Maytag MRT118FFFM01 30 Inch Top-Freezer Refrigerator User Manual

THANK YOU for purchasing this high-quality product. Register your new refrigerator at www.maytag.com. In Canada, register your

refrigerator at www.maytag.ca.

For future reference, please make a note of your product model and serial numbers. These can be located on the inside wall of the

refrigerator compartment.

Model Number ___________________________________________ Serial Number____________________________________________

Para obtener acceso a “Instrucciones para el usuario del refrigerador” en español, o para obtener información adicional acerca de su

producto, visite: www.maytag.com.

Necesitará su número de modelo y de serie, ubicado en el interior del compartimiento del refrigerador.

REFRIGERATOR

USER INSTRUCTIONS

Table of Contents/Table des matières

REFRIGERATOR SAFETY.....................................................................2

Proper Disposal of Your Old Refrigerator...........................................3

INSTALLATION INSTRUCTIONS .........................................................3

Unpack the Refrigerator...................................................................... 3

Location Requirements....................................................................... 4

Electrical Requirements ...................................................................... 4

Water Supply Requirements...............................................................4

Connect the Water Supply...............................................................

...5

Refrigerator Doors............................................................................... 6

Reversibility Kit Instructions..............................................................11

Adjust the Doors ...............................................................................11

REFRIGERATOR USE .........................................................................12

Using the Controls ............................................................................12

REFRIGERATOR FEATURES .............................................................13

Refrigerator Shelves..........................................................................13

Deli Drawer........................................................................................13

Crisper...............................................................................................13

FREEZER FEATURES .........................................................................14

Freezer Shelf .............................................................................

........14

DOOR FEATURES ...............................................................................14

Door Rails..........................................................................................14

Door Bins...........................................................................................14

Utility Compartment..........................................................................14

Ice Maker.......................................

....................................................15

REFRIGERATOR CARE.......................................................................15

Cleaning ............................................................................................15

Changing the Light Bulb ...................................................................16

Vacation and Moving Care ...............................................................16

TROUBLESHOOTING..........................................................................17

Refrigerator Operation ......................................................................17

Temperature and Moisture ...............................................................18

Ice and Water.....................

...............................................................18

ACCESSORIES ....................................................................................18

WARRANTY..........................................................................................19

BRAND BADGE PLACEMENT TEMPLATE...................BACK COVER

SÉCURITÉ DU RÉFRIGÉRATEUR ..................................................... 20

Mise au rebut appropriée de votre vieux réfrigérateur..................... 21

INSTRUCTIONS D'INSTALLATION ......................

............................. 21

Déballage du réfrigérateur ................................................................ 21

Exigences d'emplacement ............................................................... 22

Spécifications électriques................................................................. 22

Spécifications de l’alimentation en eau............................................ 23

Raccordement de la canalisation d'eau........................................... 23

Portes du réfrigérateur...................................................................... 24

Instructions pour l'ensemble d’inversion du sens d’ouverture........ 30

Ajustement des portes...................................................................... 30

UTILISATION DU RÉFRIGÉRATEUR................................................. 31

Utilisation des commandes .............................................................. 31

CARACTÉRISTIQUES DU RÉFRIGÉRATEUR .................................. 32

Tablettes du réfrigérateur ..........................

....................................... 32

Tiroir pour spécialités alimentaires................................................... 32

Bac à légumes .................................................................................. 32

CARACTÉRISTIQUES DU CONGÉLATEUR...................................... 33

Tablette du congélateur.................................................................... 33

CARACTÉRISTIQUES DE LA PORTE................................................ 33

Tringles de porte............................................................................... 33

Balconnets de porte ......................................................................... 34

Compartiment utilitaire ..................................................................... 34

Machine à glaçons..........................

.................................................. 34

ENTRETIEN DU RÉFRIGÉRATEUR ................................................... 35

Nettoyage.......................................................................................... 35

Remplacement des ampoules d’éclairage....................................... 35

Entretien avant les vacances ou lors d’un déménagement............. 36

DÉPANNAGE........................................................................................ 37

Fonctionnement du réfrigérateur..................................................

.... 37

Température et humidité .................................................................. 38

Glaçons et eau............................................................

...................... 38

ACCESSOIRES .................................................................................... 39

GARANTIE............................................................................................ 40

GABARIT DE POSITIONNEMENT

DE L’INSIGNE DE LA MARQUE.................. CO

UVERTURE ARRIÈRE

W10885251B

REFRIGERATOR SAFETY

You can be killed or seriously injured if you don't immediately

You

can be killed or seriously injured if you don't

All฀safety฀messages฀will฀tell฀you฀what฀the฀potential฀hazard฀is,฀tell฀you฀how฀to฀reduce฀the฀chance฀of฀injury,฀and฀tell฀you฀what฀can

happen฀if฀the฀instructions฀are฀not฀followed.

Your safety and the safety of others are very important.

We฀have฀provided฀many฀important฀safety฀messages฀in฀this฀manual฀and฀on฀your฀appliance.฀Always฀read฀and฀obey฀all฀safety฀

messages.

This฀is฀the฀safety฀alert฀symbol.

This฀symbol฀alerts฀you฀to฀potential฀hazards฀that฀can฀kill฀or฀hurt฀you฀and฀others.

All฀safety฀messages฀will฀follow฀the฀safety฀alert฀symbol฀and฀either฀the฀word฀“DANGER”฀or฀“WARNING.”

These฀words฀mean:

follow instructions.

instructions.

DANGER

WARNING

State฀of฀California฀Proposition฀65฀Warnings:

WARNING:฀This฀product฀contains฀one฀or฀more฀chemicals฀known฀to฀the฀State฀of฀California฀to฀cause฀cancer.

WARNING:฀This฀product฀contains฀one฀or฀more฀chemicals฀known฀to฀the฀State฀of฀California฀to฀cause฀birth฀defects฀or฀other฀

reproductive฀harm.

IMPORTANT฀SAFETY฀INSTRUCTIONS

WARNING:

To฀reducethe฀risk฀of฀fire,฀electricshock,or฀injury฀whenusingyour฀refrigerator,followthese฀basicprecautions:

SAVE฀THESE฀INSTRUCTIONS

■ Plug฀into฀a฀grounded฀3฀prong฀outlet.

■ Do฀not฀remove฀ground฀prong.

■ Do฀not฀use฀an฀adapter.

■ Do฀not฀use฀an฀extension฀cord.

■ Disconnect฀power฀before฀servicing.

■ Replace฀all฀parts฀and฀panels฀before฀operating.

■ Remove฀doors฀from฀your฀old฀refrigerator.

■ Connect฀to฀a฀potable฀water฀supply฀only.

■ Use฀nonflammable฀cleaner.

■ Keep฀flammable฀materials฀and฀vapors,฀such฀as฀gasoline,

away฀from฀refrigerator.

■ Use฀two฀or฀more฀people฀to฀move฀and฀install฀refrigerator.

■ Disconnect฀power฀before฀installing฀ice฀maker฀(on฀ice฀maker

kit฀ready฀models฀only).

■ Use฀a฀sturdy฀glass฀when฀dispensing฀ice฀(on฀some฀models).

■ Do฀not฀hit฀the฀refrigerator฀glass฀doors฀(on฀some฀models).

■ This฀appliance฀is฀not฀intended฀for฀use฀by฀persons฀(including

children)฀with฀reduced฀physical,฀sensory฀or฀mental

capabilities,฀or฀lack฀of฀experience฀and฀knowledge,฀unless

they฀have฀been฀given฀supervision฀or฀instruction฀concerning

use฀of฀the฀appliance฀by฀a฀person฀responsible฀for฀their

safety.

■ Children฀should฀be฀supervised฀to฀ensure฀that฀they฀do฀not

play฀with฀the฀appliance.

INSTALLATION INSTRUCTIONS

Unpack the Refrigerator

Remove฀the฀Packaging฀฀

IMPORTANT:฀Do฀not฀remove฀the฀white฀foam฀air฀return฀insert฀from฀

behind฀the฀control฀panel฀on฀the฀ceiling฀of฀the฀refrigerator.฀If฀the฀

insert฀is฀removed,฀ice฀may฀migrate฀down฀from฀the฀freezer฀and฀

cause฀icicles฀to฀form.

Remove฀tape฀and฀glue฀residue฀from฀surfaces฀before฀turning฀

on฀the฀refrigerator.฀Rub฀a฀small฀amount฀of฀liquid฀dish฀soap฀

over฀the฀adhesive฀with฀your฀fingers.฀Rinse฀with฀warm฀water฀

and฀dry฀with฀a฀soft฀cloth.

Do฀not฀use฀sharp฀instruments,฀rubbing฀alcohol,฀flammable฀

fluids,฀or฀abrasive฀cleaners฀to฀remove฀tape฀or฀glue.฀These฀

products฀can฀damage฀the฀surface฀of฀your฀refrigerator.฀For฀

more฀information฀see,฀“Refrigerator฀Safety.”

Clean฀Before฀Using

After฀you฀remove฀all฀of฀the฀package฀materials,฀clean฀the฀inside฀of฀

your฀refrigerator฀before฀using฀it.฀See฀the฀cleaning฀instructions฀in฀฀

“Refrigerator฀Care.”

Proper Disposal of Your Old Refrigerator

IMPORTANT:฀Child฀entrapment฀and฀suffocation฀are฀not฀problems฀

of฀the฀past.฀Junked฀or฀abandoned฀refrigerators฀are฀still฀dangerous฀

–even฀if฀they฀will฀sit฀for฀“just฀a฀few฀days.”฀If฀you฀are฀getting฀rid฀of

your฀old฀refrigerator,฀please฀follow฀these฀instructions฀to฀help

prevent฀accidents.

Before฀You฀Throw฀Away฀Your฀Old฀Refrigerator฀or฀Freezer:

Take฀off฀the฀doors.

Leave฀the฀shelves฀in฀place฀so฀that฀children฀may฀not฀easily฀

climb฀inside.

WARNING

Suffocation Hazard

Remove doors from your old refrigerator.

Failure to do so can result in death or brain damage.

Important information to know about disposal of

refrigerants:

Dispose฀of฀refrigerator฀in฀accordance฀with฀Federal฀and฀Local฀

regulations.฀Refrigerants฀must฀be฀evacuated฀by฀a฀licensed,฀

EPA฀certified฀refrigerant฀technician฀in฀accordance฀with฀

established฀procedures.

WARNING

Excessive Weight Hazard

Use two or more people to move and install

refrigerator.

Failure to do so can result in back or other injury.

When Moving Your Refrigerator:

Your฀refrigerator฀is฀heavy.฀When฀moving฀the฀refrigerator฀for฀

cleaning฀or฀service,฀be฀sure฀to฀cover฀the฀floor฀with฀

cardboard฀or฀hardboard฀to฀avoid฀floor฀damage.฀Always฀pull฀

the฀refrigerator฀straight฀out฀when฀moving฀it.฀Do฀not฀wiggle฀or฀

“walk”฀the฀refrigerator฀when฀trying฀to฀move฀it,฀as฀floor฀

damage฀could฀occur.

Important information to know about glass shelves

and covers:

Do฀not฀clean฀glass฀shelves฀or฀covers฀with฀warm฀water฀when฀

they฀are฀cold.฀Shelves฀and฀covers฀may฀break฀if฀exposed฀to฀

sudden฀temperature฀changes฀or฀impact,฀such฀as฀bumping.฀

Tempered฀glass฀is฀designed฀to฀shatter฀into฀many฀small,฀

pebble-size฀pieces.฀This฀is฀normal.฀Glass฀shelves฀and฀covers฀

are฀heavy.฀Use฀both฀hands฀when฀removing฀them฀to฀avoid฀

dropping.

