www.lg.com
OWNER’S MANUAL
MICROWAVE OVEN
PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE
OPERATING AND KEEP IT HANDY FOR REFERENCE AT ALL TIMES.
LMV1762
**
MFL06317612
- 2 -
Please record the model number and serial
number of this unit for future reference. We
also suggest you record the details of your
contact with LG (LG Electronics U.S.A., Inc.)
concerning this unit.
Staple your receipt here as proof of purchase.
Model No:
Serial No:
Dealer:
Dealer Phone No:
Customer Relations
LG Electronics U.S.A., Inc.
Service Division Bldg. #3
201 James Record Rd.
Huntsville, AL 35824-0126
(a) Do not attempt to operate this oven with
the door open. Open door operation
can result in harmful exposure to
microwave energy. It is important
not to defeat or tamper with the
safety interlocks.
(b) Do not place any object between the
oven front face and the door or allow soil
or cleaner residue to accumulate on
sealing surfaces.
(c) Do not operate the oven if it is
damaged. It is particularly important
that the oven door:
(1) closes properly,
(2) is not damaged or bent,
(3) has hinges and latches that are not
broken or loosened,
(4) has undamaged door seals and
sealing surfaces.
(d) The oven should not be adjusted or
repaired by anyone except properly
qualified service personnel.
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
Thank you for purchasing a LG microwave oven.
- 3 -
TABLE OF CONTENTS
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY.............................................................. 2
TABLE OF CONTENTS ...................................... 3
Location of Model Number .................................... 6
Oven Specifications .............................................. 6
Electrical Rating .................................................... 6
Electrical Requirements ........................................ 6
Grounding Instructions.......................................... 6
Microwave Oven Features .................................... 7
Oven Control Panel........................................... 8~9
Learn About Your Microwave Oven.......................
Audible Signals......................................................
Clock......................................................................
Interrupting Cooking...............................................
Child Lock..............................................................
Cooktop Light.........................................................
Add 30 Sec.............................................................
11
Time Defrost...........................................................
Timed Cooking.......................................................
Multi-stage Cooking...............................................
Using Quick Touch.............................................
Frozen Entree.....................................................
Potato ...............................................................
Auto Cook..........................................................
Cooking Guide for Auto Cook............................
Auto Reheat........................................................
Cooking Guide for Auto Reheat..........................
COOKING TIPS.................................................20~24
Getting The Best Cooking Results......................
Popcorn..............................................................
Pizza...................................................................
Fish & Shellfish...................................................
Cooking Fish and Shellfish: General Directions
........
Fish And Shellfish Cooking Table ......................
Appetizers/Sauces/Soups...................................
Cooking Appetizers: Tips and Techniques.........
Meat...................................................................
Cooking Meat: General Directions .....................
Meat Cooking Table ...........................................
Poultry................................................................
Cooking Poultry: General Directions ..................
Poultry Cooking Table........................................
Pasta And Rice..................................................
Cooking Pasta and Rice: Tips and Techniques
.........
Pasta Cooking Table..........................................
Rice Cooking Table............................................
MAINTENANCE.................................................25~26
Care And Cleaning.............................................
Cleaning the Grease Filters ..............................
Charcoal Filter Replacement ............................
Cooktop/Night Light Replacement .....................
Oven Light Replacement ...................................
COOKING UTENSILS............................................. 27
FAQS........................................................................28
TROUBLESHOOTING.............................................
Vent Hi/Low/Off......................................................
11
11
11
12
12
IMPORTANT SAFETY INSTRUCTIONS .......... 4~5
SPECIFICATIONS ................................................. 6
FEATURES ....................................................... 7~9
USING YOUR MICROWAVE OVEN .............. 10~19
10
10
10
10
10
Melt........................................................................
Melt Table..............................................................
Soften Table..........................................................
13
Energy Saving.......................................................
Microwave Power Levels.......................................
Auto Defrost...........................................................
Operating Tips........................................................
Soften....................................................................
13
13
13
14
15
15
16
13
20
17
17
17
17
17
18
18
19
19
20
20
20
21
21
21
21
22
23
23
23
24
24
24
25
Metal Rack.........................................................
25
25
25
26
26
27
24
Microwave Utensil Guide ...................................
LIMITED WARRANTY-USA .............................
..
30~32
29
Defrosting Tips.......................................................
- 4 -
WARNING - To reduce the risk of
burns, electric shock, fire, injury to persons,
or exposure to excessive microwave energy.
• Read all the instructions before using your oven
• Do not allow children to use this oven without
close supervision.
•
Do not use corrosive chemicals or vapors, such as
sulfide and chloride, in this appliance. This type of
oven is specifically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory use.
•
Do not store this appliance outdoors. Do not use
this product near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or in
a similar location.
• Do not use the oven cavity for storage purposes.
Do not leave paper products, cooking utensils, or
food in the oven cavity when not in use.
• Clean the ventilating hood frequently. Do not allow
grease to accumulate on the hood or the filters.
•
Use care when cleaning the vent hood filters.
Corrosive cleaning agents such as lye-based oven
cleaners may damage the filters.
•
Do not tamper with the built-in safety switches
on the oven door. The oven has several built-in
safety switches to make sure the power is off when
the door is open.
•
Suitable for use above both gas and electric cooking
equipment up to 36 inches wide.
• Do not use this oven for commercial purposes
It is designed for household use only.
• When cleaning the door and the surfaces that
touch the door, use only mild, non-abrasive
soaps or detergents and a sponge or soft cloth.
• If your oven is dropped or damaged have it
thoroughly checked by a qualified service technician
before using it again.
• To avoid a fire hazard
- Do not severely overcook food. Severely
overcooked foods can start a fire in the oven.
Watch the oven carefully, especially if you have
paper, plastic, or other combustibles in the oven.
- Do not store combustible items (bread,
cookies, etc.) in the oven, because if lightning
strikes the power lines it may cause the oven to
turn on.
- Do not use wire twist-ties in the oven. Be sure
to inspect purchased items for wire twist-ties and
remove them before placing the item in the oven.
• If a fire should start in the oven:
- Keep the oven door closed.
- Turn the oven off.
- Disconnect the power cord or shut off the
power at the fuse or circuit breaker panel.
• To avoid electric shock
- This appliance must be grounded.
Connect it
only to a properly grounded outlet. See the
electrical GROUNDING INSTRUCTIONS
on
page 6.
- Do not operate this appliance
if it has a
damaged cord or plug, if it is not working
properly or if it has been damaged or dropped.
- Do not immerse the electrical cord or plug in
water.
- Keep the cord away from heated surfaces.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
The safety instructions below will tell you how to use your oven and avoid harm to yourself
or damage to your oven.
•
Read and follow the specific
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY
found on page 2.
•
Turn the fan on to disperse steam or smoke under
the hood.
Keep the area under the hood properly
ventilated at all times. Turn off cooking equipment if
you see flames or a fire occurs.
WARNING
Hazards or unsafe practices
that may result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices
that may result in minor
personal injury or property
damage.
NOTE: Turn the microwave’s vent fan on
whenever you use the oven range cooktop
below it.The fan captures smoke, steam, and
odors and also prevents the heat from the
cooktop from damaging microwave components.
If the microwave is cooking, the vent fan turns on
automatically if the sensors detect too much heat
from the cooktop. This is normal, and is designed
to prevent microwave component damage.
- 5 -
• To avoid improperly cooking some foods.
- Do not heat any types of baby bottles or baby
food. Uneven heating may occur and possibly
cause personal injury.
- Do not heat small-necked containers, such as
syrup bottles.
- Do not deep-fat fry in your microwave oven.
- Do not attempt home canning in your
microwave oven.
