Operating Instructions
PMR1300 80 Channel UHF 2 Way
Citizen Band Radio
Keep this user guide for future reference.
Always retain your proof of purchase in case warranty
service is required.
www.oricom.com.au
Need Help?
If you need assistance setting up or using your Oricom
product now or in the future, call Oricom Support.
Australia 02 4574 8888
www.oricom.com.au
Mon-Fri 8am – 6pm AEST
New Zealand 0800 67 42 66
www.oricom.co.nz
Mon-Fri 10am – 8pm NZST
3
Table of contents
Safety Information and Warnings ................... 4
Getting Started ............................................ 11
Oricom PMR1300 instructions...................... 16
Operation ..................................................... 18
Channel Frequency Table ............................. 27
Troubleshooting guide .................................. 30
Customer Support ........................................ 31
Express Warranty (Australia) ........................ 32
This unit complies with all relevant Australian and New Zealand
approval requirements AS/NZS 4365:2011 including radio
communications (Electromagnetic Radiation Human Exposure)
standard 2003.
When a narrowband radio receives a transmission from an older wideband radio
the speech may sound loud and distorted – simply adjust your radio volume for
the best listening performance. When an older wideband radio receives a signal
from a new narrowband radio the speech may sound quieter - simply adjust your
radio volume for best listening performance. When operating a narrowband radio
or Channel 41 - 80 interference is possible from wideband radios transmitting on
high power or on adjacent frequency.
The issues described above are not a fault of the radio but a consequence of
mixed use of wideband and narrowband radios.
4
Safety Information and Warnings
Safety Information and Warnings
WARNING
Information on Safe Operation
Read This Information Before Using Your
Oricom Radio.
The operation of your UHF radio in Australia
and New Zealand is subject to conditions
in the following licenses:
In Australia, the ACMA Radio communications
(Citizen Band Radio Stations) and in New
Zealand by MED the General User Radio
License for Citizen Band Radio.
Radio Antenna
Do not use any radio that has a damaged
antenna. If a damaged antenna comes in
contact with the skin, a minor burn may
result.
Unauthorized antennas, modifications, or
attachments could damage the radio and
violate compliance. Do NOT change or
modify the antenna.
Do NOT hold the antenna when the radio
is “IN USE.” Holding the antenna reduces
range and may cause bodily harm.
Safety and general use whilst in a
vehicle
Check the State and Federal laws and
regulations regarding the use of two way
radios in the area where you drive, and
always obey them.
5
Safety Information and Warnings
WARNING
For Vehicles tted with Air Bags
Do not place your radio in the area over
an air bag or in the air bag deployment
area. Air bags inate with great force. If a
radio is placed in the air bag deployment
area and the air bag inflates, the radio
may be propelled with great force and
cause serious injury to the occupants of
the vehicle.
Read all these Safety Warnings before
you install batteries.
• Do not dispose of the batteries in a re
as they may explode.
• Exercise extreme care when handling
batteries in order not to short the
battery with conducting materials such
as rings, bracelets and keys. The battery
or conduction material may overheat
explode and or cause burns.
• Never replace batteries in a potentially
explosive atmosphere (such as where
gas is leaking) as contact sparking
may occur while installing or removing
the batteries and cause a fire or an
explosion.
• Do not modify, cut, disassemble, crush,
bend, puncture, heat or damage the
batteries
.
6
WARNING
• If batteries leak, do not let the battery
liquid touch skin or eyes. If this
happens, immediately ush the affected
areas with water, and seek medical
assistance. Released electrolyte is
corrosive and may cause damage to
the eyes and skin. It may be toxic if
swallowed.
• Do not immerse or expose the batteries
to water or other liquids.
• Never use damaged batteries as they
may explode.
• Remove batteries when they are no
longer able to hold a charge and when
the equipment will not be used for an
extended period of time.
• Dispose of batteries according to local
regulations, never in your household
rubbish.
WARNING:
Risk of explosion if battery is replaced by
an incorrect type.
Potentially Explosive Atmospheres
Turn your radio OFF when in any area with
a potentially explosive atmosphere. Sparks
in such areas could cause an explosion or
re resulting in injury or even death.
