Washing Machine
User Manual
BFL104ADW
2 / EN
Washing Machine / User’s Manual
1 General safety instructions
This section contains safety instructions that will help protect from risk of
personal injury or property damage. Failure to follow these instructions shall
void any warranty.
1.1 Life and property safety
u
Never place the product on a carpet-covered floor. Otherwise, lack of airflow
beneath the machine will cause electrical parts to overheat. This will cause
problems with your product.
u
Unplug the product if it is not in use.
u
Always have the installation and repairing procedures carried out by the
Authorised Service Agent. The manufacturer shall not be held liable for
damages that may arise from procedures carried out by unauthorised persons.
u
The water supply and draining hoses must be securely fastened and remain
undamaged. Otherwise, there is the risk of water leakage.
u
While there is still water inside the product, never open the loading door or
remove the filter. Otherwise, risk of flooding and injury from hot water will occur.
u
Do not force open the locked loading door. The door will open immediately
after the washing cycle has ended. If the door does not open, apply the
solutions provided for "Loading door cannot be opened." error in the
Troubleshooting section. In case of forcing the loading door to open, the
door and the lock mechanism may get damaged.
u
Use detergents, softeners and supplements suitable for automatic washing
machines only.
u
Follow the instructions on the label of textile products and the detergent package.
u
The water supply pressure required to run the product is between 1 to 10 bars
(0.1 – 1 MPa).
u
Do not use old or used water inlet hoses on the new product. It may cause stains
on your laundry.
1.2 Children's safety
u
This product can be used by children at and above 8 years old and by persons
whose physical, sensory or mental capabilities were not fully developed or
who lack experience and knowledge provided that they are supervised or
This product was manufactured using the latest technology in environmentally friendly conditions.
3 / EN
Washing Machine / User’s Manual
trained on the safe usage of the product and the risks it brings out. Children
should not play with the product. Cleaning and maintenance works should not
be performed by children unless they are supervised by someone. Children
under the age of 3 should be kept away unless continuously supervised.
u
Packaging materials are dangerous for the children. Keep packaging
materials in a safe place away from reach of the children.
u
Electrical products are dangerous for the children. Keep children away from
the product when it is in use. Do not allow them to play with the product.
Use child lock to prevent children from intervening with the product.
u
Do not forget to close the loading door when leaving the room where the
product is located.
u
Store all detergents and additives in a safe place away from the reach of
the children by closing the cover of the detergent container or sealing the
detergent package.
1.3 Electrical safety
u
If the product has a failure, it should not be operated unless it is repaired by
the Authorised Service Agent! There is the risk of electric shock!
u
This product is designed to resume operating in the event of powering
on after a power interruption. If you wish to cancel the programme, see
"Cancelling the programme" section.
u
Plug the product into a grounded outlet protected by a 16 A fuse.
u
Do not wash the product by spraying or pouring water onto it! There is the
risk of electric shock!
u
Never touch the power cable plug with wet hands! Never unplug by pulling
on the cable. Always press on the plug with one hand and pull out the plug
by grabbing with the other hand.
u
Product should be unplugged during installation, maintenance, cleaning
and repair procedures.
u
If the power cable is damaged, it must be replaced by the manufacturer, or
a similarly qualified person (preferably an electrician) to avoid possible risks.
1.4 Hot surface safety
The glass of the loading door gets too hot while
washing at higher temperatures. Therefore,
especially do not allow children touch the
loading door glass while washing.
4 / EN
Washing Machine / User’s Manual
2 Important instructions for environment
2.1 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and electronic equipment (WEEE).
This product has been manufactured with high quality parts and materials which can be
reused and are suitable for recycling. Do not dispose of the waste product with normal
domestic and other wastes at the end of its service life. Take it to the collection center for the
recycling of electrical and electronic equipment. Please consult your local authorities to learn
about these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful
and prohibited materials specified in the Directive.
2.2 Package information
Packaging materials of the product are manufactured from recyclable materials in accordance with our
National Environment Regulations. Do not dispose of the packaging materials together with the domestic or
other wastes. Take them to the packaging material collection points designated by the local authorities.
3
Intended use
• This product has been designed for domestic use. It is not for commercial purposes or it should not be used
out of its intended use.
• The product must only be used for washing and rinsing of laundry that are marked accordingly.
• The manufacturer waives any responsibility arisen from incorrect usage or transportation.
• This appliance is intended to be used in household and similar applications such as:
– staff kitchen areas in shops, offices and other working environments;
– farm houses;
– by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– areas for communal use in blocks of flats or in launderettes.
5 / EN
Washing Machine / User’s Manual
4 Technical specifications
Supplier name or trademark Beko
Model name BFL104ADW
Rated capacity (kg) 10
Maximum spin speed (rpm) 1400
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 67
Single Water inlet / Double Water inlet
• / -
• Available
Electrical input (V/Hz) 220-240 V / 50Hz
Total current (A) 10
Total power (W) 2000-2350
Main model code 1315
Rinse
Spin+Drain
Prewash Fast Fast+ Extra
Rinse
Extra
Water
Anti
Crease
Pet Hair
Removal
Rinse
Hold
No
Water
Drain
Soaking
Spin No
Spin
Tap
Water
(Cold)
Steam
Time
Delay
Night
Modu
Temperature Door
Lock
Child
Lock
On/Off Start /
Pause
Soil Level Add
Garment
AutoDose
Liquid
Detergent
Selection
Softener
Selection
Wash
Downloaded
Program
Steeping
Ok
(End)
Cancel
AntiCrease+ Iron
Dry
Cupboard
Dry
Extra
Dry
Timed
Drying
Clean&
Wear
Symbols Table
Drying
6 / EN
Washing Machine / User’s Manual
4.1 Installation
• Preparation of the location and electrical, tap water and waste water installations at the place of installation
is under customer's responsibility.
• Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or
crushed while pushing the product into its place after installation or cleaning procedures.
• Prior to installation, visually check if the product has any defects on it. If so, do not have it installed.
Damaged products cause risks for your safety.
4.1.1 Appropriate installation location
• Place the product on a hard and level floor. Do not put it onto a carpet with high pile or other similar
surfaces.
• When the washing machine and dryer are placed on top of each other, their total weight –when loaded–
amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying
capacity!
• Do not place the product on the power cable.
• Do not install the product in the environments where the temperature falls below 0 ºC.
• Leaving a gap at the sides of the machine is suggested to reduce vibration and noise
• On a graduated floor, do not place the product next to the edge or on a platform.
• Do not place heat sources such as Hobs, Irons, Ovens, etc. on the washing machine and do not use them
on the product.
4.1.2 Removing packaging reinforcement (If the product has)
Tilt the machine backwards to remove the packaging reinforcement.
Remove the packaging reinforcement by pulling the ribbon. Do not make
this operation alone by yourself.
4.1.3 Removing the transportation locks
1 Loosen all bolts with an appropriate wrench until they turn freely.
2 Remove the transport safety bolts by turning them slightly.
3 Insert the plastic covers in the bag containing the user manual to the openings on the rear panel.
A
CAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the product will be
damaged.
C
Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the
future.
Install the transport safety bolts in reverse order of the disassembly procedure.
Never move the product without the transportation safety bolts properly fixed in place!
7 / EN
Washing Machine / User’s Manual
4.1.4 Connecting water supply
C
It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run
smoothly. Attach a pressure reducing valve if water pressure is higher.
C
It is also recommended to attach a pressure reducing valve if you experience overflow from the detergent dispenser during
water fill between 3.5 to 10 bars (0.35 to 1 MPa).
A
CAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will
get damaged or the product will switch to protection mode and will not operate.
1 Tighten the nuts of the hose by hand. Never use a tool when
tightening the nuts.
2 When hose connection is completed, check whether there is leak
problems at the connection points by opening the taps fully. If any
leaks occur, turn off the tap and remove the nut. Retighten the nut
carefully after checking the seal. In order to prevent the water leaks
and resultant damages, keep the taps closed when you do not use
the product.
4.1.5 Connecting the drain hose to the drain
• Attach the end of the drain hose directly to waste water drain, lavatory or bathtub.
A
CAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there
is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine
performs water intake and discharge processes without any problem, fix the drain hose securely.
40 cm
100 cm
• Connect the drain hose to a minimum height of 40 cm
and a maximum height of 100 cm.
• In case the drain hose is elevated after laying it on the
floor level or close to the ground (less than 40 cm above
the ground), water discharge becomes more difficult and
the laundry may come out excessively wet. Therefore,
follow the heights described in the figure.
• To prevent the waste water to go back into the machine again and to ensure easy drainage, do not immerse
the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too
long, cut it short.
