J6/J600 Instructions for Use
2
Table of contents
Your J6/J600
Control elements 4
Important information 6
Proper use ......................................................................................................................................................6
For your safety ...............................................................................................................................................6
1 Preparing and using for the first time 10
JURA on the Internet ....................................................................................................................................10
Setting up the machine ..............................................................................................................................10
Filling the bean container ...........................................................................................................................10
Determining the water hardness ..............................................................................................................10
First-time use .................................................................................................................................................11
Connecting milk ...........................................................................................................................................14
Connect accessory (wireless connection) ................................................................................................14
2 Preparation 15
Ways of preparing a beverage ...................................................................................................................15
Ristretto, espresso and coffee ....................................................................................................................16
Two ristretti, two espressi and two coffees .............................................................................................16
Latte macchiato, cappuccino and other speciality coffees with milk .................................................17
Ground coffee ...............................................................................................................................................17
Permanently setting the amount of water for the cup size .................................................................18
Adjusting the grinder ..................................................................................................................................19
Hot water .......................................................................................................................................................19
3 Daily operation 20
Filling the water tank ..................................................................................................................................20
Switching on the machine .........................................................................................................................20
Daily maintenance .......................................................................................................................................21
Regular maintenance ..................................................................................................................................21
Switching off the machine .........................................................................................................................22
4 Permanent settings in programming mode 23
Adjusting the product settings .................................................................................................................24
Adding products to the start screen, duplicating and personalising ................................................25
Automatic switch-off ..................................................................................................................................26
Energy-saving mode ..................................................................................................................................27
Setting the water hardness .......................................................................................................................27
Display settings ...........................................................................................................................................28
Unit for amount of water ...........................................................................................................................28
Restore factory settings .............................................................................................................................29
Language ......................................................................................................................................................29
Querying information ................................................................................................................................30
5 Maintenance 31
Rinsing the machine ....................................................................................................................................31
Automatic milk system rinsing .................................................................................................................32
Cleaning the milk system ..........................................................................................................................32
3
Table of contents
Warnings
J WARNING
J CAUTION
Always take note of any information marked with the words CAUTION or
WARNING and a warning sign. The signal word WARNING draws your attention
to potential serious injury, and the signal word CAUTION to potential minor
injury.
CAUTION CAUTION draws your attention to potential damage to the machine.
Symbols used
T
Prompt to take action. This symbol means that you are being prompted to perform
some action.
E
Information and tips to make it even easier to use your JURA.
‘Coffee’ Display
Symbol description
Dismantling and rinsing the cappuccino frother .................................................................................. 33
Inserting the filter .......................................................................................................................................34
Changing the filter ......................................................................................................................................34
Cleaning the machine ................................................................................................................................35
Descaling the machine ...............................................................................................................................36
Cleaning the bean container .....................................................................................................................38
Descaling the water tank ...........................................................................................................................39
6 Display messages 40
7 Troubleshooting 41
8 Transport and environmentally friendly disposal 43
Transport/ Emptying the system .............................................................................................................43
Disposal .........................................................................................................................................................43
9 Technical data 44
10 Index 45
11 JURA contact details/ Legal information 48
4
Control elements
Control elements
3
7
4
6
10
9
8
1
2
18
19
17
20
5
11
16
12
13
14
15
1 Filler funnel cover
2 Filler funnel for ground coffee
3 Bean container cover
4 Water tank cover
5 Service socket
6 Bean container with aroma preservation
cover
7 Water tank
8 Height-adjustable cappuccino frother
9 Coffee grounds container
10 Drip tray
11 Storage compartment cover
12 Grinder adjustment switch
13 Interchangeable milk spout
14 Storage compartment insert
15 Milk pipe
16 Measuring spoon for ground coffee
17 Mains cable (side of machine)
18 Hot-water spout
19 Height- and width-adjustable coffee spout
20 Cup grille
5
Control elements
31 2
4
5
Top of the machine
1 On/Off button Q
2 Rotary Switch
3 P button (programming)
Front
4 Display
5 Multi-function buttons (button function
depends on what is shown in the display)
Container for milk system cleaning
6
6
Important information
Important information
The machine is designed and intended for private
domestic use. It should only be used for coffee
preparation and to heat milk and water. Use for any
other purpose will be deemed improper. JURA
Elektroapparate AG cannot accept any responsibil-
ity for the consequences of improper use.
Before using the machine read these instructions
for use thoroughly and completely and comply
with the instructions they contain. A warranty ser-
vice is not applicable for damage or defects caused
by non-compliance with the instructions for use.
Keep these instructions for use close to the machine
and pass them on to the next user.
Please carefully read and observe the important
safety information set out below.
To avoid danger of potentially fatal electric shock:
U
Never use a machine which is damaged or has
a defective mains cable.
U
In the event of signs of damage, for example if
there is a smell of burning, unplug the machine
immediately from the mains supply and con-
tact JURA service.
U
If the mains cable of this machine is damaged,
it must be repaired either directly by JURA or
by an authorised JURA service centre.
U
Make sure that the JURA and the mains cable
are not located close to hot surfaces.
U
Be careful to ensure that the mains cable is not
trapped and does not rub against sharp edges.
Proper use
For your safety
J
7
Important information
U
Never open and repair the machine yourself.
Do not modify the machine in any way that is
not described in these instructions for use. The
machine contains live parts. If opened, there is
a danger of potentially fatal injury. Repairs
may only be carried out by authorised JURA
service centres, using original spare parts and
accessories.
U
To completely and safely disconnect the
machine from the power supply, first switch
off the JURA using the On/Off button. Only
then should you remove the mains plug from
the power socket.
There is a risk of scalds or burns on the spouts and
the cappuccino frother.
U
Place the machine out of the reach of children.
U
Do not touch any hot parts. Use the handles
provided.
U
Ensure that the cappuccino frother is correctly
fitted and clean. If incorrectly fitted or if they
become blocked, the cappuccino frother or its
parts might come off. There is a danger of
parts being swallowed.
A defective machine is not safe and could cause
injury or fire. To avoid damage and any associated
risk of injury or fire:
U
Never allow the mains cable to loosely hang
down. The mains cable could pose a tripping
hazard or become damaged.
U
Protect the JURA from environmental influ-
ences such as rain, frost and direct sunlight.
U
Do not immerse the JURA, mains cable or con-
nections in water.
8
Important information
U
Do not put the JURA or any individual parts in
the dishwasher.
U
Switch your JURA off at the power switch
before any cleaning operation. Always wipe
the JURA with a damp cloth rather than a wet
one, and protect it from prolonged exposure
to water splash.
U
On models with glass cup grille: Do not sub-
ject the glass cup grille to shock or impact.
