EN Versatile Cordless Vacuum Cleaner 4 in 1

Translation of the original manual

SVC 0725BK

03/2021

Versatile Cordless Vacuum Cleaner 4 in 1

Important safety instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

■ This vacuum cleaner may be used by children 8 years of age

and older and by persons with physical, sensory, or mental

impairments or by inexperienced persons, if they are properly

supervised or have been informed about how to use this

vacuum cleaner in asafe manner and understand the potential

dangers.

■ Children must not play with the vacuum cleaner. Cleaning and

maintenance performed by the user must not be performed by

unsupervised children.

■ If the power adapter is damaged, it must be replaced with an

original type. For areplacement power adapter, please contact

an authorised service centre. It is forbidden to use the appliance

if it has adamaged power adapter.

WARNING:

Avoid coming into contact with the rotating parts of the

vacuum cleaner‘shand accessories. There is arisk of ge-

tting caught on these parts and possible injury.

Only use the vacuum cleaner with the original power

adapter, charging base and accessories that were

supplied with it.

This vacuum cleaner is designed for use in households, offices and similar types of areas. Do not use in industrial surroundings.

Do not expose the vacuum cleaner to direct sunlight and do not place it near an open fire or appliances that are asource of heat.

Before connecting the adapter to apower socket, check that the technical details on its rating label match the electrical voltage in the power socket.

Make sure the adapter power cord is not touching ahot surface or sharp objects. Position the adapter power cord so that it will not be tripped over.

Never submerge the vacuum cleaner, the charging base and the power adapter in water or any other liquid and do not wash under running water.

Before turning on the vacuum cleaner, make sure that all the inflow and outflow filters are installed in their place.

When the vacuum cleaner is running, ensure that the air outlets and the suction hole are not blocked.

Do not use the vacuum cleaner to vacuum the following items:

– smouldering cigarettes, burning items, matches or embers;

– water and other liquids;

03/2021

– flammable or volatile materials;

– items, e.g. broken glass, needles, pins, etc.;

– flour, wall plaster, cement and other building materials;

– larger pieces of paper or plastic bags, which can easily block the suction hole.

■ Vacuuming of some types of floors or floor surfaces can create an electrostatic discharge, which presents no danger to the user.

■ Always turn off the vacuum cleaner when leaving it without supervision, after finishing using it and before cleaning it.

■ Disconnect the power adapter from the power socket before cleaning it and after it has finished charging.

■ Disconnect the power adapter from the power socket by pulling on the plug, never pull on the power cord. Otherwise, this could damage the power

adapter or the socket.

■ If the power adapter is damaged, it must be replaced with an original type. For areplacement power adapter, please contact an authorised service

centre.

■ Do not use the vacuum cleaner if it is not working correctly if it has been damaged or has been submerged in water.

■ Do not repair the vacuum cleaner yourself or make any adjustments to it. Have all repairs performed at an authorised service centre. By tampering

with the appliance, you risk voiding your legal rights arising from unsatisfactory performance or quality warranty.

03/2021

SVC 0725BK

13 12 11 10

03/2021

22 23

1 2

5 6

8 9 10 11 1213 14

03/2021

15 16

21 22

03/2021

Versatile Cordless

Vacuum Cleaner 4 in 1

User´smanual

DESCRIPTION OF THE VACUUM CLEANER

DESCRIPTION OF THE MOTOR UNIT

A1 Output hole of the motor

unit

A2 Dust container release

button

A3 Inflow filter cover

A4 Inflow filter

A5 Speed button

A6 On / Off button

A7 Handle

A8 Charging battery light

A9 Power adapter socket

A10 Rechargeable battery

A11 Outer filter

A12 Tube filter

A13 Transparent dust container

A14 Release button of the dust

container bottom for quick

removal of dirt

A15 Battery release button

A16 Lock to release the motor

unit

A17 Metal tube

A18 Floor nozzle

A19 Lock to release the floor

nozzle

A20 Protective cover

A21 Electric rotary brush

A22 Castors

A23 Lock

A24 Side cover to remove the

rotary brush

DESCRIPTION OF THE ACCESSORIES

B1 Cat&Dog motorised mini

brush

B2 Lock to release the mini

brush

B3 Protective cover

B4 Rotary brush lock

B5 UV-Clight

B6 Castors

B7 Rotary brush

B8 Combined crevice nozzle

B9 Crevice nozzle brush

B10 Button to slide out / back

the brush

B11 Combined attachment for

upholstery and furniture

B12 Attachment brush

B13 Button to slide out / back

the brush

B14 Soft brush

B15 Articulated connector

B16 Flexible hose

B17 Holder

B18 Power adapter

B19 Wiping attachment

B20 Water tank

B21 Tank lid

B22 Water control button

Not shown

Wall plug

Screws

Removable Velcro zip sleeve (6 pcs)

