ENG This user manual includes detailed usage instructions
for your camera. Please read this manual thoroughly.
USER
MANUAL
1
Copyright information
•
Camera specications or contents of this manual may be changed
without prior notice due to upgrade of camera functions.
•
You are not allowed to reuse or distribute any part of this manual
without prior permission.
•
We recommend using your camera within the country where you
purchase it.
•
Use this camera responsibly and adhere to all laws and regulations
concerning its use.
PlanetFirst represents Samsung Electronics' commitment to
sustainable development and social responsibility through
eco-driven business and management activities.
•
Microsoft Windows and the Windows logo are registered trademarks of
the Microsoft Corporation.
•
Mac and Apple App Store are registered trademarks of the Apple
Corporation.
•
Google Play Store is a registered trademark of Google, Inc.
•
Adobe, the Adobe logo, Photoshop and Lightroom are either registered
trademarks or trademarks of Adobe Systems Incorporated in the United
States and/or other countries.
•
microSD™, microSDHC™, and microSDXC™ are registered trademarks of
the SD Association.
•
HDMI, the HDMI logo, and the term "High
Denition Multimedia Interface" are
trademarks or registered trademarks of HDMI
Licensing LLC.
•
Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered
trademarks of the Wi-Fi Alliance.
•
Trademarks and trade names used in this manual are the property of
their respective owners.
2
Health and safety information
Prevent damage to subjects’ eyesight.
Do not use the ash in close proximity (closer than 1 m/3 ft) to people or
animals. If you use the ash too close to your subject’s eyes, this can cause
temporary or permanent eyesight damage.
Keep your camera away from small children and pets.
Keep your camera and all accessories out of the reach of small children
and animals. Small parts may cause choking or serious injury if swallowed.
Moving parts and accessories may present physical dangers as well.
Do not expose the camera to direct sunlight or high
temperatures for an extended period of time.
Prolonged exposure to sunlight or extreme temperatures can cause
permanent damage to your camera’s internal components.
Avoid covering the camera or charger with blankets or clothes.
The camera may overheat, which may distort the camera or cause a re.
Do not handle the power supply cord or the charger during a
thunderstorm.
This may result in an electric shock.
Always comply with the following precautions and usage tips to avoid
dangerous situations and ensure peak performance of your camera.
Warning—situations that could cause injury to yourself
or others
Do not disassemble or attempt to repair your camera.
You can damage the camera and expose yourself to the risk of an electric
shock.
Do not use your camera near ammable or explosive gases
and liquids.
This may cause a re or explosion.
Do not insert ammable materials into the camera or store
these materials near the camera.
This may cause a re or electric shock.
Do not handle your camera with wet hands.
This may result in an electric shock.
3
Health and safety information
If liquid or foreign objects enter your camera, immediately
disconnect all power sources, such as the battery or charger,
and then contact a Samsung service center.
Comply with any regulations that restrict the use of a camera
in a certain area.
•
Avoid interference with other electronic devices.
•
Turn o the camera when in an aircraft. Your camera can cause
interference with aircraft equipment. Follow all airline regulations and
turn o your camera when directed by airline personnel.
•
Turn o the camera near medical equipment. Your camera can interfere
with medical equipment in hospitals or health care facilities. Follow all
regulations, posted warnings, and directions from medical personnel.
Avoid interference with pacemakers.
Maintain a safe distance between this camera and all pacemakers to
avoid potential interference, as recommended by the manufacturer and
research groups. If you have any reason to suspect that your camera is
interfering with a pacemaker or other medical device, turn o the camera
immediately and contact the manufacturer of the pacemaker or medical
device for guidance.
Caution—situations that could cause damage to your
camera or other equipment
Remove the batteries from your camera when storing it for an
extended period of time.
Installed batteries may leak or corrode over time and cause serious
damage to your camera.
Use only authentic, manufacturer-recommended,
Lithium-ion replacement batteries. Do not damage or heat the
battery.
Inauthentic, damaged, or heated batteries may cause a re or personal
injury.
Use only Samsung-approved batteries, chargers, cables, and
accessories.
•
Using unauthorized batteries, chargers, cables, or accessories can cause
batteries to explode, damage your camera, or cause injury.
•
Samsung is not responsible for damage or injuries caused by
unapproved batteries, chargers, cables, or accessories.
Use the battery only for its intended purpose.
Misusing the battery may cause a re or electric shock.
4
Health and safety information
Do not touch the ash while it res.
The ash is very hot when red and may burn your skin.
When you use the AC charger, turn o the camera before you
disconnect the power to the AC charger.
Failing to do so may result in re or electric shock.
Disconnect the charger from the wall socket when not in use.
Failing to do so may result in re or electric shock.
Do not use a damaged power supply cord, plug, or loose outlet
when you charge batteries.
This may cause a re or electric shock.
Do not allow the AC charger to come in contact with the +/-
terminals on the battery.
This may cause a re or electric shock.
Do not drop or subject the camera to strong impacts.
Doing so may damage the screen or external or internal components.
Exercise caution when you connect cables and install batteries
and memory cards.
If you force the connectors, improperly connect cables, or improperly
install batteries and memory cards, you can damage ports, connectors,
and accessories.
Keep cards with magnetic strips away from the camera case.
Information stored on the card may be damaged or erased.
Never use a damaged battery, or memory card.
This may result in electric shock or camera malfunction or cause a re.
Do not place the camera in or near magnetic elds.
Doing so may cause the camera to malfunction.
Do not use the camera if the screen is damaged.
If the glass or acrylic parts are broken, visit a Samsung service center to
have the camera repaired.
5
Health and safety information
Check that the camera is operating properly before use.
The manufacturer takes no responsibility for any loss of les or damage
that may result from camera malfunction or improper use.
You must plug the small end of the USB cable into your
camera.
If the cable is reversed, it may damage your les. The manufacturer is not
responsible for any loss of data.
Do not expose the lens to direct sunlight.
This may discolor the image sensor or cause it to malfunction.
If the camera overheats, remove the battery and allow it to
cool down.
•
Prolonged usage of the camera may overheat the battery and raise
the internal temperature of the camera. If the camera stops operating,
remove the battery and allow it to cool down.
•
High internal temperatures may result in noise in your photos. This is
normal and does not aect your camera’s overall performance.
Avoid interference with other electronic devices.
Your camera emits radio frequency (RF) signals that may interfere
with unshielded or improperly shielded electronic equipment, such as
pacemakers, hearing aids, medical devices, and other electronic devices in
homes or vehicles. Consult the manufacturers of your electronic devices
to solve any interference problems you experience. To prevent unwanted
interference, use only Samsung-approved devices or accessories.
Use your camera in the normal position.
Avoid contact with your camera’s internal antenna.
Data transference and your responsibilities
•
Data transferred via WLAN could be leaked, so avoid transferring
sensitive data in public areas or on open networks.
•
The camera manufacturer is not liable for any data transfers that infringe
on copyrights, trademarks, intellectual property laws, or public decency
ordinances.
6
Indications used in this manual
Mode indications
Mode Indication
Smart Auto
t
Program
P
Aperture Priority
A
Shutter Priority
S
Manual
M
Custom1
T
Custom2
U
Lens Priority
i
Smart
s
Wireless network
B
Icons used in this manual
Icon Function
Additional information
Safety warnings and precautions
[ ]
Camera buttons. For example, [Shutter] represents the
shutter button.
( )
Page number of related information
ĺ
The order of options or menus you must select to perform
a step; for example: Select b
ĺ Quality (represents
select b, and then Quality).
*
Annotation
7
Contents
Chapter 1
My Camera
Getting started ............................................................................................ 29
Unpacking.................................................................................................................... 29
Camera layout .............................................................................................. 30
Adjusting the viewnder angle and the diopter .............................................. 33
Using the DIRECT LINK button ................................................................................ 33
Inserting the battery and memory card ................................................. 34
Removing the battery and memory card ........................................................... 34
Using the memory card adapter ............................................................................. 34
Charging the battery and turning on your camera .............................. 35
Charging the battery................................................................................................ 35
Turning on your camera ......................................................................................... 35
Performing the initial setup ...................................................................... 36
Selecting functions (options) ................................................................... 38
Selecting with buttons ............................................................................................ 38
Selecting by touch .................................................................................................... 38
Using m .............................................................................................................. 39
E.g. Selecting the photo size in P mode ............................................................. 39
Using the Smart panel ............................................................................................. 40
E.g. Adjust the exposure value in P mode ......................................................... 40
Using iFn ....................................................................................................................... 41
Using the iFn standard function ............................................................................. 42
Using the iFn plus function ...................................................................................... 44
Tips
Concepts in Photography
Shooting postures....................................................................................... 13
Holding the camera ..................................................................................................... 13
Standing photography ............................................................................................... 13
Crouching photography ............................................................................................ 14
Using the display .......................................................................................................... 14
Low-angle shot .............................................................................................................. 15
High-angle shot ............................................................................................................. 15
Aperture ........................................................................................................ 16
Aperture value and the depth of eld .................................................................. 17
Shutter speed ............................................................................................... 18
ISO sensitivity .............................................................................................. 19
How the aperture setting, shutter speed, and ISO sensitivity control
exposure ....................................................................................................... 20
Correlation between focal length, angle, and perspective ................ 21
Depth of eld ............................................................................................... 22
What controls out-of-focus eects? ....................................................................... 22
DOF preview ................................................................................................................... 24
Composition ................................................................................................. 24
Rule of Thirds .................................................................................................................. 24
Photos with two subjects .......................................................................................... 25
Flash ............................................................................................................... 26
Flash guide number ..................................................................................................... 26
Bounce Photography .................................................................................................. 27
8
Contents
Display icons ................................................................................................ 45
In Shooting mode ..................................................................................................... 45
Capturing photos ........................................................................................................ 45
Recording videos ......................................................................................................... 46
About the level gauge ............................................................................................... 46
In Playback mode ...................................................................................................... 47
Viewing photos ............................................................................................................ 47
Playing videos ............................................................................................................... 47
Changing the information displayed ................................................................. 48
Viewing the notication panel ............................................................................. 48
Lenses ............................................................................................................ 49
Lens layout ................................................................................................................... 49
Locking or unlocking the lens ................................................................................. 50
Lens markings ............................................................................................................ 52
Accessories ................................................................................................... 53
External ash layout ................................................................................................. 53
Connecting the external ash ................................................................................. 54
Shooting modes .......................................................................................... 55
t Smart Auto mode ..................................................................................... 55
P Program mode ....................................................................................................... 57
Program Shift ................................................................................................................ 58
Minimum shutter speed ............................................................................................ 58
A Aperture Priority mode ..................................................................................... 59
S Shutter Priority mode.......................................................................................... 60
M Manual mode ....................................................................................................... 61
Using Framing Mode .................................................................................................. 61
Using the Bulb function ............................................................................................ 62
T U Custom mode ............................................................................................... 63
Saving custom modes ................................................................................................ 63
Selecting custom modes .......................................................................................... 63
Deleting custom modes ............................................................................................ 64
i Lens Priority mode ............................................................................................. 64
s Smart mode ......................................................................................................... 66
Using the Best Face mode ........................................................................................ 68
Capturing panoramic photos .................................................................................. 69
Using the Smart Jump Shot mode ........................................................................ 71
Recording a video ..................................................................................................... 72
3D mode ....................................................................................................................... 73
Available functions by shooting mode ............................................................. 75
Chapter 2
Shooting Functions
Size and Resolution .................................................................................... 77
Photo size ..................................................................................................................... 77
Quality ........................................................................................................................... 78
ISO sensitivity .............................................................................................. 79
OLED Color ................................................................................................... 80
White Balance .............................................................................................. 81
Customizing preset White Balance options ....................................................... 82
Picture Wizard (photo styles) .................................................................... 83
AF mode ........................................................................................................ 84
Single AF ....................................................................................................................... 85
Continuous AF ............................................................................................................ 85
Manual focus ............................................................................................................... 86
9
Contents
AF area ........................................................................................................... 87
Selection AF ................................................................................................................ 87
Multi AF ......................................................................................................................... 88
Face Detection AF ..................................................................................................... 88
Self-Portrait AF ........................................................................................................... 89
Touch AF ........................................................................................................ 90
Touch AF ....................................................................................................................... 90
AF Point ......................................................................................................................... 90
Tracking AF .................................................................................................................. 90
One touch shot .......................................................................................................... 91
Focus assist ................................................................................................... 92
MF Assist ....................................................................................................................... 92
Focus Peaking ............................................................................................................. 93
DMF (Direct Manual Focus) .................................................................................. 93
Setting DMF responsiveness ................................................................................... 93
Optical Image Stabilization (OIS) ............................................................. 94
Drive (shooting method) ........................................................................... 95
Single ............................................................................................................................. 96
Continuous .................................................................................................................. 96
Burst ............................................................................................................................... 97
Timer .............................................................................................................................. 97
Auto Exposure Bracketing (AE Bracket) ............................................................. 98
White Balance Bracketing (WB Bracket) ............................................................ 98
Picture Wizard Bracketing (P Wiz Bracket) ........................................................ 99
Depth Bracketing ..................................................................................................... 99
Bracket Settings ......................................................................................................... 99
Interval Capture ......................................................................................... 100
Flash ............................................................................................................. 101
Reducing the red-eye eect ............................................................................... 102
Using the built-in ash ......................................................................................... 102
Adjusting the ash intensity .............................................................................. 103
Flash settings ........................................................................................................... 104
Setting external ash ............................................................................................... 104
Setting wireless sync for internal or external ash ........................................ 105
Metering ...................................................................................................... 106
Multi ............................................................................................................................ 106
Center-weighted .................................................................................................... 107
Spot ............................................................................................................................. 107
Measuring the exposure value of the focus area ......................................... 108
Dynamic Range ......................................................................................... 109
Smart Filter ................................................................................................. 110
Exposure compensation .......................................................................... 111
Viewing the overexposure guide ......................................................................... 111
Exposure/Focus lock ................................................................................. 112
Exposure/Focus separation ..................................................................... 113
Video functions ......................................................................................... 114
Movie size.................................................................................................................. 114
Movie quality ........................................................................................................... 114
Multi Motion ............................................................................................................ 115
DIS (Anti-Shake) ...................................................................................................... 115
Fader ........................................................................................................................... 116
Voice ............................................................................................................................ 116
Wind Cut .................................................................................................................... 116
Mic Level .................................................................................................................... 117
10
Contents
Chapter 3
Playback/Editing
Searching and managing les ................................................................ 119
Viewing photos ....................................................................................................... 119
Viewing image thumbnails ................................................................................. 119
Viewing les by category .................................................................................... 120
Viewing les as a folder ........................................................................................ 121
Protecting les ........................................................................................................ 122
Lock/Unlock all les .................................................................................................. 122
Deleting les ............................................................................................................ 123
Deleting a single le ................................................................................................. 123
Deleting multiple les .............................................................................................. 123
Deleting all les .......................................................................................................... 123
Viewing photos .......................................................................................... 124
Enlarging a photo .................................................................................................. 124
Viewing a slide show ............................................................................................. 124
Viewing the overexposure guide ..................................................................... 125
Viewing interval shots .......................................................................................... 125
Auto rotating ........................................................................................................... 125
Playing videos ............................................................................................ 126
Scanning backward or forward ......................................................................... 126
Adjusting the brightness of a video ................................................................ 127
Adjusting the volume of a video ...................................................................... 127
Trimming a video during playback .................................................................. 128
Capturing an image during playback ............................................................. 128
Editing photos ........................................................................................... 129
Cropping a photo ................................................................................................... 129
Rotating a photo .................................................................................................... 130
Resizing photos....................................................................................................... 130
Adjusting your photos .......................................................................................... 131
Retouching faces .................................................................................................... 132
Applying Smart Filter eects .............................................................................. 133
Chapter 4
Wireless network
Connecting to a WLAN and conguring network settings ............... 135
Connecting to a WLAN ......................................................................................... 135
Setting network options ......................................................................................... 136
Manually setting the IP address ........................................................................... 136
Using the login browser....................................................................................... 137
Network connection tips ..................................................................................... 138
Entering text ............................................................................................................ 139
Using the NFC Feature (Tag & Go) ......................................................... 140
Using NFC features in Shooting mode ........................................................... 140
Using NFC features in Playback mode (Photo Beam)................................ 140
Using NFC features in Wi-Fi mode .................................................................... 140
11
Contents
Chapter 5
Camera settings menu
User settings ............................................................................................... 163
Manage Custom Mode ......................................................................................... 163
ISO Customizing ..................................................................................................... 163
ISO Step ......................................................................................................................... 163
Auto ISO Range .......................................................................................................... 163
Noise Reduction ..................................................................................................... 163
Bracket Settings ...................................................................................................... 164
DMF (Direct Manual Focus) ................................................................................ 164
DMF Responsiveness ............................................................................................ 164
Color Space ............................................................................................................... 165
Distortion Correct .................................................................................................. 166
Touch Operation ..................................................................................................... 166
iFn Setting ................................................................................................................. 166
User Display .............................................................................................................. 167
Key Mapping ............................................................................................................ 168
Live view NFC........................................................................................................... 169
MobileLink/NFC Image Size ............................................................................... 169
Display Select .......................................................................................................... 169
Grid Line .................................................................................................................... 169
AF Lamp ..................................................................................................................... 170
E-Shutter .................................................................................................................... 170
Lens Button Speed Settings ............................................................................... 170
Setting ......................................................................................................... 171
Saving les to a smart phone automatically ....................................... 141
Sending photos or videos to a smart phone ....................................... 143
Sending photos or videos to multiple smart phones ........................ 145
Using a smart phone as a remote shutter release .............................. 147
Using the Baby Monitor ........................................................................... 149
Adjusting the noise level for alarm activation ............................................. 150
Using Auto Backup to send photos or videos ..................................... 151
Installing the program for Auto Backup on your PC.................................. 151
Sending photos or videos to a PC .................................................................... 151
Sending photos or videos via email ...................................................... 153
Changing email settings ...................................................................................... 153
Storing your information ........................................................................................ 153
Setting an email password ..................................................................................... 154
Changing the email password .............................................................................. 155
Sending photos or videos via email ................................................................ 155
Using photo or video sharing services ................................................. 157
Accessing a sharing service ................................................................................ 157
Uploading photos or videos............................................................................... 158
Using Samsung Link to send les .......................................................... 159
Uploading photos to an online storage or registered devices .............. 159
Viewing photos or videos on devices that support Samsung Link ...... 160
12
Contents
Cleaning the camera ............................................................................................. 186
Camera lens and display ......................................................................................... 186
Image sensor ............................................................................................................... 186
Camera body ............................................................................................................... 186
Using or storing the camera ............................................................................... 187
Inappropriate places to use or store the camera ........................................... 187
Using on beaches or shores ................................................................................... 187
Storing for extended period of time ................................................................... 187
Using the camera with caution in humid environments ............................ 188
Other cautions ............................................................................................................ 188
About memory card .............................................................................................. 189
Supported memory card ........................................................................................ 189
Memory card capacity ............................................................................................. 190
Cautions when using memory cards .................................................................. 192
About the battery .................................................................................................. 193
Battery specications ............................................................................................... 193
Battery life .................................................................................................................... 194
Low battery message ............................................................................................... 194
Notes about using the battery .............................................................................. 194
Cautions about using the battery ........................................................................ 195
Notes about charging the battery ....................................................................... 195
Notes about charging with a computer connected...................................... 196
Handle and dispose of batteries and chargers with care ............................ 196
Updating the rmware ............................................................................. 197
Before contacting a service center ........................................................ 198
Camera specications .............................................................................. 201
Glossary ....................................................................................................... 206
Optional accessories ................................................................................. 212
Index ............................................................................................................ 213
FCC notice ................................................................................................... 216
Chapter 6
Connecting to external devices
Viewing les on an HDTV or 3D TV ........................................................ 176
Viewing les on an HDTV .................................................................................... 176
Viewing les on a 3D TV ....................................................................................... 177
Transferring les to your computer ....................................................... 178
Transferring les to your Windows OS computer ....................................... 178
Connecting the camera as a removable disk ................................................... 178
Disconnecting the camera (for Windows XP) .................................................. 179
Transferring les to your Mac OS ...................................................................... 179
Using programs on a PC........................................................................... 181
Installing programs from the provided CD ................................................... 181
Available programs when using i-Launcher .................................................... 181
Using i-Launcher .................................................................................................... 182
Requirements for Windows OS ............................................................................. 182
Requirements for Mac OS ....................................................................................... 182
Opening i-Launcher .................................................................................................. 182
Downloading the rmware .................................................................................... 183
Downloading the PC Auto Backup program ................................................... 183
Installing Adobe Photoshop Lightroom ........................................................ 183
Using Adobe Photoshop Lightroom ............................................................... 183
Chapter 7
Appendix
Error messages .......................................................................................... 185
Maintaining the camera........................................................................... 186
13
Concepts in Photography
Standing photography
Compose your shot, stand up straight with your feet shoulder-length
apart, and keep your elbows pointed down.
Shooting postures
A correct posture for stabilizing the camera is necessary for taking a good
photo. Even if you hold a camera correctly, the wrong posture can cause
the camera to shake. Stand up straight and remain still to maintain a
steady base for your camera. When shooting with a slow shutter speed,
hold your breath to minimize body movement.
Holding the camera
Hold the camera with your right hand and place your right index nger on
the shutter button. Place your left hand under the lens for support.
14
Concepts in Photography
Crouching photography
Compose your shot, crouch with one knee touching the ground, and keep
a straight posture.
Using the display
Swing the display outwards 180° and rotate it up or down for high-and
low-angle photos or self portraits (
). You can rotate the display a
maximum of 90° downward or 180° upward (
). You can also rotate the
display 180° upward and fold it (
).
•
Keep the display closed when the camera is not in use.
•
Tilt the display only within the angle allowed. Failing to do so may damage
your camera.
•
Use the Wi-Fi functions when the display is set as shown in illustrations
and
.
15
Concepts in Photography
Low-angle shot
A low-angle shot is a shot from a camera positioned below your eyeline,
looking up the subject.
High-angle shot
A high-angle shot is a shot from a camera positioned above your eyeline,
looking down on the subject.
16
Concepts in Photography
Aperture
The aperture is one of the three factors that determine the exposure. The
aperture housing contains thin, metal plates that open and close to let
light through the aperture and into the camera. The size of the aperture
is related to the amount of light: a larger aperture allows more light and a
smaller aperture allows less light.
Aperture sizes
Minimum aperture Medium aperture Maximum aperture
Aperture opened slightly Aperture opened wide
The size of the aperture is represented by a value known as an "F-number."
The f-number represents the focal length divided by the diameter of the
lens. For example, if a lens with a 50 mm focal length has an f-number of
F2, the diameter of the aperture is 25 mm. (50 mm/25 mm = F2)
The smaller the f-number, the greater the size of the aperture.
The opening in the aperture is described as the Exposure Value (EV).
Increasing the Exposure Value (+1 EV) means the amount of light doubles.
Decreasing the Exposure Value (-1 EV) means the amount of light halves.
You can also use the exposure compensation feature to ne-tune the
amount of light by subdividing exposure values into 1/2, 1/3 EV, and so on.
+1 EV
F1.4 F2 F2.8 F4 F5.6 F8
-1 EV
Exposure Value Steps
17
Concepts in Photography
Aperture value and the depth of eld
You can blur or sharpen the background of a photo by controlling the
aperture. It is closely related to the depth of eld (DOF), which can be
expressed as small or large.
A photo with a large DOF A photo with a small DOF
The aperture housing contains several blades. These blades move together and
control the amount of light passing through the center of the aperture. The
number of blades also aects the shape of light when shooting night scenes. If
an aperture has an even number of blades, light divides into an equal number
of sections. If the number of blades is odd, the number of sections is double the
number of blades.
For example, an aperture with 8 blades divides light into 8 sections and an
aperture with 7 blades into 14 sections.
7 blades 8 blades
18
Concepts in Photography
Shutter speed
Shutter speed refers to the amount of time it takes to open and close the
shutter. It controls the amount of light which passes through the aperture
before it reaches the image sensor.
Usually, the shutter speed is manually adjustable. The measurement of the
shutter speed is known as the "Exposure Value" (EV), which is marked in
intervals of 1 s, 1/2 s, 1/4 s, 1/8 s, 1/15 s, 1/1,000 s, 1/2,000 s, and so on.
Exposure
+1 EV
-1 EV
1 s 1/2 s 1/4 s 1/8 s 1/15 s 1/30 s
Shutter Speed
Therefore, the faster the shutter speed, the less light will be let in. Likewise,
the slower the shutter speed, the more light will be let in.
The photos below illustrate that a slow shutter speed allows more time
for light to enter the camera. This adds a motion blurring eect to moving
objects. On the other hand, a fast shutter speed allows less time to let light
in and the photo more easily freezes subjects in motion.
0.8 s 0.004 s
19
Concepts in Photography
ISO sensitivity
The exposure of an image is determined by the sensitivity of the camera.
This sensitivity is based on international lm standards, known as ISO
standards. On digital cameras, this sensitivity rating is used to represent
the sensitivity of the digital mechanism that captures the image.
ISO sensitivity doubles as the number doubles. For example, an
ISO 200 setting is capable of capturing images at twice the speed of an
ISO 100 setting. However, higher ISO settings can result in "noise"—small
specks, spots, and other phenomena in a photo that give the shot a noisy
or dirty appearance. As a general rule, it is best to use a low ISO setting
to prevent noise in your photos, unless you are shooting in darkened
environments or at night.
Changes in the quality and brightness according to ISO sensitivity
Because a low ISO sensitivity means the camera will be less sensitive to
light, you need more light to have an optimal exposure. When using a low
ISO sensitivity, open the aperture more or reduce the shutter speed to
allow more light to enter the camera. For example, on a sunny day when
light is abundant, a low ISO sensitivity does not require a slow shutter
speed. However, in a dark place or at night, a low ISO sensitivity will
result in a blurry photo. Therefore, it is recommended to increase the ISO
sensitivity by a moderate amount.
A photo captured with a tripod and high
ISO sensitivity
A blurred photo with a low ISO sensitivity
20
Concepts in Photography
How the aperture setting, shutter speed,
and ISO sensitivity control exposure
The aperture setting, shutter speed, and ISO sensitivity are closely
interconnected in photography. The aperture setting controls the opening
that regulates the light that enters the camera, while the shutter speed
determines the length of time that light is allowed to enter. ISO sensitivity
determines the speed at which the lm reacts to light. Together, these
three aspects are described as the triangle of exposure.
A change in shutter speed, aperture value, or ISO sensitivity can be oset
by adjustments to the others to maintain the amount of light. The results,
however, change according to the settings. For example, shutter speed is
useful in expressing movement, aperture can control the depth of eld,
and ISO sensitivity can control the graininess of a photo.
Settings Results
Aperture
value
Wide aperture
= more light
Narrow aperture
= less light
Wide = small depth of eld
Narrow = large depth of eld
Settings Results
Shutter speed
Fast speed
= less light
Slow speed
= more light
Fast = still
Slow = blurry
ISO sensitivity
High sensitivity
= more sensitive to light
Low sensitivity
= less sensitive to light
High = more grainy
Low = less grainy
21
Concepts in Photography
Correlation between focal length, angle,
and perspective
Focal length, which is measured in millimeters, is the distance between
the middle of the lens to its focal point. It aects the angle and perspective
of captured images. A short focal length translates into a wide angle,
which allows you to capture a wide shot. A long focal length translates
into a narrow angle, which allows you to capture telephoto shots.
Short focal length
wide shot
wide angle
wide-angle lens
Long focal length
telephoto shot
narrow angle
telephoto lens
Look at these photos below and compare the changes.
18 mm angle 55 mm angle 200 mm angle
Normally, a lens with a wide angle is suitable for shooting landscapes and a lens
with a narrow angle is recommended for shooting sports events or portraits.
22
Concepts in Photography
Depth of eld
Portraits or still-life photos mostly acclaimed by people are the ones on
which the background is out of focus so the subject looks pronounced.
Depending on the focused areas, a photo can be blurred or sharpened.
This is called 'a low DOF' or 'a high DOF'.
The depth of eld is the focused area around the subject. Therefore, a
small DOF signies that the focused area is narrow and a large DOF means
the focused area is wide.
A photo with a small DOF, which stresses the subject and makes the rest
of it blurred, can be obtained by using a telescope lens or selecting a low
aperture value. Conversely, a photo with a large DOF which shows all the
elements on the photo sharply focused can be achieved by using a wide
angle lens or selecting a high aperture value.
Small Depth of Field Large Depth of Field
What controls out-of-focus eects?
DOF depends on aperture value
The wider the aperture is (namely the lower the aperture value), the lower
the DOF becomes. Under the condition where the focal length is equal, a
low aperture value leads to a photo with a low DOF.
