USER GUIDE
Dual Beer
Kegerator/Beverage Cooler
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
2
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Grounding requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Kegerator parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Locating your kegerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Before using your kegerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Providing a proper power supply . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Assembling your kegerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Installing the casters (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Attaching the guard rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Installing the draft arm assembly . . . . . . . . . . . . . . . . . . . . . . . . . .11
Installing the CO2 regulator and tank . . . . . . . . . . . . . . . . . . . . . .12
Attaching the CO2 tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Installing and setting up a beer keg . . . . . . . . . . . . . . . . . . . . . . . .14
Using your kegerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Setting the temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Dispensing Beer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Maintaining your kegerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Automatic defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Replacing kegs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Replacing the CO2 tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Storing your kegerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Moving your kegerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Converting your beer dispenser to a beverage refrigerator . . . . . . .21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Beer quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
ONE-YEAR LIMITED WARRANTY - INSIGNIA . . . . . . . . . . . . . . . . . . . . . .25
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-BK2TBS8/NS-BK2TBK8 represents the state of the art in kegerator
design and is designed for reliable and trouble-free performance.
3
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
Important Safety Instructions
WARNING
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this appliance near water.
6 Clean only with damp cloth.
7 Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from
the appliance.
11 Do not attempt to modify or extend the power cord of this appliance.
12 Unplug this appliance during lightning storms or when it will not be
used for long periods of time.
13 Make sure that the available AC power matches the voltage
requirements of this appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within your kegerator/beverage cooler.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying your
kegerator/beverage cooler.
4
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
14 Do not handle the plug with wet hands. This could result in an electric
shock.
15 Unplug the power cord by holding the plug, never by pulling the cord.
16 Do not turn the appliance on or off by plugging or unplugging the
power cord.
17 Refer all servicing to qualified service personnel. Servicing is required
when the appliance has been damaged in any way, such as the
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the appliance, the appliance has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
18 To reduce the risk of fire or electric shock, do not expose this appliance
to rain, moisture, dripping, or splashing, and no objects filled with
liquids should be placed on top of it.
19 Do not use extension cords or ungrounded (two prong) adapters.
20 20 This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person
responsible for their safety.
21 Children should be supervised to ensure that they do not play with
the appliance.
22 If the SUPPLY CORD is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person in order to
avoid a hazard.
23 Take off the doors. Leave the shelves in place so that children may not
easily climb inside.
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in
electric shock, fire, or death.
1 WARNING–Keep ventilation openings in the
kegerator/beverage cooler clear of obstruction.
2 WARNING–Do not damage the refrigerant
tubing when handling, moving, or using the
kegerator/beverage cooler.
3 WARNING–Do not use electrical appliances inside the storage
compartment of the kegerator/beverage cooler, unless they are of the
type recommended by the manufacturer.
5
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
4 WARNING–DANGER—Never allow children to play with, operate, or
crawl inside the kegerator/beverage cooler.
Risk of child entrapment. Before you throw away your old
kegerator/beverage cooler:
1) Take off the doors
2) Leave the shelves in place so that children may not easily climb
inside
5 Unplug the kegerator/beverage cooler before performing user
maintenance on it.
6 This kegerator/beverage cooler can be used by children age 8 years
and older and persons with reduced physical or mental capabilities or
lack of experience and knowledge if they are given supervision or
instruction concerning the use of the kegerator/beverage cooler in a
safe way and understand the hazards involved. Children should not
play with the kegerator/beverage cooler. Cleaning and maintenance
should not be performed by children without supervision.
7 If a component part is damaged, it must be replaced by the
manufacturer, its service agent, or similar qualified persons in order to
avoid a hazard.
8 Follow local regulations regarding disposal of the kegerator/beverage
cooler due to flammable refrigerant and gas. All refrigeration products
contain refrigerants, which under the guidelines of federal law must
be removed before disposal. It is the consumer's responsibility to
comply with federal and local regulations when disposing of this
product.
9 This kegerator/beverage cooler is intended to be used in household
and similar environments.
10 Do not store or use gasoline or any flammable liquids inside or in the
vicinity of this kegerator/beverage cooler.
11 Do not use an extension cord with this kegerator/beverage cooler. If
the power cord is too short, have a qualified electrician install an outlet
near the kegerator/beverage cooler. Use of an extension cord can
negatively affect the kegerator/beverage cooler’s performance.
