RAL

RETURN

R INL

IRE

FURNACE

MAKE-UP AIR KIT

DAMPER

ZEPHYR

ZEPHYRONLINE.COM

When range hoods exhaust air out

of your home, negative air pressure

is created unless the exhausted air is

replaced by fresh outdoor air. Zephyr’s

Make-Up Air Damper is designed to

balance the air pressure in your home

by automatically opening to allow fresh

air in while the range hood is operating.

For use with any Zephyr hood operat-

ing over 300 CFM.

DAMPER SIZEMODEL

FEATURES

OPTIONAL ACCESSORIES

PRESSURE SWITCH

MUA006A

MUA008A

MUA010A

Pressure Switch Components

Transformer

DAMPER

TYPICAL INSTALLATION

• 24VAC,60HzACmotor

• MeetsInternationalResidentialCodeM1503.4

• Automaticallyopenswhenrangehoodisoperating

• Automaticallycloseswhenrangehoodisoff

• 24-gaugegalvanizedsteelconstruction

• Adjustmentscrewtoadjustdamperopening

AK00030Freshairinletcapwithscreen,6”round

AK00032Freshairinletcapwithscreen,8”round

AK00052Freshairinletcapwithscreen,10”round

Mountstoductinginhoodand

communicateswithmake-up

airdampervialow-voltage

signalwires.

Make-UpAirDamper

IncludedwithMUA006A,

MUA008A&MUA010A

Installsnexttodamper.

IncludedwithMUA006A,

MUA008A&MUA010A

CFM LEVEL

of range hood motor

MUA006A

MUA008A

MUA010A

6”round

8”round

10”round

upto600CFM

upto1,000CFM

upto1,300CFM

Specicationssubjecttochange,checkzephyronline.comforup-to-dateinformation.

ZephyrVentilation|2277HarborBayParkway,Alameda,CA94502|888.880.VENT

FEB18.0101

10”

6”

9”

10”

8”

11”

10”

13”
