• As this product undergoes a functional test, a small amount of water may remain in the product.
• Store the user manual in an easily reachable place for later use.
• Please read 'Safety Instructions' carefully before use.
※ mini is the world's first wall-mounted front-load washer developed by WINIADAEWOO.
Wall-Mounted Front Load Washer
DWD-M221MB
미니_DWD-M221MB(영)_호주향_1도.indd 1 2020-08-10 오후 4:55:57
mini is the world's first ever wall-mounted front-load
washer, which is installable in bathroom,
pantry, kitchen and various locations.
mini is a unique home appliance
featuring an innovative design and
practical functions.
World's First Ever Design
Wall-Mounted Front-Load Washer
mini features a cute and adorable design in a stable
cubic frame and harmonious colors to help decorate
house interiors.
Ultrasmall Design
WINIADAEWOO cutting-edge technologies
apply to mini, featuring a variety of essential
functions for better everyday lives.
Mini's Practical Function
Wall-Mounted Front Load Washer
미니_DWD-M221MB(영)_호주향_1도.indd 2 2020-08-10 오후 4:55:57
| 3 |
Product Features ..................................................................... 4
Safety Instructions .................................................................... 5
Preparation ............................................................................... 10
Parts and Components ............................................................. 11
Washable Items ........................................................................ 12
Non-Washable Items ................................................................ 12
Preparing Clothes for washing ................................................. 13
Directions on Detergent and Softener Containers .................... 14
Washing Course ....................................................................... 15
Preparation
Use
Buttons and Functions .............................................................. 16
Cold .......................................................................................... 17
Delicate..................................................................................... 18
Baby Care................................................................................. 19
Drum Clean .............................................................................. 20
Quick Wash .............................................................................. 21
Intensive Wash ......................................................................... 22
Q&A on Laundry ....................................................................... 23
Cleaning ................................................................................... 24
Installation Guide ...................................................................... 25
Installation
When malfunctions are suspected ........................................... 28
Before calling for service .......................................................... 29
Specifications and Wiring Diagram........................................... 30
CONTENTS
미니_DWD-M221MB(영)_호주향_1도.indd 3 2020-08-10 오후 4:55:57
| 4 |
Product Features
Remove laundry quickly and keep indoor air
fresh, washing daily laundry of towels,
underwear, shirts, and socks frequently
Daily Wash
mini's unique functions for faster and
powerful cleaning of various fabrics
Save time by washing in 15 minutes with Normal
cycle and Consume only 1/6 of energy that large
capacity front-load washer's use
15 Minute Economic & Quick Wash
mini washes baby clothes softly with steam and
rinses them completely to protect soft and
sensitive baby skin
Baby Care
mini washes delicate blouse, knitwear,
underwear and stockings requiring a hand wash
smoothly and carefully.
Delicate Cleaning for High Quality Clothes
미니_DWD-M221MB(영)_호주향_1도.indd 4 2020-08-10 오후 4:55:57
Ensure that the power
voltage, frequency, and
current match the product's
specification.
Violations may cause fire and
electric shock.
| 5 |
This appliance is not intended for use by persons (including children) with reduced physical, sensory or metal
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Cautionary information on cases that
may cause death or severe personal
injuries
Cautionary information on cases that
may cause minor personal injuries or
damage to products
Warning
Do not scratch, damage,
deform, bend, pull, twist, or
tie the power cord. Do not
place or insert a heavy item
on the cord.
Violations may damage the
power cord, raising the risk of fire
and electric shock.
Do not unplug or plug the
cord with wet hands.
Violations may cause electric
shock.
Safety Instructions
Do not use the washer when
the power cord is damaged
or loosely plugged in.
Violations may cause electric
shock, short circuit, or fire.
Contact a sales store to request
the maintenance service.
If the washer doesn't run or
smokes or unusal smells
occur, unplug the washer
and contact the service
center promptly to prevent
accidents.
Violations may cause electric
shock, short circuit, or fire.
Do not disassemble, repair,
or rebuild the washer
without the assistance of
service engineer.
Violations may cause fire, electric
shock, and personal injuries.
Contact a sales store or read the
back page of user manual to
request the maintenance service.
미니_DWD-M221MB(영)_호주향_1도.indd 5 2020-08-10 오후 4:55:58
| 6 |
Safety Instructions
Warning
If the power cord pin is
contaminated with dust or
water, wipe the pin clean
with a dry cloth before use.
Violations may cause fire.
Do not expose the washer to
rain or wind.
Violations may cause electric
shock, fire, technical problems,
or deformation.
Unplug the cord and open
the window for ventilation
without touching any
buttons if a gas leak occurs.
Violations may cause a spark
and, accordingly, explosion, fire,
or burns.
Electrical grounding is
required for safety.
Technical problems or short
circuits may cause electric
shocks.
Read user manual or contact the
service center with further
inquiries on grounding method.
Do not place gasoline,
petroleum, benzol, thinner, or
alcohol inside or beside the
washer. Do not place laundry
containing such materials
inside or beside the washer.
Violations may cause explosion
or fire.