• The end of the hose should not be bent, it should not be stepped on and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, use it by adding an original extension hose. Length of the hose may
not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the
drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.
8 / EN
Washing Machine / User’s Manual
4.1.6 Adjusting the feet
A
CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced
on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing
and vibration problems.
CAUTION: Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.
1 Loosen the lock nuts on the feet by hand.
2 Adjust the feet until the product stands in a stable and balanced way.
3. Tighten all lock nuts by hand again.
4.1.7 Electrical connection
Connect the product to a grounded outlet protected by a 16 A fuse.
The Manufacturer shall not be liable for any
damages that will arise when the product is used without grounding in accordance with the local regulations.
• Connection must comply with national regulations.
• The wiring for the electrical outlet circuit must be sufficient to meet the appliance requirements. Use of a
Groud Fault Circuit Interrupter (GFCI) is recommended.
• Power cable plug must be within easy reach after installation.
• If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified electrician
install a 16 Amp fuse.
• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.
• Do not make connections via extension cables or multi-plugs.
B
CAUTION: Damaged power cables must be replaced by the Authorised Service Agents.
4.1.8 Initial use
Before starting to use the product make sure that the preparations are
made which are in line with the “Important Safety and Environment
Instructions” and the instructions in the “Installation” section.
To prepare the product for washing laundry, perform first operation
in Drum Cleaning programme. If this program is not available in your
machine, apply the method which is described in the section 4.4.2.
C
Use an anti-limescale suitable for the washing machines.
Some water might have remained in the product due to the quality control processes in the production. It is not harmful for
the product.
9 / EN
Washing Machine / User’s Manual
4.2 Preparation
4.2.1 Sorting the laundry
• Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature.
• Always obey the instructions given on the garment tags.
4.2.2 Preparing laundry for washing
• Laundry items with metal attachments such as, underwiring, belt buckles or metal buttons will damage the
product. Remove the metal pieces or wash such clothes by putting them in a laundry bag or pillow case.
• Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out and
brush if possible. Such objects may damage the product or cause noise problem.
• Put small size clothes such as infant socks and nylon stockings in a laundry bag or a pillow case.
• Place curtains in without compressing them. Remove curtain attachment items.
• Fasten zippers, sew loose buttons and mend rips and tears.
• Wash “Machine washable” or “Hand washable” labeled products only with an appropriate programme.
• Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash them
separately.
• Persistent stains must be treated properly before washing. If unsure, check with a dry cleaner.
• Only use the dyes / color changers and descaling agents which are appropriate for machine wash. Always
follow the instructions on the package.
• Wash trousers and delicate laundry turned inside out.
•
Keep laundry items made of Angora wool in the freezer for a few hours before washing. This will reduce
piling.
• Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must be shaken
off before placing into the product. Such dusts and powders on the laundry may build up on the inner parts
of the product in time and can cause damage.
4.2.3 Tips for energy and water saving
Following information will help you use the product in an ecological and energy/water-efficient manner.
• Operate the product in the highest load capacity allowed for the programme you have selected, but do not
overload. See, „Programme and consumption table“.
• Observe the temperature instructions on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small quantities of lightly soiled laundry.
• Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a dryer, select the highest spin speed recommended during washing
process.
• Do not use more detergent than the recommended on the detergent packaging.
4.2.4 Loading the laundry
1 Open the loading door.
2 Put the laundry items into the product in a loose manner.
3 Push the loading door to close it until you hear a locking sound. Ensure that no items are caught in the
door. The loading door is locked while a programme is running. The door lock will open immediately after
the washing programme has ended. Then you can open the loading door. If the door does not open, apply
the solutions provided for "Loading door cannot be opened." error in the Troubleshooting section.
4.2.5 Correct load capacity
The maximum load capacity depends on the type of laundry, the degree of soiling and the desired washing
programme.
The product automatically adjusts the water amount according to the weight of the laundry put inside it.
A
WARNING: Comply with the information in “4.3.3 Programme and consumption table”. When overloaded, product's
washing performance will drop. Moreover, noise and vibration problems may occur.
10 / EN
Washing Machine / User’s Manual
4.2.6 Using detergent and softener
C
When using detergent, softener, starch, fabric dye, bleach and descaling agents to be added through the detergent container
2, read the manufacturer's instructions written on the package and follow the dosages specified. Use a measuring cup, if any.
For programmes where liquid detergent dosing is selected, do not add any powder detergent.
A
WARNING: Do not use liquid detergents or other cleaning products other than fabric softeners produced for washing
machines to soften the clothes.
Detergent, softener and other cleaning agents
1 2 3
1- Liquid detergent compartment
2 - Powder detergent compartment
3 - Softener compartment
• Add detergent and softener before starting the washing programme.
• Place the detergent bag or the dispensing ball directly among the laundry in the product.
• There is no pre-wash compartment and pre-wash option.
C
Washing agents such as viscous jelly detergents cannot be used in detergent drawers or dosing compartments.
A
WARNING: Close the detergent drawer before starting the washing programme and never open the drawer while the
product is running.
Choosing the detergent type
Detergent type to be used depends on the washing programme, fabric type and colour.
• Use different detergents for coloured and white laundry.
• Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) intended
solely for delicate clothes and at suggested programmes.
• When washing dark coloured clothes and quilts, it is recommended to use liquid detergent.
• Wash woollens at suggested programme with special detergent made specifically for woollens
• Please review the programme descriptions part for suggested programme for different textiles.
• All recommendations about detergents are valid for selectable temperature range of programmes.
A
WARNING: Use only detergents manufactured specifically for washing machines.
WARNING: Do not use soap powder.
4.2.6.1 Auto dosing
Initial Setup:
Switch on the machine by pressing the on/off button. The dosing symbol ( ) will appear enabled in
programmes that permit detergent dosing. If the liquid detergent and softener compartments are empty or the
remaining agents in these compartments are below the limits, the dosing symbol will flash in programmes that
permit dosing.
11 / EN
Washing Machine / User’s Manual
Adding Liquid Detergent and Softener
• Pull the detergent drawer towards yourself to open it.
• To add liquid detergent (left) and softener (right), open the lid of the
relevant container upwards as shown in the image.
MAX
• When adding liquid detergent or softener, do not exceed the tip of
the «Max» label.
• Close the lid.
• Close the detergent drawer by pushing it slowly.
• The detergent symbol ( )is expected to be steadily on after the
detergent drawer has been closed.
• For coloured and white laundry, it is recommended to fill commonly
used liquid detergent in the compartment.
A
WARNING: While the detergent drawer is full with detergent and/or softener:
a- Do not pull the machine,
b- Do not change its place,
c- Do not tilt the machine to its side or back,
WARNING: To make these actions, first you should take out the drawer from the machine.
WARNING: If you wish to start the programme when there is no detergent in the detergent drawer, please remember
that you must cancel the liquid detergent dosing and wash the laundry with powder detergent.
WARNING: The liquid detergent dosing container must be filled only with liquid detergent, and the softener dosing
container only with softener. Filling these compartments with any kind of liquid or powder chemical other than these may
harm your laundry or washing machine.
4.2.6.2 Dose Selection and Cancellation or Powder Detergent Use
• For some programmes of the machine, liquid detergent could not be selected. In such cases, powder
detergent should be used. Please see the Programme Table for details.
• After selecting the temperature, spin speed and auxiliary function, start the programme by pressing the
started/pause button.
12 / EN
Washing Machine / User’s Manual
• The machine will measure the load, and determine the detergent amount depending on the load amount
and selected functions. During the washing operation, the detergent intake is not visible, it will be taken
in directly with the water.
• If it is requested to use powder detergent in programmes where detergent dosing system activates
required amount of powder detergent should be added to the detergent compartment. If you wish to use
the detergent compartment in the middle, you need to cancel your liquid detergent selection.
• Program is started by pressing Start/Pause button. When the machine starts to take in water, the
powder detergent will also be taken in.
• If you want to use a liquid detergent whose characteristics are different than that of the detergent in
the liquid detergent compartment for once, you must add the different liquid detergent into the middle
powder detergent compartment and cancel your liquid detergent selection.
• The softener will be taken in through the dosing system.
Liquid detergent and softener dosing symbols will be active or inactive depending on the programme selected
on the display.
• If the liquid detergent symbol is on, this means that liquid detergent dosing is active.
• If the softener symbol is on, this means that softener dosing is active.
• If the liquid detergent symbol is off, this means that you can wash your laundry with powder detergent.
• If the softener symbol is off, this means no softener will be used in the rinsing step.
The first position on the display: means liquid detergent and softener are on.