Location Requirements

IMPORTANT:฀This฀refrigerator฀is฀designed฀for฀indoor฀household฀

use฀only.

To฀ensure฀proper฀ventilation฀for฀your฀refrigerator,฀allow฀for฀½"฀

(1.25cm)฀of฀space฀on฀each฀side฀and฀at฀the฀top.฀Allow฀for฀1"฀

(2.54cm)฀of฀space฀behind฀the฀refrigerator.฀If฀your฀refrigerator฀has฀

an฀ice฀maker,฀allow฀extra฀space฀at฀the฀back฀for฀the฀water฀line฀

connections.฀When฀installing฀your฀refrigerator฀next฀to฀a฀fixed฀wall,฀

leave฀a฀2"฀(5.08cm)฀minimum฀space฀on฀the฀hinge฀side฀(some฀

models฀require฀more)฀to฀allow฀the฀door฀to฀swing฀open.฀

NOTE:฀This฀refrigerator฀is฀intended฀for฀use฀in฀a฀location฀where฀the฀

temperature฀ranges฀from฀a฀minimum฀of฀55°F฀(13°C)฀to฀a฀maximum฀

of฀110°F฀(43°C).฀The฀preferred฀room฀temperatu

re฀range฀for฀

optimum฀performance

,฀which฀reduces฀electricity฀usage฀and฀

provides฀superior฀cooling,฀is฀between฀60°F฀(15°C)฀and฀90°F฀

(32°C).฀It฀is฀recommended฀that฀you฀do฀not฀install฀the฀refrigerator฀

near฀a฀heat฀source,฀such฀as฀an฀oven฀or฀radiator.

Electrical Requirements

Before฀you฀move฀your฀refrigerator฀into฀its฀final฀location,฀it฀is฀

important฀to฀make฀sure฀you฀have฀the฀proper฀electrical฀connection.

Recommended฀Grounding฀Method

A฀115-volt,฀60฀Hz,฀AC-only,฀15-฀or฀20-amp฀fused,฀grounded฀

electrical฀supply฀is฀required.฀It฀is฀recommended฀that฀a฀separate฀

circuit฀serving฀only฀your฀refrigerator฀be฀provided.฀Use฀an฀outlet฀that฀

cannot฀be฀turned฀off฀by฀a฀switch.฀Do฀not฀use฀an฀

extension฀cord.

NOTE:฀Before฀performing฀any฀type฀of฀installation,฀cleaning,

or฀removing฀a฀light฀bulb,฀turn฀cooling฀off฀or฀turn฀the฀control฀

(Thermostat,฀Refrigerator,฀or฀Freezer฀control฀depending฀on฀the฀

model)฀to฀OFF,฀and฀then฀disconnect฀the฀refrigerator฀from฀the฀

electrical฀source.฀When฀you฀are฀finished,฀reconnect฀the฀refrigerator฀

to฀the฀electrical฀source฀and฀turn฀cooling฀on฀or฀reset฀the฀control฀

(Thermostat,฀Refrigerator,฀or฀Freezer฀control฀depending฀on฀the฀

model)฀to฀the฀desired฀setting.฀See฀“Using฀the฀Controls”฀in฀the฀User฀

Instructions,฀User฀Guide,฀or฀Use฀&฀Care฀Guide.

Water Supply Requirements

Gather฀the฀required฀tools฀and฀parts฀before฀starting฀installation.฀

Read฀and฀follow฀the฀instructions฀provided฀with฀any฀tools฀listed฀

here.

TOOLS฀NEEDED:฀

NOTE:฀Your฀refrigerator฀dealer฀has฀a฀kit฀available฀with฀a฀¹⁄₄"฀

(6.35mm)฀saddle-type฀shut-off฀valve,฀a฀union,฀and฀copper฀tubing.฀

Before฀purchasing,฀make฀sure฀a฀saddle-type฀valve฀complies฀with฀

your฀local฀plumbing฀codes.฀Do฀not฀use฀a฀piercing-type฀or฀³⁄₁₆"฀

(4.76mm)฀saddle฀valve฀which฀reduces฀water฀flow฀and฀clogs฀more฀

easily.

IMPORTANT:

All฀installations฀must฀meet฀local฀plumbing฀code฀requirements.

Use฀copper฀tubing฀and฀check฀for฀leaks.฀Install฀copper฀tubing฀

only฀in฀areas฀where฀the฀household฀temperatures฀will฀remain฀

above฀freezing.

WARNING

Explosion Hazard

Keep flammable materials and vapors, such as

gasoline, away from refrigerator.

Failure to do so can result in death, explosion, or fire.

2" (1.25 cm)

2" (5.08 cm)

Flat-blade฀screwdriver

⁷⁄₁₆"฀and฀¹⁄₂"฀open-end฀or฀two฀

adjustable฀wrenches

¹⁄₄"฀nut฀driver

¹⁄₄"฀drill฀bit

Cordless฀drill

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

Water฀Pressure

A฀cold฀water฀supply฀with฀water฀pressure฀of฀between฀30฀and฀

120psi฀(207and฀827kPa)฀is฀required฀to฀operate฀the฀water฀

dispenser฀and฀ice฀maker.฀If฀you฀have฀questions฀about฀your฀water฀

pressure,฀call฀a฀licensed,฀qualified฀plumber.

Reverse฀Osmosis฀Water฀Supply

IMPORTANT:฀The฀pressure฀of฀the฀water฀supply฀coming฀out฀of฀a฀

reverse฀osmosis฀system฀going฀to฀the฀water฀inlet฀valve฀of฀the฀

refrigerator฀needs฀to฀be฀between฀30฀and฀120psi฀(207and฀

827kPa).

If฀a฀reverse฀osmosis฀water฀filtration฀system฀is฀connected฀to฀your฀

cold฀water฀supply,฀the฀water฀pressure฀to฀the฀reverse฀osmosis฀

system฀needs฀to฀be฀a฀minimum฀of฀40฀to฀60psi฀(276to฀414kPa).

If฀the฀water฀pressure฀to฀the฀reverse฀osmosis฀system฀is฀less฀than฀

40to฀60psi฀(276

to฀414kPa):

Check฀to฀see฀whether฀the฀sediment฀filter฀in฀the฀reverse฀

osmosis฀system฀is฀blocked.฀Replace฀the฀filter฀if฀necessary.

Allow฀the฀storage฀tank฀on฀the฀reverse฀osmosis฀system฀to฀refill฀

after฀heavy฀usage.

If฀you฀have฀questions฀about฀your฀water฀pressure,฀call฀a฀licensed,฀

qualified฀plumber.

Connect the Water Supply

Read฀all฀directions฀before฀you฀begin.

IMPORTANT:฀If฀you฀turn฀the฀refrigerator฀on฀before฀the฀water฀line฀is฀

connected,฀turn฀the฀ice฀maker฀off.

Connect฀to฀Water฀Line

1.Unplug฀refrigerator฀or฀disconnect฀power.

2.Turn฀off฀main฀water฀supply.฀Turn฀on฀nearest฀faucet฀long

enough฀to฀clear฀line฀of฀water.

3.Locate฀a฀½"฀to฀1¹⁄₄"฀(1.25฀cm฀to฀3.18฀cm)฀vertical฀cold฀water

pipe฀near฀the฀refrigerator.

IMPORTANT:

Make฀sure฀it฀is฀a฀cold฀water฀pipe.

Horizontal฀pipe฀will฀work,฀but฀drill฀on฀the฀top฀side฀of฀the฀

pipe,฀not฀the฀bottom.฀This฀will฀help฀keep฀water฀away฀from฀

the฀drill฀and฀normal฀sediment฀from฀collecting฀in฀the฀valve.

4.Determine฀the฀length฀of฀copper฀tubing฀you฀need.฀Measure฀

from฀the฀connection฀on฀the฀lower-left฀rear฀of฀refrigerator฀to฀the฀

water฀pipe.฀Add฀7฀ft฀(2.1฀m)฀to฀allow฀for฀cleaning.฀Use฀¹⁄₄"

(6.35฀mm)฀O.D.฀(outside฀diameter)฀copper฀tubing.฀Be฀sure฀both฀

ends฀of฀copper฀tubing฀are฀cut฀square.

5.Using฀a฀cordless฀drill,฀drill฀a฀¹⁄₄"฀hole฀in฀the฀cold฀water฀pipe฀you฀

have฀selected.฀

6.Fasten฀the฀shut-off฀valve฀to฀the฀cold฀฀water฀pipe฀with฀the฀pipe

clamp.฀Be฀sure฀the฀outlet฀end฀is฀solidly฀in฀the฀¹⁄₄"฀drilled฀hole฀in

the฀water฀pipe฀and฀that฀the฀washer฀is฀under฀the฀pipe฀clamp.

Tighten฀the฀packing฀nut.฀Tighten฀the฀pipe฀clamp฀screws฀slowly

and฀evenly฀so฀washer฀makes฀a฀watertight฀seal.฀Do฀not

overtighten฀or฀you฀may฀crush฀the฀copper฀tubing.

7.Slip฀the฀compression฀sleeve฀and฀compression฀nut฀on฀the฀

copper฀tubing฀as฀shown.฀Insert฀the฀end฀of฀the฀tubing฀into฀the฀

outlet฀end฀squarely฀as฀far฀as฀it฀will฀go.฀Screw฀compression฀nut฀

onto฀outlet฀end฀with฀adjustable฀wrench.฀Do฀not฀overtighten.

8.Place฀the฀free฀end฀of฀the฀tubing฀in฀a฀container฀or฀sink฀and฀turn฀on฀

the฀main฀water฀supply.฀Flush฀the฀tubing฀until฀water฀is฀clear.฀Turn฀

off฀the฀shut-off฀valve฀on฀the฀water฀pipe.฀Coil฀the฀copper฀tubing.

Connect฀to฀Refrigerator

1.Unplug฀refrigerator฀or฀disconnect฀power.

2.Attach฀the฀copper฀tubing฀to฀the฀valve฀inlet฀using฀a

compression฀nut฀and฀sleeve฀as฀shown.฀Tighten฀the

compression฀nut.฀Do฀not฀overtighten.

3.Use฀the฀tube฀clamp฀on฀the฀back฀of฀the฀refrigerator฀to฀secure

the฀tubing฀to฀the฀refrigerator฀as฀shown.฀This฀will฀help฀avoid

damage฀to฀the฀tubing฀when฀the฀refrigerator฀is฀pushed฀back

against฀the฀wall.

4.Turn฀shut-off฀valve฀on.

5.Check฀for฀leaks.฀Tighten฀any฀connections฀(including

connections฀at฀the฀valve)฀or฀nuts฀that฀leak.

6.The฀ice฀maker฀is฀equipped฀with฀a฀built-in฀water฀strainer.฀If฀your

water฀conditions฀require฀a฀second฀water฀strainer,฀install฀it฀in

the฀¹⁄₄"

฀(6.35mm)฀water฀line฀at฀either฀t

ube฀connection.฀Obtain

a฀water฀strainer฀from฀your฀nearest฀appliance฀dealer.

Complete฀the฀Installation

1.Plug฀into฀a฀grounded฀3฀prong฀outlet.

