fagoting cross stitch

Fagoting, bridging and

decorative stitching

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-13*

Tape attaching stitch

Attaching tape to seam in

stretch fabric

4.0 (3/16)

0.0 - 7.0

(0 - 1/4)

1.0 (1/16)

0.2 - 5.0

(1/64 - 3/16)

(N)

2-14

Ladder stitch

Decorative stitching

4.0 (3/16)

0.0 - 7.0

(0 - 1/4)

3.0 (1/8)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-15*

Rick-rack stitch

Decorative top stitching

4.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(J)

2-16*

Decorative stitch

Decorative stitching

5.5 (7/32)

0.0 - 7.0

(0 - 1/4)

1.6 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(N)

2-17*

Serpentine stitch

Decorative stitching and

attaching elastic

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

1.0 (1/16)

0.2 - 5.0

(1/64 - 3/16)

Stitch

(Presser

foot)

No. Stitch name/Applications

Stitch

width

(mm

(inch))

Auto.

Manual

Stitch

length

(mm

(inch))

Auto.

Manual

Stitch Chart

VARIOUS STITCHES

(N)

3-01*

Hemstitching zigzag

Decorative hems, top

stitching

6.0 (15/64)

0.0 - 7.0

(0 - 1/4)

3.0 (1/8)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-02

Hemstitching

Decorative hems, lace

attaching pin stitch

3.5 (1/8)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-03

Hemstitching

Decorative hems

3.0 (1/8)

0.0 - 7.0

(0 - 1/4)

3.5 (1/8)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-04

Hemstitching

Decorative hems, daisy

stitch

6.0 (15/64)

0.0 - 7.0

(0 - 1/4)

3.0 (1/8)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-05

Hemstitching

Heirloom, decorative hems

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

3.5 (1/8)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-06*

Hemstitching

Heirloom, decorative hems

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

4.0 (3/16)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-07*

Hemstitching

Heirloom, decorative hems

6.0 (15/64)

0.0 - 7.0

(0 - 1/4)

1.6 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-08

Hemstitching

Heirloom, decorative hems

6.0 (15/64)

0.0 - 7.0

(0 - 1/4)

3.0 (1/8)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-09

Hemstitching

Heirloom, decorative hems

4.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.5 (3/32)

0.4 - 5.0

(1/64 - 3/16)

(N)

3-10*

Hemstitching

Heirloom, decorative hems

5.0 (3/16)

0.0 - 7.0

(0 - 1/4)

2.0 (1/16)

0.4 - 5.0

(1/64 - 3/16)

(A)

4-01

Narrow rounded

buttonhole stitch

Buttonhole on light to

medium weight fabrics

5.0 (3/16)

3.0 - 6.0

(1/8 - 15/64)

0.4 (1/64)

0.2 - 1.0

(1/64 - 1/16)

(A)

4-02

Tapered round ended

buttonhole stitch

Reinforced waist tapered

buttonholes

5.0 (3/16)

3.0 - 6.0

(1/8 - 15/64)

0.4 (1/64)

0.2 - 1.0

(1/64 - 1/16)

(A)

4-03

Round ended buttonhole

stitch

Buttonholes with vertical

bar tack in heavyweight

fabrics

5.0 (3/16)

3.0 - 6.0

(1/8 - 15/64)

0.4 (1/64)

0.2 - 1.0

(1/64 - 1/16)

(A)

4-04

Narrow squared

buttonhole stitch

Buttonholes for light to

medium weight fabrics

5.0 (3/16)

3.0 - 6.0

(1/8 - 15/64)

0.4 (1/64)

0.2 - 1.0

(1/64 - 1/16)

(A)

4-05

Stretch buttonhole stitch

Buttonholes for stretch or

woven fabrics

6.0 (15/64)

3.0 - 6.0

(1/8 - 15/64)

1.0 (1/16)

0.5 - 2.0

(1/32 - 1/16)

(A)

4-06

Heirloom buttonhole

stitch

Buttonholes for heirloom

and stretch fabrics

6.0 (15/64)

3.0 - 6.0

(1/8 - 15/64)

1.5 (1/16)

1.0 - 3.0

(1/16 - 1/8)

(A)

4-07

Bound buttonhole stitch

The first step in making

bound buttonholes

5.0 (3/16)

0.0 - 6.0

(0 - 15/64)

2.0 (1/16)

0.2 - 4.0

(1/64 - 3/16)

Stitch

(Presser

foot)

No. Stitch name/Applications

Stitch

width

(mm

(inch))

Auto.

Manual

Stitch

length

(mm

(inch))

Auto.

Manual

(A)

4-08

Keyhole buttonhole

stitch

Buttonholes in

heavyweight or thick

fabrics for larger flat

buttons

7.0 (1/4)

3.0 - 7.0

(1/8 - 1/4)

0.5 (1/32)

0.3 - 1.0

(1/64 - 1/16)

(A)

4-09

Tapered keyhole

buttonhole stitch

Buttonholes in medium to

heavy weight fabrics for

larger flat buttons

7.0 (1/4)

3.0 - 7.0

(1/8 - 1/4)

0.5 (1/32)

0.3 - 1.0

(1/64 - 1/16)

(A)

4-10

Keyhole buttonhole

stitch

Buttonholes with vertical

bar tack for reinforcement

in heavyweight or thick

fabrics

7.0 (1/4)

3.0 - 7.0

(1/8 - 1/4)

0.5 (1/32)

0.3 - 1.0

(1/64 - 1/16)

(A)

4-11

Darning stitch

Darning of medium weight

fabric

7.0 (1/4)

2.5 - 7.0

(3/32 - 1/4)

2.0 (1/16)

0.4 - 2.5

(1/64 - 3/32)

(A)

4-12

Darning stitch

Darning of heavyweight

fabric

7.0 (1/4)

2.5 - 7.0

(3/32 - 1/4)

2.0 (1/16)

0.4 - 2.5

(1/64 - 3/32)

(A)

4-13

Bar tack stitch

Reinforcement at opening

of pocket, etc.

2.0 (1/16)

1.0 - 3.0

(1/16 - 1/8)

0.4 (1/64)

0.3 - 1.0

(1/64 - 1/16)

(M)

4-14

Button sewing stitch

Attaching buttons

3.5 (1/8)

2.5 - 4.5

(3/32 - 3/16)

(N)

4-15

Eyelet stitch

For making eyelets, holes

on belts, etc.

7.0 (1/4)

7.0 6.0 5.0

(1/4 15/64

3/16)

7.0 (1/4)

7.0 6.0 5.0

(1/4 15/64

3/16)

Stitch

(Presser

foot)

No. Stitch name/Applications

Stitch

width

(mm

(inch))

Auto.

Manual

Stitch

length

(mm

(inch))

Auto.

Manual

Utility Stitches

■ Decorative stitches

Use monogramming foot “N”.

The twin needle can only be used with satin stitch . In

addition, be sure to attach zigzag foot “J” when using the

twin needle.

Overcasting stitches

Sew overcasting stitches along the edges of cut fabric to

prevent them from fraying.

■ Using overcasting foot “G”

Attach overcasting foot “G”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Position the fabric with the edge of the fabric against

the guide of the presser foot, and then lower the

presser foot lever.

Decorative stitches

5-01 5-02 5-03 5-04 5-05 5-06 5-07

5-08 5-09 5-10 5-11 5-12 5-13 5-14

5-15 5-16

Decorative satin stitches

6-01 6-02 6-03 6-04 6-05

Satin stitches

7-01 7-02 7-03 7-04 7-05

Cross stitch stitches

8-01 8-02 8-03 8-04 8-05

Utility Stitches

CAUTION

• Before replacing the presser foot, be sure to

touch (Presser foot/Needle exchange key)

on the operation panel to lock all keys and

buttons, otherwise injuries may occur if the

“Start/Stop” button or any other button is

pressed and the machine starts. For details on

changing the presser foot, refer to “Replacing

the Presser Foot” on page 29.

No. 1-13 1-14 1-15

Stitch

CAUTION

• When using overcasting foot “G”, be sure to

select a stitch that can be used with

overcasting foot “G”. If you sew with the

incorrect stitch, the needle may hit the presser

foot. The needle may break, possibly resulting

in injury.

1 Guide

Utility Stitches

VARIOUS STITCHES

Rotate the handwheel toward you (counterclockwise).

Check that the needle does not touch the presser foot.

Sew with the edge of the fabric against the presser foot

guide.

Press the “Start/Stop” button to stop sewing when you

are finished, and raise the presser foot and needle to

pull the fabric under the presser foot towards the back

of the machine.

■ Using zigzag foot “J”

Attach zigzag foot “J”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Sew along the edge of the fabric with the needle

dropping off the edge at the right.

Blind hem stitching

Secure the lower edge of skirts and pants with a blind hem.

Turn the skirt or pants inside out.

Fold the lower edge of fabric to the desired length to

be hemmed and then press.

Using tailor's chalk, mark the fabric about 5 mm (3/16

inch) from the edge of the fabric, and then baste it.

Fold back the fabric inside along the basting.

1 The needle should

not touch the

center pin

1 Needle drop point

IMPORTANT

• Be sure to pull the fabric backward after

finished sewing. If you pull the fabric toward

side or forward, the presser foot center pin

may be damaged.

• If thread is tangled on the presser foot, remove

the entangled thread, and then raise the

presser foot lever to remove the presser foot. If

the presser foot is raised while entangled with

thread, the presser foot may be damaged.

No. 1-08 1-10 1-11 1-12

Stitch

No. 1-16 1-17 1-18 1-19

Stitch

1 Needle drop point

Memo

• When the size of cylindrical pieces is too small to

slide onto the arm or the length is too short, the

fabric will not feed and desired results may not be

achieved.

1 Wrong side of fabric

2 Right side of fabric

3 Lower edge of fabric

1 Wrong side of fabric

2 Right side of fabric

3 Lower edge of fabric

4 Desired length for hem

1 Wrong side of fabric

2 Right side of fabric

3 Lower edge of fabric

4 Desired length for hem

5 5 mm (3/16 inch)

6 Basting

1 Wrong side of fabric

2 Right side of fabric

3 Lower edge of fabric

4 Desired length for hem

5 5 mm (3/16 inch)

6 Basting

7 Basting point

356

Utility Stitches

Unfold the edge of fabric, and position the fabric with

the wrong side facing up.

Attach blind stitch foot “R”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Remove the flat bed attachment to use the free arm.

Slide the item that you wish to sew onto the free arm,

make sure that the fabric feeds correctly, and then start

sewing.

Position the fabric with the edge of the folded hem

against the guide of the presser foot, and then lower

the presser foot lever.

Adjust the stitch width until the needle slightly catches

the fold of the hem. (page 35)

When you change the needle drop point, raise the

needle, and then change the stitch width.

* To make fine adjustments to the needle drop point,

adjust the stitch width setting. (The stitch width

setting is in neither millimeters nor inches.)

Sew with the fold of the hem against the presser foot

guide.

Press the “Start/Stop” button to stop sewing when you

are finished, and raise the presser foot and needle to

pull the fabric under the presser foot towards the back

of the machine.

Remove the basting stitching and turn the fabric with

the right side facing out.

1 Wrong side of fabric

2 Right side of fabric

3 Edge of fabric

4 Desired edge of hem

5 Basting point

6 Basting

No. 2-01 2-02

Stitch

1 Free arm

1 Wrong side of

fabric

2 Fold of hem

3 Guide

1 Needle drop point

1 Thick fabric

2 Normal fabric

Memo

• Blind hem stitches cannot be sewn if the left needle

drop point does not catch the fold. If the needle

catches too much of the fold, the fabric cannot be

unfolded and the seam appearing on the right side

of the fabric will be very large, leaving an

unattractive finish.

IMPORTANT

• Be sure to pull the fabric towards the back of

the machine after sewing. If you pull the fabric

toward side or forward, the presser foot may

be damaged.

1 Wrong side of

fabric

2 Right side of

fabric

Utility Stitches

VARIOUS STITCHES

Buttonhole sewing

The maximum buttonhole length is about 28 mm (1-1/8

inches) (diameter + thickness of the button).

Buttonholes are sewn from the front of the presser foot to the

back, as shown below.

1 Reinforcement stitching

The part names of buttonhole foot “A”, which is used to create

buttonholes, are indicated below.

Use chalk to mark on the fabric the position and length

of the buttonhole.

Pull out the button guide plate of buttonhole foot “A”,

and then insert the button that will be put through the

buttonhole.

■ If the button does not fit in the button guide

plate

Add together the diameter and thickness of the button,

and then set the button guide plate to the calculated

length. (The distance between the markings on the presser

foot scale is 5 mm (3/16 inch).)

Example: For a button with a diameter of 15 mm (9/16 inch)

and a thickness of 10 mm (3/8 inch), the button guide plate

should be set to 25 mm (1 inch) on the scale.

 The size of the buttonhole is set.

Attach buttonhole foot “A”.

Position the upper thread under the presser foot by

guiding thread through the hole in the presser foot

before attaching the buttonhole foot “A”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

1 Button guide plate

2 Presser foot scale

3 Pin

4 Marks on

buttonhole foot

5 5 mm (3/16 inch)

Note

• Before sewing buttonholes, check the stitch length

and width by sewing a trial buttonhole on a scrap

piece of fabric used for your project.