If liquid detergent and softener symbols are active on the display, and if you press the
Auto Dosing button, liquid detergent will be off and powder detergent will be on.
If you press and hold the Auto Dosing button for 3 seconds, softener will be off.
4.2.6.3 When the detergent and/or softener run(s) out:
• When the detergent or softener in the detergent compartment runs out, the “dosing symbol” on the
display will flash. When this symbol flashes, you need to add detergent or softener to the dosing
compartment. The product can dose for 2 to 3 cycles as of the moment that the symbol flashes.
4.2.6.4 Adding detergent or softener to the wrong compartment:
• If the detergent or softener is added to the wrong compartments, see 4.4.1 “Cleaning the detergent
drawer”.
13 / EN
Washing Machine / User’s Manual
4.2.7 Tips for efficient washing
Clothes
Light Colours and
Whites
Colours
Black/Dark
Colours
Delicates/
Woolens/Silks
(Recommended temperature range
based on soiling level: 40-90
o
C)
(Recommended temperature
range based on soiling level:
cold -40
o
C)
(Recommended
temperature range
based on soiling level:
cold -40
o
C)
(Recommended
temperature range
based on soiling level:
cold -40
o
C)
Soiling Level
Heavily Soiled
(difficult stains such
as grass, coffee,
fruits and blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
Powder and liquid
detergents recommended
for colors can be used at
dosages recommended
for heavily soiled clothes.
It is recommended to use
powder detergents to clean
clay and soil stains and the
stains that are sensitive to
bleaches. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
heavily soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woolen and
silk clothes must be
washed with special
woolen detergents.
Normally
Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
normally soiled clothes.
Powder and liquid detergents
recommended for colors
can be used at dosages
recommended for normally
soiled clothes. Detergents
which do not contain bleach
should be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
normally soiled
clothes.
Prefer liquid detergents
produced for delicate
clothes. Woolen and
silk clothes must be
washed with special
woolen detergents.
Lightly Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
lightly soiled clothes.
Powder and liquid detergents
recommended for colors
can be used at dosages
recommended for lightly soiled
clothes. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
lightly soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woolen and
silk clothes must be
washed with special
woolen detergents.
C
If a special liquid detergent must be used, you can cancel the liquid detergent dosing and add the special detergent to the powder
detergent compartment no 2. In such cases, no time delay function should not be used.
4.2.8 Programma Time Displayed
When selecting a programme, you can see the programme duration on the display of your machine.
Programme time will be automatically set while the programme is running depending on the amount of laundry,
unbalanced load conditions, fluctuations in the power supply, water pressure and programme settings.
SPECIAL CONDITION: At the beginning of Cotton and Cotton Eco programmes, half load time will be
displayed. This is the most common method of use. The machine will detect the actual load 20-25 minutes
after the programme has started. If the detected load is more than half load, washing time will be set
accordingly; programme time will automatically extend. You can look at the display to track this change.
14 / EN
Washing Machine / User’s Manual
4.3 Operating the product
4.3.1 Control panel
1 - Programme selection knob
2 - Temperature level lights
3 - Spin level indicator lights
4 - Display
5 - Start/Pause Button
6 - Remote control button
7 - End Time Adjustment Button
8 - Auxiliary function button 3
9 - Auxiliary function button 2
10 - Auxiliary function button 1
11 - Spin speed adjustment button
12 - Temperature adjustment button
4.3.2 Display symbols
1600
1200
800
600
90
˚
60
˚
40
˚
30
˚
20
˚
a b c d e
f
h
g
ikl jno mpr
a- Temperature indicator
b- Spin speed indicator
c- Duration information
d - Door lock is engaged symbol
e- Programme follow-up indicator
f- No water indicator
g - Add laundry indicator
h- Bluetooth connection indicator
i- Remote Control indicator
j - Delayed Start Enabled indicator
k - Auxiliary function indicators 3
l - Child lock enabled symbol
m- Auxiliary function indicators 2 (Dosing symbols)
n- Auxiliary function indicators 1
o - No spin indicator
p - Rinse hold indicator
r- Cold water indicator
C
Images used in this section to describe the product are schematic and may not be exactly the same as the actual product.
1 2 3 4
79 8101112
6 5
15 / EN
Washing Machine / User’s Manual
4.3.3 Programme and consumption table
C
Note for test institutions:
Data required for performance tests shall be provided upon request. Requests can be e-mailed to the following address:
Do not forget to provide the code, stock and serial numbers of the product to be tested in your request e-mail along with your contact
information. Code, stock and serial numbers of the product is located on the type label attached to the inside of the door.
• : Selectable.
* : Automatically selected, cannot be cancelled.
** : Energy label programme (AS/NZS 2040)
*** : If the maximum spin speed of the machine is lower, you can select values up to the maximum spin speed value.
**** : Programme detects the type and quantity of the laundry to automatically adjust water and energy consumption and the
programme time.
***** : These programmes can be used with the HomeWhiz application.
- : See the programme description for maximum load.
EN 2 Auxiliary functions
Programme
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
Steam
Softener Selection
Fast+
AutoDose
Anti Crease+
Selectable
temperature range
°C
Cottons
90 10
105
2,70 1400
• •
•
• •
Cold-90
60 10 105 2,00 1400 • • • • • Cold-90
40 10 105 1,00 1400 • • • • • Cold-90
Cottons Eco 40**
10
86 1,104
1400
•
•
Cold-40
Synthetics
60 5 75 1,40 1200 • • • • • Cold-60
40 5 73 0,86 1200 • • • • • Cold-60
Daily-Quick / Quick 14’
90 10 75 2,15 1400 • • • • • Cold-90
60 10 75 1,15 1400 • • • • • Cold-90
30 10 75 0,16 1400 • • • • • Cold-90
Daily-Quick / Quick 14’ + Fast+ 30 2 38 0,15 1400 • • • • • Cold-90
Wool / Hand Wash 40 2 75 0,50 1200 • • Cold-40
Bedding & Blanket 60 - 98 0,92 800 • • • Cold-60
Outdoor / Sport 40 5,5 55 0,40 1200 • • Cold-40
StainExpert 60 5,5 88 1,75 1400 • • • 30-60
Shirts 60 5 73 1,20 800 • • • • • Cold-60
Anti-Allergy+ 90 9 140 2,25 1400 * • • 20-90
CoolClean 30 5 63 0,25 1400 • • • Cold-30
Auto Program 60 10 **** **** 1400 • • • • Cold-60
Drum Clean 90 - 80 2,20 600 * • • 90
Downloaded Program*****
Mix 40 4 85 0,90 800 • • • • • Cold-40
Dark Care / Jeans 40 6 90 0,95 1200 • • • • • Cold-40
Delicates 40 5 80 0,78 800 • • Cold-40
Towel 60 2 98 0,92 800 • • • Cold-60
Lingerie 30 2 93 0,28 600 • • Cold-30
16 / EN
Washing Machine / User’s Manual
C
The auxiliary functions in the table may vary according to the model of your machine.
Water and power consumption may vary subject to the changes in water pressure, water hardness and water temperature, ambient
temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in the mains voltage.
When selecting a programme, you can see the washing duration on the display of your machine. Depending on the amount of
laundry you have loaded into the machine, there might be a difference of 1 to 1.5 hours between the duration shown on the display
and the actual duration of the washing programme. The duration will be corrected automatically right after the washing programme
has started.
"Auxiliary function selection modes can be changed by the manufacturing company. New selection models may be added, or the
existing ones may be removed.”
"Spin speed of your machine may vary depending on the programme; the spin speed cannot exceed the maximum spin speed of
your machine."
4.3.4 Programme selection
1 In accordance with the “Programme and consumption table”, select a suitable programme for the amount
and soiling level of the laundry.
C
Programmes are limited to the highest spin speed appropriate for that particular type of fabric.
When selecting a programme, always consider the type of fabric, colour, soiling level and permissible water temperature.
Always select the lowest appropriate temperature. Higher temperature means higher electricity consumption.
2 Use the Programme Selection knob to select the desired programme.
4.3.5 Programmes
• Cottons Eco
Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other
programmes, it provides high energy and water savings. Actual water temperature may be different from the
washing temperature stated. When washing less amount of laundry (e.g. half the capacity or less), duration
of programme steps may automatically become shorter. In this case, energy and water consumption will
decrease more, providing a more economical wash.
Normally soiled laundry may be washed with reduced amount of detergent to save energy and protect the
environment.
• Cottons
You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.) in this
programme. When the quick / fast+ function button is pressed, programme duration becomes notably shorter
but effective washing performance is ensured with intense washing movements. If the quick / fast+ function is
not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
• Synthetics
You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this programme.