Safety Information and Warnings
7
WARNING
NOTE: Areas with potentially explosive
atmospheres are often, but not always
clearly marked. They include fueling
areas such as below deck on boats; fuel
or chemical transfer or storage facilities;
areas where the air contains chemicals
or particles, such as grain, dust, or metal
powders; and any other area where you
would normally be advised to turn off your
vehicle engine.
Blasting Caps and Areas
To avoid possible interference with
blasting operations, turn your radio OFF
near electrical blasting caps or in a
“blasting area” or in areas posted: “Turn
off the two way radio.” Obey all signs and
instructions.
Exposure to Radio Frequency Energy
Your Oricom two-way radio complies with
Australian Communications Authority
Radio communications (Electromagnetic
Radiation-Human Exposure) Standard,
2003.
To assure optimal radio performance
and make sure human exposure to radio
frequency electromagnetic energy is
within the guidelines set out in the above
standards always adhere to the following
procedures.
Safety Information and Warnings
8
WARNING
Transmit and Receive Procedure
Your two-way radio contains a transmitter
and a receiver. To control your exposure
and ensure compliance with the general
population/uncontrolled environment
exposure limits, always adhere to the
following procedure:
• Transmit no more than 50% of the time.
• To receive calls, release the PTT button.
• To transmit (talk), press the Push to Talk
(PTT) button.
Transmitting 50% of the time, or less, is
important because the radio generates
measurable RF energy exposure only
when transmitting (in terms of measuring
standards compliance).
Always hold the radio approximately 5cm
in front of your mouth with the antenna
pointing away from your head.
Radio Operation and EME Exposure
Unauthorized antennas, modifications, or
attachments could damage the radio and
violate compliance.
Do NOT hold the antenna when the radio
is “IN USE.” Holding the antenna reduces
the effective range.
Do not use the radio if the antenna is
damaged. If a damaged antenna makes
contact with your skin, a minor burn can
result.
Safety Information and Warnings
9
WARNING
If you wear a radio on your body when
transmitting, always fit the radio on the
belt clip (supplied). Always ensure the
radio and it's antenna are at least 5cm
from your body when transmitting.
Electromagnetic Interference/
Compatibility
Nearly every electronic device is susceptible
to electromagnetic interference (EMI). To
avoid the possibility of electromagnetic
interference and/or compatibility conicts,
turn off your radio in any location where
posted notices instruct you to do so such
as health care facilities.
Aircraft
When instructed to do so, turn off your
radio when onboard an aircraft. Any use
of a radio must be in accordance with
applicable regulations per airline crew
instructions.
Medical Devices - Pacemakers
The Advanced Medical Technology
Association recommends that a
minimum separation of 6 inches (15cm)
be maintained between a handheld
wireless radio and a pacemaker. These
recommendations are consistent with
the independent research by and
recommendations of the U.S. Food and
Drug Administration.
Safety Information and Warnings
10
WARNING
People with pacemakers should:
• ALWAYS keep the radio more than
15cm from their pacemaker when the
radio is turned ON.
• Not carry the radio in the breast pocket.
• Use the ear opposite the pacemaker to
minimize the potential for interference.
• Turn the radio OFF immediately if
there is any reason to suspect that
interference is taking place.
Medical Devices - Hearing Aids
Some radios may interfere with some
hearing aids.
In the event of such interference, you
may want to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical
device, consult the manufacturer of your
device to determine if it is adequately
shielded from RF energy. Your physician
may be able to assist you in obtaining this
information.
General warnings
Never use your radio outdoors during a
thunderstorm.
Keep the radio out of reach of babies and
young children.
Safety Information and Warnings
11
Installing/Removing Belt Clip
Installing Belt Clip
Slide the Belt clip into the slot as shown in Figure 1.
A “click” indicates the Belt
Clip is locked into position.
Removing Belt Clip
Pull the belt clip latch
back.
While pulling the belt clip
latch, push up the belt clip
as shown in Figure 2.
Installing Batteries
Lift the battery cover
lock to open it. Then
remove the battery
cover.
