Schwinn 100513 Fitness Upright Bike Series User Manual

ASSEMBLY MANUAL / OWNER’S MANUAL

Manual en Español Latino Americano:

Kttp:ZZZscKZinn¿tnesscom

170

Important Safety Instructions 3

Safety Warning Labels / Serial Number 5

Speci¿cations 

%efore Assembly 

Parts 7

Hardware 8

Tools 8

Assembly 9

Leveling the Bike 15

Moving the Bike 15

)eatures 1

Console Features 17

Bluetooth

Connectivity 20

Virtual Reality Experience on

Your Fitness Machine 20

Remote Heart Rate Monitor 21

Operations 23

Adjustments 23

Initial Setup 23

Quick Start / Manual Program 24

8ser Pro¿les 24

Pro¿le Programs 2

Pausing or Stopping 29

Results 29

GOAL TRACK Statistics 29

Console Setup Mode 31

Maintenance 32

Troubleshooting 34

Warranty 39

TABLE OF CONTENTS

To validate warranty support, keep the original proof of purchase and record the following information:

Serial Number __________________________

Date of Purchase ____________________

To register your product warranty , go to: www.SchwinnFitness.com/register

Or call 1 800 05±339

If you have Tuestions or problems with your product, please call 1 800 05±339

Or go to: wwwSchwinnFitnesscom

Nautilus, Inc, wwwNautilusInccom  Customer Service: North America 800 05339, csnls#nautiluscom _ outside 8S

wwwnautilusinternationalcom _  201 Nautilus, Inc _ ® indicates trademarks registered in the 8nited States These marks may be

registered in other nations or otherwise protected by common law Schwinn, the Schwinn Quality logo, Schwinn 170, BowÀex, Nautilus,

and 8niversal are trademarks owned by or licensed to Nautilus, Inc Polar®, OwnCode®, iTunes®, Google Play, 8nder Armour®,

MyFitnessPal®, iOS® and Android are trademarks of their respective owners The Bluetooth® word mark and logos are registered

trademarks owned by Bluetooth SIG, Inc, and any use of such marks by Nautilus, Inc is under license

IMPORTANT SAFETY INSTRUCTIONS

This icon means a potentially hazardous situation which, if not avoided, could result in death or serious

injury.

Obey the following warnings:

Read and understand all warnings on this machine.

Carefully read and understand the Assembly instructions.

 Keep bystanders and children away from the product you are assembling at all times

 'o not connect power supply to the machine until instructed to do so

 'o not assemble this machine outdoors or in a wet or moist location

 Make sure assembly is done in an appropriate work space away from foot traf¿c and exposure to bystanders

 Some components of the machine can be heavy or awkward 8se a second person when doing the assembly

steps involving these parts 'o not do steps that involve heavy lifting or awkward movements on your own

 Set up this machine on a solid, level, hori]ontal surface

 'o not try to change the design or functionality of this machine This could compromise the safety of this machine

and will void the warranty

 If replacement parts are necessary, use only genuine Nautilus replacement parts and hardware Failure to use

genuine replacement parts can cause a risk to users, keep the machine from operating correctly and void the

warranty

• Do not use until the machine has been fully assembled and inspected for correct performance in accordance with

the Manual

• Read and understand the complete Manual supplied with this machine before ¿rst use Keep the Manual for future

reference

• Do all assembly steps in the seTuence given Incorrect assembly can lead to injury or incorrect function

Before using this equipment, obey the following warnings:

Read and understand the complete Manual. Keep the Manual for future reference.

Read and understand all warnings on this machine. If at any time the Warning labels become loose,

unreadable or dislodged, contact Nautilus Customer Service for replacement labels.

• Children must not be let on or near to this machine Moving parts and other features of the machine can be

dangerous to children

• Not intended for use by anyone under 14 years of age

• Consult a physician before you start an exercise program Stop exercising if you feel pain or tightness in your

chest, become short of breath, or feel faint Contact your doctor before you use the machine again 8se the

values calculated or measured by the machine¶s computer for reference purposes only

• Before each use, examine this machine for loose parts or signs of wear Do not use if found in this condition

Monitor the Seat, Pedals, and Crank Arms closely Contact Nautilus Customer Service for repair information

• This appliance should only be used with the power supply unit provided, or a replacement power supply unit

supplied from Nautilus, Inc

• Maximum user weight limit: 300 lbs 13 kg Do not use if you are over this weight

• This machine is for home use only

• Do not wear loose clothing or jewelry This machine contains moving parts Do not put ¿ngers or other objects into

moving parts of the exercise eTuipment

• Set up and operate this machine on a solid, level, hori]ontal surface

• Make the Pedals stable before you step on them 8se caution when you step on and off the machine

• Disconnect all power before servicing this machine

• Do not operate this machine outdoors or in moist or wet locations Keep the foot pedals clean and dry

• Keep at least 24´ 0 m on each side of the machine clear This is the recommended safe distance for access

and passage around and emergency dismounts from the machine Keep third parties out of this space when

machine is in use

• Do not over exert yourself during exercise Operate the machine in the manner described in this manual

• Correctly adjust and safely engage all Positional Adjustment Devices Make sure that the Adjustment Devices do

not hit the user

• Exercise on this machine reTuires coordination and balance Be sure to anticipate that changes in speed and

resistance level can occur during workouts, and be attentive in order to avoid loss of balance and possible injury

• Prior to use, read and understand the owner¶s manual The appliance is not to be used by persons with functional

limitations and impairments, reduced physical, sensory or mental capabilities, or lack of experience and

knowledge

SAFETY WARNING LABELS AND SERIAL NUMBER

FCC Compliance

Changes or modi¿cations to this unit not expressly approved by the party responsible for compliance could void

the user¶s authority to operate the eTuipment

The machine and power supply comply with part 15 of the FCC rules Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation

Note: This machine and power supply have been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules These limits are designed to provide reasonable protection

against harmful interference in a residential installation This eTuipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications

However, there is no guarantee that interference will not occur in a particular installation If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Serial number

Product

VSHFL¿FDWLRQ

WARNING!

• Injury or death is possible if

caution is not used while using this

machine.

• Keep children and pets away.

• Read and follow all warnings on this

machine.

• Refer to the Owner’s Manual for

additional warnings and safety

information.

• The heart rate displayed is an

approximation and should be used

for reference only.

• Not intended for use by anyone

under 14 years of age.

• The maximum user weight for this

machine is 300 lbs ( 136kg ).

• This machine is for home use only.

• Consult a physician prior to using

any exercise equipment.