Grounding requirement
This kegerator/beverage cooler must be grounded. This
kegerator/beverage cooler is equipped with a cord having a grounding
wire with a grounding plug. The plug must be inserted into an outlet that
is properly installed and grounded.
Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or service person if the grounding
instructions are not completely understood, or if doubt exists as to
whether the kegerator/beverage cooler is properly grounded.
6
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Features
• Taps serve up to two beverages
• 5.7 cu. ft. holds a variety of keg sizes
• Converts between refrigerator and beverage cooler
• Black door looks stylish with any decor
• Electric control for ideal temperature
• Two wire shelves for additional storage
• Locking wheels provide mobility and stability
Package contents
Cabinet parts
CO
2
parts
Metal washers (2)
for locking caster
wheels
Drip tray (2 pieces)
Locking casters (2)
Casters (2)
Wire shelf
Guard rail
Wire half-shelf
CO
2
regulator
5 lb. CO
2
tank (shipped empty)
Notes:
• See your local beer keg provider,
air/gas or welding supplier, or
sporting goods store to fill your
CO
2
tank.
•The CO
2
tank must be empty to
return your kegerator.
CO
2
gas line and Sankey
keg couplers (D-type)
Hose clamp
Bolt and nut for
tank retainer
CO
2
tank retainer
(comes installed)
CO
2
back tank retainer (for
optional tank mount on
the back.)
7
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
Keg parts
You’ll need
• Adjustable wrench
• Phillips screwdriver
• Pair of pliers/clamp crimper
• Full keg(s) of beer (See “Installing and setting up a beer keg“ on page 14
for compatibility information.)
• Fill the included CO
2
tank with CO
2
(See your local beer keg provider,
air/gas or welding supplier, or sporting goods store to fill your CO
2
tank.)
Inside dimensions
Draft arm assembly
Beer gasket with
screws (4)
Beer tap handle
(2)
Extra valve washers
(2 each)
Metal wrench
(for cleaning)
21.2 in. (539 mm)
28.4 in. (722 mm)
16.5 in. (420 mm)
8
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Kegerator parts
Beer tap handles
Draft arm assembly
Drip tray (2 pieces)
Worktop
Guard rail
Bolt and nut for retainer
CO
2
tank retainer
CO
2
gas line
Beer keg(s) (not included)
Metal washers for locking
casters (2)
Locking casters (2)
CO
2
tank regulator
Sankey keg coupler
5 lb. CO
2
tank
Control panel
Adjust
temperature
Display
Change
temperature unit
Quick cool
9
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
Locating your kegerator
Before using your kegerator
• Let the kegerator stand upright for approximately eight hours before
connecting it to power. This reduces the possibility of a malfunction in
the cooling system from improper handling during transportation.
• Check to make sure that all accessories listed/shown are included with
your kegerator. If any accessories or parts are missing or not in good
condition, contact customer service for assistance.
• Clean the interior surface with lukewarm water using a soft cloth.
Finding a suitable location
• This kegerator is designed to be free standing only, and should not be
recessed or built-in.
• Place your kegerator on a floor that is strong enough to support the
kegerator when it is fully loaded.
• Allow three inches of space between the back and sides of the
kegerator and any surrounding walls. This allows for proper air
ventilation. If you install the casters, lock them. If not, adjust the
leveling feet to keep the kegerator level.
• Locate the kegerator away from direct sunlight and sources of heat
(stove, heater, radiator, and so on). Direct sunlight may affect the
acrylic coating and heat sources may increase electrical consumption.
Ambient temperature below 50°F (10°C) or above 85°F (29.4°C) will
hinder the performance of this kegerator. This kegerator is not
designed for use in a garage or any other outside installation.
• Avoid locating the kegerator in moist areas.
Providing a proper power supply
Check your local power source. This kegerator requires a 110V-120V, 60 Hz
power supply.
Use a receptacle that accepts the grounding prong. The power cord is
equipped with a 3-prong (grounding) plug that mates with a standard
3-prong (grounding) wall outlet to minimize the possibility of electric
shock hazard from this kegerator.
3-prong receptacle
Receptacle box cover
3-prong plug
Grounding lead
Grounding adapter Receptacle box cover
Screw
Receptacle
Using a 3-prong plug and outlet Using a grounding adapter
10
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Assembling your kegerator
Installing the casters (optional)
1 Remove all contents from the kegerator, then tip it onto its side on a
soft surface to protect it from scratches.