55 mm F5.7 55 mm F22
23
Concepts in Photography
DOF depends on focal length
The longer the focal length is, the lower the DOF gets. A telescope lens
with a longer focal length than a wide-angle lens with a short focal length
is better to capture a photo of a low DOF.
A photo captured with an 18 mm wide-angle lens
A photo captured with a 100 mm telescope lens
DOF depends on the distance between the subject and the
camera
The shorter the distance between the subject and the camera is, the lower
the DOF gets. Therefore, taking a photo close to a subject can result in a
photo of low DOF.
A photo captured with a 100 mm telescope lens
A photo captured close to the subject
24
Concepts in Photography
DOF preview
You can press [Depth preview] to get an idea of what your shot will look
like before shooting. The camera adjusts the aperture to the predened
settings and shows the results on the screen. Set the function of the Depth
preview button to Optical Preview. (p. 168)
Composition
It is fun to capture a photo of the beauty of world with a camera. No
matter how the world is beautiful, however, a poor composition cannot
capture the beauty of it.
When it comes to composition, it is very important to prioritize subjects.
Composition in photography means arranging objects in a photo. Usually,
abiding by the rule of thirds leads to a good composition.
Rule of Thirds
To use the rule of thirds, divide the image into a 3x3 pattern of equal
rectangles.
To compose photos that best emphasize the subject, make sure the
subject is located at one of the corners of the center rectangle.
25
Concepts in Photography
Using the rule of thirds will create photos with stable and compelling
compositions. Below are a few examples.
Photos with two subjects
If your subject is in one corner of the photo, it creates an unbalanced
composition. You can stabilize the photo by capturing a second subject in
the opposite corner to balance the weight of the photo.
Subject 1
Subject 2
Subject 1
Subject 2
Unstable Stable
When taking landscape photos, centering the horizon will create an
unbalanced eect. Give more weight to the photo by moving the horizon
up or down.
Subject 1
Subject 2
Subject 1
Subject 2
Unstable Stable
26
Concepts in Photography
Flash guide number
The model number of a ash refers to the ash’s power, and the maximum
amount of light created is represented by a value known as a "guide
number." The bigger the guide number, the more light is emitted from the
ash. The guide number is achieved by multiplying the distance from the
ash to the subject and the aperture value when the ISO sensitivity is set
to 100.
Guide number = Flash to Subject Distance X Aperture value
Aperture value = Guide number/Flash to Subject Distance
Flash to Subject Distance = Guide number/Aperture value
Therefore, if you know the guide number of a ash, you can estimate an
optimum ash to subject distance when setting the ash manually. For
example, if a ash has a guide number of GN 20 and is 4 meters away from
the subject, the optimal aperture value is F5.0.
Flash
Light is one of the most important components in photography. It is not
easy, however, to have an enough amount of light anytime and anywhere.
Making use of a ash allows you to optimize light settings and create a
variety of eects.
Flash, also known as strobe or speed light, helps to create adequate
exposure in low-light conditions. It is also useful in light-abundant
situations. For example, ash can be used in compensating the exposure
of a subject’s shadow or capturing clearly both the subject and the
background in backlit conditions.
Before correction After correction
27
Concepts in Photography
Bounce Photography
Bounce photography refers to the method of bouncing light o of the
ceiling or walls so that the light spreads evenly over the subject. Normally,
photos captured with ash may appear unnatural and cast shadows.
Subjects in photos captured with bounce photography cast no shadows
and look smooth due to evenly spread light.
Chapter 1
My Camera
Learn about your camera’s layout, display icons, lens, optional accessories,
and basic functions.
My Camera
29
Getting started
Unpacking
Check your product box for the following items.
Camera
(including the body cap and
hot-shoe cover)
AC adapter/USB cable Rechargeable battery Strap
Software CD-ROM
(User manual included)
Adobe Photoshop Lightroom DVD-ROM Quick Start Guide Quick Reference Guide
The illustrations may dier from your actual items.
You can purchase optional accessories at a retailer or a Samsung service center. Samsung is not responsible for any
problems caused by using unauthorized accessories. For information about accessories, refer to page 212.
My Camera
30
Camera layout
No. Name
1
Command dial
• In the Menu screen: Move to a desired
menu item.
• In the Smart panel: Adjust a selected
option.
• In Shooting mode: Adjust shutter
speed or aperture value in some
shooting modes or change the size of
a focus area.
• In Playback mode: View thumbnails
or enlarge or reduce a photo. Open
or close a folder of continuous or
burst shots in Playback mode. Scan
backward or forward a video.
2
Mode dial
• t: Smart Auto mode (p. 55)
• P: Program mode (p. 57)
• A: Aperture Priority mode (p. 59)
• S: Shutter Priority mode (p. 60)
• M: Manual mode (p. 61)
• T: Custom mode 1 (p. 63)
• U: Custom mode 2 (p. 63)
• i: Lens Priority mode (p. 64)
• s: Smart mode (p. 66)
• B: Wireless Network (p. 134)
3
Hot-shoe cover
No. Name
4
Hot-shoe
5
Built-in ash (p. 102)
6
Flash pop-up button (p. 102)
7
Microphone
8
Lens release button
9
Image sensor
10
Lens mount
11
Depth preview button (p. 24)
12
Lens mount index
13
AF-assist light/Timer lamp
14
Power switch
15
Shutter button
16
Metering button (p. 106)
17
DIRECT LINK button: Start a preset Wi-Fi
function. (p. 33)
1
3
2
4
5
6
7
8
10
9
11
12
13
17
16
15
14
My Camera > Camera layout
31
No. Name
1
Drive dial
• H: Single (p. 96)
• J: Continuous (p. 96)
• K: Timer (p. 97)
• L: Bracketing (p. 98)
2
Video recording button
Start recording a video.
3
EV adjust button (p. 111)
Press and hold the button, and then scroll
the command dial to adjust the exposure
value.
4
AEL button (p. 112)
• In Shooting mode: Lock the adjusted
exposure value or focus.
• In Playback mode: Protect the selected
le.
5
Fn button
Access the Smart panel and ne-tune
some settings.
6
o button
• In the Menu screen: Save the selected
options.
• In Shooting mode: Allow you to select
a focus area manually in some shooting
modes.
7
Delete/Custom button
• In Shooting mode: Perform the
assigned function. (p. 168)
• In Playback mode: Delete les.
No. Name
8
Navigation button (Smart dial)
• In Shooting mode
- D: Change the information on the
display.
- I: Select an ISO value.
- C: Select a White Balance option.
- F: Select an AF mode.
• In other situations
Move up, down, left, right, respectively.
(You can also rotate the navigation
button.)
9
Playback button
Enter Playback mode to view pictures or
videos.
10
Status lamp
Indicate the status of the camera.
• Blinking: When saving a photo,
shooting a video, sending data to a
computer, connecting to WLAN, or
sending a photo.
• Steady: When there is no data transfer,
when data transfer to a computer is
complete, or charging the battery.
11
MENU button
Access options or menus.
12
Proximity sensor (p. 169)
13
Viewnder (p. 33)
14
Eye-cup
6
7
9
2
1
3
4
5
8
10
11
12
13
14
My Camera > Camera layout
32
No. Name
1
Diopter adjustment dial (p. 33)
2
Eyelet for camera strap
3
External microphone port
Insert a 3.5 mm stereo microphone.
4
Speaker
5
NFC tag
6
HDMI port
7
USB and shutter release port
Connect the camera to a computer or shutter release. Use a shutter release cable with a tripod
to minimize camera movement.
8
Battery chamber/Memory card cover
Insert a memory card and battery.
9
Display (touch screen)
• To take photos at high or low angles, tilt the display up or down. (p. 14)
• Touch the screen to select a menu or an option. (p. 38)
10
Internal antenna
* Avoid contact with the internal antenna while using a wireless network.
11
Tripod mount
4
1
5
3
2
9
11
6
7
8
10
My Camera > Camera layout
33
Adjusting the viewnder angle and the diopter
Adjust the angle of the viewnder to take photos conveniently. Pull out the viewnder gently ( )
and tilt it to adjust the angle (
).
The diopter adjustment dial is accessible when you pull out the viewnder. If the image is not
clear through the viewnder, rotate the diopter adjustment dial to improve the image.
Do not adjust the viewnder angle or rotate the diopter adjustment dial beyond the permitted limits. Doing
so may damage the viewnder or the diopter adjustment dial.
Using the DIRECT LINK button
You can turn on the Wi-Fi feature conveniently by pressing [DIRECT LINK].
Press [DIRECT LINK] again to return to the previous mode.
Setting the DIRECT LINK button
You can select a Wi-Fi function to launch when you press [DIRECT LINK]. (p. 168)
To set a DIRECT
LINK option,
In Shooting mode, press [m]
ĺ
d
ĺ
Key Mapping
ĺ
DIRECT LINK
ĺ
an option.
My Camera
34
Inserting the battery and memory card
Learn how to insert the battery and an optional memory card into the
camera.
Memory card
Insert a memory card with the gold-
colored contacts facing down.
Rechargeable battery
Insert the battery with the Samsung logo
facing up.
Removing the battery and memory card
Rechargeable battery
Battery lock
Slide the lock down to release the battery.
Memory card
Push the card gently until it disengages
from the camera, and then pull it out of
the slot.
Using the memory card adapter
To use micro memory cards with this product, a PC, or a memory
card reader, insert the card into an adapter.
While the status lamp of the camera is blinking, do not remove the memory card
or battery. Doing so may damage the data stored on the memory card or your
camera.
My Camera
35
Charging the battery and turning on your camera
Charging the battery
Before you use the camera for the rst time, you must charge the battery.
Plug the small end of the USB cable into your camera, and then plug the
other end of the USB cable into the AC adapter.
Status lamp
• Red light on: Charging
• Green light on: Fully charged
• Red light blinking: Charging Error
Use only the AC adapter and USB cable supplied with your camera. If you use
another AC adapter, the camera battery may not charge or work properly.
Turning on your camera
Set the Power switch to ON.
•
To turn your camera o, set the Power switch to OFF.
•
The initial setup screen appears when you turn on the camera for the
rst time. (p. 36)
My Camera
36
Performing the initial setup
When you turn on your camera for the rst time, the initial setup screen
appears. The language is preset for the country or region where the
camera is sold. You can change the language as desired. You can also select
an item by touching it on the screen.
1
Press [I] to select Time Zone, and then press [o].
2
Press [D/I] to select a time zone, and then press [o].
Back
Time Zone
[GMT +00:00] London
[GMT -01:00] Cape Verde
[GMT -02:00] Mid-Atlantic
[GMT -03:00] Buenos Aires, Sao Paulo
[GMT -03:30] Newfoundland
3
Press [I] to select Date Settings, and then press [o].
4
Press [C/F] to select an item (Year/Month/Day).
5
Press [D/I] to set the option, and then press [o].
Back
Year
Month
Day
Date Settings
•
The screen may dier depending on the language you selected.
6
Press [I] to select Time Settings, and then press [o].
7
Press [C/F] to select an item (Hr/Min/DST).
8
Press [D/I] to set the option, and then press [o].
Time Settings
Back
DSTHr Min
My Camera > Performing the initial setup
37
9
Press [I] to select Date Type, and then press [o].
10
Press [D/I] to select a date type, and then press [o].
Back
Language
Time Zone
Date Settingss
Time Settingss
Date Type
Date Type
YYYY/MM/DD
MM/DD/YYYY
DD/MM/YYYY
London
English
11
Press [I] to select Time Type, and then press [o].
12
Press [D/I] to select a time type, and then press [o].
Back
London
2014/01/01
10:00 AM
Time Zone
Date Settings
Time Settings
Date Type
Time Type
Time Type
12H
24H
13
Press [m] to nish the initial setup.
My Camera
38
Selecting functions (options)
Selecting with buttons
Scroll the command dial or rotate the navigation button or press
[D/I/C/F] to move, and then press [o] to select an option.
Selecting by touch
Do not use sharp objects, such as pens or pencils, to touch the screen. You can
damage the screen.
Dragging: Touch and hold an area on
the screen, and then drag your nger.
Touching: Touch an icon to select a
menu or an option.
Flicking: Gently ick your nger
across the screen.
My Camera > Selecting functions (options)
39
•
When you touch or drag the screen, discolorations may occur. This is not a
malfunction, but a characteristic of the touch screen. Touch or drag lightly to
minimize the discolorations.
•
The touch screen may not work properly if you use the camera in extremely
humid environments.
•
The touch screen may not work properly if you apply screen protection lm
or other accessories to the screen.
•
Depending on the viewing angle, the screen may appear dim. Adjust the
brightness or viewing angle to improve the resolution.
Using m
Press [m] or touch on the screen, and then change shooting
options or settings.
E.g. Selecting the photo size in P mode
1
Rotate the mode dial to P.
2
Press [m] or touch .
3
Scroll the command dial or press [D/I] to move to b,
and then press [o].
•
You can also touch b on the screen.
4
Rotate the navigation button or press [D/I] to move to
Photo Size, and then press [o].
•
You can also drag the option list, and then touch an option.
SelectBack
AutoShare
Photo Size
Quality
ISO
OLED Color
O
My Camera > Selecting functions (options)
40
5
Rotate the navigation button or press [D/I] to move to
an option, and then press [o].
•
You can also drag the option list, and then touch an option.
•
Press [m] or touch Back to go back to the previous menu.
Select
AutoShare
Photo Size
Quality
ISO
OLED Color
(3:2) (5472x3648)
(3:2) (3888x2592)
(3:2) (2976x1984)
(3:2) (1728x1152)
(16:9) (5472x3080)
Photo Size
Back
6
Press [m] or touch Back to switch to Shooting mode.
Using the Smart panel
Press [f] or touch on the screen to access some functions such as
Exposure, ISO, and White Balance.
E.g. Adjust the exposure value in P mode
1
Rotate the mode dial to P.
2
Press [f] or touch .
My Camera > Selecting functions (options)
41
3
Rotate the navigation button or press [D/I/C/F]
to move to EV, and then press [o].
•
You can directly select an option by scrolling the command dial
without having to press [o].
•
You can also select an option by touching it.
EV : 0.0
Adjust
Back
You can adjust some options by
dragging them.
4
Scroll the command dial or rotate the navigation button or
press [C/F] to adjust the exposure value, and then press
[o].
•
You can also drag the dial on the screen, and then touch Set to
adjust the option.
EV : 0.0
Back Set
Using iFn
Press [i-Function] on an i-Function lens to manually select and adjust
shutter speed, aperture value, exposure value, ISO sensitivity, and White
Balance on the lens.
Select an option.
Adjust an option value.
My Camera > Selecting functions (options)
42
Using the iFn standard function
When you use [i-Function] on an i-Function lens, you can manually select
and adjust shutter speed, aperture value, exposure value, ISO sensitivity,
and White Balance on the lens. You can also use the Z function.
1
Rotate the mode dial to P, A, S, or M.
2
Press [m]
ĺ
d
ĺ
iFn Setting
ĺ
Mode
ĺ
iFn Standard.
3
Press [m] to return to Shooting mode.
4
Press [i-Function] on the lens to select a setting.
•
To select items to appear, select [m]
ĺ
d
ĺ
iFn Setting
ĺ
iFn Standard
ĺ
an item.
•
You can also press [i-Function], and then press [D/I] or drag
the screen to select a setting.
Option Description
Aperture value
Adjust the aperture value.
Shutter speed
Adjust the shutter speed.
EV
Adjust the exposure value.
ISO
Adjust the ISO sensitivity.
White Balance
Select a White Balance option.
Z
Zoom in on a subject with less degradation of
photo quality than the Digital zoom. However, the
photo resolution or size may change compared to
when you zoom in by rotating the zoom ring.
My Camera > Selecting functions (options)
43
5
Adjust the focus ring to select an option.
•
You can also scroll the command dial or rotate the navigation
button or drag the screen to select an option.
6
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
Available options
Shooting mode PASM3D
Aperture
-O-O-
Shutter speed
--OO-
EV
OOO-O
ISO
OOOO -
White Balance
OOOOO
Z
OOOO -
•
This function is not available when you attach a 3D lens and set 3D Auto
Mode in 3D mode.
•
Z is not available when you set the shooting method to Burst.
•
Z is not available when you capture photos in the RAW le format.
•
Z is deactivated when you record videos by pressing the video
recording button.
My Camera > Selecting functions (options)
44
Using the iFn plus function
On an i-Function lens, press [i-Function], and then press [N], [W],
or [a] on the camera. You can start assigned functions or open the
settings menu with i-Function.
E.g. Assigning the photo quality function to the Metering
button
1
Rotate the mode dial to P, A, S, or M.
2
Press [m]
ĺ
d
ĺ
iFn Setting
ĺ
iFn Plus
ĺ
Metering
ĺ
Quality.
3
Press [m].
4
Select iFn Setting
ĺ
Mode
ĺ
iFn Plus.
5
Press [m] to return to Shooting mode.
6
Press [i-Function] on an i-Function lens, and then press [N]
on the camera.
7
Select a photo quality option.
8
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
My Camera
45
Display icons
Capturing photos
1
2
3
1. Shooting information
Icon Description
Shooting mode
Current date
Current time
Focal length*
Notication panel bar
Memory card not inserted**
Auto exposure lock (p. 112)
Auto focus lock (p. 112)
Available number of photos
100%
Battery percentage
Auto focus frame
Spot metering area
Icon Description
: Fully charged
: Partially charged
(Red): Empty (recharge
the battery)
: Charging
Camera shake
Manual focus scale
Level gauge (p. 46)
Histogram (p. 167)
Focus
Shutter speed
Aperture value
Exposure adjustment value
ISO sensitivity (p. 79)
* This icon appears when you attach the Power Zoom lens.
** Photos that were captured without inserting a memory
card cannot be transferred to a memory card or a computer.
2. Shooting options
Icon Description
Photo size
Drive mode
Flash (p. 101)
Flash intensity adjustment
Metering (p. 106)
AF mode (p. 84)
Icon Description
Focus area
Face detection
White Balance (p. 81)
White Balance micro adjustment
Optical Image Stabilization (OIS) (p. 94)
Z on
Z ratio
RAW le
Dynamic Range (p. 109)
OLED Color (p. 80)
3. Shooting options (Touch)
Icon Description
Change Smart mode**
Save a custom mode***
Mobile Connection****
Touch AF options
Shooting options
Smart panel
** This icon appears only when you select Smart mode.
*** This icon appears when you select Custom1 or Custom2
mode.
**** You can directly select a Wi-Fi function that connects to a
smart phone.
The icons displayed will change according to
the mode you select or the options you set.
In Shooting mode
My Camera > Display icons
46
Icon Description
Video sound level
2. Shooting options
Icon Description
Video size
AF mode (p. 84)
Metering (p. 106)
White Balance (p. 81)
White Balance micro adjustment
Optical Image Stabilization (OIS) (p. 94)
Digital Image Stabilization (DIS) (p. 115)
Fader (p. 116)
Multi Motion (p. 115)
Voice recording o (p. 116)
Internal microphone in use
Zoom button*
OLED Color (p. 80)
* This icon appears when you attach the Power Zoom lens.
The icons displayed will change according to the
mode you select or the options you set.
About the level gauge
The level gauge helps you align the camera with
the horizontal and vertical lines on the display.
If the level gauge is not level, calibrate the level
gauge using the Horizontal Calibration function.
(p. 171)
Vertical
Horizontal
S Level S Unlevel
You cannot use the level gauge when you shoot
in portrait orientation.
Recording videos
1
2
1. Shooting information
Icon Description
Shooting mode
Cancel Touch AF.
Current recording time/
Available recording time
100%
Battery percentage
• : Fully charged
• : Partially charged
• (Red): Empty (recharge
the battery)
• : Charging
Zoom indicator*
Exposure value
ISO sensitivity (p. 79)
My Camera > Display icons
47
In Playback mode
Viewing photos
Information
Mode
F No
Shutter
ISO
Metering
Flash
Focal Length
White Balance
EV
Photo Size
Folder No.-File No.
Date & Time
Icon Description
View image thumbnails. (Touch)
Current le/The total number of les
Notication panel bar
Share a le. (Touch)
m
Playback/Editing menu (Touch)
RAW le
3D le
Protected le
1
2
3
No. Description
1
Captured photo
2
RGB histogram (p. 167)
3
Shooting mode, Metering, Flash,
White Balance, Aperture value, Shutter
speed, ISO, Focal length, Exposure value,
Photo size, Folder number-File number,
Date
Playing videos
Stop
Capture
Icon Description
Playback speed
Multi Motion
Current playback time
Video length
/
View previous le/Scan backward.
(Each time you touch the scan
backward icon, you change the scan
speed in this order: 2X, 4X, 8X.)
/
Pause or resume playback.
/
View next le/Scan forward. (Each
time you touch the scan forward
icon, you change the scan speed in
this order: 2X, 4X, 8X.)
Adjust the volume or mute the
sound.
My Camera > Display icons
48
Changing the information displayed
Press [D] repeatedly to change the display type.
Mode Display type
Shooting
• Basic shooting information (Shooting mode, Shutter
speed, Aperture value, Exposure value, ISO sensitivity, etc.)
• Basic shooting information + Shooting option buttons
(MENU, Fn, Mobile Connection, Touch AF) + Level gauge
• Basic shooting information + Shooting option buttons +
Current shooting options information (Photo size, Drive
mode, Flash, Metering, AF mode, etc.)
• Basic shooting information + Shooting option buttons +
Current shooting options information + Histogram + Date
and time
• No information (when connected to an HDTV or an HDMI-
enabled monitor)
Playback
• Basic information
• Display all information about the current le.
• Display all information about the current le including
RGB histogram.
Viewing the notication panel
Touch at the top of the display to open the notication panel. You
can adjust the display brightness or view battery life and data storage
information. If you have changed the camera's default settings for photo
size and quality, exposure value, and ISO sensitivity, you can view the
changed settings. Touch the bottom of the notication panel or press
[m] or [f] to close it.
Auto
Storage
10 shot(s)
Battery Level
Changed Camera Settings
Storage & Battery Level
Display Brightness
My Camera
49
Lenses
You can purchase optional lenses made exclusively for your NX series
camera.
Learn about the functions of each lens and select one that suits your needs
and preferences.
Lens layout
SAMSUNG 18-55 mm F3.5-5.6 OIS III lens (example)
8
1
2
3
5
4
67
No. Description
1
Lens mount index
2
Zoom ring
3
Focus ring (p. 92)
4
Lens hood mount index
5
Lens
6
i-Function button (p. 64)
7
AF/MF switch (p. 84)
8
Lens contacts
When not using the lens, attach the lens cap and lens mount cover to protect
the lens from dust and scratches.
My Camera > Lenses
50
SAMSUNG 20-50 mm F3.5-5.6 ED II lens (example)
7
1
2
3
5
6
4
No. Description
1
Lens mount index
2
Zoom lock switch
3
Lens
4
Focus ring (p. 92)
5
i-Function button (p. 64)
6
Zoom ring
7
Lens contacts
Locking or unlocking the lens
To lock the lens, pull and hold the zoom lock switch away from the camera
body and rotate the zoom ring as shown in the illustration.
My Camera > Lenses
51
To unlock the lens, rotate the zoom ring as shown in the illustration until
you hear the click.
You cannot capture a photo when the lens is locked.
SAMSUNG 16 mm F2.4 lens (example)
5
2
1
4
3
No. Description
1
i-Function button (p. 64)
2
Lens mount index
3
Focus ring (p. 92)
4
Lens
5
Lens contacts
My Camera > Lenses
52
Lens markings
Find out what the numbers on the lens signify.
SAMSUNG 18-200 mm F3.5-6.3 ED OIS lens (example)
1
2345
No. Description
1
Aperture value
A range of supported aperture values. For example, 1:3.5–6.3 means
the maximum aperture value range from 3.5 to 6.3.
2
Focal length
The distance from the middle of the lens to its focal point (in
millimeters). This gure is expressed in a range: minimum focal length
to maximum focal length of the lens.
Longer focal lengths result in narrower angles of view and the subject
is magnied. Shorter focal lengths result in wider angles of view.
3
ED
ED stands for Extra-low Dispersion. Extra-low dispersion glass is
eective in minimizing chromatic aberration (a distortion that occurs
when a lens fails to focus all colors to the same convergence point).
4
OIS (p. 94)
Optical Image Stabilization. Lenses with this feature can detect
camera shake and eectively cancel out the movement inside the
camera.
5
Ø
The lens diameter. When you attach a lter to the lens, make sure that
the diameters of the lens and the lter are the same.
My Camera
53
Accessories
You can use accessories such as external ash that can help you capture
better and more convenient photos.
For more information about optional accessories, refer to the manual for
each accessory.
•
The illustrations may dier from the actual items.
•
You can purchase Samsung-approved accessories at a retailer or a Samsung
service center. Samsung is not responsible for damage caused by using
another manufacturer's accessories.
External ash layout
SEF220A (example) (optional)
2
1
3
4
5
6
7
8
9
No. Description
1
Display icons
2
READY lamp/Test button
3
MODE button
4
Flash release button
5
Power button
6
Battery cover
7
Bulb
8
TELE/WIDE mode switch
9
Hot-shoe connection
My Camera > Accessories
54
Connecting the external ash
1
Remove the hot-shoe cover from the camera.
2
Mount the ash by sliding it into the hot-shoe.
•
To release the ash, gently pull the ash while you press the PUSH
button.
3
Press the power button on the ash.
•
You can capture a photo with a ash that is not fully charged, but it is
recommended to use a fully charged ash.
•
The available options may dier depending on the shooting mode.
•
There is an interval between two bursts of the ash. Do not move until the
ash res a second time.
•
For more details about optional ashes, refer to the user manual for the ash.
Use only Samsung-approved ashes. Using incompatible ashes may damage
your camera.
My Camera
55
Shooting modes
Two simple shooting modes—Smart Auto and Smart mode—help you
capture photos with numerous automatic settings. Additional modes
allow for greater customization of settings.
Icon Description
t
Smart Auto mode (p. 55)
P
Program mode (p. 57)
A
Aperture Priority mode (p. 59)
S
Shutter Priority mode (p. 60)
M
Manual mode (p. 61)
T
Custom mode 1 (p. 63)
U
Custom mode 2 (p. 63)
i
Lens Priority mode (p. 64)
s
Smart mode (p. 66)
B
Wi-Fi features (p. 134)
t Smart Auto mode
In Smart Auto mode, the camera recognizes surrounding conditions
and automatically adjusts factors that contribute to exposure, including
shutter speed, aperture value, metering, White Balance, and exposure
compensation. As the camera controls most of the functions, some
shooting functions are limited. This mode is useful for capturing quick
snapshots with the least amount of adjustment.
My Camera > Shooting modes
56
1
Rotate the mode dial to t.
2
Align your subject in the frame.
3
Half-press [Shutter] to focus.
•
The camera selects a scene. An appropriate scene icon appears at
the screen.
A
Recognizable scenes
Icon Description
Landscapes
Scenes with bright white backgrounds
Landscapes at night
Portraits at night
Icon Description
Landscapes with backlighting
Portraits with backlighting
Portraits
Close-up photos of objects
Close-up photos of text
Sunsets
Indoors, dark
Partially lit
Close-up with spot lighting
Portraits with spot lighting
Blue skies
Forested areas typically consist of green-colored subjects
Close-up photos of colorful subjects
Camera is stabilized on a tripod and the subject is not moving for a
certain period of time. (when shooting in the dark)
Actively moving subjects
Fireworks (when using a tripod)
4
Press [Shutter] to capture the photo.
My Camera > Shooting modes
57
•
The camera may detect dierent scenes, even the same subjects, depending
on external factors such as camera shake, lighting, or distance to the subject.
•
If the camera does not recognize an appropriate scene mode, it uses the
default settings for the Smart Auto mode.
•
Even if it detects a face, the camera may not select a portrait mode
depending on the subject's position or lighting.
•
Even if you use a tripod, the camera may not detect the tripod mode ( ) if
the subject is moving.
•
The camera consumes more battery power, because it changes settings often
to select appropriate scenes.
P Program mode
The camera automatically adjusts shutter speed and aperture value so that
an optimal exposure value can be achieved.
This mode is useful when you want to capture shots of constant exposure
while being able to adjust other settings.
1
Rotate the mode dial to P.
2
Set the desired options.
3
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
My Camera > Shooting modes
58
Program Shift
Program Shift function lets you adjust the shutter speed and aperture
value while the camera maintains the same exposure. When you scroll
the command dial to the left or rotate the navigation button counter-
clockwise, the shutter speed decreases and the aperture value increases.
When you scroll the command dial to the right or rotate the navigation
button clockwise, the shutter speed increases and the aperture value
decreases.