The programme duration gets notable shorter and washing with high performance is ensured. If the quick / fast+
function is not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
• Wool / Hand Wash
Use this programme to wash your woolen clothes. Select the appropriate temperature complying with the tag
of your clothes. Your laundry will be washed with very delicate movements to avoid any damage.
17 / EN
Washing Machine / User’s Manual
• Anti-Allergy+
Use this programme for your laundry (baby clothes, bed sheets, bedlinen, underwear, etc. cotton items) that
requires an anti-allergy and hygienic washing at high temperature with intensive and long washing cycle.
Steam vapour is automatically applied at the beginning of the program and helps the dirt to soften easily.
The high level of hygiene is ensured thanks to the steam application before the program, long heating duration
and additional rinsing step. Vapour is distributed inside the machine during drum rotation. It is normal that
steam vapour may not be visible during the cycle. Please note the Steam Function is automatically selected for
this cycle and cannot be cancelled.
• Programme, “British Allergy Foundation”
It has been tested by “The British Allergy Foundation - Allergy UK” while the temperature was 60°C, and its
efficiency in eliminating bacteria and mould, as well as allergens, was certified.
Allergy UK is the trademark of the British Allergy Foundation. The Seal of Approval has
been designed to provide guidance to persons who want information whether the product
significantly decreases the amount of allergens in the environment it is installed or whether
it limits/reduces/eliminates the allergens. Its purpose is to provide evidence that the
products have been tested scientifically or reviewed to provide measurable results.
• Bedding & Blanket
Use this programme to wash your fiber duvets that bear „machine washable“ tag. Check that you have loaded
the duvet correctly in order not to damage the machine and the duvet. Remove the duvet cover before loading
the duvet into the machine. Fold the duvet into two and load it into the machine. Load the duvet into the
machine paying attention to place it in a way that it will not contact the bellow or the glass.
Besides, use this programme to wash your coats, vest, jackets etc. containing feathers with a „machine-
washable“ label on them.
C
Do not load more than 1 double fiber duvet (200 x 200 cm).
Do not wash your duvets, pillows and etc. that contain cotton in the machine.
A
WARNING: Do not wash the items apart from duvets such as carpets, rugs and etc. in the machine. Permanent damage
occurs in the machine.
• Spin+Drain
You can use this function to remove the water on the garment of drain the water in the machine.
• Rinse
Use when you want to rinse or starch separately.
• Shirts
This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics altogether.
It reduces wrinkles. When the quick
/ fast+
function is selected, the Pre-treatment algorithm is executed.
• Apply the pre-treatment chemical on your garments directly or add it together with the detergent when the
machine starts to take water in the powder detergent compartment. Thus, you can obtain the same performance
as you obtain with normal washing in a much shorter period of time. Usage life of your shirts increases
.
• Daily-Quick / Quick 14’
Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme
duration can be reduced down to 14 minutes when the quick / fast+ function is selected. When the quick /
fast+ function is selected, maximum 2 (two) kg of laundry must be washed.
• Dark Care / Jeans
Use this programme to preserve the colour of your dark-coloured clothes and jeans. This programme provides
high efficiency in washing, thanks to a special drum movement, even at low temperatures. It is recommended
to use liquid detergent or woolen shampoo for dark coloured laundry. Do not wash your delicate clothes that
contain wool etc. in this programme.
• Mix
You can use this programme to wash cottons and synthetics together without the need to sort them.
18 / EN
Washing Machine / User’s Manual
• Auto Program
Use to wash frequently washable cotton, synthetic or blended (cotton+synthetic) clothes. Programme detects
the type and quantity of the laundry to automatically adjust water consumption and programme time.
A
WARNING: Do not wash your woolen and delicate clothes in this programme.
If the temperature on the temperature indicator is not in compliance with the warnings on the tag of the laundry, select a
suitable temperature.
The maximum washing temperature in Automatic programme depending on the soiling level and laundry type
is 60ºC. Washing performance may not be at the desired level for heavily soiled whites and stubborn stains
(collar, sock soil, perspiration stain, etc.). In this case, it is recommended to select Cottons programme with
prewash and set the temperature to 50-60°C.
Many types of clothing are correctly detected and safely washed in Automatic programme.
• Delicates
You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this programme. It
washes with more delicate washing action. Wash your clothes whose colour you want to preserve either at 20
degrees or by selecting the cold wash option.
• Lingerie
You can use this programme to wash delicate garments that are suitable for hand wash and delicate women’s
underwear. Small amount of garments must be washed in a washing net. Hooks, buttons etc. must be done up and
zips must be zipped up..
• CoolClean
Use to wash your moderately soiled and durable cotton/synthetic laundry. An effective washing is provided
thanks to the intense washing action and double jet system.
• Outdoor / Sports
You can use this programme to wash sports and outdoors garments that contain cotton/synthetics mix and
water repellent covers such as gore-tex etc. It makes sure your garments are washed gently thanks to special
rotating movements.
• StainExpert
The machine has a special stain programme which enables the removal of different types of stains in the most
effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate and pigmenting
clothes and laundry in this programme. Before washing, garment tags should be checked (recommended for
cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes, bed sheets, duvet covers,
pillowcases, bath-beach towels, towels, socks, cotton underwear that are suitable for washing at high temperature
and long time). In the automatic stain programme, you can wash 24 types of stains divided into two different
groups according to quick / fast+ function selection. You can see stain groups based on the selection of the quick
/ fast+ function.
You can find stain groups based on quick / fast+ function below
:
When “quick / fast+” is
not selected
When the “quick / fast+”
button is pressed once
When the “quick / fast+”
button is pressed twice
Sweat Blood Tea
Collar Soil Chocolate Coffee
Food Pudding Fruit juice
Mayonnaise Grass Ketchup
Salad Dressing Mud Red Wine
Make-up Egg Coke
Machine oil Butter Jam
Baby food Curry Coal
19 / EN
Washing Machine / User’s Manual
• Select the stain programme.
• In the stain groups stated above, find the type of stain you want to remove and select the quick auxiliary
function selection key to select the relevant group.
• Carefully read the tag of the clothing and make sure that the temperature and spin speed selected are
suitable.
• Downloaded Program
This is a special programme that allows you to download different programmes when you want to. At the start,
there is a programme you will see with the HomeWhiz application as default. However, you can use the HomeWhiz
application to select a programme from the predefined programme settings, and then change it.
C
If you wish to use the HomeWhiz and Remote Control functions, you need to select Download Programme. 4.3.15 Please see
the section HomeWhiz and Remote Control Function for more details.
• Towel
Use this program to wash durable cotton laundry such as towels. Load the towels into the machine paying
attention to place them in a way that they will not contact the bellow or the glass.
4.3.6 Temperature selection
-
-
-
-
-
-
Whenever a new programme is selected, the temperature recommended for that programme appears on the temperature
indicator. It is possible that the recommended temperature is not the highest value that can be selected for the relevant
programme.
Press the Temperature Adjustment button to change the temperature. Temperature will decrease gradually.
C
No change can be made in programmes where temperature adjustment is not allowed.
You can also change the temperature after the washing cycle has started. This can be done if the washing
steps allow it. If they don’t permit it, you can’t do it.
C
If you go to the washing option and press the Temperature Adjustment button again, the maximum temperature
recommended for the selected programme will be displayed. To decrease the temperature, press the Temperature
Adjustment button again.
4.3.7 Spin speed selection
-
-
-
-
-
-
Whenever a new programme is selected, the recommended spin speed of the selected programme is
displayed on the Spin Speed indicator.
C
It is possible that the recommended spin speed is not the highest value that can be selected for the relevant programme.
Press the Spin Speed Adjustment button to change the spin speed. Spin speed decreases gradually.
Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear on the display.
If you are not going to unload your clothes immediately after the programme ends, you can use the Rinse
Hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled
when there is no water in the machine.
20 / EN
Washing Machine / User’s Manual
This function holds the laundry in the final rinsing water.
If you want to spin your laundry after the Rinse Hold function:
- Adjust the Spin Speed.
- Press Start/Pause/Cancel. Programme will resume. The machine will drain the water and spin the clothes.
If you want to drain the water at the end of the programme without spinning, you can use the No Spin function.
C
No change can be made in programmes where spin speed is not allowed.
If the washing steps permit, you can change the spin speed after the washing cycle has started. If they don’t
permit it, you can’t do it.
Rinse hold
I
f you are not going to unload your clothes immediately after the programme ends, you can use rinse hold
function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled when there
is no water in the machine. Press Start/Pause button after this process if you want to drain the water without
spinning your laundry. Programme will resume where it left off, drain the water and then it will be complete.