2 Unscrew and remove the black front feet. Keep them in a safe place in
case you want to use the feet later.
3 Attach the two metal washers (included) to the locking casters to
prevent scratching the cabinet, then install the two locking casters in
the front positions on the bottom of the kegerator (closest to the
door).
4 Install the other two casters in the rear positions on the bottom of the
kegerator.
5 With all four casters tightened evenly, stand the unit in the upright
position.
6 Step on the front of the locking casters to lock the kegerator into place
or step on the back to unlock the kegerator.
Notes
• The kegerator should always be plugged into its own
individual electrical outlet which has a voltage rating that
matches the rating plate.
• We strongly recommend that you do not use an extension
cord. However, if you must use an extension cord, it is
absolutely essential that it be a UL/CUL-Listed, 3-wire
grounding type appliance extension cord having a
grounding type plug and outlet and that the electrical
rating of the cord be 115 volts and at least 10 amperes.
• Never unplug your kegerator by pulling on the power cord.
Always grip the plug firmly and pull straight out from the
outlet.
Casters
Front
Metal washers
Locking casters
11
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
Attaching the guard rail
• Insert the guard rail into the holes on the top of the kegerator.
Installing the draft arm assembly
1 Remove the cabinet plug from the top of the kegerator.
2 Align the beer gasket with the holes on the top of the cabinet.
3 Pass both the wing nut and the beer tube (both are attached to the
draft arm assembly) through the hole on the worktop until the draft
arm assembly is resting on the top of the cabinet.
4 Align the holes in the draft arm with the holes in the gasket, then
attach the draft arm to the worktop with the four screws provided.
5 Attach the black plastic beer tap handles to the top of the faucets,
tightening by hand. Hold the silver ring snug so it does not move.
Note
If there is a small drip after you pour a beverage, you may have
tightened the beer tap handle too much. If so, unscrew the silver
snug ring one turn, then retighten the beer tap handle.
Beer tap handle
Draft arm assembly
Wing nut and beer tube
Beer gasket screws
Beer gasket
12
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Installing the CO
2
regulator and tank
Before installing the CO
2
regulator and tank, it’s very important that you
review this list of safety tips.
1 Feed the hose clamp over one end of the CO
2
gas line.
2 Attach that end to the gas line connector on the CO
2
regulator.
3 Tighten the clamp to prevent leaks. Leave about ½ inch between the
top of the clamp and the end of the hose. You may need to squeeze
with a pliers or crimper.
WARNING
Before installing the CO
2
regulator and tank, it’s very important that you review this list
of safety tips:
• ALWAYS connect the CO
2
tank to a regulator. Failure to do so could result in explosion
with possible death or injury when the tank valve is opened.
• NEVER connect the CO
2
tank directly to the beer keg.
• ALWAYS follow correct procedures when tanks are changed.
• ALWAYS secure the tank in an upright position.
• NEVER drop or throw a CO
2
tank.
• ALWAYS keep a CO
2
tank away from heat. Store extra tanks in a cool place (preferably
70°F). Securely fasten with a chain in an upright position when storing.
• ALWAYS ventilate and leave the area immediately if CO
2
leakage has occurred.
• ALWAYS check the D.O.T. test date on the tank neck before installation. If the tank if
over five (5) years old, do not use it. Return the tank to the gas supplier.
• NEVER connect a product container unless there are two (2) safeties in the pressure
system:
•The CO
2
regulator is unpressurized.
• The product coupler and gas line are unpressurized.
Sankey keg couplers
CO
2
tank regulator
Shut-off valve
Hose clamp
CO
2
gas line
13
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
4 Attach the CO
2
regulator to the CO
2
tank by screwing the regulator nut
onto the tank valve and tightening with an adjustable wrench.
Attaching the CO
2
tank
You can install the CO
2
tank inside the kegerator for a cleaner look
(Option A) or on the back if you need more space inside your kegerator
(Option B).
Option A : Inside the kegerator
Slide the tank through the retainer and secure it with the provided bolt
and nut. Position the tank so you can read the gauge and have easy access
to the shut-off valve.
Option B: On the back of your kegerator
1 Align the four holes on the CO
2
tank retainer with the four screws on
the back of the kegerator.