Unplug the power cord before
cleaning or maintenance work.
Violations may cause electric
shock or injury.
Do not sprinkle water on the
washer. Violations may cause
short circuit or electric shock.
Do not enter the laundry
room and contact the
service center, if the washer
is submerged in water as the
water supply hose was
dislocated.
Violations may cause electric
shock.
Do not install the washer
near a heater and do not
place candles or cigarettes
on the washer.
Violations may cause fire or
deformation.
Water pressure for proper operation of the
equipment is 50kPa ~ 800kPa.
Use the supply hose and the water hose
connection with SET equipment SET is not
reuse old hoses
Insert the plug with 10A or
higher in the outlet directly.
Multiple connections to a single
outlet may cause fire due to heat.
미니_DWD-M221MB(영)_호주향_1도.indd 6 2020-08-10 오후 4:55:58
| 7 |
Safety Instructions
Warning
Do not place your hands or
metal objects below the
washer while the washer is
running.
Violations may cause personal
injuries.
Prohibit children from
operate the washer. Do not
let children stand on the
washer or insert their head
into the tub at any time.
Violations may cause personal
injury, burn, or electric shock.
Do not insert hands, sticks
or metal objects into the tub
or touch laundry during
operation.
Violations may cause personal
injuries.
With 'Door Locked', do not
open the door by force.
Violations may destroy the door
or lock, causing technical
problems.
Prevent children from having
their hands jammed in the
door and approaching the
washer.
Violations may cause personal
injuries.
Children or people who are
not well-informed of use
method must not use the
washer.
Violations may cause burn,
electric shock, or injury.
Do not press the button with
sharp object.
Violations may cause electric
shock.
Install the washer where the
electric outlet is easily
accessible. Unplug the
power cord if the washer is
not to be used for a long
time.
Violations may cause electric
shock, short circuit, or fire. Hold
the plug firmly when unplugging
the power cord.
미니_DWD-M221MB(영)_호주향_1도.indd 7 2020-08-10 오후 4:55:59
| 8 |
Caution
Turn on the tap to check for
leaks before use.
Improper connection may cause
leaks.
Do not operate the washer
with the detergent or
softener container detached.
Detachment of the detergent or
softener container causes water
leaks during operation. Please
close the detergent and softener
containers tight.
Leaks may cause personal
injuries.
Install the washer on a solid
wall and even.
Violations may cause abnormal
vibrations or noise.
Do not stand on the washer
or place a heavy item on it.
Violations may destroy the
washer or cause personal
injuries.
Prevent children from hanging on
the washer. Violations may
cause injuries.
Prevent pets and animals
from entering the washer
tub.
Violations may cause injuries.
Do not place magnets beside
the cap or the washer during
operation.
Violations may cause
malfunctioning of 'Door Lock
Sensor' and personal injuries
accordingly.
Do not use laundry net for
wash.
Violations may cause abnormal
vibrations, which can lead to
damage wall or cause personal
injuries.
Contact the service center
and do not operate the
washer when it is slanted or
out of horizontal.
Violations may cause injuries.
Safety Instructions
미니_DWD-M221MB(영)_호주향_1도.indd 8 2020-08-10 오후 4:55:59
| 9 |
Safety Instructions
Caution
Remove any detergent
residue or contaminants on
the washer with a wet soft
cloth.
Remaining contaminants may
deform plastic parts.
Turn off the tap after use.
It aims to prevent leaks caused
by poor inlet hose connections.
Do not use the washer to
wash non-clothing items.
(Footwear, potato, cabbage,
kelp, etc.)
Violations may cause abnormal
vibrations, damage the washer or
cause personal injuries.
Do not wash waterproof
clothes and items such as
raincoat, car cover, and
sleeping bags.
Violations may cause abnormal
vibrations during spin, which may
lead to personal injuries.
Violations may cause abnormal
vibrations during wash, which may
lead to damage the wall, floor, or
clothing and cause part abrasion.
Close the door carefully to
prevent laundry from getting
jammed in the door.
It may cause damage to clothes
or malfunction.
Press the Start button after turning
off the tap and then slowly turn it
on when the water supply
resumes or the inlet hose is
reconnected (or when resuming
the use of washer after a long-term
suspension)
The high air pressures built in inlet hose
or water pipes may damage the washer,
causing leaks or personal injuries.
Put detergent and softener
in detergent and softener
containers separately.
Confusion or mixture may
prevent laundry from being
washed properly.
Remove all liquid detergent
and fabric softener in the
washer when relocating it.
Violations may cause liquid leaks
and malfunctions.
미니_DWD-M221MB(영)_호주향_1도.indd 9 2020-08-10 오후 4:55:59
| 10 |
- This washer is available for use with cold water only.
Do not connect the inlet hose to the hot water tap.
Connect the drain hose to the drain.
- Check that the drain hose is tightly connected.
- A minor water leak may occur during installation or the initial cycle. The leak is
caused not by a malfunction or a mechanical problem but by the remnant for
functional test performed at the manufacturing plant.
1
Connect the inlet hose and turn on the tap.
- Check whether any leaks occur around the hose guide or inlet hose connection.