If you want to spin the laundry held in water, adjust the Spin Speed and press Start/Pause button.
Programme will resume. Water will be drained, laundry will be spun and the programme will end.
4.3.8 Auxiliary function selection
-
-
-
-
-
-
Select the desired auxiliary functions before starting the programme. When a programme is selected, symbols
of the auxiliary functions selected with it will turn on.
C
If you press the key for an auxiliary function that cannot be selected with the current programme, you will hear a warning
from the washing machine.
Also, symbols of the auxiliary functions selected for the running programme will remain on after the washing
cycle has started.
C
Some functions cannot be selected together. If a second auxiliary function conflicting with the first one is selected before starting the
machine, the function selected first will be canceled and the second auxiliary function selection will remain active. For example, if
you want to select Quick Wash after selecting Extra Water, the Extra Water option will be cancelled but Quick Wash will remain valid.
An auxiliary function which is not compatible with the programme cannot be selected. (See "Programme and consumption table")
Some programmes have auxiliary functions that must be operated with the selected programme. This function cannot be
cancelled. The frame of the auxiliary function will not be illuminated, only inner area will be illuminated.
4.3.8.1. Auxiliary functions
• Fast+
After selecting a programme, you can press the Quick / Fast+ function setting key to shorten the programme
duration. For some programmes, the duration can shorten by over 50%. Despite this, the washing
performance is good thanks to the changed algorithm.
Although it varies in each programme, when you press the Quick
/ Fast+
key once, the programme duration
decreases to a certain level, and when you press the same key for the second time, it drops to the minimum level.
For a better washing performance, do not use the Quick / Fast+ setting key when washing heavily soiled laundry.
Shorten the programme duration by using the Quick / Fast+ key for Moderately and Slightly soiled laundry
.
21 / EN
Washing Machine / User’s Manual
• Steam
Use this function to reduce the creases and ironing time of a small amount of cotton, synthetic or mixed
laundry. This function can be selected on the following cycles (See 4.3.12 Programme and consumption
table): Cottons, Synthetics, Daily-Quick / Quick 14’, Daily-Quick / Quick 14’ + Fast+, Bedding & Blanket,
Shirts, Mix, Dark Care / Jeans, Towel. This function works better on a small or half load. Vapour is distributed
inside the machine during drum rotation. It is normal that steam vapour may not be visible during the cycle.
• AutoDose
With this auxiliary function key, you can change your detergent and dose preferences. For detailed information,
see 4.2.6.2 “Dose Selection and Cancellation or Powder Detergent Use”
• Remote Control
You can use this auxiliary function button to connect your product to smart devices. For detailed information,
see 4.3.15 HomeWhiz and Remote Control Functions.
• Specialised Programme
This auxiliary function can be used for Cottons and Synthetics programmes only with the HomeWhiz
application. When this auxiliary function is enabled, you can add up to 4 additional rinse steps to the
programme. You can select and use some auxiliary functions even though they are not found on your product.
You can increase and decrease the time of the Cottons and Synthetics programmes within a safe range.
C
When the Specialised Programme auxiliary function is selected, washing performance and energy consumption will be
different than the value indicated.
• Auto Dosing Setting
This function can only be used with the HomeWhiz application. With this function, the dosing amounts of the
Liquid Detergent and Softener are changed. For all programmes, dosing will be performed based on the latest
settings you have selected until you select a new setting.
4.3.8.2 Functions/Programmes Selected by Pressing the Function Keys for Three Seconds
• Drum Clean
To select this programme, press and hold the auxiliary function button 1 for 3 seconds. Use it regularly (every
1-2 months) to clean the drum and ensure the required hygiene is provided. Steam is applied before the
programme to soften the residues in the drum. Run the programme while the machine is totally empty. For
better results, put powder lime-scale remover for washing machines into the detergent compartment no. "2".
When the programme is over, leave the loading door ajar so that the inside of the machine gets dry.
C
This is not a washing programme. It is a maintenance programme.
Do not run this programme when there are any objects in the machine. If you try to do so, the machine will automatically
detect that there is load inside and abort the programme.
• Anti Crease+
If you press and hold the spin selection button for 3 seconds, this function will be selected and the programme
follow-up light of the relevant programme will turn on. When this function is selected, the drum will rotate for up to
eight hours to ensure that the clothes do not crease at the end of the programme. At any time during these eight
hours, you can cancel the programme and unload the machine. Press the function selection key or the machine
on/off key to cancel the function. The programme follow-up light will remain on until the function is cancelled or
the step is complete. If the function is not cancelled, it will also be enabled in the next washing cycles.
• Softener Selection
Press and hold the Auxiliary Function (Automatic Dosing) button 2 for 3 seconds to select this function. If you
select this function while the softener symbol is active on the display, softener will become off. If you select
this function while the softener symbol is inactive on the display, softener will become on.
22 / EN
Washing Machine / User’s Manual
• Child lock
You can use the Child Lock to prevent children from tampering with the machine. Thus you can avoid any
changes in a running programme.
C
When the Child Lock is enabled, you can press the On/Off button to switch the machine on or off. Programme resumes
when you start the machine again.
You will hear a warning if the buttons are pressed while Child Lock is enabled. This audible warning will be canceled if the
buttons are pressed five times consecutively.
To enable Child Lock:
Press and hold the auxiliary function button 3 for 3 seconds. Once the countdown “3-2-1" is
completed on the display, the child lock symbol will turn on. When this warning is displayed, you can release
the Auxiliary Function button 3.
To disable Child Lock:
Press and hold the auxiliary function button 3 for 3 seconds. Once the countdown “3-2-1" is
completed on the display, the child lock symbol will turn off.
• Bluetooth
You can use the Bluetooth connection function to pair your machine with your smart device. This way, you can use your smart
device to get information about your machine and control it.
To enable Bluetooth:
Press and hold the Remote Control function button for 3 seconds. You will see the countdown “3-2-1”
and the Bluetooth symbol will turn on. Release the Remote Control function button. The Bluetooth icon will
flash while the product is being paired with the smart device. If the connection is successful, the light of the
icon will remain on.
To disable Bluetooth:
Press and hold the Remote Control function button for 3 seconds. You will see the countdown “3-2-1”
and the Bluetooth symbol will turn off.
C
You must complete the first setup of the HomeWhiz app for Bluetooth to be enabled. After the setup, if you press the Remote
Control function button while the button is in the Programme Download/Remote Control position, the Bluetooth connection
will be enabled automatically.
4.3.9 End Time
Time display
While the programme is running, the time remaining to the end of the programme will be displayed in hours
and minutes, e.g. “01:30”.
C
Programme time may differ from the values in section "Programme and consumption table" depending on the water
pressure, water hardness and temperature, ambient temperature, amount and the type of laundry, auxiliary functions selected
and the changes in the mains voltage.
With the End Time function, start of the programme can be delayed up to 24 hours. After pressing End Time
button, the programme's estimated end time will be displayed. If the End Time is set, End Time indicator will
turn on.
To ensure that the End Time function is enabled and the program ends at the end of the defined duration, you
should press Start / Pause after setting the duration.
23 / EN
Washing Machine / User’s Manual
If you want to cancel the End Time function, turn the knob to on/off position.
C
If you enable the End Time function, do not add liquid detergent into the powder detergent compartment 2. Stains might
remain on the clothes.
1 Open the loading door, place the laundry and put detergent, etc.
2 Select the washing programme, temperature, spin speed and, if required, the auxiliary functions.
3 Press the End Time button to set the desired end time. End Time indicator will turn on.
4 Press the Start/Pause button. Countdown starts. “:” sign in the middle of the end time on the display will
start flashing.
C
The loading door will be locked while End Time is enabled.
During the End Time countdown, you can add laundry into the machine. (See 4.3.12). At the end of the countdown, End Time
indicator will turn off, washing cycle will start and the duration of the selected will be displayed.
When End Time is selected, the time shown on the display is the end time.
4.3.10 Starting a programme
1 Press Start/Pause button to start the programme.
2 The light of the Start / Pause button, which is off, will now turn on to indicate that the programme has started.
3 Loading door will be locked. After the loading door has been locked, door lock symbol will appear on the display.
4 The programme follow-up lights on the display show the current programme step.
4.3.11 Loading door lock
There is a locking system on the loading door of the machine that prevents opening of the loading door in
cases when the water level is unsuitable.
When the door is locked, “Door Locked” symbol will be displayed.
