User Manual

For BBS2.

JUICE DISPENSER

Model BBS2

Instruction Manual

FELIX STORCH, INC.

Summit Appliance Division

770 Garrison Avenue

Bronx, New York 10474

www.summitappliance.com

Loading ...

Summary of Contents for Summit BBS2:

Congratulations! You have purchased a product manufactured to the high quality standards of Summit Appliance. Please read this manual carefully. It describes the safe operation of this Juice Dispenser and makes suggestions that will allow you to enjoy...2
FEATURES2
The Summit Model BBS2 double-tank Juice Dispenser offers the following features:2
Sturdy, crystal-clear Lexan reservoirs2
Stainless steel mixing blades2
Easy-to-operate removable taps2
Factory-set thermostat2
Energy-efficient Embraco compressor2
Quiet performance2
Commercial approval and CalCode compliance2
INSTALLATION2
When placing this unit on a counter, leave at least 4â of clearance behind the unit and at each side. This is necessary to permit proper air circulation around the unit for efficient operation. Also when installing, be sure the unit is level.2
The BBS2 Juice Dispenser requires a power source of 115V AC and 60Hz. If the power cord is damaged, it must be replaced by the manufacturer, authorized dealer or qualified personnel in order to avoid any electrical hazards during operation. Use a dedi...2
ASSEMBLY2
Install the drip trays on the front of the unit.2
Insert the grilles on the drip trays.2
NOTES:2
Remove the protective plastic cover before using the unit.2
Do not install the unit in the vicinity of heat-producing appliances like stoves or radiators, and be sure it will not be exposed to direct sunlight.2
The BBS2 should be operated within the temperature range of 41 F to 109 F (5 C to 43 C).3
When the unit is being used continuously, we recommend filling the reservoirs with previously cooled product.3
Avoid working with one reservoir full and the other empty. Instead, fill the empty reservoir with water.3
OPERATION3
Switches3
Model BBS2 has three switches; one is for turning the cooling on and off, and the others turn the mixing blades on and off (one blade per reservoir).3
Thermostat3
The thermostat is pre-adjusted at the factory for better performance and to save energy.3
If the juice freezes, turn off the device and call an authorized service technician. Only such a technician can modify the thermostatâs pre-set value.3
NOTES:3
Do not let product accumulate on the drip trays.3
Turn off the equipment prior to any cleaning or maintenance.3
CARE AND MAINTENANCE3
Disassembly3
Whenever you want to change the flavor or the type of product, perform the following procedure:3
Remove the container cover, then the mixing blade.3
To make draining easier, pour water into the container.3
Once the unit is drained, remove the container by setting your thumbs below the container and forcing upwards.3
If the container is not loosened by this procedure, repeat it at the back of the unit.3
To release the silicone nipple, press the lever backward. Pull out the nipple while continuing to press the lever.4
Pull out the tap lock pin to unblock the dispensing lever.4
The tap body can then be removed from the container.4
Wash the components under running water every time you change the flavor or type of product.4
To reassemble the juice dispenser, perform the procedure listed above in reverse order.4
Cleaning the Cabinet4
Clean heavy, greasy deposits with a soft cloth or paper towel. Then wipe with a solution of mild detergent in warm water or a dilute solution of ammonia. Dry with a soft, clean cloth.4
Remove finger prints with a soft cloth or paper towel dampened with isopropyl alcohol.4
LIMITED WARRANTY5
