en
2
Table of contents
Safety...............................................4
General information..........................4
Intended use.....................................4
Restriction on user group.................4
Safe installation ................................4
Safe use ...........................................6
Damaged appliance.........................8
Risk to children ................................8
Safety systems ...............................10
Preventing material damage ........11
Safe installation ..............................11
Safe use .........................................11
Childproof lock..............................12
Electric childproof lock...................12
Environmental protection and
saving energy................................12
Disposing of packaging .................12
Saving energy.................................12
Zeolith drying
............................13
AquaSensor....................................13
Efficient Dry ....................................13
Installation and connection..........13
Scope of supply .............................13
Installing and connecting the ap-
pliance ............................................14
Drainage connection ......................14
Drinking water connection .............14
Electrical connection ......................15
Familiarising yourself with
your appliance...............................16
Appliance .......................................16
Controls ..........................................17
Programmes ..................................20
Information for test institutes ..........21
Favourite
....................................21
Additional functions .....................22
Features.........................................22
Top basket .....................................23
Bottom basket ................................23
Cutlery drawer ................................24
Etagere ...........................................24
Folding prongs ...............................24
Basket heights................................25
Before using for the first time ......25
Performing the initial configura-
tion..................................................25
Water softening system................26
Overview of water hardness set-
tings................................................26
Setting the water softening sys-
tem .................................................26
Special salt .....................................26
Switching off the water softening
system ............................................27
Regeneration of the water
softening system ............................28
Rinse aid system...........................28
Rinse aid ........................................28
Setting the amount of rinse aid......29
Switching the rinse aid system
off ...................................................29
Detergent .......................................29
Suitable detergents ........................29
Unsuitable detergents ....................30
Information on detergents ..............30
Adding detergent ...........................31
Tableware ......................................32
Damage to glass and tableware ....32
Arrange tableware ..........................33
Removing tableware.......................34
Basic operation .............................34
Opening appliance door ................34
Switching on the appliance ............34
Setting a programme .....................34
en
3
Setting additional functions ............34
Setting timer programming ............34
Starting the programme .................35
Interrupting programme .................35
Terminate programme....................35
Switching off appliance ..................35
Basic settings................................36
Overview of basic settings .............36
Changing basic settings.................38
HomeConnect ..............................38
HomeConnect quick start .............39
HomeConnect settings..................39
Remote Start
...............................39
Remote Diagnostics ......................40
Software update .............................40
Data protection...............................40
Cleaning and servicing.................41
Cleaning the tub .............................41
Cleaning products ..........................41
Tips on appliance care...................41
Machine Care
.............................41
Filter system ...................................42
Cleaning spray arms ......................43
Troubleshooting............................45
Appliance safety.............................45
Error code / Fault display / Sig-
nal...................................................47
Washing results..............................49
Home Connect problem.................56
Information on display panel..........56
Malfunctions ...................................57
Mechanical damage.......................58
Noise ..............................................58
Clean wastewater pump.................60
Transportation, storage and
disposal .........................................60
Removing the appliance ................60
Protect appliance from frost...........60
Transporting the appliance ............61
Disposing of old appliance ............61
Customer Service..........................61
Product number (E-Nr.), produc-
tion number (FD) and consecut-
ive numbering (Z-Nr.) .....................62
AQUA-STOP guarantee ..................62
Technical specifications...............62
Information regarding Free and
Open Source Software ...................63
Declaration of Conformity ............63
en Safety
4
Safety
Observe the following safety instructions.
General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Do not connect the appliance if it has been damaged in transit.
Intended use
Only use this appliance:
¡ For cleaning household tableware.
¡ In private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of 2500 m above sea level.
Restriction on user group
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Do not let children play with the appliance.
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
Safe installation
WARNING‒Risk of injury!
Improper installation may cause injury.
▶ When installing and connecting the appliance, follow the in-
structions in the manual and installation instructions.
Safety en
5
WARNING‒Risk of electric shock!
¡ Incorrect installation is dangerous.
▶ Connect and operate the appliance only in accordance with
the specifications on the rating plate.
▶ Always use the supplied power cable for the new appliance.
▶ Connect the appliance to a power supply with alternating
current only via a properly installed socket with earthing.
▶ The protective conductor system of the domestic electrical
installation must be properly installed.
▶ Never equip the appliance with an external switching
device, e.g. a timer or remote control.
▶ When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access is not
possible, an all-pole isolating switch must be installed in the
permanent electrical installation according to the installation
regulations.
▶ When installing the appliance, check that the power cable is
not trapped or damaged.
¡ Cutting through the supply hose or immersing the Aqua-Stop
valve in water is dangerous.
▶ Never immerse the plastic housing in water. The plastic
housing on the supply hose contains an electric valve.
▶ Never cut through the supply hose. The supply hose con-
tains electric power cables.
WARNING‒Risk of fire!
¡ It is dangerous to use an extended power cord and non-ap-
proved adapters.
▶ Do not use extension cables or multiple socket strips.
▶ Only use adapters and power cords approved by the manu-
facturer.
▶ If the power cord is too short and a longer one is not avail-
able, please contact an electrician to have the domestic in-
stallation adapted.
en Safety
6
¡ Contact between the appliance and installation lines may lead
to a defect in these lines, e.g. gas pipes and power lines. Gas
from a corroded gas pipe can ignite. A damaged power line
can cause a short circuit.
▶ Check that there is a distance of at least 5cm between the
appliance and installation lines.
WARNING‒Risk of injury!
Hinges move when opening and closing the appliance door
and can cause injury.
▶ If built-under or integrable appliances are not in a cavity so
that one side is accessible, the hinge area must be covered
at the side. Covers are available from Customer Service or
specialist outlets.
WARNING‒Risk of tipping!
Improper installation may cause the appliance to tip up.
▶ Only install built-under or integrable appliances under a
continuous worktop that is securely connected to adjacent
cabinets.
Safe use
WARNING‒Risk of serious harm to health!
Failure to comply with safety instructions and directions for
use on packagings of detergent and rinse aid products may
cause serious harm to health.
▶ Follow the safety instructions and directions for use on the
packagings of detergent and rinse aid products.
WARNING‒Risk of explosion!
¡ Adding solvents to the interior of the appliance may cause ex-
plosions.
▶ Never add solvents to the interior of the appliance.
Safety en
7
¡ Highly caustic alkaline or highly acidic cleaning agents in con-
junction with aluminium parts in the interior of the appliance
may cause explosions.
▶ Never use highly caustic alkaline or highly acidic cleaning
agents, in particular commercial or industrial products, in
conjunction with aluminium parts (e.g. grease filters of ex-
tractor hoods or aluminium pans), e.g. for the Machine Care
programme.
WARNING‒Risk of injury!
¡ Leaving the appliance door open may result in injury.
▶ Only open the appliance door to load or unload tableware
in order to prevent accidents, e.g. through tripping.
▶ Do not sit or stand on the appliance door when open.
¡ Knives and utensils with sharp points can cause injuries.
▶ Arrange knives and utensils with sharp points in the cutlery
basket with the points downwards, on the knife shelf or in
the cutlery drawer.
WARNING‒Risk of scalding!
If you open the appliance door while the programme is run-
ning, hot water may splash out of the appliance.
▶ Open the appliance door carefully if the programme is still
running.
WARNING‒Risk of electric shock!
¡ An ingress of moisture can cause an electric shock.
▶ Only use the appliance in enclosed spaces.
▶ Never expose the appliance to intense heat or humidity.
▶ Do not use steam- or high-pressure cleaners to clean the
appliance.
¡ If the insulation of the power cord is damaged, this is danger-
ous.
▶ Never let the power cord come into contact with hot appli-
ance parts or heat sources.
▶ Never let the power cord come into contact with sharp
points or edges.
en Safety
8
▶ Never kink, crush or modify the power cord.
WARNING‒Risk of burns!
The blow opening of the Zeolith container becomes hot and
can cause burns.
▶ Never touch the blow opening of the Zeolith container.
Damaged appliance
WARNING‒Risk of electric shock!
¡ If the appliance or the power cord is damaged, this is danger-
ous.
▶ Never operate a damaged appliance.
▶ Never operate an appliance with a cracked or fractured sur-
face.
▶ Never pull on the power cord to unplug the appliance. Al-
ways unplug the appliance at the mains.
▶ If the appliance or the power cord is damaged, immediately
unplug the power cord or switch off the fuse in the fuse box
and turn off the water tap.
▶ "Call customer services." →Page61
¡ Incorrect repairs are dangerous.
▶ Repairs to the appliance should only be carried out by
trained specialist staff.
▶ Only use genuine spare parts when repairing the appliance.
▶ If the power cord of this appliance is damaged, it must be
replaced with a special connection cable, which is available
from the manufacturer or his Customer Service.
Risk to children
WARNING‒Risk of suffocation!
¡ Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶ Keep packaging material away from children.
▶ Do not let children play with packaging material.
Safety en
9
¡ Children may breathe in or swallow small parts, causing them
to suffocate.
▶ Keep small parts away from children.
▶ Do not let children play with small parts.
¡ Children may become trapped in the appliance and suffocate.
▶ Use the childproof lock if fitted.
▶ Never let children play with or operate the appliance.
WARNING‒Risk of harm to health!
Children can lock themselves in the appliance, thereby putting
their lives at risk.
▶ With redundant appliances, unplug the power cord. Then
cut through the cord and damage the lock on the appliance
door beyond repair so that the appliance door will no longer
close.
WARNING‒Risk of crushing!
With higher-level appliances, children can become crushed
between the appliance door and cabinet doors underneath.
▶ Keep an eye on children when opening and closing the ap-
pliance door.
WARNING‒Risk of chemical burns!
Rinse aid and detergent may cause chemical burns to the
mouth, throat and eyes.
▶ Keep children away from detergent and rinse aid products.
▶ Keep children away from the appliance when open. The wa-
ter in the interior of the dishwasher is not drinking water. It
may contain residues of detergents and rinse aid.
WARNING‒Risk of injury!
Children may get their fingers caught in the slots of the tablet
collecting tray and injure themselves.
▶ Keep children away from the appliance when open.
Preventing material damage en
11
Preventing material damage
Preventing material dam-
age
Preventing material damage
Safe installation
ATTENTION!
¡ Improper installation of the appli-
ance may cause damage.
▶ If the dishwasher is installed
above or below other domestic
appliances, follow the informa-
tion on installation in combina-
tion with a dishwasher in the in-
stallation instructions for the in-
dividual appliances.
▶ If there is no information or if the
installation instructions do not in-
clude the relevant information,
contact the manufacturer of
these appliances to check that
the dishwasher can be installed
above or below these appli-
ances.
▶ If no information is available
from the manufacturer, the dish-
washer should not be installed
above or below such appli-
ances.
▶ To ensure the safe operation of
all domestic appliances, con-
tinue following the installation in-
structions for the dishwasher.
▶ Do not install the dishwasher un-
der a hob.
▶ Do not install the dishwasher
near heat sources, e.g. radiat-
ors, heat storage tanks, ovens
or other appliances that gener-
ate heat.
¡ Contact between the appliance
and water pipes may lead to corro-
sion of these pipes, possibly caus-
ing them to leak.
▶ Check that there is a distance of
at least 5cm between the appli-
ance and the water pipe. The
pipes supplied for the drinking
water and waste water connec-
tions are not affected here.