U
Only connect the machine to the mains volt-
age in accordance with the information on the
rating plate. The rating plate is located on the
underside of your JURA. Further technical data
is provided in these instructions for use (see
Chapter 9 ‘Technical data’).
U
Connect the JURA directly to a domestic power
socket. Using multi-socket adapters or exten-
sion cords may cause overheating.
U
Please only use original JURA maintenance
products. Use of products that are not explic-
itly recommended by JURA could damage the
machine.
U
Do not use alkaline cleaning agents; only use
a soft cloth and mild cleaning agents.
U
Do not use any coffee beans treated with addi-
tives or caramelised coffee beans.
U
Only fill the water tank with fresh, cold water.
U
Switch the machine off at the power switch if
you are going to be absent for a longer period
of time.
U
Children may not clean or service the machine
unless supervised by a responsible person.
U
Do not allow children to play with the machine.
U
Keep children under the age of 8 away from
the machine, or supervise them constantly.
9
Important information
U
Children aged 8 and over may only operate
the machine without supervision if they have
been instructed in how to use it safely. Chil-
dren must be able to recognise and under-
stand the potential dangers arising from incor-
rect use.
People, including children, who
U
do not have the physical, sensory or mental
capabilities to use the machine safely or
U
are inexperienced or lack knowledge in how to
use the machine safely
must be supervised by a responsible person when
using it, or must be instructed in how to use it cor-
rectly.
Safety when handling the CLARIS Smart filter car-
tridge:
U
Filter cartridges should be kept out of the
reach of children.
U
Store filter cartridges in a dry place in the
sealed packaging.
U
Protect cartridges from heat and direct sun-
light.
U
Do not use damaged filter cartridges.
U
Do not open filter cartridges.
10
1 Preparing and using for the first time
1 Preparing and using for the first time
Visit us on the Internet. You can download short operating instruc-
tions for your machine from the JURA website (www.jura.com). You
will also find interesting and up-to-date information on your JURA
and on every aspect of coffee.
When setting up your JURA, please note the following:
U
Place the JURA on a horizontal surface that is not sensitive to
water.
U
Choose a spot for your JURA which protects the machine
against overheating. Ensure that the ventilation slots are not
covered.
The bean container has an aroma preservation cover. This will ensure
that your coffee beans retain their aroma for longer.
Coffee beans which have been treated with additives (e.g. sugar),
ground coffee or freeze-dried coffee will damage the grinder.
T Only use roasted, untreated coffee beans to fill the bean
container.
T Open the bean container cover and remove the aroma
preservation cover.
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans, then close the
aroma preservation cover and the bean container cover.
When you use the machine for the first time, you must set the water
hardness. If you do not know the hardness of your water, you can
find this out first. Use the Aquadur® test strips supplied with the
machine.
T Hold the test strip briefly (for 1second) under flowing water.
Shake off the water.
JURA on the Internet
Setting up the machine
Filling the bean container
CAUTION
Determining the water
hardness
11
1 Preparing and using for the first time
T Wait for about 1minute.
T You will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
When using the machine for the first time, you can choose whether
you want to operate JURA with or without the CLARIS Smart filter
cartridge. As well as limescale, the filter cartridge filters many other
substances that impair aroma and flavour out of the water. These
substances may negatively affect the coffee. To enjoy the best qual-
ity coffee at all times, we recommend that you use CLARIS Smart.
If the machine is operated with a defective mains cable, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged or has a defective
mains cable.
Precondition:The bean container has been filled.
T Insert the mains plug into a power socket.
T Press the On/Off button Q to switch the JURA on.
‘Sprachauswahl’ / ‘Deutsch’
E To view more languages, turn the Rotary Switch.
T Turn the Rotary Switch until the required language is dis-
played, e.g.
‘English’.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display to confirm the setting.
‘Water hardness’
E If you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
T Turn the Rotary Switch to change the water hardness set-
ting, e.g. to
‘25°dH’.
First-time use
J
WARNING
12
1 Preparing and using for the first time
T Press the ‘Save’ button.
‘Saved’ appears briefly on the display.
‘Insert filter’
E Now decide whether you want to operate your JURA with or
without a CLARIS Smart filter cartridge.
Operation with filter cartridge: go straight to the next section.
Operation without filter cartridge: see Chapter 1 ‘Preparing and
using for the first time – First-time use without filter cartridge
activation’.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Place one receptacle under the hot-water spout and another
under the cappuccino frother.
T Remove the water tank and rinse it with cold water.
T Open the filter holder.
T Fit the filter cartridge extension supplied on top of a CLARIS
Smart filter cartridge .
T Insert the filter cartridge with its extension into the water
tank.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted
the filter cartridge.
‘Filter operation’ / ‘Saved’
‘Filter is being rinsed’
, water flows out of the hot-water
spout.
Rinsing of the filter stops automatically after approximately
300ml.
First-time use with filter
cartridge activation
CAUTION
13
1 Preparing and using for the first time
‘System is filling’, water flows out of the cappuccino frother.
‘Empty drip tray’
T Empty the drip tray and put it back into the machine.
T Place a receptacle under the coffee spout.
‘Machine is heating’
‘Machine is rinsing’
, the system is rinsed. The rinse stops
automatically.
‘Please select product’ appears on the display.
Your JURA is ready for use.
E The display shows the products you can prepare.
E If the filter is active, this is indicated by a blue filter symbol in
the top right of the display.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Press the
‘No filter’ button.
‘Descaling mode’ / ‘Saved’
‘Fill water tank’
T Place a receptacle under the cappuccino frother, the coffee
spout and the hot-water spout.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘System is filling’, the system fills up with water.
‘Machine is heating’
‘Machine is rinsing’
, water flows out of the coffee spout. The
rinse stops automatically. Your JURA is ready for use.
E The display shows the products you can prepare.
First-time use without filter
cartridge activation
CAUTION
14
1 Preparing and using for the first time
Your JURA creates fine, creamy, feather-light milk foam with a per-
fect consistency. The most important requirement for frothing milk
is a milk temperature of 4–8°C. We would therefore recommend
using a milk cooler or a milk container.
E Suitable milk containers from JURA are available from special-
ised dealers.
T Remove the protective cover from the cappuccino frother.
T Attach the milk pipe to the cappuccino frother.
T Connect the other end of the milk pipe to a milk container
or a milk cooler.
You have the option of connecting your JURA wirelessly to a
compatible accessory (e.g. the Cool Control Wireless milk cooler). To
do this, the receiver of the Cool Control or the JURA Smart Connect
must be plugged into the service socket.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Connect accessory’ is dis-
played.
T Press the Rotary Switch to enter the programme item.