1 Marks on fabric

2 Buttonhole sewing

1 Presser foot scale

2 Length of

buttonhole

(diameter +

thickness of

button)

3 5 mm (3/16 inch)

1 10 mm (3/8 inch)

2 15 mm (9/16 inch)

No. 4-01 4-02 4-03 4-04 4-05

Stitch

No. 4-06 4-07 4-08 4-09 4-10

Stitch

Utility Stitches

Position the fabric with the front end of the buttonhole

mark aligned with the red marks on the sides of the

buttonhole foot, and then lower the presser foot lever.

• When lowering the presser foot, do not push in the

front of the presser foot.

Pull down the buttonhole lever as far as possible.

The buttonhole lever is positioned behind the bracket

on the buttonhole foot.

Gently hold the end of the upper thread in your left

hand, and then start sewing.

 Once sewing is completed, the machine

automatically sews reinforcement stitches, then

stops.

Press (Thread cutter button) once.

Raise the presser foot, and then remove the fabric.

Raise the buttonhole lever to its original position.

Insert a pin along the inside of one bar tack at the end

of the buttonhole stitching to prevent the stitching

from being cut.

Use the seam ripper to cut towards the pin and open

the buttonhole.

For keyhole buttonholes, use the eyelet punch to make

a hole in the rounded end of the buttonhole, and then

use the seam ripper to cut open the buttonhole.

• When using the eyelet punch, place thick paper or

some other protective sheet under the fabric before

punching the hole in the fabric.

1 Mark on fabric

(front)

2 Red marks on

buttonhole foot

3 Upper thread

1 Do not reduce the

gap.

1 Buttonhole lever

2 Bracket

Note

• When using the thread cutter on the left side of the

machine or scissors to cut the threads, press

(Needle position button) to raise the needle, raise

the presser foot, and then pull out the fabric before

cutting the threads.

1 Pin

1 Seam ripper

1 Eyelet punch

CAUTION

• When opening the buttonhole with the seam

ripper, do not place your hands in the cutting

direction, otherwise injuries may result if the

seam ripper slips.

Utility Stitches

VARIOUS STITCHES

■ Sewing buttonholes on stretch fabrics

When sewing buttonholes on stretch fabrics, use a gimp

thread.

Hook the gimp thread onto the part of buttonhole foot

“A” shown in the illustration.

It fits into the grooves, and then loosely tie it.

Attach buttonhole foot “A”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Adjust the stitch width to the thickness of the gimp

thread.

Lower the presser foot lever and the buttonhole lever,

and then start sewing.

When sewing is finished, gently pull the gimp thread to

remove any slack.

Use a handsewing needle to pull the gimp thread to the

wrong side of the fabric, and then tie it.

Button sewing

Buttons can be sewn on with the machine. Buttons with two

or with four holes can be attached.

Measure the distance between the holes in the button

to be attached.

Raise the presser foot lever, and then slide the feed dog

position switch, located at the rear of the machine on

the base, to (to the left as seen from the rear of

the machine).

Attach button fitting foot “M”.

Select stitch.

• For details, refer to “Stitch Chart” on page 41.

• Since the end of the thread will be tied off later, do

not set the machine for automatic thread cutting.

Adjust the stitch width so that it is the same as the

distance between the holes in the button.

Place the button in the position where it will be sewn,

and lower the presser foot lever.

• When attaching four-hole buttons, first sew the two

holes closest to you. Then, slide the button so that

the needle goes into the two holes toward the rear of

the machine, and then sew them in the same way.

Turn the handwheel toward you (counterclockwise) to

check that the needle correctly goes into the two holes

of the button.

If it seems as if the needle will hit the button, remeasure

the distance between the holes in the button. Adjust the

stitch width to the distance between the buttonholes.

No. 4-05 4-06

Stitch

No. 4-14

Stitch

1 Button

Utility Stitches

Set the sewing speed controller to the left (so that the

speed will be slow), then start sewing.

 The machine automatically stops after sewing

reinforcement stitches.

• Do not press (Thread cutter button).

Use scissors to cut the upper thread and the bobbin

thread at the beginning of the stitching.

Pull the upper thread at the end of the stitching to the

wrong side of the fabric, and then tie it with the bobbin

thread.

When you are finished attaching the button, slide the

feed dog position switch, to (to the right as seen

from the rear of the machine) and turn the handwheel

to raise the feed dogs.

Zipper insertion

■ Inserting a centered zipper

Stitching is sewn on both pieces of fabric butted against each

other.

Attach zigzag foot “J”.

Sew straight stitches up to the zipper opening.

With the right sides of the fabric facing each other, sew

reverse stitches after reaching the zipper opening.

Using a basting stitch, continue sewing to the edge of

the fabric.

Press open the seam allowance from the wrong side of

the fabric.

Align the seam with the center of the zipper, and then

baste the zipper in place to the seam allowance.

Remove about 5 cm (2 inches) from the end of the

basting on the outside.

Attach the presser foot holder to the right pin of zipper

foot “I”.

IMPORTANT

• When sewing, be sure that the needle does not

touch the button.

1 Right side of fabric

2 Stitching

3 End of zipper opening

1 Reverse stitches

2 End of zipper opening

1 Basting stitching

2 Wrong side of fabric

1 Wrong side of fabric

2 Basting stitching

3 Zipper

1 Wrong side of fabric

2 Zipper basting

3 Outside basting

4 5 cm (2 inches)

1 Pin on the right side

2 Needle drop point

Utility Stitches

VARIOUS STITCHES

Select stitch.

• For details, refer to “Stitch Chart” on page 41.

Topstitch around the zipper.

1 Stitching

2 Right side of fabric

3 Basting stitching

4 End of zipper opening

Remove the basting stitching.

Appliqué and patchwork

■ Appliqué stitching

Baste or glue the appliqué piece to the base fabric to

secure it.

Attach the zigzag foot “J”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Turn the handwheel toward you (counterclockwise),

and then begin sewing around the edge of the

appliqué, making sure that the needle drops just

outside of the appliqué.

When sewing around corners, stop the machine with

the needle in the fabric just outside of the appliqué,

raise the presser foot lever, and then turn the fabric as

needed to change the sewing direction.

■ Patchwork (crazy quilt) stitching

Fold the edge of the top piece of fabric and place it

over the lower piece.

Attach zigzag foot “J”.

Select a stitch.

• The stitches shown below are examples. Select the

desired stitch.

• For details, refer to “Stitch Chart” on page 41.

Sew the two pieces of fabric together so the stitch

pattern spans over both pieces.

Use pins if necessary.

No. 1-03

Stitch

Note

• When using zipper foot “I”, be sure to select the

straight stitch (middle (center) needle position), and

slowly turn the handwheel toward you

(

counterclockwise)

to check that the needle does

not touch the presser foot.

CAUTION

• When sewing, be sure that the needle does not

touch the zipper, otherwise the needle may

break and cause injury.

Memo

• If the presser foot contacts the zipper slider, leave

the needle lowered (in the fabric) and raise the

presser foot. After moving the slider so it will not

contact the presser foot, lower the presser foot and

continue sewing.

IMPORTANT

• If glue is used to hold the appliqué in place on

the fabric, do not apply glue to areas that will

be sewn with the machine. If glue adheres to

the needle or bobbin case, the machine may

be damaged.

No. 1-28 1-29 2-03 2-04

Stitch

No. 1-28 2-07 2-08 2-09

Stitch

CAUTION

• Do not stitch over pins. Otherwise, the needle

may break and cause injury.

Utility Stitches

■ Piecing

Sewing together two pieces of fabric is called “piecing”. The

fabric pieces should be cut with a 6.5 mm (1/4 inch) seam

allowance.

Sew a piecing straight stitch 6.5 mm (1/4 inch) from either the

right side or the left side of the presser foot.

Baste or pin along the seam allowance of the fabric

that you wish to piece together.

Attach zigzag foot “J”.

Select stitch.

• For details, refer to “Stitch Chart” on page 41.

Sew with the side of the presser foot aligned with the

edge of the fabric.

 For a seam allowance on the right side

Align the right side of the presser foot with the edge of the

fabric, and sew using stitch .

 For a seam allowance on the left side

Align the left side of the presser foot with the edge of the

fabric, and set the stitch width 1.5 mm (1/16 inch) and

sew using stitch .

■ Satin stitching using the sewing speed

controller

A decorative stitch can be sewn by changing the stitch width

of a satin stitch. If the machine is set so that the stitch width

can be adjusted using the sewing speed controller, the stitch

width can quickly and easily be adjusted. When this function

is set, the foot controller must be used to sew.

Connect the foot controller.

Attach zigzag foot “J”.

Touch and set [Width Control] (page 1 of the

settings screen) to [ON].

 The machine is now set so that the stitch width can

be controlled with the sewing speed controller.

The screen appears as shown below.

30.866 m m30. mm

Select stitch.

• For details, refer to “Stitch Chart” on page 41.

While sewing, slide the sewing speed controller to

adjust the stitch width.

• Adjust the sewing speed with the foot controller.

When you are finished sewing, set [Width Control]

back to [OFF].

No. 1-25

Stitch

1 6.5 mm (1/4 inch)

Memo

• To change the width of the seam allowance (needle

position), adjust the stitch width. For details, refer

to “Setting the stitch width” on page 35 and

“Sewing an even seam allowance” on page 38.

No. 1-28

Stitch

Memo

• Although the stitching results differ depending on

the type of fabric being sewn and the thickness of

the thread being used, for best results, adjust the

stitch length to between 0.3 and 0.5 mm (1/64 and

1/32 inch).

1 Narrower

2 Wider

Utility Stitches

VARIOUS STITCHES

Other stitching applications

■ Elastic attaching

When elastic tape is attached to the cuff or waist of a piece of

clothing, the finished dimensions will be that of the stretched

elastic tape. Therefore, it is necessary that a suitable length of

the elastic tape be used.

Pin the elastic tape to the wrong side of the fabric.

Pin the elastic tape to the fabric at a few points to make

sure that the tape is uniformly positioned on the fabric.

Attach zigzag foot “J”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Sew the elastic tape to the fabric while stretching the

tape so that it is the same length as the fabric.

While pulling the fabric behind the presser foot with

your left hand, pull the fabric at the pin nearest the front

of the presser foot with your right hand.

■ Bar tack stitching

Bar tacks are used to reinforce points subject to strain, such as

pocket corners and openings.

As an example, the procedure for sewing bar tacks at pocket

corners is described below.

Determine the desired length of the bar tack.

Set the button guide plate on buttonhole foot “A” to the

desired length. (The distance between the markings on

the presser foot scale is 5 mm (3/16 inch).)

Attach buttonhole foot “A”.

Position the upper thread under the presser foot by

guiding thread through the hole in the presser foot

before attaching the buttonhole foot “A”.

Select stitch.

• For details, refer to “Stitch Chart” on page 41.

Position the fabric so that the opening of the pocket

faces toward you, and then lower the presser foot lever

so that the needle drops 2 mm (1/16 inch) in front of

the pocket opening.

Pull down the buttonhole lever as far as possible.

Gently hold the end of the upper thread in your left

hand, and then start sewing.

After sewing is finished, raise the presser foot lever,

remove the fabric, and then cut the threads.

Raise the buttonhole lever to its original position.

No. 1-11 1-12 2-13

Stitch

CAUTION

• When sewing, be sure that the needle does not

touch any pins, otherwise the needle may

break and cause injury.

1 Presser foot scale

2 Length of bar tack

3 5 mm (3/16 inch)

No. 4-13

Stitch

1 2 mm (1/16 inch)

Utility Stitches

■ Darning

1 Reinforcement stitching

Determine the desired length of the darning.

Set the button guide plate on buttonhole foot “A” to the

desired length. (The distance between the markings on

the presser foot scale is 5 mm (3/16 inch).)

 Once sewing is completed, the machine

automatically sews reinforcement stitches, then

stops.

Attach buttonhole foot “A”.

Position the upper thread under the presser foot by

guiding thread through the hole in the presser foot

before attaching the buttonhole foot “A”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Position the fabric so that the needle is 2 mm (1/16

inch) in front of the area to be darned, and then lower

the presser foot.

Pull down the buttonhole lever as far as possible.

Gently hold the end of the upper thread in your left

hand, and then start sewing.

After sewing is finished, raise the presser foot lever,

remove the fabric, and then cut the threads.

Raise the buttonhole lever to its original position.

■ Eyelet stitching

Eyelets, such as those on belts, can be sewn.

Attach monogramming foot “N”.

Select stitch.

• For details, refer to “Stitch Chart” on page 41.

Adjust either the stitch width or the stitch length to

select the desired eyelet size.

• For details, refer to “Setting the stitch width” on

page 35 and “Setting the stitch length” on page 35.

Lower the needle into the fabric at the beginning of the

stitching, and then lower the presser foot lever.

Start sewing.

 Once sewing is completed, the machine

automatically sews reinforcement stitches, then

stops.

1 Presser foot scale

2 Length of darning

3 5 mm (3/16 inch)

4 2.5 - 7.0 mm (3/32 - 1/

4 inch)

No. 4-11 4-12

Stitch

1 Tear

2 2 mm (1/16 inch)

No. 4-15

Stitch

Utility Stitches

VARIOUS STITCHES

After removing the fabric, use the eyelet punch to cut a

hole in the center of the eyelet.

• When using the eyelet punch, place thick paper or

some other protective sheet under the fabric before

punching the hole in the fabric.

■ Fagoting

Stitching across an open seam is called “fagoting”. It is used

on blouses and children's clothing. This stitch is more

decorative when thicker thread is used.

Use an iron to fold the two pieces of fabric along their

seams.

