GE - General Electric RAS240DMWW Hotpoint 24" Electric User Manual

Write the model and serial

numbers here:

Model # _________________

Serial # _________________

You can find the rating label

on the front behind the range

storage drawer on GE Appliances

models and under the cooktop

for Hotpoint models.

ESPAÑOL

Para consultar una version en

español de este manual de

instrucciones, visite nuestro sitio de

internet GEAppliances.com.

OWNER’S MANUAL

RANGES

Compact Electric

49-2001026 Rev. 2 05-22 GEA

SAFETY INFORMATION .......... 3

USING THE RANGE

Surface Units ........................... 8

Oven Controls ..........................12

Sabbath Mode ..........................12

Oven Racks ............................13

Aluminum Foil and Oven Liners ...........13

Cookware Guidelines ....................14

Cooking Modes .........................14

Cooking Guide .........................15

CARE AND CLEANING

Cleaning the Range – Exterior ............16

Oven ..................................18

Cleaning the Glass Cooktop ..............19

Door and Drawer .......................21

Oven Light .............................21

Oven Door ............................ 22

TROUBLESHOOTING TIPS ....... 23

LIMITED WARRANTY ............ 26

ACCESSORIES .................... 27

CONSUMER SUPPORT ........... 28

Hotpoint Models

RAS200

RAS240

RAS300

GE Model

JAS640

GE is a trademark of the General Electric Company. Manufactured under trademark license.

2 49-2001026 Rev. 2

THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.

Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.

We take pride in the craftsmanship, innovation and design that goes into every GE Appliances

product, and we think you will too. Among other things, registration of your appliance ensures that we

can deliver important product information and warranty details when you need them.

Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration

card included in the packing material.

49-2001026 Rev. 2 3

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

SAFETY INFORMATION

WARNING

Read all safety instructions before using the product. Failure to follow these instructions may result

in fire, electrical shock, serious injury or death.

WARNING

GENERAL SAFETY INSTRUCTIONS

■ Usethisapplianceonlyforitsintendedpurposeas

described in this Owner’s Manual.

■ FIRE HAZARD: Never leave the range unattended

with the cooktop ON above a Lo setting. Keep

flammable items away from the cooktop. Turn off all

controls when done cooking. Failure to follow these

instructions can result in fire, serious injury or death.

■ Besureyourapplianceisproperlyinstalledand

grounded by a qualified installer in accordance with

the provided installation instructions.

■ Donotattempttorepairorreplaceanypartofyour

range unless it is specifically recommended in this

manual. All other servicing should be transferred to

a qualified technician.

■ Beforeperforminganyservice,unplugtherange

or disconnect the power supply at the household

distribution panel by removing the fuse or switching

off the circuit breaker.

■ Donotleavechildrenalone—childrenshouldnot

be left alone or unattended in an area where an

appliance is in use. They should never be allowed

to climb, sit or stand on any part of the appliance.

■

CAUTION

Donotstoreitemsofinterestto

children above a range or on the backguard of a

range—childrenclimbingontherangetoreach

items could be seriously injured.

■ Useonlydrypotholders—moistordamppot

holders on hot surfaces may result in burns from

steam.Donotletpotholderstouchhotsurface

unitsorheatingelements.Donotuseatowelor

other bulky cloth in place of pot holders.

■ Neveruseyourapplianceforwarmingorheating

the room.

ANTI-TIP DEVICE

To reduce the risk of tipping the range, the range

must be secured by a properly installed anti-tip

bracket. See installation instructions shipped

with the bracket for complete details before

attempting to install.

For Free-Standing Ranges

To check if the bracket is installed, ensure

there is no cookware on top of the range and all

surfaces are cool to the touch. Carefully slide

out the range from the wall approximately three

inches. Look behind the range to see if there is

a metal bracket attached to the floor or the wall. To check if the bracket is installed correctly, grasp the back of

the range, being careful not to grab or bend the rear trim piece. Tilt the range forward

slightly and confirm the anti-tip bracket engages the back of the range, limiting the

forward tip of the range. If the anti-tip bracket does not engage the range and prevent

it from tipping, verify the anti-tip bracket has been properly installed. If this does not

solvetheproblemortheanti-tipbracketisnotpresent,call800.626.8774intheUSor

800.561.3344 in Canada.

If the range is pulled from the wall for any reason, always repeat this procedure to verify

the range is properly secured by the anti-tip bracket.

Never completely remove the leveling legs or the range will not be secured to the anti-tip

device properly.

Anti-Tip

Bracket

Free-Standing Ranges

• A child or adult can tip the range and be killed.

• Verify the anti-tip bracket has been properly

installed and engaged.

• Ensure the anti-tip bracket is re-engaged when

the range is moved.

• Do not operate the range without the anti-tip bracket

in place and engaged.

• Failure to do so can result in death or serious burns

to children or adults.

Tip-Over Hazard

WARNING

4 49-2001026 Rev. 2

WARNING

KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE

Failure to do so may result in fire or personal injury.

■ Donotstoreoruseflammablematerialsinanoven

or near the cooktop, including paper, plastic, pot

holders, linens, wall coverings, curtains, drapes and

gasoline or other flammable vapors and liquids.

■ Neverwearloose-fittingorhanginggarmentswhile

using the appliance. These garments may ignite if

they contact hot surfaces causing severe burns.

■ Donotletcookinggreaseorotherflammable

materials accumulate in or near the range. Grease

in the oven or on the cooktop may ignite.

■ Cleanventilatinghoodsfrequently.Greaseshould

not be allowed to accumulate on the hood or filter.

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

WARNING

IN THE EVENT OF A FIRE, TAKE THE FOLLOWING

STEPS TO PREVENT INJURY AND FIRE SPREADING

■ Donotusewaterongreasefires.Neverpickup

a flaming pan. Turn the controls off. Smother a

flaming pan on a surface unit by covering the pan

completely with a well-fitting lid, cookie sheet or flat

tray.Useamulti-purposedrychemicalorfoam-type

fire extinguisher.

■ Ifthereisafireintheovenduringbaking,smother

the fire by closing the oven door and turning the

oven off or by using a multi-purpose dry chemical or

foam-type fire extinguisher.

■ Ifthereisafireintheovenduringself-clean,turn

the oven off and wait for the fire to go out. Donot

force the door open. Introduction of fresh air at self-

clean temperatures may lead to a burst of flame

from the oven. Failure to follow this instruction may

result in severe burns.

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

WARNING

GENERAL SAFETY INSTRUCTIONS (Cont.)

■ Donottouchthesurfaceunits,theheatingelements

or the interior surface of the oven. These surfaces

may be hot enough to burn even though they are

darkincolor.Duringandafteruse,donottouch,

or let clothing or other flammable materials contact

the surface units, areas nearby the surface units or

any interior area of the oven; allow sufficient time

for cooling first. Other surfaces of the appliance

may become hot enough to cause burns. Potentially

hot surfaces include the cooktop, areas facing the

cooktop, oven vent opening, surfaces near the

opening and crevices around the oven door.

■ Donotheatunopenedfoodcontainers.Pressure

could build up and the container could burst,

causing an injury.

■ Donotuseanytypeoffoilorlinertocoverthe

oven bottom or anywhere in the oven, except as

described in this manual. Oven liners can trap heat

or melt, resulting in damage to the product and risk

of shock, smoke or fire.

■ Avoidscratchingorimpactingglassdoors,cook

topsorcontrolpanels.Doingsomayleadtoglass

breakage.Donotcookonaproductwithbroken

glass. Shock, fire or cuts may occur.

■ Cookfoodthoroughlytohelpprotectagainst

foodborne illness. Minimum safe food temperature

recommendations can be found at

IsItDoneYet.gov and fsis.usda.gov.

Useafoodthermometertotakefoodtemperatures

and check several locations.

49-2001026 Rev. 2 5

WARNING

COOKTOP SAFETY INSTRUCTIONS

■ Neverleavethesurfaceunitsunattendedwiththe

cooktopONaboveaLosetting.Boiloverscause

smoking and greasy spillovers that may catch on fire.

