Z6 Instructions for Use
P
R
O
F
E
S
S
I
O
N
A
L
A
R
O
M
A
G
R
I
N
D
E
R
2
Control elements 4
Important information 6
Proper use ......................................................................................................................................................6
For your safety ...............................................................................................................................................6
1 Preparing and using for the first time 10
JURA on the Internet ....................................................................................................................................10
Setting up the machine ..............................................................................................................................10
Filling the bean container ...........................................................................................................................10
Determining the water hardness ...............................................................................................................11
First-time use .................................................................................................................................................11
Connecting milk ........................................................................................................................................... 13
Connect accessory (wireless connection) ................................................................................................13
2 Preparation 15
Ways of preparing a beverage ...................................................................................................................15
Ristretto, espresso and coffee ....................................................................................................................16
Two ristretti, two espressi and two coffees .............................................................................................17
Latte macchiato, cappuccino and other speciality coffees with milk .................................................17
Caffè Barista and lungo Barista .................................................................................................................18
Ground coffee ...............................................................................................................................................18
Adjusting the grinder ..................................................................................................................................19
Hot water ......................................................................................................................................................20
3 Daily operation 21
Filling the water tank ...................................................................................................................................21
Switching on the machine ..........................................................................................................................21
Daily maintenance .......................................................................................................................................21
Regular maintenance .................................................................................................................................22
Switching off the machine .........................................................................................................................22
4 Permanent settings in programming mode 23
Product settings ..........................................................................................................................................24
Adjusting the product settings .................................................................................................................24
Storing and personalising products ........................................................................................................26
Automatic switch-off .................................................................................................................................. 27
Smart mode .................................................................................................................................................28
Setting the water hardness .......................................................................................................................28
Display brightness .......................................................................................................................................29
Unit for amount of water ...........................................................................................................................29
Restore factory settings .............................................................................................................................30
Water tank illumination .............................................................................................................................30
Language .......................................................................................................................................................31
Querying information ................................................................................................................................32
Table of contents
Your Z6
3
Table of contents
Warnings
J WARNING
J CAUTION
Always take note of any information marked with the words CAUTION or
WARNING and a warning sign. The signal word WARNING draws your attention
to potential serious injury, and the signal word CAUTION to potential minor
injury.
CAUTION CAUTION draws your attention to potential damage to the machine.
Symbols used
T
Prompt to take action. This symbol means that you are being prompted to
perform some action.
E
Information and tips to make it even easier to use your Z6.
‘Coffee’ Display
Symbol description
5 Maintenance 33
Rinsing the machine ................................................................................................................................... 33
Automatic milk system rinsing .................................................................................................................33
Cleaning the milk system ..........................................................................................................................34
Dismantling and rinsing the dual spout ................................................................................................. 35
Inserting/changing the filter ......................................................................................................................36
Cleaning the machine ................................................................................................................................ 37
Descaling the machine ..............................................................................................................................39
Cleaning the bean container ......................................................................................................................41
Descaling the water tank ............................................................................................................................41
6 Display messages 42
7 Troubleshooting 43
8 Transport and environmentally friendly disposal 45
Transport/ Emptying the system .............................................................................................................45
Disposal .........................................................................................................................................................45
9 Technical data 46
10 Index 47
11 JURA contact details/ Legal information 52
4
Control elements
Control elements
4
P
R
O
F
E
S
S
I
O
N
A
L
A
R
O
M
A
G
R
I
N
D
E
R
7
3
6
11
10
8
9
5
12
13
2
1
1 Cover for powder chute for ground coffee
2 Powder chute for ground coffee
3 Water tank
4 Mains cable (permanently connected
or plug-in) (back of the machine)
5 Hot-water spout
6 Coffee grounds container
7 Drip tray
8 Cover cap for grinder adjustment switch
9 Grinder adjustment switch
10 On/Off button Q
11 Bean container with aroma preservation
cover
12 Height- and width-adjustable dual spout
13 Cup grille
5
Control elements
3
2
1
Front
1 Display
2 Multi-function buttons (button function
depends on what is shown in the display)
Top of the machine
3 Rotary Switch
Back of the machine: Service socket with JURA Smart Connect
Accessories
Container for milk system
cleaning
Measuring spoon for ground
coffee
Filler funnel for ground coffee
6
6
Important information
Important information
The machine is designed and intended for private
domestic use. It should only be used for coffee
preparation and to heat milk and water. Use for any
other purpose will be deemed improper. JURA Ele-
ktroapparate AG cannot accept any responsibility
for the consequences of improper use.
Before using the machine read these instructions
for use thoroughly and completely and comply
with the instructions they contain. A warranty ser-
vice is not applicable for damage or defects caused
by non-compliance with the instructions for use.
Keep these instructions for use close to the machine
and pass them on to the next user.
Please carefully read and observe the important
safety information set out below.
To avoid danger of potentially fatal electric shock:
U
Never use a machine which is damaged or has
a defective mains cable.
U
In the event of signs of damage, for example if
there is a smell of burning, unplug the machine
immediately from the power supply and con-
tact JURA service.
U
If the mains cable of this machine is damaged,
it must be repaired either directly by JURA or
by an authorised JURA service centre.
U
Make sure that the Z6 and the mains cable are
not located close to hot surfaces.
U
Be careful to ensure that the mains cable is not
trapped and does not rub against sharp edges.
Proper use
For your safety
J
7
Important information
U
Never open and repair the machine yourself.
Do not modify the machine in any way that is
not described in these instructions for use. The
machine contains live parts. If opened, there is
a danger of potentially fatal injury. Repairs
may only be carried out by authorised JURA
service centres, using original spare parts and
accessories.
U
To completely and safely disconnect the
machine from the power supply, first switch
off the Z6 using the On/Off button Q. Only
then should you remove the mains plug from
the power socket.
There is a risk of scalds or burns on the spouts.
U
Place the machine out of the reach of children.
U
Do not touch any hot parts. Use the handles
provided.
U
Be careful to ensure that the dual spout is cor-
rectly installed and clean. If it is incorrectly fit-
ted or becomes blocked, its parts might come
off. There is a danger of parts being swallowed.
A defective machine is not safe and could cause
injury or fire. To avoid damage and any associated
risk of injury or fire:
U
Never allow the mains cable to loosely hang
down. The mains cable could pose a tripping
hazard or become damaged.
U
Protect the Z6 from environmental influences
such as rain, frost and direct sunlight.
U
Do not immerse the Z6, mains cable or con-
nections in water.
U
Do not put the Z6 or any individual parts in the
dishwasher.
8
Important information
U
Before cleaning, switch the Z6 off with the On/
Off button Q. Always wipe the Z6 with a damp
cloth rather than a wet one, and protect it from
prolonged exposure to water splash.
