Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352
use
&
care
REFRIGERATOR
A22993702 (September 2021)
Introduction .......................................................2
Important Safety information.....................3
Features .............................................................5
Installation .........................................................6
Door Reversal ..................................................7
Controls and Settings .................................10
Care and Cleaning ........................................ 12
Troubleshooting ...........................................14
Limited Warranty .......................................... 15
2
INTRODUCTION
Doors
Door seals completely to cabinet on
all sides
Leveling
Refrigerator is level side-to-side and
front-to-back
Cabinet is set solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Final Checks
Shipping material removed
Refrigerator and freezer tempera-
tures set
Registration card sent in
Installation Checklist
Welcome to our
family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at www.frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it ocial! Be sure to register
your product.
Keep your product info here so it’s easy
to find.
Model Number ____________________
Serial Number ____________________
Purchase Date ____________________
3
WARNING
WARNING indicates a potentially haz-
ardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently haz-
ardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially haz-
ardous situation which, if not avoided,
may result in minor or moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
Safety Instructions
• DO NOT store or use gasoline, or
other flammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regarding
flammability and other hazards.
• DO NOT operate the refrigerator in
the presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
with other appliances or furniture.
WARNING
Please read all instructions before using
this appliance.
Child Safety
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after you unpack the
refrigerator. Children should NEVER use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause suocation.
IMPORTANT SAFETY INFORMATION
WARNING
CALIFORNIA RESIDENTS ONLY
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
DANGER
DANGER Risk of fire or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigerator.
Do not puncture refrigerant tubing.
DANGER Risk of fire or explosion.
Flammable refrigerant used. To be repaired
only by trained service personnel. Use
only manufacturer-authorized service
parts. Any repair equipment used must
be designed for flammable refrigerants.
Follow all manufacturer repair instructions.
Do not puncture refrigerant tubing.
CAUTION
CAUTION Risk of fire or explosion.
Dispose of refrigerator properly
in accordance with the applicable
federal or local regulations. Flammable
refrigerant used.
CAUTION Risk of fire or explosion
due to puncture of refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.
WARNING
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
4
IMPORTANT SAFETY INFORMATION
Proper Disposal of your Appliance
Risk of child entrapment
Child entrapment and suocation are not
problems of the past. Junked or aban-
doned appliances are still dangerous –
even if they will sit for “just a few days”. If
you are getting rid of your old unit, please
follow the instructions below to help pre-
vent accidents.
We strongly encourage responsible appli-
ance recycling/disposal methods. Check
with your utility company or visit www.
energystar.gov/recycle for more informa-
tion on recycling your old appliance.
Before you throw
away your old unit:
• Remove doors.
• Leave shelves in
place so children
may not easily
climb inside.
• Have refrigerant re-
moved by a qualified service technician.
Electrical information
• Plug the unit into its own dedi-
cated 115 Volt, 60 Hz., 15 Amp, AC
only electrical outlet. The power
cord of the appliance is equipped
with a 3-prong grounding plug for
your protection against electrical
shock hazards. Plug it directly into a
properly grounded 3-prong recep-
tacle. You must install the recepta-
cle in accordance with local codes
and ordinances. Consult a qualified
electrician. Avoid connecting the unit
to a Ground Fault Interrupter (GFI)
circuit. Do not use an extension cord
or adapter plug.
• If the power cord is damaged, an
authorized service technician should
replace it to prevent any risk.
• Never unplug the refrigerator by pull-
ing on the power cord. Always grip
the plug firmly, and pull it straight
out from the receptacle to prevent
damaging the power cord.
• Unplug the appliance before clean-
ing and before replacing the AC LED
light bulb to avoid electrical shock.
Use only a 5-watt or less AC LED
light bulb.
• Performance may be aected if the
voltage varies by 10% or more. Oper-
ating the refrigerator with insucient
power can damage the compressor.
Such damage is not covered under
your warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or
pull cord to prevent the unit from
being turned o accidentally.
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
IMPORTANT
Turning the Refrigerator controls to
“OFF” will disable your refrigerator’s
cooling system, but does not disconnect
the power to the light bulb and other
electrical components. To turn o power
to your refrigerator you must unplug the
power cord from the electrical outlet.
IMPORTANT
CFC/HCFC Disposal
Your old refrigerator may have a cooling
system that used CFCs or HCFCs (chlo-
rofluorocarbons or hydrochlorofluoro-
carbons). CFCs and HCFCs are believed
to harm stratospheric ozone if released
to the atmosphere. Other refrigerants
may also cause harm to the environment
if released to the atmosphere.
