Use and Care
of
Ventilating Hood Model JV650
.—.
—.
L——
:~-
—-—.~=
—
——.
..—
-—
=——-—
..-–.——–.
——.
~:—.:=..
.
.4
Quality Product of GENERAL ELECTRIC COMPANY
[he
(it:
Anwcr
(’enieY
800.626.2000
t
b
Write down the model and serial numbers.
You’ll find them on a label on the back wall of the
Model Number
hood. (Remove the filter to see the label. )
Serial Number
These numbers are also on the Consumer Product
Use these numbers in any correspondence or
ser-
Ownership Registration Card that came with your
hood. Before sending in this card, please write
vice calls concerning your hood.
these numbers here:
LAMP COVER
G’REA<E
FILTERS
Your hood is equipped with two grease filters.
When the fan is operated, air is drawn through the
two filters and discharged to the outside.
CAUTION: Before operating the hood:
Remove the Grease Filters. (See instructions on
page 2.)
Remove the wrappings from the filters.
Install the lamp bulb (not provided). See Lamp
Replacement instructions on page 2.
Reinstall the Grease Filters. The hood must not
be operated without the filters in place.
SAVE THESE INSTRUCTIONS
To Operate
Motor and Fan
To Clean Motor and Fan
FAN SWITCH
‘ LAMP SWITCH
Fan Switch
Turn knob clockwise to HI for maximum air
movement or any position between HI and LO
as desired. Turn knob counterclockwise for OFF.
Lamp Switch
Turn knob clockwise for NORMAL LIGHT and
counterclockwise for NIGHT LIGHT from OFF
position, or this control may be turned in either
direction.
To Maintain
Grease Filters
The efficiency of your hood depends on clean fil-
ters. Frequency of cleaning depends on the type of
cooking you do. BUT GREASE FILTERS SHOULD
BE CLEANED AT LEAST ONCE A MONTH.
NEVER OPERATE THE HOOD WITHOUT THE
FILTERS IN PLACE.
To remove: Grasp the knob located on the end of
the filter. Push it to the rear and downward in one
motion.
To clean: Soak and then agitate in a hot detergent
solution. Light brushing may be used to remove
imbedded soil. Rinse, shake and remove moisture
before replacing.
With careful handling, the filters will last for years.
If replacement becomes necessary, order part
number WB2X2189 from your dealer.
To replace: Put the filter rim in rear frame slot
against the spring. Push toward the rear and up.
Then, allow the filter to move forward to lock into
position in the frame.
Hood
Clean grease laden surfaces of the hood fre-
quently. Use warm detergent solution. About
1 tablespoon of ammonia may be added to the
water. TAKE CARE NOT TO COME I N CONTACT
WITH FILTERS AND OTHER NON-ENAMELED
SURFACES. The hood shell can be washed, rinsed
and dried with a soft cloth.
1.
2.
3.
4.
5.
DISCONNECT THE HOOD POWER SUPPLY
AT THE HOUSEHOLD DISTRIBUTION PANEL
BY REMOVING THE FUSE OR SWITCHING
-
OFF THE CIRCUIT BREAKER.
Remove filters.
Wipe inside surfaces and motor with cloth,
dampened only in ammonia and warm water
solution.
Replace filters.
Reconnect the hood power supply.
Lamp Replacement
● Remove the Lamp Cover retaining screws and
the Lamp Cover.
● Remove lamp and replace with an ordinary
screw-base lamp bulb NOT MORE THAN
60 WATTS.
. Reinstall Lamp Cover and Lamp Cover retaining
screws.
Before You Call for Service
●
●
●
●
If the fan does not operate when the switch is
on, check the hood power supply at the house-
-
hold distribution panel. A fuse may be blown or
a circuit breaker tripped.
If the fan fails to circulate air, possible causes
such as the fan blade striking the hood shell or
excessively soiled filter should be checked and
corrected before using the hood again.
If the fan operates but moves air slower than
normal, check to be sure the filters are clean. If
that does not correct the problem, call for
service.
If the fan keeps going off and on, the motor is
probably overheating and turning itself off. This
can be harmful to the motor. Check to be sure
the filters are clean. If off and on cycling con-
tinues, call for service.
—.
-@
~t
Consumer Services
0
,
At General Electric we’re committed to providing you with the best appliances we know how
to build and we know that you want your appliances to give you many years of dependable
service.
Our Consumer Services are designed with your needs and wants in mind.
1.
Warranty Protection
Your new appliance is a well designed and engineered See the warranty on the back page of this book for
product. Before it left the factory, it went through
details.
rigorous tests to detect manufacturing defects. And
you have a written warranty to protect you.
2.