U
Only connect the machine to the mains volt-
age in accordance with the information on the
rating plate. The rating plate is located on the
underside of your Z6. Further technical data is
provided in these instructions for use (see
Chapter 9 ‘Technical data’).
U
Connect the Z6 directly to a domestic power
socket. Using multi-socket adapters or exten-
sion cords may cause overheating.
U
Please only use original JURA maintenance
products. Use of products that are not explic-
itly recommended by JURA could damage the
machine.
U
Do not use alkaline cleaning agents; only use
a soft cloth and mild cleaning agents.
U
Do not use any coffee beans treated with addi-
tives or caramelised coffee beans.
U
Only fill the water tank with fresh, cold water.
U
Switch the machine off with the On/Off
button Q if you are going to be absent for a
longer period of time and remove the mains
plug from the power socket.
U
Children may not clean or service the machine
unless supervised by a responsible person.
U
Do not allow children to play with the machine.
U
Keep children under the age of 8 away from
the machine, or supervise them constantly.
9
Important information
U
Children aged 8 and over may only operate
the machine without supervision if they have
been instructed in how to use it safely. Chil-
dren must be able to recognise and under-
stand the potential dangers arising from incor-
rect use.
People, including children, who
U
do not have the physical, sensory or mental
capabilities to use the machine safely or
U
are inexperienced or lack knowledge in how to
use the machine safely
must be supervised by a responsible person when
using it, or must be instructed in how to use it
correctly.
Safety when handling the CLARIS Smart filter
cartridge:
U
Filter cartridges should be kept out of the
reach of children.
U
Store filter cartridges in a dry place in the
sealed packaging.
U
Protect cartridges from heat and direct
sunlight.
U
Do not use damaged filter cartridges.
U
Do not open filter cartridges.
10
1 Preparing and using for the first time
1 Preparing and using for the first time
Visit us on the Internet. You can download short operating instruc-
tions for your machine from the JURA website (www.jura.com). You
will also find interesting and up-to-date information on your Z6 and
on every aspect of coffee.
If you need assistance with using your machine, you can find this at
www.jura.com/service.
When setting up your Z6, please note the following:
U
Place the Z6 on a horizontal surface that is not sensitive to
water.
U
Choose a spot for your Z6 which protects the machine against
overheating. Ensure that the ventilation slots are not covered.
The bean container has an aroma preservation cover. This will ensure
that your coffee beans retain their aroma for longer.
Coffee beans which have been treated with additives (e.g. sugar),
ground coffee or freeze-dried coffee will damage the grinder.
T Only use roasted, untreated coffee beans to fill the bean con-
tainer.
T Remove the aroma preservation cover.
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
JURA on the Internet
Setting up the machine
Filling the bean container
CAUTION
11
1 Preparing and using for the first time
When you use the machine for the first time, you must set the water
hardness. If you do not know the hardness of your water, you can
find this out first. Use the Aquadur® test strips supplied with the
machine.
T Hold the test strip briefly (for 1second) under flowing water.
Shake off the water.
T Wait for about 1minute.
T You will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
If the machine is operated with a defective mains cable, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged or has a defective
mains cable.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
Precondition:The bean container has been filled.
T For machines with a plug-in mains cable: Connect the mains
cable to the machine.
T Insert the mains plug into a power socket.
T Press the On/Off button Q to switch the Z6 on.
‘Sprachauswahl’ / ‘Deutsch’
E To view more languages, turn the Rotary Switch.
T Turn the Rotary Switch until the required language is dis-
played, e.g.
‘English’.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display to confirm the setting.
‘Water hardness’
Determining the water
hardness
First-time use
J
WARNING
CAUTION
12
1 Preparing and using for the first time
E If you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
T Turn the Rotary Switch to change the water hardness
setting, e.g. to
‘25°dH’.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Insert filter’
T Place a receptacle under the dual spout.
T Remove the water tank and rinse it with cold water.
T Fit the filter cartridge extension supplied on top of a CLARIS
Smart filter cartridge .
T Insert the filter cartridge with its extension into the water
tank.
T Turn the filter cartridge clockwise until it audibly clicks into
place.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted
the filter cartridge.
‘Use filter’ / ‘Saved’
‘Filter is being rinsed’
, the filter is rinsed. The water flows
directly into the drip tray.
‘System is filling’, water flows out of the dual and hot-water
spout.
‘Empty drip tray’
T Empty the drip tray and put it back into the machine.
T Place a receptacle under the dual spout.
‘Machine is heating’
‘Machine is rinsing’
, the system is rinsed. The rinse stops
automatically. The start screen is displayed. Your Z6 is ready
for use.
E The display shows the products you can prepare.
13
1 Preparing and using for the first time
E If the filter is active, this is indicated by a blue filter symbol on
the display.
E The star on the display indicates that the ‘Smart mode’ is acti-
vated. This means that, after some time, the products on the
start screen will be rearranged according to your personal
preferences.
Your Z6 creates fine, creamy, feather-light milk foam with a perfect
consistency. The most important requirement for frothing milk is a
milk temperature of 4–8°C. We would therefore recommend using
a milk cooler or a milk container.
T Connect the milk pipe to the dual spout.
T Connect the other end of the milk pipe to a milk container
or a milk cooler.
E Your Z6 is equipped with the HP3 milk system.
Your Z6 is equipped with the JURA Smart Connect. This allows you
to connect the machine wirelessly to a compatible JURA accessory
(e.g. the Cool Control milk cooler).
E The Smart Connect can be protected against unauthorised
access using a PIN. Activate the PIN function via the JURA
app. You will find more information at
www.jura.com/smartconnect.
E Please note that you can only connect either the Cool Control
or only one JURA app to the coffee machine via Smart Connect
and not both at the same time.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
Connecting milk
Connect accessory
(wireless connection)
14
1 Preparing and using for the first time
T Turn the Rotary Switch until ‘Connect accessory’ is dis-
played.
E If the programme item
‘Connect accessory’ is not displayed,
Smart Connect is not inserted or is not inserted correctly into
the service socket.
T Press the Rotary Switch to enter the programme item.
‘Connect accessory’
T Now follow the instructions on the display to connect the
accessory to the Z6.
15
2 Preparation
2 Preparation
Basic information about preparing drinks:
U
During the grinding operation you can select the coffee
strength of single products by turning the Rotary Switch.
U
During preparation, you can change the preset amounts (e.g.
amount of water or milk foam) by turning the Rotary Switch.
U
You can stop preparation at any time. To do this, press the
‘’ button.
