en Safety
2
Table of contents
USER MANUAL
1 Safety....................................................................2
2 Preventing material damage ...............................4
3 Environmental protection and saving en-
ergy .......................................................................5
4 Familiarising yourself with your appliance ........6
5 Accessories..........................................................8
6 Before using for the first time ...........................10
7 Basic operation ..................................................10
8 Time-setting options..........................................11
9 Childproof lock...................................................12
10 Rapid heat-up .....................................................13
11 Sabbath mode ....................................................14
12 Basic settings.....................................................14
13 Cleaning and servicing......................................15
14 Cleaning functions.............................................17
15 Rails ....................................................................19
16 Appliance door...................................................19
17 Troubleshooting.................................................24
18 Disposal..............................................................26
19 Customer Service...............................................26
20 How it works.......................................................26
21 INSTALLATION INSTRUCTIONS .......................32
21.1 General installation instructions....................
...32
1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
This appliance is designed only to be built
into kitchen units. Read the special installation
instructions.
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡ To prepare meals and drinks.
¡ In private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of max. 4000m above
sea level.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
Always place accessories in the cooking com-
partment the right way round.
→"Accessories", Page8
WARNING‒Risk of fire!
Combustible objects that are left in the cook-
ing compartment may catch fire.
▶ Never store combustible objects in the
cooking compartment.
▶ If smoke is emitted, the appliance must be
switched off or the plug must be pulled out
and the door must be held closed in order
to stifle any flames.
Loose food remnants, fat and meat juices
may catch fire.
▶ Before using the appliance, remove the
worst of the food residues and remnants
from the cooking compartment, heating ele-
ments and accessories.
Opening the appliance door creates a
draught. Greaseproof paper may come into
Safety en
3
contact with the heating element and catch
fire.
▶ Never place greaseproof paper loosely
over accessories when preheating the ap-
pliance and while cooking.
▶ Always cut greaseproof paper to size and
use a plate or baking tin to hold it down.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
▶ Caution should be exercised here in order
to avoid touching heating elements.
▶ Young children under 8 years of age must
be kept away from the appliance.
Accessories and cookware get very hot.
▶ Always use oven gloves to remove ac-
cessories or cookware from the cooking
compartment.
When the cooking compartment is hot, any al-
coholic vapours inside may catch fire.
▶ Only use small quantities of drinks with a
high alcohol content in food.
▶ Open the appliance door carefully.
WARNING‒Risk of scalding!
The accessible parts of the appliance become
hot during operation.
▶ Never touch these hot parts.
▶ Keep children at a safe distance.
Hot steam may escape when you open the
appliance door. Steam may not be visible, de-
pending on the temperature.
▶ Open the appliance door carefully.
▶ Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
▶ Never pour water into the cooking compart-
ment when the cooking compartment is
hot.
WARNING‒Risk of injury!
Scratched glass in the appliance door may
develop into a crack.
▶ Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the oven door, as they may scratch the
surface.
The appliance and its parts that can be
touched may have sharp edges.
▶ Take care when handling and cleaning
them.
▶ If possible, wear protective gloves.
The hinges on the appliance door move when
the door is opened and closed, which could
trap your fingers.
▶ Keep your hands away from the hinges.
Components inside the appliance door may
have sharp edges.
▶ Wear protective gloves.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶ Repairs to the appliance should only be
carried out by trained specialist staff.
▶ Only use genuine spare parts when repair-
ing the appliance.
▶ If the power cord of this appliance is dam-
aged, it must be replaced by trained spe-
cialist staff.
If the insulation of the power cord is dam-
aged, this is dangerous.
▶ Never let the power cord come into contact
with hot appliance parts or heat sources.
▶ Never let the power cord come into contact
with sharp points or edges.
▶ Never kink, crush or modify the power
cord.
An ingress of moisture can cause an electric
shock.
▶ Do not use steam- or high-pressure clean-
ers to clean the appliance.
If the appliance or the power cord is dam-
aged, this is dangerous.
▶ Never operate a damaged appliance.
▶ Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
▶ If the appliance or the power cord is dam-
aged, immediately unplug the power cord
or switch off the fuse in the fuse box.
▶ Call customer services. →Page26
WARNING‒Danger: Magnetism!
Permanent magnets are used in the control
panel or in the controls. These may affect
electronic implants, e.g. heart pacemakers or
insulin pumps.
▶ Wearers of electronic implants must stay at
least 10 cm away from the control panel.
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶ Keep packaging material away from chil-
dren.
en Preventing material damage
4
▶ Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶ Keep small parts away from children.
▶ Do not let children play with small parts.
1.5 Halogen bulb
WARNING‒Risk of burns!
The bulbs in the cooking compartment get
very hot. There is still a risk of burning for
some time after they have been switched off.
▶ Do not touch the glass cover.
▶ Avoid contact with your skin when cleaning.
WARNING‒Risk of electric shock!
When changing the bulb, the bulb socket con-
tacts are live.
▶ Before replacing the bulb, ensure that the
appliance is switched off in order to pre-
vent a potential electric shock.
▶ Also unplug the appliance from the mains
or switch off the circuit breaker in the fuse
box.
1.6 Cleaning function
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices
may catch fire when the cleaning function is in
progress.
▶ Before starting the cleaning function, al-
ways remove the worst of the food residues
and remnants from the cooking compart-
ment and accessories.
The outside of the appliance gets very hot
when the cleaning function is in progress.
▶ Never hang combustible objects, e.g. tea
towels, on the door handle.
▶ Leave the front of the appliance clear.
▶ Keep children at a safe distance.
If the door seal is damaged, a large amount
of heat is generated around the door.
▶ Do not scrub or remove the seal.
▶ Never operate the appliance if the seal is
damaged or missing.
WARNING‒Risk of serious harm to
health!
The appliance gets very hot when the clean-
ing function is in progress. The non-stick coat-
ing on baking trays and tins is destroyed and
noxious gases are released.
▶ Never clean non-stick baking trays or bak-
ing tins using the cleaning function.
▶ Only clean enamelled accessories at the
same time.
WARNING‒Risk of harm to health!
The cleaning function heats up the cooking
compartment to a very high temperature so
that food left over from roasting, grilling and
baking will burn off. This process releases va-
pours, which can irritate mucous membranes.
▶ Keep the kitchen well ventilated while the
cleaning function is running.
▶ Do not remain in the room for long periods.
▶ Keep children and pets away.
WARNING‒Risk of burns!
The cooking compartment gets very hot when
the cleaning function is in progress.
▶ Never open the appliance door.
▶ Allow the appliance to cool down.
▶ Keep children at a safe distance.
The outside of the appliance gets very hot
when the cleaning function is in progress.
▶ Never touch the appliance door.
▶ Allow the appliance to cool down.
▶ Keep children at a safe distance.
2 Preventing material damage
2.1 General
ATTENTION!
Objects on the cooking compartment floor at over
50°C will cause heat to build up. The baking and
roasting times will no longer be correct and the enamel
will be damaged.
▶ Do not place any accessories, greaseproof paper or
foil of any kind on the cooking compartment floor.
▶ Only place cookware on the cooking compartment
floor if a temperature above 50°C has been set.
When the cooking compartment is hot, any water in-
side it will create steam. The change in temperature
may cause damage.
▶ Never pour water into the cooking compartment
when it is still hot.
▶ Never place cookware containing water on the
cooking compartment floor.
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶ Allow the cooking compartment to dry after use.
▶ Do not keep moist food in the cooking compartment
for a long time with the door closed.
Environmental protection and saving energy en
5
▶ Do not store food in the cooking compartment.
Leaving the appliance to cool down with the door open
will damage the front of neighbouring kitchen units over
time.
▶ Always allow the cooking compartment to cool
down with the door closed after cooking at high
temperatures.
▶ Take care not to trap anything in the appliance
door.
▶ Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced during
operation.
Fruit juice dripping from the baking tray leaves stains
that cannot be removed.
▶ When baking very juicy fruit flans, do not pack too
much on the baking tray.
▶ If possible, use the deeper universal pan.
Using oven cleaner in a hot cooking compartment
damages the enamel.
▶ Never use oven cleaner in the cooking compartment
when it is still warm.
▶ Remove all food remnants from the cooking com-
partment and the appliance door before you next
heat up the appliance.
If the seal is very dirty, the appliance door will no
longer close properly during operation. This may dam-
age the front of adjacent kitchen units.
▶ Keep the seal clean at all times.
▶ Never operate the appliance if the seal is damaged
or missing.
Sitting or placing objects on the appliance door may
damage it.
▶ Do not place or hang objects on the appliance door.
▶ Do not place cookware or accessories on the appli-
ance door.
With certain models, accessories may scratch the door
pane when closing the appliance door.
▶ Always push accessories fully into the cooking com-
partment.
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶
Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Only preheat the appliance if the recipe or the recom-
mended settings tell you to do so.
¡
Not preheating the appliance can reduce the en-
ergy used by up to 20%.
Use dark-coloured, black-coated or enamelled baking
tins.
¡
These types of baking tin absorb the heat particu-
larly well.
Open the appliance door as little as possible during
operation.
¡
This maintains the temperature in the cooking com-
partment and eliminates the need for the appliance
to reheat.
When baking multiple dishes, do so in succession or
in parallel.
¡
The cooking compartment is heated after baking
the first dish. This reduces the baking time for the
second cake.
If the cooking time is relatively long, you can switch
the appliance off 10minutes before the cooking time
ends.
¡
There will be enough residual heat to finish cooking
the dish.
Remove any accessories that are not being used from
the cooking compartment.
¡
Accessories that are not being used do not need to
be heated.
Allow frozen food to defrost before cooking.
¡
This saves the energy that would otherwise be re-
quired to defrost it.
Note:
The appliance requires:
¡ A maximum of 1W when the appliance is in opera-
tion with the display switched on
¡ A maximum of 0.5W when the appliance is in oper-
ation with the display switched off
en Familiarising yourself with your appliance
6
4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions of your appliance and to obtain information about the operat-
ing status.
1
2 23
1
Display
2
Buttons
3
Control element
4.2 Buttons
The buttons are touch-sensitive areas. To select a function, press the corresponding button.
