STEPS TO JUMP START YOUR VEHICLE
USER GUIDE
Model: Alpha 100
3 steps to fix your problem:
1. Check the clamps connection and the product’s battery is above 20%.
2. Press the Power Button and Flashlight Button simultaneously for 2-3 seconds.
3. The screen will shows “READY”, and go back to start engine ignition.
Warning: When using the Force Start Function, auto-detection and safety features will be disabled.
1.Insert the jumper cable
into the jump starter and
connect the clamps to the
car battery.
2.‘’READY’’ sign shows on
the screen.
3.Start your car engine.
If the screen doesn’t display anything when you have correctly connected the clamps to your car,
you can use the Force Start Function to enter boost mode.
Why the screen shows nothing when you try to start your car ?
ABOUT THE FORCE START FUNCTION:
Error Code Reason Solution
‘’+’’and ‘’-’’ poles of battery
clips reversed.
Reverse the clips and ensure the correct connection.
Press the Power Button and Flashlight Button simultaneously
for 2-3s to start force output. (Force Start Function)
①Please store it back to where the temperature is
between : -40°F-113°F.
②Please charge the device at room temperature.
The safe mode will be off automatically after 10 minutes
waiting. (Please do not turn off the product during the
process)
The voltage of the car battery
is between 2-8V.
① The product’s operating
temperature is too high. (≥113°F)
② Charge the device at extremely
low or high temperature.
Jump start the battery more than
5 times within 10 minutes, the
product will automatically enter
the safe mode.
ABOUT THE ERROR CODE:
ABOUT USB-A OUTPUT PORT:
1.Plug the cable into the
USB-A output port.
2.Press the Power Button.
ABOUT LED FLASHLIGHT:
1.Hold the Flashlight Button for 1-2s.
2.Press briefly to switch the light modes.
•50% Lumen Light → 100% Lumen Light → White Strobe Light → White SOS Light → Red Strobe Light
ABOUT 12V DC OUTPUT PORT (MAX 15V/10A):
1.Plug the 12V cigarette
lighter socket adapter into
the 12V DC output port.
2.Connect your 12V DC
appliances to the ciga-
rette lighter adapter.
3.Press the Power Button.
ABOUT PRE-HEAT TECH:
1.Connect the clamps to the car battery correctly.
2.The Pre-Heat Function will operate automatically and the icon will be displayed on the screen when the
detected temperature is below the ideal operating temperature.
3.The screen will show "READY" after preheating , then start your car engine.
CONTACT HULKMAN
Tel : +1 (877) 892-9703
Email：[email protected]
Address: 46 Smith Alley, Suite 200 Pasadena, CA 91103
Our help center: https://support.hulkman.com
Flashlight
Button