Install the rechargeable
batteries by following
the orientation as shown
in Figure 3.
Replace the Battery
compartment cover and
lock it correctly.
Figure 1 Figure 2
Figure 3
Getting Started
12
Getting Started
WARNING
• Follow the polar directions and insert 4 x AAA Ni-MH
rechargeable batteries.
• Incorrect positioning can damage both the batteries
and unit.
• Don’t try to recharge non-rechargeable batteries.
• Make sure the battery compartment cover is
securely locked in place when you are charging the
batteries.
• Dispose of used batteries safely and in a way that
will not harm the environment, never try to burn
them or put them anywhere, they could get burnt or
punctured.
• Don’t leave dead batteries in you unit. They might
leak if you do.
CHARGING BATTERIES
When the “Battery level ” icon is low, you need to
charge the battery with the included AC/DC adaptor.
CHARGING WITH AC Adaptor
Charging directly with AC adaptor, please make sure
the radio is off before charging.
Plug the adaptor into the wall socket and the other
end into the radio earphone / charging jack.
13
Getting Started
The LCD Icon will ash.
Note: If you forget to turn off the
radio, the radio will automatically
turn off during charging. After
charging, you must turn it off
again and wait few seconds then
turn it on.
2 radios can be charged at the
same time.
Charge time for a full charge
requires about 8 ~ 10 hours.
After charging, unplug the adaptor
from the socket.
WARNING
• To avoid damage to the radio use only original
accessories.
• The radio will be slightly warm during charging.
Transmitting Range
The talk range depends on the environment and
terrain. In general the radio can reach further in wide
open spaces, without obstructions such as hills or
buildings. Range is affected by concrete structures,
heavy foliage and by operating radios indoors or in
vehicles. Don’t try to use two radio units which are
less than 1.5m (5 feet) apart. Otherwise, you may
experience interference.
Figure 4
14
Getting Started
Optimal Range
Outdoors
Flat, open areas
Medium Range
Outdoors
Buildings or trees
Also near residential
buildings
Minimal Range
Outdoors
Dense foliage or
mountains. Also inside
some buildings
PMR1300 Pack Contents:
2 x PMR1300 UHF CB Radios
1 x AC Adaptor
8 x AAA 600mA Ni-MH Rechargeable Batteries
2 x Belt Clips
15
Oricom PMR1300 Accessories
The following Oricom PMR1300 accessories can be
purchased directly from Oricom. Visit www.oricom.com.au
or call (02) 4574 8888.
Part No. Description
2U0181 Batteries
2U0200 AC Adaptor twin cable
2U0199 Belt clip
2U0179 Ear bud MIC
2U0175 Speaker MIC
2U0178 Car charger
FOR A FULL LIST OF CURRENT PARTS AND
ACCESSORIES VISIT www.oricom.com.au
Getting Started
16
Oricom PMR1300 2-Way CB Radio
1. LCD
2. Earphone & Charger
Jack
3. Up key
4. Power On/Off/
5. Scan / Monitor key
6. Microphone
7. Antenna
8. PTT key
9. Menu / Key lock key
10. Call Tone key
11. Down key
12. Speaker
Oricom PMR1300 instructions
17
Oricom PMR1300 instructions
LCD DISPLAY ICONS
1. TX
2. RX
3. Dual Watch
4. VOX
5. Repeater
6. Battery Level
7. DCS
8. Code for CTCSS/DCS
9. CTCSS
10. Scan
11. Call Tone
12. Key Lock
13. Volume Level
14. Main Channel Digits
18
Operation
Operation
POWER ON/OFF
To Power ON;
To power On the radio, press Power On/Off Key
for 2
seconds until a beep is heard and the LCD display turns on.
To Power OFF;
To power Off the radio, press Power On/Off key
for 2
seconds until LCD display turns off.
Adjust Volume Level (6 levels)
Press the Up key
▲
to increase the volume.
Press the Down key
▼
to decrease the volume.
Changing Channels
To select the main channel
Press the MENU key once, Main channel number
displayed will ash.
Press
▲
or
▼
key to select your desired main
channel number.
