Ductless Split Air Conditioner
Indoor
AW09EH2VHA
AW12EH2VHA
AW18EH2VHA
Outdoor
1U09EH2VHA
1U12EH2VHA
1U18EH2VHA
Installation Manual
Step 1 - Preparation ...................................................................................................................... 2
Step 2 - Installation of the Indoor Unit ........................................................................................... 3
Step 3 - Installation of the Outdoor Unit ........................................................................................ 4
Step 4 - Interconnecting the Indoor and Outdoor Units ................................................................. 5
Step 5 - Leak Test and Evacuation .................................................................................................. 6
Step 6 - Charging ........................................................................................................................... 7
Section 7 - Explaining Operation to the End User ........................................................................... 8
.................................................................................................. 8
Section 9 - S
0010586954
eacoast Application ................................................................................................... 8
Table of Contents