- Do not heat the following items in the
microwave oven: whole eggs in the shell, water
with oil or fat, sealed containers, or closed glass
jars. These items may explode.
• Do not cover or block any openings in the oven.
• Use your oven only for the operations described in
this manual.
• Do not run the oven empty, without food in it.
•
Do not let the cord hang over the edge of the table or
counter.
• Preserve the oven floor:
- Do not heat the oven floor excessively.
- Do not allow the gray film on special microwave-
cooking packages to touch the oven floor. Put the
package on a microwavable dish.
- Do not cook anything directly on the oven floor or
turntable. Use a microwavable dish.
- Keep a browning dish at least 3/16 inch above floor.
Carefully read and follow the instructions for the
browning dish. If you use a browning dish
incorrectly, you could damage the oven floor.
• Install or locate this appliance only in accordance
with the provided installation instructions.
• This appliance should be serviced only by qualified
service personnel. Contact the nearest authorized
service facility for examination, repair, or adjustment.
• Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or boiling
when the container is removed from the microwave
oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A SPOON OR
OTHER UTENSIL IS INSERTED INTO THE LIQUID.
- Do not overheat the liquid.
- Stir the liquid both before and halfway through
heating it.
- Do not use straight-sided containers with narrow
necks.
- After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
- Use extreme care when inserting a spoon or other
utensil into the container.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTEREFERENCE
STATEMENT (U.S.A. ONLY)
• Reorient the receiving antenna of the radio or
television.
• Relocate the Microwave Oven with respect to the
receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so
that the microwave oven and the receiver are on
different branch circuits.
The manufacturer is not responsible for any radio or
TV interference caused by unauthorized
modification to this microwave oven. It is the
responsibility of the user to correct such interference.
w
WARNING
:
This equipment generates and uses ISM frequency
energy and if not installed and used properly, that is
in strict accordance with the manufacturer's
instructions, may cause interference to radio and
television reception. It has been type tested and
found to comply with limits for ISM Equipment
pursuant to part 18 of FCC Rules, which are designed
to provide reasonable protection against such
interference in a residential installation. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following:
To reduce the risk of injury to persons;
WARNING:
This product contains chemicals known to the State of California
to cause cancer and birth defects or other reproductive harm.
Wash hands after handling.
- 6 -
Please read this owner’s manual. It will tell you how
to use all the fine features of this microwave oven.
LOCATION OF
MODEL NUMBER
To request service information or replacement parts,
the service center will require the complete model
number of your microwave oven. The number is on the
left side of control panel as shown in the illustration
below.
OVEN
SPECIFICATIONS
Output Power 1,000W (IEC 60705 Standard)
Outer Dimensions 29-15/16” x 16-7/16” x 16-15/16”
Cavity Volume
1.7 Cu.ft
Net Weight 48.9 lbs.
ELECTRICAL RATING
* Electrical Rating of the Oven:120V AC 60Hz
* 14 Amps / 1600 Watts ( MWO + Cooktop Lamp +
Ventilation Fan)
ELECTRICAL
REQUIREMENTS
The oven is designed to operate on a Standard
120V/60Hz household outlet. Be sure the circuit is at
least 15A or 20A and the microwave oven is the only
appliance on the circuit. It is not designed for 50Hz
or any circuit other than a 120V/60Hz circuit.
GROUNDING
INSTRUCTIONS
This appliance must be grounded. If an electrical
short circuit occurs, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current. The cord for this appliance has a
grounding wire with a grounding plug. Put the plug into
an outlet that is properly installed and grounded.
WARNING
- If you use the
grouning plug improperly, you risk electric shock.
Ask a qualified electrician if you do not understand the
grounding instructions or if you wonder whether the
appliance is properly grounded.
Because this appliance fits under the cabinet, it has a
short power-supply cord. See the separate Installation
Instructions for directions on properly placing the cord.
Keep the electrical power cord dry and do not pinch or
crush it in any way.
If it is necessary to use an extension cord, use only a
3-wire extension cord that has a 3-blade grounding
plug, and a 3-slot receptacle that will accept the plug
on the appliance. The marked rating of the extension
cord shall be equal to or greater than the electrical
rating of the appliance.
For a permanently connected appliance:
This appliance must be connected to a grounded,
metallic, permanent wiring system, or an equipment
grounding conductor should be run with the circuit
conductors and connected to the equipment grounding
terminal or lead on the appliance.
Ensure proper ground
exists before use
MODEL NUMBER LABEL
w
SPECIFICATIONS
Metal Shielded
Window
Tray
Metal Rack
MICROWAVE OVEN FEATURES
w
WARNING:
- 7 -
FEATURES
Do not operate the oven when empty or without the glass tray. It is best to leave a glass of water in the oven
when not in use. The water will safely absorb all microwave energy, if the oven is accidentally started.
Your microwave oven is designed to make your cooking experience as enjoyable and productive as
possible. To get you up and running quickly, the following is a list of the oven’s basic features:
1.
Metal Shielded Window. The shield prevents
microwaves from escaping. It is designed as a
screen to allow you to view food as it cooks.
2.
3.
Charcoal Filter (behind Vent Grille)
4.
Vent Grille
Cooking
Model and Serial Number Plate
Guide Label
5.
Glass Tray. The glass tray moves food as it
cooks for more even cooking.
It must be in the oven during operation for best
cooking results.
6.
Cooktop/Countertop Light
7.
Control Panel. Press the buttons on this panel
to perform all functions.
8.
Metal Rack. Use for extra space when
cooking in more than one container at the
same time. Remove cooking rack when you
are not using it.
9.
Grease Filter
10.
Service Label
11.
Door Handle
12.
Door Safety Lock System
13.
Service Label
OVEN CONTROL PANEL
12
14
15
17
23
20
16
21
22
19
13
2
3
1
6
7
9
11
8
10
4
5
18
FEATURES
- 9 -
1. DISPLAY.
The Display includes a clock and
indicators to tell you time of day, cooking time
settings and cooking functions selected.
Touch number pads to enter cooking
time, power level, quantities or weights.
Touch this pad to turn the
Vent on or off.
Touch this pad to turn the
cooktop/countertop light on or off.
Touch this pad to stop the oven
or clear all entries.
19. STOP Clear.
Touch this pad to add 30 seconds of
cooking time each time you press it.
22. Add 30 Sec.
Touch this pad to add ten seconds of
cooking time each time you press it.
21. More.
Touch this pad to save energy.
20 .gnivaS ygrenE .
Touch this pad to start a function.
If you open the door after oven begins to cook,
retouch START Enter.
Touch this pad to select a
cooking power level.
of cooking time each time you press it.
Touch this pad to subtract ten seconds
cream,cream cheese,frozen juice.
Touch this pad to soften butter,ice
Touch this pad to melt butter or margarine,
chocolate,cheese,marshmallow.
Touch this pad when popping
popcorn in your microwave oven.
. Popcorn.
. Melt.
. Soften.
. NUMBER
. Power Level.
. Less.
18. START Enter.
. Vent Hi/Low/Off.
Light On/Off.
. Clock.
Touch this pad to enter the time of day.
3. Potato. Touch this pad to cook up to 4
potatoes without entering a cook time or power.
. Frozen Entree. uch this pad to cook a 10
ounce (284 to 567 g) frozen entree without entering
a cook time or power.
. Auto Cook. uch this pad to cook microwavable
foods without entering a cook time or power.
. Time. ch this pad followed by number pads
to set a cooking time.
. Pizza. ch this pad to reheat one or several
slices of pizza without entering a cook time or
power.
. Auto Reheat. Touch this pad to reheat
microwavable foods without entering a cook
time or power.
. Time Defrost. uch this pad to set a defrost
time.