Press the PTT key to conrm and quit or press MENU
to continue next function setting. LCD will display the
channel frequency.
Press the PTT key to conrm and quit or press MENU
to continue to the next function setting.
You have 10 seconds to decide before auto-reverting
back to the main screen.
19
Operation
Key Lock
Press and hold key for 3 seconds, LCD display
icon.
All keys are locked except PTT and
key.
To unlock, press and hold
key for 3 second again.
Scanning Channels
Press the SC/MON key once and LCD will display
and radio will start scanning.
LCD display shows the scanning channel one by one.
It will stop at those channels with signal for a while.
Note: Please aware that the scanning will stop at those
channels with the same CTCSS / DCS as your radio
setting only.
Press
▲
or
▼
key to continue scanning.
Or if you want to use this channel, press PTT to
conrm and your radio will stay on this channel.
If there is no signal, it will continue to scan. Press
SCAN key or PTT to exit Scan function and return to
preset Channel.
Monitor
Press and hold SC/MON key to break the squelch
noise and open (un-squelch) the frequency for monitor
function. Release the SC/MON key to stop.
20
Operation
Transmitting and Receiving
The radio has 75 main frequencies and 38 CTCSS
codes or 83 DCS codes. You can communicate with
any other user who is using the same combinations,
providing they are within range.
To transmit, press & hold the PTT key, LCD displays
TX icon indicating the radio is transmitting.
Hold the radio in a vertical position with the
microphone 3-5 cm from your mouth and then speak.
When you nish speaking, release the PTT key.
The radio will automatically sound the received signal
from the other radio on the same channel, the LCD will
display the receive icon
.
The transmission is SIMPLEX “one way at-a-time.”
While you are speaking, you can not receive a
transmission.
Adjust volume control if necessary.
RPT ON/OFF information
If a Repeater channel is selected, press MENU key
once, then use
▲
or
▼
button to turn on or off.
PLEASE NOTE: if the selected channel is not a
repeater channel, this feature is not available and all
other menu features will require 1 button push less to
select that feature.
21
Operation
CTCSS/DCS Sub-code Function
This function can help you to select your group
(38 CTCSS codes/or 83 DCS codes) of users on the
same channel. Only the users with the same CTCSS/
DCS code can listen and talk to each other. Please
note that selecting a CTCSS/DCS code does not
assure total privacy. In radio communication, any UHF
CB radios can listen to all communications on the
same channel when using the default standard setting
with CTCSS/DCS = 0 (OFF).
CTCSS Code
Press Menu key MENU twice, the current CTCSS
sub-channel number ashes on the LCD Screen.
Press the
▲
or
▼
button to select one of the 38
CTCSS sub-channels.
Press the PTT key to conrm and quit or press MENU
to continue next function setting.
DCS Code
Each channel also has 83 digital codes to let you set
up group of users for more private communication.
Press Menu key MENU 3 times, the DCS code will
ash on the LCD Screen.
Press the
▲
or
▼
button to select the desired DCS
code.
Press the PTT key to conrm and quit or press MENU
to continue next function setting.
22
Operation
IMPORTANT
The unit will use the last codes either CTCSS or DCS
being selected and conrmed.
Dual Watch
The unit has dual watch function. You can monitor
two channels, the current and another (dual watch)
channel. If the unit detects a signal on either channel,
it will stop and receive the signal.
Press the MENU key 4 times, The CH icon will start
ashing.
Press
▲
or
▼
key to select the dual watch channel
(1-80, except the current channel), LCD will display OF
if DW is turned OFF.
When DW is on, LCD will display
icon.
Press the PTT key to conrm and quit or press MENU
to continue next function setting.
VOX (Hands-Free Function)
The unit has a built-in Voice Activated Circuit (VOX)
function. You can enjoy talking and listening without
pressing PTT key.
The level of VOX sensitivity is shown by a number on
the LCD Screen. At the highest level, the units will pick
up softer noise (including background noise); and the
lowest level, will pick up only loud noise.
Press the MENU key 5 times, LCD will display
icon and VOX sensitivity digit will ash.
23
Operation
Press
▲
or
▼
key to select sensitivity level “OF, 1, 2,
3” for “OFF, Low, Medium and High respectively.