SPECIFICATIONS

41.3” (105cm)

21.4” (54cm)

55.6” (141cm)

Before Assembly

Select the area where you are going to set up and operate your machine For safe operation, the location must be on

a hard, level surface Allow a workout area of a minimum 90´ x 70´ (23m x 18m)

Basic Assembly Tips

Follow these basic points when you assemble your machine:

1 Read and understand the ³Important Safety Instructions´ before assembly

2 Collect all the pieces necessary for each assembly step

3 8sing the recommended wrenches, turn the bolts and nuts to the right (clockwise) to tighten, and the left (counter

clockwise) to loosen, unless instructed otherwise

4 When attaching 2 pieces, gently lift and look through the bolt holes to help insert the bolt through the holes

5 The assembly can require 2 people

Maximum User Weight: 300 lbs (13 kg)

Power Requirements:

Operational Voltage: 9VDC

Operating Current: 1500mA

Regulatory Approvals:

AC Power Adapter: 8L listed, CSA certi¿ed, Rated 120V

0H] Input, 9VDC, 1500mA Output

Class 2

PARTS

Item Qty Description Item Qty Description

1 1 Main Frame 9 1 Seat Post

2 1 Front Stabilizer 10 1 Adjustment Knob

3 1 Rear Stabilizer 11 1 Seat

4 1 Top Shroud 12 1 Left Pedal (L)

5 1 Mast Gasket 13 1 Right Pedal (R)

 1 Console Mast (with Handlebar Mount) 14 1 Water Bottle Holder

7 1 Handlebars 15 1 AC Adapter

8 1 Console 1 1 Handlebar Mount Cover

Note: Media Cable is in a bag

12 (L)

13 (R)

HARDWARE / TOOLS

Tools

Included Not Included

 mm

(recommended)

Item Qty Description

A 4 Button Head Hex Screw M8 x 25

B 5 Lock Washer M8

C 4 Curved Washer M8

D 1 Flat Washer M8

E1Thandle

Note: Select pieces of Hardware have been provided as spares on the

Hardware Card Be aware that there may be remaining Hardware

after the proper assembly of your machine

ASSEMBLY

1. Attach Stabilizers to Main Frame

Note: Hardware() is preinstalled on the stabilizers and not on Hardware Card Make sure transport wheels on the

front stabilizer point forward, and the Schwinn

decal on the rear stabilizer faces outward from the machine

2. Install Console Mast, Mast Gasket and Top Shroud on Main Assembly

NOTICE: Make sure the Console Cable connector (a) does not fall into the Console Mast Align the clips on the cable

connectors and make sure the connectors lock Do not crimp Console Cable Be sure the tabs on the Top

Shroud snap into the Main Assembly

6 mm

3. Install Handlebars on Console Mast

NOTICE: Do not crimp the cables Put the Handlebar (7) in the bracket (a), adjust the Handlebar to the desired

angle, and install the Thandle (E) through the holes 8se the pull cable in the Handlebar Mount to route

the HR cable (7a) through the slot (c) under the Handlebar Mount to the top of the mast Fully tighten

the Thandle to keep the Handlebar in position Push the cover (1) into position on the Handlebar Mount

4. Install Console on Console Mast

Note: Remove the preinstalled screws() from the back of the Console before you connect the cables

NOTICE: Do not crimp the cables

5. Install Seat Post on Frame

NOTICE: Make sure the Adjustment Knob engages the Seat Post

Do not set the Seat Post position higher than the stop mark (STOP) on the tube.

6. Attach Seat to Seat Post

NOTICE: Be sure the Seat is straight Tighten the nuts (11b) on the Seat bracket (11a) to hold the Seat in position

STOP

11a

11b

7. Install Pedals

Note: The Left Pedal is reverse-threaded. Be sure to attach Pedals on the proper side of the Bike Orientation

is based from a seated position on the bike The Left Pedal has an ³L´, the Right Pedal an ³R´

12 (L)

13 (R)

8. Install Water Bottle Holder

Note: The hardware() is preinstalled on the Console Mast and not on Hardware Card

9. Connect AC Adapter

10. Final Inspection

Inspect your machine to ensure that all hardware is tight and components are properly assembled

Be sure to record the serial number in the field provided at the front of this manual

Do not use or put the machine into service until the machine has been fully assembled and inspected for

correct performance in accordance with the Owner’s Manual.

Leveling Your Bike

Levelers are found on each side of the Rear Stabilizer Turn the knob to adjust the stabilizer foot Make sure the bike

is level and stable before you exercise

Moving Your Bike

To move the upright bike, carefully tilt the Handlebars toward you while pushing the front of the bike downward Push the

bike to the desired location

NOTICE: Be careful when you move the bike Abrupt motions can affect the computer operation

BEFORE YOU START

FEATURES

A Console L Water Bottle Holder

B Handlebars with Elbow Pads M MP3 Input

C Adjustable Seat N USB Port

D Seat Slider Adjustment Knob O Contact Heart Rate (CHR) Sensors

E Seat Post Adjustment Knob P Speakers

F Pedals Q Fan

G Stabilizers R Media Tray

H Levelers S Telemetry Heart Rate (HR) Receiver

I Fully Shrouded Flywheel T Bluetooth

Connectivity (not shown)

J Transport Rollers U Media Cable

K Power Connector

WARNING! Use the values calculated or measured by the machine’s computer for reference purposes only. The

heart rate displayed is an approximation and should be used for reference only. Over exercising may

result in serious injury or death. If you feel faint stop exercising immediately.

Console Features

The Console provides important information about your workout and lets you control the resistance levels while you

exercise The Console features the Schwinn Dual Track



display with touch control buttons to navigate you through the

exercise programs

Keypad Functions

Resistance Increase (c) button Increases the workout resistance level

Resistance Decrease (d) button Decreases the workout resistance level

QUICK START button Begins a Quick Start workout

USER button Selects a User pro¿le

PROGRAMS button Selects a category and workout program

PAUSE / END button Pauses an active workout, ends a paused workout, or goes back to the previous screen

GOAL TRACK buttonDisplays the Workout Totals and Achievements for the selected User Pro¿le

Increase (c) button Increases a value (age, time, distance, or calories) or moves through options

Left (e) button Displays different workout values during a workout, and moves through options

OK button Starts a Program workout, con¿rms information, or resumes a paused workout

Right (f) button Displays different workout values during a workout, and moves through options

Decrease (d) button Decreases a value (age, time, distance, or calories) or moves through options

Upper Display

Lower Display

Resistance Level Quick Buttons

Achievement Indicator Lights

Fan

FAN button Controls 3speed fan

Resistance Level Quick Buttons Shifts the resistance levels to the setting quickly during a workout

Achievement Indicator Lights when an achievement level is reached or a result is reviewed, the achievement indicator

light will activate

Schwinn Dual Track

™

Display

Upper Display Data

Program Display

The Program Display shows information to the User and the grid display area shows the course pro¿ le for the program

Each column in the pro¿ le shows one interval (workout segment) The higher the column, the higher the resistance level

The À ashing column shows your current interval

Intensity Display

The Intensity Display shows the level of work at that moment based on the current resistance level

Heart Rate Zone Display

The Heart Rate =one shows which zone the current heart rate value falls into for the current User These Heart Rate

=ones can be used as a workout guide for a certain target zone (anaerobic, aerobic, or fat burn)

Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in

your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again.

The heart rate displayed is an approximation and should be used for reference only.

Note: If no heart rate is detected, the display will be blank

NOTICE: To prevent interference with the telemetry HR receiver, do not place any personal electronic devices in the left

side of the media tray

Goal Display

The Goal Display shows the currently selected type of goal (Distance, Time or Calories), the current value to achieve the

goal, and the percent completed toward the goal

User Display

The User Display shows which User Pro¿ le is currently selected

10%

40%

70%

User Display

Achievement Display

Program Display

Achievement Display

The Achievement Display activates when a workout goal is reached or a workout milestone is surpassed from past

workouts The Console display will congratulate and inform the User of their achievement, along with a celebratory sound

Lower Display Data

The Lower Display shows the Workout Values and can be customized for each User (Consult the ³Edit User Pro¿ le´

section of this manual)

Speed

The Speed display ¿ eld shows the machine speed in miles per hour (mph) or kilometers per hour (km/h)

Time

The TIME display ¿ eld shows the total time count of the workout, the average Time for the User Pro¿ le, or the total opera

tional time of the machine

Note: If a Quick Start workout is performed for more than 99 minutes and 59 seconds (99:59), the units for Time will shift

to hours and minutes ( 1 hour, 40 minutes )

Distance

The Distance display shows the distance count (miles or km) in the workout

Note: To change the measurement units to English Imperial or metric, refer to the ³Console Setup Mode´ section in this

manual

Level

The LEVEL display shows the current resistance level in the workout

RPM

The RPM display ¿ eld shows the pedal revolutions per minute (RPM)

Heart Rate (Pulse)

The Heart Rate display shows the beats per minute (BPM) from the heart rate monitor When a heart rate signal is re

ceived by the Console, the icon will À ash

Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in

your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again.