¡ Modified or damaged water hoses
may result in material damage and
damage to the appliance.
▶ Never kink, crush, modify or cut
through water hoses.
▶ Only use the water hoses sup-
plied with the appliance or genu-
ine spare hoses.
▶ Never re-use water hoses that
have been used before.
¡ If the water pressure is too high or
too low, the appliance may not be
able to operate properly.
▶ Make sure that the water pres-
sure in the water supply system
is min. 50kPa (0.5bar) and
max. 1000kPa (10bar).
▶ If the water pressure exceeds
the maximum value specified, a
pressure-reducing valve must be
installed between the drinking
water connection and the hose
set of the appliance.
Safe use
ATTENTION!
¡ Escaping water vapour can dam-
age fitted units.
▶ When the programme ends,
leave the appliance to cool
down for a while before opening
the door.
¡ Special salt for dishwashers can
damage the tub due to corrosion.
▶ To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the pro-
gramme starts.
¡ Detergent may damage the water
softening system.
▶ Only fill the dispenser of the wa-
ter softening system with special
dishwasher salt.
en Childproof lock
12
¡ Unsuitable cleaning agents may
damage the appliance.
▶ Do not use a steam cleaner.
▶ So as not to scratch the finish
on the appliance, do not use
sponges with a rough surface or
abrasive cleaning agents.
▶ To prevent corrosion, do not use
sponge cloths on dishwashers
with a stainless steel front or
rinse such cloths thoroughly
several times before using them
for the first time.
Childproof lock
Childproof lock
Childproof lock
The childproof lock lets you protect
children from possible hazards result-
ing from the appliance.
The appliance is equipped with an
electrical childproof lock.
If you have activated the childproof
lock, this means that "automatic door
opening" →Page13 is deactivated.
Electric childproof lock
The electric childproof lock makes it
more difficult to open the appliance
door.
You can activate or deactivate the
electric childproof lock in the "Basic
settings" →Page36.
WARNING
Risk of suffocation!
Children may become trapped in the
appliance and thus suffocate.
▶ Activate the electric childproof lock
and close the appliance door.
→"Opening appliance door",
Page34
Environmental protection and saving energy
Environmental protection
and saving energy
Environmental protection and saving energy
Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
▶ Sort the individual components by
type and dispose of them separ-
ately.
Saving energy
If you follow these instructions, your
appliance will use less electricity and
less water.
Use the Eco50° programme.
The Eco50° programme is en-
ergy-efficient and environmentally
friendly.
→"Programmes", Page20
If you do not have much tableware to
wash, use the additional Half Load
function.
1
The programme will adjust to a
lower load and consumption will
be reduced.
→"Additional functions", Page22
Zeolith drying automatically helps to
save energy.
→"Zeolith drying ", Page13
1
Depending on the appliance specifications
Installation and connection en
13
Zeolith drying
The appliance features a Zeolith con-
tainer. Zeolith drying lets you save
energy.
Zeolite is a mineral that can store
moisture and heat energy and then
release them again.
During dishwashing heat energy is
used to heat up the washing water
and dry the mineral.
During the drying phase moisture
from the interior of the dishwasher is
stored in the mineral and heat energy
is released. The heat energy is blown
out into the interior of the dishwasher
with dry air. This speeds up and im-
proves drying.
Zeolith drying therefore saves a great
deal of energy.
Tip:To avoid impairing Zeolith drying
performance, do not position table-
ware parts directly in front of the in-
take opening or the blow opening of
the Zeolith container.
Do not position heat-sensitive table-
ware parts directly in front of the blow
opening of the Zeolith container.
→"Appliance", Page16
AquaSensor
The AquaSensor is an optical meas-
uring device (light barrier) which
measures the turbidity of the rinsing
water. You can save water with the
AquaSensor.
Use of the AquaSensor depends on
the programme. If the soiling level is
high, the rinsing water is drained off
and replaced with fresh water. If the
soiling level is lower, the rinsing wa-
ter is used in the next wash cycle, so
reducing water consumption by 3-6
litres. In the automatic programmes
the temperature and run time are ad-
ditionally adjusted to the level of soil-
ing.
Efficient Dry
The appliance door opens automatic-
ally during the drying phase. This en-
sures a particularly economical dry-
ing result.
For best drying results wait until the
end of programme before unloading
the tableware. The programme has
ended when the display shows
"0h:00m".
If automatic door opening is deactiv-
ated, energy consumption increases
and the drying phase is usually
shortened.
→"Overview of basic settings",
Page36
Installation and connection
Installation and connec-
tion
Installation and connection
To ensure proper operation, connect
the appliance to the power and water
supply correctly. Observe the spe-
cified criteria and the installation in-
structions.
Scope of supply
After unpacking all parts, check for
any damage in transit and complete-
ness of the delivery.
If you have any complaints, contact
the dealer who sold you the appli-
ance or our Customer Service.
Note:The appliance has been tested
at the factory to check it is in working
order. It is possible that water has left
marks on the appliance. These
marks will disappear after the first
wash cycle.
The delivery consists of the following:
¡ Dishwasher
¡ Operating instructions
¡ Installation Instructions
¡ Further information documents
en Installation and connection
14
¡ Installation material
¡ Steam guard plate
¡ Salt filling aid funnel
¡ Mains cable
¡ Quick reference guide
Installing and connecting the
appliance
You can position your built-under or
integrable appliance in a fitted kit-
chen between wooden and plastic
walls. If you subsequently install your
dishwasher as a free-standing appli-
ance, you must stop it from tipping
over, e.g. by screwing it to the wall or
installing it under a continuous work-
top that is securely connected to ad-
jacent cabinets.
1. "Follow the safety instructions."
→Page4
2. "Follow the instructions for elec-
trical connection." →Page15
3. Check the Scope of supply and
the condition of the appliance.
4. Consult the installation instructions
for the installation dimensions re-
quired.
5. Make the appliance level using the
height-adjustable feet.
Make sure that the appliance is
standing on the floor securely.
6. "Install the drainage connection."
→Page14
7. "Install the drinking water connec-
tion." →Page14
8. Connect the appliance to the
power supply.
Drainage connection
Connect your appliance to drainage
connection so dirty water is dis-
charged via the wash cycle.
Installing the drainage connection
1. Consult the installation instructions
supplied for the steps required
here.
2. Connect the wastewater hose to
the outlet connection of the siphon
using the enclosed parts.
3. When doing so, check that the
wastewater hose is not kinked,
crushed or twisted.
4. Also check that there is no cover
in the drainage system preventing
the wastewater from being dis-
charged.
Drinking water connection
Connect your appliance to a drinking
water connection.
Installing the drinking water
connection
Note
¡ If you are replacing the appliance,
you must use a new water supply
hose.
1. Consult the installation instructions
supplied for the steps required
here.
2. Connect the appliance to the drink-
ing water connection using the en-
closed parts.
Observe the "Technical data"
→Page62.
3. When doing so, check that the
drinking water connection is not
kinked, crushed or twisted.
Installation and connection en
15
Electrical connection
Connecting the appliance to the
electricity supply
Notes
¡ Please follow the "Safety instruc-
tions" →Page4.
¡ Connect the appliance to alternat-
ing current only, in the range of
220 - 240V and 50Hz or 60Hz.
¡ Please note that the water safety
system is only functional if there is
a power supply.
1. Insert the non-heating appliance
plug of the power cable into the
appliance.
2. Insert the mains plug of the appli-
ance into a nearby socket.
The connection data for the appli-
ance can be found on the rating
plate.
3. Check that the mains plug is inser-
ted properly.
en Familiarising yourself with your appliance
16
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Appliance
You can find an overview of the parts of your appliance here.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
Rating plate Rating plate with "E number and FD number"
→Page62.
The data you need for "Customer Service"
→Page61.
1
Depending on the appliance specifications
Familiarising yourself with your appliance en
17
2
Detergent dispenser "Detergent" →Page29 is added to the detergent
dispenser.
3
Bottom basket "Bottom basket" →Page23
4
Dispenser for special salt Add special salt to the dispenser for special salt.
→"Water softening system", Page26
5
Lower spray arm The lower spray arm washes the tableware in the bot-
tom basket.
If the tableware has not been washed properly, clean
the spray arms.
→"Cleaning spray arms", Page43
6
Tablet collecting tray During the wash cycle tablets automatically fall out of
the detergent dispenser into the tablet collecting tray
where they can fully dissolve.
7
Top basket "Top basket" →Page23
8
Cutlery drawer "Cutlery drawer" →Page24
9
Cutlery shelf
1
"Cutlery shelf" →Page24
10
Upper spray arm The upper spray arm washes the tableware in the top
basket.
If the tableware has not been washed properly, clean
the spray arms.
→"Cleaning spray arms", Page43
11
Intake opening of the Zeolith con-
tainer
The intake opening is required for "Zeolith drying"
→Page13.
12
Blow opening of the Zeolith con-
tainer
The blow opening is required for "Zeolith drying "
→Page13.
13
Filter system "Filter system" →Page42
14
Dispenser for rinse aid Add rinse aid to the dispenser for rinse aid.
→"Rinse aid system", Page28
1
Depending on the appliance specifications
Controls
You can use the control panel to configure all functions of your appliance and
to obtain information about the operating status.
With some buttons you can perform different functions.
en Familiarising yourself with your appliance
18
1 2 3 4 5 6 7 8
910111213
1
ON/OFF button and reset button "Switching on the appliance" →Page34
"Switching off the appliance" →Page35
"Terminating the programme" →Page35
2
Programme buttons "Programmes" →Page20
3
Special salt refill indicator Water softening system
→"Adding special salt", Page26
4
Rinse aid refill indicator Rinse aid system
→"Adding rinse aid", Page28
5
WLAN display "Home Connect" →Page38
6
Water supply display Display for water supply
7
Programme buttons and additional
functions
Programmes
→"Programmes", Page20
Additional functions
→"Additional functions", Page22
8
Start button "Starting the programme" →Page35
9
button If you press for approx. 3 seconds,
you can open the basic settings.
10
Remote Start →"Remote Start ", Page39
11
Timer programming "Setting timer programming" →Page34
12
Door handle
1
"Open the appliance door." →Page34
1
Depending on the appliance specifications
Familiarising yourself with your appliance en
19
13
Display The display shows information about the remain-
ing running time or the basic settings. You can
change the basic settings via the display and the
setting buttons.
1
Depending on the appliance specifications
en Programmes
20
Programmes
Programmes
Programmes
You can find an overview of the pro-
grammes that can be selected here.
Different programmes, which can be
found on the control panel of your
appliance, are available depending
on the appliance configuration.
The running time may vary depend-
ing on the programme selected. The
running time depends on the water
temperature, the quantity of table-
ware, the level of soiling and the ad-
ditional function selected. The
runtime will change if the rinse aid
system is switched off or rinse aid
needs to be added.
The consumption values can be
found in the quick reference guide.
The consumption values relate to
normal conditions and a water hard-
ness of 16-20°E. Different influen-
cing factors such as water temperat-
ure or pipe pressure may result in
deviations.
Programme: Use Programme sequence Additional func-
tions
Intensive 70°
Tableware:
¡ Washing pots and pans,
non-fragile tableware and
cutlery.