■ Alwaysbepresentattherangewhencookingwith

oil or grease. Surface cooking is an "attended"

activity.

■ Neverleaveoilunattendedwhilefrying.Ifallowed

to heat beyond its smoking point, oil may ignite

resulting in fire that may spread to surrounding

cabinets.Useadeepfatthermometerwhenever

possible to monitor oil temperature.

■ Toavoidoilspilloverandfire,useaminimum

amount of oil when shallow pan-frying and avoid

cooking frozen foods with excessive amounts of ice.

■ Useproperpansize—selectcookwarehaving

flat bottoms large enough to cover the surface

heating element. The use of undersized cookware

will expose a portion of the surface unit to direct

contact and may result in ignition of clothing. Proper

relationship of cookware to surface unit will also

improve efficiency.

■ Onlycertaintypesofglass,glass/ceramic,

earthenware or other glazed containers are suitable

for cooktop service; others may break because of

the sudden change in temperature.

■ Tominimizethepossibilityofburns,ignitionof

flammable materials and spillage, the handle of a

container should be turned toward the center of the

range without extending over nearby surface units.

■ Whenpreparingflamingfoodsunderahood,turn

the fan on.

■ Ifpowerislosttoanelectriccooktopwhilea

surface unit is ON, the surface unit will turn back on

as soon as power is restored. In the event of power

loss, failure to turn all surface unit knobs to the OFF

position may result in ignition of items on or near

the cooktop, leading to serious injury or death.

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

WARNING

COIL COOKTOP SAFETY INSTRUCTIONS

■ Donotimmerseorsoaktheremovablesurface

units.Donotputtheminadishwasher.Donotself-

cleanthesurfaceunitsinanoven.Doingsomay

cause them to fail presenting a burn or fire hazard.

■Donotuseasurfaceunit(heatingelement)ifit

develops a glowing spot during use or shows

other signs of damage. A glowing spot indicates

the surface unit may fail and present a potential

burn, fire, or shock hazard. Turn the surface unit

off immediately and have it replaced by a qualified

service technician.

■Toavoidthepossibilityofaburnorelectricshock,

always be certain that the controls for all surface

units are at the OFF position and all coils are cool

before attempting to lift or remove a coil surface unit.

■Donotusealuminumfoiltolinedrippans.Foilcan

trap heat or melt, resulting in damage to the product

and a shock or fire hazard.

■Besurethedrippansarenotcoveredandarein

place. Their absence during cooking could damage

range parts and wiring.

6 49-2001026 Rev. 2

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

WARNING

RADIANT COOKTOP SAFETY INSTRUCTIONS

■ Usecarewhentouchingthecooktop.Theglass

surface of the cooktop will retain heat after the

controls have been turned off.

■ Donotcookonabrokencooktop.Ifglasscooktop

should break, cleaning solutions and spillovers

may penetrate the broken cooktop and create a

risk of electric shock. Contact a qualified technician

immediately.

■ Avoidscratchingtheglasscooktop.Thecooktop

can be scratched with items such as knives, sharp

instruments, rings or other jewelry, and rivets on

clothing.

■ Donotplaceorstoreitemsthatcanmeltorcatch

fire on the glass cooktop, even when it is not being

used. If the cooktop is inadvertently turned on, they

may ignite. Heat from the cooktop or oven vent after

it is turned off may cause them to ignite also.

■ Useceramiccooktopcleanerandanon-scratch

cleaning pad to clean the cooktop. Wait until the

cooktop cools and the indicator light goes out

before cleaning. A wet sponge or cloth on a hot

surface can cause steam burns. Some cleaners can

produce noxious fumes if applied to a hot surface.

NOTE: Sugar spills are an exception. They should

be scraped off while still hot using an oven mitt

and a scraper. See the Cleaning the glass cooktop

section for detailed instructions.

■ Readandfollowallinstructionsandwarningsonthe

cleaning cream label.

WARNING

OVEN SAFETY INSTRUCTIONS

■ Standawayfromtherangewhenopeningtheoven

door. Hot air or steam which escapes can cause

burnstohands,faceand/oreyes.

■ Donotusetheovenifaheatingelementdevelops

a glowing spot during use or shows other signs

of damage. A glowing spot indicates the heating

element may fail and present a potential burn, fire,

or shock hazard. Turn the oven off immediately and

have the heating element replaced by a qualified

service technician.

■ Keeptheovenventunobstructed.

■ Keeptheovenfreefromgreasebuildup.Greasein

the oven may ignite.

■ Placeovenracksindesiredlocationwhileovenis

cool. If rack must be moved while oven is hot, do not

let pot holder contact hot heating element in oven.

■ Whenusingcookingorroastingbagsintheoven,

follow the manufacturer’s directions.

■ Pulltheovenracktothestop-lockpositionwhen

loading and unloading food from the oven. This

helps prevent burns from touching hot surfaces of

the door and oven walls.

■ Donotleaveitemssuchaspaper,cookingutensils

or food in the oven when not in use. Items stored in

an oven can ignite.

■ Neverplacecookingutensils,pizzaorbakingstones,

or any type of foil or liner on the oven floor. These

items can trap heat or melt, resulting in damage to

the product and risk of shock, smoke or fire.

49-2001026 Rev. 2 7

How to Remove Protective Shipping Film and Packaging Tape

Carefully grasp a corner of the protective shipping film

with your fingers and slowly peel it from the appliance

surface.Donotuseanysharpitemstoremovethefilm.

Remove all of the film before using the appliance for the

first time.

To assure no damage is done to the finish of the

product, the safest way to remove the adhesive from

packaging tape on new appliances is an application of

a household liquid dishwashing detergent. Apply with a

soft cloth and allow to soak.

NOTE: The adhesive must be removed from all parts. It

cannot be removed if it is baked on.

Consider recycling options for your appliance packaging

material.

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

PROPER DISPOSAL OF YOUR APPLIANCE

DisposeoforrecycleyourapplianceinaccordancewithFederalandLocalRegulations.Contactyourlocal

authorities for the environmentally safe disposal or recycling of your appliance.

8 49-2001026 Rev. 2

USING THE RANGE:SurfaceUnits

Throughout this manual, features and appearance may vary from your model.

How to Set

Push the knob in and turn in either direction to the

setting you want.

A surface ON indicator light will glow when any surface

unit is on

For glass cooktop surfaces:

A HOT COOKTOP indicator light will:

■ comeonwhentheunitishottothetouch.

■ stayonevenaftertheunitisturnedoff.

■ stayonuntiltheunitiscooledto

approximately 150°F.

Surface Units

WARNING

FIRE HAZARD: Never leave the range unattended with the cooktop ON above a Lo setting. Keep

flammable items away from the cooktop. Turn off all controls when done cooking. Failure to follow

these instructions can result in fire, serious injury or death.

At both OFF and HI the control clicks into position. You may hear

slight clicking sounds during cooking, indicating the control is

maintaining your desired setting.

BesureyouturnthecontrolknobtoOFF when you finish cooking.

Coil Cooktops

Each coil surface unit uses "SENSI-TEMP

TECHNOLOGY" to reduce the risk of cooktop oil and

grease fires. This feature is located in the center of each

surface unit. Power to the surface unit is temporarily

interrupted when a pot or pan exceeds expected cooking

temperatures. Even after the surface units are turned off,

the surface unit retains enough heat to continue cooking.

To avoid overcooking, remove pans from the surface

units when the food is cooked. Avoid placing anything on

the surface unit until it has cooled completely.

Cookware for Coil Cooktops

The following information will help you choose cookware which will give good performance on coil cooktops.

NOTE: Follow all cookware manufacturer’s recommendations when using any type of cookware on the coil cooktop.

Recommended

Stainless Steel

Thin unclad stainless steel will give poor performance.

Aluminum

Heavy weight recommended.

Goodconductivity.Becauseofitslowmeltingpoint,thin

weight aluminum should not be used.