NOTE:฀Allow฀24฀hours฀to฀produce฀the฀first฀batch฀of฀ice.฀Discard฀

the฀first฀three฀batches฀of฀ice฀produced.฀Allow฀3days฀to฀completely฀

fill฀ice฀container.

A. Cold water pipe

B. Pipe clamp

C. Copper tubing

D. Compression nut

E. Compression sleeve

F. Shut-off valve

G. Packing nut

DEF

A. Tube clamp

B. Tube clamp screw

C. Copper tubing

D. Compression nut

E. Valve inlet

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

Refrigerator Doors

Depending฀on฀the฀width฀of฀your฀doorway,฀you฀may฀need฀to฀

remove฀the฀doors฀to฀move฀the฀refrigerator฀into฀your฀home.฀Also,฀

the฀door฀hinges฀are฀factory฀installed฀on฀the฀right-hand฀side.฀If฀you฀

want฀the฀door฀to฀open฀from฀the฀other฀direction,฀you฀must฀reverse฀

the฀door฀swing.

IMPORTANT:

Before฀you฀begin,฀turn฀the฀refrigerator฀control฀off,฀unplug฀

refrigerator฀or฀disconnect฀power.฀Remove฀food฀and฀any฀

adjustable฀door฀or฀utility฀bins฀from฀doors.

Depending฀on฀your฀model,฀your฀refrigerator฀has฀either฀

Style1฀–฀Contour฀Doors฀or฀Style฀2฀–Standard฀Doors.฀Reference฀

the฀graphic฀specific฀to฀your฀model฀later฀in฀this฀section฀

following฀“Final฀Steps.”฀

NOTE:฀A฀Reversibility฀Kit,฀which฀includes฀a฀new฀Brand฀Badge฀

and฀hole฀covers,฀is฀available.

Tools฀Needed:฀⁵⁄₁₆"฀hex-head฀socket฀wrench,฀#2฀phillips฀

screwdriver,฀flat-blade฀screwdriver,฀⁵⁄₁₆"฀open-end฀wrench,฀flat฀

2"฀putty฀knife

Remove฀Doors฀and฀Hinges

⁵⁄₁₆

" Hex-head Hinge Screw

1.Unplug฀refrigerator฀or฀disconnect฀power.

2.Using฀a฀hex-head฀socket฀wrench,฀remove฀the฀three฀⁵⁄₁₆"

hex-head฀hinge฀screws฀from฀the฀top฀hinge฀and฀lift฀up฀to

remove฀the฀hinge.฀See฀Top฀Hinge฀graphic.

NOTE:฀Provide฀additional฀support฀for฀the฀doors฀while฀the

hinges฀are฀being฀moved.฀Do฀not฀depend฀on฀the฀door฀magnets

to฀hold฀the฀doors฀in฀place฀while฀you฀are฀working.

3.Lift฀the฀freezer฀door฀off฀of฀the฀center฀hinge฀and฀set฀it฀aside.

4.Remove฀the฀washer฀from฀the฀top฀of฀the฀center฀hinge฀pin.

5.Using฀a฀hex-head฀socket฀wrench฀and฀an฀open-end฀wrench,

remove฀the฀three฀screws฀from฀the฀center฀hinge฀and฀remove

the฀hinge.฀Set฀aside.

6.Remove฀the฀washer฀from฀the฀bott

om฀of฀the฀ce

nter฀hinge฀pin.

7.Lift฀the฀refrigerator฀door฀from฀the฀bottom฀hinge฀and฀set฀aside.

8.Using฀a฀hex-head฀socket฀wrench,฀remove฀the฀four฀⁵⁄₁₆"

hex-head฀hinge฀screws฀from฀the฀bottom฀hinge฀and฀pull฀the

hinge฀from฀the฀bottom฀of฀the฀refrigerator฀door.

Reverse฀Doors฀and฀Hinges฀(optional)฀

IMPORTANT:฀If฀you฀want฀to฀reverse฀your฀doors฀so฀that฀they฀open฀

in฀the฀opposite฀direction,฀follow฀these฀steps.฀If฀you฀are฀not฀

reversing฀the฀doors,฀see฀“Replace฀Doors฀and฀Hinges.”

See฀complete฀graphics฀later฀in฀these฀instructions.

Reverse฀Center฀Hinge

1.Remove฀the฀three฀dome฀caps฀and฀screws฀from฀the฀handle

side฀and฀use฀them฀to฀fill฀the฀holes฀created฀when฀the฀hinge

screws฀were฀removed.

2.Using฀the฀three฀⁵⁄₁₆"฀hex-head฀hinge฀screws,฀removed฀in

Step1,฀insert฀two฀screws฀halfway฀into฀the฀holes,฀leaving

space฀to฀insert฀the฀center฀hinge.

3.Once฀the฀refrigerator฀door฀is฀in฀place,฀slide฀the฀center฀hinge

from฀the฀right฀onto฀the฀screws,฀insert฀the฀third฀

screw,฀and฀then

tighten฀all

฀screws฀completely.

A. Washer

A. Center hinge

⁵⁄₁₆

" hex-head hinge screws

A. Dome cap washers

B. Hex-head hinge screws

C. Dome caps

Door฀Hinge

Hole฀Plug

Cabinet฀Hinge

Hole฀Plug

Dome฀Cap

Washer

Setscrew

Shoulder

Screw

Shoulder

Screw฀Washer

Door฀Stop

Screw

Flat-Head

Handle

Screw

Door฀Handle

Hole฀Cap

NOTE:฀Make฀sure฀the฀washers฀are฀in฀place฀on฀both฀the฀top฀

and฀bottom฀pins฀of฀the฀center฀hinge.฀

Reverse฀Freezer฀Door฀

1.Remove฀the฀three฀cabinet฀hole฀plugs฀from฀the฀top฀of฀the

cabinet฀and฀place฀them฀in฀the฀hinge฀holes฀on฀the฀opposite

side.

2.Remove฀the฀door฀handles.

■ Remove฀the฀two฀flat-head฀handle฀screws฀from฀the฀bottom

of฀the฀freezer฀door฀handle.

■ Using฀the฀¹⁄₈"฀hex฀key,฀loosen฀the฀setscrew฀attaching฀the

top฀of฀the฀handle.

■ Pull฀the฀handle฀away฀from฀the฀door฀to฀release฀it฀from฀the

shoulder฀screw.฀Keep฀all฀parts฀together.

3.Using฀the฀plastic฀tool฀(provided),฀remove฀the฀brand฀badge

from฀the฀freezer฀door฀by฀prying฀up฀the฀right-hand฀side฀and

slowly฀peeling฀the฀badge฀away฀from฀the฀door,฀revealing฀the

hole฀to฀mount฀the฀door฀handle.

NOTES:

■ To฀avoid฀scratching฀the฀finish,฀do฀not฀use฀a฀sharp฀or

metallic฀object฀to฀pry฀the฀brand฀badge฀from฀the฀door.

■ Rub฀a฀small฀amount฀of฀liquid฀dish฀soap฀over฀any฀adhesive

residue฀with฀your฀fingers.฀Rinse฀the฀door฀with฀warm฀water

and฀dry฀with฀a฀soft฀cloth.

4.Remove฀the฀shoulder฀screw฀and฀its฀washer฀from฀the฀left-hand

side฀of฀the฀door฀and฀fasten฀it฀into฀the฀hole฀that฀was฀behind฀the

brand฀badge.

5.Remove฀the฀door฀stop฀from฀the฀bottom฀of฀the฀freezer฀door.

6.Move฀the฀door฀stop฀to฀the฀opposite฀side,฀making฀sure฀that฀the

hole฀in฀the฀door฀stop฀plate฀is฀aligned฀perfectly฀with฀the฀hole฀for

the฀center฀hinge฀pin.

7.Using฀the฀screw฀removed฀earlier,฀fasten฀the฀door฀stop฀to฀the

bottom฀of฀the฀freezer฀door.

8.Place฀the฀handle฀on฀the฀shoulder฀screw฀and฀push฀the฀handle

toward฀the฀door฀until฀the฀mounting฀base฀is฀flush฀against฀the

door.

9.Fasten฀the฀bottom฀of฀the฀handle฀to฀the฀bottom฀of฀the฀freezer

door.

10.Tighten฀all฀screws.฀Set฀aside฀the฀freezer฀door฀until฀the฀hinges

and฀refrigerator฀door฀are฀in฀place.

Reverse฀Refrigerator฀Door฀

1.Remove฀the฀door฀stop฀from฀the฀bottom฀of฀the฀refrigerator

door.

2.Replace฀the฀door฀stop฀on฀the฀opposite฀side฀of฀the฀refrigerator

door,฀making฀sure฀that฀the฀hole฀in฀the฀door฀stop฀plate฀is

aligned฀perfectly฀with฀the฀hole฀for฀the฀bottom฀hinge฀pin.

3.Fasten฀the฀door฀stop฀to฀the฀door.

4.Remove฀the฀door฀handles.

■ Remove฀the฀screws฀from฀the฀top฀of฀the฀refrigerator฀door

handle.

■ Remove฀the฀setscrew฀from฀the฀lower฀part฀of฀the฀handle.

■ Pull฀the฀handle฀away฀from฀the฀door฀to฀release฀it฀from฀the

shoulder฀screw.฀Keep฀all฀parts฀together.

⁵⁄₁₆

" Hex-head hinge screws

B. Washers

A. Cabinet hole plugs

A. Shoulder screw

B. Setscrew

C. Flat-head handle screws

A. Door stop screw

B. Door stop

A. Door stop screw

B. Door stop

5.Remove฀the฀cap฀covering฀the฀hole฀on฀the฀opposite฀side฀of฀the

door฀where฀the฀refrigerator฀door฀handle฀will฀be฀installed฀and

discard฀the฀cap.

6.Remove฀the฀shoulder฀screw฀and฀its฀washer฀from฀the฀left-hand

side฀of฀the฀door฀and฀fasten฀it฀into฀the฀hole฀that฀was฀behind฀the

cap.

7.Place฀the฀handle฀on฀the฀shoulder฀screw฀and฀push฀the฀handle

toward฀the฀door฀until฀the฀mounting฀base฀is฀flush฀against฀the

door.

8.Fasten฀the฀top฀of฀the฀refrigerator฀handle฀to฀the฀top฀of฀the

refrigerator฀door.

9.Cover฀the฀remaining฀hole฀with฀the฀cap฀(provided).

10.Remove฀door฀hinge฀hole฀plug฀from฀the฀

refrigerator฀door.฀Move

to฀opposite฀side.

11.Tighten฀all฀screws.฀Set฀aside฀refrigerator฀door฀until฀bottom

hinge฀is฀installed฀on฀the฀opposite฀side฀of฀the฀refrigerator.

Reverse฀Top฀Hinge฀-฀Contour฀door฀models฀only฀

1.Remove฀the฀screw฀attaching฀the฀hinge฀pin฀to฀the฀hinge.฀Turn

the฀hinge฀over฀so฀that฀it฀is฀pointing฀in฀the฀opposite฀direction.

2.Place฀the฀plastic฀spacer฀beneath฀the฀hinge฀so฀that฀it฀will฀be

between฀the฀hinge฀and฀the฀cabinet,฀making฀sure฀the฀holes

are฀aligned.

