General
Unpack the heater carefully and retain the packaging for
possible future use, in the event of moving or returning
the re to your supplier.
These models are designed to be free standing and are
normally positioned against a wall.
The re incorporates a ame eect, which can be used
with or without heating, so that the comforting eect may
be enjoyed at any time of the year. Using the ame eect
on its own only requires little electricity.
Please note: Used in an environment where background
noise is very low, it may be possible to hear a sound
which is related to the operation of the ame eect. This
is normal and should not be a cause for concern.
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Important Safety Advice
When using electrical appliances, basic
precautions should be followed to reduce
the risk of re, electric shock, and injury to
persons, including the following:
If the appliance is damaged, check imme-
diately with the supplier before installation
and operation.
Do not use this appliance in the immediate
surroundings of a bath, shower or swimming
pool.
Do not use outdoors.
This appliance must not be located imme-
diately above or below a xed socket outlet
or connection box.
WARNING : The appliance carries
the Warning Symbol indicating that it must
not be covered or has a Do not cover label.
Do not cover or obstruct in any way the heat
outlet grille located underneath the appli-
ance Overheating will result if the appliance
is accidentally covered. Do not place materi-
al or garments on the appliance, or obstruct
the air circulation around the appliance, for
instance by curtains or furniture, as this
could cause overheating and a re risk.
In the event of a fault unplug the heater.
Unplug the appliance when not required
for long periods. The supply cord must be
placed on the right hand side of the heater
away from the heat outlet underneath the
appliance.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the appliance
by a person responsible for their safety.
Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by Children without supervision.
Children should be kept away unless con-
tinuously supervised. Children shall not
turn on/o the appliance. Children shall not
plug in, regulate and clean the appliance or
perform user maintenance.
The appliance must be positioned so that
the plug is accessible.
Although this appliance complies with safety
standards, we do not recommend its use on
deep pile carpets or on long hair type of rugs.
If the supply cord is damaged it must be
replaced by the manufacturer or service
agent or similarly qualied person in order
to avoid a hazard.
CAUTION: In order to avoid a hazard due
to inadvertent resetting of the thermal cut-
out, this appliance must not be supplied
through an external switching device, such
as a timer, or connected to a circuit that is
regularly switched on and o by the utility.
CAUTION - Some parts of this product
can become very hot and cause burns.
Particular attention has to be given where
children and vulnerable people are present.
Operating Instructions - See Fig. 2&3
Icon Display Funtion Description
A -
Power /
Standby
Press Once to turn the product ‘ON’.
Press a second time to put the product into ‘STANDBY’
(When returning from ‘STANDBY’ mode the product will return to previous settings unless
the product has been unplugged, in which case it will reset to factory settings)
B
‘FLAME EFFECT’ button this turns the ame effect ON or OFF independently of the
products other features.
+
Flame
Up
This Button will increase the brightness of the ame effect. There are 5 brightness settings
shown as F1, F2, F3, F4, F5. This button will ONLY increase the brightness level.
-
Flame
Down
This Button will decrease the brightness of the ame effect. There are 5 brightness settings
shown as F1, F2, F3, F4, F5. This button will ONLY decrease the brightness level.
-
Flame
Cycling
This setting is set by pressing the Flame Up button once more after F5. this will cause the
brightness of the ame effect to cycle from F2 to F5 in a continuous Loop.
-
Off
This will turn the ame effect off. If the heater is ON, the display will activate and remain
active to read the set temperature and show if the product is on LOW HEAT/ HIGH HEAT/
COOL BLOW.
C
Sleep
Timer
Press multiple times to change the ‘SLEEP TIMER’ in 0.5 hr increments from 0.5
hr to 8.0 hr before turning off. The remaining time on the ‘SLEEP TIMER’ displa
ys. (This icon is Green in Colour)
D
‘HEAT’ button cycles the unit sequentially through the 4 settings: LOW HEAT, HIGH HEAT,
COOL BLOW and OFF. The heat setting will be indicated by an icon in the display see Fig.1.
When the ame effect is ‘ON’ the display will turn off after 5 seconds, however if the
heater is being used independently of the ame effect. The low heat or high heat icon
will appear continuously in the display.
Low
Heat
This setting will run the heater at ‘LOW HEAT’ this setting will be indicated by the ‘LOW
HEAT’ icon. To Adjust the temperature setting the Temp Down or Temp Up buttons de-
scribed below must be used.
(This icon is Orange in Colour)
High
Heat
This icon in the display indicates ‘HIGH HEAT’ this setting will be indicated by the ‘HIGH
HEAT’ icon. To Adjust the temperature setting the Temp Down or Temp Up buttons de-
scribed below must be used.
(This icon is Red in Colour)
Cool
Blow
This icon in the oating display indicates ‘COOL BLOW’ this setting will be indicated by
the ‘COOL BLOW’ icon and the letters ‘CB’ appearing in the display.
