11/2009
User Instructions, Installation, maintenance for
•COOKERS•
Cookers characteristics
These warnings refer to different models of cookers.
Be sure that you have correctly identified the model that you possess (see the data plate).
MODEL DIMENSIONS
UP60 23 5/8” (W) x 23 5/8” (D) x [33 15/32”- 35 53/64“] (H)
UP70 27 9/16” (W) x 23 5/8” (D) x [33 15/32”- 35 53/64“] (H)
UM70 27 9/16” (W) x 27 9/16” (D) x [34 1/4”- 36 20/32”] (H)
UP76 29 7/8” (W) x 23 5/8” (D) x [33 15/32” - 35 53/64”] (H)
UM76 29 7/8” (W) x 27 9/16” (D) x [34 1/4”- 36 20/32”] (H)
UP90, UPD90, UQDC90 35 7/16” (W) x 23 5/8” (D) x [33 15/32”- 35 53/64”] (H)
UM90 35 7/8” (W) x 27 9/16” (D) x [34 1/4”- 36 20/32”] (H)
UPD100, UQDC100 39 3/8” (W) x 23 5/8” (D) x [33 15/32”- 35 53/64”] (H)
UMD100 39 3/8” (W) x 27 9/16” (D) x [34 1/4”- 36 20/32”] (H)
UP120, UPD120 47 1/4” (W) x 23 5/8” (D) x [33 15/32”- 35 53/64”] (H
UM120, UMS120 47 7/8” (W) x 27 9/16” (D) x [34 1/4”- 36 20/32”] (H)
UP150 59 1/16” (W) x 23 5/8” (D) x [33 15/32”- 35 53/64”] (H)
UM150 59 1/2” (W) x 27 9/16” (D) x [34 1/4”- 36 20/32”] (H)
Majestic • Professional • Quadra
Majestic • Professional • Quadra
cod. I/301/89