U
You can personalise all products that are stored as standard in
your Z6 with a new product name and individual settings (e.g.
amount and coffee strength) (see Chapter 4 ‘Permanent
settings in programming mode – Adjusting the product
settings’). Please note that the descriptions provided in the
following sections always refer to the default settings.
U
The star on the display indicates that the ‘Smart mode’ is
activated. This means that, after some time, the products on
the start screen will be rearranged according to your personal
preferences.
Coffee tastes best served hot. A cold porcelain cup cools the bever-
age – and impairs the taste. We therefore recommend prewarming
the cups. The full coffee aroma can develop only in prewarmed cups.
You can purchase a JURA cup warmer from your specialised dealer.
The Z6 offers various ways of preparing a speciality coffee, milk or
hot water.
Preparation using the start screen: Simply press the correspond-
ing preparation button for the product shown on the display (start
screen) that you want. The following products are displayed as
standard:
‘Espresso’
‘Coffee’
‘Caffè Barista’
‘Hot water’
‘Macchiato’
‘Flat White’
‘Cappuccino’
‘Latte macchiato’
Ways of preparing a
beverage
16
2 Preparation
Preparation using the product selector view: Only some of the
products you can prepare are shown on the start screen. As soon
as you turn the Rotary Switch, more products are displayed in a
product selector view.
Turn the Rotary Switch to bring the product you want into focus.
Start preparation by pressing the Rotary Switch. The following addi-
tional products are shown in the product selector view:
U
‘Ristretto’
U
‘Espresso doppio’ (2 brewing operations)
U
‘Lungo Barista’
U
‘Caffè latte’
U
‘1 portion milk’
U
‘1 portion milk foam’
U
‘Hot water for green tea’
U
‘Hot water for black tea’
U
‘Jug of coffee’
E The product selector view disappears automatically after
10seconds if no preparation is started.
E The last product to be displayed always appears first in the
product selector view.
Example:Proceed as follows to prepare one coffee.
Precondition:The start screen is displayed.
T Place a cup under the dual spout.
T Press the
‘Coffee’ button.
Preparation starts.
‘Coffee’ and the coffee strength are dis-
played. The preset amount of water for coffee flows into the
cup.
Preparation stops automatically. Your Z6 is once more ready
for use.
Ristretto, espresso and
coffee
17
2 Preparation
Example:Proceed as follows to prepare two coffees.
Precondition:The start screen is displayed.
T Place two cups under the dual spout.
T Press the
‘Coffee’ button twice (within two seconds) to start
preparation of two coffees.
Coffee preparation starts. The preset amount of water for
coffee flows into the cups. Preparation stops automatically.
Your Z6 is once more ready for use.
Your Z6 prepares latte macchiato, cappuccino, flat white and other
speciality coffees with milk at the touch of a button. There is no need
to move the glass or cup.
Example:Proceed as follows to prepare one latte macchiato.
Precondition:The start screen is displayed.
T Place a glass under the dual spout.
T Press the
‘Latte macchiato’ button.
The preset amounts of milk and milk foam flow into the
glass.
E There is a short interval while the hot milk separates from the
milk foam. This allows the typical layers of a latte macchiato
to form.
Coffee preparation starts. The preset amount of water for
espresso flows into the glass. Preparation stops automati-
cally. Your Z6 is once more ready for use.
E 15 minutes after preparation, the milk system is automatically
rinsed (see Chapter 5 ‘Maintenance – Automatic milk system
rinsing’). Therefore always place a receptacle under the dual
spout after preparing milk.
To ensure that the milk system in the dual spout always works
properly, you must clean it daily (see Chapter 5 ‘Maintenance –
Cleaning the milk system’).
Two ristretti, two
espressi and two coffees
Latte macchiato,
cappuccino and other
speciality coffees with
m i l k
18
2 Preparation
For the ‘caffè Barista’ and ‘lungo Barista’, the Z6 blends the coffee
with hot water using a special preparation method. This results in a
full-bodied speciality coffee which is particularly easy to digest. You
can change the amount of this additional water (see Chapter 4
‘Permanent settings in programming mode – Adjusting the product
settings’).
E The ‘caffè Barista’ and ‘lungo Barista’ can also be prepared as
a double product.
You can choose to use a second coffee variety, for example decaf-
feinated coffee, with the powder chute for ground coffee.
Basic information about ground coffee:
U
Never add more than two level measuring spoons of ground
coffee.
U
Use ground coffee which is not ground too finely. Very fine
coffee can block up the system so that the coffee only comes
out in drips.
U
If you did not fill the machine with a sufficient amount of
ground coffee,
‘Not enough ground coffee’ is displayed and
the Z6 stops the operation.
U
The desired speciality coffee must be prepared within approx-
imately one minute after filling with the ground coffee. Oth-
erwise the Z6 stops the operation and is once more ready for
use.
U
All speciality coffees with ground coffee are always prepared
following the same model.
Example:Proceed as follows to prepare a coffee using ground cof-
fee.
Precondition:The start screen is displayed.
T Place a cup under the dual spout.
T Open the powder chute cover.
‘Please add ground coffee’
Caffè Barista and lungo
Barista
Ground coffee
19
2 Preparation
T Fit the filler funnel for ground coffee.
T Place one level measuring spoon of ground coffee into the
filler funnel.
T Remove the filler funnel and close the cover of the powder
chute.
The start screen is displayed.
T Press the
‘Espresso’ button.
Preparation starts.
‘Espresso’, the preset amount of water for
coffee flows into the cup.
Preparation stops automatically. Your Z6 is once more ready
for use.
You can adjust the grinder to suit the degree of roast of your coffee.
If you adjust the consistency of grind when the grinder is not oper-
ating, the grinder adjustment switch could be damaged.
T Only adjust the consistency of grind when the grinder is run-
ning.
The consistency of grind is correct if the coffee flows regularly from
the coffee spout. In addition a fine, thick crema forms.
Example: Proceed as follows to change the consistency of grind
during the preparation of an espresso.
Precondition:The start screen is displayed.
T Place a cup under the dual spout.
T Open the cover of the grinder adjustment switch.
T Press the
‘Espresso’ button to start preparation.
T Turn the grinder adjustment switch to the desired position
while the grinder is running.
The preset amount of water flows into the cup. Preparation
stops automatically.
T Close the cover of the grinder adjustment switch.
Adjusting the grinder
CAUTION
20
2 Preparation
The Z6 allows you to prepare different variants of hot water:
U
‘Hot water’
U
‘Hot water for green tea’
U
‘Hot water for black tea’
There is a danger of scalding from hot water splashes.
T Avoid direct contact with the skin.
Example: Proceed as follows to prepare hot water for green tea
(using product selector view).
Precondition:The start screen is displayed.
T Place a cup under the hot-water spout.
T Turn the Rotary Switch to view the product selector.