Plug in the power cord.
- Check the grounding procedure to prevent electric shocks.
Preparation
Caution
2
3
미니_DWD-M221MB(영)_호주향_1도.indd 10 2020-08-10 오후 4:55:59
| 11 |
| 11 |
Parts and Components
Drum Door
(Do not open during
operation)
Control Panel
Softener
Container
Detergent Container
Power Cord
Cold Water Tap
(Turn off the tap
after cleaning
cycle is
complete)
Parts
Additional inlet hoses and drain hoses (for extension) are available for
purchase at service centers.
Note
Cushion pad
(4 units)
User manual Installation
manual
Screw
(4 units)
Elbow
(2 units)
Drain hose Inlet hoseAnchor bolt
(4 units)
Connector
valve inlet
미니_DWD-M221MB(영)_호주향_1도.indd 11 2020-08-10 오후 4:56:00
Non-Washable
Items
Washable
Items
- Underwear and socks
- Dress shirts and T-shirts
- Towel, handkerchief, pillow cover, kitchen towel, and
dust cloth
- Baby clothes, nappies, and underwear
- High-quality clothes such as blouse, knitwear, and
wool clothing
- Women's wear such as lingerie and stockings
About Laundry Shrinkage
- Easily shrinkable items:
Cotton shirts, synthetic socks, etc.
- Shrinkage-free items:
Polyester blouse, synthetic shirts (shirts), etc.
Laundry shrinkage varies by the wash cycle, type of fabric, weaving and sewing methods, and
finishing. Please examine the laundry guides before wash.
| 12 |
Leather and silk items
- Product such as pillow and comforter padded with
cotton or foamed urethane (sponge)
- All-wool blanket, electric blanket, blanket with a hair
length of 10mm or longer, and carpet cover
- Mat and carpet made of animal hair
- Wash supplements for commercial sales (laundry
ball, dust absorption filter, etc.)
- Rubber, nylon, and plastic items
- Waterproof mat, sheet, or clothing
Washable Items
미니_DWD-M221MB(영)_호주향_1도.indd 12 2020-08-10 오후 4:56:00
| 13 |
Preparing
Clothes for washing
Waterproof mat or sheet, solid and heavy clothes, doormat, and blanket, and non-
permeable fabric products are not suitable for washing, rinsing, or spinning.
- Floating laundry or abnormal vibrations may cause personal injuries or damage to
the washer, wall, floor, and clothes.
Remove dust and sand from the laundry before use.
- Removal reduces the risk of malfunction.
Remove coins, hairpins, curtain attachments, and clips from the laundry.
- The metal items may damage clothes and washer or cause malfunctions.
- The metal items may cause dust or trash clogs in the drainage, which leads to
mechanical problems with the washer.
Check the laundry guide labels.
- Wash the clothes as specified in the guides. Wash the colored and white clothes
separately.
Reverse fluffy clothes before washing. Sort the clothes by fabric
type before washing (cotton, jean, synthetic fabrics, etc.)
- Mixture may cause damage to fabrics.
Hand-wash partially contaminated clothes before using the washer.
- Use stain removal detergents or bleaches.
Tie strings and close zippers.
- It may cause damage to the clothes or the washer.
Do not wash thick or voluminous clothes in the washer.
(Jeans, bathing gown, bathroom mat, thick sportswear, etc.)
- As thick clothes are not evenly washed in the tub, vibrations increase during
the spin cycle.
| 13 |
미니_DWD-M221MB(영)_호주향_1도.indd 13 2020-08-10 오후 4:56:01
| 14 |
Directions on
Detergent and Softener
Containers
Add detergent as recommended to the detergent container.
Addition of Detergent
Addition of Fabric Softener
- Add softener as recommended to the softener container.
- Fabric softener is automatically discharged during the final rinse cycle.
- Do not leave fabric softener unused for a lon period (12 hours or longer).
- Fabric softener may get hardened and not be discharged.
Proper Amounts of Detergent and Fabric Softener
- Add detergent and softener as recommended in the
product manuals.
- Powder detergent: 2/3 of detergent container (11g)
- Liquid detergent: 2/3 of detergent
container (12g)
- Fabric softener: 1/2 of softener container (6g)
- Add concentrated detergent as recommended in the
product manual.
Spoon-Shaped
Detergent Container
Wait! Please read the following instructions before applying detergent.
- Do not add detergent more than once to the detergent container. If the washer is not heavily loaded,
a half-full detergent container is sufficient for washing.
- Remove detergent remnants from the door or control panel immediately. Such contamination may cause damage to the
washer.
- Wet detergent container may harden the contents. Wipe the container with a dry cloth carefully before adding powder
detergent.
- Overloading may cause the following problems and malfunctions.
• Overloaded detergent causes excessive foam, which lengthens the rinse cycle and disturbs the normal rinse and spin
cycles.
• Foam may remain on clothes even after rinsing.
- Detergent container is exposed to contamination or detergent remnants. You can keep it clean with weekly cleanings.
