Installation and Operating Instructions
Infrared Heater Model : IRX60/120E
(IP24)
08/53912/0 Issue 1
IMPORTANT SAFETY ADVICE
Because the IRXE Heater contains no moving
parts, little maintenance is required. Before
undertaking any maintenance work on the
heater, due attention must be paid to the
following:
This heater is designed to be horizontally wall
mounted only, it must not be ceiling mounted.
Always ensure a safe mounting height, at or
above a minimum height of 1.8 metres from
ground level, so that the heater can not be
touched when in operation.
The heater must be wall mounted level ± 5º
to the horizontal.
This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience or knowledge
if they have been given supervision or
instruction concerning the use of the
appliance in a safe way and understand the
hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Children of less than 3 years should be kept
away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/o the appliance
provided that it has been placed or installed
in its intended normal operating position
and they have been given supervision
or instruction concerning the use of the
appliance in a safe way and understand the
hazards involved.
Children aged from 3 years and less than 8
years shall not plug in, regulate and clean the
appliance or perform user maintenance.
DO NOT locate the heater immediately above
or below a fixed socket outlet or connection
box.
Always disconnect the heater from the
electricity supply before attempting to work
on or near it.
Always ensure a safe means of access using
an access tower or properly supported ladder.
DO NOT cover the heater.
Keep combustible materials away from the
heater.
DO NOT look into the heater for prolonged
periods.
DO NOT use the heater if the elements are
broken - as injury may occur.
Allow adequate time (minimum of 30 mins.)
for the elements and body casing to cool
before attempting to work on the heater.
DO NOT allow the supply cord to sit or hang
in front of the heater while in use.
NOTE: Provide sucient slack to the cable
to allow for angular adjustment of the body.
The bulbs are extremely fragile and must be
handled with extreme care at all times. If the
bulb is accidentally touched by bare fingers
remove the fingerprint with a soft cloth
moistened with methylated spirits.
DO NOT use this heater in the immediate
surroundings of a bath, shower or a swimming
pool.
This device is not fitted with equipment for
regulating room temperature. The heater
must not be used in small rooms occupied by
people who cannot leave the room without
assistance unless continuous monitoring is
guaranteed.
Some parts of this product can become very
hot and cause burns. Particular attention has
to be given where children and vulnerable
people are present.
Connection only to fixed installed cables!
The hardwired electrical installation must
be provided with a disconnect device with a
contact grap of at least 3 mm at each pole
(e.g. automatic circuit breaker)!
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