3.Fasten฀the฀top฀hinge฀to฀the฀opposite฀side฀of฀the฀cabinet,

inserting฀the฀screws฀only฀halfway,฀so฀you฀will฀be฀able฀to

replace฀an

d฀align฀the฀freezer฀door฀later.

Replace฀Doors฀and฀Hinges฀

IMPORTANT:฀Provide฀additional฀support฀for฀the฀doors฀while฀the฀

hinges฀are฀being฀moved.฀Do฀not฀depend฀on฀the฀door฀magnets฀to฀

hold฀the฀doors฀in฀place฀while฀you฀are฀working.

Install฀Refrigerator฀Door

1.Insert฀the฀hinge฀pin฀into฀the฀bottom฀hinge฀of฀the฀refrigerator

door฀and฀fasten฀the฀hinge฀to฀the฀cabinet.฀Do฀not฀tighten฀

completely.

2.Place฀the฀washer฀on฀top฀of฀the฀bottom฀hinge฀pin.

3.Place฀the฀refrigerator฀door฀onto฀the฀bottom฀hinge฀pin.

4.Measure฀the฀distance฀from฀the฀bottom฀of฀the฀refrigerator฀door

to฀the฀floor.฀The฀distance฀should฀be฀approximately฀1⁴⁄₅"

(4.6cm).

NOTE:฀If฀necessary,฀loosen฀the฀bottom฀hinge,฀without

removing฀the฀screws,฀adjust฀the฀door฀to฀the฀correct฀height฀and

fully฀tighten฀the฀screws.

A. Flat-head handle screws

B. Setscrew

A. Plastic spacer

B. Hinge pin screw

C. Hinge pin

⁵⁄₁₆

" hex-head hinge screws

B. Top hinge pin

C. Plastic spacer

A. Bottom hinge

CCA

Install฀Freezer฀Door

1.Place฀washer฀on฀the฀upper฀hinge฀pin฀of฀the฀center฀hinge.

2.Place฀the฀freezer฀door฀on฀the฀upper฀hinge฀pin฀of฀the฀center฀

hinge.

3.Insert฀the฀top฀hinge฀pin฀into฀the฀drilled฀hole฀in฀the฀top฀of฀the฀

freezer฀door.฀Do฀not฀tighten฀the฀screws฀completely.

4.Align฀the฀doors฀so฀that฀the฀bottom฀of฀the฀freezer฀door฀aligns฀

evenly฀with฀the฀top฀of฀the฀refrigerator฀door.฀Tighten฀all฀screws.฀

NOTE:฀The฀distance฀between฀the฀doors฀should฀be฀

approximately฀³⁄₄"฀(19฀mm).฀

Final฀Steps

1.Plug฀in฀the฀refrigerator฀or฀reconnect฀the฀power.

2.Reset฀the฀controls.฀See฀“Using฀the฀Controls.”

3.Return฀all฀removable฀door฀parts฀to฀doors฀and฀food฀to

refrigerator.

Style฀1–Contour฀Door

Door Swing Reversal (optional)

1-2

A.฀Door฀Hinge฀Hole฀Plug

A.฀Door฀Stop

B.฀Door฀Stop฀Screw

Removal of Door Stops

A.฀Cabinet฀Hinge฀Hole฀Plugs

Door Removal &

Replacement

A.฀Door฀Stop

B.฀Door฀Stop฀Screw

Reinstallation of Door Stops

Center Hinge

Top Hinge

1-1

A.฀

"฀Hex-Head฀Hinge฀

Screws,฀฀

Dome฀Caps฀and฀Dome฀Cap฀Washers

"฀Hex-Head฀Hinge฀Screws

A.Center฀Hinge

B.Top฀Hinge฀

C.Hinge฀Pin

A.DoorHandle

HoleCap

A.Bottom฀Hinge

Bottom Hinge

B.Washer

"฀Hex-Head฀Hinge฀Screws

A.Flat-Head฀Handle฀Screw

B.Setscrew

A.Shoulder฀Screw

B.Setscrew

C.Flat-Head฀Handle฀Screw

Style฀2–Standard฀Doors

Door Removal &

Replacement

Door Swing Reversal (optional)

A.Door฀Hinge฀Hole฀Plug

A.Door฀Handle฀Sealing฀Screws

A.Cabinet฀Hinge฀Hole฀Plugs

1-2

Top Hinge

"฀Hex-Head฀Hinge฀Screws

C.Top฀Hinge

A.Top฀Hinge฀Cover

A.Door฀Handle

Hole฀Cap

1-1

A.฀

"฀Hex-Head฀Hinge฀

Screws,฀฀

Dome฀Caps฀and฀Dome฀Cap฀Washers

Center Hinge

"฀Hex-Head฀Hinge฀Screws

A.Center฀Hinge

A.Bottom฀Hinge

Bottom Hinge

B.Washer

"฀Hex-Head฀Hinge฀Screws

A.Door฀Stop฀Screw

Door฀Stop

Side฀View

Front฀View

A.Flat-Head฀Handle฀Screw

B.Setscrew

A.Shoulder฀Screw

B.Setscrew

C.Flat-Head฀Handle฀Screw

Reversibility Kit Instructions

If฀your฀model฀came฀with฀a฀Reversibility฀kit,฀please฀use฀the฀Brand฀

Badge฀Placement฀template฀and฀the฀following฀instructions฀to฀install฀

the฀Brand฀Badge฀on฀the฀opposite฀side฀of฀the฀freezer฀door.฀

Parts฀Included:

Brand฀badge฀removal฀tool

Brand฀badge฀template฀(on฀last฀page฀of฀User฀Instructions)

Door฀handle฀hole฀cap฀

Tools฀Needed:

Scissors

Masking฀tape

Freezer฀Door

1.Using฀the฀removal฀tool฀(provided),฀remove฀the฀brand฀badge

from฀the฀freezer฀door฀by฀lifting฀up฀the฀right-hand฀side฀and

peeling฀the฀badge฀away฀from฀the฀door฀from฀right฀to฀left.

NOTE:฀To฀avoid฀scratching฀the฀door,฀do฀not฀use฀a฀sharp฀or

metallic฀object฀to฀pry฀the฀brand฀badge฀from฀the฀door.

2.Rub฀a฀small฀amount฀of฀liquid฀dish฀soap฀over฀any฀adhesive

residue฀with฀your฀fingers.฀Rinse฀the฀door฀with฀warm฀water฀and

dry฀with฀a฀soft฀cloth.

3.Cut฀the฀template฀along฀the฀dotted฀lines฀that฀match฀the฀shape

of฀the฀brand฀badge.

4.Align฀the฀edges฀of฀the฀template฀with฀the฀side฀and฀top฀of฀the

freezer฀door฀and฀tape฀the฀template฀to฀the฀door.

NOTE:฀When฀the฀template฀is฀correctly฀aligned,฀the฀hole฀in฀the

door,฀where฀the฀handle฀was,฀will฀be฀within฀the฀cutout฀of฀the

template,฀as฀shown.

5.Using฀the฀cutout฀as฀a฀guide,฀press฀the฀brand฀badge฀onto฀the

freezer฀door฀making฀sure฀that฀the฀hole฀is฀completely฀covered.

6.Slowly฀remove฀the฀template.

Adjust the Doors

IMPORTANT:฀Your฀refrigerator฀complies฀with฀American฀

Disabilities฀Act฀(ADA)฀guidelines.

Door฀Closing

Your฀refrigerator฀has฀two฀front฀adjustable฀levelers฀-฀one฀on฀the฀

right฀and฀one฀on฀the฀left.฀If฀your฀refrigerator฀seems฀unsteady฀or฀

you฀want฀the฀doors฀to฀close฀easier,฀adjust฀the฀refrigerator's฀tilt฀

using฀the฀following฀instructions:

1.Turn฀the฀leveler฀to฀lower฀or฀raise฀that฀side฀of฀the฀refrigerator.฀It

may฀take฀several฀turns฀to฀adjust฀the฀tilt฀of฀the฀refrigerator.

■ To฀raise,฀turn฀the฀leveler฀to฀the฀right.

■ To฀lower,฀turn฀the฀leveler฀to฀the฀left.

NOTE:฀Having฀someone฀push฀against฀the฀top฀of฀the฀

refrigerator฀takes฀some฀weight฀off฀the฀levelers฀and฀rollers฀

which฀makes฀it฀easier฀to฀adjust.

2.Open฀both฀doors฀again฀to฀make฀sure฀they฀close฀as฀easily฀as

you฀like.฀If฀not,฀tilt฀the฀refrigerator฀slightly฀more฀to฀the฀rear฀by

turning฀both฀leveling฀legs฀to฀the฀left;฀it฀may฀take฀several฀more

turns.

NOTE:฀To฀keep฀the฀refrigerator฀level,฀you฀should฀turn฀both

leveling฀legs฀the฀same฀amount.

3.Using฀a฀level,฀be฀sure฀that฀the฀refrigerator฀is฀still฀level฀side฀to

side.฀Readjust฀if฀necessary.

Door฀Aligning

If฀the฀space฀between฀your฀doors฀looks฀uneven,฀you฀can฀adjust฀it฀

using฀the฀following฀instructions:

1.Depending฀on฀your฀model,฀remove฀the฀top฀hinge฀cover.

2.Loosen฀the฀top฀hinge฀screws฀using฀a฀⁵⁄₁₆"฀socket฀or฀wrench.

3.Have฀someone฀hold฀the฀door฀in฀place฀or฀put฀a฀spacer฀between

the฀doors฀while฀you฀tighten฀the฀top฀hinge฀screws.

4.Replace฀the฀top฀hinge฀cover,฀if฀removed฀in฀Step฀1.

REFRIGERATOR USE

Using the Controls

Your฀refrigerator฀has฀two฀controls฀that฀affect฀the฀temperature.฀The฀

Temperature฀control฀is฀located฀at฀the฀top฀front฀of฀the฀refrigerator฀

compartment฀and฀the฀Airflow฀control฀is฀located฀on฀the฀back฀wall฀

of฀the฀freezer฀compartment.

IMPORTANT:฀

The฀recommended฀setting฀should฀be฀correct฀for฀normal฀

household฀refrigerator฀use.฀The฀controls฀are฀set฀correctly฀

when฀milk฀or฀juice฀is฀as฀cold฀as฀you฀like฀and฀when฀ice฀cream฀

is฀firm.

Wait฀24฀hours฀for฀your฀refrigerator฀to฀cool฀completely฀before฀

adding฀food.฀If฀you฀add฀food฀before฀the฀refrigerator฀has฀cooled฀

completely,฀your฀food฀may฀spoil.

NOTE:฀Adjusting฀the฀refrigerator฀and฀freezer฀temperature฀

controls฀to฀a฀colder฀than฀recommended฀setting฀will฀not฀cool฀

the฀compartments฀any฀faster.

If฀the฀temperature฀is฀too฀warm฀or฀too฀cold฀in฀the฀refrigerator฀

or฀freezer,฀first฀check฀the฀air฀vents฀to฀be฀sure฀they฀are฀not฀

blocked฀before฀adjusting฀the฀controls.

Temperature฀Control

For฀your฀convenience,฀the฀temperature฀control฀is฀preset฀at฀the฀

factory.฀When฀you฀first฀install฀your฀refrigerator,฀make฀sure฀the฀

control฀is฀still฀preset฀as฀shown.