. Auto Defrost. uch this pad followed by
number pads to thaw frozen meat by weight.
NOTE: If you try to enter incorrect instructions,
you will not hear any tones. Touch STOP Clear
and re-enter the instructions.
FEATURES
- 10 -
LEARN ABOUT YOUR MICROWAVE OVEN
This section discusses the concepts behind microwave cooking and introduces you to the basics you need to
know to operate your microwave oven. Please read this information before use.
AUDIBLE SIGNALS
Audible signals are available to guide you when
setting and using your oven:
• A programming tone will sound each time
you touch a pad.
• Four tones signal the end of a cooking cycle.
CLOCK
When your microwave oven is first plugged in or
after a power failure, the Display will show “:”.
If a time of day is not set, “:” will show on the Display
until you touch “Clock”.
Example: To set the clock for 10:30(AM or PM).
Touch: Display Shows:
:
1.
2.
1
2
:
00
3.
10
:
30
4.
10
:
30
NOTES:
•
If you enter in an incorrect time and touch “
Clock
”
,
you cannot set time of day. Enter the correct time.
• If you touch STOPClear while setting the clock, the
Display will show the last time of day set or “:”
if no time of day has been set.
Use this safety feature to lock the control panel
when you are cleaning the oven, or so that children
cannot use the oven unsupervised.
To set CHILD LOCK:
Touch: Display Shows:
CHILD LOCK
Touch and hold until
you hear 2 beeps and
“Loc” appears in the
display.
(approximately
4 seconds)
To cancel CHILD LOCK:
Touch: Display Shows:
1.
You can stop the oven during a cycle by opening
the door. The oven stops heating and the fan
stops, but the light stays on.
To restart cooking, close the door and Touch
START.
If you do not want to continue cooking,
open the door and touch STOP&OHDU.
INTERRUPTING COOKING
Touch and hold until
1.
“Loc” disappears in the
display.
(approximately
4 seconds)
USING YOUR MICROWAVE OVEN
- 11 -
The ent
ent
Touch: Display Shows:
1.
Once for HIGH
Twice for Low
2.
Turn off fan when desired
NOTE: If the temperature from the range or cooktop
below the oven gets too hot, the exhaust fan in the
vent hood will automatically turn on at the HIGH
setting to protect the oven.
It may stay on up to an hour to cool the oven.
When this occurs, the ent pad will not turn the fan
off. You cannot turn the exhaust fan off during
microwave cooking.
::
:
COOKTOP LIGHT
The pad on the bottom left of the control panel
controls the cooktop light.
Example: To set the Lamp for .
Touch: Display Shows:
1.
:
:
Once for light
Twice for light
2.
:
To turn off, touch pad one
or two times depending on
light setting.
TIME DEFROST
1.
:
0
2.
2
:
00
3.
Time counting down.
Using Time Defrost can defrost for a selected
length of time.
Example: To set Time Defrost for 2 minutes.
Touch: Display Shows:
:
At the end of the Time defrost four tones will sound.
ADD 30 SEC
A time-saving pad, this simplified control lets you
quickly set and start microwave cooking without the
need to touch STARTEnter.
Example: To cook for 2 minutes.
Touch ddec 4 times.
The oven begins cooking
and display shows time
counting down.
NOTE:
If you touch ddec, it will add 30 seconds up to
99 min 59 seconds.
USING YOUR MICROWAVE OVEN
- 12 -
:
TIMED COOKING
This feature lets you program a specific cook time
and power. For best results, there are 10 power
level settings in addition to HIGH (100%) power .
Refer to the “Microwave Power Levels Table” on
page for more information.
NOTE: If you do not select a power level, the oven
will automatically cook at HIGH (100%) power.
Example: To cook for 5 minutes, 30 seconds
at 80% power.
Touch: Display Shows:
1.
2.
3.
4.
5.
: 0
5
:
30
P-
hi
P-
80
Time counting down
and COOK.
2.
3
:
00
To set a 3 minute cook
time for first stage.
4.
P-
80
To set an 80% cook
power for the first stage.
1.
: 0
3.
P-
hi
MULTI-STAGE COOKING
For best results, some recipes call for different cook
powers during different stages of a cook cycle. You
can program your oven to switch from one power
level to another for up to 2 stages.
Example: To set a 2-stage cook cycle.
Touch: Display Shows:
5.
6.
To set a 7 minute cook
time for second stage.
7.
9.
: 0
7
:
00
P-
hi
8.
To set a 50% cook power
for the second stage.
P-
50
10.
When the first stage is over, you will hear two
short tones as the oven begins the second
cook stage.
Time counting down
and COOK.
14
USING YOUR MICROWAVE OVEN
MELT
Melt provides four preset categories for melt.
Butter, Chocolate, Cheese, Marshmallows.
Details MELT TABLE
Example: To Melt 16 oz Cheese.
1. Touch STOP Clear.
Melt
2. Touch Melt pad three times.
2
3. Choose 16 oz.
4. Touch START Enter.
NOTE: After 4 seconds, the oven will start
automatically. When the cook time
is over, you will hear four beeps and
End will display.
SOFTEN
Soften provides four preset categories for melt.
Butter, Ice Cream, Cream Cheese, Frozen Juice.
Details SOFTEN TABLE
Example: To Soften 3 oz Cream Cheese.
1. Touch STOP Clear.
Soften
2. Touch Soften pad three times.
1
3. Choose 3 oz.
4. Touch START Enter.
NOTE: After 4 seconds, the oven will start
automatically. When the cook time
is over, you will hear four beeps and
End will display.
Category
MELT TABLE
SOFTEN TABLE
Butter
Chocolate
Cheese
Marshmallows
11 stick 2 sticks
4 oz 8 oz
8 oz 16 oz
3 sticks
_
_
5 oz 10 oz
_
2
3
4
123
Touch pad number
Touch pad
times
Category
Touch pad
times
Touch pad number
123
Butter 1 1 stick 2 sticks3 sticks
Ice Cream
2
half
pint quart
gallon
Cream Cheese
3
3 oz 8 oz
_
Frozen Juice
4
6 oz 12 oz 16 oz
- 1 -
Energy Saving feature saves energy by turning off
the display by touching the Energy Saving Button.
The display will automatically turn off
of idleness if the clock has not been set.
If the clock has been set, then the display will not
automatically turn off.
5 minutes
after
1.
:
2.
:
3.
Touch STOP Clear .
USING YOUR MICROWAVE OVEN
Touch
turn the display off.
Energy Saving to
Touch
Turn the display on.
Energy Saving to
- 1 -
For best results, some recipes call for different cook
powers. The lower the cook power, the slower the
cooking. Each number from 1 to 9 stands for a
different percentage of full cook power.
The following chart gives the percentage of cook
power each number pad stands for, and the cook
power name usually used.
NOTE: Once cook time has been entered, you can also use the ower Level pad as a second Kitchen
Timer by entering “0” for the Cook Power. The oven will count down the cooking time you set without
cooking.
It also tells you when to use each cook power. Follow
recipe or food package instructions if available.
NOTE: Refer to a reliable cookbook for cooking times
based on the 1000 Watt cook power of your microwave
oven.
MICROWAVE POWER LEVELS
COOK Power NAME WHEN TO USE IT
100% of full power
High
• Quick heating many convenience foods and
foods with high water content, such as soups and
beverages.