Baste the two pieces of fabric, separated by about 4

mm (3/16 inch), onto thin paper or a sheet of water-

soluble stabilizer.

If you draw a line down the middle of the thin paper or

water-soluble stabilizer, sewing is easier.

Attach zigzag foot “J”.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Set the stitch width to 7.0 mm (1/4 inch).

Sew with the center of the presser foot aligned along

the center of the two pieces of fabric.

After sewing is finished, remove the paper.

■ Scallop stitching

The wave-shaped repeated stitch pattern that looks like shells

is called “scalloping”. It is used on the collars of blouses and

to decorate the edges of projects.

Attach monogramming foot “N”.

Select stitch.

• For details, refer to “Stitch Chart” on page 41.

Stitch along the edge of the fabric, making sure not to

sew directly on the edge of the fabric.

Trim along the stitches.

• Be careful not to cut the stitches.

■ Smocking

The decorative stitch created by stitching or embroidering

over gathers is called “smocking”. It is used to decorate the

front of blouses or cuffs.

The smocking stitch adds texture and elasticity to fabric.

Attach zigzag foot “J”.

Select the straight stitch, and then adjust the stitch

length to 4.0 mm (3/16 inch) and loosen the thread

tension.

Sew parallel stitching at intervals of 1 cm (3/8 inch)

and pull the bobbin threads to create gathers.

Smooth the gathers by ironing them.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

1 Thin paper or water-

soluble stabilizer

2 Basting stitching

3 4 mm (3/16 inch)

No. 2-11 2-12

Stitch

No. 2-06

Stitch

No. 2-10 2-11 2-12

Stitch

Utility Stitches

Stitch between the straight stitches and pull out the

threads for the straight stitches.

■ Shell tuck stitching

The gathers that look like shells are called “shell tucks”. They

are used to decorate trims, the front of blouses or cuffs made

of thin fabrics.

Draw equally spaced lines along the bias, and then fold

the fabric along the lines.

Attach zigzag foot “J”.

Select stitch, and then increase the thread tension.

• For details, refer to “Stitch Chart” on page 41.

Sew while making sure that the needle drops slightly

off the edge of the fabric.

One fold at a time, continue folding the fabric along the

line, then sewing it.

After sewing is finished, remove the fabric. Unfold the

fabric, and then iron the tucks down to one side.

■ Joining

Decorative bridging stitches can be sewn over the seam

allowance of joined fabrics. This is used when making a crazy

quilt.

Attach zigzag foot “J”.

Sew together the right sides of the two pieces of fabric,

and then open up the seam allowances.

Select a stitch.

• For details, refer to “Stitch Chart” on page 41.

Turn the fabric over so that the right side faces up, and

then sew over the seam with the center of the presser

foot aligned with the seam.

■ Using the twin needle

With the twin needle, you can sew two parallel lines of the

same stitch with two different threads. Both upper threads

should have the same thickness and quality.

Touch and install the twin needle.

• For details on installing a needle, refer to “Replacing

the Needle” on page 28.

Pass the first upper thread behind the needle bar

thread guide.

• For details, refer to steps a through j of

“Threading the upper thread” on page 23.

Manually thread the left needle with the first upper

thread.

Pass the thread through the eye of the needle from the

front.

No. 2-05

Stitch

1 Needle drop point

No. 2-07 2-08 2-09

Stitch

IMPORTANT

• Only use the twin needle (2/11 needle), and

never use the needle threader with the twin

needle. Otherwise, the needle may break or

the machine may be damaged.

Utility Stitches

VARIOUS STITCHES

Put the extra spool pin in the hole on the top of the

machine and put the thread spool onto the extra spool

pin.

Thread the machine with the second upper thread.

Without passing the thread behind the needle bar

thread guide, manually thread the right needle with the

second upper thread.

Insert the thread through the eye of the needle from the

front to the back.

Attach zigzag foot “J”.

• For details on changing the presser foot, refer to

“Replacing the presser foot” on page 29.

Touch to unlock all keys and buttons.

Touch and set [Twin Needle] (page 1 of the

settings screen) to [ON].

Select a stitch.

• Refer to “Stitch Chart” on page 41 for stitches that

use a twin needle. You can also sew with a twin

needle when you select a satin stitch pattern. In this

case, use zigzag foot “J”.

Start sewing.

1 Thread spool

2 Extra spool pin

1 Needle bar

thread

guide

Note

• When using the twin needle, be sure to attach

zigzag foot “J”. If bunched stitches occur, use

monogramming foot “N” or attach stabilizer

material.

CAUTION

• When using the twin needle, be sure to select

the twin needle setting, otherwise the needle

may break and cause injury.

CAUTION

• When using the twin needle, be sure to select

an appropriate stitch, otherwise the needle

may break and cause injury.

CAUTION

• Do not try turning the fabric while the twin

needle is down in the fabric, otherwise the

needle may break and cause injury or may

damage your machine.

Making Adjustments

Your stitch pattern may sometimes turn out poorly, depending

on the type or thickness of fabric, the stabilizer material used,

sewing speed, etc. If your sewing does not turn out well, sew

trial stitches using the same conditions as the real sewing, and

adjust the stitch pattern as explained below. If the stitch

pattern does not turn out well even after making adjustments

based on the stitch pattern described below, make

adjustments for each stitch pattern individually.

Touch and select (5-16).

Attach monogramming foot “N” and sew the stitch

pattern.

Compare the finished stitch pattern to the illustration

of the correct stitch pattern below.

Touch , and then adjust the stitch pattern with the

[Fine Adjust Verti.] display. (page 1 of the settings

screen)

 If the stitch pattern is bunched:

Touch in the [Fine Adjust Verti.] display.

 The displayed value increases each time the key is

touched and the stitch pattern will lengthen.

 If the stitch pattern has gaps:

Touch in the [Fine Adjust Verti.] display.

 The displayed value decreases each time the key is

touched and the stitch pattern will shorten.

Sew the stitch pattern again.

• If the stitch pattern still comes out poorly, make

adjustments again. Adjust until the stitch pattern

comes out correctly.

Touch to return to the original screen.

Making Adjustments

Memo

• This adjustment can be made to (1-30 Quilting

stippling stitch), (4-15 eyelet stitch) and stitch

patterns from the following categories.

Note

• Be sure to use monogramming foot “N”.

Adjustments may not be made correctly with any

other presser foot.

Using the Memory Function

VARIOUS STITCHES

Saving stitch patterns

You can save stitch patterns that you have customized in the

machine's memory or USB flash drive.

Touch .

When saving the stitch pattern in a USB flash drive,

insert the USB flash drive into the USB port on the

machine.

Touch the desired destination to start saving.

1 Save to the machine’s memory.

2 Save to the USB flash drive.

The stitch pattern is saved in a folder labeled “bPocket”.

Retrieving stitch patterns

Retrieve stitch patterns saved in the machine's memory or

USB flash drive.

When retrieving stitch patterns from a USB flash drive,

insert the USB flash drive into the USB port on the

machine.

Touch .

Touch the desired destination.

1 Retrieve from the machine’s memory.

2 Retrieve from a USB flash drive.

Select the desired stitch pattern, and then touch .

Using the Memory Function

Note

• Do not turn the main power to OFF while the

[Saving...] screen is displayed. You will lose the

stitch pattern you are saving.

Memo

• If the stitch pattern to be retrieved is in a folder of

the USB flash drive, touch the key for that folder.

Touch to return to the previous screen.

• Folders in the USB flash drive cannot be created

with the machine.

Memo

• When you touch , the selected stitch pattern will

be deleted permanently.

Using the Memory Function

Embroidering Preparation

EMBROIDERY

Follow the steps below to prepare the machine for

embroidery.

Attaching the embroidery foot

Press (Needle position button) to raise the needle.

Touch .

 The screen changes, and all keys and operation

buttons are locked (except ).

Remove the presser foot and presser foot holder.

• For details, refer to “Replacing the Presser Foot” on

page 29.

Hold the embroidery foot “Q” with your right hand, as

shown.

Hold the embroidery foot with your index finger

wrapped around the lever at the back of the foot.

1 Lever

2 Embroidery foot bar

Chapter 4

EMBROIDERY

Embroidering Preparation

Step

Aim Action Page

1 Presser foot

attachment

Attach embroidery foot “Q”. 61

2 Checking the

needle

Use needle 75/11 for

embroidery.

3 Embroidery unit

attachment

Attach the embroidery unit. 62

4Bobbin thread

setup

For the bobbin thread, wind

embroidery bobbin thread and

set it in place.

5Fabric

preparation

Attach a stabilizer material to

the fabric, and hoop it in the

embroidery frame.

6Embroidery

frame

attachment

Attach the embroidery frame

to the embroidery unit.

7 Pattern selection Select an embroidery pattern. 67

8 Checking the

layout

Check and adjust the size and

position of the embroidery.

9Embroidery

thread setup

Set up embroidery thread

according to the pattern.

Step 3

Step 1, 2

Step 5

Step 6

Step 4

Step 7, 8

Step 9

CAUTION

• Be sure to use the embroidery foot when doing

embroidery. Using another presser foot may

cause the needle to strike the presser foot. The

needle may break, possibly resulting in injury.

Embroidering Preparation

While pressing in the lever on embroidery foot “Q”

with your finger, place the embroidery foot bar above

the needle clamp screw.

1 Embroidery foot bar

2 Needle clamp screw

3 Presser bar

Secure embroidery foot “Q” with the presser foot

holder screw, making sure that embroidery foot “Q” is

vertical.

1 Mounting notch

2 Presser foot holder screw

Hold the embroidery foot in place with your right

hand, and then use the included screwdriver to

securely tighten the presser foot holder screw.

Touch to unlock all keys and buttons.

Attaching the embroidery unit

Turn off the machine.

Pull the flat bed attachment off to the left.

Insert the embroidery unit connection into the

connection port until it snaps into place.

CAUTION

• Use the included screwdriver to firmly tighten

the screw of the embroidery foot. If the screw

is loose, the needle may strike the presser foot.

The needle may break, possibly resulting in

injury.

IMPORTANT

• Before attaching the embroidery unit, be sure

to turn off the machine. Otherwise, the

machine may be damaged.

• Keep your hands and other objects away from

the embroidery carriage and frame when they

are moving. Otherwise, damage or

malfunction may occur.

CAUTION

• Do not move the machine with the embroidery

unit in place. The embroidery unit may be

dropped and cause injury.

Note

• Make sure that there is no gap between the

embroidery unit and the machine, otherwise the

embroidery pattern may not be embroidered

correctly.

Embroidering Preparation

EMBROIDERY

Turn on the machine.

 A message appears in the screen.

Be sure that no objects or hands are near the

embroidery unit and touch .

 The carriage moves to its initial position.

 The screen for selecting the embroidery pattern type

is displayed.

■ Removing the embroidery unit

Make sure that the machine is completely stopped and

follow the instructions below.

Remove the embroidery frame.

• For details on removing the embroidery frame, refer

to “Removing the embroidery frame” on page 66.

Touch , and then touch .

 The embroidery carriage moves into a position

where it can be stored.

Turn off the machine.

Hold the release button on the bottom left of the

embroidery unit, and slowly pull the embroidery unit

to the left.

Embroidering attractive finishes

There are many factors that go into beautiful embroidery.

Using the appropriate stabilizer (page 64) and hooping the

fabric in the frame (page 64) are two important factors

mentioned earlier. Another important point is the

appropriateness of the needle and thread being used. See the

explanation of threads below.

■ Thread

IMPORTANT

• Do not push on the carriage when attaching

the embroidery unit to the machine, otherwise

damage to the embroidery unit may result.

• Do not touch the connector in the embroidery

unit connection slot. The connector could be

damaged, and it may cause malfunctions.

• Do not lift up on the embroidery carriage, and

do not forcefully move it. It may cause

malfunctions.

Note

• If [Opening Screen] is set [ON] within the settings

screen, touch screen for the following message to

appear.

Memo

• Utility stitches cannot be selected when the

embroidery unit is attached.

IMPORTANT

• Always turn off the machine before removing

the embroidery unit.

It may cause malfunctions if removed when

the machine is turned on.

Upper thread Use embroidery thread intended for use with

this machine. Other embroidery threads may

not yield optimum results.

Bobbin thread Use the included bobbin pre-wound with 60

weight embroidery bobbin thread or

recommended 60 weight embroidery bobbin

thread.

Note

• Do not leave objects in the range of motion of the

embroidery frame. The frame may strike the object

and cause a poor finish to the embroidery pattern.

• When embroidering on large garments (especially

jackets or other heavy fabrics), do not let the fabric

hang off the table. Otherwise, the embroidery unit

cannot move freely, and the pattern may not turn

out as planned.

Embroidering Preparation

Hooping the fabric in the embroidery frame

■ Attaching iron-on stabilizers (backing) to the

fabric

For best results in your embroidery projects, always use

stabilizer material for embroidery.

Press the iron-on stabilizer material to the wrong side

of the fabric.

• Use a piece of stabilizer which is larger than the

embroidery frame being used.

■ Inserting the fabric

CAUTION

• Use fabrics with a thickness of less than 2 mm

(1/16 inch). Using fabrics thicker than 2 mm

(1/16 inch) may cause the needle to break,

possibly resulting in injury.

• Always use a stabilizer material for embroidery

when embroidering stretch fabrics, lightweight

fabrics, fabrics with a coarse weave, or fabrics

which cause pattern shrinkage. Otherwise, the

needle may break and cause injury.

