171503996/7A 12/2019
F 72 FL
F 72 FL Hydro
IT
Tosaerba con conducente a bordo seduto
- MANUALE DI ISTRUZIONI
ATTENZIONE: prima di usare la macchina, leggere attentamente il presente libretto.
DE
Aufsitzmäher (Rasenmäher mit Fahrersitz mit sitzendem Benutzer)
GEBRAUCHSANWEISUNG
ACHTUNG: Vor Inbetriebnahme des Gerätes die Bedienungsanleitung aufmerksam lesen.
EN
Ride-on lawnmower with seated operator
- OPERATOR’S MANUAL
WARNING: read thoroughly the instruction booklet before using the machine.
FR
Tondeuse à gazon à conducteur assis
-
MANUEL D’UTILISATION
ATTENTION: lire attentivement le manuel avant d’utiliser cette machine.
NL
Grasmaaier met zittende bediener
- GEBRUIKERSHANDLEIDING
LET OP: vooraleer de machine te gebruiken, dient men deze handleiding aandachtig te lezen.
i
ITALIANO - Istruzioni Originali ...................................................................................................
IT
БЪЛГАРСКИ - Инструкция за експлоатация ...........................................................................
BG
ČESKY - Překlad původního návodu k používání ..........................................................................
CS
DANSK - Oversættelse af den originale brugsanvisning ...............................................................
DA
DEUTSCH - Übersetzung der Originalbetriebsanleitung ...............................................................
DE
ΕΛΛΗΝΙΚΑ - Μεταφραση των πρωτοτυπων οδηγιων
.....................................................................
EL
ENGLISH - Translation of the original instruction ..........................................................................
EN
ESPAÑOL - Traducción del Manual Original ................................................................................
ES
EESTI - Algupärase kasutusjuhendi tõlge .....................................................................................
ET
SUOMI - Alkuperäisten ohjeiden käännös ....................................................................................
FI
FRANÇAIS - Traduction de la notice originale ..............................................................................
FR
HRVATSKI - Prijevod originalnih uputa .........................................................................................
HR
MAGYAR - Eredeti használati utasítás fordítása ...........................................................................
HU
LIETUVIŠKAI - Originalių instrukcijų vertimas ...............................................................................
LT
LATVIEŠU - Instrukciju tulkojums no oriģināl valodas ...................................................................
LV
NEDERLANDS - Vertaling van de oorspronkelijke gebruiksaanwijzing
....................................................
NL
NORSK - Oversettelse av den originale bruksanvisningen ...........................................................
NO
POLSKI - Tłumaczenie instrukcji oryginalnej .................................................................................
PL
PORTUGUÊS - Tradução do manual original ...............................................................................
PT
ROMÂN - Traducerea manualului fabricantului .............................................................................
RO
РУССКИЙ - Перевод оригинальных инструкций ......................................................................
RU
SLOVENSKY - Preklad pôvodného návodu na použitie ...............................................................
SK
SLOVENŠČINA - Prevod izvirnih navodil ......................................................................................
SL
SVENSKA - Översättning av bruksanvisning i original ..................................................................
SV
TÜRKÇE - Orijinal Talimatların Tercümesi ....................................................................................
TR
ii
Tr ansmission
1.1
31
32
33
34
35
36
37
38
39
41
iii
1
2
6
3
7
8
1
2
3
2
3
3
1
3.3 3.4
3
4
5
1
2
3
4
3
3.1
3.2
3 (x 2) 6 (x 4) 10 (x 2) 11 (x 4)
13 (x 2)
3.5
iv
5
64 - 5
2
13 12
1 2
3
4
3
2
12
1
6
6
89
8 10
1011
13
C
L
A
K
7
3.5
3.6
v
4.1
4.2
vi
1
3
3
2
1
5.4
5.2
5.5 5.7
1
1
5.9 5.10
5.8
5.3
1
1
5.1
vii
1
5.13
5.12
1
2
1/3
5.14
1
2
1/3
5.15
6.1
5.11
viii
2
6.6
6.5
1
6.4
1
1
6.7
1
1
6.8
2
1
2
3
11
6.2 6.3
ix
8.1
x
�1� DATI TECNICI F 72 FL
�2� Potenza nominale * kW 6,5 ÷ 7,1
�3� Giri al minuto * min
-1
2800 ± 100
�4� Impianto elettrico V 12
�5� Pneumatici anteriori 11 x 4-4
�6� Pneumatici posteriori 15 x 6-6
�7� Pressione gonaggio anteriore bar 1,5
�8� Pressione gonaggio posteriore bar 1,0
�9� Massa * kg 159 ÷ 192,5
�10� Raggio minimo di erba non tagliata cm 70
�11� Altezza di taglio cm 3 ÷ 8
�12� Larghezza di taglio cm 71
�13�
Trasmissione idrostatica
Velocità di avanzamento (indicativa) a 3000 min
-1
km/h 0 - 8,8
�14�
Trasmissione meccanica
Velocità di avanzamento (indicativa) a 3000 min
-1
km/h
1,5 ÷ 6,8
�15�
Limite di velocità con catene da neve
(se accessorio previsto)
km/h 8,8
�16� Dimensioni
�17� Lunghezza con sacco (lunghezza senza sacco) mm 1860 (1553)
�18� Larghezza mm 765
�19� Altezza mm 1107
�20� Codice dispositivo di taglio
84109503/0
84109502/0
�21� Capacità del serbatoio carburante litri 4
�22�
�23�
Livello di pressione acustica
Incertezza di misura
dB(A)
dB(A)
85,1
1,1
�24�
�23�
Livello di potenza acustica misurato
Incertezza di misura
dB(A)
dB(A)
99
0,4
�25� Livello di potenza acustica garantito dB(A) 100
�26�
�23�
Livello di vibrazioni al posto di guida
Incertezza di misura
m/s
2
m/s
2
0,99
0,36
�27�
�23�
Livello di vibrazioni al volante
Incertezza di misura
m/s
2
m/s
2
3,14
0,21
�40� ACCESSORI A RICHIESTA
�41� Carica batterie di mantenimento
�42� Kit per “mulching”
�43� Telo di copertura
* Per il dato specico, fare riferimento a quanto indicato nell’etichetta di identicazione della macchina.
xi
[1] BG - ТЕХНИЧЕСКИ ДАННИ
[2] Номинална мощност *
[3] Обороти в минута (*)
[4] Електрическа система
[5] Предни гуми
[6] Задни гуми
[7] Налягане предно напомпване
[8] Налягане задно напомпване
[9] Маса (*)
[10] Минимален радиус на неподрязана трева
[11] Височина на косене
[12] Ширина на косене
[13] Хидростатична трансмисия - Скорост на
напредване (индикативна) - 3000 min-1
[14] Механична трансмисия - Скорост на
напредване (индикативна) - 3000 min-1
[15] Граница на скоростта с верига за сняг
(ако тази принадлежност е предвидена)
[16] Размери
[17] Дължина с торбата за събиране на трева
(дължина без торбата за събиране на трева)
[18] Ширина
[19] Височина
[20] Код на инструмента за рязане
[21] Вместимост на резервоара за гориво
[22] Ниво на звуково налягане
[23] Несигурност на измерване
[24] Измерено ниво на акустична мощност
[25] Гарантирано ниво на акустична мощност
[26] Ниво на вибрации в мястото за управление
[27] Ниво на вибрации на волана
[40] Принадлежности по заявка
[41] Зарядно устройство за поддържане
[42] Набор за “mulching”
[43] Покривен брезент
* За специфични данни, вижте посоченото на
идентификационния етикет на машината
[1] CS - TECHNICKÉ PARAMETRY
[2] Jmenovitý výkon (*)
[3] Otáčky za minutu (*)
[4] Elektroinstalace
[5] Přední pneumatiky
[6] Zadní pneumatiky
[7] Tlak huštění předních pneumatik
[8] Tlak huštění zadních pneumatik
[9] Hmotnost (*)
[10] Minimální poloměr neposečené trávy
[11] Výška sekání
[12] Šířka sekání
[13] Hydrostatická převodovka
Rychlost pojezdu (přibližná) při 3000 min-1
[14] Mechanická převodovka
Rychlost pojezdu (přibližná) při 3000 min-1
[15] Mezní rychlost se sněhovými řetězy
(pokud se jedná o určené příslušenství)
[ 1 6 ] R o z m ě r y
[17] Délka s košem (Délka bez koše)
[ 1 8 ] Š í ř k a
[ 1 9 ] V ý š k a
[20] Kód sekacího zařízení
[21] Kapacita palivové nádržky
[22] Úroveň akustického tlaku
[23] Nepřesnost měření
[24] Úroveň naměřeného akustického výkonu
[25] Úroveň zaručeného akustického výkonu
[26] Úroveň vibrací na místě řidiče
[27] Úroveň vibraci na volantu
[40]
Příslušenství na vyžádání
[41]
Udržovací nabíječka akumulátoru
[42] Sada pro mulčování
[43] Krycí plachta
* Ohledně uvedeného údaje vycházejte z hodnoty
uvedené na identikačním štítku stroje.
[1] DA - TEKNISKE DATA
[2] Nominel eekt (*)
[3] Omdrejninger pr. minut (*)
[4] Elektrisk anlæg
[5] Forhjulsdæk
[6] Baghulsdæk
[7] Pumpetryk for fordæk
[8] Pumpetryk for bagdæk
[9] Vægt (*)
[10] Minimumsradius af ikke klippet græs
[11] Klippehøjde
[12] Klippebredde
[13] Hydrostatisk transmission
Fremdriftshastighed (vejledende) ved 3000 min-1
[14] Mekanisk transmission
Fremdriftshastighed (vejledende) ved 3000 min-1
[15] Hastighedsgrænse med snekæder
(hvis disse er forudset)
[ 1 6 ] M å l
[17] Længde med opsamlingspose
(længde uden pose)
[ 1 8 ] B r e d d e
[ 1 9 ] H ø j d e
[20] Skæreanordningens varenr
[21] Brændstofstankens kapacitet
[22] Lydtryksniveau
[23] Måleusikkerhed
[24] Målt lydeektniveau
[25] Garanteret lydeektniveau
[26] Vibrationsniveau på førersædet
[27] Vibrationsniveau ved rattet
[40]
Tilbehør på forespørgsel
[41] Udligningsbatterilader
[42] Sæt til “mulching”
[43] Presenning
* For disse data henvises til hvad der er angivet på
maskinens identikationsmærkat.
[1] DE - TECHNISCHE DATEN
[2] Nennleistung (*)
[3] Umdrehungen pro Minute (*)
[4] Elektrische Anlage
[5] Reifen Vorderräder
[6] Reifen Hinterräder
[7] Reifendruck vorne
[8] Reifendruck hinten
[9] Gewicht (*)
[10] Mindestradius nicht geschnittenes Gras
[11] Schnitthöhe
[12] Schnittbreite
[13] Hydrostatischer Antrieb - Vorschubgeschwindigkeit
(Richtwert) bei 3000 min
-1
[14] Mechanischer Antrieb - Vorschubgeschwindigkeit
(Richtwert) bei 3000 min-1
[15] Geschwindigkeitsgrenze mit Schneeketten
(falls als Zubehör vorgesehen)
[16] Abmessungen
[17] Länge mit Grasfangeinrichtung
(Länge ohne Grasfangeinrichtung)
[18] Breite
[19] Höhe
[20] Code Schneidwerkzeug
[21] Inhalt des Kraftstotanks
[22] Schalldruckpegel
[23] Messungenauigkeit
[24] Gemessener Schallleistungspegel
[25] Garantierter Schallleistungspegel
[26] Vibrationspegel am Fahrersitz
[27] Vibrationspegel am Lenkrad
[40]
Anbaugeräte auf Anfrage
[41] Batterieladegerät
[42] “Mulching”-kit
[43] Abdeckung
* Für die genaue Angabe nehmen Sie bitte auf das
Typenschild der Maschine Bezug.
[1] EL - ΤΕΧΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
[2] Ονομαστική ισχύς (*)
[3] Στροφές ανά λεπτό (*)
[4] Ηλεκτρικό σύστημα
[5] Εμπρόσθια ελαστικά
[6] Πίσω ελαστικά
[7] Πίεση εμπρόσθιων ελαστικών
[8] Πίεση πίσω ελαστικών
[9] Βάρος (*)
[10] Ελάχιστη ακτίνα μη κομμένου χόρτου
[11] Ύψος κοπής
[12] Πλάτος κοπής
[13] Υδροστατικό σύστημα μετάδοσης
Ταχύτητα κίνησης (ενδεικτική) στις 3000 σ.α.λ.
[14] Μηχανικό σύστημα μετάδοσης
Ταχύτητα κίνησης (ενδεικτική) στις 3000 σ.α.λ.
[15] Όριο ταχύτητας με αλυσίδες χιονιού (αν
προβλέπεται ως αξεσουάρ)
[16] Διαστάσεις
[17] Μήκος με κάδο (μήκος χωρίς κάδο)
[18] Πλάτος
[19] Ύψος
[20] Κωδικός συστήματος κοπής
[21] Χωρητικότητα του ντεπόζιτου καυσίμου
[22] Στάθμη ακουστικής πίεσης
[23] Αβεβαιότητα μέτρησης
[24] Μετρημένη στάθμη ακουστικής ισχύος
[25] Εγγυημένη στάθμη ακουστικής ισχύος
[26] Επίπεδο κραδασμών στη θέση του οδηγού
[27] Επίπεδο κραδασμών στο τιμόνι
[40] Παρελκόμενα κατόπιν παραγγελίας
[41] Φορτιστής συντήρησης μπαταρίας
[42] Σετ “mulching”
[43] Κάλυμμα προστασίας
* Για το συγκεκριμένο στοιχείο, ελέγξτε τα όσα αναγράφονται
στην ετικέτα προσδιορισμού του μηχανήματος
[1] EN - TECHNICAL DATA
[2] Nominal power (*)
[3] RPM (*)
[4] Electrical system
[5] Front tyres
[6] Rear tyres
[7] Front tyre pressure
[8] Rear tyre pressure
[9] Mass (*)
[10] Minimum radius of uncut grass
[11] Cutting height
[12] Cutting width
[13] Hydrostatic transmission
Forward speed (approximate) at 3000 min-1
[14] Mechanical transmission
Forward speed (approximate) at 3000 min-1
[15] Speed limit with snow chains (if available)
[16] Dimensions
[17] Length with grass catcher
(length without grass catcher)
[18] Width
[19] Height
[20] Cutting means code
[21] Fuel tank capacity
[22] Acoustic pressure level
[23] Measurement uncertainty
[24] Measured acoustic power level
[25] Guaranteed acoustic power level
[26] Operator position vibration level
[27] Steering wheel vibration level
[40] Optional attachments
[41] Maintenance battery charger
[42] “Mulching” kit
[43] Cloth cover
* Please refer to the data indicated on the machine’s
identication plate for the exact gure.
xii
[1] ES - DATOS TÉCNICOS
[2] Potencia nominal (*)
[3] Revoluciones por minuto (*)
[4] Instalación eléctrica
[5] Neumáticos anteriores
[6] Neumáticos posteriores
[7] Presión neumático anterior
[8] Presión neumático posterior
[9] Masa (*)
[10] Radio mínimo de hierba no cortada
[11] Altura de corte
[12] Anchura de corte
[13] Transmisión hidrostática
Velocidad de avance (indicativa) a 3000 min-1
[14] Transmisión mecánica
Velocidad de avance (indicativa) a 3000 min-1
[15] Límite de velocidad con cadenas de nieve
(si estuviera previsto el accesorio)
[16] Dimensiones
[17] Longitud con bolsa (longitud sin bolsa)
[18] Anchura
[19] Altura
[20] Código dispositivo de corte
[21] Capacidad del depósito carburante
[22] Nivel de presión acústica
[23] Incertidumbre de medida
[24] Nivel de potencia acústica medido
[25] Nivel de potencia acústica garantizado
[26] Nivel de vibraciones en el puesto de conductor
[27] Nivel de vibraciones al volante
[40] Accesorios bajo pedido
[41] Cargador de bateria de mantenimiento
[42] Kit para “mulching”
[43] Lona de cubierta
* Para el dato especíco, hacer referencia a lo indica-
do en la etiqueta de identicación de la máquina.
[1] ET - TEHNILISED ANDMED
[2] Nominaalvõimsus (*)
[3] Pöörded minutis (*)
[4] Elektrisüsteem
[5] Eesmised rehvid
[6] Tagumised rehvid
[7] Pumpamise rõhk ees
[8] Pumpamise rõhk taga
[9] Mass (*)
[10] Lõikamata rohu minimaalne raadius
[11] Lõikekõrgus
[12] Lõikelaius
[13] Hüdrostaatiline jõuülekanne
Edasiliikumise kiirus (ligikaudne) 3000 min-1
[14] Mehaaniline jõuülekanne
Edasiliikumise kiirus (ligikaudne) 3000 min-1
[15] Kiiruspiirang lumekettidega
(kui on ettenähtud lisaseade)
[16] Mõõtmed
[17] Pikkus korviga (pikkus ilma korvita)
[ 1 8 ] L a i u s
[19] Kõrgus
[20] Lõikeseadme kood
[21] Kütusepaagi maht
[22] Helirõhu tase
[23] Mõõtemääramatus
[24] Mõõdetud müravõimsuse tase
[25] Garanteeritud müravõimsuse tase
[26] Vibratsioonitase juhiistmel
[27] Vibratsioonide tase roolis
[40] Valikulised tarvikud
[41] Hooldus akulaadija
[42] „Multsimis“ komplekt
[43] Katteriie
* Konkreetse info jaoks viidata masina identitseerimi-
setiketil märgitule
[1] FI - TEKNISET TIEDOT
[2] Nimellisteho (*)
[3] Kierrosta minuutissa (*)
[4] Sähkölaitteisto
[5] Eturenkaat
[6] Takarenkaat
[7] Eturenkaiden täyttöpaine
[8] Takarenkaiden täyttöpaine
[9] Massa (*)
[10] Lõikamata rohu minimaalne raadiusi
[11] Leikkuukorkeus
[12] Leikkuuleveys
[13] Hydrostaattinen voimansiirto
Etenemisnopeus (suuntaa-antava) 3000 min-1
[14] Mekaaninen voimansiirto
Etenemisnopeus (suuntaa-antava) 3000 min-1
[15] Nopeusrajoitus lumiketjuilla
(jos kuuluu lisävarusteisiin)
[16] Mitat
[17] Pituus säkin kanssa (pituus ilman säkkiä)
[18] Leveys
[19] Korkeus
[20] Leikkuuvälineen koodi
[21] Polttoainesäiliön tilavuus
[22] Akustisen paineen taso
[23] Mittauksen epävarmuus
[24] Mitattu äänitehotaso
[25] Taattu äänitehotaso
[26] Tärinätaso kuljettajan paikalla
[27] Tärinätaso ohjauspyörässä
[40] Tilattavat lisävarusteet
[41] Ylläpitoakkulaturi
[42] Silppuamisvarusteet
[43] Suojakangas
• Määrättyä arvoa varten, viittaa laitteen tunnuslaa-
tassa annettuihin tietoihin.