Copper Bottom

Enamel (painted) on Cast Iron

Cast Iron

Avoid/Not Recommended

Enamel (painted) on Steel

Glass-ceramic

Poor performance.

Stoneware

Poor performance.

49-2001026 Rev. 2 9

Temperature Limiter on Radiant Glass Cooktops

Every radiant surface unit has a temperature limiter.

The temperature limiter protects the glass cooktop from

getting too hot.

The temperature limiter may cycle the surface units off

for a time if:

■ thepanboilsdry.

■ thepanbottomisnotflat.

■ thepanisoff-center.

■ thereisnopanontheunit.

Radiant Glass Cooktop

The radiant cooktop features heating units beneath a

smooth glass surface.

NOTE: A slight odor is normal when a new cooktop is

used for the first time. It is caused by the heating of new

parts and insulating materials and will disappear in a

short time.

NOTE: On models with light-colored glass cooktops, it is

normal for the cooking zones to change color when hot

or cooling down. This is temporary and will disappear as

the glass cools to room temperature.

The surface unit will cycle on and off to maintain your

selected control setting.

It is safe to place hot cookware on the glass surface

even when the cooktop is cool.

Even after the surface units are turned off, the glass

cooktop retains enough heat to continue cooking. To

avoid overcooking, remove pans from the surface units

when the food is cooked. Avoid placing anything on the

surface unit until it has cooled completely.

■ Waterstains(mineraldeposits)areremovableusing

the cleaning cream or full-strength white vinegar.

■ Useofwindowcleanermayleaveaniridescentfilmon

the cooktop. The cleaning cream will remove this film.

■ Don’tstoreheavyitemsabovethecooktop.Ifthey

drop onto the cooktop, they can cause damage.

■ Donotusethesurfaceasacuttingboard.

USING THE RANGE:SurfaceUnits

Surface Units (Cont.)

Never cook directly on the glass. Always

use cookware.

Always place the pan in the center of the

surface unit you are cooking on.

Donotslidecookwareacrossthecooktopbecause

itcanscratchtheglass—theglassisscratch-

resistant, not scratch proof.

10 49-2001026 Rev. 2

Surface Units (Cont.)

USING THE RANGE:SurfaceUnits

Cookware for Radiant Glass Cooktops

The following information will help you choose cookware which will give good performance on glass cooktops.

NOTE: Follow all cookware manufacturer’s recommendations when using any type of cookware on the ceramic cooktop.

Recommended

Stainless Steel

Aluminum

Heavy weight recommended.

Good conductivity. Aluminum residues sometimes

appear as scratches on the cooktop but can be removed

ifcleanedimmediately.Becauseofitslowmeltingpoint,

thin weight aluminum should not be used.

Copper Bottom

Copper may leave residues which can appear as

scratches. The residues can be removed, as long as

the cooktop is cleaned immediately. However, do not let

these pots boil dry. Overheated metal can bond to glass

cooktops. An overheated copper bottom pot will leave

a residue that will permanently stain the cooktop if not

removed immediately.

Enamel (painted) on Cast Iron

Recommended if bottom of pan is coated.

Avoid/Not Recommended

Enamel (painted) on Steel

Heating empty pans can cause permanent damage to

cooktop glass. The enamel can melt and bond to the

ceramic cooktop.

Glass-ceramic

Poor performance. Will scratch the surface.

Stoneware

Poor performance. May scratch the surface.

Cast Iron

Notrecommended—unlessdesignedspecificallyfor

glass cooktops.

Poor conductivity and slow to absorb heat. Will scratch

the cooktop surface.

49-2001026 Rev. 2 11

More about Cookware

■ Placeonlydrypansonthesurfaceelements.Donot

place lids on the surface elements, particularly wet

lids. Wet pans and lids may stick to smooth surface

when cool.

■ Donotusewoksthathavesupportrings.Thistypeof

wok will not heat on the cooktop.

■ Werecommendthatyouuseonlyaflat-bottomed

wok. They are available at your local retail store. The

bottom of the wok should have the same diameter as

the surface element to ensure proper contact.

■ Somespecialcookingproceduresrequirespecific

cookware such as pressure cookers or deep-fat

fryers. All cookware must have flat bottoms and be

the correct size.

Home Canning Tips

Besurethecanneriscenteredoverthesurfaceunit.

Make sure the canner is flat on the bottom.

To prevent burns from steam or heat, use caution when

canning.

Userecipesandproceduresfromreputablesources.

TheseareavailablefrommanufacturerssuchasBall

and Kerr

andtheDepartmentofAgricultureExtension

Service.

Flat-bottomedcannersarerecommended.Useofwater

bath canners with rippled bottoms may extend the time

required to bring the water to a boil.

Check pans for flat bottoms by

using a straight edge. You should

notbeabletopassaUSnickelcoin

under the straight edge.

Pans with rounded, curved,

ridged or warped bottoms are not

recommended.

Donotplacewetpanson

the glass cooktop.

Donotusewokswithsupport

rings on the glass cooktop.

Useflat-bottomedwoks

on the glass cooktop.

USING THE RANGE:SurfaceUnits

Surface Units (Cont.)

12 49-2001026 Rev. 2

Oven Controls

To Adjust the Thermostat

1. Pull the Oven Temp knob off the range and look

at the back side. To make an adjustment, loosen

(approximatelyoneturn),butdonotcompletely

remove, the two screws on the back of the knob.

2. With the back of the knob facing you, hold the outer

edge of the knob with one hand and with the other

hand rotate the skirt.

Rotate the skirt clockwise to increase and

counterclockwise to decrease the oven temperature.

You’ll hear a click for each notch you move the knob.

Each click will change the oven temperature

approximately10°F.(Rangeisplusorminus

30°Ffromthearrow.)Wesuggestthatyoumake

the adjustment one click from the original setting

and check oven performance before making any

additional adjustments.

3. After the adjustment is made, retighten screws so

they are snug, but be careful not to overtighten.

4. Replace the knob, matching the flat area of the knob

to the shaft, and check performance.

Donotusethermometers,suchasthosefoundin

grocery stores, to check the temperature setting of your

oven. These thermometers may vary 20-40 degrees.

Oven Temperature Knob

Turn the OVEN TEMP knob to the setting you want.

TheOven/Cyclelightcomesonwhentheburnerison.It

will cycle on and off during cooking.

Front of OVEN TEMP knob

(knobappearancemayvary)

Certain models comply with Jewish Sabbath requirements for use during the Sabbath and holidays.

Start Baking

To start baking, simply turn the thermostat knob to the

desiredtemperature.Becauseathermostatmodelwill

respond with a clicking sound when the thermostat knob

is used to turn on the oven, this operation should take

place before the Sabbath or Holidays begin.

Adjusting the Temperature

To adjust the oven temperature while in compliance with

Sabbath requirements, the user must observe the oven

ON indicator light:

■Toadjusttheoventemperaturetoahighervalue,

the user must first confirm the "OVEN ON" light is

on. Only then, can the user turn the knob to a higher

temperature than was previously set.

■

To adjust the oven temperature to a lower value, the user

must first confirm the "OVEN ON" light is off. Only then,

can the user turn the knob to a lower temperature than

was previously set.

Stop Baking

To stop baking, simply turn the thermostat knob to the off

position.Becauseathermostatmodelwillrespondwitha

clicking sound when the thermostat knob is used to turn

off the oven, this operation should take place after the

Sabbath or Holidays end.

Oven Light Operation (on some models)

The oven light can be set to either on or off prior to the

start of the Sabbath or the holiday. Opening and closing

of the door will not change the state of the oven light.

Sabbath Mode Power Outage Note

If a power outage occurs during a Sabbath bake, the unit

will return to Sabbath bake mode when power is restored

and the oven will return to the same temperature as

before the outage, without any intervention from the user.