2 Place the CO
2
tank in the retainer.
3 Feed the gas line hose through the hole in the back of the unit and
connect to the regulator as you did in “Installing the CO2 regulator
and tank“ on page 12.
Tank valve
Regulator
nut
14
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Installing and setting up a beer keg
This kegerator accepts almost all brand name kegs. Here’s what will fit in
your kegerator:
*You can have a 1/4 (slim) and a 1/6, or a 1/4 (slim) and an 1/8 in your
kegerator at the same time.
Installing the keg coupler
1 Insert the sankey keg coupler into the neck of the beer keg and turn it
clockwise to lock it into position. Make sure that the washer is in the
connector on the top of the sankey keg coupler.
2 Insert the beer tube into the top of the sankey keg coupler, then
tighten the wing nut.
3 Repeat steps 1-2 if you have a second keg.
BARREL
SIZE
GALLONS
12 oz
GLASSES
(short, pony)
(slim)
HOW MANY
WILL FIT
Sankey keg coupler
Beer tube
Wing nut
Sankey keg coupler
15
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
4 Pull the black handle on the sankey keg coupler and press it
downward until it locks into position. The keg is now tapped.
5 Insert the keg(s) into the kegerator.
Adjusting the CO
2
regulator
1 Make sure that the shut-off valve is closed (sideways if closed, down if
open), then slowly turn the main valve on the CO
2
tank
counter-clockwise until it is fully open.
2 Open the shut-off valve to allow gas to flow into the keg.
3 Release the adjustment lock nut, behind the regulator screw, by
turning it clockwise about 5-7 turns.
Note
If beer comes up through the top of the wing nut, remove the
wing nut, reposition the washer, then reattach the wingnut.
Sankey keg coupler
Shut-off valve
Closed
Open
16
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
4 Turn the regulator screw clockwise to increase pressure. The needle on
the gauge starts to climb. Set the gauge to 10-12 PSI.
5 When the tank is at the correct pressure, tighten the adjustment lock
nut by turning it counter-clockwise.
6 Allow several minutes for the keg to pressurize. The gauge may show a
drop in pressure while this happens. Adjust as needed.
7 Plug the kegerator into a 120V, 60Hz, 15A grounded outlet.
Using your kegerator
Setting the temperature
1 Press the °F/°C button to switch between Fahrenheit or Celsius.
2 Press - to adjust the temperature to 32°F (0°C), then let the kegerator
cool for 48 hours.
Note
Listen for a hissing sound at all connections to determine if there
are any leaks.
Note
Press Quick Cool to cool the kegerator to its lowest setting.
The icon appears and the kegerator cools for 24 hours. Press -
or + to exit quick cool mode early.
Adjustment lock nut
Regulator screw
17
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
3 After the kegerator is fully cooled, press - or + to adjust to the
temperature you want. The kegerator may take a few hours to stabilize
after adjusting the temperature.
Dispensing Beer
Proper foam should leave a tight, creamy head, and the head on the
average glass should be 3/4” to 1” high.
1 Hold the glass at a 45° angle.
2 Grasp the handle at the bottom and open the tap quickly.
3 Once your glass is half-full, gradually bring the glass upright, and aim
for the middle to start forming the head. Slowly lower the glass as you
approach your finish to improve the head even more.
4 When your glass is full, close the tap quickly.
Notes
• To change the thermostat setting, adjust it by one
increment at a time. Allow several hours for the
temperature to stabilize between adjustments.
• The kegerator’s temperature range 32°-50°F (0°-10°C). See
“Using different glasses for different beers“ on page 18 for
information about the best temperature for your beer type.
• If the kegerator is unplugged or loses power, wait three to
five minutes before restarting it. If you attempt to restart
before this time delay, the kegerator will not start.
18
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Preventing bad beer
Using different glasses for different beers
You wouldn’t believe how much a proper glass and temperature will
change the taste of your beer.
Problem Possible Causes Solution
Too much head Improper regulator setting Make sure that the (CO
2
) pressure is between 10
and 12 PSI.
Pressure build up Activate the pressure relief valve located on the
sankey keg coupler for three seconds.
Warm beer Make sure the temperature is between 34
°F and
38°F.
Improper pour Open the tap quickly and completely.