1 Fusible side of

stabilizer

2 Fabric (wrong side)

3 Size of the

embroidery frame

Memo

• When embroidering small pieces of fabric that

cannot be hooped on an embroidery frame, use

stabilizer material as a base. After lightly ironing the

fabric to the stabilizer material, hoop it in the

embroidery frame. If stabilizer material cannot be

ironed onto the fabric, attach it with a basting

stitch. After completing the embroidery, remove the

stabilizer material carefully.

• When embroidering on thin fabrics such as

organdy or lawn, or on napped fabrics such as terry

cloth or corduroy, use water-soluble stabilizer (sold

separately) for best results. The water-soluble

stabilizer material will dissolve completely in water,

giving the project a more attractive finish.

• In the case of thick terry cloth towels we

recommend that you place a piece of water-soluble

stabilizer on the top surface of the towel. This will

help to reduce the nap of the toweling and result in

more attractive embroidery.

• When using fabrics that cannot be ironed (such as

terry cloth or fabrics that have loops which expand

when ironed) or in places where ironing is difficult,

position the stabilizer material under the fabric

without fusing it, then position the fabric and

stabilizer in the embroidery frame, or check with

your authorized Brother dealer for the correct

stabilizer to use.

CAUTION

• If you use a frame that is too small, the presser

foot may strike the frame during embroidering

and cause injury or may damage your

machine.

Note

• If the fabric is not securely held in the embroidery

frame, the embroidery pattern will embroider out

poorly. Insert the fabric on a level surface, and

gently pull the fabric taut in the frame, being careful

not to distort hooped fabric.

1 Fabric

2 Stabilizer

3 Basting

Embroidering Preparation

EMBROIDERY

Loosen the embroidery frame adjustment screw and

remove the inner and outer frames, placing the outer

frame on a flat surface.

Separate the inner and outer frame by removing inner

frame upward.

Place the fabric with the stabilizer material on top of

the outer frame.

Have the right side of the fabric facing up.

Press the inner frame in from the top of the fabric.

Line up on the inner frame and on outer frame.

Tighten the adjustment screw by hand just enough to

secure the fabric.

Gently remove the fabric from the frame without

loosening the adjustment screw.

Press the inner frame in from the top of the fabric

again, lining up on the inner frame and on

outer frame.

• Press the inner frame into the outer frame. Before

beginning to embroider, make sure that the top edges

of the inner and outer frames are aligned.

Tighten the adjustment screw while removing any slack

in the fabric by hand. The goal is to have a drum-like

sound when the fabric is struck lightly.

■ Using the embroidery sheet

When you want to embroider the pattern in a particular

place, use the embroidery sheet with the frame.

With a chalk pencil, mark the area of the fabric you

want to embroider.

Place the embroidery sheet on the inner frame.

Line the mark on the fabric up with the base line on the

embroidery sheet.

Place the inner frame with the fabric on the outer

frame and adjust the fabric if needed to align marks on

fabric with the embroidery sheet.

• For details, refer to page 64.

Remove the embroidery sheet.

1 Inner frame

2 Outer frame

3 Adjustment screw

Memo

• This precautionary step will help reduce pattern

distortion while embroidering.

Memo

• You can use the included screwdriver when you

loosen or tighten the frame adjustment screw.

Embroidering Preparation

Attaching the embroidery frame

Raise the presser foot lever to raise the presser foot.

Pass the embroidery frame under the presser foot.

• If necessary, raise the presser foot lever even further.

Firmly insert the embroidery frame guide into the

embroidery carriage frame holder from the top.

Line up the embroidery frame guide tabs and the

embroidery carriage frame holder slots and push in until

it clicks and stops.

1 Embroidery frame guide tabs

2 Embroidery carriage frame holder slots

 The embroidery unit is attached.

■ Removing the embroidery frame

Raise the presser foot lever to raise the presser foot.

Press the part of the embroidery carriage frame holder

in the figure to the left side, and raise the embroidery

frame.

 The embroidery frame will separate from the

embroidery carriage frame holder.

Remove the embroidery frame under the presser foot

while raising the presser foot lever even further.

Note

• Wind and insert the bobbin before attaching the

embroidery frame making sure to use the

recommended bobbin thread. Check that there is

enough thread in the bobbin.

CAUTION

• Correctly set the embroidery frame into the

embroidery carriage frame holder. Otherwise,

the presser foot may hit the embroidery frame,

resulting in injury.

1 Lever

CAUTION

• Do not hit the needle with your finger or the

embroidery frame. It may cause injury or

needle breakage.

Embroidering

EMBROIDERY

■ Copyright information

The patterns stored in the machine are intended for private

use only. Any public or commercial use of copyrighted

patterns is an infringement of copyright law and is strictly

prohibited.

■ Embroidery pattern types

1 Embroidery patterns

2 Brother “Exclusives”

3 Floral alphabet patterns

4 Character patterns

5 Frame patterns

6 Touch this key to position the embroidery unit for

storage

7 Patterns saved in the machine's memory, patterns saved

in USB flash drive, or patterns transferred via the

wireless network (page 80)

• Refer to the “Embroidery Design Guide” for more

information on each category’s embroidery pattern.

Selecting an embroidery pattern

Touch in the pattern type selection screen, and

then touch .

• If the pattern type selection screen is not displayed,

touch to display the screen below.

Touch or to display the desired pattern on the

screen.

Select a desired embroidery pattern, and then touch

• Available frame options are displayed on the screen.

1 Embroidery frame (medium) can be used

2 Embroidery frame (small) (sold separately) cannot be

used

 Pattern editing screen appears.

Touch .

• For details on pattern editing screen, refer to “Editing

Patterns (Pattern Editing Screen)” on page 75. You

can move the pattern, change the size of pattern, and

perform many other editing operations.

• The pattern can also be moved by dragging it with

your finger.

 Embroidery settings screen appears.

Touch .

• For details on embroidery settings screen, refer to

“Editing Patterns (Embroidery Settings Screen)” on

page 78.

• Confirm the pattern position to be embroidered,

referring to “Checking the pattern position” on

page 69.

Embroidering

■ Selecting character patterns

Touch .

Touch the key of the font you want to embroider.

Touch a tab to display the desired selection screen, and

then type in the text.

• To enter a space, touch .

• After selecting a character if you would like to

change the character size touch . The size

changes each time you touch the key, from large to

medium to small. After the character size is changed,

all characters on the same line will have the new

character size.

• If you make a mistake, touch to erase the

mistake.

• To check all entered characters, for example, when

there are multiple text lines, touch .

• To add multiple lines, touch .

• When the Japanese font is selected, the text can be

switched between being written vertically and

horizontally by touching .

Touch .

• For details on editing the pattern, refer to “Editing

Patterns (Pattern Editing Screen)” on page 75.

Memo

• If [Embroidery Frame Identification View] in the

settings screen is set to [ON], the pattern can be

edited in the screen as if that embroidery frame is

attached.

1 The embroidery frame selected when

[Embroidery Frame Identification View] is set to

[ON] is highlighted. Touch this key to switch the

setting between [ON] and [OFF].

2 The embroidering area for the selected frame is

displayed.

3 Patterns that will not fit in the selected frame

appear shaded and cannot be selected.

• There are three embroidering area sizes for

embroidery frame (small) (sold separately).

When [Embroidery Frame Identification View] is set

to [ON] for embroidery frame (small), the area for

arranging patterns can more easily be seen. The

area outside of the embroidering area will have a

different background color.

1 2 cm × 6 cm (approx.1 inch (H) × 2-1/2 inches

(W))

2 3 cm × 5 cm (approx.1-1/8 inch (H) × 2 inches

(W))

3 4 cm × 3 cm (approx.1-1/2 inch (H) × 1-1/8 inch

(W))

4 Patterns are arranged outside of the

embroidering area.

1234

1 Current line number

2 Tab

Embroidering

EMBROIDERY

■ Selecting frame patterns

Touch .

Touch the key of the frame shape you want to

embroidery.

Touch the key of the frame pattern you want to

embroidery.

Touch .

• For details on editing the pattern, refer to “Editing

Patterns (Pattern Editing Screen)” on page 75.

■ Checking the pattern position

The embroidery frame moves and shows the pattern position.

Watch the frame closely to make sure the pattern will be

embroidered in the right place.

Touch on the embroidery settings screen.

From , touch the key for the position that you

want to check.

1 Selected position

 The carriage will move to the selected position on

the pattern.

Touch , and then touch .

Memo

• To see the entire embroidering area, touch .

The embroidery frame moves and shows the

embroidery area.

CAUTION

• Make sure the needle is up when the

embroidery frame is moving. If the needle is

down, it may break and cause injury.

Embroidering

Embroidering a pattern

Embroidery patterns are embroidered with a change of thread

after each color.

Prepare embroidery thread colors as shown on the

screen.

1 Embroidery color order

• Either the thread color name or the thread number

appears in this screen, depending on the setting

selected in the settings screen. Touch to change

the setting in the settings screen. For details, refer to

“Changing the thread color display” on page 71.

• The automatic thread cutting function will cut the

thread at the end of embroidering each color. This

function is initially turned on. To turn this function

off, touch .

Thread the machine and needle with embroidery

thread.

• Refer to “Threading the upper thread” on page 23.

Raise the presser foot lever and pass the thread through

the embroidery foot hole, and hold it lightly in your left

hand.

Give the thread a little slack.

Lower the presser foot, then press the “Start/Stop”

button to start embroidering.

After 5-6 stitches, press the “Start/Stop” button again

to stop the machine.

Trim the excess thread at the end of the seam. If the

end of the seam is under the presser foot, raise the

presser foot, then trim the excess thread.

• If the thread is left at the beginning of the stitching, it

may be embroidered over as you continue

embroidering the pattern, making it very difficult to

remove the excess thread after the pattern is finished.

Trim the thread at the beginning.

Press the “Start/Stop” button to start embroidering.

 Stitching stops automatically with reinforcement after

one color has been completed. When automatic

thread cutting is set, the thread is cut.

Remove the thread for the first color from the

machine.

Repeat the same steps for embroidering the remaining

colors.

 When the last color is embroidered, the message

informing that the embroidering is finished will

appear on the display. Touch , and the display

will return to the initial screen.

CAUTION

• When embroidering on large garments

(especially jackets or other heavy fabrics), do

not let the fabric hang over the table.

Otherwise, the embroidery unit cannot move

freely and the embroidery frame may strike the

needle, causing the needle to break and

possibly causing injury.

Note

• Make sure that there are no objects within the

moving area of the embroidery frame. If the

embroidery frame hits another object, the pattern

may become misaligned.

Embroidering

EMBROIDERY

Cut the excess thread jumps within the color.

■ Changing the thread color display

You can display the name of the thread colors or embroidery

thread number.

Touch and use or to display the following

settings screen.

Use or of the menu to select [Name of

Color] or [#123] (thread number).

• When [Name of Color] is selected, the name of the

thread colors is displayed.

• When [#123] is selected, the embroidery thread

number is displayed.

Use or of the menu to select the

thread brand.

Touch .

■ If the thread breaks or the bobbin runs out of

thread during embroidering

Press the “Start/Stop” button to stop the machine.

Touch and thread the upper thread or install the

bobbin thread again.

• If the bobbin thread is almost empty, press

(Thread cutter button) to cut the upper and bobbin

threads, remove the embroidery frame, and then

replace the bobbin with one wound with thread.

Touch .

Touch , , or to move the needle back the

correct number of stitches before the area where the

thread broke, and then touch .

• Touch to restart from the beginning.

Lower the presser foot and press the “Start/Stop”

button to continue embroidering.

■ Resuming embroidery after turning off the

power

The current color and stitch number are saved when

embroidery is stopped. The next time the machine is turned

on, you have the option to continue or delete the pattern.

Memo

• Colors on the screen may vary slightly from actual

spool colors.

• The default thread brand is set to [Original].

Imported embroidery data is displayed with the

thread brand specified in the embroidery editing

software.

Memo

• The thread brand setting will be applied with the

next pattern that is loaded.

Memo

• If you cannot move back to the area where the

thread broke, touch to select the color and

move to the beginning position of that color, then

use , or to move ahead to slightly

before where the thread broke.

Embroidering

Adjusting thread tension

The upper thread tension is changed using the thread tension

dial.

When doing machine embroidery, the thread tension dial

should be set somewhere between 2 to 6.

■ Correct thread tension

The thread tension is correct when upper thread is just visible

on the wrong side (bottom) of the fabric.

■ Upper thread is too tight

The bobbin thread will be visible on the right side (top) of the

fabric. In this instance, decrease the upper thread tension.

■ Upper thread is too loose

The upper thread has slack. In this instance, increase the

upper thread tension.

Embroidering the appliqué patterns

When the color embroidering order display shows

[ (APPLIQUE MATERIAL)],

[ (APPLIQUE POSITION)] or

[ (APPLIQUE)], follow the procedure below.

Required materials

• Fabric for the appliqué piece

• Fabric for the appliqué base

• Stabilizer material

• Fabric glue or temporary spray adhesive

• Embroidering thread

■ 1. Creating an appliqué piece

Attach stabilizer material to the wrong side of the

appliqué fabric.

Sew the cutting line of the appliqué piece. Remove the

fabric for the appliqué piece from the embroidery

frame, and then carefully cut along the sewn cutting

line.

1 Outline of appliqué

2 Appliqué material

1 Loosen (Decrease the

number)

2 Tighten (Increase the

number)

3 Thread tension dial

Note

• If the stitches appear loose, turn the tension up one

notch and embroider again.