USING THE OVEN:OvenControls/SabbathMode

Sabbath Mode

BackofOVENTEMPknob

Clockwise to Increase

Temperature

(Shownathighestsetting)

Counterclockwise to

DecreaseTemperature

(Shownatlowestsetting)

Skirt(OutsideRing)

49-2001026 Rev. 2 13

USING THE RANGE:OvenRacks/AluminumFoilandOvenLiners

CAUTION

Do not use any type of foil or oven liner to cover the oven bottom. These items can trap heat

or melt, resulting in damage to the product and risk of shock, smoke or fire. Damage from improper use of

these items is not covered by the product warranty.

Foilmaybeusedtocatchspillsbyplacingasheetonalowerrack,severalinchesbelowthefood.Donotusemore

foilthannecessaryandneverentirelycoveranovenrackwithaluminumfoil.Keepfoilatleast1-1/2”fromovenwalls

to prevent poor heat circulation.

Aluminum Foil and Oven Liners

Rack Positions

Your oven has four rack positions in the main oven.

Recommended rack positions for various types of

foods are provided in the Cooking Guide. Adjusting

the rack position is one way to impact cooking results.

For example, if you would prefer darker tops on cakes,

muffins or cookies, try moving food one rack position

higher. If you find foods are too brown on top, try moving

them down next time.

When baking with multiple pans and on multiple racks,

ensure there is sufficient space between pans to allow

air to flow. This may improve cooking evenness.

Removing and Replacing Flat Racks

When placing and removing cookware, pull the rack out

tothebump(stopposition)ontheracksupport.

To remove a rack, pull it toward you until it reaches the

stop position, tilt up the front of the rack and pull it out.

To replace a rack, place the curved end of the rack onto

the rack supports. Tilt up the front of the rack and push

the rack in until it stops. Then lay the rack flat and push

it in until it is all the way into the oven.

Racks may become difficult to slide, especially after a

self-clean cycle. To improve sliding conditions, use a soft

cloth or paper towel to rub vegetable oil on the left and

rightedgesoftheracksand/orracksupports.

NOTE: Remove unused racks when using the oven for

faster preheat, improved efficiency, and optimal cooking

performance.

Rack positions

Removing racks

Replacing racks

Rack stop

position

Oven Racks

14 49-2001026 Rev. 2

The material, finish, and size of cookware affect baking

performance.

Dark,coatedanddullpansabsorbheatmorereadily

than light, shiny pans. Pans that absorb heat more

readily can result in a browner, crisper and thicker crust.

If using dark and coated cookware check food earlier

than the minimum cook time. If undesirable results are

obtained with this type of cookware consider reducing

oven temperature by 25º F next time.

■ Shinypanscanproducemoreevenlycookedbaked

goods such as cakes and cookies.

■ Glassandceramicpansheatslowlybutretainheat

well. These types of pans work well for dishes such

as pies and custards.

■ Airinsulatedpansheatslowlyandcanreducebottom

browning.

■ Keepcookwarecleantopromoteevenheating.

Your new oven has a variety of cooking modes to help you get the best results. These modes are described below.

Refer to the Cooking Guide section for recommendations for specific foods. Remember, your new oven may perform

differently than the oven it is replacing.

Bake

The bake mode is for baking and roasting. When

preparing baked goods such as cakes, cookies and

pastries, always preheat the oven first. To use this mode

turn the thermostat knob to the desired temperature.

Warm (on some models)

Warm mode is designed to keep hot foods hot. Cover

foods that need to remain moist and do not cover foods

thatshouldbecrisp.Preheatingisnotrequired.Donot

use Warm to heat cold food. It is recommended that food

not be kept warm for more than 2 hours. To use this

mode turn the thermostat knob to Warm.

Broil

Always broil with the oven door and drawer closed.

Monitorfoodcloselywhilebroiling.Usecautionwhen

broiling on the upper rack positions as placing food

closer to the broil burner increases smoking, splattering,

and the possibility of fats igniting.

Try broiling foods that you would normally grill. Adjust

rack positions to adjust the intensity of the heat to the

food. Place foods closer to the broil burner when a

seared surface and rare interior is desired. Thicker foods

and foods that need to be cooked through should be

broiled on a lower rack position. To use this mode turn

the thermostat knob to the Broil setting.

Pre-Heat

Proper preheating ensures that the oven is hot enough

tobeginbaking.Improperpreheating(thatis,cooking

intheoventhathasnotcomeuptosettemperature)

cannegativelyaffectcooking.Dependingontherecipe

recommendations, the temperature of your foods when

they go into the oven may determine your final baking

time and baking results; if you put your food, such as

biscuits or breads, in during Pre-heat, they may over

brown on top or burn.

IMPORTANT: The more items to be heated in the oven

duringpreheat(thisincludesmultipleracks,baking

stones,etc.)willaffectthelengthofyourpre-heattime.

Always begin baking after the pre-heat signal. The signal

will be a beep, indicaotr light or chime. This lets you

know your oven is at your needed baking temperature.

For best results, turn the oven On before you begin your

prep work.

Cookware Guidelines

Cooking Modes

USING THE OVEN: CookwareGuidelines/CookingModes

Oven Cavity

49-2001026 Rev. 2 15

Cooking Guide

USING THE OVEN: Cooking Guide

FOOD TYPE

RECOMMENDED

MODE(S)

RECOMMENDED

RACK POSITION(S) ADDITIONAL SUGGESTIONS

Baked Goods

Layer Cakes, sheet cakes, bundt

cakes, muffins, quick breads on

a Single Rack

Bake 2 Useshinycookware.

Layer cakes* on Multiple Racks Bake 1 and 3

Ensure adequate airflow

(seeillustrationbelow).

Chiffoncakes(angelfood) Bake 1 Useshinycookware.

Cookies, biscuits, scones on a

Single Rack

Bake 3 Useshinycookware.

Cookies, biscuits, scones on

Multiple Racks

Bake 2 and 4 Ensure adequate airflow.

Beef & Pork

Hamburgers Broil 4

Useabroilpan;movefooddownformore

doneness/lesssearing.Watchfoodcloselywhen

broiling. For best performance center food below the

broil heating element.

Steaks & Chops Broil 4

Useabroilpan;movefooddownformore

doneness/lesssearing.Watchfoodcloselywhen

broiling. For best performance center food below the

broil heating element.

Roasts Bake 1 or 2

Usealowsidedpansuchasabroilpan.Preheating

is not necessary.

Poultry

Whole chicken Bake 2 Usealowsidedpansuchasabroilpan.

Bone-inchickenbreasts,legs,

thighs

Broil

Bake

1 or 2

IfbreadedorcoatedinsauceavoidBroilHimodes.

Broilskinsidedownfirst.Watchfoodcloselywhen

broiling. For best performance when broiling, center

food below the broil heating element.

Bonelesschickenbreasts

Broil

Bake

1 or 2

IfbreadedorcoatedinsauceavoidBroilHimodes.

Broilskinsidedownfirst.Watchfoodcloselywhen

broiling. For best performance when broiling, center

food below the broil heating element

Whole turkey Bake 1 or 2 Usealowsidedpansuchasabroilpan.

TurkeyBreast Bake 1 or 2 Usealowsidedpansuchasabroilpan.

Fish Broil 4

Watch food closely when broiling. For best

performance center food below the broil heating

element.

Casseroles Bake 2 or 3

Frozen Convenience Foods

Pizza, french fries, tator tots,

chicken nuggets, appetizers on a

Single Rack

Bake 3 Useshinycookware.

*When baking four cake layers at a time, stagger the pans

as shown so that one pan is not directly above another.

Cook food thoroughly to help protect against food

borne illness. Minimum safe food temperature

recommendations for food safety can be found at

IsItDoneYet.gov. Make sure to use a food thermometer

to take food temperatures.

Rack position for baking 4 layer cakes.

16 49-2001026 Rev. 2

Cleaning the Range – Exterior

CARE AND CLEANING: Cleaning the Range – Exterior

A child or adult can tip the range and be killed.

Verify the anti-tip bracket has been properly installed

and engaged.