After turning on the VOX function, LCD will display
icon.
Press the PTT key to conrm and quit or press MENU
to continue next function setting.
Please speak close to the mic in order to activate VOX
function.
Note: VOX operation is not recommended if the radio
will be used in a noisy or windy environment.
Call Tone
You can use 1 of 10 different “Call Tones” to get
attention of other user on the same channel.
Press the
key, while your call tone is transmitted.
The tone will sound, LCD will display the transmit
and icons.
To select a call tone
Press the MENU key 6 times, LCD displays icon and
call tone number will ash.
Press
▲
or
▼
key to select your desired call tone.
Press the PTT key to conrm and quit or press MENU
to continue next function setting.
Key Tone
This feature allows the radio to emit a conrmation
tone after pressing each button.
Press MENU key 7 times, LCD displays “t o”.
24
Operation
Press
▲
or
▼
key to select the Key Tone On/Off.
Press PTT to conrm and quit or press MENU to
continue next function setting.
Roger Beep
The Roger Beep is a tone which is automatically
transmitted whenever the PTT button is released.
Press MENU key 8 times, LCD display “r o”.
Press
▲
or
▼
key to select the Roger beep On/Off.
Press PTT to conrm and quit or press MENU to
continue next function setting.
Reset the unit
Turn off the radio.
Press and hold the PTT and Scan key.
Turn on the radio.
Microphone/Earphone Jack
The unit is equipped with a microphone/Earphone
jack located at the right side. You can use an optional
earphone (not included) for handsfree function.
25
Operation
Duplex operation via Repeaters
This feature allows you to use local repeater stations
that are designed to automatically re-transmit your
broadcast over a large area thus giving you increased
range.
Repeater stations are privately operated radio systems
installed throughout Australia.
For example, if you wish to access a repeater station
in your area which operates on channel 2, you need to
set the Duplex access on this Channel.
When you have turned on the Duplex setting in the
menu for the selected channel (and you are within
range of a local repeater), your radio will automatically
transmit to the repeater on channel 32.
Turning on/off Duplex on channels
a. Select the required channel to suit the repeater
station you wish to access (Channels 1~8 and
41 ~ 48)
b. Press the MENU key once, “RPT” icon will display.
c. Press the Up or Down key to set the Repeater
function to ON or OFF.
d. Press the PTT key to conrm your setting.
e. The RPT icon will display to indicate that Repeater
function is set on that channel.
26
Operation
Receive Channel 1 2 3 4 5* 6 7 8
Transmit channel 31 32 33 34 35* 36 37 38
Receive Channel 41 42 43 44 45 46 47 48
Transmit channel 71 72 73 74 75 76 77 78
* Channel 5 is emergency channel only
Channel 2
Channel 32
Channel 2
Channel 32
Repeater Station
27
Channel Frequency Table
Channel Frequency Table
Radiocommunications (Citizen Band Radio
Stations) Class Licence 2002
No licence is required to own or operate this radio in
Australia and New Zealand. The Radiocommunications
(Citizen Band Radio Stations) Class Licence 2002
contains the technical parameters, operating requirements,
conditions of licence and relevant standards for Citizen
Band (CB) radios. CB radios must comply with the class
licence for their use to be authorised under the class
licence.
UHF channels and frequencies
IMPORTANT NOTE: The operation of your UHF radio in
Australia and New Zealand is subject to conditions in
the following licenses:
In Australia the ACMA Radio communications (Citizen
Band Radio Stations) and in New Zealand by MED the
General User Radio License for Citizen Band Radio.