1 Right side (top) of

fabric

2 Wrong side (bottom)

of fabric

1 Right side (top) of

fabric

2 Wrong side (bottom)

of fabric

1 Right side (top) of

fabric

2 Wrong side (bottom)

of fabric

Note

• If the upper thread is not threaded correctly or the

bobbin is not installed correctly, it may not be

possible to set the correct thread tension. If the

correct thread tension cannot be achieved,

rethread the upper thread and insert the bobbin

correctly.

Note

• The correct names and numbers of the thread

colors to be used will not appear. Select the thread

colors depending on those in the appliqué pattern.

• Some appliqué patterns differ from the procedure

described in this manual. For the procedure, refer

to the “Embroidery Design Guide”.

Note

• If the appliqué piece is cut out along the inside of

the cutting line, it may not be correctly attached to

the fabric. Therefore, carefully cut out the appliqué

piece along the cutting line.

• After cutting out the appliqué piece, carefully

remove the thread.

Embroidering

EMBROIDERY

■ 2. Sewing the appliqué position on the base

fabric

Sew the appliqué position.

Remove the embroidery frame from the embroidery

unit.

■ 3. Affixing the appliqué piece to the base

fabric

Lightly apply fabric glue or temporary spray adhesive

to the back of the appliqué piece, and then attach it to

the base fabric within the outline of the position sewn

in step

a of “2. Sewing the appliqué position on the

base fabric”.

After the appliqué piece is attached, attach the

embroidery frame to the machine.

Thread the machine with the embroidery thread, lower

the presser foot lever, and then press the “Start/Stop”

button to embroider the appliqué.

Finish embroidering the remainder of the pattern.

Using a frame pattern to make an appliqué

You can use framed patterns of the same size and shape to

create an appliqué. Embroider one pattern with a straight

stitch and one pattern with a satin stitch.

■ Method 1

Select a straight stitch frame pattern. Embroider the

pattern onto the appliqué material, then cut neatly

around the outside of the shape.

Embroider the same pattern from step a onto the

base fabric.

Apply a thin layer of fabric glue or a temporary spray

adhesive to the back of the appliqué created in step

a. Attach the appliqué to the base fabric matching

the shapes.

1 Position of appliqué

2 Base material

Note

• Do not remove the base fabric from the embroidery

frame until all sewing is finished.

Note

• If the appliqué piece cannot be attached to the

base fabric with fabric glue or temporary spray

adhesive, securely baste it in place with basting

stitches.

• If thin fabric is used for the appliqué piece,

reinforce and secure it in place with an iron-on

adhesive sheet. An iron can be used to attach the

appliqué piece to the appliqué location.

Embroidering

Select the satin stitch frame pattern of the same shape

as the appliqué. Embroider over the appliqué and base

fabric from step b to create the appliqué.

■ Method 2

Select a straight stitch frame pattern, and embroider

the pattern onto the base fabric.

Place the appliqué fabric over the pattern embroidered

in step

a and embroider the same pattern on the

appliqué fabric.

• Be sure that the appliqué fabric completely covers

the stitched line.

Remove the embroidery frame from the embroidery

unit, and cut around the outside of the stitches of the

appliqué fabric.

Reattach the embroidery frame to the embroidery unit.

Select the satin stitch frame pattern of the same shape

as the appliqué and embroider the satin stitch pattern

to create an appliqué.

• Do not change the size or position of the pattern.

Note

• Do not remove the fabric from the embroidery

frame to cut it. Also, do not pull or push on the

fabric. Otherwise, the fabric may loosen in the

frame.

Editing Patterns (Pattern Editing Screen)

EMBROIDERY

Split embroidery patterns

Split embroidery patterns created with PE-DESIGN Ver.7 or

later can be embroidered. With split embroidery patterns,

embroidery designs larger than the embroidery hoop are

divided into multiple sections, which combine to create a

single pattern after each section is embroidered.

For details on creating split embroidery patterns and for more

detailed embroidery instructions, refer to the Instruction

manual included with PE-DESIGN Ver.7 or later.

Insert the USB flash drive containing the created split

embroidery pattern, and then select the split

embroidery pattern to be embroidered.

• For details, refer to “Retrieving embroidery patterns”

on page 80.

Select section to be embroidered and touch .

• Select the sections in alphabetical order.

Touch and touch .

Press the “Start/Stop” button to embroider the pattern

section.

When embroidering is finished, the following screen

appears. Touch .

 A screen appears so that a section of the split

embroidery pattern can be selected.

Repeat steps b through e to embroider the

remaining sections of the pattern.

When a pattern is selected in the pattern selection screen

and is touched, the pattern editing screen appears.

After touching any of the keys to edit the pattern, touch

to return to the previous screen. To finish all the

editing, touch to continue to the embroidery settings

screen.

■ Pattern editing screen

Editing Patterns (Pattern Editing

Screen)

CAUTION

• When you have revised the pattern, check the

display of available embroidery frames and use

an appropriate frame. If you use an embroidery

frame not displayed as available for use, the

presser foot may strike the frame, possibly

causing injuries or damage.

Memo

• If a key display is light gray, you cannot use that

function with the selected pattern.

No.

Display

Explanation

Key Name

1 Shows the embroidery frames that can

be used (page 67). In addition, after

touching the key for the embroidery

frame to be used, [Embroidery Frame

Identification View] can be set to [ON].

When setting [Embroidery Frame

Identification View] to [OFF], touch .

Embroidery frame

2 Shows the size of the entire combined

pattern.

Pattern size

1 2 3 4

A 0 9

Editing Patterns (Pattern Editing Screen)

■ Font editing screen

Font editing screen appears by touching on the pattern

editing screen.

3 Touch this key to magnify the pattern in

the screen.

When the pattern is magnified,

appears.

Touch these keys to move the display

area in the screen in the corresponding

directions, making this convenient for

checking pattern details.

After touching to apply the selected

magnification, you can continue editing

at that magnification.

Magnify key

4 Touch this key to show embroidered

image. Touch to select the

frame used in the preview.

• : Embroidery frame (medium) 10

cm × 10 cm (4 inches × 4 inches)

• : Embroidery frame (small) (sold

separately) 2 cm × 6 cm (1 inch × 2-1/

2 inches)

Touch to enlarge the image of the

pattern.

Preview key

5 Touch this key to rotate the pattern.

Touch to return the pattern to its

original position.

Rotate key

6 Touch this key to change the colors of

the displayed pattern.

Touch or to select the thread

brand.

Touch or to select the color you

want to change.

Touch or touch the color

on the color palette to choose a new

color.

To return to the original color, touch

Thread palette key

7 Touch this key to delete the selected

pattern (the pattern outlined by the red

box).

Delete key

8 Touch this key to display the font editing

screen. (page 76)

Font edit key

9 Touch this key to call up the embroidery

settings screen. (page 78)

Edit End key

0 Touch this key to save patterns to the

machine's memory or USB flash drive.

Patterns can also be transferred to a

computer via wireless network

connection. (page 80)

Memory key

No.

Display

Explanation

Key Name

A When a combined pattern is selected,

use this key to select a part of the pattern

to edit. The selected pattern is outlined

by the red box.

Pattern select key

B Touch this key to make a horizontal

mirror image of the selected pattern.

Horizontal mirror

image key

C Touch this key to change thread density

for some alphabet character and frame

patterns.

Thread density

key

D Touch this key to move the pattern.

Use to move the pattern in the

direction shown by the arrow.

Touch to center the pattern.

Move key

E Touch this key to change the size of the

pattern.

: Enlarges the pattern proportionately.

: Decreases the pattern proportionately.

: Stretches the pattern horizontally.

: Decreases the pattern horizontally.

: Stretches the pattern vertically.

: Decreases the pattern vertically.

: Returns the pattern to its original

size.

: Changes the size of the character

patterns.

Size key

No.

Display

Explanation

Key Name

1 Touch this key when you want to change

the thread color, character by character

in character embroidery. Since the

machine stops at the end of each

character, the upper thread is changed

as you embroider. Touch this key again

to cancel setting.

Multi color key

No.

Display

Explanation

Key Name

1 234

7 8 6

Editing Patterns (Pattern Editing Screen)

EMBROIDERY

2 Touch this key to change the

configuration of a character pattern.

When selecting an arc (

), use and to change the

degree of the arc.

: Make the arc flatter.

: Make the arc rounder.

When selecting , and

change to and . You can

increase or decrease the incline.

Touch to return the character

patterns to its original appearance.

Array key

3 Touch this key to change the font of the

selected characters.

Depending on the font that was selected,

it may not be possible to change the

font.

Font key

4 Touch this key to switch between text

written vertically and horizontally.

(Japanese font only)

Vertical/horizontal

text key

5 Touch this key to edit each character

separately.

When touching , select the

character by using to change

the size.

When touching , select the

character by using to change

the font.

Edit character key

6 Touch this key to split text between

characters so that they can be edited

separately.

Use to select where the

pattern is to be separated, and then

touch to separate it.

Any pattern that is split cannot be

recombined.

Split text key

No.

Display

Explanation

Key Name

7 Touch this key to change the spacing of

character patterns.

Touch / to increase or decrease

the character spacing.

Touch to return the pattern to its

original appearance.

Character spacing

key

8 When a combined pattern is selected,

use this key to select a part of the pattern

to edit. The selected pattern is outlined

by the red box. If the line feed key was

used while entering text, single lines can

be selected.

Select key

No.

Display

Explanation

Key Name

Editing Patterns (Embroidery Settings Screen)

When is touched in the editing screen, the

embroidery settings screen appears. After editing the

pattern, touch to continue to the embroidering

screen.

■ Embroidery settings screen

Aligning the pattern and the needle position

Example: Aligning the lower left side of a pattern and the

needle position

Mark the embroidery start position on the fabric, as

shown.

Touch .

Touch and touch .

1 Start position

 The needle position moves to the bottom left corner

of the pattern (the embroidery frame moves so that

the needle is positioned correctly).

Use to align the needle and the mark on the

fabric, touch and begin embroidering the pattern.

Editing Patterns (Embroidery Settings

Screen)

No.

Display

Explanation

Key Name

1 Touch these keys to move the pattern in

the direction shown by the arrow.

(Touch the center key to return the

pattern to the center of the embroidery

area.) (page 78)

Move key

2 Touch this key to rotate the entire

pattern.

Touch to return the pattern to its

original position.

Rotate key

3 Touch this key to enter the embroidery

screen.

Embroidery key

4 Touch this key to save patterns to the

machine's memory or USB flash drive.

Patterns can also be transferred to a

computer via wireless network

connection. (page 80)

Memory key

5 Touch this key to check the position of

the pattern. (page 69)

Trial key

6 Touch this key to move the needle start

position to align the needle with the

pattern position. (page 78)

Starting point key

6 5 4

Editing Patterns (Embroidery Settings Screen)

EMBROIDERY

Embroidering linked characters

Follow the procedure described below to embroider linked

characters in a single row when the entire pattern extends

beyond the embroidery frame.

Example: Linking “DEF” to the characters “ABC”

Select the character patterns for “ABC”, and then

touch and .

Touch .

Touch , and then touch .

 The needle is positioned in the lower-left corner of

the pattern. The embroidery frame moves so that the

needle is positioned correctly.

Touch .

Lower the embroidery foot and then press the “Start/

Stop” button to begin embroidering.

After the characters are embroidered, and the threads

are cut, remove the embroidery frame, and then touch

for [Finished embroidering].

Reposition the fabric in embroidery frame so that the

right side of the letter “C” will be partially inside the

embroidery frame; being careful so letters remain

straight and level. Then reattach frame again so that

the remaining characters (“DEF”) can be embroidered.

Touch to cancel the current character patterns.

Select the character patterns for “DEF”, and then

touch and .

Touch .

Touch , and then touch .

 The needle is positioned in the lower-left corner of

the pattern. The embroidery frame moves so that the

needle is positioned correctly.

Use to align the needle with the end of the

embroidering for the previous pattern.

Touch .

Lower the embroidery foot and press the “Start/Stop”

button to begin embroidering the remaining character

patterns.

1 End of the

embroidering

Using the Memory Function

Saving embroidery patterns

You can save embroidery patterns that you have customized

in the machine's memory or USB flash drive.

You can also transfer the patterns to your computer via

wireless network.

Touch when the pattern you want to save is in the

pattern editing screen or embroidery settings screen.

When saving the embroidery pattern in a USB flash

drive, insert the USB flash drive into the USB port on

the machine.

Touch the desired destination to start saving.

1 Save to the machine’s memory.

2 Save to the USB flash drive.

The pattern is saved in a folder labeled “bPocket”.

3 Temporarily save to the wireless function pocket. For the

detailed procedure, refer to the manual for PE-DESIGN

(version 11 or later).

* Embroidery patterns which were saved to the

wireless function pocket will be deleted from the

pocket when turning the machine off. Import the

embroidery patterns to PE-DESIGN (version 11 or

later) before turning the machine off.

Retrieving embroidery patterns

Retrieve embroidery patterns saved in the machine's memory,

or on a USB flash drive, or transferred via wireless network.

When retrieving the embroidery patterns from a USB

flash drive, insert the USB flash drive into the USB port

on the machine.

To retrieve embroidery patterns via wireless network,

use PE-DESIGN (version 11 or later) or Design

Database Transfer to transfer the patterns in advance.

For details on transferring embroidery patterns, refer

to the manual for PE-DESIGN or Design Database

Transfer.