‘Connect accessory’
T Press the ‘Next’ button.
T Now follow the instructions on the display to connect the
accessory to the JURA.
Connecting milk
Connect accessory
(wireless connection)
15
2 Preparation
2 Preparation
Basic information about preparing drinks:
U
During the grinding operation you can select the coffee
strength of single products by turning the Rotary Switch.
U
During preparation, you can change the preset amounts (e.g.
amount of water or milk) by turning the Rotary Switch.
U
You can stop the machine at any time while a speciality
coffee or hot water is being prepared. To do this, press the
‘’ button or the Rotary Switch.
Coffee tastes best served hot. A cold porcelain cup cools the bever-
age – and impairs the taste. We therefore recommend prewarming
the cups. The full coffee aroma can develop only in prewarmed cups.
You can purchase a JURA cup warmer from your specialised dealer.
You can make permanent settings for all products in programming
mode (see Chapter 4 ‘Permanent settings in programming mode –
Adjusting the product settings’).
The JURA offers various ways of preparing a speciality coffee, milk or
hot water:
U
Preparation using the start screen: Simply press the corre-
sponding preparation button for the product shown on the
display (start screen) that you want.
The following products are displayed as standard:
U
‘Cappuccino’
U
‘Latte macchiato’
U
‘1 portion milk’
U
‘Espresso’
U
‘Coffee’
U
‘Hot water’
U
Using the product selector view (Rotary Selection): Only
some of the products you can prepare are shown on the start
screen. As soon as you turn the Rotary Switch, more products
are displayed in a product selector view.
Turn the Rotary Switch to bring the product you want into
focus. Start preparation by pressing the Rotary Switch.
Ways of preparing a
beverage
16
2 Preparation
The following additional products are shown in the product
selector view:
U
‘Ristretto’
U
‘Flat White’
U
‘Macchiato’
E The product selector view disappears automatically after
10seconds if no preparation is started.
E You can move any of the standard products programmed in
your JURA to your preferred position on the start screen or in
the product selector and make it one of your favourites. You
can duplicate and personalise your favourite speciality coffees
by giving them a new product name and individual settings
(e.g. amount and coffee strength) (see Chapter 4 ‘Permanent
settings in programming mode – Adding products to the start
screen, duplicating and personalising’). Please note that the
descriptions provided in the following sections always refer to
the default settings.
Example:Proceed as follows to prepare one coffee.
T Place a cup under the coffee spout.
T Press the
‘Coffee’ button.
Preparation starts.
‘Coffee’ and the coffee strength are dis-
played. The preset amount of water for coffee flows into the
cup.
Preparation stops automatically. Your JURA is once more
ready for use.
To prepare two speciality coffees, press the appropriate preparation
button twice (within approximately 2 seconds).
Example:Proceed as follows to prepare two espressi.
T Place two cups under the coffee spout.
T Press the
‘Espresso’ button twice (within 2 seconds) to start
preparation.
‘2x Espresso’appears and the preset amount of water flows
into the cups.
Preparation stops automatically. Your JURA is once more
ready for use.
Ristretto, espresso and
coffee
Two ristretti, two
espressi and two coffees
17
2 Preparation
Your JURA prepares latte macchiato, cappuccino, flat white and
espresso macchiato at the touch of a button. There is no need to
move the glass or cup.
Example:Proceed as follows to prepare one latte macchiato.
T Place a glass under the cappuccino frother.
T Turn the setting wheel of the cappuccino frother to the Milk
Foam area 5.
T Press the
‘Latte macchiato’ button.
‘Latte macchiato’appears and the preset amount of milk
flows into the glass.
E There is a short interval while the hot milk separates from the
milk foam. This allows the typical layers of a latte macchiato
to form.
Coffee preparation starts. The preset amount of water for
espresso flows into the glass. Preparation stops automati-
cally. appears on the display.
‘Rinse the milk system’
E 15 minutes after preparation, the milk system is automatically
rinsed (see Chapter 5 ‘Maintenance – Automatic milk system
rinsing’). Therefore always place a receptacle under the cap-
puccino frother after preparing milk.
To ensure that the cappuccino frother always works properly,
you must clean it daily when you have been preparing milk (see
Chapter 5 ‘Maintenance – Cleaning the milk system’).
You can choose to use a second coffee variety, for example decaf-
feinated coffee, with the filter funnel for ground coffee.
E Never add more than two level measuring spoons of ground
coffee.
E Use ground coffee which is not ground too finely. Very fine
coffee can block up the system so that the coffee only comes
out in drips.
E If you did not fill the machine with a sufficient amount of
ground coffee,
‘Not enough ground coffee’ is displayed and
the JURA stops the operation.
Latte macchiato,
cappuccino and other
speciality coffees with
m i l k
Ground coffee
18
2 Preparation
E The desired speciality coffee must be prepared within approx-
imately one minute after filling with the ground coffee. Oth-
erwise the JURA stops the operation and is once more ready
for use.
All speciality coffees with ground coffee are always prepared follow-
ing the same model.
Example:Proceed as follows to prepare one espresso using ground
coffee.
T Place an espresso cup under the coffee spout.
T Open the powder chute cover.
‘Please add ground coffee’
T Place one level measuring spoon of ground coffee into the
filler funnel.
T Close the cover of the filler funnel.
‘Please select product’
T Press the ‘Espresso’ button.
Preparation starts.
‘Espresso’appears and the preset amount
of water for espresso flows into the cup.
Preparation stops automatically. Your JURA is once more
ready for use.
It is easy to permanently adjust the amount of water for all single
products to the cup size. Adjust the amount once as shown in the
following example. Every time you prepare a drink in the future, this
amount will be dispensed.
Example: Proceed as follows to permanently set the amount of
water for one coffee.
T Place a cup under the coffee spout.
T Press and hold the
‘Coffee’ button until ‘Enough coffee?
Press button’
appears.
T Release the
‘Coffee’ button.
Preparation starts and the coffee flows into the cup.
T Press any button as soon as there is sufficient coffee in the
cup.
Preparation stops.
‘Saved’ appears briefly on the display. The
set amount of water for one coffee is permanently stored.
Your JURA is once more ready for use.
Permanently setting the
amount of water for the
cup size
19
2 Preparation
E You can alter this setting at any time by repeating the above
procedure.
E You can also permanently set the amounts for all single prod-
ucts in programming mode (see Chapter 4 ‘Permanent set-
tings in programming mode – Adjusting the product set-
tings’).
You can adjust the grinder to suit the degree of roast of your coffee.
If you adjust the consistency of grind when the grinder is not oper-
ating, the grinder adjustment switch could be damaged.
T Only adjust the consistency of grind when the grinder is run-
ning.