ASSEMBLY AND DISASSAMBLY OF THE VACUUM CLEANER

1. ASSEMBLY AND DISASSAMBLY OF THE STICK VACUUM

CLEANER

Place the floor nozzle A18 on aflat, dry and stable surface. Attach

the tube A17 to the floor nozzle so that the connectors at the back

of the floor nozzle A18 are aligned with the holes inside the tube

A17 – see picture C1. Push the tube A17 until it clicks.

Insert the output hole A1 of the motor unit into the tube A17 so

that the connectors at the back of the tube A17 are aligned with

the holes inside the outlet hole A1 – see picture C2.

When you need to disassemble the stick vacuum cleaner, press

the lock A16 to release the motor unit. Then press the lock A19 to

release the floor nozzle A18.

2. ASSEMBLY AND DISASSEMBLY THE WIPING ATTACHMENT

Assemble the stick vacuum cleaner – see the previous part of the

manual.

Attach the sleeve to the bottom surface of the attachment B19

and put the attachment on the floor.

Place the vacuum cleaner above the wiping attachment B19 so

that the protrusion on the attachment B19 is aligned with the

hole on the bottom surface of the floor nozzle A18. Gently push

the vacuum cleaner until it clicks. That signalizes the correct

connection of the attachment B19 to the floor nozzle A18.

When you need to remove the attachment B19 from the vacuum

cleaner, carefully hold the attachment B19 by one hand and pull

the vacuum cleaner upwards until the floor nozzle A18 is released

from the attachment B19.

3. ASSEMBLY AND DISASSEMBLY OF THE VACUUM CLEANER

WITH ACCESSORIES

To ensure perfect cleaning of your home, you can attach any of

the supplied accessories to the output hole A1 of the motor unit.

Simply remove the accessory by pulling it out of the output hole

A1 of the motor unit. Press the lock B2 first to remove the mini

brush B1.

1. Cat&Dog motorised mini brush

Cat&Dog motorised mini brush is the ideal helper for removing

animal fur, hair, etc., while at the same time being suitable for

vacuuming hard-to-reach places. Its use is not limited to the

home and can be used for vacuuming the car. It quickly and

effectively removes hair, animal fur and other materials from car

seats, upholstery, pillows, and other textile surfaces.

2. Combined crevice nozzle

It is suitable for vacuuming hard to reach places (e.g., window

frames, corners, libraries, spaces between mattresses,

upholstery, etc.). Press and hold the B10 button and move

forward to slide the brush out. Press B10 button and move

backward to slide the brush back.

3. Combined attachment for upholstery and furniture

The attachment is suitable for vacuuming surfaces, such as

furniture or upholstery. Press and hold the B13 button and

move forward to slide the brush out. Thanks to the soft bristles,

the attachment is ideal for removing dirt from fine surfaces,

such as net curtains, curtains, etc. Press B13 button and move

backward to slide the brush back.

4. Soft brush

It is ideal for vacuuming dirt and dust from fragile objects,

libraries, walls, blinds, etc.

5. Articulated connector and flexible hose

Attach the articulated connector B15 or flexible hose B16 to

the output hole A1 when you need to extend the reach of the

used accessory, e.g., you need to vacuum dust on the wardrobe.

Note:

The picture D shows the possibilities how to combine the

accessories.

CHARGING THE BATTERY

The battery A10 can be charged either installed in the motor unit or

removed.

Insert the connector of the power adapter B18 into the socket A9 and

insert the adapter plug into the power socket.

The light A8 turns red. The charging time usually takes 4 - 5 hours. The

battery A10 is charged once the light A8 turns green. Then disconnect

the connector of the power adapter A18 from the socket A9 and

remove the plug from the power socket.

Note:

Once the battery A10 is almost discharged, the operation

of the vacuum cleaner will automatically stop to prevent

the battery A10 from being completely discharged.

