Model as shown
KICS36-BK
Tablet / phone guided cooking
Energy efcency burner
Smart Pan temperature sensing
• Precision temperature control delivers consistent cooking results.
• Powerful energy efcient induction burner only heats up surface area under
your pan and is safely cool to the touch.
• Slide touch controls offer smooth, precise selection of power.
• Low simmer allows for gentle cooking for even the most delicate of sauces.
• Versatile bridge element (36” model) transforms conveniently to a larger
cooking surface.
• Bluetooth Connectivity with Hestan Cue Smart Cookware. (1 pan included)
• Controls Lock provides an additional safety feature.
• Overow detection.
• Independent timer for each individual cooking zone including an
egg timer.
• Automated cooking functions for simmer, keep warm and water bath.
• 5 Induction Cooking Zones.
• Longlife touch control technology (zero oxidation).
• Fully automatic cooling system.
• Startup Booster function allows for elements to heat up more quickly to
the desired heat setting - 2 Booster power levels for each cooking zone.
• Pot Detection system.
• Uniquely styled professional stainless steel frame.
• Available in black or metallic silver ceramic glass.
STANDARD FEATURES
SMART INDUCTION
COOKTOPS
SMART INDUCTION
COOKTOPS
www.hestanhome.com phone 888.905.7463
3375 E. La Palma Ave., Anaheim, CA 92806
SMART INDUCTION
COOKTOPS
www.hestanhome.com phone 888.905.7463
3375 E. La Palma Ave., Anaheim, CA 92806CONTACT US:
ELECTRICAL REQUIREMENTS
:
220-240V, 50/60Hz, 50 amps
Built - In
Models
Description
Approx
SHP WT (lbs)
A (in.) B (in.)
Other?
Cutout Dimensions
Circuit Breaker
Required
KICS36-__ 36” Smart Induction Cooktop 50 Amp19 -⁄34 -⁄
_= BK (black glass nish) _=MS (metallic silver nish)
74
Hestan Indoor products are approved for indoor
use only. Hestan Commercial Corporation reserves the
right to change materials and specications without notice.
min
VERTICAL CLEARANCES
* The ventilation opening is to extend the full length of the cooktop cutout.
25” [635 mm]
min
”
2 1/2”
[64mm]
2
”
[51 mm]
2 1/2”
[65 mm]
1 5/8”
[40 mm]
max
1/4”
[6 mm]
min
36”
[915 mm]
24” [610 mm]
15 3/4”
[400 mm]
5 ”
[127 mm]
min
*1/4”
[6 mm]
min
min
19 1/4 [489 mm]
1 1/2
4 3/4
[120 mm]
[38 mm]
min
”
”
4”
[101 mm]
min
Partitian
D
G
C
E
F
D E F G
18” [45.7 cm] min
Height from counter-
top to nearest cabinet
on either side of unit*
2 -7/8” [5 cm] min clearance
from cutout to side wall
on the left and right of
the unit
13” [33 cm] Depth
of unprotected
overhead cabinets
MODEL
KICS36
KICS36
MODEL
A B C
34-1/4” [87cm] 19-1/4” [48.9cm]
36”
[91.4 cm] min
WALL COVERING CABINETS,
AND COUNTERTOP MUST
WITHSTAND HEAT UP TO 200° F [93° C]
CUTOUT REQUIREMENTS
30” [76.2 cm] min.
[see note*] Clearance
from countertop to
unprotected
overhead surface
LENGTH OF CUT LENGTH OF CUT
36-1/2”
[929 mm]
22-1/2”
[573 mm]
5/32”
[4mm]
2 1/8”
[54.5 mm]
LENGTH OF CUT
A
LENGTH
OF
CUT B
2” [5.1 cm]
MIN CLEARANCE
3 1/8” [7.9 cm]
min depth
HOLE FOR
POWER CABLE
ENCLOSURE
BOTTOM
(OPTIONAL)
36” COOKTOP DIMENSIONS (including frame)
CUTOUT DIMENSIONS