Level of soiling:
¡ Removing stubborn
burned or dried-on food
remnants containing
starch and protein.
Intensive:
¡ Pre-Rinse
¡ Cleaning 70°C
¡ Intermediate rinse
¡ Final rinse 50°C
¡ Dry
All
→"Additional
functions",
Page22
Auto 45-65°
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food remnants
lightly dried-on.
Sensor-controlled:
¡ Optimised by sensors de-
pending on the soiling of
the rinsing water.
All
→"Additional
functions",
Page22
Eco 50°
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food remnants
lightly dried-on.
Most economical pro-
gramme:
¡ Pre-Rinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Final rinse 35°C
¡ Drying
All
→"Additional
functions",
Page22
Programmes en
21
Programme: Use Programme sequence Additional func-
tions
Silence 50
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food remnants
lightly dried-on.
Reduced noise:
¡ Pre-Rinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Final rinse 35°C
¡ Dry
All
→"Additional
functions",
Page22
Express 60°
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food remnants
lightly dried-on.
Time-optimised:
¡ Cleaning 60°C
¡ Intermediate rinse
¡ Final rinse 50°C
¡ Dry
All
→"Additional
functions",
Page22
Machine Care
Use only if appliance is un-
loaded.
Machine Care 70°C None
Favourite
- - -
Note:The relatively long running time
in the Eco50° programme is due to
longer soaking and drying times. This
results in optimal consumption val-
ues.
Information for test institutes
Test institutes are provided with in-
formation for comparability tests, e.g.
according to EN60436.
These are the conditions for conduct-
ing the tests, however they are not
the results or consumption values.
E-mail enquiries to: dishwasher@test-
appliances.com
The product number (E-Nr.) and the
production number (FD) are required
here. They can be found on the rat-
ing plate on the appliance door.
Favourite
You can save a combination of a pro-
gramme and an additional function to
the button.
You can save the program via the
Home Connect app or on the appli-
ance.
The pre-rinse program is saved to
this button at the factory. Pre-rinse is
suitable for all types of tableware.
The tableware undergoes intermedi-
ate cleaning via cold rinsing.
Tip:You can use the Home Connect
app to download additional pro-
grammes and save them to the
button.
1
Save Favourite
on the appliance.
1. Open the appliance door.
2. Press .
1
Depending on the appliance specifications
en Additional functions
22
3. Press the right programme button.
→"Programmes", Page20
4. Press the button for the relevant
additional function.
→"Additional functions", Page22
5. Press
for 3 seconds.
a The selected programme and the
additional function will flash.
a
flashes.
a The programme and the additional
function are saved.
Tip:To reset the programme, either
use the Home Connect app or reset
your appliance back to the factory
settings.
→"Overview of basic settings",
Page36
Additional functions
Additional functions
Additional functions
You can find an overview of the addi-
tional functions that can be selected
here. Different additional functions,
which can be found on the control
panel of your appliance, are available
depending on the appliance configur-
ation.
Additional func-
tion
Use
SpeedPerfect+
¡ The run time is
shortened by 15% to
75% depending on the
rinse programme.
¡ The additional function
can be activated before
the start of the pro-
gramme and at any
time when the pro-
gramme is running.
¡ Energy and water con-
sumption are increased.
Additional func-
tion
Use
If you select this additional
function, "automatic door
opening" →Page36 in
the "o02" setting is deactiv-
ated.
Half Load
¡ Switch on with small
loads.
¡ It is recommended
adding less detergent
to the detergent dis-
penser than for a full
machine load.
¡ The run time is
shortened.
¡ Energy and water con-
sumption are reduced.
ExtraDry
¡ For a better drying res-
ult the final rinse tem-
perature is increased
and the drying phase
extended.
¡ Especially suitable for
drying plastic parts.
¡ There is a slight in-
crease in energy con-
sumption and the run
time is extended.
Features
Features
Features
You can find an overview of the pos-
sible features of your appliance and
how to use them here.
These features depend on the model
of your appliance.
Features en
23
Top basket
Arrange cups, glasses and small
items of tableware in the top basket.
You can adjust the height of the top
basket to make room for larger items
of tableware.
Adjusting top basket with side
levers
To wash large items of tableware in
the baskets, adjust the shelf position
of the top basket.
1. Pull out the top basket.
2. To prevent the basket from sud-
denly dropping down, hold the
side of the basket by the top edge.
3. Press in the levers on the right and
left on the outside of the basket.
4. Raise or lower the basket evenly to
the right level.
Check that the basket is level on
both sides.
5. Release the levers.
a The basket clicks into position.
6. Slide the basket back in.
Bottom basket
Arrange pans and plates in the bot-
tom basket.
Large plates up to a diameter of
31cm can be arranged in the bottom
basket as shown.
en Features
24
Cutlery drawer
Arrange cutlery in the cutlery drawer.
Arrange cutlery with the points and
sharp edges downwards.
Etagere
Use the cutlery shelf and space un-
derneath for small cups and glasses
or for large items of cutlery, e.g.
cooking spoons or serving cutlery.
If you do not need the cutlery shelf,
you can fold it up.
Folding prongs
Use the folding prongs to position
tableware securely, e.g. plates.
You can fold the prongs down to po-
sition pans, bowls and glasses
better.
1
Folding down prongs
1
If you do not need the prongs, fold
them down.
1
Depending on the appliance specifications
Before using for the first time en
25
1. Push the lever forwards and fold
down the prongs .
1
2
2. To use the prongs again, fold them
back up.
a The prongs audibly click into posi-
tion.
Basket heights
Set the baskets at the right height.
Appliance height 81.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 16 cm 30 cm/"31 cm" →Page23
2 max. ø 18.5 cm 27.5 cm
3 max. ø 21 cm 25 cm
Before using for the first time
Before using for the
first time
Before using for the first time
Performing the initial config-
uration
On initial start-up or after a reset to
the factory settings, you will need to
make settings.
Tip:Connect your appliance to a mo-
bile device. You can conveniently
change all settings via the
HomeConnect app.
→"HomeConnect quick start",
Page39
Requirement:"The appliance has
been installed and connected."
→Page13
1.
"Add special salt." →Page26
2.
"Add rinse aid." →Page28
3. "Switch on the appliance."
→Page34
4. "Setting the water softening sys-
tem." →Page26
5. "Set the amount of rinse aid to be
dispensed." →Page29
6.
"Add detergent" →Page29.
7. Start the Programme with the
highest cleaning temperature
without tableware.
To remove any marks from water
or other residues, we recommend
you operate the appliance without
tableware before using it for the
first time.
Tip:You can change these settings
and other "Basic settings"
→Page36 at any time.
en Water softening system
26
Water softening system
Water softening system
Water softening system
Hard water leaves limescale on the
tableware as well as the washing
tank and parts of the appliance may
become blocked.
To ensure good dishwashing results,
you can treat the water with special
salt and the water softening system.
To avoid damage to the appliance,
water with a hardness above 9 °E
must be softened.
Overview of water hardness settings
You can find an overview of the water hardness values that can be selected
here.
You can find out how hard your water is from your local water company or by
using a water hardness tester.
Water hardness °E Hardness range mmol/l Setting value
0 - 8 Soft 0 - 1.1 H00
9 - 10 Soft 1.2 - 1.4 H01
11 - 12 Medium 1.5 - 1.8 H02
13 - 15 Medium 1.9 - 2.1 H03
16 - 20 Medium 2.2 - 2.9 H04
21 - 26 Hard 3.0 - 3.7 H05
27 - 38 Hard 3.8 - 5.4 H06
39 - 62 Hard 5.5 - 8.9 H07
Note:Set the water hardness determ-
ined on your appliance.
→"Setting the water softening sys-
tem", Page26
With a water hardness of 0 - 8°E
you can dispense with special salt for
dishwashers and switch off the water
softening system.
→"Switching off the water softening
system", Page27
Setting the water softening
system
Set the water hardness on your appli-
ance.
1. Determine the water hardness and
the appropriate setting value.
→"Overview of water hardness set-
tings", Page26
2. Press
.
3. To open the basic settings, press
for 3 seconds.
a The display shows Hxx.
a The display shows
.
4. Press
repeatedly until the
right water hardness has been set.
The value H04 is set at the factory.
5. To save the settings, press
for 3 seconds.
Special salt
You can use special salt to soften
water.
Adding special salt
If the special salt refill indicator lights
up, add special salt to the dispenser
for special salt just before the pro-
gramme starts. The consumption of
special salt depends on the water
Water softening system en
27
hardness. The higher the water hard-
ness, the greater the consumption of
special salt.
ATTENTION!
¡ Detergent may damage the water
softening system.
▶ Only fill the dispenser of the wa-
ter softening system with special
dishwasher salt.
¡ Special salt for dishwashers can
damage the tub due to corrosion.
▶ To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the pro-
gramme starts.
1. Unscrew the lid of the dispenser
for special salt and remove.
2. On initial start-up: Fill the dispenser
right up with water.
3. Note:Only use special salt for
dishwashers.
Do not use salt tablets.
Do not use table salt.
Add the special salt to the dis-
penser.
Fill the dispenser right up with spe-
cial salt. The water in the dis-
penser is displaced and forced
out.
4. Place the lid back on the dis-
penser and turn to close.
Switching off the water
softening system
If you find the special salt refill indic-
ator irritating, e.g. when using com-
bined detergents with salt replace-
ment substances, you can switch the
indicator off.
Note
To avoid damage to the appliance, only
switch off the water softening system in
the following cases:
¡ The water hardness is max. 26 °E
and you are using combined deter-
gents with salt replacement sub-
stances. According to manufactur-
ers, combined detergents with salt
replacement substances can gen-
erally only be used up to a water
hardness of 26 °E without adding
special salt.
¡ The water hardness is 0 - 8°E.
You do not need to use special
salt.
1. Press
.
2. To open the basic settings, press
for 3 seconds.
a The display shows Hxx.
a The display shows
.
3. Press
repeatedly until the dis-
play shows H00.
4. To save the settings, press
for 3 seconds.
a The water softening system is
switched off and the salt refill indic-
ator is deactivated.
en Rinse aid system
28
Regeneration of the water
softening system
In order to obtain fault-free function of
the water softening system, the appli-
ance performs regeneration of the
water softening system at regular in-
tervals.
Regeneration of the water softening
system takes place before the end of
the main rinse cycle in all pro-
grammes. It will increase the run time
and consumption values, e.g. water
and electricity.
Overview of consumption values
with regeneration the water
softening system
Here you can find an overview of the
maximum additional run time and
consumption values during regenera-
tion of the water softening system.
Regeneration of the water softening
system after x rinse cycles
6
Additional run time in minutes 7
Additional water consumption in
litres
5
Additional power consumption in
kWh
0.05
The consumption values specified
are laboratory measurements determ-
ined in accordance with the currently
applicable standard and using the
Eco 50° programme and the factory
value of the water hardness is set to
16 - 20°E.
Rinse aid system
Rinse aid system
Rinse aid system
Rinse aid
For optimum drying results, use rinse
aid.
Only use rinse aid for domestic dish-
washers.
Adding rinse aid
If the rinse aid refill indicator lights
up, top up with rinse aid. Only use
rinse aid for domestic dishwashers.
1. Press the catch on the lid of the
dispenser for rinse aid
and lift
.