The consistency of grind is correct if the coffee flows regularly from
the coffee spout. In addition a fine, thick crema forms.
Example: Proceed as follows to change the consistency of grind
during the preparation of an espresso.
T Place a cup under the coffee spout.
T Open the storage compartment cover.
T Press the
‘Espresso’ button to start preparation.
T Turn the grinder adjustment switch to the desired position
while the grinder is running.
The preset amount of water flows into the cup. Preparation
stops automatically.
T Close the storage compartment cover.
There is a danger of scalding from hot water splashes.
T Avoid direct contact with the skin.
T Place a cup under the hot-water spout.
T Press the
‘Hot water’ button.
‘Hot water’, the preset amount of water flows into the cup.
Preparation stops automatically.
‘Please select product’
appears on the display.
Adjusting the grinder
CAUTION
Hot water
J
CAUTION
20
3 Daily operation
3 Daily operation
Daily maintenance of the machine and hygiene when handling milk,
coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Open the water tank cover.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Close the water tank cover.
Daily maintenance of the machine and hygiene when handling milk,
coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
T Place a receptacle under the coffee spout.
T Press the On/Off button Q to switch the JURA on.
‘Welcome to JURA’
‘Machine is heating’
‘Machine is rinsing’
, the system is rinsed.
The rinse stops automatically.
‘Please select product’
appears on the display. Your JURA is ready for use.
Filling the water tank
CAUTION
Switching on the
machine
21
3 Daily operation
To ensure that you get many years of reliable service out of your
JURA and to guarantee the optimum coffee quality, the machine
requires daily maintenance.
T Pull out the drip tray.
T Empty the coffee grounds container and the drip tray. Rinse
them both with warm water.
E Always empty the coffee grounds container when the machine
is switched on. This is the only way of resetting the coffee
grounds counter.
T Refit the coffee grounds container and the drip tray.
T Rinse the water tank with clean water.
T Clean the cappuccino frother (see Chapter 5
‘Maintenance – Cleaning the milk system’).
T Remove the milk pipe and rinse it thoroughly under running
water.
T Dismantle and rinse the cappuccino frother (see Chapter 5
‘Maintenance – Dismantling and rinsing the cappuccino
frother’).
T Wipe the surface of the machine with a clean, soft, damp
cloth (e.g. microfibre cloth).
Carry out the following maintenance actions regularly or as
required:
U
In the interests of hygiene, we recommend changing the milk
pipe and interchangeable milk spout on a regular basis
(approximately every 3 months). Replacements are available
from specialised dealers.
U
Clean the inside of the water tank, e.g. with a brush. Further
information about the water tank is provided in these instruc-
tions for use (see Chapter 5 ‘Maintenance – Descaling the
water tank’).
U
Traces of milk and coffee may stick to the top and bottom of
the cup grille. If this happens, clean the cup grille.
Daily maintenance
Regular maintenance
22
3 Daily operation
When the JURA is switched off, the system is automatically rinsed if
a speciality coffee has been prepared. If milk has been prepared, you
will also be prompted to clean the milk system.
T Place one receptacle under the coffee spout and another
under the cappuccino frother.
T Press the On/Off button Q.
E If milk has been prepared, you will be prompted to clean the
milk system (
‘Clean the milk system’). After 10 seconds the
switch-off process continues automatically.
If milk has been prepared but you have not started milk sys-
tem cleaning, the milk system is rinsed first (
‘Milk system is
being rinsed’
).
‘Machine is rinsing’, the system rinses itself.The operation
stops automatically.Your JURA is switched off.
Switching off the
machine
23
4 Permanent settings in programming mode
4 Permanent settings in programming mode
Press the P button to enter programming mode. You can navigate
through the programme items and permanently save the required
settings simply by turning the Rotary Switch and using the multi-
function buttons. The following settings can be made:
Programme item Sub-item Explanation
‘Maintenance
status’
‘Clean’
,
‘Change the filter’ (only if
filter is fitted),
‘Descale’,
‘Clean the milk system’,
‘Rinse’,
‘Maintenance information’
T Here you can start the required maintenance
programme or find out what maintenance
actions are required.
‘Product settings’ ‘Expert mode’
T Select your settings for speciality coffees and
hot water.
‘Classics’
T Replace the products on the start screen and
in the product selector with your favourites.
Duplicate and personalise your favourite
speciality coffees by giving them a new
product name and individual settings.
‘Machine settings’ ‘Choose language’
T Select your language.
‘Switch off after’
T Set the time after which the JURA should
switch off automatically.
‘Save energy’
T Select an energy-saving mode.
‘Factory setting’
T Reset the machine to its factory setting.
‘Units’
T Select the unit for the amount of water.
‘Display’
T Change the display settings.
‘Water hardness’
T Adjust the water hardness.
‘Product counter’,
‘Maintenance counter’
T Keep track of all products prepared and view
the number of maintenance programmes
performed.
‘Version’ Software version
‘Connect accessory’,
‘Disconnect accessories’
T Connect the machine wirelessly to a JURA
accessory or disconnect the connection again.
(Only displayed if the JURA Smart Connect is
being used.)
24
4 Permanent settings in programming mode
In the programme item ‘Product settings’/ ‘Expert mode’ you can
make individual settings for all speciality coffees and hot water. The
following permanent settings can be made:
Product Coffee
strength
Amount More settings
Ristretto,
espresso
10 levels Coffee: 15ml–80ml Temperature (low, normal, high),
Product name
Coffee 10 levels Coffee: 25ml–240ml Temperature (low, normal, high)
Two ristretti,
two espressi,
two coffees
– Coffee: the amount set for
the single product is
doubled.
Temperature (as for single product),
Product name
Latte macchiato 10 levels Coffee: 25ml–240ml
Milk: 0sec.–120sec.
Interval: 0sec.–60sec.
Temperature (low, normal, high),
Product name
Cappuccino,
flat white
10 levels Coffee: 25ml–240ml
Milk: 0sec.–120sec.
Temperature (low, normal, high),
Product name
Espresso
macchiato
10 levels Coffee: 15ml–80ml
Milk: 0sec.–120sec.
Interval: 0sec.–60sec.
Temperature (low, normal, high),
Product name
Portion of milk – Milk: 0sec.–120sec. Product name
Hot water – Water: 25ml–450ml Temperature (low, normal, high),
Product name
Permanent settings in programming mode always follow the same
model.
Example:Proceed as follows to change the amount of water and
coffee strength for one espresso.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Product settings’ is displayed.
T Press the Rotary Switch.
‘Expert mode’
T Press the Rotary Switch to enter the programme item.
‘Expert mode’
T Press the ‘Espresso’ button.