Minimum shutter speed
Set the shutter speed not to be slower than the selected speed. However, if
an optimal exposure value cannot be achieved because the ISO sensitivity
reached the maximum ISO value that is set by Auto ISO Range, shutter
speed may be slower than the selected minimum shutter speed.
To set the minimum
shutter speed,
In Shooting mode, press [m]
ĺ
b
ĺ
Minimum
Shutter Speed
ĺ
an option.
•
This feature is available only when the ISO sensitivity is set to Auto.
•
This feature is available only in Program or Aperture Priority mode.
My Camera > Shooting modes
59
A Aperture Priority mode
In Aperture Priority mode, the camera automatically calculates shutter
speed according to the aperture value you choose.
You can adjust the depth of eld (DOF) by changing the aperture value.
This mode is useful for taking portraits, owers, or landscape shots.
Large Depth of Field Small Depth of Field
1
Rotate the mode dial to A.
2
Scroll the command dial or rotate the navigation button to
adjust the aperture value.
•
You can also adjust the aperture value by pressing [f], moving
to the aperture value, and then scrolling the command dial or
dragging the screen.
3
Set the desired options.
4
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
•
In low-light settings, you may need to increase the ISO sensitivity to prevent
blurred photos.
•
To set the minimum shutter speed, in Shooting mode, press [m]
ĺ
b
ĺ
Minimum Shutter Speed
ĺ
an option.
My Camera > Shooting modes
60
S Shutter Priority mode
In Shutter Priority mode, the camera automatically adjusts the aperture
value according to the shutter speed you choose. This mode is useful for
capturing photos of fast-moving subjects or for creating tracer eects in a
photo.
For example, set the shutter speed to over 1/500 s to freeze the subject. To
make the subject appear blurred set the shutter speed to below 1/30 s.
Slow shutter speed Fast shutter speed
1
Rotate the mode dial to S.
2
Scroll the command dial or rotate the navigation button to
adjust the shutter speed.
•
You can also adjust the shutter speed by pressing [f], moving to
the shutter speed, and then scrolling the command dial or dragging
the screen.
3
Set the desired options.
4
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
In order to compensate for the reduced amount of light allowed by fast shutter
speeds, open the aperture and let in more light. If your photos are still too dark,
increase the ISO value.
My Camera > Shooting modes
61
M Manual mode
Manual mode lets you adjust the shutter speed and aperture value
manually. In this mode, you can fully control the exposure of your photos.
This mode is useful in controlled shooting environments, such as a studio,
or when it is necessary to ne-tune camera settings. The Manual mode is
also recommended for shooting night scenes or reworks.
1
Rotate the mode dial to M.
2
Scroll the command dial to adjust the shutter speed.
3
Rotate the navigation button to adjust the aperture value.
•
You can also adjust the shutter speed or the aperture value by
pressing [f], moving to the shutter speed or the aperture value,
and then scrolling the command dial or dragging the screen.
4
Set the desired options.
5
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
Using Framing Mode
When you adjust the aperture value or shutter speed, the exposure
changes according to the settings, so the display may darken. With this
function on, the brightness of the display is constant regardless of the
settings, so you can better frame your shot.
To use Framing
Mode,
In Shooting mode, press [m]
ĺ
b
ĺ
Framing Mode
ĺ
an option.
My Camera > Shooting modes
62
Using the Bulb function
Use the Bulb function to shoot night scenes or the night sky. While you are
pressing [Shutter], the shutter is left open so you can create moving light
eects.
To use a bulb,
Completely scroll the command dial to the left to Bulb
ĺ
Press
and hold [Shutter] for the desired time.
•
If you set a high ISO value or open the shutter for a long time, image noise
may increase.
•
Drive options, ash, and One touch shot cannot be used with the Bulb
function.
•
The Bulb function is available only in Manual mode.
•
Use a tripod and shutter release to prevent your camera from shaking.
•
The longer you open the shutter, the longer it takes to save a photo. Do not
turn the camera o while the camera saves a photo.
•
If you use this function for a long time, use a fully charged battery.
My Camera > Shooting modes
63
T U Custom mode
Custom mode lets you create your own shooting modes by customizing
options and saving them. Save frequently used option settings and
then open it as your own shooting mode customized for the shooting
environment. Use custom mode when you capture photos in various
environments, you have preferred shooting settings, or you frequently use
preset options in certain conditions.
Saving custom modes
1
Rotate the mode dial to P, A, S, M, T, or U.
2
Set shooting options.
3
Press [m], and then select d
ĺ
Manage Custom Mode
ĺ
Save.
•
You can also save a custom mode by touching on the screen.
•
You can also save a custom mode by pressing [f], and then
touching
.
4
Verify the shooting options, and then select Save.
5
Use the on-screen keyboard to enter a name for the mode.
(p. 139)
6
Press [o] to save a mode.
You can save up to 10 custom modes.
Selecting custom modes
1
Rotate the mode dial to T or U.
2
Scroll to a saved custom mode on a pop-up window, and then
select Ye s .
•
You can also press [m], and then select d
ĺ
Manage Custom
Mode
ĺ
Open
ĺ
a mode.
•
If there is no custom mode saved, you can select a shooting mode
from a pop-up window on the camera, set shooting options, and
save new custom modes.
3
Verify the shooting options, and then select OK.
My Camera > Shooting modes
64
Deleting custom modes
1
Rotate the mode dial to P, A, S, M, T, or U.
2
Press [m], and then select d
ĺ
Manage Custom Mode
ĺ
Delete.
3
Select a mode to delete, and then press [n].
i Lens Priority mode
Lens Priority mode lets you to adjust the depth of eld or contrast of the
photo or use the Z function.
1
Rotate the mode dial to i.
2
Press [i-Function] on the lens to select a setting.
•
You can also press [i-Function], and then press [D/I] or drag
the screen to select a setting.
My Camera > Shooting modes
65
Option Description
E
Adjust the depth of eld to blur or sharpen the
background.
G
Adjust the contrast to increase or decrease the
shading dierences in the photo.
Z
Zoom in on a subject with less degradation of photo
quality than the Digital zoom. However, the photo
resolution or size may change compared to when you
zoom in by rotating the zoom ring.
3
Adjust the focus ring to select an option.
•
You can also scroll the command dial or rotate the navigation
button or drag the screen to select an option.
4
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
•
This function is not available when you attach a 3D lens and set 3D Auto
Mode in 3D mode.
•
As you adjust the E option closer to , the aperture value increases
and the shutter speed reduces. In dark conditions, photos may be blurry.
•
As you adjust the G option closer to +4, the shading dierences in
the photo increase.
•
Z is not available when you set the shooting method to Burst.
•
Z is not available when you capture photos in the RAW le format.
•
Z is deactivated when you record videos by pressing the video
recording button.
My Camera > Shooting modes
66
s Smart mode
In Smart mode, you can capture photos with options that are preset for a
specic scene.
1
Rotate the mode dial to s.
2
Select a scene.
Drag to navigate options.
Switch to the grid view.
Portrait
Switch to the list view.
Option Description
Beauty Face
Capture a portrait with options to hide facial
imperfections.
Best Face
Capture multiple photos and replace faces to create
the best possible image.
Landscape
Capture still-life scenes and landscapes.
Macro
Capture small or close-up subjects.
Action Freeze
Capture subjects moving at high speed.
Rich Tones
Capture a photo with vibrant colors.
Panorama
Capture a wide panoramic scene in a single photo.
Waterfall
Capture scenes with waterfalls.
Multi Exposure
Capture multiple photos and overlap them to create
one photo.
Creative Shot
Capture photos with eects applied automatically.
Smart Jump Shot
Set an area to automatically capture a jumping subject
when movement is detected.
Silhouette
Capture subjects as dark shapes against a light
background.
My Camera > Shooting modes
67
Option Description
Sunset
Capture scenes at sunset, with natural-looking reds
and yellows.
Night
Capture multiple photos in low light conditions
without a ash. The camera combines them to create a
single image that is brighter and has less blurring.
Fireworks
Capture scenes with reworks.
Light Trace
Capture scenes with the light trailing in low-light
conditions.
Some options are not available when you use the viewnder.
3
Half-press [Shutter] to focus, and then press [Shutter] to
capture.
My Camera > Shooting modes
68
Using the Best Face mode
In Best Face mode, you can capture multiple photos and replace faces to
create the best possible image. Use this mode to select the best image for
each individual when capturing group photos.
1
Rotate the mode dial to s, and then select Best Face.
2
Align your subject in the frame, and then half-press [Shutter]
to focus.
3
Press [Shutter] to capture the photo.
•
The camera captures 5 photos consecutively.
•
The rst photo is set as the background image.
•
The camera automatically detects faces after shooting.
4
Touch a face to replace.
Back
Save
5
Touch the best image from the 5 faces that were captured.
•
Repeat steps 4 and 5 to replace the rest of the faces in the photo.
•
The icon will appear on the image that the camera recommends.
•
Touch to hide the captured faces.
6
Press [o] to save the photo.
•
Use a tripod to prevent your camera from shaking.
•
The resolution is set to 5.9M or less.
My Camera > Shooting modes
69
Capturing panoramic photos
Capture a 2D or 3D panoramic photo. Captured 3D panoramic photos can
be viewed only on a 3D TV or 3D monitor.
1
Rotate the mode dial to s, and then select Panorama.
2
Press [m]
ĺ
b
ĺ
Panorama
ĺ
Live Panorama or 3D.
3
Press [m] to return to Shooting mode.
4
Press and hold [Shutter] to start shooting.
5
With [Shutter] pressed, slowly move the camera in the
direction you selected.
•
In 3D Panorama mode, you can capture a scene only in horizontal
directions.
•
An arrow toward the direction of motion is displayed, and the entire
shooting image is displayed in the preview box.
•
When the scenes are aligned, the camera captures the next photo
automatically.
6
When you are nished, release [Shutter].
•
The camera will automatically save the shots into one photo.
•
If you release [Shutter] while shooting, the panoramic shooting
stops and photos that have been captured are saved.
My Camera > Shooting modes
70
•
The resolution varies depending on the panoramic photo you captured.
•
In Panorama mode, some shooting options are not available.
•
The camera may stop shooting due to the shooting composition or the
subject's movement.
•
In Panorama mode, your camera may not capture the entire last scene if you
stop moving the camera to improve the photo quality. To capture the entire
scene, move your camera slightly beyond the point where you want the
scene to end.
•
In 3D Panorama mode, your camera may not capture the very beginning or
end of a scene due to the nature of the 3D eect. To capture the entire scene,
move slightly beyond the beginning and end points you want to capture.
•
Photos captured with the 3D function are saved in JPEG (2D) and MPO (3D)
formats. On your camera's display, you can view only JPEG les.
•
To view 3D les, connect your camera to a 3D TV or 3D monitor with an
optional HDMI cable. While viewing, wear proper 3D glasses.
•
Capturing photos in 3D Panorama mode may result in a less pronounced 3D
eect than those captured with a 3D lens. To increase the 3D eect, attach
the optional 3D lens and use 3D mode. (p. 73)
•
For best results when capturing panoramic photos, avoid the following:
-
moving the camera too quickly or too slowly
-
moving the camera too little to capture the next image
-
moving the camera at irregular speeds
-
shaking the camera
-
shooting in dark places
-
capturing moving subjects nearby
-
shooting conditions where the brightness or color of light is changing
•
Photos taken are automatically saved, and shooting is stopped under the
following conditions:
-
if you change the shooting direction while shooting
-
if you move the camera too rapidly
-
if you do not move the camera
My Camera > Shooting modes
71
Using the Smart Jump Shot mode
In Smart Jump Shot mode, you can set an area to capture a jumping
subject. The camera will automatically capture a photo when movement is
detected.
1
Rotate the mode dial to s, and then select Smart Jump
Shot.
2
Drag the box on the screen to the desired location.
3
Drag the corners of the box to adjust its size to t the jumping
subject (one person).
4
Press [Shutter] or [o] to capture the photo.
•
The AF-assist light/Timer lamp will blink for 5 seconds. Informs the
subject to get ready to jump while the lamp is blinking.
•
When a subject is detected within the box on the screen after the
AF-assist light/Timer lamp stops blinking, the camera will capture 5
photos consecutively.
5
Touch the best image from the 5 photos to select it.
6
Press [o] to save the photo.
•
Press [m] to return to Shooting mode without saving the
photo.
•
Use a tripod to prevent your camera from shaking.
•
In dark environments the camera cannot capture photos.
My Camera > Shooting modes
72
Recording a video
In Shooting mode, you can record Full HD videos (1920X1080) by pressing
(Video recording). The camera lets you record a video up to 29 minutes
and 59 seconds until the size of a movie le becomes 4 GB in length at 60,
30, 24, or 15 fps, and saves the les in MP4 (H.264) format. (For 1920X1080
(60 fps), you can record up to 21 minutes and 15 seconds.) 60 fps is
available only with 1920X1080 and 1280X720 and 24 fps is available only
with 1920X810. 15 fps is available only with some Smart Filter options. The
sound is recorded via the camera's microphone. (If you attach an external
microphone, the sound will be recorded via the external microphone.)
You can set the exposure by adjusting the aperture value and shutter
speed for the mode you selected. When you use a lens that does not have
an AF/MF switch while recording a video, press [F] to deactivate or
activate the AF function. When you use the lens that has an AF/MF switch,
the AF function works according to the switch’s setting.
Select Fader to fade in or out a scene. You can also select Voice, Wind Cut,
or other options to set recording options. (p. 116)
1
Rotate the mode dial to t, P, A, S, M, T, U, i, or
s.
•
This feature may not work in some modes.
2
Set the desired options.
3
Press (Video recording) to start recording.
4
Press (Video recording) again to stop.
•
H.264 (MPEG-4 part10/AVC) is the latest video coding format established
in 2003 collaboratively by ISO-IEC and ITU-T. Since this format uses a high
compression rate, more data can be saved in less memory space.
•
If you have the image stabilizer option on when shooting a movie, the
camera may record the image stabilizer sound.
•
The zoom sound or other lens sounds may be recorded if you adjust the lens
while recording a video.
•
When using an optional video lens, the autofocus noise is not recorded.
•
If you remove the camera lens while recording a movie, the recording will be
interrupted. Do not change the lens while recording.
•
If you attach or remove an external microphone while recording a movie,
sound will be recorded via the camera's microphone.
My Camera > Shooting modes
73
•
If you change the shooting angle of the camera suddenly while shooting a
movie, the camera may not be able to record images accurately. Use a tripod
to minimize camera shake.
•
The camera supports only the Multi AF function when recording a video. You
cannot use any other focus area setting functions, such as Face Detection AF.
•
When the size of a movie le exceeds 4 GB, the camera automatically stops
recording even if the maximum recording time (29 minutes and 59 seconds)
has not been reached.
•
If you use a slow writing memory card, the recording of your movie can
be interrupted because the card cannot process data at the rate the video
is being shot. If this occurs, replace the card with a faster memory card or
reduce the video size (for example, from 1280X720 to 640X480).
•
When formatting a memory card, always format using the camera. If you
format on another camera or a PC, you can lose les on the card or cause a
change in the capacity of the card.
•
When you press the video recording button, Z turns o.
•
While recording a video in the same ISO sensitivity, the screen may be darker
than taking a photo. Adjust the ISO sensitivity.
•
When you record a video in P, A, or S mode, ISO is automatically set to Auto.
3D mode
You can capture 3D photos or videos with an optional 3D lens.
SAMSUNG 45 mm F1.8 [T6] 2D/3D lens (example)
Set the 2D/3D switch on the lens to 3D, and then capture a photo or video
1.5–5 m away from the subject.
My Camera > Shooting modes
74
•
3D mode is always on, regardless of the mode dial of the camera, except
B.
•
To use auto 3D options that enable the camera to set shooting options
automatically depending on shooting conditions in 3D mode, press
[m]
ĺ
b
ĺ
3D Auto Mode
ĺ
On.
•
To change the 3D recording option, press [m]
ĺ
g
ĺ
3D REC Mode
ĺ
a desired option.
* Default
Icon Description
Side by Side*: Displays two images next to each other.
Frame Packing: Displays the images for the left and right eye
alternately in frames.
•
Available shooting options dier compared to other shooting modes.
•
You can select either 4.1M (2688X1512) or 2.1M (1920X1080) photo size.
•
The video resolution is set to 1920X1080.
•
Videos recorded in 3D may be dark or playback may be jittery.
•
Shooting in low temperatures may result in color distortion in images and
may consume more battery power.
•
You may not be able to shoot properly in conditions below 8.5 LV/900 lux. For
best results, capture photos in places with sucient light.
•
When you photograph objects that contain polarizing material, such as a
display, sunglasses, or a polarizing lter, or use the polarizing material with
your lens, the images may appear dark or the 3D eect may not be applied
properly.
•
Use a tripod to prevent your camera from shaking.
•
If you rotate or tilt the camera vertically while shooting, the 3D eect may not
be applied properly. Capture images with the camera in the normal position.
•
If you shoot in uorescent lighting or capture images displayed by projectors
or TVs, the images may appear black due to the icker eect.
•
In 3D mode, the Enlarge x8 option of MF Assist may not be available.
•
The camera's display shows 3D videos only in 2D.
•
Photos captured with the 3D function are saved in JPEG (2D) and MPO (3D)
formats. On your camera's display, you can view only JPEG les.
•
To view 3D les, connect your camera to a 3D TV or 3D monitor with an
optional HDMI cable. While viewing, wear proper 3D glasses.
•
You cannot use the ash in 3D mode.
My Camera > Shooting modes
75
Available functions by shooting mode
For details about shooting functions, see Chapter 2.
Press a shortcut for each function.
Function Available in Shortcut
AF Area (p. 87)
P/A/S/M/i*/s* f/F
AF Mode (p. 84)
P/A/S/M/i*/s*/3D* f
Drive (Single/
Continuous/Burst/
Timer/Bracketing)
(p. 95)
P/A/S/M/i*/s*/t*/3D* f
Dynamic Range
(p. 109)
P/A/S/M -
Exposure
compensation (p. 111)
P/A/S/3D f/W
Exposure/Focus lock
(p. 112)
P/A/S/Ma
Flash (p. 101)
P*/A*/S*/M*/i*/s*/t* f
Focus Peaking (p. 93)
P/A/S/M/i/s/t -
Framing Mode (p. 61)
P/A/S/M -
Interval Capture
(p. 100)
P/A/S/M -
ISO (p. 79)
P/A/S/Mf/I
Function Available in Shortcut
Link AE to AF Point
(p. 108)
P/A/S/M -
Metering (p. 106)
P/A/S/MN
MF Assist (p. 92)
P/A/S/M/i/s/t/3D*-
OIS (Anti-Shake) (p. 94)
P/A/S/M/i/s*/t -
OLED Color (p. 80)
P/A/S/M/i/s/t -
Photo Size (p. 77)
P/A/S/M/i/s*/t/3D*-
Picture Wizard (p. 83)
P/A/S/M/3D f
Quality (p. 78)
P/A/S/M/i/s*-
Smart Filter (p. 110)
P/A/S/Mf
Touch AF (p. 90)
P/A/S/M/i/s*/t/3D*-
White Balance (p. 81)
P/A/S/M/3D* f/C
* Some functions are limited in these modes.
Chapter 2
Shooting Functions
Learn about the functions you can set in Shooting mode.
You can enjoy more customized photos and videos by using the shooting functions.
77
Shooting Functions > Size and Resolution
77
Shooting Functions >
S
ize
a
n
d
Res
olu
ti
o
n
Shooting Functions
Photo size
As you increase the resolution, your photo or video will include more
pixels, so it can be printed on larger paper or displayed on a larger screen.
When you use a high resolution, the le size will also increase. Select a low
resolution for photos that will be displayed in a digital picture frame or
uploaded to the web.
To set the size,
In Shooting mode, press [m]
ĺ
b
ĺ
Photo Size
ĺ
an option.
* Default
Icon Size Recommended for
(3:2) 5472x3648* Printing on A0 paper.
(3:2) 3888x2592 Printing on A2 paper.
(3:2) 2976x1984 Printing on A4 paper.
(3:2) 1728x1152 Printing on A5 paper.
(16:9) 5472x3080
Printing on A1 paper or viewing on an
HDTV.
(16:9) 3712x2088
Printing on A3 paper or viewing on an
HDTV.
(16:9) 2944x1656
Printing on A4 paper or viewing on an
HDTV.
(16:9) 1920x1080
Printing on A5 paper or viewing on an
HDTV.
(1:1) 3648x3648 Printing a square photo on A1 paper.
(1:1) 2640x2640 Printing a square photo on A3 paper.
(1:1) 2000x2000 Printing a square photo on A4 paper.
(1:1) 1024x1024 Attaching to an email.
Available options may dier depending on shooting conditions.
Size and Resolution
78
Shooting Functions > Size and Resolution
Quality
The camera saves photos in either the JPEG or RAW format.
Photos captured by a camera are often transformed to the JPEG format
and stored in the memory according to the settings of the camera at the
time of shooting. RAW les are not transformed to the JPEG format and are
stored in the memory without any changes.
RAW les have the le extension "SRW". To adjust and calibrate exposures,
White Balances, tones, contrasts, and colors of the RAW les, or to convert
them into JPEG or TIFF format, use the Adobe Photoshop Lightroom
program found on the supplied DVD-ROM.
Ensure you have enough space on the memory card to save photos in the
RAW format.
To set the quality,
In Shooting mode, press [m]
ĺ
b
ĺ
Quality
ĺ
an option.
* Default
Icon Format Description
JPEG
Super Fine*:
• Compressed for the best quality.
• Recommended for printing in large size.
JPEG
Fine:
• Compressed for better quality.
• Recommended for printing in normal size.
* Default
Icon Format Description
JPEG
Normal:
• Compressed for normal quality.
• Recommended for printing in small size or
uploading to the web.
RAW
RAW:
• Save a photo without data loss.
• Recommended for editing after shooting.
RAW+JPEG
RAW + S.Fine: Save a photo in both the JPEG
(S.Fine quality) and RAW format.
RAW+JPEG
RAW + Fine: Save a photo in both the JPEG (Fine
quality) and RAW format.
RAW+JPEG
RAW + Normal: Save a photo in both the JPEG
(Normal quality) and RAW format.
Available options may dier depending on shooting conditions.
79
Shooting Functions > ISO sensitivity
79
Shooting Functions >
I
SO sensitivit
y
Shooting Functions
The ISO sensitivity value represents the sensitivity of camera to light.
The larger the ISO value, the more sensitive the camera is to light.
Consequently, by selecting a higher ISO sensitivity value, you can capture
photos in dim or dark places at faster shutter speeds. However, this may
increase electronic noise and result in a grainy photo.
To set ISO sensitivity,
In Shooting mode, press [I]
ĺ
an option.
Examples
ISO 100 ISO 400
ISO 800 ISO 3200
•
You can also set the option by pressing [m]
ĺ
b
ĺ
ISO
ĺ
an option
in Shooting mode.
•
Increase the ISO value in places where ash use is prohibited. You can capture
a clear photo by setting a high ISO value without having to secure more light.
•
Use the Noise Reduction function in order to reduce the visual noise that can
appear on photos of a high ISO value. (p. 163)
•
Available options may dier depending on the shooting conditions.
ISO sensitivity
80
Shooting Functions > OLED Color
80
Shooting Functions >
O
LED C
olo
r
Shooting Functions
Set the camera to optimize colors for an OLED display when you capture
or play back photos. An OLED display has a wider color reproduction range
than a crystal liquid display and produces brighter, natural colors.
To set OLED Color,
In Shooting mode, press [m]
ĺ
b
ĺ
OLED Color
ĺ
an option.
OLED Color
81
Shooting Functions > White Balance
81
Shooting Functions >
Wh
ite B
ala
nc
e
Shooting Functions
White Balance represents the light source that inuences on the color of a
photo.
The color of a photo depends on the type and quality of the light source.
If you want the color of your photo to be realistic, select an appropriate
lighting condition to calibrate the White Balance, such as Auto WB,
Daylight, Cloudy, Tungsten, or adjust color temperature manually.
You can also adjust color for the preset light sources so that the colors of
the photo match the actual scene under mixed lighting conditions.
To set the White
Balance,
In Shooting mode, press [C]
ĺ
an option.
* Default
Icon Description
Auto WB*: Use automatic settings depending on the lighting
conditions.
Daylight: Select when taking outdoor photos on a sunny day. This
option results in photos closest to the natural colors of the scene.
Cloudy: Select when taking outdoor photos on a cloudy day or in
shadows. Photos captured on cloudy days tend to be more bluish
than on sunny days. This option osets that eect.
Fluorescent White: Select when shooting under a daylight
uorescent lamp, especially for white uorescent light.
* Default
Icon Description
N
Fluorescent NW: Select when shooting under a daylight
uorescent lamp, especially for white uorescent light of very
white hues.
D
Fluorescent Daylight: Select when shooting under a daylight
uorescent lamp, especially for white uorescent light of slightly
bluish hue.
Tungsten: Select when taking indoor photos under incandescent
bulbs or halogen lamps. Incandescent tungsten bulbs tend to have
a reddish hue. This option osets that eect.
Flash WB: Select when using a ash.
Custom Set: Use your pre-dened settings. You can manually set
the White Balance by pressing [D], and then shooting a white
sheet of paper. Fill the spot metering circle with the paper and set
the White Balance.
Color Temperature: Manually adjust the color temperature of
the light source. Color temperature is a measurement in degrees
Kelvin that indicates the specic type of light source. You can get a
warmer photo with a higher value, and a cooler photo with a lower
value. Press [D], and then adjust the color temperature.
•
You can also set the option by pressing [m]
ĺ
b
ĺ
White Balance
ĺ
an option in Shooting mode.
•
Available options may dier depending on shooting conditions.
White Balance
82
Shooting Functions > White Balance
Customizing preset White Balance options
You can also customize preset White Balance options.
To customize
preset options,
In Shooting mode, press [C]
ĺ
an option
ĺ
[D]
ĺ
scroll the command dial or rotate the navigation button or press
[D/I/C/F].
White Balance : Daylight
Back Set Reset
You can also touch an area on the screen.
Examples
Auto WB Daylight
Fluorescent Daylight Tungsten
83
Shooting Functions > Picture Wizard (photo styles)
83
Shooting Functions >
P
icture Wizar
d
(p
h
oto st
yl
es)
Shooting Functions
Picture Wizard lets you apply dierent photo styles to your photo to create
various looks and emotional moods. You can also create and save your
own photo styles by adjusting color, saturation, sharpness, and contrast for
each style.
There is no rule for which style is suitable in which conditions. Experiment
with dierent styles and nd your own settings.
To set a photo style,
In Shooting mode, press [m]
ĺ
b
ĺ
Picture Wizard
ĺ
an option.
Examples
Standard Vivid Portrait
Landscape Forest Retro
Cool Calm Classic
•
You can also adjust the value of the preset style settings. Select a Picture
Wizard option, press [D], and then adjust color, saturation, sharpness, or
contrast.
•
To customize your own picture wizard, select , , or , and then adjust
the color, saturation, sharpness, and contrast.
•
Picture Wizard options cannot be set with Smart Filter options at the same
time.
Picture Wizard (photo styles)
84
Shooting Functions > AF mode
84
Shooting Functions > AF m
od
e
Shooting Functions
AF mode
Learn how to adjust the camera’s focus according to the subjects.
You can select a focusing mode appropriate to the subject among Single
Auto Focus, Continuous Auto Focus, and Manual Focus. The AF function is
activated when you press [Shutter] halfway. In the MF mode, you have to
rotate the focus ring on the lens to focus manually.
In most cases, you can have a focus by selecting Single AF. Fast moving
subjects or subjects with small shading dierences to the background are
dicult to focus. Select an appropriate focusing mode for such instances.
If your lens has an AF/MF switch, you must set the switch according to
the selected mode. Set the switch to AF when you select Single AF or
Continuous AF. Set the switch to MF when you select Manual Focus.
When your lens has no AF/MF switch, press [F] to select a desired AF
mode.
To set the auto
focus mode,
In Shooting mode, press [F]
ĺ
an option.
•
You can also set the option by pressing [m]
ĺ
b
ĺ
AF Mode
ĺ
an option in Shooting mode.
•
The available options may dier depending on the lens in use.
85
Shooting Functions > AF mode
Single AF
Single AF is appropriate for shooting a still subject. When you press
[Shutter] halfway, the focus xes in the focus area. The area turns green
when the focus is achieved.
Continuous AF
While you are pressing [Shutter] halfway, the camera continues to
automatic focusing. Once the focus area is xed on the subject, the subject
is always in focus even when moving. This mode is recommended for
shooting a person on a bicycle, a running dog, or a car racing scene.