Touch .

Touch the desired destination, and then select the

desired embroidery pattern.

1 Retrieve from the machine’s memory.

2 Retrieve from a USB flash drive.

3 Retrieve embroidery patterns uploaded to the wireless

function pocket via wireless network.

For the detailed procedure, refer to the manual for PE-

DESIGN (version 11 or later) or Design Database

Transfer.

* Embroidery patterns which were uploaded via

wireless network will be deleted from the machine

when turning the machine off. Save patterns to the

machine memory if necessary. (page 80)

Using the Memory Function

Note

• Do not turn the main power to OFF while the

[Saving...] screen is displayed. You will lose the

pattern you are saving.

Memo

• If the embroidery pattern to be retrieved is in a

folder of the USB flash drive, touch the key for that

folder. Touch to return to the previous screen.

Using the Memory Function

EMBROIDERY

Touch .

Memo

• When saving a retrieved pattern, touch the

following keys.

1.Touch .

2.Touch the key for the desired destination.

: Saves to the machine.

: Saves to the USB flash drive.

: Temporarily saves to the wireless function

pocket.

When saving patterns retrieved via USB or

wireless network to the machine, touch

• When you touch , the selected embroidery

pattern will be deleted permanently.

Using the Memory Function

Care and Maintenance

APPENDIX

Cleaning the LCD

If the surface of the LCD is dirty, lightly wipe it with a soft dry

cloth.

Cleaning the machine surface

When wiping dirt off the machine, firmly wring a soft cloth

soaked in (lukewarm) water.

After cleaning the machine, dry it with a soft, dry cloth.

Restrictions on oiling

In order to prevent damaging this machine, it must not be

oiled by the user.

This machine was manufactured with the necessary amount

of oil applied to ensure correct operation, making periodic

oiling unnecessary.

If problems occur, such as difficulty turning the handwheel or

an unusual noise, immediately stop using the machine, and

contact your authorized Brother dealer or the nearest Brother

authorized service center.

Precautions on storing the machine

Do not store the machine in any of the locations described

below, otherwise damage to the machine may result, for

example, rust caused by condensation.

• Exposed to extremely high temperatures

• Exposed to extremely low temperatures

• Exposed to extreme temperature changes

• Exposed to high humidity or steam

• Near a flame, heater or air conditioner

• Outdoors or exposed to direct sunlight

• Exposed to extremely dusty or oily environments

Cleaning the race

Stitching performance will suffer if lint and dust collects in the

bobbin case, therefore, it should be cleaned regularly.

Press (Needle position button) to raise the needle.

Turn off the machine.

Unplug the power cord from the power supply jack on

the right side of the machine.

Raise the presser foot to remove the needle and presser

foot.

• For details, refer to “Replacing the Needle” on

page 28 and “Replacing the Presser Foot” on

page 29.

Remove the flat bed attachment or the embroidery unit

if either is attached.

Remove the bobbin cover.

Place the index finger of your right hand near the

bottom of the latch on the needle plate cover.

Insert the tip of the index finger of your left hand into

the notch at the back of the needle plate cover.

Place the thumb of your left hand at the front of the

needle plate cover.

Slide the needle plate cover toward you to remove it.

Chapter 5

APPENDIX

Care and Maintenance

CAUTION

• Unplug the power cord before cleaning the

machine, otherwise injuries may occur.

Note

• In order to extend the life of this machine,

periodically turn it on and use it.

Storing this machine for an extended period of time

without using it may reduce its efficiency.

Care and Maintenance

Grasp the bobbin case, and then pull it out.

Use the cleaning brush or a vacuum cleaner to remove

any lint and dust from the race and bobbin thread

sensor and the surrounding area.

1 Cleaning brush

2 Race

3 Bobbin thread sensor

Insert the bobbin case so that the



mark on the

bobbin case aligns with the

 mark on the machine.

• Align the  and

 marks.

1  mark

 mark

3 Bobbin case

• Make sure that the indicated points are aligned

before installing the bobbin case.

Insert the tabs on the needle plate cover into the

needle plate, and then slide the cover back on.

Reattach the bobbin cover.

Touch panel is malfunctioning

If the screen does not respond correctly when you touch a key

(the machine does not perform the operation or performs a

different operation), follow the steps below to make the

proper adjustments.

Holding your finger on the screen, turn the main

power switch to OFF and back to ON.

 The touch panel adjustment screen is displayed.

Lightly touch the center of each +, in order from 1 to 5.

Turn the main power to OFF, then turn it back to ON.

IMPORTANT

• Do not apply oil to the bobbin case.

CAUTION

• Never use a bobbin case that is scratched or has

a burr on it. Otherwise the upper thread may

become tangled, the needle may break and cause

injury. For a new bobbin case, contact your

nearest Brother authorized service center.

• Be sure that the bobbin case is correctly

installed, otherwise the needle may break and

cause injury.

Troubleshooting

APPENDIX

If the machine stops operating correctly, check the

following possible problems before requesting service.

You can solve most problems by yourself. If you need

additional help, Brother support website offers the latest

FAQs and troubleshooting tips. Visit us at https://s.brother/

cpjap/.

If the problem persists, contact your authorized Brother

dealer or the nearest Brother authorized service center.

■ Frequent troubleshooting topics

Detailed causes and remedies for common troubleshooting

topics are described below. Be sure to refer to this before

contacting us.

Upper thread tightened up

■ Symptom

• The upper thread appears as a single continuous line.

• The bobbin thread is visible from the right side of the

fabric. (Refer to the illustration below.)

• The upper thread has tightened up, and comes out

when pulled.

• The upper thread has tightened up, and wrinkles

appear in the fabric.

• The upper thread tension is tight, and the results do

not change even after the thread tension is adjusted.

1 Wrong side of fabric

2 Bobbin thread visible from right side of fabric

3 Upper thread

4 Right side of fabric

5 Bobbin thread

■ Cause

Incorrect bobbin threading

If the bobbin thread is incorrectly threaded, instead of the

appropriate tension being applied to the bobbin thread, it

is pulled through the fabric when the upper thread is

pulled up. For this reason, the thread is visible from the

right side of the fabric.

■ Remedy/check details

Correctly install the bobbin thread. (page 22)

Tangled thread on wrong side of fabric

■ Symptom

• The thread becomes tangled on the wrong side of the

fabric.

• After starting sewing, a rattling noise is made and

sewing cannot continue.

• Looking under the fabric, there is tangled thread in

the bobbin case.

■ Cause

Incorrect upper threading

If the upper thread is incorrectly threaded, the upper

thread passed through the fabric cannot be firmly pulled

up and the upper thread becomes tangled in the bobbin

case, causing a rattling noise.

■ Remedy/check details

Remove the tangled thread, and then correct the upper

threading.

Remove the tangled thread. If it cannot be removed,

cut the thread with scissors.

• For details, refer to “Cleaning the race” on page 83.

Remove the upper thread from the machine.

Correct the upper threading by following the

instructions in “Threading the upper thread” on

page 23.

• If the bobbin was removed from the bobbin case,

refer to “Installing the bobbin” on page 22 to

correctly install the bobbin.

Troubleshooting

Upper thread tightened up page 85

Tangled thread on wrong side of fabric page 85

Incorrect thread tension page 86

Fabric is caught in the machine and cannot

be removed

page 87

If the thread becomes tangled under the

bobbin winder seat

page 89

Troubleshooting

Incorrect thread tension

■ Symptoms

• Symptom 1: The bobbin thread is visible from the

right side of the fabric. (Refer to illustration below)

• Symptom 2: The upper thread appears as a straight

line on the right side of the fabric.

• Symptom 3: The upper thread is visible from the

wrong side of the fabric. (Refer to illustration below)

• Symptom 4: The bobbin thread appears as a straight

line on the wrong side of the fabric.

• Symptom 5: The stitching on the wrong side of the

fabric is loose or has slack.

1 Wrong side of fabric

2 Bobbin thread visible from right side of fabric

3 Upper thread

4 Right side of fabric

5 Bobbin thread

6 Upper thread visible from wrong side of fabric

■ Cause/remedy/check details

 Cause 1

The machine is not correctly threaded.

The bobbin threading is incorrect.

Return the thread tension dial to “4”, and then refer to

“Installing the bobbin” on page 22 to correct the

threading.

The upper threading is incorrect.

Return the thread tension dial to “4”, and then refer to

“Threading the upper thread” on page 23 to correct the

upper threading.

 Cause 2

A needle and thread appropriate for the fabric are not

being used.

The machine needle that should be used depends on the

type of fabric sewn and the thread thickness.

If a needle and thread appropriate for the fabric are not

being used, the thread tension will not be adjusted

correctly, causing wrinkles in the fabric or skipped

stitches.

• Refer to “Fabric/Thread/Needle Combinations” on

page 27 to check that a needle and thread

appropriate for the fabric are being used.

 Cause 3

An appropriate upper tension is not selected.

Select an appropriate thread tension.

Refer to “Adjusting the Thread Tension” on page 36.

The appropriate thread tension differs depending on the

type of fabric and thread being used.

* Adjust the thread tension while test sewing on a

piece of scrap fabric that is the same as that used in

your project.

• If the bobbin thread is visible from the right side of

the fabric

Turn the thread tension dial counterclockwise to

loosen the upper thread tension.

• If the upper thread is visible from the wrong side of

the fabric

Turn the thread tension dial clockwise to tighten the

upper thread tension.

 Symptom 1  Symptom 3

Note

• If the upper threading and bobbin threading are

incorrect, the thread tension cannot be adjusted

correctly. Check the upper threading and bobbin

threading first, and then adjust the thread tension.

Troubleshooting

APPENDIX

Fabric is caught in the machine and cannot

be removed

If the fabric is caught in the machine and cannot be removed,

the thread may have become tangled under the needle plate.

Follow the procedure described below to remove the fabric

from the machine. If the operation cannot be completed

according to this procedure, instead of attempting to remove it

forcefully, contact your nearest Brother authorized service

center.

■ Removing the fabric from the machine

Immediately stop the machine.

Turn off the machine.

Remove the needle.

If the needle is lowered into the fabric, turn the

handwheel away from you (clockwise) to raise the

needle out of the fabric, and then remove the needle.

• Refer to “Replacing the Needle” on page 28.

Remove the presser foot and presser foot holder.

If the thread is entangled on the presser foot, remove the

entangled thread, and then raise the presser foot lever to

remove the presser foot. Otherwise, the presser foot may

be damaged.

• Refer to “Replacing the Presser Foot” on page 29.

Lift up the fabric and cut the threads below it.

If the fabric can be removed, remove it. Continue with

the following steps to clean the race.

Remove the needle plate cover.

• Refer to “Cleaning the race” on page 83.

Cut out the tangled threads, and then remove the

bobbin.

Remove the bobbin case.

If threads remain in the bobbin case, remove them.

Use the cleaning brush or a vacuum cleaner mini

attachment to remove any lint or dust from the race

and its surrounding area.

Use the included disc-shaped screwdriver to loosen the

two screws on the needle plate.

Slightly lift up the needle plate, cut any tangled

threads, and then remove the needle plate.

Remove the fabric and threads from the needle plate.

If the fabric cannot be removed, even after completing

these steps, contact your nearest Brother authorized

service center.

Remove any threads in the race and around the feed

dogs.

Turn the handwheel to raise the feed dogs.

Fit the needle plate onto the machine.

Lightly finger-tighten the screw on the right side of the

needle plate. Then, use the disc-shaped screwdriver to

firmly tighten the screw on the left side. Finally, firmly

tighten the screw on the right side.

1 Cleaning brush

2 Race

If the fabric could be removed. Continue with step p.

If the fabric could not be removed. Continue with step j.

Note

• Be careful not to drop the removed screws in the

machine.

Troubleshooting

Turn the handwheel to check that the feed dogs move

smoothly and do not contact the edges of the slots in the

needle plate.

1 The feed dogs do not contact the needle plate.

2 The feed dogs contact the needle plate.

3 Needle plate

4 Feed dogs

Insert the bobbin case by following step k in

“Cleaning the race” on page 83.

Attach the needle plate cover according to step l in

“Cleaning the race” on page 83.

Check the condition of the needle, and then install it.

If the needle is in a poor condition, for example, if it is

bent, be sure to install a new needle.

• Refer to “Checking the needle” on page 28 and

“Replacing the needle” on page 28.

■ Checking machine operations

If the needle plate has been removed, check machine

operations to confirm that installation has been completed

correctly.

Turn on the machine.

 The needle will automatically move left and right.

Select Straight stitch (Middle).

* Refer to “Stitch Chart” on page 41.

Slowly turn the handwheel toward you

(counterclockwise), and look from all sides to check

that the needle falls at the center of the opening in the

needle plate.

If the needle or feed dogs contact the needle plate, the

machine may be malfunctioning; therefore, contact

your nearest Brother authorized service center.

Turn off the machine, and then install the bobbin and

presser foot.

Never use a scratched or damaged presser foot.

Otherwise, the needle may break, or sewing

performance may suffer.

• Refer to “Installing the bobbin” on page 22 and

“Replacing the presser foot” on page 29.

Correctly thread the machine.

• For details on threading the machine, refer to “Upper

Threading” on page 23.

Perform trial sewing with cotton fabric.

Memo

• Since the needle may have been damaged when

the fabric was caught in the machine, we

recommend replacing it with a new one.

Note

• If an error occurs, the machine may be

malfunctioning; so contact your authorized Brother

dealer or the nearest Brother authorized service

center.