1
2
2. Add rinse aid up to the max mark.
max
3. If rinse aid spills out, remove it
from the tub.
Spilled rinse aid can cause ex-
cessive frothing during the wash
cycle.
Detergent en
29
4. Close the lid of the dispenser for
rinse aid.
a The lid clicks into position.
Setting the amount of rinse
aid
If there are streaks or water marks on
tableware, change the amount of
rinse aid.
1. Press
.
2. To open the basic settings, press
for 3 seconds.
a The display shows Hxx.
a The display shows
.
3. Press
repeatedly until
the display shows the value set at
the factory r05.
4. Press
repeatedly until the
right amount of rinse aid has been
set.
– A low setting adds less rinse aid
during the wash cycle and re-
duces streaking on tableware.
– A higher setting adds more
rinse aid during the wash cycle,
reduces water marks and im-
proves the drying result.
5. To save the settings, press
for 3 seconds.
Switching the rinse aid sys-
tem off
If you find the rinse aid refill indicator
irritating, e.g. when using combined
detergents with a rinse aid compon-
ent, you can switch the rinse aid sys-
tem off.
Tip:The function of rinse aid is lim-
ited with combined detergents. You
will generally get better results using
rinse aid.
1. Press
.
2. To open the basic settings, press
for 3 seconds.
a The display shows Hxx.
a The display shows
.
3. Press
repeatedly until
the display shows the value set at
the factory r05.
4. Press
repeatedly until the dis-
play shows r00.
5. To save the settings, press
for 3 seconds.
a The rinse aid system is switched
off and the rinse aid refill indicator
is deactivated.
Detergent
Detergent
Detergent
Suitable detergents
Only use detergents that are suitable
for dishwashers. Both separate and
combined detergents are suitable.
For optimum washing and drying res-
ults, use separate detergent, adding
"Special salt" →Page26 and "Rinse
aid" →Page28 separately.
Modern, powerful detergents mainly
use a low-alkaline formulation with
enzymes. Enzymes break down
starch and remove protein. Oxygen-
based bleaching agents are generally
used to remove coloured marks, e.g.
tea or ketchup.
Note:Follow the manufacturer's in-
structions for each detergent.
Detergent Description
Tabs Tabs are suitable for all
cleaning functions and do
not need to be measured
out.
With shorter "Pro-
grammes" →Page20 tabs
sometimes do not dissolve
entirely and leave residues
of detergent. This may im-
pair the cleaning effect.
en Detergent
30
Detergent Description
Powder deter-
gent
Powder detergent is re-
commended for shorter
"Programmes" →Page20.
The dosage can be adjus-
ted to the level of soiling.
Liquid detergent Liquid detergent works
faster and is recommen-
ded for shorter "Pro-
grammes" →Page20
without PreRinse.
Sometimes liquid deter-
gent may leak out despite
the detergent dispenser
being closed. This is not a
fault and is non-critical if
you remember the follow-
ing:
¡ Only choose a pro-
gramme without PreR-
inse.
¡ Do not select timer pro-
gramming for starting
the programme.
The dosage can be adjus-
ted to the level of soiling.
Tip:Suitable detergents are available
online via our website or from "Cus-
tomer Service" →Page61.
Separate detergents
Separate detergents are products
that do not contain components other
than detergent, e.g. powder deter-
gent or liquid detergent.
With powder and liquid detergent the
dosage can be individually adjusted
to the level of soiling of the table-
ware.
For better washing and drying results
and to avoid damage to the appli-
ance, please additionally use "Spe-
cial salt" →Page26 and "Rinse aid"
→Page28.
Combined detergent
Besides conventional separate deter-
gents, a number of products are
available with additional functions.
These products contain not only de-
tergent but also rinse aid and salt re-
placement substances (3in1) and,
depending on the combination (4in1,
5in1,...), additional components such
as glass protection or stainless steel
cleaner.
According to manufacturers, com-
bined detergents generally only func-
tion up to a water hardness of 26
°E. With a water hardness above 26
°E you will need to add special salt
and rinse aid. For the best washing
and drying results we recommend
using special salt and rinse aid from
a water hardness of 17°E. If you are
using combined detergent, the wash-
ing programme is adjusted automat-
ically to ensure the best possible
washing and drying result.
Unsuitable detergents
Do not use detergent which could
cause damage to the appliance or
present a risk to health.
Detergent Description
Hand washing-up
liquid
Hand washing-up liquid
can cause increased froth-
ing and damage the appli-
ance.
Detergent con-
taining chlorine
Chlorine residue on table-
ware may present a risk to
health.
Information on detergents
Follow the instructions on detergents
in everyday use.
¡ Detergents marked as "organic" or
"ecological" (environmentally
friendly) generally contain lower
levels of active agents or com-
Detergent en
31
pletely dispense with certain sub-
stances. The cleaning effect may
be restricted here.
¡ Set the rinse aid and the water
softening system to the separate
detergent or combined detergent
in use.
¡ According to manufacturers, com-
bined detergents with salt replace-
ment substances can only be used
up to a certain water hardness,
usually 26 °E, without adding spe-
cial salt. For the best washing and
drying results we recommend us-
ing special salt from a water hard-
ness of 17°E.
¡ To prevent sticking, only touch de-
tergents in a water-soluble pouch
with dry hands and only ever place
them in a dry detergent dispenser.
¡ Even if the rinse aid and special
salt refill indicators light up, wash-
ing programmes will run properly
with combined detergents.
¡ The function of rinse aid is limited
with combined detergents. You will
generally get better results using
rinse aid.
¡ Use tablets with a special drying
performance.
Adding detergent
1. To open the detergent dispenser,
press the locking latch.
2. Add the detergent to the dry deter-
gent dispenser.
15 ml
25 ml
50 ml
If you are using tablets, one is
enough. Insert the tablets in a hori-
zontal position.
If you are using powder or liquid
detergent, follow the manufac-
turer's instructions and quantities
for dosage in the detergent dis-
penser.
20ml–25ml detergent is suffi-
cient for normal soiling. If table-
ware is only lightly soiled, slightly
less than the amount of detergent
specified is usually sufficient.
en Tableware
32
3. Close the lid of the detergent dis-
penser.
a The lid clicks into position.
a The detergent dispenser will open
automatically at the optimum time
during the programme. Powder or
liquid detergent will spread around
the washing tank and dissolve
there. Tablets will fall into the tablet
collecting tray and dissolve in the
right dosage. In order to ensure
that tablets can dissolve evenly, do
not place any other objects in the
tablet collecting tray.
Tip:If you use powder detergent and
select a program with pre-rinse, you
can also add a little detergent to the
interior door of the appliance.
Tableware
Tableware
Tableware
Only clean tableware that is suitable
for dishwashers.
Note:Decorated glassware and parts
made of aluminium or silver may
fade or discolour with dishwashing.
Delicate types of glass may turn
cloudy after a few washing cycles.
Damage to glass and table-
ware
Only put glasses and china in the
dishwasher if it is marked as dish-
washer-safe by the manufacturer.
Avoid damage to glass and table-
ware.
Cause Recommendation
The following table-
ware is not dish-
washer-safe:
¡ Items of cutlery
and tableware
made from wood
¡ Decorated glass-
ware, antique and
hand-crafted table-
ware
¡ Plastic parts not
resistant to heat
¡ Tableware made
from copper or tin
¡ Tableware soiled
with ash, wax, lub-
ricating grease or
paint
¡ Very small items of
tableware
Only put tableware in
the dishwasher if it is
marked as dish-
washer-safe by the
manufacturer.
The chemical com-
position of detergent
causes damage.
Use a detergent
marked by the manu-
facturer as gentle on
tableware.
Highly caustic alkaline
or highly acidic clean-
ing solutions, in partic-
ular commercial or in-
dustrial cleaners, are
not safe to use in the
dishwasher with alu-
minium.
If you are using highly
caustic alkaline or
highly acidic cleaning
agents, in particular
commercial or indus-
trial cleaning agents,
do not put aluminium
parts in the dish-
washer interior.
Tableware en
33
Cause Recommendation
The water temperat-
ure of the programme
is too high.
Select a programme
with lower temperat-
ures.
After the programme
has ended, take glass-
ware and cutlery out
of the appliance
without delay.
Arrange tableware
Arrange tableware correctly to optim-
ise the dishwashing result and pre-
vent damage to both the appliance
and tableware.
Tips
¡ Using the appliance allows you to
save energy and water compared
to washing-up by hand.
¡ See our website for examples of
how to load your appliance effi-
ciently, free of charge.
¡ To save energy and water, load
the machine with the number of
place settings specified (standard
load with tableware and cutlery).
→"Technical specifications",
Page62
¡ For better washing and drying res-
ults, position items with curves or
recesses at an angle so water can
run off.
1. Remove large remnants of food
from tableware.
To save resources, do not pre-
rinse tableware under running wa-
ter.
2. Observe the following when arran-
ging tableware:
– Put heavily soiled tableware in
the bottom basket, e.g. pans.
The more powerful the spray jet,
the better the dishwashing result
will be.
– To prevent damage to table-
ware, arrange it so it is stable
and cannot tip over.
– To prevent injury, arrange cut-
lery with the points and sharp
edges facing down.
– Position containers with the
openings facing down so no wa-
ter can collect in them.
– Do not block the spray arms -
make sure that they can turn
freely.
– Do not place small parts in the
tablet collecting tray and do not
block it with tableware so as not
to obstruct the lid of the deter-
gent dispenser.
en Basic operation
34
Removing tableware
WARNING
Risk of injury!
Hot tableware can cause burns to the
skin. When hot, tableware is sensitive
to shock, may crack and can result in
injury.
▶ When the programme has ended,
do not empty the appliance until
the tableware has cooled down for
a while.
1. To prevent water dripping on the
tableware, unload it starting at the
bottom and working up.
2. Check the washing tank and ac-
cessories for soiling and clean if
necessary.
→"Cleaning and servicing",
Page41
Basic operation
Basic operation
Basic operation
Opening appliance door
1. If the electric childproof lock is not
activated, press on the upper
middle section of the appliance
door.
2. If the electric childproof lock is ac-
tivated, press on the upper middle
section of the appliance door twice
with a short interval in between.
a The appliance door will open auto-
matically.
Switching on the appliance
▶ Press
.
The Eco 50° programme is set by
default.
The Eco 50° programme is espe-
cially environmentally friendly and
ideal for normally soiled tableware.
It is the most efficient programme
for the combination of energy/wa-
ter consumption for this type of
tableware and evidences conform-
ity with the EU Ecodesign Direct-
ive.
If you do not perform any actions
on the appliance for 10 minutes,
the appliance will automatically
switch off.
Setting a programme
To adjust the wash cycle to the soil-
ing level of the tableware, select a
suitable programme.
▶ Press the right programme button.
→"Programmes", Page20
a The programme is set and the pro-
gramme button flashes.
a The remaining running time of the
programme appears on the dis-
play.
Setting additional functions
You can set additional functions to
complete the washing programme
selected.
Note:The additional functions which
can be used depend on the pro-
gramme selected.
→"Programmes", Page20
▶ Press the button for the relevant
additional function.
→"Additional functions", Page22
a The additional function is set and
the additional function button
flashes.
Setting timer programming
You can delay the start of the pro-
gramme by up to 24hours.