[1] FR - CARACTÉRISTIQUES TECHNIQUES
[2] Puissance nominale (*)
[3] Tours par minute (*)
[4] Installation électrique
[5] Pneus avant
[6] Pneus arrière
[7] Pression de gonage avant
[8] Pression de gonage arrière
[9] Masse (*)
[10] Rayon minimal de l’herbe non taillée
[11] Hauteur de coupe
[12] Largeur de coupe
[13] Transmission hydrostatique
Vitesse d’avancement (indicative) à 3000 min-1
[14] Transmission mécanique
Vitesse d’avancement (indicative) à 3000 min-1
[15] Limite de vitesse avec chaînes à neige
(si accessoire prévu)
[16] Dimensions
[17] Longueur avec sac (longueur sans sac)
[18] Largeur
[19] Hauteur
[20] Code organe de coupe
[21] Capacité du réservoir de carburant
[22] Niveau de pression acoustique
[23] Incertitude de mesure
[24] Niveau de puissance acoustique mesuré
[25] Niveau de puissance acoustique garanti
[26] Niveau de vibration au poste de conduite
[27] Niveau de vibration au volant
[40] Accessoires sur demande
[41] Chargeur de batterie
[42] Kit pour “mulching”
[43] Housse de protection
• Pour la valeur spécique, se référer à ce qui est
indiqué sur la plaque signalétique de la machine.
[1] HR - TEHNIČKI PODACI
[2] Nazivna snaga (*)
[3] Broj okretaja u minuti (*)
[4] Električni sustav
[5] Prednje gume
[6] Stražnje gume
[7] Tlak zraka u prednjim gumama
[8] Tlak zraka u stražnjim gumama
[9] Masa (*)
[10] Minimalni promjer nepokošene trave
[11] Visina košnje
[12] Širina košnje
[13] Hidrostatski prijenos
Brzina napredovanja (indikativno) pri 3.000 min-1
[14] Mehanički prijenos
Brzina napredovanja (indikativno) pri 3.000 min-1
[15] Ograničenje brzine s lancima za snijeg
(ako se radi o predviđenom dijelu dodatne opreme)
[16] Dimenzije
[17] Dužina s košarom (dužina bez košare)
[18] Širina
[19] Visina
[20] Šifra noža
[21] Zapremnina spremnika goriva
[22] Razina zvučnog tlaka
[23] Mjerna nesigurnost
[24] Izmjerena razina zvučne snage
[25] Zajamčena razina zvučne snage
[26] Razina vibracija na vozačkom mjestu
[27] Razina vibracija na upravljaču
[40] Dodatna oprema na zahtjev
[41] Punjač baterija za održavanje
[42] Komplet za “malčiranje”
[43] Zaštitna cerada
* Specični podatak pogledajte na identikacijskoj
etiketi stroja.
[1] HU - MŰSZAKI ADATOK
[2] Névleges teljesítmény (*)
[3] Percenkénti fordulatszám (*)
[4] Elektromos rendszer
[5] Elülső gumiabroncsok
[6] Hátsó gumiabroncsok
[7] Elülső abroncsok légnyomása
[8] Hátsó abroncsok légnyomása
[9] Tömeg (*)
[10] Nem levágott fű minimális sugaral
[11] Nyírási magasság
[12] Munkaszélesség
[13] Hidrosztatikus erőátvitel
Haladási sebesség (hozzávetőlegesen) 3000
ford./perces fordulatszámon
[14] Mechanikus erőátvitel
Haladási sebesség (hozzávetőlegesen)
3000 ford./perces fordulatszámon
[15] Sebességkorlát hólánccal (ha tartozék)
[16] Méretek
[17] Hosszúság zsákkal (hosszúság zsák nélkül)
[18] Szélesség
[19] Magasság
[20] Vágóegység kódszáma
[21] Üzemanyagtartály kapacitása
[22] Hangnyomásszint
[23] Mérési bizonytalanság
[24] Mért zajteljesítmény szint.
[25] Garantált zajteljesítmény szint
[26] A vezetőállásnál mért vibrációszint
[27] A kormánynál mért vibrációszint
[40] Igényelt tartozékok
[41] Fenntartó akkumulátortöltő
[42] Mulcsozó készlet
[43] Takaró ponyva
* A pontos adatot lásd a gép azonosító adattábláján.
xiii
[1] LT - TECHNINIAI DUOMENYS
[2] Vardinė galia (*)
[3] Apsisukimai per minutę (*)
[4] Elektros instaliacija
[5] Priekinės padangos
[6] Užpakalinės padangos
[7] Priekinių padangų oro slėgis
[8] Užpakalinių padangų oro slėgis
[9] Svoris (*)
[10] Mažiausias nenupjautos žolės spindulys
[11] Pjovimo aukštis
[12] Pjovimo plotis
[13] Hidrostatinė transmisija
Eigos greitis (apytikslis) per 3000 min-1
[14] Mechaninė transmisija
Eigos greitis (apytikslis) per 3000 min-1
[15] Greičio riba su sniego grandinėmis
(jei šis priedas numatytas)
[16] Matmenys
[17] Ilgis su maišu (ilgis be maišo)
[ 1 8 ] P l o t i s
[ 1 9 ] A u k š t i s
[20] Pjovimo įtaiso kodas
[21] Alyvos bako talpa
[22] Garso slėgio lygis
[23] Matavimo paklaida
[24] Išmatuotas garso galios lygis
[25] Garantuotas garso galios lygis
[26] Vibracijų lygis, sėdynė
[27] Vibracijų lygis, vairas
[40] Papildomi priedai
[41] Akumuliatoriaus palaikymo įkroviklis
[42] Rinkinys mulčiavimui
[43] Apdangalas
* Konkretūs speciniai duomenys yra pateikti įrenginio
identikavimo etiketėje
[1] LV - TEHNISKIE DATI
[2] Nominālā jauda (*)
[3] Apgriezieni minūtē (*)
[4] Elektroiekārta
[5] Priekšējās riepas
[6] Aizmugurējās riepas
[7] Priekšējo riepu spiediens
[8] Aizmugurējo riepu spiediens
[9] Masa (*)
[10] Minimālais nenopļautās zāles rādiuss
[11] Pļaušanas augstums
[12] Pļaušanas platums
[13] Hidrostatiskā transmisija
Kustības ātrums (aptuvens) pie 3000 min-1
[14] Mehāniskā transmisija
Kustības ātrums (aptuvens) pie 3000 min-1
[15] Ātruma ierobežojums sniega ķēžu izmantošanas
gadījumā
(ja šis piederums ir paredzēts)
[16] Izmēri
[17] Garums ar maisu (garums bez maisa)
[18] Platums
[19] Augstums
[20] Griezējierīces kods
[21] Degvielas tvertnes tilpums
[22] Skaņas spiediena līmenis
[23] Mērījumu kļūda
[24] Izmērītais skaņas intensitātes līmenis
[25] Garantētais skaņas intensitātes līmenis
[26] Vibrāciju līmenis vadītāja vietā
[27] Stūres vibrāciju līmenis
[40] Piederumi pēc pieprasījuma
[41] Akumulatoru atbalsta lādētājs
[42] Mulčēšanas komplekts
[43] Pārvalks
* Precīza vērtība ir norādīta mašīnas identikācijas datu
plāksnītē.
[1] NL - TECHNISCHE GEGEVENS
[2] Nominaal vermogen (*)
[3] Omwentelingen per minuut
[4] Elektrische installatie
[5] Voorbanden
[6] Achterbanden
[7] Bandenspanning vooraan
[8] Bandenspanning achteraan
[9] Massa (*)
[10] Minimum straal ongemaaid gras
[11] Maaihoogte
[12] Maaibreedte
[13] Hydrostatische aandrijving
(Indicatieve) voortbewegingssnelheid bij 3000 min-1
[14] Mechanische aandrijving
(Indicatieve) voortbewegingssnelheid bij 3000
min-1
[15] Snelheidslimiet met sneeuwkettingen
(indien dit toebehoren voorzien is)
[16] Afmetingen
[17] Lengte met zak (lengte zonder zak)
[18] Breedte
[19 Hoogte
[20] Code snij-inrichting
[21] Vermogen van het brandstofreservoir
[22] Niveau geluidsdruk
[23] Meetonzekerheid
[24] Gemeten akoestisch vermogen
[25] Gewaarborgd akoestisch vermogen .
[26] Niveau trillingen op de bestuurdersplaats
[27] Niveau trillingen aan het stuur
[40] Accessoires op verzoek
[41] Batterij-oplader voor behoud
[42] Kit voor “mulching”
[43] Afdekzeil
* Voor het speciek gegeven, verwijst men naar wat aange-
geven is op het identicatielabel van de machine.
[1] NO - TEKNISKE DATA
[2] Nominell eekt (*)
[3] Omdreininger pr. minutt (*)
[4] Elektrisk system
[5] Fordekk
[6] Bakdekk
[7] Lufttrykk foran
[8] Lufttrykk bak
[9] Vekt (*)
[10] Minste radius til ikke klippet gress
[11] Klippehøyde
[12] Klippebredde
[13] Hydrostatisk transmisjon
Fremdriftshastighet (ca.) ved 3 000 o/min.
[14] Mekanisk transmisjon
Fremdriftshastighet (ca.) ved 3 000 o/min.
[15] Hastighetsgrense med snøkjettinger (hvis nnes)
[16] Mål
[17] Lengde med oppsamler (lengde uten oppsamler)
[18] Bredde
[19] Høyde
[20] Artikkelnummer for klippeinnretning
[21] Drivstotankens volum
[22] Lydtrykknivå
[23] Måleusikkerhet
[24] Målt lydeektnivå
[25] Garantert lydeektnivå
[26] Vibrasjonsnivå ved førerplassen
[27] Vibrasjonsnivå ved rattet
[40] Ekstrautstyr etter forespørsel
[41] Batterilader
[42] Mulching-sett
[43] Presenning
* For spesikk informasjon, se referansen på maskinens
identikasjonsetikett.
[1] PL - DANE TECHNICZNE
[2] Moc znamionowa (*)
[3] Liczba obrotów na minutę (*)
[4] Instalacja elektryczna
[5] Koła przednie
[6] Koła tylne
[7] Ciśnienie powietrza kół przednich
[8] Ciśnienie powietrza kół tylnych
[9] Masa (*)
[10] Minimalny promień nieskoszonej trawy
[11] Wysokość koszenia
[12] Szerokość koszenia
[13] Napęd hydrostatyczny
Szybkość postępu (przybliżona) przy 3000 min-1
[14] Napęd mechaniczny
Szybkość postępu (przybliżona) przy 3000 min-1
[15] Limit prędkości z łańcuchami
(jeżeli przewidziane)
[16] Wymiary
[17] Długość z pojemnikiem (długość bez pojemnika)
[18] Szerokość
[19] Wysokość
[20] Kod agregatu tnącego
[21] Pojemność zbiornika paliwa
[22] Poziom ciśnienia akustycznego
[23] Błąd pomiaru
[24] Poziom mocy akustycznej zmierzony
[25] Gwarantowany poziom mocy akustycznej
[26] Poziom drgań na stanowisku kierowcy
[27] Poziom drgań na kierownicy
[40] Akcesoria na zamówienie
[41] Ładowarka akumulatora
[42] Zestaw mulczujący
[43] Pokrowiec
* W celu uzyskania konkretnych danych, należy
się odnieść do wskazówek zamieszczonych na
tabliczce identykacyjnej maszyny.
[1] PT - DADOS TÉCNICOS
[2] Potência nominal (*)
[3] Rotações por minuto (*)
[4] Instalação elétrica
[5] Pneus dianteiros
[6] Pneus traseiros
[7] Pressão dos pneus dianteiros
[8] Pressão dos pneus traseiros
[9] Massa (*)
[10] Raio mínimo da relva não cortada
[11] Altura de corte
[12] Largura de corte
[13] Transmissão hidrostática
Velocidade de avanço (indicativa) a 3000 min-1
[14] Transmissão mecânica
Velocidade de avanço (indicativa) a 3000 min-1
[15] Limite de velocidade com correntes de neve
(se o acessório for previsto)
[16] Dimensões
[17] Comprimento com saco (comprimento sem saco)
[18] Largura
[19] Altura
[20] Código dispositivo de corte
[21] Capacidade do tanque de combustível
[22] Nível de pressão acústica
[23] Incerteza de medição
[24] Nível de potência acústica medido
[25] Nível de potência acústica garantido
[26] Nível de vibrações no local de condução
[27] Nível de vibrações no volante
[40] Acessórios a pedido
[41] Carregador de baterias de manutenção
[42] Kit para “mulching”
[43] Lona de cobertura
* Para o dado especíco, consulte a etiqueta de
identicação da máquina.
xiv
[1] RO - DATE TEHNICE
[2] Putere nominală (*)
[3] Rotații pe minut (*)
[4] Instalație electrică
[5] Pneuri față
[6] Pneuri spate
[7] Presiune roți față
[8] Presiune roți spate
[9] Masă (*)
[10] Raza minimă de iarbă netăiată
[11] Înălțime de tăiere
[12] Lățime de tăiere
[13] Transmisie hidrostatică- Viteză de avans
(indicativă) la 3000 min-1
[14] Transmisie mecanică - Viteza de avans
(indicativă) la 3000 min-1
[15] Limită de viteză cu lanțuri de zăpadă
(dacă acest accesoriu este prevăzut)
[16] Dimensiuni
[17] Lungime cu sac (lungime fără sac)
[ 1 8 ] L ă ț i m e
[19] Înălțime
[20] Codul dispozitivului de tăiere
[21] Capacitate rezervor carburant
[22] Nivel de presiune acustică
[23] Nesiguranță în măsurare
[24] Nivel de putere acustică măsurat
[25] Nivel de putere acustică garantat
[26] Nivel de vibrații la locul conducătorului
[27] Nivel de vibrații la volan
[40] Accesorii la cerere
[41] Încărcător de baterie de întreținere
[42] Kit pentru „mulching”
[43] Prelată pentru acoperire
* Pentru informația specică, consultați datele de pe
eticheta de identicare a mașinii.
[1] RU - ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ
[2] Номинальная мощность (*)
[3] Число оборотов в минуту (*)
[4] Электропроводка
[5] Передние шины
[6] Задние шины
[7] Давление в передних шинах
[8] Давление в задних шинах
[9] Масса (*)
[10] Минимальный радиус нескошенной травы
[11] Высота скашиваемой травы
[12] Ширина скашивания
[13] Скорость передвижения (ориентировочная)
при 3000 мин
-1
[14] Предел скорости с цепями противоскольжения
(если предусмотрено это дополнительное
оборудование)
[15] Габариты
[16] Длина с контейнером (длина без контейнера)
[17] Ширина
[18] Высота
[19] Код режущего приспособления
[20] Объем топливного бака
[21] Уровень звукового давления
[22] Погрешность измерения
[23] Измеренный уровень звуковой мощности
[24] Гарантируемый уровень звуковой мощности
[25] Уровень вибрации на месте водителя
[26] Уровень вибрации на руле
[40] Опциональные принадлежности
[41] Поддерживающее зарядное устройство
[42] Комплект для мульчирования
[43] Защитный чехол
* Точное значение см. на идентификационном
ярлыке машины
[1] SK - TECHNICKÉ PARAMETRE
[2] Menovitý výkon (*)
[3] Otáčky za minútu (*)
[4] Elektroinštalácia
[5] Predné pneumatiky
[6] Zadné pneumatiky
[7] Tlak hustenia predných pneumatík
[8] Tlak hustenia zadných pneumatík
[9] Hmotnosť (*)
[10] Minimálny akčný rádius otáčania
[11] Výška kosenia
[12] Šírka orezávania
[13] Гидростатическая трансмиссия - Скорость
передвижения (ориентировочная) при 3000 мин-1
[14] Механическая трансмиссия - Скорость
передвижения (ориентировочная) при 3000
мин-1
[15] Hraničná rýchlosť so snehovými reťazami
(ak sa jedná o určené príslušenstvo)
[16] Rozmery
[17] Dĺžka s košom (dĺžka bez koša)
[18] Šírka
[19] Výška
[20] Kód kosiaceho zariadenia
[21] Kapacita palivovej nádržky
[22] Úroveň akustického tlaku
[23] Nepresnosť merania
[24] Úroveň nameraného akustického výkonu
[25] Úroveň zaručeného akustického výkonu
[26] Úroveň vibrácií na mieste vodiča
[27] Úroveň vibrácií na volante
[40] Príslušenstvo na požiadanie
[41] Udržiavacia nabíjačka akumulátora
[42] Súprava pre mulčovanie
[43] Krycia plachta
* Ohľadne uvedeného parametra vychádzajte z hodnoty
uvedenej na identikačnom štítku stroja.
[1] SL - TEHNIČNI PODATKI
[2] Nazivna moč (*)
[3] Vrtljaji na minuto (*)
[4] Električna napeljava
[5] Prednje pnevmatike
[6] Zadnje pnevmatike
[7] Tlak v prednjih pnevmatikah
[8] Tlak v zadnjih pnevmatikah
[9] Masa (*)
[10] Minimálny akčný rádius otáčania
[11] Višina košnje
[12] Širina reza
[13] Hidrostatični menjalnik
Hitrost vožnje (približna) pri 3000 min-1
[14] Mehanski menjalnik
Hitrost vožnje (približna) pri 3000 min-1
[15] Omejitev hitrosti ob montiranih snežnih verigah (če
so predvidene kot oprema)
[16] Dimenzije
[17] Dĺžka s košom (dĺžka bez koša)
[18] Širina
[19] Višina
[20] Šifra rezalne naprave
[21] Prostornina rezervoarja za gorivo
[22] Raven zvočnega tlaka
[23] Merilna negotovost
[24] Izmerjena raven zvočne moči
[25] Zajamčena raven zvočne moči
[26] Stopnja vibracij na voznikovem sedežu
[27] Nivo vibracij na volanu
[40] Dodatna oprema po naročilu
[41] Polnilnik akumulatorja za vzdrževanje
[42] Komplet za mulčenje
[43] Prekrivno platno
* Za specični podatek glej identikacijsko nalepko
stroja.
[1] SV - TEKNISKA SPECIFIKATIONER
[2] Nominell eekt (*)
[3] Varv i minuten (*)
[4] Elanläggning
[5] Framdäck
[6] Backdäck
[7] Däcktryck fram
[8] Däcktryck bak
[9] Vikt (*)
[10] Minimiradie på oklippt gräs
[11] Klipphöjd
[12] Klippbredd
[13] Hydrostatisk transmission
Körhastighet (indikativ) vid 3000 min-1
[14] Mekanisk transm ission
Körhastighet (indikativ) vid 3000 min-1
[15] Hastighetsgräns med snökedjor
(om tillbehör förutses)
[16] Dimensioner
[17] Längd med påse (längd utan påse)
[18] Bredd
[19] Höjd
[20] Skärenhetens kod
[21] Bränsletankens kapacitet
[22] Ljudtrycksnivå
[23] Tvivel med mått
[24] Uppmätt ljudeektnivå
[25] Garanterad ljudeektnivå
[26] Vibrationsnivå på förarplatsen
[27] Vibrationsnivå på ratten
[40] Tillbehör på begäran
[41] Batteriladdare för utjämningsladdning
[42] Sats för “mulching”
[43] Presenning
* För specik information, se uppgifterna
på maskinens märkplåt.
