Frigidaire CGIF3061NFC electric range User Manual

TABLE OF CONTENTS

316902320 Rev B (Nov 2016))

Setting Oven Controls .................................. 19-33

Self-Cleaning ............................................... 34-35

Care & Cleaning .......................................... 36-39

Before You Call ........................................... 40-42

Notes .............................................................. 43

Major Appliance Warranty ..................... back cover

Important Safety Instructions ...........................3-6

Before Setting Surface Controls ........................7-9

Induction Cooking Zones ............................. 10-12

Setting Surface Controls ............................. 13-15

Before Setting Oven Controls ...................... 16-17

Oven Control Functions (540) ............................18

Thank you for choosing Frigidaire.

This Use & Care Guide is part of our commitment to

customer satisfaction and product quality throughout the

service life of your new appliance.We view your purchase

as the beginning of a relationship. To ensure our ability

to continue serving you, please use this page to record

important product information.

Registering your product with Frigidaire enhances

our ability to serve you. You can register online at

www. frigidaire.com or by dropping your Product

Registration Card in the mail.

PRODUCT RECORD AND REGISTRATION

Product Registration

Need help??

Visit the Frigidaire web site at www.frigidaire.com

Before you call for service, there are a few things you can

do to help us serve your better.

Read this Use & Care manual.

It contains instructions to help you use and maintain your

range properly.

If you received a damaged range ...

Immediately contact the dealer or builder that sold you the

range.

Save time and money.

Check the section titled “Before you call.” This sec-

tion helps step you through some common problems

that might occur. If you do need service, help is only

a phone call away. Call Frigidaire Customer Services at

1-800- 944-9044.

Contents

Serial plate location:

open drawer.

Serial plate

location

Purchase date

Model number

Serial number

Record model & serial numbers here

Product Registration ......................................................2

Important Safety Instructions ............................ 3-6

Before Setting Surface Controls ...........................7-9

 Benetsofinductionsurfacecooking ........................... 7

Induction cookware .................................................... 7

When using the cooking zones ....................................8

Home Canning ...........................................................9

Induction Cooking Zones .................................10-12

Pan Sensing ........................................................ 10-11

Cooktop display windows .......................................... 12

Setting Surface Controls ..................................13-15

Operating induction cooking zones ....................... 13-14

Cooktop operational noises ....................................... 14

Warmer Zone ........................................................... 15

Before Setting Oven Controls ...........................16-17

Removing, replacing & arranging the oven racks ........ 16

Effortless™ Oven Rack system and assembly ............. 17

Oven Controls Functions .......................................18

Setting Oven Controls ......................................19-33

Setting the clock ...................................................... 19

Changing between continuous bake or 6-Hour

Energy Saving features ............................................. 19

Setting 12 or 24 hour display mode ........................... 19

Changing oven temperature display (°F or °C) ........... 19

Setting a silent control panel ..................................... 20

Setting lockout ......................................................... 20

Setting minute timer ................................................. 20

Setting bake ............................................................ 21

Setting bake time ..................................................... 21

Setting delayed timed bake ....................................... 22

Convection cooking .................................................. 23

Convect bake ........................................................... 23

Convect roast ........................................................... 23

Convect broil............................................................ 24

Setting convect convert ............................................ 24

Probe ................................................................. 25-28

Setting broil ............................................................. 29

Setting keep warm ................................................... 30

Operating the oven light ........................................... 30

Adjusting oven temperature ...................................... 31

Restoring factory default settings .............................. 31

Setting the Sabbath mode feature ........................ 32-33

Self-cleaning ....................................................34-35

Care & Cleaning ................................................36-39

Cleaning recommendation table ................................ 36

Cooktop maintenance and cleaning ...................... 37-38

Replacing the oven light ........................................... 38

Removing and replacing oven door ............................ 39

Before You Call - Solutions to common problems ..40-42

Notes ....... ................................................................43

Appliance Warranty ..................................back cover

Read all instructions before using this appliance.

Do not attempt to install or operate your appliance until

you have read the safety precautions in this manual. Safe-

ty items throughout this manual are labeled with a WARN-

ING or CAUTION statement based on the risk type.

WARNING indicates a potentially hazardous situ-

ation which, if not avoided, may result in death or

serious injury.

Save these instructions for future reference.

IMPORTANT SAFETY INSTRUCTIONS

WARNING

This is the safety alert symbol. It is used to alert

you to potential personal injury hazards. Obey all safety

messages that follow this symbol to avoid possible injury

or death.

IMPORTANT

CAUTION indicates a potentially hazardous situa-

tion which, if not avoided, may result in minor or

moderate injury.

CAUTION

IMPORTANT indicates installation, operation, mainte-

nance or valuable information that is not hazard related.

Denitions

Important Safety Instructions

This appliance has been tested and found to comply with

the limits for a class B digital device, pursuant to Part 18

of the FCC rules. These limits are designed to provide rea-

sonable protection against harmful interference in a resi-

dential installation. This unit generates, uses and can radi-

ate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful

interference to radio communications. However there is

no guarantee that interference will not occur in a particular

installation. If this unit does cause harmful interference to

radio or television reception, which can be determined by

turning the unit off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antennae.

• Increase the distance between the unit and receiver.

• Connect the unit into an outlet or a circuit different

from that to which the receiver is connected.

• Proper installation—Be sure your appliance is

properly installed and grounded by a qualied

technician in accordance with the National

Electrical Code ANSI/NFPA No. 70 latest edition

and local electrical code requirements. Install only

per installation instructions provided in the literature

package for this range.

• Remove all tape and packaging before using

the range. Destroy the carton and plastic bags after

unpacking the range. Never allow children to play with

packaging material.

Persons with a pacemaker or similar medical device

should exercise caution using or standing near an induc-

tion unit while it is in operation, as the electromagnetic

eldmayaffecttheworkingofthepacemakerorsimilar

medical device. It would be advisable to consult your

Doctor or the pacemaker or similar medical device manu-

facturer about your particular situation.

CAUTION

WARNING

Tip-over Hazard

• A child or adult can tip the

range and be killed.

• Verify the anti-tip device has

been installed to oor or wall.

To check if the anti-tip bracket is installed properly,

use both arms and grasp the rear edge of range back.

Carefully attempt to tilt range forward. When properly

installed, the range should not tilt forward.

Refer to the anti-tip bracket installation

instructions supplied with your range for proper

installation.

• Ensure the anti-tip device is re-engaged when

the range is moved to oor or wall.

• Do not operate the range without the anti-tip

device in place and engaged.

• Failure to follow these instructions can result

in death or serious burns to children and

adults.

Range

leveling leg

Anti-Tip

bracket

CAUTION

• Do not store items of interest to children in the

cabinets above a range or on the backguard of

the range. Children climbing on the range to reach

items could be seriously injured.

• Do not touch surface heating units or surface

cooking elements, areas near these units or

elements, or interior surface of the oven. Both

surface heating and oven heating elements may be

hot even though they are dark in color. Areas near

surface cooking units may become hot enough to

cause burns. During and after use, do not touch, or

letclothingorotherammablematerialstouchthese

areasuntiltheyhavehadsufcienttimetocool.

Among these areas are the cook top, surfaces facing

the cook top, the oven vent openings and surfaces

near these openings, oven door and oven door

window.

• Wear proper apparel—loose-tting or hanging

garments should never be worn while using

the appliance. Do not let clothing or other

ammablematerialscontacthotsurfaces.

• Do not heat unopened food containers -

buildup of pressure may cause container to

burst and result in injury.

• Do not use water or our on grease res—

smother the re with a pan lid, or use

baking soda, a dry chemical or foam-type

extinguisher.

• When heating fat or grease, watch it closely.

Fatorgreasemaycatchreifallowedtobecometoo

hot.

• Use dry potholders - moist or damp potholders

on hot surfaces may result in burns from

steam. Do not let potholders touch hot heating

elements. Do not use a towel or other bulky cloth

instead of a potholder.

Do not attempt to operate the range during a

power failure. If the power fails, always turn off the

range. If the range is not turned off and the power

resumes, the range will begin to operate again. Once

the power resumes, reset the clock and oven function.

IMPORTANT

• DO NOT LEAVE CHILDREN ALONE —children

should not be left alone or unattended in the

area where appliance is in use. They should

never be allowed to sit or stand on any part of the

appliance, including the storage drawer, lower broiler

drawer, warmer drawer or lower double oven.

• Stepping, leaning or sitting on the door

or drawers of a range can result in serious

injuries and also cause damage to the

appliance. DO NOT allow children to climb or play

around the range. The weight of a child on an open

oven door may cause the range to tip, resulting in

serious burns or other injury.

• Storage in or on appliance—ammable

materials should not be stored in an oven,

warmer drawer, near surface units or in the

storage drawer. This includes paper, plastic and

cloth items, such as cookbooks, plasticware and

towels,aswellasammableliquids.Donotstore

explosives, such as aerosol cans, on or near the

range.

• Never use your appliance for warming or

heating the room. Doing so may result in

carbon monoxide poisoning.

WARNING

IMPORTANT SAFETY INSTRUCTIONS

• Never modify or alter the construction of a range by

removing the leveling legs, panels, wire covers, anti-tip

brackets/screws, or any other part of the range.

• Remove the oven door from any unused range if it is to

be stored or discarded.

• User servicing—Do not repair or replace any part of

theapplianceunlessspecicallyrecommendedinthe

manuals. All other servicing should be done only by a

qualiedtechnician.Thismayreducetheriskofpersonal

injury and damage to the range.

• Askyourdealertorecommendaqualiedtechnicianand

an authorized repair service. Know how to disconnect

the power to the range at the circuit breaker or fuse box

in case of an emergency.

• Do not cook food on the oven bottom. Always cook in

proper cookware and always use the oven racks.

• Whenyouareamingfoodsunderaventilatinghood,

turn the fan on.

• Clean ventilating hoods frequently - grease should not

beallowedtoaccumulateonthehoodorthelter.

IMPORTANT INSTRUCTIONS FOR USING

YOUR OVEN

• Use care when opening oven door , lower oven

door or warmer drawer (if equipped)—Stand to

the side of the range when opening the door of a hot

oven. Let hot air or steam escape before you remove or

replace food in the oven.

• Keep oven vent ducts unobstructed. The oven vent

is located under the left rear surface element if your

model is equipped with coil elements. The oven vent

is located below the backguard for models equipped

with ceramic-glass cook tops. Touching the surfaces in

this area when the oven is operating may cause severe

burns. Also, do not place plastic or heat-sensitive items

on or near the oven vent. These items could melt or

ignite.

• Placement of interior oven racks. Always place

oven racks in desired location while oven is cool. If rack

must be moved while oven is hot use extreme caution.

Use potholders and grasp the rack with both hands to

reposition. Do not let potholders contact the hot heating

elements in the oven. Remove all utensils from the rack

before moving.

• Do not use the broiler pan without its insert. The

broiler pan and its insert allow dripping fat to drain

and be kept away from the high heat of the broiler. Do

not cover the broiler insert with aluminum foil.

Exposed fat and grease could ignite.

• Protective liners—Do not use aluminum foil to line the

oven bottom. Only use aluminum foil as recommended

in this manual. Improper installation of these liners may

resultinriskofelectricshock,orre.