C
The door will be locked if the Remote Control function is selected. To open the door, you need to press the Remote Start
button or change the programme position to deactivate the Remote Start function.
Opening the loading door in case of power failure:
C
In case of a power failure, you can use the loading door emergency handle under the pump filter lid to manually open the
loading door.
A
WARNING: Before opening the loading door, make sure that there is no water in the machine to avoid flooding.
24 / EN
Washing Machine / User’s Manual
• Turn off and unplug the appliance.
• Open the pump filter lid.
• Remove the loading door emergency handle behind the filter cover with
a tool.
• Open the loading door by pulling the loading door emergency handle
downwards.
• Try to pull the handle downwards again if the loading door is not opened.
• Bring the loading door emergency handle to its original position after
opening the loading door.
4.3.12 Changing the selections after programme has started
Adding laundry after the programme has started :
When you press the Start / Pause button, if the level of water inside the machine is suitable (if add laundry
icon is on), the door lock will be disabled and the door will open so that you can add laundry. When the
door lock is disabled, the door lock symbol on the display will disappear. After adding the laundry, close the
door and press Start/Pause again to continue the washing cycle.
When you press Start/Pause , if the water level in the machine is not sufficient (if add laundry icon
is off), the door lock will not be disabled and the door lock symbol will still be shown on the display.
C
If the temperature of the water inside the machine is above 50°C, you cannot disable the door lock even if the water level
is suitable.
Switching the machine to pause mode:
Press the Start/Pause button to switch the machine to pause mode. Start / Pause symbol will flash on the display.
25 / EN
Washing Machine / User’s Manual
Changing the programme selection after the programme has started:
If Child Lock is not enabled, you can change programme by turning the programme selection knob while the
current programme is running. This will cancel the current programme.
C
The selected programme will start anew.
Changing the auxiliary function, speed and temperature
Depending on the step the current programme has reached, you can cancel or enable auxiliary functions. See
“Auxiliary function selection”
You can also change the speed and temperature settings. See "Spin speed selection" and "Temperature selection".
C
If the temperature of the water inside the machine is high or if the water level is above the door line, the loading door will
not open.
4.3.13 Cancelling the programme
The programme will be cancelled if the programme selection knob is switched to another programme or if the
machine is switched off and on with this button.
C
The programme will not be cancelled if you turn the programme selection knob while child lock is enabled. You should cancel
the Child Lock first.
If you want to open the loading door after you have cancelled the programme but you cannot do it since the water level in the
machine is above the loading door baseline, turn the Programme Selection knob to Pump+Spin programme and discharge
the water in the machine.
4.3.14 End of programme
Once the programme is completed, the End symbol will be displayed.
If you do not press any button for 10 minutes, the machine will switch to OFF mode. Display and all indicators
are turned off.
Completed programme steps will be displayed if you press any button.
4.3.15 HomeWhiz and Remote Control Functions.
HomeWhiz allows you to use your smart device to control your washing machine and get information about it.
Thanks to the HomeWhiz application, you can use your smart device to carry out some procedures you can
also do on the machine. Plus, you can use some features only with the HomeWhiz function.
To use the Bluetooth function of your machine, you should download the HomeWhiz app from the application
store of your device.
Make sure that your smart device is connected to internet to download the app.
If you are using the app for the first time, please follow the on-screen instructions to complete the user
registration process. Once the registration is complete, you can use all products with the HomeWhiz feature in
your house on this account.
On the HomeWhiz app, you can tap “Add/Remove Appliance” to see the products paired with your account.
You can pair these products on this page.
After installing the application, the HomeWhiz function will allow the machine to send you push notifications
via your smart device.
C
To be able to use the HomeWhiz function, make sure that the app is installed on your smart device and that your washing
machine is paired with your smart device via Bluetooth. If the washing machine is not paired with your smart device, it will
function as an appliance without the HomeWhiz feature.
Your product will run once it is paired with your smart device via Bluetooth. Checks performed on the app will be enabled
through this pairing. For this reason, the Bluetooth signal between the product and the smart device must be strong enough.
Please visit www.homewhiz.com to see the Android and iOS versions supported by the HomeWhiz application.
A
WARNING: All the safety measures described in "GENERAL SAFETY INSTRUCTIONS" section of your user
manual apply to the remote operation through HomeWhiz function as well.
26 / EN
Washing Machine / User’s Manual
4.3.15.1 HomeWhiz Setup
Your product and the HomeWhiz app must be connected for the app to run. To establish this connection,
please follow the steps below for setup both on your product and on the HomeWhiz App.
• If you are adding an appliance for the first time, tap “Add/Remove Appliance” on the HomeWhiz App.
Then tap “Tap here to setup new appliance”. Follow the steps below as well as the instructions on the
HomeWhiz App to complete the setup.
•
To start the setup process, make sure that your machine is switched off. Press and hold the Temperature
button and the Remote Control Function button simultaneously for 3 seconds to switch your machine to
HomeWhiz setup mode.
• While the device is in HomeWhiz setup mode, you will see an animation on the display, and the Bluetooth
icon will flash until the machine is paired with your smart device. In this mode, only the programme button is
enabled. Other buttons are disabled.
• On the screen of the app, select the desired washing machine and tap Next.
• Follow on-screen instructions until the HomeWhiz app asks you about the product you wish to connect to
your smart device.
• Return to the HomeWhiz app and wait until the setup is complete. Once the setup is complete, give your
washing machine a name and confirm. You can now tap the screen to see the product you have added to the
HomeWhiz App.
C
If you cannot complete the setup successfully in 5 minutes, the washing machine will switch off automatically. In this case,
you will have to start over the setup procedure. If the problem persists, please contact the Authorised Service Agent.
You can use your washing machine with more than one smart device. To do this, download the HomeWhiz app on the other smart
device as well. After launching the app, you will need to sign in to your account you have previously created and paired with your
washing machine. Otherwise, please read “Setting up a washing machine that is connected to someone else’s account”.
C
The HomeWhiz application may ask you to enter the product number stated on the label of
the product. Product label is found on the inner side of the product door. Product number is
written on this label.
4.3.15.2 Setting up a washing machine that is connected to someone else’s account
If the washing machine you want to use has previously been registered in the system with someone else’s
account, you need to establish a new connection between the HomeWhiz App and the product.
• Download the HomeWhiz App on the new smart device you want to use.
• Create a new account and log in to this account on the HomeWhiz app.
• Follow the steps in the HomeWhiz Setup (4.3.15.1 HomeWhiz Setup) to complete the setup.
C
Since the HomeWhiz and Remote Control functions of your product work through pairing via Bluetooth, the product can be
run by only one HomeWhiz app at a time.
27 / EN
Washing Machine / User’s Manual
4.3.15.3 Using the Remote Control function
After HomeWhiz setup, Bluetooth will turn on automatically. To enable or disable the Bluetooth connection,
please see 4.3.8.2 Bluetooth 3’’’.
If you switch your machine off and on while Bluetooth is enabled, it will reconnect automatically. If the paired
device goes out of the range, the Bluetooth connection will turn off automatically. For this reason, you will need
to turn on Bluetooth again if you want to use the Remote Control function.
You can check the Bluetooth symbol on the display to follow the connection status. If the symbol is on, this
means that the Bluetooth connection is established. If the symbol is established, the product is trying to
connect. If the symbol is off, this means that you have no connection.
A
WARNING: If the Bluetooth connection is enabled on your product, you can select the Remote Control function.
If the Remote Control function cannot be selected, check the connection status. If the connection fails, repeat the initial set-
up settings on the appliance.
WARNING: For safety reasons, the product’s door will remain locked while the Remote Control function is enabled,
independently of the operating mode. If you want to open the door of the product, you will need to turn the programme
selection knob or press the remote control key to deactivate the remote control function.
If you want to control your washing machine remotely, enable the Remote Control function by pressing the
Remote Control button while the programme knob is in the Programme Download/Remote Control position on
the control panel. Once the product is accessed, you will see a screen similar to the one below.
When Remote Control is enabled, you can only manage and switch off the machine and follow status on the
washing machine. All functions except child lock can be managed through the application.
You can check the function indicator on the button to follow whether the Remote Control function is On or Off.
If the Remote Control function is Off, all the operations are handled on the washing machine and only status
follow-up is allowed on the application.
If the Remote Control function cannot be enabled, you will hear a warning after pressing the button. This might
occur if the product is switched on or if there is no product paired through Bluetooth. Bluetooth setting being
Off or the washing machine's door being open are examples for such cases.
When you enable this function on the washing machine, said function will remain on except for certain cases,
allowing you to control your washing machine remotely via Bluetooth.