Recommended฀Setting฀

Cooling฀Off/On

To฀turn฀cooling฀off,฀press฀and฀hold฀TEMP฀SETTING฀for฀

4seconds฀until฀all฀lights฀turn฀on฀for฀1฀second.฀To฀turn฀cooling฀

back฀on,฀press฀and฀hold฀TEMP฀SETTING฀again฀for฀4seconds.฀

NOTE:฀Neither฀compartment฀will฀cool฀when฀the฀control฀is฀set฀to฀

OFF.฀฀฀

Adjusting฀the฀Temperature฀Control

If฀you฀need฀to฀adjust฀the฀temperature฀in฀either฀the฀refrigerator฀or฀

freezer฀compartment,฀use฀the฀settings฀listed฀in฀the฀following฀chart฀

as฀a฀guide.

NOTE:฀Except฀when฀starting฀the฀refrigerator,฀do฀not฀adjust฀the฀

control฀more฀than฀one฀setting฀at฀a฀time.฀Wait฀24฀hours฀between฀

adjustments฀for฀the฀temperature฀to฀stabilize.฀

Press฀TEMP฀SETTING฀to฀toggle฀between฀the฀four฀LED฀lights฀

which฀indicate฀the฀temperature฀setting.฀Reading฀from฀left฀to฀

right,฀the฀LED฀in฀the฀first฀position฀is฀the฀least฀cold.฀The฀LEDs฀

indicate฀increasingly฀colder฀settings฀as฀you฀continue฀to฀the฀

right฀until฀all฀four฀LEDs฀are฀illuminated.฀

NOTE:฀For฀the฀first฀to฀fourth฀setting,฀only฀one฀LED฀of฀the฀four฀

LEDs฀will฀be฀lit.฀All฀four฀LEDs฀will฀be฀lit฀when฀you฀have฀

reached฀the฀coldest฀setting.฀

Additional฀Feature฀

PowerCold฀฀Feature฀

The฀PowerCold฀฀feature฀sets฀the฀freezer฀and฀refrigerator฀to฀the฀

lowest฀temperature฀settings฀to฀assist฀with฀periods฀of฀high฀

refrigerator฀use,฀full฀grocery฀loads,฀or฀temporarily฀warm฀room฀

temperatures.฀

To฀turn฀on฀the฀PowerCold฀฀feature,฀press฀TEMP฀SETTING฀

continually฀until฀all฀the฀LED฀lights฀are฀blinking฀on/off฀

progressively฀from฀left฀to฀right.฀Press฀TEMP฀SETTING฀again฀to฀

return฀to฀the฀COLD฀set฀point.

NOTE:฀Depending฀on฀the฀environment฀conditions,฀the฀

PowerCold฀฀feature฀will฀remain฀activated฀up฀to฀24฀hours.฀When฀

the฀feature฀turns฀off,฀the฀temperature฀will฀return฀to฀the฀

recommended฀set฀point.฀

Airflow฀Control

The฀Airflow฀control฀regulates฀the฀amount฀of฀air฀flowing฀between฀

the฀freezer฀and฀the฀refrigerator฀compartments.฀

When฀you฀plug฀in฀the฀refrigerator฀for฀the฀first฀time,฀turn฀the฀Airflow฀

control฀to฀the฀Recommended฀setting.฀

Adjusting฀the฀Airflow฀Control

If฀you฀want฀to฀temporarily฀increase฀the฀cold฀airflow฀to฀a฀specific฀

compartment,฀adjust฀the฀control.

Max฀-฀Increase฀airflow฀to฀the฀freezer.

Min฀-฀Increase฀airflow฀to฀the฀refrigerator.

IMPORTANT:฀Once฀the฀performance฀is฀achieved,฀return฀the฀

Airflow฀control฀to฀the฀Recommended฀setting฀to฀keep฀the฀

refrigerator฀operating฀at฀optimum฀efficiency.฀

CONDITION/REASON:ADJUSTMENT:

REFRIGERATOR฀too฀warmTEMP฀SETTING฀control฀one฀

setting฀higher฀

FREE

ZER฀too

฀warm/

oo฀little฀ice

AIRFLOW฀or฀TEMP฀SETTING฀

control฀one฀setting฀higher

REFRIGERATOR฀too฀coldTEMP฀SETTING฀control฀one฀

setting฀lower

FREEZER฀too฀coldAIRFLOW฀or฀TEMP฀SETTING฀

control฀one฀setting฀lower

CONDITION/REASON:ADJUSTMENT:

Heavy฀ice฀useMax฀

Hot฀room฀temperatureMax฀-฀t฀o฀maintain฀ice-making฀

production฀rate

Large฀quantity฀of฀groceriesMin฀-฀t฀o฀quickly฀chill฀food฀and฀

beverages

REFRIGERATOR FEATURES

Your฀model฀may฀have฀some฀or฀all฀of฀these฀features.

Refrigerator Shelves

The฀shelves฀in฀your฀refrigerator฀are฀adjustable฀to฀match฀your฀

individual฀storage฀needs.

Storing฀similar฀food฀items฀together฀in฀your฀refrigerator฀and฀

adjusting฀the฀shelves฀to฀fit฀different฀heights฀of฀items฀will฀make฀

finding฀the฀exact฀item฀you฀want฀easier.฀It฀will฀also฀reduce฀the฀

amount฀of฀time฀the฀refrigerator฀door฀is฀open,฀and฀save฀energy.

To฀remove฀and฀replace฀a฀shelf:

1.Remove฀items฀from฀the฀shelf.

2.Slide฀the฀shelf฀straight฀out฀to฀the฀stop.

3.Depending฀on฀your฀model,฀lift฀back฀or฀front฀of฀the฀shelf฀past

the฀stop.฀Slide฀shelf฀out฀the฀rest฀of฀the฀way.

4.Replace฀the฀shelf฀by฀sliding฀the฀back฀of฀the฀shelf฀into฀the฀

track

in฀the฀wall฀of

฀the฀cabinet.

5.Guide฀the฀front฀of฀the฀shelf฀into฀the฀shelf฀track.฀Be฀sure฀to฀slide

the฀shelf฀in฀all฀the฀way.

Deli Drawer

The฀deli฀drawer฀design฀allows฀flexible฀positioning.฀

Deli฀Drawer

To฀remove฀and฀replace฀the฀deli฀drawer:

1.Slide฀deli฀drawer฀out฀to฀the฀stop.

2.Lift฀front฀of฀deli฀drawer฀with฀one฀hand฀while฀supporting฀bottom

of฀drawer฀with฀other฀hand.฀Slide฀drawer฀out฀the฀rest฀of฀the

way.

3.Replace฀the฀drawer฀by฀sliding฀it฀back฀in฀fully฀past฀the฀drawer

stop.

Meat฀Storage฀Guide

Store฀most฀meat฀in฀original฀wrapping฀as฀long฀as฀it฀is฀airtight฀and฀

moisture-proof.฀Rewrap฀if฀necessary.฀See฀the฀following฀chart฀for฀

storage฀times.฀When฀storing฀meat฀longer฀than฀the฀times฀given,฀

freeze฀the฀meat.

Fresh฀fish฀or฀shellfish.........................Use฀same฀day฀as฀purchased

Chicken,฀ground฀beef,฀variety฀meats฀(liver)......................1-2฀days

Cold฀cuts,฀steaks/roasts..................................................3-5฀days

Cured฀meats...................................................................7-10฀days

Leftovers฀-฀Cover฀leftovers฀w

ith฀plastic฀wrap,฀a

luminum฀foil,฀or฀

plastic฀containers฀with฀tight฀lids.

Crisper

Crisper฀Drawers

To฀remove฀and฀replace฀the฀crisper฀drawer:

1.Slide฀the฀crisper฀drawer฀straight฀out฀to฀the฀stop.฀Lift฀the฀front

and฀slide฀the฀drawer฀out฀the฀rest฀of฀the฀way.

2.Replace฀the฀drawer฀by฀sliding฀the฀drawer฀in฀fully฀past฀the฀stop.

Crisper฀Cover

To฀remove฀and฀replace฀the฀crisper฀cover:

1.Remove฀the฀crisper(s).

2.Pull฀the฀glass฀straight฀out.

3.Replace฀the฀glass฀by฀pushing฀it฀straight฀in.

Crisper฀Humidity฀Control

You฀can฀control฀the฀amount฀of฀humidity฀in฀the฀moisture-sealed฀

crisper.฀Adjust฀the฀control฀to฀LOW฀or฀HIGH.

LOW฀(open)฀lets฀moist฀air฀out฀of฀the฀crisper฀for฀best฀storage฀of฀

fruits฀and฀vegetables฀with฀skins.฀

Fruit:฀Wash,฀let฀dry,฀and฀store฀in฀refrigerator฀in฀plastic฀bag฀or฀

crisper.฀Do฀not฀wash฀or฀hull฀berries฀until฀they฀are฀ready฀to฀use.฀

Sort฀and฀keep฀berries฀in฀original฀container฀in฀crisper฀or฀store฀in฀

a฀loosely฀closed฀paper฀bag฀on฀a฀refrigerator฀shelf.

Vegetables฀with฀skins:฀Place฀in฀plastic฀bag฀or฀plastic฀container฀

and฀store฀in฀crisper.฀

HIGH฀(closed)฀keeps฀moist฀air฀in฀the฀crisper฀for฀best฀storage฀of฀

fresh,฀leafy฀vegetables.฀

Leafy฀vegetables:฀Wash฀in฀cold฀water,฀drain,฀and฀trim฀or฀tear฀off฀

bruised฀and฀discolored฀areas.฀Place฀in฀plastic฀bag฀or฀plastic฀

container฀and฀store฀in฀crisper.

Important information to know about glass shelves

and covers:

Do฀not฀clean฀glass฀shelves฀or฀covers฀with฀warm฀water฀when฀

they฀are฀cold.฀Shelves฀and฀covers฀may฀break฀if฀exposed฀to฀

sudden฀temperature฀changes฀or฀impact,฀such฀as฀bumping.฀

Tempered฀glass฀is฀designed฀to฀shatter฀into฀many฀small,฀

pebble-size฀pieces.฀This฀is฀normal.฀Glass฀shelves฀and฀covers฀

are฀heavy.฀Use฀both฀hands฀when฀removing฀them฀to฀avoid฀

dropping.

FREEZER FEATURES

Your฀model฀may฀have฀some฀or฀all฀of฀these฀features.฀

Freezer Shelf

Depending฀on฀your฀model,฀the฀shelf฀may฀be฀wire฀or฀glass.

To฀remove฀and฀replace฀a฀shelf:

1.Remove฀items฀from฀the฀shelf.

2.Slide฀the฀shelf฀straight฀out฀to฀the฀stop.

3.Depending฀on฀your฀model,฀lift฀back฀or฀front฀of฀the฀shelf฀past

the฀stop.฀Slide฀shelf฀out฀the฀rest฀of฀the฀way.

4.Replace฀the฀shelf฀by฀sliding฀the฀back฀of฀the฀shelf฀into฀the฀track

in฀the฀wall฀of฀the฀cabinet.

5.Guide฀the฀front฀of฀the฀shelf฀into฀the฀shelf฀track.฀Be฀sure฀to฀slide

the฀shelf฀in฀all฀the฀way.