• Cooking tender cuts of meat, ground meat,
9 = 90% of full power
• Heating cream soups
8 = 80% of full power
• Heating rice, pasta, or casseroles
7 = 70% of full power
• Cooking and heating foods that need a
Medium-High
Cook Power lower than high (for example,
whole fish and meat loaf) or when food is
cooking too fast
• Reheating a single serving of food
6 = 60% of full power
• Cooking requiring special care, such as cheese
and egg dishes, pudding, and custards
• Finishing cooking casseroles
5 = 50% of full power
Medium
• Cooking ham, whole poultry, and pot roasts
• Simmering stews
4 = 40% of full power
• Melting chocolate
• Heating pastries
3 = 30% of full power
Medium-Low,
• Manually defrosting foods, such as bread, fish,
Defrost
meats, poultry, and precooked foods
2 = 20% of full power
• Softening butter, cheese, and ice cream
1 = 10% of full power
0 = 0% of full power
Low
• Keeping food warm
• Standing time
None
USING YOUR MICROWAVE OVEN
- 1 -
Example: To defrost 1.2 lbs of ground beef.
Touch: Display Shows:
1.
2.
1. 2
To enter the weight
3.
Time counting down.
AUTO DEFROST
defrost sequences are preset in the oven.
The auto defrost feature provides you with the best
defrosting method for frozen foods. The cooking guide
will show you which defrost sequence is recommended
for the food you are defrosting.
For added convenience, the Auto Defrost
includes a built-in beep mechanism that reminds
you to check, turn over, separate, or rearrange to get
best defrost results. different defrosting levels
are provided.
1 MEAT
2 POULTRY
3 FISH
4 BREAD
*vailable weight is 0.1~6.0 lbs.
NOTE:
When you touch the STARTnter pad, the display
changesto defrost time count down. The oven will beep
duringthe Defrost cycle. At this time, open the door
andturn, separate, or rearrange the food.
Remove any portions that have thawed.
Return frozen portions to the oven and touch
STARTnter to resume the defrost cycle.
OPERATING TIPS
• For best results, remove fish, shellfish, meat, and
poultry from its original closed paper or plastic
package (wrapper). Otherwise, the wrap will hold
steam and juice close to the foods, which can cause
the outer surface of the foods to cook.
• For best results, shape your ground meat into the
form of a doughnut before freezing. When
defrosting, scrape off thawed meat when the beep
sounds and continue defrosting.
• Place foods in a shallow container.
This table shows you food type selections and the
weights you can set for each type. For best
results, loosen or remove covering on food.
FOOD
TOUCH
WEIGHTS YOU
Auto Defrost
CAN SET
(tenths of a pound)
Meat
1 Time(s) .1 to 6.0 (45g to 2722g)
Poultry
2 Time(s) .1 to 6.0 (45g to 2722g)
Fish
3 Time(s) .1 to 6.0 (45g to 2722g)
Category
MEAT
0.1 to 6.0 lbs
POULTRY
0.1 to 6.0 lbs
Food
BEEF
Ground beef, Round steak, Cubes for
stew, Tenderloin steak, Pot roast, Rib
roast, Rump roast, Chuck roast,
Hamburger patty.
LAMB
Chops (1-inch thick), Rolled roast.
PORK
Chops (
1
/
2
-inch thick), Hot dogs,
Spareribs, Countrystyle ribs.
Rolled roast, Sausage.
POULTRY
Whole (under 4 lbs), Cut up,
Breasts (boneless).
CORNISH HENS
Whole.
TURKEY
Breast (under 6 lbs).
SHELLFISH
Crab meat, Lobster tails, Shrimp,
Scallops.
FISH
0.1 to 6.0 lbs
FISH
Fillets, Whole Steaks.
BREAD
Time(s) .1 to .0 (45g to g)
0.1 to .0 lbs
Sliced bread, Buns, Baguette, etc.
Separate slices and place between paper
towel or flat plate
.T
urn food over at beep
.
After defrosting, let stand for 1-2 minutes
.
USING YOUR MICROWAVE OVEN
- 1 -
DEFROSTING TIPS
• When using Auto Defrost, the weight to be entered
is the net weight in pounds and tenths of pounds
(the weight of the food minus the container).
• Before starting, make sure you have removed any
of the metal twist-ties which often come with frozen
food bags, and replace them with strings or elastic
bands.
• Open containers such as cartons before they are
placed in the oven.
• Always slit or pierce plastic pouches or packaging.
• If food is foil wrapped, remove foil and place it in a
suitable container.
• Slit the skins, if any, of frozen food such as
sausage.
• Bend plastic pouches of food to ensure even
defrosting.
• Always underestimate defrosting time. If defrosted
food is still icy in the center, return it to the
microwave oven for more defrosting.
• The length of defrosting time varies according to
how solidly the food is frozen.
• The shape of the package affects how quickly food
will defrost. Shallow packages will defrost more
quickly than a deep block.
• As food begins to defrost, separate the pieces.
Separated pieces defrost more easily.
• Use small pieces of aluminum foil to shield parts
of food such as chicken wings, leg tips, fish tails, or
areas that start to get warm. Make sure the foil does
not touch the sides, top, or bottom of the oven. The
foil can damage the oven lining.
• For better results, let food stand after defrosting.
(For more information on standing time, see the
“Microwave Cooking Tips” section.)
• Turn over food during defrosting or standing time.
Break apart and remove food as required.
USING YOUR MICROWAVE OVEN
- 1 -
:
Your oven’s menu has been preprogrammed to cook
food automatically. Tell the oven what you want.
Then let you microwave oven cook your selections.
PIZZA
Pizza lets you reheat up to 3 slices of pizza.
A slice is based on a 5 ounce slice.
NOTE:
• Place on a low plate & paper towel.
• Do not cover.
Example: To reheat 2 slices of Pizza.
Touch: Display Shows:
Time counting down and
COOK.
When the cook time is over,
you will hear four beeps and End will display.
2
POPCORN
Popcorn lets you pop 3.0, and 3.5 ounce
bags of commercially packaged microwave
popcorn. Pop only one package at a time. If you
are using a microwave popcorn popper, follow
manufacturer’s instructions.To set your microwave
oven correctly, follow this chart:
Example: To pop a 3.0 oz. bag.
Touch: Display Shows:
once for 3.5 oz
twice for 3.0 oz
Time counting down and
COOK.
When the cook time is over,
you will hear four beeps and End will display.
once for 1 slice
twice for 2 slices
three times for 3 slices
3. 0
Using Quick Touch
FROZEN ENTREE
Frozen Entree lets you cook 10 and 20 ounce plates of
commercially packaged microwave frozen entree
without entering cooking times and power levels.
Remove tray from outer carton.
Do not remove film cover, but cut it to vent.
Example: To reheat a 20 oz. frozen entree.
Touch: Display Shows:
POTATO
The Potato lets you cook potatoes with preset times and
cook powers. You can choose from 1 to 4 potatoes.
NOTE:
•
Cooking times are based on an average 8 ounce potato.
• Before baking, pierce potato with fork several times.
• After baking, let stand for 5 minutes.
Example: To cook 2 Potatoes.
Touch: Display Shows:
When the cook time is over,
you will hear four beeps and End will display.
Time counting down and
COOK.
2 0
2
Time counting down and
COOK.
When the cook time is over,
you will hear four beeps and End will display.
once for 10 oz
twice for 20 oz
once for 1 potato
twice for 2 potatoes
three times for 3 potatoes
four times for 4 potatoes
USING YOUR MICROWAVE OVEN
- 1 -
AUTO COOK
Auto Cook provides four preset categories for cooking.
Touch: Display Shows:
Example: To cook 2 cups of Casserole.
Touch: Display Show
1.
Choose food category.
Touch pad
Category
of Time(s)
Fresh
vegetable
1
Frozen
2
vegetable
Rice
3
Casserole
4
s:
2.
Time counting down and
COOK.
Enter quantity/servings.
When the cook time is over,
you will hear four beeps and End will display.