‘Expert mode’ / ‘Espresso’
T Press the Rotary Switch.
‘Espresso’
T Press the Rotary Switch.
Adjusting the product
settings
25
4 Permanent settings in programming mode
T Turn the Rotary Switch to change the coffee strength set-
ting.
T Press the Rotary Switch to confirm the setting.
T Turn the Rotary Switch until the fill volume is in focus.
T Press the Rotary Switch.
T Turn the Rotary Switch to change the fill volume setting.
T Press the Rotary Switch to confirm the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Expert mode’ / ‘Espresso’
T Press the P button to exit programming mode.
In the programme item
‘Product settings’/ ‘Classics’ you will find all
the products stored as standard in your JURA. You can move any of
these products to your preferred position on the start screen or in
the product selector and make it one of your favourites. You can
duplicate and personalise your favourite speciality coffees by giv-
ing them a new product name and individual settings (e.g. amount
and coffee strength).
Example: Proceed as follows to replace
‘Latte macchiato’ on the
start screen with
‘Macchiato’.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Product settings’ is displayed.
T Press the Rotary Switch.
‘Expert mode’
T Turn the Rotary Switch until ‘Classics’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Add to favourites’
T Press the Rotary Switch again.
T Turn the Rotary Switch until
‘Macchiato’ is in focus.
T Press the Rotary Switch.
‘Select position’
T Press the ‘Latte macchiato’ button.
‘Macchiato’ / ‘Do you want to replace the current product?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
‘Product name’
Adding products to the
start screen, duplicating
and personalising
26
4 Permanent settings in programming mode
E You can now give the product you just added a new name.
T Press the
‘Save’ button.
‘Macchiato’
E You can now change various settings for the product. To do
this, briefly press the Rotary Switch to access the various
setting options. Confirm the settings by pressing the
‘Save’ button.
E If you do not want to change any more settings, just press the
‘’ button.
T Press the P button to exit programming mode.
By instructing your JURA to automatically switch itself off, you can
cut down your energy consumption. If this function is activated,
your JURA switches off automatically after the preset time following
the last action on the machine.
You can set the automatic switch-off to 15minutes, 30minutes or
1-9hours.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Switch off after’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Switch off after’
T Turn the Rotary Switch to change the switch-off time.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Switch off after’
T Press the P button to exit programming mode.
Automatic switch-off
27
4 Permanent settings in programming mode
In the programme item ‘Machine settings’ / ‘Save energy’ you
can permanently set an energy-saving mode (Energy Save Mode,
E.S.M.
©
):
U
‘Active’
U
Soon after the last preparation, the JURA stops heating up.
After about 5 minutes the message
‘Energy Save’ is dis-
played.
U
Before you can prepare a speciality coffee, speciality coffee
with milk, or hot water, the machine must heat up.
U
‘Inactive’
U
All speciality coffees, speciality coffees with milk and hot
water can be prepared without having to wait.
Example: Proceed as follows to change the energy-saving mode
from
‘Active’ to ‘Inactive’.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Save energy’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Save energy’
T Turn the Rotary Switch until ‘Inactive’ is displayed.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Save energy’
T Press the P button to exit programming mode.
The harder the water is, the more frequently the JURA needs to
be descaled. It is therefore important to set the water hardness
accurately.
The water hardness was set when the machine was first used. You
can change this setting at any time.
The water hardness can be adjusted on a continuous scale between
1 °dH and 30 °dH.
T Press the P button.
‘Maintenance status’
Energy-saving mode
Setting the water
hardness
28
4 Permanent settings in programming mode
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Water hardness’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Water hardness’
T Turn the Rotary Switch to change the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Water hardness’
T Press the P button to exit programming mode.
In the programme item
‘Machine settings’/ ‘Display’ you can set the
display brightness (as a percentage).
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Display’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Display’
T Turn the Rotary Switch to change the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Display’
T Press the P button to exit programming mode.
In the programme item
‘Machine settings’/ ‘Units’ you can select
the unit used for the amount of water.
Example:Proceed as follows to change the unit for the amount of
water from
‘ml’ to ‘oz’.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Units’ is displayed.
Display settings
Unit for amount of water
29
4 Permanent settings in programming mode
T Press the Rotary Switch to enter the programme item.
‘Units’
T Turn the Rotary Switch until ‘oz’ is displayed.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Units’
T Press the P button to exit programming mode.
In the programme item
‘Machine settings’ / ‘Factory setting’ the
machine can be reset to its factory setting: All user settings (apart
from the ‘filter’ and ‘water hardness’) are reset to factory settings.
Your JURA then switches off.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Factory setting’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Factory setting’ / ‘Reset the machine to the factory set-
tings?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
Your JURA is switched off.
In this programme item you can set the language used by your
JURA.
Example:Proceed as follows to change the language from
‘English’
to
‘Deutsch’.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Press the Rotary Switch to enter the programme item.
‘Choose language’
T Turn the Rotary Switch until ‘Deutsch’ is displayed
Restore factory settings
Language
30
4 Permanent settings in programming mode
T Press the ‘Save’ button.
‘Gespeichert’ appears briefly on the display.
‘Sprachauswahl’
T Press the P button to exit programming mode.
‘Bitte wählen’
In the programme item ‘Machine settings’ you can view the follow-
ing information:
U
‘Product counter’: Number of prepared speciality coffees, milk
and hot water
U
‘Maintenance counter’: Number of maintenance programmes
performed (cleaning, descaling etc.)
U
‘Version’: Software version
Example:Proceed as follows to view the number of speciality cof-
fees prepared.
T Press the P button.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Product counter’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Product counter’
E Turn the Rotary Switch to view the number of other speciality
coffees.
T Press the P button to exit programming mode.
Querying information
31
5 Maintenance
5 Maintenance
Your JURA has the following integrated maintenance programmes:
U
Rinsing the machine
U
Rinsing the milk system in the dual spout
U
Cleaning the milk system in the dual spout (‘Clean the milk
system’
)
U
Changing the filter (‘Change the filter’)
(only if filter is activated)
U
Cleaning the machine (‘Clean’)
U
Descaling the machine (‘Descale’)
(only if filter is not activated)
E Clean or descale the machine, rinse the milk system or change
the filter when you are prompted to do so.
E Press the P button to view a list of the maintenance pro-
grammes (
‘Maintenance status’). When the bar is completely
filled with red, your JURA will prompt you to perform the
appropriate maintenance programme.
E In the interests of hygiene, you should clean the milk system
daily when you have been preparing milk.
You can initiate the rinse operation manually at any time.
T Place a receptacle under the coffee spout.
T Press the P button.
‘Maintenance status’
T Press the Rotary Switch.
‘Clean’
T Turn the Rotary Switch until ‘Rinse’ is displayed.