Ensure the anti-tip bracket is re-engaged when the range

is moved.

Do not operate the range without the anti-tip bracket in

place and engaged.

Failure to follow these instructions can result in death or

serious burns to children or adults.

Tip-Over Hazard

WARNING

If your range is removed for cleaning, servicing or any reason, be sure the anti-

tip device is reengaged properly when the range is replaced. Failure to take this

precaution could result in tipping of the range and can result in death or serious

burns to children or adults.

Besureallcontrolsareoffandallsurfacesarecoolbeforecleaninganypartoftherange.

Control Knobs

The control knobs may be removed for easier cleaning.

Make sure the knobs are in the OFF positions and pull

them straight off the stems for cleaning.

The knobs can be cleaned in a dishwasher or they may

also be washed with soap and water. Make sure the

inside of the knobs are dry before replacing.

Replace the knobs, in the OFF position to ensure proper

placement.

Control Panel

It’s a good idea to wipe the control panel after each use.

Clean with mild soap and water or vinegar and water,

rinse with clean water and polish dry with a soft cloth.

Donotuseabrasivecleansers,strongliquidcleansers,

plastic scouring pads or oven cleaners on the control

panel—theywilldamagethefinish.

Oven Exterior

Donotuseovencleaners,abrasivecleansers,strong

liquid cleansers, steel wool, plastic scouring pads, or

cleaning powders on the interior or exterior of the oven.

Clean with a mild soap and water or vinegar and water

solution. Rinse with clean water and dry with a soft cloth.

When cleaning surfaces, make sure that they are at

room temperature and not in direct sunlight.

If stain on the door vent trim is persistent, use a mild

abrasive cleaner and a sponge-scrubber for best results.

Spillage of marinades, fruit juices, tomato sauces and

basting liquids containing acids may cause discoloration

and should be wiped up immediately. Let hot surfaces

cool, then clean and rinse.

Painted Surfaces

Painted surfaces include the sides of the range and the

door, top of control panel and the drawer front. Clean

these with soap and water or a vinegar and water solution.

Donotusecommercialovencleaners,cleaningpowders,

steel wool or harsh abrasives on any painted surface.

Stainless Steel Surfaces (on some models)

Donotuseasteelwoolpad;itwillscratchthesurface.

To clean the stainless steel surface, use warm sudsy

water or a stainless steel cleaner or polish. Always wipe

the surface in the direction of the grain. Follow the cleaner

instructions for cleaning the stainless steel surface.

CleanerswithoxalicacidsuchasBarKeepersFriend

Soft Cleanser™ will remove surface rust, tarnish and

smallblemishes.Useonlyaliquidcleanserfreeofgrit

and rub in the direction of the brush lines with a damp,

soft sponge.

To inquire about purchasing cleaning products

including stainless steel appliance cleaner or polish,

see the Accessories and Consumer Support sections

at the end of this manual.

For easier cleaning, the control knobs may be removed

by pulling them directly outwards once the knobs are in

theOFFposition.Donotpullknobsupordownorhang

objects on them. This can damage the gas valve shaft.

The knobs can be washed by hand with soap and water

or in a dishwasher.

To replace knobs after

cleaning, align the hole

on the knob backside

with the gas valve shaft

and push inward until

the knob is securely

fastened. All knobs are

interchangeable

Surface burner knob

49-2001026 Rev. 2 17

BesurethecontrolsareturnedtoOFFandthesurfaceunitsarecoolbeforeattemptingtoremovethem.

Surface Units

To clean the surface units, turn the control to the highest

setting for a minute. The coils will burn off any soil. To

clean the Sensi-Temp Technology Sensor cap, wipe

with a damp sponge or cloth. For cooked-on food spills,

remove the burner from the range and gently scrub the

capandsupportswithadampplasticscouringpad.Do

not use steel wool. Allow the burner to dry over night

before re-installing it.

To remove a surface unit:

To remove the drip pans for cleaning, the surface units

must be removed first.

1. Push the surface unit back toward the receptacle.

2. Lift the surface unit about 1 inch above the drip pan

and pull it out.

Donotliftthesurfaceunitmorethan1inch.Ifyoudo,it

may not lie flat on the drip pan when you plug it back in.

NOTE: Repeated lifting of the surface unit more than

1 inch above the drip pan can permanently damage the

receptacle.

To replace a surface unit:

1. Replace the drip pan into the recess in the cooktop.

Make sure the opening in the pan lines up with the

receptacle.

2. Insert the terminals of the surface unit through the

opening in the drip pan and into the receptacle.

3. Push the surface unit in and down so it rests evenly in

the cooktop.

Donotimmersethesurfaceunitsinliquidsofanykind.

Donotcleanthesurfaceunitsinadishwasher.

Donotbendthesurfaceunitplugterminals.

Donotattempttoclean,adjustorinanywayrepairthe

plug-in receptacle.

DonotpullontheSENSI-TEMPTECHNOLOGYsensor

cap.

Porcelain Enamel Cooktop

The porcelain enamel finish is sturdy but breakable if

misused. This finish is acid-resistant. However, any

acidicfoodsspilled(suchasfruitjuices,tomatoor

vinegar)shouldnotbepermittedtoremainonthefinish.

If acids spill on the cooktop while it is hot, use a dry paper

towel or cloth to wipe it up right away. When the surface

has cooled, wash with soap and water. Rinse well.

For other spills such as fat spatterings, wash with soap

and water or cleansing powders after the surface has

cooled. Rinse well. Polish with a dry cloth.

Cleaning the Range – Exterior (Cont.)

CARE AND CLEANING: Cleaning The Oven - Exterior

SurfaceUnit

DripPan

Locking Tab

Cooktop Rim

SurfaceUnit

Locking

Tab

DripPan

Receptacle

Locking Tab

When properly seated, the locking tab should lock onto

the cooktop rim through the notch in the drip pan.

18 49-2001026 Rev. 2

Cleaning the Range – Exterior (Cont.)

CARE AND CLEANING:CleaningtheRange–Exterior/Oven

Drip Pans

Remove the surface units. Then lift out the drip pans.

For best results, clean the drip pans by hand. Place

theminacoveredcontainer(oraplasticbag)with

⁄4 cup

ammonia to loosen the soil. Rinse with clean water and

polish with a clean soft cloth.

The drip pans may also be cleaned in a dishwasher.

Cleantheareaunderthedrippansoften.Built-upsoil,

especially grease, may catch fire.

Donotcoverthedrippanswithfoil.Usingfoilsoclose

to the receptacle could cause shock, fire or damage to

the range.

NOTE: If your cooktop is equipped with shiny, silver-

colored drip pans, do not clean them in the self-cleaning

oven. Permanent damage to the finish can occur.

If your cooktop is equipped with black or gray porcelain-

coated drip pans, they can be cleaned in the oven during

theself-cleaningcycle.Beforeyoubeginaself-cleaning

cycle, remove any heavy soil from the drip pans and

placethemontheporcelain-coatedovenracks.Donot

place the drip pans directly on the oven bottom. After

the self-cleaning cycle is completed and the drip pans

are cool, wipe them with a damp cloth to remove any

remaining ash or residue.

Besureallcontrolsareoffandallsurfacesarecoolbeforecleaninganypartoftheoven.

Oven Interior

The interior of your new oven can be cleaned manually

or by using steam clean process.

Spillage of marinades, fruit juices, tomato sauces and

basting liquids containing acids may cause discoloration

and should be wiped up as soon as hot surfaces cool,

then clean and rinse.

Manual Cleaning

Donotuseovencleaners,strongliquidcleansers,steel

wool, or scouring pads on the interior of the oven. For

soils on the oven bottom and other enameled surfaces,

use a gentle abrasive containing oxalic acid, such as

BarKeepersFriend

, with a non-scratch sponge. Take

care not to apply any abrasive cleaners or sponges to

the door glass, as it will scratch the reflective coating.