1. Press
.
a "h:01" appears in the display.
2. Use to set the required start
time for the programme.
Basic operation en
35
3. Press .
a This activates timer programming.
Tip:To deactivate timer program-
ming, press repeatedly until "h:00"
appears in the display.
Starting the programme
▶ Press
.
a The programme has ended when
the display shows "0h:00m".
Notes
¡ If you want to add more tableware
while the appliance is running, do
not use the tablet collecting tray as
a handle for the top basket. You
might touch the partially dissolved
tablet.
¡ You can only change a pro-
gramme when running if you can-
cel it.
→"Terminate programme",
Page35
¡ The appliance switches off auto-
matically 1minute after the end of
the programme to save energy. If
you open the appliance door im-
mediately after the programme has
ended, the appliance will switch off
after 4 seconds.
Interrupting programme
Note:When you open the appliance
door once the appliance has heated
up, leave the door slightly ajar for a
few minutes and then close it. This
will help prevent excess pressure
building up in the appliance and stop
the appliance door bursting open.
1. Open the appliance door carefully.
2. Press
.
a The programme is saved and the
appliance switches off.
3. Press
to resume the pro-
gramme.
4. Close the appliance door.
Terminate programme
To end a programme early or to
switch from a programme that has
already started, you will need to can-
cel it first.
1. Open the appliance door.
2. Press for approx.
4seconds.
3. Close the appliance door.
a All displays light up.
a As soon as the displays are off,
the display shows "0h:01m" and
the residual water is pumped out.
a The programme is cancelled and
ends after approx. 1minute.
Switching off appliance
1. Please note the information on
"Safe use" →Page11.
2. Press
.
Tip:If you press
during the wash
cycle, the programme currently run-
ning will be interrupted. When you
switch the appliance back on, the
programme continues automatically.
en Basic settings
36
Basic settings
Basic settings
Basic settings
You can configure the basic settings for your appliance to meet your needs.
Overview of basic settings
The basic settings depend on the features of your appliance.
Basic setting Display text Selection Description
Water hardness H04
1
H00 - H07 Set the water softening system to
your water hardness.
→"Setting the water softening sys-
tem", Page26
Level H00 switches the water soften-
ing system off.
Rinse aid dispensing r05
1
r00 - r06 Set the amount of rinse aid to be dis-
pensed.
→"Setting the amount of rinse aid",
Page29
Switch the rinse aid system off with
level r00.
Intensive drying d00
1
d00 - d01 The temperature is increased during
the final rinse, which improves the
drying result. This may increase the
run time slightly.
Note:Not suitable for delicate items
of tableware.
Switch Extra Dry on "d01" or off
"d00".
Hot water A00
1
A00 - A01 Set cold water or hot water connec-
tion. Only set the appliance to hot
water if this can be prepared with
little energy and a suitable installa-
tion is available, e.g. solar heating
system with circulation line. The wa-
ter temperature should be at least
40°C and max. 60°C.
Switch hot water on "A01" or off
"A00".
1
Factory setting (may vary according to model)
Basic settings en
37
Basic setting Display text Selection Description
InfoLight I01
1
I00 - I01 Switch InfoLight on or off.
While the programme is running, a
spot of light is projected onto the
floor below the appliance door. This
light will not be visible if the appli-
ance is installed at eye level with the
cabinet front fitted flush. If the appli-
ance door is not completely closed,
the spot of light will flash. The pro-
gramme has ended when the spot of
light is no longer visible on the floor.
Level "I00" switches InfoLightoff.
Tone volume b02
1
b00 - b03 Adjustment of tone volume.
Level "b00" switches the signal tone
off.
If the Eco drying function is activ-
ated, the end of the programme is
not indicated by an audible signal
tone.
Childproof lock c00
1
c00 - c01 Switch the
→"Electric childproof lock",
Page12 on or off.
Level "c00" switches the childproof
lock off.
Efficient Dry o02
1
o00 - o02 Activate or deactivate automatic
opening of the appliance door during
the drying phase.
If the function has been activated,
the running time may increase.
The following settings are possible:
¡ With the setting "o00" automatic
door opening is deactivated in all
programmes.
¡ With the setting "o01" automatic
door opening is activated in all
programmes.
¡ With the setting "o02" automatic
door opening is activated only in
the Eco 50°C programme.
→"Efficient Dry", Page13
1
Factory setting (may vary according to model)
en HomeConnect
38
Basic setting Display text Selection Description
Wi-Fi Cn0 Cn0 - Cn1 Switch the wireless network connec-
tion on or off.
Level "Cn0" switches the wireless
network connection off.
The basic setting "Wi-Fi" is only avail-
able once the appliance is connec-
ted to the HomeConnect app.
→"HomeConnect ", Page38
Remote Start rc1 rc0 - rc2 Activate or deactivate
→"Remote Start ", Page39.
The following settings are possible:
¡ With the setting "rc0", the func-
tion is permanently deactivated.
¡ With the setting "rc1", the func-
tion can be selected via the
button.
→"Activating Remote Start ",
Page40
¡ With the setting "rc2", the func-
tion is permanently activated.
This basic setting is not available un-
til after you have connected the
device with the HomeConnect app.
→"HomeConnect ", Page38
Factory setting rE Start with
YES
Confirm with
Restore changed settings to the fact-
ory settings.
The settings for initial start-up must
be configured.
1
Factory setting (may vary according to model)
Changing basic settings
1. Open the appliance door.
2. Press
.
3. To open the basic settings, press
for 3 seconds.
a The display shows Hxx.
a The display shows
.
4. Press
repeatedly until
the display shows the required set-
ting.
5. Press
repeatedly until the dis-
play shows the right value.
You can change several settings.
6. To save the settings, press
for 3 seconds.
7. Close the appliance door.
HomeConnect
HomeConnect
HomeConnect
This appliance is network-capable.
Connect your appliance to a mobile
device to control its functions via the
HomeConnect app.
The HomeConnect services are not
available in every country. The avail-
ability of the HomeConnect function
depends on the availability of
HomeConnect en
39
HomeConnect services in your coun-
try. You can find information about
this at: www.home-connect.com.
To be able to use HomeConnect,
you must first set up the connection
to the WLAN home network (Wi-Fi
1
)
and to the HomeConnect app.
¡ →"Connecting the appliance to
WLAN home network (Wi-Fi)",
Page39
The HomeConnect app guides you
through the entire login process. Fol-
low the instructions in the HomeCon-
nect app to configure the settings.
Tips
¡ Please consult the documents sup-
plied by HomeConnect.
¡ Please also follow the instructions
in the HomeConnect app.
Note:Please note the safety precau-
tions in this instruction manual and
make sure that they are also ob-
served when operating the appliance
via the HomeConnect app.
→"Safety", Page4
HomeConnect quick start
Connect your appliance to a mobile
device quickly and easily.
Installing app
1. Install the HomeConnect app on
your mobile device.
2. Start the HomeConnect app and
set up access for HomeConnect.
The HomeConnect app guides
you through the entire login pro-
cess.
Connecting the appliance to WLAN
home network (Wi-Fi)
Requirements
¡ The HomeConnect app is installed
on your mobile device.
¡ Wi-Fi is activated on the router.
¡ The appliance receives signals
from the WLAN home network (Wi-
Fi) at its installation location.
1. With the help of the HomeConnect
app scan the QR code.
2. Follow the instructions in the
HomeConnect app.
HomeConnect settings
Adapt HomeConnect to your needs.
You can find the HomeConnect set-
tings in the basic settings for your ap-
pliance. Which settings the display
shows will depend on whether
HomeConnect has been set up and
whether the appliance is connected
to your home network.
Remote Start
You can use the HomeConnect app
to start the appliance with your mo-
bile device.
Tip:If you select "rc2" in the "Basic
settings" →Page38 of this function,
the function is permanently activated
and you can start your appliance with
a mobile device at any time.
1
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
en HomeConnect
40
Activating Remote Start
When you have selected "rc1" in the
basic settings of this function, activ-
ate the function on your appliance.
Requirements
¡ The appliance is connected to your
WLAN home network.
¡ The appliance is connected to the
HomeConnect app.
¡ "rc1" is selected in the "Basic set-
tings " →Page38 of this function.
¡ A programme is selected.
▶ Press
.
If you open the appliance door, the
function is automatically deactiv-
ated.
a
button lights up.
Tip:To deactivate the function, press
.
Remote Diagnostics
Customer Service can use Remote
Diagnostics to access your appliance
if you contact them, have your appli-
ance connected to the HomeCon-
nect server and if Remote Dia-
gnostics is available in the country in
which you are using the appliance.
Tip:For further information and de-
tails about the availability of Remote
Diagnostics in your country, please
visit the service/support section of
your local website: www.home-con-
nect.com
Software update
You can use this function to update
the software of your appliance, e.g.
for optimisation, troubleshooting or
safety-relevant updating.
The HomeConnect app informs you
about available software updates.
Data protection
Please see the information on data
protection.
The first time your appliance is
registered on a home network
connected to the Internet, your
appliance will transmit the following
types of data to the HomeConnect
server (initial registration):
¡ Unique appliance identification
(consisting of appliance codes as
well as the MAC address of the
Wi-Fi communication module in-
stalled).
¡ Security certificate of the Wi-Fi
communication module (to ensure
a secure data connection).
¡ The current software and hardware
version of your appliance.
¡ Status of any previous reset to
factory settings.
This initial registration prepares the
HomeConnect functions for use and
is only required when you want to
use the HomeConnect functions for
the first time.
Note:Please note that the
HomeConnect functions can only be
utilised with the HomeConnect app.
Information on data protection can be
retrieved in the HomeConnect app.
Cleaning and servicing en
41
Cleaning and servicing
Cleaning and servicing
Cleaning and servicing
To keep your appliance working effi-
ciently for a long time, it is important
to clean and maintain it carefully.
Cleaning the tub
WARNING
Risk of harm to health!
Using detergents containing chlorine
may result in harm to health.
▶ Never use detergents containing
chlorine.
1. Remove any coarse soiling in the
interior with a damp cloth.
2. Add detergent to the detergent dis-
penser.
3. Select the programme with the
highest temperature.
→"Programmes", Page20
4. "Start the programme without
tableware." →Page35
Cleaning products
Only use suitable cleaning products
to clean your appliance.
→"Safe use", Page11
Tip:You can get our tested and ap-
proved Dishwasher Care and Ma-
chine Cleaner for Dishwashers online
at https://www.bosch-home.com/
store or from customer service.
Tips on appliance care
Follow the tips on appliance care to
make sure your appliance functions
properly at all times.
Action Benefit
Wipe the door seals,
the front of the dish-
washer and the con-
trol panel regularly us-
ing a damp cloth and
washing-up liquid.
This ensures the parts
of the appliance will
remain clean and hy-
gienic.
If the appliance is not
going to be used for a
while, leave the door
slightly ajar.
This will prevent un-
pleasant odours.
Machine Care
Deposits, e.g. from remnants of food
and limescale, can cause your appli-
ance to malfunction. To avoid such
faults and reduce odours, we recom-
mend cleaning your appliance at reg-
ular intervals.
Machine Care combined with ma-
chine care products and machine
cleaners is the right programme for
the care of your appliance.
Tip:You can get our tested and ap-
proved Dishwasher Care and Ma-
chine Cleaner for Dishwashers online
at https://www.bosch-home.com/
store or from customer service.
