Parking Assist
System
Parking Assist
System
Beep once
This parking assist system provides the driver assistance
when reversing. Driving skills such as slowing down, the use
of mirrors etc. is always essential.
1. This system is for vehicles with 12V DC.
2. This system should be installed by a professional auto
electrician.
3. Route all wiring harnesses away from heat sources and
vehicle electrical systems.
4. It is strongly recommended to check the location of the
sensors are within the correct specification heights and
distances apart before the actual drilling of the holes.
5. Perform test of the system after finishing the installation.
The PTSC1 is a 4-sensor rear parking assist system that is an
ultrasonic distance monitoring device. It electronically detects
the area behind your vehicle while reversing, and alerts you with
audible tones if the system detects an obstacle.
With features like self test and learning function the PTSC1 is
ideal for vehicles with tow-bars or spare wheels.
This parking assist system is designed as a driver assistance
device and should not be used as a substitute for safe parking
practices. The area into which the vehicle is to be reversed must
be constantly visually monitored while parking.
The manufacturer and its distributors do not guarantee or
assume liability for collisions or damages while reversing your
vehicle.
1. Using the learning function.
With the system powered off (vehicle in neutral) move the
learning switch on the ECU from the “off” to the “on” position.
Turn the vehicles ignition on and select reverse gear. After
approximately 3 seconds there will be a beep to indicate the
system has entered learning mode. Leave the vehicle in
reverse for a further 2 seconds until you hear 2 more beeps,
this indicates the learning function has completed. Immedi-
ately after hearing the 2 beeps take the vehicle out of reverse
gear, turn ignition off and move the learning switch on the
ECU back from “on” to the “off” position. The kit has now
learned any fixed objects and will ignore these.
2. Resetting the learning function.
With the system powered off (vehicle in neutral) move the
learning switch on the ECU from the “off” to the “on” position.
Turn the vehicles ignition on and select reverse gear. Leave
the vehicle in reverse gear until you hear a 2 second long
beep this will be after approximately 10 seconds of the kit
being powered up. In the 10 second period ignore all other
beeps you hear. Immediately after hearing the 2 second long
beep take the vehicle out of reverse gear, turn ignition off and
move the learning switch on the ECU back from “on” to the
“off” position. The kit has now cleared its memory of all
learned objects.
Heavy rain, dirty or damaged sensors may cause false
warning occasionally.
Ensure that the self-test procedure is completed and all
the sensors are functioning before using the system.