86
Shooting Functions > AF mode
Manual focus
You can manually focus on a subject by rotating the focus ring on the
lens. The MF Assist function lets you easily achieve a focus. While you are
rotating the focus ring, the focus area is magnied. When you use the
Focus Peaking function, the color you selected appears on the focused
subject. This mode is recommended for shooting an object similar in color
to the background, a night scene, or reworks.
If you use this function, you cannot set Touch AF, AF Area, and Link AE to AF
Point options.
87
Shooting Functions > AF area
87
Shooting Functions > AF
a
re
a
Shooting Functions
The AF area function changes the positions of the focus area.
Generally, cameras focus on the nearest subject. When there are a lot of
subjects, however, unwanted subjects can be in focus. In order to prevent
unwanted subjects from being in focus, change the focus area so that
a desired subject is in focus. You can get a clearer and sharper photo by
selecting an appropriate focus area.
To set the auto
focus area,
In Shooting mode, press [m]
ĺ
b
ĺ
AF Area
ĺ
an option.
•
Available options may dier depending on shooting conditions.
•
When the AF/MF switch is set to MF, you cannot change the AF area from the
shooting menu.
•
When you use the Face Detection AF option, the camera focuses on the area
with the white frame automatically.
•
Depending on the Picture Wizard options, Face Detection may not be
eective.
•
When you set manual focus, Face Detection may not be available.
•
Face Detection may not be eective when:
-
the subject is far from the camera
-
it is too bright or too dark
-
the subject is not facing the camera
-
the subject is wearing sunglasses or a mask
-
the subject’s facial expression changes drastically
-
the subject is backlit or the lighting conditions are unstable
Selection AF
You can set the focus on an area you want. Apply an out-of-focus eect to
make the subject more distinguishable.
The focus on the photo below was repositioned and resized so that it ts
the subject’s face.
To resize or move the focus area, in Shooting mode, press [o]. Use the
navigation button to move the focus area. Scroll the command dial to resize
the focus area. When you use the viewnder, press [f] to select a focus area
conveniently.
AF area
88
Shooting Functions > AF area
Multi AF
The camera displays a green rectangle in places where focus is set
correctly. The photo is divided into two or more areas, and the camera
obtains focus points of each area. It is recommended for scenery photos.
When you press [Shutter] halfway, the camera displays the focus areas as
shown in the photo below.
Face Detection AF
The camera focuses on human faces preferentially. Faces of up to
10 people can be detected. This setting is recommended for shooting a
group of people.
When you press [Shutter] halfway, the camera focuses on faces as shown
in the photo below. In cases of shooting a group of people, the camera
displays the focus on the nearest person’s face in white and the rest of the
people’s faces in gray.
89
Shooting Functions > AF area
Self-Portrait AF
It can be dicult to check whether your face is in focus when you are
taking a self-portrait. When this function is on, the beep from the camera
gets faster when your face is located at the center of the composition.
90
Shooting Functions > Touch AF
90
Shooting Functions >
Tou
c
h
A
F
Shooting Functions
Tracking AF
Tracking AF allows you to track and automatically focus on your subject,
even when the subject is moving or when you change the shooting
composition.
White frame: Your camera is
tracking the subject.
Green frame: Your subject is
in focus when you half-press
[Shutter].
Red frame: Your camera failed to
focus.
Select or focus on an area that you touch on the screen. Additionally, focus
on the subject and capture a photo by touching on the screen.
To set Touch AF,
In Shooting mode, press [m]
ĺ
b
ĺ
Touch AF
ĺ
an option.
Available options may dier depending on the shooting conditions.
Touch AF
Touch AF allows you to select and focus on the focus area that you touch
on the screen.
AF Point
The focus area will correspond to the area you touch on the screen and the
focus will not be achieved.
Touch AF
91
Shooting Functions > Touch AF
One touch shot
You can capture a photo with the touch of your nger. As you touch a
subject, the camera focuses on the subject automatically and captures a
photo.
•
If you do not select a focus area, the Auto Focus function does not work.
•
Tracking a subject may fail when:
-
the subject is too small
-
the subject moves irregularly
-
the subject is backlit or you are shooting in a dark place
-
colors or patterns on the subject and the background are the same
-
the subject includes horizontal patterns, such as blinds
-
the camera shakes excessively
-
you capture photos continuously
•
When tracking fails, the feature will be reset.
•
If the camera fails to track the subject, the focus area will be reset.
•
If the camera fails to focus, the focus frame will change to red and the focus
will be reset.
92
Shooting Functions > Focus assist
92
S
h
ooting Functions >
Fo
c
u
s
a
ss
i
st
Shooting Functions
In the manual focus mode, you have to rotate the focus ring on the lens to
focus. When you use the MF Assist function or the Focus Peaking function,
you can achieve a clearer focus. This function is only available on a lens
that supports manual focus.
You can also use the Direct Manual Focus (DMF) function to adjust the
focus manually. After focusing with the Auto Focus function, adjust the
focus by rotating the focus ring.
MF Assist
In the manual focus mode, you can enlarge the scene and easily adjust the
focus while rotating the focus ring.
To set the manual
focus assist,
In Shooting mode, press [m]
ĺ
b
ĺ
MF Assist
ĺ
an option.
* Default
Option Description
O
Do not use the MF Assist function.
Enlarge x5*
The focus area is magnied by 5 times when you rotate the
focus ring.
Enlarge x8
The focus area is magnied by 8 times when you rotate the
focus ring.
Focus assist
93
Shooting Functions > Focus assist
Focus Peaking
In the manual focus mode, the color you selected appears on the focused
subject to help you focus while rotating the focus ring.
To set Focus
Peaking options,
In Shooting mode, press [m]
ĺ
b
ĺ
Focus Peaking
ĺ
an option.
* Default
Option Description
Level
Set a sensitivity for detecting the focused subject.
(O, High, Normal*, Low)
Color
Set a color to appear on the focused subject.
(White*, Red, Green)
DMF (Direct Manual Focus)
You can adjust the focus manually by rotating the focus ring after
achieving the focus by half-pressing [Shutter]. This feature may not be
available with some lenses.
To set the DMF
function,
In Shooting mode, press [m]
ĺ
d
ĺ
DMF
ĺ
an option.
Setting DMF responsiveness
Set the focus ring's response when you use the DMF function. If you select
High, slight rotations of the focus ring are made to adjust the focus. If you
select Low, longer rotations of the focus ring are made to adjust the focus.
This feature is supported only when you attach a lens that has this feature.
To set DMF
Resposiveness
options,
In Shooting mode, press [m]
ĺ
d
ĺ
DMF
Responsiveness
ĺ
an option.
94
Shooting Functions > Optical Image Stabilization (OIS)
94
Shooting Functions >
O
ptica
l
Ima
g
e Sta
b
i
l
ization (OI
S
S
S
)
)
Shooting Functions
Use the Optical Image Stabilization (OIS) function to minimize camera
shake. OIS may not be available with some lenses.
Camera shake tends to occur in dark places or when shooting indoors.
In such cases, the camera uses slower shutter speeds in order to increase
the amount of light taken in, which can result in a blurry photo. You can
prevent this situation by using the OIS function.
If your lens has an OIS switch, you have set the switch to ON to use the OIS
function.
To set OIS options,
In Shooting mode, press [m]
ĺ
b
ĺ
OIS (Anti-Shake)
ĺ
an option.
* Default
Icon Description
O: The OIS function is o. (This option may not be available with
some lenses.)
Mode 1*: The OIS function is applied only when you press
[Shutter] in full or half.
Mode 2: The OIS function is on.
Optical Image Stabilization (OIS)
Without OIS correction With OIS correction
•
OIS may not function properly when:
-
you move your camera to follow a moving subject
-
there is too much camera shake
-
the shutter speed is slow (for example, when you select Night in
s mode)
-
the battery is low
-
you capture a close-up shot
•
If you use the OIS function with a tripod, your images may be blurred by
the vibration of the OIS sensor. Deactivate the OIS function when you use a
tripod.
•
If the camera is hit or dropped, the display will be blurry. If this occurs, turn o
the camera, and then turn it on again.
•
Use the OIS function only when needed because the function consumes
more battery power.
•
To set an OIS option on the menu, set the OIS switch on your lens to ON.
•
This option may not be available with some lenses.
•
O may not be available with some lenses.
95
Shooting Functions > Drive (shooting method)
95
Shooting Functions >
D
rive (s
h
ootin
g
met
h
o
d
)
Shooting Functions
You can set the shooting method, such as Continuous, Burst, Timer, or
Bracketing.
Select Single to capture one photo at a time. Select Continuous or Burst
to shoot fast moving subjects. Select AE Bracket, WB Bracket, P Wiz
Bracket, or Depth Bracket to adjust exposure, White Balance, apply
picture Wizard eects, or capture photos with dierent depths of eld. You
can also select Timer to capture a photo automatically after a specied
time.
Available options may dier depending on shooting conditions.
Icon Description
H
Single (p. 96)
J
Continuous (p. 96)
K
Timer (p. 97)
L
Bracketing (p. 98)
Do not rotate the drive dial beyond the permitted limits. Doing so may damage
the camera.
Drive (shooting method)
96
Shooting Functions > Drive (shooting method)
Single
Capture one photo whenever you press [Shutter]. Recommended for
general conditions.
To set the shooting
method,
Rotate the drive dial to H.
Continuous
Continuously capture photos while you are pressing [Shutter]. You can
capture up to 4 photos (Continuous Normal) or 9 photos (Continuous
High) per second.
To set the shooting
method,
Rotate the drive dial to J, press [m]
ĺ
b
ĺ
Drive
Settings
ĺ
Continuous
ĺ
Continuous High or Continuous
Normal.
If you select Continuous High, the noise reduction function is not available.
97
Shooting Functions > Drive (shooting method)
Burst
Consecutively capture up to 10 shots per second (3 seconds), 15 shots per
second (2 seconds), or 30 shots per second (1 second) when you press
[Shutter] once. It is recommended for shooting the rapid motion of fast
moving subjects such as racing cars.
To set the shooting
method,
Rotate the drive dial to J, press [m]
ĺ
b
ĺ
Drive
Settings
ĺ
Continuous
ĺ
Burst
ĺ
press [F] and set the
number of shots.
•
The photo size is set to 5M.
•
It may take longer to save a photo.
•
You cannot use the ash with this option.
•
Shutter speed must be faster than 1/30 second.
•
Photos captured with this option may be slightly enlarged when saving.
•
You cannot set an ISO option higher than ISO 3200.
•
This option cannot be used with the RAW le format and is not available
when the photo quality is set to RAW.
Timer
Capture a photo after a specied time. You can also set the shooting
interval, number of shots, and shooting time.
To set the shooting
method,
Rotate the drive dial to K.
•
Press [Shutter] to stop capturing.
•
To set the timer details, set the drive dial to K, press [m]
ĺ
b
ĺ
Drive Settings
ĺ
Timer
ĺ
set the shooting interval, number of shots, and
shooting time.
98
Shooting Functions > Drive (shooting method)
Auto Exposure Bracketing (AE Bracket)
When you press [Shutter], the camera captures 3 consecutive photos: the
original, one a step darker, and one a step lighter. Use a tripod to prevent
blurry photos as the camera captures three photos continuously. You can
adjust the settings in Bracket Settings menu.
To set the shooting
method,
Rotate the drive dial to L, press [m]
ĺ
b
ĺ
Drive
Settings
ĺ
Bracket
ĺ
AE Bracket.
Exposure -2
Original
Exposure +2
White Balance Bracketing (WB Bracket)
When you press [Shutter], the camera captures 3 consecutive photos:
the original and two more with dierent White Balance settings. The
original photo is captured when you press [Shutter]. The other two are
automatically adjusted according to the White Balance you have set. You
can adjust the settings in Bracket Settings menu.
To set the shooting
method,
Rotate the drive dial to L, press [m]
ĺ
b
ĺ
Drive
Settings
ĺ
Bracket
ĺ
WB Bracket.
WB-2
Original
WB+2
This option cannot be used with the RAW le format. Selecting this option will
change the photo quality from RAW to JPEG.
99
Shooting Functions > Drive (shooting method)
Picture Wizard Bracketing (P Wiz Bracket)
When you press [Shutter], the camera captures three consecutive photos,
each with a dierent Picture Wizard setting. The camera captures a photo
and applies the three Picture Wizard options you have set to the image
captured. You can select three dierent settings in Bracket Settings menu.
To set the shooting
method,
Rotate the drive dial to L, press [m]
ĺ
b
ĺ
Drive
Settings
ĺ
Bracket
ĺ
P Wiz Bracket.
Vivid
Standard
Retro
This option cannot be used with the RAW le format. Selecting this option will
change the photo quality from RAW to JPEG.
Depth Bracketing
When you press [Shutter], the camera captures three consecutive photos,
each with a dierent depth of eld by adjusting the aperture value. Use
a tripod to prevent blurry photos as the camera captures three photos
continuously. You can adjust the settings in Bracket Settings menu.
To set the shooting
method,
Rotate the drive dial to L, select [m]
ĺ
b
ĺ
Drive
Settings
ĺ
Bracket
ĺ
Depth Bracket.
This feature is available only in Program or Aperture priority mode.
Bracket Settings
You can set up the options for each bracketing. (p. 164)
To set a bracketing
option,
In Shooting mode, press [m]
ĺ
d
ĺ
Bracket Settings
ĺ
an option.
100
Shooting Functions > Interval Capture
100
Shooting Functions >
I
nterva
l
Ca
p
ture
Shooting Functions
Set the shooting interval and the number of shots to be captured
automatically. Use this function to capture photos at regular intervals
during an event such as a lunar eclipse or a sunrise.
To capture an
interval shot,
In Shooting mode, press [m]
ĺ
b
ĺ
Interval Capture
ĺ
a shooting interval and the number of shots
ĺ
press [o] or
[Shutter] to save the settings
ĺ
press [Shutter] to capture the
photo.
•
Touch to pause while capturing photos.
•
Touch to resume.
•
Touch or press [Shutter] to stop capturing.
•
Shooting intervals can be set to seconds if the shooting interval is less than
one minute. For intervals longer than one minute, intervals can be set to
minutes and hours only.
•
Use a shutter release cable with a tripod to minimize camera movement
when capturing interval shots.
•
Connect the power cable if the shooting interval is long or the number of
shots to be taken is high.
•
If the shooting interval is set to between one minute and 10 minutes, the
camera will enter Display save mode after it starts to capture a photo. If a
shooting interval exceeds 10 minutes, the camera will enter Power save mode
and turn on and capture a photo automatically at the next interval. Press
[Shutter] to cancel Power save mode.
Interval Capture
101
Shooting Functions > Flash
101
Shooting Functions >
Fla
s
h
Shooting Functions
In order to capture a realistic photo of a subject, the amount of light
should be constant. When the light source varies, you can use a ash and
supply a constant amount of light. Select appropriate settings according to
a light source and a subject.
To set ash options,
In Shooting mode, press [m]
ĺ
b
ĺ
Flash
ĺ
an option.
Icon Description
O: Do not use the ash.
A
Smart Flash: The camera automatically adjusts the brightness
of the ash according to the amount of light in the surrounding
environment.
A
Auto: The ash automatically res in dark places.
Auto Red-eye: The ash automatically res and reduces red-eyes.
Fill in: The ash res whenever you capture a photo. (Brightness is
automatically adjusted.)
Fill-in Red: The ash res whenever you capture a photo and
reduces red-eyes.
1st Curtain: The ash res
immediately after the shutter opens.
The camera captures a photo of a
subject earlier in an action sequence
clearly.
Ball moving direction
Icon Description
2nd Curtain: The ash res just
before the shutter closes. The
camera captures a photo of a
subject later in an action sequence
clearly.
Ball moving direction
H
Hi-speed: If the shutter speed is faster than the camera's sync
speed (the quickest time taken to open and close the shutter), the
ash will re multiple times at high speed. The ash starts to re
while the shutter opens. This option can be set only when you
attach a compatible, optional external ash. (SEF-580A)
•
The available options may dier depending on shooting conditions.
•
There is an interval between two bursts of the ash. Do not move until the
ash res a second time.
•
If you select O, the ash does not re even when an external ash is
attached. If you adjust the ash intensity manually, the ash will re once
without a pre-ash.
Use only Samsung-approved ashes. Using incompatible ashes may damage
your camera.
Flash
102
Shooting Functions > Flash
Reducing the red-eye eect
If the ash res when you capture a photo of a person in the dark, a red
glow may appear in the eyes. To reduce the red-eye eect, select Auto
Red-eye, or Fill-in Red.
Without red-eye reduction With red-eye reduction
If the subject is too far from the camera or moves when the rst ash res, red-
eyes may not be reduced.
Using the built-in ash
To open the built-in ash, press the ash pop-up button. The ash does
not re when the built-in ash is closed.
103
Shooting Functions > Flash
Adjusting the ash intensity
When the ash is on, adjust the ash intensity +/-2 levels.
To set the ash
intensity,
In Shooting mode, select [m]
ĺ
b
ĺ
Flash
ĺ
an
option
ĺ
[D]
ĺ
scroll the command dial or rotate the
navigation button or press [C/F] to adjust the ash
intensity.
Back Set Cancel
Flash : Fill in
•
You can also drag the slider or touch +/- to adjust the intensity.
•
Adjusting the flash intensity may not be eective when:
-
the subject is too close to the camera
-
you set a high ISO sensitivity
-
the exposure value is too big or too small
•
In some shooting modes, you cannot use this function.
•
If you attach an intensity-adjustable external ash to the camera, the intensity
settings of the ash will be applied.
•
If the subject is too close when you use the ash, some light may be blocked,
resulting in a dark photo. Ensure that the subject is within the recommended
range, which varies by lens.
•
When a lens hood is attached, the light from the ash can be blocked by the
hood. Remove the hood to use the ash.
104
Shooting Functions > Flash
Flash settings
Set the ash mode, exposure value, ash brightness, or multi ash when
you attach an external ash to the camera. You can also set wireless sync
to control internal or external ash. The ash settings are supported only
when you attach a compatible, optional external ash (SEF-580A).
Setting external ash
To set external
ash,
In Shooting mode, press [m]
ĺ
b
ĺ
External Flash
Settings
ĺ
an option.
Option Description
Flash Mode
• A-TTL: In the A-TTL (Advanced Through The Lens) mode,
the camera measures the light reected by the subject
through the lens. Then, it calculates the optimum
exposure based on the exposure value and shutter
speed.
• Manual Flash: The ash emits the full amount of light or
the ash intensity can be adjusted manually.
• Multi Flash: When you press [Shutter], the ash res
multiple times based on the number you have set.
Flash EV
Set the exposure of the ash when the ash mode is
A-TTL.
Flash Output
Set the brightness of the ash when the ash mode is
Manual Flash.
Multi Flash
Settings
Set the count, brightness, or frequency of the ash when
the ash mode is Multi Flash.
If data can be exchanged between the camera and the ash, the settings for the
external ash can be adjusted on the camera or the ash. Your previous options
will be applied.
105
Shooting Functions > Flash
Setting wireless sync for internal or external ash
Set wireless sync to control internal and external ash units remotely
via wireless signals. The remote system consists of a master ash that is
mounted on the camera and one or more slave ash units. A slave ash is
assigned to one of three groups: A, B, or C.
To set wireless
sync,
In Shooting mode, press [m]
ĺ
b
ĺ
Internal Wireless
Flash or External Wireless Flash
ĺ
an option.
* Default
Option Description
Use Wireless
Flash
Set to use wireless sync. (O*, On)
Channel
Select channels for wireless sync. There are four remote
channels available to allow multiple remote systems to
operate at the same time. Master and slave ash units, in
the same remote system, must be set to the same channel.
(Ch. 1, Ch. 2, Ch. 3, Ch. 4)
Group Flash
Mode
Set the ash mode for group A, B, or C. Changes to the
ash mode must be made on the master ash. The
changes are then applied to slave group A, B, or C, and
the slave groups operate as a remote system of the ash
mode (TTL or manual) according to the settings for the
master ash.
• A-TTL: Set the exposure of the ash when the ash
mode is A-TTL.
• Manual Flash: Set the brightness of the ash when the
ash mode is Manual Flash.
• O: Do not re the ash.
•
You cannot select External Flash Settings when you use the External
Wireless Flash function.
•
For information about using the wireless sync feature with an external ash,
refer to the optional external ash's (SEF-580A) user manual.
106
Shooting Functions > Metering
106
Shooting Functions >
M
eter
i
n
g
Shooting Functions
The metering mode refers to the way in which a camera measures the
quantity of light.
The camera measures the amount of light in a scene, and in many of its
modes, uses the measurement to adjust various settings. For example,
if a subject looks darker than its actual color, the camera captures an
overexposed photo of it. If a subject looks lighter than its actual color, the
camera captures an underexposed photo of it.
The brightness and overall mood of the photo can also be aected by how
the camera measures the amount of light. Select an appropriate setting for
a shooting condition.
To set a metering
option,
In Shooting mode, press [N]
ĺ
an option.
Multi
The Multi mode calculates the amount of light in multiple areas. When
light is sucient or insucient, the camera adjusts the exposure by
averaging the overall brightness of the scene. This mode is suitable for
general photos.
Metering
107
Shooting Functions > Metering
Center-weighted
The Center-weighted mode calculates a broader area than the Spot mode
does. It sums up the amount of light in the center portion of the shot
(60–80%) and that of the rest of the shot (20–40%). It is recommended
for situations where there is a slight dierence in brightness between a
subject and a background or an area of the subject is large compared to
the overall composition of the photo.
Spot
The Spot mode calculates the amount of light in the center. When you
capture a photo in conditions where there is a strong backlight behind a
subject, the camera adjusts the exposure so as to shoot a subject correctly.
For example, when you select the Multi mode in a strong backlight
condition, the camera calculates that the overall amount of light is
abundant, which results in a darker photo. The Spot mode can prevent this
situation as it calculates the amount of light in a designated area.
The subject is in bright color while the background is dark. The Spot mode
is recommended for a situation like this where a huge dierence in the
exposure exists between a subject and a background.
108
Shooting Functions > Metering
Measuring the exposure value of the focus area
When this function is turned on, the camera automatically sets an optimal
exposure by calculating the brightness of the focus area. This function
is only available when you select Spot metering or Multi metering, and
Selection AF.
To set this
function,
In Shooting mode, press [m]
ĺ
b
ĺ
Link AE to AF
Point
ĺ
an option.
109
Shooting Functions > Dynamic Range
109
Shooting Functions >
Dy
namic
R
ange
Shooting Functions
This function automatically corrects the loss of bright detail that can occur
due to shading dierences in the photo.
To set Dynamic Range
options,
In Shooting mode, press [m]
ĺ
b
ĺ
Dynamic Range
ĺ
an option.
Without Dynamic Range eect With Dynamic Range eect
* Default
Icon Description
O*: Do not use Dynamic Range.
Smart Range+: Correct the loss of bright detail.
You cannot set ISO 100.
HDR: Capture 2 photos with dierent exposures, and then
combine them to create a single image automatically.
•
You cannot set an ISO option higher than ISO 3200.
•
Dynamic Range options cannot be set with Picture Wizard
options at the same time.
Dynamic Range
110
Shooting Functions > Smart Filter
110
Shooting Functions >
S
m
a
rt Fi
l
te
r
Shooting Functions
Smart Filter lets you apply special eects to your photos. You can select
various lter options to create special eects that are dicult to be
achieved with normal lenses.
To set Smart Filter
options,
In Shooting mode, press [m]
ĺ
b
ĺ
Smart Filter
ĺ
an option.
* Default
Option Description
O*
No eect
Vignetting
Apply the retro-looking colors, high contrast, and strong
vignette eect of Lomo cameras.
Miniature
Apply a tilt-shift eect to make the subject appear in
miniature.
Colored Pencil
Apply a colored pencil painting eect.
Watercolor
Apply a watercolor painting eect.
Wash drawing
Apply a washed-out eect.
Oil Sketch
Apply an oil sketching eect.
Ink Sketch
Apply an ink sketching eect.
Acryl
Apply an acryl painting eect.
* Default
Option Description
Negative
Apply a negative lm eect.
Red
Desaturate all colors but red.
Green
Desaturate all colors but green.
Blue
Desaturate all colors but blue.
Yellow
Desaturate all colors but yellow.
Smart Filter options cannot be set with Picture Wizard options at the same time.
Smart Filter
111
Shooting Functions > Exposure compensation
111
Shooting Functions >
E
x
p
osure com
p
ensat
i
o
n
Shooting Functions
The camera automatically sets the exposure by measuring the levels of
light from the photo’s composition and the position of a subject. If the
exposure set by the camera is higher or lower than you expected, you can
adjust the exposure value manually. The exposure value is adjustable in ±3
increments. The camera displays the exposure warning in red for each step
beyond ±3 range.
To adjust the exposure value, while holding down [W], scroll the
command dial. You can also adjust the exposure value by pressing [f],
and then selecting EV.
You can check the exposure value by the position of the exposure level
indicator.
Exposure level
indicator
Increased exposure
(brighter)
Decreased exposure
(darker)
Exposure warning
Standard exposure index
-2
Original
+2
Viewing the overexposure guide
View overexposed areas on a photo in Shooting mode before capturing a
photo. Setting this feature will allow the overexposed areas of a photo to
blink.
To view the
overexposure
guide,
In Shooting mode, press [m]
ĺ
b
ĺ
Overexposure
Guide
ĺ
an option.
Exposure compensation
112
Shooting Functions > Exposure/Focus lock
112
Shooting Functions >
E
x
p
osure/Focus
l
oc
k
Shooting Functions
When you cannot achieve an appropriate exposure because of a strong
brightness contrast or you want to capture a photo on which the subject
is out of the auto focus area, lock the focus or exposure and then capture a
photo.
To lock the exposure or focus, adjust the photo’s composition on which
you want to focus or calculate the exposure, and then press [a].
After locking the exposure or focus, aim the lens where you desire, and
then press [Shutter].
You can change the function assigned to the button to focus lock, exposure
lock, or both of them. A function executed by half-pressing [Shutter] varies
according to the function assigned to [a]. (p. 168)
Exposure/Focus lock
113
Shooting Functions > Exposure/Focus separation
113
Shooting Functions >
E
x
p
osure/Focus se
p
aration
Shooting Functions
Separate the exposure area and the focus area or merge them again. This
feature is available only when Touch AF is set to Touch AF.
1
On the screen, touch an area to focus on it.
•
The exposure separation icon will appear at the top right of the
focus frame.
2
Drag to the exposure area.
•
The focus area and the exposure area will be separated.
•
Touch and hold each area to lock the focus or exposure setting.
•
Drag the areas together to merge the focus area and the exposure
area.
Exposure
Focus
3
Press [Shutter] to capture the photo.
•
The focus area and the exposure area will return to their pre-
shooting position.
If you press [a] while its function is set to AEL Hold, the exposure will
remain locked and the exposure area will not change after shooting.
Exposure/Focus separation
114
Shooting Functions > Video functions
114
Shooting Functions >
V
i
d
e
o
fu
ncti
o
n
s
Shooting Functions
The functions available for video are explained below.
Movie size
Set the movie size.
To set movie size
options,
In Shooting mode, press [m]
ĺ
g
ĺ
Movie Size
ĺ
an option.
* Default
Icon Size Recommended for
*
1920X1080 (60 fps) (16:9)
View on a Full HDTV. (Videos
recorded with this option may
not play on some HDTVs or smart
phones that do not support 60 fps.)
1920X1080 (30 fps) (16:9) View on a Full HDTV.
1920X1080 (15 fps) (16:9)
View on a Full HDTV. (Available only
with some Smart Filter options.)
1920X810 (24 fps)
(Approx. 2.35:1)
View on a Full HDTV.
1280X720 (60 fps) (16:9) View on an HDTV.
1280X720 (30 fps) (16:9) View on an HDTV.
640X480 (30 fps) (4:3) View on a TV.
320X240 (30 fps) (4:3)
Post on a website using the wireless
network (30 seconds maximum).
Movie quality
Set the Movie quality.
To set movie
quality options,
In Shooting mode, press [m]
ĺ
g
ĺ
Movie Quality
ĺ
an option.
* Default
Icon Extension Description
MP4 (H.264) Normal: Record videos in normal quality.
MP4 (H.264) HQ*: Record videos in high quality.
Video functions
115
Shooting Functions > Video functions
Multi Motion
Set the playing speed of a video.
To set playing
speed options,
In Shooting mode, press [m]
ĺ
g
ĺ
Multi Motion
ĺ
an option.