Number of
Category
cups
Fresh
1 - 4 cups
vegetable
Frozen
1 - 4 cups
vegetable
Rice
1 - 2 cups
Casserole
1 - 4 cups
COOKING GUIDE FOR AUTO COOK
CODE
CATEGORY
QUANTITY
DIRECTIONS
1 cup
Place in a microwavable bowl or
casserole.
2 cups
Add water according to the quantity.
FRESH
1
VEGETABLE
3 cups
Let stand 3 minutes.
* 1-2 cups: add 2 tbsp water.
4 cups
* 3-4 cups: add 2 tbsp water.
1 cup
Place in a microwavable bowl or
casserole.
FROZEN
2 cups
2
VEGETABLE
Let stand 3 minutes.
3 cups
* 1-2 cups: add 2 tbsp water.
* 3-4 cups: add 2 tbsp water.
4 cups
Place in a microwavable bowl or
1 cup
casserole.
3
RICE
2 cups
Let stand 5 minutes.
1 cup
Place in a microwavable bowl or
casserole.
4
2 cups
CASSEROLE
Stir and let stand 3 minutes.
3 cups
4 cups
Cover with vented plastic wrap.
Cover with vented plastic wrap.
Cover with vented plastic wrap.
Cover with vented plastic wrap.
USING YOUR MICROWAVE OVEN
AUTO REHEAT
Auto Reheat provides four preset categories for
Touch: Display Shows:
2.
Time counting down and
COOK.
Enter quantity/servings.
When the cook time is over,
you will hear four beeps and End will display.
Number of
Category
cups/Items
Dinner plate
1 - 2 servings
Soup/sauce
1 - 4 cups
Casserole
1 - 4 cups
Roll/Muffin
1 - 4 pieces
reheating.
Example: To reheat 2 servings of Dinner plate.
Touch: Display Shows:
1.
COOKING GUIDE FOR AUTO REHEAT
Choose food category.
Touch pad
Category
of Time(s)
Dinner plate
1
Soup/sauce
2
Casserole
3
Roll/Muffin
4
CODE CATEGORY
SERVING AMOUNT DIRECTION
1 serving (10 oz.)
Place on a low plate.
1
DINNER PLATE
Cover with vented plastic wrap.
2 servings (15 oz.)
Let stand 3 minutes.
1 cup
2
SOUP/SAUCE
Place in shallow microwavable casserole.
2 cups
Cover with vented plastic wrap.
Stir and let stand 3 minutes.
3 cups
4 cups
1 cup
3
CASSEROLE
Place in a microwavable bowl or casserole.
2 cups
Cover with plastic wrap.
3 cups
Stir and let stand 3 minutes.
4 cups
1 piece (2 oz.)
4
ROLL/MUFFIN
Place on paper towel.
2 pieces (4 oz.)
Do not cover.
3 pieces (6 oz.)
4 pieces (8 oz.)
- -
USING YOUR MICROWAVE OVEN
GETTING THE BEST COOKING
RESULTS
To get the best results from your microwave oven, read
and follow the guidelines below.
• Storage Temperature: Foods taken from the freezer
or refrigerator take longer to cook than the same
foods at room temperature. The time for recipes in
this book is based on the normal storage temperature
of the food.
• Size: Small pieces of food cook faster than large
ones, pieces similar in size and shape cook more
evenly. For even cooking, reduce the power when
cooking large pieces of food.
• Natural Moisture: Very moist foods cook more
evenly because microwave energy is attracted to
water molecules.
• Stir foods such as casseroles and vegetables from
the outside to the center to distribute the heat evenly
and speed cooking. Constant stirring is not
necessary.
• Turn over foods like pork chops, baking potatoes,
roasts, or whole cauliflower halfway through the
cooking time to expose all sides equally to microwave
energy.
• Place delicate areas of foods, such as asparagus
tips, toward the center of the dish.
• Arrange unevenly shaped foods, such as chicken
pieces or salmon steaks, with the thicker, meatier
parts toward the outside of the dish.
• Shield, with Small pieces of aluminum foil, parts of
food that may cook quickly, such as wing tips and leg
ends of poultry.
• Let It Stand: After you remove the food from the
microwave, cover food with foil or casserole lid and let
it stand to finish cooking in the center and avoid
overcooking the outer edges. The length of standing
time depends on the density and surface area of the
food.
• Wrapping in waxed paper or paper towel:
Sandwiches and many other foods containing
prebaked bread should be wrapped prior to
microwaving to prevent drying out.
• Prepare the fish for cooking.
- Completely defrost the fish or shellfish.
- Arrange unevenly shaped pieces with thicker parts
toward the outside of the dish. Arrange shellfish in a
single layer for even cooking.
- The type of cover you use depends on how you
cook. Poached fish needs a microwavable lid or
vented plastic wrap.
- Baked fish, coated fish, or fish in sauce needs to be
covered lightly with waxed paper to keep the coating
crisp and sauce from getting watery.
- Always set the shortest cooking time. Fish is done
when it turns opaque and the thickest part begins to
flake. Shellfish is done when the shell turns from
pink to red and the flesh is opaque and firm.
• The Fish and Shellfish Cooking Table below provides
specific directions with Power Level and Cooking
Time settings for most types of fish and shellfish.
Fish & Shellfish
Cooking Fish and Shellfish: General Directions
POWER
LEVEL
COOKING TIME DIRECTIONSFISH
HI
HI
7
HI
HI
3
1/2-41/2 minutes
4
1/2-51/2 minutes
4
1/2-6 minutes
3
1/2-5 minutes
3
1/2-5 minutes
Arrange fish in a single layer with thickest portion toward
outside edge of 11/2 quart microwavable baking dish.
Brush with melted butter and season, if desired. Cook
covered with vented plastic wrap. Let stand covered 2
minutes. If you are cooking more than 1 lb. of fish, turn
the fish halfway through cooking.
Arrange in a single layer. Prepare as directed above,
except stir instead of turning the shellfish.
Fish fillets
Fish steaks
Whole fish
Scallops
Shrimp, shelled
Fish And Shellfish Cooking Table
- -
COOKING TIPS
Appetizers / Sauces / Soups
Cooking Appetizers: Tips and
Techniques
Recommended
• Crisp crackers, such as melba toast, shredded wheat
and crisp rye crackers are best for microwave use.
Wait until party time to add the spreads. Place a
paper towel under the crackers while they cook in
the microwave oven to absorb extra moisture.
• Arrange individual appetizers in a circle for even
cooking.
• Stir dips to distribute heat and shorten cooking time.
Cooking Sauces: Tips and Techniques
• Use a microwavable casserole or glass measuring
cup that is at least 2 or 3 times the volume of the
sauce.
• Sauces made with cornstarch thicken more rapidly
than those made with flour.
Cooking Soups: Tips and Techniques
• Cook soups in a microwavable dish which holds
double the volume of the recipe ingredients to prevent
boil-over, especially if you use cream or milk in the
soup.
• Generally, cover microwaved soups with VENTED
plastic wrap or a microwavable lid.
• Cover foods to retain moisture. Uncover foods to
retain crispness.
• Avoid overcooking by using the minimum suggested
time. Add more time, if necessary, only after checking
the food.
Not Recommended
• Appetizers with a crisp coating or puff pastry are best
done in a conventional oven with dry heat.
• Breaded products can be warmed in the microwave
oven but will not come out crisp.
Meat
Cooking Meat: General Directions
• Prepare the meat for cooking.
- Defrost completely.
- Trim off excess fat to avoid splattering.
- Place the meat, fat side down, on a microwavable
rack in a microwavable dish.
- Use oven cooking bag for less tender cuts of meat.
- Arrange the meat so that thicker portions are toward
the outside of the dish.
