FEATURES
Check out these important
safety instructions to keep
yourself and your devices
safe.
• Before using the converter/adapter, check the product you intend
to connect to the converter/adapter for the manufacturer’s
voltage and wattage rating, which should be located on the
product.
Caution: Adapter mode does not convert voltage. To avoid
damaging your device, select the Converter mode when
appropriate.
•
The converter cannot be used with low-wattage appliances
(0–25W).
• Converter mode is designed to be used only for short periods of
time (approximately 10 minutes).
• Do not leave the converter/adapter in the power outlet when not
in use. Do not continue to use the converter/adapter if it is not
working properly, has been damaged, or has been dropped in
water.
•
Check your appliance label to see if it requires less than 2.5 A.
• No grounding. This product is for use with unearthed or
double-insulated appliances only.
• The adapter-only function should be used with dual-voltage
appliances. The converter combo should be used with
single-voltage appliances.
Warning: This product is intended for adult use. This product is NOT
intended for use by unsupervised children. Choose proper settings
and plug in this product before directly supervising children using
devices connected to this product.
Do not use the converter for electronic controlled appliances.
V1 ENGLISH 19-0300
MAKING SURE YOUR DEVICE IS
COMPATIBLE
Warning: Failure to select the correct voltage setting could damage
your device.
1 Determine the voltage of the power outlet you want to use.
See Step 4 for common voltages.
2 Check the voltage of the device you want to connect to the
power outlet.
3 Compare the power outlet voltage to your device’s voltage,
then use the table to the right to decide which mode to use
(adapter or converter).
Note: The voltage of some devices will be a range. If your power
outlet voltage is in the range of your device’s voltage (for example, a
120-240V device and a 240V power outlet), use ADAPTER mode.
4 Check the wattage of your device.
If you use ADAPTER mode:
If you use CONVERTER mode:
SELECTING YOUR PLUG
Find the power outlet you want to plug your device into. The
outlets are shown next to the plugs.
1 Locate the button for the country you are in.
2 Make sure that each plug is pushed in completely before you
push out a dierent plug.
Note: Your All-In-One Travel Converter has a lock and release
feature that prevents you from selecting more than one plug at
a time. Do not try to disable this feature.
3 Gently press the button, and then completely push out the
plug.
USA/CHINA button
North America (USA, Canada, & China)
Flat parallel, 120V
THE POWER OUTLET
VOLTAGE IS:
• The same as your device’s
voltage
• In the range of your device’s
voltage
• 100V and your device is 120V
• In a country with 110–120V AC
• Greater than your device’s
voltage
• In a country with 220–240V AC
• Less than your device’s voltage
SLIDE THE MODE
SWITCH TO:
ADAPTER
CONVERTER
Your device is not compatible.
Do NOT use this
converter/adapter with your
device
Notes:
• Use Adapter mode for dual-voltage devices (those listed as
110V/220V AC, 120V/240V AC).
• Use Adapter mode for devices such as laptop computers and
battery chargers because they automatically adjust to 110V or
220V power.
• If the power outlet is 100V and your device is 120V, you may use
the adapter.
DEVICE WATTAGE IS:
275W max. at 100
–120V
575W max. at 220
–240V
576W or more
INSTRUCTIONS:
You can use this adapter.
See “Selecting your plug”
for further instructions.
Your device is not
compatible. Do NOT use this
adapter with your device.
DEVICE WATTAGE IS:
0
–25W
26
–1875W
INSTRUCTIONS:
Your device is not
compatible. Do NOT use this
converter with your device.
You can use this converter.
See “Selecting your plug”
for further instructions.
BE
CAREFUL!
USB charging ports
USING YOUR
CONVERTER/ADAPTER
1 Mark sure that your device is compatible and that you have
selected the correct plug
2 Slide the Adapter/Converter switch to select the correct
mode (Adapter or Converter).
3 Connect your device to the converter/adapter outlet, then
plug the converter/adapter into a power outlet.
Note: When in converter mode, only use this product for short periods
of time (approximately 10 minutes).
AUST button
Australia
Flat angled, 240V
EUROPE button
European Union
Round thin, 240V
U.K. button
United Kingdom
3-prong, 240V
Adapter mode
ConverterAdapter
USA/CHINA button
EUROPE button
USB charging ports
U.K. button
AUST button
Adapter/Converter switch
TROUBLESHOOTING
My converter/adapter or device is humming
• It is normal to hear a humming sound from your converter/adapter
or device.
My device stopped working
• If your device has a built-in thermostat, it may have shut o
prematurely.
• Make sure that you have selected the correct settings.
• Wait for your device to cool down, then resume normal operation.
My device is working slowly
• Some devices may operate slower in foreign countries that use
50Hz of current (the U.S. operates on 60Hz).
I don’t know my device’s voltage or wattage
• Check on your device, its power adapter, or in its manual.
• To calculate wattage, multiple voltage by amps (for example,
100V × 2.5 A = 250W).
• Contact the device’s manufacturer.
SPECIFICATIONS
• Adapter mode: 100–240VAC, 2.5 A Max. 50/60Hz
• Converter mode:
• Input: 220–240VAC, 50Hz
• Output: 110–120VAC, 2000W Max. 50Hz
USB charging ports: +5VDC, 2.4 A total
Pull out the
insulated
ground pin from
the housing.
Converter mode
LEGAL NOTICES
FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Warning: Changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment. This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if it is not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
ICES-003 Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet apparel numérique de la classe B est conforme à la norme NMB-003 du
Canada.
Warning: Changes or modications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local
Authority for recycling advice.
ONE-YEAR LIMITED
WARRANTY
For complete warranty,
visit www.insigniaproducts.com.
CONTACT INSIGNIA
1-877-467-4289 (U.S. and Canada)
or 01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy
and its aliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2019 Best Buy. All rights reserved.
Made in China
T12A
Before using your new product, please read
these instructions to prevent any damage.
QUICK SETUP GUIDE
All-in-One
Travel
Converter
NS-MUTC2U / NS-MUTC2U-C
PACKAGE CONTENTS
• All-in-One Travel Converter
• Quick Setup Guide