Flat beer. No head. Greasy glasses Wash glasses thouroughly, then air dry. Rinse in
fresh cold water just before serving.
Improper pour Open the tap quickly and completely.
Not enough pressure Increase the pressure or refill the CO
2
tank if
empty.
Abnormal beer taste
and/or smell.
System requires cleaning See “Maintaining your kegerator“ on page 19.
Old beer. Buy a new keg.
Lagers
(35-40°F)
Stouts
(50°F)
Ales
(45-50°F)
Craft Beers
(38-41°F)
Often labeled simply as
"beer." Examples include
Budweiser, Stella Artois,
Beck's, Corona, Heineken, and
Foster's.
Dark beers made using
roasted malt or barley.
Examples include porters and
Guinness.
Includes brown ales (such as
Newcastle), golden ales, pale
ales (IPA), mild ale, and
barley wines.
Includes craft, micro, and
nano brewery beers, often
only available regionally or
locally.
19
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
Maintaining your kegerator
Your kegerator is designed for year-round use with only minimal cleaning
and maintenance.
When you first receive it, wipe the case with a mild detergent and warm
water, then wipe dry with a dry cloth. Do this periodically to keep your
kegerator looking new.
Cleaning the interior of your kegerator:
1 Unplug your kegerator from the wall outlet to turn it off.
2 Remove all kegs and all beverages.
3 Wash the inside with a damp warm cloth soaked in a solution of one
quart of lukewarm water to two tablespoons of baking soda solution.
4 Wash the shelves and metal plate with a mild detergent solution.
5 Wring excess water out of the sponge or cloth when cleaning around
the controls or any electrical parts.
6 Wash the outside cabinet with warm water and mild liquid detergent.
Rinse well and wipe dry with a clean soft cloth.
7 Be sure to keep the door gasket (seal) clean to keep the unit running
efficiently.
8 Dry the interior and exterior with a soft cloth.
Cleaning the beer components
To prevent a build-up of yeast and mold in the beer lines, and to prevent a
bad taste, clean your beer components when you replace a keg.
1 Remove the keg coupler and thoroughly rinse it in warm water.
2 Use the included wrench to remove the faucet on the draft arm
assembly. Insert the tip of the wrench into one of the holes on the
faucet, rotate it, then thoroughly rinse the faucet in warm water.
3 Clean the beer lines using either a hand pump cleaning kit or a
cleaning can (both sold separately).
Automatic defrosting
There is no need to defrost your kegerator. The defrost water collects at
the back of your cooler and passes through a drain outlet into a tray
located above the compressor where it evaporates.
Caution
To prevent damage to the finish, do not use:
• Gasoline, benzine, thinner, or other similar solvents.
• Abrasive cleaners.
20
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Replacing kegs
1 Unplug your kegerator from the wall outlet to turn it off.
2 Close the main valve on the CO
2
tank.
3 Close the shut-off valve on the CO
2
regulator.
4 Pull the black handle on the keg coupler and press it upward to close
the connection between the beer keg and the keg coupler.
5 Pull on the tap handle(s) to help drain beer from the lines.
6 Disconnect the beer line and CO
2
gas line from the keg coupler.
7 Put the beer line in a bucket to drain the remaining beer from the line.
8 Remove the beer keg(s).
9 Remove the keg coupler(s) from the keg(s).
10 Follow the steps in "Installing the keg coupler" on page 14 to insert a
new keg.
Replacing the CO
2
tank
1 Unplug your kegerator from the wall outlet to turn it off.
2 Close the main valve on the CO
2
tank.
3 Close the shut-off valve on the CO
2
regulator.
4 Disconnect the CO
2
gas line from the keg coupler.
5 Remove the CO
2
tank.
6 Follow the steps in "Installing the CO2 regulator and tank" on page 12
to insert a new tank.
Storing your kegerator
If you will be away from your kegerator for more than three weeks:
1 Unplug your kegerator from the wall outlet to turn it off.
2 Remove all kegs and all beverages.
3 Clean and dry the interior of the kegerator.
4 Leave the door open slightly to avoid possible formation of
condensation, mold, or odor.
Caution
Use extreme caution with children. The unit should not be
accessible to child's play.
21
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
Moving your kegerator
1 Unplug your kegerator from the wall outlet to turn it off.
2 Remove all kegs and beverages.
3 Securely tape down all loose items inside your kegerator.
4 Tape the door shut.
Be sure the kegerator stays in the upright position during
transportation and protect the exterior with a blanket or similar
padding.