* Default
Icon Description
x0.25: Record a video to view it at 1/4 normal speed during
playback. (Available only with 640x480 or 320x240)
x0.5: Record a video to view it at 1/2 normal speed during
playback. (Available only with 1920x1080 (30 fps), 1280x720 (30
fps), 640x480, or 320x240)
x1*: Record a video to view it at normal speed during playback.
x5: Record a video to view it at 5X normal speed during playback.
x10: Record a video to view it at 10X normal speed during
playback.
x20: Record a video to view it at 20X normal speed during
playback.
•
If you select an option other than x1, the sound recording function and the
Distortion Correct function will not be supported.
•
The available options may dier depending on shooting conditions.
DIS (Anti-Shake)
Set the Digital Image Stabilization function.
To set the DIS
function,
In Shooting mode, press [m]
ĺ
g
ĺ
DIS (Anti-Shake)
ĺ
an option.
* Default
Option Description
O*
Do not use the DIS function.
On
Use the DIS function.
•
If you record a video with the DIS function, the video will be recorded at a
narrower angle than the lens' angle.
•
The DIS function is not supported when you attach a sh-eye lens.
116
Shooting Functions > Video functions
Voice
Sometimes, a muted video is more appealing than the one with sound.
Turn the voice o to record a muted video.
To set voice
options,
In Shooting mode, press [m]
ĺ
g
ĺ
Voice
ĺ
an option.
Wind Cut
When you record videos in noisy environments, unintended sounds can
be recorded in videos. In particular, severe wind noise recorded in videos
distracts you from enjoying your videos. Use the Wind Cut function to
remove some surrounding noise in addition to wind noise.
To reduce wind
sound,
In Shooting mode, press [m]
ĺ
g
ĺ
Wind Cut
ĺ
an option.
Fader
You can fade in or fade out a scene using the fader function on the camera
without having to do it on a PC. Set the fade in option to gradually fade in
at the start of the scene. Set the fade out option to gradually fade out the
scene. Use the function appropriately and add dramatic eects on your
videos.
To set fader
options,
In Shooting mode, press [m]
ĺ
g
ĺ
Fader
ĺ
an option.
* Default
Icon Description
O*: Fader function not used.
In: Scene gradually fades in.
Out: Scene gradually fades out.
In-Out: The fader function is applied at the start and end of the
scene.
When you use the fader function, it may take longer to save a le.
117
Shooting Functions > Video functions
Mic Level
Set the mic level for the shooting conditions.
To set the mic
level,
In Shooting mode, press [m]
ĺ
g
ĺ
Mic Level
ĺ
an option.
* Default
Icon Description
A
Auto*: Set the mic level automatically.
M
Manual: Set the mic level manually.
Chapter 3
Playback/Editing
Learn about how to play back and edit photos and videos.
Refer to chapter 6 for editing les on a PC.
119
Playback/Editing
Learn how to view photo and video thumbnails and how to protect or
delete les.
If you perform no operations for a while, information and icons on the screen
disappear. When you operate the camera again, they will reappear.
Viewing photos
1
Press [y].
•
The most recent le you captured will be displayed.
2
Rotate the navigation button or press [C/F] to scroll
through les.
•
You can also drag the image left or right to move to another le.
You may not be able to edit or play back les that were captured with other
cameras, due to unsupported sizes or codecs. Use a computer or another device
to edit or play back these les.
Viewing image thumbnails
In order to search for photos and videos you want, convert to the
thumbnail view. The thumbnail view displays multiple images at a time
so that you can easily look through items you wish to nd. You can also
classify and display les by category, such as date or le type.
All
Scroll the command dial to the left to select the thumbnail
view mode.
(Scroll the command dial to the right to return to the previous
mode.)
Searching and managing files
120
Playback/Editing > Searching and managing les
Viewing les by category
1
In the thumbnail view, press [m]
ĺ
z
ĺ
Filter
ĺ
a category.
•
You can also touch the current category name to open the option
list.
* Default
Option Description
All*
View les normally.
Date
View les by the date they were saved.
Type
View les by the le type.
2
Select a list to open it.
3
Select a le to view it.
4
Touch to return to the previous view.
121
Playback/Editing > Searching and managing les
Viewing les as a folder
Continuous and burst shots appear as a folder. Selecting a folder will play
back all photos automatically. Deleting a folder will delete all photos in the
folder.
1
In Playback mode, rotate the navigation button or press
[C/F] to move to a desired folder.
•
You can also drag the image left or right to move to a desired folder.
•
The camera will automatically play back photos in the folder.
2
Scroll the command dial to the right to open the folder.
•
You can also touch the folder on the screen or press [o] to open the
folder.
3
Rotate the navigation button or press [C/F] to move to
another le.
•
You can also drag the image left or right to move to another le.
4
Scroll the command dial to the left or press [o] to return to
Playback mode.
•
You can also touch to return to Playback mode.
122
Playback/Editing > Searching and managing les
Protecting les
Protect your les from accidental deletion.
1
In Playback mode, press [m]
ĺ
z
ĺ
Protect
ĺ
Multiple Protect.
2
Rotate the navigation button or press [C/F] to select a
le, and then press [o].
3
Press [f].
•
You cannot delete or rotate a protected le.
•
You can directly protect a le in Playback mode by selecting a le, and then
pressing [
]. To unprotect the le, press [ ] again.
•
For photos that are saved as a folder, press [ ] while the folder is selected to
protect all les.
Lock/Unlock all les
Lock or unlock all les.
1
In Playback mode, press [m]
ĺ
z
ĺ
Protect
ĺ
Protect All.
2
Select an option.
Option Description
Lock
Lock all les.
Unlock
Unlock all les.
Cancel
Return to the previous menu.
123
Playback/Editing > Searching and managing les
Deleting les
Delete les in Playback mode and secure more space on your memory
card. Protected les are not deleted.
Deleting a single le
You can select a single le and delete it.
1
In Playback mode, select a le, and then press [n].
2
When the pop-up message appears, select Ye s .
Deleting multiple les
You can select multiple les and delete them.
1
In Playback mode, press [m]
ĺ
z
ĺ
Delete
ĺ
Multiple
Delete.
•
You can also press [m]
ĺ
z
ĺ
Select Item.
•
Alternatively, in thumbnails view, press [n], and then select les to
delete.
2
Select les you want to delete by rotating the navigation
button or pressing [C/F], and then press [o].
•
Press [o] again to cancel your selection.
3
Press [n].
4
When the pop-up message appears, select Ye s .
Deleting all les
You can delete all les on the memory card at once.
1
In Playback mode, press [m].
2
Select z
ĺ
Delete
ĺ
Delete All.
3
When the pop-up message appears, select Ye s .
124
Playback/Editing
Enlarging a photo
You can enlarge photos when viewing them in Playback mode. You can
also use the Trim function to extract the portion of the image displayed on
the screen and save it as a new le.
Magnied area
Magnication (The maximum
magnication may dier by
resolution.)
Full Image Crop
Scroll the command dial to the right to enlarge a photo.
(Scroll the command dial to the left to reduce a photo.)
To Do this
Move magnied area
Press [D/I/C/F].
Crop the enlarged image
Press [f]. (saved as a new le)
Return to the original image
Press [o].
•
You can also pinch your ngers together or spread them apart on the screen
to reduce or enlarge a photo. You can also double-tap an area to enlarge it
quickly.
•
You can scroll through les by rotating the navigation button, even when a
photo is enlarged.
Viewing a slide show
You can view photos in a slide show, apply various eects to the slide
show, and play background music.
1
In Playback mode, press [m].
2
Select z
ĺ
Slide Show Options.
3
Select a slide show eect option.
•
Skip to step 4 to start a slide show with no eects.
* Default
Option Description
Play Mode
Set whether or not to repeat the slide show.
(One Play*, Repeat)
Interval
Set the interval between photos. (1 sec*, 3 sec, 5 sec,
10 sec)
Music
Set background audio.
Eect
• Set a scene change eect between photos.
• Select O to cancel eects.
Viewing photos
125
Playback/Editing > Viewing photos
4
Press [m].
5
Select Start Slide Show.
6
View the slide show.
•
Press [o] to pause.
•
Press [o] again to resume.
•
Press [m] to stop the slide show and return to Playback mode.
•
Press [D/I] to adjust the volume level.
Viewing the overexposure guide
Set the overexposed areas of a photo to blink.
To view the
overexposure guide,
In Playback mode, press [m]
ĺ
z
ĺ
Overexposure
Guide
ĺ
an option.
Viewing interval shots
View photos that are captured with the Interval Capture function.
To view interval
shots,
In Playback mode, press [m]
ĺ
z
ĺ
Play Interval
Shots.
Auto rotating
With Auto Rotate on, the camera automatically rotates photos you have
captured vertically so they t the screen horizontally.
To set auto rotate
options,
In Playback mode, press [m]
ĺ
z
ĺ
Auto Rotate
ĺ
an option.
126
Playback/Editing
In Playback mode, you can play a video, capture an image from a video, or
crop a video to save as another le.
Stop
Capture
Icon Description
/
View previous le/Scan backward. (Each time you touch the icon
while playing the video, you change the scan speed in this order:
2X, 4X, 8X.)
/
Pause or resume playback.
/
View next le/Scan forward. (Each time you touch the icon while
playing the video, you change the scan speed in this order: 2X,
4X, 8X.)
Adjust the volume or mute the sound.
Scanning backward or forward
To scan backwards or forwards through a video le while it is playing, use
one of the following methods.
•
Touch / . Each time you touch the icon, you change the scan speed
in this order: 2X, 4X, 8X.
•
Press [C/F]. Each time you press the button, you change the scan
speed in this order: 2X, 4X, 8X.
•
Scroll the command dial to the left or right. Each time you scroll the
command dial, you change the scan speed in this order: 2X, 4X, 8X.
•
Drag the handles that appear on the progress bar to the left or right. You
can change the playback position in the video.
Playing videos
127
Playback/Editing > Playing videos
Adjusting the brightness of a video
Adjust the brightness of a video while playing it.
To adjust the
brightness of a
video,
Touch the left half of the display
ĺ
drag upward or downward.
Stop
Capture
Adjusting the volume of a video
Adjust the volume of a video while playing it.
To adjust the
volume of a video,
Touch the right half of the display
ĺ
drag upward or
downward.
Stop
Capture
You can also touch and drag the slider on the volume control bar upward or
downward.
128
Playback/Editing > Playing videos
•
You cannot trim a video recorded in 3D mode.
•
The original video should be at least 10 seconds long.
•
The camera will save the edited video as a new le and leave the original
video intact.
Capturing an image during playback
1
While viewing a video, press [o] or touch at the point
where you want to capture an image.
2
Press [f] or touch Capture.
•
You cannot capture an image from a video recorded in 3D mode.
•
The resolution of the captured image will be the same as the original video.
•
The captured image is saved as a new le.
Trimming a video during playback
1
In Playback mode, scroll to a video, and then press [m].
2
Select Trim Movie.
3
Press [o] or touch to start playing the video.
4
Press [o] or touch at the point where you want the
trimming to begin.
5
Press [f] or touch Start Point.
6
Press [o] or touch to resume playing the video.
7
Press [o] or touch at the point where you want the
trimming to end.
8
Press [f] or touch End Point.
9
Press [f] or touch Trim to trim a video.
•
You can adjust the scene to be cropped by dragging the handles
that appear on the progress bar.
10
When the pop-up message appears, select Ye s .
129
Playback/Editing
Edited photos are saved as new les under dierent le names. Photos
captured in some modes cannot be edited with the Image Edit function.
To edit images,
In Playback mode, scroll to a photo, and then press [f]
ĺ
an option.
You can also edit images in Playback mode by selecting a photo, and then
pressing [m]
ĺ
z
ĺ
Edit Image.
Some images may not be edited with the Image Edit function. In this case, use
the supplied image editing software.
The camera will save edited photos as new les.
When you edit photos, the camera will automatically convert them to a lower
resolution. Photos that you rotate or resize manually are not automatically
converted to a lower resolution.
You cannot edit photos while viewing les as a folder. Open the folder and
select a photo to edit each photo.
Cropping a photo
1
Touch
ĺ
.
2
Drag the sides of the box to adjust the size of the area.
3
Drag the box to move the location of the area.
4
Press [f] or touch Done.
5
Touch to save.
Editing photos
130
Playback/Editing > Editing photos
Rotating a photo
1
Touch
ĺ
.
2
Touch an option.
Rotate : Right 90˚
Cancel Done
3
Press [f] or touch Done.
4
Touch to save.
•
You can also rotate a photo in Playback mode by pressing [m], and then
selecting z
ĺ
Rotate
ĺ
a desired option.
•
The camera will overwrite the original le.
Resizing photos
Change the size of a photo and save it as a new le.
1
Touch
ĺ
.
2
Touch an option.
Resize : 10.1M 3:2
Cancel Done
3
Press [f] or touch Done.
4
Touch to save.
Available resize options dier depending on the original size of the photo.
131
Playback/Editing > Editing photos
Adjusting your photos
You can correct captured photos by adjusting the brightness, contrast, or
color.
1
Touch .
2
Touch an adjusting option.
•
If you selected (Auto adjustment), skip to step 4.
Icon Description
Original (Reset to the original image.)
Auto adjustment
Brightness
Contrast
Saturation
RGB adjustment
Color Temperature
Exposure
Hue
3
Scroll the command dial or rotate the navigation button or
press [C/F] to adjust the option.
•
You can also drag the slider or touch +/- to adjust the option.
4
Press [f] or touch Done.
5
Touch to save.
132
Playback/Editing > Editing photos
Retouching faces
1
Touch
ĺ
.
2
Scroll the command dial or rotate the navigation button or
press [C/F] to adjust the option.
You can also drag the slider or touch +/- to adjust the option.
As the number increases, the skin tone becomes brighter and
smoother.
3
Press [f] or touch Done.
To cancel correction, touch .
4
Touch to save.
133
Playback/Editing > Editing photos
Applying Smart Filter eects
Apply special eects to your photos.
1
Touch , and then touch an option.
Smart Filter : Vignetting
Cancel Done
Option Description
Original
No eect
Vignetting
Apply the retro-looking colors, high contrast,
and strong vignette eect of Lomo cameras.
Miniature
Apply a tilt-shift eect to make the subject
appear in miniature.
Colored Pencil
Apply a colored pencil painting eect.
Watercolor
Apply a watercolor painting eect.
Wash drawing
Apply a washed-out eect.
Option Description
Oil Painting
Apply an oil painting eect.
Ink Painting
Apply an ink painting eect.
Acryl
Apply an acryl painting eect.
Negative
Apply a negative lm eect.
Red
Desaturate all colors but red.
Green
Desaturate all colors but green.
Blue
Desaturate all colors but blue.
Yellow
Desaturate all colors but yellow.
2
Press [f] or touch Done.
3
Touch to save.
Chapter 4
Wireless network
Learn how to connect to wireless local area networks (WLANs) and use functions.
135
Wireless network
Connecting to a WLAN and configuring network settings
Learn to connect via an access point (AP) when you are in a range of a
WLAN. You can also congure network settings.
Connecting to a WLAN
1
Rotate the mode dial to B.
2
Select , , , , or .
3
Follow the on-screen instructions until the Wi-Fi Setting screen
appears.
•
In some modes, press [f], and then select Wi-Fi Setting.
•
The camera automatically searches for available AP devices.
4
Select an AP.
Samsung1
Samsung2
Samsung3
Samsung4
Wi-Fi Setting
Refresh
•
Select Refresh to refresh the list of connectable APs.
•
Select Add wireless network to add an AP manually. The AP name
must be in English to add the AP manually.
Icon Description
Ad hoc AP
Secured AP
WPS AP
Signal strength
Press [F] or touch to open network setting options.
•
When you select a secured AP, a pop-up window appears. Enter the
required passwords to connect to the WLAN. For information about
entering text, refer to "Entering text". (p. 139)
•
When a login page appears, refer to "Using the login browser".
(p. 137)
•
When you select an unsecured AP, the camera will connect to the
WLAN.
•
If you select a WPS prole supported AP, select
ĺ
WPS PIN
connection, and then enter a PIN on the AP device. You can also
connect to a WPS prole supported AP by selecting
ĺ
WPS
button connection on the camera, and then pushing the WPS
button on the AP device.
•
The same AP may be listed twice, with dierent frequencies,
because your camera supports the dual band function.
•
If a pop-up message about data collection regulations appears,
read and agree to it.
136
Wireless network > Connecting to a WLAN and conguring network settings
Setting network options
1
In the Wi-Fi Setting screen, move to an AP, and then press
[F] or touch
.
2
Select each option, and then enter the required information.
Option Description
Network Password
Enter the network password.
IP Setting
Set the IP address automatically or manually.
Manually setting the IP address
1
In the Wi-Fi Setting screen, move to an AP, and then press
[F] or touch
.
2
Select IP Setting
ĺ
Manual.
3
Select each option, and then enter the required information.
Option Description
IP
Enter the static IP address.
Subnet Mask
Enter the subnet mask.
Gateway
Enter the gateway.
DNS Server
Enter the DNS address.
137
Wireless network > Connecting to a WLAN and conguring network settings
Using the login browser
You can enter your login information via the login browser when
connecting to some APs, sharing services, or cloud servers.
Icon Description
Close the login browser.
Move to the previous page.
Move to the next page.
Stop loading the page.
Reload the page.
•
You may not be able to select some items depending on the page you
connected to. This does not indicate a malfunction.
•
The login browser may not close automatically after you log into some pages.
If this occurs, close the login browser by touching
, and then proceed
with the desired operation.
•
It may take longer to load the login page due to the page size or network
speed. If this occurs, wait until the login information input window appears.
138
Wireless network > Connecting to a WLAN and conguring network settings
Network connection tips
•
You must insert a memory card to use the Wi-Fi features.
•
The quality of the network connection will be determined by the AP.
•
The further the distance between your camera and the AP, the longer it
will take to connect to the network.
•
If a nearby device is using the same radio frequency signal as your
camera, it may interrupt your connection.
•
If your AP name is not in English, the camera may not be able to locate
the device or the name may appear incorrectly.
•
For network settings or a password, contact your network administrator
or network service provider.
•
If a WLAN requires authentication from the service provider, you may not
be able to connect to it. To connect to the WLAN, contact your network
service provider.
•
Depending on the encryption type, the number of digits in the password
may dier.
•
A WLAN connection may not be possible in all surroundings.
•
The camera may display a WLAN enabled printer on the AP List. You
cannot connect to a network via a printer.
•
You cannot connect your camera to a network and a TV simultaneously.
•
Connecting to a network may incur additional charges. Costs will vary
based on the conditions of your contract.
•
If you cannot connect to a WLAN, try another AP from the available AP
list.
•
A login page may appear when you select free WLANs provided by some
network service providers. Enter your ID and password to connect to
the WLAN. For information about registering or the service, contact the
network service providers.
•
Be cautious when you enter personal information for an AP connection.
Do not enter any payment or credit card information on your camera.
The manufacturer is not liable for any problem caused by entering such
information.
•
Available network connections may dier by country.
•
The WLAN feature of your camera must comply with radio transmission
laws in your region. To ensure compliance, use the WLAN feature only in
the country where you purchased the camera.
•
The process for adjusting network settings may dier, depending on
network conditions.
•
Do not access a network that you are not authorized to use.
•
Before you connect to a network, ensure your battery is fully charged.
•
You cannot upload or send les captured in some modes.
•
Files that you transfer to another device may not be supported by the
device. In this case, use a computer to play back the les.
139
Wireless network > Connecting to a WLAN and conguring network settings
Entering text
Learn how to enter text. The icons in the table let you move the cursor,
change the case, etc. Touch a key to enter it.
Icon Description
Move the cursor.
Stop entering text and return to the previous page.
Change case.
Switch between Symbol/Number mode and the normal mode.
Change the input language.
Enter a space.
Save the displayed text.
Delete the last letter.
•
You can use only the English alphabets in some modes, regardless of the
display language.
•
The number of characters you can enter varies depending on the situation.
•
The screen may dier depending on the input mode.
•
Touch and hold a key to enter the character at the upper right corner of the
key.
140
Wireless network
Using the NFC Feature (Tag & Go)
Using NFC features in Playback mode (Photo
Beam)
In Playback mode, the camera transfers the current le to the smart phone
automatically when you read a tag from an NFC-enabled device.
•
To transfer multiple les, select les from the thumbnail view, and then
read a tag from an NFC-enabled device.
Using NFC features in Wi-Fi mode
Select MobileLink or Remote Viewnder from the pop-up window that
appears by reading a tag from an NFC-enabled device. (p. 143, 147)
Place a smart phone's NFC antenna near the camera’s NFC tag to launch
the feature for saving photos to a smart phone automatically or the feature
for using a smart phone as a remote shutter. You can also transfer les to
an NFC-enabled device in Playback mode.
•
This feature is supported by NFC-enabled smart phones running Android OS.
It is recommended that you use the latest version. This feature is not available
for iOS devices.
•
You should install Samsung SMART CAMERA App on your phone or device
before using this feature. You can download the application from Samsung
Apps or the Google Play Store. Samsung SMART CAMERA App is compatible
with Samsung camera models manufactured in 2013 or later.
•
To read an NFC tag, place the NFC-enabled device near the camera’s NFC tag
for more than 2 seconds.
•
You can set the size for transferred photos by pressing [m], and then
selecting d
ĺ
MobileLink/NFC Image Size
ĺ
an option.
•
Do not modify the NFC tag in any way.
Using NFC features in Shooting mode
Launch AutoShare or Remote Viewnder by reading a tag from an NFC-
enabled device. (p. 141, 147) Preset to launch the Wi-Fi function by reading
a tag on an NFC-enabled device. (p. 169)
141
Wireless network
Saving files to a smart phone automatically
The camera connects to a smart phone that supports the AutoShare
feature via a WLAN. When you capture a photo with your camera, the
photo is saved to a smart phone automatically.
•
The AutoShare feature is supported by smart phones or tablets running
Android OS or iOS. (Some features may not be supported by some models.)
Before using this feature, update the device’s rmware to the latest version.
If the rmware version is not the most recent, this function may not perform
properly.
•
You should install Samsung SMART CAMERA App on your phone or device
before using this feature. You can download the application from Samsung
Apps, the Google Play Store, or the Apple App Store. Samsung SMART
CAMERA App is compatible with Samsung camera models manufactured in
2013 or later.
•
If you set this function, the setting is maintained even when you change the
Shooting mode.
•
This feature may not be supported in some modes or may not be available
with some shooting options.
1
In Shooting mode, touch
ĺ
.
•
You can also press [m]
ĺ
b
ĺ
AutoShare
ĺ
On.
•
If the pop-up message that prompts you to download the
application appears, select Next.
2
On the smart phone, turn on Samsung SMART CAMERA App.
•
For iOS devices, turn on the Wi-Fi feature before turning on the
application.
•
To start the application automatically on an NFC-enabled smart
phone, turn on the function and place the smart phone near
the NFC tag (p. 32) on the camera. Verify that the smart phone is
connected to your camera, and then skip to step 5.
3
Select the camera from the list and connect the smart phone
to the camera.
•
The smart phone can connect to only one camera at a time.
142
Wireless network > Saving les to a smart phone automatically
4
On the camera, allow the smart phone to connect to your
camera.
•
If the smart phone has been connected to your camera before, it is
connected automatically.
•
An icon that shows the connection status ( ) will appear on the
camera’s screen.
5
Capture a photo.
•
The captured photo is saved to the camera, and then transferred to
the smart phone. If a memory card is not inserted or the memory is
full, the captured photo is transferred to the smart phone without
being saved to the camera.
•
If you recorded a video, it is saved only to the camera.
•
The image le captured while recording a video is not saved on the
smart phone.
•
If the GPS feature is activated on the smart phone, the GPS
information will be saved with the captured photo.
143
Wireless network
The camera connects to a smart phone that supports the MobileLink
feature via a WLAN. You can easily send photos or videos to your smart
phone.
•
The MobileLink feature is supported by smart phones or tablets running
Android OS or iOS. (Some features may not be supported by some models.)
Before using this feature, update the device’s rmware to the latest version.
If the rmware version is not the most recent, this function may not perform
properly.
•
You should install Samsung SMART CAMERA App on your phone or device
before using this feature. You can download the application from Samsung
Apps, the Google Play Store, or the Apple App Store. Samsung SMART
CAMERA App is compatible with Samsung camera models manufactured in
2013 or later.
•
For devices running Android OS 2.3.3 – 2.3.7, download Samsung SMART
CAMERA App from www.samsung.com.
•
When there are no les in the camera memory, you cannot use this feature.
•
You can view up to 1,000 recent les and send up to 1,000 les at a time.
•
When you send Full HD videos using MobileLink feature, you may not be able
to play back les on some devices.
•
When using this feature on an iOS device, the device may lose its Wi-Fi
connection.
•
You cannot send RAW les.
•
You can set the size for transferred photos by pressing [m], and then
selecting d
ĺ
MobileLink/NFC Image Size
ĺ
an option.
•
You can also touch
ĺ
MobileLink on the screen in Shooting mode.
•
You can also send les in Playback mode by pressing [m], and then
selecting Share(Wi-Fi)
ĺ
MobileLink or by selecting
ĺ
MobileLink.
•
The screen turns o if you perform no operations on the camera for 30
seconds.
1
On the camera, rotate the mode dial to B.
2
On the camera, select .
•
If the pop-up message that prompts you to download the
application appears, select Next.
3
On the camera, select a sending option.
•
If you select Select Files from Smartphone, you can use your
smart phone to view and share les stored on the camera. The
screen turns o if you perform no operations on the smart phone
for 30 seconds.
•
If you select Select Files from Camera, you can select les to send
from the camera.
Sending photos or videos to a smart phone
144
Wireless network > Sending photos or videos to a smart phone
4
On the smart phone, turn on Samsung SMART CAMERA App.
•
For iOS devices, turn on the Wi-Fi feature before turning on the
application.
•
To start the application automatically on an NFC-enabled smart
phone, turn on the function and place the smart phone near
the NFC tag (p. 32) on the camera. Verify that the smart phone is
connected to your camera, and then skip to step 7.
5
Select the camera from the list and connect the smart phone
to the camera.
•
The smart phone can connect to only one camera at a time.
6
On the camera, allow the smart phone to connect to your
camera.
•
If the smart phone has been connected to your camera before, it is
connected automatically.
7
On the smart phone or camera, select les to transfer from the
camera.
8
On the smart phone, touch the copy button or on the camera,
select Send.
•
The camera will send the les to the smart phone.
145
Wireless network
The camera connects to a smart phone that supports the Group Share
feature via a WLAN. You can easily send photos or videos to multiple smart
phones.
•
The Group Share feature is supported by smart phones or tablets running
Android OS or iOS. (Some features may not be supported by some models.)
Before using this feature, update the device’s rmware to the latest version.
If the rmware version is not the most recent, this function may not perform
properly.
•
You should install Samsung SMART CAMERA App on your phone or device
before using this feature. You can download the application from Samsung
Apps, the Google Play Store, or the Apple App Store. Samsung SMART
CAMERA App is compatible with Samsung camera models manufactured in
2013 or later.
•
For devices running Android OS 2.3.3 – 2.3.7, download Samsung SMART
CAMERA App from www.samsung.com.
•
When there are no les in the camera memory, you cannot use this feature.
•
Transferring les to multiple smart phones may take longer than transferring
les to one device.
•
When you send Full HD videos using Group Share feature, you may not be
able to play back les on some devices.
•
When using this feature on an iOS device, the device may lose its Wi-Fi
connection.
•
You cannot send RAW les.
•
You can set the size for transferred photos by pressing [m], and then
selecting d
ĺ
MobileLink/NFC Image Size
ĺ
an option.
•
You can also send les in Playback mode by pressing [m], and then
selecting Share(Wi-Fi)
ĺ
Group Share or by selecting
ĺ
Group Share.
1
On the camera, rotate the mode dial to B.
2
On the camera, select .
•
If the pop-up message that prompts you to download the
application appears, select Next.
3
On the smart phone, turn on Samsung SMART CAMERA App.
•
For iOS devices, turn on the Wi-Fi feature before turning on the
application.
•
To start the application automatically on an NFC-enabled smart
phone, turn on the function and place the smart phone near
the NFC tag (p. 32) on the camera. Verify that the smart phone is
connected to your camera, and then skip to step 6.
Sending photos or videos to multiple smart phones
146
Wireless network > Sending photos or videos to multiple smart phones
4
Touch Connect next to the desired smart phone listed on the
camera.
•
If the smart phone has been connected to your camera before, it is
connected automatically.
•
You can connect to up to 4 smart phones.
5
Select Next.
6
On camera, select les to transfer from the camera.
7
On the camera, select Send.
•
The camera will send the les to the smart phone.
•
When you connect to multiple smart phones, the camera will send
the les to all devices at the same time.
147
Wireless network
The camera connects to a smart phone that supports the Remote
Viewnder feature via a WLAN. Use the smart phone as a remote shutter
release with the Remote Viewnder feature. The captured photo will
display on the smart phone.