If you are throwing away your old refrig-
erator, make sure the refrigerant is re-
moved for proper disposal by a qualified
technician. If you intentionally release
refrigerant, you may be subject to fines
and imprisonment under provisions of
environmental legislation.
5
FEATURES
*Features may vary according to model
A Freezer Drawers
B Chiller
C Crisper
D Crisper Cover
E Refrigerator Shelves
F Thermostat and Light
G Door Bins
H Leveling Feet
IMPORTANT
Cleaning your Refrigerator
Remove tape and glue residue from sur-
faces before turning the refrigerator on.
Rub a small amount of liquid dish soap
over the adhesive with your fingers.
Rinse with warm water and dry with a
soft cloth.
Do not use sharp instruments, rubbing
alcohol, flammable fluids, or abrasive
cleaners to remove tape or glue. These
products can damage the surface of
your refrigerator.
After you remove all of the package ma-
terials, clean the inside of your refriger-
ator before using it. See the CARE AND
CLEANING section in this manual.
See important information about
cleaning glass shelves and covers in the
STORAGE FEATURES section of this
manual.
IMPORTANT
Moving your Refrigerator
Your refrigerator is heavy. When
moving the refrigerator for cleaning or
service, be sure to cover the floor with
cardboard or hardboard to avoid floor
damage. Always pull the refrigerator
straight out when moving it. Do not
wiggle or “walk” the refrigerator when
trying to move it as you could damage
the floor.
H
A
A
A
B
C
D
E
E
F
G
G
G
H
6
INSTALLATION
This Use & Care Guide provides general
operating instructions for your model.
Use the appliance only as instructed in
this Use & Care Guide. Before starting the
unit, follow these important first steps.
Location
• Choose a place that is near a ground-
ed electrical outlet. Do Not use an
extension cord or an adapter plug.
• When first locating unit, it is ad-
visable to wait at least 4 hours to
connect unit to electrical outlet to
allow the oil to flow back into the
compressor.
• If possible, place the refrigerator out of
direct sunlight and away from the range,
dishwasher or other heat sources.
• The refrigerator must be installed on
a floor that is level and strong enough
to support a fully loaded refrigerator.
Guidelines for final positioning of
your refrigerator:
• All 4 corners of the cabinet must rest
firmly on the floor.
• The cabinet should be level at the
front and rear.
• To level unit, adjust the two leveling
feet at the front of the unit.
Installation
CAUTION
Do not install the refrigerator where the
temperature will drop below 50°F (10°C)
or rise above 110°F (43°C). The compres-
sor will not be able to maintain proper
temperatures inside the refrigerator.
WARNING
This appliance is intended to be used
in household and similar applications
such as:
• sta kitchen areas in shops, oces
and other working environments;
• farm houses and by clients in hotels,
motels and other residential type
environments;
• bed and breakfast type
environments;
• catering and similar non-retail
applications.
WARNING
Installation clearances
Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Top 4” 100 mm
Side/Back 2” 50 mm
7
DOOR REVERSAL
NOTE
The direction in which your refriger-
ator doors open (door swing) can be
reversed, from left to right or right to
left, by moving the door hinges from
one side to the other. Reversing the
door swing should be performed by a
qualified person.
IMPORTANT
Before you begin, turn the refrigerator tem-
perature control to OFF and remove the
electrical power cord from the wall outlet.
Remove any food from door shelves.
Socket
Wrench Set
Door Closer
#2 Phillips
Top Hinge
Screw
5/16"
(8mm)
T20
Bottom
Hinge
Screw
T25
Center
Hinge
Screw
Phillips™
Head
&
Flathead
Screwdriver
Hammer
Putty
Knife
T20 & T25
Torx Head
Screwdriver
T20
T25
T20
* Hand held
Drill/Driver
* Optional Tool:
Door Reversal:
1. Unplug your refrigerator.
2. Unscrew top hinge cover and
disconnect connectors from door
switch.
Tools Needed
Accessory Bag Door Reversal
Components
Left Door
Hinge Cover
x1
Left Aid-
Closer on
Upper Door
x1
Left Aid-
Closer on
Lower Door
x1
3. Remove top hinge with socket wrench.
4. Remove pin with adjustable wrench.
Flip hinge bracket over, attach pin to
opposite side of bracket.
5. Move door switch from right hinge
cover to left hinge cover (accessory
bag).
6. Move top left cover to right side.
8
DOOR REVERSAL
7. Take o the upper door. Using a
Phillips screw driver, take out the
screw from the middle hinge. Take o
the lower door.
8. Move the hinge hole covers from left
side to right side.
