EN
1
DAILY REFERENCE
GUIDE
Before using the appliance carefully read Safety Instructions.
PRODUCT DESCRIPTION
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.hotpoint.eu/register
You can download the Safety Instructions and the User
Manual, by visiting our website docs.hotpoint.eu and
following the Instructions on the back of this booklet.
APPLIANCE
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Space zone
7. Cutlery basket
8. Lower spray arm
9. Filter Assembly
10. Salt reservoir
11. Detergent and Rinse Aid dispensers
12. Rating plate
13. Control panel
CONTROL PANEL
1
2
3
4
5
7
8
10
9
13
0000 000 00000
Service:
1112
6
1. On-O/Reset button with indicator light
2. Program selection button with indicator light
3. Zone Wash button with indicator light / Key lock
4. Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid rell indicator light
11. Salt rell indicator light
12. Extra Dry button with indicator light / Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
3
1
2
8
13
14
5
4
6
7 11 12
9
10