Symbol Name Use
On/off Switch the appliance on or off
Main menu Select operating modes and settings
Time-setting options/
childproof lock
¡ Set the "timer", "cooking time" or "Ready at" time for delayed starts
¡ Activate or deactivate the "childproof lock"
Information ¡ View additional information
¡ View the current temperature
Rapid heat-up ¡ Activate or deactivate the "Rapid heat-up" function
¡ Activate or deactivate the "PowerBoost" function
Start/stop Start or pause the appliance
4.3 Control element
You can configure all the functions on your appliance using the control element. You can change the setting values
that are displayed more brightly.
Press and hold a button to scroll through the setting values quickly. Release the button to stop scrolling quickly.
Button Name Use
Left Navigate to the left on the display
Familiarising yourself with your appliance en
7
Button Name Use
Right Navigate to the right on the display
Up Navigate upwards on the display
Down Navigate downwards on the display
4.4 Display
The display shows the current settings, options or rel-
evant information.
4.5 Main menu
The main menu provides an overview of your appliance's functions.
Press the
button to open the main menu.
Function Name Use
Heating functions Select the required heating function and temperature for your food
Settings Individually adjust the appliance settings
EasyClean Clean less stubborn dirt from the cooking compartment
Pyrolytic self-cleaning Clean the cooking compartment
4.6 Types of heating
This is where you will find an overview of the types of heating. You will find recommendations for using the types of
heating.
For temperatures above 275°C, the appliance reduces the temperature to approx. 275°C after around 40minutes.
Symbol Heating function Temperature Use
CircoTherm hot air 40-200°C Bake or roast on one or more levels.
The fan distributes the heat from the ring-shaped heating ele-
ment in the back wall evenly around the cooking compartment.
Top/bottom heating 50-275°C Traditionally bake or roast on one level. This type of heating is
especially good for cakes with moist toppings.
The heat is emitted evenly from above and below.
Circo-roasting 50-250°C Roast poultry, whole fish or larger pieces of meat.
The grill element and the fan switch on and off alternately. The
fan circulates the hot air around the food.
CircoTherm Intensive 50-275°C Cook pizza or food that requires a lot of heat from below.
The bottom heating element and the ring-shaped heating ele-
ment in the back wall heat the cooking compartment.
Bread-baking setting 180-240°C For baking bread, bread rolls and baked goods that require
high temperatures.
Grill, large area 50-290°C For grilling flat items such as steaks, sausages or bread, and
for cooking au gratin.
The entire area below the grill element becomes hot.
Grill, small area 50-290°C For grilling small amounts of steaks, sausages or bread, and
for cooking au gratin.
The central area below the grill element becomes hot.
Bottom heating 50-250°C For cooking in a bain marie and for baking food for extra time.
The heat is emitted from below.
Low Temperature
Cooking
70-120°C For gentle, low temperature cooking of seared, tender pieces
of meat in cookware without a lid.
The heat is emitted evenly from above and below at a low tem-
perature.
Dough proving 35-55°C For proving dough and culturing yoghurt.
Dough will prove more quickly than at room temperature. The
surface of the dough does not dry out.
en Accessories
8
Symbol Heating function Temperature Use
Top/bottom heating
eco
50-275°C For gently cooking selected types of food.
Heat is emitted from above and below.
This type of heating is most effective between 150 and
250°C.
This type of heating is used to determine the energy consump-
tion in the conventional mode.
CircoTherm eco 40-200°C For gently cooking selected types of food on one level without
preheating.
The fan distributes the heat from the ring-shaped heating ele-
ment in the back wall around the cooking compartment.
This type of heating is most effective between 125 and
200°C.
This type of heating is used to determine the energy consump-
tion in circulating-air mode and the energy efficiency class.
4.7 Cooking compartment
The functions in the cooking compartment make your
appliance easier to use.
Shelf supports
The rails in the cooking compartment enable you to
place accessories at different heights.
→"Accessories", Page8
Your appliance has four shelf positions. The shelf posi-
tions are numbered from bottom to top.
The rails are equipped with pull-out rails on one or
more levels, depending on the appliance type.
You can remove the rails, e.g. for cleaning.
→"Rails", Page19
Lighting
One or more oven lights illuminate the cooking com-
partment.
When you open the appliance door, the light in the
cooking compartment switches on. If the appliance
door remains open for longer than 15minutes, the light
switches off again.
For most operating modes, the lighting is switched on
during operation. The lighting switches off again when
the operation ends.
Cooling fan
The cooling fan switches on and off depending on the
appliance's temperature. The hot air escapes above
the door.
ATTENTION!
Do not cover the ventilation slot above the appliance
door. The appliance overheats.
▶ Ensure that the ventilation slots are unobstructed.
To ensure that the appliance cools down more quickly
after operation, the cooling fan continues to run for a
certain period afterwards.
Appliance door
If you open the appliance door during operation, the
operation stops. When you close the appliance door,
the operation continues automatically.
5 Accessories
Use original accessories. These have been made espe-
cially for your appliance.
Note:Accessories may become deformed if they get
hot. Deformation has no effect on function. As the ac-
cessory cools down, it will regain its original shape.
The accessories supplied may differ depending on the
appliance model.
Accessories en
9
Accessories Use
Wire rack ¡ Cake tins
¡ Ovenproof dishes
¡ Cookware
¡ Meat, e.g. roasting joints or steak
¡ Frozen meals
Universal pan ¡ Moist cakes
¡ Baked items
¡ Bread
¡ Large roasts
¡ Frozen meals
¡ Catch dripping liquids, e.g. fat when
grilling food on the wire rack.
Accessory support When using the cleaning function, you can
accessories at the same time, e.g. the univer-
sal pan.
→"Self-cleaning function", Page17
5.1 Locking function
The locking function prevents the accessories from tilt-
ing when they are pulled out.
You can pull out the accessories approximately halfway
without them tipping. The accessories must be inserted
into the cooking compartment correctly for the tilt pro-
tection to work properly.
5.2 Sliding accessories into the cooking
compartment
Always slide the accessory into the cooking compart-
ment the right way round. This is the only way to en-
sure that accessories can be pulled out approximately
halfway without tipping.
1.
Turn the accessories so that the notch
is at the
rear and is facing downwards.
2.
Insert the accessory between the two guide rods for
a shelf position.
Wire rack Insert the wire rack with the open
side facing the appliance door and
the curved lip facing downwards.
Baking tray
E.g. univer-
sal pan or
baking tray
Slide the tray in with the sloping
edge towards the appliance door.
3.
To place the accessory at shelf positions with pull-
out rails, pull out the pull-out rails.
Wire rack
or baking
tray
Position the accessory so that its
edge is behind the lug on the pull-
out rail.
Note:The pull-out rails lock in place when they are
fully pulled out. Gently push the pull-out rails back
into the cooking compartment.
4.
Push the accessory all the way in, making sure that
it does not touch the appliance door.
Note:Take any accessories that you will not be using
out of the cooking compartment while the appliance is
in operation.
Combining accessories
You can combine the wire rack with the universal pan
to catch any liquid that drips down.
1.
Place the wire rack on the universal pan so that
both spacers
are on the rear edge of the univer-
sal pan.
2.
Insert the universal pan between the two guide rods
for a shelf position. In so doing, the wire rack is on
top of the upper guide rod.
Wire rack
on univer-
sal pan
en Before using for the first time
10
5.3 Other accessories
You can purchase other accessories from our after-
sales service, specialist retailers or online.
You will find a comprehensive range of products for
your appliance in our brochures and online:
www.neff-international.com
Accessories vary from one appliance to another. When
purchasing accessories, always quote the exact
product number (E no.) of your appliance.
You can find out which accessories are available for
your appliance in our online shop or from our after-
sales service.
6 Before using for the first time
Configure the settings for initial start-up. Clean the ap-
pliance and accessories.
6.1 Initial use
When the appliance is connected to the power supply
for the first time or following a lengthy power failure, the
settings that you will need to configure before you can
use it will appear.
Note:You can change these settings at any time by
going to the basic settings.
→"Basic settings", Page14
Setting the language
1.
Connect the appliance to the power supply.
a The first setting will appear after a few seconds.
2.
Use the
button to navigate to the bottom row.
3.
Use the or button to select the language.
4.
Use the button to navigate back to the top row.
5.
Use the button to select the next setting.
Setting the time
1.
Use the
button to navigate to the next row.
2.
Use the or button to select the current time.
3.
Use the button to navigate back to the top row.
4.
Use the button to select the next setting.
Setting the date
1.
Use the
button to navigate to the next row.
2.
Use the or button to select the correct day.
3.
Use the button to navigate back to the top row.
4.
Use the button to select the next setting.
5.
Use the button to navigate to the next row.
6.
Use the or button to select the correct month.
7.
Use the button to navigate back to the top row.
8.
Use the button to select the next setting.
9.
Use the button to navigate to the next row.
10.
Use the or button to select the correct year.
11.
Use the button to navigate back to the top row.
12.
Open and close the appliance door once.
a The appliance will perform a self-test, after which it
will be ready to use.
a Initial configuration is now complete.
6.2 Cleaning the appliance
Before using the appliance to cook food for the first
time, you must clean the cooking compartment and ac-
cessories.
1.
Remove the product information, accessories and
any leftover packaging (e.g. polystyrene pellets)
from the cooking compartment.
2.
Wipe the smooth surfaces in the cooking compart-
ment with a soft, damp cloth.
3.
Press
to switch the appliance on.
→"Switching on the appliance", Page10
4.
Set the required heating function and temperature
for the heat-up process and press
to start.
→"Setting the type of heating and temperature",
Page11
Heating up
Heating function CircoTherm hot air
Temperature Maximum
Cooking time 1hour
5.
Keep the kitchen ventilated while the appliance is
heating.
6.
Press to switch off the appliance after 1hour.
→"Switching off the appliance", Page10
7.
Allow the appliance to cool down.
8.
Clean the smooth surfaces with soapy water and a
dish cloth.
9.
Thoroughly clean any accessories you used with
soapy water and a dish cloth.
7 Basic operation
7.1 Switching on the appliance
▶
Press
to switch the appliance on.
Notes
¡ In the basic settings, you can specify whether the
heating functions or the main menu should appear
when you switch on the appliance.
→"Basic settings", Page14
¡ If you do not perform any actions on the appliance
for an extended period, it will automatically switch it-
self off.
7.2 Switching off the appliance
▶
Press
to switch the appliance off.
Notes
¡ The residual heat indicator will appear on the dis-
play while the cooking compartment is still hot.