[1] TR - TEKNİK VERİLER
[2] Nominal güç (*)
[3] Dakikadaki devir sayısı (*)
[4] Elektrik tesisi
[5] Ön tekerlekler
[6] Arka tekerlekler
[7] Ön şişirme basıncı
[8] Arka şişirme basıncı
[9] Kütle (*)
[10] Minimum kesilmemiş çim yarıçapı
[11] Kesim yüksekliği
[12] Kesim genişliği
[13] Hidrostatik transmisyon
3000 dak-1’de ilerleme hızı (yaklaşık)
[14] Mekanik transmisyon
3000 dak-1’de ilerleme hızı (yaklaşık)
[15] Kar zincirleri ile (aksesuar öngörülmüş ise)
hız limiti
[ 1 6 ] E b a t l a r
[17] Sepetli uzunluk (sepetsiz uzunluk)
[18] Genişlik
[19] Yükseklik
[20] Kesim düzeni kodu
[21] Yakıt deposu kapasitesi
[22] Ses basınç seviyesi
[23] Ölçü belirsizliği
[24] Ölçülen ses gücü seviyesi
[25] Garanti edilen ses gücü seviyesi
[26] Sürücü mahalinde titreşim seviyesi
[27] Direksiyonda titreşim seviyesi
[40] İsteğe bağlı aksesuarlar
[41] Koruma batarya şarjörü
[42] “Malçlama” kiti
[43] Kaplama kılıfı
* Spesik değer için, makine belirleme etiketinde
belirtilenleri referans alın
1
EN
WARNING: READ THOROUGHLY THE INSTRUCTION BOOKLET BEFORE US-
ING THE MACHINE. Keep for future reference.
For information on the engine and the bat-
tery, read the relevant owner manuals.
TABLE OF CONTENTS
1. SAFETY REGULATIONS .......................... 1
2. GETTING TO KNOW THE MACHINE ....... 4
3. UNPACKING AND ASSEMBLY ................. 6
4. CONTROLS AND INSTRUMENTS ........... 7
5. OPERATING INSTRUCTIONS .................. 8
5.1 Safety recommendations ................... 8
5.2 Why the safety devices cut in ............. 9
5.3 Preliminary operations before
starting work ....................................... 9
5.4 Using the machine ........................... 10
5.5 Using on slopes ................................ 12
5.6 Suggestions for maintaining
a nice lawn ........................................ 12
6. MAINTENANCE ...................................... 12
6.1 Safety recommendations ................. 12
6.2 Accessing the engine ....................... 13
6.3 Routine maintenance ....................... 13
6.4 Interventions on the machine ........... 15
7. TROUBLESHOOTING ............................. 16
8. ATTACHMENTS ...................................... 18
HOW TO READ THE MANUAL
Some paragraphs in the manual contain impor-
tant information regarding safety and operation
and are emphasized in this manner:
NOTE or IMPORTANT
These give details or further information on what
has already been said, and aim to prevent dam-
age to the machine.
WARNING! Non-observance will result
in the risk of injury to oneself or others.
DANGER! Non-observance will result in
the risk of serious injury or death to oneself
or others.
The manual describes several machine models
that can mainly dier in:
– the inclusion of components or attachments
which are not widely available;
– special equipment tted.
The symbol ” “ highlights all the dierences
in usage and is followed by the indication of the
version to which it refers.
NOTE Whenever reference is made to a posi-
tion on the machine “front”, “back”, “left” or “right”
hand side, this is determined from where the
operator is seated. (Fig. 1.1)
IMPORTANT For all operations regarding the
use and maintenance of the engine or the battery
not described in this manual, refer to the relevant
manuals which form an integral part of all the
documentation supplied with the machine.
1. SAFETY REGULATIONS
to be a followed scrupulously
A) TRAINING
1) WARNING! Read these instructions care-
fully before operating the machine. Become
acquainted with the controls and the proper use
of the machine. Learn how to stop the engine
quickly. Failure to follow the warnings and in-
structions may result in re and/or serious injury.
Save all warnings and instructions for future
reference.
2) Never allow children or persons unfamiliar
with these instructions to use the machine. Lo-
cal laws can restrict the minimum age of the
operator.
3) Never mow while people, especially children,
or pets are nearby.
4) Never use the machine if the user is tired or
unwell, or has taken medicine, drugs, alcohol or
any substances which may slow his reexes and
compromise his judgement.
5) Bear in mind that the operator or user is re-
sponsible for accidents or unexpected events
occurring to other people or their property. It is
the user’s responsibility to assess the potential
risk of the area where work is to be carried out,
and to take all the necessary precautions to en-
sure his own safety and that of others, particu-
larly on slopes or rough, slippery and unstable
ground.
6) If the machine is sold or lent to others, make
sure that the operator looks over the user in-
structions contained in this manual.
7) Do not allow children or other passengers to
ride on the machine as they could fall o and
injure themselves or compromise safe driving by
the operator.
8) The machine operator must follow the driving
instructions carefully and, in particular:
– Avoid distractions and maintain concentration
whilst working;
– Bear in mind that control of a machine sliding
on a slope will not be regained by the applica-
2
tion of the brake. The main reasons for loss of
control are:
• Insucient wheel grip;
• Excessive speed;
• Inadequate braking;
• Type of machine unsuitable for its task;
• Lack of awareness of the eect of ground
conditions, especially slopes;
• Incorrect use as a towing machine.
9) The machine is supplied with a series of
micro-switches and safety devices which must
never be tampered with or removed; this will
invalidate the warranty and relieve the manufac-
turer from all responsibility. Always check that
the safety devices are working properly before
using the machine.
B) PRELIMINARY OPERATIONS
1) While using the machine, always wear anti-
slip and resistant work footwear and long pants.
Do not operate the machine when barefoot or
wearing open sandals. Avoid wearing chains,
bracelets, clothing that is loose tting or has
hanging cords or ties. Tie hair back if it is long.
Always wear protective earplugs.
2) Thoroughly inspect the entire work area and
remove anything that could be thrown by the
machine or damage the cutting-means as-
sembly or engine (stones, branches, iron wire,
bones, etc.).
3) WARNING: DANGER! Petrol is highly am-
mable.
– Store the fuel in special containers;
– add fuel, using a funnel, only outdoors; do not
smoke during this operation and each time
fuel is handled;
– Top-up with fuel before igniting the engine;
never remove the tank cap or add fuel while
the engine is running or when it is hot;
– if you have spilled some fuel, do not attempt
to ignite the engine but move the machine
away from the area of spillage and avoid cre-
ating any source of ignition until the fuel has
evaporated and fuel vapours have dissipated:
– Always put the tank and fuel container caps
back on and tighten well;
4) Replace faulty silencers.
5) Before using the machine, check its general
condition and in particular:
the appearance of the cutting means, and check
that the screws and cutting-means assembly
are not worn or damaged. Replace the entire
cutting means and all damaged or worn screws
to preserve balance. Any repairs must be done
at a specialised centre.
6) Check the battery status regularly, and re-
place it if there is any damage to the casing,
cover or terminals.
7) Before starting work, always t the exit
guards (grass catcher, side discharge guard or
rear discharge guard).
C) DURING USE
1) Do not operate the engine in a conned space
where dangerous carbon monoxide fumes can
develop. All ignition operations have to be ef-
fected in an open or well-ventilated area. Always
remember that exhaust fumes are toxic.
2) Work only in daylight or with good articial
light in good visibility conditions. Keep persons,
children and animals away from the working
area.
3) If possible, avoid mowing wet grass. Avoid
working in the rain and when there is a risk of
a thunderstorm risk. Do not use the machine in
bad weather conditions, especially when there
is risk of lightening.
4) Before starting the engine, disengage the
blade, shift the gear lever (for mechanical trans-
mission) or the speed change lever (for hydro-
static transmission) into neutral and engage the
parking brake.
5) Pay special attention when approaching ob-
stacles that could compromise visibility.
6) Engage the parking brake when parking the
machine.
7) The machine must not be used on slopes of
over 10° (17%), regardless of the mowing direc-
tion.
8) Remember there is no such thing as a “safe”
slope. Driving on grass slopes requires particu-
lar care. To prevent overturning or loss of control
over the machine:
– Do not stop or start suddenly when going up
or downhill;
– Engage clutch slowly, always keep the ma-
chine in gear (for mechanical transmission) or
engage the speed change lever slowly both
for forward and reverse movement (for hydro-
static transmission), especially when travel-
ling downhill;
– Machine speeds should be kept low on slopes
and during tight turns;
– Watch out for humps, hollows and other hidden
hazards;
– Never mow across the face of the slope.
Lawns on a slope have to be mowed moving
up and down and never across them. When
changing direction, take great care that the
wheels facing the slope do not hit any obsta-
cles (such as stones, branches, roots, etc.)
that may cause the machine to slide side-
ways, tip over or make you lose control.
Reduce speed before any change of direction
on slopes, and always apply the parking brake
before leaving the machine at a standstill and
unattended.
10) Be very careful near ravines, ditches or
3
embankments. The machine could overturn if a
wheel slides over the edge or if the earth gives
way.
11) Pay maximum attention when working in re-
verse gear. Look behind you to make sure there
are no obstacles before and during operations
in reverse gear.
12) Disengage the cutting means or the power
socket when crossing areas with no grass, when
moving to or from areas that require mowing,
and move the cutting-means assembly to its
highest position.
13) Pay attention to trac when using the ma-
chine near roads.
14) WARNING! The machine has not been ap-
proved for use on public roads. It must be used
(as indicated by the highway code) in private
areas closed to trac.
15) Never operate the machine with damaged
guards or without the grass catcher, side dis-
charge guards or rear discharge guards.
16) Never place your hands and feet near or
under rotating parts. Keep away from the dis-
charge opening.
17) Do not leave the machine stationary on high
grass with the engine running to avoid the risk of
starting a re.
18) When using the attachments, never direct
the opening towards people.
19) Use manufacturer-recommended attach-
ments only.
20) Don’t use the machine if the attachments/
tools are not installed in their seats.
21) Pay attention when using the grass catcher
and attachments that can alter the stability of
the machine, especially on slopes.
22) Do not change the engine settings or over-
rev the engine.
23) Do not touch the engine parts as they get
very hot when running. Danger of burns.
24) Disengage the cutting means or power
socket, put in neutral and engage the parking
brake, turn o the engine and remove the igni-
tion key (checking that all moving parts are com-
pletely stationary):
– Whenever the machine is left unattended or
the operator dismounts from the driving seat:
– Before clearing blockages or unclogging the
discharge chute;
– Before checking, cleaning or working on the
machine;
– After striking a foreign object. Inspect the
machine for damage and make repairs before
using it again.
25) Disengage the cutting means or the power
socket and switch o the engine (making sure
that all moving parts are stationary):
– Before refuelling;
– Whenever you remove or reattach the grass
catcher;
– Whenever you remove or reattach the side
discharge chute;
– Before adjusting the cutting height, if this op-
eration cannot be performed from the driving
seat.
26) Disengage the cutting device or the power
socket during transport and whenever it is not
in use.
27) Reduce the throttle setting before stopping
the engine. Shut o the fuel supply on complet-
ing the work, following the instructions in the
engine manual.
28) Pay attention to cutting means assemblies
with more than one cutting means, as a rotat-
ing cutting means can trigger the rotation of the
others,
29) WARNING – If something breaks or an ac-
cident occurs whilst working, turn o the engine
immediately and move the machine away to pre-
vent further damage; if an accident occurs with
injuries or third parties are injured, carry out the
rst aid measures most suitable for the situation
immediately and contact the medical authorities
for any necessary health care. Carefully remove
any debris that might cause damage or harm
persons or animals should it not be seen.
30) WARNING - The noise and vibration levels
shown in these instructions are the maximum
levels for use of the machine. The use of an
unbalanced cutting means, excessive speed of
movement, or lack of maintenance have a sig-
nicant inuence on noise emissions and vibra-
tions. Consequently, it is necessary to take pre-
ventive steps to eliminate possible damage due
to high levels of noise and stress from vibration.
Maintain the machine well, wear ear protection
devices, and take breaks while working.
D) MAINTENANCE AND STORAGE
1) WARNING! - Before cleaning or doing main-
tenance work, take out the ignition key and read
the relevant instructions. Wear proper clothing
and protective gloves whenever your hands are
at risk.
2) WARNING! – Never use the machine with
worn or damaged parts. Faulty or worn-out parts
must always be replaced and not repaired. Use
original spare parts only: the use of non-original
and/or incorrectly tted parts will jeopardize the
safety of the machine, may cause accidents or
personal injuries for which the Manufacturer is
under no circumstance liable or responsible.
3) Any adjustments or maintenance operations
not described in this manual must be carried out
by your Dealer or a specialized Service Centre
with the necessary knowledge and equipment to
ensure that the work is done correctly maintain-
ing the machine’s original safety level. Any op-
erations performed in unauthorized centres or
4
by unqualied persons will totally invalidate the
Warranty and all obligations and responsibilities
of the Manufacturer.
4) After each use, remove the ignition key and
check for damage.
5) Keep all nuts, bolts and screws tight to be
sure the equipment is in safe working condition.
Routine maintenance is essential for safety and
for maintaining a high performance level.
6) Check that the cutting means screws are
properly tightened on a regular basis.
7) Wear work gloves when handling, disassem-
bling and reassembling all cutting means.
8) Keep the cutting means well balanced during
sharpening. All works on the cutting means (dis-
assembly, sharpening, balancing, reassembly
and/or replacing) are demanding jobs that re-
quire special skills as well as special tools. For
safety reasons, these jobs are best carried out
at a specialised centre.
9) Check that the brakes work properly on a
regular basis. It is vital for brakes to undergo
regular maintenance and, where necessary,
repair work.
10) Check the side discharge guard, the rear
discharge guard, the grass catcher and the
intake grille frequently. Replace them if they are
damaged.
11) Replace any instruction or warning message
stickers, if damaged.
12) When the machine is to be stored or left un-
attended, lower the cutting-means assembly.
13) Store the machine out of the reach of chil-
dren.
14) Do not store the machine with fuel in the tank
in an area where the fuel vapours could reach
an open ame, a spark or a strong heat source.
15) Allow the engine to cool down before storing
in any enclosure.
16) To reduce re hazards, keep the engine, si-
lencer, battery compartment and petrol storage
area free of grass, leaves, or excessive grease.
Always empty the grass catcher and do not
leave containers full of cut grass inside storage
areas.
17) To reduce re hazards, check there are no
oil and/or fuel leaks on a regular basis.
18) If the fuel tank has to be emptied, this should
be done outdoors once the engine has cooled
down.
19) Never leave the keys in the ignition or within
reach of children or unauthorised persons. Al-
ways remove the ignition key before doing any
maintenance.
E) TRANSPORT
1) WARNING! - If the machine must be trans-
ported on a truck or trailer, use ramps with
suitable resistance, width and length. Load the
machine with the engine switched o, without
a driver and pushed by an adequate number of
people. During transport, close the fuel stop-
cock (if tted), lower the cutting-means assem-
bly or attachment, engage the parking brake
and fasten the machine securely with ropes or
chains to the hauling device.
F) ENVIRONMENTAL PROTECTION
1) Environmental protection should be a priority
of considerable importance when using the ma-
chine, for the benet of both social coexistence
and the environment in which we live. Try not to
cause any disturbance to the surrounding area.
2) Scrupulously comply with local regulations
and provisions for the disposal of packaging,
oils, petrol, lters, damaged parts or any ele-
ments which have a strong impact on the envi-
ronment; this waste must not be disposed of as
normal waste, it must be separated and taken
to specied waste disposal centres where the
material will be recycled.
3) Scrupulously comply with local regulations for
the disposal of waste materials after mowing.
4) At the time of decommissioning, do not pol-
lute the environment with the machine, but hand
it over to a disposal centre, in accordance with
the local laws in force.
2. GETTING TO KNOW THE MACHINE
2.1 DESCRIPTION OF THE MACHINE
AND ITS RANGE OF USE
This machine is a garden tool and precisely a
ride-on lawnmower with seated operator.
The machine is equipped with an engine which
drives a cutting unit protected by a casing, as
well as a transmission unit that moves the ma-
chine.
The operator is able to operate the machine and
use the main controls, always seated in the op-
erator’s position.
The devices tted on the machine stop the
engine and the cutting means within a few sec-
onds, should the operator behave in a manner
that does not comply with the necessary safety
precautions.
This manual describes both mechanically and
hydrostatically driven machines.
Intended use
This machine was designed and built to cut
grass.
The use of special attachments provided for
by the Manufacturer as original equipment or
which may be purchased separately, allows this
work to be done in various operating modes,
illustrated in this manual or the instructions that
5
accompany the single attachments.
Likewise, the intended use can be extended to
include other functions by applying supplemen-
tary attachments (if provided for by the Manu-
facturer), abiding by the restrictions and condi-
tions indicated in the instructions accompanying
the attachment.
User types
This machine is intended for use by consumers,
i.e. non-professional operators. The machine is
intended for “DIY” use only.
Improper use
Any other usage not in keeping with the above-
mentioned ones may be hazardous and harm
persons and/or damage things.
Examples of improper use may include, but are
not limited to:
– use of the machine for riding over unstable,
slippery, icy, stony, rough, marshy ground or
puddles that do not allow the consistency of
the ground to be assessed;
– using the cutting means on surfaces other
than grass.
– use of the machine for leaf or debris collec-
tion;
Improper use of the machine will invalidate the
warranty, relieve the Manufacturer from all li-
abilities, and the user will consequently be liable
for all and any damage or injury to himself or
others.
2.2 IDENTIFICATION LABEL AND
MACHINE COMPONENTS
(see gures on page ii)
1. Acoustic power level
2. CE conformity marking
3. Year of manufacture
4. Operating engine power and speed
5. Type of machine
6. Serial number
7. Weight in kg
8. Name and address of Manufacturer
9. Type of transmission (if indicated)
10. Article code
The example of the Declaration of Conformity is
provided on the penultimate page of the manual.
/–––/–––/–––/–––/–––/–––/–––/
Write the serial number of your machine (6)
here.
As soon as you have purchased the machine,
do not forget to write the identication numbers
(3 - 5 - 6) in the spaces on the last page of the
manual.
The machine is composed of a series of main
components that have the following functions:
11. Cutting-means assembly: this is the cas-
ing that houses the rotating cutting means.
12. Cutting means: these are what cut the
grass; the ns at the ends help convey the
cut grass towards the collector channel.
13. Collector cha nnel: this is the part con-
necting the Cutting-means assembly to the
grass catcher.
