SPOTCLEAN TURBO
_______________
USER GUIDE
15582
F
L
O
O
R
C
L
E
A
N
I
N
G
E
X
P
E
R
T
S
E
S
T
.
1
8
7
6
U
.
S
.
A
.
www.BISSELL.com.au
2
IMPORTANT SAFETY INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
» This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way
and understand the hazards involved.
Cleaning and user maintenance shall not
be made by children without supervision.
» Children should be supervised to ensure
that they do not play with the appliance.
» Unplug from electrical socket when not
in use, before cleaning, maintaining, or
servicing the appliance.
» Do not immerse in water or liquid.
» Keep hair, loose clothing, fingers, and all
parts of body away from openings and
moving parts of the appliance and its
accessories.
» Do not immerse. Use only on surfaces
moistened by the cleaning process. Use
only BISSELL® cleaning products intended
for use with this machine.
» Use only the type and amount of liquids
specified under the operations section of
this guide.
» Use only on carpet moistened by the
cleaning process.
» Liquid must not be directed towards
equipment containing electrical
components.
» Always connect to a properly earthed electrical socket. Do
not modify earthed plug.
» Always install float before any wet pick-up operation.
» Plastic film can be dangerous. To avoid danger of
suffocation, keep away from children.
» Use only as described in this user guide.
» Use only manufacturer’s recommended attachments.
» If appliance is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water; do not
attempt to operate it and have it repaired at an authorised
service center.
» Do not put any object into openings.
» Do not use with any opening blocked; keep free of dust,
lint, hair, and anything that may reduce air flow.
» Use extra care when cleaning on stairs.
» Do not use to pick up flammable or combustible liquids,
such as petroleum, or use in areas where they may be
present.
» Do not pick up toxic material (chlorine bleach, ammonia,
drain cleaner, etc.).
» Do not use appliance in an enclosed space filled with
vapours given off by oil-based paint, paint thinner, some
moth-proofing substances, flammable dust, or other
explosive or toxic vapours.
» Do not pick up hard or sharp objects such as glass, nails,
screws, coins, etc.
» Do not pick up anything that is burning or smoking, such
as cigarettes, matches or hot ashes.
» Do not use without filters in place.
» Indoor use only.
» If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
person in order to avoid a hazard.
» Do not run appliance over cable.
» Do not leave appliance when plugged in.
» Do not use with damage cable or plug.
» Do not pull or carry by cable, use cable as a handle,
close door on cable, or pull cable around sharp edges or
corners.
» Keep cable away form heated surfaces.
» To unplug, grasp the plug, not the cable.
» Do not handle plug or appliance with wet hands.
» Turn off all controls before unplugging.
» Always install float before any wet pick-up operation.
SAVE THESE INSTRUCTIONS
ORIGINAL INSTRUCTIONS. FOR OPERATION ON A 220-240 VOLT
A.C. 50-60 HZ POWER SUPPLY ONLY.
THIS MODEL IS FOR HOUSEHOLD USE ONLY.
IMPORTANT INFORMATION
» Keep appliance on a level surface.
» To reduce the risk of a leaking condition, do not store unit where freezing may occur. Damage to internal components
may result.
READ ALL INSTRUCTIONS BEFORE USING YOUR APPLIANCE.
When using an electrical appliance, basic precautions should be observed, including the following:
www.BISSELL.com.au
3
Th for buying a BISSELL
®
portable spot cleer
We’re glad you purchased a
BISSELL portable spot cleaner.
Everything we know about floor
care went into the design and
construction of this complete,
high-tech home cleaning system.
Your BISSELL portable spot cleaner
is well made, and we back it with a
limited two year guarantee. We also
stand behind it with a knowledgeable,
dedicated Consumer Care
department, so, should you ever
have a problem, you’ll receive fast,
considerate assistance.
My great-grandfather invented the
floor sweeper in 1876. Today, BISSELL
is a global leader in the design,
manufacture, and service of high
quality homecare products like your
BISSELL portable spot cleaner.
Thanks again, from all of us at
BISSELL.
