1 2
D - 90 °C VTemp. °C Select the temperature (D = cold)
1 - 24h Ready in Programme end after
- 1100* rpm Select the spin speed (*depending on the model) or
laundry soaks in the last rinsing water, display panel
Status displays Programme sequence displays:
1üüüücü-0- Wash, rinse, spin, programme duration or end (-0-)
$
c2
>
$
$
Correct installation according to the
separate Installation instructions.
Checking the machine
– Never use a damaged machine.
– Inform customer service.
Connecting the mains
plug
Make sure your hands are dry.
Take hold of the plug only.
Turning the tap on
Compartment II: Detergent for the main wash, water
softener, bleach, stain remover
a
a
Close the washing machine door. Take care not to tra
Pour liquid detergent into the appropriate dispense
Your washing machine
Congratulations ä You have opted for a modern, high-quality
domestic appliance manufactured by Bosch. This washing machine
is distinguished by its economical water and energy consumption.
Each machine that leaves our factory has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
Further information: www.bosch-home.com
You can find the contact details for your nearest after-sales service
here or in the after-sales service directory (depending on model).
GB 0844 8928979
Calls from a BT landline will be charged at up to 3 pence per
minute. A call set-up fee of up to 6 pence may apply.
IE 01450 2655
0.03 € per minute at peak. Off peak 0.0088 € per minute.
Environmentally friendly waste disposal
Dispose of packaging in an environmentally-responsible manner.
This appliance is labelled in accordance with European Directive
2012/19/EU concerning used electrical and electronic appliances
(waste electrical and electronic equipment - WEEE).
The guideline determines the framework for the return and recycling
of used appliances as applicable throughout the EU.
Intended use
Contents Page
ʋIntended use .......................................................................................1
ʋProgrammes .......................................................................................1
ʋSetting and adjusting the programme ...........................................3
ʋWashing ...........................................................................................3/4
ʋAfter washing ......................................................................................4
ʋIndividual settings ..............................................................................5
ʋImportant information ...................................................................... 6
ʋOverview of programmes ................................................................7
ʋSafety instructions .............................................................................8
ʋConsumption values .........................................................................8
ʋCare .....................................................................................................9
ʋInformation on the display panel ....................................................9
ʋMaintenance .................................................................................... 10
ʋWhat to do if ... ................................................................................ 11
Protection of the environment/Conservation tips
– Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled laundry without a pre-wash.
– The selectable temperatures apply to the care labels on the
textiles. The temperatures in the machine may deviate from this
so that you get the optimum mix of energy-saving and washing
results.
– Measure the detergent according to the manufacturer's
instructions and water hardness.
– If the laundry is then dried in the tumble dryer, select the spin
speed according to the instructions of the dryer manufacturer.
Preparation
a
Display panel /
options buttons
Programme selectorStart/Pause
Programmes
Detailed overview of programmes apage 7.
Temperature and spin speed can be selected individually,
irrespective of the selected programme and programme
progress.
L Cottons
hard-wearing fabrics
ºCottons Stains
Cottons Eco
Delicate/Silk delicate washable fabrics
// :÷Wool hand/machine-washable wool
IEasy-Care easy-care fabrics
KDark Load dark textiles
2Rinse/Freshen Up with subsequent spin cycle; for hand-
washed items, starching or freshen
up items apage 6.
Spin laundry washed by hand
Gentle Spin laundry washed by hand with a
reduced spin speed
>Drain the rinsing water if
(without final
spin) occurs
1Mixed Load different types of laundry
6Super 15´ short programme
$÷Sportswear fabrics made from microfibre
ā÷Allergy Plus hard-wearing fabrics
a
$
~
Compartment ~: Fabric softener, starch
Compartment I: Detergent for pre-wash
ʋfor domestic use only,
ʋfor washing machine-washable fabrics and hand-
washable wool in detergent solution,
ʋto be operated with cold drinking water and commer-
cially available detergents and care products which are
suitable for use in washing machines.
.
– Do not leave children unattended near the
washing machine.
– The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing machine.
Read these instructions and the separate
installation instructions before operating
the washing machine.
ʑ
ʑ
V
ʑ
$
ʑ
c
ʑ
a
c
c
ʑ
$
ʑ
Additional
functions
>
$
c
c
L$
$
$
~
2