Frozen฀Food฀Storage฀Guide

Storage฀times฀will฀vary฀according฀to฀the฀quality฀and฀type฀of฀food,฀

the฀type฀of฀packaging฀or฀wrap฀used฀(should฀be฀airtight฀and฀

moisture-proof),฀and฀the฀storage฀temperature.฀Seal฀the฀package฀

or฀container฀securely฀to฀avoid฀taste฀and฀odor฀transfer฀throughout฀

the฀product.฀Ice฀crystals฀inside฀a฀sealed฀package฀are฀normal.฀This฀

simply฀means฀that฀moisture฀in฀the฀food฀and฀air฀inside฀the฀package฀

have฀condensed,฀creating฀ice฀crystals.

Put฀no฀more฀unfrozen฀food฀into฀the฀freezer฀than฀will฀freeze฀within฀

24hours฀(no฀more฀than฀2฀to฀3lbs฀of฀food฀per฀cubic฀foot฀[907฀to฀

1,350g฀per฀L]฀of฀freezer฀space).฀Leave฀enough฀space฀in฀the฀

freezer฀for฀air฀to฀circulate฀around฀packages.฀The฀freezer฀door฀must฀

close฀tightl

y.฀

NOTE:฀For฀mor

e฀information฀on฀preparing฀food฀for฀freezing,฀check฀

a฀freezer฀guide฀or฀reliable฀cookbook.

DOOR FEATURES

Your฀model฀may฀have฀some฀or฀all฀of฀these฀features.฀

Door Rails

The฀door฀rails฀may฀be฀removed฀for฀easier฀cleaning.

To฀remove฀and฀replace฀the฀rails:

1.Depending฀on฀your฀model,฀remove฀the฀rails฀by฀pushing฀in

slightly฀on฀the฀front฀of฀the฀bracket฀while฀pulling฀out฀on฀the

inside฀tab.฀Repeat฀these฀steps฀for฀the฀other฀end.

2.Replace฀the฀rails฀by฀aligning฀the฀ends฀of฀the฀brackets฀with฀the

buttons฀on฀the฀sides฀of฀the฀door฀liner.฀Firmly฀snap฀bracket฀and

assembly฀onto฀the฀tabs฀above฀the฀shelf฀as฀shown.

Door Bins

To฀remove฀and฀replace฀the฀bins:

1.Remove฀the฀bin฀by฀lifting฀it฀and฀pulling฀it฀straight฀out.

2.Replace฀the฀bin฀by฀sliding฀it฀in฀above฀the฀desired฀support฀and

pushing฀it฀down฀until฀it฀stops.

Utility Compartment

The฀utility฀compartment฀may฀be฀removed฀for฀easier฀cleaning.

To฀remove฀and฀replace฀the฀utility฀compartment:

1.Remove฀the฀utility฀compartment฀by฀squeezing฀against฀one

side฀while฀raising฀the฀utility฀compartment฀up฀and฀pulling฀it

straight฀out.

2.Replace฀the฀utility฀compartment฀by฀positioning฀one฀side฀in฀the

lock฀and฀sliding฀in฀the฀opposite฀side฀until฀it฀stops.

Important information to know about glass shelves

and covers:

Do฀not฀clean฀glass฀shelves฀or฀covers฀with฀warm฀water฀when฀

they฀are฀cold.฀Shelves฀and฀covers฀may฀break฀if฀exposed฀to฀

sudden฀temperature฀changes฀or฀impact,฀such฀as฀bumping.฀

Tempered฀glass฀is฀designed฀to฀shatter฀into฀many฀small,฀

pebble-size฀pieces.฀This฀is฀normal.฀Glass฀shelves฀and฀covers฀

are฀heavy.฀Use฀both฀hands฀when฀removing฀them฀to฀avoid฀

dropping.

Ice Maker

IMPORTANT:฀For฀models฀with฀a฀water฀filter,฀after฀connecting฀the฀

refrigerator฀to฀a฀water฀source฀or฀replacing฀the฀water฀filter,฀fill฀and฀

discard฀three฀full฀containers฀of฀ice฀to฀prepare฀the฀water฀filter฀for฀

use.฀

Turning฀the฀Ice฀Maker฀On/Off

To฀turn฀the฀ice฀maker฀on,฀simply฀lower฀the฀wire฀shut-off฀arm.

To฀manually฀turn฀the฀ice฀maker฀off,฀lift฀the฀wire฀shut-off฀arm฀to฀the฀

Off฀(arm฀up)฀position฀and฀listen฀for฀the฀click.

NOTE:฀Your฀ice฀maker฀has฀an฀automatic฀shutoff.฀As฀ice฀is฀made,฀

the฀ice฀cubes฀will฀fill฀the฀ice฀storage฀bin฀and฀the฀ice฀cubes฀will฀

raise฀the฀wire฀shut-off฀arm฀to฀the฀Off฀(arm฀up)฀position.฀Do฀not฀

force฀the฀wire฀shut-off฀arm฀up฀or฀down.

Ice฀Storage฀Bin

1.Wash฀the฀ice฀storage฀bin฀with฀mild฀soap฀and฀warm฀water.

2.Slide฀the฀ice฀storage฀bin฀under฀the฀ice฀maker฀and฀push฀it

toward฀the฀back฀as฀far฀as฀it฀will฀go.

3.Lower฀the฀arm฀on฀the฀ice฀maker฀to฀the฀“On”฀position.

NOTE:฀It฀usually฀takes฀approximately฀24฀hours฀for฀the฀ice

maker฀to฀begin฀producing฀ice.฀You฀may฀notice฀the฀ice฀has

an฀“off-taste.”฀If฀so,฀discard฀the฀first฀three฀batches฀of฀ice

produced.฀After฀that฀the฀“off-taste”฀should฀be฀gone.

Ice฀Production฀Rate

The฀ice฀maker฀should฀produce฀approximately฀8฀to฀12batches฀

of฀ice฀in฀a฀24-hour฀period.฀Allow฀3days฀to฀completely฀fill฀the฀

ice฀container.฀

To฀increase฀ice฀production,฀lower฀the฀freezer฀and฀refrigerator฀

temperatures.฀See฀“Using฀the฀Controls.”฀Wait฀24hours฀

between฀adjustments.

Remember

The฀quality฀of฀your฀ice฀will฀be฀only฀as฀good฀as฀the฀quality฀of฀the฀

water฀supplied฀to฀your฀ice฀maker.฀Avoid฀connecting฀the฀ice฀

maker฀to฀a฀softened฀water฀supply.฀Water฀softener฀chemicals฀

(such฀as฀salt)฀can฀damage฀parts฀of฀the฀ice฀maker฀and฀lead฀to฀

poor฀quality฀ice.฀If฀a฀softened฀water฀supply฀cannot฀be฀avoided,฀

make฀sure฀the฀water฀softener฀is฀operating฀properly฀and฀is฀well฀

maintained.

Do฀not฀use฀anything฀sharp฀to฀break฀up฀the฀ice฀in฀the฀bin.฀This฀

can฀cause฀damage฀to฀the฀ice฀storage฀bin฀and฀the฀dispenser฀

mechanism.

Do฀not฀store฀anything฀on฀top฀of฀or฀in฀the฀ice฀maker฀or฀ice฀

storage฀bin.฀

REFRIGERATOR CARE

Cleaning

Both฀the฀refrigerator฀and฀freezer฀sections฀defrost฀automatically.฀

However,฀clean฀both฀sections฀about฀once฀a฀month฀to฀avoid฀

buildup฀of฀odors.฀Wipe฀up฀spills฀immediately.

IMPORTANT:

Because฀air฀circulates฀between฀both฀sections,฀any฀odors฀

formed฀in฀one฀section฀will฀transfer฀to฀the฀other.฀You฀must฀

thoroughly฀clean฀both฀sections฀to฀eliminate฀odors.฀To฀avoid฀

odor฀transfer฀and฀drying฀out฀of฀food,฀wrap฀or฀cover฀foods฀

tightly.

For฀stainless฀steel฀models,฀stainless฀steel฀is฀corrosion-

resistant฀and฀not฀corrosion-proof.฀To฀help฀avoid฀corrosion฀of฀

your฀stainless฀steel,฀keep฀your฀surfaces฀clean฀by฀using฀the฀

following฀cleaning฀instructions.

To฀Clean฀Your฀Refrigerator:

NOTE:฀Do฀not฀use฀abrasive฀or฀harsh฀cleaners฀such฀as฀window฀

sprays,฀scouring฀cleansers,฀flammable฀fluids,฀muriatic฀acid,฀

cleaning฀waxes,฀concentrated฀detergents,฀bleaches,฀or฀cleansers฀

containing฀petroleum฀products฀on฀exterior฀surfaces฀(doors฀and฀

cabinet),฀plastic฀parts,฀interior฀and฀door฀liners,฀or฀gaskets.฀Do฀not฀

use฀paper฀towels,฀scouring฀pads,฀or฀other฀harsh฀cleaning฀tools.

1.Unplug฀refrigerator฀or฀disconnect฀power.

2.Hand฀wash,฀rinse,฀and฀dry฀removable฀parts฀and฀interior

surfaces฀thoroughly.฀Use฀a฀clean฀sponge฀or฀soft฀cloth฀and฀a

mild฀detergent฀in฀warm฀water.

3.Clean฀the฀exterior฀surfaces.

Painted฀metal:฀Wash฀painted฀metal฀exteriors฀with฀a฀clean,

soft฀cloth฀or฀sponge฀and฀a฀mild฀detergent฀in฀warm฀water.

Rinse฀surfaces฀with฀clean,฀warm฀water฀and฀dry฀immediately฀to

avoid฀water฀spots.

Stainless฀steel:฀Wash฀stainless฀steel฀surfaces฀with฀a฀clean,

soft฀cloth฀or฀sponge฀and฀a฀mild฀detergent฀in฀warm฀water.

Rinse฀surfaces฀with฀clean,฀warm฀water฀and฀dry฀immediately฀to

avoid฀water฀spots.

NOTE:฀When฀cleaning฀stainless฀steel,฀always฀wipe฀in฀the

direction฀of฀the฀grain฀to฀avoid฀cross-grain฀scratching.

4.There฀is฀no฀need฀for฀routine฀condenser฀cleaning฀in฀normal

home฀operating฀environments.฀If฀the฀environment฀is

particularly฀greasy฀or฀dusty฀or฀there฀is฀significant฀pet฀traffic

in฀the฀home,฀the฀condenser฀should฀be฀cleaned฀every฀2฀to

3฀months฀to฀ensure฀maximum฀efficiency.

If฀you฀need฀to฀clean฀the฀condenser:

Remove฀the฀base฀grille.

Use฀a฀vacuum฀cleaner฀with฀a฀soft฀brush฀to฀clean฀the฀grille,฀

the฀open฀areas฀behind฀the฀grille,฀and฀the฀front฀surface฀area฀

of฀the฀condenser.

Replace฀the฀base฀grille฀when฀finished.

5.Plug฀in฀refrigerator฀or฀reconnect฀power.

WARNING

Explosion Hazard

Use nonflammable cleaner.

Failure to do so can result in death, explosion, or fire.

bluB thgiL eht gnignahC

Freezer Compartment Light

1. Unplug refrigerator or disconnect power.

2. Remove the light shield (on some models).

Top of the freezer compartment - Slide the light shield

toward the back of the compartment to release it from the

light assembly.

3. Remove the light bulb and replace it with an appliance bulb of

the same size and shape.

To replace an LED light bulb in the freezer compartment,

order part number W10565137 (3.6 watts).

NOTE: Some LED replacement bulbs are not

recommended for wet/damp environments. The

refrigerator and freezer compartments are considered to

be wet/damp environments. If using a brand of LED bulb

other than the recommended LED bulb, before

installation, read and follow all instructions on the LED

packaging.