T Turn the Rotary Switch until
‘Hot water for green tea’ is
displayed.
T Press the Rotary Switch.
‘Hot water for green tea’, the preset amount of water flows
into the cup.
Preparation stops automatically. Your Z6 is once more ready
for use.
Hot water
J
CAUTION
21
3 Daily operation
3 Daily operation
Daily maintenance of the machine and hygiene when handling milk,
coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Place a receptacle under the dual spout.
T Press the On/Off button Q to switch the Z6 on.
‘Machine is heating’
‘Machine is rinsing’
, the system is rinsed.
The rinse stops automatically. The start screen is displayed.
To ensure that you get many years of reliable service out of your Z6
and to guarantee the optimum coffee quality, the machine requires
daily maintenance.
T Pull out the drip tray.
T Empty the coffee grounds container and the drip tray. Rinse
them both with warm water.
E Always empty the coffee grounds container when the machine
is switched on. This is the only way of resetting the coffee
grounds counter.
T Refit the coffee grounds container and the drip tray.
Filling the water tank
CAUTION
Switching on the
machine
Daily maintenance
22
3 Daily operation
T Rinse the water tank with clean water.
T Clean the milk system in the dual spout (see Chapter 5
‘Maintenance – Cleaning the milk system’).
T Remove the milk pipe and rinse it thoroughly under running
water.
T Dismantle and rinse the dual spout (see Chapter 5 ‘Mainte-
nance – Dismantling and rinsing the dual spout’).
T Wipe the surface of the machine with a clean, soft, damp
cloth (e.g. microfibre cloth).
You will find more information about caring for your Z6 in program-
ming mode under
‘Maintenance status’ / ‘Maintenance informa-
tion’
.
Carry out the following maintenance actions regularly or as
required:
U
In the interests of hygiene, we recommend changing the milk
pipe and interchangeable milk spout on a regular basis
(approximately every 3 months). Replacements are available
from specialised dealers. Your Z6 is equipped with the HP3
milk system.
U
Clean the inside of the water tank, e.g. with a brush. Further
information about the water tank is provided in these instruc-
tions for use (see Chapter 5 ‘Maintenance – Descaling the
water tank’).
U
Traces of milk and coffee may stick to the top and bottom of
the cup grille. If this happens, clean the cup grille.
When the Z6 is switched off, the system is automatically rinsed if a
speciality coffee has been prepared.
T Place a receptacle under the dual spout.
T Press the On/Off button Q.
E If milk has been prepared, you will be prompted to clean the
milk system (
‘Clean the milk system’). After 10 seconds the
switch-off process continues automatically.
‘Machine is rinsing’, the system rinses itself. The operation
stops automatically. Your Z6 is switched off.
Regular maintenance
Switching off the
machine
23
4 Permanent settings in programming mode
4 Permanent settings in programming mode
Briefly press the Rotary Switch to enter programming mode. You
can navigate through the programme items and permanently save
the required settings simply by turning the Rotary Switch and using
the multi-function buttons. The following settings can be made:
Programme item Sub-item Explanation
‘Maintenance
status’
‘Clean’
,
‘Descale’,
‘Change the filter’ (only if
filter is fitted),
‘Clean the milk system’,
‘Rinse’,
‘Maintenance information’
T Start the required maintenance programme
here.
‘Product settings’ ‘Expert mode’
T Select your settings for speciality coffees,
milk specialities and hot water.
‘Classics’
T Replace products with your favourites.
Personalise your favourite speciality coffees by
giving them a new product name and
individual settings.
‘Machine settings’ ‘Choose language’
T Select your language.
‘Switch off after’
T Set the time after which the Z6 should switch
off automatically.
‘Factory setting’
T Reset the machine to its factory setting.
‘Units’
T Select the unit for the amount of water.
‘Display’
TChange the display brightness.
‘Water hardness’
T You can set the water hardness of the water
used.
‘Product counter’ /
‘Maintenance counter’
T Keep track of all products prepared and view
the number of maintenance programmes
performed.
‘Version’ Software version
‘Water tank illumination’
T Change the setting for water tank illumination.
‘Smart mode’
T Have the products arranged on the start
screen according to how often they are
prepared.
24
4 Permanent settings in programming mode
Programme item Sub-item Explanation
‘Connect accessory’,
‘Disconnect accessories’
(Only displayed if the JURA
Smart Connect is being
used.)
T Connect the Z6 wirelessly to a JURA
accessory or disconnect the connection again.
In the programme item
‘Product settings’ you can make the follow-
ing settings:
U
‘Expert mode’: Specify individual settings such as coffee
strength, amount of water, etc., for all products (see
Chapter 4 ‘Permanent settings in programming mode –
Adjusting the product settings’).
U
‘Classics’:
U
‘Add to product selector’: Add your favourite products to the
product selector. Personalise the products you want by
giving them a new product name and individual settings
(see Chapter 4 ‘Permanent settings in programming
mode – Storing and personalising products’).
U
‘Add to favourites’ (only displayed when the ‘Smart mode’ is
deactivated): Replace the products on the start screen with
your favourites.
The following settings can be set permanently for all speciality cof-
fees, milk and hot water:
Product Coffee
strength
Amount More settings
Ristretto,
espresso
10 levels Coffee: 15ml–80ml Temperature (low, normal,
high), product name
Coffee 10 levels Coffee: 25ml–240ml Temperature (low, normal,
high), product name
Caffè Barista,
lungo Barista
10 levels Coffee: 25ml–240ml
Bypass water:
0ml–240ml
Temperature (low, normal,
high), product name
Product settings
Adjusting the product
settings
25
4 Permanent settings in programming mode
Product Coffee
strength
Amount More settings
Two ristretti,
two espressi,
two coffees,
two caffè Barista,
two lungo Barista
– Coffee: The amount set for
the single product is
doubled.
Temperature (as for single
product),
product name
Cappuccino 10 levels Coffee: 25ml–240ml
Milk foam: 0sec.–120sec.
Milk foam temperature,
temperature (low, normal,
high), product name
Latte macchiato 10 levels Coffee: 25ml–240ml
Milk foam: 0sec.–120sec.
Milk: 0sec.–120sec.
Interval: 0sec.–60sec.
Milk and milk foam tempera-
ture, temperature (low, normal,
high), product name
Espresso macchiato 10 levels Coffee: 15ml–80ml
Milk foam: 0sec.–120sec.
Milk foam temperature,
temperature (low, normal,
high), product name
Flat white,
caffè latte
10 levels Coffee: 25ml–240ml
Milk foam: 0sec.–120sec.
Milk: 0sec.–120sec.