28
Channel Frequency Table
EMC Technologies (NZ) Ltd
Test Report No 101127.1
Report date: 25
th
November 2010
6.2 Nominal Carrier
Table 1 Nominal Carrier Frequency
Channel
Tx Rx
Channel
Tx Rx
Freq Freq Freq Freq
MHZ MHz MHz MHz
01* 476.4250 476.4250 21 476.9250 476.9250
41* - 476.4375 61‡ — —
02* 476.4500 476.4500 22† 476.9500 476.9500
42* - 476.4625 62‡ — —
03* 476.4750 476.4750 23† 476.9750 476.9750
43* - 476.4875 63‡ — —
04* 476.5000 476.5000 24 477.0000 477.0000
44* - 476.5125 64 477.0125 477.0125
05* 476.5250 476.5250 25 477.0250 477.0250
45* - 476.5375 65 477.0375 477.0375
06* 476.5500 476.5500 26 477.0500 477.0500
46* - 476.5625 66 477.0625 477.0625
07* 476.5750 476.5750 27 477.0750 477.0750
47* - 476.5875 67 477.0875 477.0875
08* 476.6000 476.6000 28 477.1000 477.1000
48* - 476.6125 68 477.1125 477.1125
9 476.6250 476.6250 29 477.1250 477.1250
49 476.6375 476.6375 69 477.1375 477.1375
10 476.6500 476.6500 30 477.1500 477.1500
50 476.6625 476.6625 70 477.1625 477.1625
11 476.6750 476.6750 31* 477.1750 477.1750
51 476.6875 476.6875 71* 477.1875 -
12 476.7000 476.7000 32* 477.2000 477.2000
52 476.7125 476.7125 72* 477.2125 -
13 476.7250 476.7250 33* 477.2250 477.2250
53 476.7375 476.7375 73* 477.2375 -
14 476.7500 476.7500 34* 477.2500 477.2500
54 476.7625 476.7625 74* 477.2625 -
15 476.7750 476.7750 35* 477.2750 477.2750
55 476.7875 476.7875 75* 477.2875 -
16 476.8000 476.8000 36* 477.3000 477.3000
56 476.8125 476.8125 76* 477.3125 -
17 476.8250 476.8250 37* 477.3250 477.3250
57 476.8375 476.8375 77* 477.3375 -
18 476.8500 476.8500 38* 477.3500 477.3500
58 476.8625 476.8625 78* 477.3625 -
19 476.8750 476.8750 39 477.3750 477.3750
59 476.8875 476.8875 79 477.3875 477.3875
20 476.9000 476.9000 40 477.4000 477.4000
60 476.9125 476.9125 80 477.4125 477.4125
* The primary use for these channels is repeater operation using 750 kHz offset. Channels 1-8
inclusive are used for mobile reception and channels 31-38 for mobile transmission. They may also
_________________________________ ____________________________________________________________________________________________________________________
EMC Technologies (NZ) Ltd
STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, NZ Phone: +64 9 360 0862 Fax: +64 9 360 0861
POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand E-mail: aucklab@ihug.co.nz
Page 11 of 23 This report may not be reproduced except in full
EMC Technologies (NZ) Ltd
Test Report No 101127.1
Report date: 25
th
November 2010
6.2 Nominal Carrier
Table 1 Nominal Carrier Frequency
Channel
Tx Rx
Channel
Tx Rx
Freq Freq Freq Freq
MHZ MHz MHz MHz
01* 476.4250 476.4250 21 476.9250 476.9250
41* - 476.4375 61‡ — —
02* 476.4500 476.4500 22† 476.9500 476.9500
42* - 476.4625 62‡ — —
03* 476.4750 476.4750 23† 476.9750 476.9750
43* - 476.4875 63‡ — —
04* 476.5000 476.5000 24 477.0000 477.0000
44* - 476.5125 64 477.0125 477.0125
05* 476.5250 476.5250 25 477.0250 477.0250
45* - 476.5375 65 477.0375 477.0375
06* 476.5500 476.5500 26 477.0500 477.0500
46* - 476.5625 66 477.0625 477.0625
07* 476.5750 476.5750 27 477.0750 477.0750
47* - 476.5875 67 477.0875 477.0875
08* 476.6000 476.6000 28 477.1000 477.1000
48* - 476.6125 68 477.1125 477.1125
9 476.6250 476.6250 29 477.1250 477.1250
49 476.6375 476.6375 69 477.1375 477.1375
10 476.6500 476.6500 30 477.1500 477.1500
50 476.6625 476.6625 70 477.1625 477.1625
11 476.6750 476.6750 31* 477.1750 477.1750
51 476.6875 476.6875 71* 477.1875 -
12 476.7000 476.7000 32* 477.2000 477.2000
52 476.7125 476.7125 72* 477.2125 -
13 476.7250 476.7250 33* 477.2250 477.2250
53 476.7375 476.7375 73* 477.2375 -
14 476.7500 476.7500 34* 477.2500 477.2500
54 476.7625 476.7625 74* 477.2625 -
15 476.7750 476.7750 35* 477.2750 477.2750