Mark J. Bissell
Chairman & CEO
Safety Instructions...........2
Product View................4
Assembly ...................5
Operations ..................6
Maintenance & Care .........7
Troubleshooting .............7
Guarantee ...................8
Consumer Care ..............8
WARNING
AN ACTION OR ATTENTION IS NEEDED TO THIS AREA IN ORDER
TO REDUCE THE RISK OF ELECTRIC SHOCK, FIRE, OR INJURY
GUIDE
READ USER GUIDE FOR COMPLETE SAFETY AND USER
INSTRUCTIONS
WEEE
DO NOT THROW THE APPLIANCE AWAY WITH THE NORMAL
HOUSEHOLD WASTE AT THE END OF ITS LIFE, BUT HAND IT IN
AT AN OFFICIAL COLLECTION POINT FOR RECYCLING. BY DOING
THIS YOU WILL HELP TO PRESERVE THE ENVIRONMENT.
www.BISSELL.com.au
4
Product View
WARNING
» To reduce the risk of fi re and electric shock
due to internal component damage, use
only BISSELL® cleaning formulas intended
for use with the deep cleaner.
» Do not plug in your cleaner until you have
completely assembled it per the above
instructions and are familiar with all
instructions and operating procedures.
ONLY BISSELL Wash & Protect formulas protect from future stains with Scotchgard™ Protector. Scotchgard™ is a trademark of 3M®.
Certain trademarks used under license from The Procter & Gamble Company or its affilitates.
Dirty Water
Tank
Power Cord
Carry Handle
Quick
Release
Cord
Wrap
Formula
& Clean
Water Tank
Flex Hose
Power Button
Cleaning
Tool
NOTICE: Use of cleaning formulas which contain lemon, eucalyptus or pine oil may
damage this appliance and void the guarantee. Chemical spot cleaners or solvent-
based soil removers also should not be used. These products may react with the
plastic materials used in your cleaner, causing cracking or pitting.
CLEANING FORMULAS
WASH & PROTECT
WASH &
REMOVE
WASH & REFRESH WASH & SHINE
Professional
Stain & Odour
Pet Stain &
Odour
Stain & Odour
Allergen
Removal
Ambipur
Blossom &
Breeze
Natural Orange Hard Floor
Professional
strength to
remove extra
tough stains and
odours
Includes
Scotchgard™
Protector
Removes tough
pet stains
and contains
odour removal
technology
Includes
Scotchgard
Protector
Removes tough
stains and
odours Includes
Scotchgard
Protector
Helps remove
allergens like
pet, pollen and
dust mite waste
Powerful
cleaning
with a
refreshing
spring scent
Powerful
cleaning with
a refreshing
natural orange
scent
Removes tough
dirt and grime
and leaves a
natural shine
PRETREAT
PRETREAT SPOTS AND STAINS TO IMPROVE CARPET CLEANING
PERFORMANCE
Stain PreTreat Pet Stain PreTreat
Pretreat to penetrate and loosen
tough stains
Pretreat to help remove tough pet stains
and odours
www.BISSELL.com.au
5
Before You Clean
1. Remove loose dirt and impediments before
deep cleaning.
2. Pretreating (optional):
2a. Pretreating is recommended to improve
cleaning effectiveness for heavily soiled
carpet in high traffic areas such as entryway
and hallways.
2b. BISSELL® Stain Pretreat
Spray the BISSELL Stain
Pretreat formula onto heavy traffic areas,
soiled areas or stains.
Allow to penetrate for at least 3 minutes.
Clean as normal, following the
instructions below.
Preparing the Machine
1. Release flex hose by twisting the
hose secure latch clockwise. Unwrap
flex hose completely.
2. Attach the Large Stain Tool or Tough Stain
Tool to the hose grip until it snaps together.
Make certain the tool is securely attached.
3. Twist the Quick Release Cord Wrap
clockwise to unwrap the power
cord completely and plug into
grounded outlet.
Filling the Formula & Water Tank
1. Remove tank from the back of the
machine by lifting up tank carry handle.
Note: This tank was designed with a
flat bottom so it can be easily filled.
