Leading Edge
Dimmer Controller
Installation Instructions
Instructions d’installation
Installationsanweisungen
Instrucciones de instalación
Istruzioni per l’installazione
Installatie-instructies
インストール 手 順
安装指示
DLE410
RJ12
X 4
X 4
X 4
174 mm (6.85 in)
212 mm (8.34 in)
340 mm (13.38 in)
176 mm (6.92 in)
320 mm (12.59 in)
200 mm
(7.87 in)
200 mm
(7.87 in)
200 mm
(7.87 in)
200 mm
(7.87 in)
30 mm
(1.18 in)
30 mm
(1.18 in)
1
40° C (104° F)
0° C (32° F)
≤
90%
IEC Pollution Degree II
Devices must be installed by a
qualied electrician in accordance with
all national and local electrical and
construction codes and regulations.
Les appareils doivent être installés par un
électricien diplômé conformément à tous les
codes et réglementations électriques et de
construction nationaux et locaux.
Die Geräte sind von einem qualizierten Elektriker
in Übereinstimmung mit allen geltenden
Vorschriften zu installieren.
Los dispositivos deben ser instalados por un
electricista calicado y cumpliendo todas las
normas y regulaciones, tanto nacionales como
locales, sobre instalaciones eléctricas y obras.
I dispositivi devono essere installati da un
elettricista qualicato in conformità con le norme
locali e nazionali vigenti in materia di costruzioni
edilizie e installazione di impianti elettrici.
De apparaten moeten worden aangebracht
door een gekwaliceerde elektricien en in
overeenstemming met alle nationale en
plaatselijke elektriciteits- en bouwvoorschriften.
装置を取り付ける際は、資格のある電気技師に依頼し、
国および地域の電気および建設に関するすべての法令に
従 ってください 。
根据国家/地区及当地的电气与建筑规范和法规，该设
备必须由有资质的电工进行安装。
.
2
2
3
5
N
N
N
N
E
AUX/
UL924
+12 V
D +
D -
GND
CH1
CH2
CH3
CH4
µP
N
L
SHLD
RS-485 DyNet/DMX Rx
RJ12
1
230 V
± 14%
40 A
12 V 200 mA
SELV/Class 2 (UL)
N
CH1
CH2
L
L
N
N
CH3
CH4
L
L
N
40 A10 A/CH
≤ 6 mm
2
9+ AWG
0.6 Nm
5.5 Lb-in
≤ 5 mm
2
10+ AWG
2.0 Nm
17.7 Lb-in
4
6
IEC Overvoltage Category III
3
7
0.56 Nm
5 Lb-in
0.3-2.5 mm
2
22-12 AWG
RS-485 DyNet
GND AUX/UL924
< 20 m
SHLD
GND
D+
D-
+12 V
AUX/
UL924
≤ 2 A
≤ 20 mm (0.79 in)
+12 V
RS-485 DyNet
+12 V
D-
D+
GND
GND
GND
GND
D+
D–
+12 V
+12 V
1
2
3
4
5
6
8 A 8 B
N
L1
1.4 Nm
12.4 Lb-in
≤ 10 mm
2
6+ AWG
2.0 Nm
17.7 Lb-in
≤ 16 mm
2
6+ AWG
9
RS-485 DyNet
8
Apply de-rating for electronic and LED loads.
The manufacturer is not responsible for dimmable lamp selection. Each lamp/dimmer combination must be tested for compatibility prior to installation.
This is a class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures.
Professional dimmers rated > 1000 W are out of scope of EN 61000-3-2.
AZZ 390 1021 R15
© 2021 Signify Holding. All rights reserved. Specications are subject to
change without notice. No representation or warranty as to the accuracy or
completeness of the information included herein is given and any liability
for any action in reliance thereon is disclaimed. Philips and the Philips
Shield Emblem are registered trademarks of Koninklijke Philips N.V. All other
trademarks are owned by Signify Holding or their respective owners.
www.lighting.philips.com/dynalite