Machine Care is a programme which
removes various deposits in one
washing cycle. Cleaning takes place
in two phases:
Phase Removal of Detergent Placement
1 Grease and limescale Liquid machine care product
or machine descaler in
powder form.
Appliance interior, e.g. bottle
hung in the cutlery basket or
powder in the interior.
2 Food remnants and de-
posits
Machine cleaner Detergent dispenser
en Cleaning and servicing
42
To ensure optimum cleaning perform-
ance, the programme doses the de-
tergents independently of each an-
other during the relevant cleaning
phase. Correct placement of the de-
tergents is necessary here.
Run Machine Care without tableware
if the indicator for Machine Care
lights up on the control panel or if ad-
vised to do so by the display. The in-
dicator will go out after you have run
Machine Care. If your appliance does
not have a reminder function, we re-
commend performing Machine Care
every 2months.
RunningMachine Care
Notes
¡ Run the Machine Care programme
without any tableware in the dish-
washer.
¡ Only use machine care products
and machine cleaners specially
designed for dishwashers.
¡ Make sure that there are no alu-
minium parts, e.g. extractor hood
grease filters or aluminium pans, in
the interior of the appliance.
¡ If you have not run Machine Care
after 3 washing cycles, the indic-
ator for Machine Care will go out
automatically.
¡ For optimum cleaning perform-
ance, ensure the correct place-
ment of cleaners.
¡ Follow the safety instructions given
on the packagings of the machine
care products and machine clean-
ers.
1. Remove any coarse soiling in the
interior with a damp cloth.
2. Clean the filters.
3. Place the machine care product in
the appliance interior.
Only use machine care products
specially designed for dishwash-
ers.
4. Pour the machine cleaner into the
detergent dispenser until it is filled
completely.
Do not place any additional ma-
chine cleaner in the appliance in-
terior.
5. Press
.
6. Press
.
a Machine Care is run.
a Once the programme has ended,
the indicator for Machine Care
goes out.
Filter system
The filter system removes coarse
soiling from the dishwashing cycle.
1
2
3
1
Micro filter
2
Fine filter
3
Coarse filter
Cleaning filters
Soiling in the dishwashing water may
block the filters.
1. After each wash check the filters
for residue.
Cleaning and servicing en
43
2. Turn the coarse filter anticlockwise
and remove the filter system .
‒ Check that no foreign objects
fall into the sump.
1
2
3. Pull down the micro filter to re-
move.
4. Press the locking catches to-
gether and lift the coarse filter out
.
1
2
5. Clean the filter elements under run-
ning water.
Carefully clean the rim of dirt
between the coarse and the fine fil-
ter.
6. Re-assemble the filter system.
Make sure that the locking catches
on the coarse filter click into posi-
tion.
7. Insert the filter system into the ap-
pliance and turn the coarse filter
clockwise.
‒ Make sure that the arrow mark-
ings match up.
Cleaning spray arms
Limescale and soiling in the dish-
washing water may block the nozzles
and bearings on the spray arms.
Clean the spray arms regularly.
1. Unscrew the upper spray arm
and pull down to remove .
1
2
en Cleaning and servicing
44
2. Pull up the lower spray arm to re-
move.
3. Check the outlet nozzles on the
spray arms for blockages under
running water and remove any for-
eign bodies.
4. Insert the lower spray arm.
a The spray arm clicks into position.
5. Insert the upper spray arm and
screw it firmly in place.
Troubleshooting en
45
Troubleshooting
Troubleshooting
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshoot-
ing information before contacting after-sales service. This will avoid unneces-
sary costs.
WARNING
Risk of electric shock!
Incorrect repairs are dangerous.
▶ Repairs to the appliance should only be carried out by trained specialist
staff.
▶ Only use genuine spare parts when repairing the appliance.
▶ If the power cord of this appliance is damaged, it must be replaced with a
special connection cable, which is available from the manufacturer or his
Customer Service.
Appliance safety
Fault Cause Troubleshooting
Appliance door opens acci-
dently.
Automatic door opening ac-
tivated accidently.
▶ To prevent the appliance door
opening accidentally, activate the
childproof lock.
Appliance door does not
open at the end of the pro-
gramme.
Automatic door opening is
not activated.
▶ Activate the automatic door open-
ing.
→"Overview of basic settings",
Page36
Childproof lock is activated. ▶ Deactivate the childproof lock.
Door is not correctly adjus-
ted.
▶ Adjust the appliance door as de-
scribed in the installation instruc-
tions.
The door gap must be at least
70mm - 100mm.
Appliance door and door
seal are soiled.
▶ Clean the appliance door and door
seal with a damp cloth and a little
washing-up liquid.
Wrong screws used to ad-
just the door gap.
▶ Use size 4X30 bolts to adjust the
door gap.
The bolts are included in the scope
of supply.
If you use bolts that are too long,
this can deactivate the function of
automatic door opening.
The safety device switches
off automatic door opening.
▶ Call "Customer Service."
→Page61
en Troubleshooting
46
Fault Cause Troubleshooting
Appliance door does not
open at the end of the pro-
gramme.
Appliance door brushes
against the appliance or kit-
chen cabinets
▶ Install the appliance correctly as de-
scribed in the installation instruc-
tions and align.
Appliance door opens too
wide at the end of the pro-
gramme.
Door is not correctly adjus-
ted.
▶ Adjust the appliance door as de-
scribed in the installation instruc-
tions.
The door gap must be at least
70mm - 100mm.
Wrong screws used to ad-
just the door gap.
▶ Use size 4X30 bolts to adjust the
door gap.
The bolts are included in the scope
of supply.
If you use bolts that are too long,
this can deactivate the function of
automatic door opening.
Appliance door does not
open.
Childproof lock is activated. ▶ Press the top of the door in the
middle twice in quick succession.
Door is not correctly adjus-
ted.
▶ Adjust the appliance door as de-
scribed in the installation instruc-
tions.
Appliance has no power. ▶ Check the mains plug and fuses.
1. Position the emergency release
supplied on the top right and left of
the cabinet panel.
2. Open the appliance door by pulling
lightly.
Appliance door and door
seal are soiled.
▶ Clean the appliance door and door
seal with a damp cloth and a little
washing-up liquid.
Automatic door opening is
not in home position.
▶ Wait one second after closing the
appliance door.
Troubleshooting en
47
Fault Cause Troubleshooting
Appliance door opens too
wide when activated.
Door is not correctly adjus-
ted.
▶ Adjust the appliance door as de-
scribed in the installation instruc-
tions.
Error code / Fault display / Signal
Fault Cause Troubleshooting
E:20-60 lights up alternately. Appliance has detected cal-
cified heating element.
1. Descale the appliance.
2. Operate the appliance with the wa-
ter softening system.
1
E:21-30 will light up altern-
ately.
Intake opening of Zeolith
container is covered by
items of tableware.
▶ Re-arrange the tableware in the ap-
pliance so the "Intake opening of
the Zeolith container " →Page16
is no longer obstructed.
E:30-00 will light up altern-
ately.
Water protection system is
activated.
1. Turn off the water tap.
2. Call "Customer Service"
→Page61.
E:31-00 will light up altern-
ately.
Water protection system is
activated.
1. Turn off the water tap.
2. Call "Customer Service"
→Page61.
E:32-00 will light up altern-
ately or indicator for water
supply lights up.
Supply hose is kinked. ▶ Install the supply hose without
kinks.
Water tap is turned off. ▶ Turn on the water tap.
Water tap is jammed or
furred up.
▶ Turn on the water tap.
The flow rate must be at least 10 l/
min when the water supply is open.
The filters in the water con-
nection of the supply or
AquaStop hose are blocked.
1. Switch off the appliance.
2. Pull out the mains plug.
3. Turn off the water tap.
4. Unscrew the water connection.
1
Depending on the appliance specifications
en Troubleshooting
48
Fault Cause Troubleshooting
E:32-00 will light up altern-
ately or indicator for water
supply lights up.
5. Remove the filter from the supply
hose
6. Clean the filter.
7. Re-insert the filter in the supply
hose.
8. Screw the water connection back
on.
9. Check the water connection for
leaks.
10. Restore the power supply.
11. Switch the appliance on.
E:34-00 will light up altern-
ately.
Water is continuously run-
ning into the appliance.
1. Turn off the water tap.
2. Call "Customer Service"
→Page61.
E:61-02 will light up altern-
ately.
Wastewater pump is
blocked.
▶ Clean the wastewater pump.
→"Clean wastewater pump",
Page60
Cover of the wastewater
pump is loose
▶ Secure the cover of the "Wastewa-
ter pump " →Page60 so it clicks
into position.
E:61-03 will light up altern-
ately. Water is not drained.
Wastewater hose is blocked
or kinked.
1. Reposition the wastewater hose
without kinks.
2. Remove residues.
Siphon connection is still
sealed.
▶ Check the connection to the siphon
and open if necessary.
Cover of the wastewater
pump is loose.
▶ Secure the cover of the "Wastewa-
ter pump " →Page60 so it clicks
into position.
Troubleshooting en
49
Fault Cause Troubleshooting
E:90-01 will light up altern-
ately.
Mains voltage is too low. This is not a fault on the appliance.
1. Contact an electrician.
2. Have the mains voltage and elec-
trical installation checked by an
electrician.
E:92-40 will light up altern-
ately.
Filters are soiled or blocked. ▶ Clean the filters.
→"Cleaning filters", Page42
A different error code ap-
pears in the display window.
E:01-00 to E:90-10
A technical fault is present. 1. Press .
2. Unplug the appliance or switch off
the fuse.
3. Wait at least 2minutes.
4. Insert the mains plug of the appli-
ance in a socket or switch on the
fuse.
5. Switch the appliance on.
6. If the problem occurs again:
‒ Press
.
‒ Turn off the water tap.
‒ Pull out the mains plug.
‒ Contact "Customer Service"
→Page61 and give the er-
ror code.
Washing results
Fault Cause Troubleshooting
Tableware is not dry. No rinse aid used or dosage
set too low.
1. Add "Rinse aid" →Page28.
2. Set the amount of rinse aid to be
dispensed.
→"Setting the amount of rinse aid",
Page29
Programme or programme
option has no drying phase,
or the drying phase is too
brief.
▶ "Select a programme with drying,
e.g. intensive, strong or ECO pro-
gramme." →Page20
Some option buttons decrease the
drying result, e.g varioSpeed.
en Troubleshooting
50
Fault Cause Troubleshooting
Tableware is not dry. Water collects in recesses of
the tableware or cutlery.
▶ Position tableware at an angle
where possible.
The combined detergent
used has a poor drying per-
formance.
1. Use rinse aid to improve drying per-
formance.
2. Use a different combined detergent
with a better drying performance.
Extra Dry not activated to im-
prove drying performance.
▶ Activate Extra Dry.
Tableware removed too
early or drying process not
yet ended.
1. Wait until the programme ends.
2. Only remove tableware 30minutes
after the programme has ended.
Rinse aid used has a limited
drying performance.
▶ Use a name-brand rinse aid.
Eco products may have limited ef-
fectiveness.
Appliance door does not
open automatically at the
end of the programme
▶ Adjust the appliance door as de-
scribed in the installation instruc-
tions.