→"Residual heat indicator", Page11
¡ The cooling fan will continue to run until the cooking
compartment has cooled down.
→"Cooling fan", Page8
Time-setting options en
11
7.3 Residual heat indicator
After you have switched off the appliance, the residual
heat indicator will appear on the display.
Display Meaning
-H- Residual heat high (over 120°C)
-h- Residual heat low (between 60 and
120°C)
7.4 Setting the type of heating and
temperature
1.
Press
to switch the appliance on.
a The heating functions will then be displayed.
2.
Use the
or button to select the required heating
function.
3.
Use the button to navigate to the next row.
4.
Use the or button to select the required temperat-
ure or setting.
5.
Press to start.
a The cooking time will appear on the display.
a The heat-up indicator bar visualises the rising tem-
perature.
6.
When the food is ready, press
to switch the appli-
ance off.
7.5 Changing the temperature
You can also change the temperature once you have
started the appliance.
1.
Use the
or button to select the temperature
row.
2.
Use the or button to select the required temperat-
ure.
a The temperature will now be changed.
7.6 Changing the type of heating
If you switch to a different heating function, the appli-
ance will reset all the settings.
1.
Press
to pause operation.
2.
Use the or button to select the required heating
function.
3.
Use the button to navigate to the next row.
4.
Use the or button to select the required temperat-
ure.
5.
Press to start.
7.7 Pausing operation
1.
Press
.
2.
Press again to resume operation.
7.8 Cancelling operation
Note:Some functions, e.g. cleaning functions, cannot
be cancelled.
▶
Press and hold the button until the function that is
currently in progress is cancelled.
a Operation will stop and all the settings will be reset.
a The cooling fan will continue to run until the cooking
compartment has cooled down.
7.9 Viewing the current temperature
You can view the current temperature while the appli-
ance is heating up.
▶
Press
.
a The temperature will be displayed for a few
seconds.
7.10 Displaying information
Requirement:The button must be lit.
▶
Press
.
a The information will be displayed for a few seconds.
8 Time-setting options
Your appliance has different time-setting options, with
which you can control its operation.
8.1 Overview of the time-setting options
When you are setting a time, the time values will in-
crease by greater increments as you scroll through the
higher values. The cooking time, for example, can be
set in 1-minute increments up to 1 hour, and then in 5-
minute increments thereafter.
Time-setting
option
Use
Timer When you set a time on the timer,
the timer will run independently of
the appliance and will not intervene
in its operation. The timer does not
affect the appliance.
Time-setting
option
Use
Cooking
time
Once the cooking time has elapsed,
the appliance automatically stops
heating.
Ready at Along with the cooking time (dura-
tion), you can set the time at which
you want cooking to end. The appli-
ance will start up automatically so
that it finishes cooking at the re-
quired time.
8.2 Timer
You can set the timer regardless of whether the appli-
ance is on or off.
Setting the timer
1.
Press
.
2.
Once the appliance is switched on, use the
button to select "Timer" .
en Childproof lock
12
3.
Use the or button to select the timer duration.
4.
Press to start the timer.
a
will appear on the display. The timer duration will
then count down.
a Once the timer duration has elapsed, an audible sig-
nal will sound.
5.
Press any button to end the audible signal.
Changing the timer
1.
Press
.
2.
Use the or button to change the timer duration.
a The setting will then be applied.
Cancelling the timer
1.
Press
.
2.
Use the button to set a timer duration of "00:00".
a This cancels the current timer duration.
8.3 Cooking time
Once the set cooking time has elapsed, the appliance
switches off automatically. You can only use the cook-
ing time in conjunction with a heating function.
Setting the cooking time
1.
Set a heating function and a temperature.
2.
Press
.
3.
Select the default value.
Button Default value
10minutes
30minutes
4.
Use the or button to select the required cooking
time.
5.
Once the cooking time has been set, press to
start.
a The cooking time will appear on the display. The
cooking time will count down.
a Once the cooking time has elapsed, an audible sig-
nal will sound.
6.
Press any button to end the audible signal.
Changing the cooking time
1.
Press
.
2.
Use the or button to change the cooking time.
a The setting will then be applied.
Cancelling the cooking time
1.
Press
.
2.
Use the button to set a cooking time of "00:00".
a This cancels the current cooking time.
3.
To continue without setting a cooking time, press
.
8.4 Delayed start/"Ready at" time
With this function, the appliance automatically switches
itself on, and then switches itself off at the preselected
end time. To enable it to do this, you set the cooking
time (duration) and specify when you want your food to
be ready. You can only use the delayed start function
in conjunction with a heating function.
Setting the Ready at time for delayed starts
Notes
¡ Do not leave food that spoils easily in the cooking
compartment for too long.
¡ You cannot use the delayed start function with every
heating function.
1.
Place the food into the cooking compartment and
close the appliance door.
2.
Set a heating function and a temperature.
3.
Press
.
4.
Use the or button to select the required cooking
time.
5.
Use the button to navigate to "Ready at" .
a The time at which your food will be ready will ap-
pear on the display.
6.
Use the
button to select the required end time.
7.
Press to confirm the delayed start.
a The appliance will start at the appropriate time.
a Once the cooking time has elapsed, an audible sig-
nal will sound.
8.
Press any button to end the audible signal.
Changing the Ready at time for delayed starts
1.
Press
.
2.
Use the button to select "Ready at" .
3.
Use the or button to change the end time.
a The setting will then be applied.
Cancelling the Ready at time for delayed starts
1.
Press
.
2.
Use the button to reset the end time.
a The end time corresponds to the current time plus
the set cooking time.
a The appliance will start heating using the set cook-
ing time.
9 Childproof lock
You can secure your appliance to prevent children
from accidentally switching it on or changing the set-
tings.
9.1 Locks
Your appliance has two different locks:
Lock Activate/deactivate
Automatic childproof lock Via the Settings menu
One-time childproof lock Using the button
9.2 Activating the automatic childproof lock
The automatic childproof lock disables the control
panel to prevent children from accidentally switching
on the appliance. To switch on the appliance, interrupt
the automatic childproof lock. Once the appliance has
finished cooking, it automatically disables the control
panel.
Note:When you activate the automatic childproof lock,
the appliance will immediately disable the control
panel. The
and buttons will not be disabled.
Requirement:The appliance must be switched on.
Rapid heat-up en
13
1.
Press .
2.
Use the or button to select "Settings" .
3.
Use the button to navigate to the next row.
4.
Use the or button to select "Automatic childproof
lock".
5.
Use the button to select the required settings.
6.
Use the button to set the lock to "Activated".
7.
Press .
8.
Use the button to save your settings.
a When you switch off the appliance,
will appear
on the display.
9.3 Interrupting the automatic childproof
lock
1.
Press and hold the button until "Childproof lock
deactivated" appears on the display.
2.
Press to switch the appliance on and then start it
up.
9.4 Deactivating the automatic childproof
lock
1.
Press and hold the
button until "Childproof lock
deactivated" appears on the display.
2.
Press to switch the appliance on.
3.
Press .
4.
Use the or button to select "Settings" .
5.
Use the button to navigate to the next row.
6.
Use the or button to select "Automatic childproof
lock".
7.
Use the button to select the required settings.
8.
Use the button to set the lock to "Deactivated".
9.
Press .
10.
Use the button to save your settings.
9.5 Activating the one-time childproof lock
The one-time childproof lock disables the control panel
to prevent children from accidentally switching on the
appliance. To switch on the appliance, deactivate the
one-time childproof lock. After you have switched off
the appliance, the control panel will no longer be dis-
abled.
Note:When you activate the automatic childproof lock,
the appliance will immediately disable the control
panel. The and buttons will not be disabled.
▶
Press and hold the button until "Childproof lock
activated" appears on the display.
9.6 Deactivating the one-time childproof
lock
▶
Press and hold the
button until "Childproof lock
deactivated" appears on the display.
10 Rapid heat-up
You can use the "Rapid heat-up" and "PowerBoost" functions to reduce the heat-up time. Whether the appliance is
preheated with the "Rapid heat-up" function or the "PowerBoost" function depends on the heating function that has
been set.
10.1 Rapid heat-up and PowerBoost
Function Heating function Food in the cooking compartment
Rapid heat-up Top/bottom heating After preheating
PowerBoost ¡ CircoTherm hot air
¡ Bread-baking setting
Before heating up
Only cook on one level
10.2 Activating the "Rapid heat-up" function
1.
Set Top/bottom heating
and a temperature of at
least 100°C.
2.
Press to start.
a The
button will be lit.
3.
Use the button to activate the "Rapid heat-up"
function.
a
will appear on the display.
a Once the set temperature has been reached, the
"Rapid heat-up" function will switch itself off auto-
matically and an audible signal will sound.
will go
out on the display.
4.
Place the food in the cooking compartment.
10.3 Deactivating the "Rapid heat-up"
function
▶
Use the button to deactivate the "Rapid heat-up"
function early.
10.4 Activating the "PowerBoost" function
1.
Place the food on a single level in the cooking com-
partment.
2.
Set CircoTherm hot air or the Bread-baking
setting and a temperature of at least 100°C.
3.
Press to start.
a The
button will be lit.
4.
Press the button to activate the "PowerBoost"
function.
a
will appear on the display.
a Once the set temperature has been reached, the
"PowerBoost" function will switch itself off automatic-
ally and an audible signal will sound.
will go out
on the display.
en Sabbath mode
14
10.5 Deactivating the "PowerBoost"
function
▶
Use the
button to deactivate the "PowerBoost"
function early.
11 Sabbath mode
You can set a cooking time of up to 74hours using
Sabbath mode. You can use top/bottom heating to
keep food warm between 85°C and 140°C during
this time without having to switch the appliance on or
off.
11.1 Starting Sabbath mode
Notes
¡ If you open the appliance door during operation, the
appliance stops heating. When you close the appli-
ance door, the appliance continues to heat again.
¡ Once you have started the operation, you cannot
change any settings or pause operation.
Requirement:Sabbath mode must be activated in "Fa-
vourites" in the basic settings.
→"Basic settings", Page14
1.
Press to switch the appliance on.
2.
Use or to select "Sabbath mode".
3.
Use to navigate to the next row.
4.
Use or to select the temperature.
5.
Use to navigate to the next row.
6.
Use or to select the cooking time.
7.
Press to start Sabbath mode.
a The cooking time appears on the display. The cook-
ing time counts down.
8.
