QUICK START GUIDE
100
JBL quantum100 headset REMOVABLE MIC QSG | WARRANTY CARD |
WARNING CARD
Windshield foam for
boom microphone
001 WHAT'S IN THE BOX
01 Volume Control
02 Microphone Mute/unMute
03 2.5mm jack for boom microphone
04 Flat-fold ear cup
03
04
01
02
002 OVERVIEW
003 SETUP
PC | Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR
004 MICROPHONE
Driver size: 40 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Max input power: 20 mW
Sensitivity: 96 dB @ 1 kHz / 1 mW
Impedance: 32 ohm
Microphone frequency response: 100 Hz - 10 KHz
Microphone sensitivity: -42 dBV @ 1 kHz / Pa
Microphone pickup pattern: Directional
Microphone type: Detachable boom
Cable length: 1.2 m
Weight: 220 g
005 TECH SPEC