The door gap must be at least
70mm - 100mm.
Plastic tableware is not dry. Not a fault. As plastic does
not store heat so well, it also
does not dry as well.
▶ No remedial action possible.
Cutlery is not dry. Cutlery not arranged prop-
erly in the cutlery basket or
cutlery drawer.
Droplets can form on the cutlery con-
tact points.
1. "Arrange cutlery individually where
possible." →Page33
2. Avoid points of contact.
Troubleshooting en
51
Fault Cause Troubleshooting
Appliance interior still wet
after wash cycle.
Not a fault. The condensa-
tion drying principle causes
water droplets in the tub –
they are indeed desirable
here. The moisture in the air
condenses on the inside
walls, runs off and is
pumped out.
No action required.
Remnants of food on table-
ware.
Tableware is placed too
close together or basket is
overfilled.
1. Arrange tableware with sufficient
space in between.
The spray jets must reach the sur-
faces of the tableware.
2. Avoid points of contact.
Spray arm rotation is
blocked.
▶ Arrange tableware so that it does
not obstruct spray arm rotation.
Spray arm nozzles are
blocked.
▶ Clean the "Spray arms" →Page43.
Filters are soiled. ▶ Clean the filters.
→"Cleaning filters", Page42
Filters are inserted incor-
rectly and/or not engaged.
1. Insert the filters properly.
→"Filter system", Page42
2. Engage the filters.
Washing programme selec-
ted too weak.
▶ Select a more intensive washing
programme.
→"Programmes", Page20
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶ Only remove large remnants of food
and do not prerinse tableware.
Tall narrow receptacles in
corner areas are not rinsed
adequately.
▶ Do not position tall narrow recept-
acles at too great an angle or in
corner areas.
Top baskets on right and left
are not set to same height.
▶ Set the top baskets on the left and
right to the same level.
en Troubleshooting
52
Fault Cause Troubleshooting
Detergent residue in the ap-
pliance
Lid of the detergent dis-
penser is blocked by items
of tableware parts and will
not open.
1. Arrange tableware in the top basket
tableware so the tab collecting tray
is not obstructed by tableware.
→"Arrange tableware", Page33
Items of tableware are blocking the
dispenser lid.
2. Do not place tableware or fra-
grance dispensers in the tablet col-
lecting tray.
The lid of the detergent dis-
penser is blocked by the tab
and will not open.
▶ Position the tab in the detergent dis-
penser crosswise, not vertically.
Tabs are used in the quick
or short programme. Dissolv-
ing time of the tab is not at-
tained.
▶ Select a more intensive "Pro-
gramme" →Page20 or use
"Powder detergent" →Page29.
Washing effect and dissolv-
ing performance are re-
duced after a prolonged
storage time or detergent is
very lumpy.
▶ Change your "detergent"
→Page29.
Water marks on plastic
parts.
Due to laws of physics
droplet formation on plastic
surfaces is unavoidable.
After drying water marks are
visible.
▶ Select a more intensive pro-
gramme.
→"Programmes", Page20
▶ Position tableware at an angle.
→"Arrange tableware", Page33
▶ Use rinse aid.
→"Rinse aid", Page28
▶ Set the water softening system
higher.
Wipeable or water-soluble
coatings are present inside
the appliance or on the door.
Detergent substances are
deposited there. These coat-
ings cannot generally be re-
moved with chemicals.
▶ Change your "detergent"
→Page29.
▶ Clean the appliance mechanically.
White coating is deposited in
the appliance interior.
1. Set the water softening system cor-
rectly.
In most cases you will need to in-
crease the setting.
2. Change your detergent if required.
Special salt dispenser is not
screwed tight.
▶ Screw the special salt dispenser
tight.
Troubleshooting en
53
Fault Cause Troubleshooting
Stubborn white coatings are
present on tableware, inside
the appliance or the door.
Detergent substances are
deposited there. These coat-
ings cannot generally be re-
moved with chemicals.
▶ Change your "detergent"
→Page29.
▶ Clean the appliance mechanically.
The hardness range is set in-
correctly or the water hard-
ness is greater than 62°E
(8,9mmol/l).
▶ Set the Water softening system to
the water hardness or add special
salt.
3in1/organic/eco detergent
is not effective enough.
▶ Set the Water softening system to
the water hardness and use separ-
ate detergents (proprietary deter-
gent, special salt, rinse aid).
Too little detergent is being
used.
▶ Increase the amount of detergent
used or change "Detergent "
→Page29.
Washing programme selec-
ted too weak.
▶ Select a more intensive washing
programme.
→"Programmes", Page20
Tea residue or lipstick marks
on tableware.
Washing temperature is too
low.
▶ Select a programme with a higher
washing temperature.
→"Programmes", Page20
Too little detergent is being
used or is unsuitable.
▶ Use a suitable "Detergent "
→Page29 and follow the manufac-
turer's instructions for the amount
to be used.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶ Only remove large remnants of food
and do not prerinse tableware.
Coloured coatings (blue, yel-
low, brown) that are difficult
or impossible to remove are
present inside the appliance
or on stainless steel table-
ware.
The formation of films is due
to substances contained in
vegetables (cabbage, celery,
potatoes, noodles, etc.) or
tap water (manganese).
▶ Clean the appliance.
You can remove deposits with
"Mechanical cleaning" →Page41
or a machine cleaning product. It
may not always be possible to com-
pletely remove deposits but they
are harmless to health.
The formation of films is due
to metal components on sil-
ver or aluminium tableware.
▶ Clean the appliance.
You can remove deposits with
"Mechanical cleaning" →Page41
or a machine cleaning product. It
en Troubleshooting
54
Fault Cause Troubleshooting
Coloured coatings (blue, yel-
low, brown) that are difficult
or impossible to remove are
present inside the appliance
or on stainless steel table-
ware.
may not always be possible to com-
pletely remove deposits but they
are harmless to health.
Coloured deposits (yellow,
orange, brown) that are easy
to remove are present inside
the appliance (mainly at the
bottom).
The formation of films is due
to ingredients of food rem-
nants and tap water (limes-
cale) "soaplike".
1. Check the setting of the water
softening system.
2. Add special salt.
→"Adding special salt", Page26
3. If you are using combined deter-
gents (tabs), activate the water
softening system.
Follow the information about deter-
gents.
→"Information on detergents",
Page30
Plastic parts inside the appli-
ance are discoloured.
Plastic parts inside the appli-
ance may become discol-
oured during the life of the
dishwasher.
▶ Discolouration can come about and
will not impair functioning of the ap-
pliance.
Plastic parts are discol-
oured.
Washing temperature is too
low.
▶ Select a programme with a higher
washing temperature.
→"Programmes", Page20
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶ Only remove large remnants of food
and do not prerinse tableware.
Removable streaks are
present on glasses, glass-
ware with a metallic appear-
ance and cutlery.
Amount of rinse aid to be
dispensed is set too high.
▶ Set the rinse aid system to a lower
setting.
No rinse aid has been ad-
ded.
▶ →"Adding rinse aid", Page28
Detergent residue is present
in the final rinse. Lid of the
detergent dispenser is
blocked by tableware items
and will not open fully.
1. Arrange tableware in the top basket
tableware so the tab collecting tray
is not obstructed by tableware.
→"Arrange tableware", Page33
Items of tableware are blocking the
dispenser lid.
2. Do not place tableware or fra-
grance dispensers in the tablet col-
lecting tray.
Troubleshooting en
55
Fault Cause Troubleshooting
Removable streaks are
present on glasses, glass-
ware with a metallic appear-
ance and cutlery.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶ Only remove large remnants of food
and do not prerinse tableware.
Irreversible clouding of
glassware.
Glasses are not dishwasher-
proof, only suitable for dish-
washers.
▶ Use dishwasher-proof glasses.
Glasses are usually only suitable for
use in a dishwasher, i.e. long-term
wear or long-term changes must be
expected.
▶ Avoid a lengthy steam phase
(standing time after wash cycle
ends).
▶ Use a programme with a lower tem-
perature.
→"Programmes", Page20
▶ Set the softening system to the wa-
ter hardness.
▶ Use detergent with a glass protec-
tion component.
Rust spots on cutlery. Cutlery is not sufficiently
rust-resistant. Knife blades
are often more severely af-
fected.
▶ Use rust-resistant tableware.
Cutlery may also rust if
washed together with rust-
ing items.
▶ Do not wash rusting items.
Salt content in washing wa-
ter is too high.
1. Remove any spilled special salt
from the tub.
2. Screw the cap of the special salt
dispenser on tight.
Detergent residue is present
in the detergent dispenser
or the tablet collecting tray.
Spray arms were blocked by
tableware so detergent was
not rinsed out.
▶ Check that the spray arms are not
blocked and can rotate freely.
Detergent dispenser was
damp when detergent was
added.
▶ Only add detergent to a detergent
dispenser when dry.
Excessive formation of foam
occurs.
Hand washing-up liquid is
present in dispenser for
rinse aid.
▶ Immediately add rinse aid to the
dispenser.
→"Adding rinse aid", Page28
Rinse aid has been spilled. ▶ Remove the rinse aid with a cloth.
en Troubleshooting
56
Fault Cause Troubleshooting
Excessive formation of foam
occurs.
Detergent or appliance care
product used causes excess-
ive foaming.
▶ Change the brand of detergent.
Home Connect problem
Fault Cause Troubleshooting
Connection to home net-
work is not established.
WLAN on router is not act-
ive.
▶ Check the wireless network con-
nection of your router.
WLAN display is flashing. Connection to home net-
work is not available.
▶ Activate the wireless network con-
nection on your router.
Home Connect cannot be
implemented correctly.
Home Connect set incor-
rectly.
▶ Please consult the documents sup-
plied for HomeConnect.
Technical fault is present. ▶ Please consult the information
about support in the documents
supplied for HomeConnect.
Information on display panel
Fault Cause Troubleshooting
Special salt refill indicator
lights up.
Insufficient special salt. ▶ Add "Special salt" →Page26.
Sensor does not detect spe-
cial salt tablets.
▶ Do not use special salt tablets.
Refill indicator for special
salt does not light up.
Water softening system is
switched off.
▶ Setting the water softening system
Refill indicator for rinse aid
lights up.
Insufficient rinse aid. 1. Add "Rinse aid" →Page28.
2. Set the amount of rinse aid to be
dispensed.
→"Setting the amount of rinse aid",
Page29
Refill indicator for rinse aid
does not light up.
Rinse aid system is switched
off.
▶ Set the amount of rinse aid to be
dispensed.
Display flashes. Appliance door is not closed
properly.
▶ Close the appliance door.
‒ Arrange the tableware so
that no parts project beyond
the basket and prevent the
appliance door from closing
properly.
Troubleshooting en
57
Malfunctions
Fault Cause Troubleshooting
Water is left in the appliance
at the end of the pro-
gramme.
Filter system or area under
the filters is blocked.
1. Clean the "Filters" →Page42.
2. Clean the "Wastewater pump"
→Page60.
Programme has not yet
ended.
▶ Wait until the programme ends or
cancel the programme with Reset.
▶ →"Terminate programme",
Page35
Appliance cannot be
switched on or operated.
Software update is taking
place.
▶ Wait until the software update has
finished.
Appliance functions have
failed.
1. Pull out the mains plug or switch off
the fuse.