9. Remove the adjustable feet from
both sides. (See Figure A.) Remove
the bottom hinge. (See Figure B.)
Figure A Figure B
10. Remove the bottom hinge pin with
adjustable wrench, turn bracket over
and replace on opposite side.
11. Attach the bottom hinge bracket
to the unit. (See Figure A.) Replace
both adjustable feet. See Figure B.)
12. Remove aid-closers from bottom of
upper and lower doors, then take
new aid-closers from accessory bag
and install them to left side.
Figure A Figure B
13. Detach the refrigerator and freezer
door gaskets and then attach them
after rotating.
9
DOOR REVERSAL
14. Install the lower door, adjust and fix
the middle hinge onto the cabinet.
15. Replace upper door. Place door on
middle hinge and align with cabinet
ensuring that the door gasket seals
tightly with cabinet. Secure the top
hinge tightly to the cabinet.
16. Connect door switch terminals to
top hinge cover. Screw top hinge
cover in place.
10
CONTROLS AND SETTINGS
Control Panel Display
Buttons and Temperature Settings
Mode: Press Mode to select Vacation Mode or Freeze Boost Mode and wait until
the flash turns to continuous light, then the Mode is selected successfully.
Zone: Under Normal Mode, press Zone to select the compartment for which you
plan to adjust the temperature.
Temp: Under Normal Mode, press Temp to adjust temperature of refrigerator or
freezer compartments. Press Temp and hold longer than 3 seconds to switch
between Fahrenheit and Celsius. The set temperature of the refrigerator and
freezer compartments cycles as follows:
Refrigerator
Freezer
Display and Light
1 It will illuminate when Vacation Mode is selected using the Mode button.
2 It will illuminate when Freeze Boost Mode is selected using the Mode button.
3 It shows set temperature of refrigerator and freezer compartments in Fahrenheit
or Celsius.
4 It will illuminate when the freezer compartment is selected using the Mode
button.
5 It will illuminate when the refrigerator compartment is selected using the Mode
button.
Running Modes
Vacation Mode
In this mode, the temperature of the refrigerator and freezer is automatically set
at 41°F (5 °C) and 0°F (-18°C). The temperature of the 2 compartments are not
adjustable. The appliance will run with lower energy consumption.
Freeze Boost Mode
In this mode, the temperature of the freezer is automatically set at -13°F (-25°C). The
temperature in the freezer compartment will be reduced quickly.
If you plan to freeze a large amount of food at one time, please select Freeze Boost
Mode. In this mode, the temperature of Refrigerator compartment is still adjustable.
The appliance will go back to previous mode automatically after 50 hours.
7 5 3 1 0 -2 -4 -6 -8
35 37 39 41 43 45 47
11
CONTROLS AND SETTINGS
Normal Mode
The default mode is Normal Mode. In this mode, you can set the temperatures of
both Refrigerator and Freezer compartments.
Door Open Alarm
If door is left open for more than 60 seconds, alarm will sound. Close door
immediately to conserve energy.
Error Codes
If there is a fault, the display will show ERROR codes.
Error Fault Codes
Signal transmission between control board and main board.
Probably defects of harness (wire and connectors), main board
or control board
E0
Temperature sensor of refrigerator compartment E1
Temperature sensor of freezer compartment E2
Defrost temperature sensor in freezer compartment E3
Defrost heater or the fuse connected with heater E5
CHILLDRAWER Temperature Control
• Temperatures in the CHILLDRAWER can be adjusted based on
the type of food to be stored.
• To decrease the temperature, push the knob upward from the
bottom.
• When the knob is placed at the “Cold” position, the
CHILLDRAWER can be functioned as a crisper zone and
maintain the appropriate temperature and humidity for fruits and
vegetables.
• When the knob is placed at the “Coldest” position, it is suitable
for short-term storage of fish or other fresh food. The food will
be kept fresh but not frozen which makes it the best choice for
storing fresh food.
• Tip: When you choose “Coldest” position, it is recommended
to set the refrigerator temperature below 4 °C in order to keep
food the freshest.
Coldest
Cold
CHILLDRAWER
Call service to report error codes.
12
CARE AND CLEANING
Protecting your investment
Keeping your refrigerator clean maintains
appearance and prevents odor build-up.
Wipe up any spills immediately and clean
the freezer and refrigerator compartments
at least twice a year. When cleaning, take
the following precautions:
• Never use CHLORIDE or cleaners with
bleach to clean stainless steel.
• Do not wash any removable parts in
a dishwasher.
• Always unplug the electrical power cord
from the wall outlet before cleaning.