•
The Remote Viewnder feature is supported by smart phones or tablets
running Android OS or iOS. (Some features may not be supported by some
models.) Before using this feature, update the device’s rmware to the latest
version. If the rmware version is not the most recent, this function may not
perform properly.
•
You should install Samsung SMART CAMERA App on your phone or device
before using this feature. You can download the application from Samsung
Apps, the Google Play Store, or the Apple App Store. Samsung SMART
CAMERA App is compatible with Samsung camera models manufactured in
2013 or later.
•
For devices running Android OS 2.3.3 – 2.3.7, download Samsung SMART
CAMERA App from www.samsung.com.
•
You can also touch
ĺ
Remote Viewnder on the screen in Shooting
mode.
•
This function is not available when you attach a 3D lens in 3D mode.
1
On the camera, rotate the mode dial to B.
2
On the camera, select .
•
If the pop-up message that prompts you to download the
application appears, select Next.
3
On the smart phone, turn on Samsung SMART CAMERA App.
•
For iOS devices, turn on the Wi-Fi feature before turning on the
application.
•
To start the application automatically on an NFC-enabled smart
phone, turn on the function and place the smart phone near
the NFC tag (p. 32) on the camera. Verify that the smart phone is
connected to your camera, and then skip to step 6.
4
Select the camera from the list and connect the smart phone
to the camera.
•
The smart phone can connect to only one camera at a time.
Using a smart phone as a remote shutter release
148
Wireless network > Using a smart phone as a remote shutter release
5
On the camera, allow the smart phone to connect to your
camera.
•
If the smart phone has been connected to your camera before, it is
connected automatically.
6
On the smart phone, select q to open the smart panel.
7
On the smart phone, set the shooting options.
•
While using this feature, some buttons are not available on your
camera.
•
The zoom button and the shutter button on your smart phone will
not function when using this feature.
•
Some shooting options are not supported.
•
Shooting options that you have set will remain on the camera after
the connection with the smart phone has ended.
8
Touch to return to the shooting screen.
9
On the smart phone, touch and hold to focus, and then
release it to capture the photo.
•
Touch to record a video and touch to stop a video.
•
If the GPS feature is activated on the smart phone, the GPS
information will be saved with the captured photo.
•
The focus is automatically set to Multi AF.
•
When you use this feature, the ideal distance between the camera and the
smart phone may vary, depending on your surroundings.
•
The smart phone must be within 7 m of the camera to use this feature.
•
It will take some time to capture the photo after you release on the smart
phone.
•
If the le save option is set to Smartphone + Camera, only photos will be
transferred to the smart phone. (Videos and RAW les will not be transferred.)
•
The Remote Viewnder function will deactivate when:
-
there is an incoming call on the smart phone
-
either the camera or the smart phone turns o
-
device loses its connection to the WLAN
-
the Wi-Fi connection is poor or unstable
-
you perform no operations for approximately 3 minutes while connected
-
folder and le number are max values
149
Wireless network
Using the Baby Monitor
3
On the camera, select an AP from the list, and then position
the camera.
•
Place the camera in a safe location where children or pets cannot
reach it.
•
Point the camera lens at the subject.
•
We recommend you connect the camera to a power outlet with the
AC adapter.
4
On the smart phone, select the AP that the camera is
connected to.
•
For iOS devices, turn on the Wi-Fi feature before turning on the
application.
5
On the smart phone, turn on the Samsung Home Monitor
application.
Use the Baby Monitor feature to connect the camera to a smart phone on
which the Samsung Home Monitor is installed, and monitor a location.
•
The Baby Monitor feature is supported by smart phones that support WVGA
(800X480) or higher resolution and run the Android OS or iOS. (Some features
may not be supported by some models.) Before using this feature, update the
device’s rmware to the latest version. If the rmware version is not the most
recent, this function may not perform properly.
•
You should install the Samsung Home Monitor application on your smart
phone before using this feature. You can download the application from
Samsung Apps, the Google Play Store, or the Apple App Store.
•
Use this feature indoors only.
1
On the camera, rotate the mode dial to B.
2
On the camera, select .
•
If the pop-up message that prompts you to download the
application appears, select Next.
150
Wireless network > Using the Baby Monitor
6
Start live video or sound monitoring.
•
Watch live video from the camera on your smart phone. During
video monitoring, touch the Sound Monitoring Mode button on
the smart phone to stop the video stream. If the camera detects
noise, an alarm will notify you on the smart phone.
•
During live video monitoring via the smart phone, video is not saved on
the camera.
•
If the monitored location is dark, touch to turn on the AF-assist light.
•
During sound monitoring, alarms will sound on the smart phone if the
camera detects noise for a short period at a volume that is higher than
the designated level.
•
During live video monitoring, alarms will not sound on the smart phone
even if the camera detects noise.
7
Touch to exit the Samsung Home Monitor application.
Adjusting the noise level for alarm
activation
You can set the level of noise that will activate an alarm while using sound
monitoring. Press [D/I] to adjust the noise level.
Noise level for alarm
activation:
When the camera
detects noise that
exceeds the designated
level for a short period,
an alarm will sound.
Do not use this feature for illegal purposes.
Exit Wi-Fi Setting
151
Wireless network
Using Auto Backup to send photos or videos
You can send photos or videos that you captured with the camera to a PC
wirelessly.
Installing the program for Auto Backup on
your PC
1
Install i-Launcher on the PC. (p. 181)
2
Connect the camera to the PC with the USB cable.
3
When the Auto Backup program icon appears, click it.
The Auto Backup program is installed on the PC. Follow the on-
screen instructions to complete the installation.
4
Remove the USB cable.
Before installing the program, ensure that the PC is connected to a network.
Sending photos or videos to a PC
1
Rotate the mode dial to B.
2
Select .
If the pop-up message that prompts you to download the
application appears, select Ye s .
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 135)
3
Select a backup PC.
152
Wireless network > Using Auto Backup to send photos or videos
4
Select OK.
•
To cancel sending, select Cancel.
•
You cannot select individual les to backup. This function backs up
only new les on the camera.
•
The backup's progress will be shown on the PC monitor.
•
When the transfer is completed, the camera will turn o
automatically in approximately 30 seconds. Select Cancel to return
to the previous screen and prevent the camera from turning o
automatically.
•
To turn o your PC automatically after the transfer is complete,
select Shut down PC after backup.
•
To change the backup PC, select Change PC.
•
When you connect the camera to the WLAN, select the AP that is connected
to the PC.
•
The camera will search for available access points even if you are connecting
to the same access point again.
•
If you turn o the camera or remove the battery while sending les, the le
transfer will be interrupted.
•
While you are using this feature, the shutter control is disabled on your
camera.
•
You can connect only one camera to the PC at a time for sending les.
•
The backup may be canceled due to network conditions.
•
When there are no les in the camera memory, you cannot use this feature.
•
You must turn o Windows Firewall and any other rewalls before using this
feature.
•
You can send up to 1,000 recent les.
•
On the PC software, the server name must be entered in the Latin alphabet
and can contain no more than 48 characters.
•
When multiple le types are created at once, only the image les (JPG) will be
sent to the PC with this feature.
153
Wireless network
5
Select the Name box, enter your name, and then touch .
Sender Setting
Name
Save
Email
Reset
6
Select the Email box, enter your email address, and then
touch
.
7
Select Save to save your changes.
•
To delete your information, select Reset.
You can change settings in the email menu and send photos or videos
stored on the camera via email.
Changing email settings
In the email menu, you can change settings for storing your information.
You can also set or change the email password. For information about
entering text, refer to "Entering text". (p. 139)
Storing your information
1
Rotate the mode dial to B.
2
Select .
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 135)
3
Press [f].
4
Select Sender Setting.
Sending photos or videos via email
154
Wireless network > Sending photos or videos via email
Setting an email password
1
Rotate the mode dial to B.
2
Select .
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 135)
3
Press [f].
4
Select Setting Password
ĺ
On.
•
To deactivate the password, select O.
5
When the pop-up appears, select OK.
6
Enter a 4-digit password.
7
Enter the password again.
8
When the pop-up appears, select OK.
If you lost your password, you can reset it by selecting Reset on the password
setting screen. When you reset the information, the previously saved user’s
setting information and email address will be deleted.
155
Wireless network > Sending photos or videos via email
Changing the email password
1
Rotate the mode dial to B.
2
Select .
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 135)
3
Press [f].
4
Select Change Password.
5
Enter your current 4-digit password.
6
Enter a new 4-digit password.
7
Enter the new password again.
8
When the pop-up appears, select OK.
Sending photos or videos via email
You can send photos or videos stored on the camera via email. For
information about entering text, refer to "Entering text". (p. 139)
1
Rotate the mode dial to B.
2
Select .
3
Connect to a WLAN. (p. 135)
4
Select the Sender box, enter your email address, and then
touch
.
•
If you have previously saved your information, it will be inserted
automatically. (p. 153)
•
To use an address from the list of previous senders, select
ĺ
an address.
156
Wireless network > Sending photos or videos via email
5
Select the Receiver box, enter an email address, and then
touch
.
•
To use an address from the list of previous recipients, select
ĺ
an address.
•
Select to add additional recipients. You can input up to
30 recipients.
•
Select to delete an address from the list.
6
Select Next.
7
Select les to send.
•
You can select up to 20 les. The total size must be 7 MB or less.
8
Select Next.
9
Select the comment box, enter your comments, and then
touch
.
10
Select Send.
•
The camera will send the email.
•
If an email fails to send, a message prompting you to send it again
appears.
•
Even if a photo appears to have transferred successfully, errors with the
recipient’s email account may cause the photo to be rejected or recognized
as spam.
•
You may not be able to send an email if no network connection is available or
if your email account settings are incorrect.
•
You cannot send an email if the combined le sizes exceed the 7 MB. The
maximum resolution of photos you can send is 2M. The maximum resolution
of videos you can send is
. If the selected photo has a resolution higher
than 2M, it will be automatically resized to a lower resolution.
•
If you cannot send an email because of rewall or user authentication
settings, contact your network administrator or network service provider.
•
When there are no les in the camera memory, you cannot use this feature.
•
You can also send an email in Playback mode by pressing [m], and then
selecting Share(Wi-Fi)
ĺ
Email or by selecting
ĺ
Email.
157
Wireless network
Upload your photos or videos to le sharing services. Available sharing
services will be displayed on your camera. To upload les to some sharing
services, you must visit the website and register before connecting your
camera.
Accessing a sharing service
1
Rotate the mode dial to B.
2
Select .
3
Connect to a WLAN. (p. 135)
4
Select a sharing service.
•
If the pop-up message that prompts you to create an account
appears, select OK.
5
Enter your ID and password to log in.
•
For information about entering text, refer to "Entering text".
(p. 139)
•
If you connected to some sharing services, refer to "Using the login
browser". (p. 137)
•
To select an ID from the list, select
ĺ
an ID.
•
If you have previously logged in to the sharing service, you may be
logged in automatically.
You must have an existing account on the le sharing service to use this feature.
Using photo or video sharing services
158
Wireless network > Using photo or video sharing services
Uploading photos or videos
1
Access the sharing service with your camera.
2
Select les to upload.
•
You can select up to 20 les. The total size must be 10 MB or less.
(On some sharing services, the total size or number of les may
vary.)
3
Select Upload.
•
The camera will upload photos or videos.
•
When an upload fails, a message prompting you to upload it again
appears.
•
On some sharing services, you can enter your comments by
selecting the comment box. For information about entering text,
refer to "Entering text". (p. 139)
•
You can set an upload folder for Facebook by pressing [f], and then
selecting Upload Folder (Facebook) on the sharing service's list screen.
•
You cannot upload les if the le size exceeds the limit. The maximum
resolution of photos you can upload is 2M. The maximum resolution of videos
you can upload is
. If the selected photo has a resolution higher than 2M, it
will be automatically resized to a lower resolution. (On some sharing services,
the maximum photo resolution may vary.)
•
The method of uploading photos or videos may dier depending on the
selected sharing service.
•
If you cannot access a sharing service because of rewall or user
authentication settings, contact your network administrator or network
service provider.
•
Uploaded photos or videos may be automatically titled with the date they
were captured.
•
The speed of your internet connection may aect how quickly photos upload
or web pages open.
•
When there are no les in the camera memory, you cannot use this feature.
•
You can also upload photos or videos to le sharing services in Playback
mode by pressing [m], and then selecting Share(Wi-Fi)
ĺ
a sharing
service or by selecting
ĺ
a sharing service.
•
You cannot upload videos to some sharing services.
•
When you upload photos to a le sharing service, the photo may be resized
to 2M or 1M depending on their policy.
159
Wireless network
Using Samsung Link to send files
You can upload les from your camera to the Samsung Link online storage
or to registered devices, or view les on a Samsung Link device connected
to the same AP.
Uploading photos to an online storage or
registered devices
1
Rotate the mode dial to B.
2
Select
ĺ
Web storage.
•
If the guide message appears, select OK.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 135)
•
To change the size for uploaded photos, press [f], and then select
Upload Image Size.
3
Enter your ID and password, and then select Login
ĺ
OK.
•
For information about entering text, refer to "Entering text". (p. 139)
•
To select an ID from the list, select
ĺ
an ID.
•
If you have previously logged in to the website, you may be logged
in automatically.
To use this feature, you must create a Samsung Link account and an
account with an aliated online storage service using your PC. After you
have nished creating the accounts, add your online storage account to
Samsung Link.
4
Select an online storage service or a registered device.
•
To refresh the list of online storage or registered devices, touch .
•
Devices that are not currently connected to the network will not
appear on the list.
•
Before you use this feature, you must visit the Samsung Link
website with your PC and register an online storage or device.
5
Select les to upload, and then select Upload.
•
You cannot upload video les to Samsung Link online storage.
•
When there are no les in the camera memory, you cannot use this feature.
•
You can upload up to 20 les.
•
You can also upload photos in Playback mode by pressing [m], and then
selecting Share(Wi-Fi)
ĺ
Samsung Link or by selecting
ĺ
Samsung
Link.
160
Wireless network > Using Samsung Link to send les
Viewing photos or videos on devices that
support Samsung Link
1
Rotate the mode dial to B.
2
Select
ĺ
Nearby devices.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 135)
•
You can set to allow only selected devices or all devices to connect
by pressing [f], and then selecting DLNA Access Control on the
screen.
•
A sharing le list is created. Wait until other devices can nd your
camera.
3
Connect the Samsung Link device to a network, and then turn
on the Samsung Link feature.
•
Refer to your device's user manual for more information.
4
On the camera, allow the Samsung Link device to connect to
your camera.
5
On the Samsung Link device, select a camera to connect to.
6
On the Samsung Link device, browse the shared photos or
videos.
•
For information about searching for the camera and browsing the
photos or videos on the Samsung Link device, refer to the device's
user manual.
•
Videos may not play smoothly depending on the type of Samsung
Link device or the network condition. For smooth playback, use a
5 GHz dual-band AP device.
AP
S
The camera is connected to a TV that supports Samsung Link via WLAN.
161
Wireless network > Using Samsung Link to send les
•
You can share up to 1,000 recent les.
•
On a Samsung Link device, you can view only photos or videos captured with
your camera.
•
The range of the wireless connection between your camera and a Samsung
Link device may vary depending on the specications of the AP.
•
If the camera is connected to 2 Samsung Link devices, playback may be
slower.
•
Photos or videos will be shared in their original sizes.
•
You can use this feature only with devices that support Samsung Link.
•
Shared photos or videos will not be stored on the Samsung Link device, but
they can be stored in the camera to meet the device's specications.
•
Transferring photos or videos to the Samsung Link device may take some
time depending on the network connection, the number of les to be shared,
or the sizes of the les.
•
If you power o the camera abnormally while viewing photos or videos on
a Samsung Link device (for example, by removing the battery), the device
considers the camera to still be connected.
•
The order of photos or videos on the camera may be dierent than on the
Samsung Link device.
•
Depending on the number of photos or videos you want to share, it may
take some time to load your photos or videos and complete the initial set-up
process.
•
While viewing photos or videos on the Samsung Link device, continuously
using the device's remote or performing additional operations on the device
may prevent this feature from working properly.
•
If you reorder or sort les on the camera while viewing them on a Samsung
Link device, you must repeat the initial set-up process to update the list of
les on the device.
•
When there are no les in the camera memory, you cannot use this feature.
•
We recommend you use a network cable to connect your Samsung
Link device to your AP. This will minimize any video ‘Stuttering’ you may
experience when streaming content.
•
To view les on a Samsung Link device using the Nearby devices feature,
enable multicast mode on your AP.
•
1920X1080 (60 fps) videos can be played only on Full HDTVs capable of
playback at 60 fps.
•
You can view 3D les only on 3D-compatible TVs or monitors.
Chapter 5
Camera settings menu
Learn about the user settings and general settings menu.
You can adjust the settings to better suit your needs and preferences.
163
Camera settings menu
You can set the user environment with these settings.
To set user options,
In Shooting mode, press [m]
ĺ
d
ĺ
an option.
Available items and the order of them may dier depending on shooting
conditions.
Manage Custom Mode
Create your own shooting modes by adjusting options and saving them.
Open saved custom modes or delete them.
ISO Customizing
ISO Step
You can set the size for the ISO sensitivity by either 1/3 or 1 step.
Auto ISO Range
You can set the maximum ISO value under which each EV step is chosen
when you set the ISO to Auto.
* Default
Option Value
1/3 Step
ISO 125, ISO 160, ISO 200, ISO 250, ISO 320, ISO 400,
ISO 500, ISO 640, ISO 800, ISO 1000, ISO 1250, ISO 1600,
ISO 2000, ISO 2500, ISO 3200*
1 Step
ISO 200, ISO 400, ISO 800, ISO 1600, ISO 3200*
Noise Reduction
Use the Noise Reduction to reduce the visual noise in photos.
* Default
Option Description
High ISO NR
This function reduces noise that may occur when you
set a high ISO sensitivity. (O, High, Normal*, Low)
Long Term NR
This function reduces noise when you set the camera
for a long exposure. (O, On*)
User settings
164
Camera settings menu > User settings
Bracket Settings
You can set up the options for each bracketing.
* Default
Option Description
AE Bracketing
Settings
Set the exposure interval. Use the command dial or
the navigation button to select an option. You can
also drag the slider or touch the arrows. (-/+0.3 EV*,
-/+0.7 EV, -/+1.0 EV, -/+1.3 EV, -/+1.7 EV,
-/+2.0 EV, -/+2.3 EV, -/+2.7 EV, -/+3.0 EV)
WB Bracketing
Settings
Adjust the White Balance interval range of the
3 bracketed photos. Use the command dial or the
navigation button to select an option. You can also
touch the left/right arrows to adjust the Amber/Blue
values or touch the up/down arrows to adjust the
Magenta/Green values. (AB-/+3*, AB-/+2, AB-/+1,
MG-/+3, MG-/+2, MG-/+1)
For example, AB-/+3 adjusts the Amber value plus
or minus three steps. MG-/+3 adjusts the Magenta
value the same amount.
P Wiz Bracket Set
Select 3 Picture Wizard settings the camera uses to
capture the 3 bracketed photos.
Depth Bracket Set
Set the depth interval. Use the command dial or
the navigation button to select an option. You can
also drag the slider or touch the arrows to select
an option. (-/+0.3, -/+0.7, -/+1.0*, -/+1.3, -/+1.7,
-/+2.0, -/+2.3, -/+2.7, -/+3.0)
DMF (Direct Manual Focus)
You can adjust the focus manually by rotating the focus ring after
achieving the focus by half-pressing [Shutter]. This feature may not be
available with some lenses.
DMF Responsiveness
Set the focus ring response when you use the DMF function. If you select
High, slight rotations of the focus ring are made to adjust the focus. If you
select Low, longer rotations of the focus ring focus are made to adjust the
focus. This feature is supported only when you attach a lens that has this
feature. (High, Medium*, Low)
165
Camera settings menu > User settings
Color Space
The color space option allows you to select methods for representing
colors. Digital imaging devices such as digital cameras, monitors, and
printers have their own methods for representing colors, which are called
color spaces.
* Default
Option Description
sRGB*
sRGB (Standard RGB) is an international specication
to dene the color space created by IEC (International
Electrotechnical Commission). It is widely used for
creating colors on PC monitors and is also the standard
color space for Exif. sRGB is recommended for regular
images and images you intend to publish on the
Internet.
Adobe RGB
Adobe RGB is used for commercial printing and has a
larger color range than sRGB. Its wider range of colors
helps you to easily edit photos on a computer. Note
that individual programs are generally compatible
with a limited number of color spaces.
Adobe RGB
sRGB
When the color space is set to Adobe RGB, photos will be saved as
"_SAMXXXX.JPG".
166
Camera settings menu > User settings
Distortion Correct
You can correct lens distortion that might occur from lenses.
This feature may not be available with some lenses.
Touch Operation
Set to enable touch operation in Shooting mode.
* Default
Option Description
O
Do not use touch operations in Shooting mode. (You can use
touch operations in other situations.)
On*
Use touch operations in Shooting mode.
iFn Setting
You can select options that can be adjusted when you press [i-Function]
on an i-Function lens.
Option Description
Mode
• iFn Standard: Adjust the shutter speed, aperture
value, and other options on the lens by pressing
[i-Function].
• iFn Plus: On an i-Function lens, press [i-Function]
and a button on the camera at the same time to
assign a function to that button.
iFn Standard
Select options that can be adjusted when you press
[i-Function].
iFn Plus
• Metering: Select an option that can be adjusted
when you press [i-Function] and [N] together.
• EV: Select an option that can be adjusted when you
press [i-Function] and [W] together.
• AEL: Select an option that can be adjusted when
you press [i-Function] and [a] together.
167
Camera settings menu > User settings
User Display
You can add or remove shooting information from the display.
1
2
3
No. Description
1
Icons
Set to display icons on the right in Shooting mode.
2
Date & Time
Set to display the date and time.
3
Histogram
Set the histogram on the display on or o.
About histogram
A histogram is a graph that shows the brightness distribution of a
photo. A histogram inclined to the left indicates a dark photo.
A histogram inclined to the right indicates a bright photo. The height
of the graph is related to color information. The graph gets higher if a
specic color is more common.
Insucient exposure Balanced exposure Excessive exposure
168
Camera settings menu > User settings
Key Mapping
You can change the function assigned to the Preview button, the Custom
button, the AEL button or the DIRECT LINK button.
* Default
Button Function
Preview
Set the Depth Preview button's function.
• Optical Preview*: Execute the Depth of Field
Preview function for the current aperture value.
(p. 24)
• One Touch WB (White Balance): Execute the Custom
White Balance function.
• One Touch RAW +: Save a le in the RAW+JPEG
format. To save a le in JPEG format, press the button
again.
Custom
Set the Custom button's function.
• Drive Settings*: Select a shooting method.
• AF Area: Select an auto focus area option directly.
• Reset: Reset some settings.
* Default
Button Function
AEL
Set the AEL button’s function. You can change the
function assigned to the button to focus lock or
exposure lock. The AEL and AFL functions save the
exposure value or focus area respectively when
a photo is captured. A function executed by half-
pressing [Shutter] varies according to the function
assigned to [a].
• AEL*: Execute the auto exposure lock function.
(Half-pressing [Shutter] executes the auto focus lock
function.)
• AEL Hold: Keep executing the auto exposure lock
function after shooting. (The exposure remains
locked even after you capture a photo.)
• AFL: Execute the auto focus lock function. (Half-
pressing [Shutter] executes the auto exposure lock
function.)
• AEL + AFL: Execute the auto exposure and focus
lock functions together. (Half-pressing [Shutter]
executes no function.)
DIRECT LINK
Set the DIRECT LINK button's function. (AutoShare,
MobileLink, Remote Viewnder, Baby Monitor,
Auto Backup, Email, SNS & Cloud, Samsung Link)
169
Camera settings menu > User settings
Display Select
Set how the camera display and viewnder function.
* Default
Option Description
Auto*
Set the proximity sensor to automatically select the
display or viewnder.
EVF Only
Set to use the viewnder.
Main Display
Set to use the display.
•
Wi-Fi functions, slideshow functions, and Manage Custom Mode, Edit Image
functions are not available when you use the viewnder.
•
The camera does not automatically select the display or viewnder when you
record or play videos. For example, if you start recording or playing a video
while seeing through the viewnder, the main display will not be available
during recording or playing back.
Grid Line
Select a guide to help you compose a scene.
(O*, 4 X 4, 3 X 3, Cross, Diagonal)
Live view NFC
In Shooting mode, turn on the NFC feature on an NFC-enabled smart
phone and place the smart phone's NFC antenna near the camera’s NFC
tag to launch AutoShare or Remote Viewnder. This feature is supported
by NFC-enabled smart phones running Android OS. It is recommended
that you use the latest version. This feature is not available for iOS devices.
MobileLink/NFC Image Size
Set the size of photos to transfer to a smart phone using the MobileLink or
NFC functions.
* Default
Option Description
Resize to 2M or
lower
If a photo's size is larger than 3M, it will be transferred
after resizing it to 2M or lower.
Original*
The photo will be transferred in its original size.
170
Camera settings menu > User settings
AF Lamp
When shooting in dark places, turn the AF lamp on in order to have a
better auto focus. The Auto Focus functions more accurately in dark places
when the AF lamp is on.
E-Shutter
* Default
Option Description
O
Set to use the mechanical shutter. The fastest shutter speed is
limited to 1/6,000 s.
On*
Set to use the electronic shutter curtain rst and the
mechanical curtain second. It allows you to use fast shutter
speeds from 1/6,000 to 1/8,000 s.
•
This feature is available only when you attach a Samsung lens with Samsung
NX mount.
•
When you use a large diameter lens and a fast shutter speed, a "bokeh" eect
(an aesthetic blur in out-of-focus areas) may be aected by the subject and
the shooting conditions. To make the bokeh eect appear correctly, set the
E-Shutter to O.
•
When you change the E-Shutter settings, the rst curtain of the shutter is
adjusted and you will hear a noise as the shutter adjusts. This is a normal
situation when preparing the camera to operate the E-Shutter.
•
This feature is not available when you attach the external ash (SEF-580A).
Lens Button Speed Settings
Set the zoom speed for the Power Zoom lens' buttons at either fast,
medium, or slow speed. At fast speed, zoom noise increases and can be
recorded in videos. This function is available only when you attach the
Power Zoom lens.
171
Camera settings menu
Learn to congure your camera's settings.
To set Setting
options,
In Shooting or Playback mode, press [m]
ĺ
q
ĺ
an option.
* Default
Item Description
Sound
• System Volume: Set the sound volume or turn all sound
o entirely. (O, Low, Medium*, High)
Even if the system volume is turned o, the camera emits
the sound while playing a video or a slide show.
• AF Sound: Set the sound the camera emits when you
half-press the shutter button on or o. (O, On*)
• Button Sound: Set the sound the camera emits when
you press the buttons or touch the screen on or o.
(O, On*)
• E-Shutter Sound: Set to emit a sound when you use the
electronic shutter. (O*, On)
•
The camera emits a sound only when the shutter speed
is longer than 0.5 second.
•
This option may not be available in Smart mode.
Quick View
Set the Quick View time length–the amount of time the
camera displays a photo immediately after you capture it.
(O, 1 sec*, 3 sec, 5 sec, Hold)
* Default
Item Description
Display
Adjust
Adjust the display brightness, auto brightness setting,
display color, or level gauge.
• Display Brightness: You can adjust the display
brightness manually.
• Auto Brightness: Turn auto brightness on or o.
(O, On*)
• Display Color: You can adjust the display color manually.
• Horizontal Calibration: Calibrate the level gauge. If the
level gauge is not level, position the camera on the level
surface, and then follow the on-screen instructions.
•
You cannot access the Horizontal Calibration option
in Playback mode.
•
You cannot calibrate the level gauge in portrait
orientation.
Auto Display
O
Set the display o time. The display turns o if you do not
use the camera for the time you set.
(O, 30 sec*, 1 min, 3 min, 5 min, 10 min)
Setting
172
Camera settings menu > Setting
* Default
Item Description
Power Save
Set power shut o time. The camera shuts o if you do not
use it for the time you set. (30 sec, 1 min*, 3 min, 5 min,
10 min, 30 min)
•
The camera retains the power-o time setting even if
you replace the battery.
•
Power Save may not work if the camera is connected to
a computer or a TV or playing a slide show or a movie.
Help Guide
Display
• Mode Help Guide: Set to display help text about the
selected mode when changing shooting modes.
(O, On*)
• Function Help Guide: Set to display help text about
menus and functions. (O, On*)
Press [n] to hide the help text.