14 . Gra ss catcher: as well as collecting the
grass cuttings, this is also a safety element
that stops any objects drawn up by the cut-
ting devices from being hurled away from
the machine.
15. Engine: this moves the cutting means and
drives the wheels. Its specications and
regulations for use are described in a spe-
cic manual.
16. Battery: provides the energy for starting
the engine. Its specications and regula-
tions for use are described in a specic
manual.
17. Driving seat: this is where the machine
operator sits. It has a sensor connected to
safety devices for detecting the presence of
the operator.
18. Warning and safety labels: these give
reminders on the main regulations for work-
ing in safety.
19. Inspection hatch: Inspection hatch: to pro-
vide easy access to the spark plug, the fuel
stopcock and the engine cover fastener nut.
20. Intake grid: provides air to circulate inside
the cutting-means assembly and prevents
expelling of foreign bodies through the
front.
2.3 SAFETY REQUIREMENTS
Your machine should be used with due care and
attention. Therefore, labels have been placed
on the machine to remind you pictorially of the
main precautions to take during use. These
labels are to be considered an integral part of
the machine. If a label should fall o or become
illegible, contact your Retailer to replace it. Their
meaning is explained below.
31. Warning: Read the instructions before op-
erating the machine.
32. Warning: Disconnect the key and read the
instructions before carrying out any mainte-
nance or repair work.
6
33. Danger! Ejected objects: Never use
the machine without having tted the exit
guard!
34. Danger! Ejected objects: Keep bystand-
ers away.
35. Danger! Machine rollover: Do not use this
machine on slopes greater then 10°.
36. Danger! Dismemberment: Make sure that
children stay clear of the machine all the
time when engine is running.
37. Danger of cutting yourself. Cutting
means in motion. Do not put hands or feet
near or under the opening of the cutting
means housing.
38. Warning! Keep away from hot surfaces.
39. Avoid injuries caused by moving belts:
Never start up the machine without the
safety guards in place. Keep a safe dis-
tance between you and the belts.
NOTE The images corresponding to the texts
in chapters 3 et seq., can be found on pages iii et
seq. of this manual.
3. UNPACKING AND ASSEMBLY
For storage and transport purposes, some com-
ponents of the machine are not installed in the
factory and have to be assembled after unpack-
ing. Follow the instructions below.
IMPORTANT The machine is supplied without
engine oil or fuel. Before starting up the engine,
fill with oil and fuel following the instructions given
in the engine manual.
WARNING! Unpacking and completing
the assembly should be done on a flat and
stable surface, with enough space for mov-
ing the machine and its packaging, always
making use of suitable equipment.
3.1 UNPACKING
When unpacking the machine, take care to
gather all individual parts and ttings, and do
not damage the cutting-means assembly when
taking the machine o the pallet.
The standard packaging contains:
– the machine;
– the steering wheel;
– the seat;
– cutting means engagement control lever ex-
tension;
– dashboard cover;
– steering wheel column caster;
– the grass catcher components;
– the syringe used to suction the engine oil.
– an envelope containing the instructions
manual, documents and screw supply also
containing 2 sets of keys and a spare 10 Am-
pere fuse (6.3 A with Honda motor).
NOTE To avoid damaging the cutting-means
assembly when getting the machine down from
the pallet, take it to the maximum height and be
very careful.
Hydrostatic transmission:
– To make it easier to get the machine o
the pallet and to move it, the rear drive dis-
engage lever should be put in position «B»
(see 4.21.3).
Disposal of the packaging should be done in ac-
cordance with the local regulations in force.
3.2 ASSEMBLY AND CONNECTING
THE BATTERY (Fig. 3.1)
Remove the front cover (1) lifting it from the
lower part.
Connect the three red cables (3) to the positive
terminal (+) and the three black cables (4) to the
negative terminal (–) using the screws supplied.
Follow the instructions given.
Reassemble the front cover (1) inserting the two
tabs (2) in their housing correctly and pressing
the lower part till it clicks.
Charge the battery following the battery manu-
facturer’s instructions.
IMPORTANT To prevent the safety device in
the electronic circuit board from cutting in, never
start the engine until the battery is fully charged!
WARNING! Follow the battery manufac-
turer’s instructions regarding safe handling
and disposal.
3.3 FITTING THE DASHBOARD
AND STEERING WHEEL (Fig. 3.2)
Put the machine on a at surface and straighten
the front wheels.
Fit the caster (3) on the steering column (2),
making sure the plug (1) is correctly tted into
the caster seat.
Fit the dashboard cover (5) making sure all
fastenings click into their respective housings
correctly.
Fit the steering wheel (6) onto the caster (3) with
all the spokes directed towards the seat.
Fit the steering wheel fastening it with the
screws (7) supplied, in the indicated order.
Fit the steering wheel cover (8) clicking the three
fasteners into place.
7
3.4 ASSEMBLY OF THE CUTTING MEANS
ENGAGEMENT CONTROL LEVER EX-
TENSION (Fig. 3.3)
Fit the extension (1) onto the lever (2), position-
ing it so that the two grains (3) face the rear of
the machine, then tighten the two grains (3)
completely.
3.5 ASSEMBLING THE MOBILE COVER
Fit the mobile cover following instructions sup-
plied.
3.6 FITTING THE SEAT (Fig. 3.4)
Fit the seat (1) onto the plate (2) using the
screws (3).
3.7 ASSEMBLING THE GRASS CATCHER
(Fig. 3.5)
First of all assemble the frame, joining the upper
part (1), that includes the opening, to the lower
part (2) using the supplied screws and nuts (3)
in the indicated order.
Position the angle plates (4) and (5), making
sure that they are for the right (R↑) and left (L↑),
sides, and attach them to the frame using the
four self-threading screws (6).
Insert the assembled frame in the canvas cover,
making sure it is correctly positioned on the
base perimeter. Hook the plastic proles onto
the frame tubes with the aid of a screw-driver
(7).
Insert the handle (8) in the cover holes (9), fas-
ten the ensemble to the frame using the screws
provided (10) in the indicated order and com-
plete the assembly with the four front and rear
self-threading screws (11).
Last of all, fasten the reinforcement bar (12) un-
der the frame, positioning the at part facing the
canvas, using the screws and nuts provided (13)
in the indicated order.
3.8 ASSEMBLING THE SIDE PANELS OF
THE CUTTING-MEANS ASSEMBLY
(FIG. 3.6).
Assemble the two side panels right (1) and left
(2), following the assembly direction carefully
and fasten them with the screws (3) and nuts (4)
supplied.
4. CONTROLS AND INSTRUMENTS
4.1 STEERING WHEEL (Fig. 4.1 no.1)
Turns the front wheels.
4.2 THROTTLE LEVER (Fig. 4.1 no.2)
Regulates the engine’s r.p.m. The positions are
indicated on the plate showing the following
symbols:
«CHOKE» cold start
«SLOW» for minimum engine speed
«FAST» for maximum engine speed
– The «CHOKE» position enriches the mixture
so it must only be used for the time necessary
for cold starts.
– When moving from one area to another, put
the lever in a position between «SLOW» and
«FAST».
– When cutting, shift into «FAST».
4.3 PARKING BRAKE (Fig. 4.1 no.3)
This lever stops the machine from moving when
it has been parked. There are two positions:
«A» = Brake disengaged
«B» = Brake engaged
– The brake is applied by pressing the pedal
right down (4.21) and moving the lever to posi-
tion “B”. When you take your foot o the pedal
it will be blocked by the lever in the lowered
position.
– To disengage the parking brake, press the
pedal (4.21). The lever will return to position
«A».
4.4 KEY IGNITION SWITCH (Fig. 4.1 no.4)
This key operated control has four positions:
«OFF» everything is switched o;
«HEADLIGHTS ON»;
«ON» activates all parts;
«START» engages the starter motor.
– On being released at the «START» position,
the key will automatically return to «ON».
– After turning the engine on, turn the lights on
(if tted) by turning the key to the «HEAD-
LIGHTS ON» position.
– To switch them o, turn the key to «ON».
4.5 INDICATOR LAMP AND DEVICES
(Fig. 4.1 no.5)
This lamp comes on when the key (4.4) is in the
«ON» position and stays on while the machine
8
is running.
– When it ashes, it means that it is not ready to
be started (see 5.2).
– When the cutting means is engaged, the
sound warning signals that the grass catcher
is full (see 5.3.6).
4.6 CUTTING MEANS ENGAGE AND
BRAKE CONTROLS (Fig. 4.1 no.6).
This lever has two positions, as shown on the
plate:
Position «A» = Cutting means
disengaged
Position «B» = Cutting means engaged
– If you engage the cutting means without tak-
ing the necessary safety precautions, the
engine shuts down and cannot be restarted
(see 5.2).
– On disengaging the cutting means (Pos. «A»),
a brake is simultaneously activated which
stops their rotation within a few seconds.
4.7 CUTTING HEIGHT ADJUSTMENT
LEVER (Fig. 4.1 no.7)
There are seven positions for this lever, shown
as «1» to «7» on the label, which correspond to
various heights between 3 and 8 cm.
To go from one position to another, move the le-
ver sideways and put it back in one of the seven
stop notches.
4.8 REVERSE GEAR CUTTING CONSENT
PEDAL (Fig. 4.1 no.8)
By pressing and holding the pedal down, it is
possible to switch to reverse gear with the cut-
ting means engaged without causing the engine
to stop.
4.21 HYDROSTATIC TRANSMISSION
4.21.1 BRAKE PEDAL (Fig. 4.2 no.21)
This pedal works the brake on the rear
wheels.
4.21.2 SPEED CHANGE LEVER
(Fig. 4.2 no.22)
This lever is used to engage wheel drive and
adjust machine speed, when in forward and
reverse gear.
– Forward machine gear gradually increases
by moving the gear lever towards «F»; re-
verse is engaged by moving the gear lever
towards «R».
– Return to neutral position «N» occurs auto-
matically when the brake pedal is pressed
(Fig. 4.2 no.21) or can be performed manu-
ally, when the pedal is not used.
IMPORTANT The lever is blocked in the
«N» position when the parking brake is en-
gaged and cannot be moved until the parking
brake is disengaged and the brake pedal is
released.
4.21.3 HYDROSTATIC TRANSMISSION
DISENGAGEMENT LEVER
(Fig. 4.2 no.23)
This lever has two positions as shown on the
label:
«A» = Transmission engaged: for all uses,
when moving and during cutting;
«B» = Transmission disengaged: this
makes it much easier to move the
machine by hand, with the engine
turned o.
IMPORTANT To avoid damaging the trans-
mission unit, this operation must be carried
out only when the engine has stopped with
the lever (Fig. 4.22) at position «N».
4.22 MECHANICAL TRANSMISSION
4.22.1 CLUTCH / BRAKE PEDAL (Fig.
4.2 no.21.A)
This pedal has a double function during the
rst part of its travel it acts as a clutch, en-
gaging and dis-engaging drive to the wheels,
and in the second part it acts as a brake on
the rear wheels.
It is important not to take too long in using
the clutch as this can cause overheating and
damage the transmission belt.
NOTE When the machine is in movement,
keep your foot off the pedal.
4.22.2 SPEED CHANGE LEVER (Fig. 4.2
no.22.A)
This lever has seven positions for the 5 for-
ward speeds, the neutral position «N», and
reverse «R».
– To go from one speed to another, press the
pedal half way and move the lever as per the
indications on the label.
WARNING! Forward gear must only
be engaged when the machine is stopped.
9
WARNING! Reverse must only be en-
gaged when the machine is stopped.
5. OPERATING INSTRUCTIONS
5.1 SAFETY RECOMMENDATIONS
WARNING! If the machine is likely to
be used mostly on sloping ground (never
steeper than 10°), fit counterweights (sup-
plied on request (see 8.1) beneath the
cross-member of the front wheels. These
improve stability at the front and reduce the
chances of tipping over.
IMPORTANT All the references relating to
the positions of controls are those described in
chapter 4.
5.2 WHY THE SAFETY DEVICES CUT IN
The safety devices work in two ways:
– they prevent the engine from starting if all the
safety requirements have not been met;
– by stopping the engine if even just one of the
safety requirements is lacking.
a) To start the engine, it is necessary that:
– the transmission is in “neutral”;
– all the cutting means are disengaged;
– the operator is seated.
b) The engine stops when:
– the operator leaves his seat;
– the grass catcher is lifted when the cutting
means are engaged;
– the parking brake is engaged without disen-
gaging the cutting means;
– the cutting means is engaged without the
grass catcher in place;
– the parking brake is engaged without disen-
gaging the cutting means.
– the speed change is activated (see 4.22) with
the parking brake on.
5.3 PRELIMINARY OPERATIONS BEFORE
STARTING WORK
Before starting to mow, it is necessary to carry
out several checks and operations to ensure
you can work eciently and in maximum safety.
5.3.1 Seat adjustment (Fig. 5.1)
To change the seat position, loosen the four x-
ing bolts (1) and slide it along the slots.
Once you have found the right position, tighten
the four screws (1) thoroughly.
5.3.2 Tyre pressure (Fig. 5.2)
Having the right tyre pressure is the main condi-
tion for ensuring that the cutting-means assem-
bly is horizontal and mows evenly.
Unscrew the valve caps and connect a com-
pressed air line with a gauge to the valves and
adjust the pressure to the indicated values.
5.3.3 Filling with oil and fuel
NOTE The type of oil and fuel to use is given
in the engine manual
To reach the oil dipstick, turn the seat over and
open the cover underneath.
With the engine o, check the oil level. Accord-
ing to the instructions in the engine manual, this
must be between the MIN and MAX marks on
the dipstick. Fig. 5.3)
Refuel using a funnel, but do not completely ll
the tank. Fig. 5.4)
DANGER! Refuelling should be carried
out in an open or well-ventilated area with
engine stopped. Always remember that pet-
rol fumes are inflammable. DO NOT TAKE A
NAKED FLAME TO THE TANK’S OPENING
IN ORDER TO SEE THE TANK’S CONTENTS
AND DO NOT SMOKE WHEN REFUELLING.
IMPORTANT Do not drip petrol onto the plas-
tic parts to avoid ruining them. In the event of ac-
cidental leaks, rinse immediately with water. The
warranty does not cover for damage to plastic
parts of the bodywork or the engine caused by
petrol.
5.3.4 Fitting the guard at the exit
(grass catcher)
WARNING! Never use the machine with-
out having fitted the exit guard!
Lift the mobile cover (1) and hook on the grass
catcher inserting the two joint pins (2) in the
holes on the two supports (3) Fig. 5.5).
5.3.5 Checking machine safety
and eciency
1. Check that the safety devices function as de-
scribed (see 5.2).
2. Check that the brake is in perfect working
order.
3. Do not start mowing if the cutting means
vibrate or if you are unsure whether they are
sharp enough. Always remember that:
– A badly sharpened cutting means pulls at
10
the grass and causes the lawn to turn yel-
low.
– A loose cutting means causes abnormal
vibrations and can be dangerous.
WARNING! Do not use the machine if
you are unsure whether it is working safely
or efficiently. If in doubt, contact your Dealer
immediately to make the necessary checks
or repairs.
5.4 USING THE MACHINE
5.4.1 Ignition
To start the engine (Fig. 5.7):
– open the fuel stopcock (1) (if tted) accessing
it from the left rear wheel compartment;
– put the transmission into neutral («N»)
(see 4.22);
– disengage the cutting means (see 4.6);
– apply the parking brake on sloping ground;
– for a cold start, use the choke (see 4.2);
– if the engine is already warm, just put the lever
between «SLOW» and «FAST»;
– insert the ignition key and turn to «ON» to
make electrical contact, then turn to «START»
to start the engine;
– release the ignition key once the engine has
started.
When the engine has started, put the accelera-
tor in the «SLOW» position.
IMPORTANT The choke must be closed as
soon as the engine is running smoothly. Using
it when the engine is already warm can foul the
spark plugs and cause the engine to run errati-
cally.
NOTE If there are engine starting problems,
do not insist as you can risk running the battery
flat and flooding the engine. Turn the key to the
«OFF» position, wait for a few seconds and then
repeat the operation. If the malfunction persists,
refer to the engine manual and chapter «7» in
this manual.
IMPORTANT Always bear in mind that the
safety devices prevent the engine from starting
if safety requirements have not been met (see
5.2). In these cases, once the situation has been
corrected, the key must first be turned back to
«OFF» before the engine can be restarted.
5.4.2 Forward gear and riding without
mowing
When moving the machine:
– disengage the cutting means;
– bring the cutting-means assembly to the high-
est position (position «7»);
– put the accelerator control between the
«SLOW» and «FAST» positions.
Mechanical transmission
Push the pedal down as far as possible (see
4.22.1) and move the gear change lever into
1st gear (see 4.22.2).
Keep the pedal pressed down and disen-
gage the parking brake. Slowly release
the pedal which will turn from «brake» to
«clutch», thus operating the rear wheels (see
4.11).
WARNING! The pedal has to be re-
leased gradually, as a sudden engage-
ment may cause the vehicle to tip over
and the driver to lose control.
Gradually reach the desired speed using
the throttle and gear lever. To change gear,
press the clutch halfway down (see 4.22.1).
IMPORTANT Forward gear must only be
engaged when the machine has stopped.
Hydrostatic transmission:
Disengage the parking brake and release
the brake pedal (see 4.21.1).
Move the speed change lever (see 4.21.2)
to position «F» and use the lever and accel-
erator to reach the desired speed.
WARNING! Drive must be engaged
as described below (see 4.21.2) to pre-
vent sudden engagement from causing
tipping up and loss of control of the vehi-
cle, particularly on slopes.
5.4.3 Braking
Mechanical transmission
To use the brake, press the brake pedal to
the oor (see 4.22.1), after reducing speed
using the accelerator so as not to overload
the braking system.
Hydrostatic transmission
First reduce the machine’s speed by reduc-
ing the engine’s r.p.m., and then press the
brake pedal (see 4.21.1) to slow down the
machine until it stops.
11
Pressing the brake pedal also causes the speed
change lever to return to the «N» position (see
4.21.2).
5.4.4 Reverse
IMPORTANT Reverse must only be engaged
when the machine has stopped.
IMPORTANT To proceed in reverse gear with
the cutting means engaged, it is necessary to
press and hold the consent pedal down (see 4.8)
so as not to cause the engine to stop.
Mechanical transmission
Press the pedal until the machine stops and
then switch into reverse by shifting the le-
ver sideways and into position «R» (see
4.22.2). Gradually release the pedal to en-
gage the clutch and then begin moving in re-
verse.
Hydrostatic transmission:
When the machine is stopped, move the
speed change lever to the «R» position to
change to reverse gear (see 4.21.2).
5.4.5 Grass cutting (Fig. 5.8)
To start cutting:
– move the throttle to «FAST»;
– bring the cutting-means assembly to the high-
est position;
– engage the cutting means (see 4.6) only on
grass lawns; avoid engaging them on stony
ground or when the grass is very high;
– start moving forwards on the grass very
slowly and with utmost caution, as already
described;
– regulate the cutting height and speed (see
4.7) considering the conditions of the lawn
(the height, density and dampness of the
grass).
