Place rear side
down rst
INSERTING THE BATTERIES
1 Locate the battery compartment underneath the lid.
2 Push the tab on the battery cap in and carefully lift up to open.
3 Insert three heavy duty D-size batteries (not included) in
accordance with the positive (+) and negative (-) poles shown
in the battery compartment.
4 To close, insert the side without the clip rst, then push the
battery cap down. Make sure that it’s securely fastened (it
should click into place).
SETTING UP YOUR TRASH CAN
1 Remove your lid and liner ring.
2 Insert the trash bag through the liner ring.
3 Fold the upper rim of the bag around the liner ring.
4 Place the trash bag and the liner ring in the trash container.
5 Tuck the bag completely into the bottom of the container so
that the edges of the bag are concealed after the lid is closed.
Note: Do not put the liner ring inside the bag.
6 Repeat steps 2-5 on the other side.
7 Align the lid with the base and gently place the lid on top.
PACKAGE CONTENTS
• Lid
• Liner rings (2)
• Base
• Magnetic labels (2)
• Quick Setup Guide
FEATURES
• Two compartments (9.3 gal/35 l each) with magnetic labels let
you sort trash and recycling
• IR sensor detects your hand (or another object) to automatically
open and close the lid
• Battery operated (3 D batteries, not included) for cordless
operation
• Liner rings hold standard trash bags in place
• Fingerprint-free stainless steel ts seamlessly into any living
space
Before using your new product, please read these instructions to prevent any damage.
QUICK SETUP GUIDE
Automatic
Trash Can
NS-ATC18DSS1
Liner ring
Trash bag
Final at size (W×H): 12.75 × 7 in. (323.85 × 234.95 mm)
Final folded size (W×H): 4.25 × 9.25 in. (107.95 × 234.95 mm)
# ITEM
1 Hands-free
automatic lid
2 Liner ring
(inside)
3 Manual close
button
4 LED indicator
and infrared
motion
detecting sensor
5 Manual open
button
6 Power saving
on/o switch
7 Battery
compartment
8 Magnet labels
DESCRIPTION
Move an object or hand above the
strategically placed infrared motion
sensor. The lid opens automatically.
After the object or the hand is out of
sensor range, the lid closes
automatically within seconds.
Secures the trash bag.
Closes the lid and reactivates the
sensor.
• Flashing green: Trash can is in sensor
mode
• Solid green: Lid opens
• Flash 3 times: Lid closes
• Red: Low battery power
Keeps lid open and sensor o.
Located on the back side of the lid.
Located underneath the lid (holds
three “D” batteries not included)
Trash and recycling magnet labels
Battery
compartment
Bottom of lid
Lid
Liner rings
Base