Quick Panel
Display
(Power On)
Set to view the notication panel when the camera turns
on. (O*, On)
Language
Set a language the camera shows on the display.
* Default
Item Description
Date and
Time
Set date, time, date format, time zone and whether to
imprint the date on photos. (Time Zone, Date Settings,
Time Settings, Date Type, Time Type, Imprint)
•
The date appears on the lower right side of the photo.
•
When you print a photo, some printers may not print
the date appropriately.
Video Out
Set the video signal output appropriate for your country
when connecting the camera to an external video device
such as a monitor or HDTV.
• NTSC: USA, Canada, Japan, Korea, Taiwan, Mexico, etc.
• PAL (Supports only PAL B, D, G, H, or I): Australia, Austria,
Belgium, China, Denmark, Finland, France, Germany,
England, Italy, Kuwait, Malaysia, New Zealand, Singapore,
Spain, Sweden, Switzerland, Thailand, Norway, etc.
Anynet+
(HDMI-CEC)
When you connect the camera to an HDTV that supports
Anynet+ (HDMI-CEC), you can control the play function of
the camera with the TV remote control.
• O: You cannot control the play function of camera with
the TV remote control.
• On*: You can control the play function of camera with the
TV remote control.
173
Camera settings menu > Setting
* Default
Item Description
HDMI Output
When you connect the camera to an HDTV with an HDMI
cable, you can change the resolution of the image.
• NTSC: Auto*, 1080p, 720p, 480p,
576p (activates only when PAL is selected)
If the connected HDTV does not support the resolution
you select, the camera sets the resolution one level lower.
3D HDMI
Output
Select an option for playing les on a 3D TV.
• Side by Side*: Displays two images next to each other.
• Frame Packing: Displays the images for the left and right
eye alternately in frames.
File Name
Set the method of creating le names.
• Standard*: SAM_XXXX.JPG (sRGB)/
• Date:
- sRGB les - MMDDXXXX.JPG. For example, for a photo
captured on Jan. 01, the le name would be
0101XXXX.jpg.
- Adobe RGB les - _MDDXXXX.JPG for the months Jan
through Sept. For the months Oct through Dec, the month
number is replaced by the letters A (Oct.), B (Nov.) and
C (Dec.).
For example, for a photo captured on Feb. 03, the le
name would be _203XXXX.jpg. For a photo captured on
Oct. 05, the le name would be _A05XXXX.jpg.
* Default
Item Description
File Number
Set the method of numbering les and folders.
• Reset: After using the reset function, the next le name is
started at 0001.
• Series*: New le numbers continue the existing number
sequence, even if you have installed a new memory card,
formatted the card, or deleted all photos.
•
The rst folder name is 100PHOTO, if you have selected
the sRGB color space and Standard le naming, the rst
le name is SAM_0001.
•
File name numbers are increased by 1 from SAM_0001 to
SAM_9999.
•
Folder numbers are increased by 1 from 100PHOTO to
999PHOTO.
•
The maximum number of les that can be saved in one
folder is 9,999.
•
File numbers are assigned according to DCF (Design rule
for Camera File system) specications.
•
If you change a le name (for example, on a computer),
the camera will not be able to play the le.
Folder Type
Set the type of folder.
• Standard*: XXXPHOTO
• Date: XXX_MMDD
174
Camera settings menu > Setting
* Default
Item Description
Format
Format the memory card. Formatting deletes all existing
les including protected les. (No*, Ye s )
Errors can occur if you use a memory card formatted by
another brand of camera, a memory card reader, or a
computer. Please format memory cards in the camera
before using them to capture photos.
Device
Information
View the rmware version of the body and the lens, Mac
address, and network certication number, or update the
rmware.
• Software Update: Update the rmware of the camera
body or lens. (Body Firmware, Lens Firmware)
•
You can update the rmware by connecting the camera
to the computer and starting i-Launcher. For more
details, refer to page 197.
•
You cannot run a rmware upgrade without a fully
charged battery. Recharge the battery fully before
running a rmware upgrade.
•
If you update the rmware, user settings and values will
be reset. (Date, time, language, and video out will not
change.)
•
Do not turn the camera o while the update is in
progress.
* Default
Item Description
Dual-band
Mobile AP
Set a frequency for using the camera as an AP for the
AutoShare, MobileLink, Remote Viewnder, or Baby Monitor
feature. (2.4 GHz*, 5 GHz)
If you use the camera in a country other than the one
where it was purchased, the 5 GHz Wi-Fi feature may not
function properly, due to dierences in radio frequencies.
In this case, use the 2.4 GHz Wi-Fi feature instead.
Sensor
Cleaning
• Sensor Cleaning: Remove dust from the sensor.
• Start-Up Action: When on, the camera performs sensor
cleaning each time you turn it on. (O*, On)
• Shut down Action: When on, the camera performs
sensor cleaning each time you turn it o. (O*, On)
As this product uses interchangeable lenses, the sensor
can get dust on it when you change lenses. This can lead
to dust particles appearing in the photos you capture. It
is recommended not to change lenses when you are in a
particularly dusty area. Also, make sure to attach the lens
cap to the lens when not using it.
Reset
Reset the setup menu and shooting options to the factory
defaults. (Date, time, language, and video output settings
do not change.) (No*, Ye s )
Open Source
License
View open source licenses.
Chapter 6
Connecting to external devices
Make full use of the camera by connecting it to external devices such as a computer, HDTV, or 3D TV.
176
Connecting to external devices
Play back photos or videos by connecting your camera to an HDTV (3D TV)
using an optional HDMI cable.
Viewing les on an HDTV
1
In Shooting or Playback mode, press [m]
ĺ
q
ĺ
HDMI Output
ĺ
an option. (p. 173)
2
Turn o your camera and HDTV.
3
Connect your camera to your HDTV with the optional HDMI
cable.
4
Turn on your HDTV, and then select the HDMI video source.
5
Turn on the camera.
6
View photos or play videos using the camera buttons.
•
When using the HDMI cable, you can connect the camera to an HDTV using
the Anynet+(CEC) method.
•
The Anynet+(CEC) functions allow you to control connected devices using the
TV remote control.
•
If the HDTV supports Anynet+(CEC), the TV turns on automatically when used
in conjunction with the camera. This feature may not be available on some
HDTVs.
•
You can capture a photo or video when the camera is connected to an HDTV,
but some functions are limited. Shooting functions are supported only when
HDMI Output is set to 1080p or Auto on the camera and the TV's HDMI
output option is set to 1080p.
•
When connected to an HDTV, some of the camera’s playback functions may
not be available.
•
The length of time after which the camera and an HDTV are connected may
vary depending on the memory card that you are using. As the main feature
of a memory card is to increase the transfer speed, it is not necessarily true
to say that a memory card with a faster transfer speed is also fast in using the
HDMI function.
•
1920X1080 (60 fps) videos can be played only on Full HDTVs capable of
playback at 60 fps.
•
To view 3D photos on a TV that does not support the 3D function, press the
ź
button and switch to Anaglyph mode.
•
You can also play back or capture photos or videos when connected to an
HDMI-enabled monitor. Connections may vary depending on the monitor.
Refer to the monitor’s manual for more details.
Viewing files on an HDTV or 3D TV
177
Connecting to external devices > Viewing les on an HDTV or 3D TV
Viewing les on a 3D TV
You can view photos or videos captured in 3D mode or with the 3D
Panorama option in Smart mode on a 3D TV.
1
In Shooting or Playback mode, press [m]
ĺ
q
ĺ
HDMI Output
ĺ
an option. (p. 173)
2
Select 3D HDMI Output
ĺ
an option. (p. 173)
3
Turn o your camera and 3D TV.
4
Connect your camera to your 3D TV with the optional HDMI
cable.
5
Turn on your 3D TV, and then select the HDMI video source.
6
Turn on your camera.
7
Move to a 3D le, and then press [I] to switch to 3D mode.
•
Press [I] again to switch to 2D Mode.
8
Turn on your TV's 3D function.
•
Refer to your TV's user manual for more details.
9
View 3D photos or play 3D videos using the camera buttons.
•
You cannot view an MPO le in 3D eect on TVs that do not support the le
format.
•
Use proper 3D glasses when you view an MPO le or a 3D video le on a
3D TV.
•
Capturing photos in 3D Panorama mode may result in a less pronounced 3D
eect than those captured in 3D mode with a 3D lens.
Do not view the 3D photos or videos captured by your camera on a 3D TV or
3D monitor for an extended period of time. It may cause unpleasant symptoms,
such as eyestrain, fatigue, nausea, and more.
178
Connecting to external devices
Transfer les on a memory card to your computer by connecting the
camera to the PC.
Transferring les to your Windows OS
computer
Connecting the camera as a removable disk
You can connect the camera to your computer as a removable disk. Open
the removable disk and transfer les to your computer.
1
Turn o the camera.
2
Connect the camera to your computer with the USB cable.
•
You must plug the small end of the USB cable into your camera. If the
cable is reversed, it may damage your les. The manufacturer is not
responsible for any loss of data.
•
If you try to plug the USB cable into the HDMI port, the camera may not
work properly.
3
Turn on the camera.
•
The computer recognizes the camera automatically.
4
On your computer, select My Computer
ĺ
Removable Disk
ĺ
DCIM
ĺ
100PHOTO or 101_0101.
5
Select the les you want, and then drag or save them to your
computer.
If the Folder Type is set to Date, the folder name appears as "XXX_MMDD".
For example, if you capture a photo on January 1, the folder name will be
"101_0101".
Transferring files to your computer
179
Connecting to external devices > Transferring les to your computer
Disconnecting the camera (for Windows XP)
With Windows Vista, Windows 7, and Windows 8, the methods for
disconnecting the camera are similar.
1
Ensure that no data is being transferred between the camera
and the computer.
•
If the status lamp on your camera is blinking, it means the data
transfer is in progress. Please wait until the status lamp stops
blinking.
2
Click on the tool bar at the bottom right of your computer
screen.
3
Click the pop-up message.
4
Click the message box indicating safely removed.
5
Remove the USB cable.
Transferring les to your Mac OS
Mac OS 10.5 or later is supported.
1
Turn o the camera.
2
Connect your camera to a Macintosh computer with the USB
cable.
•
You must plug the small end of the USB cable into your camera. If the
cable is reversed, it may damage your les. The manufacturer is not
responsible for any loss of data.
•
If you try to plug the USB cable into the HDMI port, the camera may not
work properly.
180
Connecting to external devices > Transferring les to your computer
3
Turn on the camera.
•
The computer recognizes the camera automatically and displays a
removable disk icon.
4
On your computer, open the removable disk.
5
Transfer photos or videos to the Mac OS computer.
181
Connecting to external devices
You can view and edit les using the provided programs. You can also send
the les to a PC wirelessly.
Installing programs from the provided CD
1
Insert the installation CD into your PC.
2
Select a language.
3
Select a program to install.
4
Follow the on-screen instructions.
5
Click Exit to complete the installation.
Available programs when using i-Launcher
Item Description
Firmware Upgrade
You can download the rmware of your camera.
PC Auto Backup
i-Launcher provides a link for downloading the
PC Auto Backup program when you connect the
camera to a computer. You can send photos or
videos that you captured with the camera to a
PC wirelessly.
Using programs on a PC
182
Connecting to external devices > Using programs on a PC
Using i-Launcher
i-Launcher allows you update the rmware of the camera or the lens or
provides a link to download the PC Auto Backup program.
Requirements for Windows OS
Item Requirements
CPU
Intel
®
i5 3.3 GHz or higher/
AMD Phenom™ IIx4 3.2 GHz or higher
RAM
Minimum 512 MB RAM (1 GB or more recommended)
OS*
Windows 7, Windows 8
Hard disk
capacity
250 MB or more (1 GB and above recommended)
Others
• CD-ROM drive
• 1024X768 pixels, 16-bit color display compatible
monitor (1280X1024 pixels, 32-bit color display
recommended)
• USB 2.0 port
• nVIDIA Geforce 7600GT or higher/
ATI X1600 series or higher
* A 32-bit version of i-Launcher will be installed—even on 64-bit editions of Windows 7 and
Windows 8.
•
The requirements on the following page are recommendations only.
i-Launcher may not work properly even when the computer meets the
requirements, depending on the condition of your computer.
•
If your computer does not meet the requirements, videos may not play
correctly.
The manufacturer is not responsible for any damage that results from using
unqualied computers such as a computer you assembled yourself.
Requirements for Mac OS
Item Requirements
OS
Mac OS 10.5 or higher (except PowerPC)
RAM
Minimum 256 MB RAM (512 MB or more
recommended)
Hard disk capacity
Minimum 110 MB
Others
USB 2.0 port, CD-ROM drive
Opening i-Launcher
On your computer, select Start
ĺ
All Programs
ĺ
Samsung
ĺ
i-Launcher
ĺ
Samsung i-Launcher. Or, click Applications
ĺ
Samsung
ĺ
i-Launcher on your Mac OS computer.
183
Connecting to external devices > Using programs on a PC
Downloading the rmware
From the Samsung i-Launcher screen, click Firmware Upgrade. For
information about updating the rmware, refer to page 197.
Downloading the PC Auto Backup program
From the Samsung i-Launcher screen, click PC Auto Backup. For
information about installing the PC Auto Backup program, refer to page
151.
Installing Adobe Photoshop Lightroom
1
Insert Adobe Photoshop Lightroom DVD-ROM into your PC.
2
Select a language.
3
Follow the on-screen instructions.
Using Adobe Photoshop Lightroom
Photos captured by a camera are often transformed to JPEG formats and
stored in the memory according to the settings of the camera at the time
of shooting. RAW files are not transformed to JPEG formats and are stored
in the memory without any changes. With Adobe Photoshop Lightroom,
you can calibrate exposures, White Balances, tones, contrasts, and colors
of photos. You can also edit JPEG or TIFF les as well as RAW les. For more
information, refer to the program guide.
•
Depending on your version of Adobe Photoshop Lightroom, you may not
be able to open RAW les. In this case, update the program from the Adobe
website.
•
In Adobe Photoshop Lightroom, an image’s brightness, color and other eects
may be displayed dierently. This occurs because the original camera settings
and options applied during image capture are removed, ready for it to be
processed in Adobe Photoshop Lightroom.
Chapter 7
Appendix
Get information about error messages, camera maintenance,
trouble shooting tips, specications, and optional accessories.
185
Appendix
When the following error messages appear, try these remedies.
Error messages Suggested remedies
Lens is locked
The lens is locked. Rotate the lens counter-clockwise
until you hear a click. (p. 50)
Card Error
• Turn o the camera, and then turn it on again.
• Remove the memory card and insert it again.
• Format the memory card.
Low Battery
Insert a charged battery or recharge the battery.
No Image File
Capture photos or insert a memory card that contains
photos.
File Error
Delete the damaged le or contact a service center.
Memory Full
Delete unnecessary les or insert a new memory card.
Card Locked
You can lock SD, SDHC, or SDXC card to prevent les
from being deleted. Unlock the card when shooting.
(p. 189)
Error messages Suggested remedies
Folder and le
number are max
values. Replace
the card
File names do not match the DCF standard. Transfer
the les on the memory card to your computer and
format the card. (p. 174)
Error 00
Turn o your camera and remount the lens. If the
message still appears, contact a service center.
Error 01/02
Turn o your camera, remove the battery, and insert
again. If the message still appears, contact a service
center.
Error messages
186
Appendix
Cleaning the camera
Camera lens and display
Use a brush to remove dust and wipe the lens gently with a soft cloth.
If any dust remains, apply lens cleaning liquid to a piece of cleaning paper
and wipe gently.
Image sensor
Depending on dierent shooting conditions, dust may appear in photos
because the image sensor is exposed to the external environment. This
problem is normal, and the exposure to dust occurs in everyday use
of the camera. You can remove dust from the sensor by operating the
sensor cleaning function. (p. 174) If dust remains after cleaning the sensor,
contact a service center. Do not insert the blower into the mounting
opening of the lens.
Camera body
Wipe gently with a soft, dry cloth.
Never use benzene, thinners, or alcohol to clean the device. These solutions can
damage the camera or cause it to malfunction.
Maintaining the camera
187
Appendix > Maintaining the camera
Using on beaches or shores
•
Protect your camera from sand and dirt when you use it on beaches or in
other similar areas.
•
Your camera is not waterproof. Do not handle the battery, adapter, or
memory card with wet hands. Operating the camera with wet hands
may cause damage to your camera.
Storing for extended period of time
•
When you store the camera for an extended period, place it in a sealed
container with an absorbent material, such as silica gel.
•
Over time, unused batteries will discharge and must be recharged before
use.
•
The present date and time can be initialized when the camera is turned
on after the camera and battery have been separated for a prolonged
period.
Using or storing the camera
Inappropriate places to use or store the camera
•
Avoid exposing the camera to very cold or very hot temperatures.
•
Avoid using your camera in areas with extremely high humidity, or
where the humidity changes drastically.
•
Avoid exposing the camera to direct sunlight and storing it in hot, poorly
ventilated areas, such as in a car during summer time.
•
Protect your camera and the display from impact, rough handling, and
excessive vibration to avoid serious damage.
•
Avoid using or storing your camera in dusty, dirty, humid, or poorly
ventilated areas to prevent damage to moving parts and internal
components.
•
Do not use your camera near fuels, combustibles, or ammable
chemicals. Do not store or carry ammable liquids, gases, or explosive
materials in the same compartment as the camera or its accessories.
•
Do not store the camera where there are mothballs.
188
Appendix > Maintaining the camera
Using the camera with caution in humid environments
When you transfer the camera from a cold environment to a warm one,
condensation can form on the lens or internal components of the camera.
In this situation, turn o the camera and wait for at least 1 hour.
If condensation forms on the memory card, remove the memory card from
the camera and wait until all moisture has evaporated before reinserting it.
Other cautions
•
Do not swing your camera by the strap. This may cause injury to yourself
or others or damage to your camera.
•
Do not paint your camera, as paint can clog moving parts and prevent
proper operation.
•
Turn o the camera when not using it.
•
Your camera consists of delicate parts. Avoid impacts to the camera.
•
Protect the display from external force by keeping it in the case when
not in use. Protect the camera from scratches by keeping it away from
sand, sharp implements, or loose change.
•
Do not use the camera if the screen is cracked or broken. Broken glass or
acrylic could cause injury to your hands and face. Take the camera to a
Samsung service center to have it repaired.
•
Never place cameras, batteries, chargers, or accessories near, on, or in
heating devices, such as microwave ovens, stoves, or radiators. Heat can
deform or overheat these devices, which can cause a re or explosion.
•
Do not expose the lens to direct sunlight, as this may discolor the image
sensor or cause it to malfunction.
•
Protect your lens from ngerprints and scratches. Clean your lens with a
soft, clean, debris-free lens cloth.
•
The camera may turn o if impacted from the outside. This is to protect
the memory card. Turn on the camera to use it again.
•
While you use the camera, it may heat up. This is normal and should not
aect your camera’s lifespan or performance.
•
When you use the camera in low temperatures, it may take some time to
turn on, the color of the display may be changed temporarily, or after-
images may appear. These conditions are not malfunctions and they will
correct themselves when the camera is returned to milder temperatures.
•
Paint or metal on the outside of the camera may cause allergies,
itchy skin, eczema, or swelling for people with sensitive skin.
If you experience any of these symptoms, stop using the camera
immediately and consult a doctor.
•
Do not insert foreign objects into any of your camera’s compartments,
slots, or access points. Damage due to improper use may not be covered
by your warranty.
•
Do not allow unqualied personnel to service the camera or attempt to
service the camera yourself. Any damage that results from unqualied
service is not covered by your warranty.
189
Appendix > Maintaining the camera
About memory card
Supported memory card
This product supports SD (Secure Digital), SDHC (Secure Digital High
Capacity), SDXC (Secure Digital eXtended Capacity), microSD, microSDHC,
or microSDXC memory cards.
Terminal
Write-protect switch
Label (front)
You can prevent les from being deleted by using the write-protect switch
on an SD, SDHC, or SDXC card. Slide the switch down to lock or slide it up
to unlock. Unlock the card when capturing photos and videos.
Memory card adapter
Memory card
To use micro memory cards with this product, a PC, or a memory card
reader, insert the card into an adapter.
190
Appendix > Maintaining the camera
Memory card capacity
The memory capacity may dier depending on shooting scenes or shooting conditions. These capacities are based on a 2 GB SD card.
Size
Quality
Super Fine Fine Normal RAW RAW + S.Fine RAW + Fine RAW + Normal
20.0M (5472X3648) 150 180 224 57 41 43 45
10.1M (3888X2592) 271 325 405 - 52 53 55
5.9M (2976X1984) 411 492 613 - 58 60 61
2.0M (1728X1152) 797 952 1180 - 66 67 68
Burst 464 555 690 - - - -
16.9M (5472X3080) 174 209 261 - 44 46 48
7.8M (3712X2088) 335 401 499 - 55 57 58
4.9M (2944X1656) 471 564 701 - 60 61 63
2.1M (1920X1080) 781 933 1158 - 66 66 67
13.3M (3648X3648) 214 257 321 - 48 50 52
7.0M (2640X2640) 363 435 542 - 56 58 59
4.0M (2000X2000) 538 643 800 - 62 63 64
1.1M (1024X1024) 1030 1227 1519 - 68 69 69
191
Appendix > Maintaining the camera
Size
Quality
HQ Normal
Video
1920X1080 (60 fps)
Approx. 10' 10" Approx. 12' 43"
1920X1080 (30 fps)
Approx. 17' 41" Approx. 22' 09"
*
1920X1080 (15 fps)
Approx. 23' 38" Approx. 29' 24"
1920X810 (24 fps)
Approx. 21' 35" Approx. 27' 02"
1280X720 (60 fps)
Approx. 16' 51" Approx. 21' 06"
1280X720 (30 fps)
Approx. 29' 11" Approx. 36' 35"
640X480 (30 fps)
Approx. 120' 47" Approx. 153' 30"
For Sharing (30 fps)
Approx. 218' 48" Approx. 278' 24"
* is available only with some Smart Filter options.
•
The gures above are measured without using the zoom function.
•
Available recording time may vary if you use the zoom.
•
Several videos were recorded in succession to determine the total recording time.
•
The maximum recording time is 29 minutes and 59 seconds per le.
•
The maximum playback time ofFor Sharing videos is 30 seconds perle.
192
Appendix > Maintaining the camera
•
Prevent memory cards from making contact with liquids, dirt, or foreign
substances. If dirty, wipe the memory card clean with a soft cloth before
you insert the memory card in your camera.
•
Do not allow liquids, dirt, or foreign substances to come in contact with
memory cards or the memory card slot. Doing so may cause memory
cards or the camera to malfunction.
•
When you carry a memory card, use a case to protect the card from
electrostatic discharges.
•
Transfer important data to other media, such as a hard disk, CD, or DVD.
•
When you use the camera for an extended period, the memory card may
become warm. This is normal and does not indicate a malfunction.
•
Use a memory card that meets the standard requirements.
The manufacturer is not responsible for any loss of data.
Cautions when using memory cards
•
Avoid memory cards to very cold or very hot temperatures (below
0 °C/32 °F or above 40 °C/104 °F). Extreme temperatures can cause
memory cards to malfunction.
•
Insert a memory card in the correct direction. Inserting a memory card in
the wrong direction may damage your camera and memory card.
•
Do not use memory cards that have been formatted by other cameras or
by a computer. Reformat the memory card with your camera.
•
Turn o the camera when you insert or remove the memory card.
•
Do not remove the memory card or turn o your camera while the lamp
is blinking, as this may damage your data.
•
When the lifespan of a memory card has expired, you cannot store any
more photos on the card. Use a new memory card.
•
Do not bend, drop, or subject memory cards to heavy impact or
pressure.
•
Avoid using or storing memory cards near strong magnetic elds.
•
Avoid using or keeping memory cards in areas with high temperature,
high humidity, or corrosive substances.
193
Appendix > Maintaining the camera
•
Do not rest the device on ammable surfaces, such as bedding, carpets, or
electric blankets for a prolonged period.
•
When the device is switched on, do not leave it in any conned space for a
prolonged period.
•
Do not allow battery terminals to come in contact with metallic objects, such
as necklaces, coins, keys, or watches.
•
Use only authentic, manufacturer-recommended, Lithium-ion replacement
batteries.
•
Do not disassemble the battery or puncture it with any sharp object.
•
Avoid exposing the battery to high pressure or crushing forces.
•
Avoid exposing the battery to major impacts, such as dropping it from high
places.
•
Do not expose the battery to temperatures of 60 °C (140 °F) or above.
•
Do not allow the battery to come in contact with moisture or liquids.
•
Battery shall not be exposed to excessive heat such as sunshine, re, or the
like.
Disposal guidelines
•
Dispose of the battery with care.
•
Do not dispose of the battery in a re.
•
Disposal regulations may dier by country or region. Dispose of the battery in
accordance with all local and federal regulations.
Guidelines for charging the battery
Charge the battery only by the method described in this user manual.
The battery can ignite or explode if not charged properly.
About the battery
Use only Samsung-approved batteries.
Battery specications
Item Description
Model
BP1410
Type
Lithium-ion battery
Cell capacity
1,410 mAh
Voltage
7.6 V
Charging time* (When the battery
is completely discharged.)
Approx. 200 min
* The gures above are based on when you use the provided USB cable and AC adaptor.
Charging the battery by connecting it to a computer may take longer.
Personal injury or death can occur if the battery is handled carelessly or
improperly. For your safety, follow these instructions for proper battery
handling:
•
The battery can ignite or explode if not handled properly. If you notice
any deformities, cracks, or other abnormalities in the battery, immediately
discontinue use of the battery and contact your manufacturer.
•
Use only authentic, manufacturer-recommend battery chargers and charge
the battery only by the method described in this user manual.
•
Do not place the battery near heating devices or expose to excessively warm
environments, such as the inside of an enclosed car in the summertime.
•
Do not place the battery in a microwave oven.
•
Avoid storing or using the battery in hot, humid places, such as spas or
shower enclosures.
194
Appendix > Maintaining the camera
Battery life
Shooting mode Average time / Number of photos
Photos
Approx. 180 min/Approx. 360 photos
Videos
Approx. 145 min (Record videos at 1920X1080
resolution and 60 fps.)
•
The gures above are based on the CIPA test standards.
Your results may dier depending on your actual usage.
•
Available shooting time diers depending on background, shooting
interval, and use conditions.
•
Several videos were recorded in succession to determine the total
recording time.
Low battery message
When the battery has fully discharged, the battery icon will turn red and
the "Low Battery" message will appear.
Notes about using the battery
•
Avoid exposing batteries to very cold or very hot temperatures (below
0 °C/32 °F or above 40 °C/104 °F). Extreme temperatures can reduce the
charging capacity of your batteries.
•
When you use the camera for an extended period, the area around the
battery chamber may become warm. This does not aect the normal use
of the camera.
•
Do not pull the power supply cord to disconnect the plug from the
power outlet, as this may cause a re or electric shock.
•
In temperatures below 0 °C/32 °F, battery capacity and battery life may
decrease.
•
Battery capacity may decrease in low temperatures, but will return to
normal in milder temperatures.
•
Remove the batteries from your camera when storing it for an extended
period. Installed batteries may leak or corrode over time and cause
serious damage to your camera. Storing the camera for extended
periods with the battery installed causes the battery to discharge. You
may not be able to recharge a fully discharged battery.
•
When you do not use the camera for an extended period (3 months or
more), check the battery and recharge it regularly. If you let the battery
discharge continually, its capacity and life may decrease, which can lead
to a malfunction, re, or explosion.
195
Appendix > Maintaining the camera
Cautions about using the battery
Protect batteries, chargers, and memory cards from damage.
Prevent batteries from making contact with metal objects, as this can
create a connection between the + and – terminals of your battery and
lead to temporary or permanent battery damage and may cause a re or
electric shock.
Notes about charging the battery
•
If the status lamp is o, ensure that the battery is inserted correctly.
•
If the camera is on while charging, the battery may not fully charge. Turn
o the camera before charging the battery.
•
Do not use your camera when you are charging the battery. This may
cause a re or electric shock.
•
Do not pull the power supply cord to disconnect the plug from the
power outlet, as this may cause a re or electric shock.
•
Let the battery charge for at least 10 minutes before turning on the
camera.
•
If you connect the camera to an external power source when the battery
is depleted, using high energy-consuming functions will cause the
camera to turn o. To use the camera normally, recharge the battery.
•
If you reconnect the power cable when the battery is fully charged, the
status lamp turns on for approximately 30 minutes.
•
Using the ash or recording videos depletes the battery quickly. Charge
the battery until the red status lamp turns o.
•
If the status lamp blinks in red, reconnect the cable, or remove the
battery and insert it again.