The heart rate displayed is an approximation and should be used for reference only.

Calories

The Calories display ¿ eld shows the estimated calories that you have burned during the exercise

Bluetooth

Connectivity with the “Schwinn Trainer™” Fitness App

This ¿tness machine is equipped with Bluetooth

connectivity and can wirelessly sync with the ³Schwinn Trainer´

Fitness App on supported devices The Software App syncs with your ¿tness machine to track total calories burned, time,

distance, and more It records and stores every workout for quick reference Plus, it automatically syncs your workout data

with MyFitnessPal

, and Under Armour

Connected Fitness to make hitting your daily calorie goal easier than ever! Track

your results and share with friends and family

1 Download the free Software App, named Schwinn Trainer The software app is available on iTunes

and Google

Play

Note: For a complete list of supported devices, review the software app on iTunes

or Google Play

2 Follow the instructions on the Software App to sync your device to your exercise machine

3 To sync your workout data with MyFitnessPal

or Under Armour

Connected Fitness, click on the desired program

and login with your information

Note: The ³Schwinn Trainer´ Fitness App will automatically sync your workouts after the initial syncing

Workout with Other Fitness Apps

This ¿tness machine has integrated Bluetooth® connectivity which allows it to work with a number of digital partners For

our latest list of supported partners, please visit: www.nautilus.com/partners

USB Charging

If a USB Device is attached to the USB Port, the Port will attempt to charge the Device The power supplied from the USB

Port may not be enough to operate the Device and charge it at the same time

9LUWXDO5HDOLW\H[SHULHQFHRQ\RXU¿WQHVVPDFKLQH

This ¿tness machine is equipped to support a Virtual Reality (VR) experience on supported devices

Review, understand, and follow all warning instructions and the correct operation as supplied with your

Virtual Reality equipment.

No one under the age of 13 should use this exercise equipment or the Virtual Reality experience.

Before starting a workout with the Virtual Reality experience, be sure the workout area is and will be clear

throughout the workout, and that all persons or pets are restricted from the workout area. If necessary, a

second person should be used to help secure the area.

The VR experience produces an immersive virtual reality experience that distracts and blocks the view of

WKHDFWXDOVXUURXQGLQJV)RUWKHVDIHVWH[SHULHQFHRQO\XVHWKH95H[SHULHQFHZKHQRSHUDWLQJWKH¿WQHVV

equipment in the seated position. Do not start the VR experience until seated and ready to start a workout.

Be sure the area is secure and that the workout area is safe from potential harm and clear of all obstacles

within reach. Damage to you or items in the workout area could result during a VR workout. Stay seated on

the exercise equipment until the VR gear has been removed and the actual surroundings are viewable.

If dizziness or motion sickness is experienced from the Virtual Reality experience, safely balance yourself

and stop the Virtual Reality experience as soon as possible. Coordination and balance is required when

using the VR experience with the exercise machine.

Consult with a doctor before using the VR experience if you have any conditions which may be affected by

an immersive Virtual Reality experience, such as epilepsy, pregnant, elderly, psychotic disorders, vision

abnormalities, heart conditions, or any other medical condition.

Remote Heart Rate Monitor

Monitoring your Heart Rate is one of the best procedures to control the intensity of your exercise Contact Heart Rate

(CHR) sensors are installed to send your heart rate signals to the Console The Console can also read telemetry HR

signals from a Heart Rate Chest Strap Transmitter that operates in the 45kHz  55kHz range

Note: The heart rate chest strap must be an uncoded heart rate strap from Polar Electro or an uncoded POLAR

compatible model (Coded POLAR

heart rate straps such as POLAR

OwnCode

chest straps will not work with

this equipment)

If you have a pacemaker or other implanted electronic device, consult your doctor before using a wireless

chest strap or other telemetric heart rate monitor.

NOTICE: To prevent interference with the telemetry HR receiver, do not

place any personal electronic devices in the left side of the me

dia tray

Contact Heart Rate Sensors

Contact Heart Rate (CHR) sensors send your heart rate signals to the

Console The CHR sensors are the stainless steel parts of the Handlebars

To use, put your hands comfortably around the sensors Be sure that your hands touch both the top and the bottom of the

sensors Hold ¿rm, but not too tight or loose Both hands must make contact with the sensors for the Console to detect a

pulse After the Console detects four stable pulse signals, your initial pulse rate will be shown

Once the Console has your initial heart rate, do not move or shift your hands for 10 to 15 seconds The Console will now

validate the heart rate Many factors inÀuence the ability of the sensors to detect your heart rate signal:

• Movement of the upper body muscles (including arms) produces an electrical signal (muscle artifact) that can interfere

with pulse detection Slight hand movement while in contact with the sensors can also produce interference

• Calluses and hand lotion may act as an insulating layer to reduce the signal strength

• Some Electrocardiogram (EKG) signals generated by individuals are not strong enough to be detected by the sensors

• The proximity of other electronic machines can generate interference

If your heart rate signal ever seems erratic after validation, wipe off your hands and the sensors and try again

Heart Rate Calculations

Your maximum heart rate usually decreases from 220 Beats Per Minute (BPM) in childhood to approximately 10 BPM by

age 0 This fall in heart rate is usually linear, decreasing by approximately one BPM for each year There is no indication

that training inÀuences the decrease in maximum heart rate Individuals of the same age could have different maximum

heart rates It is more accurate to ¿nd this value by completing a stress test than by using an age related formula

Your atrest heart rate is inÀuenced by endurance training The typical adult has an at rest heart rate of approximately 72

BPM, whereas highly trained runners may have readings of 40 BPM or lower

The Heart Rate table is an estimate of what Heart Rate Zone (HRZ) is effective to burn fat and improve your cardiovas

cular system Physical conditions vary, therefore your individual HRZ could be several beats higher or lower than what is

shown

The most ef¿cient procedure to burn fat during exercise is to start at a slow pace and gradually increase your intensity un

til your heart rate reaches between 50 ± 70 of your maximum heart rate Continue at that pace, keeping your heart rate

in that target zone for over 20 minutes The longer you maintain your target heart rate, the more fat your body will burn

The graph is a brief guideline, describing the generally suggested target heart rates based on age As noted above, your

optimal target rate may be higher or lower Consult your physician for your individual target heart rate zone

Note: As with all exercises and ¿tness regimens, always use your best judgment when you increase your exercise time

or intensity



&!4"52.).'4!2'%4(%!242!4%

(EART2ATE"0-

BEATSPERMINUTE

!GE















        













































-AXIMUM(EART2ATE

4ARGET(EART2ATE:ONE

KEEPWITHINTHISRANGE

FOROPTIMUMFATBURNING























OPERATIONS

What to Wear

Wear rubbersoled athletic shoes You will need the appropriate clothes for exercise that allow you to move freely

How Often Should You Exercise

Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in

your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again.

Use the values calculated or measured by the machine’s computer for reference purposes only. The heart

rate displayed on the console is an approximation and should be used for reference only.