In order to ensure the long life of the battery A10, it is

advised to fully charge the battery A10 before the first use

and to discharge before the second charging (operation of

the vacuum cleaner will automatically stop).

Tip:

This vacuum cleaner contains a built-in Li-ion battery.

To ensure the longest possible lifetime of the battery, we

recommend:

– do not unnecessarily leave the battery fully charged or

completely flat for too long,

– do not keep the battery permanently fully charged. Its

lifetime will be extended by keeping it at approximately

half charge.

– do not fully discharge the battery.

03/2021

INSERTING AND REMOVING THE BATTERY

1. Inserting the battery: Carefully turn the motor unit upside

down and insert the fully charged battery A10 so that the

battery A10 fits into the connective grooves – see picture E.

Push the battery A10 until it clicks. The battery A10 can only be

inserted with one side.

Warning:

Never insert the battery A10 in the opposite way or

with great force. There is arisk of damage.

2. Removing the battery: When you need to remove the battery

A10, press the A15 button to release the battery A10. Carefully

remove it from the motor unit.

Warning:

If you do not use the vacuum cleaner for along time,

remove the battery A18 from it and store it in acold

and dry place. Charge the battery regularly. Keep

it away from the reach of metal objects to prevent

excessive discharge.

USING THE STICK VACUUM CLEANER

1. Assemble the vacuum cleaner according to the instructions in

the section “ASSEMBLY AND DISASSAMBLY OF THE STICK

VACUUM CLEANER”.

2. Insert the fully charged A10 into the motor unit.

3. Press the On / Off button A6 and the vacuum cleaner turns on.

4. You can adjust the speed using the A5 button. Press the A5

button repeatedly to switch the speed as following:

I(low speed – ensures longer vacuuming time)

II (high speed – vacuuming at high power)

III (turbo speed – vacuuming at maximum power)

5. When vacuuming is completed, press the On / Off button A6

and the vacuum cleaner turns off.

Note:

Electric rotary brush A21 will automatically stop once it is

blocked by, e.g., aforeign object or large amount of hair

or animal hair. It is asafety feature that prevent the brush

from damage. In such case, turn the vacuum cleaner off by

pressing the On / Off button A6 and remove the blocked

object or hair from the brush A21.

USING THE VACUUM CLEANER WITH WIPING ATTACHMENT

Place the wiping attachment B19 with the attached sleeve on the floor.

Remove the lid B21 and pour water or cleaning solution into the water

tank B20. Put the lid B21 back.

Note:

Always use a neutral cleaning agent with low foaming

effect.

Attach the vacuum cleaner to the attachment B19.

In order to vacuum and wipe at the same time, pull the B22 button

up. Water slowly begins to flow from the tank into the sleeve. Turn the

vacuum cleaner on, and while vacuuming you will also wipe the floor.

Note:

Regularly check the water/solution level in the water tank

B20 and fill it up as necessary.

When no longer using the wiping attachment B19, turn the vacuum

cleaner off and push the B22 button down. This will prevent air from

entering the water tank and the water will stop flowing out. Pull the

vacuum cleaner out in the upward direction.

STORAGE UNDER NORMAL USE

The vacuum cleaner SVC 0725BK is supplied with aholder B17 which

can be fixed on the wall. Choose the place where the holder B17 will be

easily accessible and there will be free space around it.

Mounting the holder on the wall

1. Put the holder B17 on the wall and using apencil, mark the

points where it is necessary to drill the holes.

2. Drill two holes which you insert the wall plugs into.

3. Place the holder B17 to the wall and insert the screws into the

holes in the holder. Use ascrewdriver to fix them. Make sure

the holder B17 does not move and the screws are properly

tightened.

Warning:

Never install the holder B17 in environments with

high huminidity or dustiness.

Storage of the motor unit and accessories

The holder B17 is designed to store the motor unit and accessories in it.

Insert the motor unit into the holder B17 and you can attach the

selected accessories you use the most often to two pins – see the

picture F.

CLEANING AND MAINTENANCE

Before cleaning, always make sure the vacuum cleaner is switched off.

Remove the battery A10 from the motor unit.

CLEANING THE MOTOR UNIT AND ACCESSORIES

Use asoft cloth, lightly dampened in a lukewarm water, to clean the

outer parts of the vacuum cleaner. Do not use abrasive cleaning agents,

solvents, or dissolving agents, otherwise the unit surface may be

damaged.