•
If you charge the battery when the cable is overheated or the
temperature is too high, the status lamp may blink in red. Charging will
start when the battery cools down.
•
Overcharging batteries may shorten battery life. After charging is
nished, disconnect the cable from your camera.
•
Do not bend or place heavy objects on the AC cable. Doing so may
damage the cable.
196
Appendix > Maintaining the camera
Notes about charging with a computer connected
•
Use only the provided USB cable.
•
The battery may not charge when:
- you use a USB hub
- other USB devices are connected to your computer
- you connect the cable to the port on the front side of your computer
- the USB port of your computer does not support the power output standard
(5 V, 500 mA)
Handle and dispose of batteries and chargers with care
•
Never dispose of batteries in a re. Follow all local regulations when you
dispose of used batteries.
•
Never place batteries or cameras on or in heating devices, such as
microwave ovens, stoves, or radiators. Batteries may explode when they
are overheated.
197
Appendix
Updating the firmware
Connect the camera to the computer and update the rmware of the
camera of the lens.
•
You cannot run a rmware upgrade without a fully charged battery. Recharge
the battery fully before running a rmware upgrade.
•
If you update the rmware, user settings and values will be reset. (Date, time,
language, and video out will not change.)
•
Do not turn the camera o while the update is in progress.
1
Turn o the camera.
2
Connect your camera to the computer with the USB cable.
•
You must plug the small end of the USB cable into your camera. If the
cable is reversed, it may damage your les. The manufacturer is not
responsible for any loss of data.
•
If you try to plug the USB cable into the HDMI port, the camera may not
work properly.
3
Turn on the camera.
4
On the computer, select i-Launcher
ĺ
Firmware Upgrade.
5
Follow the on-screen instructions to download the rmware to
the camera.
•
You can download the rmware of the camera or the lens.
6
Turn o the camera when the download completes.
7
Remove the USB cable.
8
Turn on the camera.
9
Press [m]
ĺ
q
ĺ
Device Information
ĺ
Software
Update
ĺ
Body Firmware
or
Lens Firmware
.
10
Select Ye s from a pop-up window on the camera to update
the rmware.
198
Appendix
Before contacting a service center
If you are having trouble with your device, try these troubleshooting
solutions before contacting a service professional.
When you leave your camera at a service center, be sure to also leave the other
components that may have contributed to the malfunction, such as the memory
card and battery.
Situation Suggested remedies
Cannot turn on the
camera
• Ensure that the battery is inserted.
• Ensure that the battery is inserted correctly.
• Charge the battery.
The power turns o
suddenly
• Charge the battery.
• Your camera may be in Power save mode or the
display turns o automatically. (p. 172)
• The camera may be turned o automatically to
prevent the memory card from being damaged
due to excessive heat. Turn on your camera
again.
The camera is losing
battery power quickly
• The battery may lose power more quickly in
low temperatures (below 0 °C/32 °F). Keep the
battery warm by putting it into your pocket.
• Using the ash or recording videos depletes the
battery quickly. Recharge if needed.
• Batteries are consumable parts that must be
replaced over time. Get a new battery if the
battery life is diminishing quickly.
Situation Suggested remedies
Cannot capture
photos
• There is no space on the memory card. Delete
unnecessary les or insert a new card.
• Format the memory card.
• The memory card is defective. Get a new
memory card.
• The memory card is locked. Unlock the card.
(p. 189)
• Ensure that the camera is switched on.
• Charge the battery.
• Ensure that the battery is inserted correctly.
The camera freezes
Remove the battery and insert it again.
The camera heats up
While using the camera, it may heat up.
This is normal and should not aect your camera’s
lifespan or performance.
The ash res
unexpectedly
The ash may re due to static electricity.
The camera is not malfunctioning.
The ash does not
work
• The ash option may be set to O. (p. 101)
• You cannot use the ash in some modes.
The date and time are
incorrect
Set the date and time under the q menu.
(p. 172)
The display or buttons
do not work
Remove the battery and insert it again.
199
Appendix > Before contacting a service center
Situation Suggested remedies
The memory card has
an error
• Turn o the camera, and then turn it on again.
• Remove the memory card, and then insert it
again.
• Format the memory card.
See "Cautions when using memory cards" for
more details. (p. 192)
Your computer does
not recognize an SDXC
or UHS-1 memory card
SDXC memory cards use the exFAT le system. To
use SDXC memory cards or UHS-1 memory cards
that are formatted with the exFAT le system on
a Windows XP computer, download and update
the exFAT le system driver from the Microsoft
website.
Your TV or computer
cannot display photos
and videos that are
stored on an SDXC or
UHS-1 memory card
SDXC memory cards use the exFAT le system. To
use SDXC memory cards or UHS-1 memory cards
that are formatted with the exFAT le system,
ensure that the external device is compatible
with the exFAT le system before connecting the
camera to the device.
Cannot display les
If you change the name of a le, your camera may
not play the le (the name of the le should meet
the DCF standard). If you encounter this situation,
display les on your computer.
The photo is blurry
• Ensure that the focus option you set is suitable
for the kind of shot you are capturing.
• Use a tripod to prevent your camera from
shaking.
• Ensure that the lens is clean. If not, clean the
lens. (p. 186)
Situation Suggested remedies
The colors in the
photo do not match
the actual scene
An incorrect White Balance can create unrealistic
color. Select the proper White Balance option to
suit the light source. (p. 81)
The photo is too
bright or too dark.
Your photo is overexposed or underexposed.
• Adjust the aperture value or the shutter speed.
• Adjust the ISO sensitivity. (p. 79)
• Turn the ash o or on. (p. 101)
• Adjust the exposure value. (p. 111)
Photos are distorted
This camera can have minute distortion when
using a wide-angle lens that enables shooting
with a wide angle of view. This is normal, and
does not cause malfunction.
Playback screen does
not appear on the
connected external
device
• Ensure that HDMI cable is properly connected
to the external monitor.
• Ensure that the memory card is properly
recorded.
Your computer does
not recognize your
camera
• Ensure that the USB cable is connected
correctly.
• Ensure that the camera is switched on.
• Ensure that you are using a supported
operating system.
Your computer
disconnects the
camera while
transferring les
The le transfer may be interrupted by static
electricity. Disconnect the USB cable and connect
it again.
200
Appendix > Before contacting a service center
Situation Suggested remedies
i-Launcher is not
functioning properly
• End i-Launcher and restart the program.
• Depending on your computer's specications
and environment, the program may not
launch automatically. In this case, click
Start
ĺ All Programs ĺ Samsung ĺ
i-Launcher
ĺ Samsung i-Launcher on your
Windows computer. (For Windows 8, open
Start screen, and then select All apps
ĺ
Samsung i-Launcher.) Or, click Applications
ĺ Samsung ĺ i-Launcher on your Mac OS
computer.
Auto Focus does not
work
• Subject is not in focus. When the subject is
outside the AF area, shoot by moving the
subject inside the AF area and half-pressing
[Shutter].
• Subject is too close. Step back from the subject
and shoot.
• The focus mode is set to MF. Switch the mode
to AF.
Situation Suggested remedies
AEL feature does not
work
AEL feature does not work in t, M, i,
and s modes. Select another mode to use this
feature.
Lens does not work
• Ensure that the lens is properly mounted.
• Remove the lens from the camera and
remount it.
External ash does not
work
Ensure that the external device is properly
mounted and turned on.
The date & time
settings screen
appears when you
power on the camera
• Set the date and time again.
• This screen appears when the camera’s internal
power source is completely discharged. Insert
a fully charged battery and wait at least 72
hours in power o status for the internal power
source to be recharged.
201
Appendix
Camera specifications
Image Sensor
Type
CMOS
Sensor size
23.5X15.7 mm
Eective pixels
Approx. 20.3 mega-pixels
Total pixels
Approx. 21.6 mega-pixels
Color lter
RGB primary color lter
Lens Mount
Type
Samsung NX Mount
Available lens
Samsung lenses
Image Stabilization
Type
Lens shift (depends on lens)
Mode
O/Mode 1/Mode 2
Distortion Correct
O/On (depends on lens)
i-Function
E, Z (X1.2, 1.4, 1.7, 2.0), G
Dust Reduction
Type
Super sonic drive
Display
Type
Super AMOLED with Touch Panel (C-type Touch
Control Enabled)
Size
3.0" (Approx. 76.7 mm)
Resolution
FVGA (720X480) 1037 k dots (S-Stripe)
Field of view
Approx. 100 %
Angle
Swivel (Horizontal 180°, Vertical 270°)
User display
Grid Line, Icons, Histogram, Distance Scale, Level
gauge, Overexposure Guide
Viewnder
Elements in Group
3 Aspherical lens
Eye relief
Approx. 18.5 mm
Diopter adjustment
Approx. -4.0–+1.0 DPT
Field of view
Approx. 100 %
Magnication
Approx. 0.96 X (APS-C, 50 mm)
202
Appendix > Camera specications
Focusing
Type
Hybrid AF (Phase Detection & Contrast)
Focusing point
• Total AF point: 105 points (Phase Detection
AF), 247 points (Contrast AF)
• Selection: 1 point (Free selection)
• Multi: Normal 21 (3X7) points,
Close up 35 points
• Face detection: Max. 10 faces
Mode
Single AF, Continuous AF, Manual Focus, Touch
AF & Shutter
AF Assist Lamp
Yes
Shutter
Type
Electronically controlled vertical-run focal plane
shutter
Speed
• Auto: 1/8,000–1/4 sec. (EFS available)
• Manual: 1/8,000–30 sec. (1/3 EV Step)
(EFS available)
• Bulb (time limit: 4 min)
The fastest shutter speed is limited to 1/6,000 sec.
when you use the mechanical shutter.
Exposure
Metering system
TTL 221 (17X13) Block segment
Metering: Multi, Center-weighted, Spot
Metering range: EV -3–18 (ISO100 · 30 mm, F2)
Compensation
±3 EV (1/3 EV Step)
AE lock
AEL button
ISO equivalent
• 1 Step: Auto, ISO 100, ISO 200, ISO 400,
ISO 800, ISO 1600, ISO 3200, ISO 6400,
ISO 12800, ISO 25600
• 1/3 Step: Auto, ISO 100, ISO 125, ISO 160,
ISO 200, ISO 250, ISO 320, ISO 400, ISO 500,
ISO 640, ISO 800, ISO 1000, ISO 1250,
ISO 1600, ISO 2000, ISO 2500, ISO 3200,
ISO 4000, ISO 5000, ISO 6400, ISO 8000,
ISO 10000, ISO 12800, ISO 16000, ISO 20000,
ISO 25600
* Auto ISO settings are selectable up to ISO 3200.
203
Appendix > Camera specications
Drive Mode
Mode
Single, Continuous, Burst (5M only), Timer,
Bracket (Auto Exposure, White Balance, Picture
Wizard, Depth)
Continuous shooting
• JPEG: High (9 fps), Normal (4 fps)
• Burst: 10, 15, or 30 frames per second
• RAW: High (9 fps), Normal (4 fps)
Bracket shooting
Auto exposure bracketing (±3 EV),
White Balance bracketing,
Picture Wizard bracketing, Depth bracketing
Self-timer
2–30 sec. (1 second interval)
Shutter release
via Micro USB port
Flash
Type
A-TTL pop-up ash
Mode
Smart Flash, Auto, Auto Red-eye, Fill in,
Fill-in Red, 1st Curtain, 2nd Curtain, O,
Auto FP Sync (available only with supported
external ashes)
Guide number
11 (based on ISO 100)
Angle of view
28 mm (35 mm lm equivalent)
Sync speed
Less than 1/200 sec.
Flash EV
-2–+2 EV (0.5 EV Step)
External ash
Optional Samsung external ashes
Sync terminal
Hot-shoe
White Balance
Mode
Auto WB, Daylight, Cloudy, Fluorescent White,
Fluorescent NW, Fluorescent Daylight, Tungsten,
Flash WB, Custom Set, Color Temperature
(Manual)
Micro adjustment
Amber/Blue/Green/Magenta 7 steps respectively
Dynamic Range
O/Smart Range+/HDR
Picture Wizard
Mode
Standard, Vivid, Portrait, Landscape, Forest,
Retro, Cool, Calm, Classic, Custom1, Custom2,
Custom3
Parameter
Color, Saturation, Sharpness, Contrast
204
Appendix > Camera specications
Shooting
Mode
Smart Auto, Program, Aperture Priority,
Shutter Priority, Manual, Custom1, Custom2,
Lens Priority, Smart
Smart mode
Beauty Face, Best Face, Landscape, Macro,
Action Freeze, Rich Tones, Panorama, Waterfall,
Silhouette, Sunset, Night, Fireworks, Light Trace,
Creative Shot, Multi Exposure, Smart Jump Shot
Smart lter
Vignetting, Miniature, Colored Pencil, Watercolor,
Wash drawing, Oil Sketch, Ink Sketch, Acryl,
Negative, Red, Green, Blue, Yellow
Size
• JPEG (3:2): 20.0M (5472X3648),
10.1M (3888X2592), 5.9M (2976X1984),
5.0M (2736X1824) (Burst mode only),
2.0M (1728X1152)
• JPEG (16:9): 16.9M (5472X3080),
7.8M (3712X2088), 4.9M (2944X1656),
2.1M (1920X1080)
• JPEG (1:1): 13.3M (3648X3648),
7.0M (2640X2640), 4.0M (2000X2000),
1.1M (1024X1024)
• RAW: 20.0M (5472X3648)
* 3D mode with 3D lens is available only with
JPEG (16:9) 4.1M (2688X1512) or 2.1M (1920X1080).
Quality
Super Fine, Fine, Normal
RAW standard
SRW (ver.2.0.0)
Color space
sRGB, Adobe RGB
Video
Type
MP4 (H.264)
Format
Movie: H.264, Sound: AAC
Movie AE mode
Program, Aperture Priority, Shutter Priority,
Manual
Movie clip
Audio on/o (Shooting time: Max. 29' 59'')
Smart lter
Vignetting, Miniature, Colored Pencil, Watercolor,
Wash drawing, Oil Sketch, Ink Sketch, Acryl,
Negative, Red, Green, Blue, Yellow
Size
1920X1080, 1920X810, 1280X720, 640X480,
320X240 (For Sharing)
Frame rate
60 fps, 30 fps, 24 fps (available only with
1920X810) (3D: only 30 fps is available)
Multi Motion
x0.25 (640X480, 320X240 only), x0.5 (1280X720,
640X480, 320X240 only), x5, x10, x20
Quality
HQ, Normal
Sound
Stereo (with Input Level Adjustment, Audio Level
Display)
Edit
Still image capture, Time trimming
205
Appendix > Camera specications
Playback
Type
Single image, Thumbnails (15/24), Slide show,
Movie
Edit
Smart Filter, Resize, Rotate, Face Retouch,
Display Brightness, Contrast
Smart lter
Vignetting, Miniature, Colored Pencil, Watercolor,
Wash drawing, Oil Painting, Ink Painting, Acryl,
Negative, Red, Green, Blue, Yellow
Storage
Media
External memory (optional):
SD card (2 GB guaranteed),
SDHC card (up to 32 GB guaranteed),
SDXC card (up to 64 GB guaranteed, UHS-1
supported)
- Class 6 and above recommended
File format
RAW (SRW (ver.2.0.0)), JPEG (EXIF 2.3),
MPO (3D), DCF
Wireless network
Type
IEEE 802.11b/g/n support Dual Band
Function
MobileLink, Remote Viewnder, Baby Monitor,
Auto Backup, Email, SNS & Cloud, Samsung
Link, AutoShare, Group Share, Photo Beam,
HomeSync
NFC
Yes
Interface
Digital output
USB 2.0 (micro USB jack)
Video output
NTSC, PAL (selectable)
HDMI
Audio interface
3.5 mm stereo mic input
External release
Yes
External microphone
Yes
DC power input
DC 5.0 V, 1 A via micro USB
Power Source
Type
Rechargeable battery:
BP1410 (1,410 mAh, 7.6 V )
* The power source may dier depending on your region.
Dimensions (W X H X D)
127 X 95.5 X 41.7 mm (without protrusions)
Weight
375 g (without battery and memory card)
Operating Temperature
0–40 °C
Operating Humidity
5–85%
Software
i-Launcher, Adobe Photoshop Lightroom 5
* Specications may change without notice to improve performance.
* Other brands and products names are trademarks of respective owners.
206
Appendix
Glossary
AP (Access Point)
An access point is a device that allows wireless devices to connect to a
wired network.
Ad-Hoc network
An ad-hoc network is a temporary connection for sharing les or an
internet connection and between computers and devices.
AdobeRGB
Adobe RGB is used for commercial printing and has a larger color range
than sRGB. Its wider range of colors helps you to easily edit photos on a
computer.
AEB (Auto Exposure Bracket)
This feature automatically captures several images at dierent exposures
to help you capture a properly-exposed image.
AEL/AFL (Auto Exposure Lock/Auto Focus Lock)
These features help you lock the exposure or focus on which you want to
focus or calculate the exposure.
AF (Auto Focus)
A system that automatically focuses the camera lens on the subject. Your
camera uses the contrast to focus automatically.
AMOLED (Active-matrix organic light-emitting diode)/
LCD (Liquid Crystal Display)
AMOLED is a visual display that is very thin and light, as it does not
need backlighting. LCD is a visual display commonly used in consumer
electronics. This display needs a separate backlight, such as CCFL or LED, to
reproduce colors.
Aperture
The aperture controls the amount of light that reaches the camera’s sensor.
207
Appendix > Glossary
Composition
Composition in photography means arranging objects in a photo. Usually,
abiding by the rule of thirds leads to a good composition.
DCF (Design rule for Camera File system)
A specication to dene a le format and le system for digital cameras
created by the Japan Electronics and Information Technology Industries
Association (JEITA).
Depth of eld
The distance between the nearest and farthest points that can be
acceptably focused in a photograph. Depth of eld varies with lens
aperture, focal length, and distance from the camera to the subject.
Selecting a smaller aperture, for example, will increase the depth of eld
and blur the background of a composition.
Camera shake (Blur)
If the camera is moved while the shutter is open, the entire image may
appear blurred. This occurs more often when the shutter speed is slow.
Prevent camera shake by raising the sensitivity, using the ash, or using
a faster shutter speed. Alternatively, use a tripod or the OIS function to
stabilize the camera.
Cloud Computing
Cloud computing is a technology that allows you to store data on remote
servers and to use them from a device with internet access.
Color space
The range of colors that the camera can see.
Color temperature
Color Temperature is a measurement in degrees Kelvin (K) that indicates
the hue of a specic type of light source. As the color temperature
increases, the color of the light source has a more bluish quality. As the
color temperature decreases, the color of the light source has a more
reddish quality. At 5,500 degrees Kelvin, the color of the light source is
similar to the sun at midday.
208
Appendix > Glossary
Flash
A speed light that helps to create adequate exposure in low-light
conditions.
Focal length
The distance from the middle of the lens to its focal point(in millimeters).
Longer focal lengths result in narrower angles of view and the subject is
magnied. Shorter focal lengths result in wider angles of view.
Histogram
A graphical representation of the brightness of an image. The horizontal
axis represents the brightness and the vertical axis represents the number
of pixels. High points at the left (too dark) and right (too bright) on the
histogram indicate a photo that is improperly exposed.
H.264/MPEG-4
A high-compression video format established by international standard
organizations ISO-IEC and ITU-T. This codec is capable of providing good
video quality at low bit rates developed by the Joint Video Team (JVT).
EV (Exposure Value)
All the combinations of the camera’s shutter speed and lens aperture that
result in the same exposure.
EV Compensation
This feature allows you to quickly adjust the exposure value measured by
the camera, in limited increments, to improve the exposure of your photos.
Exif (Exchangeable Image File Format)
A specication to dene an image le format for digital cameras created by
the Japan Electronic Industries Development Association (JEIDA).
Exposure
The amount of light allowed to reach the camera’s sensor. Exposure is
controlled by a combination of the shutter speed, the aperture value, and
ISO sensitivity.
209
Appendix > Glossary
Metering
The metering refers to the way in which the camera measures the quantity
of light to set the exposure.
MF (Manual Focus)
A system that manually focuses the camera lens on the subject.
You can use the focus ring to focus on a subject.
MJPEG (Motion JPEG)
A video format which is compressed as a JPEG image.
MPO (Multi Picture Object)
An image le format that contains multiple images in a le. An MPO le
provides a 3D eect on MPO-compatible displays, such as 3D TVs or 3D
monitors.
Image sensor
The physical part of a digital camera that contains a photosite for each
pixel in the image. Each photosite records the brightness of the light that
strikes it during an exposure. Common sensor types are CCD (Charge-
coupled Device) and CMOS (Complementary Metal Oxide Semiconductor).
IP (Internet protocol) address
An IP address is a unique number that is assigned to every device that is
connected to the internet.
ISO sensitivity
The sensitivity of the camera to light, based on the equivalent lm speed
used in a lm camera. At higher ISO sensitivity settings, the camera uses a
higher shutter speed, which can reduce blur caused by camera shake and
low light. However, images with high sensitivity are more susceptible to
noise.
JPEG (Joint Photographic Experts Group)
A lossy method of compression for digital images. JPEG images are
compressed to reduce their overall le size with minimal deterioration of
the image resolution.
210
Appendix > Glossary
PAL (Phase Alternate Line)
A video color encoding standard used in numerous countries throughout
Africa, Asia, Europe, and the Middle East.
Quality
An expression of the rate of compression used in a digital image. Higher
quality images have a lower rate of compression, which usually results in a
larger le size.
RAW (CCD raw data)
The original, unprocessed data, collected directly from the camera’s image
sensor. White Balance, contrast, saturation, sharpness, and other data can
be manipulated with editing software before the image is compressed into
a standard le format.
Resolution
The number of pixels present in a digital image. High resolution images
contain more pixels and typically show more detail than low resolution
images.
Noise
Misinterpreted pixels in a digital image that may appear as misplaced or
random, bright pixels. Noise usually occurs when photos are shot with a
high sensitivity or when a sensitivity is automatically set in a dark place.
NFC (Near Field Communication)
NFC is a set of standards for radio communication at very close proximity.
You can use NFC-enabled devices to activate features or exchange data
with other devices.
NTSC (National Television System Committee)
A video color encoding standard used most commonly in Japan, North
America, the Philippines, South America, South Korea, and Taiwan.
Optical zoom
This is a general zoom which can enlarge images with a lens and does not
deteriorate quality of images.
211
Appendix > Glossary
Shutter speed
Shutter speed refers to the amount of time it takes to open and close the
shutter, and it is an important factor in the brightness of a photo, as it
controls the amount of light which passes through the aperture before
it reaches the image sensor. A fast shutter speed allows less time to let
light in and the photo becomes darker and more easily freezes subjects in
motion.
sRGB (Standard RGB)
International standard of color space established by the IEC (International
Electrotechnical Commission). This is dened from color space for PC
monitors and is also used as the standard color space for Exif.
Vignetting
A reduction of an image’s brightness or saturation at the periphery (outer
edges) compared to the center of the image. Vignetting can draw interest
to subjects positioned in the center of an image.
White Balance (Color balance)
An adjustment of the intensities of colors (typically the primary colors red,
green, and blue), in an image. The goal of adjusting the White Balance, or
color balance, is to correctly render the colors in an image.
Wi-Fi
Wi-Fi is a technology that allows electronic devices to exchange data
wirelessly over a network.
WPS (Wi-Fi Protected Setup)
WPS is a technology that secures wireless home networks.
212
Appendix
Optional accessories
You can purchase the following optional items:
Lens, External ash, Shutter release (micro USB type), External microphone,
Rechargeable battery, Battery charger, Camera bag, Camera case, Memory
card, Filter, USB cable, HDMI cable, Strap
•
To locate the type, image and availability of accessories, visit the Samsung
website.
•
Before purchasing accessories, make sure they are compatible with your
camera. GPS10 and EM10 are not compatible with this camera.
•
Use only Samsung-approved accessories. Samsung is not responsible for
damage caused by using another manufacturer’s accessories.
213
Appendix
A
Adobe Photoshop Lightroom 183
Aperture 16, 20
Auto Backup 151
Auto focus 84
B
Baby Monitor 149
Battery
Caution 193
Charging 35
Insert 34
Best Face mode 68
Bracketing 98
C
Camera
Connecting as removable disk 178
Connecting to PC 178
Disconnecting (Windows) 179
Layout 30
Camera specications 201
Charging 35
Color space 165
D
Date & Time 172
Depth of Field (DOF) 17, 22
DIRECT LINK 33
Display brightness 171
Display type 48
Drive 95
E
Enlarging 124
Exposure Value (EV) 16, 111
F
Fader 116
Files
Deleting 123
Photo type 78
Protecting 122
Video type 114
Flash
Bounce photography 27
Flash options 101
Guide number 26
Intensity 103
F-number 16
Focal length 21
Focus assist 92
Focus Peaking 93
I
Icons
Playback mode 47
Shooting mode 45
i-Launcher 182
Image adjustment
Adjusting photos 131
Retouching faces 132
ISO sensitivity 79
L
Lenses
Layout 49
Locking 50
Markings 52
Unlocking 51
M
Maintenance 186
Memory card
Caution 189
Insert 34
Metering 106
MobileLink 143
Index
214
Appendix > Index
N
NFC (Tag & Go) 140
O
One touch shot 91
Optical Image Stabilization
(OIS) 94
Optional accessories
Connect the ash 54
Flash layout 53
P
Panorama mode 69
Photos
Editing 129
Enlarging 124
Shooting options 77
Viewing on 3D TV 177
Viewing on camera 119
Viewing on HDTV 176
Picture Wizard 83
Posture 13
Power save mode 172
R
Red-eye eect 102
Remote Viewnder 147
Resolution
Playback mode 130
Shooting mode (Movie) 114
Shooting mode (Photo) 77
Retouching faces 132
Rotating 130
Rule of thirds 24
S
Samsung Link 159
Service center 198
Settings 171
Shooting modes
Aperture Priority 59
Custom 63
Manual 61
Program 57
Recording 72
Shutter Priority 60
Smart 66
Smart Auto 55
Shutter speed 18, 20
Slide show 124
Smart lter
Playback mode 133
Shooting mode 110
Smart Jump Shot 71
Smart panel 40
T
Thumbnails 119
Timer 97
Touch AF 90
Touch screen 38
Tracking AF 90
Transferring les
Mac 179
Windows 178
TV 176
U
Unpacking 29
V
Video Out 172
Videos
Capturing 128
Options 114
Recording 72
Viewing 126
W
White balance 81
Wireless network 135
3
3D mode 73
215
Appendix
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories, or literature indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased
this product or their local government oce for details of where and how
they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
This product is RoHS compliant.
Correct disposal of batteries in this product
(Applicable in countries with separate collection systems)
This marking on the battery, manual, or packaging indicates that the
batteries in this product should not be disposed of with other household
waste at the end of their working life. Where marked, the chemical symbols
Hg, Cd, or Pb indicate that the battery contains mercury, cadmium, or
lead above the reference levels in EC Directive 2006/66. If batteries are not
properly disposed of, these substances can cause harm to human health or
the environment.
To protect natural resources and to promote material reuse, please
separate batteries from other types of waste and recycle them through
your local, free battery return system.
CAN ICES-3 (B)/NMB-3(B)
Dispose unwanted electronics through an approved recycler.
To nd the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect Or call, (877) 278 - 0799
216
Appendix
FCC notice
Caution:
Any changes or modications in construction of this device which are
not expressly approved by the party responsible for compliance could
void theuser's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorientate, or relocate, the receiving antenna.
- Increase the distance between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF Radiation exposure limits set forth for
an uncontrolled environment. This device and its antenna must not be co-
located or operating in conjunction with any other antenna or transmitter.
Caution:
Any changes or modications to the equipment not expressly
approved by the party responsible for compliance could void
user’s authority to operate the equipment.
IC: 649E-NX30
FCC ID:A3LNX30
217
33017/SDPPI/2014
1258
TRC/SS/2014/5
TA-2013/1994
APPROVED
No.: ESD-1408378C
Model : NX30
Year of Manufacture : 2014
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Caution:
Any changes or modications to the equipment not expressly
approved by the party responsible for compliance could void
user’s authority to operate the equipment.
IC: 649E-NX30
This equipment may be operated in all EU countries.
In France, this equipment may only be used indoors.
Complies with
IDA Standards
DA100790
Declaration of Conformity
Trade Name : Samsung Electronics America, Inc.
Model No. : Samsung NX30
Responsible Party: Samsung Electronics America, Inc.
Address : 85 Challenger Road, Ridgeeld Park, NJ 07660
Telephone No.: 1-800-SAMSUNG (726-7864)
This device complies with Industry Canada License-Exempt RSS standard (S)
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