2. Wait at least 2minutes.
3. Connect the appliance to the power
supply.
4. Switch the appliance on.
Appliance does not start. The mains fuse has tripped. ▶ Check the relevant fuse.
Mains cable is not inserted. 1. Check whether the socket works.
2. Check whether the mains cable is
properly inserted in the socket and
on the rear of the appliance.
Appliance door is not closed
properly.
▶ Close the appliance door.
Programme starts automat-
ically.
You did not wait until pro-
gramme ended.
▶ →"Terminate programme",
Page35
Appliance stops during the
programme or cuts out.
Appliance door is not closed
properly.
▶ Close the appliance door.
Power and/or water supply
has been interrupted.
1. Check the power supply.
2. Check the water supply.
Top basket is pressing
against inner door and pre-
venting appliance door from
being closed securely.
▶ Check whether the rear panel of the
appliance is being pressed in by a
socket or hose holder that has not
been removed.
▶ Arrange the tableware so that no
parts project beyond the basket
and prevent the appliance door
from closing properly.
en Troubleshooting
58
Fault Cause Troubleshooting
All LEDs lit up or flashing. Electronics have detected a
fault.
1. Press the main switch button for ap-
prox. 4seconds.
→"Controls", Page17
The appliance is reset and restar-
ted.
2. If the problem occurs again:
‒ Switch off the appliance.
‒ Pull out the mains plug or
switch off the fuse in the fuse
box.
‒ Wait at least 2minutes.
‒ Switch on the fuse in the fuse
box or insert the mains plug.
‒ Switch the appliance on.
3. If the problem occurs again:
‒ Contact customer service.
→"Customer Service",
Page61
Mechanical damage
Fault Cause Troubleshooting
Appliance door cannot be
closed.
Door lock has been activ-
ated.
▶ Close the appliance door with
greater force.
Door cannot be closed due
to installation method.
▶ Check whether the appliance has
been installed properly.
When closed, the appliance door,
its decor or attached parts should
not knock against adjacent cabin-
ets or the worktop.
Automatic door opening is
not in home position.
▶ Wait for a second after opening the
appliance door.
Lid on the detergent dis-
penser cannot be closed.
Detergent dispenser or lid
are blocked by sticky deter-
gent residue.
▶ Remove detergent residue.
Noise
Fault Cause Troubleshooting
Filling valves making knock-
ing noises.
Caused by the domestic in-
stallation. No appliance fault
present. Does not affect
functioning of the appliance.
▶ Can only be remedied in the do-
mestic installation.
Troubleshooting en
59
Fault Cause Troubleshooting
Knocking or rattling noise. Spray arm is striking table-
ware.
▶ Arrange tableware so that the spray
arms do not strike tableware.
With a small load the water
jets directly strike against
the tub.
▶ Distribute the tableware evenly.
▶ Load the appliance with more table-
ware.
Light items of tableware
move about during the wash
cycle.
▶ Position light items of tableware se-
curely.
en Transportation, storage and disposal
60
Clean wastewater pump
Large remnants of food or foreign
bodies can block the waste water
pump. As soon as the rinsing water
no longer drains properly, the waste
water pump must be cleaned.
WARNING
Risk of injury!
Sharp and pointed objects or frag-
ments of glass may block the waste
water pump and cause injury.
▶ Remove any foreign bodies care-
fully.
1. Disconnect the appliance from the
power supply.
2. Remove the top and bottom bas-
ket.
3. Remove the filter system.
4. Scoop out any water.
Use a sponge if necessary.
5. Prise off the pump cover using a
spoon and grip it by the
crosspiece.
6. Lift the pump cover inwards at an
angle and remove.
a You can now reach the impeller
with your hand.
7. Remove any remnants of food and
foreign bodies in the area of the
impeller.
8. Insert the pump cover
and press
down .
1
2
a The pump cover clicks into posi-
tion.
9. Install the filter system.
10.Insert the top and bottom basket.
Transportation, storage and disposal
Transportation, storage
and disposal
Transportation, storage and disposal
Removing the appliance
1. Disconnect the appliance from the
mains power supply.
2. Turn off the water tap.
3. Detach the drainage connection.
4. Detach the drinking water connec-
tion.
5. Loosen any screws fastening the
appliance to cabinet parts.
6. Remove the base panel if fitted.
7. Pull the appliance out carefully,
along with the hose behind it.
Protect appliance from frost
If there is a risk of frost where the ap-
pliance will be standing, e.g. in a holi-
day home, empty the appliance com-
pletely.
▶ Empty the appliance.
→"Transporting the appliance",
Page61
Customer Service en
61
Transporting the appliance
To avoid damage to the appliance,
empty it before transporting.
Note:Always transport the dish-
washer upright to prevent residual
water getting into the machine's con-
trols and damaging the appliance.
1. Remove tableware from the appli-
ance.
2. Secure loose parts.
3. "Switch on the appliance."
→Page34
4. Select the programme with the
highest temperature.
→"Programmes", Page20
5.
"Start the programme." →Page35
6. To drain the appliance, terminate
the programme after approx.
4minutes.
→"Terminate programme",
Page35
7. "Switch off the appliance."
→Page35
8. Turn off the water tap.
9. To empty the residual water out of
the appliance, detach the supply
hose and let the water drain out.
Disposing of old appliance
Valuable raw materials can be re-
used by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the
appliance, thereby putting their lives
at risk.
▶ With redundant appliances, unplug
the power cord. Then cut through
the cord and damage the lock on
the appliance door beyond repair
so that the appliance door will no
longer close.
1. Unplug the appliance from the
mains.
2. Cut through the power cord.
3. Dispose of the appliance in an en-
vironmentally friendly manner.
Information about current disposal
methods are available from your
specialist dealer or local authority.
This appliance is labelled in ac-
cordance with European Direct-
ive 2012/19/EU concerning
used electrical and electronic
appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the
framework for the return and re-
cycling of used appliances as
applicable throughout the EU.
Customer Service
Customer Service
Customer Service
Function-relevant genuine spare parts
according to the corresponding Eco-
design Order can be obtained from
Customer Service for a period of at
least 10 years from the date on
which your appliance was placed on
the market within the European Eco-
nomic Area.
Note:Under the terms of the manu-
facturer's warranty the use of Cus-
tomer Service is free of charge.
Detailed information on the warranty
period and terms of warranty in your
country is available from our after-
sales service, your retailer or on our
website.
If you contact Customer Service, you
will require the product number (E-
Nr.), the production number (FD) and
the consecutive numbering (Z-Nr.) of
your appliance.
en Technical specifications
62
The contact details for Customer Ser-
vice can be found in the enclosed
Customer Service directory or on our
website.
Product number (E-Nr.), pro-
duction number (FD) and con-
secutive numbering (Z-Nr.)
You can find the product number (E-
Nr.), the production number (FD) and
the consecutive numbering (Z-Nr.) on
the appliance's rating plate.
The rating plate is located inside the
appliance door.
Make a note of your appliance's de-
tails and the Customer Service tele-
phone number to find them again
quickly.
AQUA-STOP guarantee
In addition to warranty claims against
the seller under the purchase agree-
ment and in addition to our manufac-
turer's warranty, we offer compensa-
tion under the following conditions.
¡ If our Aqua-Stop system is defect-
ive and causes water damage, we
will make good the damage for
private users. To ensure protection
from water damage, the appliance
must be connected to the power
supply.
¡ The liability guarantee is valid for
the service life of the appliance.
¡ A claim can only be made under
the guarantee if the appliance has
been correctly installed and con-
nected with Aqua-Stop according
to our instructions; this also in-
cludes correctly fitting the Aqua-
Stop extension (genuine access-
ory). Our guarantee does not cover
defective supply lines or fittings up
to the Aqua-Stop connection on
the tap.
¡ If your appliance is fitted with
Aqua-Stop, you can in principle
leave your appliance unattended
during operation and the tap
turned on afterwards. The tap only
needs to be turned off if you are
away from home for a long period,
e.g. on holiday for several weeks.
Technical specifications
Technical specifications
Technical specifications
Weight Max.: 60kg
Voltage 220 - 240V, 50Hz or
60Hz
Power rating 2000 - 2400W
Fuse 10 - 16A
Water pressure ¡ min. 50kPa
(0.5bar)
¡ max. 1000kPa
(10bar)
Inlet rate Min. 10l/min
Water temperature Cold water.
Hot water max.: 60°C
Capacity 14place settings
You can find more information about
your model online at
https://eprel.ec.europa.eu/
1
. This web
address is linked to the official EU
EPREL product database. Please
then follow the instructions on
searching for the model. The model
identifier is made up of the charac-
ters before the slash in the product
number (E-Nr.) on the rating plate. Al-
ternatively, you can also find the
model identifier in the first line of the
EU energy label.
1
Only applies to countries in the European Economic Area
Declaration of Conformity en
63
Information regarding Free
and Open Source Software
This product includes software com-
ponents that are licensed by the
copyright holders as free or open
source software.
The applicable licence information is
stored on your home appliance. You
can also access the applicable li-
cence information via your
HomeConnect app: "Profile -> Legal
information -> Licence Information".
1
You can download the licence in-
formation on the brand product web-
site. (Please search on the product
website for your appliance model
and additional documents). Alternat-
ively, you can request the relevant in-
formation from oss-
[email protected] or BSH Hausger-
äte GmbH, Carl-Wery-Str. 34, 81739
Munich, Germany.
The source code will be made avail-
able to you on request.
Please send your request to oss-
[email protected] or BSH Hausger-
äte GmbH, Carl-Wery-Str.34, 81739
Munich, Germany.
Subject: „OSSREQUEST“
The cost of performing your request
will be charged to you. This offer is
valid for three years from the date of
purchase or at least as long as we
offer support and spare parts for the
relevant appliance.
Declaration of Conformity
Declaration of Conformity
Declaration of Conformity
BSH Hausgeräte GmbH hereby de-
clares that the appliance with Home
Connect functionality conforms to the
basic requirements and other relev-
ant provisions of Directive 2014/53/
EU.
A detailed RED Declaration of Con-
formity can be found online at
www.bosch-home.com among the
additional documents on the product
page for your appliance.
Hereby, BSH Hausgeräte GmbH de-
clares that the appliance with
HomeConnect functionality is in
compliance with relevant statutory
requirements.
2
A detailed Declaration of Conformity
can be found online at www.bosch-
home.co.uk among the additional
documents on the product page for
your appliance.
2
Only applies to Great Britain
2.4 GHz band (2400–2483.5MHz):
Max. 100mW
5 GHz band (5150–5350MHz +
5470–5725MHz): Max. 100mW
BE BG CZ DK DE EE IE EL ES
FR HR IT CY LI LV LT LU HU
MT NL AT PL PT RO SI SK FI
SE NO CH TR IS UK (NI)
5GHz WLAN (Wi-Fi): For indoor use only.
1
Depending on the appliance specifications
2
Only applies to Great Britain
en Declaration of Conformity
64
AL BA MD ME MK RS UK UA
5GHz WLAN (Wi-Fi): For indoor use only.
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
•Expert tips & tricks for your appliance
•Warranty extension options
•Discounts for accessories & spare-parts
•Digital manual and all appliance data at hand
•Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service direct-
ory.
*9001592365*
9001592365 (020422) 650 V5
en
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
