PARTS SUPPLIED
Remove the hardware accessory bag and other
parts from inside the packaging. Check contents
against illustrations to ensure that all parts are
included.
Installation
Instructions
Questions? Call 800.GE.CARES (800.432.2737) or visit our Website at: ge.com
1
197D8125P001 31-46533 12-08 JR
BEFORE YOU BEGIN
• IMPORTANT – Save these instructions for
local inspector’s use. Observe all governing codes
and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions
with your Owner’s Manual for future reference.
• Skill Level – Installation of this kit requires basic
mechanical skills. Proper installation is the
responsibility of the installer. Product failure due
to improper installation is not covered under the
GE Appliance Warranty.
• Completion Time – 20 to 30 minutes.
If you received a damaged kit, you should
immediately contact your dealer or builder.
Read carefully. Keep these instructions.
CAUTION: Door panels may have
sharp edges.
FOR YOUR SAFETY: Read and observe
all CAUTIONS and WARNINGS shown throughout
these instructions.
Foam Pads (2)
REMOVE BOTTOM TRIM COVER
ON TOP DRAWER
Use a Phillips-head screwdriver to unscrew the
three screws on the bottom trim cover.
NOTE: Support weight of trim panel as trim
cover is removed (if applicable).
Remove trim panel by sliding downward (if
applicable).
1
A
B
Doors With Handles (2)
Screws (6)
TOOLS YOU WILL NEED
Phillips-Head Screwdriver
INSTALLING YOUR KIT
Double Drawer
Clad Door Kit
ZIDI240PII, ZIDI240WII