Once the cooking time has elapsed, an audible sig-
nal sounds. A note appears on the display confirm-
ing that the operation has finished. The appliance
stops heating up and responds again as usual out-
side of Sabbath mode.
‒ Press
to switch the appliance off.
The appliance automatically switches off after ap-
prox.10to 20 minutes.
11.2 Cancelling Sabbath mode
▶
Press
to cancel Sabbath mode.
12 Basic settings
You can configure the appliance to meet your needs.
12.1 Overview of the basic settings
Here you can find an overview of the basic settings
and factory settings. The basic settings depend on the
features of your appliance.
Basic setting Selection
Language See selection on the appliance
Time 00:00 - 23:59
Date Day, month and year
Favourites
→"Changing your
favourites",
Page15
Set the heating functions that
you want to appear in the heat-
ing functions menu
Audible signal dura-
tion
¡ Short
¡ Medium
¡ Long
Button tone ¡ Off (except for )
¡ On
Display brightness 5 settings
Clock display ¡ Digital
¡ Off
Lighting ¡ On during operation
¡ Off during operation
Childproof lock ¡ Button lock only
¡ Door lock and button lock
Automatic childproof
lock
¡ Deactivated
¡ Activated
1
Depending on the appliance specifications
Basic setting Selection
Operation after
switch-on
¡ Main menu
¡ Types of heating
Night-time dimming ¡ Switched off
¡ On (display dimmed
between 10 p.m. and 5.59
a.m.)
Brand logo ¡ Indicators/symbols
¡ Do not display
Fan run-on time ¡ Recommended
¡ Minimum
Pull-out rail system
1
¡ No (rack or single set of
pull-out rails fitted)
¡ Yes (two or three sets of
pull-out rails retrofitted)
Factory settings Load
1
Depending on the appliance specifications
12.2 Changing basic settings
1.
Press
to switch the appliance on.
2.
Press .
3.
Use the or button to select "Settings" .
4.
Use the button to navigate to the next row.
5.
Use the or button to select a setting.
6.
Use the button to navigate to the next row.
7.
Use the or button to change the setting.
8.
Press .
9.
To save your settings, use the
button to select
"Save".
‒ To discard your settings, use the button to se-
lect "Discard".
Cleaning and servicing en
15
12.3 Changing your favourites
In Favourites, you can set the heating functions that
you want to appear in the heating functions menu.
Note:
Some heating functions cannot be deactivated:
¡ CircoTherm hot air
¡ Circo-roasting
¡ Full-surface grill
1.
Press
to switch the appliance on.
2.
Press .
3.
Use the or button to select "Settings" .
4.
Use the button to navigate to the next row.
5.
Use the or button to select "Favourites".
6.
Use the button to navigate to the next row.
7.
Use the or button to select the required heating
function.
8.
Use the button to navigate to the next row.
9.
Use the or button to select a setting.
Setting Display in the heating func-
tions menu?
Activated Yes
Deactivated No
10.
Press .
11.
To save your settings, use the button to select
"Save".
‒ To discard your settings, use the button to se-
lect "Discard".
13 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
13.1 Cleaning products
In order to avoid damaging the various oven surfaces
on the appliance, do not use unsuitable cleaning
products.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶ Do not use steam- or high-pressure cleaners to
clean the appliance.
ATTENTION!
Unsuitable cleaning products may damage the sur-
faces of the appliance.
▶ Do not use harsh or abrasive cleaning products.
▶ Do not use cleaning products with a high alcohol
content.
▶ Do not use hard scouring pads or cleaning
sponges.
▶ Do not use any special cleaners for cleaning the ap-
pliance while it is hot.
Using oven cleaner in a hot cooking compartment
damages the enamel.
▶ Never use oven cleaner in the cooking compartment
when it is still warm.
▶ Remove all food remnants from the cooking com-
partment and the appliance door before you next
heat up the appliance.
New sponge cloths contain residues from production.
▶ Wash new sponge cloths thoroughly before use.
Suitable cleaning agents
Only use cleaning agents that are suitable for the differ-
ent surfaces on your appliance.
Follow the instructions on cleaning the appliance.
→"Cleaning the appliance", Page16
Appliance front
Surface Suitable cleaning agents Information
Stainless steel ¡ Hot soapy water
¡ Special stainless steel
cleaning products
suitable for hot sur-
faces
To prevent corrosion, remove any limescale, grease, starch or albu-
min (e.g. egg white) stains on stainless steel fronts immediately.
Apply a thin layer of the stainless steel cleaning product with a soft
cloth.
Plastic or painted
surfaces
E.g. control panel
¡ Hot soapy water Do not use glass cleaner or a glass scraper.
To avoid permanent stains, remove any descaling agent that gets
onto the surface immediately.
Appliance door
Area Suitable cleaning agents Information
Door panels ¡ Hot soapy water Do not use a glass scraper or a stainless steel wool.
Tip:Remove the door panels in order to clean them thoroughly.
→"Appliance door", Page19
en Cleaning and servicing
16
Area Suitable cleaning agents Information
Door cover ¡ Made of stainless
steel:
Stainless steel cleaner
¡ Made of plastic:
Hot soapy water
Do not use glass cleaner or a glass scraper.
Do not use stainless steel care products.
Tip:Remove the door cover for thorough cleaning.
→"Appliance door", Page19
Stainless steel in-
terior door frame
Stainless steel cleaner Discolouration can be removed using stainless steel cleaner.
Do not use stainless steel care products.
Door handle ¡ Hot soapy water To avoid permanent stains, remove any descaling agent that gets
onto the surface immediately.
Door seal ¡ Hot soapy water Do not remove or scrub.
Cooking compartment
Area Suitable cleaning agents Information
Enamel surfaces ¡ Hot soapy water
¡ Vinegar water
¡ Oven cleaner
Soak any heavily soiled areas and use a brush or steel wool.
Leave the appliance door open to dry the cooking compartment
after cleaning it.
Notes
¡ It is best to use the cleaning function.
→"Self-cleaning function", Page17
¡ Enamel burns at very high temperatures, causing minor discol-
ouration. The functionality of your appliance is not affected by
this.
¡ The edges of thin trays cannot be completely enamelled and may
be rough. This does not impair corrosion protection.
¡ Food residues will leave a white coating on the enamel surfaces.
The coating does not pose a health risk. The functionality of your
appliance is not affected by this. You can remove residues with
lemon juice.
Glass cover for
the oven light
¡ Hot soapy water Use oven cleaner to remove very heavy soiling.
Rails ¡ Hot soapy water Soak any heavily soiled areas and use a brush or steel wool.
Note:To clean thoroughly, detach the rails.
→"Rails", Page19
Pull-out system ¡ Hot soapy water Use a brush to remove very heavy soiling.
Clean the pull-out rails while they are pushed in so that you do not
remove the lubricant.
Do not clean in the dishwasher.
Note:To clean thoroughly, detach the pull-out system.
→"Rails", Page19
Accessories ¡ Hot soapy water
¡ Oven cleaner
Soak any heavily soiled areas and use a brush or steel wool.
Enamelled accessories are dishwasher-safe.
13.2 Cleaning the appliance
In order to avoid damaging the appliance, you must
clean your appliance only as specified, and with suit-
able cleaning products.
WARNING‒Risk of burns!
The appliance and its parts that can be touched be-
come hot during use.
▶ Caution should be exercised here in order to avoid
touching heating elements.
▶ Young children under 8 years of age must be kept
away from the appliance.
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices may catch
fire.
▶ Before using the appliance, remove the worst of the
food residues and remnants from the cooking com-
partment, heating elements and accessories.
Requirement:Read the information on cleaning
products.
→"Cleaning products", Page15
1.
Clean the appliance using hot soapy water and a
dish cloth.
‒ For some surfaces, you can use alternative
cleaning agents.
→"Suitable cleaning agents", Page15
2.
Dry with a soft cloth.
Cleaning functions en
17
14 Cleaning functions
You can use the cleaning functions to clean the appli-
ance.
14.1 Self-cleaning function
The "Self-cleaning" function cleans the cooking com-
partment virtually automatically.
Use this cleaning function to clean the cooking com-
partment every 2 to 3 months. You can use the clean-
ing function more often, if required. The cleaning func-
tion requires approx. 2.5 - 4.7 kilowatt hours.
Preparing the appliance for the cleaning
function
To achieve a good cleaning result and prevent dam-
age, prepare the appliance carefully.
WARNING‒Risk of fire!
Combustible objects that are left in the cooking com-
partment may catch fire.
▶ Never store combustible objects in the cooking
compartment.
▶ If smoke is emitted, the appliance must be switched
off or the plug must be pulled out and the door
must be held closed in order to stifle any flames.
Loose food remnants, fat and meat juices may catch
fire when the cleaning function is in progress.
▶ Before starting the cleaning function, always remove
the worst of the food residues and remnants from
the cooking compartment and accessories.
The outside of the appliance gets very hot when the
cleaning function is in progress.
▶ Never hang combustible objects, e.g. tea towels, on
the door handle.
▶ Leave the front of the appliance clear.
▶ Keep children at a safe distance.
If the door seal is damaged, a large amount of heat is
generated around the door.
▶ Do not scrub or remove the seal.
▶ Never operate the appliance if the seal is damaged
or missing.
1.
Remove accessories and cookware from the cook-
ing compartment.
2.
Detach the shelf supports and remove them from
the cooking compartment.
→"Rails", Page19
3.
Remove coarse dirt from the cooking compartment.
4.
Use a detergent solution and a soft cloth to clean
the surfaces at the edges of the cooking compart-
ment around the door seal.
Do not remove or scrub the door seal.
Use oven cleaner to remove stubborn dirt from the
inner door pane.
5.
Remove any objects from the cooking compartment.
The cooking compartment must be empty.
Using accessory supports
With the accessory supports, you can clean an access-
ory at the same time when cleaning using the cleaning
function.
1.
Attach the accessory supports in the same way as
the rails.
→"Rails", Page19
Note:
The vertical bar
must be to the front of the ac-
cessory supports.
2.
Remove coarse dirt from the accessory.
3.
Place the accessory on the accessory supports.
Note:Only clean accessories that were included
with the appliance and that are enamelled, e.g. the
universal pan or the baking tray. Wire racks are not
suitable for the cleaning function and will become
discoloured.
Configuring the Self-cleaning function
WARNING‒Risk of harm to health!