Note

• Do not yet install the presser foot and thread.

1 Opening in the needle

plate

2 Handwheel

Note

• Incorrect sewing may be the result of incorrect

upper threading or sewing thin fabrics. If there are

poor results from the trial sewing, check the upper

threading or the type of fabric being used.

Troubleshooting

APPENDIX

If the thread becomes tangled under the

bobbin winder seat

If the bobbin winding starts when the thread is not passed

under the pretension disk of the bobbin winding thread guide

correctly, the thread may become tangled under the bobbin

winder seat.

Stop the bobbin winding.

Cut the thread with scissors beside the bobbin winding

thread guide.

Slide the bobbin winder shaft to the left, and then

remove the bobbin from the shaft and cut the thread

leading to the bobbin in order to be able to completely

remove the bobbin from shaft.

Hold the thread end with your left hand, and wind off

the thread clockwise from under the bobbin winder

seat with your right hand as shown below.

List of symptoms

Check the following possible problems before requesting

service. If the reference page is “*”, contact your authorized

Brother dealer or the nearest Brother authorized service

center.

■ Getting ready

CAUTION

• Do not remove the bobbin winder seat even if

the thread becomes tangled under the bobbin

winder seat. Otherwise, there is a risk of being

injured by the cutter of the bobbin winder

seat.

Do not remove the screw on the bobbin

winder guide post, otherwise the machine may

be damaged; you cannot wind off the thread

by removing the screw.

1 Screw of the bobbin winder guide post

Symptom, Cause/solution

Reference

Cannot thread the needle.

Needle is not in the correct position.

• Press the “Needle position” button to raise the

needle.

Needle is installed incorrectly. 28

Needle is turned, bent or the point is dull. 28

Upper threading is incorrect.

The needle threader lever is not lowered until it

clicks.

The needle threader hook is bent and does not

pass through the eye of the needle.

The needle threader lever cannot be moved or

returned to its original position.

A size 65/9 needle is being used.

• The needle is incompatible with the needle

threader. Manually pass the thread through the

eye of the needle.

Bobbin thread does not wind neatly on the bobbin.

The thread is not passed through the bobbin

winding thread guide correctly.

The thread that was pulled out from the bobbin

winding thread guide was incorrectly wound onto

the bobbin.

The empty bobbin was not set on the pin

properly.

While winding the bobbin, the bobbin thread was

wound below the bobbin winder seat.

The thread was incorrectly passed under the

pretension disk on the bobbin winding thread

guide.

• Remove any entangled thread, and then wind

the bobbin.

19, 89

The bobbin thread cannot be pulled up.

Needle is turned, bent or the point is dull. 28

Bobbin is set incorrectly. 22

Nothing appears in the LCD.

Main power switch is not turned on. 11

The plug of the power cord is not inserted into an

electrical outlet.

Troubleshooting

■ While sewing

The LCD screen is fogged up.

Condensation has formed on the LCD screen.

• After a while, the cloudiness will disappear.

–

The operation keys do not respond, or the key

response is too sensitive.

A glove is worn when the keys are touched.

The keys are touched with a fingernail.

A non-electrostatic touch pen is being used.

The sensitivity of the operation keys is not set for

the user.

10, 16

The sewing light does not come on.

[Light] is set to [OFF] in the settings screen. 15

Embroidery unit does not operate.

Embroidery unit is not attached correctly. 62

Cannot retrieve an embroidery pattern via wireless

network.

Embroidery patterns unavailable for this machine

cannot be retrieved.

• Check the embroidery data and the message

displayed on the application.

–

Symptom, Cause/solution

Reference

Machine does not operate.

“Start/Stop” button was not pressed. 31

The bobbin winder shaft is pushed to the right. 19

There is no stitch selected. 31

Presser foot is not lowered. 32

“Start/Stop” button was pressed with the foot

controller attached.

The “Start/Stop” button was pressed while the

machine is set for the sewing speed controller to

control the zigzag stitch width.

15, 52

Needle breaks.

Needle is installed incorrectly. 28

Needle clamp screw is not tightened. 28

Needle is turned or bent. 28

Using improper needle or thread for the selected

fabric.

Wrong presser foot was used. 29

Upper thread tension is too tight. 36

Fabric is pulled during sewing. –

Spool of thread is set incorrectly. 19

Symptom, Cause/solution

Reference

There are scratches around the opening in the

needle plate.

* There is a notch on the left side of the opening

in the needle plate. This is not a scratch.

There are scratches around the opening in the

presser foot.

There are scratches on the bobbin case. *

A bobbin designed specifically for this machine is

not used.

Upper threading is incorrect. 23

Bobbin is set incorrectly. 22

Presser foot is attached incorrectly. 29

Screw of the presser foot holder is loose. 30

Fabric is too thick. 27, 39

Fabric is fed forcefully when sewing thick fabric or

thick seams.

Stitch length is too short. 35

Stabilizer is not attached to fabric being

embroidered.

Bobbin thread is incorrectly wound. 19

Upper thread breaks.

Machine is not threaded correctly (used the wrong

spool cap, spool cap is loose, the thread did not

catch the needle bar thread guide, etc.).

Knotted or tangled thread is being used. –

The selected needle is not appropriate for the

thread being used.

Upper thread tension is too tight. 36

Thread is tangled. 85

Needle is turned, bent or the point is dull. 28

Needle is installed incorrectly. 28

There are scratches around the opening in the

needle plate.

* There is a notch on the left side of the opening

in the needle plate. This is not a scratch.

There are scratches around the opening in the

presser foot.

There are scratches on the bobbin case. *

Using improper needle or thread for the selected

fabric.

A bobbin designed specifically for this machine is

not used.

The thread is tangled on the wrong side of the fabric.

Upper threading is incorrect. 23, 85

Using improper needle or thread for the selected

fabric.

Symptom, Cause/solution

Reference

1 Notch

Troubleshooting

APPENDIX

■ After sewing

The upper thread is too tight.

The bobbin thread is incorrectly installed. 22

Bobbin thread breaks.

Bobbin is set incorrectly. 22

Bobbin thread is incorrectly wound. 19

A scratched bobbin is being used. 22

Thread is tangled. 87

A bobbin designed specifically for this machine is

not used.

Fabric puckers.

There is a mistake in the upper or bobbin

threading.

19, 23

Spool of thread is set incorrectly. 19

Using improper needle or thread for the selected

fabric.

Needle is turned, bent or the point is dull. 28

Stitches are too long when sewing thin fabrics. 35

Thread tension is set incorrectly. 36, 86

Wrong presser foot was used. 29

The fabric is not pressed down correctly. –

The stitch is not sewn correctly.

The presser foot that is used is not appropriate for

the type of stitch that you wish to sew.

The thread tension is incorrect.

36, 86

The thread is tangled, for example, in the bobbin

case.

Feed dogs are set in the down position.

• Slide the feed dog position switch to the right

().

9, 50

Skipped stitches

Machine is threaded incorrectly. 19, 23

Using improper needle or thread for the selected

fabric.

Needle is turned, bent or the point is dull. 28

Needle is installed incorrectly. 28

Dust or lint has collected under the needle plate. 83

Thin or stretch fabrics are being sewn.

• Attach stabilizer material to the fabric.

Not stitching

Needle is turned, bent or the point is dull. 28

Bobbin is set incorrectly. 22

Upper threading is incorrect. 23

High-pitched sound while sewing

Dust or lint is caught in the feed dogs. 83

Pieces of thread are caught in the race. 83

Upper threading is incorrect. 23

A bobbin designed specifically for this machine is

not used.

There are needle holes or friction scratches in the

bobbin case.

Symptom, Cause/solution

Reference

Fabric does not feed through the machine.

Feed dogs are set in the down position.

• Slide the feed dog position switch to the right

().

9, 50

Stitches are too close together. 35

Wrong presser foot was used. 29

Needle is turned, bent or the point is dull. 28

Thread is entangled. 87

Zigzag foot “J” is slanted on a thick seam at the

beginning of stitching.

The fabric feeds in the opposite direction.

The feed mechanism is damaged. *

The needle contacts the needle plate.

The needle clamp screw is loose. 28

Needle is turned, bent or the point is dull. 28

Fabric being sewn with the machine cannot be

removed.

Thread is tangled below the needle plate. 87

A broken needle has fallen into the machine.

• Turn off the machine, and remove the needle

plate. If the needle that fell into the machine can

be seen, use tweezers to remove it. After

removing the needle, return the needle plate to

its original position and insert a new needle.

Before turning on the machine, slowly turn the

handwheel toward you to check that it turns

smoothly and that the new needle enters

through the center of the needle plate opening.

If the handwheel does not turn smoothly or the

needle that fell into the machine cannot be

removed, consult your authorized Brother dealer

or the nearest Brother authorized service center.

The handwheel does not turn smoothly.

Thread is tangled in the bobbin case. 83, 85, 87

Symptom, Cause/solution

Reference

Thread tension is incorrect.

Upper threading is incorrect. 23, 86

Bobbin is set incorrectly. 22, 86

Using improper needle or thread for the selected

fabric.

Presser foot holder is not attached correctly. 29

Thread tension is set incorrectly. 36, 86

Bobbin thread is incorrectly wound. 22

Needle is turned, bent or the point is dull. 28

A bobbin designed specifically for this machine is

not used.

Symptom, Cause/solution

Reference

Troubleshooting

Decorative stitch patterns are misaligned.

Wrong presser foot was used. 29

Stitch pattern adjustment settings were set

incorrectly.

Stitch pattern is irregular.

Wrong presser foot was used. 29

Thin or stretch fabrics are being sewn.

• Attach stabilizer material to the fabric.

Thread tension is set incorrectly. 36, 86

Fabric was pulled, pushed or fed at an angle while

it was being sewn.

• Sew while guiding the fabric with your hands so

that the fabric is fed in a straight line.

The thread is tangled, for example, in the bobbin

case.

Embroidery pattern does not embroider correctly.

Thread is twisted. 87

Thread tension is set incorrectly. 72, 86

Fabric was not inserted into the frame correctly

(fabric was loose, etc.).

Stabilizing material was not attached.

• Always use stabilizing material, especially with

stretch fabrics, lightweight fabrics, fabrics with a

coarse weave, or fabrics that often cause

pattern shrinkage. See your authorized Brother

dealer for the proper stabilizer.

There was an object placed near the machine, and

the carriage or embroidery frame hit the object

during embroidering.

Material coming out of the embroidery frame is

causing problems.

• Stretch the fabric on the frame once again so

that the material coming out of the embroidery

frame does not cause problems, rotate the

pattern and embroider.

A heavy fabric is being embroidered, and the

fabric is hanging off the table.

• If embroidery is done with the fabric hanging off

the table, the embroidery unit movement will be

impaired. Support the fabric while embroidering.

Fabric is snagged or caught on something.

• Stop the machine and place the fabric so that it

does not get caught or snagged.

–

The carriage was moved while the embroidery

frame was being removed or attached during

embroidery.

• If the carriage is moved during the process, the

pattern may be misaligned. Be careful when

removing or attaching the embroidery frame.

Stabilizer is incorrectly attached, for example, it is

smaller than the embroidery frame.

Embroidery pattern does not embroider in a particular

position.

Fabric is not positioned with the proper position in

the embroidery frame.

• Use the embroidery sheet.

Loops appear on the surface of the fabric when

embroidering.

The thread tension is incorrectly set. 72

Embroidery bobbin thread intended for use with

this machine is not being used.

Symptom, Cause/solution

Reference

Troubleshooting

APPENDIX

Error messages

When erroneous operations are performed messages and advice on operation will be displayed on the LCD. Follow what is

displayed. If you touch or do the operation correctly while the error message is displayed, the message disappears.

Error messages Cause/solution

A malfunction occurred. Turn the machine off, then

on again.

This message is displayed if some malfunction occurs.

Turn the machine off, then back on again.

If this message continues to appear, please contact your authorized Brother

dealer or the nearest Brother authorized service center.

Cannot change the configuration of the characters. This message is displayed when there are too many characters and the

curved character configuration is impossible.

Cannot recognize the data for the selected pattern.

The data may be corrupted. Please turn off the

power and turn on again.

This message appears when you try to retrieve pattern data that is invalid.

Since any of the following may be the cause, check the pattern data.

• The pattern data is damaged.

• The data that you tried to retrieve was created using another

manufacturer’s data design system.

Turn the machine off, then on again to return it to its normal condition.

Data volume is too large for this pattern. This message is displayed when the patterns you are editing take up too

much memory, or if you are editing too many patterns for the memory.

OK to recall and resume previous memory? This message appears if the machine is turned off while embroidering, then

turned on again.

Touch to return the machine to the condition (pattern position and

number of stitches) when it was turned off. Follow the procedure described

in “If the thread breaks or the bobbin runs out of thread during embroidering”

on page 71 to align the needle position and embroider the remainder of the

pattern.

Pattern extends to the outside of embroidery frame. This message appears when the selected embroidery pattern is larger than

the embroidery frame selected when [Embroidery Frame Identification View]

is set to [ON]. Select a larger frame.

Pattern extends to the outside of embroidery frame.

Add no additional characters.

This message is displayed when the character pattern combination is too

large to fit in the embroidery frame. Change the character pattern size or

layout the patterns to fit the embroidery frame. If [Embroidery Frame

Identification View] is set to [ON], select a larger frame.