Milk and milk foam tempera-
ture, temperature (low, normal,
high), product name
Pot of coffee 10 levels Coffee: 25ml–200ml
Bypass water:
0ml–200ml
Temperature (low, normal,
high), product name,
number of strokes (1–5; set
number is displayed during
preparation)
Portion of milk foam,
milk
– Milk foam: 0sec.–120sec. Milk and milk foam
temperature, product name
Hot water,
hot water for green
tea,
hot water for black
tea
– Water: 25ml–450ml Temperature (low, normal,
high), product name
Permanent settings in programming mode always follow the same
model.
Example:Proceed as follows to change the coffee strength for one
espresso.
Precondition:The start screen is displayed.
26
4 Permanent settings in programming mode
T Press the ‘Espresso’ button for about 2 seconds until ‘Expert
mode’
appears.
T Press the Rotary Switch.
‘Coffee strength’
T Press the Rotary Switch again.
T Turn the Rotary Switch to change the coffee strength set-
ting.
T Press the Rotary Switch to confirm the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Expert mode’
T Press the ‘’ button.
The start screen is displayed.
In the programme item
‘Product settings’/ ‘Classics’ you will find all
the products stored as standard in your Z6. You can move any of
these products to your preferred position on the start screen or in
the product selector and make it one of your favourites. You can
personalise the products you want by giving them a new product
name and individual settings (e.g. amount and coffee strength).
E The products on the start screen can only be replaced if the
‘Smart mode’ is deactivated.
Example:Proceed as follows to add a ‘coffee’ to the product selec-
tor view and change the product name to ‘My coffee’.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Product settings’ is displayed.
T Press the Rotary Switch.
‘Expert mode’
T Turn the Rotary Switch until ‘Classics’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Add to product selector’
T Press the Rotary Switch again.
T Turn the Rotary Switch until
‘Coffee’ is in focus.
T Press the Rotary Switch.
‘Do you want to add the product to the product selector?’
Storing and personalising
products
27
4 Permanent settings in programming mode
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
‘Product name’
E You can now give the product you just added a new name, e.g.
‘My coffee’.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Coffee strength’
E You can now change various settings for the product. To do
this, briefly press the Rotary Switch to access the various
setting options. Confirm the settings by pressing the
‘Save’
button.
E If you do not want to change any more settings, just press the
‘’ button.
T Press the
‘’ button until the start screen is displayed again.
By instructing your Z6 to automatically switch itself off, you can cut
down your energy consumption. If this function is activated, your Z6
switches off automatically after the preset time following the last
action on the machine.
You can set the automatic switch-off to 15minutes, 30minutes or
1–9hours.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Switch off after’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Switch off after’
T Turn the Rotary Switch to change the switch-off time.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Switch off after’
T Press the ‘’ button until the start screen is displayed again.
Automatic switch-off
28
4 Permanent settings in programming mode
Your Z6 has a ‘Smart mode’. If this mode is activated, the products
on the start screen will be rearranged according to your personal
preferences after some time.
E The star on the start screen indicates that the ‘Smart mode’ is
activated.
Example:Proceed as follows to deactivate the ‘Smart mode’.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Smart mode’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Smart mode’
T Turn the Rotary Switch until ‘Inactive’ is displayed.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Smart mode’
T Press the ‘’ button until the start screen is displayed again.
The harder the water is, the more frequently the Z6 needs to be
descaled. It is therefore important to set the water hardness accu-
rately.
The water hardness was set when the machine was first used. You
can change this setting at any time.
The water hardness can be adjusted on a continuous scale between
1° dH and 30° dH.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Water hardness’ is displayed.
Smart mode
Setting the water
hardness
29
4 Permanent settings in programming mode
T Press the Rotary Switch to enter the programme item.
‘Water hardness’
T Turn the Rotary Switch to change the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Water hardness’
T Press the ‘’ button until the start screen is displayed again.
In the programme item
‘Machine settings’/ ‘Display’ you can set the
display brightness (as a percentage).
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Display’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Display’
T Turn the Rotary Switch to change the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Display’
T Press the ‘’ button until the start screen is displayed again.
In the programme item
‘Machine settings’/ ‘Units’ you can select
the unit used for the amount of water.
Example:Proceed as follows to change the unit for the amount of
water from
‘ml’ to ‘oz’.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Units’ is displayed.
Display brightness
Unit for amount of water
30
4 Permanent settings in programming mode
T Press the Rotary Switch to enter the programme item.
‘Units’
T Turn the Rotary Switch until ‘oz’ is displayed.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Units’
T Press the ‘’ button until the start screen is displayed again.
In the programme item
‘Machine settings’ / ‘Factory setting’ the
machine can be reset to its factory setting: This resets all user set-
tings to the factory setting. Your Z6 then switches off.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Factory setting’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Factory setting’ / ‘Reset the machine to the factory set-
tings?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
Your Z6 is switched off.
In the programme item
‘Machine settings’ / ‘Water tank illumina-
tion’
you can change the setting for water tank illumination:
U
‘Permanent’: The water tank is always illuminated.
U
‘Temporary’: The water tank is only illuminated when an
action is being performed by the machine.
Example:Proceed as follows to change the water tank illumination
setting from
‘Permanent’ to ‘Temporary’.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
Restore factory settings
Water tank illumination
31
4 Permanent settings in programming mode
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Water tank illumination’ is dis-
played.
T Press the Rotary Switch to enter the programme item.
‘Water tank illumination’
T Turn the Rotary Switch until ‘Temporary’ is displayed.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Water tank illumination’
T Press the ‘’ button until the start screen is displayed again.
In this programme item you can set the language used by your Z6.
Example:Proceed as follows to change the language from
‘English’
to
‘Deutsch’.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Press the Rotary Switch to enter the programme item.
‘Choose language’
T Turn the Rotary Switch until ‘Deutsch’ is displayed
T Press the
‘Speichern’ button.
‘Gespeichert’ appears briefly on the display.
‘Sprachauswahl’
T Press the ‘’ button until the start screen is displayed again.
Language
32
4 Permanent settings in programming mode
In the programme item ‘Machine settings’ you can view the follow-
ing information:
U
‘Product counter’: Number of prepared coffee speciality
coffees, speciality coffees with milk and hot water
U
‘Maintenance counter’: Number of maintenance programmes
performed (cleaning, descaling etc.)
U
‘Version’: Software version
Example: Proceed as follows to view the number of speciality
coffees prepared.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Turn the Rotary Switch until ‘Machine settings’ is displayed.
T Press the Rotary Switch.
‘Choose language’
T Turn the Rotary Switch until ‘Product counter’ is displayed.
T Press the Rotary Switch to enter the programme item.
‘Product counter’
E Turn the Rotary Switch to view the number of other speciality
coffees.
T Press the
‘’ button until the start screen is displayed again.