Mechanical transmission
– High and dense grass – wet lawn:
1st gear
– Average conditions grass:
2nd 3rd gear
– Low grass – dry lawn: 4th gear
NOTE The fifth gear is just a transfer gear
to be used on the flat.
Hydrostatic transmission
Speed can be adjusted according to lawn
conditions by gradually and continuously
pressing the speed adjustment lever accord-
ingly.
WARNING! When cutting on sloping
ground, the forward speed must be reduced
to ensure safe conditions (see 1C 7-8-9 +
5.5).
Whatever the conditions, always reduce the
speed if you notice a drop in engine speed – if
you travel too fast compared to the amount of
grass being cut, you will not be able to mow the
grass well.
Disengage the cutting means and raise the
cutting-means assembly as high as possible
whenever you need to get past an obstacle.
5.4.6 Emptying the grass catcher
(Fig. 5.8)
NOTE The emptying of the grass catcher can
only be done with the cutting means disengaged,
otherwise the engine stops.
Do not let the grass catcher become too full as
this may block the collection channel.
When the grass catcher is full you will hear a
warning sound; at this point:
– disengage the cutting means (see 4.6) and
the warning sound will stop;
– lower the engine speed;
– shift into neutral (N) (see 4.21, 4.22) and stop
moving forward;
– engage the parking brake on slopes;
– hold onto the rear handle and tip up the grass
catcher to empty it;
NOTE At times the audible warning may be
heard at the moment of engaging the cutting
means even when the grass catcher has been
emptied. This is due to grass-cuttings left on the
sensor of the micro-switch. To stop the signal,
remove the grass debris, disengage the cutting
means and then immediately engage it again.
5.4.7 Unblocking the collector channel
Cutting very tall or wet grass, particularly at ex-
cessively high speed, can clog up the collector
channel. If this happens proceed as follows:
– stop forward movement immediately, disen-
12
gage the cutting means and stop the engine;
– remove the grass catcher;
– remove the grass cuttings; you can reach
them from the channel discharge opening.
WARNING! This job must only be per-
formed with the engine turned off.
5.4.8 End of mowing
When you have nished mowing, disengage the
cutting means, reduce the engine speed and
ride the machine with the cutting-means assem-
bly in the highest position.
5.4.9 End of work
Stop the machine, put the accelerator lever in
the «SLOW» position and turn o the engine by
putting the ignition key into the «OFF» position.
When the engine has stopped, close the fuel
stopcock (1) (if tted) (Fig. 5.9)
WARNING! To avoid backfire, put the
accelerator in the «SLOW» position for 20
seconds before stopping the engine.
IMPORTANT To keep the battery charged,
do not leave the ignition key in the «ON» position
when the engine is not running.
5.4.10 Cleaning the machine
After each mowing session, clean the outside
of the machine, empty the grass catcher and
shake it to remove residual grass and earth.
Clean the plastic parts of the body with a damp
sponge using water and detergent, taking care
not to wet the engine, the electrical parts or the
electronic circuit board located under the dash-
board.
IMPORTANT Never use hose-nozzles or
harsh detergents for cleaning the body and en-
gine!
WARNING! Do not let debris and dried
grass accumulate in the upper part of the
cutting-means assembly in order to maintain
maximum machine efficiency and safety
levels.
After each use, clean the cutting-means as-
sembly thoroughly to remove any grass remains
or debris.
WARNING! Wear eye protection and
keep people or animals away from the sur-
rounding area when cleaning the cutting-
means assembly.
a) When washing the inside of the cutting-
means assembly and the collector channel, the
machine must be on rm ground with:
– the grass catcher tted;
– the operator seated;
– the cutting-means assembly in position «1»;
– the engine running;
– the transmission in neutral;
– the cutting means engaged.
Connect a water hose to its pipe tting (1), and
run water through it. Engage the cutting means
and allow it to run idle for a few minutes (Fig.
5.10).
Now remove the grass catcher, empty and rinse
it, then place it where it can dry quickly.
b) To clean the upper part of the cutting-
means assembly:
– lower the cutting-means assembly completely
(position «1»);
– blow a jet of compressed air to remove any
remains of grass (Fig. 5.11).
5.4.11 Storage and inactivity for long
periods
If you intend not to use the machine for a long
period (more than 1 month), disconnect the
battery cables and follow the instructions in the
engine instruction manual.
Empty the fuel tank by disconnecting the tube
(1) situated at the inlet of the fuel lter, and col-
lect the fuel in a suitable container (Fig. 5.12).
Reconnect the tube (1) making sure you position
the clamp properly.
Put the machine away in a dry, sheltered place
and preferably covered with a cloth (see 8.5).
IMPORTANT The battery must be kept in a
cool and dry place. Before a long storage period
(more than 1 month), always charge the bat-
tery, and then recharge before using again (see
6.3.3).
The next time the machine is used, check that
there are no fuel leaks from the tubes, fuel stop-
cock or carburettor.
5.4.12 Circuit board protection device
The electronic circuit board has a self-resetting
protector which breaks the circuit if there is a
fault in the electrical system. This will stop the
engine and switch o the light.
The circuit automatically resets after a few sec-
onds but the cause of the fault should be ascer-
tained and dealt with to avoid reactivating the
protection device.
13
IMPORTANT To avoid activating the protec-
tion device:
– do not invert the leads on the battery terminals;
– do not use the machine without its battery or
damage may be caused to the charge regula-
tor;
– be careful not to cause short-circuits.
5.5 USING ON SLOPES (Fig. 5.13)
Observe the indicated limits (max 10° - 17).
WARNING! Take care when beginning
forward movement on sloping ground to
prevent the risk of tipping up. Reduce the
forward speed before going on a slope, par-
ticularly downhill.
DANGER! Never switch to reverse gear
to decrease speed when going downhill:
this could cause loss of control of the ma-
chine, especially on slippery ground.
Mechanical transmission
DANGER! Never ride the machine on
slopes in neutral or with the clutch out!
Always shift into a low gear before leav-
ing the machine at a standstill and unat-
tended.
Hydrostatic transmission:
Drive down slopes with your foot o the drive
pedal (see 4.21.1) to use the braking eect
of the hydrostatic transmission when the
transmission is not engaged.
5.6 SUGGESTIONS FOR MAINTAINING
A NICE LAWN
1. To keep a lawn green and soft with a good
appearance, it should be cut regularly with-
out damaging the grass. A lawn can be com-
posed of dierent types of grass. If the lawn
is cut frequently, grass and roots grow more
vigorously, forming a solid grassy bed. If the
lawn is cut is less frequently, higher grass
and weeds start growing (clover and daisies,
etc.).
2. It is always better to cut the grass when dry.
3. The cutting means must be in good condition
and well sharpened so that the grass is cut
straight without a ragged edge that leads to
yellowing at the ends.
4. The engine must run at full speed, both to
ensure a sharp cut of the grass and to get the
necessary thrust to push the cuttings through
the collector channel.
5. The frequency of mowing should be in rela-
tion to the rate of growth of the grass, which
should not be left to grow too much between
one cut and the next.
6. During hot and dry periods, the grass should
be cut a little higher to prevent the ground
from drying out.
7. The best height of the grass on a well-kept
lawn is approx. 4-5 cm. and with one mowing,
you do not need to remove more than a third
of the total height. If the grass is very tall,
it should be cut twice in a twenty-four hour
period. The rst time with the cutting means
at maximum cutting height, possibly reducing
the cutting width and the second cut at the
height desired. Fig. 5.14)
8. The appearance of the lawn will improve if
you alternate the cutting in both directions.
Fig. 5.15)
9. If the collector system tends to get blocked
with grass, you should reduce the forward
speed as it may be too high for the condi-
tion of the grass. If the problem persists, the
probable causes are either badly sharpened
cutting means or deformed ns.
10. Be very careful when mowing near bushes
or kerbs as these could distort the horizontal po-
sition of the cutting-means assembly and dam-
age its edge as well as the cutting means.
6. MAINTENANCE
6.1 SAFETY RECOMMENDATIONS
WARNING! You must go to a special-
ized Service Centre or contact your Dealer if
the following are malfunctioning:
– the brake;
– the cutting means engage and disengage
functions,
– switching the drive to forward or reverse
gears.
6.2 ACCESSING THE ENGINE (Fig. 6.1)
Turning over the engine cover (1), you can ac-
cess the engine and all the mechanical parts
below it.
To perform this operation, you need to:
– position the machine on a at surface, move
the cutting-means assembly to the fully raised
position and place some shims (2) measuring
about 65-70 mm under the edge to support
it while you proceed with the required opera-
tions;
14
MECHANICAL TRANSMISSION
– engage the parking brake;
HYDROSTATIC TRANSMISSION
– put the drive release lever into the «EN-
GAGED» position (Fig. 4.2 no. 23), since it is
necessary for the parking brake to be disen-
gaged to ensure that the speed change lever
has enough movement;
– remove the grass catcher;
– unscrew the lever knob (3) and shift the lever to
the «R» position;
– open the access hatch (4) and unscrew the fas-
tener nut (5) using a 13 mm key;
– release the lever (6) so that the cutting-means
assembly rests on the shims and keep it
moved to the side so that no stop notches are
engaged; now grasp the bottom of the seat (7)
and tip the cover backwards.
To close it again:
– check that the collector channel (8) is securely
positioned on the support (9) resting on the
right hand side;
– move the lever (3) to the «R» position and lower
the cover (1) to the same level as the levers (3)
and (6);
– insert lever (6) and then lever (3) in their seat,
and lower the cover until it is aligned with the
fastener screw.
WARNING! With the cover (1) lowered,
check that:
– the collector channel (8) opening fits inside
the rear discharge opening (10) and is rest-
ing correctly on the support (11).
Next:
– fully tighten the fastener nut (5);
– move the lever (6) to position «7» engaging it in
the relative stop notch;
– remove the shims (2), replace the lever knob (3)
and the hatch (4).
6.3 ROUTINE MAINTENANCE
The table will help you maintain your machine’s
safety and performance. It summarises the main
interventions to be made and the frequency ap-
plicable to each of them.
The boxes at the side are for you to mark the date
or number of working hours at which the interven-
tion was made.
Operation
Hours
Completed (Date or Hours)
1. MACHINE
1.1
Cutting means positioning and sharpening
check
3)
25
1.2
Replacing cutting means
3)
100
1.3
Transmission belt check
3)
25
1.4
Transmission belt replacement
2) 3)
–
1.5
Cutting means control belt check
3)
25
1.6
Replacing the cutting means control belt
check
2) 3)
–
1.7
Check and adjustment of brake
3)
25
1.8
Drive regulation and check
3)
25
1.9
Cutting means engage and brake check
3)
25
1.10
Complete bolt and screw check 25
1.11
General lubrication
4)
25
15
Operation
Hours
Completed (Date or Hours)
2. ENGINE
1)
2.1
Replacement of the engine oil …
2.2
Air lter cleaning and check …
2.3
Air lter replacement …
2.4
Fuel lter check …
2.5
Fuel lter replacement …
2.6
Spark plug points cleaning and check …
2.7
Replace spark plug …
1)
See the engine manual for the full list and
frequency.
2)
At the rst signs of any malfunction, contact
your Dealer.
3)
The operation must be carried out by your
Dealer or a specialized Service Centre.
4)
General lubrication of all joints should also be
carried out whenever the machine is to be left
unused for a long period.
6.3.1 Engine (Fig. 6.2)
Follow all the instructions in the engine manual.
The engine oil is emptied using the supplied sy-
ringe, after unscrewing the cap (1).
Fit a small pipe (2 onto the syringe (3), push
the small pipe as far as possible into the hole,
then suck all the oil out; please remember that
this operation has to be repeated a few times to
empty it completely.
6.3.2 Rear axle
This is a sealed single unit that does not require
maintenance. It is permanently lubricated and
its lubricant does not need changing or topping
up.
6.3.3 Battery (Fig. 6.3)
To ensure long life to the battery it is essential to
keep it carefully maintained.
The machine battery must always be charged:
– before using the machine for the rst time
after purchase;
– before leaving the machine disused for a long
period;
– before starting up the machine after a pro-
longed period of inactivity.
Carefully read and observe the battery recharg-
ing instructions in the booklet provided with the
battery. Failure in following the procedure or in
charging the battery could permanently damage
the battery elements.
A at battery must be recharged as soon as
possible.
IMPORTANT Recharging must be done us-
ing a battery charger at constant voltage. Other
recharging systems can irreversibly damage the
battery.
The machine comes with a connector (1) for re-
charging; this is connected to the corresponding
connector for the special maintenance battery-
charger supplied (if included) or available on
request (see 8.2).
IMPORTANT This connector must only be
used for connection to the maintenance battery-
charger indicated by the Manufacturer. For its
use:
– follow the indications given in the relative in-
structions manual;
– follow the instructions in the battery manual.
6.3.4 Greasing (Fig. 6.4)
Every 100 operating hours, grease:
– the steering pins, using the two grease guns
(1);
– the progress control lever joint using the
grease gun (2) accessible from the hatch
placed at the bottom of the seat.
6.4 INTERVENTIONS ON THE MACHINE
6.4.1 Aligning the cutting-means
assembly (Fig. 6.5)
The cutting-means assembly should be prop-
erly adjusted to obtain an evenly mown lawn.
16
If mowing is uneven, check the tyre pressure.
If this is not sucient to achieve an even cut,
please contact your Dealer to adjust the align-
ment of the cutting-means assembly.
6.4.2 Replacing the wheels (Fig. 6.6)
Stop the machine on at ground and put a block
under a load-bearing part of the frame on the
side that the wheel is to be changed.
The wheels are held by a snap ring (1) which
can be removed with a screwdriver.
NOTE If you have to replace one or both rear
wheels, make sure that any differences in their
external diameter does not exceed 8-10 mm; on
the contrary, you must adjust the cutting-means
assembly alignment to prevent uneven mowing.
IMPORTANT Before remounting the wheel,
apply grease to the axle. Put the snap ring (1)
and shoulder washer (2) back in place.
6.4.3 Repairing or replacing tyres
All puncture repairs or replacements will have to
be carried out by a tyre repair expert in accord-
ance with the methods for the kind of tyre used.
6.4.4 Replacing a fuse (Fig. 6.7)
The machine is tted with fuses (1) with dierent
capacities and functions. Specically:
– 10 A fuse = protects the main and power cir-
cuits of the electronic circuit board. When it
blows, the machine stops and the dashboard
light switches o.
– 25 A fuse = protects the battery recharge cir-
cuit. When it blows, the battery gradually runs
down and the machine will have problems
starting.
With Honda engine
– 10 A fuse = protects the main and pow-
er circuits of the electronic circuit board.
When it blows, the machine stops and the
dashboard light switches o.
– 25 A fuse = protects the battery recharge
circuit. When it blows, the battery gradu-
ally runs out and the machine will have
problems starting.
– T6.3 A (delayed) fuse (2) = protects the
main and power circuits of the electronic
circuit board. When it blows, the machine
stops and the dashboard light switches o.
The fuse capacity is indicated on the fuse.
IMPORTANT A blown fuse must always be
replaced by one of the same type and ampere
rating, and never with one of another rating.
If you are unable to understand why it has
blown, contact Your Dealer.
6.4.5 Replacing bulb (if tted) (Fig. 6.8)
The bulb (18W) has a bayonet tting and is in-
stalled in the bulb holder which can be taken out
by turning it anti-clockwise with pliers.
6.4.6 Removing, replacing and
reassembling of cutting means
WARNING! Always wear strong protec-
tive gloves to handle the cutting means.
WARNING! Always replace damaged or
bent cutting means; never attempt to repair
them! ALWAYS USE ORIGINAL CUTTING
MEANS!
Only cutting means bearing the code indicated
in the table on page ii must be used on this ma-
chine.
Given product evolution, the above mentioned
cutting means may be replaced in time with oth-
ers having similar interchangeable and operat-
ing safety features.
17
7. TROUBLESHOOTING
PROBLEM LIKELY CAUSE SOLUTION
1. With the key on «ON», the light
stays o
The safety device of the electronic
circuit board has cut in due to:
– badly connected battery
– battery terminals crossed
– badly earthed
– at battery
– blown fuse
– wet circuit board
Turn the ignition key to the «STOP»
position and look for the cause of
the problem:
– check connections (see 3.2)
– check connections (see 3.2)
– check connections (see 3.2)
– recharge the battery (see 6.3.3)
– replace the fuse (10 A) (see 6.4.4)
– dry using luke warm air
2. With the ignition key turned to
«START» the light ashes and
the starter motor does not run
– starting conditions have not
been met
– check that all starting conditions
are met (see 5.2.a)
3. With the key on «START» the
light comes on but the starter
motor does not run
– insuciently charged battery
– battery charger fuse blown
– malfunction on the starter relay
– recharge the battery (see 6.3.3)
– replace the fuse (25 A)
(see 6.4.4)
– contact your Dealer
4. With the ignition key turned to
«START» the starter motor runs
but the engine does not start
– insuciently charged battery
– faulty fuel supply
– faulty ignition
– recharge the battery (see 6.3.3)
– check the level in the tank
(see 5.3.3)
– open the fuel stopcock (if tted)
(see 5.4.1)
– check the fuel lter
– check that spark plug cap is
securely tted
– check that the electrodes are
clean and have the correct gap
between them
5. Starting is dicult or the engine
runs erratically
– faulty carburetion – clean or replace the air lter
– ush out the oat chamber
– empty the fuel tank and rell with
fresh fuel
– check and replace the fuel lter if
necessary
6. Weak engine performance
during cutting
– forward speed too high in relation
to cutting height
– reduce the forward speed and/or
raise the cutting height
(see 5.4.5)
7. The engine stops while working
and the lamp ashes
The safety device of the electronic
circuit board has cut in due to:
– the safety devices have cut in
Turn the ignition key to «STOP»
and look for the cause of the
problem:
– check that all starting conditions
are met (see 5.2.b)
8. The engine stops and the light
goes o
The safety device of the electronic
circuit board has cut in due to:
– at battery
– overvoltage caused by the
charge regulator
– badly connected battery
(poor contact)
Turn the ignition key to «STOP»
and look for the cause of the
problem:
– recharge the battery (see 6.3.3)
– contact a Licensed Service
Centre
– check battery connections
(see 3.2)
9. The engine stops but the light
stays on
– problems in the engine – contact a Licensed Service
Centre
10. The cutting means do not
engage or do not stop promptly
when they are disengaged
– problems with the engagement
mechanism
– contact your Dealer
18
PROBLEM LIKELY CAUSE SOLUTION
11. Uneven mowing and poor grass
collection
– cutting-means assembly is not
parallel to the ground
– inecient cutting means;
– forward speed too high
compared to the height of grass
being cut
– collector channel is blocked
– check the tyre pressure
(see 5.3.2)
– reinstate the alignment of the
cutting-means assembly in
relation to the ground (see 6.4.1)
– contact your Dealer
– reduce the forward speed and/
or raise the cutting-means
assembly (see 5.4.5)
– wait for the grass to dry
– remove the grass catcher and
empty the collector channel
(see 5.4.7)
12. Unusual vibrations while
working
– cutting-means assembly is full
of grass
– the cutting means are
unbalanced or loose
– loose bolts and screws
– clean the cutting means
assembly (see 5.4.10)
– contact your Dealer
– check and tighten all the engine
and frame bolts
13. Uncertain or ineective braking – the brake is not adjusted
correctly
– contact your Dealer
14. Erratic forward movement,
poor drive when going uphill or
if the machine has a tendency
to rear up
– problems with the belt or the
engagement device
– contact your Dealer
15. With the engine running, the
machine does not move when
the drive pedal is pressed
– release lever in position «B» – move it to position «A» (see 4.33)
16. The machine starts to vibrate
abnormally
– damaged or loose parts – stop the machine and
disconnect the spark plug cable
– inspect for damage
– check for and tighten any loose
parts.