- Water may remain in the container after a wash cycle. As it is caused by the process of cleaning detergent and softener
containers, it is not the remnant of detergent or softener. Remove water before starting a wash cycle.
Caution
■ Open :
Turn the detergent and softener containers counterclockwise and then pull them.
■ Close :
Turn the detergent and softener containers clockwise to close them tight and then run the washer.
Softener Container
2
3
1
2
Detergent Fabric Softener
미니_DWD-M221MB(영)_호주향_1도.indd 14 2020-08-10 오후 4:56:01
| 15 |
| 15 |
Laundry Weight (Standards)
Washing
Course
- Wash your clothes as recommended in the manual.
- Overloading may reduce the washing efficiency or cause abnormal vibrations.
- Apply the recommended Course. Other Course are available for use.
(Fabric deformation may occur because of the type of fabric)
Note
Baby clothing set Approx.
200g in cotton
Bath towel
Approx. 300g in cotton
Sleepwear set
Approx. 500g in cotton
Panties
Approx. 50g in cotton
Dress shirt Approx. 150g in
synthetic fabrics
Pants
Approx. 600g in cotton
Underwear
Approx. 130g in cotton
Baby towel
Approx. 10g in cotton
Cold Delicate Baby Care
Quick
Wash
Intensive
Wash
Load
Recommendations
Cotton shirt (150g)
● ● ●
11 to 12 shirts
A pair of socks (50g)
● ● ●
19 to 20 pairs
Underwear set (50g)
● ● ●
9 to 10 sets
Towel (150g)
● ● ●
8 to 9 sheets
Kitchen towel (25g)
● ● ● ●
16 to 17 sheets
Baby clothes (150g)
● ● ● ●
7 to 8 items
Diaper (50g)
●
9 to 10 sheets
Dress shirt (200g)
● ●
4 to 5 shirts
Swimsuit (100g)
●
4 to 5 items
Long underwear set (400g)
●
3 to 4 sets
Knitwear (350g)
●
1 to 2 items
Handkerchief (10g)
● ● ●
16 to 17 sheets
Stockings (80g)
●
9 to 10 pairs
Pants (600g)
● ● ●
1 to 2 pants
미니_DWD-M221MB(영)_호주향_1도.indd 15 2020-08-10 오후 4:56:01
| 16 |
Buttons and Functions
- Push the door slightly if the door is not easily opened after the completion of
washing.
- If 'Door Lock' is not working due to the overloading of laundry or incomplete
door closing, push the door slightly.
- You can open the door of running washer about 5 minutes after a power
interruption.
- Please open the door carefully for safety if the washer stops running during a
wash or rinse cycle because of a power interruption. (Reset the 'Door Lock' mode
if it remains unsafe after power supply resumes)
Note
Power
- Use the Power button to turn the washer on
or off.
Course
- Press the Course button to select a cycle.
- Course lamps indicate the selection.
Add Rinse
- Press the Add Rinse button to add a rinse
cycle after selecting a wash cycle. (Up to 5
cycles addable)
Display LED
- LED displays cleaning time and Course
information.
Child Lock (Button Lock)
- Press the Child Lock button to prevent your
kids from controlling the washer.
- In Child Lock mode, only the Power button is
available for use.
- Press the Course and Rinse button for 3
seconds to lock or unlock the mode.
Start/Pause
- Press the button to start the cycle.
- The washer runs and stops alternately when the press is pressed.
- If you press the "Start/Pause" button after turning on the washer, the normal cycle starts.
1 2
6
3
6
4
5
미니_DWD-M221MB(영)_호주향_1도.indd 16 2020-08-10 오후 4:56:02
| 17 |
Cold
Select the Cold Course for daily laundry (towel, socks, and dress shirts) and other regular
items.
Open the door and load the washer with clothes. Add detergent and fabric
softener into the detergent and softener containers respectively and then
close the door.
- Turn detergent and softener containers clockwise to close them tight before use.
Press the Course button to select 'Cold'.
- Cold water, two rinse cycles, and strong spin cycle are selected automatically.
Press the Power button slightly for a second.
- Press the Start/Pause button and then select other buttons to change the setting
while the washer is running.
- If you press the Start/Pause button after turning on the washer, the initial setting
applies automatically to the wash cycle.
Note
Tip
Press the Add Rinse button to change the number of rinse cycles.
(Up to 5 rinse cycles are available)
Press the Start/Pause button.
- The wash cycle starts with water supply after the door is locked.
"Do not pile up your daily laundry of towels, socks, and shirts.
Cold Course takes only 29 minutes to complete its entire cycle."
1
2
3
4
2 3 4
미니_DWD-M221MB(영)_호주향_1도.indd 17 2020-08-10 오후 4:56:02
| 18 |
Delicate
Select the Delicate Course for items washable with water such as knitwear, wool
clothing, and lingerie.
- Do not select the Delicate Course for easily shrinkable or deformable leather
or cashmere items.
- Press the Start/Pause button and then select other buttons to change the
setting while the washer is running.
Note
"Wash your high-quality knitwear and wool clothing,
underwear and stockings without concern. Delicate Course helps wash your laundry
gently and safely without causing any fabric damage or discoloration."