- Cover the meat with waxed paper to prevent
splattering.
• Tend the meat as it cooks.
- Drain juices as they accumulate to reduce
splattering and keep from overcooking the bottom of
the meat.
- Shield thin or bony portions with strips of foil to
prevent overcooking.
NOTE: Keep the foil at least 1 inch from the oven
walls, and do not cover more than one-third of the meat
with foil at any one time.
• Let the meat stand covered with foil 10-15 minutes
after you remove it from the oven. The internal
temperature of the meat may rise from 5-10°F during
standing time.
The Meat Cooking Table on the next page provides
detailed directions, Power Level, and Cooking Time
settings for most cuts of meat.
• Cook sauces made with cornstarch or flour uncovered
so you may stir them 2 or 3 times during cooking for a
smooth consistency.
• To adapt a conventional sauce or gravy recipe,
reduce the amount of liquid slightly.
• Stirring occasionally will help blend flavors, distribute
heat evenly, and may even shorten the cooking time.
• When converting a conventional soup recipe to cook
in the microwave, reduce the liquid, salt, and strong
seasonings.
- 2 -
COOKING TIPS
Meat Cooking Table
POWER
LEVEL
COOKING TIME DIRECTIONSMEAT
HI
5
5
HI
3
3
HI
1-1
1/2 minutes
1
1/2-2 minutes
2
1/2-31/2 minutes
8-10 minutes
per pound
RARE(135°F)
11-13 minutes
per pound
MEDIUM(155°F)
11-12 minutes
per pound
RARE(135°F)
12-13 minutes
per pound
MEDIUM(145°F)
13-14 minutes
per pound
WELL(155°F)
1
1/2-2 minutes
2-3 minutes
4-5 minutes
7-8 minutes
18-20 minutes
per pound
15-17 minutes
per pound
25-27 minutes
per pound
(165°F)
45-60 seconds
1-1
1/2 minutes
1
1/2-2 minutes
1
3/4-2 minutes
Form patties with depression in center of each.
Place on microwavable roast rack. Brush with browning
agent, if desired. Cover with waxed paper.
Turn over halfway through cooking.
Let stand covered 1 minute.
Place roast fat side down on microwavable roasting rack.
Add desired seasonings and cover with waxed paper.
Turn meat over halfway through cooking and shield if
necessary.
Remove roast from microwave oven when desired
temperature is reached. Let stand covered with foil 15
minutes.(Temperature may rise about 10°F).
Place roast fat side down on microwavable roasting rack.
Brush lamb with marinade or desired seasonings such
as rosemary, thyme or marjoram. Cover with waxed
paper.
Turn roast over after 15 minutes, and again after 30
minutes. Shield if necessary.
Remove roast from microwave when desired
temperature is reached. Let stand covered with foil 15
minutes (Temperature may rise about 10°F).
Place bacon slices on microwavable roasting rack.
Cover with paper towels.
After cooking, let stand 1 minute.
Place chops in microwavable baking dish.
Add desired seasonings and cover with vented plastic
wrap. Cook until no longer pink or until internal
temperature reaches 170°F. Turn chops over halfway
through cooking.
Let stand covered 5 minutes.
(Temperature may rise about 10°F).
Place roast in cooking bag in microwavable dish.
Add seasonings and browning agent if desired. Close
bag loosely with microwavable closure or string. After
cooking, let stand in bag 15 minutes. (Temperature may
rise about 10°F.) Internal temperature of pork should
reach 170°F before serving.
Pierce links and place on microwavable roasting rack.
Cover with waxed paper or paper towel.
Turn over halfway through cooking.
After cooking, let stand covered 1 minute.
Beef
Hamburgers,
Fresh or
defrosted
(4 oz. each)
1 patty
2 patties
4 patties
Sirloin tip roast
(3-4 lbs.)
Lamb
Lamb roast,
rolled
boneless
(3-4 lbs.)
Pork
Bacon slices
2 slices
4 slices
6 slices
Chops
(5-7 oz. each)
2 chops
4 chops
Loin Roast,
rolled, boneless
(3
1/2- 4 1/2 lbs.)
Sausage links,
Fresh or
Frozen,
defrosted
(1-2 oz. each)
2 links
4 links
6 links
10 links
(8 oz. pkg.)
10slices
- 2 -
COOKING TIPS
• Prepare the poultry for cooking.
- Defrost completely.
- Arrange poultry pieces with thicker pieces at the
outside edge of the baking dish. When cooking legs,
arrange them like the spokes of a wheel.
- Cover the baking dish with waxed paper to reduce
splattering.
- Use a browning agent or cook with a sauce to give a
browned appearance.
• Tend the poultry as it cooks.
- Drain and discard juices as they accumulate.
- Shield thin or bony pieces with small strips of
aluminum foil to prevent overcooking. Keep foil at
least 1 inch from the oven walls and other pieces of
foil.
• The poultry is done when it is no longer pink and the
juices run clear. When done, the temperature in the
thigh meat should be 180-185°F.
• Let the poultry stand after cooking covered with foil for
10 minutes.
The Poultry Cooking Table below provides detailed
directions, Power Level, and Cooking Time settings for
most cuts and types of poultry.
Poultry
Cooking Poultry: General Directions
POWER
LEVEL
COOKING TIME DIRECTIONSPOULTRY
HI
HI
HI
4
1/2-51/2 minutes
per lb
12-13 minutes
per lb
6-7 minutes
per lb
Wash pieces, shake the water off, and go on with cooking.
Place pieces in a single layer in a microwavable baking
dish with thicker pieces to the outside. Brush with butter
or browning agent and seasonings if desired. Cover with
waxed paper. Cook until no longer pink and juices run
clear. Let stand covered 5 minutes.
Wash pieces, shake the water off, and go on with cooking.
Place breast side down on a microwavable roasting rack.
Brush with butter, or browning agent and seasoning if
desired. Cover with waxed paper. Cook 1/3 of estimated
time. Turn breast side up, brush with butter, or browning
agent. Replace waxed paper. Cook 1/3 of estimated time
again. Shield if necessary. Cook remaining 1/3 of
estimated time or until no longer pink and juices run
clear. Let stand covered with foil 10 minutes. (The
temperature may rise about 10°F.) The temperature in
the high should be 180°F-185°F when the poultry is
done.
Wash, shake the water off, and go on with cooking. Tie
wings to body of hen and the legs to tail. Place hens
breast side down on microwavable rack. Cover with
waxed paper. Turn breast side up halfway through
cooking. Shield bone ends of drumsticks with foil.
Remove and discard drippings. Brush with butter or
browning agent and seasonings if desired. Cook until no
longer pink and juices run clear. Remove hens from
microwave when they reach desired temperature. Let
stand covered with foil 5 minutes.
(Temperature may rise about 10°F). Temperature in
breast should be 170°F before serving.
Chicken pieces
(2
1/2-3 lbs).
Chicken whole
(3-3
1/2 lbs)
Cornish Hens
Whole
(1-1 lbs.
each)
Poultry Cooking Table
1/2
- 2 -
COOKING TIPS
Microwave cooking and conventional cooking of pasta,
rice, and cereal require about the same amount of time,
but the microwave is a more convenient method
because you can cook and serve in the same dish.
There is no stirring needed and leftover pasta tastes
just like fresh cooked when reheated in the microwave
oven.
Pasta And Rice
• If you are planning to use rice or pasta in a casserole,
undercook it so it is still firm.
• Allow for standing time with rice, but not for pasta.
• The Pasta and Rice Cooking Tables below provide
specific directions, with Power Level and Cooking
Time settings for most common types of pasta and
rice.