– have all checks, repair work and
replacements carried out by a
specialized Centre only
If problems persist after having performed the above operations, contact your dealer.
WARNING! Do not take on complicated repair work without the necessary equipment and
technical knowledge. The guarantee is automatically revoked and the manufacturer declines
all responsibility for any poorly effected repairs.
8. ATTACHMENTS
8.1
- MAINTENANCE BATTERY CHARGER
(Fig. 8.1 nr. 41)
This keeps the battery in good working order
when the machine is in storage, guaranteeing
an optimum level of charge and longer battery
life.
- MULCHING” KIT (Fig. 8.1 nr. 42)
It chops the grass cuttings nely and leaves
them on the lawn, instead of collecting them in
the grass catcher.
- CLOTH COVER (Fig. 8.1 nr. 43)
Protects the machine from dust when not in use.
doc_base r.15 – RO-FM-P_0
DICHIARAZIONE CE DI CONFORMITÁ
(Istruzioni Originali)
(Direttiva Macchine 2006/42/CE, Allegato II, parte A)
1. La Società: ST. S.p.A. – Via del Lavoro, 6 – 31033 Castelfranco Veneto (TV) – Italy
2. Dichiara sotto la propria responsabilità, che la macchina: Tosaerba con conducente a bordo seduto / taglio erba
a) Tipo / Modello Base
F 72 FL
b) Mese/Anno di costruzione
c) Matricola
d) Motore
a scoppio
3. É conforme alle specifiche delle direttive:
• MD: 2006/42/EC
e) Ente Certificatore: /
f) Esame CE del tipo: /
• OND: 2000/14/EC, ANNEX VI - 2005/88/EC
D. Lgs. 262/2002, ANNEX VI, proc. 1 (Italy)
e) Ente Certificatore: N°0197–TÜV Rheinland LGA Products GmbH
Tillystrasse 2, 90431 Nürnberg – Germany
• EMCD: 2014/30/EU
• RoHS II: 2011/65/EU - 2015/863/EU
4. Riferimento alle Norme armonizzate:
EN ISO 5395-1:2013+A1:2018
EN ISO 5395-3:2013+A1:2017+A2:2018
EN 55012:2007+A1:2009
EN ISO 14982:2009
EN 50581:2012
g) Livello di potenza sonora misurato
99
dB(A)
h) Livello di potenza sonora garantito
100
dB(A)
i) Ampiezza di taglio
71
cm
n) Persona autorizzata a costituire il Fascicolo Tecnico: ST. S.p.A.
Via del Lavoro, 6
31033 Castelfranco Veneto (TV)- Italia
o) Castelfranco V.to, 01.09.2019 CEO Stiga Group
Sean Robinson
171512689_10
FR (
Traduction de la notice originale)
Déclaration CE de Conformité
(Directive Machines 2006/42/CE, Annexe II, partie
A)
1. La Société
2. Déclare sous sa propre responsabilité que la
machine : Tondeuse à gazon à conducteur
assis/ coupe du gazon
a) Type / Modèle de Base
b) Mois / Année de construction
c) Série
d) Moteur: moteur essence
3. Est conforme aux prescriptions des
directives :
e) Organisme de certification
f) Examen CE du Type
4. Renvoi aux Normes harmonisées
g) Niveau de puissance sonore mesuré
h) Niveau de puissance sonore garanti
i) Largeur de coupe
n) Personne habilitée à établir le Dossier
Technique :
o) Lieu et Date
EN (
Translation of the original instruction)
EC Declaration of Conformity
(Machine Directive 2006/42/EC, Annex II, part A)
1. The Company
2. Herby declares under its own responsibility
that the machine: ride-on lawnmower with
seated operator/ Grass cutting
a) Type / Base Model
b) Month / Year of manufacture
c) Serial number
d) Motor: petrol
3. Conforms to directive specifications:
e) Certifying body
f) EC examination of Type
4. Reference to harmonised Standards
g) Sound power level measured
h) Sound power level guaranteed
i) Range of cut
n) Person authorised to create the Technical
Folder:
o) Place and Date
DE (
Übersetzung der Originalbetriebsanleitung
)
EG-Konformitätserklärung
(Maschinenrichtlinie 2006/42/EG, Anhang II, Teil
A)
1. Die Gesellschaft
2. Erklärt auf eigene Verantwortung, dass die
Maschine: Aufsitzmäher / Rasenschnitt
a) Typ / Basismodell
b) Monat / Baujahr
c) Seriennummer
d) Motor: Verbrennungsmotor
3. Den Anforderungen der folgenden Richtlinien
entspricht:
e) Zertifizierungsstelle
f) EG-Baumusterprüfung
4. Bezugnahme auf die harmonisierten Normen
g) Gemessener Schallleistungspegel
h) Garantierter Schallleistungspegel
i) Schnittbreite
n) Zur Verfassung der technischen Unterlagen
befugte Person:
o) Ort und Datum
NL
(
Vertaling van de oorspronkelijke gebruiksaanwijzing)
EG-verklaring van overeenstemming
(Richtlijn Machines 2006/42/CE, Bijlage II, deel A)
1. Het bedrijf
2. Verklaart onder zijn eigen
verantwoordelijkheid dat de machine:
Grasmaaier met zittende bediener / grasmaaier
a) Type / Basismodel
b) Maand / Bouwjaar
c) Serienummer
d) Motor: benzinemotor
3. Voldoet aan de specificaties van de
richtlijnen:
e) Certificatie-instituut
f) EG-onderzoek van het Type
4. Verwijzing naar de Geharmoniseerde normen
g) Gemeten niveau van geluidsvermogen
h) Gegarandeerd niveau van geluidsvermogen
i) Snijbreedte
n) Bevoegd persoon voor het opstellen van het
Technisch Dossier
o) Plaats en Datum
ES
(Traducción del Manual Original)
Declaración de Conformidad CE
(Directiva Máquinas 2006/42/CE, Anexo II, parte
A)
1. La Empresa
2. Declara bajo su propia responsabilidad que la
máquina: Cortadora de pasto con conductor
sentado/ Corte hierba
a) Tipo / Modelo Base
b) Mes / Año de fabricación
c) Matrícula
d) Motor: motor de explosión
3. Cumple con las especificaciones de las
directivas:
e) Ente certificador
f) Examen CE del Tipo
4. Referencia a las Normas armonizadas
g) Nivel de potencia sonora medido
h) Nivel de potencia sonora garantizado
i) Amplitud de corte
n) Persona autorizada a realizar el Manual
Técnico:
o) Lugar y Fecha
PT
(Tradução do manual original)
Declaração CE de Conformidade
(Diretiva de Máquinas 2006/42/CE, Anexo II,
parte A)
1. A Empresa
2. Declara sob a própria responsabilidade que a
máquina: Corta-relvas para operador sentado/
corte da relva
a) Tipo / Modelo Base
b) Mês / Ano de fabrico
c) Matrícula
d) Motor: motor a explosão
3. É conforme às especificações das diretivas:
e) Órgão certificador
f) Exame CE do Tipo
4. Referência às Normas harmonizadas
g) Nível medido de potência sonora
h) Nível garantido de potência sonora
i) Amplitude de corte
n) Pessoa autorizada a elaborar o Caderno
Técnico
o) Local e Data
EL (
Μετάφραση του πρωτοτύπου των οδηγιών
χρήσης)
EK-Δήλωση συμμόρφωσης
(Οδηγία Μηχανών 2006/42/CE, Παράρτημα II,
μέρος A)
1. Η Εταιρία
2. Δηλώνει υπεύθυνα ότι η μηχανή:
Χλοοκοπτικό τρακτέρ με εποχούμενο χειριστή/
κοπή της χλόης
a) Τύπος / Βασικό Μοντέλο
b) Μήνας / Έτος κατασκευής
c) Αριθμός μητρώου
d) Κινητήρας: κινητήρας εσωτερικής ανάφλεξης
3. Συμμορφώνεται με τις προδιαγραφές της
οδηγίας:
e) Οργανισμός πιστοποίησης
f) Εξέταση CE του Τύπου
4. Αναφορά στους Κανονισμούς εναρμόνισης
g) Στάθμη μέτρησης ακουστικής ισχύος
h) Στάθμη εγγυημένης ακουστικής ισχύος
i) Εύρος κοπής
n) Εξουσιοδοτημένο άτομο για την κατάρτιση
του Τεχνικού Φυλλαδίου:
o) Τόπος και Χρόνος
TR (Orijinal Talimatların Tercümesi)
AT Uygunluk Beyanı
(2006/42/CE Makine Direktifi, Ek II, bölüm A)
1. Şirket
2. Şahsi sorumluluğu altında aşağıdaki
makinenin: Oturan sürücülü çim biçme makinesi
/ çim kesimi
a) Tip / Standart model
b) Üretimin Ay / yıl
c) Sicil numarası
d) Motor: patlamalı motor
3. Aşağıdaki direktiflerin özelliklerine uygun
olduğunu beyan etmektedir:
e) Sertifikalandıran kurum
f) ... Tipi CE incelemesi
4. Harmonize standartlara atıf
g) Ölçülen ses güç seviyesi
h) Garanti edilen ses güç seviyesi
i) Kesim genişliği
n) Teknik Dosyayı oluşturmaya yetkili kişi:
o) Yer ve Tarih
MK (Превод на оригиналните упатства)
Декларација за усогласеност со ЕУ
(Директива за машини 2006/42/CE, Анекс II,
дел A)
1. Компанијата
2. изјавува со целосна лична одговорност
дека следната машина: Тревокосачка со
седнат управувач / косење трева
а) Тип / основен модел
б) Месец / Година на производство
в) етикета
г) мотор: мотор со согорување
3. Усогласено со спецификациите според
директивите:
д) тело за сертификација
ѓ) тест СЕ за типот
4. Референци за усогласени нормативи
е) Акустички притисок
ж) измерено ниво на звучна моќност
з) Ниво на гарантирана звучна моќност
н) овластено лице за составување на
Техничката брошура
o) место и датум
EXAMPLE
doc_base r. 15 – RO-FM-P_0
NO (Oversettelse av orginal bruksanvisning)
EF- Samsvarserklæring
(Maskindirektiv 2006/42/EF, Vedlegg II, del A)
1. Firmaet
2. Erklærer på eget ansvar at maskinen:
Sittegressklipper / gressklipping
a) Type / Modell
b) Måned / Byggeår
c) Serienummer
d) Motor: forbrenningsmotor
3. Oppfyller kravene i direktivene:
e) Sertifiseringsorgan
f) EF-typeprøving
4. Henvisning til harmoniserte standarder
g) Målt lydeffektnivå
h) Garantert lydeffektnivå
i) Klippebredde
n) Person som har fullmakt til å utferdige teknisk
dokumentasjon:
o) Sted og dato
SV (Översättning av bruksanvisning i original)
EG-försäkran om överensstämmelse
(Maskindirektiv 2006/42//EG, bilaga II, de la)
1. Företaget
2. Försäkrar på eget ansvar att maskinen
Åkgräsklippare / gräsklippning
a) Typ / Basmodell
b) Månad / Tillverkningsår
c) Serienummer
d) Motor: förbränningsmotor
3. Överensstämmer med föreskrifterna i
direktivet
e) Intygsorgan_ Anmält organ
f) EG typgodkännande
4. Referens till harmoniserade standarder
g) Uppmätt ljudeffektnivå
h) Garanterad ljudeffektnivå
i) Skärbredd
n) Auktoriserad person för upprättandet av den
tekniska dokumentationen:
o) Ort och datum
DA (Oversættelse af den originale brugsanvisning)
EF-overensstemmelseserklæring
(Maskindirektiv 2006/42/EF, bilag II, del A)
1. Firmaet
2. Erklærer på eget ansvar, at maskinen:
Havetraktor/ klipning af græsset a) Type / Model
b) Måned / Konstruktionsår
c) Serienummer
d) Motor: forbrændingsmotor
3. Er i overensstemmelse med specifikationerne
ifølge direktiverne:
e) Certificeringsorgan
f) EF-typeafprøvning
4. Henvisning til harmoniserede standarder
g) Målt lydeffektniveau
h) Garanteret lydeffektniveau
i) Klippebredde
n) Person, der har bemyndigelse til at udarbejde
det tekniske dossier:
o) Sted og dato
FI (
Alkuperäisten ohjeiden käännös)
EY-VAATIMUSTENMUKAISUUSVAKUUTUS
(Konedirektiivi 2006/42/EY, Liite II, osa A)
1. Yritys
2. Vakuuttaa omalla vastuullaan, että kone:
Päältäajettava ruohonleikkuri / ruohonleikkuu
a) Tyyppi / Perusmalli
b) Kuukausi /Valmistusvuosi
c) Sarjanumero
d) Moottori : räjähdysmoottori
3. On yhdenmukainen seuraavien direktiivien
asettamien vaatimusten kanssa:
e) Sertifiointiyritys
f) EY-tyyppitarkastus
4. Viittaus harmonisoituihin standardeihin
g) Mitattu äänitehotaso
h) Taattu äänitehotaso
i) Leikkuuleveys
n) Teknisten asiakirjojen laatimiseen valtuutettu
henkilö:
o) Paikka ja päivämäärä
CS (
Překlad původního návodu k používání)
ES – Prohlášení o shodě
(Směrnice o Strojních zařízeních 2006/42/ES,
Příloha II, část A)
1. Společnost
2. Prohlašuje na vlastní odpovědnost, že stroj:
Sekačka se sedící obsluhou/ sekačka na trávu
a) Typ / Základní model
b) Měsíc / Rok výroby
c) Výrobní číslo
d) Motor: spalovací motor
3. Je ve shodě s nařízeními směrnic:
e) Certifikační orgán
f) ES zkouška Typu
4. Odkazy na Harmonizované normy
g) Naměřená úroveň akustického výkonu
h) Zaručená úroveň akustického výkonu
i) Šířka řezání
n) Osoba autorizovaná pro vytvoření
Technického spisu:
o) Místo a Datum
PL (
Tłumaczenie instrukcji oryginalnej)
Deklaracja zgodności WE
(Dyrektywa maszynowa 2006/42/WE, Załącznik II,
część A)
1. Spółka
2. Oświadcza na własną odpowiedzialność, że
maszyna: Kosiarka z operatorem jadącym, w
pozycji siedzącej na maszynie/ cięcie trawy
a) Typ / Model podstawowy
b) Miesiąc / Rok produkcji
c) Numer seryjny
d) Silnik: silnik o zapłonie iskrowym
3. Spełnia podstawowe wymogi następujących
Dyrektyw:
e) Jednostka certyfikująca
f) Badanie typu WE
4. Odniesienie do Norm zharmonizowanych
g) Zmierzony poziom mocy akustycznej
h) Gwarantowany poziom mocy akustycznej
i) Szerokość cięcia
n) Osoba upoważniona do zredagowania
Dokumentacji technicznej:
o) Miejscowość i data
HU (
Eredeti használati utasítás fordítása)
EK-megfelelőségi nyilatkozata
(2006/42/EK gépirányelv, II. melléklet "A" rész)
1. Alulírott Vállalat
2. Felelősségének teljes tudatában kijelenti,
hogy az alábbi gép: Vezetőüléses fűnyírógép/
fűnyírás
a) Típus / Alaptípus
b) Hónap / Gyártás éve
c) Gyártási szám
d) Motor: robbanómotor
3. Megfelel az alábbi irányelvek előírásainak:
e) Tanúsító szerv
f) CE vizsgálat típusa
4. Hivatkozás a harmonizált szabványokra
g) Mért zajteljesítmény szint
h) Garantált zajteljesítmény szint
i) Vágási szélesség
n) Műszaki Dosszié szerkesztésére
felhatalmazott személy:
o) Helye és ideje
RU (
Перевод оригинальных инструкций)
Декларация соответствия нормам ЕС
(Директива о машинном оборудовании
2006/42/ЕС, Приложение II, часть A)
1. Предприятие
2. Заявляет под собственную
ответственность, что машина: Ездовая
косилка с водителем / стрижка газона
a) Тип / Базовая модель
b) Месяц /Год изготовления
c) Паспорт
d) Двигатель: двигатель внутреннего
сгорания
3. Соответствует требованиям следующих
директив:
e) Сертифицирующий орган
f) Испытание ЕС типового образца
4. Ссылки на гармонизированные нормы
g) Измеренный уровень звуковой мощности
h) Гарантируемый уровень звуковой
мощности
i) Амплитуда кошения
n) Лицо, уполномоченное на
подготовку
технической документации:
o) Место и дата
HR (
Prijevod originalnih uputa)
EK Izjava o sukladnosti
(Direktiva 2006/42/EZ o strojevima, dodatak II,
dio A)
1. Tvrtka:
2. pod vlastitom odgovornošću izjavljuje da je
stroj: Sjedeća kosilica trave s operaterom/
košenje trave
a) Vrsta / Osnovni model
b) Mjesec / Godina proizvodnje
c) Matični broj
d) Motor: motor s unutarnjim izgaranjem
3. sukladan s temeljnim zahtjevima direktiva:
e) Certifikacijsko tijelo
f) Tipsko ispitivanje EZ
4. Primijenjene su slijedeće harmonizirane
norme:
g) Izmjerena razina zvučne snage
h) Zajamčena razina zvučne snage
i) Širina rezanja
n) Osoba ovlaštena za pravljenje Tehničke
datoteke:
o) Mjesto i datum
SL (Prevod izvirnih navodil)
ES izjava o skladnosti
(Direktiva 2006/42/ES) , priloga II, del A)
1. Družba
2. pod lastno odgovornostjo izjavlja, da je stroj:
Traktorska kosilnica/ košnja trave
a) Tip / osnovni model
b) Mesec /Leto izdelave
c) Serijska številka
d) Motor: motor z notranjim izgorevanjem
3. Skladen je z določili direktiv :
e) Ustanova, ki izda potrdilo
f) ES pregled tipa
4. Sklicevanje na usklajene predpise
g) Izmerjen nivo zvočne moči
h) Zagotovljen nivo zvočne moči
i) Obseg košnje
n) Oseba, pooblaščena za sestavo tehnične
knjižice:
o) Kraj in datum
BS (Prijevod originalnih uputa)
EZ izjava o sukladnosti
(Direktiva o mašinama 2006/42/EZ, Prilog II, deo
A)
1. Firma
2. Daje izjavu pod vlastitom odgovornošću da je
mašina: Traktorska kosilica (traktorčić) /
Košenje trave
a) Tip / Osnovni model
b) Mjesec / Godina proizvodnje
c) Serijski broj
d) Motor: motor s unutrašnjim izgaranjem
3. sukladna s osnovnim zahtjevima direktive:
e) Certifikaciono tijelo
f) EZ ispitivanje tipa
4. Pozivanje na usklađene norme
g) Izmjereni nivo zvučne snage
h) Garantovani nivo zvučne snage
i) Širina košenja
n) Osoba ovlaštena za izradu tehničke brošure:
o) Mjesto i datum
SK (Preklad pôvodného návodu na použitie)
ES vyhlásenie o zhode
(Smernica o Strojných zariadeniach 2006/42/ES,
Príloha II, časť A)
1. Spoločnosť
2. Vyhlasuje na vlastnú zodpovednosť, že stroj:
Kosačka so sediacou obsluhou/ kosačka na
trávu
a) Typ / Základný model
b) Mesiac / Rok výroby
c) Výrobné číslo
d) Motor: spaľovací motor
3. Je v zhode s nariadeniami smerníc:
e) Certifikačný orgán
f) Skúška typu ES
4. Odkaz na Harmonizované normy
g) Nameraná úroveň akustického výkonu
h) Zaručená úroveň akustického výkonu
i) Šírka kosenia
j) Čistý inštalovaný výkon
n) Osoba autorizovaná na vytvorenie
Technického spisu:
o) Miesto a Dátum
RO (
Traducerea manualului fabricantului)
CE -Declaratie de Conformitate
(Directiva Maşini 2006/42/CE, Anexa II, partea A)
1. Societatea
2. Declară pe propria răspundere că maşina:
Mașină de tuns iarba cu șofer la volan/ tăiat
iarba
a) Tip / Model de bază
b) Luna /Anul de fabricație
c) Număr de serie
d) Motor: motor cu combustie
3. Este în conformitate cu specificaţiile
directivelor:
e) Organism de certificare
f) Examinare CE de Tip
4. Referinţă la Standardele armonizate
g) Nivel de putere sonoră măsurat
h) Nivel de putere sonoră garantat
i) Lăţimea de tăiere
n) Persoană autorizată să întocmească Dosarul
Tehnic
o) Locul şi Data
LT (
Originalių instrukcijų vertimas)
EB atitikties deklaracija
(Mašinų direktyva 2006/42/CE, Priedas II, dalis A)
1. Bendrovė
2. Prisiima atsakomybę, kad įrenginys: Balninė
vejapjovė su sėdinčiu operatoriumi / žolės
pjovimas
a) Tipas / Bazinis Modelis
b) Mėnuo / Pagaminimo metai
c) Serijos numeris
d) Variklis: vidaus degimo variklis
3. Atitinka direktyvose pateiktas specifikacijas:
e) Sertifikavimo įstaiga
f) CE tipo tyrimas
4. Nuoroda į suderintas Normas
g) Išmatuotas garso galios lygis
h) Užtikrinamas garso galios lygis
i) Pjovimo plotis
n) Autorizuotas asmuo sudaryti Techninę
Dokumentaciją:
o) Vieta ir Data
LV (
Instrukciju tulkojums no oriģinālvalodas)
EK atbilstības deklarācija
(Direktīva 2006/42/EK par mašīnām, pielikums II,
daļa A)
1. Uzņēmums
2. Uzņemoties par to pilnu atbildību, paziņo, ka
mašīna: Sēžot vadāma zālienu pļaujmašīna/
zāles pļaušana
a) Tips / Bāzes modelis
b) Mēnesis / Ražošanas gads
c) Sērijas numurs
d) Motors: iekšdedzes motors
3. Atbilst šādu direktīvu prasībām:
e) Sertifikācijas iestāde
f) CE tipveida pārbaude
4. Atsauce uz harmonizētiem standartiem
g) Izmērītais skaņas intensitātes līmenis
h) Garantētais skaņas intensitātes līmenis
i) Pļaušanas platums
n) Pilnvarotais darbinieks, kas sagatavoja
tehnisko dokumentāciju:
o) Vieta un datums
SR (
Prevod originalnih uputstvaI)
EC deklaracija o usaglašenosti
(Direktiva o mašinama 2006/42/EC, Prilog II, deo
A)
1. Preduzeće
2. Daje izjavu pod vlastitom odgovornošću da je
mašina: Traktorska kosačica (traktorčić)/
košenje trave
a) Tip / Osnovni model
b) Mesec /Godina proizvodnje
c) Serijski broj
d) Motor: motor s unutrašnjim sagorevanjem
3. u skladu s osnovnim zahtevima direktiva:
e) Sertifikaciono telo
f) EC ispitivanje tipa:
4. Pozivanje na usklađene norme
g) Izmereni nivo zvučne snage
h) Garantovani nivo zvučne snage
i) Širina košenja.....................