Prompt Service at your Convenience
Whether your appliance is in or out of warranty,
you’re just a phone call away from our nationwide
network of Factory Trained Service professionals.
Simply call our GE service organization.
You’ll find
them in the White Pages under “General Electric
Company” or “General Electric Factory
Service;’
and in the Yellow Pages under “General Electric
Customer
Care” Service!’
Service is scheduled at your convenience and the
technician drives a fully-stocked parts service truck
so that, in most cases, the repair can be completed
in one visit.
We’re proud of our service and want you to be
pleased, but if for some reason you are not happy
with the service you receive, here are three steps to
follow for further help.
FIRST
contact the people who serviced your
appliance. Explain why you are not pleased. In most
cases, this will solve the problem.
NEXT, if you are still not pleased write all the details
—
including your phone number to:
Manager, Consumer Relations
General Electric Company
Appliance Park
Louisville, Kentucky 40225
FINALLY, if your problem is still not resolved, write:
Major Appliance Consumer Action Panel
20 North Wacker Drive
Chicago, Illinois 60606
3.
Service Contracts
For trouble-free service beyond
the written warranty period.
o
keep your appliance in good operating
,;.:..’
J.
...,
condition during the contract period at
no additional charge. Service contracts
let you pay today’s prices for service
If you prefer to budget your repair expenditures
a month, a year, or several years from
instead of being surprised by them, GE offers
service contracts for varying lengths of time on
nowAfld,y
ou’llreceiveservicef
rom
GE trained service technicians using
all GE major appliances. With a contract,
we’ll
,,
,..;:”+
only Genuine GE parts.
4.
The Quick Fix
TM
System
You can save money and time
by doing it yourself.
For do-it-you rselfers who would
prefer to fix GE major appliances
themselves ... GE offers an industry
first, the Quick
FixT” System.
A program for do-it-yourself appliance repair,
the system includes step-by-step repair
manua/s for refrigerators, most non-microwave
electric ranges, dishwashers, and standard
and large capacity washers and dryers, plus
specially packaged replacement parts, and
technical help with a
toll
tree
800
number
-5.
Help for You By Phone
The GE Answer
CenterTM
800.626.2000
Should you need help in the selection and purchase
consumer information service is open 24 hours a
of new appliances, or have questions about the
day, seven days a week.
operation of the GE appliances you now own-or have
any other questions about our consumer products
Our staff of experts stands ready to assist you
or services, you are only a TOLL-FREE call away.
anytime.
@ars
-
Your Direct Line to General Electric
~
The GE Answer
Centd~
800.626.2000
Save proof of original purchase date such as your sales slip or can celled check to establish warranty period.
——
-.
WHAT IS COVERED
FULL ONE-YEAR WARRANTY
This warranty is extended to the
original purchaser and any succeed-
For one year from date of original
purchase, we will provide, free of
Ing
owner for products purchased
charge, parts and service labor in
for ordinary
home use in the 48
your home to repair or replace
mainland states, Hawaii and
any
part
of
the
hood
that fails
Washington,
D.C. In Alaska the
because of manufacturing defect. ‘a
rr
a
nt
y ‘he ‘
ame
except ‘hat ‘
t
IS LIMITED because you must pay
to ship the product to the service
shop or for the service technician’s
travel costs to your home.
All warranty service will be provided
by our Factory Service Centers or
by our authorized Customer
Care@
servicers during normal working
hours. Check the White Pages
for
GENERAL ELECTRIC COMPANY
or GENERAL ELECTRIC FACTORY
SERVICE. Look in the Yellow
Pages for GENERAL ELECTRIC
CUSTOMER
CARE@
SERVICE or
GENERAL ELECTRIC-HOTPOINT
CUSTOMER
CARE@
SERVICE.
WHAT IS NOT COVERED . Service trips to
your
home to
● Replacement of house fuses
teach you how to use the product.
or resetting of circuit breakers.
.-
Read your Use and Care material.
. Failure of the product if it is
If you then have any questions
used for other than its intended
about operating the product,
purpose or used commercially.
please contact your dealer or our
● Damage to product caused
Consumer Affairs office at the
by accident, fire, floods or acts
address below,
or call, toll free;
of God.
The GE Answer
Center’”
WARRANTOR IS
NOT
RESPON-
800.626.2000
SIBLE
FOR CONSEQUENTIAL
consumer information service
DAMAGES.
● Improper installation.
If you have an installation problem,
contact your dealer or installer.
You are responsible for providing
adequate electrical, exhausting
and other connecting facilities.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company
If further help is
rrseded
concerning this warranty, contact:
Manager–Consumer Affairs, General Electric Company, Appliance Park, Louisville, KY 40225
;