Cooking Pasta and Rice: Tips and Techniques
POWER
LEVEL
COOKING TIME DIRECTIONSTYPE OF PASTA
HI
5
HI
5
HI
5
HI
5
9 to 10 minutes
7
1/2 to 81/2 minutes
6 to 7 minutes
5
1/2 to 61/2 minutes
7 to 8 minutes
11 to 12
1/2 minutes
8 to 10 minutes
5
1/2 to 61/2 minutes
Combine hot tap water and salt, if desired. Use a
2-quart microwavable baking dish and cover with
vented plastic wrap for spaghetti and lasagna
noodles. Use microwavable lid or vented plastic
wrap for macaroni and egg noodles.
Cook as directed in chart or until water boils.
Stir in pasta; cook covered as directed in chart
or until tender.Drain in a colander.
Spaghetti
4 cups water.
Add 8 oz. spaghetti.
Macaroni
3 cups water.
Add 2 cups macaroni.
Lasagna noodles
4 cups water.
Add 8 oz. lasagna noodles.
Egg noodles
6 cups water.
Add 4 cups noodles.
Pasta Cooking Table
POWER
LEVEL
COOKING TIME DIRECTIONSTYPE OF RICE
HI
3
HI
5
Hi
3
HI
3
1/2 to 41/2 minutes
18 minutes
4
1/2 to 51/2 minutes
28 minutes
4 to 5 minutes
28 minutes
2 to 3 minutes
Combine hot tap water and salt, if desired, in 2
quart microwavable casserole. Cover with
microwavable lid or vented plastic wrap. Cook as
directed in chart or until water boils.Stir in rice
and any seasonings.
Cook covered as directed in chart or until water is
absorbed and rice is tender.
Let stand covered 5 to 10 minutes. Fluff with fork.
Cook water until it boils. Stir rice into boiling water
and let stand, covered 5 to 10 minutes or until water
is absorbed and rice is tender. Fluff with fork.
Long grain
2
1/4 cups water.
Add 1 cup rice.
Brown
2
1/2 cups water.
Add 1 cup rice.
Long grain and
wild rice mix
2
1/3 cups water.
Add 6 oz. pkg.
Quick cooking
1 cup water.
Add 1 cup rice.
Rice Cooking Table
- 2 -
COOKING TIPS
MAINTENANCE
CARE AND CLEANING
For best performance and safety, keep the oven
clean inside and outside. Take special care to
keep the inner door panel and the oven front
frame free of food or grease build-up.
Never use abrasive powder or pads. Wipe the
microwave oven inside and out, including the
hood bottom cover, with a soft cloth and a warm
(not hot) mild detergent solution. Then rinse and
wipe dry.
Use a chrome cleaner and polish on chrome,
metal and aluminum surfaces. Wipe spatters
immediately with a wet paper towel, especially
after cooking chicken or bacon. Clean your oven
weekly or more often, if needed.
The grease filters should be removed and
cleaned often, at least once a month.
2. Soak grease filters in hot water and a mild
detergent. Rinse well and shake to dry. Do not use
ammonia or place them in a dishwasher. The
aluminum will darken.
NOTE: Do not operate the hood without the filters
in place.
If your oven is vented inside, the charcoal filter
should be replaced every 6 to 12 months, and more
often if necessary. The charcoal filter cannot be
cleaned. To order a new charcoal filter, call
1-800-243-0000 or go to www.lg.com/us/support/
parts-accessories.
2. Remove the two vent grille mounting screws.
(2 outside screws)
3. Tip the grille forward, then lift it out.
1.
To remove the grease filters, slide each
filter to the side, then pull the filters downward.
The filters will drop out.
ĸĸ
ķ
3. To reinstall the filters, slide them into the side
slots, then push up and forward to lock.
ĸĸ
ķ
METAL RACK
Wash the metal rack with a mild soap and a soft
or nylon scrub brush.Dry completely.
Do not use abrasive scrubbers or cleaners to
clean rack.
1. Turn the power off at the main power supply and
wear
gloves
CLEANING THE GREASE
FILTERS
CHARCOAL FILTER
REPLACEMENT
- 25 -
MAINTENANCE
OVEN LIGHT REPLACEMENT
1. Unplug the oven or turn off power at the main
power supply and wear gloves.
2.
Remove the vent cover mounting screws.
(2 outside screws)
3. Tip the cover forward, then lift out to remove.
4.
Remove the cover screw,pull the cover
forward and then lift up the bulb holder.
5. Replace the bulb with a 30 watt appliance bulb.
6.
Replace the bulb holder and screw.
7. Slide the top of the vent cover into place. Push
the bottom until it snaps into place. Replace the
mounting screws. Turn the power back on at the
main power supply.
COOKTOP/NIGHT LIGHT
REPLACEMENT
3. Replace the bulb with a 30 watt appliance bulb.
4. Replace the bulb cover and mounting screws.
5. Turn the power back on at the main power supply.
2. Remove the bulb cover mounting screws.
1. Unplug the oven or turn off power at the
main power supply.
7.
Slide the bottom of the vent cover into place. Push
the top until it snaps into place. Replace the
mounting screws. Turn the power back on at the
main power supply and set the clock.
6. Slide a new charcoal filter into place and close the
door. The filter should rest at the angle shown.
4. Open the door.
5.
Remove the old filter.
- 26 -
- 2 -
USE
OVENPROOF GLASS (treated for high
intensity heat):
utility dishes, loaf dishes, pie plates,
cake plates, liquid measuring cups,
casseroles and bowls without metallic
trim.
CHINA:
bowls, cups, serving plates and platters
without metallic trim.
PLASTIC:
Plastic wrap (as a cover)-- lay the plastic
wrap loosely over the dish and press it to
the sides.
Vent plastic wrap by turning back one
edge slightly to allow excess steam to
escape. The dish should be deep
enough so that the plastic wrap will not
touch the food. As the food heats it may
melt the plastic wrap wherever the wrap
touches the food.
Use plastic dishes, cups,
semirigid freezer containers, and plastic
bags only for short cooking time. Use
these with care because the plastic
may soften from the heat of the food.
PAPER:
Paper towels, waxed paper, paper
napkins, and paper plates with no
metallic trim or design. Look for the
manufacturer's label for use in the
microwave oven.
DO NOT USE
METAL UTENSILS:
Metal shields the food from microwave energy and produces
uneven cooking. Also avoid metal skewers, thermometers, or foil
trays. Metal utensils can cause arcing, which can damage your
microwave oven.
METAL DECORATION:
Metal-trimmed or metal-banded dinnerware, casserole dishes,
etc. The metal trim interferes with normal cooking and may
damage the oven.
ALUMINUM FOIL:
Avoid large sheets of aluminum foil because they hinder cooking
and may cause harmful arcing. Use small pieces of foil to shield
poultry legs and wings. Keep ALL aluminum foil at least 1 inch
from the side walls and door of the oven.
WOOD:
Wooden bowls and boards will dry out and may split or crack
when you use them in the microwave oven. Baskets react in the
same way.
TIGHTLY COVERED UTENSILS:
Be sure to leave openings for steam to escape from covered
utensils. Pierce plastic pouches of vegetables or other food items
before cooking. Tightly closed pouches could explode.
BROWN PAPER:
Avoid using brown paper bags.
They absorb too much heat and could burn.
FLAWED OR CHIPPED UTENSILS:
Any utensil that is cracked, flawed, or chipped may break in the
oven.
METAL TWIST TIES:
Remove metal twist ties from plastic or paper bags.
They become hot and could cause a fire.
MICROWAVE UTENSIL GUIDE
COOKING UTENSILS
Do not use recycled paper products in the microwave oven.
They sometimes contain impurities that cause sparks to occur.