Open the door and load the washer with clothes. Add detergent and fabric
softener into the detergent and softener containers respectively and then
close the door.
- Turn detergent and softener containers clockwise to close them tight before use.
- Do not use bleaches for Delicate Course to prevent decoloration of your laundry.
Press the course button twice to select ‘delicate’
- Cold water, two rinse cycles, and medium spin cycle are selected automatically.
Press the Power button slightly for a second.
Tip
Press the Add Rinse button to change the number of rinse cycles.
(Up to 5 rinse cycles are available)
Press the Start/Pause button.
- The wash cycle starts with water supply after the door is locked.
1
2
3
4
2 3 4
미니_DWD-M221MB(영)_호주향_1도.indd 18 2020-08-10 오후 4:56:02
2 3 4
| 19 |
Baby Care
Select the Baby Care Course to wash baby clothes, 100% cotton products, and
clothing requiring steam wash and bleaching.
"Select the Baby Care Course to steam wash baby
clothes and cotton products. The Course helps clean your laundry
hygienically with hot water and three rinse cycles."
- The water temperature is maintained at 95℃without any changes during the cycle.
- If the steam wash causes excessive bubbles, you can remove them by
repeating the process of Drain(spin)→ Water Supply(rinse+spin)→ Start/Pause.
- Do not wash clothes that are not resistant to heat.
- Press the Start/Pause button and then select other buttons to change the setting
while the washer is running.
- Three rinse cycles apply automatically for sensitive baby skin.
Note
- Please check whether the laundry is suitable for steam wash (Pure cotton and
100% cotton baby clothes, diapers, etc.).
- Wash white and bright-colored clothes and dark items separately.
Caution
Open the door and load the washer with clothes. Add detergent and fabric
softener into the detergent and softener containers respectively and then
close the door.
- Turn detergent and softener containers clockwise to close them tight before use.
1
Press the Power button slightly for a second.
2
Press the Course button to select 'Baby Care'.
- The water temperature of 95℃, three rinse cycles, and strong spin cycle are selected automatically.
Tip
Press the Add Rinse button to change the number of rinse cycles.
(Up to 5 rinse cycles are available)
3
Press the Start/Pause button.
- The wash cycle starts with water supply after the door is locked.
4
미니_DWD-M221MB(영)_호주향_1도.indd 19 2020-08-10 오후 4:56:02
| 20 |
Drum Clean
Select the Drum Clean Course to cleanse the inside of tub.
- All options other than Add Rinse are unavailable.
- Do not load the washer with laundry during the Drum Clean cycle.
- Drum Clean is recommended to be performed on a monthly basis.
Note
"Use the drum clean cycle regularly.
The Drum Clean Course cleanses the drum and ensures cleaner washing."
Add powder bleaches into the detergent container.
- Add a proper amount of detergent to the detergent container.
Press the Course button to select 'Drum Clean'.
- Cold water, two rinse cycles, and strong spin cycle are selected automatically.
Press the Power button slightly for a second.
Tip
Press the Add Rinse button to change the number of rinse cycles.
(Up to 5 rinse cycles are available)
Press the Start/Pause button.
- The Drum Clean cycle starts with water supply after the door is locked.
1
2
3
4
2 3 4
미니_DWD-M221MB(영)_호주향_1도.indd 20 2020-08-10 오후 4:56:02
| 21 |
| 21 |
Use this feature when a small amount of laundry in a short time.
- If you need to change the setting program during the washing process,
press the "Start / Pause" button, the program stops can change the program
settings.
Note
" When the laundry is washed with a small amount of relatively
clean or wash clothes, please use the program,
Washing process can be completed in a short time. "
The laundry into the drum and close the door.
1
Press the Power button slightly for a second.
2
Press the Course button to select ‘Quick Wash'.
- The program automatically sets the cold water, rinse again, dehydrated again.
- If you need to change the number of rinsing, press the "Rinse Add" button (up to 4 times)
3
Press the Start/Pause button.
4
Quick Wash
2 3 4
미니_DWD-M221MB(영)_호주향_1도.indd 21 2020-08-10 오후 4:56:03
| 22 |
Intensive Wash
Select the Intensive wash Course to wash highly soiled laundry
- The cycle time is increased for each cycle.
- Intensive Wash, 6H( Course push 3 times) , Water temperature 40°C,
Test Load 2.0 kg, 230V, detergent dosing : in 1 litre warm water,
use programme is suitable for a normally soiled load and tested in
accordance or in conformity with AS/NZS 2040.1.in Capacity : 2kg
Note
"For stained clothes, The intensive wash Course provides
outstanding stain removal performance."
Add powder bleaches into the detergent container.
- Add a proper amount of detergent to the detergent container.
1
Press the Power button slightly for a second.
2
Press the Course button to select 'Intensive wash'.
- Press the course button to select the level.
- Intensive 1 : Cold, three rinse cycles
- Intensive 2 : 40℃, three rinse cycles
- Intensive 3 : 60℃, two rinse cycles
Tip
Press the Add Rinse button to change the number of rinse cycles.
