NEED HELP?
FCC Statement
This equipment has been tested and found to comply with the limits
for Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
FCC RF Radiation Exposure Statement Caution: To maintain
compliance with the FCC’s RF exposure guidelines, place the
product at least 20cm from nearby persons. The device must not
be co-located or operating in conjunction with any other antenna
or transmitter.
Modifications not approved by the party responsible for compliance
could void user’s authority to operate the equipment.
EU Declaration of Conformity
Hereby, Swann Communications, declares that this device is in
compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU. A copy of the Declaration of
Conformity can be found at: www.swann.com/uk/compliance
IC Statement
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
The device is compliance with RF field strength limits, users can
obtain Canadian information on RF exposure and compliance.
This Class B digital apparatus complies with Canadian ICES-003.
This equipment complies with IC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the
radiator & your body.
RECYCLING: This product bears the selective sorting symbol for
waste electrical and electronic equipment (WEEE) should not be
disposed with other household wastes throughout the EU. This
means that this product must be handled pursuant to European
Directive 2012/19/EU in order to be recycled or dismantled to
minimize its impact on the environment.
© Swann Communications 2018
QSGWHDOUTCAMVER1E
tech@swann.com
Install the camera in a location with strong, reliable Wi-Fi reception to ensure best streaming
performance. You can easily check the Wi-Fi signal strength of the camera using the app.
As a general rule, the nearer your camera is to your Wi-Fi router, the better the wireless
connection quality.
Mounting the camera
The camera can be mounted to a flat surface using screws. The surface must have sufficient
strength to hold the camera. Materials such as hardwood, brick or masonry are good options.
To mount the camera, simply follow the instructions in the supplied mounting template.
Motion detection
The camera’s PIR motion sensor detects heat signatures of moving objects. You’ll generally
get good detection results by pointing the camera downwards at an angle where people will
be moving across the coverage area before heading directly towards the camera.
Adjusting the camera angle
Using the supplied L-wrench, loosen the appropriate hex screws on the stand of the camera
to pan, tilt or rotate the camera. Remember to tighten the screws back securely to lock the
camera’s position in place after adjusting the angle.
QUICK START GUIDE
Camera LED Indicator Guide
Slow Blinking Blue
(& Blinking Infrared LEDs)
Wi-Fi Pairing mode
Solid Red
Live streaming / Motion recording
Blinking Purple
Out of Wi-Fi range
There's more information and support online for your product. Find latest
guides, FAQs, customer support, and more, by visiting support.swann.com.
Product Registration
Product Guides
Customer Support
Support Community
ENGLISH
Outdoor Security Camera
CAMERA PLACEMENT HELP AND RESOURCES
This symbol indicates the DC voltage