• Clean the range regularly to keep all parts free of

grease that could catch re. Pay particular attention

to the area around each surface element. Do not allow

grease to accumulate.

• Kitchen cleaners and aerosols—Always follow the

manufacturer’s recommended directions for use.

Be aware that excess residue from cleaners and aerosols

may ignite causing damage and injury.

• Clean ventilating hoods frequently—Grease

should not be allowed to accumulate on the hood

or lter. Follow the manufacturer’s instructions for

cleaning hoods.

FOR CERAMIC-GLASS COOK TOP MODELS

• Do not cook on broken cook top—If cook top should

break, cleaning solutions and spillovers may penetrate

the broken cook top and create a risk of electric shock.

Contactaqualiedtechnicianimmediately.

• Clean cook top with caution—If a wet sponge or

cloth is used to wipe spills on a hot cooking area, be

careful to avoid a steam burn. Some cleaners can

produce noxious fumes if applied to a hot surface.

SELF-CLEANING OVENS

• Clean in the self-cleaning cycle only the parts

listed in this Use & Care Manual. Before self-cleaning

the oven, remove the broiler pan and any utensils or

foods from the oven.

• Do Not Use Oven Cleaners—No commercial oven

cleaner or oven liner protective coating of any kind

should be used in or around any part of the oven.

• Do Not Clean Door Gasket—The door gasket is

essential for a good seal. Care should be taken not to

rub, damage or move the gasket.

• The health of some birds is extremely sensitive to the

fumes given off during the self-cleaning cycle of any

range. Move birds to another well-ventilated room.

Before manually cleaning any part of the range, be sure

all controls are turned OFF and the range is COOL. The

range may be hot and can cause burns.

CAUTION

IMPORTANT INSTRUCTIONS FOR CLEANING

YOUR RANGE

IMPORTANT SAFETY NOTICE

The California Safe Drinking Water and Toxic Enforcement

Act requires the Governor of California to publish a

list of substances known to the state to cause cancer,

birth defects or other reproductive harm, and requires

businesses to warn customers of potential exposure to

such substances.

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT INSTRUCTIONS FOR USING

YOUR COOKTOP

• Know which keypad controls each surface cooking

zone. Place a pan with food on the cooking zone before

turning it on, and turn the cooking zone off before

removing the pan.

• Use proper pan size —This appliance is equipped with

induction cooking zones of different sizes. Select utensils

specicallymanufacturedandapprovedforinduction

cookingthathaveatbottomsthatmatchtheinduction

cooking zone size. Proper relationship of utensil to

cookingzonewillalsoimproveefciency.

• Utensil handles should be turned inward and not extend

over adjacent cooking zones—To reduce the risk of

burns,ignitionofammablematerials,andspillagedue

to unintentional contact with the utensil, the handle

of the utensil should be positioned so that it is turned

inward, and does not extend over adjacent cooking

zones.

• Never leave surface cooking zones unattended —

Boilovers cause smoking and greasy spillovers that may

ignite, or a pan that has boiled dry could be damaged.

IMPORTANT SAFETY INSTRUCTIONS

GROUNDING INSTRUCTIONS

For models factory-equipped with a power cord:

For personal safety, this appliance must be properly

grounded. For maximum safety, the power cord must be

plugged into an electrical outlet that is correctly polarized

and properly grounded. If a 2-prong wall receptacle is the

only available outlet, it is the personal responsibility of the

consumer to have it replaced with a properly grounded

3-prongwallreceptacleinstalledbyaqualiedelectrician.

See the INSTALLATION INSTRUCTIONS packaged

with this appliance for complete installation and grounding

instructions.

•Avoidrehazardorelectricalshock.Donotuse

an adapter plug, an extension cord, or remove

grounding prong from electrical power cord. Failure

tofollowthiswarningcancauseseriousinjury,reor

death.

• This appliance may be equipped with a 3-prong

grounding plug. For your protection against shock

hazard, it should be plugged directly into a properly

grounded receptacle. Do not cut or remove the

grounding prong from this plug

WARNING

BEFORE SETTING SURFACE CONTROLS

Benets of induction surface cooking

Fast and efcient - The induction cooking zones heat

faster while using less energy. Induction power levels are

quicktoboilandefcientwhensimmering.

A cooler cooktop - A unique feature of the induction

cooking zones is whether turned on or off, the cooking

zones remain cooler than radiant type elements. Virtually

no wasted heat is produced since the heat begins with the

presence of cookware.

Easy cleanups - The cooler cooking zones make cleanup

easier. Spills resist sticking or burning so they wipe up

easily.

Magnetic detector - The cooking zone has a sensor that

automatically detects whether cookware is magnetic. This

will reduce accidental “turn-ons.”

Pan size detection - The pan size recognition sensor

automatically detects and adapts the induction cooking

zones to the pan sizes in use for consistent, more even

cooking.

More responsive - The induction cooking zones are more

responsive than their electric or gas counterparts because

only the pan heats. This type of cooking heats easier and

will be just as responsive when reducing to a simmer.

Induction cooking directly heats the pan; heating will only

begin when cookware is properly placed on the cooking

zones.

About the induction cooktop

Your cooktop is equipped with four differently-sized

induction cooking zones and a radiant heat warmer zone.

Induction cookware

When purchasing pans for use on the induction

cooktop,lookforcookwarespecicallyidentiedbythe

manufacturer as induction ready, induction capable,

or a similar statement by the manufacturer that the

cookwareisspecicallydesignedforinductioncooking.

The cooking zones will not activate if the cookware is not

constructed with a base magnetic material. To check if

the cookware base material is suitable, use a magnet to

test (See Fig. 1). If a magnet sticks to the bottom of the

cookware, the material type is correct.

For the best possible surface cooking results, it is

recommended to only use high quality heavy gauge

cookware on the induction cooking zones.

Be sure to follow all the manufacturer’s recommendations

when using cookware made for induction cooking.

Before using the induction cooking zones, be

sure to carefully read and follow these cookware

recommendations and the instructions in the pan

sensing section.

IMPORTANT

Left rear

cooking zone

Warmer zone

Right front

cooking zone

Right rear

cooking zone

Left front

cooking zone

Fig. 1

Induction cookware types

The most common induction cookware types available are:

Stainless steel - Generally, excellent for induction

cooking. Is durable, easy to clean and resists staining.

Cast iron - Good for induction cooking. Cooks evenly.

Do not slide cast iron cookware on cooktop. Cast iron

cookware with a rough surface will scratch ceramic

cooktop.

Porcelain-enamel on ferrous metal - Heating

characteristics will vary depending on quality of base

material. Porcelain-enamel coating must be smooth to

avoid scratching ceramic cooktop.

Not all stainless steel cookware is magnetic; stainless

steel is not always suitable for induction cooking.

IMPORTANT

BEFORE SETTING SURFACE CONTROLS

Moving cookware on smoothtop

It is recommended to always use heavier gauge high

quality cookware on the cooking zones. Even high quality

cookware can still scratch the cooktop surface. Do not

slide cookware on the ceramic cooktop.

Sliding any type of cookware over the surface will scratch

the cooktop over time. Scratches will make cleaning the

ceramiccooktopdifcultanddegradetheappearanceof

the cooktop.

For more detailed information about the cooktop see

“Cooktop maintenance” and “Cooktop cleaning” in the

Care & Cleaning section.

When using the cooking zones

• Be sure to use cooktop cookware made with a magnetic

base material.

• Use quality cooktop cookware with heavier bottoms for

better heat distribution, allowing for more even cooking

results.

• Check that cookware bottom rests level on cooktop

surface.Cookwareshouldhaveatbottomsthatmake

good contact with the entire induction cooking zone

area.Checkforatnessbyrotatingaruleracrossthe

bottom of the cookware (See Fig. 1).

• Be sure cookware is properly balanced and does not tilt

from a heavy handle.

• Be sure that the pan size matches the amount of food

to be prepared. The size and type of cookware used will

inuencethesettingneededforbestcookingresults.

• Never let cookware boil dry. This may cause permanent

damage such as breakage, fusion, or marring that can

affect the cooktop.

• Use cookware that meets the minimum and maximum

cookware size requirements for each cooking zone.

Fig. 1

IMPORTANT

• Always lift cookware before moving on the ceramic

glass smoothtop.

• Any cookware that has rough or dirty bottoms can

mark and scratch the ceramic glass surface. Always

start with clean cookware.

Fig. 2

BEFORE SETTING SURFACE CONTROLS

Home Canning

Be sure to read and observe all the following points when

home canning with your appliance. Check with the USDA

(United States Department of Agriculture) website and

be sure to read all the information they have available as

well as follow their recommendations for home canning

procedures.

• Useonlyqualityatbottomcannerswhenhome

canning. Use a straight-edge to check canner bottom

(see Cookware Recommendations section).

• Use only a completely at bottom canner with no

ridges that radiate from the bottom center when home

canning using a range with a ceramic glass cooktop.

• Make sure the diameter of the canner does not

exceed 1 inch beyond the cooking zone markings.

It is recommended to use smaller diameter canners on

ranges with ceramic glass or open coil electric cooktops.

• Start with hot tap water to bring water to boil more

quickly.

• Usethehighestheatsettingwhenrstbringingthe

water to a boil. Once boiling is achieved, reduce heat to

lowest possible setting to maintain that boil.

IMPORTANT

NEVER place or straddle a cooking utensil over 2 dif-

ferent surface cooking zones heating at the same time.

This will cause uneven heating results and could cause

the ceramic cooktop to fracture.

• Unlike radiant surface elements, the cooking zones

will not glow red when they are hot. The glass

surface may be hot from residual heat transferred

from the cookware and burns may occur.

• Do not touch hot cookware or pans directly

with hands. Always use oven mitts or pot holders to

protect hands from burns.

CAUTION

The type and size of cookware, cooking duration, the

number of cooking zones in use and their power level

settings are all factors that will affect the amount of heat

that will spread beyond the cooking zones.

The induction cooking zones and areas surrounding

the cooking zones may become hot enough to cause

burns. Be sure to read all cautions.

Hot cookware and residual heat

INDUCTION COOKING ZONES

Theconditionsthatmaygenerateaashingerrormessage

are illustrated in Figure 2. Use Figure 2 as a guide to help

to correct the problem or problems before attempting to

reactivate any of the cooking zones.

If the problem or problems are not corrected, the affected

cooking zone will automatically deactivate after 3 minutes.

Pan sensing

The cooking zone sensors located below the cooktop

surface require that certain cookware conditions are met

before the induction cooking zones can operate.

The cooking zone display windows may display a pan

sensing error message. If a cooking zone is activated and

no cookware is detected, the affected induction cooking

zonedisplaywindowwillashwiththelastpowerlevel

request setting (See Fig. 1). If the cookware does not

meet the correct conditions, the cooking zones may not

heat.

Fig. 1

It is recommended that you lower the requested power

level setting before correcting the pan sensing message.

NOTE

Fig. 2

Correct Incorrect

• Cookware centered correctly

on cooking zone.

• Flat pan bottom and straight

sides.

• Pan size meets or exceeds

the recommended minimum

size for cooking zone.

• Pan rests completely and is

level on the cooktop surface.

• Pan is properly balanced.

• Pan does not meet the minimum

size required (too small) for

cooking zone.

• Pan bottom rests on cooktop

edge.

• Heavy handle tilts pan.

• Cookware not centered on cook-

ing zone.