(Up to 5 rinse cycles are available)
3
Press the Start/Pause button.
- The Intensive cycle starts with water supply after the door is locked.
- "Intensive 3" course(Press the Course button twice at 'Intensive Wash') is suitable
for cleaning normally soiled loads.
4
2 3 4
미니_DWD-M221MB(영)_호주향_1도.indd 22 2020-08-10 오후 4:56:03
| 23 |
The following instructions are about the cleaning of washer parts for long-term sanitary use.
Can freezing cause the washer to malfunction?
A small amount of water remains in the inlet hose or drum tub after the completion of
washing cycle. The water may freez at low temperatures. Follow the following instructions
in such an event.
- Wrap the inlet hose connection with a hot towel.
- Turn off the tap and detach the inlet hose. Then, put the hose in hot water (less than 50℃).
- Add 2ℓ of hot water (less than 50℃) into the tub and then wait for about 10 minutes.
- Reconnect the inlet hose and then turn on the tap to check the water supply and drainage.
- Do not take the above measure when the inlet hose is frozen as it may cause malfunctions.
Caution
How can I change the laundry setting while the washer is running?
There are available and unavailable options.
- You can change the wash, rinse, and spin cycles before the completion of the entire wash cycle.
- Press the Start/Pause button to change your setting.
How can I clean the inside of drum tub?
Cleanse the drum tub with washer Drum Cleaners available for retail sales.
- Use the cleaner correctly as instructed in user manual.
- Follow the following instructions to clean the drum tub.
1. Add washer Drum Cleaners to the detergent container.
2. Select the Drum Clean Course.
3. Press the Start/Pause button to start the Drum Clean cycle.
Q&A on Laundry
미니_DWD-M221MB(영)_호주향_1도.indd 23 2020-08-10 오후 4:56:03
| 24 |
Cleaning
Follow these cleaning instructions for long-term sanitary use of washer.
- Unplug the power cord before cleaning the washer.
Violations may cause electric shocks or personal injuries.
- Do not sprinkle water on the washer.
Violations may cause short circuits or electric shocks.
Warning
- Turn the detergent and softener containers counterclockwise and pull them. Wash the
containers with water.
- Remove the detergent powder in the detergent container before use.
※ If contaminants remain in the detergent and softener containers or the discharge holes for a
long time, they may cause malfunctions.
- Water may remain in the container after a wash cycle. As it is caused by the
process of cleaning detergent and softener containers, it is not the remnant of
detergent or softener.
Note
■ Cleaning of Detergent and Softener Containers!
- Rust: If rusty water or an easily rustable item such as hair pin is added or water remains in the
tub for a long time, it may cause rust.
- Rust Removal: Apply rust removal cream to a soft cloth or sponge and then scrub the rusty
part with it. ※ Do not use a steel scrub as it damages the drum tub.
- Detergent Residue: (Dark and spotty) Detergent residues may occur and contaminate the
laundry if you use the washer for a long time, add too much detergent, or repeat the wash
cycles with detergents incompletely dissolved. Select the Drum Clean course to cleanse the
drum tub.
■ Cleaning of Drum!
- Clean the filter net when water leaks from the water inlet
1.
Separate the inlet hose and pull out of the filter net with your fingers or a pair of needle-nose pliers.
2. Soak the filter net in water and remove the dirt with a toothbrush
3. Insert the filter net back into the inlet filter
4. Reconnect the inlet hose and make sure the hose is connected tightly
■ Cleaning the water filter inlet!
- Clean the washer with a wet cloth.
■ Cleaning of Washer!
- Do not use synthetic detergents, benzol, or thinner. It may damage plastic parts.
- Use chemical cleaners as described in the user manual.
Caution
- When you need to clean the drainage filter, please contact to the nearby service center.
- Drainage filter cleaning should be done by service worker or professionally trained personnel.
■ Cleaning the drain filter!
- Plesae place a bowl before opening the filter cap. Water could be droped from the filter.
- Do not try to open the filter cap when product is running in order to avoid scald.
Caution
미니_DWD-M221MB(영)_호주향_1도.indd 24 2020-08-10 오후 4:56:03
| 25 |
The washer is recommended to be installed by a professional service engineer.
Installation Guide
- Determine the installation site after discussing
the site structure with the customer.
※ Breast-high location is convenient for installation.
※ Installation and use are convenient with access to water
supply, drainage, and electric outlets.
1. Determine the location for installation
- Knock on the wall with your hand to check the
existence of retaining wall inside.
※ Install the washer on an even wall.
2. Inspect wall
- Use a level meter for attachment.
- Attach a guide and mark the hole spot.
※ Attach the manual in consideration of actual product
size.
3. Attach installation instruction manual
- Fix set anchors with an anchor hammer.
※ Redo the fixation if the anchor cap protrudes above the
wall surface after fixation.
6. Fix set anchors
- Connect the fixing nut (1EA) after inserting the
flat washer (1EA) and spring washer (1EA) and
then connecting a regular nut (1EA).
- Fasten the nut with Ø14 spanner.
※ Excessive fastening of nut may destroy the product or
wall tile.