• Remove adhesive labels by hand. Do
not use razor blades or other sharp
instruments which can scratch the
appliance surface.
• Do not remove the serial plate.
Do not use abrasive cleaners such as win-
dow sprays, scouring cleansers, brushes,
flammable fluids, cleaning waxes, concen-
trated detergents, bleaches or cleansers
containing petroleum products on plastic
parts, interior doors, gaskets or cabinet
liners. Do not use paper towels, metallic
scouring pads, or other abrasive cleaning
materials or strong alkaline solutions.
CAUTION
Pull the refrigerator straight out to
move it. Shifting it from side to side may
damage flooring. Be careful not to
move the refrigerator beyond the
plumbing connections.
NOTE
If you set your temperature controls
to turn o cooling, power to lights and
other electrical components will contin-
ue until you unplug the power cord from
the wall outlet.
13
Care and Cleaning Tips
Part What To Use Tips and Precautions
Interior
& Door
Liners
• Soap and water
• Baking soda
and water
Use 2 tbsp of baking soda in 1 qt of warm
water. Be sure to wring excess water out
of sponge or cloth before cleaning around
controls, light bulb or any electrical part.
Door
Gaskets
• Soap and water Wipe gaskets with a clean soft cloth.
Drawers &
Bins
• Soap and water Use a soft cloth to clean drawer runners
and tracks.
Glass
Shelves
• Soap and water
• Glass cleaner
• Mild liquid sprays
Allow glass to warm to room temperature
before immersing in warm water.
Exterior • Soap and water
• Non Abrasive
Glass Cleaner
Do not use commercial household cleaners
containing ammonia, bleach or alcohol to
clean handles. Use a soft cloth to clean smooth
handles. DO NOT use a dry cloth to clean
smooth doors.
Replacing
LED
Lights
• LED lights The internal light is LED. To replace the light,
please contact a qualified technician.
CARE AND CLEANING
14
1-800-265-8352 (Canada)
Frigidaire.ca
1-800-374-4432 (United States)
Frigidaire.com
TROUBLESHOOTING
Common Occurences
Refrigerator does not run. • Ensure the plug is tightly pushed into an
electrical outlet.
• Check/replace the fuse with a 15-amp time-delay
fuse. Reset the circuit breaker.
Appliance freezes or cools
too much.
• Temperature is set too cold.
• Turn the temperature control to a warmer setting
temporarily.
The food is not frozen
enough.
• Temperature is not properly adjusted. Please look in
the initial Temperature Setting section.
• Door was open for an extended period. Open the
door only as long as necessary
• A large quantity of warm food was placed in
the appliance within the last 24 hours. Turn
the temperature control to a colder setting
temporarily.
• The appliance is near a heat source. Do not locate
near any heat source.
Side panel is hot. • The condenser is in the panel, this is normal.
Refrigerator is noisy
or vibrates.
• The cabinet is not level.
• The appliance is touching the wall or other objects,
move the appliance slightly.
Odors in the refrigerator. • The interior needs to be cleaned.
• Foods that produce odors should be covered or
wrapped.
Cabinet light is not working. • Ensure the plug is tightly pushed into an
electrical outlet.
• The internal light is LED. To replace the light, please
contact a qualified technician.
Let us help you troubleshoot your concern! This section will help you with common
issues. If you need us, visit our website, chat with an agent, or call us. We may be able
to help you avoid a service visit. If you do need service, we can get that started for you!
15
LIMITED WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that
prove to be defective in materials or workmanship when such appliance is installed, used and
maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be
readily determined.
2. Product that has been transferred from its original owner to another party or removed
outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or
for appliances not in ordinary household use or used other than in accordance with the
provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use
your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,
shelves, etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other
consumables, or knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls,
tolls, ferry trip charges, or mileage expense for service calls to remote areas, including the
state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not
limited to floors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts
other than genuine Electrolux parts or parts obtained from persons other than authorized
service companies; or external causes such as abuse, misuse, inadequate power supply,
accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED
WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT
LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY
BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND
PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the
warranty period should service be required. If service is performed, it is in your best interest
to obtain and keep all receipts. Service under this warranty must be obtained by contacting
Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by
Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada,
your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person to change or
add to any obligations under this warranty. Obligations for service and parts under this warranty must
be performed by Electrolux or an authorized service company. Product features or specifications as
described or illustrated are subject to change without notice.
USA
1-800-374-4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
welcome
home
Frigidaire.com
1-800-374-4432
Frigidaire.ca
1-800-265-8352
owner support
accessories
service
Our home is your home. Visit us if you
need help with any of these things:
registration
(See your registration card
for more information.)