Preventive maintenance is recommended. Once this message appears, it is recommended to take your machine to an

authorized Brother dealer or the nearest Brother authorized service center for

a regular maintenance check. Although this message will disappear and the

machine will continue to function once you touch , the message will

display several more times until the appropriate maintenance is performed.

The authentication and encryption methods used

by the selected wireless LAN access point/router

are not supported by your machine.

The authentication/encryption methods used by the selected wireless

access point/router are not supported by your machine.

For infrastructure mode, change the authentication and encryption methods

of the wireless access point/router.

Your machine supports the following authentication methods:

If your problem is not solved, the SSID or network settings you entered may

be incorrect. Reconfirm the wireless network settings. (page 17)

Refer to “How can I find the wireless security information (SSID and network

key)” on page 95.

Authentication method Encryption method

WPA-Personal TKIP

AES

WPA2-Personal TKIP

AES

Open WEP

None (without encryption)

Shared key WEP

Troubleshooting

The bobbin thread is almost empty. This message is displayed when the bobbin thread is running out. Although a

few stitches can be sewn when the “Start/Stop” button is pressed, replace

with a wound bobbin immediately.

When embroidering, press (Thread cutter button) to cut the threads, raise

the presser foot, remove the embroidery frame, and then replace the bobbin

with one wound with plenty of embroidery bobbin thread.

The bobbin winder safety device has activated. Is

the thread tangled?

This message is displayed when the bobbin is being wound, and the motor

locks because the thread is tangled, etc.

The safety device has been activated. Is the

thread tangled? Is the needle bent?

This message is displayed when the motor locks due to tangled thread or for

other reasons related to thread delivery.

The “Start/Stop” button does not operate with the

foot controller attached. Remove the foot controller.

This message is displayed when the “Start/Stop” button is pressed to sew

Utility stitches or Decorative stitches while the foot controller is connected.

The SSID and Network Key are incorrect. The security information (SSID/network key (password)) is incorrect.

Reconfirm the SSID and security information (network key (password)).

(page 17)

Refer to “How can I find the wireless security information (SSID and network

key)” on page 95.

The wireless LAN access point/router cannot be

detected.

The wireless access point/router cannot be detected.

1. Check the following 4 points.

- Make sure that the wireless access point/router is powered on.

- Move your machine to an area where no items can obstruct the wireless

network signal, such as metal doors or walls, or closer to the wireless

access point/router.

- Temporarily place your machine within about 1 m (3.3 feet) from the

wireless access point when you are configuring the wireless settings.

- If your wireless access point/router is using MAC address filtering,

confirm the MAC address of this machine is allowed in the filter.

2. If you manually entered the SSID and security information (SSID/

authentication method/encryption method/network key (password)), the

information may be incorrect. Reconfirm the SSID and security information

and re-enter the correct information as necessary. (page 17)

Refer to “How can I find the wireless security information (SSID and

network key)” on page 95.

The wireless security information (Authentication

method, Encryption method, Network Key) is

incorrect.

The wireless security information (authentication method/encryption

method/network key (password)) is incorrect.

Refer to the table for the [The authentication and encryption methods used

by the selected wireless LAN access point/router are not supported by your

machine.] error message, and reconfirm the wireless security information

(authentication method/encryption method/network key (password)).

(page 17)

Refer to “How can I find the wireless security information (SSID and network

key)” on page 95.

The wireless setting is not activated. The wireless network setting is not activated.

Activate the wireless network. (page 17)

This pattern cannot be used. This message appears when you try to retrieve a pattern that cannot be used

with this machine, such as when the data is corrupted, or when trying to

combine split patterns.

This USB media cannot be used. This message is displayed when you try to use incompatible media. Please

visit our website https://s.brother/cpjap/

for details on the USB media that

can be used.

Error messages Cause/solution

Troubleshooting

APPENDIX

How can I find the wireless security information (SSID and network key)

* The network key may also be described as a password, security key or encryption key.

* If the wireless access point/router is not broadcasting the SSID, the SSID will not automatically be detected. You will have to manually

enter the SSID.

When the speed controller is set to control the

zigzag stitch width, the "Start/Stop" button does

not operate.

This message is displayed when the speed control lever is set to control the

zigzag stitch width, and the “Start/Stop” button is pressed. Set [Width

Control] to [OFF] in the settings screen (page 15), or use the foot controller to

operate the machine.

F**

If error message [F**] appears in the LCD while the machine is being used,

the machine may be malfunctioning. Contact your authorized Brother dealer

or the nearest Brother authorized service center.

1) You should see the documentation provided with your wireless access point/router.

2) The default SSID (wireless network name) could be the manufacturer’s name or the model name.

3) If you do not know the security information, please consult the router manufacturer, your system administrator, or

internet provider.

4) Some Wireless SSIDs and network keys (passwords) are case (upper case and lower case) sensitive. Please

properly record your information.

1 SSID

2 Network key (password)

Error messages Cause/solution

Specifications

The wireless network connection complies with IEEE 802.11b/g/n standards and uses the 2.4 GHz frequency. A wireless network cannot

be set up with WPA/WPA2 Enterprise.

Use Design Database Transfer or PE-DESIGN version 11 or later to transfer data from your computer to the machine. For the operating

systems compatible with the software, visit our website https://s.brother/cnjkb/

.pmx and .pmu stitch data files can be retrieved; however, when this machine is used to save the file, it is saved as a .pmv stitch data file.

Using data other than that created using this machine or the machine that created the .pmv, .pmx or .pmu data file, may cause this

machine to malfunction.

Using data other than that saved using our data design systems or this machine may cause this machine to malfunction. When the

machine is used to save a file with any extension, it is saved as a .phc data file.

.dst data is displayed in the pattern list screen by file name (the actual image cannot be displayed). The full file name may not be

displayed depending on the number of characters in the file name. Since Tajima (.dst) data does not contain specific thread color

information, it is displayed with our default thread color sequence. Check the preview and change the thread colors as desired.

USB flash drive is commercially available, but some USB flash drive may not be usable with this machine.

Please visit our website https://s.brother/cpjap/

for more details.

* Please be aware that some specifications may change without notice.

Specifications

Item Specification

Dimensions of machine Approx. 419 mm (W) × 197 mm (D) × 307 mm (H)

(Approx. 16-1/2 inches (W) × 7-3/4 inches (D) × 12-3/32 inches (H))

Weight of machine Approx. 6.8 kg (Approx. 15 lb)

Dimensions of machine with embroidery unit

attached

Approx. 522 mm (W) × 219 mm (D) × 307 mm (H)

(Approx. 20-9/16 inches (W) × 8-5/8 inches (D) × 12-3/32 inches (H))

Weight of machine with embroidery unit

attached

Approx. 8.3 kg (Approx. 18 lb)

Sewing speed 70 to 710 stitches per minute

Maximum embroidery speed 400 stitches per minute

Compatible interface

Wireless LAN

Memory Stitch patterns Up to 128 KB or 15 stitch patterns

Embroidery patterns Up to 1024 KB or 20 embroidery patterns

(Up to 100,000 stitches per pattern)

Data types

Stitch patterns

.pmv .pmx .pmu

Embroidery patterns

.pes .phc .dst .pen

Number of decorative stitch pattern

combinations

Up to 70

Embroidery pattern size Maximum of 10 cm × 10 cm (4 inches × 4 inches)

Types of USB Devices/ Media that can be

used

Stitch patterns, Embroidery patterns Stitch patterns and embroidery patterns can be

saved to or recalled from USB flash drive.

Note

• We recommend using the 26 letters of the alphabet (uppercase and lowercase), the numbers 0 through 9, “-”, and

“_” for the name of the file/folder.

IMPORTANT

• When using embroidery data other than our original patterns, the thread may break or the needle may

break or bend when embroidering with a stitch density that is too fine or when embroidering three or

more overlapping stitches. In that case, use one of our original data design systems to edit the embroidery

data.

Updating Your Machine’s Software

APPENDIX

The machine’s software can be updated using USB flash

drive.

When an update program is available on Brother support

website at https://s.brother/cpjap/

, please download the

file(s) following the instructions on the website and steps

listed below.

When using the wireless function, the update mark is

displayed on the wireless LAN key.

: Updated software is available on our website.

Update the software.

: No updated software is available.

Version information can be checked from the settings

screen. (page 16)

Turn on the machine while pressing and holding

(Needle position button).

 The following screen appears.

Insert the USB flash drive into the USB port on the

machine.

Touch .

• Do not turn off the machine during the update.

 When updating is finished, the completion message

appears.

Remove the USB flash drive, and turn the machine off

and on again.

Updating Your Machine’s Software

Note

• Save only the update file on the USB flash drive.

Index

Aligning the position .................................................................... 78

Appliqué

...................................................................... 51, 72, 73

Ball point needle .......................................................................... 27

Bar tack stitch

.............................................................................. 53

Basting stitch

................................................................................ 41

Blind hem stitch

........................................................................... 45

Bobbin

......................................................................................... 19

Bobbin case

................................................................................. 84

Bobbin installation

....................................................................... 22

Bobbin thread

...................................................................... 19, 63

Bobbin winding

........................................................................... 19

Bobbin winding thread guide

....................................................... 19

Button sewing

.............................................................................. 49

Buttonhole

................................................................................... 47

Character spacing ........................................................................ 77

Cleaning

...................................................................................... 83

Cylindrical pieces

........................................................................ 37

Darning ....................................................................................... 54

Decorative stitches

............................................................... 13, 31

Denim

................................................................................. 27, 39

Elastic tape ................................................................................... 53

Embroidery

.................................................................................. 61

Embroidery foot

........................................................................... 61

Embroidery frames

............................................................... 64, 66

Embroidery sheet

......................................................................... 65

Error messages

............................................................................. 93

Even seam allowance

................................................................... 38

Fabric .......................................................................... 27, 39, 64

Fagoting

....................................................................................... 55

Feed dog position switch

............................................................... 9

Feed dogs

...................................................................................... 9

Font

..................................................................................... 33, 68

Foot controller

............................................................................. 32

Included accessories .................................................................... 11

Joining ......................................................................................... 56

L/R Shift ....................................................................................... 35

Language

..................................................................................... 15

LCD

..................................................................................... 10, 13

Leather

......................................................................................... 40

Light

............................................................................................ 15

Maintenance ............................................................................... 83

Memory

............................................................................... 59, 80

Metallic thread

..................................................................... 20, 25

Mirroring

.............................................................................. 14, 76

Needle ................................................................................. 27, 28

Needle plate

........................................................................... 9, 87

Needle plate cover

................................................................. 9, 83

Needle position

............................................................ 14, 15, 38

Needle threader

.......................................................................... 25

Operation beep ........................................................................... 15

Overcasting stitches

.................................................................... 44

Patchwork ................................................................................... 51

Piecing

........................................................................................ 52

Power supply

.............................................................................. 12

Presser foot

........................................................... 13, 29, 32, 41

Presser foot holder

......................................................................... 9

Pulling up bobbin thread

............................................................. 26

Race ............................................................................................ 84

Reinforcement stitch

.................................................................... 34

Retrieving

............................................................................. 59, 80

Reverse stitch

.............................................................................. 34

Rotate

................................................................................... 76, 78

Satin stitch ............................................................................ 14, 31

Saving

.................................................................................. 59, 80

Scallop stitching

.......................................................................... 55

Sewing speed controller

.............................................................. 10

Shell tuck stitch

........................................................................... 56

Size

............................................................................................. 76

Smocking

.................................................................................... 55

Speed

................................................................................... 21, 32

Split embroidery patterns

............................................................. 75

Spool cap

.................................................................................... 20

Spool net

..................................................................................... 20

Stabilizer

..................................................................................... 64

Stitch length

................................................................................ 35

Stitch width

................................................................................. 35

Straight stitch

................................................................ 38, 41, 52

Stretch fabrics

.............................................................................. 39

Thick fabrics

................................................................................ 39

Thin fabrics

................................................................................. 39

Thread

.................................................................................. 27, 63

Thread color display

.................................................................... 71

Thread cutting

...................................................................... 32, 34

Thread density

...................................................................... 14, 76

Thread tension

............................................................. 36, 72, 86

Transparent nylon thread

............................... 20, 21, 25, 27, 42

Troubleshooting

.......................................................................... 85

Twin needle

................................................................................ 56

Index

APPENDIX

Updating ..................................................................................... 97

Upper thread

................................................................ 23, 27, 63

Vinyl fabrics ................................................................................ 40

Wireless LAN .............................................................................. 17

Zigzag stitch ........................................................................ 35, 52

Zipper

......................................................................................... 50

English

888-P10

D029HR-001

Please visit us at https://s.brother/cpjap/ where you

can get the support information (Instruction Videos,

FAQs, etc.) for your Brother product.

Various optional accessories are available to be

purchased separately.

Visit our website https://s.brother/cojkb/.

Brother SupportCenter is a mobile app that provides the support

information for your Brother product.

Visit the Google Play™ or App Store to download.

This machine is approved for use in the country of purchase only. Local Brother companies or

their dealers will only support machines purchased in their own countries.

Be sure to install the latest software.

A variety of functional improvements are being performed in the latest version.

Design Database Transfer is a dedicated Windows application for wirelessly

transferring embroidery data from a computer to the machine. This application can

also be used to view and manage embroidery data.

Visit us at https://s.brother/cajkb/ to download the application.

Google Play™ App Store

Brother SE725 Computerized Sewing and Embroidery Machine with 4" x 4" Embroidery Area

Product's Documents

Operation Manual

Specifications

Brother SE725 Questions and Answers