Querying information
33
5 Maintenance
5 Maintenance
Your Z6 has the following integrated maintenance programmes:
U
Rinsing the machine
U
Rinsing the milk system in the dual spout
U
Cleaning the milk system in the dual spout (‘Clean the milk
system’
)
U
Changing the filter (‘Change the filter’) (only if filter is fitted)
U
Cleaning the machine (‘Clean’)
U
Descaling the machine (‘Descale’)
E Clean or descale the machine, rinse the milk system or change
the filter when you are prompted to do so.
E In the interests of hygiene, you should clean the milk system
daily when you have been preparing milk.
You can initiate the rinse operation manually at any time.
Precondition:The start screen is displayed.
T Place a receptacle under the dual spout.
T Press the Rotary Switch.
‘Maintenance status’
T Press the Rotary Switch again.
‘Clean’
T Turn the Rotary Switch until ‘Rinse’ is displayed.
T Press the Rotary Switch to initiate the rinse operation.
‘Machine is rinsing’, ‘Milk system is being rinsed’, water
flows out of the dual spout.
The rinse stops automatically. The start screen is displayed.
15 minutes after milk preparation, the milk system is automatically
rinsed. Therefore always place a receptacle under the dual spout
after preparing milk.
Rinsing the machine
Automatic milk system
rinsing
34
5 Maintenance
To ensure that the milk system in the dual spout always works prop-
erly, you must clean it daily when you have been preparing milk.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E JURA milk system cleaner is available from specialised dealers.
E To clean the milk system, use the container supplied.
Precondition:The start screen is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Press the Rotary Switch again.
‘Clean’
T Turn the Rotary Switch until ‘Clean the milk system’ is dis-
played.
T Press the Rotary Switch.
‘Clean the milk system’
T Press the Rotary Switch again.
‘Clean the milk system’
T Press the ‘Next’ button.
T Press the
‘Next’ button again.
‘Cleaning agent for milk system’ / ‘Connect the milk tube’
T Remove the milk pipe from the milk container.
T Add 1 capful of milk system cleaner to the outer, rectangular
part of the container.
T Place the container under the dual spout and connect the
milk pipe with the container.
E To connect the milk pipe to the container correctly, the pipe
must be fitted with a connector.
T Slide the dual spout down to fix the container in place.
Cleaning the milk system
CAUTION
6
6
35
5 Maintenance
T Press the ‘Start’ button.
‘Milk system is being cleaned’, the dual spout and the milk
pipe are cleaned. Water flows out of the dual spout.
The operation stops automatically. Your Z6 is once more
ready for use.
The dual spout must be dismantled and rinsed daily if milk has been
prepared to make sure it functions perfectly and also in the interests
of hygiene.
T Remove the milk pipe and rinse it thoroughly under running
water.
T Press the releasing devices and pull the cover of the dual
spout up and off.
T Remove the milk system from the dual spout.
T Dismantle the milk system into its individual parts.
T Rinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in a solution of 250ml cold water and 1 capful of JURA milk
system cleaner. Then rinse the parts thoroughly.
Dismantling and rinsing
the dual spout
36
5 Maintenance
T Reassemble the milk system.
T Fit the assembled individual parts back in the dual spout and
press it firmly.
T Fit the cover of the dual spout. Make sure the cover of the
dual spout is correctly fitted.
T Connect the milk pipe to the dual spout.
Your Z6 no longer has to be descaled if you are using the CLARIS
Smart filter cartridge.
E Once the filter cartridge stops working (depending on the
water hardness setting), the Z6 will prompt you to change the
filter.
E CLARIS Smart filter cartridges are available from specialised
dealers.
Inserting/changing the
filter
37
5 Maintenance
Precondition:The start screen is displayed. ‘Change the filter’ is dis-
played and the filter symbol is red (if you are using a filter).
T Remove and empty the water tank.
T Turn the filter cartridge anticlockwise and remove it along
with the extension from the water tank.
T Fit the filter cartridge extension on top of a new CLARIS
Smartfilter cartridge.
T Insert the filter cartridge with its extension into the water
tank.
T Turn the extension clockwise until it audibly clicks into place.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted/
changed the filter cartridge.
‘Use filter’ / ‘Saved’
‘Filter is being rinsed’
, the filter is rinsed. The water flows
directly into the drip tray.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
The start screen is displayed. Your Z6 is once more ready for
use.
After 180preparations or 80switch-on rinses, the Z6 will prompt you
to clean it.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E The cleaning programme lasts approximately 20 minutes.
E Do not interrupt the cleaning programme. The quality of
cleaning will be impaired if you do so.
E JURA cleaning tablets are available from specialised dealers.
Precondition:
‘Clean machine’ is displayed.
T Press the Rotary Switch.
‘Maintenance status’
Cleaning the machine
CAUTION
38
5 Maintenance
T Press the Rotary Switch.
‘Clean’
T Press the Rotary Switch again.
T Press the
‘Next’ button.
T Press the
‘Start’ button.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Press the Rotary Switch’
T Place a receptacle under the dual spout.
T Press the Rotary Switch.
‘Machine is being cleaned’, water flows out of the dual spout.
The operation is interrupted,
‘Add cleaning tablet’.
T Open the powder chute cover.
T Insert a JURA cleaning tablet into the powder chute.
T Close the cover.
‘Press the Rotary Switch’
T Press the Rotary Switch.
‘Machine is being cleaned’, water flows out of the dual spout
repeatedly.
The operation stops automatically.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
The start screen is displayed. Your Z6 is once more ready for
use.
39
5 Maintenance
The Z6 builds up deposits of limescale over time and automatically
prompts you to descale it when necessary. The degree of calcifica-
tion depends on the hardness of your water.
E If you are using a CLARIS Smart filter cartridge, you will not be
prompted to descale.
If the descaling agent comes into contact with the skin or eyes, this
can cause irritation.
T Avoid contact with the skin or eyes.
T Rinse off the descaling agent with clean water. Should you get
any descaling agent in your eye, see a doctor.
If the wrong descaling agent is used, the machine could be dam-
aged and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
If the descaling operation is interrupted, there may be damage to
the machine.
T Allow the descaling programme to run to the end.
If the descaling agent comes into contact with sensitive surfaces
(e.g. marble), damage cannot be ruled out.
T Clean up any splashes immediately.
E The descaling programme lasts approximately 45minutes.
E JURA descaling tablets are available from specialised dealers.
Precondition:
‘Decalcify machine’ is displayed.
T Press the Rotary Switch.
‘Maintenance status’
T Press the Rotary Switch.
‘Descale’
T Press the Rotary Switch again.
T Press the
‘Next’ button.