n) Osoba ovlašćena za sastavljanje tehničke
brošure
o) Mesto i datum
BG (
Превод на оригиналните инструкции)
ЕО декларация за съответствие
(Директива Машини 2006/42/ЕО, Приложение
II, част А)
1. Дружеството
2. На собствена отговорност декларира, че
машината: Косачка със седнал водач/ рязане
на трева
а) Вид / Базисен модел
б) Месец / година на производство
в) Сериен номер
г) Мотор: мотор с вътрешно горене
3. Е в съответствие със спецификата на
директивите:
д) Сертифициращ орган
е) ЕО изследване на вида
4. Базирано на хармонизираните норми
ж) Ниво на измерена акустична мощност
и) Гарантирано ниво на акустична мощност
й) Широчина на косене
р) Лице, упълномощено да състави
Техническата Документация:
o) Място и дата
ET (
Algupärase kasutusjuhendi tõlge)
EÜ vastavusdeklaratsioon
(Masinadirektiiv 2006/42/EÜ, Lisa II, osa A)
1. Firma
2. Kinnitab omal vastutusel, et masin: Istuva
juhiga muruniitja / muruniitja
a) Tüüp / Põhimudel
b) Kuu aega / Tootmisaasta
c) Matrikkel
d) Mootor: Sisepõlemismootor
3. Vastab direktiivide nõuetele:
e) Kinnitav asutus
f) EÜ tüübihindamine
4. Viide ühtlustatud standarditele
g) Mõõdetud helivõimsuse tase
h) Garanteeritud helivõimsuse tase
i) Lõikelaius
n) Tehnilise Lehe autoriseeritud koostaja:
o) Koht ja Kuupäev
doc_base r. 15 – RO-FM-P_0
DICHIARAZIONE CE DI CONFORMITÁ
(Istruzioni Originali)
(Direttiva Macchine 2006/42/CE, Allegato II, parte A)
1. La Società: ST. S.p.A. – Via del Lavoro, 6 – 31033 Castelfranco Veneto (TV) – Italy
2. Dichiara sotto la propria responsabilità, che la macchina: Tosaerba con conducente a bordo seduto / taglio erba
a) Tipo / Modello Base
F 72 FL
b) Mese/Anno di costruzione
c) Matricola
d) Motore
a scoppio
3. É conforme alle specifiche delle direttive:
• MD: 2006/42/EC
e) Ente Certificatore: /
f) Esame CE del tipo: /
• OND: 2000/14/EC, ANNEX VI - 2005/88/EC
D. Lgs. 262/2002, ANNEX VI, proc. 1 (Italy)
e) Ente Certificatore: N°0197–TÜV Rheinland LGA Products GmbH
Tillystrasse 2, 90431 Nürnberg – Germany
• EMCD: 2014/30/EU
• RoHS II: 2011/65/EU - 2015/863/EU
4. Riferimento alle Norme armonizzate:
EN ISO 5395-1:2013+A1:2018
EN ISO 5395-3:2013+A1:2017+A2:2018
EN 55012:2007+A1:2009
EN ISO 14982:2009
EN 50581:2012
g) Livello di potenza sonora misurato
99
dB(A)
h) Livello di potenza sonora garantito
100
dB(A)
i) Ampiezza di taglio
71
cm
n) Persona autorizzata a costituire il Fascicolo Tecnico: ST. S.p.A.
Via del Lavoro, 6
31033 Castelfranco Veneto (TV)- Italia
o) Castelfranco V.to, 01.09.2019 CEO Stiga Group
Sean Robinson
171512689_10
FR (
Traduction de la notice originale)
Déclaration CE de Conformité
(Directive Machines 2006/42/CE, Annexe II, partie
A)
1. La Société
2. Déclare sous sa propre responsabilité que la
machine : Tondeuse à gazon à conducteur
assis/ coupe du gazon
a) Type / Modèle de Base
b) Mois / Année de construction
c) Série
d) Moteur: moteur essence
3. Est conforme aux prescriptions des
directives :
e) Organisme de certification
f) Examen CE du Type
4. Renvoi aux Normes harmonisées
g) Niveau de puissance sonore mesuré
h) Niveau de puissance sonore garanti
i) Largeur de coupe
n) Personne habilitée à établir le Dossier
Technique :
o) Lieu et Date
EN (
Translation of the original instruction)
EC Declaration of Conformity
(Machine Directive 2006/42/EC, Annex II, part A)
1. The Company
2. Herby declares under its own responsibility
that the machine: ride-on lawnmower with
seated operator/ Grass cutting
a) Type / Base Model
b) Month / Year of manufacture
c) Serial number
d) Motor: petrol
3. Conforms to directive specifications:
e) Certifying body
f) EC examination of Type
4. Reference to harmonised Standards
g) Sound power level measured
h) Sound power level guaranteed
i) Range of cut
n) Person authorised to create the Technical
Folder:
o) Place and Date
DE (
Übersetzung der Originalbetriebsanleitung
)
EG-Konformitätserklärung
(Maschinenrichtlinie 2006/42/EG, Anhang II, Teil
A)
1. Die Gesellschaft
2. Erklärt auf eigene Verantwortung, dass die
Maschine: Aufsitzmäher / Rasenschnitt
a) Typ / Basismodell
b) Monat / Baujahr
c) Seriennummer
d) Motor: Verbrennungsmotor
3. Den Anforderungen der folgenden Richtlinien
entspricht:
e) Zertifizierungsstelle
f) EG-Baumusterprüfung
4. Bezugnahme auf die harmonisierten Normen
g) Gemessener Schallleistungspegel
h) Garantierter Schallleistungspegel
i) Schnittbreite
n) Zur Verfassung der technischen Unterlagen
befugte Person:
o) Ort und Datum
NL
(
Vertaling van de oorspronkelijke gebruiksaanwijzing)
EG-verklaring van overeenstemming
(Richtlijn Machines 2006/42/CE, Bijlage II, deel A)
1. Het bedrijf
2. Verklaart onder zijn eigen
verantwoordelijkheid dat de machine:
Grasmaaier met zittende bediener / grasmaaier
a) Type / Basismodel
b) Maand / Bouwjaar
c) Serienummer
d) Motor: benzinemotor
3. Voldoet aan de specificaties van de
richtlijnen:
e) Certificatie-instituut
f) EG-onderzoek van het Type
4. Verwijzing naar de Geharmoniseerde normen
g) Gemeten niveau van geluidsvermogen
h) Gegarandeerd niveau van geluidsvermogen
i) Snijbreedte
n) Bevoegd persoon voor het opstellen van het
Technisch Dossier
o) Plaats en Datum
ES
(Traducción del Manual Original)
Declaración de Conformidad CE
(Directiva Máquinas 2006/42/CE, Anexo II, parte
A)
1. La Empresa
2. Declara bajo su propia responsabilidad que la
máquina: Cortadora de pasto con conductor
sentado/ Corte hierba
a) Tipo / Modelo Base
b) Mes / Año de fabricación
c) Matrícula
d) Motor: motor de explosión
3. Cumple con las especificaciones de las
directivas:
e) Ente certificador
f) Examen CE del Tipo
4. Referencia a las Normas armonizadas
g) Nivel de potencia sonora medido
h) Nivel de potencia sonora garantizado
i) Amplitud de corte
n) Persona autorizada a realizar el Manual
Técnico:
o) Lugar y Fecha
PT
(Tradução do manual original)
Declaração CE de Conformidade
(Diretiva de Máquinas 2006/42/CE, Anexo II,
parte A)
1. A Empresa
2. Declara sob a própria responsabilidade que a
máquina: Corta-relvas para operador sentado/
corte da relva
a) Tipo / Modelo Base
b) Mês / Ano de fabrico
c) Matrícula
d) Motor: motor a explosão
3. É conforme às especificações das diretivas:
e) Órgão certificador
f) Exame CE do Tipo
4. Referência às Normas harmonizadas
g) Nível medido de potência sonora
h) Nível garantido de potência sonora
i) Amplitude de corte
n) Pessoa autorizada a elaborar o Caderno
Técnico
o) Local e Data
EL (
Μετάφραση του πρωτοτύπου των οδηγι ών
χρήσης)
EK-Δήλωση συμμόρφωσης
(Οδηγία Μηχανών 2006/42/CE, Παράρτημα II,
μέρος A)
1. Η Εταιρία
2. Δηλώνει υπεύθυνα ότι η μηχανή:
Χλοοκοπτικό τρακτέρ με εποχούμενο χειριστή/
κοπή της χλόης
a) Τύπος / Βασικό Μοντέλο
b) Μήνας / Έτος κατασκευής
c) Αριθμός μητρώου
d) Κινητήρας: κινητήρας εσωτερικής ανάφλεξης
3. Συμμορφώνεται με τις προδιαγραφές της
οδηγίας:
e) Οργανισμός πιστοποίησης
f) Εξέταση CE του Τύπου
4. Αναφορά στους Κανονισμούς εναρμόνισης
g) Στάθμη μέτρησης ακουστικής ισχύος
h) Στάθμη εγγυημένης ακουστικής ισχύος
i) Εύρος κοπής
n) Εξουσιοδοτημένο άτομο για την κατάρτιση
του Τεχνικού Φυλλαδίου:
o) Τόπος και Χρόνος
TR (Orijinal Talimatların Tercümesi)
AT Uygunluk Beyanı
(2006/42/CE Makine Direktifi, Ek II, bölüm A)
1. Şirket
2. Şahsi sorumluluğu altında aşağıdaki
makinenin: Oturan sürücülü çim biçme makinesi
/ çim kesimi
a) Tip / Standart model
b) Üretimin Ay / yıl
c) Sicil numarası
d) Motor: patlamalı motor
3. Aşağıdaki direktiflerin özelliklerine uygun
olduğunu beyan etmektedir:
e) Sertifikalandıran kurum
f) ... Tipi CE incelemesi
4. Harmonize standartlara atıf
g) Ölçülen ses güç seviyesi
h) Garanti edilen ses güç seviyesi
i) Kesim genişliği
n) Teknik Dosyayı oluşturmaya yetkili kişi:
o) Yer ve Tarih
MK (Превод на оригиналните упатства)
Декларација за усогласеност со ЕУ
(Директива за машини 2006/42/CE, Анекс II,
дел A)
1. Компанијата
2. изјавува со целосна лична одговорност
дека следната машина: Тревокосачка со
седнат управувач / косење трева
а) Тип / основен модел
б) Месец / Година на производство
в) етикета
г) мотор: мотор со согорување
3. Усогласено со спецификациите според
директивите:
д) тело за сертификација
ѓ) тест СЕ за типот
4. Референци за усогласени нормативи
е) Акустички притисок
ж) измерено ниво на звучна моќност
з) Ниво на гарантирана звучна моќност
н) овластено лице за составување на
Техничката брошура
o) место и датум
doc_bas e r.15 – RO-FM-P_0
NO (Oversettelse av orginal bruksanvisning)
EF- Samsvarserklæring
(Maskindirektiv 2006/42/EF, Vedlegg II, del A)
1. Firmaet
2. Erklærer på eget ansvar at maskinen:
Sittegressklipper / gressklipping
a) Type / Modell
b) Måned / Byggeår
c) Serienummer
d) Motor: forbrenningsmotor
3. Oppfyller kravene i direktivene:
e) Sertifiseringsorgan
f) EF-typeprøving
4. Henvisning til harmoniserte standarder
g) Målt lydeffektnivå
h) Garantert lydeffektnivå
i) Klippebredde
n) Person som har fullmakt til å utferdige teknisk
dokumentasjon:
o) Sted og dato
SV (Översättning av bruksanvisning i original)
EG-försäkran om överensstämmelse
(Maskindirektiv 2006/42//EG, bilaga II, de la)
1. Företaget
2. Försäkrar på eget ansvar att maskinen
Åkgräsklippare / gräsklippning
a) Typ / Basmodell
b) Månad / Tillverkningsår
c) Serienummer
d) Motor: förbränningsmotor
3. Överensstämmer med föreskrifterna i
direktivet
e) Intygsorgan_ Anmält organ
f) EG typgodkännande
4. Referens till harmoniserade standarder
g) Uppmätt ljudeffektnivå
h) Garanterad ljudeffektnivå
i) Skärbredd
n) Auktoriserad person för upprättandet av den
tekniska dokumentationen:
o) Ort och datum
DA (Oversættelse af den originale brugsanvisning)
EF-overensstemmelseserklæring
(Maskindirektiv 2006/42/EF, bilag II, del A)
1. Firmaet
2. Erklærer på eget ansvar, at maskinen:
Havetraktor/ klipning af græsset a) Type / Model
b) Måned / Konstruktionsår
c) Serienummer
d) Motor: forbrændingsmotor
3. Er i overensstemmelse med specifikationerne
ifølge direktiverne:
e) Certificeringsorgan
f) EF-typeafprøvning
4. Henvisning til harmoniserede standarder
g) Målt lydeffektniveau
h) Garanteret lydeffektniveau
i) Klippebredde
n) Person, der har bemyndigelse til at udarbejde
det tekniske dossier:
o) Sted og dato
FI (
Alkuperäisten ohjeiden käännös)
EY-VAATIMUSTENMUKAISUUSVAKUUTUS
(Konedirektiivi 2006/42/EY, Liite II, osa A)
1. Yritys
2. Vakuuttaa omalla vastuullaan, että kone:
Päältäajettava ruohonleikkuri / ruohonleikkuu
a) Tyyppi / Perusmalli
b) Kuukausi /Valmistusvuosi
c) Sarjanumero
d) Moottori : räjähdysmoottori
3. On yhdenmukainen seuraavien direktiivien
asettamien vaatimusten kanssa:
e) Sertifiointiyritys
f) EY-tyyppitarkastus
4. Viittaus harmonisoituihin standardeihin
g) Mitattu äänitehotaso
h) Taattu äänitehotaso
i) Leikkuuleveys
n) Teknisten asiakirjojen laatimiseen valtuutettu
henkilö:
o) Paikka ja päivämäärä
CS (
Překlad původního návodu k používání)
ES – Prohlášení o shodě
(Směrnice o Strojních zařízeních 2006/42/ES,
Příloha II, část A)
1. Společnost
2. Prohlašuje na vlastní odpovědnost, že stroj:
Sekačka se sedící obsluhou/ sekačka na trávu
a) Typ / Základní model
b) Měsíc / Rok výroby
c) Výrobní číslo
d) Motor: spalovací motor
3. Je ve shodě s nařízeními směrnic:
e) Certifikační orgán
f) ES zkouška Typu
4. Odkazy na Harmonizované normy
g) Naměřená úroveň akustického výkonu
h) Zaručená úroveň akustického výkonu
i) Šířka řezání
n) Osoba autorizovaná pro vytvoření
Technického spisu:
o) Místo a Datum
PL (
Tłumaczenie instrukcji oryginalnej)
Deklaracja zgodności WE
(Dyrektywa maszynowa 2006/42/WE, Załącznik II,
część A)
1. Spółka
2. Oświadcza na własną odpowiedzialność, że
maszyna: Kosiarka z operatorem jadącym, w
pozycji siedzącej na maszynie/ cięcie trawy
a) Typ / Model podstawowy
b) Miesiąc / Rok produkcji
c) Numer seryjny
d) Silnik: silnik o zapłonie iskrowym
3. Spełnia podstawowe wymogi następujących
Dyrektyw:
e) Jednostka certyfikująca
f) Badanie typu WE
4. Odniesienie do Norm zharmonizowanych
g) Zmierzony poziom mocy akustycznej
h) Gwarantowany poziom mocy akustycznej
i) Szerokość cięcia
n) Osoba upoważniona do zredagowania
Dokumentacji technicznej:
o) Miejscowość i data
HU (
Eredeti használati utasítás fordítása)
EK-megfelelőségi nyilatkozata
(2006/42/EK gépirányelv, II. melléklet "A" rész)
1. Alulírott Vállalat
2. Felelősségének teljes tudatában kijelenti,
hogy az alábbi gép: Vezetőüléses fűnyírógép/
fűnyírás
a) Típus / Alaptípus
b) Hónap / Gyártás éve
c) Gyártási szám
d) Motor: robbanómotor
3. Megfelel az alábbi irányelvek előírásainak:
e) Tanúsító szerv
f) CE vizsgálat típusa
4. Hivatkozás a harmonizált szabványokra
g) Mért zajteljesítmény szint
h) Garantált zajteljesítmény szint
i) Vágási szélesség
n) Műszaki Dosszié szerkesztésére
felhatalmazott személy:
o) Helye és ideje
RU (
Перевод оригинальных инструкций)
Декларация соответствия нормам ЕС
(Директива о машинном оборудовании
2006/42/ЕС, Приложение II, часть A)
1. Предприятие
2. Заявляет под собственную
ответственность, что машина: Ездовая
косилка с водителем / стрижка газона
a) Тип / Базовая модель
b) Месяц /Год изготовления
c) Паспорт
d) Двигатель: двигатель внутреннего
сгорания
3. Соответствует требованиям следующих
директив:
e) Сертифицирующий орган
f) Испытание ЕС типового образца