The cleaning function heats up the cooking compart-
ment to a very high temperature so that food left over
from roasting, grilling and baking will burn off. This pro-
cess releases vapours, which can irritate mucous mem-
branes.
▶ Keep the kitchen well ventilated while the cleaning
function is running.
▶ Do not remain in the room for long periods.
▶ Keep children and pets away.
WARNING‒Risk of burns!
The cooking compartment gets very hot when the
cleaning function is in progress.
▶ Never open the appliance door.
▶ Allow the appliance to cool down.
▶ Keep children at a safe distance.
The outside of the appliance gets very hot when the
cleaning function is in progress.
▶ Never touch the appliance door.
▶ Allow the appliance to cool down.
▶ Keep children at a safe distance.
Note:The oven light will not be lit while the cleaning
function is running.
Requirement:→"Preparing the appliance for the
cleaning function", Page17.
1.
Press
to switch the appliance on.
2.
Press .
3.
Use the or button to set "Self-cleaning" .
4.
Use the button to navigate to the next row.
5.
Use the or button to select the cleaning setting.
en Cleaning functions
18
Cleaning set-
ting
Cleaning
level
Duration in hours
1 Low Approx. 1:15
2 Medium Approx. 1:30
3 High Approx. 2:00
Select a higher cleaning setting if the cooking com-
partment is particularly dirty or has not been
cleaned for a while.
You cannot change the duration of the cleaning
function.
Once the cleaning function is in progress, you can-
not change the cleaning setting.
a The duration of the cleaning setting will appear on
the display.
6.
Note:Keep the kitchen ventilated while the cleaning
function is running.
Press
to start the cleaning function.
a The cleaning function will start. The duration will
count down on the display.
a For your safety, the appliance door locks the cook-
ing compartment.
will appear on the display.
a Once the cleaning function has run through to the
end, an audible signal will sound.
7.
Press
to switch the appliance off.
The appliance door will remain locked until the ap-
pliance has cooled down sufficiently and has
gone out.
8.
After using the cleaning function, prepare the appli-
ance so that it is ready to use again.
→"Preparing the appliance for use following the
cleaning function", Page18
Preparing the appliance for use following the
cleaning function
1.
Allow the appliance to cool down.
2.
Wipe off any ash that has been left behind in the
cooking compartment and around the appliance
door with a damp cloth.
3.
Remove white residues with lemon juice.
Note:White residues on the enamel surfaces may
be caused by heavy soiling. These food residues
are harmless. The deposits do not compromise the
functionality of the appliance.
4.
Attach the shelf supports.
→"Rails", Page19
14.2 EasyClean cleaning aid
You can use the "EasyClean" cleaning aid to clean light
soiling from the cooking compartment between full
cleans. The "EasyClean" cleaning aid soaks dirt by
evaporating soapy water. It is then easier to remove the
dirt.
Setting the EasyClean cleaning aid
WARNING‒Risk of scalding!
If there is water in the cooking compartment when it is
hot, this may create hot steam.
▶ Never pour water into the cooking compartment
when the cooking compartment is hot.
Requirements
¡ You can only start the cleaning aid once the cooking
compartment is cold (room temperature) and the ap-
pliance door is closed.
¡ Do not open the appliance door while the appliance
is in operation, as this will abort the cleaning aid.
¡ To remove particularly stubborn dirt, leave the soapy
water to work for a while before starting the cleaning
aid.
¡ To remove particularly stubborn dirt, rub washing-up
liquid onto dirty areas on the smooth surfaces before
starting the cleaning aid.
1.
Remove any accessories from the cooking compart-
ment.
2.
ATTENTION!
Distilled water in the cooking compartment leads to
corrosion.
▶ Do not use distilled water.
Mix 0.4litres water with a drop of washing-up liquid
and pour into the centre of the cooking compart-
ment floor.
3.
Press
to switch the appliance on.
4.
Press .
5.
Use the or button to select "EasyClean" .
6.
Use the button to navigate to the next row.
7.
Press to start the cleaning aid.
a The cleaning aid will start. The duration will count
down on the display.
a Once the cleaning aid has run through to the end,
an audible signal will sound.
8.
Press any button to end the audible signal.
9.
After using the cleaning aid, finish cleaning the
cooking compartment.
→"Wiping down the cooking compartment",
Page18
Wiping down the cooking compartment
ATTENTION!
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶ After using the cleaning aid, wipe the cooking com-
partment clean and allow it to dry fully.
Requirement:The cooking compartment must have
cooled down.
1.
Open the appliance door and remove the remaining
water with an absorbent sponge cloth.
2.
Clean the smooth surfaces in the cooking compart-
ment with a dish cloth or a soft brush. Remove stub-
born food remnants using a stainless steel scouring
pad.
3.
Remove limescale with a cloth soaked in vinegar.
Then wipe with clean water and rub dry with a soft
cloth (including under the door seal).
4.
If there is any stubborn dirt that you are unable to
remove, run the cleaning aid again once the cook-
ing compartment has cooled down.
5.
Leave the cooking compartment to dry with the ap-
pliance door open for approx. 1hour.
Rails en
19
15 Rails
To thoroughly clean the rails and the cooking compart-
ment, or to replace the rails, you can remove the rails.
15.1 Detaching the rails
WARNING‒Risk of burns!
The shelf supports get very hot
▶ Never touch the shelf supports when hot.
▶ Always allow the appliance to cool down.
▶ Keep children at a safe distance.
1.
Lift the rail forwards slightly
and detach it .
2.
Pull the whole rail to the front and remove it.
3.
Clean the rail.
→"Cleaning products", Page15
15.2 Attaching the rails
Notes
¡ The rails only fit on the right or left.
¡ For both pull-out rails, ensure that you can pull them
forwards and out.
1.
First, push the rail into the middle of the rear
socket
until the rail rests against the cooking
compartment wall, and then push this back .
2.
Push the rail into the front socket until the rail
also rests against the cooking compartment wall,
and then press this downwards .
16 Appliance door
To clean the appliance door thoroughly, you can disas-
semble the appliance door.
WARNING‒Risk of injury!
If the hinges are not secured due to an incomplete
lock, they can snap shut with great force.
▶ To detach or attach the appliance door, always turn
the two locks as far as they will go.
▶ If the hinge snaps closed when detaching or attach-
ing the appliance door, do not reach into the hinge
– call the after-sales service.
16.1 Detaching the appliance door
Requirements
¡ Have a torch ready.
¡ Have a small slotted screwdriver ready.
¡ Have a coin ready.
1.
To make it easier to see the door lock, shine the
torch into the gap beside the appliance door.
en Appliance door
20
2.
Hold the screwdriver horizontally and use it to
push the door lock (black component) on each side
of the door upwards as far as it will go .
Door lock open
Door lock closed
3.
Open the appliance door approx. 45° wide.
4.
Insert the coin in the gap in the lock and rotate as
far as it will go .
‒ Turn the lock on the left-hand side in a clockwise
direction.
‒ Turn the lock on the right-hand side in an anti-
clockwise direction.
Left-hand lock secured
The arrows point to
each other
Left-hand lock released
a The lock audibly engages.
5.
ATTENTION!
Opening and closing the appliance door when it is
in the lock position damages the door hinges.
▶ Never force the appliance door open or closed.
▶ If the door hinge has been damaged, call the
after-sales service.
Move the appliance door up and down until you
hear a quiet click. You can still only move the appli-
ance door slightly.
a The appliance door is in the lock position.
Appliance door en
21
6.
WARNING‒Risk of injury!
The appliance door has a weight of 7–10 kg and
may fall if it is not handled carefully.
▶ Handle the appliance door carefully.
The door handle is not suitable for carrying the ap-
pliance door. The door handle may break off.
▶ Never carry the appliance door by the door
handle.
▶ Grab hold of the appliance door with both hands
on the left and right to carry it.
Take hold of the appliance door with both hands,
one on the left and one on the right, and rotate the
door handle upwards until you are able to pull up
the appliance door and remove it .
7.
Set the appliance door down on a flat, soft, clean
surface.
16.2 Attaching the appliance door
1.
Tip:Ensure that the appliance door is not wedged
at an angle and that it is properly fitted in place.
Attach the appliance door via the left- and right-hand
guide rollers simultaneously
.
2.
Rotate the door handle upwards slightly .
a The appliance door slides the short distance re-
maining to the bottom .
3.
Use a coin to release both locks on the appliance
door. Insert the coin in the gap in the lock and ro-
tate as far as it will go .
‒ Turn the lock on the left-hand side in an anti-
clockwise direction.
‒ Turn the lock on the right-hand side in a clock-
wise direction.
4.
Open the appliance door slightly until you hear a
quiet click, and then close the appliance door.
5.
WARNING‒Risk of injury!
If the door locks are unsecured, the appliance door
may become detached.
▶ After attaching the appliance door, close the left-
and right-hand door locks.
Hold the screwdriver horizontally
and use it to
push the door lock (black component) on each side
of the door downwards as far as it will go .
a The door lock is closed.
en Appliance door
22
16.3 Removing the door panes
To facilitate cleaning, you can remove the door pane.
WARNING‒Risk of injury!
Components inside the appliance door may have sharp
edges.
▶ Wear protective gloves.
Requirement:The appliance door is detached.
1.
Lay the appliance door with the front side facing
down on a flat surface that is soft and clean.
2.
Undo and remove the left- and right-hand screws on
the appliance door.
3.
Carefully lift the inner pane upwards at an angle
and remove the holder .
4.
Carefully lift the inner pane upwards at an angle and
remove it in the direction of the arrow .
5.
Push down on the intermediate pane lightly around
, and carefully lift the retainer until you are able
to pull it out.
6.
Lift the first and second intermediate panes from be-
low and remove them in the direction of the arrow
.
7.
Remove the spacers and seals for cleaning, if
required.
8.
WARNING‒Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
▶ Do not use any harsh or abrasive cleaners or
sharp metal scrapers to clean the glass on the
oven door, as they may scratch the surface.
Clean the door panes on both sides with glass
cleaner and a soft cloth.
9.
Dry the door panes and refit them.
16.4 Fitting the door panes
WARNING‒Risk of injury!
If a door pane or appliance door has not been installed
correctly, this is dangerous.
▶ Make sure that all of the door panes and the appli-
ance door have been correctly fitted before you
switch the appliance back on again.
Appliance door en
23
1.