55 476.7875 476.7875 75* 477.2875 -
16 476.8000 476.8000 36* 477.3000 477.3000
56 476.8125 476.8125 76* 477.3125 -
17 476.8250 476.8250 37* 477.3250 477.3250
57 476.8375 476.8375 77* 477.3375 -
18 476.8500 476.8500 38* 477.3500 477.3500
58 476.8625 476.8625 78* 477.3625 -
19 476.8750 476.8750 39 477.3750 477.3750
59 476.8875 476.8875 79 477.3875 477.3875
20 476.9000 476.9000 40 477.4000 477.4000
60 476.9125 476.9125 80 477.4125 477.4125
* The primary use for these channels is repeater operation using 750 kHz offset. Channels 1-8
inclusive are used for mobile reception and channels 31-38 for mobile transmission. They may also
_________________________________ ____________________________________________________________________________________________________________________
EMC Technologies (NZ) Ltd
STREET ADDRESS - 47 MacKelvie Street, Grey Lynn, Auckland, NZ Phone: +64 9 360 0862 Fax: +64 9 360 0861
POSTAL ADDRESS - PO Box 68 307, Newton, Auckland, New Zealand E-mail: aucklab@ihug.co.nz
Page 11 of 23 This report may not be reproduced except in full
29
Channel Frequency Table
* The primary use for these channels is repeater operation
using 750 kHz offset. Channels 1-8 and 41-48 inclusive
are used for mobile reception and channels 31-38 and
71-78 for mobile transmission. In addition, any designated
repeater channel may be used for simplex operation in
areas where it is not used for repeater operation.
† Speech telephony shall be inhibited on these channels.
‡ At the time of production, Channels 61, 62 and 63 are
guard channels and are not available for use.
Channel 5 and 35 (paired for Duplex repeaters) are reserved
as emergency channels and should be used only in an
emergency.
CTCSS and DCS will not operate on channels 5 and 35.
A list of currently authorised channels can be obtained from
the ACMA website in Australia and the MED website in New
Zealand. Channel 11 is a calling channel generally used to
call others and channel 40 is the customary road vehicle
channel.
Once contact is established on the calling channel, both
stations should move to another unused “SIMPLEX” channel
to allow others to use the calling channel.
Channels 22 and 23 are for Telemetry and Telecommand
use, voice communications are not allowed on these
channels by law.
Channel 9 and above are the best choices for general use in
Simplex mode.
30
Troubleshooting guide
TROUBLE SHOOTING GUIDE
PROBLEM GUIDE
No power or radio
switches off after a
short time
1: Check charger and
batteries are installed
correctly.
2: Clean battery contacts
(Important!).
3: Replace batteries with fully
charged or new batteries.
4: Battery capacity poor:
battery defective or at end
of life, replace batteries.
I cannot
communicate
with other group
members
1: Verify, that the channel
frequency and the CTCSS
settings are the same on all
radios.
2: The other group members
are not within radio
coverage.
Audio cutting in and
out at receivers end.
1: Too weak signal-too far away.
2: External mic defective?
Please contact Oricom
Support.
Too many
transmissions heard
on my channel.
1: Another group is using
the same channel number
-change channel
31
Customer Support
Customer Support
If you have any problems setting up or using this
product, you will nd useful tips and information in
the Troubleshooting section of this user guide as
well as “Frequently Asked Questions” on our website
www.oricom.com.au.
If you have further questions about using the product after
reviewing the resources above or would like to purchase
replacement parts or accessories, please call our Customer
Support Team.
Important
Please retain your purchase receipt and attach to the back
page of this user guide as you will need to produce this if
warranty service is required.