※Fixing nut must be fastened tight.
11. Fix the washing machine
Lock the water supply valve Disassemble the water supply valve
Install the branching adapter Branch off the inlet hose
※ Wrap the connection of branching adapter and water supply valve with Teflon tape.
※ Examine whether a water leak occurs after instillation.
12-1. Install the inlet hose - Regular Tap
Install the washer without plugging in the power cord.
- Insert the inlet hose until the elbow makes a snapping sound.
- Connect the clamp inside the synchronous motor after fixing the
drain house to the synchronous motor.
※ Connect hoses properly to prevent leaks.
※ Insert the inlet/drain hoses into the back holes after
connection.
7. Connect inlet and drain hoses
Before installation
Perform a test run to identify any water leaks or abnormal noise.
After installation
- Place hoses in the hole.
※ Prevent the hoses from becoming jammed between the
wall and washer.
8. Organize hoses
미니_DWD-M221MB(영)_호주향_1도.indd 25 2020-08-10 오후 4:56:04
| 26 |
Follow the installation instructions to install the washer more conveniently.
Installation Guide
- Notch below the marking hole.
- Drill a hole perpendicular to the wall surface.
※ Do not drill a hole on the edge of wall tile.
※ Do not drill a hole right below the faucet.
4-1. Drill a hole through tile
- Set the hammer drill perpendicular to the wall
surface and then drill a hole into the retaining
wall.
※ Follow the instructions on the diameter and depth
specifications for the hole.
※ Remove dirt from inside the hole.
4-2. Drill a hole into the retaining wall
- Insert set anchors into holes.
- Set anchors are included in the product
package.
※ Insert set anchors to the end of holes.
※ The set anchor bolt must be 75mm long or longer above
the wall.
5. Insert set anchors (4 holes)
- Install the washer on the surface of wall so as
not to create a large gap.
10. Install the washing machine
Lock the water supply valve Disassemble the water supply valve
Install the branching adapter (Install adapters respectively on cold and hot water taps)
Branch off the inlet hose
12-2. Install the inlet hose - Kitchen sink, shower
- Run a test operation to identify any
malfunctions or leaks.
13. Test Operation
Hot water
For
hot
water
For
cold
water
Cold
water
- Inject chemical anchor into the fixed set anchors.
- Insert cushion pads on the fixed anchors.
- Attach pads to the wall.
9. Inject chemical anchor and insert cushion pads
미니_DWD-M221MB(영)_호주향_1도.indd 26 2020-08-10 오후 4:56:04
| 27 |
Note
Warning
▶ Grounding is required to prevent electric shocks. Check the availability of circuit breaker.
- Contact the sales store or service center for further details.
▶ If the power outlet has no grounding terminal:
- Grounding must apply for the safe use of washer.
- Grounding is performed by the service center engineers or qualified personnel only.
- Contact your nearby service center for details.
▶ Grounding is prohibited in the following locations.
- Gas pipe (It has the risk of explosion or fire)
- Phone wire or lightning rod (It is risky when struck by lightning)
- Water pipe (Many water pipes are made of plastic materials)
If a power cord is broken, you should contact the sales store or service
center as a special tool is required.
Contact the service center to relocate the installation.
(Additional charge applies)
Exchange of Power Cord
Relocation
- Organize inlet and drain hoses and power cord
with molding and hose guide.
14. Organize inlet and drain hoses and power cord
- Connect 4 nuts and bolts above and below after
mounting the body.
15. Mount the body
※ Wipe the attachment area clean with a dry cloth and
then attach the molding and hose guides tightly.
※ Check whether any cleavages exist on both sides.
Wall Type Depth of Hole Bit diameter of hammer drill Bit diameter of tile hole
Concrete 45mm
Ø 13mm
-
Tile
Distance between tile and
retaining wall + 45mm
Ø 14mm
미니_DWD-M221MB(영)_호주향_1도.indd 27 2020-08-10 오후 4:56:04
| 28 |
[1] The smell of excess waste in drainage flows back. You need to clean the drainage
regularly.
[2] Review the error indications E5, E6, E7, and E8 and then contact the sales store or
service center.
[3] Check whether the water supply valve is open.
[4] Did you use too much detergent? If the laundry gets excessively foam, the washer
drains water even in the middle of a wash cycle.
[5] The washer resumes water supply to balance the laundry in the drum in a spin cycle.
[6] The low water pressure lengthens the water supply and the entire cleaning cycle as
well.
[7] Towel may get stiff as the front load washer cleans the laundry by utilizing falling
pressures. Use fabric softener to reduce the stiffness.
[8] Check whether the power cord is properly connected to the washer.
[9] The remaining time increases when the laundry is unevenly located in the drum.
[1] Unpleaser smell for drum.
[2] The washer stops running in the
middle of a wash cycle.
[3] The water supply doesn't start
after running the washer.
[4] The washer drains water while
washing clothes.
[5] The water supply starts in the
middle of a spin cycle.
[6] The wash cycle takes too long.
[7] Towels are stiff after washing.
[8] The washer makes strange
noises during a spin cycle.