• Curved or warped pan bottoms

or sides.

• Cookware base material has

good magnetic characteristics.

• Cookware base material is

non-magnetic.

INDUCTION COOKING ZONES

Pan sensing-induction cooking zones (cont’d)

Minimum pan size

Induction cooking zones require a minimum pan size in

order to activate. The graphics on each cooking zone

location are your guide to the correct minimum pan size

for that zone.The shorter lines guide the minimum pan

size (see Figure 1). The cookware bottom must meet the

minimum area for the heating process to begin.

If a pan that is induction-capable is centered properly

but is too small, the affected cooking zone display will

ashthelastpowerlevelsettingandthepanwillnot

heat. Select a larger pan that meets the minimum size

requirement to activate the cooking zone.

See Figure 1 for the minimum pan size requirements for

each cooking zone location.

The graphics on each cooking zone location are your guide

to the correct maximum pan size for that zone.The longer

lines guide the maximum pan size (see Figure 1).

It is recommended to not use pans with bottoms that

extend more than 1/2” (13mm) beyond any of the longer

line marks provided on the cooktop.

The cookware must make full contact with the ceramic

glass surface. Cookware should not rest on or touch the

metal edges of the cooktop.

Maximum recommended pan size

Fig. 1 - Induction cooking zones minimum pan size requirements

3.5 inch (90mm)

minimum

5.5 inch (140mm)

minimum

8.25 inch (210mm)

minimum

cookware should not exceed 1/2 inch (13mm)

from the outer cooking zone markings

4.5 inch (110mm)

minimum

INDUCTION COOKING ZONES

Cooktop display windows

The range backguard provides a digital window for each

of the cooking zones located on the cooktop. Power levels

and messages are easily monitored and controlled using

the window displays in combination with the corresponding

control knobs.

Available power level settings

The cooktop control (Fig. 1) will display power levels

ranging from Pb (power boost, Fig. 2), Hi (Fig. 3) to Lo

(Fig. 4).

The settings between 9.5 (Fig. 5) and 1.5 (Fig. 7)

decrease and increase in 0.5 increments.

Use the “Suggested cooking zone power level settings

table” provided in Setting Surface Controls section to

determine the correct power level setting for the type of

food you are preparing.

The induction cooking zones will not operate when the

oven is set for Sabbath mode. For more details on the

Sabbath feature, see Setting Oven Controls section.

IMPORTANT

Pb (Power Boost) power level

When setting an induction cooking zone for Hi, the display

will initially show Pb (Power Boost) power level for up to

10 minutes (See Fig. 1). After 10 minutes the cooking zone

will automatically return to the Hi (Fig. 3) setting. The

Pb setting is only available immediately after activating a

cooking zone by turning the knob to Hi.

(HE) Hot surface window message

After using an induction cooking zone, the cooktop

may become very hot. After turning any cooking zone

OFF, the cooktop may remain HOT for some time. The

corresponding HE (hot element - Fig. 8) message will

remain ON until the cooktop has cooled.

ESEC Error Indicator Message (Er)

Anerrormessagewillbedisplayed(ashing“Er”) (Fig. 6)

at power up (or after a power failure) if ANY of the surface

control knobs were left in the ON positions. If a power

failure should ocur, be sure to set all of the 4 surface

control knobs to the OFF position (See Fig. 1). This will

reset the surface controls.

Be sure to reset the clock (See page 19). Once the surface

controls have been set to the OFF positions and the clock

has been set with the correct time of day, the surface

controls should return to normal operation. If the surface

controls do not function and the “Er” message remains in

any display after following these procedures, contact an

authorized servicer for assistance.

(- -) Lockout window message

The (- -) message will appear whenever the Lockout, Self-

clean or Sabbath feature is active (See Fig. 9). Refer to the

Lockout instructions for more details.

Fig. 1

Fig. 3

Fig. 4

Fig. 6 Fig. 7

Fig. 8

Fig. 9

Fig. 5

Fig. 2

SETTING SURFACE CONTROLS

Be aware that induction cooking may decrease the amount

of time required to preheat a cooking utensil compared

to cooking on a radiant element cooktop or gas surface

burner.

Whenever using the cooktop or oven always pay close

attention to all food items cooking and remain very

attentive until all the cooking processes are complete.

Pan preheat recommendations

IMPORTANT

Remember that induction surface cooking will initially

heat the cooking utensil very quickly.

1. Place induction cookware on the desired cooking

zone.

2. To activate the cooking zone, push in and turn the

control knob in either direction to the desired setting.

3. Adjust the power level by turning the knob. This

will decrease or increase the power level. Power

levels 9.5 through 1.5 decrease and increase by 0.5

increments. Lo is the lowest power level available.

4. Once cooking is complete, turn the control knob to

OFF and remove cookware.

Step

To operate induction cooking zones:

• The suggested power level settings shown in Fig. 1

are based on cooking with medium sized pans with

lids. Be sure to make any further setting adjustments

needed for best surface cooking results.

• The size and type of utensil used, and the amount

andtypeoffoodbeingcookedwillinuencethe

setting needed for best cooking results.

NOTES

Fig. 1

Operating induction cooking zones

Start most surface cooking on a higher setting and then

adjusttoalowersettingtonishcooking.

The suggested settings (provided in Fig. 1) may vary

slightly depending on the cookware design, quality and

amount of food being prepared.

Be sure to use quality cookware that is constructed with

magnetic base material and meets the minimum and

maximum pan size requirements.

Suggested cooking zone power level settings

Settings

Type of cooking

Power boost (Pb)

High (8.0-Hi)

Medium high

(5.0 - 8.0)

Medium (4.0 - 5.0)

Medium low

(2.0 - 4.0)

Low (Lo - 2.0)

Use to start heating pans that

contain large amounts of food

or to bring large pans of water

to boil

Start most foods, bring water to

a boil, pan broiling

Continue a rapid boil, fry, deep

fat fry

Maintain a slow boil, thicken

sauces and gravies or steam

vegetables

Keep foods cooking, poach, stew

(3.0 or lower is a simmer setting)

Keep warm, melt, simmer

SETTING SURFACE CONTROLS

• Unlike radiant surface elements, the induction

cooking zones will not glow red when they are hot.

The glass surface may be hot from residual heat

transferred from the cookware and burns may occur.

• Do not touch hot cookware or pans directly

with hands. Always use oven mitts or pot holders to

protect hands from burns.

• The cooking zones may appear to have cooled after

they have been turned OFF. The glass surface

may still be hot from residual heat and burns may

occur if the cooktop is touched before it has cooled

sufciently.

• Do not place ammable items such as plastic

salt and pepper shakers, spoon holders or plastic

wrappings on the cooktop when it is in use. These

items could melt or ignite if placed too close to hot

cookware.

CAUTION

• The HE (hot element) message will appear in the

display windows once a heating element or cooking

zone is turned OFF and will remain ON until the

heatingsurfaceareaorareashavecooledsufciently.

• Do not allow aluminum foil, or ANY material

that can melt to make contact with the ceramic

glass cooktop. If these items melt on the cooktop

they may damage the ceramic cooktop.

• If the cookware is moved from the center of any

active induction cooking zone, the pan sensor will

detect the situation and the cookware will no longer

heat. The affected cooking zone display window will

ashuntilthecookwareismovedbacktocenter

of cooking zone. If the cookware is placed back

properly centered on the cooking zone, the zone will

resume heating. The cooking zone will remember the

power level setting for up to 3 minutes before the

cooking zone will automatically shut OFF.

The electronic processes involved with induction cooking

may create some background noises. You may hear a

slight “buzzing” sound when cooking on the cooktop.

These noises are part of the induction cooking process are

considered normal.

Some cookware will “buzz” depending on the construction

or base material. The “buzz” may be more noticeable if

the contents of the pan are cold. As the pan heats up,

the noise will decrease. The noise will also decrease if the

power level setting is reduced.

Cooktop operational noises

NOTE

When using the induction cooktop, operational noises

are more noticeable while cooking at the “Pb” level.

Very loud noises are not part of normal induction

cooking.

Oven vent location

The oven vent is located under the left side of the

control panel (See Fig. 1). When the oven is on, warm

air passes through this vent. This venting is necessary for

proper air circulation in the oven and good baking results.

Do not block the oven vent.

oven vent location

Fig. 1

SETTING SURFACE CONTROLS

To operate warmer zone:

1. Place cookware on the warmer zone.

2. Push in and turn the warmer zone’s control knob to the

On position, indicated by the semi-circle line around the

knob. You may turn the knob either way (left or right)

to activate the burner. (The warmer zone indicator light

will turn on).

3.Whennished,turnthecontrolknobtotheOFF position.

Step

• Radiant surface elements may appear to have cooled

after they have been turned off. The glass surface

may still be hot and burns may occur if the glass

surface is touched before it has cooled.

• Do not place ammable items such as plastic

salt and pepper shakers, spoon holders or plastic

wrappings on top of the range when it is in use.

These items could melt or ignite. Potholders, towels or

woodenspoonscouldcatchreifplacedtoocloseto

the surface elements.

CAUTION

Warmer zone

The purpose of the warmer zone is to

keep foods at serving temperature,

such as: vegetables, gravies,

casseroles, soups, stews, breads,

pastries and oven-safe dinner plates.

Warmer zone setting

The warmer zone is a traditional cooktop element. It

does not use induction technology. As a result, magnetic

cookware is not required to activate the heating operations

for this portion of the cooktop. When the control knob is

turned and the heat is activated, the knob’s light will glow.

In addition, after the knob is returned to the OFF position,

the burner will remain warm for a certain amount of time-

-the indicator light will continue to glow until the heating

surfaceareahascooledsufciently.

For best results, when warming pastries or breads, the

cover should have an opening to allow moisture to escape.

Do not use plastic wrap to cover food. Plastic may melt

ontothesurfaceandbeverydifculttoremove.Useonly

dishware, utensils and cookware recommended for oven

and cooktop use.

Always start with hot food. Do not heat cold food on the

warmer zone. All food placed on the warmer zone should

be covered with a lid to maintain quality.

CAUTION

• The warmer zone is radiant heat, but it will not glow

red when it is hot.To avoid possible burns always use

potholders or oven mitts when moving food to and

from the warmer zone as cookware and plates will

be hot.

BEFORE SETTING OVEN CONTROLS

The at oven rack or at handle oven rack (some

models) may be used for most cooking needs.

The half rack (some models) design comes with a

removable section that allows for taller cooking utensils.

The offset oven rack (some models) is designed to

place the base of the rack about 1/2 of a rack position

lower than normal. This rack design provides several

additional possible positions between the standard

positions.

To maximize oven cooking space place the bottom oven

rack (some models) in the lowest rack position for baking

or roasting large cuts of meat.

The Effortless™ Oven Rack (some models) is described

in the “Effortless™ Oven Rack system” section.

Removing, replacing & arranging racks

Air circulation in the oven

For best baking results allow at least 2 inches (5 cm)

around the cookware for proper air circulation and be

sure pans and cookware do not touch each other, the oven

door, sides or back of the oven cavity. Hot air must be able

to circulate around the pans and cookware in the oven for

even heat to reach around the food.

Types of oven racks

at

oven rack

athandle

oven rack

bottom

oven rack

offset

oven rack

half oven

rack

To remove - pull the rack

forward until it stops. Lift

up front of rack and slide

out.