CLEANING THE STICK VACUUM CLEANER

Empty the dust container

It is advised to empty the dust container A13 after each use. However,

if the dirt level reaches the MAX mark, it is necessary to empty the dust

container A13 immediately.

1. Remove the accessory from the motor unit.

2. Place the motor unit above the waste bin with the dust

container bottom facing down.

3. Press the A14 button and the dust container bottom is released

and opens – see picture G1.

4. This will empty the container content directly into the waste

bin.

5. Use your hand to close the container bottom. It clicks once

correctly fitted.

Cleaning the dust container

Clean the dust container A13 regularly to prevent unpleasant odours.

1. Remove the accessory from the motor unit and empty the dust

container A13 according to the instructions above.

2. Press the A2 button to release the dust container and at the

same time, turn the container A13 until the arrow on the motor

unit points at the

symbol. Carefully remove it from the

motor unit – see picture G2.

3. Wipe the inner walls of the dust container A13 using a light

dampened soft sponge. Dry with aclean cloth.

4. Turn the outer filter A11 until the arrow on the filter A11 points

at the symbol to release the outer filter A11. Carefully

remove it from the motor unit downwards – see picture G3.

Remove the tube filter A12 from the motor unit downwards –

see picture G4.

5. Remove the dirt from both filters. If necessary, you can wash

them under the running clean water. And then dry them with

clean cloth.

Warning:

Never insert wet or damp filters A22 and A12 into the

motor unit! Always wait until it is completely dry.

6. Attach the tube filter A12 to the motor unit.

7. Attach the outer filter A11 to the motor unit so that the arrow

on the filter A11 is aligned with the

symbol. Then turn the

filter A11 until the arrow on the filter A11 points at the

symbol and it clicks.

8. Attach the container A13 to the motor unit so that the arrow

on the motor unit is aligned with the

symbol. Turn until

the arrow on the motor unit points at the

symbol. Correct

securing of the container A13 is signalised by aclick.

03/2021

Cleaning and change of the inflow filter

It is advised to clean inflow filter A4 regularly to ensure proper vacuum

cleaner operation. Depending on how often you use the vacuum cleaner,

change the inflow filter A4 once every 3 or 6 months.

1. Take the cover A3 and pull it upwards.

2. Turn the filter A4 clockwise to release it – see picture G5.

3. Remove the dirt from the filter A4 over the waste bin. If the filter

A4 is heavily soiled, rinse it under running clean water – see

picture G6. Leave it to dry.

4. Insert the filter A4 to the bottom of the cover A3 by aligning the

protrusions on the filter A4 with the grooves inside the cover

A3. Turn the filter A4 counter clockwise until you feel resistance.

5. Insert the cover A3 with installed filter A4 into the motor unit.

Cleaning the floor nozzle

It is necessary to clean the floor nozzle A18 regularly to ensure the

desired and stable suction power.

1. Remove the floor nozzle A18 from the vacuum cleaner and turn

it upside down.

2. Move the lock A23 up to remove the side cover A24 – see

picture G7. Remove it.

3. Carefully remove the rotary brush A21 – see picture G8.

4. Remove tangled hair, animal hair and other dirt from the rotary

brush A21. You can use scissors to remove tangled hair or

animal hair quicker.

5. Clean the inner part of the floor nozzle A18 by adry cloth.

6. Insert the clean rotary brush A21 into the floor nozzle A18.

7. Finally, attach the side cover A24.

CLEANING THE WIPING ATTACHMENT

Always empty out the tank B20 after every use of the attachment B19.

Wipe the attachment B19 with asoft sponge lightly dampened in warm

water. Wipe dry using aclean wiping cloth.

Remove the sleeve and wash it by hand in cold water. Allow it to dry

naturally.

Warning:

Under no circumstances submerge or wash the

attachment B19 in water or any other liquid.

Cleaning the Cat&Dog Mini brush

It is necessary to clean the Cat&Dog Mini brush regularly to ensure the

desired and stable suction power.

1. Remove the rotary brush B1 from the vacuum cleaner and turn

it upside down.

2. Turn the lock B4 to release the brush and take it out – see

picture H.

3. Remove tangled hair, animal hair and other dirt from the brush.

You can use scissors to remove tangled hair or animal hair

quicker.

