USER MANUAL
SWA-9100S
SAFETY INFORMATION
Thank you for purchasing this product (SWA-9100S).
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols which may
be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product comes
with important literature concerning operation
and maintenance.
Class II product : This symbol indicates that a
safety connection to electrical earth (ground) is
not required.
If this symbol is not present on a product with
a power cord, the product MUST have a reliable
connection to protective earth (ground).
AC voltage : Rated voltage marked with this
symbol is AC voltage.
DC voltage : Rated voltage marked with this
symbol is DC voltage.
Caution. Consult Instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
• The slots and openings in the cabinet and in the back or bottom
are provided for necessary ventilation. To ensure reliable
operation of this apparatus, and to protect it from overheating,
these slots and openings must never be blocked or covered.
– Do not place this apparatus in a conned space, such as a
bookcase, or built-in cabinet, unless proper ventilation is
provided.
– Do not place this apparatus near or over a radiator or heat
register, or where it is exposed to direct sunlight.
– Do not place vessels (vases etc.) containing water on this
apparatus.
A water spill can cause a re or electric shock.
• Do not expose this apparatus to rain or place it near water
(near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.). If this apparatus
accidentally gets wet, unplug it and contact an authorized dealer
immediately.
• Do not overload wall outlets, extension cords or adaptors beyond
their capacity, since this can result in re or electric shock.
• Route power-supply cords so that they are not likely to be walked
on or pinched by items placed on or against them. Pay particular
attention to cords at the plug end, at wall outlets, and the point
where they exit from the apparatus.
• To protect this apparatus from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the set due to lightning and power line
surges.
• Before connecting the AC power cord to the DC adaptor
outlet, make sure the voltage designation of the DC adaptor
corresponds to the local electrical supply.
• Never insert anything metallic into the open parts of this
apparatus. Doing so may create a danger of electric shock.
• To avoid electric shock, never touch the inside of this apparatus.
Only a qualied technician should open this apparatus.
• Make sure to plug the power cord in until it is rmly seated.
When unplugging the power cord from a wall outlet, always pull
on the power cord’s plug. Never unplug by pulling on the power
cord. Do not touch the power cord with wet hands.
• If this apparatus does not operate normally - in particular, if
there are any unusual sounds or smells coming from it - unplug it
immediately and contact an authorized dealer or service center.
• Maintenance of Cabinet.
– Before connecting other components to this product, be sure
to turn them off.
• Be sure to pull the power plug out of the outlet if the product is
to remain unused or if you are leaving the house for an extended
period of time (especially when children, elderly, or disabled
people will be left alone in the house).
– Accumulated dust can cause an electric shock, an electric
leakage, or a re by causing the power cord to generate sparks
and heat or the insulation to deteriorate.
• Contact an authorized service center for information if you
intend to install your product in a location with heavy dust, high
or low temperatures, high humidity, chemical substances, or
where it will operate 24 hours a day such as in an airport, a train
station, etc. Failing to do so may cause serious damage to your
product.
• Use only a properly grounded plug and wall outlet.
– An improper ground may cause electric shock or equipment
damage. (Class l Equipment only.)
• To turn this apparatus off completely, you must disconnect it
from the wall outlet. Consequently, the wall outlet and power
plug must be readily accessible at all times.
• Do not allow children to hang on the product.
• Store the accessories (battery, etc.) in a location safely out of the
reach of children.
• Do not install the product in an unstable location such as a shaky
self, a slanted oor, or a location exposed to vibration.
• Do not drop or strike the product. If the product is damaged,
disconnect the power cord and contact a service center.
• To clean this apparatus, unplug the power cord from the wall
outlet, and then wipe the product using a soft, dry cloth. Do
not use any chemicals such as wax, benzene, alcohol, thinners,
insecticide, air fresheners, lubricants, or detergent. These
chemicals can damage the appearance of the product or erase
the printing on the product.
• Do not expose this apparatus to dripping or splashing. Do not put
objects lled with liquids, such as vases, on the apparatus.
• Do not plug multiple electric devices into the same wall socket.
Overloading a socket can cause it to overheat, resulting in a re.