Tip:When fitting the door panes, make sure that
they are in the original order.
Insert the intermediate pane so that the
arrow on
the right-hand side is pointing upwards.
2.
Check the fit of the four spacers and two seals.
‒ Place the spacers on the centre of the lines .
‒ Secure the seals at the corners
.
3.
Insert the intermediate pane with spacers and seals
in the direction of the arrow .
The arrow on the intermediate pane must line up
with the arrow on the frame .
4.
Insert the second intermediate pane without the
spacers and seals, and slide it in the direction of the
arrow until it is inserted in the sheet metal frame .
The arrow on the intermediate pane must line up
with the arrow on the frame .
5.
Push down lightly on the first intermediate pane
around , slide the retainer in at an angle and
push down until it clicks into place.
a The retainer has been inserted.
6.
Place the inner pane onto the appliance door so
that the number is legible at the bottom right. In-
sert the inner pane into the fixing rail at an angle
towards the back.
7.
Carefully lift the inner pane upwards at an angle and
attach the holder .
en Troubleshooting
24
8.
Insert the inner pane with the holder into the
opening.
9.
Screw both screws back in on the left and right of
the appliance door.
17 Troubleshooting
You can rectify minor faults on your appliance yourself.
Read the troubleshooting information before contacting
after-sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
▶ Repairs to the appliance should only be carried out
by trained specialist staff.
▶ If the appliance is defective, call Customer Service.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶ Repairs to the appliance should only be carried out
by trained specialist staff.
▶ Only use genuine spare parts when repairing the
appliance.
▶ If the power cord of this appliance is damaged, it
must be replaced by trained specialist staff.
17.1 Malfunctions
Fault Cause and troubleshooting
The appliance is not
working.
The circuit breaker is faulty.
▶
Check the circuit breaker in the fuse box.
There has been a power cut.
▶
Check whether the lighting in your kitchen or other appliances are working.
"Language English"
appears on the dis-
play.
There has been a power cut.
▶
Configure the initial configuration settings.
→"Initial use", Page10
"-H-" or "-h-" appears
on the display.
Cooking compartment too hot for operating mode.
1.
Wait until the appliance has cooled down.
2.
Start the operating mode again.
The appliance cannot
be switched on;
appears on the dis-
play.
Automatic childproof lock or childproof lock is activated
▶
Press and hold the
button until "Childproof lock deactivated" appears on the display.
Appliance will not
start or cuts out dur-
ing operation.
Different causes are possible.
▶
Check any notifications that appear on the display.
→"Displaying information", Page11
Malfunction
▶
Call the after-sales service.
→"Customer Service", Page26
The appliance is not
heating;
appears
on the display.
Demo mode is activated in the basic settings.
1.
Briefly disconnect the appliance from the power supply by switching the circuit breaker in
the fuse box off and then on again.
2.
Deactivate Demo mode within the next 3 minutes in the
→"Basic settings", Page14.
There has been a power cut.
▶
Open and close the appliance door once after a power failure.
a The appliance will perform a self-test, after which it will be ready to use.
Troubleshooting en
25
Fault Cause and troubleshooting
Time not displayed
when appliance
switched off.
Basic setting has been changed.
▶
Change the basic setting for the clock display.
→"Basic settings", Page14
Appliance door can-
not be opened.
The cleaning function locks the appliance door; is lit on the display.
▶
Allow the appliance to cool down until
goes out on the display.
→"Self-cleaning function", Page17
The childproof lock locks the appliance door.
▶
Use the
button to deactivate the childproof lock.
→"Childproof lock", Page12
You can switch off the lock in the basic settings.
→"Basic settings", Page14
The interior lighting
does not work.
The halogen lamp is defective.
▶
Change the oven light bulb.
→"Replacing the oven light bulb", Page25
Maximum operating
time reached.
To prevent the appliance from continuing to run when it is no longer needed, it automatically
stops heating after a few hours if the settings are not changed during this time. A notifica-
tion appears on the display.
The point at which the maximum operating time is reached is determined by the corres-
ponding settings for an operating mode.
1.
Press any button to continue operation.
2.
If you do not need to use the appliance, press
to switch it off.
Tip:To prevent the appliance from switching off when you do not want it to, set a cooking
time.
→"Setting the cooking time", Page12
A message with "D"
or "E" appears in the
display, e.g. D0111
or E0111.
The electronics have detected a fault.
1.
Switch the appliance off and on again.
a If the fault was a one-off, the message disappears.
2.
If the message appears again, call the after-sales service. Please specify the exact error
message when calling.
→"Customer Service", Page26
The cooking result is
not satisfactory.
Settings were unsuitable.
Setting values, e.g. temperature or cooking time, depend on the recipe, quantity and food.
▶
Next time, set lower or higher values.
Tip:A lot of information about the food preparation and corresponding setting values
can be found on our website www.neff-international.com.
17.2 Replacing the oven light bulb
If the light in the cooking compartment fails, change
the oven light bulb.
Note:Heat-resistant, 40-watt, 230 V halogen bulbs are
available from the after-sales service or specialist retail-
ers. Only use these bulbs. Hold the new halogen bulbs
only with a clean, dry towel. This increases the service
life of the bulb.
WARNING‒Risk of burns!
The appliance and its parts that can be touched be-
come hot during use.
▶ Caution should be exercised here in order to avoid
touching heating elements.
▶ Young children under 8 years of age must be kept
away from the appliance.
WARNING‒Risk of electric shock!
When changing the bulb, the bulb socket contacts are
live.
▶ Before replacing the bulb, ensure that the appliance
is switched off in order to prevent a potential electric
shock.
▶ Also unplug the appliance from the mains or switch
off the circuit breaker in the fuse box.
Requirements
¡ The appliance is disconnected from the power sup-
ply.
¡ The cooking compartment has cooled down.
¡ You have a new halogen bulb to replace the old one.
1.
Place a tea towel in the cooking compartment to
prevent damage.
2.
Turn the glass cover anti-clockwise to remove it
.
3.
Pull out the halogen bulb without turning it .
en Disposal
26
4.
Insert the new halogen lamp and press it firmly into
the socket.
Make sure the pins are positioned correctly.
5.
Depending on the appliance model, the glass cover
may have a sealing ring. Put the sealing ring in posi-
tion.
6.
Screw the glass cover on.
7.
Take the tea towel out of the cooking compartment.
8.
Connect the appliance to the power supply.
18 Disposal
Find out here how to dispose of old appliances cor-
rectly.
18.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are
available from your specialist dealer or local author-
ity.
This appliance is labelled in accord-
ance with European Directive
2012/19/EU concerning used elec-
trical and electronic appliances
(waste electrical and electronic equip-
ment - WEEE).
The guideline determines the frame-
work for the return and recycling of
used appliances as applicable
throughout the EU.
19 Customer Service
If you have any queries on use, are unable to rectify
faults on the appliance yourself or if your appliance
needs to be repaired, contact Customer Service.
Function-relevant genuine spare parts according to the
corresponding Ecodesign Order can be obtained from
Customer Service for a period of at least 10 years from
the date on which your appliance was placed on the
market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information on the warranty period and terms
of warranty in your country is available from our after-
sales service, your retailer or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD) of your appliance.
The contact details for Customer Service can be found
in the enclosed Customer Service directory or on our
website.
This product contains light sources from energy effi-
ciency class G.
19.1 Product number (E-Nr.) and production
number (FD)
You can find the product number (E-Nr.) and the pro-
duction number (FD) on the appliance's rating plate.
The rating plate bearing these numbers can be found
on the base of the appliance when you open the appli-
ance door.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
20 How it works
Here, you can find the ideal settings for various types
of food as well as the best accessories and cookware.
We have perfectly tailored these recommendations to
your appliance.
20.1 General cooking tips
Please take note of the following information when
cooking all types of food.
¡ The temperature and cooking time depend on the
amount of food and the recipe. Settings ranges are
specified for this reason. Try using the lower values
to start with.
¡ The setting values apply to food placed in the cook-
ing compartment while the cooking compartment is
still cold. Do not place accessories into the cooking
compartment until it has finished preheating.
¡ Remove any accessories that are not being used
from the cooking compartment.
20.2 Baking tips
¡ Dark-coloured metal baking tins are most suitable
for baking cakes, bread and other baked goods.
¡ Use wide, shallow cookware for bakes and gratins.
Food takes longer to cook in deep, narrow cook-
ware and it browns more on top.
How it works en
27
¡ If you are cooking bakes directly in the universal
pan, place the universal pan into the cooking com-
partment at level2.
¡ The setting values for bread dough apply to both
dough placed on a baking tray and dough placed in
a loaf tin.
ATTENTION!
When the cooking compartment is hot, any water in-
side it will create steam. The change in temperature
may cause damage.
▶ Never pour water into the cooking compartment
when it is still hot.
▶ Never place cookware containing water on the
cooking compartment floor.
Shelf positions
If you are using the CircoThermhot air heating func-
tion, you can choose between shelf positions 1, 2, 3
and 4.
Baking on one level Shelf position
Tall baked items and tins/dishes on
the wire rack
2
Shallow baked items/baking trays 3
Baking on two or more levels Shelf position
2levels
¡ Universal pan
¡ Baking tray
3
1
2levels
¡ Baking tins on two wire racks 3
1
3levels
¡ Baking tray
¡ Universal pan
¡ Baking tray
4
3
1
4levels
¡ 4 wire racks with greaseproof pa-
per
4
3
2
1
Use the CircoThermhot air heating function.
Note:Items that are placed in the appliance on baking
trays or in baking tins/dishes at the same time will not
necessarily be ready at the same time.
20.3 Roasting, braising and grilling tips
¡ The recommended settings are for fridge-temperat-
ure food and unstuffed, oven-ready poultry.
¡ Place the poultry onto the cookware breast-side or
skin-side down.
¡ Turn roasting joints, grilled items or whole fish after
approx. ½ to ⅔ of the specified time.
Calculating the cooking time, e.g. 20+35:
¡ To calculate the cooking time, assume 20minutes
per 500g of meat. Then add an extra 35minutes to
that figure.
¡ For 1.5kg, the cooking time would therefore be
95minutes.
Cooking time range, e.g. 10-15:
¡ Your food will be ready within the specified range of
time (in minutes).
Roasting on the wire rack
Food roasted on the wire rack will become very crispy
on all sides. You can roast large poultry, for example,
or multiple individual pieces at the same time.