- 28 -
FAQS
FREQUENTLY ASKED QUESTIONS
Q. Can I use a rack in my microwave oven so that I may reheat or cook on two levels at a time?
A. Only use the rack that is supplied with your rmicrowave oven. Use of any other rack can result in
poor cooking performance and/or arcing and may damage your oven.
Q. Can I use either metal or aluminum pans in my microwave oven?
A. Usable metal includes aluminum foil for shielding (use small, flat pieces), and shallow foil trays (if tray
is 3/4 inch deep and filled with food to absorb microwave energy). Never allow metal to touch walls or
door.
Q. Sometimes the door of my microwave oven appears wavy. Is this normal?
A. This appearance is normal and does not affect the operation of your oven.
Q. What are the humming noises that I hear when my microwave oven is operating?
A. You hear the sound of the transformer when the magnetron tube cycles on and off.
Q. Why does the dish become hot when I microwave food in it? I thought that this should not
happen.
A. As the food becomes hot it will conduct the heat to the dish. Use hot pads to remove food after
cooking.
Q. What does “standing time” mean?
A. ”Standing time” means that food should be taken out of the oven and covered for additional time after
cooking. This process allows the cooking to finish, saves energy and frees the oven for other purposes.
Q. Can I pop popcorn in my microwave oven? How do I get the best results?
A. Yes. Pop packaged microwave popcorn following manufacturer’s guidelines or use the preprogrammed
Popcorn button.
Do not use regular paper bags. Use the “listening test” by stopping the oven as soon as the popping
slows to a “pop” every one or two seconds. Do not try to repop unpopped kernels. You can also use
special microwave poppers. When using a popper, be sure to follow manufacturer’s directions. Do not pop
popcorn in glass utensils.
Q. Why does steam come out of the air exhaust vent?
A. Steam is normally produced during cooking. The microwave oven has been designed to vent this
steam out the top vent.
Steam exhaust here
- 29 -
Check the following list to be sure a service call
is really necessary. A quick review of this
manual as well as the additional information in
this checklist may prevent an unneeded
service call.
If nothing on the oven operates:
•
check for a blown circuit fuse or a tripped
main circuit breaker.
•
check if oven is properly connected to electric
circuit in house.
check that controls are set properly.
•
If the oven interior light does not work:
• the light bulb is loose or defective.
If the oven will not cook:
• check that cooking program was entered correctly.
check that door is firmly closed.
check that Start button was touched.
check that probe was inserted correctly into
receptacle.
•
check that timer wasn't started instead of a
cook function.
If oven takes longer than normal to cook or
cooks too rapidly:
be sure the Power Level is programmed properly.•
If the time of day clock does not always
keep correct time:
• check that the power cord is fully inserted into the
outlet receptacle.
•
be sure the oven is the only appliance on
the electrical circuit.
If food cooks unevenly:
• be sure food is evenly shaped.
be sure food is completely defrosted before cooking.•
•
check placement of aluminum foil strips used to
prevent overcooking.
If food is undercooked:
•
check recipe to be sure all directions (amount,
time, power levels) were correctly followed.
be sure microwave oven is on a separate circuit.•
• be sure food is completely defrosted before cooking.
If food is overcooked:
•
check recipe to be sure all directions (amount,
power level, time, size of dish) were followed.
If arcing (sparks) occur:
• be sure microwavable dishes were used.
.desut’nerewseittsiwteriweruseb•
• be sure oven wasn’t operated when empty.
•
make sure metal rack (if used) is properly installed
on supports.
If the Display shows a time counting down but
the oven is not cooking:
• check that door is firmly closed.
• check that timer wasn’t started instead of a cooking
function.
BEFORE CALLING FOR SERVICE
TROUBLESHOOTING
•
•
•
- 30 -
LG Electronics Inc. will repair or replace your product, at LG’s option, if it proves to be defective in material or
workmanship under normal use, during the warranty period set forth below, effective from the date of original
consumer purchase of the product. This limited warranty is good only to the original purchaser of the product and
effective only when used in the United States, including U.S. Territories.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO
THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE
EXPRESS WARRANTY PERIOD ABOVE. LG WILL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INDIRECT,
OR INCIDENTAL DAMAGES OF ANY KIND, INCLUDING LOST REVENUES OR PROFITS, IN CONNECTION
WITH THE PRODUCT. SOME STATES DO NOT ALLOW LIMITATION ON HOW LONG AN IMPLIED
WARRANTY LASTS OR THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY DOES NOT APPLY TO:
1. Service trips to your home to deliver, pick up, and/or install the product, instruct, or replace house
fuses or correct wiring, or correction of unauthorized repairs; and
2. Damages or operating problems that result from misuse, abuse, operation outside environmental
specifications or contrary to the requirements or precautions in the Operating Guide, accident,
vermin, fire, flood, improper installation, acts of God, unauthorized modification or alteration, incorrect
electrical current or voltage, or commercial use, or use for other than intended purpose.
3. Therefore, the cost of repair or replacement of such a defective product shall be borne by the
consumer.
WARRANTY PERIOD:
Model:
LMV1762
Labor: 1 Year from the Date of Purchase.
Parts: 1 Year from the Date of Purchase.
Magnetron: Years from the Date of Purchase.
HOW SERVICE IS HANDLED:
Call 1-800-243-0000 and choose the appropriate prompt.
Please have product type (Microwave) and ZIP code ready.
LIMITED WARRANTY – USA
**
- 31 -
Problem Cause Solution
Microwave oven
Installation issue
- Vibration noise
- Unit is not level
- Installation damage
1. Mounting bracket screw not xed
completely
2. Mounting plate not aligned
Check with installer rst
C
B
A
Wall
Mounting
Plate
Space More Than Wall Thickness
Bolt
En
d
Toggle Bolt
Toggle Wings1
3/16 Hole on Studs
5/8 Hole on Drywall Only
Minimum 66
From the Floor
For Wall -
Venting Only
Draw Lines
on Studs
Draw
Center Line
Center Line
Mounting Plate
Support Tab
Support Tab
3. Product carried/installed improperly
Spark / Arcing Aluminum foil or metal utensil used in
microwave mode
DO NOT use aluminum foil or
metal utensils in microwave mode
- Check user instructions
The cost of repair or replacement under these excluded circumstances shall be borne by the consumer.
LIMITED WARRANTY – USA
- 32 -
Problem Cause Solution
Unit has no power 1. House power turned off (power supply)
2. Tripped breaker
3. The power cord is not installed properly
1. Check house power supply
2. Check proper power cord
connection
3. Check extension cord
Vent is not working
- Weak or no ventilation
- Abnormal noise during
operation
- Product overheating
1. Improper blower unit direction or installation
2. Improper ductwork or damper connection
1. Check blower unit direction and
reinstall if necessary.
2. Properly align the exhaust
ports and blower plate opening.
Slide exhaust
adapter into
guides on
rear panel.
Exhaust Adapter
Damper
(hinge side up)
Locking
Tabs
Guides
3. Blower unit exhaust ports
should be completely exposed
to the outside
4. After installation, check the air
ventilation path
The cost of repair or replacement under these excluded circumstances shall be borne by the consumer.
CUSTOMER INTER-ACTIVE CENTER NUMBERS:
To Prove Warranty Coverage
Retain your Sales Receipt to prove date of purchase. A
copy of your Sales Receipt must be submitted at the time
warranty service is provided.
Call 1-800-243-0000 (Phone answered 24 hours - 365
days a year) and choose the appropriate prompt
from the menu; or visit our website at:
www.lg.com.
To Obtain Nearest Authorized Service
Center or Sales Dealer, or to Obtain Product,
Customer, or Service Assistance
LIMITED WARRANTY – USA