The oven interior and door glass may be cleaned using

a soft cloth with a mild soap and water, or vinegar and

water solution. After cleaning, rinse with clean water and

dry with a soft cloth.

Steam Cleaning

Steam Cleaning is for cleaning light soil from your oven.

To use the Steam Clean feature:

1. Start with the oven at room temperature.

2. Wipe excess grease and soils from the oven.

3.Pour1/2cupofwaterontothebottomoftheoven.

4. Close the door.

5. Turn your oven temperature knob to 200ºF.

6.Setatimerfor21/2minutes.Whentimeisfinish,

turn oven temperature knob to Off.

7. Set a timer for 27 minutes to allow oven to cool down.

DonotopenthedoorduringtheSteamCleaning.Atthe

end of the cycle, soak up the remaining water, and wipe

the moisture-softened soil from the oven walls and door.

Oven Exterior

Donotuseovencleaners,abrasivecleansers,strong

liquid cleansers, steel wool, plastic scouring pads or

cleaning powders on the interior or exterior of the oven.

Cleanwithamildsoapandwaterora50/50solutionof

vinegar and water. Rinse with clean water and dry with a

soft cloth. When cleaning surfaces, make sure that they

are at room temperature and not in direct sunlight.

Spillage of marinades, fruit juices, tomato sauces and

basting liquids containing acids may cause discoloration

and should be wiped up as soon as hot surfaces cool,

then clean and rinse.

Oven Racks

All oven racks may be cleaned by hand with an abrasive

cleaner or steel wool.

After cleaning the racks, use a soft cloth or paper towel

to rub a small amount of vegetable oil on the left and

right edges of the rack. This will ensure the racks are

easy to slide in and out of the oven

Oven

49-2001026 Rev. 2 19

CARE AND CLEANING: Oven/CleaningtheGlassCooktop

Oven (Cont.)

Oven Heating Elements

Donotcleanthebakeelementorthebroilelement.Any

soil will burn off when the elements are heated.

To clean the oven floor, gently lift the bake element.

Clean the oven floor with warm, soapy water.

Gently lift the bake element

Cleaning the Glass Cooktop

Normal Daily Use Cleaning

To maintain and protect the surface of your glass cooktop,

follow these steps:

1. Beforeusingthecooktopforthefirsttime,cleanit

with a ceramic cooktop cleaner. This helps protect the

top and makes cleanup easier.

2. Regular use of ceramic cooktop cleaner will help keep

the cooktop looking new.

3. Shake the cleaning cream well. Apply a few drops of

ceramic cooktop cleaner directly to the cooktop.

4. Useapapertowelornon-scratchcleaningpadfor

ceramic cooktops to clean the entire cooktop surface.

5. Useadryclothorpapertoweltoremoveallcleaning

residue. No need to rinse..

NOTE:ItisveryimportantthatyouDONOTheatthe

cooktop until it has been cleaned thoroughly.

Burned-On Residue

NOTE:DAMAGEtoyourglasssurfacemayoccurifyou

use scrub pads other than those recommended.

1. Allow the cooktop to cool.

2. Spread a few drops of ceramic cooktop cleaner on

the entire burned residue area.

3. Usinganon-scratchcleaningpadforceramic

cooktops, rub the residue area, applying pressure as

needed.

4. If any residue remains, repeat the steps listed above

as needed.

5. For additional protection, after all residue has been

removed, polish the entire surface with ceramic

cooktop cleaner and a paper towel.

Useanon-scratchcleaningpadfor

ceramic cooktops

Clean your cooktop after each

spill.Useaceramiccooktop

cleaner.

For cleaning videos and

instructions, scan the QR code

with your device.

Ceramic

Cooktop

Cleaner

20 49-2001026 Rev. 2

CARE AND CLEANING: Cleaning the Glass Cooktop

Cleaning the Glass Cooktop (Cont.)

Metal Marks and Scratches

1. Becarefulnottoslidepotsandpansacrossyour

cooktop. It will leave metal markings on the cooktop

surface.

These marks are removable using the ceramic

cooktop cleaner with a non-scratch cleaning pad for

ceramic cooktops.

2. If pots with a thin overlay of aluminum or copper

are allowed to boil dry, the overlay may leave black

discoloration on the cooktop.

This should be removed immediately before heating

again or the discoloration may be permanent.

NOTE: Carefully check the bottom of pans for roughness

that would scratch the cooktop.

3. Becarefulnottoplacealuminumbakingsheetsor

aluminum frozen entrée containers on a hot cooktop

surface. It will leave shinny dots or markings on the

cooktop surface. These markings are permanent and

cannot be cleaned off.

Damage from Sugary Spills and Melted Plastic

Special care should be taken when removing hot substances to avoid permanent damage of the glass surface.

Sugaryspillovers(suchasjellies,fudge,candy,syrups)ormeltedplasticscancausepittingofthesurfaceofyour

cooktop(notcoveredbythewarranty)unlessthespillisremovedwhilestillhot.Specialcareshouldbetakenwhen

removing hot substances.

Besuretouseanew,sharprazorscraper.

Donotuseadullornickedblade.

1. Turn off all surface units. Remove hot pans.

2. Wearing an oven mitt:

  a.Useasingle-edgerazorbladescrapertomove

the spill to a cool area on the cooktop.

b. Remove the spill with paper towels.

3. Any remaining spillover should be left until the surface

of the cooktop has cooled.

4. Don’tusethesurfaceunitsagainuntilallofthe

residue has been completely removed.

NOTE: If pitting or indentation in the glass surface has

already occurred, the cooktop glass will have to be

replaced. In this case, service will be necessary.

Cooktop Seal

To clean the cooktop seal around the edges of the glass,

lay a wet cloth on it for a few minutes, then wipe clean

with nonabrasive cleaners.

Heavy, Burned-On Residue

1. Allow the cooktop to cool.

2. Useasingle-edgerazorbladescraperatapproximately

a 45° angle against the glass surface and scrape the

soil. It will be necessary to apply pressure to the razor

scraper in order to remove the residue.

3. After scraping with the razor scraper, spread a few

drops of ceramic cooktop cleaner on the entire burned

residuearea.Useanon-scratchcleaningpadto

remove any remaining residue.

4. For additional protection, after all residue has been

removed, polish the entire surface with ceramic cooktop

cleaner and a paper towel.

The ceramic cooktop scraper and all recommended

supplies are available through our Parts Center. See the

Accessories and Consumer Support sections at the end

of this manual.

NOTE:Donotuseadullornickedblade.

49-2001026 Rev. 2 21

Cleaning the Oven Door

Cleaning the Door Interior

Donotallowexcesswatertorunintoanyholesorslots

in the door .

Wipe dish soap over any baked-on spatters on the glass.

Useasinglesidedsafetyrazorbladetocleanitoff.Then

wipe over the glass with a soapy cloth to remove any

residue and dry off.

The area outside the gasket can be cleaned with a soap-

filledplasticscouringpad.Donotruborcleanthedoor

gasket - it has an extremely low resistance to abrasion.

If you notice the gasket becoming worn, frayed or

damaged in any way or if it has become displaced on the

door, you should have it replaced.

Cleaning the Door Exterior

If a stain on the door vent trim is persistent, use a mild

abrasive cleaner and a sponge-scrubber for best results.

Donotusethismethodonanyothersurface.

Stainless Steel Surfaces (on some models)

Donotuseasteelwoolpad;itwillscratchthesurface.

To clean the stainless steel surface, use warm sudsy

water or a stainless steel cleaner or polish. Always

wipe the surface in the direction of the grain. Follow

the cleaner instructions for cleaning the stainless steel

surface.

To inquire about purchasing cleaning products including

stainless steel appliance cleaner or polish, see the

Accessories and Consumer Support sections at the end

of this manual.

Door and Drawer

CARE AND CLEANING: DoorandDrawer/OvenLight

WARNING

SHOCK OR BURN HAZARD:Beforereplacingovenlightbulb,disconnecttheelectricalpowertothe

range at the main fuse or circuit breaker panel. Failure to do so may result in electric shock or burn.