[9] The remaining running time
fluctuates.
[10] The washer heats the water to raise the water temperature during a wash. The
remaining time may not change for a while in winter as the washer heats the water to
a preset temperature.
[11] The buzz is caused by the electronic break to suspend the spin cycle. It is not caused
by a mechanical problem.
[10] The remaining running time
doesn't change.
[11] The washer buzzes when the
spin cycle stops.
[12] Front load washers consume a small amount of water for washing.
- The water surface is not easily identifiable due to the low water level, but this is not
caused by a mechanical problem.
- The front load washer consumes a small amount of water as it soaks the laundry with
water and washes and rinses it by rotating and dropping the clothes.
[12] A small amount of water is
supplied to wash or rinse
laundry. (Low water level)
[13] The washer resumes water supply after detecting the quantity of water and laundry
condition to improve washing efficiency. It may be caused by either of the following
reasons.
- Laundry was added after starting a wash cycle.
- The low water level activates the water supply automatically.
[13] The water supply resumes
during a wash or rinse
cycle.
[14] When detergents were applied excessively or the drain hose is bent upward in the
middle so that the water is not properly drained, the spinning speed may decrease.
Drain the water and then resume the spin cycle.
[14] The drum is not spinning or
it is running slowly for a
while after the spin cycle
starts.
Problems Causes
- Some troubles are wrongly considered to be mechanical malfunctions although they are not.
- If any malfunctions are suspected, you may contact the sales store or service center with inquiries.
When malfunctions are suspected
미니_DWD-M221MB(영)_호주향_1도.indd 28 2020-08-10 오후 4:56:04
| 29 |
- Press the button(power) to suspend the operation of washer and then examine the following items.
- Press the button(power) again to resume operation.
Checkpoints and SolutionsProblem/Display
- Is the power cord correctly connected to an electric outlet?
- Is the power supply on?
- Did you press the Start/Pause button?
- Is there a power failure?
- Did the circuit breaker cut the power supply?
Washer is not
operating.
No display
- If LE error is displayed on the LED panel, please open and close the door.
- If LE error continues to take place, please turn off and restart the washer.
Note
- Is the tap turned on?
- Is the drainage hose filter clogged with dirt?
- Is inlet hose frozen?
- Is the water supply cut off?
Water supply
is unavailable.
- Did you put down the drain hose properly?
- Is the outlet of drain hose closed as it is inserted deep into the drain?
- Is the drain hose bent?
- Is the drain hose placed too high?
- Is the drain clogged with dirt and threads?
- Is there excessive dirt inside the drain filter?
Water drainage
is unavailable.
- Is the door open?
- Is the door end closed tightly?
Washer is not
operating.
- Contact your local service center.
Drum is not
spinning.
- Contact your local service center.
Water is not
adjustable.
- Do not touch or disassemble the inner parts when you have not identified any problems
with the checkpoints above. Contact your local service center after unplugging the washer
and turning off the faucet.
Other troubles
without error
displays
Before calling for service
미니_DWD-M221MB(영)_호주향_1도.indd 29 2020-08-10 오후 4:56:05
Specifications and Wiring Diagram
| 30 |
Product specifications are subject to change without prior notice for the improvement of product quality.
Model DWD-M221MB
Dimensions 550(W) X 600(H) X 302(D) mm
Weight 16.5kg
Water Consumption (Standard course) 25ℓ
Voltage / Frequency 240V / 50Hz
Power Input 1500W
Max. Laundry Load 2.0kg
Operating Water Pressure 98.1kPa~784kPa(1kgf/cm²~8kgf/cm²)
Wiring Diagram
미니_DWD-M221MB(영)_호주향_1도.indd 30 2020-08-10 오후 4:56:05
Please read the user manual before contacting the service center as call-out charges may apply to services on the use
or installation of washer.
Wall-Mounted Front Load Washer
미니_DWD-M221MB(영)_호주향_1도.indd 31 2020-08-10 오후 4:56:05
ABOUT THIS MANUAL
(주)신광씨링
광주광역시 서구 하남대로
502번길 14
담 당 이청휘 님
브 랜 드 Winia 언 어 영문
F.MODEL
B.MODEL DWD-M221MB
B U Y E R 호주향
제 판 인 쇄
MEMO접수:
170525 - 총 14p(표지,2,4,10,11,14,16,17,18,19,20,21,22,27)
총 28p(1~28)_원본없음(원본 신규제작)_베이직 화일 영문본 원본 없음
이미지 합성 : 총 4cut(영면, 측면, 정면 등등)
170530 - 총 2p(22,27)
(총 31p)
170704 - 총 7p(3,15,16,17,25,26,27)_이청휘님
171208 - 총 4 p(11.25.26.27)_이청휘님
180118 - 총 1p(11)_악세사리 삭제_고영학 님
200707 - 총 2p(표지,특징)_WINIA_김정환 님
200729 - 총 1p(30)_김정환 님
200810 - 총 1p(30)_김정환 님
NO NEED PRINT
미니_DWD-M221MB(영)_호주향_1도.indd 32 2020-08-10 오후 4:56:05
