3
5
2
4
1
• Features
• Control Panel
• Before First Use
• Cleaning and Maintenance
• How to Cook in the Air Fryer
• How to Program the Air Fryer
RJ38-SQPF-45TDB
CONTROL PANEL
©CHEFMAN 2021
TurboFry
®
Touch
Dual
Air Fryer
QUICK START GUIDE
FEATURES
1. Control Panel
2. Basket 1
3. Basket 2
4. Basket Rack
5. Basket Handles
+ and –
buttons
Use to increase
or decrease time
and temperature.
Press and hold
on left side to
change from °F
to °C; press and
hold on right side
to turn sound off
and on.
Cooking
Preset Buttons
Automatically
set time and
temperature for
popular foods.
Sync Baskets
Button
Programs
both baskets
to cook at the
same time and
temperature.
Sync Finish
Button
Programs
baskets with
different
cooking
times and/or
temperatures
to nish at the
same time.
Time/Temp
Buttons
Select time or
temperature
to set for each
basket. Time
adjusts by
1 minute and
temperature
by 5°.
Start/Stop Button
Starts and stops
the cooking cycle
for the basket
number that’s
illuminated in
blue, or for both
baskets if the Sync
Baskets button is
illuminated.
Running Lights
Illuminate
when basket
is actively
cooking.
Shake Lights
Illuminate
midway
through
cooking as
a reminder
to shake
basket.
Time/Temp
Displays
Toggle between
time and
temperature for
each basket.
To cook in one basket To cook in two baskets
with Sync Baskets
To cook in two baskets
with Sync Finish
Set temperature for
basket 1. Press Time/
Temp on left until
temperature displays,
then press + or – to set.
OR press a preset icon.
Set temperature for
basket 1. Press Time/
Temp on left until
temperature displays,
then press + or – to set.
OR press a preset icon.
Set temperature for
basket 1. Press Time/
Temp on left until
temperature displays,
then press + or – to set.
OR press a preset icon.
Set time for basket 1. If
not using preset, press
Time/Temp button until
time displays, then press
+ or – to set time.
Set time for basket 1. If
not using preset, press
Time/Temp button until
time displays, then press
+ or – to set time.
Set time for basket 1. If
not using preset, press
Time/Temp button until
time displays, then press
+ or – to set time.
Press the button.
Press Sync Baskets.
Set time and
temperature for basket
2 as you did
for basket 1 above.
Press Sync Finish.
Press Start. Press Start. Press Start.
STEP 4
STEP 6
STEP 5
STEP 1
STEP 2
Put food on the
rack(s). Do not
fill the basket(s)
past the Max
line.
STEP 3
HOW TO COOK IN THE AIR FRYERBEFORE FIRST USE
1. Remove all packaging materials, such as plastic bags and foam inserts. Ensure that all parts
and accessories are accounted for.
2. Read and remove any stickers on the unit except for the rating label on the bottom, which
should remain on the unit.
3. Wipe down the interior and exterior with a damp cloth. Wash the baskets and racks with
warm, soapy water. Dry thoroughly.
Set the time and temperature,
independently or in sync as desired
(see chart at right). Press Start.
When the timer is done,
the air fryer will turn off
automatically. Remove
the basket, check food
for doneness, then
carefully transfer food
to plates or a platter
and serve.
CLEANING AND MAINTENANCE
Set the unit on a
hard, flat surface
and plug in.
Lower the racks
into the baskets,
or just one rack
if cooking in one
basket. Press on
the rack(s) to
ensure they are
secure and level.
1. Unplug the unit and let cool completely before cleaning. (For faster cooling, take hot baskets
out of the unit.)
2. To remove the cooled racks from the baskets, pinch the center grip bar on the rack, and pull
the rack straight up and out of the basket. WARNING: Do not lift the rack out of the basket
when hot, or injury can occur.
3. Wash the baskets and racks with warm, soapy water, rinse, and dry well with a towel for best
results. Baskets and racks are also top-rack dishwasher-safe.
4. Wipe down the outside and the inside of the unit with a damp cloth as needed. Do not put the
unit in the dishwasher or submerge in water or any other liquid.
5. Do not use abrasive cleansers on baskets, racks, or the exterior and interior of the appliance,
or you could damage the nishes.
HOW TO PROGRAM THE AIR FRYER
Slide the basket(s) into
the air fryer.
NOTE: If cooking
in one basket,
the other does
not need to
be in place.
During cooking, the Shake light will turn
on for active baskets (not necessarily
simultaneously), and the air fryer will beep
as a reminder to shake (or flip) food as
necessary. If your food does not need to be
shaken, simply ignore the warning.