• 3 times a week for 30 minutes each day

• Schedule workouts in advance and try to follow the schedule

Seat Adjustment

Correct seat placement encourages exercise ef¿ciency and comfort, while reducing the risk of

injury

1 With a Pedal in the forward position, center the ball of your foot over the center of it Your leg

should be bent slightly at the knee

2 If your leg is too straight or your foot cannot touch the Pedal, move the seat down on the upright

bike If your leg is bent too much, move the seat up

Step off the bike before you adjust the seat.

Loosen and pull the adjustment knob on the seat tube Adjust the seat to the desired height

Release the adjustment knob to engage the locking pin Be sure that the pin is fully engaged and

fully tighten the knob

Do not set the Seat Post position higher than the stop mark (STOP) on the tube.

To move the seat closer to, or away from the console, loosen the seat slider adjustment knob Slide

the seat forward or rearward to the desired position and tighten the knob

Foot Position / Pedal Strap Adjustment

Foot pedals with straps provide secure footing to the exercise bike

1 Put the ball of each foot on the Pedals

2 Rotate the Pedals until one can be reached

3 Fasten the strap over the shoe

4 Repeat for the other foot

Be sure toes and knees point directly forward to ensure maximum Pedal ef¿ciency Pedal straps

can be left in position for subsequent workouts

Power-Up / Idle Mode

The Console will enter PowerUp / Idle Mode if it is plugged into a power source, any button is

pushed, or if it receives a signal from the RPM sensor as a result of pedaling the machine

Auto Shut-Off (Sleep Mode)

If the Console does not receive any input in approximately 5 minutes, it will automatically shut off The LCD display is off

while in Sleep Mode

Note: The Console does not have an On/Off switch

Initial Setup

During the ¿rst powerup, the Console should be setup with the date, time and your preferred measurement units

1 Date: Push the Increase/Decrease buttons to adjust the currently active value (Àashing) Push the Left/Right buttons

to change which segment is the currently active value (month / day / year)

2 Push OK to set

3 Time: Push the Increase/Decrease buttons to adjust the currently active value (Àashing) Push the Left/Right buttons

to change which segment is the currently active value (hour / minute / AM or PM)

4 Push OK to set

5 Units of Measurement: Push the Increase/Decrease buttons to adjust between ³MILES´ (Imperial English) or ³KM´

(metric)

 Push OK to set The Console goes back to the PowerUp / Idle Mode screen

Note: To adjust these selections, consult the ³Console SetUp Mode´ section

Quick Start ( Manual ) Program

The Quick Start ( Manual ) program lets you start a workout without entering any information

During a Manual Workout, each column represents a 2 minute time period The active column will advance across the

screen every 2 minutes If the workout lasts for more than 30 minutes, the active column is ¿xed on the farthest column on

the right and pushes the previous columns off the display

1 Sit on the machine

2 Push the Increase/Decrease button to select the correct User pro¿le If you do not have a User pro¿le set up, you can

select a User pro¿le that has no customized data (default values only)

3 Push the QUICK START button to start the Manual program

4 To change the resistance level, push the Resistance Increase/Decrease buttons The current interval and future

intervals are set to the new level The default Manual resistance level is 4 The time will count up from 00:00

Note: If a Manual workout is performed for more than 99 minutes and 59 seconds (99:59), the units for Time will shift to

hours and minutes ( 1 hour, 40 minutes )

5 When done with your workout, stop pedaling and push PAUSE/END to pause the workout Push PAUSE/END again

to end the workout

Note: The workout results are recorded to the current User Profile

User Profiles

The Console lets you store and use 4 User profiles The User profiles automatically record the workout results for each

workout, and allow the workout data to be reviewed

The User profile stores the following data:

• Name—up to 10 characters

• Age

• Weight

• Height

• Gender

• Preferred Workout Values

Select a User Profile

Every workout is saved to a User Pro¿le Be sure to select the proper User Pro¿le before starting a workout The last User

that completed a workout will be the default user

User Pro¿les are assigned the default values until they are customized by editing Be sure to edit the User Pro¿le for more

accurate calorie and heart rate information

From the PowerUp Mode screen, push the User button to select one of the User Pro¿les The Console will display the

name of the User Pro¿le and the User Pro¿le Icon

Edit User Profile

1 From the PowerUp Mode screen, push the User button to select one of the User Pro¿les

2 Push the OK button to select the User Profile

3 The Console display shows the EDIT prompt and the current User Profile name Push OK to start the Edit User Pro¿le

option

To exit the Edit User Pro¿le option, push the PAUSE/END button and the console will go back to the PowerUp Mode

screen

4 The Console display shows the NAME prompt and the current User Profile name

Note: The User name will be blank if this is the first edit The name of a User Profile is limited to 10 characters

The currently active segment will flash Use the Increase/Decrease buttons to move through the alphabet and blank

space (found between A and Z) To set each segment, use the Left(e) or Right(f) buttons to shift between segments

Push the OK button to accept the displayed User name

5 To edit the other User data (EDIT AGE, EDIT WEIGHT, EDIT HEIGHT, EDIT GENDER), use the Increase/Decrease

buttons to adjust, and push OK to set each entry

 The Console display shows the SCAN prompt This option controls how the workout values are displayed during a

workout The ³OFF´ setting allows the user to push the Right(f) or Left(e) buttons to view the other workout value

channels when desired The ³ON´ setting allows the Console to automatically display the workout value channels

every  seconds

The default is ³OFF

´

Push the OK button to set how the workout values are displayed

7 The Console display shows the WIRELESS HR prompt If you are using the Console speakers at their higher settings

and / or using a larger sized personal electronic device, the Console may show Heart Rate interference This option

allows the Telemetry Heart Rate Receiver to be deactivated blocking the interference

The Upper Display shows the current value setting: ³ON´ or ³OFF´ Push the Increase(c) or Decrease(d) buttons to

change the value

The default is ³ON´

Push the OK button to set the Telemetry Heart Rate Receiver to active

8 The Console display shows the EDIT LOWER DISPLAY prompt This option allows you to customize which Workout

Values are displayed during a workout

The Lower Display will show all of the workout values, with the active Workout Value flashing The Upper Display shows

the active value setting: ³ON´ or ³OFF´ Push the Increase(c) or Decrease(d) buttons to hide the active workout

value, and push the Left(e) or Right(f) buttons to shift the active value

Note: To show a hidden workout value, repeat procedure and change Upper Display value to ³ON´ for that value

When done with customizing the Lower Display, push the OK button to set it

9 The Console will go to the PowerUp Mode screen with the user selected

Reset a User Profile

1 From the PowerUp Mode screen, push the User button to select one of the User Pro¿les

2 Push the OK button to select the User Profile

3 The Console display shows the current User Profile name and the EDIT prompt Push the Increase(c) or Decrease(d)

buttons to change the prompt

Note: To exit the Edit User Pro¿le option, push the PAUSE/END button and the console will go back to the PowerUp

Mode screen

4 The Console display shows the RESET prompt and the current User Profile name Push OK to start the Reset User

Pro¿le option

5 The Console will now confirm the request to reset the User profile (the default selection is µNO¶) Push the Increase(c)

or Decrease(d) buttons to adjust the selection

 Push OK to make your selection

7 The Console will go to the PowerUp Mode screen

Changing Resistance Levels

Push the Resistance Level Increase(c) or Decrease(d) buttons to change the resistance level at any time in a workout

program To rapidly change the resistance level, push the desired Resistance Level Quick Button The Console will adjust

to the selected resistance level of the quick button

3UR¿OH3URJUDPV

These programs automate different resistance and workout levels The Pro¿le Programs are organized into Categories