T Press the
‘Start’ button.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Agent in tank’
Descaling the machine
J
CAUTION
CAUTION
CAUTION
CAUTION
40
5 Maintenance
T Remove and empty the water tank.
T Completely dissolve 3JURA descaling tablets in a receptacle
holding 600ml of water. This may take several minutes.
T Pour the solution into the empty water tank and insert it
into the machine.
‘Press the Rotary Switch’
T Place a receptacle under the hot-water spout.
T Press the Rotary Switch.
‘Machine is being descaled’, water flows out of the hot-water
spout repeatedly.
The operation is interrupted,
‘Empty drip tray’.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Fill water tank’
T Empty the receptacle and place it under the hot-water and
dual spouts.
T Remove the water tank and rinse it thoroughly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘Press the Rotary Switch’
T Press the Rotary Switch.
‘Machine is being descaled’, the descaling operation is con-
tinued, water flows out of the dual spout and the hot-water
spout.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
The start screen is displayed. Your Z6 is once more ready for
use.
E If the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
41
5 Maintenance
Coffee beans may be covered with a slight oil film which remains on
the walls of the bean container. These traces may negatively affect
the coffee result. For this reason clean the bean container from time
to time.
Precondition:
‘Fill bean container’ is displayed.
T Switch the machine off with the On/Off button Q.
T Remove the aroma preservation cover.
T Clean the bean container with a soft, dry cloth.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
Limescale deposits may form in the water tank. To ensure correct
function of the machine, descale the water tank from time to time.
T Remove the water tank.
T If you use a CLARIS Smart filter cartridge, remove this.
T Completely fill the water tank and dissolve 3 JURA descaling
tablets in it.
T Leave the water tank with the descaling solution for several
hours (e.g. overnight).
T Empty the water tank and rinse it thoroughly.
T If you use a CLARIS Smart filter cartridge, insert this again.
T Fill the water tank with fresh, cold water and reinsert the
tank.
Cleaning the bean
container
Descaling the water tank
42
6 Display messages
6 Display messages
Message Cause/Result Action
‘Fill water
tank’
The water tank is empty. You cannot
prepare any products.
T Fill the water tank (see Chapter 3 ‘Daily
operation – Filling the water tank’).
‘Empty coffee
grounds
container’
The coffee grounds container is full.
You cannot prepare any products.
T Empty the coffee grounds container and
the drip tray (see Chapter 3 ‘Daily
operation – Daily maintenance’).
‘Drip tray not
fitted’
The drip tray is not inserted
correctly or is not inserted at all. You
cannot prepare any products.
T Fit the drip tray.
‘Fill bean con-
tainer’
The bean container is empty. You
cannot prepare any speciality
coffees, but you can prepare hot
water and milk.
T Fill the bean container (see Chapter 1
‘Preparing and using for the first time –
Filling the bean container’).
‘Clean the
milk system’
The Z6 prompts you to clean the
milk system.
T Perform milk system cleaning (see
Chapter 5 ‘Maintenance – Cleaning the
milk system’).
‘Change filter’ The filter cartridge no longer works.
The Z6 is prompting a filter change.
T Replace the CLARIS Smart filter cartridge
(see Chapter 5 ‘Maintenance – Inserting/
changing the filter’).
‘Clean
machine’
The Z6 is prompting you to clean it.
T Perform cleaning (see Chapter 5
‘Maintenance – Cleaning the machine’).
‘Decalcify
machine’
The Z6 is prompting you to descale
it.
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the machine ’).
‘Not enough
ground
coffee’
There is insufficient ground coffee in
the machine; the Z6 stops the
operation.
T The next time you prepare a beverage,
add more ground coffee (see Chapter 2
‘Preparation – Ground coffee’).
‘Spout is not
fitted’
The cover of the dual spout has not
been fitted.
T Correctly fit the cover of the dual spout.
‘Machine too
hot for
maintenance’
The system is too hot to start a
maintenance programme.
T Wait for several minutes until the
system has cooled or prepare a speciality
coffee or hot water.
43
7 Troubleshooting
7 Troubleshooting
Problem Cause/Result Action
Insufficient foam is
produced when the
milk is frothed or
milk sprays from the
dual spout.
The dual spout is dirty.
T Make sure the cover of the dual spout is
correctly fitted.
T Clean the milk system in the dual spout
(see Chapter 5 ‘Maintenance – Cleaning the
milk system’).
T Dismantle and rinse the dual spout (see
Chapter 5 ‘Maintenance – Dismantling and
rinsing the dual spout’).
The milk and milk foam
temperature is set too
high.
T Set a lower milk and milk foam tempera-
ture for the product.
Coffee only comes
out in drips when it
is being prepared.
Coffee or ground coffee
has been ground too
finely and is blocking the
system. The water
hardness may not have
been correctly set.
T Put the grinder on a coarser setting or use
coarser ground coffee (see Chapter 2
‘Preparation – Adjusting the grinder’).
T Perform descaling (see Chapter 5 ‘Mainte-
nance – Descaling the machine ’).
Little or no steam
comes out of the
dual spout. The
pump is very quiet.
The connector of the milk
system in the dual spout
may be blocked by milk
residues or limescale
fragments loosened
during descaling.
T Press the releasing devices and pull the
cover of the dual spout up and off.
T Remove the milk system from the dual
spout.
T Unscrew the black connector with the aid
of the hexagonal hole on the measuring
spoon for ground coffee.
T Clean the connector thoroughly.
T Screw the connector back on by hand.
T Carefully tighten it using the hexagonal
hole on the measuring spoon, turning by no
more than a quarter of a rotation.
‘Fill water tank’ is not
displayed although
the water tank is
empty.
There is a lot of limescale
in the water tank.
T Descale the water tank (see Chapter 5
‘Maintenance – Descaling the water tank’).
44
7 Troubleshooting
Problem Cause/Result Action
Grinder is making a
very loud noise.
There are foreign objects
in the grinder.
T Contact customer support in your country
(see Chapter 11 ‘JURA contact details/ Legal
information’).
‘Error2’ or ‘Error5’ is
displayed.
If the machine has been
exposed to the cold for a
long period of time,
heating may be disabled
for safety reasons.
T Warm the machine at room temperature.
Other
‘Error’
messages are
displayed.
–
T Switch the Z6 off with the On/Off button Q.
Contact customer support in your country
(see Chapter 11 ‘JURA contact details/ Legal
information’).
E If you were unable to solve the problem, contact customer
support in your country (see Chapter 11 ‘JURA contact details/
Legal information’).
45
8 Transport and environmentally friendly disposal
8 Transport and environmentally friendly disposal
Keep the packaging for your Z6. It should be used to protect the
machine during transport.
In order to protect the Z6 from frost during transport, the system
must be emptied.