32
Express Warranty (Australia)
Express Warranty (Australia)
This Express Warranty is provided by Oricom International
Pty Ltd ABN 46 086 116 369, Unit 1, 4 Sovereign Place,
South Windsor NSW 2756, herein after referred to as
“Oricom”.
Oricom warrants that the product is free from defects in
materials or workmanship during the Express Warranty
Period. This Express Warranty does not extend to any
product from which the serial number has been removed
or was purchased outside of Australia.
The benefits of this Express Warranty are in addition
to other rights and remedies you may have under
the Australian Consumer Law. Our goods come with
guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not
amount to a major failure. In the event of a minor failure,
Oricom reserves the right to choose to repair or replace the
product.
The Express Warranty Period will be a period of 3 years
beginning on the date of purchase of the product evidenced
33
Express Warranty (Australia)
by your dated sales receipt. You are required to provide
proof of purchase as a condition of receiving Express
Warranty services.
You are entitled to a replacement product or repair of
the product at our discretion according to the terms and
conditions of this document if your product is found to be
faulty within the Express Warranty Period. This Express
Warranty extends to the original purchaser only and is not
transferable.
Products distributed by Oricom are manufactured using
new materials or new and used materials equivalent to
new in performance and reliability. Spare parts may be
new or equivalent to new. Spare parts are warranted to
be free from defects in material or workmanship for thirty
(30) days or for the remainder of the Express Warranty
Period of the Oricom branded product in which they are
installed, whichever is longer. During the Express Warranty
Period, Oricom will where possible repair and if not replace
the faulty product or part thereof. All component parts
removed under this Express Warranty become the property
of Oricom. In the unlikely event that your Oricom product
has a recurring failure, Oricom may always, subject to the
Competition and Consumer Act 2010, at its discretion, elect
to provide you with a replacement product of its choosing
that is at least equivalent to your product in performance.
34
Express Warranty (Australia)
No change to the conditions of this Express Warranty
is valid unless it is made in writing and signed by an
authorised representative of Oricom.
Oricom will not be liable under this Express Warranty,
and to the extent permitted by law will not be liable for
any defect, loss, damage or injury arising out of or in
connection with a:
1. Failure by you to adhere to the warnings and follow the
instructions set out in this user guide for the proper
installation and use of the product;
2. Willful misconduct or deliberate misuse by you of the
product;
3. Any external cause beyond our control, including but
not limited to power failure, lightning or over voltage;
or
4. Modication to the product or services carried out on
the product by anyone other than Oricom or Oricom’s
authorised service provider.
How to make a claim under your Express
Warranty in Australia
Oricom has a simple warranty process for you to follow:
• Please call or email our Customer Support Team,
02 4574 8888 or [email protected].
• A Customer Support Team member will verify after
troubleshooting with you if your product qualies under
warranty. If so, they will give you a Product Return
Authorisation number.
35
Express Warranty (Australia)
• We will then email a Return Authorisation form and a
Repair Notice (if necessary), together with instructions
on how to return the product for warranty service.
Please note that if a Customer Support Team member
advises that your product does not qualify for return, this
warranty does not apply to your product. Products that
are authorised to be returned to Oricom in Australia must
include all of the following:
• A completed Return Authorisation form
• A copy of your Proof of Purchase (please keep your
original copy)
• The faulty product, including all accessories.
Send the approved returns to:
Oricom International Pty Ltd
Locked Bag 658
South Windsor NSW 2756 Australia
Please note that this Express Warranty excludes expenses
incurred by you in returning any faulty product to us. You
must arrange and pay any expenses incurred (including
postage, delivery, freight, transportation or insurance of the
product) to return the faulty product to us, however, we will
arrange delivery of the repaired or replaced faulty product
to you.
36
Express Warranty (Australia)
Important Information
Repair Notice
Please be aware that the repair of your products may
result in the loss of any user-generated data (such as
stored telephone numbers, text messages and contact
information). Please ensure that you have made a copy of
any data saved on your product before sending for repair.
Please also be aware that products presented for repair
may be replaced by refurbished products or parts of the
same type rather than being repaired.
