With High-Quality Sound & Refined Design, The Component System Enriches Your Life
D-F101MB
Micro System with 2 Speakers
NEW MODEL INFORMATION
DRA-F101
DCD-F101
MS-M71B
Receiver
CD Player
MISSION Compact Loudspeakers
DRA-F101
Receiver
The DRA-F101 receiver represents the heart of the Denon D-F101
component system featuring space-saving 250mm depth design
and luxurious aluminum front panels.
Its remote control unit also controls the main functions of other
components in the system.
Amplifier Section
Engineering for high-quality sound inherited from high-end Denon
amps, including:
- Discrete configuration for clear stereo separation
- Large transformer for robust yet stable power (35W+ 35W)
- High-capacity heat sink
- Parts strictly selected for their contribution to sound quality
Input and Output terminals
Input: PHONO (MM), CD, DVD/AUX, TAPE, MD
Output: TAPE, MD, Subwoofer (Mono)
Tuner Section
40-station Preset Memory (FM/AM) for easy selection of your
favorite stations
Tuning of preset stations possible by remote control
Remote Control Unit
Controls entire D-F101 system
Frequently-used buttons in large, easy-to-find size
Less-used controls stored behind door to avoid confusion
General
Rated output ........................ 35W + 35W (4 ohms)
Frequency response............ 5 Hz - 80 kHz
Power supply ....................... AC 120 V, 60 Hz
Dimensions.......................... 250 (W) x 82 (H) x 250 (D) mm
9.8” (W) x 3.2” (H) x 9.8” (D)
Weight ................................. 3.5 kg, 7.7 lbs
System-wide Features
Gently reflective half-mirror displays
Display brightness dimmable in 4 stages
Auto Function Change, for one-touch switching from one sound source
to another
Everyday Timer, to automatically turn on/off the system at the same
time each day
Sleep Timer, to automatically turn off the system in 10 to 60 minutes
(set in 10-min. increments)
Auto Power On
Energy-saving power consumption of less than 1W during standby