¡ Roast pieces of a similar weight and thickness. The
grilled food will brown evenly and will remain succu-
lent and juicy.
¡ Place the food to be roasted directly on the wire
rack.
¡ To catch any liquids that drip down, place the uni-
versal pan, with the wire rack inside it, into the cook-
ing compartment at the specified shelf height.
¡ Add up to ½litre of water to the universal pan, de-
pending on the size and type of food that you want
to roast.
You can make a sauce from the juices that are col-
lected. This also means that less smoke is pro-
duced and the cooking compartment does not be-
come as dirty.
Roasting in cookware
If you cover the cookware when you cook your food,
this will keep the cooking compartment cleaner.
General information about roasting in cookware
¡ Use heat-resistant, ovenproof cookware.
¡ Place the cookware on the wire rack.
¡ Glass cookware is best.
¡ Follow the manufacturer's instructions for your roast-
ing dishes.
Roasting in uncovered cookware
¡ Use a deep roasting dish.
¡ If you do not have any suitable cookware, you can
use the universal pan.
Roasting in covered cookware
¡ Use a suitable lid that seals well.
¡ When roasting meat, there should be at least 3cm
between the food and the lid. The meat may ex-
pand.
WARNING‒Risk of scalding!
Very hot steam may escape when the lid is opened
after cooking. Steam may not be visible, depending on
the temperature.
▶ Lift the lid in such a way that the hot steam can es-
cape away from you.
▶ Keep children away from the appliance.
Grilling
Grill food if you want it to be crispy.
The "Grill" heating function is good for cooking thinner
pieces of poultry, meat and fish such as steaks, drum-
sticks and burgers. It is also excellent for toasting
bread.
Circo-roasting is very well suited to cooking whole
poultry and fish, as well as meat, e.g. roast pork with
crackling.
¡ When grilling several food items, choose pieces that
are of a similar weight and thickness. The grilled
food will brown evenly and will remain succulent
and juicy.
en How it works
28
¡ Place the food to be grilled directly onto the wire
rack.
¡ To catch any liquids that drip down, place the uni-
versal pan into the cooking compartment at least
one level below the wire rack.
Notes
¡ The grill element switches on and off continuously.
This is normal. The temperature that you set determ-
ines how frequently this occurs.
¡ Smoke may be produced when grilling.
20.4 Cooking instructions for ready meals
¡ The cooking result greatly depends on the quality of
the food. Pre-browning and irregularities are some-
times already present on the raw product.
¡ Do not use frozen products that are covered with a
thick layer of ice. Remove any ice on the food.
¡ Distribute foods that are in the form of separate
pieces, such as bread rolls and potato products, so
that they are spread out flat and evenly on the ac-
cessory. Leave a little space between the individual
pieces.
¡ Follow the manufacturer's instructions on the pack-
aging.
20.5 List of foods
Recommended settings for a variety of foods, sorted into food categories.
Recommended settings for various types of food
Food Accessory/cookware Shelf pos-
ition
Heating
function
→Page7
Temperature in
°C
Cooking time in
mins
Victoria sponge cake x2
Baking tin, dia.
20cm
2 160–170
1
20–25
Rich fruit cake High Ø23cm tin 2 130–150 150–180
Rich fruit cake High Ø23cm tin 2 140–160 120–180
Fruit pie Plate Ø20cm
or
Pie tin
2 160–170 55–65
Fruit pie Plate Ø20cm
or
Pie tin
2 170–190 55–70
Fruit pie Plate Ø20cm
or
Pie tin
2 170–190 60–75
Quiche Dark coated quiche
tin
3 190–210 35–45
Bread or white bread Loaf tin, 1 x 900g or
2 x 450g
2 190–210
1
25–40
Bread or white bread Loaf tin, 1 x 900g or
2 x 450g
2 180–200
1
20–30
Bread or white bread Loaf tin, 1 x 900g or
2 x 450g
2 190–200 40–50
Scones Baking tray 3 180–200
1
10–14
Biscuits Baking tray 3 140–160
1
10–25
Small cakes 12-cup-tin 3 140–160
1
20–30
Pavlova Baking tray 3 90–100
1
120–180
Yorkshire pudding 12-cup-tin 3 200–220
1
15–25
Pizza, home-made Baking tray 3 200–220 25–35
Pizza, home-made, thin crust Pizza tray 2 210–220 25–30
1
Preheat the appliance.
2
Add the food after approx. one hour.
3
Preheat the appliance for 5 minutes.
4
Preheat the appliance for three minutes.
5
Turn the dish several times.
How it works en
29
Food Accessory/cookware Shelf pos-
ition
Heating
function
→Page7
Temperature in
°C
Cooking time in
mins
Victoria sponge cake, 2 levels 4 pcs
Baking tin, dia.
20cm
3+1 160–170
1
20–25
Biscuits, on 2levels x2
Baking tray
3+1 140 - 160
1
10 - 25
Top side, top rump Wire rack 2 160 - 170 30 + 25
Leg, bone-in Wire rack 2 160 - 170 25 + 25
Belly Wire rack 2 170 - 180 30 + 25
Chicken, whole Wire rack 2 170 - 180 25 + 15
Turkey, crown Wire rack 2 150 - 160 20 + 15
Turkey, whole, 4-8kg Wire rack 2 150 - 160 12 + 12
2
Diced meat, e.g. beef, pork,
lamb, 500g meat
Covered cookware 2 140
1
100 - 120
Diced meat, e.g. beef, pork,
lamb, 500g meat
Covered cookware 2 140 100–120
Complete meal with chicken Wire rack
+
Wire rack
4+1 180 Calculation for
chicken (see
table above)
Bacon rashers Wire rack 3 290
3
1. First side 4-5
2. Second side
3-4
Sausages, 2-4cm thick Wire rack 3 290
4
10 - 15
5
Belly Wire rack 2 200 - 220 30 + 25
Gammon joint Wire rack 2 180 - 200 30 + 25
Chicken, whole Wire rack 2 200–220 20 + 15
Yoghurt Individual moulds Cooking
compart-
ment floor
35 - 40 8-9 hrs
1
Preheat the appliance.
2
Add the food after approx. one hour.
3
Preheat the appliance for 5 minutes.
4
Preheat the appliance for three minutes.
5
Turn the dish several times.
20.6 Special cooking methods and other
applications
Information and recommended settings for special
cooking methods and other applications, e.g. slow
cooking or preserving.
Yoghurt
Use your appliance to make yoghurt.
Making yoghurt
1.
Remove the accessories and shelves from the
cooking compartment.
2.
Heat 1litre of whole milk (3.5% fat) to 90°C on the
hob and then leave it to cool down to 40°C.
It is sufficient to heat UHT milk to 40°C.
3.
Mix 150g of chilled yoghurt into the milk.
4.
Pour the mixture into small containers, e.g. cups or
small jars.
5.
Cover the containers with film, e.g. cling film.
6.
Place the containers on the cooking compartment
floor.
7.
Use the recommended settings when configuring
the appliance settings.
8.
After making the yoghurt, leave it to cool in the refri-
gerator for at least 12hours.
Recommended settings for yoghurt
Food Accessory/cookware Shelf pos-
ition
Heating
function
→Page7
Temperature in
°C
Cooking time in
mins
Yoghurt Individual moulds Cooking
compart-
ment floor
35 - 40 8-9 hrs
en How it works
30
Slow cooking
Cook prime cuts of meat slowly at a low temperature,
e.g. tender cuts of beef, veal, lamb or poultry.
Low temperature cooking poultry or meat
Note:When using the low temperature cooking type of
heating, you cannot delay the start of the programme
by setting an end time.
Requirement:The cooking compartment is cold.
1.
Use fresh, clean, hygienic meat without bones.
2.
Place the cookware onto the wire rack at level 2 in
the cooking compartment.
3.
Preheat the cooking compartment and cookware for
approx. 15minutes.
4.
Sear the meat on all sides on the hob at a very high
heat.
5.
Immediately place the meat into the pre-warmed
cookware in the cooking compartment.
To ensure that the climate in the cooking compart-
ment remains constant, keep the cooking compart-
ment door closed during low temperature cooking.
6.
After low temperature cooking, remove the meat
from the cooking compartment.
Tips for slow cooking
Here you will find tips for achieving good results when
slow cooking food.
Issue Tip
You want to slow
cook a duck breast.
¡ Place the cold duck breast
into a pan.
¡ Sear the skin side first.
¡ Slow cook the duck breast.
¡ After slow cooking, grill the
duck breast for 3 to
5minutes until crispy.
You want to serve
your slow-cooked
meat as hot as pos-
sible.
¡ Preheat the serving plate.
¡ Make sure that the sauces
that accompany the duck
breast are very hot when
you serve them.
Recommended settings for slow cooking
Food Accessory/cook-
ware
Shelf pos-
ition
Searing
time in
mins
Heating function
→Page7
Temperature
in °C
Cooking
time in
mins
Duck breast, medium
rare, 300g each
Uncovered cook-
ware
2 6 - 8 90
1
45 - 60
Fillet of pork, whole Uncovered cook-
ware
2 4 - 6 80
1
45 - 70
Fillet of beef, 1kg Uncovered cook-
ware
2 4 - 6 80
1
90 - 120
Veal medallions, 4cm
thick
Uncovered cook-
ware
2 4 80
1
30 - 50
Saddle of lamb, bone-
less, 200g each
Uncovered cook-
ware
2 4 80
1
30 - 45
1
Preheat the appliance.
Defrosting
You can defrost frozen food in your appliance.
Tips for defrosting food
¡ You can use the appliance to defrost frozen fruit, ve-
getables or baked goods.
¡ It is better to defrost poultry, meat and fish in the re-
frigerator.
¡ Remove frozen food from its packaging before you
defrost it.
¡ The recommended settings are for freezer-temperat-
ure food (-18°C).
¡ When defrosting food, use the following shelf posi-
tions:
– 1 wire rack: Shelf position 2
– 2 wire racks: Shelf positions 3+1
¡ Stir or turn the food 1-2times during defrosting.
Turn large items several times. Split the food into
smaller pieces as it defrosts.
Remove pieces that have already defrosted from the
cooking compartment.
¡ Once the food has defrosted, switch off the appli-
ance and leave the food in the appliance for another
10 to 30minutes to allow the temperature to equal-
ise.