(Fun Rides, Mountains, and Challenges)

Note: Once a User views all the Categories, they will be expanded to display the Programs within each of the

Categories

FUN RIDES

Rolling Hills Ride in the Park

Easy Tour Stream Crossing

MOUNTAINS

Pike’s Peak Mount Hood

Pyramids Summit Pass

CHALLENGES

Uphill Finish CrossTraining

Interval Stairs

:RUNRXW3UR¿OHDQG*RDO3URJUDP

The Console lets you select the Pro¿le Program and type of Goal for your workout (Distance, Time or Calories), and set

the Goal value

1 Sit on the machine

2 Push the User button to select the correct User pro¿le

3 Push the Programs button

4 Push the Left(e) or Right(f) buttons to select a Category of Workout

5 Push the Increase(c) or Decrease(d) buttons to select a Profile Workout, and push OK

 Use the Increase(c) or Decrease(d) buttons to select a type of Goal (Distance, Time or Calories), and push OK

7 Use the Increase(c) or Decrease(d) buttons to adjust the workout value

8 Push OK to begin the goaloriented workout The GOAL value will count down as the value for percent completed

increases

Note: During a Calories Goal, each column is for a 2 minute time period The active column will advance across the

screen every 2 minutes If the workout lasts for more than 30 minutes, the active column will ¿x to the last right

column and push the previous columns off the display

Fitness Test Program

The Fitness Test measures the improvements of your physical ¿tness level The test compares your power output (in

Watts) to your heart rate As your ¿tness level improves, your power output will increase at a given heart rate

Note: The Console must be able to read the heart rate information from the Contact Heart Rate (CHR) sensors or Heart

Rate Monitor (HRM) to work correctly

You can start the Fitness Test from the FEEDBACK category The Fitness Test program ¿rst prompts you to select your

¿tness level—Beginner ( ³BEG´ ) or Advanced ( ³ADV´ ) The Console will use the Age and Weight values for the selected

User Pro¿le to calculate the Fitness Score

Start to workout and hold the Heart Rate Sensors When the test starts, the intensity of the workout slowly increases This

means you will work harder, and as a result, your heart rate increases The intensity continues to increase automatically

until your heart rate reaches the ³Test Zone´ This zone is individually computed to be near 75 percent of the maximum

heart rate of your User Pro¿le When you reach the Test Zone, the machine holds the intensity steady for 3 minutes

This lets you reach a stable condition (where your heart rate becomes steady) At the end of the 3 minutes, the Console

measures your heart rate and the power output These numbers, along with information about your age and weight, are

computed to produce a ³Fitness Score´

Note: Fitness Test scores should only be compared to your previous scores and not to other User Profiles

Compare your Fitness Scores to see your improvement

Recovery Test Program

Recovery Test shows how quickly your heart recovers from an exercise state to a more restful state Improved recovery is

an indicator of increasing ¿tness

Note: The Console must be able to read the heart rate information from the Contact Heart Rate (CHR) sensors or Heart

Rate Monitor (HRM) to work correctly

From an elevated heart rate, select the Recovery Test Program The Console will show ³STOP E;ERCISING´ and the

goal will begin to count down Stop exercising but continue to grip the contact heart rate sensors After 5 seconds, the

display will show ³RELA;´ and will continue to count down to 00:00 For the entire minute the console will also show your

heart rate You must grip the heart rate sensors for the duration of the test if not using a Remote Heart Rate Monitor

The display will continue to show ³RELA;´ and your heart rate until the goal reaches 00:00 The console will then calcu

late your recovery score

Recovery Score Your heart rate at 1:00 (the beginning of the test) minus your heart rate at 00:00 (the end of the test)

The higher the Recovery Test score value, the quicker your heart rate is returning to a more restful state and is an indica

tion of improving ¿tness By recording these values over time you can see the trend toward better health

When you select the Recovery Test Program and there is no heart rate signal or display, the Console will show ³NEED

HEART RATE´ This message will show for 5 seconds If no signal is detected, the program will end

Helpful Tip: For a more relevant score, try to obtain a steady heart rate for 3 minutes before starting the Recovery Pro

gram This will be easier to achieve, and obtain the best result, in the Manual program so you can control the levels of

resistance

Heart Rate Control (HRC) Workout Programs

The Heart Rate Control (HRC) programs let you set a heart rate goal for your workout The program monitors your heart

rate in beats per minute (BPM) from the Contact Heart Rate (CHR) sensors on the machine or from a Heart Rate Monitor

(HRM) chest strap, and adjusts the workout to keep your heart rate in the selected zone

Note: The console must be able to read the heart rate information from the CHR sensors or HRM for the HRC program

to work correctly

The Target Heart Rate programs use your age and other User information to set the Heart Rate Zone values for your

workout The console display then gives prompts for you to set up your workout:

1 Select the Heart Rate Control workout level: BEGINNER ( ³BEG´ ) or ADVANCED ( ³ADV´ ) and push OK

2 Push the Increase(c) or Decrease(d) buttons to select the percentage of maximum heart rate: 50±0, 0±70,

70±80, 80±90

Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in

your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again.

Use the values calculated or measured by the machine’s computer for reference purposes only. The heart

rate displayed on the console is an approximation and should be used for reference only.

3 Push the Increase(c) or Decrease(d) buttons to select the Goal type, and push OK

4 Push the Increase(c) or Decrease(d) buttons to set the goal value for the workout

Note: Be sure to allow time for your heart rate to reach the desired heart rate zone when setting the goal

5 Push OK to start the workout

A User can set a Heart Rate zone instead of a value by selecting the Heart Rate Control  User program The Console will

adjust the workout to keep the User in the desired Heart Rate zone

1 Select HEART RATE CONTROL  USER, and push OK

2 Push the Increase(c) or Decrease(d) buttons to set the Heart Rate zone for the workout, and push OK The Console

shows the Heart Rate zone (percent) on the left, and the Heart Rate range for the User on the right side of the display

3 Push the Increase(c) or Decrease(d) buttons to select the Goal type, and push OK

4 Push the Increase(c) or Decrease(d) buttons to set the value for the workout

5 Push OK to start the workout

Custom Program

The Custom Program lets you set the resistance level for each interval and select type of Goal (Distance, Time or Calo

ries) to create a personalized workout One custom workout is available for each User Pro¿le

1 Sit on the machine

2 Push the User button to select the correct User pro¿le

3 Push the Programs button

4 Push the Increase(c) or Decrease(d) buttons to select Custom Program, and push OK

5 The Console shows Heart Rate Control To select Heart Rate Control, push OK

To continue in the Custom Program, push the Left button and the Console shows Custom Program again Push OK

 To edit the Custom Program, use the Right(f) button to move to the next interval and use the Increase(c) or

Decrease(d) buttons to adjust the resistance values Push the OK button to accept the displayed values

7 Use the Increase(c) or Decrease(d) buttons to select a type of Goal (Distance, Time or Calories), and push OK

8 Use the Increase(c) or Decrease(d) buttons to adjust the workout value

9 Push OK to start the workout The GOAL value will count down as the value for percent completed increases

Changing a Workout Program During a Workout

The Console allows a different Workout Program to be started from an active workout

1 From an active workout, push PROGRAMS

2 Push the Increase(c) or Decrease(d) buttons to select the desired workout program, and push OK

3 Push the Increase(c) or Decrease(d) buttons to select the Goal type, and push OK

4 Push the Increase(c) or Decrease(d) buttons to set the value for the workout

5 Push OK to stop the active workout and start the new workout

The previous workout values are saved to the User Pro¿le

Pausing or Stopping

The Console will go into Pause Mode if the user stops pedaling and pushes PAUSE/END during a workout, or there is no