T Press the Rotary Switch to initiate the rinse operation.
‘Machine is rinsing’, ‘Milk system is being rinsed’, water
flows out of the coffee spout.
The rinse stops automatically.
‘Please select product’
appears on the display.
Rinsing the machine
32
5 Maintenance
15 minutes after milk preparation, the milk system is automatically
rinsed. Therefore always place a receptacle under the cappuccino
frother after preparing milk.
When
‘Rinse the milk system’ is displayed, you can start rinsing by
pressing the Rotary Switch.
To ensure that the cappuccino frother always works properly, you
must clean it daily when you have been preparing milk
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E JURA milk system cleaner is available from specialised dealers.
E To clean the milk system, use the container supplied.
T Press the P button.
‘Maintenance status’
T Press the Rotary Switch.
‘Clean’
T Turn the Rotary Switch until ‘Clean the milk system’ is dis-
played.
T Press the Rotary Switch.
‘Clean the milk system’
T Press the Rotary Switch again.
T Press the
‘Start’ button.
T Remove the milk pipe from the milk container or carton.
T Add milk system cleaner to the front part of the container
up to the bottom mark (indicated by 6).
T Then fill with water up to the upper mark.
T Place the container under the cappuccino frother.
T Turn the setting wheel of the cappuccino frother to the Milk
position z.
Automatic milk system
rinsing
Cleaning the milk system
CAUTION
6
33
5 Maintenance
T Connect the milk pipe to the container.
E To connect the milk pipe to the container correctly, the pipe
must be fitted with a connector.
T Press the
‘Next’ button.
‘Milk system is being cleaned’ appears and the cappuccino
frother and the milk pipe are cleaned.
T During the first brief interruption, set the setting wheel of
the cappuccino frother to the Milk Foam position 5.
‘Water for cleaning milk system’
T Rinse the container thoroughly and fill the front part with
fresh water up to the upper mark.
T Place this under the cappuccino frother and reconnect the
milk pipe to the container.
T Press the
‘Next’ button.
‘Milk system is being cleaned’ appears and the cappuccino
frother and the milk pipe are rinsed with fresh water.
The start screen is displayed.
To make sure the cappuccino frother works properly, and in the
interests of hygiene, it must be dismantled and rinsed daily if you
have been preparing milk.
T Remove the milk pipe and rinse it thoroughly under running
water.
T Carefully pull the cappuccino frother down and off.
T Dismantle the cappuccino frother into its individual parts.
T Rinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in a solution of 250ml cold water and 1 capful of JURA milk
system cleaner. Then rinse the parts thoroughly.
T Reassemble the cappuccino frother.
E Ensure that all individual parts are correctly and firmly con-
nected to ensure correct operation of the cappuccino frother.
T Firmly attach the frother to the connector.
6
Dismantling and rinsing
the cappuccino frother
34
5 Maintenance
Your JURA no longer has to be descaled if you are using the CLARIS
Smart filter cartridge. If you did not insert the filter cartridge the first
time you used the machine, you can do this now as follows.
T Place a receptacle under the hot-water spout.
T Remove and empty the water tank.
T Open the filter holder.
T Fit the filter cartridge extension supplied on top of a CLARIS
Smart filter cartridge .
T Insert the filter cartridge with its extension into the water
tank.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted
the filter cartridge.
‘Filter operation’ / ‘Saved’
‘Filter is being rinsed’
, water flows out of the hot-water
spout.
Rinsing of the filter stops automatically after approximately
300ml.
‘Empty drip tray’
T Empty the drip tray and put it back into the machine.
‘Filter operation’, ‘Filter rinsing complete’
‘Please select product’
appears on the display. Your JURA is
once more ready for use.
E Once the filter cartridge stops working (depending on the
water hardness setting), the JURA will prompt you to change
the filter.
E CLARIS Smart filter cartridges are available from specialised
dealers.
Precondition:
‘Change filter’ is displayed.
Inserting the filter
Changing the filter
35
5 Maintenance
T Place a receptacle under the hot-water spout.
T Remove and empty the water tank.
T Open the filter holder and remove the old CLARIS Smart
filter cartridge and filter extension.
T Fit the filter cartridge extension on top of a new CLARIS filter
cartridge Smart.
T Insert the filter cartridge with its extension into the water
tank.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just changed
the filter cartridge.
‘Change the filter’ / ‘Saved’
‘Filter is being rinsed’
, water flows out of the hot-water
spout.
‘Empty drip tray’
T Empty the drip tray and put it back into the machine.
‘Change the filter’, ‘Filter rinsing complete’
‘Please select product’
appears on the display. Your JURA is
once more ready for use.
After 180preparations or 80switch-on rinses, the JURA will prompt
you to clean it.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E The cleaning programme lasts approximately 20 minutes.
E Do not interrupt the cleaning programme. The quality of
cleaning will be impaired if you do so.
E JURA cleaning tablets are available from specialised dealers.
Precondition:
‘Clean machine’ is displayed.
T Press the P button.
‘Clean’
Cleaning the machine
CAUTION
36
5 Maintenance
T Press the Rotary Switch.
T Press the
‘Start’ button.
T Press the
‘Start’ button again.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Press the Rotary Switch’
T Place one receptacle under the coffee spout and another
under the cappuccino frother.
T Press the Rotary Switch.
‘Machine is being cleaned’, water flows out of the coffee
spout.
The operation is interrupted,
‘Add cleaning tablet’.
T Open the cover of the filler funnel for ground coffee.
T Insert a JURA cleaning tablet into the filler funnel.
T Close the cover of the filler funnel.
‘Press the Rotary Switch’
T Press the Rotary Switch.
‘Machine is being cleaned’, water flows repeatedly out of the
coffee spout and the cappuccino frother.
The operation stops automatically.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
Cleaning is now complete. The start screen is displayed.
The JURA builds up deposits of limescale over time and automati-
cally prompts you to descale it when necessary. The degree of calci-
fication depends on the hardness of your water.
E If you are using a CLARIS Smart filter cartridge, you will not be
prompted to descale.
If the descaling agent comes into contact with the skin or eyes, this
can cause irritation.
T Avoid contact with the skin or eyes.
T Rinse off the descaling agent with clean water. Should you get
any descaling agent in your eye, see a doctor.
Descaling the machine
J
CAUTION
37
5 Maintenance
If the wrong descaling agent is used, the machine could be dam-
aged and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
If the descaling operation is interrupted, there may be damage to
the machine.
T Allow the descaling programme to run to the end.
If the descaling agent comes into contact with sensitive surfaces
(e.g. marble), damage cannot be ruled out.
T Clean up any splashes immediately.