To replace-ttherack

onto the guides on the

oven walls. Tilt the front of

the rack upward and slide

the rack back into place.

Arranging - always

arrange the oven racks

when the oven is cool (prior

to operating the oven).

Only the Effortless™ Oven Rack should be used

in oven rack position 2. Placing any other rack in

rack position 2 will prevent the oven door from fully

closing.

IMPORTANT

Always use oven mitts when using the oven.

When using the appliance, oven racks and cooktop will

become very hot which can cause burns.

CAUTION

Effortless™ Oven Rack system

Some models are equipped with a special oven rack

system that automatically extends the oven rack to assist

in access to your food items. This rack extends when the

oven door is opened or closed.

To assemble the Effortless™ Oven Rack system:

1. Locate all required parts. You will need the supplied

ovenrack(Effortless™OvenRackisaatrackwith

a special dark coating on the left and right rack

sides) and the 2 supplied chrome connector arms.

2. Open the oven door. Be sure the oven is completely

cool before proceeding.

3. Place the oven rack in positions 2, 3 or 4 only (see

previous page to verify positions). Be sure the rack

connector brackets are at the rear of the range and

pointing towards oven bottom (See Fig. 2).

4. Assemble one connector arm at a time. With the

oven door open and the oven rack in place, install

one end of the connector arm to the hole in the door

connector bracket (Fig. 1) and the other end in the

hole in the rack connector bracket (Fig. 2 and as

in Fig. 3). The oven rack may need to be adjusted in

or out in the rack position to match the length of the

connector arm.

5. While holding the connector arm in place, twist the

connector arm so the ends of the connector arm point

upwards (See Figs. 4 & 5). The connector arm should

now be locked into position.

6. Repeat steps 4 and 5 for the other connector arm.

7. Once both connector arms are properly in place, be

sure to test the oven rack operation by gently closing

the oven door. The oven rack should move in and out

of the oven freely when the door is opened or closed.

Fig. 6 - Effortless™ Oven Rack after assembly

left and right

door connector

brackets

with connector arm ends

shown in locked position

(pointing upwards)

connector

arm

connector

arm

Fig. 5

door con-

nector

bracket

rack connector

bracket

connector

arm

connector

arm

oven

rack

open oven

door

Fig. 2

Fig. 1

Fig. 3 - assembly

of the Effortless™

Oven Rack

• Only the Effortless™ Oven Rack system should

be used in oven rack position 2. Placing ANY other

rack in oven rack position 2 will prevent the oven door

from fully closing and may damage the oven door,

oven cavity or the door connector brackets.

• If the rack system is not assembled with the connector

arms the Effortless™ Oven rack may be used in oven

rack positions 2 thru 6. Do not attempt to use the

Effortless™ Oven rack in rack position 1.

Fig. 4

CAUTION

• REMOVE ALL OVEN RACKS and accessories

before starting a self-clean cycle. If the oven

racks are left in the oven during the self-clean cycle,

the gliding ability of the Effortless™ Oven Rack system

will be damaged and oven racks will loose their shiny

nishandmayturnblue.RemoveALL oven racks and

clean according to instructions provided in the Care &

Cleaning section of this manual.

• Make sure the oven and oven racks are COMPLETLY

cool before attempting to assemble or disassemble

the Effortless™ Oven Rack system. Never pick up

hot oven racks or parts.

BEFORE SETTING OVEN CONTROLS

READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.

OVEN CONTROL FUNCTIONS

1 2

3 4

10 11 12

13 14 15

17 18

10. probe — Use to set and monitor the meat probe.

11. keep warm — Use to set the keep warm features.

12. quick preheat — Use to quickly preheat the oven.

13. bake —Use to set the normal Bake feature.

14. convect — Use to set and toggle between the

convection bake, roast, and broil features.

15. broil — Use to set broil feature.

16. numeric keypad — Use to enter temperature and

times.

17. start — Use to start all oven features (not used with

oven light).

18. off — Use to cancel any oven mode previously entered

except the oven lockout, time of day & minute timer.

Press off to stop cooking.

Minimum & maximum control settings

All of the features listed have minimum

and maximum time or temperature settings

that may be entered into the control. An

acceptance beep will sound each time a

control pad is touched (the Oven Lockout

pad is delayed by 3 seconds).

An ERROR tone (3 short beeps) will sound if

the temperature or time entered is below the

minimum or above the maximum settings for

the feature.

1. convect convert — Use to convert a standard bake

recipe to a convection bake recipe.

2. self-clean — Use to set a 2, 3 or 4 hour self-clean

cycle.

3. delay start — Use with bake, convect, convect

convert and self-clean features to program a

delayed time bake or delayed self-cleaning cycle.

4. bake time — Use to enter the length of baking time

needed.

5. set clock— Use to set the time of day.

6. timer on/off — Use to set or cancel the minute timer.

7. oven light —Use to turn the oven light ON and OFF.

8. oven lockout — Use to activate oven lockout setting.

9. oven control display — Use to view active features,

temperatures, and cooking times.

Feature

quick preheat temperature

bake temperature

broil temperature

timer

self-clean time

convect bake

convect roast

convect broil (some models)

Min. temp. /time

170°F / 77°C

400°F / 205°C

1 Min.

2 hours

170°F / 77°C

400°F / 205°C

Max. temp. /time

500°F / 260°C

550°F / 288°C

11 Hrs. 59 Mins.

4 hours

500°F / 260°C

550°F / 288°C

SETTING OVEN CONTROLS

Changing oven temperature display

The oven control is preset to display °F (Fahrenheit) when

shipped from the factory.

To change the temperature to display °C (Celsius)

(oven should not have bake or self-clean active

when setting this feature):

Setting the clock

Whentherangeisrstpoweredup,“12:00”willashin

the display (See Fig. 1).

To set the clock to 1:30:

Step Press

1. Press set clock.

2. Enter 1:30.

3. Press start.

Changing between continuous bake setting

or 6-Hour Energy Saving feature

The oven control has a factory preset built-in 6 Hour

Energy Saving feature that will turn off the oven if it is left

on for more than 6 hours. The control can be programmed

to override this feature to continuously bake.

To turn off 6-Hour Energy saving mode:

Step Press

1. Press and hold timer on•off

for 6 seconds.

2. Press self-clean

to toggle between “6 Hr OFF”

(Fig. 2) or “StAY On” (Fig. 3).

Select “StAY On” to turn off

6-Hour Energy Saving mode.

3. Press start to accept.

Fig. 2 Fig. 3

Setting 12 or 24 hour display mode

The clock display mode allows you to choose between 12

or 24 hr mode. The factory pre-set clock display mode is

12 hr. See the example below to change the default mode

to 24 hr display.

To set 12 or 24 hour mode:

Step Press

1. Press and hold set clock

for 6 seconds.

2. Press self-clean

to toggle between “12 Hr dAY”

or “24 Hr dAY” display modes

(See Figs. 4 & 5).

3. Press start to accept.

Step Press

1. Press and hold broil for

6 seconds.

2. Press self-clean to toggle

between “FAhrn ht” or

“CELSIUS” temperature display

modes (Figs. 6 & 7).

If Celsius display is needed, select

“CELSIUS”.

3. Press start to accept.

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Fig. 1

It is recommended to always set the clock for the

correct time of day before using the appliance. The

clock cannot be changed if any timed or delayed time

feature is active.

NOTE

SETTING OVEN CONTROLS

Setting lockout

The control may be programmed to lock the oven door,

lock the cooktop and lock the oven control keypad.

Fig. 1

Fig. 2

Setting a silent control panel

Silent mode allows the oven control to operate without

sounds. The control may be programmed for silent

operation and later returned to operating with all the

normal sounds.

To set silent mode:

Step Press

1. Press and hold

delay start for 6 seconds.

2. Press self-clean

to toggle between “bEEP On” or

“bEEP OFF”. Select “bEEP OFF” for

silent mode. (Figs. 1 & 2)

3. Press start to accept

To set the lockout feature:

Step Press

Press and hold lock pad for 3 seconds.

“door Loc” will appear in the display until

the oven door is completely locked.

Setting the minute timer

The timer allows you to track your cooking times without

interfering with the cooking process. The timer may be set

from 1 minute up to 11 hours and 59 minutes.

To set the timer for 5 minutes:

Step Press

1. Press timer on•off.

2. Enter 5 minutes.

3. Press start.

Press timer on•off to turn

the minute timer off.

Press and hold lock pad for

3 seconds. Once the oven door has

unlocked the “door Loc” message will

no longer display (See Fig. 3).

To unlock the lockout feature:

Step Press

Fig. 3

DO NOT attempt to open the oven door while the

“door Loc” (door lock) message is visible. Allow 15

seconds for the oven door to completely lock. Once

the oven door has locked, the current time of day will

reappear in the display. If a control pad is pressed

when the oven lockout feature is active, the error tone

indicates the control pad is not available when the oven

lockout is active.

NOTES

The minute timer will display hours and minutes

until 1 hour remains on the timer. Once less than 1

hour remains, the display will count down in minutes

and seconds. Once the timer has less than 1 minute

remaining only seconds will display.

The minute timer does not start or stop the cooking

process. It serves as an extra timer in the kitchen that

will beep when the set time has run out. The minute

timer can be used alone or while using other oven

features. The minute timer cannot be used with self-

clean feature or when the oven door is locked.

When the minute timer is in use during a cooking

process, the minute timer will be shown in the display.

To view the status of other features, press the pad once

for the other feature to view the status of that feature.

NOTES

Setting bake time

Use the timed bake feature to automatically turn the oven

off after a desired length of time.

The default maximum bake time setting is 6 hours.

After the bake time feature has been activated, press

the bake time pad to display the bake time remaining.

The bake time feature may be set with the convect

bake and convect roast features. Bake time will not

operate with the broil feature.

NOTES

1. Press bake time.

2. Enter 30 minutes.

3. Press start.

4. Press bake.

5. Press start.

To set bake with the default temperature (350ºF) and

end after 30 minutes:

Step Press

When the set bake time runs out:

1. “END” will appear in the display window and the oven

will shut-off automatically.

2. The control will beep 3 times every 30 seconds as a

reminder until the cancel key pad is pressed.

FOOD POISONING HAZARD. Do not let food sit for

more than one hour before or after cooking. Doing so

can result in food poisoning or sickness.

WARNING

The convection fan will begin rotating once the

bake or bake time features are started. The convection

fan will turn off once the set oven temperature is

reached.

1. Press bake.

2. Press start

Setting bake

Use the bake feature to cook most food items that require

normal cooking temperatures. A reminder tone will sound

once the oven reaches the set temperature. Bake can be

set at any temperature from 170°F to 500°F.

To set bake using a default temperature of 350°F:

Step Press

SETTING OVEN CONTROLS

Baking layer cakes with 1 or 2 oven racks

When using a single oven rack, position rack so cookware

is in the middle of the oven. For best results when baking

cakes and cookies, use convection bake. When using

radiantbakeusingtwoatovenracks,placecookwareon

rack positions 2 and 5 (see Figure 1). Place pans as shown

in Figure 2.

The oven will bake no longer than 6 hours from the last

time the oven door was opened.

If you wish to bake longer than 6 hours, see “Changing

between continuous bake setting or 6-Hour Energy

Saving feature” for further instructions.