WARNING :
• TO PREVENT THE SPREAD OF FIRE, KEEP
CANDLES AND OTHER ITEMS WITH OPEN
FLAMES AWAY FROM THIS PRODUCT AT ALL
TIMES.
• This product contains chemicals known to the
State of California to cause cancer and birth defects or other
reproductive harm.
• To reduce the risk of re or electric shock, do not expose this
appliance to rain or moisture.
FCC NOTE (for U.S.A):
FCC Supplier’s Declaration of Conformity
Responsible Party - U.S. Contact Information:
Samsung Electronics America, Inc.
85 Challenger Road.
Ridgeeld Park, NJ 07660
Phone: 1-800-SAMSUNG (726-7864)
FCC Compliance Statement :
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution :
• Any changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate this equipment.
• This product satises FCC regulations when shielded cables and
connectors are used to connect the unit to other equipment.
To prevent electromagnetic interference with electric
appliances, such as radios and televisions, use shielded cables
and connectors for connections.
Class B FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
• Reorienting or relocating the receiving antenna.
• Increasing the separation between the equipment and receiver.
• Connecting the equipment to an outlet that is on a different
circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for
help.
FCC Radiation Exposure Statement :
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna
or transmitter.
CALIFORNIA USA ONLY (Applicable for networking models only.)
This Perchlorate warning applies only to primary CR(Manganese
Dioxide) Lithium coin cells in the product sold or distributed ONLY
in California USA “Perchlorate Material - special handling may
apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.”
Dispose unwanted electronics through an approved recycler. To
nd the nearest recycling location, go to our website:
www.samsung.com/recycling Or call, 1‐800‐SAMSUNG
WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov.
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
PRECAUTIONS
1. Ensure that the AC or DC power supply in your house complies
with the power requirements listed on the identication sticker
located on the back of your product. Install your product
horizontally, on a suitable base (furniture), with enough space
around it for ventilation (3~4 inches).
Make sure the ventilation slots are not covered. Do not place the
unit on ampliers or other equipment which may become hot.
This unit is designed for continuous use. To fully turn off the
unit, disconnect the AC plug from the wall outlet.
2. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the unit to
malfunction.
3. Unplug the Power cord from the AC wall socket if the unit
malfunctions. Your product is not intended for industrial use. It
is for personal use only. Condensation may occur if your product
has been stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until the unit has
reached room temperature before using it.
4. If the electricity supplied to your home is rated at 240V AC, use
a suitable plug adapter to connect this unit to your electrical
outlets.
01 CHECKING THE
COMPONENTS
Wireless Receiver Module / Surround Speaker X 2 / Speaker
Cable X 2 (AH81-02137A) / Power Cord (3903-001117)
NOTES
• For more information about the power supply and power
consumption, refer to the label attached to the product.
(Label: Rear of the Main Unit)
• Design and specications are subject to change without prior
notice.
02 CONNECTING THE
SWA-9100S TO A
SOUNDBAR
1. Connect the Wireless Receiver Module to
2 Surround Speakers
Use the speaker cables to connect the two surround sound
speakers to the Wireless Receiver Module.
• When connecting the speaker cable, connect the core wire to
the speaker.
SURROUND-RIGHT
SURROUND-RIGHT
• The speaker cables are color coded.
SURROUND-LEFT
ID SET
L
R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
POWER
ID SET
L
R
SURROUND SPEAKERS OUT
SPEAKER IMPEDANCE : 3Ω
SURROUND-RIGHT
SURROUND-LEFT SURROUND-RIGHT
• When connecting the speaker cables to the Wireless Receiver
Module, follow these steps:
1. Insert the grey plug into the grey jack on the Wireless
Receiver.
2. Insert the blue plug into the blue jack on the Wireless
Receiver.
© 2021 Samsung Electronics Co., Ltd. All rights reserved.
QUESTIONS OR COMMENTS?
Country
IN THE US
1-800-SAMSUNG
(726-7864)
www.samsung.com/us/support
Samsung Electronics America, Inc.
85 Challenger Road
Ridgefi eld Park, NJ 07660
Samsung Service Center
Web Site Address
VA81-01112A-01
NSPBI00840A-01
Loading ...
Loading ...
Loading ...