Converting your beer dispenser to a
beverage refrigerator
1 Follow the steps in "Replacing kegs" on page 20 and "Replacing the
CO2 tank" on page 20.
2 Remove the draft arm assembly and pull the beer line thru the top of
the cabinet.
3 Replace the top cabinet plug.
4 Remove the guard rail and cover the guard rail installation holes with
the plugs provided.
5 Install the two wire shelves.
6 Adjust the temperature as desired.
22
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Troubleshooting
Beer quality
Problem Possible cause Possible solution
Excess formation of
foam “head.” Beer is all
foam, or too much foam
and not enough liquid
beer.
Recent keg agitation. If the keg has recently been moved, let it stand a minimum of
two hours before tapping.
Improper regulator setting. Verify that the (CO
2
) pressure is reading between 10 and 12 PSI.
The internal temperature of
the kegerator is too warm.
Make sure that the kegerator is cooling between the high 30s to
mid 40s. If the beer keg has been exposed to a warm
environment for an extended period, give it sufficient time to
cool before attempting to draw beer.
Pressure build up. Activate the pressure relief valve located on the keg coupler for
three seconds.
Flat beer - no formation
of foam. The foamy
head disappears quickly
and the beer lacks its
usual zestful brewery
fresh flavor.
Improper draw technique. See “Dispensing Beer” on page 17.
Improper regulator setting. Make sure that the (CO
2
) pressure is reading between
10 and 12 PSI.
Glassware is not clean enough. Residue on glassware in the form of oils quickly dissolves the
formation of foam. Make sure that the glassware is clean.
Dispensing hose too long. All recommended temperatures and gauge settings are
calculated for a five foot hose. Use a shorter hose.
No beer flow from the
beer faucet.
Low/Empty CO
2
tank. Make sure that the CO
2
tank has pressure.
Closed CO
2
valve and/or
shutoff valve.
Make sure that both the CO
2
tank and regulator shutoff valve
are open.
Empty beer keg. Replace beer keg.
Line or dispenser obstructions. Verify that there are no kinks or obstructions in either the air
line or the dispenser line and that neither are frozen.
Improper connection(s). Make sure that all connections are secure and all seals are in
place and in good condition.
Sputtering draw. System requires cleaning. See “Maintaining your kegerator” on page 19.
Keg tap installed incorrectly. Check the seal between the keg and the faucet.
Obstructions in the line or
dispenser.
Verify that there are no obstructions in either the air line or
dispenser line and that neither are frozen.
Improper draw technique. See “Dispensing Beer” on page 17.
Faucet dripping. Handle not fully returned to
close position.
After every pour, make sure that the handle is returned to the
off position.
Faucet requires cleaning. See “Maintaining your kegerator” on page 19.
Rapid CO
2
tank
discharge.
Improper connection causing
an air line leak.
Make sure that all lines are properly connected and/or check air
line for possible leaks.
Difficulty manipulating
faucet handle.
Faucet requires cleaning. See “Maintaining your kegerator” on page 19.
Damaged faucet handle. Remove the faucet handle and connector nuts and inspect for
possible damage.
23
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
Cooler
You can solve many common beer dispenser problems easily, saving
yourself the cost of a possible service call. Try the suggestions below to
see if you can solve the problem before calling the service center.
Abnormal beer taste
and/or smell.
System requires cleaning. See “Maintaining your kegerator” on page 19.
System contamination. Check hoses for possible air leaks.
The beer has exceeded its shelf
life.
Replace the beer keg with a fresh one.
Caution
Do not try to repair your kegerator yourself. Doing so invalidates
the warranty.
Problem Possible cause Possible solution
The kegerator does not
operate.
The kegerator is unplugged. Make sure that the kegerator is plugged in and that the plug is
pushed completely into the outlet.
The fuse on the circuit is blown
or the circuit breaker is
tripped.
Check the house fuse/circuit breaker box and replace the fuse or
reset the circuit breaker.
Power failure. If a power failure occurs, the kegerator turns off. Wait until the
power is restored, then turn it on again.
The cooler door does
not close completely.
The door was not properly
installed.
Make sure that the door was properly installed.
The shelf is out of position. Adjust the shelf properly.
