PACKAGE CONTENTS
A
B
C
D
E
Anchor x 6
SAFETY INFORMATION
• Your motion light is not a toy. Keep it out of reach from small children.
• You can mount your motion light indoors, but your solar panel must be installed outdoors to receive light from the sun.
• If using a step ladder, you may require a second person to help install the solar motion light.
• Prior to installation, lay out all components and check against the part list section in this manual.
• CAUTION! Never look directly into the solar motion light when illuminated.
CLEANING AND MAINTENANCE
• From time to time, ensure the plug between the solar panel and light is securely connected.
• It is advisable to adjust the angle of the solar panel to optimize the exposure of the sun during the winter months.
• The solar panel should be cleaned with a damp cotton cloth on a regular basis. This will ensure optimal
performance and battery charging. Periodically, utilize the same technique to clean the lenses of the motion lights.
• Never let any abrasive material come into contact with the solar panel.
• To prolong the original appearance, clean the light fixture with a soft, damp cloth. Do not use paints, solvents, or other chemicals on this light
fixture. They could cause a premature deterioration of the finish.
LOCATION: Fixture can be wall mounted.
Some environmental factors may affect the sensor range and could result in a reduction in sensor detection distance.
It is recommended not to mount the fixture near a heat source like an air conditioner, vent, or furnace exhaust, or in a direction facing a light
reflecting object.
Screw x 6
Read all instructions before installation, then store in a safe place for future reference. Failure to do so may
result in faulty assembly and potential injury.
Light Fixture x 1
Solar Panel x 1
Mounting Plate x 1
SKU Number: 343-2418
Solar Powered LED Security Light
Model Number: ES00992G
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 855-232-6423
Monday – Friday 8:00 a.m. – 8:00 p.m. (EST)
1
INSTALLATION AND OPERATION INSTRUCTIONS
INSTALLATION
Gently remove all parts from the package and lay them out on a smooth surface.
IMPORTANT: Ensure your solar panel is placed where it is exposed to optimized sunlight. Be aware of objects such as trees or property overhangs
that may impede the panel’s ability to generate a charge.
Recommended installation height: 6.5 -10 feet above the ground.
At such a height, adjust motion sensor's angle by following illustrations below. The fixture will provide a detection distance of up to 45 feet (Max) at
77 degrees Fahrenheit.
The sensor will be more sensitive to motion across than motion towards it directly.
FEATURES:
Motion sensor: At night, turns light ON automatically when motion is detected and turns light OFF automatically when motion stops.
• Adjustable motion sensor
• Adjustable time and sensitivity settings
• Solar panel with 15 ft wire
Sensor Range: Up to 13.5 m / 45 ft. x 180 degree spread (Varies with various environment).
Lumens output: 1,000 lumens / 5,000K (Max, full charging).
PREPARATION: Tools required for assembly (not included): Phillips screwdriver, safety goggles, power drill and ladder.
1. Use a power drill (not included)
to create the holes on your chosen
mounting surface.
Use 4 of the included anchors and
screws to fasten the solar panel to
the surface.
2. Use a power drill (not included) to
drill the holes on your chosen mounting
surface.
Place the mounting plate over the
holes & use 2 of the included anchors
and screws to fasten the mounting
plate to the surface.
3. Slide light fixture back onto the
mounting plate to secure.
4. Installation completed.
5. Connect the wire from the solar
panel into the socket located under the
light fixture. Your solar motion light will
now begin to charge.
6. SENSOR HEAD ADJUSTMENT:
After installation, aim sensor head
toward desired detection area and
make sure sensor head is positioned
with controls facing toward the
ground.
2
Q: Will decorative or street lights have an effect on the motion sensor's ability to operate?
A: Yes, the sensor of the solar motion light is light-sensitive. For nighttime usage, ensure no other light activates the motion sensor.
OPERATIONAL INSTRUCTIONS
Remark: Prior to using your solar motion light, the solar panel needs to be connected to the light for a period of three days. This initial charge
should be done in the OFF mode.
After the third day, your included battery will be enough power for operation of solar motion light.
1. Adjust the head of light fixture toward to left or right direction to get the desired light direction.
2. Adjust the head of light fixture up and down to get the desired light direction.
3. Mode Button Switch:
Push Mode button once the light will turn on and enter a "warm-up" period for about 6 seconds, then automatically entering into Auto Mode.
At night, turns light ON automatically when motion is detected and turns light OFF automatically in setting time after all motion is
stopped.
Push Mode button once again. The light will enter ON mode. The light will turned on during the day or night.
Push Mode button once again. The light will turned off.
Push Mode button once again. The light will enter Auto mode again. Circle in order to change these modes.
4. Rotary Switch adjustment:
Two different control switches adjust the light’s illumination time and range of motion detection.
TIME: Determines the duration of the light once motion is detected: 30 seconds, 60 seconds or 120 seconds.
• Test: Allows the positioning of the light’s motion sensor to be tested day or night. Once the motion sensor is in the desired position,
attempt to trigger the light by moving in the intended detection zone. If the light illuminates, the motion sensor is positioned correctly.
You are now ready to move the switch to the preferred duration option. The light will now only turn on in darkness at Auto mode.
SENSITIVITY: Controls the distance of the range of motion detection: low, medium or high.
Battery is located in the battery housing behind the light fixture. Push Mode button to OFF Mode prior to opening the battery housing.
Remove the screws to reveal the battery.
When replacing the battery, observe the correct polarity and match the battery specifications with the battery you have removed. Use
rechargeable battery only.
The first time use after new battery change. Push Mode button once the light will turn on and enter a "warm-up" period for about 15
seconds.
FREQUENTLY ASKED QUESTIONS
BATTERY REPLACEMENT
Q: Where should the solar panel be mounted?
A: Mount your solar panel in a position that will enable the most amount of light to be absorbed. In the Northern Hemisphere this is usually south
facing.
Q: Does the solar panel require direct sun to charge?
A: The solar panel can charge the internal battery in direct and indirect light. For best results, try to optimize your solar panel’s sun exposure.
Q: Can additional or extended cable wire for the solar panel be purchased?
A: At this point there are no extensions available for the cable that connects the light to the solar panel. Any additions to the cable will void the
warranty.
Q: What type of battery does my solar motion light require to operate?
A: Your solar motion light requires the use of 1 pc of 3.7V 18650 1,800 mAh Lithium ion rechargeable battery (18650 3.7V 2,000mAh Lithium ion
rechargeable battery also works in this unit).
When replacing the battery, be sure to:
• Use same specification rechargeable battery (1 pc 18650 3.7V 1,800mAh Lithium ion rechargeable battery,
1 pc 18650 3.7V 2,000mAh Lithium ion rechargeable battery also works in this unit).
• Observe the correct polarity (+ and -) when installing the replacement battery.
• IMPORTANT: Dispose of the Lithium ion battery in accordance with local, state and federal regulations.
3