(This icon is Blue in Colour)
- Off
This switches the heater and blower ‘OFF’, no icon will be displayed in the display. Note
the blower will run for 5-10 seconds after being turned off, this is to ensure the product
cools down safely.
E -
Temp
Up
Press multiple times to increase the heater temperature in 1
0
C in-
crements. The highest temperature that can be set 30
0
C .
When High Heat is selected, the letters ‘HH’ appear in the display, this means
the heat will remain ON continusously and is not controlled by the thermostat.
F -
Temp
Down
Press multiple times to lower the heater temperature in 1
0
C in-
crements. The lowest temperature that can be set is18
0
C .
-
‘Top light’ button this turns the top light ON or OFF independently of the products other
features.
User Modes:
Mode Name /Discription Action (Actions cannot be input by remote control)
Change Celsius (
0
C) to Fahrenheit (
0
F)
Press both Temp down ( ) and Temp up ( ) on the unit and hold until
beep is heard and display flashes. (To revert back to Celsius repeat this action)
Disable/Enable Heat Options
on product and remote control
Hold both Heat Cycle ( ) and Temp Up ( ), on the prod-
uct, for 5 seconds, when the heater has been disabled the display
will read “--” and beep 1 time. To enble heat repeat this action.
Disable/Enable Heat Options
on product only
Hold both Flame Cycle ( ) and Heat Cycle ( ), on the product, for 5 sec-
onds, when the heater has been disabled the product will beep. This will
disable heat control functions on the product only. To enble heat repeat this
action.Note: the remote control will still be able to operate heat functions.
G
Thermal Safety Cut-out
The built-in overheat cut-out switches o the appliance automatically in
the event of a fault. If this occurs switch o the appliance or disconnect
the mains plug from the socket. After a short cooling down phase, the
appliance is ready for use again. If the fault should occur again, see
your local dealer.
Cleaning
WARNING – ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE CLEANING THE HEATER.
For general cleaning use a soft clean duster – never use abrasive
cleaners. The glass viewing screen should be cleaned carefully with a
soft cloth. DO NOT use proprietary glass cleaners.
To remove any accumulation of dust or u the soft brush attachment of
a vacuum cleaner should occasionally be used to clean the outlet grille
of the fan heater.
Recycling
At the end of the electrical products useful life it should not
be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for
recycling advice in your country.
After Sales Service
Should you require after sales service or should you need to
purchase any spares, please contact the retailer from whom
the appliance was purchased or contact the service number
relevant to your country on the warranty card.
Please do not return a faulty product to us in the rst instance
as this may result in loss or damage and delay in providing
you with a satisfactory service. Please retain your receipt as
proof of purchase.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on an AC ~ supply only and the voltage
marked on the heater must correspond to the supply voltage.
Before switching on, please read the safety warnings and operating
instructions.
Remote control - see Fig. 3
The maximum range of use is ~ 5metres.
Warning: It takes time for the receiver to respond to the transmitter.
Do not press the buttons more than once within two seconds for
correct operation.
Battery information - see Fig. 3
1. To activate the remote control remove the battery isolation strip,
which is used to ensure your remote control reaches you fully charged.
2. To replace the remote control battery, turn over the remote control,
and follow the diagram embossed on the remote control
3. Only use CR2025 size of batteries.
Discard leaking batteries
Dispose of batteries in the proper manner according to provincial
and local regulations.
Any battery may leak electrolyte if mixed with a dierent battery
type, if inserted incorrectly, if all the batteries are not replaced at the
same time, if disposed of in a re, or if an attempt is made to charge
a battery not intended to be recharged.
WARNING - KEEP BATTERIES OUT OF REACH
OF CHILDREN
1. Swallowing may lead to serious injury in as little as 2 hours or death,
due to the chemical burns and potential perforation of the oesophagus.
2. If you suspect your child has swallowed or inserted a button battery
immediately call the 24-hour Poisons Inforation Centre on 13 11 26 (in
Australia) or 0800 764 766 (in New Zealand) for fast, expert advice.
3. Examine devices and make sure the battery compartment is
correctly secured, e.g. that the screw or other mechanical fastener
is tightened. Do not use if the compartment is not secure.
4. Dispose of used button batteries immediately and safely. at
batteries can still be dangerous.
Maintenance
WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY
BEFORE ATTEMPTING ANY MAINTENANCE.
Light Emitting Diode
This re is tted with LED (Light Emitting Diode) lamps. These LED
lamps are maintenance-free and should not require replacing during
the life of the product.
Glen Dimplex Australia
8 Lakeview Drive,
Scoresby,
VIC 3179,
Australia
www.dimplex.com.au
Ph: 1300 556 816
© Glen Dimplex Heating & Ventilation.
All rights reserved. Material contained in this publication may not be reproduced in whole or part, without
prior permission in writing of Glen Dimplex Heating & Ventilation.
Glen Dimplex New Zealand Pty Ltd.
38 Harris Road,
East Tamaki,
Auckland 2013
New Zealand
www.dimplex.co.nz
Ph: 0800 666 2824