2. Unscrew the black cap and remove
bottle insert.
3. Fill tank with hot tap water (140° F/60° C
MAX) to the water
fill line. Add 60 mL of BISSELL 2X formula to
the tank.
4. Replace the bottle insert in the tank and tight-
en the black cap. Replace the tank
on the machine.
2b.
ATTENTION
Some Berber carpets have a tendency to fuzz with
wear. Repeated strokes in the same area may
aggravate this condition.
1.
2.
Make only one trip to
the sink by bringing
the entire portable
cleaner. Fill and empty
in the same trip.
As mbly
Tip
www.BISSELL.com.au
6
2.
3.
4.
5.
WARNING
Keep spray away from face. Failure to do so may
result in personal injury.
IMPORTANT
Check the manufacturer’s tag before
cleaning upholstery. Test a small, hidden
area for colourfastness. If colour is
aected, do not use. If manufacturer’s
tag is missing or not coded, check with
your furniture dealer.
Operatis
Cleaning with your Spot Cleaner
1. Plug unit in and turn on by pressing power
button.
2.
Hold cleaning tool approximately 2.5cm
above soiled surface. Press spray trigger to
apply cleaning solution to soiled area.
3.
Using the brush on the cleaning tool, gently
scrub area to be cleaned.
4. For thorough cleaning, spray additional
solution while brush and suction are in
contact with surface.
5.
Apply downward pressure on cleaning
tool and pull it toward you. The suction
will remove the dirt and cleaning solution.
Continue until no more dirt can be removed.
6. As a final step, use “drying strokes” (by not
pressing the spray trigger) to remove as
much liquid/moisture as possible. Repeat this
step as often as necessary.
Emptying the Dirty Water Tank
1. When the Dirty Water Tank reaches the “FULL”
line on the tank it is time to empty.
2. Remove Dirty Water Tank and carry to a utility
sink, toilet or outside (where you will
dispose of the dirty water).
3. To unlock the Dirty Water Tank lid, rotate handle
over the back of the tank. Remove lid and pour
out dirty water. Rinse out Dirty Water Tank
to remove any debris.
4. Replace top of tank, and rotate the handle
forward to lock in place on front of tank.
5. Before replacing tank on machine, wipe debris
from red filter.
Cleaning your Machine
1. Remove and rinse the tools under clean,
running water. Allow tools to dry.
2. It is recommended that you suction clean
water from a bowl to rinse out the hose. Then
lift end of hose and stretch out to ensure all
water is cleared from hose.
3. Wrap the Flex Hose around the hose wrap and
secure with latch.
For best results
empty, rinse and
dry tanks and tools
before storing.
Tip
www.BISSELL.com.au
7
Trbleshting
Mainnce & Care
Machine Care (check regularly)
Cleaning Debris Filter
1. Remove all hair and debris from the red
filter.
2. Place the Dirty Water Tank back onto the
machine.
WARNING
To reduce the risk of fire, electric shock, or injury, turn
power OFF and disconnect plug from electrical outlet
before performing maintenance or troubleshooting.
WARNING
To reduce the risk of electric shock, turn power OFF
and disconnect plug from electrical outlet before
performing maintenance or troubleshooting checks.
Problem Possible causes Remedies
Reduced spray
or
no spray
Formula and Clean Water Tank
may be empty
Refill tank
Formula and Clean Water Tank
may not be seated completely
Turn power OFF; Remove and reseat tank
Pump may have lost prime Hold end of hose below water level in tank
to prime
Loss of suction
power
Tanks may not be seated prop-
erly
Pick up both tanks and reseat them so they
fit snuggly on the unit
Dirty Water Tank has picked up
maximum amount of dirty water
and has reached full line
Empty Dirty Water Tank
Formula and Clean Water Tank
is empty
Check fluid levels in Formula and Clean
Water Tank
Debris
Filter
©2019 BISSELL Inc.
Grand Rapids, Michigan
All rights reserved. Printed in China
Part Number 162-0069 05/19
Visit the BISSELL website: www.BISSELL.com.au
When contacting BISSELL, have model number of cleaner available.
