No.
1
2
3
4
5
6
7
Qty
1
6
1
13
12
13
12
Description
Plastic Body
3" Swivel Castor
Head Rest
Bolt
Nut M6
Flat Washer
Sleeve
1
3
5
6
7
2
4
DRAPER TOOLS LTD, HURSLEY ROAD, CHANDLER'S FORD, EASTLEIGH, HANTS. SO53 1YF. U.K.
www.draper.co.uk e-mail: [email protected]
RWJB0917
MECHANICS
CRE EPER
81906
SPECIFICATION
Stock no. .............................................................................................................................................81906
Part no. .............................................................................................................................................. CC4/B
Overall length ................................................................................................................................. 1010mm
Overall width ......................................................................................................................................475mm
Max. weight capacity............................................................................................................................120kg
SAFETY INSTRUCTIONS
•
Do not place under car tyres or use to move or reposition vehicle.
•
Do not use as a toy or skateboard.
•
Do not stand on car creeper or use as a stepping device.
•
Do not use if any part of the car creeper is defective or damaged in any way.
•
Always store in an upright position in a secure place.
•
Keep out of the reach of children.
ASSEMBLY
•
Put bolt (4) through hole of caster (2) and thread into underside of creeper body.
•
Put sleeve (7) over bolt thread.
•
Place flat washer (6) up to sleeve and screw nut (5) onto bolt until tight.
•
Repeat for all 6 castors.