Precondition:The start screen is displayed.
T Remove the milk pipe from the dual spout.
T Place a receptacle under the dual spout.
T Press the
‘1 portion milk foam’ button.
‘1 portion milk foam’, hot steam is discharged from the dual
spout.
T Remove and empty the water tank.
T Turn the Rotary Switch until
‘Amount of milk foam’/ ‘60sec.’
is displayed.
Steam will continue to be discharged from the dual spout
until the system is empty.
‘Fill water tank’
T Press the On/Off button Q.
Your Z6 is switched off.
Please dispose of old machines in an environmentally neutral way.
H
Old machines contain valuable, recyclable materials which should
be recycled. Please therefore dispose of old machines via suitable
collection systems.
Transport/ Emptying the
system
Disposal
46
9 Technical data
9 Technical data
Voltage 220–240V~, 50Hz
Power 1450W
Conformity mark
A
Energy consumption approx. 6Wh
Pump pressure static, max. 15bar
Holding capacity of water tank 2.4l
Holding capacity of bean container 280g
Holding capacity of coffee grounds
container
max. 20 portions
Cable length approx. 1.1m
Weight approx. 12.5kg
Dimensions (W×H×D) 32 × 37.5 × 45cm
Milk system HP3
Information for testers (repeat test in accordance with DIN VDE
0701-0702): The central grounding point (CGP) is located on the back
of the machine under the service cover.
47
10 Index
10 Index
A
Addresses 52
Adjusting the product settings 24
Aroma preservation cover
Bean container with aroma preservation
cover 4
Automatic switch-off 27
B
Bean container
Bean container with aroma preservation
cover 4
Cleaning 41
Filling 10
Bus bar
Technical data 46
Button
On/Off button 4
Bypass amount of water 18
C
Caffè Barista 18
Caffè latte 17
Cappuccino 17
Cappuccino frother cleaning
Cleaning the milk system 34
Central grounding point 46
Changing the product assigned to a button
26
CLARIS Smart filter cartridge
Changing 36
Inserting 36
Classics 24
Cleaning
Bean container 41
Machine 37
Coffee 16
Two coffees 17
Coffee grounds container 4
Connecting an accessory 13
Consistency of grind
Adjusting the grinder 19
Grinder adjustment switch 4
Contact details 52
Cup grille 4
Customer support 52
D
Daily maintenance 21
Descaling
Machine 39
Water tank 41
Display 5
Display brightness 29
Display messages 42
Disposal 45
Double product 17
Drip tray 4
Dual spout
Dismantling and cleaning 35
Height- and width-adjustable dual spout
4
E
Emptying the system 45
Errors
Troubleshooting 43
Espresso 16
Two espressi 17
Espresso macchiato 17
Expert mode 24
F
Factory settings
Restore factory settings 30
Filler funnel
Filler funnel for ground coffee 5
Filling
Bean container 10
Water tank 21
Filter
Changing 36
Inserting 36
First-time use 11
Flat white 17
G
Grinder adjustment switch 4
Ground coffee 18
Measuring spoon for ground coffee 5
Powder chute for ground coffee 4
Grounding point 46
48
10 Index
H
Homepage 10
Hotline 52
Hot water 20
Hot-water spout 4
I
Instant coffee
Ground coffee 18
Internet 10
J
JURA
Contact details 52
Internet 10
L
Language 31
Latte macchiato 17
M
Machine
Cleaning 37
Daily maintenance 21
Descaling 39
Regular maintenance 22
Rinsing 33
Setting up 10
Switching off 22
Switching on 21
Mains cable 4
Maintenance 33
Daily maintenance 21
Regular maintenance 22
Measuring spoon for ground coffee 5
Messages, display 42
Milk
Connecting milk 13
Milk system 46
Cleaning 34
Milk system rinsing 33
P
Permanent settings in programming mode
23
Personalising products 26
Powder chute
Powder chute for ground coffee 4
Preparation 15, 17
At the touch of a button 15
Caffè latte 17
Cappuccino 17
Coffee 16
Espresso 16
Espresso macchiato 17
Flat white 17
Ground coffee 18
Hot water 20
Latte macchiato 17
Lungo Barista 18
Ristretto 16
Two coffees 17
Two espressi 17
Two ristretti 17
Two speciality coffees 17
Using the product selector 15
Preparation options 15
Problems
Troubleshooting 43
Product selector view 15
Product settings 24
Adjusting 24
Programming mode 23
Automatic switch-off 27
Display brightness 29
Language 31
Product settings 24
Querying information 32
Restore factory settings 30
Setting the water hardness 28
Smart mode 28
Storing products 26
Unit for amount of water 29
Water tank illumination 30
Proper use 6
Q
Querying information 32
R
Regular maintenance 22
Rinsing
Machine 33
Ristretto 16, 17
Two ristretti 17
Rotary Selection 15
Rotary Switch 5
49
10 Index
S
Safety 6
Safety information 6
Service socket 5
Settings
Permanent settings in programming
mode 23
Setting up
Setting up the machine 10
Short operating instructions 10
Smart Connect 5
Smart mode 28
Spout
Height- and width-adjustable dual spout
4
Hot-water spout 4
Storing products 26
Switching off 22
Switching on 21
Switch-off
Automatic switch-off 27
Symbol description 3
T
Technical data 46
Milk system 46
Tel 52
Transport 45
Troubleshooting 43
Two products 17
U
Unit for amount of water 29
Use, First-time 11
W
Water hardness
Determining the water hardness 11
Setting the water hardness 28
Water tank 4
Descaling 41
Filling 21
Water tank illumination 30
Website 10
Wireless connection 13
50
51
52
11 JURA contact details/ Legal information
11 JURA contact details/ Legal information
JURA Elektroapparate AG
Kaffeeweltstrasse 10
CH-4626 Niederbuchsiten
Tel. +41 (0)62 38 98 233
E You will find additional contact details for your country at
www.jura.com.
E If you need assistance with using your machine, you can find
this at www.jura.com/service.
The machine complies with the following directives:
U
2014/35/EU– Low Voltage Directive
U
2014/30/EU– Electromagnetic Compatibility
U
2009/125/EC– Ecodesign Directive
U
2011/65/EU– RoHS Directive
We reserve the right to make technical changes. The diagrams used
in these instructions for use are for illustration purposes only and do
not represent the original colours of the machine. Some details of
your Z6 may vary.
Your opinion is important to us! Use the contact details at
www.jura.com.
The instructions for use contain information which is protected by
copyright. It is not permitted to photocopy these instructions for use
or translate them into another language without the prior written
consent of JURA Elektroapparate AG.
Directives
Technical changes
Feedback
Copyright
J73920/Z6/en/201807
