LED5050TW3M *RGB.
!!!!! ! ! RGB%LED!FLEXIBLE!TAPE!LIGHTING!KIT!
QUESTIONS OR CONCERNS
CONTACT CANARM AT:
1-800-265-1833 (English) – 1-800-567-2513 (French)
Monday through Friday 8:00 AM to 5:00PM E.S.T.
WARNING
RISK OF ELECTRIC SHOCK
- Transformer must be located indoors. - Turn power off before servicing - see instructions.
- Ensure that no bare wires are exposed outside the electrical connections.
PACKAGE CONTENTS
LED5050TW3M-RGB
• 3 meters Indoor/Outdoor RGB - FLEXIBLE LED TAPE
(SMD5050 30pcs/meter);
• 5’ 12V 1A 24W cULus power supply with on/off switch
• silicone cap • colour changing dimmer with remote
ASSEMBLY AND INSTALLATION INSTRUCTIONS
1. MEASURE – and lay-out the installation prior to removing the backing exposing the adhesive.
Ensure mounting surface is clean and free of any debris or residue.
ATTENTION: ONCE THE LED FLEXIBLE TAPE
IS CUT IT CANNOT BE RE-CONNECTED!!
2. IF CUTTING – Cut the tape at the flat welding plate along the line,
as indicated. (avoid the bulge tin welding plate).
Every 3 LED’s in group is cuttable.
3. CAP – Place a small amount of silicone glue into
the end cap, slide cap on to the end of the tape.
This will ensure a water-tight seal.
4 3/4" power feed cable
assembled on the tape
LED tape
60"cord with on/off switch
silicone cap
dimmer
remote control
Transformer must be located indoors
RGB Dimmer Control with remote:
Voltage: DC12V
Size: 64 X 34.5 X 22.5mm
Remote Distance: 8 m
Current: 2A X 3
Batteries: CR2025, 3V
Work Temperature: -20 ~ 60ºC
Connecting mode：Common anode
4. MOUNT – Remove the backing to expose
adhesive tape. Place in the desired location. To
obtain optimum adhesion, ensure the surface is
clean.
Mounting clips are also provided for extra support.
5. CONNECT –
Connect the power feed cable assembled on the tape to the
RGB Dimmer Control. Then connect the Dimmer Control to the
power supply cord and plug in. RGB Dimmer Control must be
placed in a dry location
Turn on switch in cord, now your remote is ready to use.
To use the RGB Remote Control make sure you are no more than 8 metres away from dimmer.
The RGB Remote Control is capable of many colour changing effects.
(flashing, strobe flash, fade, smooth etc.)
See table below for some options.
Pattern Table
Brightness+
Brightness-
OFF
ON
Static red
Static green
Static blue
Static white
Static rose
Static light green
Static sapphire blue
3 colors jump
Static oranges
Static green blue
Static violet and grey
3 colors gradual
Static light
yellow
Static sky blue
Static brown and purple
7 colors gradual
Static yellow
Static cyan
Static purple
7 colors jump
ONE YEAR LIMITED WARRANTY
The manufacturer warrants this product to be free from defects in workmanship and material present at time of shipment
from the factory for one year from the date of purchase. This warranty applies only to the original purchaser. The
manufacturer agrees to correct such defect at no charge or at our option replace the product with a comparable or superior
model.
Any damage to the product by accident, misuse or improper installation, or by affixing accessories not produced by the
manufacturer, is the purchaser’s responsibility. The manufacturer assumes no responsibility whatsoever for product
installation during the warranty period. There is no further expressed warranty. The manufacturer disclaims any and all
implied warranties. The manufacturer shall not be liable for incidental, consequential or special damages arising at or in
connection with product use or performance except as may otherwise be accorded by law. This warranty gives you specific
legal rights and you may also have other rights which vary from province to province. This warranty supersedes all prior
warranties.
Imported By: CANARM LTD., 2157 Parkedale Ave., P.O. Box 367,
Brockville Ontario, K6V 5V6 • Tel: (613) 342-5424, FAX: (613) 342-8437