NOTES

To set bake for oven temperature of 425°F:

Step Press

1. Press bake.

2. Enter 425.

3. Press start

Fig. 1

Fig. 2

SETTING OVEN CONTROLS

When the set bake time runs out:

1. “END” will appear in the display window and the oven

will shut-off automatically (See Fig. 2).

2. The control will beep 3 times every 30 seconds as a

reminder until the cancel key pad is pressed.

To program the oven for a delay start and to shut-off

automatically (example for baking at 375°F for 50

minutes and starting at 5:30):

Step Press

Setting delayed bake time and timed bake

The delay start feature allows you to set a starting and

ending time to the baking process. Prior to setting a delay

start, be sure the time of day is set correctly. If the delay

start needs to be set more than 12 hours in advance

(12-24hours),thecontrolmustrstbeprogrammedfor

24 hour display mode. See “Setting 12 or 24 hour display

modes” section.

After the delay start feature has activated and started

the cooking process, press the bake time pad to

display the bake time remaining.

The delay start feature may be used with the

convect or convect convert cooking features. Bake

time will not operate when using the broil or convect

broil features.

NOTES

FOOD POISONING HAZARD. Do not let food sit for

more than one hour before or after cooking. Doing so

can result in food poisoning or sickness.

WARNING

Fig. 1

Fig. 2

1. Press bake time.

2. Enter 50 mintues.

3. Press start.

4. Press delay start (See Fig. 1).

5. Enter 530.

6. Press start.

7. Press bake.

8. Enter 375.

9. Press start.

Fig. 3

Setting quick preheat

Use the quick preheat feature for single rack baking to

quickly heat the oven. Use this feature only for standard

baking. A reminder tone will sound indicating when to

place the food in the oven.

Whentheovenisnishedpreheating,quickpreheatwill

change to the bake feature and continue to bake until

cancelled.

1. Press quick preheat.

2. Press start (See Fig. 3).

To set quick preheat with a default set temperature

of 350°F:

Step Press

For batter and dough-based baked good such as cakes,

pastries and breads, use the standard bake function for

best results

IMPORTANT

Convect roast

Suggestion for convect roast

1. Preheating is not necessary when roasting foods using

convect roast.

2. Since convect roast cooks food faster, reduce the

cook time by 25% from the recommended cook

time of your recipe (check the food at this time).

If necessary, increase cook time until the desired

doneness is obtained.

3. Do not cover foods when dry roasting - this will

prevent the meat from browning properly.

Convect bake

Suggestions for convect baking

1. Preheat the oven when baking foods such as cookies,

biscuits and breads.

2. Reduce oven temperature 25°F/14ºC from recipe’s

listed oven temperature. Follow the minimum

recommended cook time.

3. When using a single oven rack, position rack so

cookware is in the middle of the oven.

4. When using two oven racks at the same time, place

in positions 2 and 5 for best results (see Fig. 2). Place

pans as shown in Figure 3.

Convection Cooking

Benets of the convect feature

— Foods may cook up to 25 to 30% faster, saving time and

energy.

— No special pans or bakeware needed.

— Recommended cooking method for baked goods such as

cakes, biscuits, pastries, and bread.

Convect uses a fan to circulate heat inside the oven.

Improved heat distribution allows for fast, even cooking

and browning. It gives better baking results when using

two racks at the same time.

NOTES

• When choosing between the convect features, use

the convect key to choose convect bake, convect

roast or convect broil functions.

• When using convection, cook time reductions may

vary depending on the amount and type of food

being cooked.

• The convection fan will begin rotating once

convection bake or convection roast has been

activated.

1. Press convect.

2. Press start (See Fig. 4).

To set convect (convection bake) with a default oven

set temperature of 350°F:

Step Press

Fig. 4

1. Press convect.

2. Press convect again.

3. Press start (See Fig. 5).

To set convect roast (convection roast) with a

default oven set temperature of 350°F:

Step Press

Fig. 5

SETTING OVEN CONTROLS

Fig. 1

Fig. 3

Fig. 2

SETTING OVEN CONTROLS

Suggestions for convect broil:

1. When using a broil pan, carefully follow all

recommended instructions for placing the oven racks

as provided in the “Broil” section in this Use & Care

Guide.

2. Since convect broil cooks food faster, reduce the

cook time by 25% from the recommended cook

time of your recipe (check the food at this time).

If necessary, increase cook time until the desired

doneness is obtained.

3. Close the oven door when using convect broil.

Convect broil

Use the convect broil feature to cook thicker cuts of

meats that require direct exposure to radiant heat and the

convection fan for optimum browing results.

Setting convect convert

The convect convert feature allows you to convert any

baking recipe using the convect (convection) feature. The

control uses the normal recipe settings and adjusts to a

lower temperature for convection baking. Convect convert

can only be set with the convect bake feature.

To set convect using default oven set temperature

of 350°F and adding the convect convert:

Step Press

1. Press convect.

2. Press convect convert.

1. Press convect key 3 times.

2. Press start (See Fig. 1).

To set convect broil with a default oven set

temperature of 550°F:

Step Press

NOTE

Fig. 1

The convection fan will begin rotating once

convection broil has been activated.

NOTES

• When convect convert is used with bake time , the

convect convert feature will display a “CF” for check

food when the bake time is 75% complete (See Fig.

2). At this time the oven control will sound one long

beep at regular intervals until the set cook time has

nished.

Fig. 2

• The convection fan will begin rotating once

convection bake or convection roast has been activated.

• When using convect convert, cook time reductions may

vary depending on the oven set temperature.

• The minimum amount of cook time allowed using the

convect convert feature with a bake time or a delay

time bake setting is 20 minutes.

• Layer cakes will have better results using the normal

bake feature.

Probe

• Insert the probe so that the tip is centered in the

thickest part of the food (see Fig. 2). For best results, do

not allow the probe temperature sensor to contact bone,

fat, gristle, or cookware.

• For bone-in ham or lamb, insert the probe into the

center of lowest large muscle or joint. For dishes such as

meat loaf or casseroles, insert the probe into center of

food.Whencookingsh,insertmeatprobejustabove

the gill.

• For whole poultry or turkey, insert the probe sensor into

the thickest part of inner thigh, just below the leg (See

Fig. 3).

Proper probe placement in food:

For some food types, especially poultry and roasts, using

a probe to check the internal temperature is the safest

possible method to ensure properly cooked food.

The probe feature, when set correctly, will alert when the

internal food temperature reaches the desired “target”

temperature.

When active, the probe will display the internal food

temperature, eliminating the need for any guesswork.

To avoid the possibility of burns after cooking with the

probe, use care when disconnecting the probe from the

receptacle or food. The probe may be hot. Be sure to

always use a pot holder to protect your hands.

CAUTION

Use the probe for best results when cooking foods such

as roasts, hams or poultry. The probe also works well with

foods such as meat loaf and casseroles.

Fig. 3

Fig. 2

Insert

probe tip

to center of

food

Fig. 1

handle

probe

cable

probe

sensor

handle

• To avoid damaging the probe, do not use kitchen

utensils such as tongs to pull on the probe cable or

handles. Always insert and remove the probe using

the provided handles (See Fig. 1) and always use a

pot holder to protect hands from possible burns.

• Do not store the probe inside the oven. Always

removetheprobefromtheovenwhennished.

• Use only the original probe provided with this

appliance. Connecting any other probe or device into

the probe receptacle could result in damage to the

oven control, electronics and the receptacle.

• Before starting self-clean, check that the probe

is removed from the oven interior. The high

temperatures during self-clean may damage or destroy

the probe.

• To avoid damaging the probe, defrost frozen foods

completely before inserting.

IMPORTANT

SETTING OVEN CONTROLS

Probe (cont’d)

† The U.S. Department of Agriculture states, “Rare

fresh beef is popular, but you should know that

cooking it to only 140°F/60°C means some food

poisoning organisms may survive.” (Source: Safe

Food Book, Your Kitchen Guide, USDA Rev. June 1985.)

Information courtesy the U.S. Department of Agriculture

Food Safety and Inspection Service.

Visit the U.S. Department of Agriculture Food Safety and

Inspection Service website at www. fsis.usda.gov

To set probe:

1. Insert the probe into the food.

2. Place prepared food on the desired oven rack position

and slide into the oven.

3. Plug the connector end of the probe all the way

into the receptacle while the oven is still cool. The

receptacle is located on the upper left front oven

cavity wall (Fig. 1).

4. When the probe is detected, a tone will sound, the

icon will illuminate and the current probe temperature

will appear in the display (Fig. 2). Close the oven door.

5. Press keypad once.

6. Enter the desired temperature for food type (Refer

to USDA Chart) using the numeric keypad. The

minimum target setting is 140ºF/60ºC; the maximum

target setting is 210ºF/99ºC. The default target is

170ºF/77ºC.

7. Press to accept the target temperature.

8. Set for quick preheat, bake, convect bake,

convect roast or convect convert and if necessary

adjust the oven temperature accordingly.

9. The control will sound 3 beeps when the internal

target temperature is reached. By default the oven will

change to keep warm (“HLd” and the actual probe

temperature will alternate in the display). keep warm

will maintain the oven temperature at 170° F (77°C)

for 3 hours unless otherwise cancelled.

To stop cooking at any time press cancel.

USDA recommended minimum internal cooking

temperatures:

Food type Internal temp.

Ground meat & meat mixtures

Beef, Pork, Veal, Lamb 160°F (71°C)

Turkey, Chicken 165°F (74°C)

Fresh beef, veal, lamb

Medium rare† 145°F (63°C)

Medium 160°F

(71°C)

Well done 170°F (77°C)

Poultry

Chicken & Turkey, whole 165°F (74°C)

Poultrey Breasts, Roasts 165°F (74°C)

Poultrey Thighs, Wings 165°F (74°C)

Duck & Goose 165°F (74°C)

Stufng(cookedaloneorinbird)  165°F

(74°C)

Fresh pork 160°F (71°C)

Ham

Fresh (raw) 160°F (71°C)

Pre-cooked (to reheat) 140°F (60°C)

Eggs & egg dishes

Eggs   Cookuntilyolk&whitearerm.

Egg dishes 160°F (71°C)

Leftovers & Casseroles 165°F (74°C)

Fig. 2

Fig. 1

receptacle

probe

connector

handle

Probe (cont’d)

To set the oven to continue cooking after reaching

the target temperature:

1. Press keypad and hold for 6 seconds.

2. Press keypad and toggle until the “Continu”

message appears (Fig. 1) then press to accept.

To set the oven to automatically stop cooking and

start keep warm once reaching target temperature:

1. Press

keypad and hold for 6 seconds.

2. Press keypad and toggle until “CAnCEL”

message appears (Fig. 2) then press to accept.

Choosing a setting for how the oven will operate

once the probe reaches the target temperature

Your oven is factory preset to automatically stop cooking

and start the keep warm feature once the probe sensor

reaches the set target temperature. This setting may be

changed to continue cooking if desired.

IMPORTANT

Setting the option for how the oven will heat once the

probe reaches the target temperature must be done

when the oven is inactive. The probe is not required to

be connected to the probe receptacle when setting this

option.

Fig. 2

Fig. 1

NOTES

• During the cooking process, the internal food

temperature will display by default. To review the

target temperature, press the

key once. After

6 seconds the display will return to the internal food

temperature.