E The descaling programme lasts approximately 45minutes.
E JURA descaling tablets are available from specialised dealers.
Precondition:
‘Decalcify machine’ is displayed.
T Press the P button.
‘Descale’
T Press the Rotary Switch.
T Press the
‘Start’ button.
T Press the
‘Start’ button again.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Pour descaling agent into water tank’
T Remove and empty the water tank.
T Completely dissolve 3JURA descaling tablets in a receptacle
holding 500ml of water. This may take several minutes.
T Pour the solution into the empty water tank and insert it
into the machine.
T Place one receptacle under the hot-water spout and another
under the cappuccino frother.
‘Press the Rotary Switch’
T Press the Rotary Switch.
‘Machine is being descaled’ appears and water flows repeat-
edly out of the hot-water spout and the cappuccino frother.
The operation is interrupted,
‘Empty drip tray’.
CAUTION
CAUTION
CAUTION
38
5 Maintenance
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Fill water tank’
T Remove the water tank and rinse it thoroughly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘Press the Rotary Switch’
T Place a receptacle under the cappuccino frother, the coffee
spout and the hot-water spout.
T Press the Rotary Switch.
‘Machine is being descaled’, The descaling operation is
continued.
The operation is interrupted,
‘Empty drip tray’.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
Descaling is now complete. The start screen is displayed.
E If the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
Coffee beans may be covered with a slight oil film which remains on
the walls of the bean container. These traces may negatively affect
the coffee result. For this reason clean the bean container from time
to time.
Precondition:
‘Fill bean container’ is displayed.
T Switch the machine off with the On/Off button Q.
T Open the bean container cover and remove the aroma
preservation cover.
T Clean the bean container with a soft, dry cloth.
T Fill the bean container with coffee beans, then close the
aroma preservation cover and the bean container cover.
Cleaning the bean
container
39
5 Maintenance
Limescale deposits may form in the water tank. To ensure correct
function of the machine, descale the water tank from time to time.
T Remove the water tank.
T If you use a CLARIS Smart filter cartridge, remove this.
T Completely fill the water tank and dissolve 3 JURA descaling
tablets in it.
T Leave the water tank with the descaling solution for several
hours (e.g. overnight).
T Empty the water tank and rinse it thoroughly.
T If you use a CLARIS Smart filter cartridge, insert this again.
T Fill the water tank with fresh, cold water and reinsert the
tank.
Descaling the water tank
40
6 Display messages
6 Display messages
Message Cause/Result Action
‘Fill water tank’ The water tank is empty. You
cannot prepare any products.
T Fill the water tank (see Chapter 3 ‘Daily
operation – Filling the water tank’).
‘Empty coffee
grounds
container’
The coffee grounds container is
full. You cannot prepare any
products.
T Empty the coffee grounds container
and the drip tray (see Chapter 3 ‘Daily
operation – Daily maintenance’).
‘Drip tray not
fitted’
The drip tray is not inserted
correctly or is not inserted at all.
You cannot prepare any products.
T Fit the drip tray.
‘Fill bean
container’
The bean container is empty. You
cannot prepare any speciality
coffees, but you can prepare hot
water and milk.
T Fill the bean container (see Chapter 1
‘Preparing and using for the first time –
Filling the bean container’).
‘Rinse the milk
system’
The JURA requests a milk system
rinse.
T Press the Rotary Switch to start rinsing
or wait 15 minutes until rinsing starts
automatically (see Chapter 5 ‘Mainte-
nance – Automatic milk system rinsing’).
‘Change filter’ The filter cartridge no longer
works. The JURA is prompting a
filter change.
T Replace the CLARIS Smart filter
cartridge (see Chapter 5 ‘Maintenance –
Changing the filter’).
‘Clean machine’ The JURA is prompting you to
clean it.
T Perform cleaning (see Chapter 5
‘Maintenance – Cleaning the machine’).
‘Decalcify
machine’
The JURA is prompting you to
descale it.
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the machine’).
‘Not enough
ground coffee’
There is insufficient ground coffee
in the machine; the JURA stops the
operation.
T The next time you prepare a beverage,
add more ground coffee (see Chapter 2
‘Preparation – Ground coffee’).
‘Machine too
hot for
maintenance’
The system is too hot to start a
maintenance programme.
T Wait for several minutes until the
system has cooled or prepare a
speciality coffee or hot water.
41
7 Troubleshooting
7 Troubleshooting
Problem Cause/Result Action
Insufficient foam is
produced when the
milk is frothed or milk
sprays from the
cappuccino frother.
The cappuccino frother is
dirty.
T Clean the cappuccino frother (see
Chapter 5 ‘Maintenance – Cleaning the
milk system’).
T Dismantle and rinse the cappuccino
frother (see Chapter 5 ‘Maintenance –
Dismantling and rinsing the cappuccino
frother’).
Coffee only comes out
in drips when it is being
prepared.
The coffee is ground too
finely and obstructs the
system. The water
hardness may not have
been correctly set.
T Set the grinder to a coarser setting (see
Chapter 2 ‘Preparation – Adjusting the
grinder’).
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the machine ’).
‘Fill water tank’ is
displayed although the
water tank is full.
The water tank float is
trapped.
T Descale the water tank (see Chapter 5
‘Maintenance – Descaling the water
tank’).
Little or no water or
steam comes out of the
cappuccino frother. The
pump is very quiet.
The connector of the
cappuccino frother may be
blocked by milk residues or
limescale fragments
loosened during descaling.
T Remove the cappuccino frother.
T Unscrew the black connector with the
aid of the hexagonal hole on the
measuring spoon for ground coffee.
T Clean the connector thoroughly.
T Screw the connector back on by hand.
T Carefully tighten it using the hexagonal
hole on the measuring spoon, turning by
no more than a quarter of a rotation.
Grinder is making a
very loud noise.
There are foreign objects in
the grinder.
T Contact customer support in your
country (see Chapter 11 ‘JURA contact
details/ Legal information’).
‘Error2’ or ‘Error5’ is
displayed.
If the machine has been
exposed to the cold for a
long period of time,
heating may be disabled
for safety reasons.
T Warm the machine at room
temperature.
42
7 Troubleshooting
Problem Cause/Result Action
Other
‘Error’ messages
are displayed.
–
T Switch the JURA off with the On/Off
button Q. Contact customer support in
your country (see Chapter 11 ‘JURA
contact details/ Legal information’).
E If you were unable to solve the problem, contact customer
support in your country (see Chapter 11 ‘JURA contact details/
Legal information’).
43
8 Transport and environmentally friendly disposal
8 Transport and environmentally friendly disposal
Keep the packaging for your JURA. It should be used to protect the
machine during transport.