RPM signal for 5 seconds (user not pedaling) The Console will cycle through a series of messages that change every 4

seconds:

 WORKOUT PAUSED

 PEDAL TO CONTINUE (if a bike) / STRIDE TO CONTINUE (if an elliptical)

 PUSH END TO STOP

During a paused workout, you can use the Increase/Decrease buttons to move through the result channels manually

1 Stop pedaling and push the PAUSE/END button to pause your workout

2 To continue your workout, push OK or start pedaling

To stop the workout, push the PAUSE/END button The Console will go into Results / Cool Down mode

Results / Cool Down Mode

After a workout the GOAL display shows 03:00 and then starts to count down During this Cool Down period, the Console

shows the Workout Results All workouts except Quick Start have a 3minute Cool Down period

The LCD display shows the Current Workout values in three channels:

a) TIME (total), DISTANCE (total), and CALORIES (total)

b) SPEED (average), RPM (average), and HEART RATE (average)

c) TIME (average), LEVEL (average), and CALORIES (average)

Push the Left(e) or Right(f) buttons to move through the result channels manually

During the Cool Down period, the Resistance Level will adjust to a third of the average Level of the workout The Cool

Down resistance level can be adjusted with the Resistance Increase and Decrease buttons, but the Console will not dis

play the value

You can push PAUSE/END to stop the Results / Cool Down period and go back to PowerUp Mode If there is no RPM or

HR signal, the Console automatically goes into Sleep Mode

GOAL TRACK Statistics (and Achievements)

The statistics from every workout are recorded to a User Pro¿le

The Schwinn Dual Track



Console shows the Goal Track workout Statistics on the Lower Display in three channels:

a) TIME (total), DISTANCE (total), and CALORIES (total)

b) SPEED (average), RPM (average), and HEART RATE (average)

c) TIME (average), DISTANCE (average) / or LEVEL (average) *, and CALORIES (average)

* If the Goal Track Statistic is a single workout, LEVEL (average) is displayed If the Goal Track Statistic is a

combination of multiple workouts, DISTANCE (average) is displayed instead of LEVEL (average)

To view the GOAL TRACK statistics of a User Pro¿le:

1 From the PowerUp screen, push the User button to select a User Profile

2 Push the GOAL TRACK button The Console will display the LAST WORKOUT values and activate the corresponding

Achievement light

Note: Goal Track statistics can be viewed even during a workout Push GOAL TRACK and the LAST WORKOUT values

will be displayed The workout values for the current workout will be hidden except for the GOAL display Push

GOAL TRACK again to return to the PowerUp screen

3 Push the Increase(c) button to move to the next GOAL TRACK statistic, ³LAST 7 DAYS´ The Console will display the

calories burnt on the display (50 calories per segment) for the previous seven days, along with the workout value totals

Use the Left(e) or Right(f) buttons to move through all the workout statistic channels

4 Push the Increase(c) button to move to ³LAST 30 DAYS´ The Console will display the total values for the previous

thirty days Use the Left(e) or Right(f) buttons to move through all the workout statistic channels

5 Push the Increase(c) button to move to the ³LONGEST WORKOUT

´ The Console will display the workout values with

the most Time value Use the Left(e) or Right(f) buttons to move through all the workout statistic channels

 Push the Increase(c) button to move to the ³CALORIE RECORD´ The Console will display the workout values with the

most Calories value Use the Left(e) or Right(f) buttons to move through all the workout statistic channels

7 Push the Increase(c) button to move to ³BMI´, or Body Mass Index The Console will display the BMI value based on

the User settings Be sure the height value is correct for your User Pro¿le, and the weight value is current

The BMI Measurement is a useful tool that shows the relationship between weight and height that is associated with body

fat and health risk The table below gives a general rating for the BMI score:

Underweight Below 185

Normal 185 ± 249

Overweight 250 ± 299

Obesity 300 and above

Note: The rating may overestimate body fat in athletes and others who have a muscular build It may also underesti

mate body fat in older persons and others who have lost muscle mass

Contact your doctor for more information about Body Mass Index (BMI) and the weight that is appropriate

for you. Use the values calculated or measured by the machine’s computer for reference purposes only.

8 Push the Increase(c) button to move to the ³SAVE TO USB  OK"´ prompt Push OK and the ³ARE YOU SURE"

NO´ prompt will display Push the Increase(c) button to change it to yes and push OK The Console will display the

³INSERT USB´ prompt Insert a USB Flash Drive into the USB Port The Console will record the Statistics to the USB

Flash Drive

The Console will display ³SAVING´, and then ³REMOVE USB´ when it is safe to remove the USB Flash Drive

Note: Push the PAUSE/END button to force an exit from the ³SAVING´ prompt

9 Push the Increase(c) button to move to the ³CLEAR WORKOUT DATA OK"´ Push OK, and the ³ARE YOU SURE"

 NO´ prompt will display Push the Increase(c) button to change to the ³ARE YOU SURE"  YES´ display, and push

OK The user workouts have been reset

10 Push GOAL TRACK to return to the PowerUp screen

When a User performs a workout that surpasses the ³LONGEST WORKOUT´ or ³CALORIE RECORD´ of the previous

workouts, the Console will congratulate with an audible sound and tell the User the new achievement The corresponding

Achievement Indicator Light will also be active

The Console Setup Mode lets you input the date and time, set the units of measurement to either English or Metric,

control the sound settings ( on/ off), or see maintenance statistics (Error Log and Run Hours ± for service technician use

only)

1 Hold down the PAUSE/END button and Right button together for 3 seconds while in the PowerUp Mode to go into

the Console Setup Mode

Note: Push PAUSE/END to exit the Console Setup Mode and return to the PowerUp Mode screen

2 The Console display shows the Date prompt with the current setting To change, the Increase/Decrease buttons to

adjust the currently active value (Àashing) Push the Left/Right buttons to change which segment is the currently ac

tive value (month / day / year)

3 Push OK to set

4 The Console display shows the Time prompt with the current setting Push the Increase/Decrease buttons to adjust

the currently active value (Àashing) Push the Left/Right buttons to change which segment is the currently active value

(hour / minute / AM or PM)

5 Push OK to set

 The Console display shows the Units prompt with the current setting To change, push OK to start the Units option

Push the Increase/Decrease buttons to change between ³MILES´ (Imperial English units) and ³KM´ (metric units)

Note: If the units change when there is data in User Statistics, the statistics convert to the new units

7

Push OK to set

8 The Console display shows the Sound Settings prompt with the current setting Push the Increase/Decrease buttons

to change between ³ON´ and ³OFF´

9 Push OK to set

10 The Console display shows the TOTAL RUN HOURS for the machine

11 For the next prompt, push the OK button

12 The Console display shows the Software Version prompt

13 For the next prompt, push the OK button

14  The Console will display the PowerUp Mode screen

CONSOLE SETUP MODE

Read all maintenance instructions fully before you start any repair work In some conditions, an assistant is necessary to

do the necessary tasks

Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that

regular maintenance is done. Worn, damaged or loose components must be repaired or replaced immedi-

ately. Only manufacturer supplied components can be used to maintain and repair the equipment.

If at any time the Warning labels become loose, unreadable or dislodged, contact Nautilus Customer

Service for replacement labels.

Disconnect all power to the machine before you service it.