• To assure temperature accuracy, do not remove the

probe from the food or receptacle until the desired

internal temperature is met.

• If the probe feature is active but the probe is removed

from the receptacle, the probe feature will cancel but

the oven will continue to cook.

• If the probe is active and the probe is removed from

the food, the probe feature will remain active. The

displayed internal food temperature may no longer

be reliable. This may eventually cause a “Probe Too

Hot” message.

• The oven will automatically turn OFF if the probe

sensor reaches 300°F (149°C) or more.

• The probe feature cannot be set with broil,

convection broil, or self-clean.

• To change the target temperature while cooking,

press the keypad once. Use the numeric keypad

to change the target temperature. Press the start key

to accept any change.

SETTING OVEN CONTROLS

Probe (cont’d)

“Probe Too Hot” message:

If the message “Prob” ... “Too”... “Hot”...ashesinthe

display, the probe sensor temperature has exceeded 250°F

(121°C). If the probe is not removed, this message may

continue until the sensor reaches 300°F (149°C) or higher,

at which time the oven will turn OFF and display “Prob

ERR” message.

This message may occur if the probe sensor is exposed to

direct oven heat or the food internal temperature is over

250°F (121°C). Be sure the probe sensor is fully inserted

into food. If the food is done, press cancel and remove

food and probe from the oven.

If the error message “Prob ERR” displays, check to

be sure the probe connector is fully inserted into the

receptacle. If the probe is fully inserted in the receptacle

and the error message continues, the probe may need to

be replaced.

If “Prob ERR” displays, the oven control will deactivate all

other features until corrected or the probe is removed. If

the error message continues, remove the probe from the

receptacle and oven.

Probe error message:

Use the broil function to cook meats that require

direct exposure to heat for best browning results.

When broiling, always remember to arrange the oven

racks while oven is still cool. Position the oven rack as

suggested in the broil settings table (See Fig. 4).

Broil

1. Place the food on appropriate

cookware. If using a broiler pan with

an insert, remember to follow all

warnings and cautions.

2. Arrange the interior oven rack to

recommended position (Fig. 1 and

Fig. 4). For best browning results,

preheat oven for 5 minutes before

adding food.

3. Be sure to place food directly

under upper oven element. Leave the

oven door open to the broil position

(Fig. 2).

4. Press broil.

5. Press start (See Fig. 3)

To set broil:

Step Press

Suggested broil settings table (electric oven)

Food Rack position Setting Cook time in minutes

1st side 2nd side Doneness

Steak 1” thick 6th or 7th* 550°F 6 4 Medium

Steak 1” thick 6th or 7th* 550°F 7 5 Medium-well

Steak 1” thick 6th or 7th* 550°F 8 7 Well

Pork chops 3/4” thick 6th 550°F 8 6 Well

Chicken-bone in 5th 450°F 20 10 Well

Chicken-boneless 6th 450°F 8 6 Well

Fish 6th 550°F - as directed - Well

Shrimp 5th 550°F - as directed - Well

Hamburger 1” thick 7th* 550°F 9 7 Medium

Hamburger 1” thick 6th 550°F 10 8 Well

Fig. 4

*Use the offset or bottom oven rack if you choose to use rack position 7.

NOTE

Always pull the oven rack out to the stop position

before turning or removing the food.

Fig. 3

WARNING

Shouldanovenreoccur,closetheovendoorand

turntheovenOFF.Iftherecontinues,useare

extinguisher. DO NOTputwaterorouronthere.

Flour may be explosive.

Fig. 2

Fig. 1

SETTING OVEN CONTROLS

Setting keep warm

The keep warm feature will keep foods warm for serving

up to 3 hours. The keep warm feature may be used alone

oraftercookinghasnishedusingbake time and or

delay start.

1. Press keep warm.

2. Press start.

The keep warm temperature and the warm icon will appear

in the display (Fig. 1).

Step Press

To set the oven to keep warm:

To set the oven to keep warm automatically after bake

time has ended:

1. Program the desired cook time

or delay start.

2. Program the desired baking function

3. When cooking program is started,

press keep warm.

4. Press start.

Step Press

The keep warm feature will come on when the cooking is

nished.Thekeepwarmtemperatureandthewarmicon

will appear in the display (Fig. 1).

Fig. 1

Operating the oven light

The interior oven light will automatically turn ON when the

oven door is opened.

Press

to turn the interior oven light ON and OFF

whenever the oven door is closed.

The interior oven light is located at the upper left rear wall

of the oven interior and is covered with a glass shield.

The glass shield must be in place whenever the oven is

in use. The shield will protect the halogen bulb from food

splatters.

To change the interior oven light, see “Changing the oven

light” in the Care & Cleaning section.

FOOD POISONING HAZARD. Do not let food sit for

more than one hour before or after cooking. Doing so

can result in food poisoning or sickness.

WARNING

The keep warm feature will automatically turn the oven

off after 3 hours.

NOTE

Your appliance has been factory calibrated and tested

toensureanaccuratebakingtemperature.Fortherst

few uses, follow your recipe times and temperature

recommendations carefully. If you think the oven is

cooking too hot or too cool for your recipe times, you can

adjust the control so the oven cooks hotter or cooler than

the temperature displayed.

The oven temperature may be increased +35°F (+19°C)

or decreased -35°F (-19°C) from the factory settings.

Example: increase the oven temperature by 30°F:

Adjusting the oven temperature

Oven temperature adjustments made will not affect the

broil or self-cleaning feature temperatures.

If the temperature shows an adjustment of -30°F, and

a +30°F adjustment is needed, you can toggle between

the (-) or (+) in the display by pressing self clean.

DO NOT USE oven thermometers such as those found in

grocery stores to check the temperature settings inside

your oven. These oven thermometers may vary as much

as 20 to 40 degrees from actual temperatures.

Step Press

1. Press and hold bake

for 6 seconds.

2. Enter 30.

3. Press start.

Example: decrease the oven temperature by 30°F:

Step Press

1. Press and hold bake

for 6 seconds.

2. Enter 30.

3. Press self-clean.

4. Press start.

NOTES

Restoring factory default settings

When new, your appliance left the factory with

predetermined oven control default settings. Over time,

the user may make changes to these settings. The

following options have user preferences that could be

modiedandmayhavebeenchangedsincetheappliance

was new:

Step Press

1. Press and hold 7 key pad

untilrstbeepsounds

(about 6 seconds).

2. Press start.

• 12 or 24 hour display mode

• Continuous bake or 6-Hour Energy Savings mode

• Silent control panel

• Oven temperature display (Fahrenheit or Celsius)

• Adjusting the oven temperature

Please remember that if you choose to restore, ALL of

the above preferences will be restored to factory default

settings, the oven temperature offset will reset and any

stored information will be cleared.

To restore all user settings to factory default:

SETTING OVEN CONTROLS

The bake time and delay start pads are used to set

the Sabbath feature. The Sabbath feature may only be

used with the bake feature. The oven temperature may

be set higher or lower after setting the Sabbath feature

(the oven temperature adjustment feature should be used

only during Jewish Holidays), however the display will not

be visible and no audible tones will be provided when a

change occurs.

Once Sabbath mode is active, the oven will remain ON

until cancelled. The Sabbath mode will override the factory

preset 6-Hour Energy Saving feature.

If the oven light(s) are needed during the Sabbath, press

the oven light key before activating the Sabbath feature.

Once the oven light is turned on and the Sabbath feature

is active, the oven light will remain on until the Sabbath

feature is turned OFF. If the oven light needs to be off,

be sure to turn the oven light off before activating the

Sabbath feature.

It is recommended that any oven temperature change

made during active Sabbath feature active be followed

with 2 presses of the start pad. This will insure the

oven remains ON even if the attempt to set the oven

temperature was lower or higher than the oven control can

accept. If the oven temperature is set incorrectly, the oven

temperature will default to 170°F or 500°F. Try to set the

desired oven temperature again.

1. Be sure that the clock is set with

the correct time of day.

2. Arrange the oven racks and place

the food in the oven and close door.

3. Press bake.

4. Press start.

5. If a timed bake or delayed

timed bake is needed

then enter the time in this step.

If not, skip this step and continue

to step 6. Refer to the bake time

or delay start instructions.

Remember the oven will shut-off

after completing a

timed bake or delay start and

therefore may only be used once

during the Sabbath/Jewish Holidays.

The maximum delay start time

is 11 hours & 59 minutes.

6. Press and hold both the +

bake time and delay start pads

for at least 3 seconds

simultaneously.

The control will beep and SAb will appear in the display

(See Fig. 1). The oven is properly set for the Sabbath once

SAb appears in the display.

The induction cooktop will not operate when the oven is

set for Sabbath Day feature. The cooktop displays will

show the cooktop lockout “ - - ” messages whenever the

Sabbath Day feature is active (Fig. 2).

To program the oven to bake at 350°F and then

activate the Sabbath Day feature:

Step Press

FOOD POISONING HAZARD. Do not let food sit for

more than one hour before or after cooking. Doing so

can result in food poisoning or sickness.

WARNING

Setting the Sabbath ModeFeature (for use on

the Jewish Sabbath & Holidays)

For further assistance, guidelines for proper

usage and a complete list of models with

the Sabbath feature, please vist the web at

http:\\www.star-k.org.

Fig. 1

Fig. 2

To Set the Sabbath Feature (cont’d)

What to do during a power failure or power

interruption after the Sabbath feature was

activated:

Should you experience a power failure or interruption, the

oven will shut off. When power is restored the oven will

not turn back on automatically. The control will remember

that it is set for the Sabbath and the oven display will

show the message “SF” for Sabbath failure (Fig. 1).

To turn off the oven but keep the Sabbath feature

active:

Press cancel.

To turn off the Sabbath feature:

Press and hold both the

bake time and delay start pads

for at least 3 seconds. The control

will beep and SAb will disappear

from the display. The oven is no

longer programmed for the

Sabbath feature.

After the Sabbath observance, turn OFF the Sabbath

feature. At the same time press and hold both the

+ pads for at least 3 seconds.

SF will disappear from the display and the oven may be

used with all normal functions.

Fig. 1

• If a delay start time longer than 12 hours (maximum

of 24 hours) in advance is desired, set the display

mode for the 24 hour setting. For detailed instructions

see the section “Setting 12 or 24 hour display modes”.

• It is not advised to attempt to activate any other

program feature except BAKE while the Sabbath

feature is active. ONLY the following key pads will

function correctly with the Sabbath feature: 0-9

number pads, bake, start & cancel. NO OTHER

KEYS can be used once the Sabbath feature is

activated. The cooktop will also be inactive.

• You may change the oven temperature once baking

has started. Press bake , enter the oven temperature

change (170 to 500F°) and press start. Remember

that the oven control will no longer beep or

display any changes once the oven is set for the

Sabbath feature.

• If the keep warm feature was activated and the

Sabbath feature was set, the keep warm feature will

automatically shut-off the oven after 3 hours.

NOTES

SETTING OVEN CONTROLS

SELF-CLEANING

Self-cleaning

A self-cleaning oven cleans itself with high temperatures

(well above normal cooking temperatures) which eliminate

soilscompletelyorreducesthemtoanepowderedash

you can wipe away with a damp cloth.