CAUTION

BURN HAZARD: The glass cover and bulb should be removed when cool. Touching hot glass with

bare hands or a damp cloth can cause burns.

Oven Light

Removable Storage Drawer (on some models)

The storage drawer is a good place to store cookware

andbakeware.Donotstoreplasticsorflammable

material in the drawer.

The storage drawer may be removed for cleaning under

the range. Clean the storage drawer with a damp cloth or

sponge. Never use harsh abrasives or scouring pads.

Yourstoragedrawermayhaveplasticslides(shownto

theright)ormetalrails.Followtherespectiveremovaland

replacement instructions for your model’s configuration.

Removing the Storage Drawer:

1. Pull drawer straight out until it stops.

2. Continue to pull the drawer until it is detached from

the oven.

Replacing the Storage Drawer:

1. Rest the left drawer rail around the inner left rail guide

and slide it in slightly.

2. Place the right drawer rail around the inner right rail

guide and slide it in slightly.

2. Slide the drawer all the way in.

Oven Light Replacement

Besuretoletthelightcoverandbulbcoolcompletely.

To remove the cover:

1. Hold a hand under the cover so it doesn’t fall when

released. With fingers of the same hand, firmly push

back the wire cover holder. Lift off the cover.

 Donotremoveanyscrewstoremovethecover.

2. Replace bulb with a 40-watt appliance bulb.

To replace the cover:

1. Place it into groove of the light receptacle. Pull wire

forward to the center of the cover until it snaps into place.

2. Connect electrical power to the range.

Wire cover holder

22 49-2001026 Rev. 2

Oven Door

Thedoorisveryheavy.Becarefulwhenremovingandliftingthedoor.Donotliftdoorbythehandle.

To Remove the Door:

1. Fully open the door.

2. Pull the hinge locks up and away from the range

frame to the unlocked position.

3. Firmly grasp both sides of the door near the top.

4. Close door until the top of the door is approximately

6”fromtherangeframe.

5. Lift door up and away from the range until both hinge

arms are clear of the slots in the range frame.

To Replace the Door:

1. Firmly grasp both sides of the door near the top.

2. With the door at the same angle as the removal

position, rest the notch on the underside of the left

hinge arm on the bottom edge of the left hinge slot.

The notch in the hinge arm must be fully seated into

the bottom of the slot. Repeat for the right side.

3. Fully open the door. If the door will not fully open, the

notches in the bottoms of the hinge arms have not

seated correctly in the bottom edge of the slot. Lift the

door off the range and repeat previous step.

4. Push the hinge locks toward the range cavity and

down to the locked position.

5. Close the oven door.

CARE AND CLEANING:OvenDoor

Removal position

Pull hinge locks up to unlock

Push hinge locks down to lockRest notch on bottom edge

of hinge slot

Notch

Bottom

edge of

slot

Hinge arm

49-2001026 Rev. 2 23

Problem Possible Cause What To Do

Surface units will not

maintain a rolling boil

or cooking is not fast

enough

Improper cookware being used. Usepanswhichareflatandmatchthediameterofthe

surface unit selected.

Insomeareas,thepower(voltage)maybe

low.

Cover pan with a lid until desired heat is obtained.

Coil surface units do

not work properly

The surface units are not plugged in

solidly.

With the controls off, check to make sure the surface

unit is plugged completely into the receptacle.

The surface unit controls improperly set. Check to see the correct control is set for the surface

unit you are using.

The drip pans are not set securely in the

cooktop.

With the controls off, check to make sure the drip pan is

in the recess in the cooktop and that the opening in the

pan lines up with the receptacle.

A fuse in your home may be blown or the

circuit breaker tripped.

Replace the fuse or reset the circuit breaker.

Sensi-Temp Technology sensor cap is

overly soiled.

Clean Sensi-temp Technology sensor cap per cleaning

the range section.

Sensi-temp sensor cap stuck or will not

flex up and down.

Call a qualified technician for replacement. Replace coil

surface units with only the exact replacement part.

Surface units do not

work properly

A fuse in your home may be blown or the

circuit breaker tripped.

Replace the fuse or reset the circuit breaker.

Cooktop controls improperly set. Check to see the correct control is set for the surface

unit you are using.

Surface unit stops

glowing when turned

to a lower setting

The unit is still on and hot. This is normal.

Scratches (may appear

as cracks) on cooktop

glass surface

Incorrect cleaning methods being used. Scratches are not removable. Tiny scratches will

become less visible in time as a result of cleaning.

Cookware with rough bottoms being used

orcoarseparticles(saltorsand)were

between the cookware and the surface

of the cooktop. Cookware has been slid

across the cooktop surface.

To avoid scratches, use the recommended cleaning

procedures. Make sure bottoms of cookware are clean

before use, and use cookware with smooth bottoms.

Areas of discoloration

on the cooktop

Food spillovers not cleaned before next use.

See the Cleaning the glass cooktop section.

Hot surface on a model with a light-colored

cooktop.

This is normal. The surface may appear discolored

when it is hot. This is temporary and will disappear as

the glass cools.

Plastic melted to the

surface

Hot cooktop came into contact with plastic

placed on the hot cooktop.

SeetheGlasssurface—potentialforpermanentdamage

section in the Cleaning the glass cooktop section.

Pitting (or indentation)

of the cooktop

Hot sugar mixture spilled on the cooktop. Call a qualified technician for replacement.

Frequent cycling off

and on of surface units

Improper cookware being used. Useonlyflatcookwaretominimizecycling.

My new oven doesn't

cook like my old one.

Is something wrong

with the temperature

settings?

Your new oven has a different cooking

system from your old oven and therefore

may cook differently than your old oven.

For the first few uses, follow your recipe times and

temperatures carefully. If you still think your new oven

is too hot or too cold, you can adjust the temperature

yourself to meet your specific cooking preference.

NOTE:ThisadjustmentaffectsBaketemperatures;it

willnotaffectBroil.

Troubleshooting Tips ... Beforeyoucallforservice

Save time and money! Review the charts on the following pages first and you may not need to call for service.

TROUBLESHOOTING TIPS

24 49-2001026 Rev. 2

Troubleshooting Tips ... Beforeyoucallforservice

Problem Possible Cause What To Do

Food does not bake

properly

Oven controls improperly set. See the Cooking Modes section.

Rack position is incorrect or rack is not level. See the Cooking Modes section and Cooking Guide.

Incorrect cookware or cookware of improper

size being used.

See the Cookware section.

Oven temperature needs adjustment. See the Oven Controls section.

Ingredient substitution Substituting ingredients can change the recipe

outcome.

Food does not broil

properly

Oven controls improperly set. Make sure you select the appropriate broil mode.

Improper rack position being used. See Cooking Guide for rack location suggestions.

Food being cooked in a hot pan. Make sure cookware is cool.

Cookware not suited for broiling. Useapanspecificallydesignedforbroiling.

Aluminum foil used on the broiling pan and

grid has not been fitted properly and slit as

recommended.

If using aluminum foil conform to pan slits.

Insomeareasthepower(voltage)maybelow. Preheat the broil element for 10 minutes.

Oven temperature

too hot or too cold

Oven temperature needs adjustment. See the Oven Controls section or adjust the

thermostat.

Oven does not work

or appears not to

work

A fuse in your home may be blown or the

circuit breaker tripped.

Replace the fuse or reset the circuit breaker.

Oven controls improperly set. SeetheUsingtheOvensection.

Oven is in Sabbath Mode. Verify, that the oven is not in Sabbath Mode. See the

Oven Controls section.

“Crackling” or

“popping” sound

This is the sound of the metal heating and

cooling during both the cooking and cleaning

functions.

This is normal.

Why is my range

making a "clicking"

noise when using

my oven?

Your range cycles the heating elements by

turning relays on and off to maintain the oven

temperature.

This is normal.

Storage drawer

won’t close

Power cord may be obstructing drawer in the

lower back of the range.