In order to protect the JURA from frost during transport, the system
must be emptied.
T Remove the milk pipe from the cappuccino frother.
T Place a receptacle under the cappuccino frother.
T Turn the Rotary Switch until
‘1 portion milk’ is in focus.
T Press the Rotary Switch.
‘1 portion milk’ appears and hot steam is discharged from
the cappuccino frother.
T Remove and empty the water tank.
T Turn the Rotary Switch until
‘60sec.’ is displayed.
Steam will continue to be discharged from the cappuccino
frother until the system is empty.
‘Fill water tank’
T Press the On/Off button Q.
Your JURA is switched off.
Please dispose of old machines in an environmentally neutral way.
H
Old machines contain valuable, recyclable materials which should
be recycled. Please therefore dispose of old machines via suitable
collection systems.
Transport/ Emptying the
system
Disposal
44
9 Technical data
9 Technical data
Voltage 220–240V~, 50Hz
Power 1450W
Conformity mark
A
Energy consumption
‘Save energy’ / ‘Active’
approx. 6Wh
Energy consumption
‘Save energy’ / ‘Inactive’
approx. 11Wh
Pump pressure static, max. 15bar
Holding capacity of water tank 2.1l
Holding capacity of bean container 250g
Holding capacity of coffee grounds
container
max. 16 portions
Cable length approx. 1.1m
Weight 10.7kg
Dimensions (W×H×D) 28.5 × 34.2 × 43.3cm
45
10 Index
10 Index
A
Adding products to the start screen 25
Addresses 48
Adjusting the product settings 24
Aroma preservation cover
Bean container with aroma preservation
cover 4
Automatic switch-off 26
B
Bean container
Bean container with aroma preservation
cover 4
Cleaning 38
Filling 10
Bus bar
Technical data 44
Button
On/Off button 5
P button (programming) 5
C
Caffè latte 17
Cappuccino 17
Cappuccino frother cleaning
Cleaning the milk system 32
Changing the product assigned to a button
25
CLARIS Smart filter cartridge
Change 34
Insert 34
Cleaning
Bean container 38
Machine 35
Coffee 16
Two coffees 16
Coffee grounds container 4
Coffee spout
Height- and width-adjustable coffee
spout 4
Connect accessory 14
Consistency of grind
Adjusting the grinder 19
Grinder adjustment switch 4
Contact details 48
Cover
Bean container 4
Filler funnel for ground coffee 4
Storage compartment 4
Water tank 4
Cup grille 4
Customer support 48
D
Daily maintenance 21
Descaling
Machine 36
Water tank 39
Dismantling
Cappuccino frother 33
Dismantling and rinsing
the cappuccino frother 33
Display 5
Display messages 40
Display settings 28
Disposal 43
Double product 16
Drip tray 4
E
Emptying the system 43
Energy-saving mode 27
Errors
Troubleshooting 41
Espresso 16
Two espressi 16
Espresso macchiato 17
F
Factory settings
Restore factory settings 29
Filler funnel
Filler funnel for ground coffee 4
Filling
Bean container 10
Water tank 20
Filter
Change 34
Insert 34
First-time use 11
With filter cartridge activation 12
Without filter cartridge activation 13
46
10 Index
Flat white 17
Frother
Cappuccino frother 4
G
Grinder adjustment switch 4
Ground coffee 17
Measuring spoon for ground coffee 4
H
Homepage 10
Hotline 48
Hot water 19
Hot-water spout 4
I
Instant coffee
Ground coffee 17
Interchangeable milk spout 4
Internet 10
J
JURA
Contact details 48
Internet 10
L
Language 29
Latte macchiato 17
M
Machine
Cleaning 35
Daily maintenance 21
Descaling 36
Regular maintenance 21
Rinsing 31
Setting up 10
Switching off 22
Switching on 20
Mains cable 4
Maintenance 31
Daily maintenance 21
Regular maintenance 21
Measuring spoon for ground coffee 4
Messages, display 40
Milk
Connecting milk 14
Milk spout 4
Milk system
Cleaning 32
Milk system rinsing 32
P
Permanently setting the water for the cup
size 18
Permanent settings in programming mode
23
Personalising products 25
Preparation 15, 17
At the touch of a button 15
Caffè latte 17
Cappuccino 17
Coffee 16
Espresso 16
Espresso macchiato 17
Flat white 17
Ground coffee 17
Hot water 19
Latte macchiato 17
Ristretto 16
Two coffees 16
Two espressi 16
Two ristretti 16
Two speciality coffees 16
Using the product selector 15
Preparation options 15
Problems
Troubleshooting 41
Product selector view 15
Product settings
Adjusting 24
Programming mode 23
Adding products to the start screen 25
Automatic switch-off 26
Display settings 28
Duplicating products 25
Energy-saving mode 27
Language 29
Querying information 30
Restore factory settings 29
Setting the water hardness 27
Unit for amount of water 28
Proper use 6
47
10 Index
Q
Querying information 30
R
Regular maintenance 21
Rinsing
Machine 31
Ristretto 16
Two ristretti 16
Rotary Selection 15
Rotary Switch 5
S
Safety 6
Safety information 6
Service socket 4
Settings
Permanent settings in programming
mode 23
Setting up
Setting up the machine 10
Short operating instructions 10
Spout
Hot-water spout 4
Switching off 22
Switching on 20
Switch-off
Automatic switch-off 26
Symbol description 3
T
Technical data 44
Tel 48
Transport 43
Troubleshooting 41
Two products 16
U
Unit for amount of water 28
Use, First-time 11
W
Water hardness
Determining the water hardness 10
Setting the water hardness 27
Water tank 4
Descaling 39
Filling 20
Website 10
Wireless connection 14
48
11 JURA contact details/ Legal information
11 JURA contact details/ Legal information
JURA Elektroapparate AG
Kaffeeweltstrasse 10
CH-4626 Niederbuchsiten
Tel. +41 (0)62 38 98 233
@ You will find additional contact details for your country at
www.jura.com.
The machine complies with the following directives:
U
2014/35/EU– Low Voltage Directive
U
2014/30/EU– Electromagnetic Compatibility
U
2009/125/EC– Ecodesign Directive
U
2011/65/EU– RoHS Directive
We reserve the right to make technical changes. The diagrams used
in these instructions for use are for illustration purposes only and do
not represent the original colours of the machine. Some details of
your JURA may vary.
Your opinion is important to us! Use the contact details at
www.jura.com.
The instructions for use contain information which is protected by
copyright. It is not permitted to photocopy these instructions for use
or translate them into another language without the prior written
consent of JURA Elektroapparate AG.
Directives
Technical changes
Feedback
Copyright
J72926/J6-J600/en/201608