Your oven allows you to set 3 different self-cleaning cycle

durations. A 3-hour cleaning time is best used for normal

cleaning; 2-hour time for light soils and a 4-hour time

option for heavier burnt-on soils.

During the self-cleaning cycle, the outside of the range

can become very hot to the touch. DO NOT leave small

children unattended near the appliance.

The health of some birds is extremely sensitive to the

fumes given off during the self-cleaning cycle of any

range. Move birds to another well-ventilated room.

DO NOT force the oven door open. This can damage

the automatic door locking system. Use caution

when opening the door after the self-cleaning cycle is

completed. The oven may still be VERY HOT.

Adhere to the following self-clean precautions:

• DO NOT use oven cleaners or oven protective

coatings in or around any part of the oven interior.

• DO NOT clean the oven door gasket. The woven

material of the oven door gasket is essential for a

good seal. Care should be taken not to rub, damage

or remove the gasket.

• DO NOT use any cleaning materials on the oven

door gasket. Doing so could cause damage (See

Fig. 1).

• Remove the broiler pan and insert, all utensils

and ANY ALUMINUM FOIL. These items

cannot withstand high cleaning temperatures

and will melt.

• Completely remove ALL OVEN RACKS and

ANY ACCESSORIES. If the oven racks are not

removed they will lose their special coating

properties and no longer slide in and out of

the oven cavity easily.

• Remove any excessive spillovers. Any spills on

the oven bottom should be wiped-up and removed

before starting the self-cleaning cycle. To clean,

use hot, soapy water and a cloth. Large spillovers

cancauseheavysmokeorrewhensubjectedto

high temperatures. DO NOT allow food spills with a

high sugar or acid content (such as milk, tomatoes,

sauerkraut,fruitjuicesorpielling)toremainon

the surface as they may leave a dull spot even after

cleaning.

• Clean any soil from the oven frame, the door liner

outside the oven door gasket and the small area at

the front center of the oven bottom.

These areas

heatsufcientlytoburnsoilon.Cleanwithsoap

and water. These areas are shown in white (See

Fig. 1).

CAUTION

Fig. 1

IMPORTANT

Before manually cleaning any part of the range, be sure

all controls are turned OFF and the range is COOL. The

range may be hot and can cause burns.

CAUTION

As soon as the controls are set, the motor driven door

lock will begin to close automatically. “door Loc” will

appear in the display (See Fig. 1). DO NOT open the

oven door while “door Loc” is on (allow 15 seconds for

the oven door to completely lock).

Once the door has locked “CLn” will appear in the

display indicating the oven will begin the self-clean

process (Fig. 2).

1. Press cancel.

2. Allow enough time for the oven to cool and for the

“door OPn” message to appear (Fig. 4). When this

message turns off the oven door may be opened.

If a self-clean cycle was active, then stopped or

interrupted by power failure, it may be necessary to

run a self-clean cycle again to thoroughly clean the

oven. Please be aware that you may need to allow up

to four hours before self-clean can be started again.

Setting a self-clean cycle or a delayed start

self-clean cycle

When the self-clean cycle has completed:

1. The time of day and “Hot” will appear in the display

window (See Fig.3).

2. Once the oven has cooled down for about 1 hour

and “Hot” is no longer displayed the “door OPn”

message should appear (Fig. 4). When this message

turns off the oven door may be opened. Use caution

and avoid possible burns when opening the door after

the self-cleaning cycle has completed. The oven may

still be VERY HOT.

When the self-clean feature is active you may check

the amount of time remaining in the self-clean cycle

by pressing the

pad once. The oven door will be

lockeduntiltherangehascooledsufciently.Youwill

need to allow about 1 additional hour to the time

displayed before you can open the oven door. When the

oven is cool, wipe away any residue or powdered ash

with a damp cloth or paper towel.

To avoid possible burns use care when opening the

oven door after the self-cleaning cycle. Stand to the

side of the oven when opening the door to allow hot

air or steam to escape.

DO NOT force the oven door open. This can damage

the automatic door locking system. Use caution and

avoid possible burns when opening the door after the

self-cleaning cycle has completed. The oven may still be

VERY HOT.

CAUTION

Step Press

1. Be sure the clock is set with the correct

time of day, ALL the oven racks are

removed and the oven door is closed.

Go to step 5 if you wish to start

self-clean immediately.

Finish steps 2 thru 6 if setting a

delayed start self-clean cycle.

2. Press delay start.

3. Enter 9 0 0.

4. Press start.

5. Press self clean once for a 3-hour

clean time, press self clean twice for

4-hour clean and press 3 times

for a 2-hour self-clean cycle time.

6. Press start.

Examples: To start an immediate self-cleaning

cycle and/or how to add a delay start time of 9:00

o’clock and shut-off self-clean automatically:

IMPORTANT

NOTES

Fig. 1

Fig. 2

Fig. 3

Fig. 4

If it becomes necessary to stop a self-clean cycle

once it has been activated:

SELF-CLEANING

CARE & CLEANING

• Control panel

• Control keypad membrane

• Decorative trim (some models)

Surface type Recommendation

• Easy Care™ Stainless

Steel (some models)

• Interior oven racks

• Oven door

Oven racks must be removed from the oven before starting

self-clean. Clean by using a mild, abrasive cleaner following manu-

facturer’s instructions. Rinse with clean water and dry.

Use soap & water to thoroughly clean the top, sides and front of the

oven door. Rinse well. You may use a glass cleaner on the outside

glass of the oven door. Do not immerse the door in water. Do not

spray or allow water or the glass cleaner to enter the door

vents. Do not use oven cleaners, cleaning powders or any harsh

abrasive cleaning materials on the outside of the oven door. Do

not clean the oven door gasket. On self-cleaning models the oven

door gasket is made of a woven material which is essential for a

good seal. Care should be taken not to rub, damage or remove this

gasket.

Cleaning recommendation table

See “Cooktop Cleaning and Maintenance” in the Care & Cleaning

section.

• Ceramic cooktop

Gentle scouring with a soapy non-abrasive scouring pad will remove

most spots. Rinse with a 1:1 solution of clear water and ammonia. If

necessary,coverdifcultspotswithanammonia-soakedpapertowel

for 30 to 40 minutes. Rinse with clean water and a damp cloth, and

thenscrubwithasoap-llednon-abrasivescouringpad.Rinseand

wipe dry with a clean cloth. Remove all cleaners or the porcelain may

become damaged during future heating.

For general cleaning, use hot, soapy water and a cloth. For more

difcultsoilsandbuilt-upgrease,applyaliquiddetergentdirectlyonto

the soil. Leave on soil for 30 to 60 minutes. Rinse with a damp cloth

and dry. Do not use abrasive cleaners on any of these materials; they

can scratch. To remove control knobs (some models), turn to the OFF

position;grasprmlyandpullstraightofftheshaft.Toreplaceknobs

aftercleaning,lineuptheatsidesofboththeknobandtheshaft;

then push the knob into place.

IfyourrangenishisEasy Care™ Stainless Steel (some models),

clean the stainless with warm soapy water using a clean sponge or

cloth. Rinse with clean water and dry with a soft clean cloth. DO NOT

use ANY store bought cleaners like Stainless Steel cleaners or any

other types of cleaners containing any abrasive, chlorides, chlorines

or ammonia. It is recommended to use mild dish soap and water or a

50/50 solution of water and vinegar.

• Painted body parts

• Painted decorative trim

• Control knobs (some models)

• Aluminum, plastic or vinyl trim pieces

• Porcelain door liner & body parts

• Storage drawer interior (some models)

• Porcelain enamel broiler pan and broiler

pan insert (some models)

Before cleaning the control panel, turn all controls OFF, activate

Lockout (on some models) and remove control knobs (on some

models). Do not use abrasive cleaners on any of these materials; they

can scratch. Clean using hot, soapy water and a dishcloth. Be sure

to squeeze excess water from dishcloth before wiping control

panel, especially when wiping around the controls area. Excess

water in or around the controls may cause damage to the appliance.

When rinsing, use clean water and a dishcloth and be sure to squeeze

excess water from dishcloth before wiping the control panel.

Consistent and proper cleaning is essential to

maintaining your ceramic glass cooktop.

Do not:

• Slide anything across the cooktop.

• Use cookware with dirt or dirt build-up on bottom;

replace with clean cookware before using.

• Use your cooktop as a cutting board or work surface in

the kitchen.

• Drop heavy or hard objects on the ceramic glass

cooktop, they may cause it to crack.

For light to moderate soil:

Apply a few drops of cooktop cleaning cream directly

to the cooktop. Use a clean paper towel to clean the

entire cooktop surface. Make sure the cooktop is cleaned

thoroughly, leaving no residue. Do not use the towel you

use to clean the cooktop for any other purpose.

For heavy, burned on soil:

Apply a few drops of cooktop cleaning cream directly to

the soiled area. Rub the soiled area using a non-abrasive

plastic type no-scratch cleaning pad, applying pressure as

needed. Do not use the pad you use to clean the cooktop

for any other purpose.

If soils remain, carefully scrape soils with a metal razor

blade scraper, holding scraper at a 30 degree angle to

the surface. Remove loosened soils with cooktop cleaning

cream and buff surface clean.

Priortousingyourcooktopforthersttime,apply

a ceramic cooktop cleaning cream (available in most

hardware, grocery and department stores) to the ceramic

surface. Clean and buff with a clean paper towel. This will

make cleaning easier when soiled from cooking. Cooktop

cleaningcreamsleaveaprotectivenishontheglassto

help prevent scratches and abrasions.

Sliding metal pans on the cooktop can cause metal

markings on the cooktop surface. These marks should be

removed immediately after the cooktop has cooled using

the cooktop cleaning cream. Metal marks can become

permanent if not removed prior to future use.

Cookware (cast iron, metal, ceramic or ceramic-coated)

with rough or dirty bottoms can mark or scratch the

cooktop surface.

Before cleaning the cooktop, be sure the controls are

turned to OFF and the cooktop is COOL.

Cooktop maintenance

Cooktop cleaning

IMPORTANT

CAUTION

Plastic or foods with a high sugar content:

These types of soils need be removed immediately if

spilled or melted onto the cooktop surface. Permanent

damage (such as pitting of the cooktop surface) may occur

if not removed immediately.

After turning the surface elements OFF, use a razor blade

scraper or a metal spatula with a mitt and scrape the soil

from the hot surface (as illustrated). Allow cooktop to cool,

and use the same method for heavy or burned on soils.

30°

CARE & CLEANING

Damage to the ceramic glass cooktop may occur if you

use an abrasive type cleaning pad. Only use cleaning

productsthathavebeenspecicallydesignedfor

ceramic glass cooktops.

Caution for aluminum use on the cooktop

• Aluminum Foil - Use of aluminum foil on a hot

cooktop may damage the ceramic cooktop. Do not use

thin aluminum cooking utensils or allow aluminum foil to

touch the ceramic cooktop under ANY circumstances.

Do not use the following on the cooktop:

• Do not use abrasive cleaners and scouring pads, such

as metal and some nylon pads. They may scratch the

cooktop,makingitmoredifculttoclean.

• Do not use harsh cleaners, such as chlorine bleach,

ammonia or oven cleaners, as they may etch or discolor

the cooktop.

• Do not use dirty sponges, cloths or paper towels, as they

can leave soil or lint on the cooktop which can burn and

cause discoloration.