In certain cases, it deactivates itself for safety reasons:
• When your washing machine undergoes a power interruption.
• When the programme knob is turned to select a different programme or when the product is switched off.
4.3.15.4 Troubleshooting
Follow the steps below if you are having problem with controlling or connection. Observe whether the problem
persists or not after the action you have performed. Do the following if the problem is not resolved.
• Check whether your smart device is connected to the relevant home network.
• Restart the product application.
• Turn Bluetooth off and on through the user control panel.
• If the connection cannot be established with the above processes, repeat the initial set-up settings on the
washing machine.
If the problem persists, consult an Authorised Service Agent.
4.3.15.5 Drum Illumination
Drum illumination light of your machine will turn on during programme selection. The light will turn off
when you start the programme. If no programme is started or no key is pressed within 10 minutes during
programme selection process, the drum illumination light will turn off.
Drum illumination light of your machine will turn on after the programme is completed. It will go off when
you press the On/Off button. The drum illumination light will turn off if you do not press any button within 10
minutes after the programme has ended.
28 / EN
Washing Machine / User’s Manual
4.4 Maintenance and cleaning
Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular
intervals.
4.4.1 Cleaning the detergent drawer
When to clean
• If you see hardened, viscous detergent or softener when you open the dosing container lid,
• If you are not satisfied with the washing results (the detergent or softener may not be taken into the
washing medium since it is hardened),
• If the liquids in the compartment do not decrease for a long time even though you do not add detergent
or softener and dosing is selected,
• If you want to change the washing agents you have added to the compartment (for example, if you are
not satisfied with the detergent and do not want to use it) or if you have made a mistake when adding
the agents (for example, if you have added detergent to the softener compartment or softener to the
detergent compartment),
• If you are going to add a detergent or softener from a different brand than the one you normally use,
• If you are adding a washing agent of a different nature (for example, if you are adding detergent for
coloured laundry when there is detergent for white laundry in the compartment),
• If you are adding a washing agent with a different concentration (To not waste the old detergent, you
can add it to the powder detergent compartment in the next wash and select «powder detergent active»
on the display.)
• If the new softener to be added has the same characteristics but has a different scent (please keep in
mind that if you add the new softener without cleaning the remnants of the previous one, this mixture
will give a different smell),
• If you are not going to use the product for a long time (for example, when going to the summer house
and when returning - 3 months or more) (the washing agent may increasingly thicken and get hardened
in the end, and thus the system may not perform dosing even if it shows that the compartments are full.)
Cleaning:
Before cleaning, press the On/Off button to switch of the product and unplug it.
C
It is recommended for you to wear a glove to avoid contacting the detergent you will take out of the detergent drawer and
other washing agents.
• Press the blue part in the middle of the detergent
drawer and then pull the drawer towards yourself
to take it out.
• Take out the discharge bar that is located at the back of the drawer.
• The hole behind the detergent compartment that will be emptied is placed over a container.
• Slightly push the discharge bar into the slot at the back of the detergent compartment.
• The detergent starts to flow to the container.
• Repeat the same process for softener.
29 / EN
Washing Machine / User’s Manual
• Use a flat screwdriver to remove the tabs holding the upper cover of the detergent drawer (there are
6 tabs in total: two on the right side of the drawer, two on the left and two at the back) and wash the
inside of the drawer.
• After washing it, place the cover back to its location. Make sure that all tabs are fitted. If the tabs do not
seat properly, liquids may leak or the detergent drawer may get stuck or difficultly move on the drawer
slide. For this reason, please ensure that the tabs are fitted in place.
• Fit the discharge bar to its slot at the back of the drawer.
• Paying attention to its slot and slides, fit the drawer back in place and push it to close. After adding
detergent and softener, it will be ready to be used in programmes with dosing function.
4.4.2 Cleaning the loading door and the drum
For products with drum cleaning programme, please see Operating the product - Programmes.
C
Repeat Drum Cleaning process in every 2 months.
Use an anti-limescale suitable for the washing machines.
After every washing make sure that no foreign substance is left in the
product.
If the holes on the bellow shown in the figure is blocked, open the holes
using a toothpick.
Foreign metal substances will cause rust stains in the drum. Clean the
stains on the drum surface by using cleaning agents for stainless steel.
Never use steel wool or wire wool. These will damage the painted,
chromated and plastic surfaces.
4.4.3 Cleaning the body and control panel
Wipe the body of the product with soapy water or non-corrosive mild gel detergents as necessary, and dry
with a soft cloth.
Use only a soft and damp cloth to clean the control panel.
4.4.4 Cleaning the water intake filters
There is a filter at the end of each water intake valve at the rear of the product and also at the end of each
water intake hose where they are connected to the tap. These filters prevent foreign substances and dirt in
the water to enter the product. Filters should be cleaned if they are dirty.
30 / EN
Washing Machine / User’s Manual
1. Close the taps.
2. Remove the nuts of the water intake hoses to access the filters on the water intake valves. Clean them
with an appropriate brush. If the filters are too dirty, remove them from their places with a pliers and
clean in this way.
3. Take out the filters on the flat ends of the water intake hoses together with the gaskets and clean
thoroughly under running water.
4. Replace the gaskets and filters carefully and tighten their nuts by hand.
4.4.5 Draining remaining water and cleaning the pump filter
The filter system in your product prevents solid items such as buttons, coins and fabric fibers clogging the
pump impeller during draining of washing water. Thus, the water will be drained without any problem and the
service life of the pump will extend.
If the product fails to drain water inside it, the pump filter is clogged. Filter must be cleaned whenever it is
clogged or in every 3 months. Water must be drained off first to clean the pump filter.
In addition, prior to transporting the product (e.g., when moving to another house) water should be drained
completely.
A
WARNING: Foreign substances left in the pump filter may damage your product or may cause noise problem.
WARNING: In regions where freezing is possible, the tap must be closed, system hose must be removed and the water
inside the product must be drained when the product is not in use.
WARNING: After each use, turn off the tap to which the mains hose is connected.
In order to clean the dirty filter and drain the water:
1 Unplug the product to cut off the supply power.
A
WARNING: Temperature of the water inside the product may rise up to 90 ºC. To avoid the risk of scalding, clean the
filter after the water inside the product is cooled down.
2 Open the filter cover.
3 Follow the below procedures in order to drain water.
If the product has an emergency water draining hose, in order to drain the water:
a Pull the emergency draining hose out from its
seat.
b Place a large container at the end of the hose.
Drain the water into the container by pulling
out the plug at the end of the hose. When the
container is full, block the inlet of the hose
by replacing the plug. After the container is
emptied, repeat the above procedure to drain the
water in the product completely.
c When draining of water is finished, close the end
by the plug again and fix the hose in its place.
d Turn and remove the pump filter.
4 Clean any residues inside the filter as well as fibers, if any, around the pump impeller region.
5. Replace the filter.
6. If the filter cap is composed of two pieces, close the filter cap by pressing on the tab. If it is one piece, seat
the tabs in the lower part into their places first, and then press the upper part to close.
31 / EN
Washing Machine / User’s Manual
5 Troubleshooting
Problem Cause Solution
Programs do not start after the
loading door is closed.
Start / Pause / Cancel button is not pressed. • *Press Start / Pause / Cancel button.
It may be difficult to close the loading door in case of
excessive loading.
• Reduce the amount of laundry and make sure
that the loading door is closed properly.
Programme cannot be started or
selected.
The product has switched to self protection mode
due to a supply problem (line voltage, water pressure,
etc.).
• To cancel the programme, turn the Programme
Selection knob to select another programme.
Previous programme will be canceled.
(see.“Cancellation of program”)
Water inside the product. Some water has remained in the product due to the
quality control processes in the production.
• This is not a failure; water is not harmful to the
product.
The product does not take water
in.
Tap is turned off. • Turn on the taps.
Water inlet hose is bent. • Flatten the hose.
Water inlet filter is clogged. • Clean the filter.
Loading door is not closed. • Close the door.
The product does not drain water. Water drain hose is clogged or twisted. • Clean or flatten the hose.
Pump filter is clogged. • Clean the pump filter.
Product vibrates or makes noise. Product is standing unbalanced. • Stable the product by adjusting the feet.
A hard substance has entered into the pump filter. • Clean the pump filter.
Transportation safety bolts are not removed. • Remove the transportation safety bolts.
Laundry quantity in the product is too little. • Add more laundry to the product.
Excessive laundry is loaded in the product. • Take out some of the laundry from the product
or distribute the load by hand to balance it
homogeneously in the product.
Product is leaning on a rigid item. • Make sure that the product is not leaning on
anything.
There is water leaking from the
bottom of the product.
