IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE
SAFE AND EFFECTIVE USE OF THIS PRODUCT.
INSTRUCTIONS
These instructions accompanying the product are the original instructions. This document is part of the product,
keep it for the life of the product passing it on to any subsequent holder of the product. Read all these
instructions before assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been
designed, and contains all the necessary information to ensure its correct and safe use. By following all the
general safety instructions contained in this manual, it will ensure both product and operator safety, together
with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper
Tools policy of continuous improvement determines the right to make modifications without prior warning.
550mm
PRECISION
MITRE SAW
88192
1. PARTS DRAWING AND COMPONENTS
2. IMPORTANT WARNING
- 2 -
Vice clamp assembly.
Length stop assembly.
Cut depth stop.
Cut depth stop screws.
Base.
Base socket head screws.
Pre-set angle arm.
Pivot pin.
Cursor screw.
Cursor.
Blade tensioning nut.
Pivot screw.
Saw table.
Saw frame handle.
Saw frame guide bar carriers.
Saw blade.
Saw frame carriers.
Saw frame assembly.
45°
36°
30°
15°
22.5°
90°
Saw and Guide Assembly
Body
Pivot Arm Assembly
Clamp and
Clamp Stud
Assembly
Fence and
Fence Stud
Assembly
• After assembly, test the angles with some scrap timber to ensure the machine is assembled
correctly and cutting true.
To get the best use from this mitre saw ensure that:-
• The saw blade is tensioned sufficiently to avoid “whip” which will cause the blade to deviate
from a true cut.
• The blade is in line and central to the frame.
• The workpiece is square and true to the base casting.
• Blade tension is released after use.
• You read the instruction leaflet supplied thoroughly before use.