4. Clean the inner part of the rotary brush B1 by a dry cloth.

5. Place the brush back and turn the lock B4 until it clicks.

Storage

If you do not use the vacuum cleaner, clean it according to the

instructions above and remove the battery A10 from the motor unit.

Before storing, make sure the vacuum cleaner and all accessories are

clean and dry.

Store the appliance on adry, clean and well-ventilated place where it

will not be exposed to extreme temperature and out of reach of children

or animals.

It is advised to regularly charge the battery A10 every 6months.

TROUBLESHOOTING

Before you decide to contact an authorised service centre, please read

through the following table:

Problem Possible cause Solution

Vacuum cleaner

does not work.

Battery A10 is

discharged.

Charge the battery

A10 before using the

vacuum cleaner.

Suction hole is blocked. Remove the dirt from

the suction hole.

Vacuum cleaner is not

correctly assembled.

Make sure all the parts

are correctly assembled.

Suction power

is low.

Dust container A13 is

full, or the filters A11

and A12 are soiled.

Empty the dust

container A13 and

clean the filters A11 and

A12.

A large amount of hair

or animal hair is wound

on the rotary brush

A21.

Clean the rotary brush

A21.

Short operation

time of battery

A10 after

charging.

Battery A10 is not fully

charged.

Fully charge the battery

A10.

Battery A10 is at the

end of its life.

Buy anew battery A10.

Cautions:

If you cannot find your problem in the table above, or

the problem persists, stop using the vacuum cleaner,

turn it off and contact the authorised service centre.

TECHNICAL SPECIFICATIONS

Adapter

Input .........................................................................100 – 240 V~, 50/60 Hz, 0.8 A

Output ............................................................................................ 30 V , 0.6 A

Electric shock protection class .............................................................................. II

Vacuum cleaner

Power input ........................................................................................................ 400 W

Electric rotary brush ...........................................................................................30 W

Cat&Dog electric rotary brush .......................................................................... 5 W

Battery .............................................................. Li-Ion / 25.2 V / 2,500 mAh

Time required for charging to full capacity..................... approx.4 - 5 hours

Operating time when fully charged .............................................up to 50 min

Noise level ...................................................................................................≤ 83 dB(A)

Dust container capacity ...................................................................................0.58 l

Water tank capacity ........................................................................................... 0,25 l

■ The declared noise emission level of vacuum cleaner is ≤ 83 dB(A),

which represents level Aof acoustic power with respect to areference

acoustic power of 1pW.

We reserve the right to change text and technical specifications.

Electric shock protection class

Class II – Electrical shock protection is provided by

double or heavy-duty insulation.

The product is intended for household use only. The

product is not intended for outdoor use.

Thoroughly read the all the instructions before using

the product.

03/2021

DISPOSAL OF BATTERIES

Prior to disposing of the product or handing it over at

a specialised collection facility, it is necessary to ensure

that the battery is removed. Before removing the battery,

it is necessary to start the vacuum cleaner and wait until

it is completely flat. The battery contains environmentally

damaging substances and therefore does not belong in

standard household waste. Their correct disposal will be

performed by the respective collection facility.

INSTRUCTIONS AND INFORMATION REGARDING THE

DISPOSAL OF USED PACKAGING MATERIALS

Dispose of used packaging material at a site designated for waste in

your municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol on products or original documents means

that used electric or electronic products must not be

added to ordinary municipal waste. For proper disposal,

renewal and recycling, hand over these appliances to

determined collection points. Alternatively, in some

European Union states or other European countries you

may return your appliances to the local retailer when

buying an equivalent new appliance.

Correct disposal of this product helps save valuable natural resources

and prevents potential negative effects on the environment and human

health, which could result from improper waste disposal. Ask your local

authorities or collection facility for more details.

In accordance with national regulations penalties may be imposed for

the incorrect disposal of this type of waste.

For business entities in European Union states

If you want to dispose of electric or electronic equipment, ask your

retailer or supplier for the necessary information.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of this

product, request the necessary information about the correct disposal

method from the local council or from your retailer.

This product meets all the basic requirements of EU

directives related to it.

Sencor SVC 0725BK Cordless Stick Vacuum Cleaner

Product's Documents

User's Manual

Specifications

Sencor SVC 0725BK Questions and Answers
