0 1
Note
Base
A list of Accessories
Manual×1
peration Instruction
Control Panel
Buttons Function description
On/Off button
Atomization
adjustment
Lamp control
Timing button
Sleep mode
Humidity setting
Product Introduction
Name of Parts
• The pictures of the Manual are for reference only, and the actual product
in the packing box shall prevail
• The product appearance and function vary with the model; Please be
subject to the real product, with optional reading of the respective
function description.
Atomization outlet
Water tank
Water tray
Control panel
Upper cover
SC-3C40
The current gear is
displayed by default.
SC-3C40B/SC-3C50
The current environmental
humidity is displayed by default
Humidity value
Unit: %RH
After power up, the appliance can be set to be on/idle.
Under normal working conditions short press to enter the
idle status.
Under working conditions, the humiliation and atomization
amount can be set to three levels (small, medium and
large)
SC-3C40
Short press this button while the appliance is working, turn off
the atmosphere lamp -> turn off the dual 8-bit digital screen
-> normal display, and then cycle in order.
SC-3C40B/SC-3C50
Short press this button while the appliance is working, to
switch the light switch.
Under working conditions, the timed shutdown can be set at
1H, 2H, 4H and 8H.
Flash three times, which indicates successful timing.
The humidity value can be set from 40% to 60%. After the
maximum value is achieved, press this button again to
display F (indicating continuous humidification). Press this
button again to recover to 40% (SC-3C40B/SC-3C50 have
such function)
When the sleep mode is activated, the atmosphere lamp is
automatically turned off. In sleep mode, press the sleep
mode button to exit the sleep mode. (SC-3C40B/SC-3C50
have such function)