Water drain hose is clogged or twisted. • Clean or flatten the hose.
Pump filter is clogged. • Clean the pump filter.
Product stopped shortly after the
programme started.
Machine has stopped temporarily due to low voltage. • Product will resume running when the voltage
restores to the normal level.
Product directly drains the water
it takes in.
Draining hose is not at adequate height. • Connect the water draining hose as described in
the user manual.
No water can be seen in the
product during washing.
Water is inside the invisible part of the product. • This is not a failure.
Loading door cannot be opened. Loading door lock is activated because of the water
level in the product.
• Drain the water by running the Pump or Spin
programme.
Product is heating up the water or it is at the spinning
cycle.
• Wait until the programme completes.
Loading door may be stuck because of the pressure it
is subjected to.
• Grab the handle and push and pull the loading
door to release and open it.
If there is no power, loading door of the product will
not open.
• To open the loading door, open the pump filter
cap and pull down the emergency handle
positioned at the rear side of the said cap. See
"Loading door lock"
32 / EN
Washing Machine / User’s Manual
Problem Cause Solution
Washing takes longer than
specified in the user manual.(*)
Water pressure is low. • Product waits until taking in adequate amount
of water to prevent poor washing quality due to
the decreased amount of water. Therefore, the
washing time extends.
Voltage is low. • Washing time is prolonged to avoid poor washing
results when the supply voltage is low.
Input temperature of water is low. • Required time to heat up the water extends
in cold seasons. Also, washing time can be
lengthened to avoid poor washing results.
Number of rinses and/or amount of rinse water have
increased.
• Product increases the amount of rinse water
when good rinsing is needed and adds an extra
rinsing step if necessary.
Excessive foam has occurred and automatic foam
absorption system has been activated due to too
much detergent usage.
• Use recommended amount of detergent.
Programme time does not
countdown. (On models with
display) (*)
Timer may stop during water intake. • Timer indicator will not countdown until the
product takes in adequate amount of water. The
product will wait until there is sufficient amount
of water to avoid poor washing results due to lack
of water. Timer indicator will resume countdown
after this.
Timer may stop during heating step. • Timer indicator will not countdown until the
product reaches the selected temperature.
Timer may stop during spinning step. • Automatic unbalanced load detection system is
activated due to the unbalanced distribution of the
laundry in the product.
Programme time does not
countdown. (*)
There is unbalanced load in the product. • Automatic unbalanced load detection system is
activated due to the unbalanced distribution of the
laundry in the product.
Product does not switch to
spinning step. (*)
There is unbalanced load in the product. • Automatic unbalanced load detection system is
activated due to the unbalanced distribution of the
laundry in the product.
The product will not spin if water is not drained
completely.
• Check the filter and the draining hose.
Excessive foam has occurred and automatic foam
absorption system has been activated due to too
much detergent usage.
• Use recommended amount of detergent.
Washing performance is poor:
Laundry turns gray. (**)
Insufficient amount of detergent has been used over a
long period of time.
• Use the recommended amount of detergent
appropriate for water hardness and the laundry.
Washing has been made at low temperatures for a
long time.
• Select the proper temperature for the laundry to
be washed.
Insufficient amount of detergent is used with hard
water.
• Using insufficient amount of detergent with hard
water causes the soil to stick on the cloth and
this turns the cloth into gray in time. It is difficult
to eliminate graying once it happens. Use the
recommended amount of detergent appropriate
for water hardness and the laundry.
Excessive amount of detergent is used. • Use the recommended amount of detergent
appropriate for water hardness and the laundry.
33 / EN
Washing Machine / User’s Manual
Problem Cause Solution
Washing performance is poor:
Stains persist or the laundry is not
whitened. (**)
Insufficient amount of detergent is used. • Use the recommended amount of detergent
appropriate for water hardness and the laundry.
Excessive laundry is loaded in. • Do not load the product in excess. Load with
amounts recommended in the "4.3.3 Programme
and consumption table".
Wrong programme and temperature were selected. • Select the proper programme and temperature for
the laundry to be washed.
Wrong type of detergent is used. • Use original detergent appropriate for the product.
Excessive amount of detergent is used. • Put the detergent in the correct compartment. Do
not mix the bleaching agent and the detergent
with each other.
Washing performance is poor: Oily
stains appeared on the laundry.
(**)
Regular drum cleaning is not applied. • Clean the drum regularly. For this procedure,
please see "4.4.2 Cleaning the loading door and
the drum".
Washing performance is poor:
Clothes smell unpleasantly. (**)
Odours and bacteria layers are formed on the drum as
a result of continuous washing at lower temperatures
and/or in short programmes.
• Leave the detergent drawer as well as the loading
door of the product ajar after each washing.
Thus, a humid environment favorable for bacteria
cannot occur in the machine.
Colour of the clothes faded. (**) Excessive laundry was loaded in. • Do not load the product in excess.
Detergent in use is damp. • Keep detergents closed in an environment free
of humidity and do not expose them to excessive
temperatures.
A higher temperature was selected. • Select the proper programme and temperature
according to the type and soiling degree of the
laundry.
Washing machine does not rinse
well.
The amount, brand and storage conditions of the
detergent used are inappropriate.
• Use a detergent appropriate for the washing
machine and your laundry. Keep detergents
closed in an environment free of humidity and do
not expose them to excessive temperatures.
Detergent was put in the wrong compartment. • Add the detergent and the softener to the right
compartment.
Pump filter is clogged. • Check the filter.
Drain hose is folded. • Check the drain hose.
Laundry became stiff after
washing. (**)
Insufficient amount of detergent is used. • Using insufficient amount of detergent for the
water hardness can cause the laundry to become
stiff in time. Use appropriate amount of detergent
according to the water hardness.
Detergent was put in the wrong compartment. • Add the detergent and the softener to the right
compartment.
Detergent was mixed with the softener. • Do not mix the softener with detergent. Wash and
clean the drawer with hot water.
Laundry does not smell like the
softener. (**)
Detergent was put in the wrong compartment. • Add the detergent and the softener to the right
compartment.
Detergent was mixed with the softener. • Do not mix the softener with detergent. Wash and
clean the drawer with hot water.
Softener dosing setting level is low. • Increase the softener dosing amount by one level.
See “Auto Dosing Setting”
34 / EN
Washing Machine / User’s Manual
Problem Cause Solution
Detergent residue in the detergent
drawer. (**)
Detergent was put in wet drawer. • Dry the detergent drawer before putting in
detergent.
Detergent has gotten damp. • Keep detergents closed in an environment free
of humidity and do not expose them to excessive
temperatures.
Water pressure is low. • Check the water pressure.
The detergent in the main wash compartment got
wet while taking in the prewash water. Holes of the
detergent compartment are blocked.
• Check the holes and clean if they are clogged.
There is a problem with the detergent drawer valves. • Call the Authorised Service Agent.
Detergent was mixed with the softener. • Do not mix the softener with detergent. Wash and
clean the drawer with hot water.
Regular drum cleaning is not applied. • Clean the drum regularly. For this procedure,
please see "4.4.2 Cleaning the loading door and
the drum".
Too much foam forms inside the
product. (**)
Improper detergents for the washing machine is used. • Use detergents appropriate for the washing
machine.
Excessive amount of detergent is used. • Use only sufficient amount of detergent.
Detergent was stored under improper conditions. • Store detergent in a closed and dry location. Do
not store in excessively hot places.
Some meshed laundry such as tulle may foam too
much because of their texture.
• Use smaller amounts of detergent for this type
of item.
Detergent was put in the wrong compartment. • Put the detergent in the correct compartment.
Foam is overflowing from the
detergent drawer.
Too much detergent is used. • Mix 1 tablespoonful softener and ½ l water and
pour into the main wash compartment of the
detergent drawer.
• Put detergent into the product suitable for the
programmes and maximum loads indicated
in the “4.3.3 Programme and consumption
table”. When you use additional chemicals (stain
removers, bleaches and etc), reduce the amount
of detergent.
Laundry remains wet at the end of
the programme. (*)
Excessive foam has occurred and automatic foam
absorption system has been activated due to too
much detergent usage.
• Use recommended amount of detergent.
(*) The product does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the
product and to its surrounding environment. Laundry should be rearranged and re-spun.
(**) Regular drum cleaning is not applied. Clean the drum regularly. See 4.4.2
A
WARNING: If you cannot eliminate the problem although you follow the instructions in this section, consult your dealer or
the Authorised Service Agent. Never try to repair a nonfunctional product yourself.
A
WARNING: Check the HomeWhiz section for the relevant troubleshooting information.