Daily: Before each use, examine the exercise machine for loose, broken, damaged, or worn parts

Do not use if found in this condition Repair or replace all parts at the ¿rst sign of wear or

damage After each workout, use a damp cloth to wipe your machine and Console free of

moisture

Note: Avoid excessive moisture on the Console

NOTICE: If necessary, only use a mild dish soap with a soft cloth to clean the Console Do not

clean with a petroleum based solvent, automotive cleaner, or any product that contains

ammonia Do not clean the Console in direct sunlight or at high temperatures Be sure

to keep the Console free of moisture

Weekly: Clean the machine to remove any dust, dirt, or grime from the surfaces Check for smooth seat

slider operation If needed, apply a very thin coating of silicone lube to ease operation

Silicone lubricant is not intended for human consumption. Keep out of reach of

children. Store in a safe place.

Note: Do not use petroleum based products

Monthly

or after 20 hours:

Check pedals and crank arms and tighten as necessary Make sure all bolts and screws are

tight Tighten as necessary

NOTICE: Do not clean with a petroleum based solvent or an automotive cleaner Be sure to keep the Console free

of moisture

MAINTENANCE

A Console L HR Cables W Flywheel

B Console Mast M CHR Sensors ; Brake Assembly

C Pedals N Seat Y RPM Sensor

D Crank Arms O Seat Post w/ Slider Z Speed Sensor Magnets (8)

E Left Shroud P Adjustment Knob AA Servo Motor

F Power Inlet Q Seat Post Shroud BB Drive Belt

G Right Shroud R Water Bottle Holder CC Drive Pulley

H Top Shroud S Rear Stabilizer DD Handlebar Mount Cover

I Mast Gasket T Levelers EE Thandle

J Data Cable U Front Stabilizer

K Handlebars V Transport Wheels

Maintenance Parts

TROUBLESHOOTING

Condition/Problem Things to Check Solution

No display/partial display/

unit will not turn on

Check electrical (wall)

outlet

Make sure unit is plugged into a functioning wall outlet

Check connection on

console

Connection should be secure and undamaged Replace

adapter or connection at unit if either are damaged

Check data cable integrity All wires in cable should be intact If any are visibly crimped or

cut, replace cable

Check data cable

connections/orientation

Be sure cable is connected securely and oriented properly

Small latch on connector should line up and snap into place

Check console display for

damage

Check for visual sign that console display is cracked or other

wise damaged Replace Console if damaged

Console Display If Console only has partial display and all connections are ¿ne,

replace the Console

If the above steps do not resolve the problem, contact Cus

tomer Care for further assistance

Unit operates but Contact

HR not displayed

HR cable connection at

Console

Be sure cable is connected securely to Console

Sensor grip Be sure hands are centered on HR sensors Hands must be

kept still with relatively equal pressure applied to each side

Dry or calloused hands Sensors may have dif¿culty with dried out or calloused hands

A conductive electrode cream (heart rate cream) can help

make better conduct These are available on the web or at

medical or some larger ¿tness stores

Handlebar If tests reveal no other issues, Handlebars should be replaced

Unit operates but

Telemetric HR not

displayed

Chest Strap (optional) Strap should be ³POLAR®´ compatible and uncoded Make

sure strap is directly against skin and contact area is wet

Chest Strap Batteries If strap has replaceable batteries, install new batteries

Check User Pro¿le Select the Edit User Pro¿le option for the User Pro¿le Go to

the WIRELESS HR setting and make sure that the current

value is set to ON

Interference Try moving unit away from sources of interference (TV, Micro

wave, etc)

Replace Chest Strap If interference is eliminated and HR does not function, replace

strap

Replace Console If HR still does not function, replace Console

Unit operates but

Telemetric HR displayed

incorrectly

Interference Make sure that the HR receiver is not blocked by a personal

electronic device in the left side of the media tray

Console displays ³E2´

error code

Check data cable integrity All wires in cable should be intact If any are cut or crimped,

replace cable

Check data cable

connections/orientation

Be sure cable is connected securely and oriented properly

Small latch on connector should line up and snap into place

Console Electronics If tests reveal no other issues, contact Customer Care for fur

ther assistance

Condition/Problem Things to Check Solution

No speed/RPM reading,

Console displays ³Please

Pedal” error code

Check data cable integrity All wires in cable should be intact If any are cut or crimped,

replace cable

Check data cable

connections/orientation

Be sure cable is connected securely and oriented properly

Small latch on connector should line up and snap into place

Check magnet position

(requires shroud removal)

Magnets should be in place on pulley

Check Speed Sensor

(requires shroud removal)

Speed sensor should be aligned with magnet and connected to

data cable Realign sensor if necessary Replace if there is any

damage to the sensor or the connecting wire

Resistance does not

change (machine turns on

and operates)

Batteries (if equipped) Replace batteries and check for proper operation

Check Console Check for visual sign that Console is damaged Replace Con

sole if damaged

Check data cable integrity All wires in cable should be intact If any are visibly crimped or

cut, replace cable

Check data cable

connections/orientation

Be sure cable is connected securely and oriented properly

Reseat all connections Small latch on connector should line up

and snap into place

Check Servo Motor

(requires shroud removal)

If magnets move, adjust until they are within the proper range

Replace Servo Motor if not functioning properly

If the above steps do not resolve the problem, contact Cus

tomer Care for further assistance

Console shuts off (enters

sleep mode) while in use

Check electrical (wall)

outlet

Make sure unit is plugged into a functioning wall outlet

Check connection on

console

Connection should be secure and undamaged Replace

adapter or connection at unit if either are damaged

Check data cable integrity All wires in the cable should be intact If any are cut or crimped,

replace cable

Check data cable

connections/orientation

Be sure cable is connected securely and oriented properly

Small latch on connector should line up and snap into place

Reset Machine Unplug unit from electrical outlet for 3 minutes Reconnect to

outlet

Check magnet position

(requires shroud removal)

Magnets should be in place on pulley

Check Speed Sensor

(requires shroud removal)

Speed sensor should be aligned with magnet and connected to

data cable Realign sensor if necessary Replace if there is any

damage to the sensor or the connecting wire

Unit rocks/does not sit

level

Check leveler adjustment Adjust levelers until bike is level

Check surface under unit Adjustment may not be able to compensate for extremely un

even surfaces Move bike to level area

Pedals loose/unit dif¿cult

to pedal

Check pedal to crank arm

connection

Pedal should be tightened securely to crank Insure connection

is not crossthreaded

Check crank arm to axle

connection

Crank should be tightened securely to axle Be sure cranks are

connected at 180 degrees from each other

Condition/Problem Things to Check Solution

Clicking sound when

pedaling

Check pedal to crank arm

connection

Remove pedals Make sure there is no debris on threads, and

reinstall the pedals

Seat post movement Check locking pin Be sure adjustment pin is locked into one of the seat post

adjustment holes

Check adjustment knob Be sure knob is securely tightened

Workout results will not

sync with Bluetooth

en

abled device

Current console mode Machine must be in Idle Mode to sync Push the PAUSE/STOP

button until the PowerUp Mode screen is displayed

Total time of workout A workout must be longer than 1 minute to be saved and

posted by the Console

Fitness machine Unplug unit from electrical outlet for 5 minutes Reconnect to

outlet

Bluetooth

enabled device Consult your device to be sure that the Bluetooth

wireless

feature has been enabled on it

Fitness App Review Speci¿cations of Fitness App and con¿rm your device

is compatible

Contact appsupport#nautiluscom for further assistance

Workout results not post

ing from Schwinn Train

er App to MyFitnessPal

account or Under Armour

Connected Fitness

Sync accounts From the Menu icon on the Schwinn Trainer App, select the

Sync to MyFitnessPal

or Under Armour

Connected Fitness

Sync fails Review account and password

Contact appsupport#nautiluscom for further assistance

WARRANTY

Who Is Covered

This warranty is valid only to the original purchaser and is not transferable or applicable to any other person(s).