How it works en
31
20.7 Test dishes
The information in this section is provided for test institutes to facilitate testing of the appliance in accordance with
EN 60350‑1.
Baking
¡ The setting values apply to food that is placed into a
cold cooking compartment.
¡ Please take note of the information on preheating in
the recommended settings tables. These setting val-
ues assume that the rapid heat-up function is not
being used.
¡ For baking, use the lower of the specified temperat-
ures to start with.
¡ Items that are placed in the appliance on baking
trays or in baking tins/dishes at the same time will
not necessarily be ready at the same time.
¡ Shelf positions when baking on 2levels:
– Universal pan: Shelf position3
Baking tray: Shelf position1
– Baking tins/dishes on the wire rack:
First wire rack: Shelf position3
Second wire rack: Shelf position1
¡ Shelf positions when baking on 3levels:
– Baking tray: Shelf position4
– Universal pan: Shelf position3
– Baking tray: Shelf position1
¡ Hot water sponge cake
– When baking on two levels, place the springform
tins at diagonally opposite corners of the wire
racks.
Recommended settings for baking
Food Accessory/cookware Shelf pos-
ition
Heating
function
→Page7
Temperature in
°C
Cooking time in
mins
Viennese whirls Baking tray 3 140 - 150
1
25 - 40
Viennese whirls Baking tray 3 140 - 150
1
25 - 40
Viennese whirls, on 2levels Universal pan
+
Baking tray
3+1 140 - 150
1
30 - 40
Viennese whirls, on 3levels x2
Baking tray
+
x1
Universal pan
4+3+1 130 - 140
1
35 - 55
Small cakes Baking tray 3 160
1
20 - 30
Small cakes Baking tray 3 150
1
25 - 35
Small cakes, on 2levels Universal pan
+
Baking tray
3+1 150
1
25 - 35
Small cakes, on 3levels x2
Baking tray
+
x1
Universal pan
4+3+1 140
1
35 - 45
Hot water sponge cake Springform cake tin,
diameter 26 cm
2 160 - 170
2
25 - 35
Hot water sponge cake Springform cake tin,
diameter 26 cm
2 160 - 170
2
30 - 40
Hot water sponge cake, on
2levels
Springform cake tin,
diameter 26 cm
3+1 150 - 170
2
30 - 50
1
Preheat the appliance for five minutes. Do not use the rapid heating function.
2
Preheat the appliance. Do not use the rapid heating function.
en Installation instructions
32
Recommended settings for grilling
Food Accessory/cookware Shelf pos-
ition
Heating
function
→Page7
Temperature in
°C
Cooking time in
mins
Toasting bread Wire rack 4 290
1
4 - 6
1
Do not preheat the appliance.
21 Installation instructions
Observe this information when installing the appliance.
21.1 General installation instructions
Follow these instructions before you start with
the installation of the appliance.
¡ The safe operation of this appliance can
only be guaranteed if it has been installed
to a professional standard in accordance
with these installation instructions. The in-
staller shall be liable for damages incurred
as a result of incorrect installation.
¡ Do not use the door handle for the trans-
port or installation.
¡ Check the appliance for damage after un-
packing it. Do not connect the appliance if
it has been damaged in transit.
¡ Before starting up the appliance, remove
any packaging material and adhesive film
from the cooking compartment and the
door.
¡ Proceed in accordance with the installation
sheets for installing accessories.
¡ Fitted units must be heat-resistant up to
95°C, and adjacent unit fronts up to
70°C.
¡ Do not install the appliance behind a decor-
ative door or the door of a kitchen unit.
There is a risk of overheating.
¡ Cut-out work on the units should be carried
out before installing the appliance. Remove
any shavings. Otherwise, the correct opera-
tion of electrical components may be ad-
versely affected.
¡ The mains socket for the appliance must
either be located in the hatched area
or
outside of the area where the appliance is
installed.
Any unsecured units must be secured to
the wall using a standard bracket .
¡ Wear protective gloves so that you do not
cut yourself. Parts that are accessible dur-
ing installation may have sharp edges.
¡ Dimensions of the figures in mm.
WARNING‒Danger: Magnetism!
Permanent magnets are used in the control
panel or in the controls. They may affect elec-
tronic implants, e.g. pacemakers or insulin
pumps.
▶ Wearers of electronic implants must stay at
least 10 cm away from the control panel or
controls during the installation.
WARNING‒Risk of fire!
It is dangerous to use an extended power
cord and non-approved adapters.
▶ Do not use multiple socket strips.
▶ Only use extension cables that are certified,
have a minimum cross section of 1.5mm²
and comply with the applicable national
safety requirements.
▶ If the power cord is too short, contact cus-
tomer service.
▶ Only use adapters approved by the manu-
facturer.
Installation instructions en
33
ATTENTION!
Carrying the appliance by the door handle
could break it. The door handle cannot sup-
port the weight of the appliance.
▶ Do not carry or hold the appliance by the
door handle.
21.2 Appliance dimensions
You will find the dimensions of the appliance here
21.3 Installation below a worktop
Observe the installation dimensions and the installation
instructions when installing below a worktop.
¡ To ventilate the appliance, the intermediate floor
must have a ventilation cut-out.
¡ The worktop must be secured to the built-in unit.
¡ Observe any available installation instructions for the
hob.
21.4 Installation underneath a hob
If the appliance is installed under a hob, the following
minimum dimensions must be adhered to (including
substructure, if applicable).
The minimum worktop thickness a is based on the
required minimum clearance .
Hob type a raised in mm a flush in mm b in mm
Induction hob 37 38 5
Full-surface induction hob 47 48 5
Gas hob 27 38 5
Electric hob 27 30 2
en Installation instructions
34
21.5 Installation in a tall unit
Observe the installation dimensions and the installation
instructions when installing in a tall unit.
¡ To ventilate the appliance, the intermediate floors
must have a ventilation cut-out.
¡ If the tall unit has another back panel in addition to
the element back panels, this must be removed.
¡ Only fit the appliance up to a height which allows
accessories to be easily removed.
21.6 Installing two appliances on top of
each other
Your appliance can also be installed above or below
another appliance. Observe the installation dimensions
and the installation instructions when installing appli-
ances on top of each other.
¡ To ventilate the appliances, the intermediate floor
must have a ventilation cut-out.
¡ To ensure sufficient ventilation of the two appli-
ances, there must be a ventilation opening of at
least 200cm² in the base area. To do this, trim the
base panel or fit a ventilation grille.
¡ Ensure that air exchange is guaranteed in accord-
ance with the diagram.
¡ Only fit appliances up to a height that allows ac-
cessories to be easily removed.
21.7 Corner installation
Observe the installation dimensions and the installation
instructions when installing in a corner.
¡ To ensure that the appliance door can be opened,
you must take the minimum dimensions into consid-
eration when installing in a corner. The dimension
is dependent on the thickness of the unit front and
the handle.
21.8 Electrical connection
In order to safely connect the appliance to the elec-
trical system, follow these instructions.
¡ The appliance corresponds to protection class I and
must only be operated with a protective earth con-
nection.
¡ The fuse protection must correspond to the power
rating specified on the appliance's rating plate and
to local regulations.
¡ The appliance must be disconnected from the
power supply whenever installation work is being
carried out.
¡ The appliance must only be connected using the
power cable provided.
¡ The power cable must be plugged in at the rear of
the appliance until you hear a clicking sound. A 3 m
power cable can be obtained from the after-sales
service.
¡ The power cable must only be replaced with a cable
from the original manufacturer. This is available from
after-sales service.
Installation instructions en
35
¡ Contact protection must be guaranteed by the in-
stallation.
Electrically connect the appliance with the
protective contact plug
Note:The appliance must only be connected to a pro-
tective contact socket that has been correctly installed.
▶
Insert the plug into the protective contact socket.
When the appliance is installed, the mains plug of
the power cord must be freely accessible. If free ac-
cess to the mains plug is impossible, an all-pole
isolating switch must be integrated into the perman-
ent electrical installation in accordance with the in-
stallation regulations.
Electrically connecting an appliance without a
protective contact plug
Note:Only a licensed professional may connect the ap-
pliance. Damage caused by incorrect connection is not
covered under the warranty.
An all-pole isolating switch must be integrated into the
permanent electrical installation according to the install-
ation regulations.
1.
Identify the phase and neutral conductors in the
socket.
The appliance may be damaged if it is not connec-
ted correctly.
2.
Connect the hob in accordance with the connection
diagram.
See the rating plate for the voltage.
3.
Connect the wires of the mains power cable accord-
ing to the colour coding:
‒ Green/yellow = Protective conductor
‒ Blue = Neutral conductor
‒ Brown = Phase (external conductor)
21.9 Installing the appliance
Note:Do not use a cordless screwdriver to secure the
panels. This may damage the panels.
1.
If required, you can adjust the gap between the ap-
pliance door and the panels using the adjustment
screws on the left and right.
Turning the screws clockwise makes the gap larger
Turning the screws anti-clockwise makes the gap
smaller
2.
Push the appliance in fully.
Do not kink or trap the connection cable, or route it
over sharp edges.
3.
Centre the appliance.
There must be an air gap of at least 4mm between
the appliance and adjacent unit fronts.
4.
Open the appliance door slightly and unscrew pan-
els on the left and right.
5.
Close the appliance door.
6.
If required, you can adjust the height of the appli-
ance door using the adjustment screws on the left
and right.
Turning the screws clockwise makes the gap smal-
ler
Turning the screws anti-clockwise makes the gap
larger
en Installation instructions
36
7.
Screw the appliance into place.
8.
For handleless kitchens with vertical bar handle
strips:
‒ Attach a suitable filling piece in order to cover
any sharp edges and to guarantee a safe install-
ation.
‒ Pre-drill aluminium profiles to establish a screw
connection .
‒ Secure the appliance using a suitable screw .
9.
Open the appliance door slightly, then refit the pan-
els and screw them in place, first at the top and
then at the bottom.
Note:The gap between the worktop and the appliance
must not be closed by additional battens.
Thermal insulation strips must not be fitted to the side
panels of the surround unit.
21.10 Removing the appliance
1.
Disconnect the appliance from the power supply.
2.
Open the appliance door slightly and unscrew the
left and right-hand panels.
3.
Undo the fastening screws.
4.
Lift the appliance slightly and pull it out completely.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
*9001629450*
9001629450
020201
en
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