If an incandescent bulb is used to replace an LED bulb,

use only incandescent bulbs for household appliances

with a maximum of 25 watts.

4. Replace the light shield.

5. Plug in refrigerator or reconnect power.

Vacation and Moving Care

Vacations

If You Choose to Leave the Refrigerator On While You’re

Away:

1. Use up any perishables and freeze other items.

2. If your refrigerator has an automatic ice maker and is

connected to the household water supply, turn off the water

supply to the refrigerator. Property damage can occur if the

water supply is not turned off.

3. If you have an automatic ice maker, turn off the ice maker.

NOTE: o thet mra ffo-tuhs eriw eht esiaR tisop )pu( ffO ion.

4. Empty the ice bin.

If You Choose to Turn Off the Refrigerator Before You

Leave:

1. Remove all food from the refrigerator.

2. If your refrigerator has an automatic ice maker:

Turn off the water supply to the ice maker at least one day

ahead of time.

When the last load of ice drops, raise the wire shut-off arm

to the Off (up) position.

3. Turn off the Temperature controls. See “Using the Controls.”

4. Clean refrigerator, wipe it, and dry well.

5. Tape rubber or wood blocks to the tops of both doors to prop

them open far enough for air to get in. This stops odor and

mold from building up.

Moving

When you are moving your refrigerator to a new home, follow

these steps to prepare it for the move.

1. If your refrigerator has an automatic ice maker:

Turn off the water supply to the ice maker at least one day

ahead of time.

Disconnect the water line from the back of the refrigerator.

When the last load of ice drops, raise the wire shut-off arm

to the Off (up) position.

2. Remove all food from the refrigerator and pack all frozen food

in dry ice.

3. Empty the ice bin.

4. Turn off the Temperature controls. See “Using the Controls.”

5. Unplug refrigerator.

6. Clean, wipe, and dry thoroughly.

7. Take out all removable parts, wrap them well, and tape them

together so they don’t shift and rattle during the move.

8. Depending on the model, raise the front of the refrigerator so it

rolls more easily OR raise the leveling screws so they don't

scrape the floor. See “Adjust the Door(s)” or “Door Closing

and Door Alignment.”

. Tape the doors closed and tape the power cord to the back of

the refrigerator.

When you get to your new home, put everything back and refer to

the “Installation Instructions” section for preparation instructions.

Also, if your refrigerator has an automatic ice maker, remember to

reconnect the water supply to the refrigerator.

NOTE: Applies to some models.

IMPORTANT: The light bulbs in both the refrigerator and freezer

compartments of your new refrigerator use LED technology. If the

lights do not illuminate when the refrigerator and/or freezer door is

opened, call for assistance or service.

1. Unplug refrigerator or disconnect power.

2. Remove the light bulb and replace it with an appliance bulb

of the same size and shape.

3. Plug in refrigerator or reconnect power.

To replace the LED bulb with an LED bulb, order part

number W10716219 (4 watts).

NOTE: Some LED replacement bulbs are not

recommended for wet/damp environments. The

refrigerator and freezer compartments are considered to

be wet/damp environments. If using a brand of LED bulb

other than the recommended LED bulb, before

installation, read and follow all instructions on the LED

packaging.

To replace an LED bulb with an incandescent bulb, use

only incandescent bulbs for household appliances with

a maximum of 60 watts.

Refrigerator Compartment Light

The refrigerator light bulb is located behind the control.

TROUBLESHOOTING

First try the solutions suggested here. If you need further assistance or more recommendations that may help you avoid a service call,

refer to the warranty page in this manual and scan the code with your mobile device, or visit www.maytag.com/product_help.

In Canada, visit www.maytag.ca.

In the U.S.A.:

Maytag Brand Home Appliances

Customer eXperience Center

553 Benson Road

Benton Harbor, MI 49022-2692

In Canada:

Maytag Brand Home Appliances

Customer eXperience Centre

200 – 6750 Century Ave.

Mississauga, Ontario L5N 0B7

Please include a daytime phone number in your correspondence.

Refrigerator Operation

The refrigerator will not operate

Power cord unplugged? Plug into a grounded 3 prong outlet.

Is outlet working? Plug in a lamp to see if the outlet is

working.

Household fuse blown or circuit breaker tripped? Replace

the fuse or reset the circuit breaker. If the problem continues,

call an electrician.

Controls on? Make sure the refrigerator control is ON. See

“Using the Controls.”

New installation? Allow 24 hours following installation for the

refrigerator to cool completely.

NOTE: Adjusting the temperature controls to coldest setting

will not cool the refrigerator more quickly.

The lights do not work

Light bulb burned out? Replace light bulb. See “Changing the

Light Bulb.”

The motor seems to run too much

Your new refrigerator may run longer than your old one due to its

high-efficiency compressor and fans. The unit may run even

longer if the room is warm, a large food load is added, the door is

opened often, or if the door has been left open.

The refrigerator seems noisy

Refrigerator noise has been reduced over the years. Due to this

reduction, you may hear intermittent noises from your new

refrigerator that you did not notice from your old model. Below are

listed some normal sounds with explanations.

Buzzing - heard when the water valve opens to fill the ice

maker

Pulsating - fans/compressor adjusting to optimize

performance

Hissing/Rattling - flow of refrigerant, movement of water

lines, or from items placed on top of the refrigerator

Sizzling/Gurgling - water dripping on the heater during

Defrost cycle

Popping - contraction/expansion of inside walls, especially

during initial cooldown

Water running/dripping - may be heard when ice melts

during defrosting and water runs into the drain pan

Creaking/Cracking - occurs as ice is being ejected from the

ice maker mold

The doors will not close completely or they pop open

Door blocked open? Move food packages away from door.

Bin or shelf in the way? Push bin or shelf back in the correct

position.

Crisper cover in the way? Make sure the crisper cover is fully

pushed in so that the back rests on the supports.

Refrigerator not tilted toward the rear? So the doors will

close easier, raise the front of the refrigerator so that it tilts

slightly downward toward the rear. See “Adjust the Doors.”

Door closed too quickly? Close the door slowly and firmly to

keep the door from popping open.

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

The฀door฀is฀difficult฀to฀open

Gaskets฀dirty฀or฀sticky?฀Clean฀gaskets฀and฀contact฀surfaces฀

with฀mild฀soap฀and฀warm฀water.฀Rinse฀and฀dry฀with฀soft฀cloth.

Temperature and Moisture

Temperature฀is฀too฀warm

New฀installation?฀Allow฀24hours฀following฀installation฀for฀the฀

refrigerator฀to฀cool฀completely.

Door฀opened฀often฀or฀left฀open?฀Allows฀warm฀air฀to฀enter฀

refrigerator.฀Minimize฀door฀openings฀and฀keep฀door฀fully฀

closed.฀

Large฀load฀of฀food฀added?฀Allow฀several฀hours฀for฀

refrigerator฀to฀return฀to฀normal฀temperature.฀

Controls฀set฀correctly฀for฀the฀surrounding฀conditions?

Adjust฀the฀controls฀a฀setting฀colder.฀Check฀temperature฀in฀

24hours.฀See฀“Using฀the฀Controls.”

There฀is฀interior฀moisture฀buildup

NOTE:฀Some฀moisture฀buildup฀is฀normal.

Humid฀room?฀Contributes฀to฀moisture฀buildup.

Door฀opened฀often฀or฀left฀open?฀Allows฀humid฀air฀to฀enter฀

refrigerator.฀Minimize฀door฀openings฀and฀keep฀door฀fully฀

closed.

Ice and Water

The฀ice฀maker฀is฀not฀producing฀ice฀or฀not฀enough฀ice

Refrigerator฀connected฀to฀a฀water฀supply฀and฀the฀supply฀

shut-off฀valve฀turned฀on?฀Connect฀refrigerator฀to฀water฀

supply฀and฀turn฀water฀shut-off฀valve฀fully฀open.฀

Kink฀in฀the฀water฀source฀line?฀A฀kink฀in฀the฀line฀can฀reduce฀

water฀flow.฀Straighten฀the฀water฀source฀line.฀

Ice฀maker฀turned฀on?฀Make฀sure฀wire฀shut-off฀arm฀or฀switch฀

(depending฀on฀model)฀is฀in฀the฀On฀position.฀

New฀installation?฀Wait฀24฀hours฀after฀ice฀maker฀installation฀

for฀ice฀production฀to฀begin.฀Allow฀3days฀to฀completely฀fill฀the฀

ice฀container.฀

Large฀amount฀of฀ice฀recently฀removed?฀Allow฀24hours฀for฀

ice฀maker฀to฀produce฀more฀ice.฀

Ice฀cube฀jammed฀in฀the฀ice฀maker฀ejector฀arm?฀Remove฀

ice฀from฀the฀ejector฀arm฀with฀a฀plastic฀utensil.฀

Reverse฀osmosis฀water฀filtration฀system฀connected฀to฀

your฀cold฀water฀supply?฀This฀can฀decrease฀water฀pressure.฀

See฀“Water฀Supply฀Requirements.”฀

The฀ice฀cubes฀are฀hollow฀or฀small

NOTE:฀This฀is฀an฀indication฀of฀low฀water฀pressure.

Water฀shut-off฀valve฀not฀fully฀open?฀Turn฀the฀water฀shut-off฀

valve฀fully฀open.

Kink฀in฀the฀water฀source฀line?฀A฀kink฀in฀the฀line฀can฀reduce฀

water฀flow.฀Straighten฀the฀water฀source฀line.฀

Reverse฀osmosis฀water฀filtration฀system฀connected฀to฀

your฀cold฀water฀supply?฀This฀can฀decrease฀water฀pressure.฀

See฀“Water฀Supply฀Requirements.”

Questions฀remain฀regarding฀water฀pressure?฀Call฀a฀

licensed,฀qualified฀plumber.

Off-taste,฀odor,฀or฀gray฀color฀in฀the฀ice

New฀plumbing฀connections?฀New฀plumbing฀connections฀

can฀cause฀discolored฀or฀off-flavored฀ice.฀

Ice฀stored฀too฀long?฀Discard฀ice.฀Wash฀ice฀bin.฀Allow฀

24hours฀for฀ice฀maker฀to฀make฀new฀ice.฀

Odor฀transfer฀from฀food?฀Use฀airtight,฀moisture-proof฀

packaging฀to฀store฀food.฀

Are฀there฀minerals฀(such฀as฀sulfur)฀in฀the฀water?฀A฀water฀

filter฀may฀need฀to฀be฀installed฀to฀remove฀the฀minerals.฀

ACCESSORIES

The฀following฀accessories฀are฀available฀for฀your฀refrigerator.฀

To฀order,฀contact฀us฀and฀ask฀for฀the฀part฀number.

In฀the฀U.S.A.,฀visit฀www.maytag.com/accessories฀or฀call฀

1-800-688-9900.

In฀Canada,฀visit฀www.maytag.ca฀or฀call฀1-800-807-6777.

affresh

฀Stainless฀Steel฀Cleaner:฀

In฀U.S.A.,฀order฀Part฀#W10355016

In฀Canada,฀order฀Part฀#W10355016B

affresh

฀Stainless฀Steel฀Wipes:

In฀U.S.A.,฀order฀Part฀#W10355049

In฀Canada,฀order฀Part฀#W10355049B

affresh

฀Kitchen฀&฀Appliance฀Cleaner:

In฀U.S.A.,฀order฀Part฀#W10355010

In฀Canada,฀order฀Part฀#W10355010B

Air฀Filter:฀

Order฀Part฀#W10311524฀

Reversibility฀Kit:

Order฀Part฀#฀W10395149

WARNING

Explosion Hazard

Use nonflammable cleaner.