Cooktop cleaning (cont’d)

IMPORTANT

DO NOT use a cooktop cleaner on a hot cooktop.

The fumes can be hazardous to your health and

can chemically damage the ceramic glass surface.

WARNING

Replacing the oven interior light

Be sure the range is unplugged and all parts are COOL

before replacing oven light. Wear a leather-faced glove

for protection against possible broken glass.

CAUTION

The interior oven light bulb is located at the rear oven

cavity and is covered with a glass shield. The glass shield

must be in place whenever the oven is in use (See Fig. 1).

Replacing the oven interior light bulb:

1. Turn electrical power off at the main source or unplug

the appliance.

2. Remove interior oven light shield (See Fig. 1).

3. Replace bulb with a new T-4 type 40 Watt Halogen

appliancebulb.Pleasenote:donotallowyourngers

to touch the new bulb when replacing. This will

shorten the life of the new bulb. Use a paper towel to

cover the new bulb when installing.

4. Replace glass interior oven light shield.

5. Turn power back on again at the main source (or plug

the appliance back in).

6. Be sure to reset the time of day on the clock.

Fig. 1

glass shield

oven interior

light bulb

rear oven

cavity

The door is heavy. For safe, temporary storage, lay the

dooratwiththeinsideofthedoorfacingdown.

To remove oven door:

1. Openovendoorcompletely(horizontalwithoor-See

Fig. 1).

2. Pull the door hinge locks on both left and right door

hinges down from the oven frame completely towards

theovendoor(SeeFig.2).Atoolsuchasasmallat-

blade screwdriver may be required.

3. Firmly grasp both sides of oven door along the door

sides (Do not use the oven door handle - See Fig. 3).

4. Close the door to the broil stop position (the oven door

will stop into this position just before fully closing).

5. With the oven door in the broil stop position, lift the

oven door hinge arms over the roller pins located on

each side of the oven frame (See Fig. 4).

To replace oven door:

1. Firmly grasp both sides of oven door along the door

sides (Do not use the oven door handle - See Fig. 3).

2. Holding the oven door at the same angle as the

removal position, seat the hook of the hinge arm over

the roller pins located on each side of the oven door

frame (See Fig. 4). The hook of the hinge arms must

be fully seated onto the roller pins.

3. Fullyopentheovendoor(horizontalwithoor-See

Fig. 1).

4. Push the door hinge locks up towards and into the

oven frame on both left and right oven door hinges

(See Fig. 2) to the locked position.

5. Close the oven door.

Special door care instructions - Most oven doors

contain glass that can break.

Read the following recommendations:

1. Do not close the oven door until all the oven racks are

fully in place.

2. Do not hit the glass with pots, pans, or any other

object.

3. Scratching, hitting, jarring or stressing the glass may

weaken its structure causing an increased risk of

breakage at a later time.

Removing and replacing the oven door

CAUTION

Oven door

hinge

locations

Fig. 3

Fig. 1

Fig. 4

roller

hinge

arm

about

10°

hinge

oven

door

Fig. 2

CARE & CLEANING

BEFORE YOU CALL • Solutions to common problems

Entire appliance does not operate. • Thetimeofdayisnotset.Thetimeofdaymustrstbesetinordertooperate

the oven. See “Setting the clock” in the Setting Oven Controls section.

• Make sure cord/plug is plugged correctly into outlet.

• Electrical power outage. Check house lights to be sure. Call your local electric

company for service.

• Service wiring is not complete. Contact your dealer, installing agent or authorized

service agent.

• Be sure the oven controls are set properly for the desired cooking feature. See

Setting Oven Controls in this manual or read the instructions “Entire appliance

does not operate” in this checklist.

Cannot move appliance easily. Appliance

must be accessible for service.

• Cabinets not square or are built in too tightly. Contact builder or installer to make

appliance accessible.

• Carpetinterfereswithappliance.Providesufcientspacesoappliancecanbelifted

over carpet.

Problem Solution

Appliance is not level. • Besureoorislevel,strong&stableenoughtoadequatelysupportrange.

• Ifoorissaggingorsloping,contactacarpentertocorrectthesituation.

• Poor installation. Place oven rack in center of oven. Place a level on the oven rack.

Adjust leveling legs at base of appliance until the rack is level.

• Kitchen cabinet alignment may make range appear not level. Be sure cabinets are

square&havesufcientroomforapplianceclearance.

Poor baking results. • Many factors affect baking results. Make sure the proper oven rack position is

used. Center food in the oven and space pans to allow air to circulate. Allow

the oven to preheat to the set temperature before placing food in the oven. Try

adjusting the recipe’s recommended temperature or baking time. If you feel the

oven is too hot or cool, see “Adjusting Oven Temperature” section in this Use &

Care Guide.

Oven portion of appliance does not operate.

Surface cookware seems too hot or not

hot enough.

• Incorrect induction cooktop power level setting. Adjust power level setting higher or

lower as needed.

Induction cooking zone does not heat

cookware or does not heat evenly.

• Be sure the correct surface control is activated for the cooking zone.

• Be sure to use the correct cookware material type for induction cooking. Use

cookwarespecicallyidentiedbythemanufacturertouseforinductioncooking.

If you’re not sure, use a magnet to test whether the cookware type will work. If

a magnet sticks to the bottom of the cookware, the material type is correct for

induction cooking.

• Be sure to read about pan-sensing in the Induction Cooking section and correct any

pan-sensing issues in the checklist provided.

• Use quality heavier gauge cookware.

Cooking zones do not glow when heating.

• The induction cooking zones do not glow even when they are hot. Induction cooking

uses electromagnetic energy to induce heat directly to the cookware.

Oven smokes excessively during broiling.

• Incorrect setting. Follow broiling instructions in Setting Oven Controls.

• Make sure oven door is opened to broil stop position.

• Meat too close to the broil element. Reposition the broil rack to provide proper

clearance between the meat & the element. Preheat the broil element for searing.

• Meat not properly prepared. Remove excess fat from meat. Cut remaining fatty

edges to prevent curling, but do not cut into lean.

• Broiler pan (on some models) insert wrong side up and grease not draining.

Always place insert on the broiler pan with ribs up & slots down to allow grease to

drip into pan.

• Grease has built up on oven surfaces. Regular cleaning is necessary when broiling

frequently. Old grease or food spatters cause excessive smoking.

Flames inside oven or smoking from oven

vent.

• Excessive spillovers in oven. For example this will happen for pie spillovers or large

amounts of grease left on the oven bottom. Wipe up excessive spillovers before

startingoven.Ifamesorexcessivesmokearepresentsee“Broiling”inthe

Setting Oven Controls section.

Oven control beeps & displays any F or E

error code message.

• Electronic control has detected a fault or error condition. Press CANCEL to clear

the display and stop beeping. Try the selected feature again. If the E or F error

code repeats, remove power from appliance, wait 5 minutes and then return

power to appliance. Try the selected feature again. If the fault continues, record

the fault or error code and call for service.

Problem Solution

Soil not completely removed after

running self-cleaning cycle.

Self-cleaning cycle does not work.

• Self-cleaning cycle was interrupted. Follow steps under “Stopping or interrupting a

self-cleaning cycle” under Self-cleaning.

• Excessive spillovers on oven bottom. Remove before starting self-clean.

• Failure to clean bottom, front top of oven, frame of oven or door area outside

oven seal. These areas are not in the self-cleaning area, but get hot enough

to burn on residue. Clean these areas before the self-cleaning cycle is started.

Burned-on residue can be cleaned with a stiff nylon brush and water or a nylon

scrubber. Be careful not to damage the oven gasket.

• Oven control not set properly. Follow instructions under Self-cleaning.

Oven light does not work.

• Be sure the light is secure in the socket. Also see “Changing & replacing the oven

light” in the Care & Cleaning section.

Convection fan does not rotate.

• Oven door is open. Convection fan will turn off if oven door is opened when

Convection is active. Close oven door.

Solutions to common problems • BEFORE YOU CALL

Problem Solution

Brown streaks or specks on cooktop

surface.

• Boilovers are cooked onto surface. Use razor blade scraper to remove soil. See

“Cooktop cleaning and maintenance” in the Care & Cleaning section.

Metal marks on the cooktop.

• Sliding or scraping of metal utensils on cooktop surface. Do not slide metal utensils

on cooktop surface. Use a cooktop cleaning cream to remove the marks. See

“Cooktop Cleaning and Maintenance” in the Care and Cleaning section.

Scratches or abrasions on cooktop surface. • Coarse particles such as salt or sand between cooktop and utensils can cause

scratches. Be sure cooktop surface and bottoms of utensils are clean before

usage. Small scratches do not affect cooking and will become less visible with

time.

• Cleaning materials not recommended for ceramic-glass cooktop have been used.

See “Cooktop cleaning and maintenance” in the Care and Cleaning section of

this Use & Care Guide.

• Cookwarewithroughbottomhasbeenused.Usesmooth,at-bottomedcookware.

Areas of discoloration with metallic sheen on

cooktop surface.

• Mineral deposits from water and food. Remove using a cooktop cleaning cream. Use

cookware with clean, dry bottoms.

BEFORE YOU CALL • Solutions to common problems

NOTES

MAJOR APPLIANCE WARRANTY

Your appliance is covered by a one year limited warranty. For one year from your original date of

purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove

to be defective in materials or workmanship when such appliance is installed, used and maintained in

accordance with the provided instructions.

Exclusions

This warranty does not cover the following:

1. Products with original serial numbers that have been removed, altered or cannot be readily determined.

2. Product that has been transferred from its original owner to another party or removed outside the USA or

Canada.

3. Rust on the interior or exterior of the unit.

4. Products purchased “as-is” are not covered by this warranty.

5. Food loss due to any refrigerator or freezer failures.

6. Products used in a commercial setting.

7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances

not in ordinary household use or used other than in accordance with the provided instructions.

8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.

9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,

etc., which are not a part of the appliance when it is shipped from the factory.

10. Servicecallstorepairorreplaceappliancelightbulbs,airlters,waterlters,otherconsumables,or

knobs, handles, or other cosmetic parts.

11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip

charges, or mileage expense for service calls to remote areas, including the state of Alaska.

12. Damagestothenishofapplianceorhomeincurredduringinstallation,includingbutnotlimitedtooors,

cabinets, walls, etc.

13. Damages caused by: services performed by unauthorized service companies; use of parts other than gen

uine Electrolux parts or parts obtained from persons other than authorized service companies; or external

causessuchasabuse,misuse,inadequatepowersupply,accidents,res,oractsofGod.

CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT

REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR

OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT

BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL

EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED

WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE

LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC

LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.

Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period

should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.

Service under this warranty must be obtained by contacting Electrolux at the addresses or phone

numbers below.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances

North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.

Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under

thiswarrantymustbeperformedbyElectroluxoranauthorizedservicecompany.Productfeaturesorspecicationsasdescribed

or illustrated are subject to change without notice.

If You Need

Service

Canada

1.800.265.8352

Electrolux Canada Corp.

5855 Terry Fox Way

Mississauga, Ontario, Canada

L5V 3E4

USA

1.800.944.9044

Electrolux Home Products, Inc.

10200 David Taylor Drive

Charlotte, NC 28262

Frigidaire CGIF3061NFC electric range

Product's Documents

Use & Care

Specifications

Frigidaire CGIF3061NFC Questions and Answers