The door gaskets are dirty. Clean the door gaskets.
The cooler is not level. Level the cooler with the leveling feet.
The cooler is not cold
enough.
The door has been opened too
often or was not closed
properly.
Make sure that the door is closed properly.
You have just added a large
amount of warm beverage to
the cooler.
Allow time for the new beverage to cool, then check again.
The temperature control is set
too warm.
Set the control to a colder setting.
Problem Possible cause Possible solution
24
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
Specifications
The cooler turns on and
off frequently.
The room temperature is
hotter than normal.
Make sure that the door was properly installed.
The door has been opened too
often or was not closed
properly.
Make sure that the door is closed properly.
The door gaskets do not seal
properly.
Clean the door gaskets.
The temperature control is set
too warm.
Set the control to a colder setting.
The kegerator makes
unusual noises or
vibrates.
The kegerator may not be level
on the floor.
Level the kegerator with the leveling feet.
The body of the kegerator is
touching a wall.
Move the kegerator out from the wall.
• A rattling noise may be
heard. This is caused by the
flow of refrigerent in the
kegerator.
• As each cooling cycle ends,
you may hear gurgling
sounds.
• Contraction and expansion
of the inside walls may
cause popping or crackling
noises.
This is normal.
Moisture is building up
in the interior of the
cooler.
The door has been opened too
often or was not closed
properly.
Make sure that the door is closed properly.
The cooler is in a location that
is very humid.
Move the cooler to a dryer location.
The bottles in the cooler are
not packaged properly.
Rearrange the bottles in the cooler to make sure that they are
sealed.
Dimensions (HxWxD) 33.7 x 23.6 x 23.6 in. (85.5 x 60.0 x 60.0 cm)
Weight 102.5 lbs. (46.5 kg)
Power requirements 115V~60Hz
Current 0.86 A
Power consumption (annual) 310 kwh
Problem Possible cause Possible solution
25
Dual Beer Kegerator/Beverage Cooler
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY - INSIGNIA
Definitions:
The Distributor* of Insignia branded products warrants to you, the original purchaser of this new
Insignia-branded product (“Product”), that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of one (1) year from the date of your purchase
of the Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the United States or Canada from a Best
Buy branded retail store or online at www.bestbuy.com or www.bestbuy.ca, and is packaged with this
warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product. Your purchase
date is printed on the receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of the Product is
determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its
sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with
new or rebuilt comparable products or parts. Products and parts replaced under this warranty become
the property of Insignia and are not returned to you. If service of Products or parts are required after the
Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own
your Insignia Product during the Warranty Period. Warranty coverage terminates if you sell or otherwise
transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location, please take your original receipt and the
Product to any Best Buy store. Make sure that you place the Product in its original packaging or packaging
that provides the same amount of protection as the original packaging. If you purchased the Product
from a Best Buy online web site (www.bestbuy.com or www.bestbuy.ca), mail your original receipt and the
Product to the address listed on the web site. Make sure that you put the Product in its original packaging
or packaging that provides the same amount of protection as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY, Canada call 1-866-BESTBUY. Call
agents may diagnose and correct the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy branded retail stores or websites to
the original purchaser of the product in the county where the original purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Food loss/spoilage due to failure of refrigerator or freezer
• Customer instruction/education
•Installation
•Set up adjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God, such as power surges
• Accidental damage
•Misuse
•Abuse
•Negligence
26
NS-BK2TBS8/NS-BK2TBK8
www.insigniaproducts.com
• Commercial purposes/use, including but not limited to use in a place of business or in communal
areas of a multiple dwelling condominium or apartment complex, or otherwise used in a place of
other than a private home.
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
• Products where the factory applied serial number has been altered or removed
• Loss or Theft of this product or any part of the product
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly illuminated)
grouped in an area smaller than one tenth (1/10) of the display size or up to five (5) pixel failures
throughout the display. (Pixel based displays may contain a limited number of pixels that may not
function normally.)
• Failures or Damage caused by any contact including but not limited to liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY FOR BREACH
OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT
LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA
PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND
IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES
OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR
IMPLIED, WILL APPLY AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
©2017 Best Buy. All rights reserved.
Made in China
www.insigniaproducts.com
1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico)
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2017 Best Buy. All rights reserved.
Made in China.
V1 ENG
16-1100