Failure to do so can result in death, explosion, or fire.

11/14

MAYTAG

฀REFRIGERATION฀

LIMITED฀WARRANTY

ATTACH฀YOUR฀RECEIPT฀HERE.฀PROOF฀OF฀PURCHASE฀IS฀REQUIRED฀

TO฀OBTAIN฀WARRANTY฀SERVICE.

Please฀have฀the฀following฀information฀available฀when฀you฀call฀the฀

Customer฀eXperience฀Center:

Name,฀address฀and฀telephone฀number

Model฀number฀and฀serial฀number

A฀clear,฀detailed฀description฀of฀the฀problem

Proof฀of฀purchase฀including฀dealer฀or฀retailer฀name฀and฀address

IF฀YOU฀NEED฀SERVICE:

1.Before฀contacting฀us฀to฀arrange฀service,฀please฀determine฀whether฀your฀product฀requires฀repair.฀Some

questions฀can฀be฀addressed฀without฀service.฀Please฀take฀a฀few฀minutes฀to฀review฀the฀Troubleshooting฀or

Problem฀Solver฀section฀of฀the฀Use฀and฀Care฀Guide,฀scan฀the฀QR฀code฀on฀the฀right฀to฀access฀additional

resources,฀or฀visit฀https://www.maytag.com/product_help.

2.All฀warranty฀service฀is฀provided฀exclusively฀by฀our฀authorized฀Maytag฀Service฀Providers

.฀In฀the฀U.S.฀and฀Canada,

direct฀all฀requests฀for฀warranty฀service฀to:฀

Maytag฀Customer฀eXperience฀Center

In฀the฀U.S.A.,฀call฀1-800-688-9900.฀In฀Canada,฀call฀1-800-807-6777.

If฀outside฀the฀50฀United฀States฀or฀Canada,฀contact฀your฀authorized฀Maytag฀dealer฀to฀determine฀whether฀another฀

warranty฀applies.

https://www.maytag.com/

product_help

TEN YEAR LIMITED WARRANTY

WHAT IS COVERED WHAT IS NOT COVERED

FIRST฀YEAR฀LIMITED฀WARRANTY฀(PARTS฀AND฀LABOR)

For฀one฀year฀from฀the฀date฀of฀purchase,฀when฀this฀major฀

appliance฀is฀installed,฀operated฀and฀maintained฀according฀

to฀instructions฀attached฀to฀or฀furnished฀with฀the฀product,฀

Maytag฀brand฀of฀Whirlpool฀Corporation฀or฀Whirlpool฀

Canada,฀LP฀(hereafter฀“Maytag”)฀will฀pay฀for฀factory฀

specified฀replacement฀parts฀and฀repair฀labor฀to฀correct฀

defects฀in฀materials฀or฀workmanship฀that฀existed฀when฀this฀

major฀appliance฀was฀purchased,฀or฀at฀its฀sole฀discretion฀

replace฀the฀product.฀In฀the฀event฀of฀product฀replacement,฀

your฀appliance฀will฀be฀warranted฀for฀the฀remaining฀term฀of฀

the฀original฀unit's฀warranty฀period.

SECOND฀THROUGH฀TENTH฀YEAR฀LIMITED฀

WARRANTY฀(

COMPRESSOR฀ONLY฀-฀LABOR฀NOT฀

CLUDED)

In฀the฀second฀through฀tenth฀years฀from฀the฀date฀of฀original฀

purchase,฀when฀this฀major฀appliance฀is฀installed,฀operated฀

and฀maintained฀according฀to฀instructions฀attached฀to฀or฀

furnished฀with฀the฀product,฀Maytag฀will฀pay฀for฀a฀factory฀

specified฀replacement฀compressor฀to฀correct฀non-cosmetic฀

defects฀in฀materials฀or฀workmanship฀in฀this฀part฀that฀prevent฀

function฀of฀the฀refrigerator฀and฀that฀existed฀when฀this฀major฀

appliance฀was฀purchased.฀This฀limited฀10-year฀warranty฀is฀

for฀the฀compressor฀only฀and฀does฀not฀include฀labor.

YOUR฀SOLE฀AND฀EXCLUSIVE฀REMEDY฀UNDER฀THIS฀

LIMITED฀WARRANTY฀SHALL฀BE฀PRODUCT฀REPAIR฀AS฀

PROVIDED฀HEREIN.฀Service฀must฀be฀provided฀by฀a฀Maytag฀

designated฀service฀

company.฀This฀lim

ited฀warranty฀is฀valid฀

only฀in฀the฀United฀States฀or฀Canada฀and฀applies฀only฀when฀

the฀major฀appliance฀is฀used฀in฀the฀country฀in฀which฀it฀was฀

purchased.฀This฀limited฀warranty฀is฀effective฀from฀the฀date฀

of฀original฀consumer฀purchase.฀Proof฀of฀original฀purchase฀

date฀is฀required฀to฀obtain฀service฀under฀this฀limited฀warranty.

1.Commercial,฀non-residential฀or฀multiple-family฀use,฀or฀use฀inconsistent฀with

published฀user,฀operator฀or฀installation฀instructions.

2.In-home฀Instruction฀on฀how฀to฀use฀your฀product.

3.Service฀to฀correct฀improper฀product฀maintenance฀or฀installation,฀installation฀not

in฀accordance฀with฀electrical฀or฀plumbing฀codes฀or฀correction฀of฀household

electrical฀or

฀plumbing฀(i.e.฀house฀wiring,฀fuses

฀or฀water฀inlet฀hoses).

4.Consumable฀parts฀(i.e.฀light฀bulbs,฀batteries,฀air฀or฀water฀filters,฀preservation

solutions,฀etc.).

5.Defects฀or฀damage฀caused฀by฀the฀use฀of฀non-genuine฀Maytag฀parts฀or

accessories.

6.Damage฀from฀accident,฀misuse,฀abuse,฀fire,฀floods,฀acts฀of฀God฀or฀use฀with

products฀not฀approved฀by฀Maytag.

7.Repairs฀to฀parts฀or฀systems฀to฀correct฀product฀damage฀or฀defects฀caused฀by

unauthorized฀service,฀alteration฀or฀modification฀of฀the฀appliance.

8.Cosmetic฀damage฀including฀scratches,฀dents,฀chips,฀and฀other฀damage฀to

appliance฀finishes฀unless฀such฀damage฀results฀from฀defects฀in฀materials฀and

workmanship฀and฀is฀reported฀to฀Maytag฀within฀30฀days.

9.Discoloration,฀rust฀or฀oxidation฀of฀surfaces฀resulting฀from฀caustic฀or฀corr

osive

environme

nts฀including฀but฀not฀limited฀to฀high฀salt฀concentrations,฀high฀moisture

or฀humidity฀or฀exposure฀to฀chemicals.

10.Food฀or฀medicine฀loss฀due฀to฀product฀failure.

11.Pick-up฀or฀delivery.฀This฀product฀is฀intended฀for฀in-home฀repair.

12.Travel฀or฀transportation฀expenses฀for฀service฀in฀remote฀locations฀where฀an

authorized฀Maytag฀servicer฀is฀not฀available.

13.Removal฀or฀reinstallation฀of฀inaccessible฀appliances฀or฀built-in฀fixtures฀(i.e.฀trim,

decorative฀panels,฀flooring,฀cabinetry,฀islands,฀countertops,฀drywall,฀etc.)฀that

interfere฀with฀servicing,฀removal฀or฀replacement฀of฀the฀product.

14.Service฀or฀parts฀for฀appliances฀with฀original฀model/serial฀numbers฀removed,

altered฀or฀not฀easily฀d

etermined.

The฀cost฀of

฀repair฀or฀replacement฀under฀these฀excluded฀circumstances฀shall฀be฀

borne฀by฀the฀customer.฀

DISCLAIMER฀OF฀IMPLIED฀WARRANTIES

IMPLIED฀WARRANTIES,฀INCLUDING฀ANY฀IMPLIED฀WARRANTY฀OF฀MERCHANTABILITY฀OR฀IMPLIED฀WARRANTY฀OF฀FITNESS฀FOR฀A฀

PARTICULAR฀PURPOSE,฀ARE฀LIMITED฀TO฀ONE฀YEAR฀OR฀THE฀SHORTEST฀PERIOD฀ALLOWED฀BY฀LAW.฀Some฀states฀and฀provinces฀do฀not฀allow฀

limitations฀on฀the฀duration฀of฀implied฀warranties฀of฀merchantability฀or฀fitness,฀so฀this฀limitation฀may฀not฀apply฀to฀you.฀This฀warranty฀gives฀you฀

specific฀legal฀rights,฀and฀you฀also฀may฀have฀other฀rights฀that฀vary฀from฀state฀to฀state฀or฀province฀to฀province.

DISCLAIMER฀OF฀REPRESENTATIONS฀OUTSIDE฀OF฀WARRANTY

Maytag฀makes฀no฀representations฀about฀the฀quality,฀durability,฀or฀need฀for฀service฀or฀repair฀of฀this฀major฀appliance฀other฀than฀the฀representations฀

contained฀in฀this฀warranty.฀If฀you฀want

฀a฀longer฀or฀more฀comprehensive฀warranty฀than฀the฀limited฀warranty฀that฀comes฀with฀this฀major฀appliance,฀

you฀should฀ask฀Maytag฀or฀your฀retailer฀about฀buying฀an฀extended฀warranty.

LIMITATION฀OF฀REMEDIES;฀EXCLUSION฀OF฀INCIDENTAL฀AND฀CONSEQUENTIAL฀DAMAGES

YOUR฀SOLE฀AND฀EXCLUSIVE฀REMEDY฀UNDER฀THIS฀LIMITED฀WARRANTY฀SHALL฀BE฀PRODUCT฀REPAIR฀AS฀PROVIDED฀HEREIN.฀MAYTAG฀

SHALL฀NOT฀BE฀LIABLE฀FOR฀INCIDENTAL฀OR฀CONSEQUENTIAL฀DAMAGES.฀Some฀states฀and฀provinces฀do฀not฀allow฀the฀exclusion฀or฀limitation฀of฀

incidental฀or฀consequential฀damages,฀so฀these฀limitations฀and฀exclusions฀may฀not฀apply฀to฀you.฀This฀warranty฀gives฀you฀specific฀legal฀rights,฀and฀

you฀also฀may฀have฀other฀rights฀that฀vary฀from฀state฀to฀state฀or฀province฀to฀province.

Align with top of the door.

Aligner avec le sommet de la porte.

Standard Door

Porte Standard

Align with side of the door.

Aligner avec le côté de la porte.

Ideal position of hole (shown as suggestion)

Position idéale du trou (suggérée)

²⁹⁄₃₂

(12,5 cm)

⁵⁄₃₂

(10,6 cm)

W10885251

Utilisé฀sous฀licence฀au฀Canada.฀Tous฀droits฀réservés.

06/16

Maytag MRT118FFFM01 30 Inch Top-Freezer Refrigerator with 18.15 cu. ft. Capacity

Product's Documents

User Instructions

Specifications

Maytag MRT118FFFM01 Questions and Answers