4. Ссылки на гармонизированные нормы
g) Измеренный уровень звуковой мощности
h) Гарантируемый уровень звуковой
мощности
i) Амплитуда кошения
n) Лицо, уполномоченное на
подготовку
технической документации:
o) Место и дата
HR (
Prijevod originalnih uputa)
EK Izjava o sukladnosti
(Direktiva 2006/42/EZ o strojevima, dodatak II,
dio A)
1. Tvrtka:
2. pod vlastitom odgovornošću izjavljuje da je
stroj: Sjedeća kosilica trave s operaterom/
košenje trave
a) Vrsta / Osnovni model
b) Mjesec / Godina proizvodnje
c) Matični broj
d) Motor: motor s unutarnjim izgaranjem
3. sukladan s temeljnim zahtjevima direktiva:
e) Certifikacijsko tijelo
f) Tipsko ispitivanje EZ
4. Primijenjene su slijedeće harmonizirane
norme:
g) Izmjerena razina zvučne snage
h) Zajamčena razina zvučne snage
i) Širina rezanja
n) Osoba ovlaštena za pravljenje Tehničke
datoteke:
o) Mjesto i datum
SL (Prevod izvirnih navodil)
ES izjava o skladnosti
(Direktiva 2006/42/ES) , priloga II, del A)
1. Družba
2. pod lastno odgovornostjo izjavlja, da je stroj:
Traktorska kosilnica/ košnja trave
a) Tip / osnovni model
b) Mesec /Leto izdelave
c) Serijska številka
d) Motor: motor z notranjim izgorevanjem
3. Skladen je z določili direktiv :
e) Ustanova, ki izda potrdilo
f) ES pregled tipa
4. Sklicevanje na usklajene predpise
g) Izmerjen nivo zvočne moči
h) Zagotovljen nivo zvočne moči
i) Obseg košnje
n) Oseba, pooblaščena za sestavo tehnične
knjižice:
o) Kraj in datum
BS (Prijevod originalnih uputa)
EZ izjava o sukladnosti
(Direktiva o mašinama 2006/42/EZ, Prilog II, deo
A)
1. Firma
2. Daje izjavu pod vlastitom odgovornošću da je
mašina: Traktorska kosilica (traktorčić) /
Košenje trave
a) Tip / Osnovni model
b) Mjesec / Godina proizvodnje
c) Serijski broj
d) Motor: motor s unutrašnjim izgaranjem
3. sukladna s osnovnim zahtjevima direktive:
e) Certifikaciono tijelo
f) EZ ispitivanje tipa
4. Pozivanje na usklađene norme
g) Izmjereni nivo zvučne snage
h) Garantovani nivo zvučne snage
i) Širina košenja
n) Osoba ovlaštena za izradu tehničke brošure:
o) Mjesto i datum
SK (Preklad pôvodného návodu na použitie)
ES vyhlásenie o zhode
(Smernica o Strojných zariadeniach 2006/42/ES,
Príloha II, časť A)
1. Spoločnosť
2. Vyhlasuje na vlastnú zodpovednosť, že stroj:
Kosačka so sediacou obsluhou/ kosačka na
trávu
a) Typ / Základný model
b) Mesiac / Rok výroby
c) Výrobné číslo
d) Motor: spaľovací motor
3. Je v zhode s nariadeniami smerníc:
e) Certifikačný orgán
f) Skúška typu ES
4. Odkaz na Harmonizované normy
g) Nameraná úroveň akustického výkonu
h) Zaručená úroveň akustického výkonu
i) Šírka kosenia
j) Čistý inštalovaný výkon
n) Osoba autorizovaná na vytvorenie
Technického spisu:
o) Miesto a Dátum
RO (
Traducerea manualului fabricantului)
CE -Declaratie de Conformitate
(Directiva Maşini 2006/42/CE, Anexa II, partea A)
1. Societatea
2. Declară pe propria răspundere că maşina:
Mașină de tuns iarba cu șofer la volan/ tăiat
iarba
a) Tip / Model de bază
b) Luna /Anul de fabricație
c) Număr de serie
d) Motor: motor cu combustie
3. Este în conformitate cu specificaţiile
directivelor:
e) Organism de certificare
f) Examinare CE de Tip
4. Referinţă la Standardele armonizate
g) Nivel de putere sonoră măsurat
h) Nivel de putere sonoră garantat
i) Lăţimea de tăiere
n) Persoană autorizată să întocmească Dosarul
Tehnic
o) Locul şi Data
LT (
Originalių instrukcijų vertimas)
EB atitikties deklaracija
(Mašinų direktyva 2006/42/CE, Priedas II, dalis A)
1. Bendrovė
2. Prisiima atsakomybę, kad įrenginys: Balninė
vejapjovė su sėdinčiu operatoriumi / žolės
pjovimas
a) Tipas / Bazinis Modelis
b) Mėnuo / Pagaminimo metai
c) Serijos numeris
d) Variklis: vidaus degimo variklis
3. Atitinka direktyvose pateiktas specifikacijas:
e) Sertifikavimo įstaiga
f) CE tipo tyrimas
4. Nuoroda į suderintas Normas
g) Išmatuotas garso galios lygis
h) Užtikrinamas garso galios lygis
i) Pjovimo plotis
n) Autorizuotas asmuo sudaryti Techninę
Dokumentaciją:
o) Vieta ir Data
LV (
Instrukciju tulkojums no oriģinālvalodas)
EK atbilstības deklarācija
(Direktīva 2006/42/EK par mašīnām, pielikums II,
daļa A)
1. Uzņēmums
2. Uzņemoties par to pilnu atbildību, paziņo, ka
mašīna: Sēžot vadāma zālienu pļaujmašīna/
zāles pļaušana
a) Tips / Bāzes modelis
b) Mēnesis / Ražošanas gads
c) Sērijas numurs
d) Motors: iekšdedzes motors
3. Atbilst šādu direktīvu prasībām:
e) Sertifikācijas iestāde
f) CE tipveida pārbaude
4. Atsauce uz harmonizētiem standartiem
g) Izmērītais skaņas intensitātes līmenis
h) Garantētais skaņas intensitātes līmenis
i) Pļaušanas platums
n) Pilnvarotais darbinieks, kas sagatavoja
tehnisko dokumentāciju:
o) Vieta un datums
SR (
Prevod originalnih uputstvaI)
EC deklaracija o usaglašenosti
(Direktiva o mašinama 2006/42/EC, Prilog II, deo
A)
1. Preduzeće
2. Daje izjavu pod vlastitom odgovornošću da je
mašina: Traktorska kosačica (traktorčić)/
košenje trave
a) Tip / Osnovni model
b) Mesec /Godina proizvodnje
c) Serijski broj
d) Motor: motor s unutrašnjim sagorevanjem
3. u skladu s osnovnim zahtevima direktiva:
e) Sertifikaciono telo
f) EC ispitivanje tipa:
4. Pozivanje na usklađene norme
g) Izmereni nivo zvučne snage
h) Garantovani nivo zvučne snage
i) Širina košenja.....................
n) Osoba ovlašćena za sastavljanje tehničke
brošure
o) Mesto i datum
BG (
Превод на оригиналните инструкции)
ЕО декларация за съответствие
(Директива Машини 2006/42/ЕО, Приложение
II, част А)
1. Дружеството
2. На собствена отговорност декларира, че
машината: Косачка със седнал водач/ рязане
на трева
а) Вид / Базисен модел
б) Месец / година на производство
в) Сериен номер
г) Мотор: мотор с вътрешно горене
3. Е в съответствие със спецификата на
директивите:
д) Сертифициращ орган
е) ЕО изследване на вида
4. Базирано на хармонизираните норми
ж) Ниво на измерена акустична мощност
и) Гарантирано ниво на акустична мощност
й) Широчина на косене
р) Лице, упълномощено да състави
Техническата Документация:
o) Място и дата
ET (
Algupärase kasutusjuhendi tõlge)
EÜ vastavusdeklaratsioon
(Masinadirektiiv 2006/42/EÜ, Lisa II, osa A)
1. Firma
2. Kinnitab omal vastutusel, et masin: Istuva
juhiga muruniitja / muruniitja
a) Tüüp / Põhimudel
b) Kuu aega / Tootmisaasta
c) Matrikkel
d) Mootor: Sisepõlemismootor
3. Vastab direktiivide nõuetele:
e) Kinnitav asutus
f) EÜ tüübihindamine
4. Viide ühtlustatud standarditele
g) Mõõdetud helivõimsuse tase
h) Garanteeritud helivõimsuse tase
i) Lõikelaius
n) Tehnilise Lehe autoriseeritud koostaja:
o) Koht ja Kuupäev
EXAMPLE
© by ST. S.p.A.
IT • Il contenuto e le immagini del presente manuale d’uso sono stati realizzati per conto di ST. S.p.A. e sono tutelati da diritto d’autore – E’
vietata ogni riproduzione o alterazione anche parziale non autorizzata del documento.
BG • Съдържанието и изображенията в настоящото ръководство са извършени за ST. S.p.A. и са защитени с авторски права –
Забранява се всяко неоторизирано възпроизвеждане или промяна, дори и отчасти на документа.
BS • Sadržaj i slike iz ovog korisničkog priručnika napravljeni su isključivo za ST. S.p.A. i zaštićeni su autorskim pravima – zabranjena je
svaka neovlaštena reprodukcija ili izmjena dokumenta, djelomično ili u potpunosti.
CS • Obsah a obrázky v tomto návodu k použití byly zpracovány jménem společnosti ST. S.p.A. a jsou chráněny autorským právem –
Reprodukce či nepovolené pozměňování tohoto dokumentu, a to i částečné, je zakázáno.
DA • Indhold og illustrationer i denne vejledning er blevet skabt på vegne af ST. S.p.A. og er beskyttet af ophavsret – Enhver gengivelse
eller ændring, også delvis, af dokumentet uden autorisation hertil er forbudt.
DE • Inhalt und Bilder dieser Bedienungsanleitung wurden im Namen von ST. S.p.A. erstellt und sind urheberrechtlich geschützt – Jede
nicht genehmigte Vervielfältigung oder Veränderung, auch auszugsweise, dieses Dokuments ist verboten.
EL • Το περιεχόμενο και οι εικόνες στο παρόν εγχειρίδιο χρήσης δημιουργήθηκαν για λογαριασμό της εταιρείας ST. S.p.A. και
προστατεύονται από πνευματικά δικαιώματα – Απαγορεύεται οποιαδήποτε αναπαραγωγή ή τροποποίηση, έστω και μερική, του
εγγράφου χωρίς έγκριση.
EN • The content and images in this User Manual were produced expressly for ST. S.p.A. and are protected by copyright – any unauthori-
sed reproduction or modication to the document, either partially or in full, is prohibited.
ES • El contenido y las imágenes del presente manual de uso han sido creados por ST. S.p.A. y están protegidos por los derechos de
autor – Se prohíbe toda reproducción o modicación, incluso parcial, no autorizada del documento.
ET • Käesoleva kasutusjuhendi sisu ja kujutised on toodetud konkreetselt ettevõttele ST. S.p.A. ja neile rakendub autorikaitseseadus –
dokumendi igasugune osaline või täielik ilma loata reprodutseerimine või muutmine on keelatud.
FI • Tämän käyttöoppaan sisältö ja kuvat on valmistettu ST. S.p.A. -yhtiön toimesta ja niitä suojaa tekijänoikeuslaki. – Asiakirjan kaikenlai-
nen kopioiminen tai muuttaminen, osittainkin, on kielletty ilman erityistä lupaa.
FR • Le contenu et les images du présent manuel d’utilisation ont été réalisés pour le compte de ST. S.p.A. et sont protégés par un droit
d’auteur - Toute reproduction ou modication non autorisée, même partielle, du document, est interdite.
HR • Sadržaj i slike u ovom priručniku za uporabu izrađeni su za tvrtku ST. S.p.A. te su obuhvaćeni autorskim pravima – Zabranjuje se
neovlašteno umnožavanje ili prilagodba, djelomična ili u cijelosti, ovog dokumenta.
HU • Ennek a használati útmutatónak a tartalma és a benne szereplő képek kizárólag a ST. S.p.A. számára készültek és szerzői joggal
védettek – tilos a dokumentum bármely részének vagy egészének engedély nélküli sokszorosítása és módosítása.
LT • Šio naudotojo vadovo turinys ir paveikslėliai skirti tik „ST. S.p.A.“ ir yra saugomi autorių teisėmis – dokumentą atgaminti ar modikuoti,
visiškai arba iš dalies, yra draudžiama.
LV • Šīs lietotāja rokasgrāmatas saturs un attēli ir veidoti tikai ST. S.p.A. un ir aizsargāti ar autortiesībām. Jebkāda dokumenta vai tā daļas
prettiesiska kopēšana vai pārveide ir stingri aizliegta.
MK • Содржината и сликите во Упатството за корисникот се подготвени исклучиво за ST. S.p.A. и се заштитени со авторски
права – забрането е секое делумно или целосно неовластено репродуцирање или измена на документот.
NL • De inhoud en de afbeeldingen van deze gebruikshandleiding werden gerealiseerd voor rekening van ST. S.p.A. en zijn beschermd
door het auteursrecht – Elke niet-geautoriseerde reproductie of wijziging, ook gedeeltelijke, van het document is verboden.
NO • Innholdet og bildene i denne brukerveiledningen er utført på oppdrag fra ST. S.p.A. og er beskyttet ved opphavsrett - Enhver gjengi-
velse eller endring, selv kun delvis, er forbudt.
PL • Treść oraz ilustracje zawarte w niniejszej instrukcji obsługi powstały na zlecenie spółki ST. S.p.A. i są chronione prawami autorskimi –
Zabrania się wszelkiego kopiowania bądź modykowania, także częściowego, niniejszego dokumentu bez uzyskania stosownej zgody.
PT • As imagens e os conteúdos contidos no presente Manual do Utilizador foram expressamente criados para uso exclusivo da ST.
S.p.A., encontrando-se protegidos por direitos de autor. Qualquer tipo de reprodução ou alteração, parcial ou integral, não autorizadas
deste Manual estão expressamente proibidas.
RO • Conținutul şi imaginile din manualul de utilizare de față au fost realizate în numele ST. S.p.A. şi sunt protejate de drepturi de autor –
Este interzisă orice reproducere sau modicare chiar şi parțială neautorizată a documentului.
RU • Тесты и изображения, содержащиеся в настоящем руководстве, были созданы в интересах ST. S.p.A. и защищены
авторскими правами – Любое несанкционированное воспроизведение или изменение документа запрещено.
SK • Obsah a obrázky v tomto návode na používanie boli spracované menom spoločnosti ST. S.p.A. a sú chránené autorským právom –
Reprodukcie či nepovolené pozmeňovanie tohto dokumentu, a to aj čiastočné, je zakázané.
SL • Vsebine in slike v tem uporabniškem priročniku so izdelane za podjetje ST. S.p.A. in so zaščitene z avtorskimi pravicami – vsakršno
nepooblaščeno razmnoževanje ali spreminjanje dokumenta, v celoti ali delno, je prepovedano.
SR • Sadržaj i slike ovog priručnika za upotrebu su napravljeni u ime ST. S.p.A. i zaštićeni su autorskim pravima – Zabranjena je svaka
potpuna ili delimična reprodukcija ili izmena dokumenta bez odobrenja.
SV • Innehållet och bilderna i denna användarhandbok har framställts för ST. S.p.A. och skyddas av upphovsrätt – all form av reproduktion
eller ändring, även partiell, som inte auktoriserats är förbjuden.
TR • Bu Kullanıcı Kılavuzundaki içerik ve resimler açıkça ST. S.p.A. için üretilmiştir ve telif hakkı ile korunmaktadır – dokümanın izinsiz
olarak tamamen ya da kısmen herhangi bir şekilde çoğaltılması ya da değiştirilmesi yasaktır.
ST. S.p.A.
Via del Lavoro, 6
31033 Castelfranco Veneto (TV) ITALY
dB
L
WA
Type:
................................
.................. -s/n ........................................
Art.N .......................................................