Reposition the drawer and power cord. See the

StorageDrawerRemovalinstructionsintheCareand

cleaning of the range section.

Rear drawer support is on top of the guide rail. Repositionthedrawer.SeeDoorandDrawerinthe

Care and Cleaning section.

Oven door is

crooked

The door is out of position. Becausetheovendoorisremovable,itsometimes

gets out of position during installation. To straighten

the door, push down on the high corner.

Oven light does not

work

Light bulb is loose or defective. Tighten or replace bulb.

Switch operating light is broken. Call for service.

Excessive smoking

during broiling

Food too close to burner element. Lower the rack position of the food.

Strong odor An odor from the insulation around the inside

of the oven is normal for the first few times the

oven is used.

This is temporary and will go away after several uses

or a self-clean cycle.

My oven door glass

appears to be

"tinted" or have a

"rainbow" color. Is

this defective?

No. The inner oven glass is coated with a heat

barrier to reflect the heat back into the oven to

prevent heat loss and keep the outer door cool

while baking.

Thisisnormal.Undercertainlightorangles,youmay

see this tint or rainbow color.

TROUBLESHOOTING TIPS

49-2001026 Rev. 2 25

TROUBLESHOOTING TIPS

Troubleshooting Tips ... Beforeyoucallforservice

Problem Possible Cause What To Do

Sometimes the oven

takes longer to preheat

to the same temperature

Cookware or food in oven. The cookware or food in the oven will cause the

oven to take longer to preheat. Remove items to

reduce preheat time.

Number of racks in oven. Adding more racks to the oven will cause the oven

to take longer to preheat. Remove some racks.

Oven racks are difficult

to slide

The shiny, silver-colored racks were cleaned

in a self-clean cycle.

Apply a small amount of vegetable oil to a paper

towel and wipe the edges of the oven racks with

thepapertowel.DonotspraywithPam

or other

lubricant sprays.

Drawer does not slide

smoothly or drags

The drawer is out of alignment. Fully extend the drawer and push it all the way in

SeeDoorandDrawerintheCareandCleaning

section.

Drawerisover-loadedorloadisunbalanced. Reduce weight. Redistribute drawer contents.

Steam from the vent When using the ovens, it is normal to see

steam coming out of the oven vents. As the

number of racks or amount of food being

cooked increases, the amount of visible

steam will increase.

This is normal.

26 49-2001026 Rev. 2

Staple your receipt here. Proof of the original purchase

date is needed to obtain service under the warranty.

GEAppliances.com

All warranty service is provided by our Factory Service Centers, or an authorized Customer Care

technician. To

schedule service online, visit us at GEAppliances.com/service_and_support/, or call GE Appliances at 800.GE.CARES

(800.432.2737).Pleasehaveyourserialnumberandyourmodelnumberavailablewhencallingforservice.

Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE Appliances factory

service technician the ability to quickly diagnose any issues with your appliance and helps GE Appliances improve its

products by providing GE Appliances with information on your appliance. If you do not want your appliance data to be

sent to GE Appliances, please advise your technician not to submit the data to GE Appliances at the time of service.

What GE Appliances will not cover:

■ Service trips to your home to teach you how to use

the product.

■ Improperinstallation,deliveryormaintenance.

■ Failureoftheproductifitisabused,misused,

modified or used for other than the intended purpose

or used commercially.

■ Damagetotheglasscooktopcausedbyuseof

cleaners other than the recommended cleaning

creams and pads.

■ Damagetotheglasscooktopcausedbyhardenedspills

of sugary materials or melted plastic that are not cleaned

according to the directions in the Owner's Manual.

■ Replacementofhousefusesorresettingofcircuit

breakers.

■ Damagetotheproductcausedbyaccident,fire,

floods or acts of God.

■ Damagetofinish,suchassurfacerust,tarnish,orsmall

blemishes not reported within 48 hours of delivery.

■ Incidentalorconsequentialdamagecausedby

possible defects with this appliance.

■ Damagecausedafterdelivery.

■ Productnotaccessibletoproviderequiredservice.

■ Servicetorepairorreplacelightbulbs,exceptfor

LEDlamps.

■ ImmersingortamperingwiththeSensi-Temp

Technology coil surface units.

■ EffectiveJanuary1,2022,cosmeticdamagetothe

glass cooktop such as, but not limited to, chips,

scratches, or baked on residue not reported within 90

days of installation.

■ EffectiveJanuary1,2022,damagetotheglass

cooktop due to impact or misuse.

See example.

LIMITED WARRANTY

GE Appliances Electric Range Limited Warranty

EXCLUSION OF IMPLIED WARRANTIES

Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,

including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or

the shortest period allowed by law.

This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for

homeusewithintheUSA.IftheproductislocatedinanareawhereservicebyaGEAppliancesAuthorizedServicer

is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized

GE Appliances Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service

calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty

gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your

legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.

Warrantor: GE Appliances, a Haier company

Louisville, KY 40225

Extended Warranties: Purchase a GE Appliances extended warranty and learn about special discounts that are

available while your warranty is still in effect. You can purchase it online anytime at

GEAppliances.com/extended-warranty

or call 800.626.2224 during normal business hours. GE Appliances Service will still be there after your warranty expires.

For the period of GE Appliances will replace

One year

From the date

of the original

purchase

Any partoftherangewhichfailsduetoadefectinmaterialsorworkmanship.Duringthis

limited one-year warranty, GE Appliances will provide, free of charge, all labor and in-home

service to replace the defective part.

49-2001026 Rev. 2 27

Looking For Something More?

GE Appliances offers a variety of accessories to

improve your cooking and maintenance experiences!

Refer to the Consumer Support page for phone numbers

and website information.

The following products and more are available:

Accessories

 SmallBroilerPan(8¾”x1¼”x13½”)

Parts

Oven racks

Oven burners

Light bulbs

Cleaning Supplies

CitruShine™ Stainless Steel Wipes

Stainless Steel Appliance Cleaner

Cleaning Pads for Ceramic Cooktops

Ceramic Cooktop Cleaner

Ceramic Cooktop Scraper

 Kit(Kitincludescreamandcooktopscraper)

Graphite Lubricant

Accessories

ACCESSORIES

28 49-2001026 Rev. 2

Consumer Support

CONSUMER SUPPORT

GE Appliances Website

Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day

of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support

servicesdesignedforyourconvenience.IntheUS:GEAppliances.com

communication and prompt service under the terms of your warranty, should the need arise. You may also mail in

thepre-printedregistrationcardincludedinthepackingmaterial.IntheUS:GEAppliances.com/register

Schedule Service

Expert GE Appliances repair service is only one step away from your door. Get on-line and schedule your service at

yourconvenienceanydayoftheyear.IntheUS:GEAppliances.com/service

or call 800.432.2737 during normal business hours.

Extended Warranties

Purchase a GE Appliances extended warranty and learn about special discounts that are available while your

warranty is still in effect. You can purchase it on-line anytime. GE Appliances Services will still be there after your

warrantyexpires.IntheUS:GEAppliances.com/extended-warranty

or call 800.626.2224 during normal business hours.

Remote Connectivity

Forassistancewithwirelessnetworkconnectivity(formodelswithremoteenable),

visit our website at GEAppliances.com/connect orcall800.220.6899intheUS.

Parts and Accessories

Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes

(VISA,MasterCardandDiscovercardsareaccepted).Orderon-linetoday24hourseveryday.

IntheUS:GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.

Instructions contained in this manual cover procedures to be performed by any user. Other servicing

generally should be referred to qualified service personnel. Caution must be exercised, since improper

servicing may cause unsafe operation.

If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the

details including your phone number, or write to:

IntheUS:GeneralManager,CustomerRelations|GEAppliances,AppliancePark|Louisville,KY40225

GEAppliances.com/contact

GE - General Electric RAS240DMWW Hotpoint 24" Electric Free-Standing Front-Control Range

Product's Documents

User Manual

Specifications

GE - General Electric RAS240DMWW Questions and Answers