What Is Covered

Nautilus, Inc. warrants that this product is free from defects in materials and workmanship, when used for the purpose intended, under normal conditions, and provided it receives proper care and

maintenance as described in the Product’s Assembly and Owner’s manual. This warranty is good only for authentic, original, legitimate machines manufactured by Nautilus, Inc. and sold through an

authorized agent and used in the United States or Canada.

Terms

• Frame 10 years

• Mechanical parts 2 years

• Electronics 1 year

• Labor 90 days

(Labor support does not include the installation of replacement parts involved in the initial product assembly and preventative maintenance services.)

How Nautilus Will Support the Warranty

Throughout the terms of the warranty coverage, Nautilus, Inc. will repair any machine that proves to be defective in materials or workmanship. Nautilus reserves the right to replace the product in

the event a repair is not possible. When Nautilus determines replacement is the correct remedy, Nautilus may apply a limited credit reimbursement toward another Nautilus Inc. brand Product, at

our discretion. This reimbursement may be prorated based on length of ownership. Nautilus, Inc. provides repair service within major metropolitan areas. Nautilus, Inc reserves the right to charge

the consumer for travel outside these areas. Nautilus Inc. is not responsible for dealer labor or maintenance charges beyond the applicable warranty period(s) stated herein. Nautilus, Inc. reserves

the right to substitute material, parts or products of equal or better quality if identical materials or products are not available at the time of service under this warranty. Any replacement of the product

under the terms of the Warranty in no way extends the original Warranty period. Any

limited credit reimbursement may be prorated based on length of ownership. THESE REMEDIES ARE THE EXCLUSIVE AND SOLE REMEDIES FOR ANY BREACH OF WARRANTY.

What You Must Do

• Retain appropriate and acceptable Proof of Purchase.

• 2SHUDWHPDLQWDLQDQGLQVSHFWWKH3URGXFWDVVSHFL¿HGLQWKH3URGXFW'RFXPHQWDWLRQ0DQXDOV$VVHPEO\2ZQHU¶V0DQXDOVHWF

• Product must be used exclusively for the purpose intended.

• Notify Nautilus within 30 days after detecting an issue with the Product.

• Install replacement parts or components in accordance with any Nautilus instructions.

• Perform diagnostic procedures with a trained Nautilus, Inc representative if requested.

What Is Not Covered

• 'DPDJHGXHWRDEXVHWDPSHULQJRUPRGL¿FDWLRQRIWKH3URGXFWIDLOXUHWRSURSHUO\IROORZDVVHPEO\LQVWUXFWLRQVPDLQWHQDQFHLQVWUXFWLRQVRUVDIHW\ZDUQLQJVDVVWDWHGLQWKH3URGXFW

Documentation (Assembly, Owner’s Manuals, etc), damage due to improper storage or the effect of environmental conditions such as moisture or weather, misuse, mishandling, accident,

natural disasters, power surges.

• $PDFKLQHSODFHGRUXVHGLQDFRPPHUFLDORULQVWLWXWLRQDOVHWWLQJ7KLVLQFOXGHVJ\PVFRUSRUDWLRQVZRUNSODFHVFOXEV¿WQHVVFHQWHUVDQGDQ\SXEOLFRUSULYDWHO\HQWLW\WKDWKDVDPDFKLQHIRU

XVHE\LWVPHPEHUVFXVWRPHUVHPSOR\HHVRUDI¿OLDWHV

• 'DPDJHFDXVHGE\H[FHHGLQJPD[LPXPXVHUZHLJKWVDVGH¿QHGLQWKH3URGXFW¶V2ZQHU¶VPDQXDORUZDUQLQJODEHO

• Damage due to normal usage and wear and tear.

• This warranty does not extend to any territories or countries outside the United States and Canada.

How to Obtain Service

)RU3URGXFWVSXUFKDVHGGLUHFWO\IURP1DXWLOXV,QFFRQWDFWWKH1DXWLOXVRI¿FHOLVWHGRQWKH&RQWDFWVSDJHRIWKHSURGXFWV2ZQHU¶VPDQXDO<RXPD\EHUHTXLUHGWRUHWXUQWKHGHIHFWLYHFRPSRQHQWWR

DVSHFL¿HGDGGUHVVIRUUHSDLURULQVSHFWLRQDW\RXUH[SHQVH6WDQGDUGJURXQGVKLSSLQJRIDQ\ZDUUDQW\UHSODFHPHQWSDUWVZLOOEHSDLGE\1DXWLOXV,QF)RUSURGXFWVSXUFKDVHGIURPDUHWDLOHU\RX

may be asked to contact your retailer for warranty support.

Exclusions

The preceding warranties are the sole and exclusive express warranties made by Nautilus, Inc. They supersede any prior, contrary or additional representations, whether oral or written. No

agent, representative, dealer, person or employee has the authority to alter or increase the obligations or limitations of this warranty. Any implied warranties, including the WARRANTY OF

MERCHANTABILITY and any WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, are limited in duration to the term of the applicable express warranty provided above, whichever is longer.

Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Limitation of Remedies

EXCEPT AS OTHERWISE REQUIRED BY APPLICABLE LAW, THE PURCHASER’S EXCLUSIVE REMEDY IS LIMITED TO REPAIR OR REPLACEMENT OF ANY COMPONENT DEEMED BY

NAUTILUS, INC. TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS STATED HEREIN. IN NO EVENT WILL NAUTILUS, INC. BE LIABLE FOR ANY SPECIAL, CONSEQUENTIAL,

INCIDENTAL, INDIRECT OR ECONOMIC DAMAGES, REGARDLESS OF THE THEORY OF LIABILITY (INCLUDING, WITHOUT LIMITATION, PRODUCT LIABILITY, NEGLIGENCE OR OTHER

TORT) OR FOR ANY LOST REVENUE, PROFIT, DATA, PRIVACY OR FOR ANY PUNITIVE DAMAGES ARISING OUT OF OR RELATED TO THE USE OF THE FITNESS MACHINE EVEN IF

NAUTILUS, INC. HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THIS EXCLUSION AND LIMITATION SHALL APPLY EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL

PURPOSE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF CONSEQUENTIAL OR INCIDENTAL TYPE DAMAGES SO THE ABOVE LIMITATION MAY NOT APPLY TO

YOU.

State Laws

7KLVZDUUDQW\JLYHV\RXVSHFL¿FOHJDOULJKWV<RXPD\DOVRKDYHRWKHUULJKWVZKLFKYDU\IURPVWDWHWRVWDWH

Expirations

,IWKHZDUUDQW\KDVH[SLUHG1DXWLOXV,QFPD\DVVLVWZLWKUHSODFHPHQWVRUUHSDLUVWRSDUWVDQGODERUEXWWKHUHZLOOEHDFKDUJHIRUWKHVHVHUYLFHV&RQWDFWD1DXWLOXVRI¿FHIRULQIRUPDWLRQRQSRVW

warranty parts and services. Nautilus does not guarantee availability of spare parts after expiration of warranty period.

International Purchases

If you purchased your machine outside of the United States consult your local distributor or dealer for warranty coverage.