Please record your Model Number:
Please record your Purchase Date:
NOTE: Please keep your original sales receipt. It provides proof of the date
of purchase in the event of a guarantee claim. See guarantee for details.
This guarantee gives you specific legal rights, in addition to rights you may
have under the Australian Consumer Law. If you need additional instruction
regarding this guarantee or have questions regarding what it may cover,
please contact your local BISSELL Consumer Services on the details set out
below.
Limited 2 Year Guarantee
(from the date of purchase by
original purchaser)
Subject to the *CONDITIONS identified below, BISSELL will repair or replace
(with new, refurbished, lightly used, or remanufactured components or
products), at BISSELL’s option, free of charge, any defective or malfunctioning
part due to manufacturer defect. This guarantee applies to product used for
personal purposes, and not commercial or rental service. This guarantee does
not apply to fans or routine maintenance or consumable components such as
filters, belts, brush rolls, etc., damage or malfunction caused by negligence,
abuse, neglect, unauthorized repair, or any other use not in accordance with
the user guide. BISSELL recommends that the original packaging be kept
for the duration of the guarantee period in case such need arises within the
guarantee period that the item needs re-packing and transportation.
It may be necessary to obtain some of your personal information, such as a
mailing address, to fulfill terms of this guarantee. Any personal data will be
handled pursuant to BISSELL’s Privacy Policy, which can be found at
www.BISSELL.eu.
*CONDITIONS OF THE GUARANTEE
Subject to whether such loss is reasonably foreseeable, BISSELL and its
in-country distributors are not liable for incidental or consequential damages
of any nature associated with the use of this product.
FOR AUSTRALIAN CONSUMERS ONLY:
OUR GOODS COME WITH GUARANTEES THAT CANNOT BE EXCLUDED UNDER
THE AUSTRALIAN CONSUMER LAW. YOU ARE ENTITLED TO A REPLACEMENT
OR REFUND FOR A MAJOR FAILURE AND FOR COMPENSATION FOR ANY OTHER
REASONABLY FORESEEABLE LOSS OR DAMAGE. YOU ARE ALSO ENTITLED TO HAVE
THE GOODS REPAIRED OR REPLACED IF THE GOODS FAIL TO BE OF ACCEPTABLE
QUALITY AND THE FAILURE DOES NOT AMOUNT TO A MAJOR FAILURE.
THIS GUARANTEE IS IN ADDITION TO OTHER RIGHTS OR REMEDIES UNDER LAW.
NOTHING IN THIS GUARANTEE EXCLUDES, LIMITS OR MODIFIES ANY LIABILITY
OF BISSELL WHICH IS IMPOSED BY LAW, OR LIMITS OR MODIFIES ANY REMEDY
AVAILABLE TO THE CONSUMER WHICH IS GRANTED BY LAW. TO MAKE A CLAIM
UNDER THIS GUARANTEE CONTACT BISSELL AUSTRALIA PTY LTD (DETAILS
BELOW). CONTACT BISSELL PRIOR TO RETURNING ANY GOODS. WHERE AGREED,
BISSELL WILL REIMBUSE REASONABLE POSTAGE / HANDLING COSTS (IF ANY) FOR
RETURNING GOODS TO BISSELL. TO CLAIM EXPENSES INCURRED IN MAKING A
CLAIM UNDER THIS GUARANTEE PLEASE PROVIDE BISSELL WITH A COPY OF THE
RECEIPT OF THE EXPENSES BY EMAIL OR POST.
If your BISSELL® product should require service or to claim under our limited guarantee,
please contact us as follows:
Website and Email:
www.BISSELL.com.au
www.BISSELL.co.nz
Telephone:
Australia: 1300-247-735
New Zealand: 0800-247-735
Write:
BISSELL AUSTRALIA PTY LIMITED
42 Rocco Dr.
Scoresby 3179
Victoria
Australia
Replacement parts and accessories are available for purchase.
To purchase visit www.BISSELL.com.au.
Consumer Guarantee
Consumer Care
